Contents

Important information . . . . . . .5

Overview of features . . . . . . . .9

SIM and battery . . . . . . . . . . . . 10

Quick start . . . . . . . . . . . . . . . .13

Your phone. . . . . . . . . . . . . . . .17

Display icons . . . . . . . . . . . . . .19

Menu structure . . . . . . . . . . . . .21

Voice calls . . . . . . . . . . . . . . . .23

Text entry . . . . . . . . . . . . . . . . .30

Settings . . . . . . . . . . . . . . . . . . .33

Contacts list . . . . . . . . . . . . . . .51

Games. . . . . . . . . . . . . . . . . . . .59

Browser . . . . . . . . . . . . . . . . . .61

Camera . . . . . . . . . . . . . . . . . . .66

Messaging. . . . . . . . . . . . . . . . .72

Data folders . . . . . . . . . . . . . . .90

Organiser . . . . . . . . . . . . . . . . .101

Connect. . . . . . . . . . . . . . . . . . .111

Accessories. . . . . . . . . . . . . . . .116

Care and maintenance . . . . . . .119

Troubleshooting . . . . . . . . . . . .121

Glossary . . . . . . . . . . . . . . . . . .124

X70DPK11B1.book Page 3 Thursday, September 18, 2003 5:12 PM

Contents

Specifications. . . . . . . . . . . . . . 126

EU warranty and licensing. . . . 128

Personal settings and notes . . . 136

Index . . . . . . . . . . . . . . . . . . . . 139

X70DPK11B1.book Page 4 Thursday, September 18, 2003 5:12 PM

Important information

Thank you for purchasing this Panasonic digital cellular phone. This phone is designed

to operate on GSM networks – GSM900, GSM1800 and GSM1900. It also supports

GPRS for packet data connections. Please ensure the battery is fully charged before use.

We, Panasonic Mobile Communications Development of Europe Ltd., declare, that the

EB-X70 conforms with the essential and other relevant requirements of the directive

1999/5/EC.

A Declaration of Conformity to this effect can be found at

http://www.panasonicmobile.com

Safety considerations

You should read and understand the following information as it provides details for

operating your phone in a manner which is both safe to you and your environment, and

conforms to any legal requirements regarding the use of cellular phones.

A Fast Travel Charger (EB-CAX70UK or EB-CAX70EU) is supplied

with the phone. Other recommended equipment for charging is the Car

Charger (EB-CDX70).

This equipment should only be charged with approved charging

equipment, to ensure optimum performance and avoid damage to your

phone. Other usage will invalidate any approval given to this apparatus

and may be dangerous. Ensure the voltage rating of the Fast Travel

Charger is compatible with the area of use when travelling abroad.

Use of a battery pack other than that recommended by the manufacturer

may result in a safety hazard.

If you use a feature that keeps the key backlight on continuously for a long

time, for example, Camera, Games, or Browser, you will reduce your

battery life. To maintain longer battery life, set the key backlight off.

See Setting the key backlight on page 34.

Switch off your cellular phone when in an aircraft. The use of cellular

phones in an aircraft may be dangerous to the operation of the aircraft,

disrupt the cellular network and may be illegal. Failure to observe this

instruction may lead to the suspension or denial of cellular phone services

to the offender, or legal action or both.

Do not incinerate or dispose of the battery as ordinary rubbish. The battery

must be disposed of in accordance with local legislation and may be

recycled.

X70DPK11B1.book Page 5 Thursday, September 18, 2003 5:12 PM

Important information

This equipment should only be used with Panasonic approved accessories to ensure

optimum performance and avoid damage to your phone. Panasonic is not responsible for

damages caused by using non-Panasonic approved accessories. This Panasonic mobile

phone is designed, manufactured and tested to ensure that it complies with the

specifications covering RF exposure guidelines applicable at the time of manufacture, in

accordance with EU, USA FCC, and Australian ACA regulations.

Please refer to our website for latest information/standards compliance in your country/

region of use.

http://www.panasonicmobile.com

It is advised not to use the equipment at a refuelling point. Users are

reminded to observe restrictions on the use of radio equipment in fuel

depots, chemical plants or where blasting operations are in progress.

Never expose the battery to extreme temperatures (in excess of 60°C).

It is imperative that the driver exercises proper control of the vehicle at all

times. Do not hold a phone while you are driving; find a safe place to stop

first. Do not speak into a handsfree microphone if it will take your mind

off the road. Always acquaint yourself thoroughly with restrictions

concerning the use of cellular phones within the area you are driving and

observe them at all times.

Care must be taken when using the phone in close proximity to personal

medical devices, such as pacemakers and hearing aids.

Do not leave the camera facing direct sunlight, as this may impair its

performance.

For most efficient use hold the phone as you would any normal phone. To

avoid deterioration of signal quality or antenna performance, do not touch

or cup the antenna area while the phone is switched on. (See SAR on

page 8). Unauthorised modifications or attachments may damage the

phone and violate applicable regulations. The use of an unapproved

modification or attachment may result in the invalidation of your

guarantee – this does not affect your statutory rights.

X70DPK11B1.book Page 6 Thursday, September 18, 2003 5:12 PM

Important information

This phone must be used in compliance with any applicable international or national law

governing its use in specified applications and environments. This includes use in

hospitals, aircraft, and whilst driving or refuelling a vehicle.

It is recommended that you create a copy or backup as appropriate for any important

information and data which you store in your phone's memory. In order to avoid

accidental loss of data, please follow all instructions relating to the care and maintenance

of your phone and its battery. Panasonic Mobile Communications will not accept any

liability for loss of data if these instructions are not followed.

Your phone has the capability of storing and communicating personal information such

as a credit card number. It is recommended that you take care to ensure that this

information is secure and protected with any security features provided. Panasonic

Mobile Communications will not accept any liability for damages resulting from misuse

of such personal information.

Your phone has the capability of downloading and storing information and data from

external sources, and from the internal camera. It is your responsibility to ensure that in

doing this you are not infringing any copyright laws. Panasonic Mobile Communications

will not accept any liability for damages resulting any such infringement.

You are advised to take appropriate care over the use of the internal camera. It is your

responsibility to ensure that you have permission to take photographs of people and

objects and that you do not infringe any personal and public rights in the use of the

camera. You must comply with any applicable international or national law governing

camera use in specified applications and environments. This includes not using the

camera in places where the use of photographic and video equipment is prohibited.

The display layouts and screenshots within this document are for illustrative purposes and

may differ from the actual displays on your phone. Panasonic Mobile Communications

reserve the right to change the information in this document without prior notice.

X70DPK11B1.book Page 7 Thursday, September 18, 2003 5:12 PM

Important information

SAR

European union - RTTE

THIS PANASONIC PHONE (MODEL EB-X70) MEETS THE EU REQUIREMENTS

FOR EXPOSURE TO RADIO WAVES.

Your mobile phone is a radio transmitter and receiver. It is designed and manufactured

not to exceed the limits for exposure to radio frequency (RF) energy recommended by

The Council of the European Union. These limits are part of comprehensive guidelines

and establish permitted levels of RF energy for the general population. The guidelines

were developed by independent scientific organisations through periodic and thorough

evaluation of scientific studies. The limits include a substantial safety margin designed to

assure the safety of all persons, regardless of age and health.

The exposure standard for mobile phones employs a unit of measurement known as the

Specific Absorption Rate, or SAR. The SAR limit recommended by The Council of the

European Union is 2.0 W/kg.* Tests for SAR have been conducted using standard

operating positions with the phone transmitting at its highest certified power level in all

tested frequency bands. Although the SAR is determined at the highest certified power

level, the actual SAR level of the phone while operating can be well below the maximum

value. This is because the phone is designed to operate at multiple power levels so as to

use only the power required to reach the network. In general, the closer you are to a base

station antenna, the lower the power output.

Before a phone model is available for sale to the public, compliance with the European

R&TTE directive must be shown. This directive includes as one essential requirement the

protection of the health and the safety for the user and any other person. The SAR value

for this model phone, when tested for use at the ear, for compliance against the standard

was 0.459 W/kg. While there may be differences between the SAR levels of various

phones and at various positions, they all meet the EU requirements for RF exposure.

* The SAR limit for mobile phones used by the public is 2.0 watts/kilogram (W/kg)

averaged over ten grams of tissue. The limit incorporates a substantial margin of safety

to give additional protection for the public and to account for any variations in

measurements. SAR values may vary depending on national reporting requirements and

the network band.

For SAR information in other regions please look under product information at

http://www.panasonicmobile.com/health.html

X70DPK11B1.book Page 8 Thursday, September 18, 2003 5:12 PM

Overview of features

Your phone has the following features:

Bluetooth® connectivity

Use this to transfer information between your phone and another Bluetooth® device.

Calculator

Use this to perform basic calculations.

Camera

Use the digital camera to take pictures to send in your messages or use as your wallpaper.

Converter

Use this to convert currency values when you are abroad.

Games

Use this to play games on your phone.

Infrared connectivity

Use this to transfer information between your phone and another device that has an

infrared port.

MMS (Multimedia Messaging)

Use this to send and receive pictures and sounds.

