Panasonic of North America 96NKX-HGC200 2.4 GHz Wireless LAN Card User Manual HGC200
Panasonic Corporation of North America 2.4 GHz Wireless LAN Card HGC200
Exhibit H User Manual
Model No. KX-HGC200
PLEASE READ BEFORE USE AND SAVE.
Contents:
Part Names . . . . . . . . . . . . . . . . . . . . . . 3
Hardware Installation . . . . . . . . . . . . . . . 4
FCC and Other Information . . . . . . . . . . 6
OPERATING INSTRUCTIONS
Panasonic World Wide Web address: http://www.panasonic.com
for customers in the USA or Puerto Rico
– 2 –
Thank you for purchasing your new Panasonic wireless card.
Attach your purchase receipt here.
For your future reference
Serial No. Date of purchase
(found on the bottom of the unit)
Name and address of dealer
– 3 –
Part Names
∫Part Names
KX-HGC200
LINK
ANT.
READY
Indicator
– 4 –
Hardware Installation
To use the wireless network, inserting of the KX-HGC200 to the KX-HGW200
and to the computer(s) is needed. The KX-HGC200 can be inserted to the
PCMCIA Type
II
card slot of a computer.
1Insert the KX-HGC200 to the KX-HGW200.
a:Make sure the power of the KX-HGW200 is off by checking the POWER
indicator of the KX-HGW200.
b:Open the cover on the front side of the KX-HGW200.
c:Insert the KX-HGC200 to the card slot of the KX-HGW200 with the arrow
mark on the KX-HGC200 pointing to the slot.
d:Close the cover of the KX-HGW200.
To remove the KX-HGC200 from the KX-HGW200,
press the lever on the KX-HGW200 along with the card slot.
Note:
≥Be sure to insert the KX-HGC200 fully.
≥Insert on the proper direction. When you feel resistance while
inserting, turn the KX-HGC200 over and reinsert it.
HomePNA
WIRELESS
ETHERNET
INTERNET
POWER
KX-HGW200
KX-HGC200
LINK
ANT.
READY
Arrow mark
KX-HGW200
KX-HGC200
Card slot
– 5 –
2Insert the KX-HGC200 to the computer.
a:Insert the KX-HGC200 to the PCMCIA Type
II
slot of the computer with
the arrow mark on the KX-HGC200 pointing to the slot.
To remove the KX-HGC200 from the computer,
press the lever on the computer along with the card slot.
Note:
≥Be sure to insert the KX-HGC200 fully.
≥Insert on the proper direction. When you feel resistance when
inserting, turn the KX-HGC200 over and reinsert it.
KX-HGC200
LINK
ANT.
READY
FCC and Other Information
– 6 –
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
CAUTION:
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this device.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
≥Environment—do not place the unit in a room where the temperature is less than 5oC
(41oF) or greater than 40oC (104oF). Allow 10 cm (4q) clearance around the unit for
proper ventilation. Avoid excessive smoke, dust, mechanical vibration, shock, or direct
sunlight.
≥Medical—consult the manufacturer of any personal medical devices, such as
pacemakers, to determine if they are adequately shielded from external RF (radio
frequency) energy. (The unit operates in the frequency range of 2401MHz to 2483MHz
and the power output level is 0.1 watt.) Do not use the unit in health care facilities if any
regulations posted in the area instruct you not to do so. Hospitals or health care
facilities may be using equipment that could be sensitive to external RF (radio
frequency) energy.
≥Routine care—wipe the unit with a soft cloth. Do not use benzine, thinner, or any
abrasive powder.
Responsible Party: Matsushita Electric Corporation of America
One Panasonic Way, Secaucus, NJ 07094
Tel No: 1-800-272-7033
For product service
≥Panasonic Servicenters are listed in the servicenter directory.
≥Call 1-800-211-PANA(7262) for the location of an authorized servicenter.
≥Panasonic’s e-mail address for customer inquiries:
consumerproducts@panasonic.com
for customers in the USA or Puerto Rico ONLY
When you ship the product
≥Carefully pack your unit, preferably in the original carton.
≥Attach a letter, detailing the symptom, to the outside of the carton.
Symptom
≥Send the unit to an authorized servicenter, prepaid and adequately insured.
≥Do not send your unit to the Panasonic Consumer Electronics Company listed
on the next page or to executive or regional sales offices. These locations do
not repair consumer products.
– 7 –
≥This unit is designed for use in the United States of America. Sale or
use of this product in other countries may violate local laws.
≥Ce appareil est conçu pour être utilisé aux États-Unis d’Amérique. La
vente ou l’emploi de cet appareil dans certains autres pays peut
constituer une infraction à la législation locale.
≥Esta unidad fue elaborada para uso en los Estados Unidos de
América. La venta o el empleo de este producto en ciertos países
puede constituir violación de la legislación local.
Panasonic Consumer Electronics Company,
Division of Matsushita Electric Corporation of America
One Panasonic Way, Secaucus, New Jersey 07094
Panasonic Sales Company,
Division of Matsushita Electric of Puerto Rico, Inc.
Ave. 65 de Infantería, Km. 9.5, San Gabriel Industrial Park
Carolina, Puerto Rico 00985
Printed in Japan
