Panasonic Mobile Communications Development of USA 21C001A GSM Cellular Mobile Radio User Manual X800 China OI

Panasonic Mobile Communications Development Corpor GSM Cellular Mobile Radio X800 China OI

Contents

User Manual 3

109
VOICE TAGS
When your phone is set language that is not available in Voice Commands, Voice Tags
allows you to record names and related phone numbers and store them in memory. That
you can dial these numbers using Voice Commands.
Record Voice Tags
1. Press and hold .
• If you are using this feature for the first time, the phone displays a message that
no voice tags are recorded.
2. Select Add voice tag.
3. After the text prompt to say a name, say a name that you will say each time you wish
to call this person.
4. The phone will repeat the name. Press Yes to confirm, or press No to record it
again.
5. After you have confirmed, enter the number to dial by pressing to , then
press OK.
Dial a Number using a Voice Tag
1. Press and hold .
2. After the text prompt asking who you would like to call, say a name of a voice tag
you have recorded.
3. The phone will begin dialing the number assigned to the voice tag.
Add or Edit Voice Tags
You can store up to 30 voice tags, and edit or erase voice tags as needed.
To add a voice tag:
1. Press and hold .
2. Press Settings.
3. A list of voice tag phone numbers displays.
4. Select Add voice tag.
Application
Launcher
Check to select applications from the list to open using Open
Applications.
Contacts Update Each time Voice Commands is opened, it checks your Contacts
list for name additions or edits, and if so, automatically reloads
the list. If the list is large, the reload requires more time. Select
Configure to choose Automatic or Manual reloading.
About Copyright information about the voice recognition software.
Note: Voice Tags appears only when your phone is set to a language that is
not available in Voice Commands.
X800_China_OI.book Page 109 Tuesday, November 16, 2004 11:25 AM
110
5. Continue with step 3 in Record Voice Tags on page 109.
To edit a voice tag:
1. Press and hold .
2. Press Settings.
3. A list of voice tag phone numbers displays.
4. Highlight and select desired voice tag phone number to edit.
5. Choose from: Play, Re-record, Erase, or Erase all.
PRINTBOY SETUP
PrintBoy Setup works with your Quickoffice menu to print your Quickoffice documents
wirelessly from your phone to supported printers.
From Settings menu:
1. Open PB Setup.
2. On the Drvrs tab is a list of supported printer drivers. Scroll to desired printer.
3. Press Options and select Configure. Select from:
4. After the printer is configured, press Options and select:
To set a printer as default, scroll to Drvrs tab, highlight desired printer, then press
Options and select Set as Default.
ABOUT
View copyright information about the phone and software used on the phone.
From Settings application:
1. Open About.
Communications Select the method to send data to the printer.
Paper Size Choose a paper size.
Left Margin Choose desired left margin measurement.
Test Print Send a test print.
Bluetooth > Select Find Printer to pair with the printer.
X800_China_OI.book Page 110 Tuesday, November 16, 2004 11:25 AM
111
TOOLS
Tools allows you to take care of a variety of tasks in one place. Use the Calculator to
make quick calculations. Use the Converter to convert currencies and measurements.
Jot down quick notes on the Notepad. Record short voice clips using Recorder. See
your files in one place using File Mgr and manage data stored on the miniSD Card.
Install Java™ MIDlet (Mobile Information Device) applications using App Mgr.
Tools menu contains these main options:
CALCULATOR
Perform simple mathematic calculations using the calculator.
From Tools application:
1. Open Calculator.
2. A virtual calculator displays. Type in first number of calculation,
which appears in field near bottom of screen.
• To enter a decimal, press .
• To erase digits, press .
• To change number to positive or negative, scroll to positive/
negative button and select.
3. Scroll or to move box to desired mathematic action,
press to select.
4. Enter the next number. To get result, scroll to equal button and
select.
• To view the last result, press Options and select Last result.
The left side of the screen serves as a “tape” to record your calculations. Use the double
up and double down arrow buttons on the screen to scroll up and down the “tape.”
To save a number in calculator memory, select the MS (Memory Save) button. To recall
the number, select the MR (Memory Recall) button.
Calculator Converter Notepad
Recorder miniSD To-do
App Mgr File Mgr PhotoLight
SIM Tool Kit
(optional)
Shortcut: To automatically add, subtract, multiply, or divide, enter first
number. Press until you reach desired numeric
operation, stop pressing , and the operation is inserted.
X800_China_OI.book Page 111 Tuesday, November 16, 2004 11:25 AM
112
CONVERTER
Convert a variety of measurements such as world currencies, area, length, volume,
temperature, power, and velocity.
Set the Base Currency
From Tools application:
1. Open Converter.
2. If the Type field is not set to Currency, open and change to Currency.
3. Press Options and select Currency rates. A list of world currencies (3 letter
currency codes) appears with the base currency (if set) noted at the top of the
screen.
• Most commonly used codes are listed first. They are USD = U.S. dollar; EUR =
European Union euro, GBP = British pound sterling, JPY = Japanese yen.
4. Scroll to the desired currency code you wish to set as the base, press Options and
select Set as base curr..
• Any rates entered earlier are reset to zero.
5. Scroll to desired currency codes and type in currency exchange rates, based on
your newly set base currency = 1.
• To enter a decimal, press .
6. Press Done.
7. Continue with step 3 in Convert Measurements on page 112.
Convert Measurements
From Tools application:
1. Open Converter.
2. Open the Type field, scroll to desired measurement type and press OK.
3. Scroll to first Unit field, press Options and select Select unit.
• If converting Currency, press Options and select Change
currency.
4. Scroll to the desired unit to convert FROM, and press OK.
5. Scroll to second Unit field, press Options and select Select
unit.
• If converting Currency, press Options and select Change
currency.
6. Scroll to the desired unit to convert TO, and press OK.
7. Scroll to the first Amount field, press to erase zero. Type in desired unit amount
to convert.
• To enter a decimal, press .
Note: To edit the currency rates, press Options and select Currency rates.
X800_China_OI.book Page 112 Tuesday, November 16, 2004 11:25 AM
113
• To enter + and - (for temperature) and E (exponent) symbols, press .
Converted amount automatically displays in second Amount field.
NOTEPAD
Jot down quick notes into the notepad. Open and edit simple text documents (.txt) saved
from text attachments sent using messaging.
From Tools application:
1. Open Notepad.
2. Press Options and select New note.
To send a note:
From Tools application:
1. Open Notepad.
2. Press Options and select Send > Via text message, Via multimedia, Via e-mail,
Via Bluetooth or Via infrared.
3. To complete text messages, see page 42; or multimedia messages on page 42; or
E-mail messages on page 44; or Bluetooth on page 83; or Infrared on page 85.
RECORDER
Record voice memos up to 1 minute in length. You can also record a two-way phone
conversation. Recorded sound clips are stored in .amr format.
Record a Sound Clip
From Tools application:
1. Open Recorder.
2. Press Options and select Record sound clip.
3. Begin speaking into microphone. Press Stop to stop recording.
• Seconds counter bar near bottom of screen and Length counter both keep track
of seconds elapsed.
