PEGATRON WL227NMIIV2 Wireless Module User Manual WL 227N MII V2

PEGATRON CORPORATION Wireless Module WL 227N MII V2

User Manual

WL-227N_MII_V2 Hardware & Driver Reference
WL-227N_MII_V2
MII WiFi (comply with 802.11n draft 2.0 and 802.11 a/b/g)
Hardware and Driver Reference
WL-227N_MII_V2 Hardware & Driver Reference
CONTENTS
INTRODUCTION .........................................................................................................3
SCOPE...................................................................................................................3
ACRONYMS AND DEFINITIONS .....................................................................3
FEATURES AND SPECIFICATIONS..................................................................3
Driver installation for Linux..........................................................................................5
Federal Communication Commission Interference Statement ......................................7
NOTE: Information in this document is subject to change after this document is
made available.
WL-227N_MII_V2 Hardware & Driver Reference
INTRODUCTION
SCOPE
The purpose of this specification is to document the requirements for 802.11 a/b/g/n, it is a
iNIC card that not only can be acted as traditional AP/Router but also providing WLAN dual
band access capabilities.
ACRONYMS AND DEFINITIONS
Acronym Description
BBP Base Band Processor
BER Bit Error Rate
BPSK Binary Phase Shift Keying
CCK Complementary code keying
EVM Error Vector Magnitude
MAC Media Access Controller
OFDM Orthogonal Frequency Division Multiplexing
QAM Quadrature Amplitude Modulation
QPSK Quadrature Phase Shift Keying
FEATURES AND SPECIFICATIONS
Features Description
Network Standard Fully comply with IEEE 802.11n draft 2.0 and IEEE 802.11 a/b/g
standards
Chipset Highly Integrated MIMO 2T3R MAC/BBP chip (RT2880) with MII
Interface and Single-chip Transceiver (RT2850) with 2.4 GHz
(low-band) and 5~6GHz(high-band) ISM bands
Transmitter/Receiver Two Tx transmits from transceiver through external PAs to the
antennas.
Mechanism Three Rx act as MIMO coming from the antennas.
Host interface Mini PCI Type III A, 124 Pin
WL-227N_MII_V2 Hardware & Driver Reference
Dimension L: 64.5mm by W:60.0mm
Data Rate 300Mbps Receive PHY Rate, 300Mbps Transmit PHY Rate and
supports 2 streams
Modulation Modulation Technology support Orthogonal Frequency Division Multiplexing
(OFDM), DSSS
Operating Frequency 2.4 ~ 2.5GHz and 4.9~5.9GHz
Operating Channels Ch1~Ch14, CH36~CH48,CH52~CH64,CH149~CH161
Antenna Connectors 3 U.FL I-PEX RF connectors
Security 64-bit/128-bit WEP, TKIP, and AES hardware encryption Wi-Fi
alliance WPA, WPA2
Driver Support OS Linux Windows XP
Transmitter/Receiver Two Tx transmits from transceiver through an external PA to the
antenna.
Mechanism Three Rx act as MIMO coming from the antennas.
Weight NW 15g
Application This module will be used in a 12 inch or greater laptop.
WL-227N_MII_V2 Hardware & Driver Reference
Driver installation for Linux
1. Insert USB flash disk & WL-227N NIC before booting
2. Boot Linux system and login
3. Create path [Wireless]: mkdir /etc/Wireless
4. Mount USB Hard Disk: mount /dev/sda1 /mnt
5. Copy tar file to Linux from USB Hard Disk:
cp /mnt/2008_0812_RT2880_iNIC_v1.1.8.0.tar.bz2 /etc/Wireless/
6. Decompress tar file to /etc/Wireless/, and it will generate a
directory[2008_0812_RT2880_iNIC_v1.1.8.0]:
tar -jxvf /etc/Wireless/2008_0812_RT2880_iNIC_v1.1.8.0.tar.bz2
7. Rename directory [2008_0812_RT2880_iNIC_v1.1.8.0] to [RT2880], in other words,
the driver’s path was /etc/Wireless/RT2880 (default path in Ralink manual): mv
2008_0812_RT2880_iNIC_v1.1.8.0 RT2880
