NCZ-3201 KEY FOB
User Guide
Product Summary:
Nyce Control’s NCZ-3201 is a wireless key fob using the ZigBee radio protocol. It is used in conjunction
with a low RF transmit power wireless ZigBee network for access control to other devices operating in a
ZigBee Home Automation network.
• Button functions: network commands, state change commands for other devices
• Accurate battery voltage level measurement and reporting back to co-ordinator
• Network operation based on the ZigBee open profile Home Automation
• Up to 4 years projected battery life
Troubleshooting:
To improve communication:
Operate the device closer to the router / director
Move a ZigBee router / range extender closer to the desired operating area
Replace battery
Technical Specifications:
Model Number: NCZ-3201
Battery Type: 3.0 V CR2032 Lithium coin cell
RF Frequency: ZigBee channels 11-26, 2.405 - 2.48 GHz
Operating Temperature: -10oC to 50oC (14oF to 122oF)
Dimensions: 32mm x 56mm x 6mm
Battery Replacement:
Remove back cover to expose battery
Replace with 3.0 volt CR2032 Lithium coin cell battery, noting the correct polarity of the battery
Button Functionality (Generic Commands):
Button
Function
Lock Button
Unlock Button
Star Button
1 Tap
ACE: Arm all zones
(Endpoint 1)
ACE: Disarm
(Endpoint 1)
ACE: Panic (Endpoint
1)
2 Taps
ACE: Arm all zones
(Endpoint 2)
ACE: Disarm
(Endpoint 2)
ACE: Panic (Endpoint
2)
3 Taps
ACE: Arm all zones
(Endpoint 3)
ACE: Disarm
(Endpoint 3)
ACE: Panic (Endpoint
3)
Press
ACE: Arm all zones
(Endpoint 4)
ACE: Disarm
(Endpoint 4)
ACE: Panic (Endpoint
4)
Release
ACE: Arm all zones
(Endpoint 5)
ACE: Disarm
(Endpoint 5)
ACE: Panic (Endpoint
5)
Button Functionality (Network Commands):
Action
Mode
Action
Press button 1 and button 2 together, then
button 1 once
Un-associated to any network
Network Join to Open Std network
Press button 1 and button 2 together, then
Button 1 four times
Un-associated to any network
Network Join to C4 Network
Press button 1 and button 2 together, then
Button 1 six times
Associated to the network
Leave network
Press button 1 and button 2 together, then
Button 1, 10 times
Associated to the network
Restore defaults, leave network
Press button 1 and button 2 together, then
Button 1, 10 times
Un-associated to any network
Restore defaults
Press button 1 and button 2 together, then
Button 1 two times
any
Indicate network connectivity
Press other than 1,2,4,6 10 times or other
button combination
any
Single orange LED flash –
unsupported command.
The next press of multiple presses must occur within 1 seconds of the end of the last button press.
Any button held down for more than 1 second will cause the keyfob to disregard the button press.
Press-hold functionality will not be supported – only multi-press.
LED Indicators:
LED Response
Definition
One green flash
Message acknowledged by
Coordinator, or button pressed
(command mode)
Two green flash
Network join succeeded, or status =
joined
One red flash
button pressed (network mode)
2 red flashes
Network leave or status = not joined
3 slow Red flashes, 1
second after other LED
signalling is complete
Low battery
One Orange flashes
Unsupported button command
Two Orange Flashes
Network Error
Five Green flash
Successfully reset to factory defaults
All flashes are 250ms in duration. Repeated flashes are each followed by a 250ms pause, unless
otherwise indicated. A “slow” flash is 250ms in duration followed by a 1sec pause.
MODEL #: NCZ-3201
FCC ID: Y8R-Z32011
IC ID: 9488A-Z32011
Compliance Statements:
For complete declarations and certifications please visit:
www.nycecontrol.com/compliance
Notices
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Note: the manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user’s authority to operate the
equipment.
Changes or modifications not expressly approved by NYCE Control, Inc can void the user’s authority to
operate the equipment.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is Subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Warranty:
For product warranty information please visit:
www.nycecontrol.com
Support:
For product support please email:
support@nycecontrol.com
