Users Manual Part 5

Service Provider Features 49
Service Provider Features
Service Provider
Features
Several features on your phone are available only if you sign up for them
with your wireless service provider. If you do not have one of the services
listed below, contact your wireless service provider for more information.
Caller ID
This feature displays the phone number of the person calling you. If the
caller’s phone number matches an entry in the Phonebook, the backlight
changes color and the corresponding name is displayed. The ring tone,
and color depend on the settings you selected in the Phonebook.
Call Waiting
1An alert sounds when you receive an incoming call during a
conversation.
• The display indicates that a call is waiting.
• If the caller’s phone number matches an entry in
the Phonebook, the backlight changes color and
the corresponding name is displayed.
2Press (ACCEPT) to connect with the incoming call and place the
first call on hold.
OR
Press (IGNORE) to silence the ring and continue your current call.
3Press to switch between the two calls.
4Press to end the current call.
Three-Way Calling
This feature lets you dial a third person while you are in a call. You can
continue your conversation with one person when the other one hangs up.
1While in a call, enter a phone number or recall it from the Phonebook.
2Press .
• The phone call you are in is temporarily placed on hold.
3When the third person answers, press again to connect all three
parties.
4Press to end all calls.
Note: This feature may not be available in all areas. Contact
your wireless service provider for more information.
7
Chapter 7
50 Service Provider Features
Text Messaging
Composing a Text Message
You can type a text message (up to 160 characters including the e-mail
address).
Entering the Send To Information
1From the Text Message menu, scroll to Compose and press (OK).
2Press (SELECT) to select Send To.
3From the Send To screen, select From Phonebook, Phone#, or
E-mail Address. Follow the display prompts or enter characters. (See
Chapter 4, “Text Entry Operations”.) Press (OK).
If you decide to change the phone number or e-mail address you
entered, reselect the check-marked Send To: entry, and press
(CHANGE). Repeat the first part of this step.
OR
If you have created a group list, you can send the message to several
people at once, by selecting Group Lists and pressing (OK).
Select an entry from your group lists and press (OK). (See
“Creating a Group List” on page 55 for information on how to set up
group lists.)
• The Compose menu is displayed with a check mark next to Send To,
indicating that this field has been completed.
Entering the Text of Your Message
4Scroll to Message and press (SELECT).
5Enter the text of your message and press (OK). (See Chapter 4,
“Text Entry Operations”.)
• The Compose menu is displayed with a check mark next to Send To
and Message, indicating that both these fields have been completed.
Message Options
6Do one of the following:
-To send the message, press (OK).
-To store the message in the outbox before sending it, scroll to Save
and press (OK).
• The outbox holds up to 20 unsent messages. If the outbox is full,
delete or send an outbox message to make more room in the
outbox.
-To delete the message and return to the Text Message menu, scroll
to Exit and press (OK).
Accessing Text Messages
1From standby, press .
OR
From standby, press (MENU), scroll to Messages, and press
(OK)
2Scroll to Text Message, and press (OK).
Chapter 7
Service Provider Features 51
3Do one of the following:
-To look at messages in the Inbox, press (OK). See “Viewing
Inbox Messages” on page 53.
-To compose a message, scroll to Compose and press (OK).
See “Composing a Text Message” on page 50.
-To create a group list so that you can send a message to several
people at once, scroll to Group Lists and press (OK). See
“Creating a Group List” on page 55.
-To delete all messages in the Inbox or Outbox, scroll to Delete All
and press (OK). See “Deleting All Inbox or Outbox Messages”
on page 54.
-To look at messages in the Outbox, scroll to Outbox and press
(OK). See “Viewing Outbox Messages” on page 53.
Reading New Text Messages
When a new text message is received, an alert sounds and appears
on the top of the display.
• If you have received 40 messages, the oldest read message will be
overwritten when you receive a new message.
• If the envelope icon is dark ( ), you have 40 unread (including locked)
messages waiting and the inbox is full. See “Deleting a Text Message”
on page 54 and delete a message.
• The display indicates how many new text messages you have received.
1Press (VIEW) to view the inbox message list.
• The display icons indicate the message status:
:Unread message
:Locked message
:Read message
• The urgency level of the received message is also displayed:
!! :Very urgent message
! :Urgent message
:Normal message
:Bulk message
Chapter 7
52 Service Provider Features
2If you have one new message, press or to scroll through the
message, sender, and reception time.
OR
If you have more than one message, press or to scroll through
the list of messages. When the arrow points to the message you want
to read, press or to scroll through the message, sender, and
reception time.
3Once you read a message, you can do any of the following:
-To reply to the message, see “Replying to a Text Message (Inbox
Only)” on page 52.
-To lock the message, see “Locking a Text Message” on page 52.
-To forward the message, see “Forwarding a Text Message” on
page 52.
-To call a number shown in the message, see “Calling Back a Text
Message” on page 53.
-To delete the message, see “Deleting a Text Message” on page 54.
Replying to a Text Message (Inbox Only)
1With a message displayed, press (OPTION).
