Oki Electric Industry RX4004A RFID Reader Module User Manual

User Manual

ＲＸ４００４A set up manual

RX4004A are attached in printer base unit according to

the following figure.

FCC WARNING

Changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate the equipment.

NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation.This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures: -Reorient or relocate the

receiving antenna -Increase the separation between the equipment an d receiver. -Connect

the equipment into an outlet on a circuit different from that to which the receiver is

connected. -Consult the dealer or an experienced radio/TV techn ician for help.

RX4004A

toner cartridges

set area

Function of RX4004A is next page.

Printer base unit

A toner cartridge is equipped with RF-ID TAG.

If toner cartridges are set to a printer, communication of RF-ID TAG and a RFID

read writer module(RX4004A) will be attained. The function of this system is the

following.

- Management of the existence detection and toner residual qua ntity of a toner

cartridge

toner cartridge

RF-ID TAG