4. To rename the sound clip to find it in the list, press Options and select Rename
sound clip.
Play Back a Sound Clip
If sound clip was just recorded, go to step 4. Or from Tools application:
1. Open Recorder.
2. Press Options and select Go to Gallery.
3. Open desired folder, then scroll to desired sound clip and open.
Note: You can also convert amounts in reverse. Type in amount in
second field, converted amount automatically displays in first field.
X800_China_OI.book Page 113 Tuesday, November 16, 2004 11:25 AM
114
4. Select on screen Play button.
• Volume control - Scroll to adjust volume. Note speaker icon and volume steps in
upper part of screen.
• To select buttons on screen, scroll or to move box to button and press :
To play a sound clip during a call, open the sound clip from its current location and play.
The other person hears the sound clip.
Record a Conversation
1. During a phone conversation, press and follow steps 1 to 3 in Record a Sound
Clip on page 113.
2. The conversation records.
3. Press Stop to stop recording.
Send a Sound Clip
If sound clip was just recorded, go to step 4. Or, from Tools application:
1. Open Recorder.
2. Press Options and select Go to Gallery.
3. Open desired folder, then scroll to desired sound clip.
4. Press Options and select Send > Via multimedia, Via e-mail, Via Bluetooth or
Via infrared.
5. To complete multimedia messages, see page 42; or E-mail messages on page 44;
or Bluetooth on page 83; or Infrared on page 85.
Recorder Settings
From Tools application:
1. Open Recorder.
2. Press Options and select Settings. Scroll to:
Play: Pause: Rewind:
Stop: Fast forward: Record:
Caution: You are responsible for the security of a recorded message.
Ask for the other party’s consent before recording, and
abide by local voice recording laws.
Memory in use Store recordings in phone memory or miniSD Card
Default speaker Choose Loudspeaker or Handset
X800_China_OI.book Page 114 Tuesday, November 16, 2004 11:25 AM
115
Use Recording as a Ringing Tone
To use a recording as a ringing tone, record a sound clip as described in Record a
Sound Clip on page 113.
The new sound clip automatically appears in the Ringing tone lists in the Ringtones,
Contacts, Clock, and Calendar alarm applications. See Ringtones on page 91; Assign a
Ringing Tone on page 33; and Set Alarms on page 105 to assign ringing tones.
MINISD CARD (MEMORY CARD)
Backup your phone memory onto the miniSD memory card. miniSD Cards can be
installed into the standard size memory card socket of other devices using the miniSD
Card adapter (see Using miniSD Card and miniSD Adapter on page 116). Data file size
of miniSD Card may vary with current availability.
Remove miniSD Card
1. Press , scroll to Eject miniSD Card and press OK. Wait for file saving or copying
process to finish before removing miniSD Card.
2. Continue with Removing miniSD Card on page 10.
Format, View Details of miniSD Card
Backup Files
From Tools application:
1. Open miniSD. A list indicating name, storage capacity, storage used, and storage
free displays.
2. Press Options and select:
Warning: Do not format a miniSD Card that contains important
software as this destroys all data on the miniSD Card.
Remove miniSD Card Saves data and closes applications before ejecting miniSD Card
Backup phone mem. Backup the phone contents to the miniSD Card
X800_China_OI.book Page 115 Tuesday, November 16, 2004 11:25 AM
116
Password in some miniSD Cards
Some brands of miniSD Cards can be locked from unapproved use by entering a
password. If you insert a miniSD Card with locking capability into your phone, the
following option items will appear.
From Tools application:
1. Open miniSD.
2. Press Options and select:
Using miniSD Card and miniSD Adapter
By inserting the miniSD Card into the miniSD adapter, you can use the miniSD Card in
an SD memory card compatible personal computer. Back up data and print images
using a printer.
To insert the miniSD Card into the miniSD adapter:
1. On miniSD adapter, move lock tab into
unlocked position.
2. Slide miniSD Card in with notched
corner entering the left side of the
miniSD adapter first into the pocket until
it clicks.
3. Follow manufacturer’s instructions for
inserting an SD card in the compatible
personal computer and accessing the
data.
Restore from card Restore earlier backed up miniSD Card data to the phone mem-
ory
Format miniSD Card Format other brand miniSD Cards if needed before first use
miniSD Card name Write a name or title for the miniSD Card
Memory details View number of bytes stored in separate applications such as
Calendar, Messages, documents. Also view total memory in use
and free memory.
Set password Enter a password to use to lock the miniSD Card. Thereafter, the
password must be entered to use the miniSD Card in any
device.
Remove password Removing the password unlocks the miniSD Card, and it can be
used in another device without a password.
Change password Change locking password for this miniSD Card.
Unlock miniSD Enter the password to unlock the miniSD Card.
X800_China_OI.book Page 116 Tuesday, November 16, 2004 11:25 AM
117
WRITE-PROTECT miniSD CARD
• To protect important data, move write-protect switch to Lock position. The miniSD
Card is write-protected and you cannot write, save, or delete data or format the card.
• To write data to the miniSD Card, move write-protect switch to unlocked position.
TO-DO LIST
Make a list of tasks, and set a deadline and priority for each.
Create a New To-do Task
From Tools application:
1. Open To-Do.
2. Press Options and select New to-do note.
3. Enter information in fields:
4. Press Done to save.
Edit and Mark To-do Tasks
From Tools application:
1. Open To-Do.
2. Scroll to the desired task.
• To edit, open task and edit information in fields as desired.
• To mark the task as completed or to restore task, press Options and select Mark
as done, or Mark as not done.
Subject Description of task or subject
Due date Assign a due date
Priority Open and select High, Normal or Low.
Note: In the list of tasks, ! icon means High priority task;
- icon means Low priority task.
Note: A checkmark within a box means task is completed.
A blank box means task is unfinished.
X800_China_OI.book Page 117 Tuesday, November 16, 2004 11:25 AM
118
APPLICATION MANAGER
The Application Manager allows you to install and manage both Java™ MIDlet (Mobile
Information Device) applications and device software installation files. Examples include
games, secure information storage, and compression software. You can also view and
manage Authority and Personal certificates (see Certificate Management on page 101).
View Details of Application
From Tools application:
1. Open App Mgr.
2. Scroll to desired application installation file.
• Files with extension .sis are device software installation files. Files with
extensions .jad or .jar are Java™ applications.
3. Press Options and select View details.
• A list displays with details such as name, version, type, certificate and signature
details, trust status for MIDlets, application size, application supplier.
View Certificate
From Tools application:
1. Open App Mgr.
2. Scroll to desired application installation file.
3. Press Options and select View certificate.
• A list displays with details such as issuer, subject, validity period, serial number,
and fingerprint.
See Certificate Management on page 101.
Install Application or Software
Your phone supports installation of software and applications suitable for the Symbian™
operating system. Because these files are usually large and compressed, be sure to
reserve enough time and phone memory for the entire installation procedure.