• The OPTIONS menu is displayed.
2Press (OK) to select Reply.
• The Compose screen appears with a check mark next to Send To,
indicating that this field is already completed.
3Scroll to Message and press (SELECT).
4Enter the text of your message in the Message screen and press
(OK).
• The Compose screen is displayed.
Locking a Text Message
You can lock a message so that it will not be overwritten by another
incoming message when your inbox is full.
1With the message selected or displayed, press (OPTION).
2Scroll to Lock and press (OK).
•Message Locked is shown on the display and the icon appears
next to the message in the Inbox list.
Forwarding a Text Message
1With the message selected or displayed, press (OPTION).
2Scroll to Forward and press (OK).
• The Compose screen appears with a check mark next to Message,
indicating that the message field is completed.
3Press (SELECT).
4From the Send To screen, do one of the following:
-To select a number or e-mail address from the Phonebook, press
(OK).
Scroll to a name and then to the phone number or e-mail address to
forward the message to, and press (OK).
-To enter a phone number, scroll to Phone# and press (OK).
Chapter 7
Service Provider Features 53
Enter the phone number to forward the message to, and press
(OK).
-To enter an e-mail address, scroll to E-mail Address and press
(OK).
Enter the e-mail address to forward the message to, and press
(OK).
-To select a group list, scroll to Group List, and press (OK).
Scroll to the group list to forward the message to, and press
(OK).
-The Compose screen is displayed with check marks next to
Send To and Message.
Calling Back a Text Message
When the text of a message contains a telephone number, you can call
that number without having to press the keys yourself.
1With the message displayed, press (OPTION).
2Scroll to Call Back, and press (OK).
3Scroll to the phone number you want to call back. (Phone numbers are
automatically inserted.)
4Press (OPTION) and then select Prefix to add a prefix to the
phone number, or select Save to save the number in the Phonebook
as a home, work, cell, or other phone number.
OR
Press (SEND) to place the call.
Viewing Inbox Messages
1From the Text Message menu, press (OK).
2Press or to scroll to the message of your choice, then or
to scroll through the message, sender, and the reception time.
3Do one of the following:
-To reply to a message, see “Replying to a Text Message (Inbox
Only)” on page 52.
-To lock a message so that it cannot be overwritten by another
incoming message, see “Locking a Text Message” on page 52.
-To forward a message, see “Forwarding a Text Message” on
page 52.
-To call a number shown in the message, see “Calling Back a Text
Message” above.
-To delete the message, see “Deleting a Text Message” on page 54.
Note: If a phone number is displayed after From: in an Inbox
message, pressing calls the displayed number.
Viewing Outbox Messages
1From the Text Message menu, scroll to Outbox and press (OK).
2Press or to scroll to the message of your choice, then or
to scroll through the message, destination, and the time.
3After reading through a message, press (OPTION).
Chapter 7
54 Service Provider Features
4From the Options menu, do one of the following:
-To edit the destination or the text of a message, press (OK) to
select Edit.
• The Compose screen is displayed. See “Composing a Text
Message” on page 50 for instructions on editing a message.
• To send the message, scroll to Send and press (OK).
• To delete the message, scroll to Delete and press (OK).
Deleting a Text Message
1With the message selected or displayed, press (OPTION).
2Scroll to Delete, and press (OK).
3Press (YES) to delete the message.
Deleting All Inbox or Outbox Messages
1From the Text Message menu, scroll to Delete All and press (OK).
2Do one of the following:
-Press (OK) to delete all messages in the Inbox.
• If you press (OK), the display asks you to confirm that you
want to delete all messages in your Inbox.
• If you press (NO), you are returned to the Delete All menu.
Press (YES).
OR
-Scroll to Outbox and press (OK).
• If you press (OK), the display asks you to confirm that you
want to delete all messages in your Outbox.
• If you press (NO), you are returned to the Delete All menu.
Press (YES).
Note: You cannot delete Locked messages in the Inbox with
Delete All.
Group Lists
A group list is a convenient way to send a message to several people at
once. Usually, group lists consist of people with some common element,
such as members of a team at work, family members, or friends with
similar interests. Each group list can have up to five members and you can
have a total of five group lists. You have to assign a name to your group list
first and then add members from your Phonebook entries.
Remember, that you must create your Phonebook entries before you can
select them for a group list. Once you have created a group list, you can
add or delete members, delete the entire group list, and send a message
to a group.
Note: When you send a message to a group list, the message is
sent individually to each name in the group list, even though it
appears to you that only one message is being sent.
Chapter 7
Service Provider Features 55
Creating a Group List
1From the Text Message menu, scroll to Group Lists and press
(OK).
2Press (OK) to select Create.
• The display prompts for a name for your group list.
3Press and hold to delete Untitled and then enter a name for your
group list.
• Enter a name (up to 16 characters) that will remind you who is in the list.
For example, Book Club, Project Team, and so on. (See Chapter 4, “Text
Entry Operations” for information on entering text on your display.)
4Press (OK).
• The display shows the name you entered for the Group List, and
prompts for names of people to include.
