Specification leaflet
O0210000480 (eng) / O0210000490 (blanco)
dual reader
RF-IDtag / barcode
PHL 2700
RF-ID
handheld terminal
Opticon Sensors Europe B.V. / Opaallaan 35 / 2132 XV Hoofddorp / The Netherlands
phone: (31) 23-5692700 / fax: (31) 23-5638266 / e-mail: sales@opticon.nl
internet: www.opticon.nl (www.opticon-sensors.com)
The PHL2700 terminal is a programmable handheld terminal, well suited
for a variety of indoor portable applications. Different identification
methods can be chosen for data collection: the built-in scanner is able
to read all popular barcodes in combination with RF-ID tags.
The PHL2700 terminal can be programmed in C-language. The clear
and easily readable graphic display enables the user to use the
terminal in combination with advanced application programs.
Operating power is supplied by the main battery. A rechargeable battery
pack, that can be charged in the cradle, or non-rechargeable penlite
batteries can be used.
For communication the PHL2700 is provided with an IrDA interface.
Through this interface the terminal is able to communicate with the
cradle, or apart from the cradle to all computer devices that use IrDA.
Also belt printers can easily be approached by the PHL2700 thanks
to the smart location of the IrDA window.
Features Benefits
Rechargeable Nickel Metal Hydride Long life batteries
battery pack
8 MB Memory available Enables continuous working
even with large data storage
Easily readable graphic display Enables advanced applications
RS232 data transmission Easy data storage into the
by cradle computer system
Built-in IrDA interface Ideal to use together with portable
computers, like note books.
Integrated laser technology Possibility to read both
and RF-ID technology bar codes and RF-ID tags
IRU2700
cradle for data transmission and
charging rechargeable battery pack
Dual data collection
programmability and portability
barcode reading and RF tag reading
in one terminal
Preliminary specifications
Environmental specifications
Temperature 0 - 40 oC in operation
-20 - 60 oC in storage
Humidity 30 - 85 % in operation
(non condensing) 30 - 90 % in storage
Shock: vibration: 10 - 50 Hz with 1G for 30 min, cycle for X,Y,Z.
Emission According to EN50081, part 1
Immunity According to EN50082, part 1
Electrical specifications
Battery charging time when battery in terminal:
8 hours charge
Physical specifications
Dimensions (l x w x d) 150 x 90 x 81 mm
Case material ABS
Weight 250 g
Standard connector RS232 - D Sub 9P Female
RS485 - 6 pins modular plug
Functionality
Interfaces supported RS232
RS485
Serial communication RS232 Baudrate: 1200 - 115200
RS485 Baudrate: 1200 - 115200
Transmission modes Half duplex RS232
Half duplex RS485
Parity Odd, Even, None
IRU-2700 cradle
The Netherlands Hoofddorp - France Issy Les Moulineaux Cedex - Germany Mainhausen
Italy Bologna - Sweden Järfälla - U.K. Banbury, Oxon
Australia Lane Cove - Japan Ashibetsu - Warabi - Osaka - Taiwan Taipei - U.S.A. Orangeburg
Preliminary specifications are subject to change without notice. Printed 01-2003
Electrical specifications
Main battery rechargeable pack: Ni-MH
dry cell: Alkaline penlite
optional: other 2 x AA-size penlite
Main battery Ni-MH: When having every 10 seconds on:
operating time 1 sec laser, 0.4 sec. green LED, 0.4 sec. buzzer,
1 sec. RFIDtag reading, 0,2 sec. RFIDtag writing,
operating time is: approx. 22 hours
Alkaline: When having every 10 seconds on:
1 sec laser, 0.4 sec. green LED, 0.4 sec. buzzer,
1 sec. RFIDtag reading, 0,2 sec. RFIDtag writing,
operating time is: approx. 43 hours
Different operation conditions affect the
operating time
Use of other penlite batteries affect the
operating time
Backup battery Lithium (CR2032)
Backup battery If fully charged: 30 days backup time
operating time
Battery management Low voltage indicated on the terminal display.
When battery is low the terminal switches
off automatically.
Charging method Rechargeable Ni-MH pack in terminal via
cradle
Specifications laser module (barcode reading)
Light source 650 nm visible laser diode
Scan rate 100 scans/sec
Decode rate 100 decodes/sec
Reading width 62 mm at 30 mm
111 mm at 100 mm
Resolution at PCS 0,9 0.15 mm (6mil)
Depth of field 0 - 140 mm (at PCS 0.9, res. 0.25)
Specifications RF-ID module (RF-ID tag reading)
Reading range up to 15 mm, dependent on type of RF-ID tag
Physical specifications
Dimensions (l x w x d) 177 x 62 x 41 mm
Case material ABS
Weight body (excl. battery): 195 g
Direct cable optional for maintenance: RS232 - DB9 female
PHL2700 RF-ID handheld terminal Functionality
Memory ROM: 32 kB
FlashROM (for O/S and program): 512 kB
fast RAM: 2kB
battery backed up D-RAM (for data): 8 MB
Microprocessor 16-bit
Real time clock Quartz RTC, time and date programmable,
leap year handling, (accuracy + 60 sec./month)
Display 128x64 Pixels graphic LCD with backlight
Character fonts:
4/8 lines x 16 characters
5/10 lines x 21 characters
Keyboard 27 keys total (26 keys user definable)
8 Function keys
Alpha/Numeric mode
Trigger mode Manual
Programming Functionality is provided by user application. The
application may be downloaded from PC via cable,
com port or IrDA.
Interfaces supported RS232 by direct cable
RS232 by cradle
IrDA on terminal
Transmission speed RS232 direct cable: 2400 - 115200 baud
RS232 cradle: 2400 - 115200 baud
IrDA terminal: 2400 - 115200 baud
Environmental specifications
Temperature -10 - 40 oC in operation
-20 - 60 oC in storage
Humidity 20 - 80 % in operation
(non condensing) 20 - 90 % in storage
Shock: drop: 1.5 m drop onto concrete surface
Shock: vibration: 10 - 50 Hz with 1G for 30 min, cycle for X,Y,Z.
Ambient light rejection fluorescent 3.000 lux max.
direct sun 50.000 lux max.
Emission According to EN50081, part 1
Immunity According to EN50082, part 1
R&TTE According to EN300-330
Protection against
dust and moisture According to IEC529, IP 42
Safety, Laser class According to IEC825, Class I laserproduct
Supported Chinese Post 2of5 - Codabar incl. ABC and CX - Code 39 - Code 93 - Code 128 - EAN-8 incl. +2,+5 - EAN-13 incl. +2,+5
symbologies IATA - Industrial 2of5 - Interleaved 2of5 - Italian Pharmaceutical - Laetus - Matrix 2of5
MSI/Plessey - UK/Plessey - S-Code - Telepen - UPC-A incl. +2,+5 - UPC-E incl. +2,+5
Supported RF Tags at 13.56 MHz Philips I-Code Texas Instruments Tag-It ISO 15693
Supported RF Tags at 134.2 kHz Texas Instruments TIRIS For other requests contact Opticon.