From Tools application:
1. Open App Mgr.
2. Scroll to desired application installation file.
3. Press Options and select Install.
If there is no digital signature or certificate attached to the software or application, the
phone issues warnings of the risks of installing without verifying the source. You should
only install software or applications from sources that you have personally verified and
of which you are absolutely sure.
Note: Panasonic is not responsible for the performance of downloaded
content or possible corruption of phone software.
X800_China_OI.book Page 118 Tuesday, November 16, 2004 11:25 AM
119
You will see messages asking if you wish to continue or cancel during different phases
of the installation process.
If the installation process is cancelled for some reason, such as the phone runs out of
memory, then the installation is not complete, or partial. To complete the partial
installation, either delete the partially installed application, or reinstall the application.
If there are problems with installation, you can view the installation log or send the
installation log to a help desk for troubleshooting. Press Options and select View log or
Send log.
Remove Application or Software
From Tools application:
1. Open App Mgr.
2. Scroll to desired application installation file.
3. Press Options and select Remove.
FILE MANAGER
Organise and manage files stored in the phone memory and on the miniSD Card. It’s an
easy way to find files and folders.
View Folders and Files
From Tools application:
1. Open File Mgr.
2. A list of folders and files stored in the phone memory appears.
Some folders may have sub folders, for example, Images
folder has two sub folders - Picture msgs. and Wallpapers.
Files that have not been stored in a folder are listed after the
folder names.
• Scroll to view folders and files stored on the miniSD Card.
3. Scroll to desired folder or file and open.
Find Folders and Files
Type letters or keywords in a search box to find a folder or file.
From Tools application:
1. Open File Mgr.
2. Press Options and select Find.
3. Choose to look in the phone memory or miniSD Card.
Note: Removing a software application may cause you to not be able
to view documents created with that software, and other
software may not work if it relies on the removed software.
X800_China_OI.book Page 119 Tuesday, November 16, 2004 11:25 AM
120
4. Type in the keyword to find, or just type in a few letters, and press Find.
5. After a brief period of searching, a list of files and folders containing the keyword
displays.
6. The list is sorted from closest match first to farthest match last. Folders and files with
the same name appear with folder before file.
Manage Folders and Files
From Tools application:
1. Open File Mgr.
2. Press Options and select:
Send Files
From Tools application:
1. Open File Mgr.
2. Open desired folder, then open file.
3. Press Options and select Send > Via multimedia, Via e-mail, Via Bluetooth, or
Via infrared.
Open Open the selected folder or file.
Delete Delete the selected folder or file.
Move to folder Move selected item to another folder.
Copy to folder Copy selected item to another folder, leaving the original in its
current place.
New folder Create a new folder.
Mark/Unmark Mark or unmark several files at once. Not available for folders.
Rename Change name of item. Default folders cannot be renamed.
Receive via infrared To receive a file via Infrared, see page 85.
View details View name, format type, date and time modified, size in bytes or
kilobytes (if item is a folder, size is total of all files and folders
inside the folder), whether it is a default folder, amount of sub
folders, and amount of files.
Memory details View number of bytes stored in separate applications such as
Calendar or Messages. Also view total memory in use and free
memory. View phone memory on phone memory tab, or scroll
for miniSD Card memory.
X800_China_OI.book Page 120 Tuesday, November 16, 2004 11:25 AM
121
4. To complete multimedia messages, see page 42; or e-mail messages on page 44;
or Bluetooth on page 83; or Infrared on page 85.
PHOTOLIGHT
Light up your subject before snapping a picture or recording
a video clip. To turn on the PhotoLight,
1. From standby mode, press and hold .
2. Open Camera and continue with Take a Picture on
page 58. To record a video clip, continue with Record a
Video Clip on page 71.
To switch off PhotoLight, return to standby mode, then press
and hold .
Or, you can switch on or off PhotoLight from Tools
application:
1. Open PhotoLight.
Unlike a camera flash, the PhotoLight does not flash. PhotoLight remains on until you
switch it off.
Use PhotoLight as a Flashlight
The PhotoLight can be switched on to use as a small flashlight.
1. In standby mode, press and hold . The PhotoLight switches on.
To switch off the PhotoLight, return to standby mode, then press and hold .
• Whether or not you close the flip, the PhotoLight remains on until you switch it off.
• The PhotoLight also switches off when the phone is switched off.
Note: The phone may not allow you to copy, modify, transfer or forward
some copyrighted images, ringtones or other content.
Send is not available if a folder or playlist is highlighted.
Note: Do not use the PhotoLight near the eyes. The PhotoLight is
intended as an auxiliary light source for shooting photos in dim
areas. It does not produce the intense light of a typical camera flash.
Battery note: Keeping PhotoLight switched on consumes battery power more
rapidly. To conserve battery power, switch off PhotoLight when not in
use.
PhotoLight
X800_China_OI.book Page 121 Tuesday, November 16, 2004 11:25 AM
122
SIM TOOL KIT
The SIM Tool Kit allows applications existing on the SIM card to interact and operate
with your phone. These applications, stored in the SIM memory, are Value Added
Services. Your network operator can configure your SIM card with applications that can
be seen on your phone as additional menu items.
Contact your network operator for further information.
X800_China_OI.book Page 122 Tuesday, November 16, 2004 11:25 AM
123
CALL LOGS
Check your recent missed calls, received calls, and dialled numbers. View the amount
of data sent and received via GPRS. View details for each incoming and outgoing
communication event such as voice calls, text messages, and GPRS connections.
These features are SIM card dependent.
MISSED CALLS, RECEIVED CALLS, AND DIALLED NUMBERS
When you miss an incoming call, a missed call icon and a note displays on the
standby screen. Press Show to view the details of the missed call.
From Call Logs application:
1. Open Recent calls.
2. Open Missed calls, Received calls, or Dialled nos..
3. List of last 20 calls appears with caller or dialled phone number (or name if entered
in Contacts), date and time of call. Also, scroll or to view lists.
To clear all Recent calls lists (Missed calls, Received calls, and Dialled nos.) at once,
open Recent calls, then press Options and select Clear recent calls.
Call or Add to Contacts
Make a call using a number from the recent calls lists, or add the number to your
Contacts list.
From Call Logs application:
1. Open Recent calls.
2. Locate desired number in Missed calls, Received calls, or Dialled nos., and
highlight.
3. Press Options and select:
Shortcut: To view the Dialled nos. list from the standby screen, press .
Call Dial the number.
Create message > Select Via text message or Via multimedia to create a new
message addressed to the number.
Use number Use the number as a base to edit for dialling a similar number.
Delete Delete highlighted number.
Clear list Erase all numbers from selected list.
Add to Contacts >Create new Contacts card or Update existing card using the
number.
X800_China_OI.book Page 123 Tuesday, November 16, 2004 11:25 AM
124
CALL DURATION
Check duration of last call and accumulated duration of dialled calls, received calls, and
all calls.
From Call Logs application:
1. Open Call duration.
2. Scroll to view duration of Last call, Dialled nos., Received calls, and All calls
(since last counter reset).
• Times indicated in hours:minutes:seconds.
To clear all Call duration lists (Last calls, Dialled nos., Received calls and All calls) at
once, press Options and select Clear timers. Enter the phone lock code and press OK.
