Openmatics s r o SMART ZF Smart Service User Manual edited ZF Smart Service Manual 27112017
Openmatics s.r.o. ZF Smart Service edited ZF Smart Service Manual 27112017
User Manual
3. If the tool is not working
what to check
5. Simplified EU Declaration of Conformity
Hereby, Openmatics s. r. o. declares that the radio equipment type
is in compliance with Union harmonization legislation 2014/30/EU,
2014/35/EU, 2014/53/EU. The full text of the EU declaration of conformity
is available at the following internet address: www.OPENMATICS.com.
Trademark
Manufacturer
Type of Equipment
Model Names
Part Numbers
Openmatics
Openmatics s. r. o.
Passenger Car Service Device
ZF Smart Service
0501.337.224
Ensure there is a Blue LED in the ZF Smart Service Device.
Ensure the software is up to date by connecting to the internet.
The ZF Smart Service App will check automatically.
Is the ZF Smart Service Device connected to the Android device?
4. Technical Support
Should you have a problem then please contact technical support.
Please make sure when contacting support you have the following
information: Unit Serial number, Function being used, Software version,
Vehicle Manufacture and Model
Openmatics s.r.o.
Poděbradova 2842/1, 301 00 Pilsen, Czech Republic
Copyright © Openmatics s. r. o.
This document is protected by copyright.
Complete or partial reproduction or dissemination of this document is prohibited without the consent
of Openmatics s. r. o. Infringements lead to civil and criminal prosecution.
ZF Smart Service
support@zfsmartservice.com
www.zfsmartservice.com
0501.337.224
ZF Smart Service
The ZF Smart Service device allows you to carry out the following service
functions:
Reset Service indicator
Brake Bleed
Brake Pad replacement
Steering Angle calibration
EOBD diagnostics
1. App download
Download the ZF Smart
Service App on Google Play.
Keep the card in a safe place
2. Registration
and device
activation
The Serial number
and Activation code
are on the rear
of the Activation Card
Radio operating frequencies:
Bluetooth:
Operating frequency: 2402-2480 MHz (79 channels)
Maximum output power: -0.7 dBm EIRP average (calculated)
Bluetooth low energy:
Operating frequency: 2402-2480 MHz (40 channels)
Maximum output power: -1.4 dBm EIRP average (calculated)
FCC Statement
15.19
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
15.21
Note: The grantee is not responsible for any changes or modifications not expressly approved by
the party responsible for compliance. Such modifications could void the user’s authority to operate
the equipment.
15.105(b)
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help
RF Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance of 20 cm
between the radiator and your body.