5Scroll to 1st:, 2nd:, 3rd:, 4th:, or 5th:—you can add names in any
order—and press (SELECT).
• The names in your Phonebook are displayed.
6Scroll to the name you want to add to the group list and press
(SELECT).
• All phone numbers for that person (and an e-mail address, if present)
are displayed.
7Scroll to the phone number or e-mail address you want to use and
press (SELECT).
• The person’s name is added to the group list. An icon next to the name
indicates which phone number (or e-mail address) will be used:
(home number), (work number), (cell phone number), (other
number), or @ (e-mail address).
8When you have entered all the names (up to five) to be included in this
group list, press (FINISH).
• The display asks if you want to save the entry.
9Press (YES) to save the entry or (NO) to cancel it.
Editing a Group List
1From the Text Message menu, scroll to Group Lists and press
(OK).
2Scroll to Edit and press (OK).
Chapter 7
56 Service Provider Features
• The names of your group lists are displayed.
3Scroll to the one you want to edit and press (EDIT).
4To change or delete an entry, scroll to the entry and press
(SELECT).
5To change the entry, press (CHANGE).
Scroll through the names in your Phonebook, and press (SELECT)
when the name you want to enter is displayed.
Scroll through the phone numbers and e-mail address for the selected
name, and press (SELECT) when the arrow points to the number
(or e-mail address) you want.
OR
To delete the entry, press (DELETE).
6To change or delete another entry, press (SELECT).
OR
To return to the Group List menu, press (FINISH).
7To save your change(s), press (YES).
OR
To cancel your changes and return to the Group List menu, press
(NO).
Viewing Your Group Lists
You can view your group lists, edit them, and delete them.
1From the Text Message menu, scroll to Group Lists and press
(OK).
2On the Group List menu, scroll to View and press (OK).
3Scroll to the group list you want to view and press (VIEW).
4Press (OPTION).
5From the View Options menu, do one of the following:
-To edit a group list, press (OK) and follow the instructions from
step 4 in “Editing a Group List” above.
-To delete an entire group list, scroll to Delete and press (OK).
When asked to confirm the deletion, press (YES).
-To send a message to the people in the selected group list, scroll to
Send To and press (OK). Follow the instructions in “Composing
a Text Message” on page 50.
Chapter 7
Service Provider Features 57
Voice Mail
Note: You must subscribe to voice mail through your wireless
service provider before you can retrieve voice mail messages.
To check if voice mail has been programmed, press and hold
. If the display indicates that the Voice Mailbox number is
empty, voice mail has not been programmed. Contact your
wireless service provider for programming instructions.
Listening to New Voice Mail
1When a new voice mail message is received, an alert sounds and
appears on the top of the display.
2Press (LISTEN) to automatically dial your voice mail number.
OR
From the standby display, press and hold until it calls your voice
mailbox.
3Follow the recorded instructions for your voice mail.
4Press to end your call and return to standby.
Saving and Deleting Voice Mail
Saving and deleting voice mail is a function of your wireless service
provider. Once you call your voice mailbox, follow the instructions given by
your wireless service provider.
Resetting the Voice Mailbox Number
Caution: Do not reset your voice mailbox number if it is
preprogrammed by your wireless service provider. Your voice
mail will be inaccessible if an incorrect number is entered. Check
with your wireless service provider for specific information.
1From standby, press (MENU) to enter the Main Menu.
2Press to scroll to Messages and press (OK).
3Press (OK) to select Voice Mail.
• Your voice mailbox phone number is displayed.
• If a voice mailbox number has not been
programmed, (Empty) is displayed.
4Press (EDIT) and enter a new voice mailbox phone number.
• You can also program Pause and Wait times for your password or PIN.
See “Programming Pauses or Waits” on page 30.
5Press (OK) to save the new phone number.
Chapter 7
58 Service Provider Features
System Settings 59
System Settings
This chapter contains information about settings in the System Settings
menu. You should not have to change these settings. The procedures in
this chapter are provided for technically knowledgeable users.
Caution: Before making any changes to these settings, contact
technical support. Random changes to these settings could
negatively affect your phone’s performance.
Voice Privacy Mode
When this feature is on, conversations and messages are encrypted with a
special code that can be interpreted only by your wireless service provider.
Voice privacy is available only if offered by your wireless service provider.
Contact your wireless service provider for additional information.
1From standby, press (MENU) to enter the Main Menu.
2Press to scroll to System Setting and press (OK).
3Press (OK) again to select Network.
4Press (OK) again to select Voice Privacy.
5To change the setting, scroll to the other option and press (OK).
• If you selected On, the encryption icon ( ) is displayed during calls (if
you have subscribed to voice privacy with your service provider).
Selecting Your Phone Number (NAM)
Your phone can have up to two phone numbers (programmed by your
wireless service provider). You can select either phone number to make a
call. These phone numbers are referred to as NAM1 and NAM2. NAM
stands for Number Assignment Module.
Your wireless service provider must program a NAM into your handset in
order for it to operate correctly on their network. This can be done by a
sales representative, or optionally, it can be programmed into your phone
over the airwaves.
