Unihan UPW L6 0 3 8 1 HP
1 .Ge nera l Description
The UPWL60381HP wireless m odule is a fully assem bled and test ed
general-purpose m odule using the AR9381wireless
Syst em - on- Chip( SoC) . The m odule cont ains AR9381 chip and all
other necessary com ponent s to operat e the UPWL60381HP.
For det ailed inform ation on the UPWL60381HP com ponent itself, refer
to the UPWL60381HP dat asheet .
2 . Fe at ure s
Features Description
Network Standard IEEE 802.11 b/g/n (final n)
Chipset Atheros AR9381
Input Voltage 3.3V
Data Rate 802.11b: 1, 2, 5.5, 11Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps
802.11n-20 MHz: MCS0~MCS23
802.11n-40 MHz: MCS0~MCS23(450Mbps)
Modulation
802.11b:DBPSK(1Mbps),DQPSK(2Mbps),CCK(5.5Mbps,11Mbps)
802.11g:BPSK(6Mbps,9Mbps),QPSK(12Mbps,18Mbps),
16QAM(24Mbps,36Mbps),64QAM(48Mbps,54Mbps)
802.11n:BPSK(MCS0,MCS8, MCS16),
QPSK(MCS1,MCS2,MCS9,MCS10, MCS17, MCS18),
16QAM(MCS3,MCS4,MCS11,MCS12, MCS19, MCS20),
64QAM(MCS5,MCS6,MCS7,MCS13,MCS14,MCS15, MCS21,
MCS22, MCS23)
Operating Frequency 802.11b/g/n (2412 ~ 2462 MHz)
Operating Channel 1~11 for North America,
Transceiver/Receiver
Mode 3T3R Mode
3 . Be nefits
Sm all, self- cont ained SMT m odule.
3X3 MI MO function support
High power solut ion support high speed transm it t ance
Fede ral Com m unicat ions Com m ission St a t em ent
This device com plies with FCC Rules Part 15. Operat ion is subj ect t o t he following
i. This device m ay not cause harm ful interference, and
ii. This device m ust accept any interference received, including int erference t hat m ay cause
undesired operat ion.
This equipm ent has been tested and found t o com ply wit h t he lim it s for a class B digit al device,
pursuant to Part 15 of t he Federal Com m unicat ions Com m ission (FCC) rules. These lim it s are
designed t o provide reasonable prot ect ion against harm ful int erference in a resident ial inst allation.
This equipm ent generates, uses, and can radiate radio frequency energy and, if not inst alled and
used in accordance wit h t he inst ructions, m ay cause harm ful interference t o radio com m unicat ions.
How ev er, there is no guarant ee that int erference w ill not occur in a part icular inst allat ion. I f t his
equipm ent does cause harm ful interference t o radio or television recept ion, which can be
det erm ined by t urning the equipm ent off and on, the user is encouraged t o try to correct the
int erference by one or m ore of t he following m easures:
i. Reorient or relocate t he receiving antenna.
ii. I ncrease the separat ion bet ween t he equipm ent and receiver.
iii. Connect the equipm ent into an outlet on a circuit different from that to which the receiver is
connect ed.
iv. Consult the dealer or an experienced radio/ TV t echnician for help.
CAUTI ON ! You are caut ioned t hat changes or m odifications not expressly approved by t he party
responsible for com pliance could void your authorit y t o operat e the equipm ent.
Reprinted from t he Code of Federal Regulat ions # 47, part 15.193, 1993. Washingt on DC: Office of t he
Federal Regist er, Nat ional Archives and Records Adm inist rat ion, U.S. Governm ent Print ing Office.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one of the following
measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
● Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
For product available in the USA/Canada market, only channel 1~11 can be operated. Selection
of other channels is not possible.
This device and its antenna(s) must not be co-located or operation in conjunction
with any other antenna or transmitter.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
IMPORTANT NOTE:
This module is intended for OEM integrator. The OEM integrator is still responsible for the FCC
compliance requirement of the end product, which integrates this module.