See Security Settings on page 99.
To separate Call duration lists into summaries for each of both lines, Line 1, or Line 2,
press Options and select Filter timers.
GPRS DATA COUNTER
View the amount of data in kilobytes sent and received by the phone via GPRS data
packets, for example, WAP pages, e-mail messages, downloaded ringtones and
applications.
From Call Logs application:
1. Open GPRS counter.
2. All sent data and All receiv. data amounts display in kilobytes.
To clear the GPRS counter, press Options and select Clear counters. Enter the phone
lock code and press OK.
See Security Settings on page 99.
CALL LOGS SETTINGS
From Call Logs application:
1. Press Options and select Settings.
2. Scroll to select:
Note: Actual times invoiced from your wireless service provider for calls
and services may vary from the call timers depending on number
of network features purchased, when billing begins and ends,
billing rounding off, etc.
Log duration Choose from No log, 1 day, 10 days, or 30 days to store call
information in the logs.
Show call duration Select Yes to switch on a time elapsed counter to display during
a call.
X800_China_OI.book Page 124 Tuesday, November 16, 2004 11:25 AM
125
GENERAL CALL LOGS
View details for each incoming and outgoing communication event such as voice calls,
text messages, and GPRS connections.
From Call Logs application:
1. Scroll to General Logs tab .
2. A list of communication events displays. Up arrow icon indicates outgoing or
sent; down arrow icon indicates incoming or received events.
3. Press Options and select:
View details Scroll to desired event to view details such as direction (in/out),
type (voice, data, etc.), duration (for calls).
Clear log Clear all events from the log.
Filter Separate events into a list by type such as Outgoing, Incoming,
Voice calls, Data calls.
Add to Contacts > Scroll to desired event to Create new Contacts card or Update
existing card using number or address.
X800_China_OI.book Page 125 Tuesday, November 16, 2004 11:25 AM
126
QUICKOFFICE
Store your Microsoft® Word, Excel, and PowerPoint® documents on your phone. Edit
them right on the phone, then beam or send the new documents to another device, or
save them to the miniSD Card.
VIEW DOCUMENTS
From Quickoffice application:
1. Scroll to Quickword, Quicksheet, or Quickpoint documents tabs.
2. A list of documents in phone memory appears.
3. Press Options and select:
VIEW MICROSOFT® WORD DOCUMENTS
Documents open in read-only full screen view. You must press Options and select Edit
mode to make edits to a document.
Scroll to move one line at a time or scroll to move one page at a time.
Go to shortcuts (percentage through the document): Press for 20%, for 30%,
etc., to go to beginning.
Note: For customer support and more information on Quickoffice, visit
www.quickoffice.com.
Open Open highlighted file.
New Create a new document.
Browse Select the memory to browse. Open folders as needed to view
documents.
File management > Sort files to sort by name, size, date or ext., or Scan location to
Scan default, Scan mail, or Scan all.
Refresh Refresh the list view.
Properties View details of highlighted file.
Send as Send file Via multimedia, Via e-mail, Via Bluetooth, Via
infrared.
Delete Delete highlighted file.
About product View copyright information about the software.
EULA View software license agreement.
Note: You can also view and move your documents from File Manager (see page 119).
X800_China_OI.book Page 126 Tuesday, November 16, 2004 11:25 AM
127
Press Options and select:
EDIT MICROSOFT® WORD DOCUMENTS
1. From an open document, press Options and select Edit mode.
2. Save the document with a new file name.
3. Scroll through the document using:
-- move down one line -- move up one line
-- move left one space -- move right one space
To highlight text to apply a format, press and hold , then scroll or . The text will
highlight. For more text editing options, see Entering Text on page 23.
Press Options and select:
Edit mode Go to Edit mode.
Search > Choose Find, Find Next or Replace. Enter text to be located in
Find field. In other fields, scroll to choose a search range.
Then press Find.
Goto > To go to desired place in the document, choose Top, Percent, or
Bottom.
Zoom > Zoom out, Zoom 100%, or Zoom in document by desired
amount.
Autoscroll Automatically scroll document line by line. Scroll to increase
speed, scroll to decrease speed.
Print Print document by sending it via Multimedia, Bluetooth or
infrared.
View mode Go to View mode.
Font Choose a font name and size to apply to highlighted text.
Style > Choose bold, italic, or underline to apply to highlighted text.
Alignment > Choose left, centre, or right alignment to apply to highlighted
text.
Color Choose a colour to apply to highlighted text.
Bullet Apply bullet to highlighted text.
Search > Choose Find, Find Next or Replace. Enter text to be located in
Find field. In other fields, scroll to choose a search range.
Then press Find.
Print Print document by sending it via Multimedia, Bluetooth or
infrared.
X800_China_OI.book Page 127 Tuesday, November 16, 2004 11:25 AM
128
VIEW MICROSOFT® EXCEL DOCUMENTS
Documents open in read-only full screen view.
Scroll through the document using:
-- move down one cell -- move up one cell
-- move left one cell -- move right one cell
-- toggle between view mode and edit mode
Press Options and select:
EDIT MICROSOFT® EXCEL DOCUMENTS
Documents open in read-only full screen view.
-- toggle between view mode and edit mode
In edit mode:
-- move cursor left within a cell -- move cursor right within a cell
To select cells, press and hold , then scroll , , or .
Press Options and select:
Note: Tables, pictures or embedded objects in Microsoft® Word
documents cannot be displayed on the phone.
If a file containing tables, pictures or embedded objects is
edited and saved on the phone, then the non-text material
may not be saved.
Edit Cell Edit highlighted cell.
Worksheets > Select, insert, rename or delete worksheets.
Toggle Full Screen Toggle between full screen and reduced screen.
Zoom > Choose a size to zoom document.
Freeze > Freeze Row, Column or Both for the highlighted cell.
Adjust Column Width Scroll to adjust column width.
Clipboard > Choose Cut, Copy, Paste or Select All to apply to highlighted
cells.
Search > Choose Find or Replace. Enter text to be located in Find field.
In other fields, scroll to choose a search range. Then press
Find.
Properties Set cursor movement after entry and toggle auto-recalculations.
Print Print document by sending it via Multimedia, Bluetooth or
infrared.
Accept Text Edit Enter the edit.
X800_China_OI.book Page 128 Tuesday, November 16, 2004 11:25 AM
129
VIEW MICROSOFT® POWERPOINT® DOCUMENTS
Documents open in outline view.
Scroll to move between outline, notes, slide, and thumbnail views.
Navigation Shortcuts
Revert Text Edit Revert to previous cell content.
Operators > Choose from list of math operators and commonly used
symbols.
Functions > Choose from list of spreadsheet functions.
Range Select Select a range of cells by highlighting.
Formatting > Choose from list of formatting.
Alignment > Choose Default, Left, Center or Right to apply to highlighted
cells.
Font > Apply Bold or Underline font style.
Color > Apply colour to font or cell.
Style > Choose from list of text and number styles.
Clipboard > Choose Undo, Cut, Copy, Paste or Select All to apply to
highlighted cells.
