PHILIPS Consumer Electronics SE450 US DECT PHONE-BASE User Manual
PHILIPS Consumer Electronics US DECT PHONE-BASE Users Manual
Users Manual
SE450
master US-EN Telephone
Warning
Use only rechargeable batteries.
Charge the handset for 24 hours before use.
Register your product and get support at
www.philips.com/welcome
01GB01COV.fm Page 1 Thursday, July 3, 2008 4:26 PM
01GB01COV.book Page 2 Thursday, July 3, 2008 9:27 AM
1
Table of contents
1 Important Safety
Instructions 4
2 Environment and safety 6
2.1 Safety information 6
2.2 Power requirements 6
2.3 Battery requirements 6
2.4 Telephone connection 6
2.5 Environmental care 7
2.6 Precautions 7
2.7 Equipment Approval
Information 8
2.7.1 Notification to the Local
Telephone Company 8
2.7.2 Rights of the
Phone Company 8
2.8 Interference Information 9
2.9 Hearing Aid Compatibility
(HAC) 10
2.10 FCC RF Radiation
Exposure Statement 10
3Important 10
3.1 Power requirements 11
3.2 Electric, Magnetic and
Electromagnetic Fields
(“EMF”) 12
3.3 Recycle your batteries 12
4The RBRC
® seal 12
4.1 Service Centers 13
5 Your phone 14
5.1 What’s in the box 14
5.2 Overview of your phone 15
5.3 Display icons and Messages 17
5.4 Overview of the
base station 18
6 Getting started 19
6.1 Connect the base station 19
6.2 Wall mounting the base 19
6.3 Install your phone 20
6.3.1 Install battery 20
6.3.2 Charge battery 21
6.4 Remove/Attach belt clip 21
6.5 Install optional headset 22
6.6 Using multipacks 22
6.7 Menu structure 23
7 Using your phone 28
7.1 Make a call 28
7.1.1 Predialling 28
7.1.2 Direct dialling 28
7.1.3 Call from redial list 28
7.1.4 Call from the call log 28
7.1.5 Call from the phonebook 28
7.1.6 Call from the phonebook
while already on the phone 28
7.1.7 Call using Direct Access
Memory 29
7.1.8 Enter a Dialing Pause 29
7.2 Answer a call 29
7.2.1 Handsfree answering 29
7.3 End a call 29
8Use more of
your phone 30
8.1 Switch the handset off/on 30
8.2 Keypad lock/unlock 30
Table of contents
01GB01COV.book Page 1 Thursday, July 3, 2008 9:27 AM
2Table of contents
8.3 Text or number entry 30
8.4 Call in progress 30
8.4.1 Adjust earpiece or speaker
volume 30
8.4.2 Mute/Unmute microphone 30
8.4.3 Activate/Deactivate
loudspeaker mode 30
8.5 Chain dialing 31
8.6 Using your Phonebook 31
8.6.1 Store a contact in the
phonebook 31
8.6.2 Access phonebook 31
8.6.3 Modify a phonebook entry 32
8.6.4 Select phonebook melody 32
8.6.5 Delete a phonebook entry 33
8.6.6 Delete all phonebook
entries 33
8.6.7 Direct Access Memory 33
8.7 Using the Redial list 34
8.7.1 Access Redial list 34
8.7.2 View redial number details 34
8.7.3 Save a redial number into
the phonebook 34
8.7.4 Delete a redial number 35
8.7.5 Delete all redial numbers 35
8.8 Call waiting 35
8.9 Using the Call log 35
8.9.1 Access the Call log 35
8.9.2 Save call list entry into the
phonebook 36
8.9.3 Delete a call list entry 37
8.9.4 Delete all call list entries 37
8.10 Using the Intercom 37
8.10.1 Intercom another handset 37
8.10.2 Transfer an external call to
another handset 37
8.10.3 Answer an external call
during intercom 38
8.10.4 Switch between an internal
and external call 38
8.10.5 Establish a three-party
conference call 38
8.11 Handset locator 38
8.12 Clock and Alarm settings 39
8.12.1 Set Date and Time
39
8.12.2 Set Time and Date Format
39
8.12.3 Set Alarm
39
8.12.4 Set Alarm Tone
40
9 Personal settings 40
9.1 Change the Handset Name 40
9.2 Handset Tones 40
9.2.1 Set the Ring Volume 40
9.2.2 Set the Ring Tones 41
9.2.3 Activate/Deactivate
Key Beep 41
9.3 Change the
Display Language 41
9.4 Select the
Display Wallpaper 41
9.5 Select the Color Theme 42
9.6 Set the Display Contrast 42
9.7 Set the Backlight Time 42
9.8 Deactivate/Activate Auto
Hang-Up 42
10 Advanced settings 43
10.1 Easy Call 43
10.1.1 Set Easy Call to On or Off 43
10.1.2 Set Easy Call number 43
10.2 Auto Conference 44
10.3 Call Barring 44
10.3.1 Set Call Barring Mode 44
10.3.2 Set a Call Barring number 44
10.4 XHD Sound 45
10.5 Change PIN 45
10.6 Registration 45
01GB01COV.book Page 2 Thursday, July 3, 2008 9:27 AM
3
Table of contents
10.6.1 Easy registration 46
10.7 Unregister 46
10.8 Reset Unit 46
10.9 Set Area Code 47
10.10 Set Auto Prefix 47
10.11 Change Flash time 48
10.12 Change the Dial Mode 48
10.13 Set First Ring Detection 48
10.14 Default Settings 49
11 Network Service 49
11.1 Call Forward 50
11.1.1 Change Call Forward
Activation Codes 50
11.1.2 Change Call Forward
Deactivation Code 50
11.2 Call Forward when Busy 51
11.2.1 Change Call Forward when
Busy Activation Codes 51
11.2.2 Change Call Forward when
Busy Deactivation Code 52
11.3 Call Forward when
Unanswered 52
11.3.1 Change Call Forward when
Unanswered Activation
Codes 52
11.3.2 Change Call Forward when
Unanswered Deactivation
Code 53
11.4 Voice Mail 53
11.4.1 Access Voice Mail 53
11.4.2 Set Voice Mail Number 53
11.5 Voice Mail 2 53
11.6 Information Service 53
11.6.1 Access Info Service 54
11.6.2 Set Info Service Number 54
11.7 Information Service 2 54
11.8 Call Return 54
11.8.1 Access the Call Return
Service 54
11.8.2 Set Call Return Service
Number 54
11.9 Cancel Call Back 54
11.9.1 Call the Cancel Call Back
Number 55
11.9.2 Set the Cancel Call Back
Number 55
11.10 Withhold ID 55
11.10.1 Activating Withhold ID
55
11.10.2 Set the Withhold ID Code
55
12 Technical data 56
13 Frequently asked
questions 56
13.1 Connection 56
13.2 Set-up 57
13.3 Sound 57
13.4 Product behavior 57
15 INDEX 59
01GB01COV.book Page 3 Thursday, July 3, 2008 9:27 AM
4Important Safety Instructions
1Important Safety
Instructions
Some of the following information may
not apply to your particular product;
however, when using telephone
equipment, basic safety precautions
should always be followed to reduce the
risk of fire, electric shock and injury to
persons, including the following:
1Read and understand all
instructions.
2Follow all warnings and instructions
marked on the product.
3Unplug this product from the wall
outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
4Telephones should not be used
while you are in a bathtub, shower
or pool. Immersion of the
telephone or handset in water could
cause an electrical shock.
5Slots and openings in the cabinet
back or bottom are provided for
ventilation, to protect it from
overheating.These openings must
not be blocked or covered. The
openings should never be blocked
by placing the product on the bed,
sofa, rug, or other similar
surface.This product should not be
placed in a built-in installation unless
proper ventilation is provided.
6This product should be operated
only from the type of power source
indicated on the marking label. If
you are not sure of the type of
power supply to your home, consult
your dealer or local power
company.
7Do not allow anything to rest on
the power cord. Do not locate this
product where the cord will be
abused by persons walking on it.
8Do not overload wall outlets and
extension cords as this can result in
the risk of fire or electric shock.
9Never push objects of any kind into
this product through cabinet slots as
they may touch dangerous voltage
points or short out parts that could
result in a risk of fire or electric
shock.
Never spill liquid of any kind on the
product.
10 To reduce the risk of electric shock,
do not disassemble this product, but
take it to a qualified service
personnel when service or repair
work is required. Opening or
removing covers may expose you to
dangerous voltages or other risks.
Incorrect reassembly can cause
electric shock when the appliance is
subsequently used.
11 Do not expose the product to
extreme temperatures such as areas
near a hot radiator or stove or in a
hot car.
12 Do not place lighted candles,
cigarettes, cigars, etc., on the
telephone.
13 Never touch uninsulated telephone
wires or terminals unless the
01GB01COV.book Page 4 Thursday, July 3, 2008 9:27 AM
5
Important Safety Instructions
telephone line has been
disconnected at the network
interface.
14 Never install or modify telephone
wiring during a lightning storm.
15 Never install telephone jacks in wet
locations unless the jack is
specifically designed for wet
locations.
16 Use caution when installing or
modifying telephone lines to
prevent electrical shock and/or fire.
17 Unplug this product from the wall
outlet and refer servicing to
qualified service personnel under
the following conditions:
AWhen the power supply cord or
plug is damaged or frayed.
BIf the product has been exposed to
rain or water.
CIf the product does not operate
normally by following the operating
instructions.
DIf the product’s cabinet has been
damaged.
EIf the product exhibits a distinct
change in performance.
18 Avoid using a telephone (other than
a cordless type) during an electrical
storm. There may be a remote risk
of electric shock from lightning.
19 Do not use the telephone to report
a gas leak in the vicinity of the leak.
20 Do not place this product on an
unstable cart, stand or table.The
product may fall, causing serious
damage to the product.
IF YOUR PRODUCT UTILIZES
BATTERIES,THE FOLLOWING
ADDITIONAL PRECAUTIONS
SHOULD BE OBSERVED:
1Use only the type and size of
battery(ies) specified in the user
manual.
2Do not dispose of the battery(ies)
in fire. They may explode. Check
with local codes for possible special
disposal instructions.
3Do not open or mutilate the
battery(ies). Released electrolyte is
corrosive and may cause damage to
the eyes or skin. It may be toxic if
swallowed.
4Exercise care in handling
battery(ies) in order not to short
out the battery(ies) with conducting
materials such as rings, bracelets,
and keys.The battery(ies) or
conductor may overheat and cause
burns.
5Do not attempt to recharge the
battery(ies) provided with or
identified for use with this product
that are not intended to be
charged.The battery(ies) may leak
corrosive electrolyte or explode.
6Do not attempt to rejuvenate the
battery(ies) provided with or
identified for use with this product
by heating them. Sudden release of
the battery(ies) electrolyte may
occur causing burns or irritation to
eyes or skin.
7When replacing battery(ies), all
batteries should be replaced at the
same time. Mixing fresh and
discharged batteries could increase
internal cell pressure and rupture
01GB01COV.book Page 5 Thursday, July 3, 2008 9:27 AM
6Environment and safety
the discharged battery(ies). (Applies
to products employing more than
one separately replaceable primary
battery.)
8When inserting battery(ies) into
this product, the proper polarity or
direction must be observed.
Reverse insertion of battery(ies) can
cause charging, and that may result
in leakage or explosion.
9Remove battery(ies) from this
product if storing over 30 days
because the battery(ies) could leak
and damage the product.
10 Discard “dead” battery(ies) as soon
as possible since “dead” batteries
are more likely to leak in a product.
11 Do not store this product, or the
battery(ies) provided with or
identified for use with this product,
in high temperature areas.
Batteries that are stored in a freezer
or refrigerator for the purpose of
extending shelf life should be
protected from condensation during
storage and defrosting. Batteries
should be stabilized at room
temperature prior to use after cold
storage.
