Panasonic of North America 96NKX-HNH100 DECT 6.0 Handset User Manual Operating Instructions English

Panasonic Corporation of North America DECT 6.0 Handset Operating Instructions English

Users Manual

Operating Instructions
Additional Digital Cordless Handset
Model No. KX-HNH100
Before initial use, see “Getting Started”
on page 9.
Thank you for purchasing a Panasonic product.
Please read these operating instructions before using the unit and save them for
future reference.
For assistance, visit our Web site: http://www.panasonic.com/help for customers
in the U.S.A. or Puerto Rico.
Please register your product: http://www.panasonic.com/prodreg
Accessory information
Supplied accessories
No. Accessory item/Order number Quantity
ARechargeable batteries/HHR-4DPA 1
BHandset cover*11
CCharger/PNLC1055ZAW 1
*1 The handset cover comes attached to the handset.
AB C
Additional/replacement accessories
Please contact your nearest Panasonic dealer for sales information.
Accessory item Order number
Rechargeable
batteries
HHR-4DPA*1
RTo order, please call 1-800-332-5368 or visit
http://www.panasonic.com/batterystore
Battery type:
– Nickel metal hydride (Ni-MH)
– 2 x AAA (R03) size for each handset
*1 Replacement batteries may have a different capacity from that of the supplied batteries.
Other information
RDesign and specifications are subject to change without notice.
RThe illustrations in these instructions may vary slightly from the actual product.
Expanding your phone system
The Panasonic Home Network System lets you create a powerful wireless network of cameras,
sensors, and smartplugs in your home, and control them all with an easy-to-use mobile app.
A total of 50 devices can be registered to the base unit. The maximum number of devices for
each device type is listed below.
2For assistance, please visit http://www.panasonic.com/help
Introduction
Cordless handset (KX-HNH100: 6 max.)*1
RMakes and receives calls using your home landline
RCan be used to change the system’s security mode
RDisplays system status
Outdoor camera (KX-HNC600: 4 max.*2)
RFull-color camera with night vision and built-in microphone for
live monitoring and recording
RBuilt-in motion sensor
RBuilt-in microphone and speaker for two-way communication
RSplashproof design for permanent, outdoor installation
Indoor camera (KX-HNC200: 4 max.*2)
RFull-color camera with night vision and built-in microphone for
live monitoring and recording
RBuilt-in motion sensor and temperature sensor
RNon-permanent installation for added flexibility
Door/window sensor (KX-HNS101: 50 max.)
RDetects when the corresponding door or window is opened
RCan be used to trigger other events (camera recording, turning
on a light, etc.)
Motion sensor (KX-HNS102: 50 max.)
RDetects motion in the surrounding area
RCan be used to trigger other events (camera recording, turning
on a light, etc.)
RNon-permanent installation for added
Smartplug (KX-HNA101: 50 max.)
RCan be turned on and off using the Smartphone app or when
triggered by a sensor
*1 Optional handsets may be a different color from that of the supplied handsets.
*2 A total of 4 cameras can be registered includes outdoor camera (KX-HNC600) and indoor
camera (KX-HNC200).
For assistance, please visit http://www.panasonic.com/help 3
Introduction
Smartphone
Your smartphone: 4 max.
You can expand your phone system by installing the Smartphone
app on your smartphone and registering your smartphone to the
base unit.
RYou must configure the base unit and download the app before
you can use these features.
4For assistance, please visit http://www.panasonic.com/help
Introduction
For your safety
To prevent severe injury and loss of life/
property, read this section carefully before
using the product to ensure proper and safe
operation of your product.
WARNING
Power connection
RUse only the power source marked on the
product.
RDo not overload power outlets and
extension cords. This can result in the risk
of fire or electric shock.
RCompletely insert the AC adaptor/power
plug into the power outlet. Failure to do so
may cause electric shock and/or excessive
heat resulting in a fire.
RRegularly remove any dust, etc. from the
AC adaptor/power plug by pulling it from
the power outlet, then wiping with a dry
cloth. Accumulated dust may cause an
insulation defect from moisture, etc.
resulting in a fire.
RUnplug the product from power outlets if it
emits smoke, an abnormal smell, or makes
an unusual noise. These conditions can
cause fire or electric shock. Confirm that
smoke has stopped emitting and contact
the Panasonic Call Center at
1-800-211-PANA (1-800-211-7262).
RUnplug from power outlets and never touch
the inside of the product if its casing has
been broken open.
RNever touch the plug with wet hands.
Danger of electric shock exists.
