PD V8 User Manual HTML Version

User Manual

Installation Instructions P D - V 8

1) Provide 5V DC on pad 1 (4.75V-5.25V)

2) Provide DC ground onto PAD3

3) Connect PAD 2 (IF) to the µPC for signal processing

4) Operating temperature: -10-70°C

PAD1

PAD3

PAD2

The use of the transceiver is authorized into mobile or fixed devices taking into

account the conditions listed below :

• OEM Integrator may be sure that the end user manual may not contain any

information about the way to install or remove the module from the final

product.

Microwave Sensor

• Depends on final host configuration additional authorization requirements for

the non-transmitter functions on the transmitter module may be required (i.e.,

Verification, or Declaration of Conformity) OEM integrator is responsible for

ensuring that after the module is installed and operational into the host, it

continues to be compliant with the Part 15B unintentional radiator

requirements.

• The information on label and user manual is required to be incorporated in the

user manual of the final system. see 47 CFR15 requirements for more details

(e.g. 15.19 / 15.21 / 15.101 / 15.105 / RSS-GEN / ICES)

• Additional label with the words ‘Contains FCC ID:2AIWWPD-V8 and ‘Contains

IC:20845-STACK102’ shall be applied and visible from the outside of the end

product.

• The module must be installed and used in strict accordance with the

manufacturer’s instructions as described in the user documentation that

comes with the product.

• The antenna of the module may not be removed, replaced nor modified. The

antenna must not be co-located or operating in conjunction with any other

antenna or transmitter. No additional antenna must be used.

20X12mm

Microwave Sensor

IC:20845-STACK102

FCC ID:2AIWWPD-V8

MODEL:PD-V8

Microwave Sensor

IC:20845-STACK102

FCC ID:2AIWWPD-V8

MODEL:PD-V8

FCCCaution.



Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwo

conditions:

(1)Thisdevicemaynotcauseharmfulinterference,and

(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause

undesiredoperation.



AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliance

couldvoidtheuser'sauthoritytooperatetheequipment.



Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigital

device,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable

protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates

usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe

instructions,maycauseharmfulinterferencetoradiocommunications.However,thereisno

guaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoes

causeharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturning

theequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneor

moreofthefollowingmeasures:

‐Reorientorrelocatethereceivingantenna.

‐Increasetheseparationbetweentheequipmentandreceiver.

‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris

connected.

‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.