12 If your product uses rechargeable
battery(ies), charge the battery(ies)
only in accordance with the
instructions and limitation specified
in the User Manual.
SAVE THESE INSTRUCTIONS
2 Environment and
safety
2.1 Safety information
This telephone is not designed for
making emergency telephone calls when
the power fails. An alternative should be
made available for access to emergency
calling.
2.2 Power requirements
This product requires an electrical supply
of 120 volts, single phase alternating
current, excluding IT installations defined
in standard UL 60950.
2.3 Battery requirements
The handset requires power source of
two rechargeable NiMH batteries, size
AAA 1.2V 600mAh (Hr11/45). IF THE
INCORRECT TYPE OF BATTERIES ARE
USED,A WARNING MESSAGE WILL BE
DISPLAYED.
Use only Philips Multi-Life 600mAh
rechargeable NimH batteries.
For servicing or replacement, you can
purchase a suitable headset through
service centre or retail shop.
2.4 Telephone connection
The voltage on the network is classified
as TNV- 3 (Telecommunication Network
Voltages, as defined in the standard UL
01GB01COV.book Page 6 Thursday, July 3, 2008 9:27 AM
7
Environment and safety
60950). Following a power cut, the call in
progress is lost.
Users should ensure for their own
protection that the electrical ground
connections of the power utility,
telephone lines and internal metallic
water pipe system, if present, are
connected together. This precaution may
be particularly important in rural areas.
2.5 Environmental care
Please remember to observe the local
regulations regarding the disposal of your
packaging materials, exhausted batteries
and old phone and where possible
promote their recycling.
2.6 Precautions
• Do not allow the handset to come
into contact with liquids or moisture.
• Do not open the handset, base station
or charger.This could expose you to
high voltages.
• Do not allow the charging contacts of
the charger or the battery to come
into contact with extraneous
conductive materials.
• There is a slight chance that the
telephone could be damaged by an
electrical storm. It is recommended
that users unplug the phone from the
USB socket and the phone line from
the phone wall socket during a storm.
• Because the phone works by sending
radio signals between the base unit
and the handset, wearers of hearing
aids may experience interference in
the form of a humming noise.
• We advise that this phone should not
be used near intensive care medical
equipment, nor by persons with
pacemakers.
• Your phone can interfere with
electrical equipment such as
answering machines, TV and radio
sets, clock radios and computers if
placed too close. It is recommended
that you position the base unit at least
one meter from such appliances.
Use only the mains adapter supplied with
this telephone. Incorrect adapter polarity
or voltage can seriously damage the unit.
Base adapter:
Input: 100 V - 240 VAC 50/60 Hz
Output: 6 VDC 500 mA
Charger adapter:
Input: 100 V - 240 VAC 50/60 Hz
Output: 6 VDC 210 mA
RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE.
Never use non-rechargeable batteries;
use recommended type supplied with
this telephone. NiMH batteries must be
disposed of in accordance with the
applicable waste disposal regulations.
FCC CERTIFICATION NUMBER IS
LOCATED ON THE CABINET
BOTTOM
The term “IC:” before the certification
number signifies that Industry Canada
technical specifications were met.This
certification means that the equipment
Caution
Caution
Caution
01GB01COV.book Page 7 Thursday, July 3, 2008 9:27 AM
8Environment and safety
meets certain radio communications and
operational requirements.
2.7 Equipment Approval
Information
Your telephone equipment is approved
for connection to the public switched
telephone network and is in compliance
with parts 15 and 68, FCC Rules and
Regulations and the Technical
Requirements for Telephone Terminal
Equipment published by ACTA.
2.7.1 Notification to the Local
Te l e p h o n e C o m p a n y
On the bottom of this equipment is a
label indicating, among other
information, the US number and Ringer
Equivalence Number (REN) for the
equipment.You must, upon request,
provide this information to your
telephone company.
The REN is useful in determining the
number of devices you may connect to
your telephone line and still have all of
these devices ring when your telephone
number is called. In most (but not all)
areas, the sum of the RENs of all devices
connected to one line should not exceed
5. To be certain of the number of devices
you may connect to your line as
determined by the REN, you should
contact your local telephone company.
A plug and jack used to connect this
equipment to the premises wiring and
telephone network must comply with the
applicable FCC Part 68 rules and
requirements adopted by the ACTA.
A compliant telephone cord and modular
plug is provided with this product. It is
designed to be connected to a
compatible modular jack that is also
compliant. See installation instructions
for details.
Notes
• This equipment may not be used on
coin service provided by the
telephone company.
• Party lines are subject to state tariffs,
and therefore, you may not be able to
use your own telephone equipment if
you are on a party line. Check with
your local telephone company.
• Notice must be given to the
telephone company upon permanent
disconnection of your telephone from
your line.
• If your home has specially wired alarm
equipment connected to the
telephone line, ensure the installation
of this product does not disable your
alarm equipment. If you have
questions about what will disable
alarm equipment, consult your
telephone company or a qualified
installer.
2.7.2 Rights of the Phone
Company
Should your equipment cause trouble on
your line which may harm the telephone
network, the telephone company shall,
where practicable, notify you that
01GB01COV.book Page 8 Thursday, July 3, 2008 9:27 AM
9
Environment and safety
temporary discontinuance of service may
be required.Where prior notice is not
practicable and the circumstances
warrant such action, the telephone
company may temporarily discontinue
service immediately. In case of such
temporary discontinuance, the telephone
company must:
(1) promptly notify you of such
temporary discontinuance; (2) afford you
the opportunity to correct the situation;
and (3) inform you of your right to bring
a complaint to the Commission pursuant
to procedures set forth in Subpart E of
Part 68, FCC Rules and Regulations.
The telephone company may make
changes in its communications facilities,
equipment, operations or procedures
where such action is required in the
operation of its business and not
inconsistent with FCC rules and
Regulations. If these changes are
expected to affect the use or
performance of your telephone
equipment, the telephone company must
give you adequate notice, in writing, to
allow you to maintain uninterrupted
service.
2.8 Interference Information
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful
interference; and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to Part 15
of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation.
If this equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna (that is, the antenna for radio
or television that is “receiving” the
interference).
• Reorient or relocate and increase the
separation between the
telecommunications equipment and
receiving antenna.
• Connect the telecommunications
equipment into an outlet on a circuit
different from that to which the
receiving antenna is connected.
If these measures do not eliminate the
interference, please consult your dealer
or an experienced radio / television
technician for additional suggestions.
Also, the Federal Communications
01GB01COV.book Page 9 Thursday, July 3, 2008 9:27 AM
10 Important
Commission has prepared a helpful
booklet, “How To Identify and Resolve
Radio/TV Interference Problems”. This
booklet is available from the U.S.
Government Printing Office,
Washington, D.C. 20402.
Please specify stock number 004-000-
00345-4 when ordering copies.
Notice: The changes or modifications
not expressly approved by the party
responsible for compliance could void
the user’s authority to operate the
equipment.
2.9 Hearing Aid Compatibility
(HAC)
This telephone system meets FCC and
Industry Canada standards for Hearing
Aid Compatibility.
2.10 FCC RF Radiation Exposure
Statement
This equipment complies with FCC RF
radiation exposure limits set forth for an
uncontrolled environment.This
equipment should be installed and
operated with a minimum distance of
20 centimeters between the radiator and
your body.This transmitter must not be
co-located or operating in conjunction
with any other antenna or transmitter.
For hand held operation, this phone has
been tested and meets the FCC RF
exposure guidelines. Use of other
accessories may not ensure compliance
with FCC RF exposure guidelines.
3Important
Take time to read this user manual
before you use your phone. It contains
important information and notes
regarding your phone.
NOTICE: This product meets the
applicable Industry Canada technical
specifications.
The equipment must be installed using an
acceptable method of connection. The
customer should be aware that
compliance with the above conditions
may not prevent degradation of service
in some situations.
Repairs to certified equipment should be
made by an authorized Canadian
maintenance facility designated by the
supplier. Any repairs or alterations made
by the user to this equipment, or
equipment malfunctions, may give the
telecommunications company cause to
request the user to disconnect the
equipment.
Users should ensure for their own
protection that the electrical ground
connections of the power utility,
telephone lines and internal metallic
water pipe systems, if present, are
connected together. This precaution may
be particularly important in rural areas.
CAUTION: Users should not attempt to
make such connections themselves, but
should contact the appropriate electric
inspection authority, or electrician, as
appropriate.
01GB01COV.book Page 10 Thursday, July 3, 2008 9:27 AM
11
Important
NOTES: This equipment may not be used
on coin service provided by the
telephone company.
3.1 Power requirements
• This product requires an electrical
supply of 100-240 volts AC. In case of
power failure, the communication can
be lost.
• The Electrical network is classified as
hazardous. The only way to power
down the charger is to unplug the
power supply from the electrical
outlet. Ensure that the electrical
outlet is always easily accessible.
• The voltage on the network is
classified as TNV-3
(Telecommunication Network
Voltages), as defined in the standard
UL 60950.
To avoid damage or malfunction:
• Do not allow the charging contacts or
the battery to come into contact with
metal objects.
• Do not open it as you could be
exposed to high voltages.
• Do not allow the charger to come
into contact with liquids.
• Never use any other battery than the
one delivered with the product or
recommended by Philips: risk of
explosion.
• Always use the cables provided with
the product.
• Handsfree activation could suddenly
increase the volume in the earpiece to
a very high level: make sure the
handset is not too close to your ear.
• This equipment is not designed to
make emergency calls when the
power fails. An alternative has to be
made available to allow emergency
calls.
• Do not expose the phone to
excessive heat caused by heating
equipment or direct sunlight.
• Do not drop your phone or allow
objects to fall on your phone.
• Do not use any cleaning agents
containing alcohol, ammonia, benzene,
or abrasives as these may harm the
set.
• Do not use the product in places
where there are explosive hazards.
• Do not let small metal objects come
into contact with the product. This
can deteriorate audio quality and
damage the product.
• Active mobile phones in the vicinity
may cause interference.
About operating and storage
temperatures:
• Operate in a place where
temperature is always between 0 and
35º C (32 to 95º F).
• Store in a place where temperature is
always between -20 and 70º C (-4 to
158º F).
• Battery life may be shortened in low
temperature conditions.
Warning
01GB01COV.book Page 11 Thursday, July 3, 2008 9:27 AM
12 The RBRC® seal
3.2 Electric, Magnetic and
Electromagnetic Fields
(“EMF”)
1. Philips Royal Electronics
manufactures and sells many
consumer oriented products which
usually, as with any electronic
apparatus, have the ability to emit
and receive electro magnetic signals.
2. One of Philips’ leading Business
Principles is to take all necessary
health and safety precautions for
our products, to comply with all
applicable legal requirements and to
stay well within the EMF standards
applicable at the time of producing
the products.
3. Philips is committed to develop,
produce and market products that
cause no adverse health effects.
4. Philips confirms that if its products
are handled properly for their
intended use, they are safe to use
according to scientific evidence
available today.
5. Philips plays an active role in the
development of international EMF
and safety standards, enabling Philips
to anticipate further developments
in standardisation for early
integration in its products.
3.3 Recycle your batteries
Do not dispose your rechargeable
batteries. Call the toll fee number 1-800-
822-8837 to get instructions on how to
recycle your batteries.
4 The RBRC® seal
The RBRC® Seal
on the nickel metal
hydride battery
indicates that
Philips Royal
Electronics is
voluntarily
participating in an industry program to
collect and recycle these batteries at the
end of their useful lives, when taken out
of service within the United States and
Canada.
The RBRC® program provides a
convenient alternative to placing used
nickel metal hydride batteries into the
trash or municipal waste, which may be
illegal in your area.
Philips’s participation in RBRC® makes it
easy for you to drop off the spent battery
at local retailers participating in the
RBRC® program or at authorized Philips
product service centers.