Schedule

Use this to set reminders for important events.

SMS (text messaging)

Use this to send and receive text messages.

SMS Chat

Use this to have a text conversation.

Synchronization

Use this to synchronize your Schedule and Contacts List with an external server.

Voice dial

Use this to dial a number by talking to the phone.

WAP browser

Use this to access the Internet.

X70DPK11B1.book Page 9 Thursday, September 18, 2003 5:12 PM

SIM and battery

Fitting and removing the SIM

You insert the SIM into the back of the phone, underneath the battery.

If your SIM contains contact details, the first time that you turn the phone on after you

have fitted the SIM, you are asked whether you want to transfer the SIM data to your

phone.

Fitting the SIM

Removing the SIM

X70DPK11B1.book Page 10 Thursday, September 18, 2003 5:12 PM

SIM and battery

Fitting and removing the battery

Before you remove the battery, ensure that the phone is switched off and that the charger

is disconnected from the phone.

Charging the battery

The battery must be fitted in the phone before you connect the charger. Press the button

on the top of the connector and insert it into the base of the phone.

Connect the charger to the mains power supply. When the phone is charging, the charging

indicator will light and a flashing plug icon will appear in the main display and the case

screen.

When charging is complete, turn off the mains power supply and disconnect the charger.

Note: Do not force the connector as this may damage the phone and/or the charger.

Fitting the battery

Removing the battery

X70DPK11B1.book Page 11 Thursday, September 18, 2003 5:12 PM

SIM and battery

While the battery is charging, the following icons appear on the phone’s display and case

screen:

Low battery warning

When the battery power is low, a warning tone sounds, and a flashing low battery icon

(L) is displayed. If this happens during a conversation, end your call immediately.

The power automatically shuts off after the warning tone. You need to fully recharge your

battery, see Charging the battery on page 11. You can still make and receive calls while

the battery is charging.

While charging Charging complete

Phone on K Flashing H

Phone off K Flashing No icon.

X70DPK11B1.book Page 12 Thursday, September 18, 2003 5:12 PM

Quick start

Switching the phone on and off

To switch the phone on or off, press and hold E.

If you have set an animation and greeting, these are displayed. The phone starts in idle

mode.

Making calls

Ensure that the phone is switched on, the network operator logo is displayed and the

signal strength icon shows that network coverage is available in the current area.

From idle mode, enter the area code and phone number.

Press D.

Camera mode

To change to camera mode either select Camera from the main menu (press Q twice),

or press B from idle mode if the shortcut key is set for camera.

Leaving camera mode

To leave camera mode press E to return to idle mode.

Taking a picture

When you are in camera mode, move the phone around until you can see the image

you want on the preview screen.

Press Q to capture the image.

If you decide that you do not want the image that you have taken, you can press B to

delete it.

Note: Some services are network dependent or may only be available on a subscription

basis. Some functions are SIM dependent. For more information contact your

service provider.

X70DPK11B1.book Page 13 Thursday, September 18, 2003 5:12 PM

Quick start

Setting the wallpaper

The wallpaper is a picture that displays when the phone is in idle mode.

Select Menu > Data Folders.

Find a picture.

Select Menu > Use As > Wallpaper.

Select Menu > Settings > Display > Wallpaper.

Select the folder where the picture is stored.

Select your picture.

Setting the ring type

Select Menu > Data Folders.

Find a sound.

Select Menu > Use As.

Select the type of call.

Select Menu > Settings > Alerts > Ring Type.

Select the type of call that you want to change.

Select the folder where your sound is stored.

Select your sound.

Setting quiet mode

In quiet mode the microphone amplifies your voice, so you can whisper and still be heard

by the person on the other end of the call. You should use quiet mode in situations where

you do not want to disturb the people around you.

In quiet mode, the phone will not ring when you receive a call or message, unless you set

a ring volume for quiet mode.

From idle mode, press and hold #.

Select Menu > Settings > Alerts > Quiet Mode > On/Off > On.

Using your browser

Before you can start using your browser, you need to contact your service provider. When

your phone is set up to access the internet see Start browser on page 62 for information

about using the browser.

X70DPK11B1.book Page 14 Thursday, September 18, 2003 5:12 PM

Quick start

Creating a multimedia message

Use the Create option on the Messaging menu to create a multimedia

(MMS) message.

Select Create > MMS.

Press Q.

Select the item that you want to enter.

When your message is complete, select Ok.

Select Addr:.

Select Edit to enter an address.

Enter an address.

Select Subj:.

Select Edit to enter a subject.

Enter a subject.

To send your message, press A or press Q and select Send.

To save your message press Q and select Save. Your message is stored in the Outbox,

so you can send it or edit it later.

Creating a text message

Use the Create option on the Messaging menu to create a text (SMS)

message.

Select Create > SMS.

Enter your text.

Press Q.

Select Ok or Cancel.

Press Q to send the message.

Enter the phone number.

Press Q.

Select Ok or Cancel.

You are asked ‘Request Delivery Confirmation?’ Press Q.

Select No or Yes.

Menu > Messaging > Create

X70DPK11B1.book Page 15 Thursday, September 18, 2003 5:12 PM

Quick start

Setting up the Bluetooth® headset

The headset gives you wireless, hands free operation.

Before you can use the headset you need to pair the headset and the phone.

First you need to turn on Bluetooth® on the phone:

Select Menu > Connect > Bluetooth > On/Off > On.

The Bluetooth® icon appears on the screen.

You now need to set up the headset:

Turn on the headset. (See headset instructions).

Make the headset discoverable. (See headset instructions).

Finally you need to pair the devices:

On the phone select Discover & Pair.

As the phone discovers devices it displays them on the screen.

When the headset appears in the list you can select Stop to stop the search.

If the phone does not discover your headset, press A to try again.

Highlight the headset in the list.

Select Pair.

Enter the Bluetooth® Passkey provided with the headset.

You can select Paired Devices to confirm that the devices are paired. This lists all the

devices that are paired with the phone.

Once the headset and phone are paired, you can answer calls using the headset. If the

headset is on when you receive a call, the headset rings. For information on how to answer

a call with the headset, see the headset instructions.

Note: The headset is only discoverable for a short time. If it is not discovered during this

period, the pairing will fail. You can try again by making the headset discoverable

again.

Note: The pairing will fail if you enter the wrong passkey, or if the headset is already

paired with another device.

Menu > Connect > Bluetooth

X70DPK11B1.book Page 16 Thursday, September 18, 2003 5:12 PM

Your phone

Ear Piece

Main Display

Navigation Key

This is a multi function key.

It is represented by Q in

the text. Press the edges

of this key to move around

the display.

Keypad

Left Soft Key A

Use to:

Access the Contacts

List from idle mode.

Switch between text

entry types.

Select the option in the

left hand selection area. Right Soft Key B

Use to:

Cancel the current option.

Return to the previous

menu.

Delete last character in

text entry.

Select the option in the

right hand selection area

Call Key D

End Call Key EMicrophone Accessory Connector

@ Key j

Use to:

Go to the Browser

default home page from

idle mode.

X70DPK11B1.book Page 17 Thursday, September 18, 2003 5:12 PM

Your phone

Camera Lens

Self-portrait Mirror

Photo Light

Case Screen

IrDA (Infrared)

Memo Key /

Camera

Shutter Key

Personal

Handsfree

Connector

X70DPK11B1.book Page 18 Thursday, September 18, 2003 5:12 PM

Display icons

After some operations, the display automatically clears after three seconds or when you

press any key.

Status icons

The status icons are displayed according to the currently activated functions. The

antenna, GSM signal strength and battery icons are displayed when the phone is switched

on and connected to a network.

Status icons

Main display

Right

selection

area

Left

selection

area

Primary selection area

Information

area

qSTI

--:--

X70DPK11B1.book Page 19 Thursday, September 18, 2003 5:12 PM

Display icons

YRegistered to a non-home network - Roaming.

z or /The number of the current call when connected to two calls.

tCall divert on.

NNew message received.

; Message store is full.

qGPRS service available.

SAntenna. Indicates that you can make a call. If it is the only icon

displayed, you can only make emergency calls.

TGSM signal strength: \– weak signal, T – strong signal.

HBattery level: H – full, L (flashing) – low.

oAll tones off or ring volume off.

]Vibration alert on.

o] Quiet mode on.

OPhone lock on.

?Alarm set.

wBluetooth® enabled

X70DPK11B1.book Page 20 Thursday, September 18, 2003 5:12 PM

Menu structure

The nine main menus are as follows:

Note: The menus may not display in the same order or with the same icons as listed here.

The order and icons vary according to your service provider.