1From standby, press (MENU) to enter the Main Menu.
2Press to scroll to System Setting and press (OK).
3Press to scroll to NAM Selection and press (OK).
• The display shows your current phone number setting.
4If you have a second phone number (NAM2), view it by pressing
or .
5To select the other phone number (other than the one you are currently
using), make sure that phone number (NAM) is displayed and press
(OK).
• If you changed the NAM setting, a network search occurs.
Note: If you would like to have a second phone number
programmed for your phone, contact your wireless service
provider.
8
Chapter 8
60 System Settings
Searching for Available Systems
Your phone’s search default is set to Normal, which means it automatically
searches for available network systems, and then selects the appropriate
one. It will default to this setting every time you turn on your phone, even
when you have changed the search setting. To search for a particular
network, select Manual. Up to 16 network names may be displayed. When
New Search is selected, your phone begins a new search for available
systems and asks if you use the network.
1From standby, press (MENU) to enter the Main Menu.
2Press to scroll to System Setting and press (OK).
3Press to scroll to Search and press (OK).
4Scroll to your preferred search setting and press (OK).
5Do one of the following:
-If you selected Normal, press any key or wait 3 seconds to return to
standby.
-If you selected Manual, press to scroll to a network you use and
press (OK) to select it. Then, press any key or wait 3 seconds to
return to standby.
-If you selected New Search, an available network name is
displayed. Press (YES) to select it or (NO) to have the
phone search for another available network. After you select a
network, press any key or wait 3 seconds to return to standby.
Service Priority
Your phone automatically searches for available networks when powered
on. To change the service priority order, follow this procedure. If you are
not sure which service you have, contact your wireless service provider.
1From standby, press (MENU) to enter the Main Menu.
2Scroll to System Setting and press (OK).
3Scroll to SVC Priority and press (OK).
4Scroll to Custom and press (OK).
• This display shows the default search order:
Residential: When turned on, the phone first
searches for its home base station.
Private: The phone then searches for an in-
building system.
Public: The phone searches for any available
networks.
5Press or to change the SVC Priority order.
6When your preferred order is displayed, press (OK).
Before Requesting Help 61
A
Before Requesting Help
A
As you learn how to use all of your phone’s features, you may occasionally experience
minor problems. Fortunately, you can fix most of these problems yourself. Listed below
are some of the problems you might encounter, as well as procedures that may help
you arrive at a solution. If your problem persists, please contact your wireless service
provider or visit Panasonic’s website at www.panasonic.com.
Problems and Solutions
Problem Possible Cause(s) Solution(s)
Phone will not turn
on
Battery is too low or not
charged.
Recharge the battery. Or, connect the
AC or DC adapter.
Battery contacts need to
be cleaned.
Wipe the battery contacts and phone
contacts with a dry cloth.
was not pressed
long enough.
Try pressing and holding for at
least three seconds.
“Initialization
Error xxxx” or
“Run Time Error
xxxx” is displayed
Your phone has detected
a programming error.
Contact your wireless service
provider.
Phone turns off
inadvertently
Battery is too low or will
not hold a charge.
Connect an AC or DC adapter and
confirm that the battery icon is
displayed. If the battery icon is not
displayed, contact your wireless
service provider.
Keys do not work
when pressed
Keypad may be locked.
(The display shows Key
Lock On.)
If Key Lock On is displayed, press
(UNLOCK) and then (YES)
to unlock.
Phone may not be on. Verify that phone is on.
Unable to store
entries into
Phonebook
The Phonebook is full. Delete an entry from the Phonebook.
(See
“Editing/Deleting a Phonebook
Entry” on page 31 for details.)
Appendix A
62 Before Requesting Help
The Basics
Battery will not
recharge
The ambient air
temperature exceeds
113°F (45°C) or is less
than 32°F (0°C).
Lower or raise the air temperature;
allow the phone to cool off or warm up
before recharging.
Contact between your
battery and recharger is
incomplete.
Disconnect your charger from the
phone and then try reconnecting it.
The battery has not been
charged for a long time
and has been deeply
discharged.
Attempt to recharge the battery. It
may take a few minutes for recharging
to begin. If the battery will not
recharge, replace it.
The battery is defective. Replace the battery.
Note: It’s normal for a battery to
slowly lose its ability to hold a charge.
No Service is
displayed
Signal is too weak. Move to another location, or wait a
few minutes if you are traveling in an
automobile.
If you are in a building, move near a
window or go outside to send or
receive calls.
Note: If you know you are in a cellular
service area and the phone continues
to indicate No Service, contact your
wireless service provider.
Unable to receive
calls
Phone is off. Turn on phone.
Security features may be
set so that the phone will
not receive calls.
Check Security Options settings. (See
“Call Lock” on page 47 for more
information.)
Answer Options setting is
set to use to
answer a call.
Press to answer a call or
change the Answer Key setting to
Any Key. (See “Answer Key Options”
on page 28.)
Service is not activated. Contact your wireless service
provider.