20cm minimum distance has to be able to be maintained between the antenna and the users for
the host this module is integrated into. Under such configuration, the FCC radiation exposure
limits set forth for an population/uncontrolled environment can be satisfied.
Any changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate this equipment.
USERS MANUAL OF THE END PRODUCT:
In the users manual of the end product, the end user has to be informed to keep at least 20cm
separation with the antenna while this end product is installed and operated. The end user has to
be informed that the FCC radio-frequency exposure guidelines for an uncontrolled environment
can be satisfied. The end user has to also be informed that any changes or modifications not
expressly approved by the manufacturer could void the user's authority to operate this equipment.
If the size of the end product is smaller than 8x10cm, then additional FCC part 15.19 statement is
required to be available in the users manual: This device complies with Part 15 of FCC rules.
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference and (2) this device must accept any interference received, including interference that
may cause undesired operation.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains TX FCC ID:
VUIUPWL60381HP ". If the size of the end product is larger than 8x10cm, then the following FCC
part 15.19 statement has to also be available on the label: This device complies with Part 15 of
FCC rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Sa fe t y st atem e nts
Regulat ory I nform at ion / Discla im ers
I nst allat ion and use of t his m odule device m ust be in st rict accordance with t he inst ructions included in
the user docum entation provided wit h t he product . Any changes or m odificat ions (including the
antennas) m ade t o this device t hat are not expressly approved by the m anufact urer m ay void the user’s
authority to operate t he equipm ent. The m anufact urer is not responsible for any radio or television
int erference caused by unaut horized m odificat ion of this device, or t he subst it ut ion of t he connect ing
cables and equipm ent ot her than m anufact urer specified. I t is the responsibilit y of t he user t o correct
any interference caused by such unauthorized m odificat ion, substit ut ion or at tachm ent. Manufacturer
and it s authorized resellers or distribut ors will assum e no liability for any dam age or violat ion of
governm ent regulat ions arising from failing to com ply wit h t hese guidelines.
CAUTI ON ! To m aintain com pliance wit h FCC’s RF exposure guidelines, this equipm ent should be
installed and operat ed wit h m inim um distance [ 20cm ] bet ween t he radiator and your body. Use on t he
supplied ant enna. Unaut horized antenna, m odificat ion, or at tachm ents could dam age t he t ransm it ter
and m ay violat e FCC regulations.
Sa fe t y I nform a t ion
I n order to m aintain com pliance wit h the FCC RF exposure guidelines, t his equipm ent should be
installed and operat ed wit h m inim um dist ance [ 2 0 cm ] bet ween t he radiator and your body. Use only
with supplied ant enna.
Unauthorized ant enna, m odificat ion, or att achm ent s could dam age t he t ransm it ter and m ay violat e FCC
regulat ions.
CAUTI ON ! Any changes or m odifications not expressly approved in t his m anual could void your
authorizat ion t o use this device.
MPE St a t em en t
Your device cont ains a low power transm itt er. When device is t ransm it ted it sends out Radio Frequency
( RF) signal.
FCC Ra dio Freque ncy Ex posure
This m odule device has been evaluated under FCC Bulletin OET 65C and found com pliant to t he
requirem ents as set fort h in CFR 47 Sect ions 2.1091, 2.1093, and 15.247( b)(4) addressing RF Exposure
from radio frequency devices. The radiation out put power of t his m odule device is far below the FCC
radio frequency exposure lim it s. Nevert heless, t his device shall be used in such a m anner t hat t he
potential for hum an contact during norm al operat ion – as a m obile or port able device but use in a
body- worn way is st rict ly prohibit . When using this device, a certain separat ion distance bet ween
antenna and nearby persons has t o be kept to ensure RF exposure com pliance. I n order t o com ply wit h
t he RF exposure lim it s est ablished in t he ANSI C95.1 st andards, t he dist ance bet ween t he antennas and
the user should not be less than [ 20cm ] .
