CONGRATULATIONS ON YOUR NEW NYMI BAND™!
We want to make sure you have the absolute best experience with your Nymi
Band! If you have any questions or comments, we are here for you. Email, phone,
or send us some old fashioned snail mail.
help@nymi.com 1-855-781-9655 Nymi Inc, 82 Peter Street
Toronto, ON, Canada, M5V 2G5
TO GET STARTED, GO TO:
In the Box
Adjusting your Nymi Band
Lengthen
Shorten
Using Windows PC with your Nymi Band
First-Time Use
Daily Activation of your Nymi Band
Authorizing Applications to your Nymi Band
Charging your Nymi Band
Check the Status of your Nymi Band
Taking Care of your Nymi Band
Troubleshooting
Resetting your Nymi Band
Legal Information
1
3
3
4
5
7
9
11
12
13
14
15
17
19
TABLE OF CONTENTS
12
IN THE BOX
Bottom Sensor
Core
Band
Contact Pins
Lights
Cover
Top Sensor Nymi Connector
USB End
Charging Cable
Reset Hole
34
CAUTION !
TIGHT ON YOUR WRIST?
You should adjust your Nymi
Band to t comfortably around
your wrist. It should not be
worn too loose or too tight.
1ADJUST TO LENGTHEN
Hold the Nymi Core in your hand
with the bottom sensor facing you.
Using your other hand, pull the band
to adjust to your desired length.
Stop pulling when the band locks up.
2
Pulling the band beyond
the point where it locks
up will result in damage
to the band.
!LOOSE ON YOUR WRIST?
You should adjust your Nymi
Band to t comfortably around
your wrist. It should not be
worn too loose or too tight.
1ADJUST TO SHORTEN
Hold the Nymi Core in your hand
with the bottom sensor facing you.
Using your thumb, push down and
feed the band through the Nymi
Core to your desired length.
2CAUTION
Do not cut your Nymi
Band due to electronics
within the band.
LENGTHEN YOUR NYMI BAND™ SHORTEN YOUR NYMI BAND™
56
!
HOW DO I USE IT?
Plug it into your computer’s USB
port and keep it there. Do not use
a USB hub as this may interfere with
the module’s functionality.
!HOW DO I GET MORE?
If you have more than one Windows
computer that you would like to use
with your Nymi, you can order more
modules at help@nymi.com.
!
For all other platforms,
enable Bluetooth on your
device to connect to your
Nymi Band.
USING WINDOWS PC WITH YOUR NYMI BAND
WHAT IS A NYMI-COMPATIBLE BLUETOOTH DONGLE?
The BLED112 Bluetooth® Smart Module is the buddy for your
Nymi Band™, if you have a Windows® computer. You need it in
order to use the Windows version of the Nymi Companion or
any Nymi-Enabled Applications.
WHY DO I NEED IT?
The Bluetooth module passes data between your computer and
your Nymi Band, because the default way that Windows handles
Bluetooth does not work well with the Nymi. You need the
module for all Windows computers - regardless of whether or
not it already has Bluetooth. Bluegiga’s BLED112 Bluetooth Smart
Module is the only dongle that is Nymi-compatible.
Contact help@nymi.com for more info
78
Once clasped onto your wrist,
your Nymi Band’s lights will pulse
twice indicating the battery level
of your band.
DOWNLOAD NYMI COMPANION
1WEAR YOUR NYMI BAND
Clasp your Nymi Band onto your
wrist with the lights facing you. It
will light up. If not, unclasp and
reclasp your Nymi Band.
3
ENABLE BLUETOOTH
Turn on Bluetooth® on your device. For
Windows® PC, you need to use a Nymi-
compatible Bluetooth module. If you don’t
have one, contact help@nymi.com.
2BATTERY LEVEL
4APP SEARCH MODE
Your Nymi Band will place itself
into search mode. If you do not
see the above light sequence
appear, unclasp and reclasp your
Nymi Band.
5LAUNCH NYMI COMPANION
The Nymi Companion will guide you
through setting up your Nymi Band.
6
IMPORTANT - Consult Safety Instructions Before Use.
FIRST-TIME USE
Pick one device that you would like to
use to activate your Nymi Band daily
(mobile device is recommended). Go to
got.nymi.com to download the Nymi
Companion onto it.
910
BATTERY LEVEL
Once clasped onto your wrist,
your Nymi Band’s lights will pulse
twice indicating the battery level
of your band.
2APP SEARCH MODE
Your Nymi Band will place itself
into search mode. If you do not
see the above light sequence
appear, unclasp and reclasp your
Nymi Band.
3
WEAR YOUR NYMI BAND
Clasp the Nymi Band onto your wrist
with the lights facing you. You will
need to activate your Nymi Band every
time you put it on. Once activated, it
will stay activated until you unclasp it.