Settings

1Display

2Alerts

3Keys

4 Phone Settings

5Clock

6 Call Service

7Call Divert

8 Security

9Network

10 Defaults

Contacts List

1Browse

2 Create

3 Voice Dial

4 Groups

5 Settings

6SIM

7Storage

Games

Browser

1 Home Page

2 Bookmarks

3 Enter URL

4Page Memo

5 Push Message

6 Browser Settings

7Server List

8 Cookie

9Last Status

Camera

Messaging

1 Settings

2 Inbox

3Broadcasts

4 Voice Mail

5 Create

6e-mail

7 Data Folders

8 Outbox

9SMS Chat

Data Folders

1My Pictures

2 My Sounds

3 My Themes

4 User 1 - 5

Organiser

1 Synchronization

2 Contacts List

3 Converter

4 Business Card

5 Schedule

6 Calculator

7Alarm

8Memo

9 Receive object

Connect

1 Bluetooth

2 Infrared Dialup

3 Receive Object

X70DPK11B1.book Page 21 Thursday, September 18, 2003 5:12 PM

Menu structure

Navigation key

The navigation key is a multi-function key. You use the top, bottom, left and right edges

to move around the display. These actions are indicated by b, a, d and c in this user

guide. You press the centre of the navigation key Q to:

zAccess the menu system.

zDisplay a submenu.

zSelect a highlighted menu item.

zConfirm a selection.

zSelect the item in the primary selection area.

zTake a picture with the camera

Menu shortcuts

When you are familiar with the menu system, you can enter the menu number instead of

navigating through the display menus. For example, to browse your contacts list:

From idle mode, press Q, 2, 1.

X70DPK11B1.book Page 22 Thursday, September 18, 2003 5:12 PM

Voice calls

Making calls

Ensure that the phone is switched on, the network operator logo is displayed, and the

antenna and signal strength icons (ST) show that network coverage is available in the

current area.

From idle mode, enter the area code and phone number.

Press D.

Ending calls

Press E.

Answering a call

To receive a call the phone must be switched on and the signal strength icon (T) must

be displayed.

To answer a call, press any key except E.

Answering a call handsfree

Press and hold D.

Sending DTMF tones during a call

You can send DTMF tones during a call to access voice mail, paging and computerised

home banking. For example, you may need to enter a number to remotely access voice

mail messages.

To send DTMF tones during a call, press the required digit keys.

Rejecting a call

If you do not want to answer an incoming call, press E.

Note: Do not hold the phone to your ear when in handsfree mode.

Note: If you do not answer a call, or reject a call, the number of incoming calls missed

is displayed. Press any key to clear the display.

X70DPK11B1.book Page 23 Thursday, September 18, 2003 5:12 PM

Voice calls

Making international calls

If you know the international number, you can enter it in the normal way, followed by the

area code and phone number.

You can use the automatic international access code (+), to dial international numbers

without knowing the code for the international exchange.

From idle mode, press and hold 0 until + is displayed.

Use e to scroll through a list of country codes.

Select the code you want.

Enter the area code and phone number.

Press D.

Making emergency calls

To make an emergency call, the antenna symbol (S) must be present.

If a SIM is installed, enter 112 and press D.

If a SIM is not installed, press Q, select SOS, press Q.

Using automatic redial

If a connection is unsuccessful, press Q when Ok is displayed.

To stop redialling, press Q when Cancel or C is displayed.

Using hotkey dialling

If you have set up hotkey dialling, you can press and hold a digit key to call contacts on

your Contacts List. As each entry in your Contacts List is stored in a numbered location,

press and hold the digit key relating to that location. To turn on hotkey dialling

see Enabling and disabling hotkey dialling on page 57.

Note: Many countries/regions include an initial 0 in the area

code. In most cases, you should omit this when

dialling international numbers. If you have difficulties

making international calls, contact your service

provider.

Note: Making Emergency calls without a SIM installed is country or SIM dependent.

qTI

List

BTN

BWA

CAF

CAM

CAN

Ok C

X70DPK11B1.book Page 24 Thursday, September 18, 2003 5:12 PM

Voice calls

Displaying caller ID

If the caller’s number and name are stored in your Contacts List, they can be displayed

during an incoming call.

Setting the ear piece volume

During a call press e to adjust the ear piece volume.

Swapping between handsfree and handheld modes

From handheld to handsfree

Press Q.

Select H’free.

From handsfree to handheld

Press Q twice.

Holding a call

Press Q.

Select Hold.

Resuming a call

Press Q.

Select Resume.

Press Q.

Note: This is network dependent R.

Note: Caller ID may not always be available.

Note: You can adjust the volume for the personal handsfree accessory in the same way.

X70DPK11B1.book Page 25 Thursday, September 18, 2003 5:12 PM

Voice calls

Making a second call

If Call Waiting is enabled, you can make a second call. You can check your call waiting

status from Settings > Call Service > Calls > Call Waiting.

Press A.

Select contact number to dial.

Select Recall.

Press Q.

Press D.

The first call is put on hold.

Receiving a second call

If Call Waiting is enabled, you can receive a second call. You can check your call

waiting status from Settings > Call Service > Calls > Call Waiting.

Accept or reject a second call

Press Q.

Select Accept or Reject.

End current call and receive second call

Press E.

Press D to answer the second call.

Note: This is network dependent R.

Note: You cannot make more than one fax or data call at a time.

Note: You must end all voice calls before you can make or receive a fax or data call.

Note: This is network dependent R.

Note: You cannot receive more than one fax or data call at a time.

Note: You must end all voice calls before you can make or receive a fax or data call.

Note: If you accept the second call, the current call is put on hold.

X70DPK11B1.book Page 26 Thursday, September 18, 2003 5:12 PM

Voice calls

Operating during two calls

Swapping between calls

An icon (z or /) indicates the current call.

Press Q.

Select Swap to change to the other call.

Ending current call

Press Q.

Select End.

Ending both calls

Press E.

Transferring a call

When you are connected to two calls, you can connect them together, and end your

connections, leaving the two callers to talk to each other.

Press Q.

Select Trans.

Multi-party calls

In a multi-party call three to five people can have a conversation at the same time. You

can swap between a multi-party call and another call as you do for two separate calls.

Enabling a multi-party call

With two calls connected (one active and one on hold), press Q.

Select Merge.

All three parties can now talk to each other.

Note: You cannot do this while in multi-party mode.

Note: This is SIM dependent M.

X70DPK11B1.book Page 27 Thursday, September 18, 2003 5:12 PM

Voice calls

Adding people

You can add people to the multi-party call (up to a maximum of five), either by making

a call or accepting an incoming call. You can then merge the new call into the multi-party.

Press Q.

Select Merge.

Splitting a multi-party call

You can select a caller from the multi-party call and remove their connection, so that you

can talk privately to them.

Press Q.

Select Option.

Select a caller.

Select Split.

The selected caller is split from the multi-party and the multi-party call is placed on hold.

The remaining multi-party callers can still talk to each other.

Rejoining a multi-party call

When you have finished talking to an individual you can rejoin the multi-party call:

Press Q.

Select Merge.

Ending a single connection to a multi-party call

Press Q.

Select Option.

Select a caller.

Select End.

Ending all connections to a multi-party call

Press E.

Note: When you make a call or accept an incoming call, the multi-party call is placed on

hold. The other callers in the multi-party call can continue to talk to each other

while on hold from you.

Note: You cannot end an individual caller if you have a call on hold or another call is

incoming.

X70DPK11B1.book Page 28 Thursday, September 18, 2003 5:12 PM

Voice calls

Using the notepad

During a call you can enter numbers that you may want to dial when you have finished

the call. You can make a note of these numbers on the notepad.

Enter the number.

When you have finished your call, press D to dial the number.

Press A while the number is displayed to store the number in your Contacts List.

The current call remains active.

In call options

During a call select Menu > Menu to access the following menus:

Schedule, Browser, Contacts List, Messaging and Memo.

For information on using these menus, see the relevant section in this user guide.

X70DPK11B1.book Page 29 Thursday, September 18, 2003 5:12 PM

Text entry

You use alphanumeric characters to enter details into the Contacts List, to create text and

e-mail messages.

There are five different text entry modes: normal (ABC or abc), Greek (V), extended

alphabet (W), numbers (X) and T9® (T9). To change your text entry mode press A,

or select Menu > Input Mode, and select the mode that you want. The icon for the

current mode appears in the information area on the display. To change between upper

and lower case letters press *. The table below shows the characters that you can enter

in the different text modes.

Text Mode

Key T9® Normal (ABC) Greek Extended Numeric (0 - 9)

0Alternatives + _ 0

1Punctuation . @ / : ; * # + - “ , ! ¡ ? ¿ _ ( ) [ ] { } ’ & % \ ^

~ | < > = € £ $ ¥ ¤ §

2abc ABCabc ΑΒΓ AÄÅÆBCÇ

aäåæàbc

3def DEFdef ∆ΕΖ DEÉFdeéèf 3

4ghi GHIghi ΗΘΙ GHIghiì 4

5jkl JKLjkl ΚΛΜ JKLjk 5

6mno MNOmno ΝΞΟ MNÑOÖØm

nñoöøò

7pqrs PQRSpqrs ΠΡΣ PQRSpqrsß 7

8tuv TUVtuv ΤΥΦ TUÜVtuüùv 8

9wxyz WXYZwxyz ΧΨΩ WXYZwxyz 9

*Shift/Lock Shift/Lock Shift/Lock *

#Space #

X70DPK11B1.book Page 30 Thursday, September 18, 2003 5:12 PM

Text entry

T9®

Using T9® reduces the number of key presses required.