Please call 1-800-8-BATTERY for
information on Ni-MH battery recycling
and disposal bans/restrictions in your
area. Philips’s involvement in this
program is part of its commitment to
protecting our environment and
conserving natural resources.
RBRC® is a registered trademark of
Rechargeable Battery Recycling
Corporation.
01GB01COV.book Page 12 Thursday, July 3, 2008 9:27 AM
13
The RBRC® seal
4.1 Service Centers
US service center
Philips Accessories & Computer
Peripherals North America1881 Route
46 WestLedgewood, NJ 07852
Phone: (800) 233-8413
E-mail support:
http://www.support.philips.com/support
01GB01COV.book Page 13 Thursday, July 3, 2008 9:27 AM
14 Yo u r p h o n e
5 Your phone
Congratulations on your purchase and welcome to Philips!
To fully benefit from the support that Philips offers, register your product at
www.philips.com/welcome.
5.1 What’s in the box
In multihandset packs, you will find one or more additional handsets, chargers with power
supply units and additional rechargeable batteries.
Handset with belt clip Base Station with bracket Battery door
2 AAA rechargeable
batteries
Power supply Line cord
User manual Guarantee
Do not return
leaflet
Quick Start
Guide
Note
01GB01COV.book Page 14 Thursday, July 3, 2008 9:27 AM
15
Yo u r p h o n e
5.2 Overview of your phone
AEvent LED
If you have subscribed to Caller Line
Identification, the event LED also blinks
when there is a new call, or a new voice
mail message.
BEarpiece
CDisplay
See section 5.3 for an overview of the
display icons.
D Select key o
Select the function displayed on the
screen or go to the next lower level in a
menu. Also used to confirm entries (for
example when setting date and time).
EBack/Clear key c
Press to clear (delete) a character or
number when making an entry. Long
press to clear all.
When navigating menus, press to move
to the previous higher menu level (Back
is displayed).
F Navigation keys n
In idle mode: Scroll up u to access the
Call log and scroll down d to access
the Phonebook.
During a call: Scroll n to increase or
decrease earpiece and speaker volume.
Editing and entry: Move to the previous
character u or next character d.
In other modes: Scroll up u and down
d a menu list or go to the previous
or next record in the Phonebook, Redial
list, or Call log.
GTalk key t
In idle mode: Make an external call or
answer an incoming external or internal
call.
During a call: Activate the flash function.
In other modes: Dial the selected
number in the Phonebook, Redial list, or
Call log.
H Hang-up/Exit key h
In idle mode: Long press (5 seconds) to
switch off the handset.
When the handset is switched off: Long
press (1 second) to switch it on.
During a call: Hang up a call.
In other modes: Press to return to idle
mode.
C
E
D
G
H
F
B
A
01GB01COV.book Page 15 Thursday, July 3, 2008 9:27 AM
16 Yo u r p h o n e
IMenu key m
In idle mode: Go to the main menu.
JRedial key r
Access the Redial list in idle mode.
KLoudspeaker key l
In idle mode: Turn on the loudspeaker
and dial the number. Answer an incoming
call using handsfree mode.
During a call: Toggle the loudspeaker on/
off.
L Number keys
Use to dial numbers and write characters.
With key 1, a long press dials your
voice mail subscriber access number.
With keys 3 to 9, a long press dials
one of your direct memory access
numbers.
M */Keypad lock & Format key *
In idle mode: Long press to lock/ unlock
keypad.
Predialling or editing: Press to enter a “*”.
Off hook: Long press to temporarily
switch to tone (DTMF) dialling if using
pulse.
During call log display: Toggles area code
and long distance display on/off.
N #/Ringer on/off & Pause key #
In idle mode: Long press to turn the
ringer on/off.
Dialling or editing: Long press to insert a
pause (during predialling) and short press
to insert a “#”.
Editing: Short press to switch upper/
lower case.
OMute key s
When off hook: Deactivate/activate the
microphone.
P Call transfer key & Intercom
key i
In idle mode: Initiate an internal call.
During a call: Short press to hold the line
and page another handset. Long press to
set up a conference between an external
call and two handsets.
Q Microphone
RBelt clip
S Loudspeaker (underneath the
belt clip)
Handsfree activation can suddenly
increase the volume of the earpiece to a
very high level. Make sure the handset is
not too close to your ear.
T Headset jack
U Battery door
Warning
S
T
R
U
J
N
P
I
M
O
L
K
Q
01GB01COV.book Page 16 Thursday, July 3, 2008 9:27 AM
17
Yo u r p h o n e
5.3 Display icons and Messages
Indicates that the battery is fully
charged. This icon blinks during
charge and when the battery is
low.
When the Icon is empty the
battery is practically discharged.
If
Warning Batt
flashes together
with a blinking battery icon,
batteries of the wrong type are
installed in the handset. Replace
with batteries of the correct type.
Blinks when there is an incoming
call. Steady On during a call.
Blinks when there is new voice
mail.
Indicates new and missed calls
in the call log records. Blinks
when there are missed calls.
Appears when the alarm clock
is activated. Blinks when the
alarm time comes.
Appears when the loudspeaker
is activated.
Appears when the ringer is off.
Note
Indicates that the handset is
registered and within range of
the base station. Icon blinks
when the handset is out of
range or is searching for a base.
Select/
OK
Select appears when in menu
mode. Press the key directly
below to move to the next
menu level or to confirm a
selection.
OK appears to request
confirmation of an operation.
Press the key directly below to
confirm.
Indicates that more options are
available in a scroll list, or that
you can adjust the volume.
Back/
Clear
Back appears when in menu
mode. Press the key directly
below to return to the previous
menu level.
Clear appears when making an
entry. Press the key directly
below to clear (delete) a
character or number when
making an entry. Long press to
clear all.
01GB04C02.fm Page 17 Friday, July 4, 2008 11:22 AM
18 Yo u r p h o n e
5.4 Overview of the base station
APaging key a
Page handset.
Long press to start registration
procedure.
A
01GB04C02.fm Page 18 Friday, July 4, 2008 2:29 PM
19
Getting started
6 Getting started
6.1 Connect the base station
1Place the base station in a central
location near the telephone line
socket and electricity socket.
2Connect the line cord and the
power cable to their corresponding
connectors at the back of the base
station.
3Connect the other end of the line
cord and power cable to their
respective sockets .
The line adaptor may not be attached to
the line cord. In this case, you have to
connect the line adaptor to the line cord
first before plugging the line cord to the
line socket.
Avoid placing the base station too close
to large metal objects such as filing
cabinets, radiators or electrical
appliances. This can impair the range and
sound quality. Buildings with thick
internal and external walls may impair
transmission of signals to and from the
base.
Power is applied when the power
adaptor is plugged into the unit and
connected to the electricity socket. The
only way to power down the unit is to
unplug the power adaptor from the
electricity socket. Therefore, ensure that
the electricity socket is easily accessible.
The power adaptor and telephone line
cord have to be connected correctly, as
incorrect connection could damage the
unit. Always use the telephone line cord
supplied with the unit. Otherwise, you
may not get a dial tone.
6.2 Wall mounting the base
The base is designed to support wall
mounting. To wall mount the base, follow
the instructions below.
1Remove the bracket from the back
of the base station by ➀ pressing
the two latches on the inside of the
Note
Warning
Warning
01GB04C02.fm Page 19 Thursday, July 3, 2008 2:10 PM
20 Getting started
bracket and ➁ rotating the bracket
outward.
2Turn the bracket around.
3Attach the bracket to the opposite
side of the base station.
4Use the pedestal wall mounting to
plug your base station.
6.3 Install your phone
Before using the handset, the batteries
have to be installed and fully charged.
When the batteries are inserted for the
first time, the unit will not be able to
start normally due to the low battery.
You must charge the batteries on the
base station before you can use the
handset.
6.3.1 Install battery
Always use AAA rechargeable batteries
supplied with your unit. If alkaline
batteries are used instead of
rechargeable batteries, “Warning
Batt” will show on the display and the
battery icon will blink quickly.
1Slide out the battery cover.
Warning
Warning
5.20
5.20
17.00
83.00
01GB01COV.book Page 20 Thursday, July 3, 2008 9:27 AM
21
Getting started
2Place the batteries in the correct
polarity as indicated and replace the
cover.
6.3.2 Charge battery
The handset must be charged for at least
24 hours before using it for the first time.
When the battery level becomes low, the
low battery sensor warns you by blinking
the battery icon. If this occurs during a
conversation, an alert tone sounds to
inform you that the battery is low. If the
battery level becomes exceedingly low,
the phone automatically switches off
shortly after the icon starts blinking and
any function in progress will not be
saved.
1Place the handset on the charging
cradle of the base station. A beep is
emitted if the handset is placed
correctly.
2The battery icon on the display
blinks during charge.
3
The battery icon becomes steady
when the handset is fully charged.
Optimal battery life is reached after 3
cycles of complete charging (over 15
hours) and discharging, allowing
approximately 12 hours of talk-time and
150 hours of stand-by time.
The indoor and outdoor range of the
phone is up to 50 metres and 300 metres
respectively. When the handset moves
beyond the operation range, the antenna
icon will blink.
When you reach the range limit the
conversation may become crackly. Move
closer to the base.
6.4 Remove/Attach belt clip
A belt clip allows you to carry your
handset on your belt.
1To remove the belt clip, simply pull
the clip away from the handset.
2To attach the belt clip to your
handset, fit the tabs on the belt clip
into the slots at the back of the
handset and push into place.
Warning
Note
Tip
01GB01COV.book Page 21 Thursday, July 3, 2008 9:27 AM
22 Getting started
6.5 Install optional headset
Your phone may be used with an optional
headset (not included in the box). To use
this feature, insert the headset plug into
the headset jack. Your phone is ready for
hands-free conversations.
6.6 Using multipacks
If you have purchased a multipack you
will have additional handsets, chargers,
power adaptors and AAA rechargeable
batteries.
1Plug the chargers into a power
socket.
2Install the batteries supplied into the
handsets.
3Place the handsets on the chargers
to charge the batteries.
Diameter: 2.5 mm
01GB01COV.book Page 22 Thursday, July 3, 2008 9:27 AM
23
Getting started
6.7 Menu structure
The SE450 has five menus as shown in the following table.
Press the menu key m to enter menu mode. Use navigation keys n to navigate
within the menus and all submenus.
Press oSelect to enter the next lower menu level. Press cBack to go to the
previous menu level.
The charts below show the menu trees of your phone.
Phonebook
Menu Name Icon
1 Phonebook
2 Personal Settings
3 Clock and Alarm
4 Advanced Settings
5 Network Services
Phonebook New Entry Enter Name: Enter Number:
List
Entry list displayed
Edit Entry
Select Melody
Entry list displayed
Melody details List of melodies
for selected entry
Delete
Entry list displayed
Delete?
Delete All Delete All?
Direct Memory
Key list and status
Edit
Delete
01GB01COV.book Page 23 Thursday, July 3, 2008 9:27 AM
24 Getting started
Personal S ettings
Personal Set Handset Name Enter name
Handset Tones Ring Volume No bar (off)
One bar
…
Five bars
Progressive
Ring Tones Name of tones 1
…
Name of tones 15
Key Beep On
Off
Language List of languages
Wallpaper Wallpaper 1
Wallpaper 2
Wallpaper 3
Wallpaper off
Color Theme Color 1
…
Color 4
Contrast Level 1
…
Level 5
Backlight Time 20 Seconds
40 Seconds
60 Seconds
Auto Hang-up On
Off
01GB01COV.book Page 24 Thursday, July 3, 2008 9:27 AM
25
Getting started
Clock and Alarm
Clock & Alarm Set Date/Time Enter date & time
Set Format Time Format 12 Hours
24 Hours
Date Format DD/MM
MM/DD
Alarm Off
On Once
On Daily
Alarm Tone Melody 1
Melody 2
Melody 3
01GB01COV.book Page 25 Thursday, July 3, 2008 9:27 AM
26 Getting started
Advanced Settings
Advanced Set Easy Call Mode On Enter Number:
Off
(by default)
Number Enter number
Conference
On (by default)
Off
Call Barring Enter PIN Mode On
Off
(by default)
Number Number 1
…
Number 4
XHD Sound On
(by default)
Off
Change PIN
Register
Unregister
Reset Reset?