Clear > Clears highlighted cell formatting, formula content, or both.
Print Print document by sending it via Multimedia, Bluetooth or
infrared.
Note: Macros, pictures, graphs or embedded objects in Microsoft®
Excel documents cannot be displayed on the phone.
If a file containing macros, pictures, graphs or embedded
objects is edited and saved on the phone, then the non-text
material may not be saved.
View Action Keypress
Outline, Notes,
Slide
Toggle between full screen
and partial screen
Slide view full
screen
Zoom out
Zoom in
Fit to screen
Outline, Notes,
Slide
Previous slide
Next slide
or
or
X800_China_OI.book Page 129 Tuesday, November 16, 2004 11:25 AM
130
Options Menu
The Options menu varies in an open PowerPoint® document, depending on which of the
4 views you are using.
Press Options and select:
Thumb
(4 slides per page)
Page up
Page down
Next slide
Previous slide
Outline Collapse slide
Expand slide
Collapse all
Expand all
Edit slide
Toggle Screen Toggle screen in outline, notes, and slide view.
Edit > In outline view, you can edit the entry, insert and delete slides. In
notes view, you can edit the entry.
Outline > In outline view, expand and collapse one or all slides.
Navigate > In all views, move to next or previous page or slide.
Goto > Go to another view.
Pitch > Start or stop pitch device.
Print In outline or notes view, print document by sending it via Multi-
media, Bluetooth or infrared.
Exit > In thumb view, choose Close and save, Close and save as, or
Close and discard.
Note: Animation, multimedia, or embedded objects in Microsoft®
PowerPoint® documents cannot be displayed on the phone.
If a file containing animation, multimedia or embedded objects
is edited and saved on the phone, then the non-text material
may not be saved.
View Action Keypress
X800_China_OI.book Page 130 Tuesday, November 16, 2004 11:25 AM
131
GAMES
Your phone is supplied with two games, MicroGolf and Balloon-Headed Boy.
Download Games
See Download Files from the Internet on page 77. For customer support of downloaded
content, visit the respective supplier’s website.
Free content is available for your X800 phone. For downloading information, visit
www.panasonicbox.com. Availability of this service is dependent on your country/region
or network. The downloaded content is free, however there will be a communication fee
to download.
MICROGOLF GAME
Play 18 holes of a miniature golf game.
From Games application:
1. Open MicroGolf icon.
2. Navigation options:
Note: For customer support and more information on MicroGolf and
Balloon-Headed Boy games, visit the forum at www.morpheme.co.uk.
Battery note: When using a game, keeping Keypad Backlight on
continuously for a long time consumes battery power more
rapidly. To conserve battery power, set Keypad Backlight Time
to “Always off”. See Keypad Backlight Time on page 94.
Note: Panasonic is not responsible for the performance of downloaded
content or possible corruption of phone software.
Rotate clockwise: Scroll or press .
Rotate
counterclockwise:
Scroll or press .
Snap direction to the
diagonal:
Press , , , or .
Increase power: Press or . Release to hit the ball.
Toggle golfer on or off: Press .
Toggle manual scroll to
see further than ball
centered view allows:
Press . Scroll for 4 directions to move the view.
Switch sound on or off: See Options menu.
X800_China_OI.book Page 131 Tuesday, November 16, 2004 11:25 AM
132
BALLOON-HEADED BOY GAME
Move Balloon-Headed Boy through different levels to rescue balloons to bring to the
birthday party. Watch out for the frogs!
From Games application:
1. Open Balloon-Headed Boy icon.
2. The game may show hints of which key to press to move.
3. Navigation options:
Move right: Scroll or press .
Move left: Scroll or press .
Move up: Scroll or press .
Move down: Scroll or press .
Go back one screen: Press .
Switch sound on or off: Press when at title screen below speaker icon.
X800_China_OI.book Page 132 Tuesday, November 16, 2004 11:25 AM
133
FAVOURITES
Favourites serves as a “bulletin board” storing shortcuts to your frequently used
applications or documents stored in phone memory or miniSD Card.
OPEN A FAVOURITES SHORTCUT
Open Favourites application:
1. Scroll to the desired shortcut; press Options and select Open.
Or, press to open.
ADD A SHORTCUT TO FAVOURITES
1. Open the item within the application or open the document in
which you want to store a shortcut in Favourites.
2. Press Options and select Add to favourites.
• Adding to Favourites is available only for certain applications.
MANAGE FAVOURITES
Open Favourites application:
1. Scroll to the desired shortcut.
2. Press Options and select:
To change the wallpaper of the Favourites screen, see Change Wallpaper or
Screensaver on page 93.
Edit shortcut name Change the name of the shortcut.
Shortcut icon When this option appears, choose a different icon picture by
scrolling through grid.
Move A checkmark appears on the shortcut icon. Scroll or to
move to desired location, press OK.
List view/Grid view View the shortcuts in a list view or grid view.
Delete shortcut Remove shortcut from Favourites.
Note: The default shortcuts to Today in Calendar, Inbox in Messages,
and Notepad cannot be deleted, nor can the icon be changed.
X800_China_OI.book Page 133 Tuesday, November 16, 2004 11:25 AM
134
ACCESSORIES
Many accessories are available for your Panasonic phone. Contact your wireless
service provider to purchase Genuine Panasonic accessories. Using non-Panasonic
accessories or accessories not recommended by your wireless service provider may
result in poor performance of your phone, or even cause an electrical hazard.
BATTERY LITHIUM-ION 780 mAh
(EB-BSX800)
Carry a spare battery.
TRAVEL CHARGER
(EB-CAX) (EB-CAX) (EB-CAX)
(EB-CAX) (EB-CAX)
Recharge the battery using any electrical outlet. Plugs for use in many
countries are available.
miniSD CARD
miniSD (secure data) memory card stores sound, video, picture, and voice
files. Card memory size varies.
miniSD CARD ADAPTER
This adapter allows you to use your miniSD Card in a standard SD socket.
See Using miniSD Card and miniSD Adapter on page 116.
CAR CHARGER (DC ADAPTER)
(EB-CDX800)
Recharge the battery using your vehicle’s cigarette lighter socket.
CAR HOLDER
(EB-KAX800)
Mounted in your vehicle to store your phone. Use with personal handsfree
headset for handsfree operation.
Warning: When you use a miniSD Card with an SD Memory Card application
device, please insert the card in the miniSD adapter which is included in
the package. When you use the card with an SD Memory Card
application device, please insert and remove the card with the adapter
at the same time and never leave the adapter in the device.
TBD
TBD
TBD
TBD
X800_China_OI.book Page 134 Tuesday, November 16, 2004 11:25 AM
135
CARRY CASE
(EB-YKX800)
Clip your case to your clothing or purse to keep your phone close.
PERSONAL HANDSFREE HEADSET
(EB-EMD800)
Plug into your phone and talk without holding the phone to your ear.
PRODUCT CD
Transfer data between your phone and your PC, using Bluetooth, Infrared,
or USB data cable.
USB DATA CABLE WITH CHARGING CAPABILITY
(EB-UCX800)
Use this to connect your phone to a PC to transfer data between them.