When in T9® mode:

Press a key once for any letter you require on that key. The desired letter may not be

displayed.

Continue pressing other keys until the end of a word is reached.

Check that the word has been typed correctly before continuing to the next word.

If the combination of letters typed has produced a word which is not the one you

require, press e until the correct word is displayed.

Continue to the next word.

If the word you require is not in the internal dictionary, you can enter it using the

Normal mode, or add it to the internal T9® dictionary.

Adding entries to the T9® dictionary

If the internal T9® dictionary does not contain a word, name, or abbreviation that you

require, you can add it. Words that you add to the T9® dictionary are available for future

use.

From T9® entry mode, press the key 2 - 9 that displays the character required.

Use e to select the required character.

Use c to move to the next character.

Repeat these steps until the word is complete.

Press # to add the word to the internal dictionary.

T9® is a trademark of Tegic Communications Inc. T9® Text Input is licensed under one or more of the following:

U.S. Pat Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Canadian Pat No. 1,331,057; United

Kingdom Pat No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat No. 51383;

Euro. Pat No. 0 842 463 (969272260.8) DE/DK,FI, FR, IT, NL, PT, ES, SE, GB: and additional patents are pending

worldwide.

Entering text

In Normal, Greek and Extended modes, each time you press a key in quick succession the

next character available on that key is displayed. For example, to enter ‘c’ you need to

press 2 three times in quick succession. To enter the displayed character, release the

key or press another key. The cursor then moves to the next position. If you want to enter

two consecutive letters from the same key, for example ‘on’ or ‘ll’, you may need to press

c to move to the next position.

You can also select Menu > Char.List and choose a character. Only the characters

available in your current text entry mode are displayed.

X70DPK11B1.book Page 31 Thursday, September 18, 2003 5:12 PM

Text entry

Editing text

Press e to move up or down one line of text.

Press f to move left or right one character.

Press B to delete the character to the left of the cursor.

Press and hold B to delete the current line.

If you move the cursor over a character and press another key, the new character is

inserted immediately before the selected character.

Cut, copy and paste

You can cut, copy and paste text from other messages or contacts list entries on your

phone.

To cut text:

Select Menu > Cut.

Move to the start of the text that you want to cut, and select Start.

Use f to highlight the text that you want to cut, and select Stop.

To copy text:

Select Menu > Copy.

Move to the start of the text that you want to copy, and select Start.

Use f to highlight the text that you want to copy, and select Stop.

You can only paste text if you have previously cut or copied some text. To paste text:

Move where you want to paste the text.

Select Menu > Paste.

X70DPK11B1.book Page 32 Thursday, September 18, 2003 5:12 PM

Settings

Use the Settings menu to personalise your phone.

Display

Setting the wallpaper

The wallpaper is a picture that displays when the phone is in idle mode.

Select Wallpaper.

Select the folder where the picture is stored.

Select your picture.

Changing the start up events

The start up events are an animation that you can select and a greeting that you enter.

These appear when you turn on the phone. The animation is also shown when you turn

off the phone.

Setting the brightness

You can adjust the brightness of the display. To make the display brighter select +1, to

dim the display select -1.

Select Brightness.

Use e to move between +1, 0 and –1.

Press Q.

Display

Wallpaper On/Off

Show Brightness Backlight

Time Key

Backlight Clock/

Calendar Case

Screen

On/Off Show

Animation Greeting

Enter the text of

your greeting

Select one of

the preset

animations

Off

Menu > Settings > Display

X70DPK11B1.book Page 33 Thursday, September 18, 2003 5:12 PM

Settings

Setting the backlight time

The Backlight Time is the time that your screen remains lit when you are not using your

phone.

Select Backlight Time.

Select from 10 seconds, 30 seconds and 60 seconds.

Setting the key backlight

The Key Backlight illuminates your phone’s keys.

Select Key Backlight.

Select On or Off.

Displaying the clock/calendar in idle mode

You can choose whether or not to display a clock or calendar on the screen when in idle

mode. Use e to move between the options.

Changing the case screen settings

The Case Screen is the screen on the front of the phone. It has a clock, icon area,

incoming message area and call alerts area.

Note: Setting the Backlight Time to 60 seconds, can reduce the talk and standby time

of your battery.

Note: Turning on the Key Backlight can reduce the talk and standby time of your

battery.

Clock/Calendar

Calendar Digital

Clock

Remove Clock/

Calendar Analog

Clock

Case Screen

Backlight

Colour OrientationContrast Case

Screen

Menu > Settings > Display

X70DPK11B1.book Page 34 Thursday, September 18, 2003 5:12 PM

Settings

Changing the contrast

Select Contrast.

Use e to move between 0 and 10.

Select Ok.

Changing the backlight colour

You set the backlight colour, to see what type of call you are receiving, or what mode you

are in when the phone is closed. You can set the backlight colour for:

zAlarm/Schedule

zVoice Calls

zFax Calls

zData Calls

zMessages

zMMS Notify

zWAP Services

zVoice Mail

zCamera Mode

zOthers

To set your backlight colours:

Select BacklightColour.

Select the item you want to change.

Select a colour.

Changing the orientation

The orientation changes the alignment of the information on the case screen.

Select Orientation.

Select Left or Right.

Changing the case screen display

Select Case Screen.

Select from Clock/Status, Analog and Digital.

If you select Clock/Status the battery level and GSM signal strength appear in the

information area.

Menu > Settings > Display >Case Screen

X70DPK11B1.book Page 35 Thursday, September 18, 2003 5:12 PM

Settings

Alerts

Changing the ring volume

You can change the ring volume so that you can hear your phone ring. For example, in a

noisy environment you may want to set the volume to maximum.

Select Ring Volume.

Use e to move between 0 and 4 on the volume scale.

Press Q to select the new volume level.

Setting the ring type

Use ring type to select the sound you want to hear when you receive a call.

Select Ring Type.

Select the type of call that you want to change.

Select the folder where your sound is stored.

Select your sound.

Setting quiet mode

In quiet mode the microphone amplifies your voice, so you can whisper and still be heard

by the person on the other end of the call. You should use quiet mode in situations where

you do not want to disturb the people around you.

In quiet mode, the phone will not ring when you receive a call or message, unless you set

a ring volume for quiet mode.

Note: This option is unavailable if you are in quiet mode.

Alerts

Ring

Volume Ring Type Quiet

Mode Vibration

Alert Melody

Composer Voice

Recorder Auto

Answer

Quiet Mode

Ring Volume VibrationOn/Off

On Off

0 - 4

Continuous Intermittent Off

Menu > Settings > Alerts

X70DPK11B1.book Page 36 Thursday, September 18, 2003 5:12 PM

Settings

Setting a vibration alert

If you set a vibration alert, the phone vibrates when you receive a call or message. This

setting is separate from the vibration alert that you set for quiet mode.

Select Vibration Alert.

Select from Continuous, Intermittent and Off.

Creating a ring type

Select Melody Composer > Create.

Using the following table, enter the notes, rests and durations to create your melody.

When you have completed your melody, you can save it:

Press Q.

Select Ok.

Enter a name.

Select Save.

Select the folder where you want to save your melody.

At any time during your composing, you can press A to play back your melody.

Key 1st press 2nd press 3rd press 4th press 5th press

1C2 C3 C4 C5

2D2 D3 D4 D5

3E2 E3 E4 E5

4F2 F3 F4 F5

5G2 G3 G4 G5

6A2 A3 A4 A5

7B2 B3 B4 B5

0Rest

*1/8 1/4 1/2 1 1/16

#Sharp

Menu > Settings > Alerts

X70DPK11B1.book Page 37 Thursday, September 18, 2003 5:12 PM

Settings

Once you have saved your melody you can edit it.

Select Edit from the Melody Composer menu.

Select the data folder where your melodies are stored.

Select the melody you want to edit.

Select Edit.

Use the relevant keys to insert new notes and rests.

Recording a voice message

You can record a message to use as your ring type.

Select Voice Recorder > Record.

Record your message.

Store the recording in a data folder.

You can now select and use this sound in the same way as you do for any other ring types.

Once you have recorded a voice message you can edit it. Select Edit from the Voice

Recorder menu, then edit it as necessary.

Setting auto answer

When auto answer is on, and your phone is connected to a car kit or personal handsfree

adaptor, incoming calls are automatically answered.

Select Auto Answer > On.

To turn off auto answer:

Select Auto Answer > Off.

Keys

Choosing the function for the shortcut key

The right soft key ( B ) is a shortcut key from idle mode. You can choose which function

you want this key to access. The default is camera.

Select Shortcut Key.

Select the function that you want.

Keys

Shortcut Key Keyguard Key Volume Key Tone Answer

Key

Menu > Settings > Keys

Menu > Settings > Alerts

X70DPK11B1.book Page 38 Thursday, September 18, 2003 5:12 PM

Settings

Setting the keyguard

The keyguard stops the keypad being accessed.

Select Keyguard.

You are asked ‘Guard Keypad?’. Press Q.