Area Code Enter number
Auto Prefix Detect Digit: Prefix
Flash Time Short
Long
Dial Mode Tone
Pulse
First Ring On
Off
01GB01COV.book Page 26 Thursday, July 3, 2008 9:27 AM
27
Getting started
Network Services
Netw. Services Call Forward Activate Enter Number:
Deactivate
Change Code Activation
Prefix (enter code)
Suffix (enter code)
Deactivation Change Code
Call Fwd Busy Activate Enter Number:
Deactivate
Change Code Activation
Prefix (enter code)
Suffix (enter code)
Deactivation Change Code
Call Fwd Unans
Activate Enter Number:
Deactivate
Change Code Activation
Prefix (enter code)
Suffix (enter code)
Deactivation Change Code
Voicemail Call
Settings Enter Number
Voicemail 2 Call
Settings Enter Number
Info Call
Settings Enter Number
Info 2 Call
Settings Enter Number
Call Return Call
Settings Enter Number
Cancel Call BK
Call
Settings Enter Number
Withhold ID Activate
Settings Enter Number
01GB01COV.book Page 27 Thursday, July 3, 2008 9:27 AM
28 Using your phone
7 Using your phone
7.1 Make a call
7.1.1 Predialling
1Enter the number. (A maximum of
24 digits including * and # are
allowed. Press c Clear to delete
the last digit.) Or long press to
delete all.
2Press t.
• The call is initiated.
7.1.2 Direct dialling
1Pick up the handset and press t.
(Or press
l
to start a call in
speaker mode.)
2Dial the number.
• The call is initiated.
7.1.3 Call from redial list
1Press r in idle mode.
2Scroll n to an entry in the redial
list.
3Press t.
• The call is initiated.
• In multihandset packs, each handset
has its own redial list.
• You can also press t first and then
press c Redial to enter the redial
list. Then scroll n to select a number
in the list and press o Select. The
number is dialed automatically.
7.1.4 Call from the call log
• In multihandset packs, the call log is
shared between all handsets.
• You need to subscribe to Caller Line
Identification service to be able to see
the caller’s number or name in the call
log. See section 8.9.1 - “Access the
Call log”.
1Press u in idle mode, then scroll
n to an entry in the call list.
If the list is empty, then “List Empty” is
displayed.
2Press t.
• The call is initiated.
7.1.5 Call from the phonebook
1Press d in idle mode.
2Scroll n to a phonebook entry.
3Press t.
• The call is initiated.
Instead of scrolling n to browse the
phonebook entries, you can press the
numeric key corresponding to the first
letter of the entry you wish to locate.
For example, pressing 2 will show the
entries starting with A. Pressing 2 again
will show the entries starting with B, etc.
7.1.6 Call from the phonebook
while already on the phone
1While on the phone, press o
Option and then o Select to
enter the phonebook name list.
2Scroll n to a phonebook entry.
Note
Note
Note
Tip
01GB01COV.book Page 28 Thursday, July 3, 2008 9:27 AM
29
Using your phone
3Press o Select.
• The call is initiated.
7.1.7 Call using Direct Access
Memory
Press a number key 3 to 9 for more
than 2 seconds to dial a stored direct
access memory number.
• In multihandset packs, each handset
has its own direct access memories.
• See section 8.6.7 for instructions on
how to store, edit, and delete direct
access memory numbers.
7.1.8 Enter a Dialing Pause
Long press # to enter a pause in the
dialling sequence. The pause is indicated
by a P.
7.2 Answer a call
When the handset rings during an
incoming call, please do not hold the
handset too close to your ear as the
volume of the ringing tone may damage
your hearing.
When the phone rings, press the t
key.
• The call is established.
• Incoming call has priority over other
events. Whenever there is an
incoming call, other status in progress
such as phone setting, menu
navigation, etc will be aborted.
You can mute the ring tone of an
incoming call before answering by
pressing on c Silent.
7.2.1 Handsfree answering
Handsfree activation can suddenly
increase the volume in the earpiece to a
very high level. Make sure the handset is
not too close to your ear.
When the phone rings, press l.
• The handset loudspeaker is activated.
7.3 End a call
To end a conversation, press h.
•The call ends.
When auto hang-up is on, you can simply
place the handset back to its base station
or charger to end the call. This feature is
activated by default.
The call duration (MM:SS) will be
displayed on the handset screen for
about 5 seconds.
Note
Danger
Note
Tip
Danger
Tip
Note
01GB01COV.book Page 29 Thursday, July 3, 2008 9:27 AM
30 Use more of your phone
8 Use more of your
phone
8.1 Switch the handset off/on
To switch the handset off, press and hold
h in idle mode for at least 5 seconds.
To switch it on, press and hold h for at
least one second.
8.2 Keypad lock/unlock
Press and hold * for 3 seconds to lock/
unlock the keypad in idle mode.
8.3 Text or number entry
When you select a field in which you can
enter text, you can enter the letters that
are printed on the keys by pressing the
relevant key once or several times. For
example, to enter the name “PAUL”:
1Press 7 once: P
2Press 2 once: PA
3Press 8 twice: PAU
4Press 5 three times: PAUL
The table below gives you the character
assignment during text or number entry:
• Press c Clear to delete the last
digit or character entered or long
press to delete all.
• Short press # to shift between
lowercase and uppercase.
•Long press # to insert a pause.
8.4 Call in progress
Some options are available to you during
a call. The available options are :
8.4.1 Adjust earpiece or speaker
volume
During a call, press n to select from
level 1 to level 5.
8.4.2 Mute/Unmute microphone
When the microphone is muted, your
correspondent cannot hear you.
1During a call, press s to turn off
the microphone.
2Press s again to turn on the
microphone.
8.4.3 Activate/Deactivate
loudspeaker mode
Handsfree activation can suddenly
increase the volume in the earpiece to a
Keys Assigned characters
0. 0 , / : ; “ ‘ ! ¡ ? ¿ * + - % \ ^
~ |
1SPACE 1 @ _ # = < > ( ) &
€ £ $ ¥ [ ] { } ¤ § ...
2a b c 2 à æ ä å
3d e f 3 è é Δ Φ
4g h i 4 ì Γ
5j k l 5 Λ
6m n o 6 ñ ö ò
7p q r s 7 ß Π Θ Σ
8t u v 8 ù ü
9w x y z 9 ø Ω Ξ Ψ
Tip
Danger
Keys Assigned characters
01GB01COV.book Page 30 Thursday, July 3, 2008 9:27 AM
31
Use more of your phone
very high level. Make sure the handset is
not too close to your ear.
1During a call, press l to activate
the loudspeaker mode.
2Press l again to return to
deactivate the loudspeaker mode.
8.5 Chain dialing
This feature allows you to dial an
extension to a number already saved in
the phonebook during a call.
1Press t or l on the handset to
take the line. Then, press o
Option and then o Select to
enter the phonebook name list.
2Scroll n to a phonebook entry.
3Press o Select.
• The first part is dialed.
4Enter the extension.
8.6 Using your Phonebook
Your phone can store up to 100
phonebook memories. Each phonebook
entry can have a maximum of 24 digits
for the phone number and 14 characters
for the name.
All names and numbers in the
phonebook must be unique.
If you have more than one handset, the
phonebook can only be accessed by one
user at a time.
8.6.1 Store a contact in the
phonebook
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
2New Entry is highlighted; press
o Select.
3Enter Name is displayed. Enter
the name of the contact (maximum
14 characters) and press o OK.
4Enter Number is displayed. Enter
the number (maximum 24 digits)
and press o OK.
• A validation tone is emitted.
• Press c Clear to delete the last
digit or character entered or long
press to delete all.
• To return to the previous menu, press
c Back.
You cannot store a new phonebook
entry when the memory is full. In this
case, you have to delete existing entries
to make space for new entries.
8.6.2 Access phonebook
1Press d in idle mode and scroll
n to browse the phonebook. (You
can also access the phonebook
through the menu mode. m➝
Phonebook ➝ List)
• The phonebook entries will be
listed in alphabetical order.
2To view the details, press o
View.
Note
Note
Tip
01GB01COV.book Page 31 Thursday, July 3, 2008 9:27 AM
32 Use more of your phone
Instead of scrolling n to browse the
phonebook entries, you can press the
numeric key corresponding to the first
letter of the entry you wish to locate.
For example, pressing 2 will show the
entries starting with A. Pressing 2 again
will show the entries starting with B, etc.
3Press t to dial the number. (Press
h to return to idle mode.)
8.6.3 Modify a phonebook entry
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
2Scroll n to Edit Entry and press
o Select.
3Scroll n to select an entry to edit.
4Press o Select to display the
name.
5Press c Clear to erase the
letters one by one.
6Edit the name and press o OK to
confirm.
7Edit the number and press o OK
to confirm.
• A validation tone is emitted.
While editing, press c Clear to delete
the last digit or character entered or
long press to delete all.
8.6.4 Select phonebook melody
With this function you can personalize
the melody played when someone in the
phonebook calls you.
You need to subscribe to Caller Line
Identification service to be able to
benefit from this feature.
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
2Scroll n to Select Melody and
press o Select.
3Scroll n to the entry you want to
select a melody for, then press o
View.
4The screen shows the melody
currently selected for that entry.
Press o Change to change the
melody.
5Scroll n the list of melodies.
(There are 15 melodies plus No
Melody to choose from. The
melodies play as you scroll through
them.)
6Press o Select to select the
melody you prefer.
• A validation tone is emitted and
the screen returns to the
Phonebook menu.
When first ring detection is set On, a
normal tone sounds first, then it changes
to the personalized phonebook melody.
When it is set Off, the personalized
phonebook melody plays from the start.
See Section 10.13 for how to set first
ring detection On or Off.
Tip
Note
Note
Note
01GB01COV.book Page 32 Thursday, July 3, 2008 9:27 AM
33
Use more of your phone
8.6.5 Delete a phonebook entry
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
2Scroll n to Delete and press o
Select.
3Scroll n to select an entry to
delete and press o Select.
4Delete? is displayed on the screen.
Press o OK to confirm deletion.
• A validation tone is emitted.
Press c Back to discard the deletion.
The screen returns to the phonebook
list.
8.6.6 Delete all phonebook entries
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
2Scroll n to Delete All and press
o Select.
3Delete All? is displayed on the
screen. Press o OK to confirm
deletion.
• A validation tone is emitted.
8.6.7 Direct Access Memory
There are 7 direct access memories
(Keys 3 to 9) included in the
phonebook memory. A long press on the
keys in idle mode will automatically dial
the stored phone number.
Key 1 and key 2 are reserved for use
with Voicemail 1 and Voicemail 2 in the
network services menu. If you subscribe
to these services, this allows you to dial
your voice mail access numbers using key
1 or key 2.
8.6.7.1 Add/Edit Direct Access
Memory
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
2Scroll n to Direct Memory and
press o Select.
• The current number stored in
the direct access memory
location will be displayed. If no
number is stored, No number
will be displayed.
3Scroll n to the key you wish to
edit (Key 3 to Key 9) and press
o Menu.
4Scroll n to Edit and press o
Select.
5
The Phonebook list will be displayed.
Scroll
n
to the Phonebook entry
you wish to store in the selected
direct access memory number and
press
o
Select
.
6Press o OK to confirm.
• A validation tone is emitted and
the screen returns to the
previous menu.
Each handset has its own direct access
memories.
