FCC Addendum
Safety First
Your new phone is a convenient and effective communications tool,
but it can be hazardous when used improperly. To avoid harming
yourself or anyone else, please review the following information
before using your phone.
Batteries
Batteries can cause property damage, injury, or burns if the terminals
are touched with a conductive material (for example, metal jewelry,
keys, and so on). Therefore, use caution when handling a charged
battery. Additional precautions and notes are listed below:
•Never throw a battery into a fire; it may explode.
•Fully recharge the battery if the battery is low or as soon as the
low-battery alert beeps.
•Do not drop the battery.
•Do not bridge battery contacts together with metallic objects.
•Do not remove the battery from the phone while the phone is
powered on. Settings you have changed may revert to their
previous settings.
A recyclable lithium ion/polymer battery powers your phone. Please
call 1-800-8-BATTERY for information on how to recycle the battery.
Charging Devices
Use only Genuine Panasonic charging accessories. Use of
attachments not recommended by Panasonic or your wireless service
provider may result in fire, electrical shock, or injury. Panasonic is not
responsible for damage caused by using non-Panasonic accessories.
•Do not expose charging adapters to moisture, water, or the
weather.
•Do not use an adapter with a damaged cord.
When using a DC adapter in an automobile, a small amount of
electricity flows through the adapter, even if the phone is turned off.
Remove the plug from the cigarette lighter whenever the phone will be
left in the vehicle for long periods of time.
Caution: The cigarette lighter must have a 12V negative ground
socket. Do not use the adapter in a vehicle that has a positive ground
system.
Safety First 1
PRELIMINARY
General
•Do not use the phone in extreme temperature or humidity. The
specified operating temperature range is -22°F to +140°F (-30°C to
+60°C).
•Do not expose the phone (particularly the display) to direct sunlight
for extended periods of time.
•Do not attempt to disassemble the phone. There are no
user-serviceable parts inside.
•Do not expose the phone to rain or spill liquids on it.
•Do not carry the phone by holding the antenna.
•Do not use any accessories other than those designed for use with
your phone.
•Use of attachments not recommended or sold by your wireless
service provider may result in fire, electrical shock, or injury.
•Panasonic cannot be held responsible for damages caused by using
non-Panasonic accessories.
Availability of Service
This phone, like any wireless phone, operates using radio signals,
wireless and landline networks, and user-programmed functions.
Because of this, connection in all conditions cannot be guaranteed.
Therefore, you should never rely solely on any wireless phone for
essential communications (for example, medical emergencies). When
operating in analog mode, the service area where you can place and
receive calls will be smaller than with other phones.
Emergency (911) Service
If you need to make an emergency (911) call, power the phone on, dial
911, and press SEND. Emergency calls can be made regardless of
lock setting.
Note: When you purchase your phone, the 9 key is programmed as a
Super Dial key to call the emergency number 911. However, you have
to enable this key assignment before you can use it.
Remember, to make or receive any call, the phone must be switched
on and in a service area that has adequate signal strength. Emergency
calls might not be possible on all wireless phone networks or when
certain network service and/or phone features are in use.
2 Safety First
PRELIMINARY
Safety Tips
Following the suggestions in this section will help ensure safe and
efficient operation of your Panasonic phone.
This Model Phone Meets The Government’s Requirements For
Exposure To Radio Waves.
Your wireless phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure to
radiofrequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy
for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6W/kg. Tests for SAR are conducted
using standard operating positions specified by the FCC with the
phone transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone while
operating can be well below the maximum value. This is because the
phone is designed to operate at multiple power levels so as to use
only the power required to reach the network. In general, the closer
you are to a wireless base station antenna, the lower the power
output.
Before a phone model is available for sale to the public, it must be
tested and certified to the FCC that it does not exceed the limit
established by the government-adopted requirement for safe
exposure. The tests are performed in positions and locations (e.g., at
the ear and worn on the body) as required by the FCC for each model.
The highest SAR value for this model phone when tested for use at
the ear is 0.626 W/kg and when worn on the body, as described in this
user guide, is 0.622 W/kg. (Body-worn measurements differ among
phone models, depending upon available accessories and FCC
requirements). While there may be differences between the SAR
levels of various phones and at various positions, they all meet the
government requirement for safe exposure.
Safety First 3
PRELIMINARY
The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC
RF emission guidelines. SAR information on this model phone is on file
with the FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID NWJ22B001A.
Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications Industry Association (CTIA)
web-site at http://www.wow-com.com.
Caution: All Panasonic branded accessories are tested and comply
with FCC RF exposure requirements. Non-Panasonic accessories may
not comply.