To turn off the keyguard:

From idle mode press Q.

You are asked ‘Free keypad?’. Press Q.

Changing the key volume

The key volume is the volume of the tone made when you press a key.

Select Key Volume.

Use e to move the volume level between 0 and 4.

Changing the key tone

The key tone is the sound made when you press a key.

Select Key Tone.

Select the tone you want.

Choosing the key to use for the answer key

You can choose whether to use any key or just the send key (D) to answer a call.

Select Answer Key.

Select Any Key or Send Key.

Note: When the keyguard is on, you must turn it off before you can use the phone.

Menu > Settings > Keys

X70DPK11B1.book Page 39 Thursday, September 18, 2003 5:12 PM

Settings

Phone settings

Changing the language

You can change the language that the phone uses for display messages and text entry.

Select Language.

Select DisplayLanguage or Tegic Language.

Select the language.

Changing the DTMF length

DTMF stands for Dual Tone Multi-Frequency. You can send DTMF tones during a

conversation to access voice mail, paging and computerised home banking. For example,

you may need to enter a number to remotely access voice mail messages.

Select DTMF Length.

Select Long or Short.

Turning tones on and off

You can turn on or off all tones or just warning tones.

Select All Tones or Warning Tones.

Select On or Off.

Active flip

If you enable active flip, you can answer a call by opening the phone, end the call by

closing the phone and reject a call by pressing the memo/camera shutter key.

Select Active Flip.

Select On or Off.

Selecting camera tones

The camera tone is the sound the phone makes when you take a picture.

Select Camera Tones.

Select a tone type.

Note: Tegic language is the language used by T9® text entry. For more information on

T9® text entry, see Entering text on page 31.

Phone Settings

Language DTMF

Length All Tones Active Flip Warning

Tones Camera

Tones User

Messages

Menu > Settings > Phone Settings

X70DPK11B1.book Page 40 Thursday, September 18, 2003 5:12 PM

Settings

Editing user messages

The phone contains some standard user messages that you can send to other people. You

can edit these messages to suit you.

Select User Messages.

Select the message you want to edit.

Edit the message.

Clock

Setting the clock

Setting the time

Use this to set the current time and date on your phone.

Enter the date (day/month/year).

Enter the time (24 hour clock)

Setting summertime

You can set summertime when you are at home or away. When you set summertime, the

clock automatically moves on by one hour.

Select Home Summertime or Away Summertime.

Select On or Off.

Setting your home area

Select Home Area.

Select World List to choose a country. Select the country you are in.

Select City List to choose a city. Select the city closest to your current location.

Clock

Clock Set Current

Location Display

Format Away Clock Power Time

Clock Set

Time Set Home

Summertime Away

Summertime Time

Difference Auto

Adjustment

Home Area

Menu > Settings > Phone SettingsMenu > Settings > Clock > Clock Set

X70DPK11B1.book Page 41 Thursday, September 18, 2003 5:12 PM

Settings

Auto adjusting the time difference

If you are away, in a country with one time zone, then the time difference can be adjusted

automatically.

Select Clock Set > Auto Adjustment > On.

The phone gets your location from the local network provider, and adjusts the clock

automatically.

Setting the time difference

If you are away, in a country with more than one time zone, then you can set the time

difference manually.

Select Clock Set > Time Difference.

Select the difference from your home area.

Changing your location

You can change your location so that the phone’s clock automatically adjusts depending

on whether you are at home or abroad. All the clocks on the phone display the time of the

selected location.

Select Current Location.

Select Home or Away.

If you select Away, you may need to adjust the time difference, so your clock is correct.

To do this see Setting the time difference on page 42.

Changing the display format

You can choose how you want the time and date to display.

Select Display Format

Select from the displayed list of date and time formats.

Changing the appearance of the away clock

You can choose how you want the away clock to display.

Select Away Clock.

Select from Off, Large Clock or Case Clock.

Setting the power on and off times

You can use this to set the phone to turn itself on or off automatically at a specified time.

Select Power Time.

Select --:-- On or --:-- Off.

If times are already set then these times appear before the words On and Off.

Select --:-- or the existing time.

Enter the time you want the phone to power on or off.

Set whether these power on/off times are Repeat Daily, Once or Disabled.

Press A to save your settings.

qSTI

Display Format

HH:MM

HH:MM AM

HH:MM AM DD/MM

HH:MM AM MM/DD

HH:MM DD/MM/YYYY

YYYY/MM/DD HH:MM

Ok C

MM/DD/YYYY HH:MM

Menu > Settings > Clock

X70DPK11B1.book Page 42 Thursday, September 18, 2003 5:12 PM

Settings

Disabling the power on and off times

Select the power on or off time.

Select the frequency option.

Select Disabled.

Press A to save your alarm settings.

Highlight the power on or off time.

Press A to cycle through Repeat Daily, Once or Disabled.

Stop at Disabled.

Press Q then A to save your alarm settings.

Call service

Calls

Viewing the length of your last call

Select Calls > Last Call Timer.

The length of your last call is displayed.

Viewing the combined length of all your outgoing or incoming calls

Select Calls > All Calls Timer.

Select Incoming or Outgoing.

The combined length of all your incoming or outgoing calls since the timer was last

reset, is displayed.

Caution: You need to ensure that the times you set will not automatically power on

when you are in an aircraft, medical facility etc. See Important information on

page 5.

Call Service

Connections Send My

Number

Calls

Last Call Timer All Calls Timer Call Waiting Caller’s ID Withhold ID

Menu > Settings > Clock > Power TimeMenu > Settings > Call Service

X70DPK11B1.book Page 43 Thursday, September 18, 2003 5:12 PM

Settings

Once you have seen the total time you can reset the timer:

Press Q.

You are asked ‘Reset?’. Press Q.

You are asked ‘Reset Total Time?’. Press Q.

Enter the lock code.

Checking the status of call waiting, caller’s id and withhold id

Select Calls.

Select Call Waiting, Caller’s ID or Withhold ID.

The status is displayed.

For Call Waiting, you can change the status:

If Call Waiting is disabled and you want it enabled, select Menu > Enable.

If Call Waiting is enabled and you want it disabled, select Menu > Disable.

Connections

Viewing details of your last connection

Select Connections > Last Connection.

The time and data transfer details are displayed.

Viewing the combined details of your previous connections

Select Connections > All Connections.

The combined length of all your incoming or outgoing calls since the timer was last reset,

is displayed.

Once you have seen all the details you can reset the total time and data:

Press Q.

You are asked ‘Reset Total Time and Data?’. Press Q.

Enter the lock code.

Note: The lock code is preset to 0000. For security you should change this to a four

figure number that you can remember, see Changing the phone lock code on

page 47.

Note: This is network dependent R.

Connections

All ConnectionsLast Connection Call Priority

Menu > Settings > Call Service

X70DPK11B1.book Page 44 Thursday, September 18, 2003 5:12 PM

Settings

Allowing incoming calls during data transfer

With this enabled, you can transfer data and accept incoming calls on your phone. With

this disabled, you cannot answer incoming calls while you are transferring data.

Select Connections > Call Priority.

Select On or Off.

Sending your number

If your network supports this function, you can decide whether you want your phone

number to be sent when you make a call.

Select Send My Number.

Select from Network Set, On and Off.

If you select Network Set, your network’s default setting is used.

Call divert

Setting and cancelling diverts

To set diverts for specific call types:

Select the type of call you want to divert.

Select Set.

Select from All, Busy, No Reply and Unreachable.

Enter the number to divert to.

Note: The lock code is preset to 0000. For security you should change this to a four

figure number that you can remember, see Changing the phone lock code on

page 47.

Note: This is network dependent R.

Note: You must be registered with a service provider before you can choose to send your

number.

Call Divert

Divert Voice Divert Fax Divert Data Cancel All Status

Menu > Settings > Call ServiceMenu > Settings > Call Divert

X70DPK11B1.book Page 45 Thursday, September 18, 2003 5:12 PM

Settings

To cancel diverts for specific call types:

Select the type of call you want to cancel the divert on.

Select Cancel.

Select from All, Busy, No Reply and Unreachable.

To cancel all diverts:

Select Cancel All.

Confirm that you want to cancel all the diverts you have set.

Viewing the divert status

Select Status.

Use e to scroll through the list, only one item at a time appears on the screen.

Security

Setting and cancelling the phone lock

When the phone lock is set you can only use the phone to receive incoming calls and to

make emergency calls.

Select Phone Lock > On/Off > On.

Enter the lock code.

The lock icon (O) is displayed on the screen.

When the phone lock is on you have to enter the lock code from the idle screen before

you can use the phone.

To cancel the phone lock:

Select Phone Lock > On/Off > Off.

Enter the lock code.

Note: The phone lock code is preset to 0000. For security, you should change this to your

own four-figure number, see Changing the phone lock code on page 47.

Security

Phone Lock Call Bar PIN Fixed Dial Barred

Dial

PIN2

Menu > Settings > Call Divert Menu > Settings > Security

X70DPK11B1.book Page 46 Thursday, September 18, 2003 5:12 PM

Settings

Changing the phone lock code

You can change the phone lock code to a four figure number that you find easy to

remember.

