Issue department：Bedding Division Date： 2018-05-17

Product Function

instruction

Author： Gary

No：CB3332

CB.33.32.02 Version： 1.1

Page 1 of 5

1

CB.33.32.02 Functioninstruction

1. Electricalconfigurationdiagram：

FCC: PCU-RF2512

IC:21319-RF2512

CB.33.32.02

Issue department：Bedding Division Date： 2018-05-17

Product Function

instruction

Author： Gary

No：CB3332

CB.33.32.02 Version： 1.1

Page 2 of 5

2

2. FunctionPicture

1. Processoftest

1.1. HEADMOTOR

Connecttoheadactuator,controlbyremotesingle:

Clickhead upbuttonontheremote,headactuatormovesout,stopwhenreleased；

Clickheaddownbutton，headactuatormovesin,stopwhenreleased；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

1.2. FOOTMOTOR

Connecttofootactuator,controlbyremotesingle:

Clickfoot up button，footactuatormovesout，stopwhenreleased；

Clickfoot downbutton，footactuatormovesin，stopwhenreleased；

Issue department：Bedding Division Date： 2018-05-17

Product Function

instruction

Author： Gary

No：CB3332

CB.33.32.02 Version： 1.1

Page 3 of 5

3

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

1.3. LumberMOTOR

Connecttofootactuator,controlbyremotesingle:

ClickLumber up button，footactuatormovesout，stopwhenreleased；

ClickLumber downbutton，footactuatormovesin，stopwhenreleased；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

1.4. Massage

Connecttohead&Footmassage,controlbyremote:

Clickheadmassage+button,headmassagestrengthensbyonelevel;

Clickheadmassage‐button,headmassageweakenbyonelevel;

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

1.5. Testforunderbedlight

Clickbuttonofunderbedlight,turnson(orturnsoff)theunderbedlight,switchthestatusoncewhenclickonce；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

1.6. SYNCport

ConnectwiththesameotherControlboxorOtheraccessories;

1.7. PowerLED&PAIRINGLED

Powersupplyforcontrolbox,PAIRINGLEDofcontrolboxisblue,POWERLEDisgreen。

1.8. Power

Connecttothe29VDC;

Issue department：Bedding Division Date： 2018-05-17

Product Function

instruction

Author： Gary

No：CB3332

CB.33.32.02 Version： 1.1

Page 4 of 5

4

1.9. RESETbutton

PressandholdtheRESETbutton，theHead,Footactuatorswillmovestolowerposition.

1.10. PairFunction

DoubleclickRESETbutton，pairingLEDturnson，thecontrolboxentersintomodeofcodeparing；

PressandholdtheparingLEDofRemote,thebacklightofparingLEDflashes,thebacklightofremoteflashes,the

remoteentersintomodeofcodeparing;

ThebacklightofparingLEDofremotestopsflashing,andtheparingledofcontrolboxturnsoff,itindicatesthat

thecodeparingissuccessful;

Iffails,repeatalltheprocessesabove;

Issue department：Bedding Division Date： 2018-05-17

Product Function

instruction

Author： Gary

No：CB3332

CB.33.32.02 Version： 1.1

Page 5 of 5

5

FCC warning：

Any Changes or modifications not expressly approved by the party responsible for compliance could void the

user’sauthoritytooperatetheequipment.

Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:

(1)Thisdevicemaynotcauseharmfulinterference,and

(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.

ISEDRSSWarning:

ThisdevicecomplieswithInnovation,ScienceandEconomicDevelopmentCanada

licenceexemptRSSstandard(s).Operationissubjecttothefollowingtwoconditions:

(1)thisdevicemaynotcauseinterference,and

(2)thisdevicemustacceptanyinterference,includinginterferencethatmaycauseundesired

operationofthedevice.

LeprésentappareilestconformeauxCNRd'ISEDapplicablesauxappareilsradio

exemptsdelicence.

L'exploitationestautoriséeauxdeuxconditionssuivantes:

(1)l'appareilnedoitpasproduiredebrouillage,et

(2)l'utilisateurdel'appareildoitacceptertoutbrouillageradioélectriquesubi,

mêmesilebrouillageestsusceptibled'encompromettrelefonctionnement.