RF Ex posure
The antenna( s) used for t his transm it ter m ust not be co- locat ed or operat ing in conj unct ion w ith any
ot her antenna or transm it ter.
About t his guide
This user guide contains the inform at ion your PEGATRON WI FI Module.
IC Statement:
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B conforme á la norme NMB-003 du Canada.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible
d'en compromettre le fonctionnement.
For product available in the USA/Canada market, only channel 1~11 can be operated. Selection
of other channels is not possible.
Pour les produits disponibles aux États-Unis / Canada du marché, seul le canal 1 à 11 peuvent être exploités.
Sélection d'autres canaux n'est pas possible.
This device and its antenna(s) must not be co-located or operation in conjunction with any other
antenna or transmitter.
Cet appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association avec une autre
antenne ou transmetteur.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
Declaración de exposición a la radiación de Canada:
Este equipo cumple con los límites de exposición a la radiación de la IC establecidos para un ambiente no
controlado.
Este equipo se debe instalar y operar con una distancia mínima de 20 cm entre el radiador y su cuerpo.
This module is intended for OEM integrator. The OEM integrator is still responsible for the IC
compliance requirement of the end product, which integrates this module.
20cm minimum distance has to be able to be maintained between the antenna and the users for
the host this module is integrated into. Under such configuration, the IC RSS-102 radiation
exposure limits set forth for an population/uncontrolled environment can be satisfied.
Any changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate this equipment.
This radio transmitter (identify the device by certification number, or model number if Category II)
has been approved by Industry Canada to operate with the antenna types listed below with the
maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for
that type, are strictly prohibited for use with this device.
Le présent émetteur radio (identifier le dispositif par son numéro de certification ou son numéro de modèle s'il fait
partie du matériel de catégorie I) a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne
énumérés ci-dessous et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les
types d'antenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement
interdits pour l'exploitation de l'émetteur.
Ant.
Group Ant. Brand Model Name
Antenna
Type Connector
Gain
(dBi)
Antenna
length
(cm)
Remark
1 1-3 Airgain N2420S PCB U.FL 1.3 16.2 TX/RX
2 4-6 Airgain N2420S PCB U.FL 1.42 12.3 TX/RX
3 7-9 Airgain N2420S PCB U.FL 1.63 5.7 TX/RX
4 10-12 WANSHIH
WPB243
(UC3WFI0053)
PCB MHF 3.10 22.4 TX/RX
5 13-15 WANSHIH
WPB243
(UC3WFI0055)
PCB MHF 5.03 15.8 TX/RX
6 16-18 WANSHIH
WPB243
(UC3WFI0054)
PCB MHF 3.03 5 TX/RX
7 19-21 WANSHIH
WC3WFI0054
PCB MHF 5.4 21.3 TX/RX
USERS MANUAL OF THE END PRODUCT:
In the users manual of the end product, the end user has to be informed to keep at least 20cm
separation with the antenna while this end product is installed and operated. The end user has to
be informed that the IC radio-frequency exposure guidelines for an uncontrolled environment can
be satisfied. The end user has to also be informed that any changes or modifications not
expressly approved by the manufacturer could void the user's authority to operate this equipment.
IC statement is required to be available in the users manual: This Class B digital apparatus
complies with Canadian ICES-003. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference and (2) this device must accept any interference
received, including interference that may cause undesired operation.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains TX IC :
7582A-UPWL60381HP ".
Syst em requirem ents
Before inst alling the PEGATRON WI FI m odule, m ake sure that your syst em m eet s t he
following requirem ent s:
I nt el® Pent ium ® 4 or AMD K7/ K8 syst em
Minim um 64MB syst em m em ory
Windows® XP/ VI STA operat ing syst em
I nst alling the de vice drivers
To inst all the device driver in your com put er:
I nsert the support CD to t he opt ical drive and follow t he following procedure.
St ep 1
St ep 2
St ep 3
St ep 4