Select Phone Lock > Change Code.

Enter the current phone lock code.

Enter the new phone lock code.

Verify the new phone lock code.

Setting and cancelling call bar

Call barring restricts certain types of incoming and/or outgoing calls, using a password

provided by your service provider. When you check the status of the Call Bar, your phone

must be registered with a network. You can set call barring for voice, fax and data calls.

Select Call Bar.

Select the type of call that you want to bar.

Select Set or Cancel.

Select when you want to bar the calls.

Enter the password, provided by your service provider.

To cancel all the current call bars:

Select Call Bar > Cancel All.

Enter the password.

Confirm that you want to cancel all the set call bars.

Viewing the call bar status

You can see whether you have any call types barred.

Select Call Bar > Status.

Use e to scroll through the list, only one item at a time appears on the screen.

Changing the password

You can change the password to something that you find easy to remember.

Select Call Bar > Password.

Enter the password, supplied by your service provider.

Enter the new password.

Verify the new password.

Note: You can change your password to something that you find easy to remember,

see Changing the password on page 47.

Menu > Settings > Security

X70DPK11B1.book Page 47 Thursday, September 18, 2003 5:12 PM

Settings

Enabling and disabling PIN and PIN2

The PIN protects your phone against unauthorised use. If you enable the PIN, you have

to enter it every time you turn on the phone.

You need PIN2 to set fixed dial numbers.

Your PIN and PIN2 are supplied by your service provider.

Select PIN or PIN2.

Select Enable/Disable.

Select On or Off.

Enter the PIN or PIN2.

Changing the PIN

You can change the PIN to an eight figure number that you find easy to remember.

Select PIN.

Select Change.

Enter the PIN.

Enter the new PIN.

Verify the new PIN.

Enabling and disabling fixed dial

Fixed dial is part of the Contacts List, but with added security. When you enable fixed

dial:

zYou can only dial numbers that are in the fixed dial store

zIf you manually dial a number, it must match one in the fixed dial store.

zIf you store, edit or delete a phone number, you have to enter your PIN2.

To enable or disable fixed dial:

Select Fixed Dial.

Select On or Off.

Enter your PIN2, provided by your service provider.

Note: If you enter the PIN or PIN2 incorrectly three times, the phone will lock and you

will need to enter the PUK or PUK2 code. If you enter the PUK or PUK2 code

incorrectly ten times, your phone will no longer operate. All information stored in

the SIM will be lost, and you will need to replace the SIM. Contact your service

provider for the PUK and PUK2 codes. Contact your service provider for more

details.

Note: You can only change the PIN when it is enabled.

Menu > Settings > Security

X70DPK11B1.book Page 48 Thursday, September 18, 2003 5:12 PM

Settings

When you enable fixed dial, in the Contacts List you can only browse the numbers that

are in the fixed dial store.

Enabling and disabling barred dial

When you enable barred dial you can no longer dial the numbers that you entered as

barred dial numbers. You can use this to stop certain numbers being dialled.

To enable or disable barred dial:

Select Barred Dial.

Select On or Off.

Enter your password.

Network

Changing to a new network

When you are not in your home country or region, you may be able to use a network that

you are not directly subscribed to. This is called roaming.

Use the options on the Network menu to select a network that is available in your current

location.

Select New Network.

Select a new network.

An X appears in the information area if you cannot register with the selected network.

Search mode

You can set the Search Mode to Automatic or Manual. When the Search Mode is

Manual, the phone only uses the selected network. If coverage is lost, you need to select

another network. When the Search Mode is Automatic, the phone automatically

reselects a new network to maintain network availability.

Note: National Law may not permit roaming in your home region.

Network

Mode Network

List

New

Network

Menu > Settings > SecurityMenu > Settings > Network

X70DPK11B1.book Page 49 Thursday, September 18, 2003 5:12 PM

Settings

Network list

In Automatic Mode, the phone uses the Network List to find a new network. The

location numbers in the Network List show the search priority. You can change the list

as follows:

Insert stores a new network in the currently displayed location, and moves other

networks down.

Edit overwrites the old network with a new one.

Delete deletes the currently displayed network.

Ok selects the currently displayed network.

Defaults

Use this to return your personal settings to their factory default. You cannot return the

Phone Lock or Language to their default settings.

Menu > Settings > Network Menu > Settings > Defaults

X70DPK11B1.book Page 50 Thursday, September 18, 2003 5:12 PM

Contacts list

Use the Contacts List menu to store a person’s phone numbers, e-mail

addresses, company name, picture and other information. You can also set

up how your contacts list is organised and displayed.

Create

Creating a new contact

Select Contact.

Select an item.

Enter the data using the keypad, or select an item from the list available.

For each contact you can enter:

Note: Fixed Dial Number and Barred Dial Number are only available if you have

enabled Fixed Dial (see Enabling and disabling fixed dial on page 48) or Barred

Dial (see Enabling and disabling barred dial on page 49).

Note: When you create or edit any entries, you must remember to press A to save your

changes, or they will be lost.

Item Number of characters

First name 16

Last name 16

Home number 40

Work number 40

Mobile number 40

Other number 40

Home e-mail 80

Work e-mail 80

Other e-mail 80

Create

Fixed Dial

Number Barred Dial

Number

Contact

Menu > Contacts List > Create

X70DPK11B1.book Page 51 Thursday, September 18, 2003 5:12 PM

Contacts list

When you have entered all the details, press A to save the contact.

Entering DTMF digits in a phone number

You can enter DTMF digits at the end of a phone number, so that these numbers are

automatically sent after the main phone number.

Enter the phone number.

Press and hold 0 until a P is displayed at the end of the phone number.

Enter the DTMF digits, for example, the number to access voice mail messages.

When you call this number the DTMF tones will be sent after 3 seconds.

Entering a picture

You can choose from Camera and Select. Choose Camera to take a picture with the

phone’s camera.

Select Camera.

Take the picture.

Rename the picture.

Press A to return to the Contact.

Choose Select to select a picture from your Data Folders. The default folder is My

Pictures. If you want to select a picture from another folder, press A to see the list of

Data Folders.

URL 80

Title 16

Company 16

Note 32

Picture Select a picture from the list or take a picture with the camera

Group name Select a group from the list.

Ring type Select a tone from the list.

Vibration alert Select a vibration type from the list.

Case screen colour Select a colour from the list.

Location 3 (up to 500 locations)

Note: Location is the location number in your Contacts List.

Note: If you put a contact in a group which has a ring type, case screen colour and

vibration alert, then these options are not available for the individual contact.

Item Number of characters

Menu > Contacts List > Create

X70DPK11B1.book Page 52 Thursday, September 18, 2003 5:12 PM

Contacts list

Setting fixed dial numbers

Fixed dial is part of the Contacts List, but with added security. When you enable fixed

dial:

zYou can only dial numbers that are in the fixed dial store

zIf you manually dial a number, it must match one in the fixed dial store.

zIf you store, edit or delete a phone number, you have to enter the PIN2, provided by

your service provider.

To enter a fixed dial number:

Select Fixed Dial Number.

Enter the number.

Enter your PIN2.

The number is stored in your fixed dial store.

Setting barred dial numbers

When you enable barred dial you can no longer dial the numbers that you entered as

barred dial numbers. You can use this to stop certain numbers being dialled.

Select Barred Dial Number.

Enter the number that you want to bar.

Enter your password.

‘Wild’ numbers

Wild numbers are spaces that you can store in a phone number. You must fill the wild

numbers before you can dial that phone number. You can use wild numbers in

conjunction with fixed dial, to, for example, restrict calls to a specific area by storing the

area code then adding the remainder of the number when it is recalled.

To enter a wild number:

While entering a phone number, press and hold 0, until _ is displayed.

When you recall this phone number, enter the required number to replace the wild

number.

Note: Fixed Dial Number is only available if you have enabled Fixed Dial (see Enabling

and disabling fixed dial on page 48).

Note: Barred Dial Number is only available if you have enabled Barred Dial

(see Enabling and disabling barred dial on page 49).

Menu > Contacts List > Create

X70DPK11B1.book Page 53 Thursday, September 18, 2003 5:12 PM

Contacts list

Browse

This menu only applies to contacts stored on your phone. For contacts stored on the SIM

see SIM on page 58.

View. Displays all the details for the entry you selected. You need to scroll down the

screen to see all the information.

Recall. Displays the phone number for the entry you selected. You can either call it or

change it. To call it press D.

Delete. Deletes the entry.

Create. Creates a new entry in the Contacts List.

Infrared. Sends the details of the current entry to another device via the infrared port.

Bluetooth. Sends the details of the current entry to another Bluetooth device.

–> SIM. Copies the details of the current entry to the SIM.

Voice dial

With voice dial you can save a number using your voice. You can then dial the number

by saying the name that you want to call.

Creating a voice dial entry

Select Voice Dial.

Select Add.

Select a contact.

Select Recall.

Select Ok.

Hold the phone about 20cm away from your mouth.

Speak clearly into the microphone to record the required name.