Note
Note
Note
01GB01COV.book Page 33 Thursday, July 3, 2008 9:27 AM
34 Use more of your phone
8.6.7.2 Delete Direct Access
Memory
1Press m in idle mode.
Phonebook is highlighted; press
o Select.
2Scroll n to Direct Memory and
press o Select.
3Scroll n to the key you wish to
delete the memory from and press
o Menu.
4Scroll n to Delete and press o
Select.
• A validation tone is emitted and
the screen returns to the
previous menu.
8.7 Using the Redial list
The redial list stores the last 10 numbers
dialed. A maximum of 32 digits can be
displayed for each entry.
8.7.1 Access Redial list
1Press r to go to the redial list and
scroll n to browse the redial list.
• The last number dialed will
appear first in the redial list. If
the redial number matches a
phonebook entry, the name will
be displayed instead.
2To open the redial list options, press
o Menu.
Press c Back to return to the
previous menu.
8.7.2 View redial number details
1Press r in idle mode, scroll n to
select an entry and press o
Menu.
2View is highlighted on the screen;
press o Select to display
information about the number
dialed.
3Press o Next to display further
information. Afterward, you can
press o Prev. to return to the
former screen. After viewing, press
c Back to return to previous
menu levels.
8.7.3 Save a redial number into the
phonebook
1Press r in idle mode, scroll n to
select an entry and press o
Menu.
2View is highlighted on the screen.
Scroll n to Save Number and
press o Select.
3Enter Name is displayed. Enter
the name of the contact (maximum
14 characters) and press o OK.
4Enter Number is displayed and
the selected number from the redial
list appears in the number field. At
this time you can edit the number if
you wish to.
5Press o OK. The screen returns
to the redial list.
Press c Clear to delete the last digit
or character entered. Long press c
Clear to clear the entire entry.
Note
Note
01GB01COV.book Page 34 Thursday, July 3, 2008 9:27 AM
35
Use more of your phone
8.7.4 Delete a redial number
1Press r in idle mode, scroll n to
select an entry and press o
Menu.
2Scroll n to Delete and press o
Select.
3Delete? is displayed on the screen.
4Press o OK to confirm deletion.
• A validation tone is emitted.
Press c Back to discard the deletion.
The screen returns to the previous
menu.
8.7.5 Delete all redial numbers
1Press r in idle mode, and press
o Menu.
2Scroll n to Delete All and press
o Select.
3Delete All? is displayed on the
screen.
4Press o OK to confirm deletion.
• A validation tone is emitted.
8.8 Call waiting
If you have subscribed to Call Waiting
services, the earpiece will emit a beep
tone to inform you that there is a second
incoming call. The number or name of
the second caller will also be displayed if
you have subscribed to Caller Line
Identification service (CLI). Please
contact your network provider for more
information on this service.
To answer the second call, press t.
8.9 Using the Call log
The call log stores the last 50 external
calls and any new voice mail received. In
idle mode, the icon flashes on the
display for new and unanswered calls. If
you have subscribed to Caller Line
Identification (CLI), and provided the
identity of the caller is not withheld, the
name (or number) of the caller will be
displayed.
During CLI display, you can press * to
toggle area code and long distance code
display on/off.
If the identity of the caller is witheld,
External Call is displayed in the call log
along with the date and time of the call. If
you have not subscribed to Caller Line
Identification service, there will not be
any caller information displayed in the call
log.
8.9.1 Access the Call log
1Press u in idle mode, and then
scroll n to browse the call log.
• The calls (missed and received)
are displayed in chronological
order with the most recent call
at the top of the list. If the call is
unviewed and unanswered, New
appears on the display. After you
view the message, New
disappears.
• Press t to dial out the number
of the selected call log entry.
2To view the call details, press o
Menu and then press o Select.
Note
Note
01GB01COV.book Page 35 Thursday, July 3, 2008 9:27 AM
36 Use more of your phone
The display shows the caller
information.
•Press c Back at any time to
return to the previous menu.
8.9.1.1 To choose the format for
call log display
You must choose the correct format to
dial the area code and number of the call
log record chosen. The original incoming
number from the call log will appear as a
7, 10 or 11-digit number. If it is a long
distance call, the prefix digit 1 will
automatically appear in front of the 10-
digit local calls.
1When viewing the call log, press *
to change the format of the call log
display as it should be dialed from
your location. For example, if the
call log entry appears as “234-567-
8900”:
•Press * once to display “1-234-
567-8900”
•Press * twice to display “567-
8900”
•Press * 3 times to display “1-
567-8900”
•Press * 4 times to display
“234-567-8900” again.
2To dial the current displayed
number, press t key.
• The call is initiated.
You need to subscribe to Caller Line
Identification service to be able to see
the caller’s number or name in the call
log (see section 8.9.1 - “Access the Call
log”).
When you store an incoming number in
the phonebook, the digits of the number
will be saved exactly as they appear on
the screen.
If the first 3 digits of the incoming
number corresponds to the local area
code set in your phone, they will be
filtered automatically when you press the
t or l key to dial. To change the
local area code, see section 10.9 - “Set
Area Code”.
8.9.2 Save call list entry into the
phonebook
1Press u in idle mode, and then
scroll n to select an entry and
press o Menu.
2Scroll n to Save Number and
press o Select.
3Enter Name is displayed on the
screen. Enter the name of the
contact (maximum 14 characters)
and press o OK.
4Enter Number is displayed and
the selected number from the call
list appears in the number field. At
this time you can edit the number if
you wish to.
5Press o OK.
• A confirmation tone sounds and
the screen returns to call log.
Press c Clear to delete the last digit
or character entered or long press to
delete all.
Note
Note
01GB01COV.book Page 36 Thursday, July 3, 2008 9:27 AM
37
Use more of your phone
8.9.3 Delete a call list entry
1Press u in idle mode, and then
scroll n to select an entry and
select o Menu.
2Scroll n to Delete and press o
Select.
3Delete? is displayed on the screen.
4Press o OK to confirm deletion.
• A validation tone is emitted, the
call list entry is deleted, and the
display goes to the next entry in
the call list.
Press c Back to discard the deletion.
The screen returns to the Call List
menu.
8.9.4 Delete all call list entries
1Press u in idle mode, and then
press o Menu.
2Scroll n to Delete All and press
o Select.
3Delete All? is displayed on the
screen. Press o OK to confirm
deletion.
• A validation tone is emitted. The
display shows List Empty for 2
seconds and returns to the idle
mode.
8.10 Using the Intercom
Intercom and call transfer is only possible
when you have at least 2 handsets
registered to the same base station.
It allows you to make free internal calls,
transfer external calls from one handset
to another and use the conference option.
8.10.1 Intercom another handset
If the handset does not belong to SE450/
455 range, this function may not be
available.
1Press i in idle mode.
• Intercom is established
immediately if there are only 2
registered handsets.
2If there are more than 2 registered
handsets, scroll n to select the
handset to call and press o OK.
• Once the intercom call is
initiated the icon is displayed
on the handset.
3Press t on the called handset.
• The intercom is established.
Pressing h on any handset will exit
intercom mode and return other
handsets to idle mode. If an external call
arrives during intercom mode and you
want to accept this call, you must first
exit intercom mode.
8.10.2 Transfer an external call to
another handset
1During the call, press i to put the
external call on hold (the caller can
no longer hear you).
• The display shows the numbers
of the handsets registered to the
base.
Note
Warning
Note
Note
01GB01COV.book Page 37 Thursday, July 3, 2008 9:27 AM
38 Use more of your phone
2Scroll n to the handset number
you wish to transfer your external
call to and press o Select.
3Press t on the called handset to
answer the internal call, where both
internal callers can talk.
• Intercom is established.
4Press h on the first handset to
transfer the external call to the
called handset.
• The external call is transferred.
If there is no answer from the called
handset, press i to resume the
external call.
8.10.3 Answer an external call
during intercom
1During intercom, a new call tone is
emitted when there is an incoming
external call.
2Press h to exit intercom mode.
3Press t to pick up the external
call.
8.10.4 Switch between an internal
and external call
During the call, press i to switch
between an internal or external call.
8.10.5 Establish a three-party
conference call
The conference call feature allows one
external call to be shared with two
handsets (in intercom). The three parties
can share the conversation and no
network subscription is required.
1During the call, press i to put the
external call on hold (the caller can
no longer hear you).
• The display shows the numbers
of the handsets registered to the
base.
2Scroll n to the number of the
handset you wish to establish the
conference call with and press o
Select.
3Press t on the called handset to
answer the internal call, where both
internal callers can talk.
• Intercom is established.
4Press c Conf. or long press i
on the first handset to start the
three-party conference.
•Conference will be displayed on
the screen once the conference
call is established.
8.11 Handset locator
The handset locator feature enables you
to locate a missing handset if the handset
is in range and contains charged
batteries.
1Press a on the base station.
• All the registered handsets start
to ring.
• Once a handset is found, press
c Silent on a handset to stop
its ringing.
2Press a again to end the handset
locator.
If there are no key presses within 30
seconds, the handset will automatically
return to idle mode.
Note
Note
01GB01COV.book Page 38 Thursday, July 3, 2008 9:27 AM
39
Use more of your phone
8.12 Clock and Alarm settings
This feature allows you to set the date,
time and alarm settings for your phone.
8.12.1 Set Date and Time
1Press m in idle mode, scroll n to
Clock & Alarm, and press o
Select.
2Set Date/Time is highlighted.
Press o Select.
3The last stored date and time are
displayed. Enter the current time
and current date (HH:MM DD/MM/
YY). Press u to move the cursor
left, or press d to move it right.
If using the 12 hour format, just
after setting the minutes, use * to
switch between AM and PM.
4Press o OK.
• A validation tone is emitted and
the screen returns to the idle
mode.
You can change the format as shown in
the next section.
8.12.2 Set Time and Date Format
8.12.2.1 Set Time Format
1Press m in idle mode, scroll n to
Clock & Alarm, and press o
Select.
2Scroll n to Set Format and press
o Select.
3Time Format is highlighted in the
display. Press o Select, then
scroll n to select 12hours or
24hours.
4Press o Select to select the
option.
• A validation tone is emitted and
the screen returns to the Set
Format menu.
8.12.2.2 Set Date Format
1Press m in idle mode, scroll n to
Clock & Alarm, and press o
Select.
2Scroll n to Set Format and press
o Select.
3Scroll n to Date Format and
press o Select.
4Scroll n to select DD/MM or
MM/DD and press o Select to
select the option.
• A validation tone is emitted and
the screen returns to the Set
Format menu.
8.12.3 Set Alarm
1
Press
m
in idle mode, scroll
n
to
Clock & Alarm
, and press
o
Select
.
2Scroll
n
to Alarm and press
o
Select.
3Scroll
n
to Off, On Once, or On
Daily and press
o
Select.
4If you select On Once or On
Daily, enter the time (HH-MM) for
the alarm. (If using the 12 hour
format, you can switch between AM
and PM by pressing
*
.) Press o
OK to confirm.
Note
01GB01COV.book Page 39 Thursday, July 3, 2008 9:27 AM
40 Personal settings
• A validation tone is emitted and
the screen returns to the Alarm
menu. And the alarm icon is
displayed.
• If you select Off, a validation
tone is emitted and the screen
returns to the Clock & Alarm
menu.
The alarm tone and alarm icon will
sound/blink for 1 minute when the alarm
time is reached. To mute the alarm tone,
simply press any key on the handset.
8.12.4 Set Alarm Tone
1Press
m
in idle mode, scroll
n
to
Clock & Alarm, and press
o
Select.
2Scroll
n
to Alarm Tone and press
o
Select.
3Scroll
n
to select the tone. (Three
tones are available. The tones sound
as you scroll.) Press
o
Select to
confirm your selection.
• A validation tone is emitted and
the screen returns to the Clock
& Alarm menu.
