Otter OBFTC-0010-A Bluetooth Eearphones User Manual Customer
Otter Products, LLC. Bluetooth Eearphones Customer
Otter >
user manual
Otter Products, LLC.
OBFTC-0010-A
Page 1 of 2
Function of the headset operation
Before operating each function of the headset, please read the following introduction:
function button and time
(seconds) status sketch remarks
Power on
In off mode ,pull apart
the headset, it will power
on .
Red and blue
indicator light will
flash ,it will last for 1
second
Could hear “Power on”/YEJ
Pairing
1.Pull apart the
headset ,it will enter into
pairing mode
automatically （never
connected / paired with
any devices ）；
2. In pairing
mode,headset
disconnect with phone
and other devices,it will
pair automatically
Blue and red light is
rapid flashing
alternately
After enter into the pairing mode,
blue and red light alternately
flashing,it will last for 2 minutes.Enter
into pairing/YEJ warning voice
Power off
In On mode,touch the
magnet together,it will
power off
Red and blue
indicator light will
flash ,it will last for 1
second
YEJ warning voice
Last Number
Redialing
Pree MFB for twice;If
in 2 link status,then press
and hold “+”volume key
for 2 seconds
Aim at redialing
the last phone number
that you called
(your phone must be supported
with Bluetooth redialing mode
Answering
the call
1.听In On mode,shortly
press MFB ； When in
On mode ,could not use
the magnetic function to
answer the call
2. In off mode ：
Requirement:headset
must be have
pairing
record with the phone
When a call coming,pull
apart the magnet,it will
pair with the phone
again ,if successful,could
answer the call
automatically
Can answer the call
through the headset
In music state ,press MFB to
answer the call. If use the magnetic
function to end the call ,music will
transfer to your phone. (Recommend
not use the magnetic function to end
the call under such condition)
(End the
call)
1.Shortly press MFB
2.Touch the magnet
together ,at the same
When you want to
cut off the call Beep once
FCC ID: 2AEEVOBFTC-0010-A
BS156RL
IC: 20048-OBFTC0010A
Otter Products, LLC.
OBFTC-0010-A
Page 2 of 2
time, headset will power
off.
Rejecting call
Press and hold MFB for
2 seconds(In pairing
mode)
Directly rejecting the
incoming call
Could hear beep twice ,and
headset will enter into standby
mode(you phone need to support it)
Mute Press and hold “V+”
button for 3 seconds
The caller won’t hear
the sound from headset Could here Beep twice
Two link
function
Separated twice to
Connected with 2 phone
Connected with two
phone at the same
time, enter into standby
mode
your phone need to support
Music play
/stop
1.In standby mode,
shortly press MFB
2. touch the magnetic to
pause music and power
off
3. pull apart magnetic for
playing music
On music state Led shining once on every 10 second
forward Long press V- for 2
second on music state With voice guidance of “dou”
backward Long press V+ for 2
second on music state With voice guidance of “dou”
Ring for
coming call No need any operation It should support by phone
sirr
On music state, shortly
press V+ AND v- at the
same time
automaticed by
cellphone(voice dial) it should support by phone
Clear pairing
list
Without connection
state. Long press V+ and
V- until the red and blue
light flashed twice at the
same time, then power
off for clearing pairing list
red and blue light
flashed twice at the
same time
Voice guidance with “dou do”
1.Some function will differ due to phone’s brand
2.For the Aptx function, it should be supported by phone with aptx
BS156RL
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1)this device may not cause interference, and(2) this device must
accept any interference, includinginterference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables auxappareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes :(1) l'appareil ne doit
pas produire de brouillage, et(2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre lefonctionnement.