Each entry will prompt you to record the name a second time so that the phone will

recognise your voice and intonation.

Note: When you create or edit any of your entries, you must press A to save your

changes, or they will be lost.

Browse

View Recall

Select a

contact

Create Infrared Bluetooth –> SIMDelete

Menu > Contacts List > Browse Menu > Contacts List > Voice Dial

X70DPK11B1.book Page 54 Thursday, September 18, 2003 5:12 PM

Contacts list

When you have finished recording, the display shows whether or not the recording was

successful. If the recording failed, you need to try again. You can try as many times as

you need to.

Recalling a voice dial entry

From idle mode press and hold b or a.

Say clearly the name that you want to recall.

Press D to call the number.

Dialling a voice dial entry

You can set up voice dial to dial a voice dial number directly from idle mode, so you don’t

have to press D to call the number.

Select Voice Dial.

Select On/Off.

Select Enable.

To turn it off select Disable.

Editing a voice dial entry

Select Voice Dial.

Select an entry.

Select from Add, Play and Delete.

Add. Add a new Voice Dial entry.

Play. Listen to the recording for the selected entry.

Delete. Delete the selected entry.

Groups

From the Groups menu, you can set up groups of contacts. You can use groups to collect

together types of entries, for example, business, friends and family. You can give each

group a suitable title, for quick access to the entries.

Creating a group

Select a preset group name or one of the available user group names from the list.

You can enter a name, ring type, vibration alert and case screen colour.

Note: Each recording is short, so be ready to speak soon after initiating the recording.

Note: If you already have ring type, vibration alert and case screen colour set for an

individual that you add to the group, then the group’s settings are used in

preference to those set for the individual.

Menu > Contacts List > Voice DialMenu > Contacts List > Groups

X70DPK11B1.book Page 55 Thursday, September 18, 2003 5:12 PM

Contacts list

Viewing a group

Once you have created a group, you can view its settings.

Select the group on the list.

Select View from the menu.

From this view you can then edit the group settings:

Select the item that you want to edit.

Select Edit.

Make your changes.

Select Ok to make your changes or Cancel to revert to the original.

You can revert to the original settings by selecting Reset.

Previewing a group

This simulates an incoming call, so that you can review your settings and see if they are

what you want.

Select a group.

Select Preview.

You can then adjust your settings using View.

Adding and removing members

Once you have created a group, you can add or remove members.

To add a new member:

Select the group on the list.

Select Members from the menu.

Select Add.

Select a contact from your list.

Highlight the group on the list.

Press A.

Select Add.

Select a contact from your list.

To remove a member:

Select the group on the list.

Select Members from the menu.

Highlight a contact.

Select Remove to remove this contact from the group.

Menu > Contacts List > Groups

X70DPK11B1.book Page 56 Thursday, September 18, 2003 5:12 PM

Contacts list

Highlight the group on the list.

Press A.

Highlight a contact.

Select Remove to remove this contact from the group.

Settings

Setting how to sort or search entries

You can choose how to sort and search the entries in your Contacts List.

Select Sort by or Display by.

Select First Name or Surname.

Setting how to display entries

You can choose how to display the entries in your Contacts List.

Select Separator.

Select Space or Comma.

Enabling and disabling hotkey dialling

With hotkey dialling, you can press and hold the digit key that relates to a location

number to call contacts on your Contacts List. For example, to call the contact in location

3 of your Contacts List, press and hold 3.

To enable hotkey dialling, select Hotkey Dialling, then select either SIM Phonebook or

Mobile Phonebook.

To disable hotkey dialling, select Hotkey Dialling > Off.

Enabling and disabling voice dialling

With voice dialling, you can call a contact by speaking into the microphone.

Select Voice Dial.

Select On or Off.

To set up voice dial numbers see Creating a voice dial entry on page 54.

Settings

Sort by Display by Separator Hotkey

Dialling Voice Dial

Menu > Contacts List > Settings

X70DPK11B1.book Page 57 Thursday, September 18, 2003 5:12 PM

Contacts list

SIM

This shows the contacts stored on your SIM.

View. Displays all the details for the entry you selected. You need to scroll down the

screen to see all the information.

Recall. Displays the phone number for the entry you selected. You can either call it or

change it. To call it press D.

Delete. Deletes the entry.

Create. Creates a new entry in the Contacts List.

–> Phone. Copies the details of the current entry to the phone.

Profile. Displays the entry’s profile.

Storage

This shows the amount of space you have used on your SIM and your phone. Use e to

move between the two.

You can copy all the SIM contacts to the phone or copy all the phone contacts to the SIM:

Select Menu > Copy All.

Select SIM to phone or Phone to SIM.

You can delete all the SIM contacts or all the phone contacts:

Select Menu > Delete All.

Select SIM Contacts or Phone Contacts.

Note: When you create or edit any of your entries, you must press A to save your

changes, or they will be lost.

SIM

View Recall

Select a

contact

Create –> Phone ProfileDelete

Menu > Contacts List > SIM Menu > Contacts List > Storage

X70DPK11B1.book Page 58 Thursday, September 18, 2003 5:12 PM

Games

The games that are on your phone are network dependent. If you have

four games listed then you have embedded games and should follow the

instructions in the Embedded games section. If you have one game listed then you have

downloadable games and should follow the instructions in the Downloadable games

section.

Embedded games

To play the embedded games, select the required game, then follow the on-screen

instructions.

Demo

Select this to see a demonstration of a game.

Welcome

Select this to read the welcome screen.

Instructions

Select this to see general instructions for playing the games.

Settings

Nickname

Use this to create a name to use when you play games. When you first select this item, it

displays no pseudo. Use B to delete the existing text, then enter your nickname.

Sound

Use this to set the sound level for your games. You can select from Off, Low, Medium

and High.

Games

Space

War RollerKid Panko Crazy

Cobra Demo Welcome SettingsInstructions

Settings

Sound VibrationsNickname Back light

Menu > Games

X70DPK11B1.book Page 59 Thursday, September 18, 2003 5:12 PM

Games

Vibrations

If you turn vibrations on, the phone vibrates when a target is hit in the game. You can

select from On and Off.

Backlight

Use this to set your key back light. You can select from Off, On 30s and Always on.

Downloadable games

You have one embedded game - Wallbreaker. You can download one other game.

Catalogue

This displays a list of the games that you can download. To download a game:

Select a game.

Details of the game are displayed.

Press A to download the game.

Confirm that you want to download the game.

The game is downloaded to your phone.

News

Displays SMS broadcast messages from Infusio™, the games provider.

Instructions

Select this to see information about downloading games, and general instructions for

playing the games.

Settings

This is the same as the Settings menu for embedded games. See Settings on page 59.

Note: If you select Always on, this may affect the talk and standby time of your battery.

Note: This is network dependent.

Note: When you download a new game it overwrites the previously downloaded game.

Games

Wallbreaker Catalogue News Instructions Settings

Menu > Games

X70DPK11B1.book Page 60 Thursday, September 18, 2003 5:12 PM

Browser

Use the Browser menu to access Internet services supported by the

network, such as news, weather reports and sport.

Server list

Before you can access the Internet, your SIM must be data enabled and the configuration

information must be entered.

You can manually set up five servers on your phone.

For Circuit Switch, select Set, then select Edit and set:

zDigital Dial number

zAnalog Dial number

zCircuit Type. Select from Digital and Analog.

zUser ID

zUser Password

For GPRS, select Set, then select Edit and set:

zAccess Point Name

zUser ID

zUser Password

zAuthentication. Select from Normal, Encrypted and None.

Note: The configuration information may have been pre-programmed by your service

provider. If you modify these settings, your browser may no longer work.

Server List

<1> to <5>Server

Auto

Edit

Profile

Name Home

URL Linger Time Security Bearer

Type

Gateway

Circuit

Switch GPRS

Menu > Browser > Server List

X70DPK11B1.book Page 61 Thursday, September 18, 2003 5:12 PM

Browser

Start browser

To start the browser, select Home Page (to start the browser from idle mode press the

jkey).

This opens the browser at your service provider’s home page. This is recalled from the

cache each time you start the browser. The cache is the phone’s memory where pages that

you have previously downloaded are stored.

The phone remains off line (i.e. not connected to a server) when it recalls pages from the

cache.

The browser menu

The browser has its own menu, which you use when an Internet page is currently

displayed, either on line or off line. To access this menu press A.

Home Page. Displays the page defined by your service provider.

Bookmark. Saves the current page as a bookmark, so you can return to it another time.

Current URL. Displays the current URL.

Enter URL. Enter the address of the URL that you want to go to.

Page Memo. Saves the currently displayed page.

Save Image. Saves the currently displayed image.

Reload. Reloads and updates the current page.

Browser Images. Disables images, to display a page more quickly.

Cookie. Enable, disable or delete cookies.

Push Message. View all your push messages.

Clear Cache. Deletes the page(s) in the cache, and displays the Home Page.

Exit. Stops the browser.