Use in conjunction with the software provided on the CD-ROM.
BLUETOOTH® HEADSET
(EB-BHX70)
Talk handsfree and without wires. Place the headset on your ear and the
phone in your pocket, with no wires connecting the two.
BLUETOOTH® CAR KIT
Parrot model CK3000 or Parrot model DriveBlue
Made by Parrot, these Bluetooth enabled handsfree car kits allow you to
use your phone handsfree in your car. Model CK3000 requires installation,
model DriveBlue plugs into your car cigarette lighter.
How to identify a genuine Panasonic accessory
Panasonic produces some of the most advanced mobile phones available. So, as you’d
expect from this class leader, the range of accessories are second to none. Most
genuine Panasonic accessories will have a label showing an “EB-XXXXX” model
number.
TBD
TBD
TBD
X800_China_OI.book Page 135 Tuesday, November 16, 2004 11:25 AM
136
SPECIFICATIONS
Size
-Length x width x thickness: xx mm x xx mm x xx mm
-Weight: xxx g
Network bands supported
-Standard: GSM900 Class 4 GSM1800 Class 1 GSM1900 Class 1
-Data bearer: GPRS Class 10; CSD
Battery
-Standard: xxx mAh Lithium Ion
-Talk time: x to x hours
-Standby time: xxx to xxx hours
-Charging time: approximately xx to xxx minutes
Displays
-Main display: 176 x 208 pixels TFT LCD; 65k colours
-External display: 64 x 96 pixels CSTN LCD; 56k colours
Camera
-Type: VGA CMOS
-PhotoLight: Range 1-2 m
-Video: H.263 Encode and Decode; MPEG4 Decode; 3GPP OMA compliant streaming
-Other features: “Superbright” Photolight; up to 4X Zoom; Frames; Crop
Connectivity
-Bluetooth: Serial port, Dial-up networking, Object push, File transfer, Headset, and Handsfree
profiles (v1.1)
-Infrared: SIR (slow infrared)
-USB: v1.1
Note: Talk and Standby time are dependent upon network conditions, battery condition,
and use of certain features such as data calls, games, Bluetooth, camera.
Charging time is dependent on usage and battery conditions.
X800_China_OI.book Page 136 Tuesday, November 16, 2004 11:25 AM
137
Software features
-Operating System: Symbian v7.0s, Series 60 v2.0
-Browser: WAP 2.0 (WML, XHTML MP, WCSS, cHTML, other)
-Java: MIDP2.0, CLDC1.0, JSR 82, 118, 120, 135
-Digital Rights Management security: Forward lock DRM + additional content protection
-Messaging: MMS 2.0, SMS, Smart messaging
-E-mail: SMTP, IMAP4, POP3, MIME2
-Personal Information Management: Contacts; Calendar; Scheduler; Clocks (analog, digital);
Alarm; Calculator; Converter
-SyncML: v1.1.1, Device Management and Data Synchronisation
- OMA Client Provisioning
-Document Viewer: view/edit native Microsoft® Word, Excel, and PowerPoint® documents
-Image Editing: Crop, slide show, panorama, frames
-Predictive text: Tegic T9 predictive text input
-Voice Recognition: Speaker independent name, continuous digit dial, command and control
Content and file formats supported
-Still Imaging: JPEG, TIFF, WMF, GIF, BMP, WBMP, PNG, EXIF, MBM, SMS OTA, ICO
-Video playback: 3GPP, MPEG4, RealVideo7 and RealVideo8
-Video record: 3GPP
-Audio: RealAudio Voice, RealAudio7, and RealAudio8, AMR-NB, AMR-WB, WAV, WVE, MIDI,
GSM 6.10, RAW, RMF, XMF, SMAF.
Bluetooth audio devices are limited to voice calls
-Text: Text/plain
-Ringtones: 40+ polyphonic, OTA ringtones
-Application installation package: Symbian .sis file
-Java: JAD and JAR files
-Digital certificates: Yes - can download
-vCard: Send/receive business cards (Contacts cards)
-vCalendar: Send/receive calendar event
X800_China_OI.book Page 137 Tuesday, November 16, 2004 11:25 AM
138
TROUBLESHOOTING
PROBLEMS
Problem Remedy
Phone does not switch on • Check that the battery is properly installed and charged.
• Press and hold for at least two seconds.
Short battery life for a new
battery
Battery life is reduced when:
• playing games
• leaving Bluetooth switched on
• taking pictures with Camera
• recording video clips with Video recorder
• recording sound clips with Recorder
• using the PhotoLight often
• browsing the Internet
• downloading data
• leaving Cell Broadcast switched on
• phone is in a weak service area, requiring more battery
power
Battery charging indicator does
not appear, and phone cannot
be switched on when starting
battery charge session
Allow phone to charge for a few minutes before switching on.
Battery may have been fully discharged.
Battery fails to charge Do not connect the Travel Charger until after the battery has
been installed.
Display looks faded Check the Brightness setting (see Display Settings on
page 94).
Emergency calls cannot be
made
Check that the antenna symbol is displayed - move to a
coverage area and operate your phone when the antenna
symbol appears.
Calls cannot be made or
received
• Check to make sure the phone is switched on.
• If keypad is locked, press Unlock softkey, then press .
• If phone is locked, enter lock code.
• Check that the network signal strength indicator displays
at least one bar. Move to a stronger coverage area.
• If no network name appears, the phone may not be
registered to a network. Move to another area and watch for
the phone to register to a network.
• Check Call barring, Fixed dialling, Closed user group, and
Call divert settings in Settings application.
X800_China_OI.book Page 138 Tuesday, November 16, 2004 11:25 AM
139
Error Messages
These are some of the important error messages which may be displayed.
Note: The quality of display images may vary depending on the
object or environment.
Display images may distort when shooting moving objects,
especially in a fast moving environment.
Error Message Meaning
Unable to install.
Unable to install game, ringing tone, application, etc., for
various reasons such as not enough memory, or downloading
failed.
No access points defined.
Define now?
You need to set up an access point for your phone to access
the service you are requesting, such as Multimedia
messaging, e-mail, or browsing the Internet.
Memory full. Phone memory is full. Delete some files before new files can
be stored. See Shared Phone Memory on page 28.
No network coverage There is no network service in your current location.
Network busy
Connection error
Network is overloaded with calls or there was an error trying to
connect to the network.
Unable to send message.
Maximum message size is xxx.
File size of object attached to message is too large to send.
The xxx will be replaced by a file size. You may be able to
send the file by infrared, Bluetooth, or transfer by PC Software
Suite.
Unable to connect. No network
coverage. Cannot connect to server you are requesting.
Secure connection not available Network cannot establish a secure connection.
SIM card registration failed The network cannot register your SIM card. Contact your
wireless service provider.
PIN code blocked. Enter PUK
code:
PIN code was entered incorrectly 3 times, therefore the SIM
card is locked. Enter the PUK code, supplied by wireless
service provider.
PIN2 code blocked. Enter PUK2
code:
PIN2 code was entered incorrectly 3 times, therefore the SIM
card is locked. Enter the PUK2 code, supplied by wireless
service provider.