Problems and Solutions
Problem Possible Cause(s) Solution(s)
Appendix A
Before Requesting Help 63
Missing incoming
calls
Ring volume may be set
to silent.
Set ring volume on.
Phone was not
programmed correctly by
dealer or carrier.
Contact your wireless service
provider.
Calls dropped/
disconnected
inadvertently
You are outside of a
cellular service area.
Check your wireless service
provider’s coverage map (including
roaming areas) and try to move to a
location within the coverage area. If
problems persist, contact your
wireless service provider.
Phone automatically
disconnects calls when
the battery level is low.
Recharge the battery.
Unable to enter text
as intended when
pressing keys
Phone may be in
WORD T9 ( ) mode
instead of Letter ( )
mode.
If shows above the right
softkey ( ), press the right softkey
( ) until appears above it.
(See Chapter 4, “Text Entry
Operations”.)
Lost or forgot lock
code
Try entering 1234 as the lock code.
Check inside back cover for new lock
code.
Contact your wireless service
provider.
Unable to place
calls
Phone is off. Confirm phone is on.
Security features may be
set so that the phone
cannot place calls.
Check Security Options settings. (See
“Call Lock” on page 47 for more
information.)
You are outside of a
cellular service area.
Check your wireless service
provider’s coverage map (including
roaming areas) and try to move to a
location within the coverage area.
An error was made
dialing the number.
Confirm the number is correct.
Service is not activated. Contact your wireless service
provider.
Problems and Solutions
Problem Possible Cause(s) Solution(s)
Appendix A
64 Before Requesting Help
The Basics
Unable to access
Voice Mailbox
Voice Mail phone number
is not programmed into
phone.
Program Voice Mail phone number.
Refer to additional information from
your wireless service provider.
DTMF tones may be set
to short instead of long.
Set DTMF tones to long. (See “DTMF
Duration” on page 46 for details.)
Voice Mail service is not
activated.
Contact your wireless service
provider.
Unable to set a
subscriber feature
The feature you are
trying to set is not offered
by your wireless service
provider.
Contact your wireless service provider
for more information.
It is difficult to hear
the other party
Your phone’s earpiece
volume is set too low.
Press during conversation.
You can hear the
other party, but the
other party can’t
hear you
Your microphone may be
muted.
If the display shows Muted, press
(UNMUTE).
Handsfree headset
does not work
when plugged into
phone
TTY Mode is set to On. Select TTY Mode in the Miscella-
neous menu and set it to Off.
TTY device does
not work when
plugged into phone
TTY Mode is set to Off. Select TTY Mode in the Miscella-
neous menu and set it to On.
Problems and Solutions
Problem Possible Cause(s) Solution(s)
Phone Accessories 65
B
Phone Accessories
B
A variety of accessories are available for your Panasonic phone. Contact
your local wireless service provider to purchase Genuine Panasonic
accessories.
Note: Replacement antennas are available from Panasonic.
In the U.S., call 1 (800) 833-9626.
In Canada, contact your cellular dealer.
Using non-Panasonic accessories or accessories not recommended by your
wireless service provider may result in poor performance of your phone, or even
cause an electrical hazard.
EB-TX320 Accessories
Battery (Li-Ion 740 mAh)
EB-BS310B (Blue)
EB-BS310S (Silver)
EB-BS310K (Titanium) Private Handsfree Headset
EB-EM300
AC Adapter (400 mA)
EB-CA340
AC Adapter (700 mA)
EB-CA370
Data Cable
EB-RS300 DC Adapter
EB-CD300
Appendix B
66 Phone Accessories
The Basics
EB-TX320 Accessories (cont.)
TTY Cable
EB-WA300 Belt Clip
EB-YK300
EB-HF300EZ Handsfree Car Kit
DC Adapter
EB-CD300 Headset
Handset Holder Car Holder
Consumer Update 67
C
Consumer Update
C
Consumer Update on Mobile Phones
(Published by U.S. Food and Drug Administration, Center for Devices and Radiological
Health, October 20, 1999.)
FDA has been receiving inquiries about the safety of mobile phones, including cellular
phones and PCS phones. The following summarizes what is known--and what remains
unknown--about whether these products can pose a hazard to health, and what can be done
to minimize any potential risk. This information may be used to respond to questions.
Why the concern?
Mobile phones emit low levels of radiofrequency energy (i.e., radiofrequency radiation) in
the microwave range while being used. They also emit very low levels of radiofrequency
energy (RF), considered non-significant, when in the stand-by mode. It is well known that
high levels of RF can produce biological damage through heating effects (this is how your
microwave oven is able to cook food). However, it is not known whether, to what extent, or
through what mechanism, lower levels of RF might cause adverse health effects as well.
Although some research has been done to address these questions, no clear picture of the
biological effects of this type of radiation has emerged to date. Thus, the available science
does not allow us to conclude that mobile phones are absolutely safe, or that they are
unsafe. However, the available scientific evidence does not demonstrate any adverse health
effects associated with the use of mobile phones.