Browser

Home

Page

Bookmark Enter URL

Page

Memo

Browser

Images

Clear

Cache

Exit

Current

URL

Save


Reload

Push

Message

Menu > Browser

X70DPK11B1.book Page 62 Thursday, September 18, 2003 5:12 PM

Browser

Navigating pages

Use e to scroll up and down.

Use B to return to previous page.

Use c to return to next page. This is only available if you have gone back to a previous

page.

Press Q to follow a highlighted link.

( indicates a table. Select View.

) indicates an image that cannot be displayed.

~ indicates on line browsing (non secure).

_ indicates on line browsing (secure).

Bookmarks

This lists the bookmarks that you have stored. Select a bookmark from the list to go

directly to that page.

Adding a bookmark

While viewing content, select Bookmark from the Browser menu.

Select <Register>.

Deleting bookmarks

While viewing content, select Bookmark from the Browser menu.

Press A to select Menu.

Select from Delete This, Delete Any and Delete All.

Renaming a bookmark

Select Bookmark from the Browser menu.

Select Menu > Edit Title.

Press and hold B to delete the current name.

Enter the new name.

Grouped bookmarks

If you have set your bookmarks to display in groups (see Bookmarks on page 65), then

you can highlight a group and select Menu, to make changes to that group. The options

are:

Edit Title. Change the title of the group.

Display. Select List to display your bookmarks as one list.

Delete All. Delete all the bookmarks in that group.

Menu > Browser > Home PageMenu > Browser > Bookmarks

X70DPK11B1.book Page 63 Thursday, September 18, 2003 5:12 PM

Browser

Enter URL

Use this to enter a URL to go to a known site.

Page memo

Use this to view a previously saved page.

Push message

Push messages are SMS messages that the phone receives that relate to the browser. Use

this to view the received messages.

Browser settings

Use this to customise the browser interface.

Setting the colour priority

You can choose whether to use your colour settings, or those set by the Internet site that

you are viewing.

Select Colour Priority.

Select from Prefer Content and Prefer User’s.

Setting the font size

You can choose the font size of the text.

Select Font Size.

Select from Large, Standard and Small.

Arranging the colour

You can set the colours for your background, text, visited site and new site.

Select Arrange Colour.

Select from Background, Text Colour, Visited Site or New Site.

Select a colour.

Browser Settings

Colour

Priority Font Size Arrange

Colour Bookmarks Push

Reception

Browser

Images

List Group

Menu > Browser

X70DPK11B1.book Page 64 Thursday, September 18, 2003 5:12 PM

Browser

Enabling and disabling the browser images

If you disable browser images, pages display more quickly.

Select Browser Images.

Select from On and Off.

Bookmarks

You can choose whether to have one list of bookmarks, or whether to group your

bookmarks.

Select Bookmarks.

Select from List and Group.

If you select Group, you can set up five different groups to store your bookmarks.

Enabling and disabling push reception

If you enable Push Reception, you will receive all the push messages sent by your

service provider.

Select Push Reception.

Select from On and Off.

Cookies are information saved about a site to allow you to access it more quickly when

you return to it.

If you want the phone to save cookies, select Cookie > Enable > On.

If you do not want the phone to save cookies, select Cookie > Enable > Off.

To delete an existing cookie, select Cookie > Delete.

Last status

This displays the status of the last site that you visited. If your browser stops working,

you may need this information to find the problem.

Menu > Browser > Browser SettingsMenu > Browser

X70DPK11B1.book Page 65 Thursday, September 18, 2003 5:12 PM

Camera

You can take pictures with the built-in camera, and send them in

multimedia (MMS) and e-mail messages, or use them as wallpaper.

Changing to camera mode

To change to camera mode either select Camera from the main menu, or press B from

idle mode.

Leaving camera mode

To leave camera mode press E to return to idle mode.

Taking a picture

When you are in camera mode, move the phone around until you can see the image

you want on the preview screen.

Press Q to capture the image.

If you decide that you do not want the image that you have taken, you can press B to

delete it.

Camera Lens

Self-portrait Mirror Camera

Shutter Key

Photo Light

X70DPK11B1.book Page 66 Thursday, September 18, 2003 5:12 PM

Camera

Taking a self-portrait

You can take a self-portrait using the shutter button on the side of the phone.

Ensure that the phone is in camera mode.

Close the phone.

View the image in the self-portrait mirror.

Press the shutter button on the side of the phone.

You can use this image in the same way as any other picture that you take with the

camera.

Saving a picture

When you take a picture, it is automatically given a default name and stored in a data

folder. You can change the name of the picture using Rename, see Renaming the

picture on page 69.

Incoming calls when in camera mode

If you receive an incoming call while you are in camera mode, the phone leaves camera

mode and switches to the incoming call. If a captured image is on the preview screen, it

is temporarily saved. If you want to store the image, you need to do this when you return

to camera mode.

Using your picture

Once you have taken a picture, press Q to access the menu.

Sending the picture in a multimedia or e-mail message

Select MMS or e-mail.

A multimedia or e-mail message is opened, with the picture already embedded or

attached.

Take a picture

MMS e-mail Edit Rename Delete

Menu > Camera

X70DPK11B1.book Page 67 Thursday, September 18, 2003 5:12 PM

Camera

Editing the picture

When you have finished editing the picture, you must press Q to save your changes.

Select Edit.

Select Menu.

Changing the brightness

Select Brightness.

Press c to make it lighter or d to make it darker.

Changing the effect

Use this to change your picture’s colours by using an effect.

Select Effect.

Select from Sepia, Monochrome and Negative.

Selecting a frame

Use this to enhance your picture, by adding one of the predefined frames.

Select Frame.

Select from a list of frames. You can preview the frame by highlighting it then

pressing Q.

Changing the size

Use this to make your picture larger or smaller.

Select Size.

Choose Width or Height.

Select Edit.

Enter the percentage by which you want to change the size.

Press Q.

Note: This does not cut your image, it compresses and/or stretches it. To cut your image,

use Trim.

Edit

Brightness Effect Frame Size Format Trim

Menu > Camera > Q > Q > Q > Edit > Menu

X70DPK11B1.book Page 68 Thursday, September 18, 2003 5:12 PM

Camera

Changing the format

Select Format.

Choose from JPEG Fine, JPEG Normal, JPEG Economy and PNG.

JPEG Economy produces a small file but with a low resolution.

JPEG Normal produces a file which is acceptable for most uses.

JPEG Fine and PNG produce large files with high resolution.

Trimming your picture

Use this to select and save just a small part of your picture.

Select Trim.

Use g to increase and decrease the size of the box to include just the part of the

picture that you want.

First adjust up and left, then press Q to adjust down and right. The white corner of

the box indicates the directions that you can go.

When you have the selection you want, press Q to select the area.

Press Q.

Renaming the picture

Select Rename.

Use B to remove the existing text.

Enter the new text.

Press Q.

Select Ok to save your changes or Cancel to revert to the old name.

Deleting the picture

Select Delete or press B .

Press Q to confirm, or B to cancel.

Close up picture

When the image is on the preview screen, press b to see a close up picture. This zooms

in on the centre of the image. Press a to return to the original image.

Brightness adjustment

You can set the brightness of an image both before and after taking the picture. The

brightness can be increased or decreased by two levels.

Changing brightness while taking a picture

When the image is on the preview screen, press c to make it lighter or d to make it

darker. The brightness icon at the top of the screen changes to show how much lighter or

darker you have made the image.

Menu > Camera > Q > Q > Q > Edit > Menu

X70DPK11B1.book Page 69 Thursday, September 18, 2003 5:12 PM

Camera

Changing brightness after taking a picture

See Changing the brightness on page 68.

Preview screen menu

These are all set up using the same basic method:

When the required image is shown in the preview screen, press A.

Select the required option.

Select the required setting.

Press B to leave the menu.

Photo light

Turns on a light on the front of the phone.Twilight mode

Turn Twilight Mode on when taking pictures in low light conditions.

Effect

With Effect you can choose from Off, Sepia, Monochrome or Negative.

Frame

This places a border round the image. You can preview the frame by highlighting it then

pressing Q.

Format

With Format you can choose the format for saving your image.

JPEG Economy produces a small file but with a low resolution.

JPEG Normal produces a file which is acceptable for most uses.

JPEG Fine and PNG produce large files with high resolution.

Preview Screen

Photo Light Twilight Effect Capture

Mode

Frame Format

Menu > Camera > A

X70DPK11B1.book Page 70 Thursday, September 18, 2003 5:12 PM

Camera

Capture mode

With Capture Mode you can choose from:

Single Shot takes a single picture.

Multi Shot captures images at 1 second intervals while you hold Q down, to a maximum

of six images.

Self Timer delays the taking of an image.

Remote takes a picture immediately, then returns to the capture screen.

Photo light

Turns on a light on the front of the phone.

Menu > Camera > A

X70DPK11B1.book Page 71 Thursday, September 18, 2003 5:12 PM

Panasonic Mobile Communications Development of USA 22B001A GSM Cellular Mobile Radio User Manual X70DPK11B1

Panasonic Mobile Communications Development Corporation of USA GSM Cellular Mobile Radio X70DPK11B1

Contents

Part 1

Navigation menu

Namespaces

Views

Navigation
