![](/img.php?id=2962879&img=bg1.png)
XS-1000MKⅡ
INSTRUCTION MANUAL
![](/img.php?id=2962879&img=bg2.png)
![](/img.php?id=2962879&img=bg3.png)
1
2000 W
8
115/230V~60/50Hz.
![](/img.php?id=2962879&img=bg4.png)
18
19
22
21
POWER
ON
OFF
MP3 CONTROL DIGITAL DISPLAY
MIC
INPUT
AUX
R L
LINE
INPUT
LINE
OUTPUT
MP3 LEVEL
MIC LEVEL
BASS
-12 +12
POWER
LINE LEVEL
VOLUME
TREBLE
-12 +12
SPEA KE R OUT
8Ω
MIN MAX
MIN MAX
MIN MAX
MIN MAX
AC 115/230V 60/50Hz
USB
SD
SCAN
115V 23 0V
1. LCD screen
2. MP3 control
MODE:USB/SD/BT/FM convertor
:Play / Pause
SCAN:Long press to auto search under FM radio
:Repeat one / Repeat all / Random
:PRE/NEXT under FM mode
Long hold to search lower/
higher station manually
:Short press to tune to saved station
:Previous Song
Long press for fast rewind
:Next Song
Long press for fast forward
3.SD card input
4.USB input
5.MP3 input level control
6.Mic input level control
7.Line input level control
8.Master Volume control
9.Treble control for high frequencies
10.Bass control for low frequencies
11.XLR microphone input
12.6.35mm microphone input
13.3.5mm line input
14.RCA phone (R+L) line inputs
15.XLR line input
16. 6.35mm line output
17. Speaker out 8 Ohm
18.Clip LED indicator
19.Power LED indicator
20.115V/230V Switch
21.Main power switch
22.Fused IEC mains inlet
23.LED Light Switch(ON/OFF)
OFF ON
LED
23
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