SIM card rejected The phone is set to accept only certain SIM cards. It will not
accept the currently inserted SIM card.
X800_China_OI.book Page 139 Tuesday, November 16, 2004 11:25 AM
140
COPYRIGHTS
© 2004 Panasonic Mobile Communications Co., Ltd. All rights reserved.
Information in this document is subject to change without notice. No part of these
instructions may be reproduced or transmitted in any form or by any means without
obtaining express permission from Panasonic Mobile Communications Co., Ltd.
CP8 Patent
Copyright © Arcsoft 2004. All rights reserved.
Powered by Mascot Capsule®Engine Micro3D Edition
Mascot Capsule® is a registered trademark of HI Corporation.
Panasonic X800 with Bluetooth® Technology
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of
such marks by Panasonic is under license. Other trademarks and trade names are those
of their respective owners.
miniSD™ Memory Card
Java and all Java based trademarks and logos are trademarks or registered
trademarks of Sun Microsystems, Inc. in the U.S. and other countries
This Product Includes Software Licensed from Symbian Ltd. © 1998-2004; this
product is based on Symbian OS.
This software is based in part of the work of the FreeType Team. This product is
covered by one or more of the following patents: United States Patent 5,155,805,
United States Patent 5,325,479, United States Patent 5,159,668, United Kingdom
Patent 2232861 and France Patent 90 05712.
T9® Text Input is licensed under one or more of the following: U.S. Pat. Nos.
5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Australian Pat. No.
727539; Canadian No. 1,331,057; United Kingdom Pat. No. 2238414B; Hong
Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.
Pat. No. 0 842 463 (96927260.8) DE/DK, FI, FR, IT, NL, PT.ES, SE, GB; Republic
of Korea Pat. Nos. KR201211B1 and KR226206B1; and additional patents are
pending worldwide.
X800_China_OI.book Page 140 Tuesday, November 16, 2004 11:25 AM
141
MicroGolf is Copyright © 2004 Morpheme Limited. All rights reserved.
Balloon-Headed Boy is Copyright © 2004 Morpheme Limited. All rights reserved.
PC Suite Synchronisation includes synchronisation software. © 1996 - 2004 Time
Information Services Limited. All rights reserved.
VoiceSignal Technologies
This product contains software licensed from Nokia Corporation. Copyright © 2004
Nokia Corporation. All rights reserved.
This product is licensed under the MPEG-4 patent portfolio license for the personal
and non-commercial use of a consumer to (i) encode video in compliance with the
MPEG-4 Visual Standard (“MPEG-4 Video”) and/or (ii) decode MPEG-4 Video that
was encoded by a consumer engaged in a personal and non-commercial activity
and/or was obtained from a licensed video provider.
No license is granted or implied for any other use.
Additional information may be obtained from ‘MPEG LA, LLC’
TM
X800_China_OI.book Page 141 Tuesday, November 16, 2004 11:25 AM
142
© 2003-2004 Mobility Electronics, Inc.
IMPORTANT-READ CAREFULLY:
MOBILITY TEXAS, INC. ("LICENSOR") IS WILLING TO LICENSE THIS SOFTWARE TO YOU ONLY IF
YOU ACCEPT ALL THE TERMS OF THIS END USER LICENSE AGREEMENT ("EULA"). PLEASE
READ THE TERMS CAREFULLY BEFORE YOU INSTALL THIS SOFWARE BECAUSE BY
EXERCISING YOUR RIGHTS TO USE THE SOFTWARE, YOU ARE AGREEING TO BE BOUND BY
THE TERMS OF THIS EULA. IF YOU DO NOT AGREE TO THESE TERMS, LICENSOR WILL NOT
LICENSE THIS SOFTWARE TO YOU, AND IN THAT CASE YOU SHOULD REMOVE ALL FILES FROM
YOUR PHONE, HANDHELD DEVICE, AND/OR PERSONAL COMPUTER.
Ownership of the Software This Quickoffice™ software program and other software product(s) included
("Software") and the accompanying written materials, including all intellectual property and confidential
information relating to it, are owned or licensed by Licensor and are protected by United States copyright
laws, by laws of other nations, and by international treaties.
Grant Of License Licensor grants to you the non-exclusive right to use one copy of the Software on a
single computer or handheld device ("Device"). You may load one copy into storage memory of one
Device and may use that copy, only on that same Device.
Restrictions on Use and Transfer If this Software package contains multiple media types, then you may
use only the type of media appropriate for your Device. You may not use the other size media on another
Device or computer, or loan, rent, transfer, or assign them to another user except as part of the
permanent transfer of the Software and all written materials (as provided for below). You may not copy
the Software, except that (1) you may make one copy solely for backup or archival purposes, and (2) you
may transfer the Software to a single hard disk provided you keep the original solely for backup or
archival purposes. You may not copy the written materials. You may permanently transfer the Software
and accompanying written materials (including the most recent update and all prior versions) if you retain
no copies and the transferee agrees to be bound by the terms of this EULA. Such a transfer terminates
your license. You may not rent, lease, allow multiple users, time sharing, use the Software in a service
bureau or otherwise transfer or assign the right to use the Software, or any adaptation or part thereof,
except as stated in this paragraph. You may not reverse engineer, decompile, or disassemble the
Software.
Limited Warranty, Disclaimer, and Damages Limitation
Licensor warrants that the Software will perform substantially in accordance with the accompanying
written materials for a period of 30 days from your purchase date of the Software. LICENSOR
DISCLAIMS ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, AND NON-INFRINGEMENT, WITH RESPECT TO THE SOFTWARE AND THE
ACCOMPANYING WRITTEN MATERIALS. LICENSOR DOES NOT WARRANT ERROR-FREE OR
UNINTERRUPTED USE OF THE SOFTWARE. This limited warranty gives you specific legal rights. You
may have others, which vary from one state, country, or region to another. Some laws prohibit the
foregoing limitations, so they may not apply to you. LICENSOR'S ENTIRE LIABILITY AND YOUR
EXCLUSIVE REMEDY FOR SOFTWARE THAT DOES NOT MEET THIS LIMITED WARRANTY SHALL
BE, AT LICENSOR'S CHOICE, EITHER TO (A) REFUND THE PRICE PAID OR (B) REPLACE THE
SOFTWARE IF RETURNED TO LICENSOR WITH A COPY OF YOUR RECEIPT. Any replacement
Software will be warranted for the remainder of the original warranty period or 30 days, whichever is
longer. This Limited Warranty is void if failure of the Software has resulted from modification, accident,
abuse, or misapplication. IN NO EVENT WILL LICENSOR BE LIABLE TO YOU FOR DAMAGES,
INCLUDING ANY LOSS OF PROFITS, LOST SAVINGS, OR OTHER INDIRECT, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES ARISING OUT OF YOUR USE OR INABILITY TO USE THE
SOFTWARE. Because some states, countries, or regions do not allow the exclusion or limitation of
liability for consequential or incidental damages, the above limitation may not apply to you. This EULA is
governed by the laws of the State of Texas, and may be enforced by Mobility's licensors, including without
limitation, Schema Software, Inc. If you have any questions concerning this EULA or wish to contact
Licensor for any reason, please write: Mobility Texas, Inc. 5508 W. Plano Parkway, Suite E, Plano, TX
75220; email: support@quickoffice.com, www.quickoffice.com phone: 1 + 214-956-9806 (English only).