Body-Worn Operation
This device was tested for typical body-worn operations using the
belt-clip Model: EB-YKX70.
This device was also tested for body-worn operations
with the back of the phone kept 1.5 cm. from the body. To maintain
compliance with FCC RF exposure requirements, use only belt-clips,
holsters or similar accessories that maintain a 1.5 cm. separation
distance between the user’s body and the back of the phone, including
the antenna, whether extended or retracted. The use of belt-clips,
holsters and similar accessories should not contain metallic
components in its assembly. The use of accessories that do not satisfy
these requirements may not comply with FCC RF exposure
requirements, and should be avoided.
Antenna Care
Do not use the phone with a damaged antenna.
Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could damage
the phone and may violate FCC regulations.
Phone Operation
Normal Position: Hold the phone as you would any other telephone,
with the antenna pointed up and over your shoulder.
For Efficient Operation: For your phone to operate most efficiently, do
not touch the antenna unnecessarily when the phone is in use. Contact
4 Safety First
PRELIMINARY
with the antenna affects call quality and may cause the phone to
operate at a higher power level than otherwise needed.
Driving
Important: Check the laws and regulations on the use of wireless
telephones in the areas where you drive. Always obey them. Also, if
using your phone while driving:
•Give full attention to driving—driving safely is your first
responsibility;
•Use handsfree operation, if available;
•Pull off the road and park before making or answering a call if
driving conditions so require.
Electronic Devices
Most modern electronic equipment is shielded from RF signals.
However, certain electronic equipment may not be shielded against
the RF signals from your wireless phone.
Pacemakers: The Health Industry Manufacturers Association
recommends that a minimum separation of 6 inches (6”) or 15
centimeters (15 cm) be maintained between a handheld wireless
phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with independent
research and recommendations of Wireless Technology Research.
Persons with pacemakers:
•Should ALWAYS keep the phone more than six inches from their
pacemaker when the phone is turned ON;
•Should not carry the phone in a breast pocket;
•Should use the ear opposite the pacemaker to minimize the
potential for interference;
•If you have any reason to suspect that interference is taking place,
turn your phone OFF immediately.
Hearing Aids: Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you may want to
consult your service provider.
Other Medical Devices: If you use any other personal medical
device, consult the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your physician may be
able to assist you in obtaining this information.
Safety First 5
PRELIMINARY
Turn your phone OFF in health care facilities when any regulations
posted in these areas instruct you to do so. Hospitals or health care
facilities may be using equipment that could be sensitive to external RF
energy.
Vehicles: RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with the
manufacturer or its representative regarding your vehicle. You should
also consult the manufacturer of any equipment that has been added to
your vehicle.
Posted Facilities: Turn your phone OFF in any facility where posted
notices so require.
Aircraft
FCC regulations prohibit using your phone while in the air; switch off
your phone before boarding an aircraft unless otherwise advised by
airline personnel.
Blasting Areas
To avoid interfering with blasting operations, turn your phone OFF
when in a “blasting area” or in other areas posted: “Turn off two-way
radio.” Obey all signs and instructions.
Potentially Explosive Atmospheres
Turn your phone OFF when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such areas
could cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not
always, clearly marked. They include fueling areas such as gas
stations; below deck on boats; fuel or chemical transfer or storage
facilities; vehicles using liquefied petroleum gas (such as propane or
butane); areas where the air contains chemicals or particles, such as
grain, dust or metal powders; and any other area where you would
normally be advised to turn off your vehicle engine.
6 Safety First
PRELIMINARY
For Vehicles Equipped with an Air Bag
An air bag inflates with great force. DO NOT place objects, including
both installed or portable wireless equipment, in the area over the air
bag or in the air bag deployment area. If in-vehicle wireless equipment
is improperly installed and the air bag inflates, serious injury could
result.
For U.S. Customers: Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the National Fire Protection
Standard (NFPA-58).
For a copy of this standard, contact the National Fire Protection
Association,
One Batterymarch Park,
PO Box 9101, Quincy, MA 02269.
E-mail address: Custserv@NFPA.org.
Web site: www.nfpa.org.
Refer to Appendix C for the FDA Consumer Update on Mobile Phones
published by the U.S. Food and Drug Administration.
Safety First 7
PRELIMINARY
FCC Compliance
FCC ID: NWJ22B001A
To comply with the applicable sections of FCC Rules and
Regulations, Parts 15 and 24, please follow these instructions:
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Any changes or modifications not expressly approved by the grantee
of this device could void the user authority to operate the equipment.