What kind of phones are in question?
Questions have been raised about hand-held mobile phones, the kind that have a built-in
antenna that is positioned close to the user’s head during normal telephone conversation.
These types of mobile phones are of concern because of the short distance between the
phone’s antenna — the primary source of the RF — and the person’s head. The exposure to
RF from mobile phones in which the antenna is located at greater distances from the user
(on the outside of a car, for example) is drastically lower than that from hand-held phones,
because a person’s RF exposure decreases rapidly with distance from the source. The
safety of so-called “cordless phones", which have a base unit connected to the telephone
wiring in a house and which operate at far lower power levels and frequencies, has not been
questioned.
How much evidence is there that hand-held mobile phones might be harm-
ful?
Briefly, there is not enough evidence to know for sure, either way; however, research efforts
are on-going. The existing scientific evidence is conflicting and many of the studies that
have been done to date have suffered from flaws in their research methods. Animal
experiments investigating the effects of RF exposures characteristic of mobile phones have
yielded conflicting results. A few animal studies, however, have suggested that low levels of
RF could accelerate the development of cancer in laboratory animals. In one study, mice
genetically altered to be predisposed to developing one type of cancer developed more than
twice as many such cancers when they were exposed to RF energy compared to controls.
There is much uncertainty among scientists about whether results obtained from animal
studies apply to the use of mobile phones. First, it is uncertain how to apply the results
obtained in rats and mice to humans. Second, many of the studies that showed increased
tumor development used animals that had already been treated with cancer-causing
chemicals, and other studies exposed the animals to the RF virtually continuously — up to
22 hours per day.
For the past five years in the United States, the mobile phone industry has supported
research into the safety of mobile phones. This research has resulted in two findings in
particular that merit additional study:
Appendix C
68 Consumer Update
The Basics
1 In a hospital-based, case-control study, researchers looked for an association between
mobile phone use and either glioma (a type of brain cancer) or acoustic neuroma (a benign
tumor of the nerve sheath). No statistically significant association was found between mobile
phone use and acoustic neuroma. There was also no association between mobile phone use
and gliomas when all types of gliomas were considered together. It should be noted that the
average length of mobile phone exposure in this study was less than three years.
When 20 types of glioma were considered separately, however, an association was found
between mobile phone use and one rare type of glioma, neuroepithelliomatous tumors. It is
possible with multiple comparisons of the same sample that this association occurred by
chance. Moreover, the risk did not increase with how often the mobile phone was used, or
the length of the calls. In fact, the risk actually decreased with cumulative hours of mobile
phone use. Most cancer causing agents increase risk with increased exposure. An ongoing
study of brain cancers by the National Cancer Institute is expected to bear on the accuracy
and repeatability of these results.1
2 Researchers conducted a large battery of laboratory tests to assess the effect of exposure to
mobile phone RF on genetic material. These included tests for several kinds of
abnormalities, including mutations, chromosomal aberrations, DNA strand breaks, and
structural changes in the genetic material of blood cells called lymphocytes. None of the tests
showed any effect from the RF except for the micronucleus assay, which detects structural
effects on the genetic material. The cells in this assay showed changes after exposure to
simulated cell phone radiation, but only after 24 hours of exposure. It is possible that
exposing the test cells to radiation for this long resulted in heating. Since this assay is known
to be sensitive to heating, heat alone could have caused the abnormalities to occur. The data
already in the literature on the response of the micronucleus assay to RF are conflicting.
Thus, follow-up research is necessary.2
FDA is currently working with government, industry, and academic groups to ensure the
proper follow-up to these industry-funded research findings. Collaboration with the Cellular
Telecommunications Industry Association (CTIA) in particular is expected to lead to FDA
providing research recommendations and scientific oversight of new CTIA-funded research
based on such recommendations.
Two other studies of interest have been reported recently in the literature:
1 Two groups of 18 people were exposed to simulated mobile phone signals under laboratory
conditions while they performed cognitive function test. There were no changes in the
subjects’ ability to recall words, numbers, or pictures, or in their spatial memory, but they
were able to make choices more quickly in one visual test when they were exposed to
simulated mobile phone signals. This was the only change noted among more than 20
variables compared.3
2 In study of 209 brain tumor cases and 425 matched controls, there was no increased risk of
brain tumors associated with mobile phone use. When tumors did exist in certain locations,
however, they were more likely to be on the side of the head where the mobile phone was
used. Because this occurred in only a small number of cases, the increased likelihood was
too small to be statistically significant.4
In summary, we do not have enough information at this point to assure the public that
there are, or are not, any low incident health problems associated with use of mobile
phones. FDA continues to work with all parties, including other federal agencies and
industry, to assure that research is undertaken to provide the necessary answers to the
outstanding questions about the safety of mobile phones.
What is known about cases of human cancer that have been reported in
users of handheld mobile phones?