U.S. Government Restricted Rights. The Software and documentation are provided with Restricted
Rights. Use, duplication, or disclosure by the Government is subject to restrictions set forth in
subparagraph (c)(1) of The Rights in Technical Data and Computer Software clause at DFARS 252.227-
7013 or subparagraphs (c)(1)(ii) and (2) of Commercial Computer Software - Restricted Rights at 48 CFR
52.227-19, as applicable. Supplier is Mobility Texas, Inc. 5508 W. Plano Parkway, Suite E, Plano, TX
75093; phone: 1 + 214-956-9806.
X800_China_OI.book Page 142 Tuesday, November 16, 2004 11:25 AM
143
INDEX
A
About (copyrights) 110
Access point settings 96
Accessories 134
Active clamshell 96
Alarm set
Calendar 36
Clock 105
Application manager 118
Applications
Close 27
Menu map 29
Navigating 25
Open 27
Options softkey 26
B
Barring 103
Battery
Charging 9
Installing 8
Removing 8
Bluetooth 81
Browser 74–79
Bookmarks 77
Connect to Internet 75
Download files from
Internet 77
Online options 76
Saved pages 79
Set up 75
Settings 78
C
Calculator 111
Calendar 36–39
Alarm set 36
Chinese Lunar
calendar 39
Create new 36
Send events 39
Settings 39
Views 37
Call
Answer by opening
flip 96
Answering 18
Duration 124
Ending 22
Handsfree talking 20
Hold or unhold 19
Making 16
Mute or unmute 20
Open applications
during 21
Options 19
Volume 20
Call barring 103
Call divert 102
Call logs 123
Call settings 95
Call waiting 20
Calls
Dialled 123
Emergency 18
Missed 123
Multi-party
(conference) 21
Received 123
Camera 58–61
PhotoLight 121
Picture quality 60
Save pictures 59
Send pictures 60
Take a picture 58
View pictures 60
Cell broadcast
messages 56
Certificate
management 101
Chinese Lunar calendar 39
Clip art, add to photos 68
Clock 104
Close applications 27
Closed user group 100
Conference calls 21
Connection manager 86
Connection settings 96
Connectivity 74–90
Bluetooth 81
Browser 74
Connection manager 86
Device manager 88
Infrared 84
Modem 80
Operator menu 79
Synchronisation 86
USB 85
Contacts 30–35
Create new 30
Edit 32
Find 31
Groups 34
Make a call 31
My numbers 31
Send a Contacts
card 34
X800_China_OI.book Page 143 Tuesday, November 16, 2004 11:25 AM
144
Service numbers 34
SIM directory 30
Converter 112
Copyrights 140
Create e-mail messages 44
Create multimedia
messages 42
Create text message 42
D
Data call
Access points 96
Definition 74
Device manager 88
Dictionary 23
E
Eject miniSD Card 10, 12
E-mail messages 48
Emergency calls 18
Ending calls 22
Enhancement settings 104
F
Favourites 133
File manager 119
Fixed dialling 100
Flashlight 121
Frames, add to photos 68
G
Gallery 62–66
Add clip art, frames 68
Edit photos 67
Play video, sound clips,
and streaming
media 63
Player controls 64
Send pictures, video,
sound clips 65
Slide show 67
View images 62
Zoom 63
Games 131
GPRS
Access points 96
Definition 74
GPRS data counter 124
Groups in Contacts 34
H
Handsfree talking 20
I
Icons (indicators) 14
Inbox 45
Infrared 84
International calling 18
Internet. See Browser
K
Key functions 12
Keys, lock 12
L
Language
Browser page display 78
Cell broadcast 56
Phone 94
Writing 94
Lock code 99
Lock keys 12
Lock phone 99
Loudspeaker 20
M
Making a call 31
Mark 26
Media 62–73
Gallery 62
PhotoBase 66
RealOne Player 69
Video recorder 71
Memory card. See miniSD
Card
Memory details 28
Menu map 29
Messages 40–57
Cell broadcast 56
Create new e-mail 44
Create new
multimedia 42
Create new text 42
Create presentation 43
Drafts 51
E-mail (Mailbox) 48
Inbox 45
My folders 47
Outbox 53
Receive new 45
Reports 54
Sent 52
Service command 57
Settings 54
SIM 56
Types 40
miniSD Card
Application 115
Installing 10
Removing 10, 12
Missed calls 123
Modem 80
Moving in the
applications 25
Multi-party calls 21
X800_China_OI.book Page 144 Tuesday, November 16, 2004 11:25 AM
145
Multitasking 27
My numbers 31
N
Navigating in the
applications 25
Network settings 103
Notepad 113
O
On or off, switch phone 16
Open applications 27
Operator menu 79
Options softkey 26
Outbox 53
Overview, phone 11
P
Phone
Memory 28
Overview 11
Settings 94
Switch on or off 16
PhotoBase 66
PhotoLight 121
Photos, edit 67
Picture quality 60
Picture, take 58
PIN code 99
PIN2 code 99
Play video, sound clips, and
streaming media 63
Problems 138
Q
Quickoffice 126
R
RealOne Player 69
Recorder, voice 113
Ringtones 91
S
Search 28
Security settings 99
Send Calendar events 39
Send Contacts card 34
Send data via Bluetooth 83
Send data via infrared 85
Send DTMF touch tones 20
Send pictures 60, 65
Send sound clips 65
Send video clips 65
Service numbers 34
Set time and date 104
Settings 94–104
Access point 96
Alarm 105
Barring 103
Call 95
Call divert 102
Certificate
management 101
Clock 104
Connection 96
Enhancement 104
Network 103
Phone 94
Security 99
Speed dial 106
SIM card
Installing 7
Removing 8
SIM directory 30
Sound clips, play 63
Sound controls 64
Specifications 136
Speed dial 106
Standby mode displays 15
Streaming media, play 63
SyncML 86
T
Tabs 25
Take a picture 58
Text entry
Dictionary for predictive
text entry 23
General text entry 23
Themes 92
Time and date, set 104
To-do 117
Tools 111–122
Troubleshooting 138
U
Unmark 26
USB 135
V
Video clips, play 63
Video player controls 64
Video recorder 71
Voice commands 107
Voice dial 107
Voice mail 40
Voice recorder 113
Volume
Call 20
Player 64
Ringtone 91
Sound clip 64
Video clip 64
X800_China_OI.book Page 145 Tuesday, November 16, 2004 11:25 AM
146
W
Wallpaper, change 93
Z
Zoom
Camera 58
Gallery 63
PhotoBase album 67
PhotoBase camera 66
Video recorder 71
X800_China_OI.book Page 146 Tuesday, November 16, 2004 11:25 AM

Navigation menu