9 Personal settings
9.1 Change the Handset Name
You can name the handset and display the
handset name in idle mode. The default
handset name of your handset is Philips.
1Press m in idle mode, scroll n to
Personal Set and press o
Select.
2Handset Name is highlighted;
press o Select.
3The last stored name is displayed.
Press c Clear to delete the
characters one by one or a long
press to delete all.
4Enter the new name and press o
OK to confirm.
• A validation tone is emitted and
the screen returns to the
Personal Set menu.
9.2 Handset Tones
9.2.1 Set the Ring Volume
When the handset rings during an
incoming call, please do not hold the
handset too close to your ear as the
volume of the ringing tone may damage
your hearing.
In multihandset packs, you can set the
ring volume independently on each
registered handset. There are 5 ringer
volume levels plus progressive and off.
The default is level 3.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Handset Tones and
press o Select. Ring Volume is
highlighted; press o Select.
Note
Danger
01GB01COV.book Page 40 Thursday, July 3, 2008 9:27 AM
41
Personal settings
3Scroll n to your desired volume
level. The ring tone sounds at each
level.
4Press o OK to confirm.
• A validation tone is emitted and
the screen returns to the
Handset Tones menu.
If ring volume is set to off, the icon
will be displayed on the screen.
If ring volume is set to progressive, the
ringer will start at level 1 and go up one
level volume every ring.
9.2.2 Set the Ring Tones
There are 15 ring tones available on your
handset.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Handset Tones and
press o Select. Then scroll n to
Ring Tones and press o Select.
3Scroll n to your desired melody.
The melodies will play as you scroll
them.
4Press o Select to set the ring
tone.
• A validation tone is emitted and
the screen returns to the
Handset Tones menu.
9.2.3 Activate/Deactivate Key
Beep
A single beep tone is emitted when a key
is pressed. You can enable or disable the
key beep.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Handset Tones and
press o Select. Then scroll n to
Key Beep and press o Select.
3Scroll n to select On or Off and
press o Select to confirm.
• A validation tone is emitted and
the screen returns to the
Handset Tones menu.
9.3 Change the Display Language
Your handset can support different
display languages.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Language and press
o Select.
3Scroll n to your desired language
and press o Select to confirm.
• A validation tone is emitted and
the screen returns to the
Personal Set menu.
Once the display language is set, the
option menus on the handset will
immediately switch to display in the
selected language.
9.4 Select the Display Wallpaper
There are 3 wallpaper images available on
your handset as well as an option to set it
off.
Note
Note
01GB01COV.book Page 41 Thursday, July 3, 2008 9:27 AM
42 Personal settings
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Wallpaper and press
o Select.
3Scroll n to your desired wallpaper.
The image on the display will change
as you scroll.
4Press o Select to confirm.
• A validation tone is emitted and
the screen returns to the
Personal S et menu.
9.5 Select the Color Theme
There are 4 color themes available on
your handset.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Color Theme and
press o Select.
3Scroll n to your desired color
theme. The color theme used on
the display will change as you scroll.
4Press o Select to confirm.
• A validation tone is emitted and
the screen returns to the
Personal S et menu.
9.6 Set the Display Contrast
You can change the contrast of the text
on the display. There are 5 contrast levels
available on your handset. The default is
level 3.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Contrast and press
o Select.
3Scroll n to the desired display
contrast, and press o Select to
confirm.
• A validation tone is emitted and
the screen returns to the
Personal Set menu.
9.7 Set the Backlight Time
You can change the backlight timing for
the display. There are 3 options available
- 20, 40, or 60 seconds.
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Backlight Time and
press o Select.
3Scroll n to the desired backlight
time, and press o Select to
confirm.
• A validation tone is emitted and
the screen returns to the
Personal Set menu.
9.8 Deactivate/Activate Auto
Hang-Up
If auto hang-up is set to On, it will
automatically release the line when the
phone is put back on the cradle.
If auto Hang-up is set to Off, putting the
handset back on the cradle while in talk
mode will switch the handset to hands
free talk mode. This allows you to charge
the handset during calls.
The default setting for auto hang up is On.
01GB01COV.book Page 42 Thursday, July 3, 2008 9:27 AM
43
Advanced settings
1Press m in idle mode, scroll n to
Personal Set, and press o
Select.
2Scroll n to Auto Hang-up and
press o Select.
3Scroll n to On or Off and press
o Select to confirm.
• A validation tone is emitted and
the screen returns to the
Personal S et menu.
10 Advanced settings
10.1 Easy Call
When activated, this feature allows you
to dial a preset number by pressing any
key on the handset (except c
Cancel). This feature is useful for fast
access to emergency services.
10.1.1 Set Easy Call to On or Off
Follow this procedure to switch Easy Call
on. To switch Easy Call off, see the Note
at the end of this section.
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Easy Call is highlighted. Press o
Select to enter the Easy Call menu.
3Mode is highlighted in the display.
Press o Select again to select
Mode, then scroll n to On.
4Press o Select to confirm the
selection.
• If an Easy Call number has not
been set, you will be prompted
to input the Easy Call number.
• If an Easy call number has already
been set, the screen returns to
idle mode. If you want to edit the
number, press c Cancel and
scroll to Number and press o
Select, edit the new number and
press o OK.
When you switch Easy Call on, Easy
Call On will be displayed on your screen
in standby mode. You can still answer any
incoming call as normal.
To switch Easy Call off from idle mode,
press c Cancel. Mode is highlighted
in the display. Press o Select again to
select Mode, and then scroll n to Off.
Press o Select to confirm.
10.1.2 Set Easy Call number
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Easy Call is highlighted in the
display. Press o Select to enter
the Easy Call menu.
3Mode is highlighted in the display.
Scroll n to Number and press
o Select.
4Input the Easy Call number.
5Press o OK to confirm.
• A validation tone is emitted and
the screen returns to the Easy
Call menu.
Note
01GB01COV.book Page 43 Thursday, July 3, 2008 9:27 AM
44 Advanced settings
10.2 Auto Conference
If activated, this feature allows another
handset to join a conversation with an
external call by simply pressing t. The
default setting is On.
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Scroll n to Conference and press
o Select.
3Scroll n to select On or Off and
press o Select to confirm.
• A validation tone is emitted and
the screen returns to the
Advanced Set menu.
10.3 Call Barring
If activated, this function prevents dialing
out to numbers beginning with
designated barring numbers. This is
useful for preventing outgoing long
distance calls or calls to specific prefixes.
You can store up to four numbers, each
with up to 4 digits.
If you switch call barring on, Call Barr
On is displayed on the screen in idle
mode. By default call barring is off.
10.3.1 Set Call Barring Mode
By default, Call Barring is OFF.
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Scroll n to Call Barring and
press o Select.
3Enter the PIN number.
• If you enter and incorrect PIN
number, an error tone will sound
and “Wrong PIN!” will be
displayed. Then, the display will
return to idle screen.
4Mode is highlighted in the display.
Press o Select.
5Scroll n to select On or Off and
press o Select to confirm.
• If a Call Barring number has not
been set, you will be prompted
to input a Call Barring number.
To switch Call Barring mode off again
from idle mode, press c Cancel and
enter the PIN number. Mode is
highlighted in the display. Press o
Select to select Mode, then scroll n
to Off and press o Select.
10.3.2 Set a Call Barring number
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Scroll n to Call Barring and
press o Select.
3Enter the PIN number.
4Mode is highlighted in the display.
Scroll d to Number and press
o Select.
5Scroll n to select a call barring
number location, and press o
Select to confirm.
6Input the call barring number (up to
4 digits) and press o OK.
• A validation tone is emitted and
the screen returns to the Call
Barring menu.
Note
Note
01GB01COV.book Page 44 Thursday, July 3, 2008 9:27 AM
45
Advanced settings
10.4 XHD Sound
XHD (extra high definition) Sound can
increase voice quality when On. The
default setting is On.
To turn it off:
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Scroll n to XHD Sound and
press o Select.
3Scroll n to select On or Off and
press o Select to confirm.
• A validation tone is emitted and
the screen returns to the
Advanced Set menu.
10.5 Change PIN
The PIN is used for setting call barring
numbers and registration/unregistration
of handsets. The default PIN number is
0000. This PIN is also used to protect
the settings of your handset. Your
handset will prompt you whenever the
PIN is required.
The default PIN code is preset to 0000. If
you change this PIN code, keep the PIN
details in a safe place where you have
easy access to them. Do not lose the PIN
code.
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Scroll n to Change PIN and
press o Select.
3Old PIN: will be displayed. Enter
the current PIN and press o OK.
• The PIN entered will be shown
as asterisks (*) on the screen.
• If you enter an incorrect PIN
number, an error tone will sound
and “Wrong PIN!” will be
displayed. Then, you will be
prompted to enter the current
PIN again.
4New PIN: will be displayed. Enter
the new PIN and press o OK.
5Confirm PIN: will be displayed.
Enter the new PIN again and press
o OK to confirm PIN change.
• A validation tone is emitted,
Saved! is displayed and the
screen returns to the Advanced
Set menu.
If you forget your PIN, you will need to
reset your phone to its default settings.
For more details, see section 10.8 -
“Reset Unit.”
10.6 Registration
If you wish to register an additional
handset or if you have inadvertently
unregistered your phone’s handset and
want to re-register it, follow the
procedure described below. This is the
procedure for registering handsets of
one of the model described in this
manual. Procedures may vary for other
types of handsets. In this case, please
refer to the manufacturer of the handset.
Additional handsets must be registered
to the base station before you can use
them. Up to 8 handsets can be registered
to one base station. The PIN is required
before you can register or unregister
handsets.
Note
Tip
01GB01COV.book Page 45 Thursday, July 3, 2008 9:27 AM
46 Advanced settings
By default, the PIN is 0000.
1On the base station, press and hold
a for 3 seconds.
If no action is taken on the handset
within 90 seconds, the registration
procedure will be aborted. If this
happens, repeat from Step 1.
2
On the handset, press
m
, scroll
n
to
Advanced Set
and press
o
Select
.
3
Scroll
n
to
Register
and press
o
Select
.
4Enter the PIN when prompted and
press
o
OK to confirm.
Registering… is displayed on the
screen.
• Upon successful registration, a
validation tone is emitted and the
handset number (1 to 8) will be
assigned by the base
automatically.
10.6.1 Easy registration
1Insert the unregistered handset in
the base station to automatically
begin registration.
2Registering… is displayed on the
screen.
• Upon successful registration, a
validation tone is emitted and the
handset number (1 to 8) will be
assigned by the base
automatically.
The easy registration is possible only
when PIN has not been changed and is
still the default PIN 0000.
10.7 Unregister
1Press
m
in idle mode, scroll
n
to
Advanced Set and press
o
Select
.
2Scroll
n
to Unregister and press
o
Select.
3Enter the PIN when prompted and
press
o
OK to confirm.
4Scroll n to select the handset
number to unregister and press o
Select. Press o OK to confirm.
• A validation tone is emitted to
indicate successful unregistration.
A registered handset other than one of
the model described in this manual can
only be unregistered using a handset
described in this manual.
10.8 Reset Unit
You can reset your phone to its default
settings with this feature. (see 10.14
“Default Settings”)
Upon reset, all your personal settings, call
log and redial list entries will be deleted
and the phone will return to its default
settings. However, your phonebook will
remain unchanged after reset.
You may have to configure your phone
once again.
Note
Note
Note
Note
Caution
Note
01GB01COV.book Page 46 Thursday, July 3, 2008 9:27 AM
47
Advanced settings
1Press m in idle mode, scroll n to
Advanced Set and press
o
Select
.
2Scroll n to Reset and press
o
Select
.
3Reset? is displayed on the screen.
Press
o
OK to confirm.
• A validation tone is emitted.
• The unit is reset to its default
settings. (See section 10.14
below.)