1LAUNCH NYMI COMPANION
Have your Nymi Companion open
on your phone or computer so it can
search for your Nymi Band.
4ACTIVATE YOUR NYMI BAND
Place one nger on the top sensor
of your Nymi Band for your heart’s
electrocardiogram to be read.
5ONCE ACTIVATED, CLOSE APP
Your Nymi Band will stay activated as
long as it stays clasped on your wrist.
Now it can interact with Nymi-Enabled
Applications.
6
DAILY ACTIVATION OF YOUR NYMI BAND™
11 12
OPEN NYMI-ENABLED APP
To use your Nymi Band with
applications like phone unlock,
you need to authorize the
application to your Nymi Band.
1AUTHORIZE THE APP
When asked to put your Nymi Band
in pairing mode, quickly tap the top
of your Nymi Band four times.
2PAIRING MODE
Your Nymi Band will indicate
that it is looking for nearby
applications when the above
light sequence appears.
3LOW BATTERY
If the Nymi Band vibrates
and then one light appears,
this means it is low battery
and needs to be charged.
1CONNECT THE CHARGER
A pulsing light indicates that your
Nymi Band is charging. If you do
not see the lights, your charger
may be on backwards.
2FULL CHARGE
A full charge takes approximately
two hours when you use a wall
outlet or your computer’s USB port.
3
AUTHORIZE APPLICATIONS TO YOUR NYMI BAND™ CHARGING YOUR NYMI BAND™
13 14
CHECK STATUS
CHECK THE STATUS OF YOUR NYMI BAND™
! !
!
WATER RESISTANT DESIGN
The Nymi Band is water resistant,
but not waterproof. Do not shower
or swim with your Nymi Band on. If
water is splashed on it, dry it o as
soon as possible.
TEMPERATURE
Do not heat, microwave, or freeze
your Nymi Band. Do not store it with
direct sunlight exposure. Do not
leave your Nymi Band in a hot car.
CLEANING YOUR NYMI BAND
Use only a clean, damp cloth to
clean your Nymi Band. Do not use
chemicals.
TAKING CARE OF YOUR NYMI BAND™
INACTIVE
Your Nymi has not been
activated yet. Activate it
with the Nymi Companion.
!READY
Your Nymi Band is
activated and ready
to go!
!BUSY
Your Nymi Band is currently
connected to an application,
and unable to connect to
another one.
!
Whenever your Nymi
Band is idle, you can
check its status by
double tapping it.
!
15 16
MY NYMI BAND™ IS NOT CHARGING
Refer to the diagram in “Charging my Nymi Band” on page 12 for
the proper orientation of the charger. Plug the USB end of the
charging cable into a wall charger or a computer that is turned
on. If you do not see the lights on your Nymi Band light up after
30 seconds, you may have the charger on backwards, or the
charger is not making full contact with the pins.
NYMI COMPANION IS NOT FINDING MY NYMI BAND
The Nymi Companion can only nd Nymi Bands that you are
wearing on your wrist. Also make sure your Bluetooth is enabled
on your device. If the Nymi Companion does not nd your Nymi
Band, unclasp and reclasp it. You should see that the Nymi Band
is in search mode when there is one light running back and forth
on the Nymi Core. Please also ensure that you’ve charged the
Nymi Band for at least 30 minutes.
HOW DO I TURN MY NYMI BAND ON?
When you clasp the Nymi Band onto your wrist, you should see
one or more lights appear. This means that the Nymi band has
been connected properly and is sending information through
Bluetooth®. However, Nymi-Enabled Applications will not be
able to recognize your Nymi Band until you’ve activated your
band with the Nymi Companion.
You have to activate your Nymi Band every time you put it on.
That is how the Applications know who you are. If you do not
see any lights appear when you put on your Nymi Band, ensure
that it is charged. Next, ensure that you’ve properly clasped your
Nymi Band. There should not be any space between the core and
the band when the clasp is closed.
TROUBLESHOOTING
Go to got.nymi.com for more Troubleshooting Info
17
RESETTING
RESETTING YOUR NYMI BAND™
SOFT RESET
Using a pin, push down on the
reset button once to reboot
your Nymi Band. Your data will
not be aected.
!FACTORY RESET
Using a pin, push and hold
down on the reset button for
5 seconds to clear all settings.
All data will be erased.
!
Connect the charger to your Nymi
Band and make sure the USB end is
connected to a power source.
!
19 20
LEGAL INFORMATION
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation. See instructions if interference to radio or TV reception is suspected.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Your Nymi must be disposed of properly according to local laws and regulations. Because this product contains a battery, the product must be disposed of separately from household waste. When your Nymi
reaches its end of life, contact Bionym or your local authorities to learn about recycling options. For information about Bionym’s recycling program, go to: www.getnymi.com/environment/recycling .