Some people who have used mobile phones have been diagnosed with brain cancer. But
it is important to understand that this type of cancer also occurs among people who have
not used mobile phones. In fact, brain cancer occurs in the U.S. population at a rate of
about 6 new cases per 100,000 people each year. At that rate, assuming 80 million users
of mobile phones (a number increasing at a rate of about 1 million per month), about 4800
cases of brain cancer would be expected each year among those 80 million people,
whether or not they used their phones. Thus it is not possible to tell whether any
Appendix C
Consumer Update 69
individual’s cancer arose because of the phone, or whether it would have happened
anyway. A key question is whether the risk of getting a particular form of cancer is greater
among people who use mobile phones than among the rest of the population. One way to
answer that question is to compare the usage of mobile phones among people with brain
cancer with the use of mobile phones among appropriately matched people without brain
cancer. This is called a case-control study. The current case-control study of brain cancers
by the National Cancer Institute, as well as the follow-up research to be sponsored by
industry, will begin to generate this type of information.
What is FDA’s role concerning the safety of mobile phones?
Under the law, FDA does not review the safety of radiation-emitting consumer products
such as mobile phones before marketing, as it does with new drugs or medical devices.
However, the agency has authority to take action if mobile phones are shown to emit
radiation at a level that is hazardous to the user. In such a case, FDA could require the
manufacturers of mobile phones to notify users of the health hazard and to repair, replace
or recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory actions at this time, FDA
has urged the mobile phone industry to take a number of steps to assure public safety.
The agency has recommended that the industry:
• support needed research into possible biological effects of RF of the type emitted by mobile
phones;
• design mobile phones in a way that minimizes any RF exposure to the user that is not
necessary for device function; and
• cooperate in providing mobile phone users with the best possible information on what is
known about possible effects of mobile phone use on human health.
At the same time, FDA belongs to an interagency working group of the federal agencies
that have responsibility for different aspects of mobile phone safety to ensure a
coordinated effort at the federal level. These agencies are:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Health and Safety Administration
• National Telecommunications and Information Administration
The National Institutes of Health also participates in this group.
In the absence of conclusive information about any possible risk, what
can concerned individuals do?
If there is a risk from these products — and at this point we do not know that there is — it
is probably very small. But if people are concerned about avoiding even potential risks,
there are simple steps they can take to do so. For example, time is a key factor in how
much exposure a person receives. Those persons who spend long periods of time on their
hand-held mobile phones could consider holding lengthy conversations on conventional
phones and reserving the hand-held models for shorter conversations or for situations
when other types of phones are not available.
People who must conduct extended conversations in their cars every day could switch to
a type of mobile phone that places more distance between their bodies and the source of
the RF, since the exposure level drops off dramatically with distance. For example, they
could switch to
• a mobile phone in which the antenna is located outside the vehicle,
• a hand-held phone with a built-in antenna connected to a different antenna mounted on the
outside of the car or built into a separate package, or
• a headset with a remote antenna to a mobile phone carried at the waist.
Again, the scientific data do not demonstrate that mobile phones are harmful. But if people
are concerned about the radiofrequency energy from these products, taking the simple
precautions outlined above can reduce any possible risk.
Appendix C
70 Consumer Update
The Basics
Where can I find additional information?
For additional information, see the following websites:
• Federal Communications Commission (FCC) RF Safety Program (select “Information on
Human Exposure to RF Fields from Cellular and PCD Radio Transmitters”):
http://www.fcc.gov/oet/rfsafety
• World Health Organization (WHO) International Commission on Non-lonizing Radiation
Protection (select Qs & As):
http:// www.who.int/peh-emf
• United Kingdom, National Radiological Protection Board:
http://www.nrpb.org.uk
• Cellular Telecommunications Industry Association (CTIA):
http://www.wow-com.com
• U.S. Food and Drug Administration (FDA) Center for Devices and Radiological Health:
http://www.fda.gov/cdrh/consumer/
1 Muscat et al. “Epidemiological Study of Cellular Telephone Use and Malignant Brain
Tumors”. In: State of the Science Symposium; 1999 June 20; Long Beach,
California.
2 Tice et al. “Tests of mobile phone signals for activity in genotoxicity and other
laboratory assays”. In: Annual Meeting of the Environmental Mutagen Society.
March 29,1999, Washington, D.C. and personal communication, unpublished
results.
3 Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K, Butler, S, Lim, E, and Varey, A.
“Effect of a 915-MHz simulated mobile phone signal on cognitive function in man”.
Int. J. Radiat. Biol., April 8, 1999.
4 Hardell, L, Nasman, A, Pahlson, A, Hallquist, Aand Mild, KH. “Use of cellular
telephones and the risk for brain tumors: a case-control study”. Int. J. Oncol., 15:
113-116, 1999.