10.9 Set Area Code
This feature is useful when you have
subscribed to Caller Line Identification
service. It allows you to set an area code
in your phone. Once the local area code
is set, the phone automatically filters the
area code for all incoming calls, by
removing the area code for local calls and
retaining the area code for calls from
other areas.
If it is a local call, then only the phone
number of the caller is displayed during
an incoming call or when you call the
number from the call log. If it is a long
distance call, then both the area code and
phone number will be displayed in a
proper format to be dialed out directly
from the call log, or saved into the
phonebook.
You can enter 3 digits for the area code.
You need to subscribe to Caller Line
Identification service to be able to see
the caller’s number or name in the call
log. See 7.1.4 “Call from the call log” for
details.
1Press m in idle mode, scroll n to
Advanced Set and press o
Select.
2Scroll n to Area Code and press
o Select.
3Area Code will appear in the
display. Input your area code and
press o OK to confirm.
• A validation tone is emitted and
the screen returns to the
Advanced Set menu.
10.10 Set Auto Prefix
This feature allows you to define a prefix
number to be added to the beginning of a
number during predialling (see
“Predialling” - section 7.1.1). You may
also use this feature to add a detect
string to match and replace the first few
digits of the number during predialing.
You can enter up to a maximum of 5
digits for the detect string and 10 digits
for the auto prefix number.
1Press m in idle mode, scroll n to
Advanced Set and press
o
Select
.
2Scroll n to Auto Prefix and press
o
Select
.
3Detect Digit: is displayed on the
screen. Enter a detect string
number (maximum 5 digits) and
press
o
OK to confirm.
4Prefix: is displayed on the screen.
Enter the prefix number (maximum
10 digits) and press
o
OK to
confirm.
Note
01GB01COV.book Page 47 Thursday, July 3, 2008 9:27 AM
48 Advanced settings
• A validation tone is emitted and
the screen returns to the
Advanced Set menu.
If no detect string (blank) is entered, the
prefix number will be automatically
added to the predial number after t is
pressed.
For numbers starting with *, # or P, the
prefix number will not be added to the
predial number after t is pressed.
10.11 Change Flash time
Flash time is the time delay by which the
line will be disconnected after you press
the t key. It can be set to short or
long.
The default value is Long.
1Press m in idle mode, scroll n to
Advanced Set, and press o
Select.
2Scroll n to Flash Time and press
o Select.
3Scroll n to Short or Long and
press o Select to confirm.
• A validation tone is emitted and
the screen returns to the
Advanced Set menu.
The use of your phone cannot be
guaranteed on all PABX.
10.12 Change the Dial Mode
The default value for dial mode that is
preset in your handset should be the best
suited for your subscribed network and
therefore you should not need to change
it.
1Press m in idle mode, scroll n to
Advanced Set, and press
o
Select
.
2Scroll n to Dial Mode and press
o
Select
.
3Scroll n to To n e or Pulse and
press
o
Select
to confirm.
• A validation tone is emitted and
the screen returns to the
Advanced Set menu.
10.13 Set First Ring Detection
First ring detection allows the phone to
ring upon reception of the first ring
signal. It is recommended that you set
first ring detection Off if you subscribe
to caller line identification service.
(When using personalized phonebook
melodies, this will prevent a normal ring
tone from sounding before a melody
starts playing.) If you do not subscribe to
caller line identification service, it is
recommended that you set first ring
detection On. (See Section 8.6.4.)
1Press m in idle mode, scroll n to
Advanced Set, and press
o
Select
.
2Scroll n to First Ring and press
o
Select
.
3Scroll n to On or Off and press
o
Select
to confirm.
• A validation tone is emitted and
the screen returns to the
Advanced Set menu.
Note
Note
01GB01COV.book Page 48 Thursday, July 3, 2008 9:27 AM
49
Network Service
The default setting for first ring detection
is On. The setting automatically switches
to Off when you receive a call containing
caller line identification. However, this
occurs only if you do not first manually
change the setting. (It does not change
automatically
if you manually change the first ring
setting even once.)
10.14 Default Settings
11 Network Service
The network service functions provide a
convenient way for you to access some
network provider services. Subscriptions
are required in order to benefit from
these services. Contact your network
provider for details. Depending on your
subscribed network, some of the
services and menus described in this
Note
Parameter Default Value
Ring Volume Level 3
Ring Tone Ring 1
Earpiece
Volume
Level 3
Speaker
Volume
Level 3
Key Beep On
Display
Language
English
Wallpaper Wallpaper 1
Color
Theme
Color 1
Display
Contrast
Level 3
Backlight
Time
20 Seconds
Auto Hang-
Up
On
Handset
Name
Philips
Time/Date
Format
MM/DD 12Hours
Time/Date 00:00 01/01/2008
Set Alarm Off
Alarm Tone Bell 2
Dial Mode Tone
Flash Time Long
PIN Code 0000
Call Barring Off
Call Barring
Number
Cleared
XHD Sound On
Easy Call Off
Easy Call
Number
Cleared
Auto Prefix Cleared
Set First Ring On
Phonebook
Memory
After a reset,
phonebook is
maintained as it was just
before the reset
Redial
Memory
Cleared
CLI Memory Cleared
Network
Service
Empty (no preset
numbers)
Auto
Conference
On
Parameter Default Value
01GB01COV.book Page 49 Thursday, July 3, 2008 9:27 AM
50 Network Service
chapter may not be available in your
phone.
The Call Forward, Call Forward
when Busy, and Call Forward when
Unanswered functions require
activation codes (prefix and suffix) and a
deactivation code. You must get these
codes from your service provider.
11.1 Call Forward
You can use Call Forward to forward
incoming calls to another number. This
can be useful if you want calls to go to
another number overnight or when
traveling. You can activate or deactivate
Call Forward as follows:
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Call Forward and
press o Select.
3To activate Call Forward, scroll
n to Activate and press o
Select. To deactivate Call
Forward, scroll to Deactivate
and press o Select.
4If you selected Activate, you will
be prompted to enter the number
for call forward. Enter the number
(maximum 24 digits) and press o
OK.
5The Call forward codes and the
number are dialed. Press h and
return to idle mode.
11.1.1 Change Call Forward
Activation Codes
There are two parts to the Call Forward
activation code - a prefix and a suffix.
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Call Forward and
press o Select.
3Scroll n to Change Code and
press o Select.
4Scroll n to Activation and press
o Select.
5You are now at the Activation
screen. Scroll n to Prefix or
Suffix, then press o Select.
6You will be prompted to enter the
prefix/suffix code. Enter the number
(maximum 14 digits) and press o
OK.
• A confirmation tone will sound
and the display will return to the
Activation screen.
Press c Clear to delete entered
numbers. Long press c Clear to clear
the entire entry.
7Repeat from step 5 until you are
finished inputting both the prefix
and suffix codes.
11.1.2 Change Call Forward
Deactivation Code
You must get the deactivation code from
your service provider.
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
Note
Note
01GB01COV.book Page 50 Thursday, July 3, 2008 9:27 AM
51
Network Service
2Scroll n to Call Forward and
press o Select.
3Scroll n to Change Code and
press o Select.
4Scroll n to Deactivation and
press o Select.
5Enter the deactivation code
(maximum 14 digits) and press o
OK.
• A confirmation tone will sound
and the display will return to the
Call Forward screen.
Press c Clear to delete entered
numbers. Long press c Clear to clear
the entire entry.
11.2 Call Forward when Busy
This function will forward incoming calls
to another number if the line is busy. You
can activate or deactivate Call Forward
when Busy as follows:
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Call Fwd Busy and
press o Select.
3To activate Call Fwd Busy, scroll
n to Activate and press o
Select. To deactivate Call Fwd
Busy, scroll to Deactivate and
press o Select.
4If you selected Activate, you will
be prompted to enter the number
for call forward when busy. Enter
the number (maximum 24 digits)
and press o OK.
5The Call forward when busy codes
and the number are dialed. Press
h and return to idle mode.
11.2.1 Change Call Forward when
Busy Activation Codes
There are two parts to the Call Forward
when Busy activation code - a prefix and
a suffix.
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Call Fwd Busy and
press o Select.
3Scroll n to Change Code and
press o Select.
4Scroll n to Activation and press
o Select.
5You are now at the Activation
screen. Scroll n to Prefix or
Suffix, then press o Select.
6You will be prompted to enter the
prefix/suffix code. Enter the number
(maximum 14 digits) and press o
OK.
• A confirmation tone will sound
and the display will return to the
Activation screen.
Press c Clear to delete entered
numbers. Long press c Clear to clear
the entire entry.
7Repeat from step 5 until you are
finished inputting both the prefix
and suffix codes.
Note
Note
01GB01COV.book Page 51 Thursday, July 3, 2008 9:27 AM
52 Network Service
11.2.2 Change Call Forward when
Busy Deactivation Code
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Call Fwd Busy and
press o Select.
3Scroll n to Change Code and
press o Select.
4Scroll n to Deactivation and
press o Select.
5Enter the deactivation code
(maximum 14 digits) and press o
OK.
• A confirmation tone will sound
and the display will return to the
Call Fwd Busy screen.
Press c Clear to delete entered
numbers. Long press c Clear to clear
the entire entry.
11.3 Call Forward when
Unanswered
This function will forward unanswered
calls to another number. You can activate
or deactivate Call Forward when
Unanswered as follows:
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Call Fwd Unans and
press o Select.
3To activate Call Fwd Unans, scroll
n to Activate and press o
Select. To deactivate Call Fwd
Unans, scroll to Deactivate and
press o Select.
4If you selected Activate, you will
be prompted to enter the number
for call forward when unanswered.
Enter the number (maximum 24
digits) and press o OK.
5The Call forward when unanswered
codes and the number are dialed.
Press h and return to idle mode.
11.3.1 Change Call Forward when
Unanswered Activation
Codes
There are two parts to the Call Forward
when Unanswered activation code - a
prefix and a suffix.
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Call Fwd Unans and
press o Select.
3Scroll n to Change Code and
press o Select.
4Scroll n to Activation and press
o Select.
5You are now at the Activation
screen. Scroll n to Prefix or
Suffix, then press o Select.
6You will be prompted to enter the
prefix/suffix code. Enter the number
(maximum 14 digits) and press o
OK.
• A confirmation tone will sound
and the display will return to the
Activation screen.
Press c Clear to delete entered
numbers. Long press c Clear to clear
the entire entry.
Note
Note
01GB01COV.book Page 52 Thursday, July 3, 2008 9:27 AM
53
Network Service
7Repeat from step 5 until you are
finished inputting both the prefix
and suffix codes.
11.3.2 Change Call Forward when
Unanswered Deactivation
Code
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Call Fwd Unans and
press o Select.
3Scroll n to Change Code and
press o Select.
4Scroll n to Deactivation and
press o Select.
5Enter the deactivation code
(maximum 14 digits) and press o
OK.
• A confirmation tone will sound
and the display will return to the
Call Fwd Unans screen.
Press c Clear to delete entered
numbers. Long press c Clear to clear
the entire entry.
11.4 Voice Mail
Use this function to access your voice
mail account.
11.4.1 Access Voice Mail
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Voicemail and press
o Select.
3You are now at the Voice mail
menu and Call is highlighted. Press
o Select to connect to the voice
mail account number.
You can also access your voice mail
number by long-pressing 1.
11.4.2 Set Voice Mail Number
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Voicemail and press
o Select.
3Scroll n to Settings and press
o Select.
4Enter the voice mail account
number (maximum 14 digits) and
press o OK.
• A confirmation tone will sound
and the display will return to the
Voic e mai l screen.
11.5 Voice Mail 2
Use this function to access an alternate
voice mail account. Access and setting
procedure is same as for Voice Mail.
You can also access your voice mail
number by long-pressing 2.
11.6 Information Service
Use this function to access your
information service account.
Note
Note
Note
01GB01COV.book Page 53 Thursday, July 3, 2008 9:27 AM
54 Network Service
11.6.1 Access Info Service
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Info and press o
Select.
