Users Manual

Issue department：Bedding Division Date： 2017-08-23

Product Function

instruction

Author： Kyle

No：CB1322

CB.13.22.02

Version： 1.1

Page 2 of 5

1

FunctionPicture

1. Processoftest

1.1. HEADMOTOR

Connecttoheadactuator,controlbyremotesingle:

Clickhead upbuttonontheremote,headactuatormovesout,stopwhenreleased；

Clickheaddownbutton，headactuatormovesin,stopwhenreleased；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

1.2. FOOTMOTOR

Connecttofootactuator,controlbyremotesingle:

Clickfoot up button，footactuatormovesout，stopwhenreleased；

Function instruction

Issue department：Bedding Division Date： 2017-08-23

Product Function

instruction

Author： Kyle

No：CB1322

CB.13.22.02

Version： 1.1

Page 3 of 5

2

Clickfoot downbutton，footactuatormovesin，stopwhenreleased；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

1.3. Massage

Connecttohead&Footmassage,controlbyremote:

Clickheadmassage+button,headmassagestrengthensbyonelevel;

Clickheadmassage‐button,headmassageweakenbyonelevel;

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

1.4. Testforunderbedlight

Clickbuttonofunderbedlight,turnson(orturnsoff)theunderbedlight,switchthestatusoncewhenclickonce；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

1.5. SYNCport

ConnectwiththesameotherControlboxorOtheraccessories;

1.6. PowerLED&PAIRINGLED

Powersupplyforcontrolbox,PAIRINGLEDofcontrolboxisblue,POWERLEDisgreen。

1.7. Power

Connecttothe29VDC;

1.9. PairFunction

DoubleclickRESETbutton，pairingLEDturnson，thecontrolboxentersintomodeofcodeparing；

PressandholdtheparingLEDofRemote,thebacklightofparingLEDflashes,thebacklightofremoteflashes,the

remoteentersintomodeofcodeparing;

1.8. RESETbutton

PressandholdtheRESETbutton(Corresponding Pair

button)，theHead,Footactuatorswillmovestolowerposition.Long press is reset.

Issue department：Bedding Division Date： 2017-08-23

Product Function

instruction

Author： Kyle

No：CB1322

CB.13.22.02

Version： 1.1

Page 4 of 5

3

ThebacklightofparingLEDofremotestopsflashing,andtheparingledofcontrolboxturnsoff,itindicatesthat

thecodeparingissuccessful;

Iffails,repeatalltheprocessesabove;

1.10. FLATfunction

1.11. ZEROGpositionfunction

PressandreleaseZERO Gbuttononremote，theheadandfootactuatormovestopresetmemoryposition，stop

whenpressanybutton；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

FCC warning：

AnyChangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidthe

user’sauthoritytooperatetheequipment.

Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:(1)This

devicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,including

interferencethatmaycauseundesiredoperation.

ISEDRSSWarning:

ThisdevicecomplieswithInnovation,ScienceandEconomicDevelopmentCanadalicenceexempt

RSSstandard(s).Operationissubjecttothefollowingtwoconditions:(1)thisdevice

maynotcauseinterference,and(2)thisdevicemustacceptanyinterference,including

interferencethatmaycauseundesiredoperationofthedevice.

LeprésentappareilestconformeauxCNRd'ISEDapplicablesauxappareilsradio

exemptsdelicence.

L'exploitationestautoriséeauxdeuxconditionssuivantes:

(1)l'appareilnedoitpasproduiredebrouillage,et

(2)l'utilisateurdel'appareildoitacceptertoutbrouillageradioélectriquesubi,

mêmesilebrouillageestsusceptibled'encompromettrelefonctionnement.

PressandreleasetheFLATbuttononremote ，theheadandfootactuatorsmovestolowerposition(whent

he actuatorisfree,canturnoffthevibrationmotorandturnofftheindicatorlightwhenpressonce)，stopwhen

pressanybuton；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

2 0 1 7 .0 7 .3 1

M550 V1.3

John

B.15227 B.15226

CB.13.22.02

R5.113.00.011

R5.504.01.250

JLDP.10.023.000

JLDP.14.027.000

JLDP.05.032.000

R5.216.01.015C

NO.

Product name Product code number

Head Motor

B.15227 1

Foot Motor

B.15226 1

Massage Motor

JLDQ.9.001.130C 2

Massage Motor Cable

R5.410.01.009 1

Control Box CB.13.22.02

Power Supply

JLDP.10.023.000 1

Power Cord

R5.217.01.016 1

ANSI power cord

R5.504.01.250 1

Y cable

R5.216.01.015C 1

Patch cord of LED strip

R5.413.01.005 1

LED strip/ LED

R5.113.00.011 1

USB Socket/USB

JLDP.05.032.000 1

Double USB Chager

JLDP.14.027.000 2

19Keys remote

RF.30.19.02 1

R5.413.01.005

R5.217.01.016

RF.30.19.02

JLDQ.9.001.130C

R5.410.01.009