8. Now, we can complier driver (basic function):
a. Enter [RT2880] directory: cd RT2880
b. Rename [module-1.1.8.0] to [module]: mv module-1.1.8.0 module
c. Enter [/etc/Wireless/RT2880/module] directory: cd module
d. Complier driver: make
After make, it will generate five files:
Module.sysmvers
rt2880_iNIC.ko
rt2880_iNIC.mod.c
rt2880_iNIC.mod.o
rt2880_iNIC.o
e. Copy iNIC_sta.bin and iNIC_sta_dat to [/etc/Wireless/RT2880/] from
[/etc/Wireless/RT2880/firmware/]:
• Enter [/etc/Wireless/RT2880/firmware/]: cd firmware
• Copy iNIC_sta.bin and iNIC_sta_dat to [/etc/Wireless/RT2880/] from
[/etc/Wireless/RT2880/firmware/]: cp iNIC_sta.* ../../
WL-227N_MII_V2 Hardware & Driver Reference
9. Setup and bootstrap WL-227N NIC:
a. Setup WL-227N NIC:
insmod /etc/Wireless/RT2880/module/rt2880_iNIC.ko mode=sta
• If it shows “ra0:Ralink iNIC at 0xe0cc0000(hardware address),
00:43:0c:00:00:00 (MAC address), IRQ169 (IRQ address)”, the NIC is boot
strap successfully.
b. Bootstrap NIC parameters:
• IP address: ifconfig ra0 inet 192.168.0.11 up
• If it shows the message as below, it is bootstrap successfully:
Send STARTUP to RT2880
close Firmware file
RACFG_CMD_BOOT_STARTUP
Update MAC(0)=00:11:22:33:44:55
Or, type [ifconfig ra0] configuration. If it shows the message as below,
it is bootstrap successfully, too:
ra0 Link encap:Ethernet HWaddr 00:11:22:33:44:55
inet addr:192.168.0.122 Bcast:192.168.0.255 Mask:255.255.255.0
inet6 addr: fe80::211:22ff:fe33:4455/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:2445 errors:0 dropped:0 overruns:0 frame:0
TX packets:2188 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:2235102 (2.1 MiB) TX bytes:2236428 (2.1 MiB)
Interrupt:169
c. Setup NIC connect function:
Setup NIC frequency band: iwpriv ra0 set WirelessMode=9
Setup NIC connect target of AP: iwpriv ra0 set SSID=dlink
type [iwconfig ra0] configuration. If it shows the message as below,
it is connect successfully:
ra0 RT2880 iNIC STA ESSID:”dlink”
Mode:Managed Frequency:2.412 GHz Access Point: 00:1F:C6:69:BE:95
Bit Rate:54 Mb/s
RTS thr:off Fragment thr:off
Encryption key:off
Link Quality=91/100 Signal level:-72 dBm Noise level:-71 dBm
Rx invalid nwid:0 Rx invalid crypt:0 Rx invalid frag:0
Tx excessive retries:0 Invalid misc:0 Missed beacon:0
WL-227N_MII_V2 Hardware & Driver Reference
Federal Communication
Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installa-tion. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interfer-ence will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate this
equipment.
FOR PRODUCTS AVAILABLE IN USA/CANADA: Only channels 1 to 11 can be
operated. Selection of other channels is not possible. This device and its
antenna(s) must not be co-located or operation in conjunction with any other
antenna or transmitter. This device is going to be operated in 5.15GHz to
5.25GHz frequency ranges, it is restricted in indoor environment only.
END PRODUCTS SMALLER THAN 8cm x 10cm: This device complies with Part
15 of FCC rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference and (2) this device must accept any
interference received, including interference that may cause undesired
operation.
MINIMUM DISTANCE: This module is intended for OEM integrator. The OEM
integrator is still responsible for the FCC compliance requirement of the end
product, which integrates this module. 20cm minimum distance has to be able
WL-227N_MII_V2 Hardware & Driver Reference
to be maintained between the antenna and the users for the host this module is
integrated into. Under such configuration, the FCC radiation exposure limits set
forth for an population/uncontrolled environment can be satisfied.
END PRODUCT LABEL: Contains TX FCC ID: VUI-WL227NMIIV2