3
You are now at the
Info
menu and
Call
is highlighted. Press
o
Select
to connect to the information
service account number.
11.6.2 Set Info Service Number
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Info and press o
Select.
3Scroll n to Settings and press
o Select.
4Enter the information service
account number (maximum 14
digits) and press o OK.
• A confirmation tone will sound
and the display will return to the
Info screen.
11.7 Information Service 2
Use this function to access a second
information service account. Access and
setting procedure is same as for Info
Service.
11.8 Call Return
This function allows you to get
information on who called you last.
11.8.1 Access the Call Return
Service
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Call Return and press
o Select.
3You are now at the Call Return
menu and Call is highlighted. Press
o Select to connect to the call
return account number.
11.8.2 Set Call Return Service
Number
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Call Return and press
o Select.
3Scroll n to Settings and press
o Select.
4Enter the call return service number
(maximum 14 digits) and press o
OK.
• A confirmation tone will sound
and the display will return to the
Call Return screen.
11.9 Cancel Call Back
When calling a busy line, some operators
prompt you to press a key to activate a
call back option. By activating the call back
option, you will receive a call from the
network as soon as your correspondent’s
line is free. When responding to this call,
the network will automatically connect
you to that correspondent. Your call log
01GB01COV.book Page 54 Thursday, July 3, 2008 9:27 AM
55
Network Service
will not record this call either. The Cancel
call back feature enables you to deactivate
the call back feature when you have
activated it.
11.9.1 Call the Cancel Call Back
Number
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Cancel Call BK and
press o Select.
3You are now at the Cancel Call
BK menu and Call is highlighted.
Press o Select to connect to the
Cancel Call Back number.
11.9.2 Set the Cancel Call Back
Number
Get the cancel call back number from
your service provider.
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Cancel Call BK and
press o Select.
3Scroll n to Settings and press
o Select.
4Enter the cancel call back number
(maximum 14 digits) and press o
OK.
• A confirmation tone will sound
and the display will return to the
Cancel Call BK screen.
11.10 Withhold ID
Use this function to make a call without
sending your ID.
11.10.1 Activating Withhold ID
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Withhold ID and
press o Select.
3You are now at the Withhold ID
menu and Activate is highlighted.
Press o Select to activate the
withhold ID function.
11.10.2 Set the Withhold ID Code
When withhold ID is active (see above),
this code is appended before the number
you dial to tell the handset to withhold
ID information. Get this code from your
service provider.
1Press m in idle mode, scroll n to
Netw. Services, and press o
Select.
2Scroll n to Withhold ID and
press o Select.
3Scroll n to Settings and press
o Select.
4Enter the withhold ID code and
press o OK.
• A confirmation tone will sound
and the display will return to the
Withhold ID screen.
01GB01COV.book Page 55 Thursday, July 3, 2008 9:27 AM
56 Technical data
12 Technical data
Display
• Color LCD with backlight
• Selectable wallpaper
• Selectable color theme
General telephone features
• Caller name & number identification
• 5 standard + 10 polyphonic ringer
melodies
• Wideband synthesis for receiver and
loudspeaker
Phonebook list, Redial list and Call
log
• Phonebook list with 100 entries
• Redial list with 10 entries
• Call log with 50 entries
Battery
• 2 × AAA, 600mAh batteries
Radio specifications
• Frequence Band: 1920 - 1930Mhz
• Maximum output power: 120mW
Weight and dimensions
Base:
• 145.5 grams
• 77mm × 115mm × 116.5mm
(H × D × W)
Handset:
• 128.5 grams
• 160mm × 28mm × 46mm
(H × D × W)
Temperature range
• Operation: Between 0 and 35ºC
(32 to 95ºF).
• Storage: Between -20 and 70ºC
(-4 to 158ºF).
Relative humidity
• Operation: Up to 95% at 40°C
• Storage: Up to 95% at 40°C
13 Frequently asked
questions
www.philips.com/support
In this chapter, you will find the most
frequently asked questions and answers
about your phone.
13.1 Connection
The handset does not switch on!
• Charge the batteries: Put the handset
on the base station to charge. After a
few moments, the phone will switch
on.
• You may have accidentally switched off
the handset. In this case, press and
hold h for at least 1 second to
switch it on again (see section 8.1 -
“Switch the handset off/on”).
The handset does not charge!
• Check charger connections.
01GB01COV.book Page 56 Thursday, July 3, 2008 9:27 AM
57
Frequently asked questions
icon is not blinking during
charge!
• Battery is full: There is no need to
charge the battery.
• Bad battery contact: Adjust the
handset slightly.
• Dirty contact: Clean the batteries
contact with a cloth moistened with
alcohol.
Communication is lost during a call!
• Charge the battery
• Move closer to the base station.
The phone is “Out of range”!
• Move closer to the base station.
13.2 Set-up
Searching... is displayed on handset
and icon is blinking!
• Move closer to the base station.
• Make sure that your base station is
on.
• Reset your unit and restart handset
registration.
13.3 Sound
Handset does not ring!
Check that the Ring Volume is not set
to no bars (Ringer Off), and make sure
the icon is not displayed on the
screen (see section 9.2.1 - “Set the Ring
Vol u me ” ) .
Caller does not hear me!
Microphone may be muted: During a call,
press s.
There’s no dialling tone!
• No power: Check the connections.
• Batteries are empty: Charge the
batteries.
• Move closer to the base station.
• Wrong line cable used: Use the line
cable provided.
• Line adaptor is required: Connect the
line adaptor to the line cord.
Caller does not hear me clearly!
• Move closer to the base station.
• Move the base station at least one
metre away from any electronic
appliances.
Frequent noise interference on my
radio or television!
• Move the base station as far away as
possible from the electrical appliances.
13.4 Product behavior
Keypad does not work!
• Unlock your keypad: Long press *
in idle mode.
The handset warms up when
making a long call and when it is on
the base station!
• This is a normal behavior. The handset
consumes energy while calling and
charging.
01GB01COV.book Page 57 Thursday, July 3, 2008 9:27 AM
58 Frequently asked questions
The handset cannot be registered
to the base station!
• Maximum number of handsets (8) has
been reached. To register a new
handset, unregister an existing
handset.
• Remove and replace the handset
batteries.
• Try again by disconnecting and
connecting the base station power
supply and follow the procedure to
register a handset (see section 10.6).
Caller number is not displayed!
• Service is not activated: Check your
subscription with your network
operator.
I cannot change the settings of my
voice mail!
• Operator voice mail is managed by
your operator and not the phone
itself. Please contact your operator
should you want to change the
settings.
My handset keeps going into idle
mode!
• If there are no key presses for 30
seconds, the handset will
automatically return to idle mode. It
will also return to idle mode
automatically when you place the
handset back on the base station (if
auto hang-up feature is on).
Phonebook entry cannot be stored
and Memory Full is displayed!
• Delete an entry to free memory
before saving your contact again.
The PIN code is wrong!
• The default PIN is 0000.
• Reset the handset to revert to the
default PIN code if it has been
changed before (see “Reset Unit” -
Section 10.8).
01GB01COV.book Page 58 Thursday, July 3, 2008 9:27 AM
59 INDEX
15 INDEX
A
Access Info Service 54
Access phonebook 31
Access Redial list 34
Access the Call log 35
Access the Call Return Service 54
Activate/Deactivate loudspeaker
mode 30
Activating Withhold ID 55
Adjust earpiece or speaker volume 30
Advanced settings 43
Advanced Settings menu tree 26
Answer a call 29
Answer an external call during
intercom 38
Auto Conference 44
Auto hang-up 42
Auto Prefix 47
B
Backlight timing 42
Base station 18
Batteries 20
C
Call Barring 44
Call Forward 50
Call Forward when Busy 51
Call Forward when Unanswered 52
Call from redial list 28
Call from the call log 28
Call from the phonebook 28
Call Return 54
Call the Cancel Call Back Number 55
Call using Direct Access Memory 29
Cancel Call Back 54
Change Call Forward Activation
Codes 50
Change Call Forward Deactivation
Code 50
Change Call Forward when Busy
Activation Codes 51
Change Call Forward when Busy
Deactivation Code 52
Change Call Forward when Unanswered
Activation Codes 52
Change Call Forward when Unanswered
Deactivation Code 53
Change PIN 45
Change the Dial Mode 48
Change the Display Language 41
Change the Handset Name 40
Charge battery 21
Clock and Alarm menu tree 25
Clock and Alarm settings 39
Color themes 42
Connect the base station 19
Contrast 42
D
Deactivate/Activate Auto Hang-Up 42
Default PIN code 45
Default settings 49
Delete a call list entry 37
Delete a phonebook entry 33
Delete a redial number 35
Delete all call list entries 37
Delete all phonebook entries 33
Delete all redial numbers 35
Delete Direct Access Memory 34
01GB01COV.book Page 59 Thursday, July 3, 2008 9:27 AM
60 INDEX
Dial mode 48
Direct Access Memory 33
Direct dialling 28
Display icons and Messages 17
Display languages 41
E
Easy Call 43
End a call 29
Establish a three-party conference call 38
F
Frequently asked questions 56
G
Getting started 19
H
Handset locator 38
Handset name 40
Handset Tones 40
Handsfree answering 29
I
Information Service 1 53
Install battery 20
Install your phone 20
Intercom 37
K
Key Beep 41
Keypad lock/unlock 30
M
Make a call 28
Menu structure 23
Modify a phonebook entry 32
Mute/Unmute microphone 30
N
Network Service 49
Network Services menu tree 27
O
Overview of the base station 18
Overview of your phone 15
P
Personal settings 40
Personal Settings menu tree 24
Phonebook menu tree 23
PIN 45
Power requirements 6
Predialling 28
R
Registration 45
Reset Unit 46
Ring tones 41
Ring Volume 40
S
Save a redial number 34
Save call list entry 36
Select phonebook melody 32
Select the Color Theme 42
Select the Display Wallpaper 41
Set a Call Barring number 44
Set Alarm 39
Set Alarm Tone 40
Set Auto Prefix 47
Set Call Barring Mode 44
Set Call Return Service Number 54
Set Date and Time 39
Set Date Format 39
Set Easy Call number 43
Set Easy Call to On or Off 43
Set First Ring Detection 48
01GB01COV.book Page 60 Thursday, July 3, 2008 9:27 AM
61
INDEX
Set Info Service Number 54
Set the Backlight Time 42
Set the Cancel Call Back Number 55
Set the Display Contrast 42
Set the Ring Tones 41
Set the Ring Volume 40
Set the Withhold ID Code 55
Set Time Format 39
Set Voice Mail Number 53
Store a contact in the phonebook 31
Switch between an internal and external
call 38
Switch the handset off/on 30
T
Technical data 56
Text or number entry 30
The call log 35
Transfer an external call 37
U
Unregister 46
Using the Call log 35
Using the Intercom 37
Using the Redial list 34
Using your phone 28
Using your Phonebook 31
V
Voice Mail 53
W
Wallpaper images 41
What’s in the box 14
Withhold ID 55
X
XHD Sound 45
Y
Your phone 14
01GB01COV.book Page 61 Thursday, July 3, 2008 9:27 AM
01GB07BCO.fm Page 62 Thursday, July 3, 2008 2:13 PM
01GB07BCO.fm Page 63 Thursday, July 3, 2008 2:13 PM
01GB07BCO.fm Page 64 Thursday, July 3, 2008 2:13 PM
UCZZ01xxxxZ(0)
01GB07BCO.fm Page 65 Thursday, July 3, 2008 2:13 PM
©2008 Koninklijke Philips Electronics N.V.
All rights reserved
Reproduction in whole or in part is prohibited without the written
consent of the copyright owner
Document order number: XXXX XXX XXXXX (master US-EN)
01GB07BCO.fm Page 66 Thursday, July 3, 2008 2:13 PM