European Union—Disposal Information: This symbol means that according to local laws and regulations your product should be disposed of separately from household waste. When this product reaches its end
of life, take it to a collection point designated by local authorities. Some collection points accept products for free. The separate collection and recycling of your product at the time of disposal will help conserve
natural resources and ensure that it is recycled in a manner that protectshuman health and the environment.
The grantee is not responsible for any changes or modications not expressly approved by the party responsible for compliance. Such modications could void the user’s authority to operate the equipment.
WARNING: Failure to follow these safety instructions could result in re, electric shock, or other injuries, or damage to the Nymi Band™ or other property. Read all the safety information below before using the
Nymi Band.
Handling Handle the Nymi Band with care. It is made of metal and plastic and has sensitive electronic components inside both the Nymi Core and the wristband. The Nymi Band can be damaged if dropped
from an excessive height, burned, punctured, crushed, comes in contact with a corrosive liquid, or submerged under water. Don’t use a damaged Nymi Band.
Repairing Don’t open the Nymi Core and don’t attempt to repair the Nymi Band by yourself. Disassembling the Nymi Band may damage it or may cause injury to you. If the Nymi Band is damaged or
malfunctions contact Nymi at help@nymi.com.
Battery Don’t attempt to replace the Nymi Band’s battery yourself—you may damage the battery, which could cause overheating and injury. The lithium-ion battery in the Nymi Core should be replaced only by
Nymi or a Nymi Authorized Service Provider, and must be recycled or disposed of separately from household waste. Don’t incinerate the battery. For information about battery recycling and replacement, see
got.nymi.com.
Water Your Nymi Band is water resistant. Do not wear in the shower or swimming, or submerge in water for any reason. If the Nymi Band gets wet, dry it as soon as possible.
Charging Use only the provided USB charging cable. Should you require a replacement or additional Nymi USB charging cable(s), you may contact help@nymi.com to purchase them. Please follow the
manufacturer instructions provided with your computer, operating system or USB charging device. Do not leave the Nymi USB charging cable plugged in when not charging your Nymi Band.
IMPORTANT SAFETY INFORMATION
21 22
IMPORTANT SAFETY INFORMATION
Sizing Your Nymi Band comes in various wristband sizes and can be adjusted (see Nymi Band installation in this Instruction Sheet). Do NOT cut, tear or otherwise damage the wristband; doing so will damage
the critical electronics within the wristband and render your Nymi Band inoperative.
Operating Temperature Use the Nymi Band where the ambient temperature is between 0º and 35º C (32º to 95º F). Low- or high-temperature conditions might cause the device to change its behavior to
regulate its temperature. Using the Nymi Band in very cold conditions outside of its operating range may temporarily shorten battery life and could cause the device to turn o. Store the Nymi Band where the
temperature is between -20º and 45º C (-4º to 113º F). For example, don’t leave your Nymi Band in a parked car.
Cleaning Use only a clean, damp cloth to clean your Nymi Band. Harsh chemicals may damage the Nymi Band.
Magnet Nymi Core, Nymi Band and the Nymi USB charger contain a magnet that may erase data on credit cards or other devices. To preserve your data, do not place these or other magnetically sensitive
material or devices within 1 inch (2.5 cm) of Nymi.
Child Safety The Nymi Band and its accessories contain small parts, which can be a choking hazard. Please keep away from young children.
REGULATORY COMPLIANCE INFORMATION
FCC Compliance Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation. See instructions if interference to radio or TV reception is suspected.
Industry Canada Statement
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1)
l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre
le fonctionnement.
CAN ICES-3 (B)/NMB-3(B)
FCC ID: 2ADLK101100
IC ID: 12505A-101100
23
DISPOSAL AND RECYCLING INFORMATION
Your Nymi Band must be disposed of properly according to local laws and regulations. Because this product contains a battery, the product must be disposed of separately from household waste. When your
Nymi Band reaches its end of life, contact help@nymi.com or your local authorities to learn about recycling options.
©2014 Nymi Inc. All rights reserved. Nymi™, Nymi Band™, Nymi Core, and the Nymi logo are trademarks of Nymi Inc. Other product and company names mentioned herein may be trademarks of their
respective companies.
Mention of third-party products is for informational purposes only and constitutes neither an endorsement nor a recommendation. Nymi assumes no responsibility with regard to the performance or use
of these products. All understandings, agreements, or warranties, if any, take place directly between the vendors and the prospective users. Every eort has been made to ensure that the information in this
manual is accurate. Nymi is not responsible for printing or clerical errors.
25 Nymi Band vDK