Index 71
Index
A
Accessories 65
Accessory connector 7
Adjusting voice volume 17
Aircraft
using your phone in 4
Alarm clock, using your phone as 42
Alarm, setting 42
Alert mode 41
Alert settings
general rings 39
message alert type 39
ring alert 13
vibration alert 13
Answered calls 36
Answering calls 17
Answering your phone
key options 20
Auto answer 41
Automatic redial 21
B
Battery precautions 1
C
Call history
adding a prefix to a number 36
deleting a number 37
deleting all entries 37
dialed calls 35
missed calls 35
received calls 36
saving a number 37
Call lock 47
Call timers 38
Call waiting 49
Caller ID 49
Charge time 6
Charging precautions 1
Clear key 7, 8
Creating group lists 55
D
Daily alarm 43
Date and time, setting 42
Decreasing voice volume 17
Deleting all Phonebook entries 32
Deleting messages 54
Digit keys 8
Digital service 15
Display icon descriptions 9
Displaying your own number 18, 32
Driving while using phone 3
Dropped call tone 40
DTMF duration 46
E
Emergency (911) calls 2
Emergency call
enabling & disabling Super Dial key
45
Ending a call 15
Entering symbols (SYM) mode 25
Entering text
using Letter Entry mode 23
using Word Entry (Word T9) mode
24
F
Fixing phone problems
"Initialization Error xxxx" appears on
display 61
"Run Time Error xxxx" appears on
display 61
battery won’t recharge 62
calls dropped inadvertently 63
difficult to hear other party 64
handsfree headset does not work 64
keys do not work when pressed 61
lock code lost or forgotten 63
missing incoming calls 63
No Service is displayed 62
other party unable to hear you 64
phone won’t turn on 61
Index
72 Index
Fixing phone problems (cont.)
TTY device does not work 64
unable to access Voice Mailbox 64
unable to place calls 63
unable to receive calls 62
unable to set a subscriber feature 64
unable to store entries in phonebook
61
Function key descriptions 8
G
General precautions 1
Group lists 54
creating 55
viewing 56
H
Handsfree headset
using 14
Headset/TTY Connector 7
Home key 8
I
Icons appearing on display 9
Icons used in manual viii
In-call features 17
Increasing voice volume 17
Indicator light 7
Intercept tone 40
K
Key entry table 25
Key lock 22
Key volume 38
L
Language
setting for your phone 44
Last dialed calls 35
Left softkey 8
Listening to voice mail 20, 57
Lock code
changing 46
lost or misplaced 46
Locking outgoing calls 47
Lost lock code 47
M
Making a call 15
MEMO key 7, 8
Memory location map 28
Message alert settings 39
general rings 39
Message key 8
Messages
accessing 50
calling back 53
composing 50
deleting 54
forwarding 52
locking 52
reading 51
replying to 52
Miscellaneous menu 44
Missed calls
viewing 19
Muting mouthpiece 18
N
NAM (Number Assignment Module)
59
Navigation key 7, 8
Normal mode 41
O
One time alarm 43
Outbox messages
viewing 53
P
Pause key 8
Pauses
programming in phone number 30
Phone description 7
Phone settings
alarm setting 42
alert mode 41
answer key 20
answer mode 41
display 40
DTMF duration 46
emergency call 45
languages 44
model type 44
time setting 11
TTY mode 45
warning tone 44
welcome screen 44
Index 73
Phonebook
creating an entry 27
deleting all entries 33
deleting an entry 31
dialing calls from 16
editing an entry 31
searching 32
Phonebook entry
saving in memory 28
Phonebook icons 10
Placing a call 15
with Speed Dial 16
with Super Dial 16
Power-on lock 48
Precautions 1
Preset message, selecting 43
PWR/End key 7, 8
Q
Quiet mode 41
R
Reading text messages 51
Received calls 36
Recharging your battery
battery specifications 6
low-battery warning 6
recharging tips 6
Redialing numbers 21
automatically 21
Reorder tone 40
Restricting calls 47
Right softkey 8
Ring alert settings
general rings 13
Ring alert, selecting 13
Ring volume, setting 12
S
Safety tips
aircraft 4
antenna care 3
blasting areas 4
driving 3
electronic devices 3
explosive atmospheres 4
phone operation 3
vehicles with air bags 4
Scratchpad
using display as 18
Security options
call lock 47
changing lock code 46
turning off power-on lock 48
Selecting your phone number 59
Send key 7, 8
Softkeys 7
Speakerphone, turning on and off 19
Speakerphone/Quiet Mode key 8
Speed dial 16
Standby display 11
Standby time 6
Super Dial
assigning keys 16
enabling & disabling emergency call
assignment 45
Symbols
entering in a text message 25
System setting menu 59
searching for available systems 60
selecting your phone number (NAM)
59
service priority 60
voice privacy 59
T
Talk time 6
Three-way calling 49
Time and date settings
changing 11
Tone settings
keypad volume 38
message alert 39
ring alert 13
ring volume 12
vibration alert 13
warning tone 39
TTY mode
setting on and off 45
U
Unanswered (missed) calls 19
74 Index
V
Vibration alert, setting 13
Viewing group lists 56
Viewing your phone number 32
during a call 18
Voice mail 53
listening to new 20
Voice mailbox number
resetting 57
Voice privacy 59
Voice volume
adjusting 17
Volume (keypad) 38
W
Waits
programming in phone number 30
Warning tone settings 39
Welcome screen, creating 44

Navigation menu