Installation
RTo prevent the risk of fire or electrical
shock, do not expose the product to rain or
any type of moisture.
RDo not place or use this product near
automatically controlled devices such as
automatic doors and fire alarms. Radio
waves emitted from this product may cause
such devices to malfunction resulting in an
accident.
RDo not allow the AC adaptor or telephone
line cord to be excessively pulled, bent or
placed under heavy objects.
Operating safeguards
RUnplug the product from power outlets
before cleaning. Do not use liquid or
aerosol cleaners.
RDo not disassemble the product.
RDo not spill liquids (detergents, cleansers,
etc.) onto the telephone line cord plug, or
allow it to become wet at all. This may
cause a fire. If the telephone line cord plug
becomes wet, immediately pull it from the
telephone wall jack, and do not use.
Medical
RConsult the manufacturer of any personal
medical devices, such as pacemakers or
hearing aids, to determine if they are
adequately shielded from external RF
(radio frequency) energy. DECT features
operate between 1.92 GHz and 1.93 GHz
with a peak transmission power of 115 mW.
Wi-Fi features operate between 2.412 GHz
and 2.462 GHz with a peak transmission
power of 100 mW.
RDo not use the product in health care
facilities if any regulations posted in the
area instruct you not to do so. Hospitals or
health care facilities may be using
equipment that could be sensitive to
external RF energy.
CAUTION
Installation and location
RNever install wiring during a lightning storm.
RNever install telephone line jacks in wet
locations unless the jack is specifically
designed for wet locations.
RNever touch uninsulated telephone wires or
terminals unless the telephone line has
been disconnected at the network interface.
RUse caution when installing or modifying
telephone lines.
RThe AC adaptor is used as the main
disconnect device. Ensure that the AC
outlet is installed near the product and is
easily accessible.
For assistance, please visit http://www.panasonic.com/help 5
Important Information
RThis product is unable to make calls when:
–the handset batteries need recharging or
have failed.
– there is a power failure.
Battery
RWe recommend using the batteries noted
on page 2. USE ONLY rechargeable
Ni-MH batteries AAA (R03) size.
RDo not mix old and new batteries.
RDo not open or mutilate the batteries.
Released electrolyte from the batteries is
corrosive and may cause burns or injury to
the eyes or skin. The electrolyte is toxic and
may be harmful if swallowed.
RExercise care when handling the batteries.
Do not allow conductive materials such as
rings, bracelets, or keys to touch the
batteries, otherwise a short circuit may
cause the batteries and/or the conductive
material to overheat and cause burns.
RCharge the batteries provided with or
identified for use with this product only, in
accordance with the instructions and
limitations specified in this manual.
ROnly use a compatible charger to charge
the batteries. Do not tamper with the
charger. Failure to follow these instructions
may cause the batteries to swell or explode.
Attention:
A nickel metal hydride battery that is
recyclable powers the product you have
purchased.
Please call 1-800-8-BATTERY
(1-800-822-8837) for information on how to
recycle this battery.
Important safety
instructions
When using your product, basic safety
precautions should always be followed to
reduce the risk of fire, electric shock, and
injury to persons, including the following:
1. Do not use this product near water for
example, near a bathtub, washbowl,
kitchen sink, or laundry tub, in a wet
basement or near a swimming pool.
2. Avoid using a telephone (other than a
cordless type) during an electrical storm.
There may be a remote risk of electric
shock from lightning.
3. Do not use the telephone to report a gas
leak in the vicinity of the leak.
4. Use only the power cord and batteries
indicated in this manual. Do not dispose of
batteries in a fire. They may explode.
Check with local codes for possible special
disposal instructions.
SAVE THESE INSTRUCTIONS
For best performance
Base unit location/avoiding noise
The base unit and other compatible Panasonic
units use radio waves to communicate with
each other.
RFor maximum coverage and noise-free
communications, place your base unit:
– at a convenient, high, and central
location with no obstructions between
the handset and base unit in an indoor
environment.
– away from electronic appliances such as
TVs, radios, personal computers,
wireless devices, or other phones.
– facing away from radio frequency
transmitters, such as external antennas
of mobile phone cell stations. (Avoid
putting the base unit on a bay window or
near a window.)
RCoverage and voice quality depends on the
local environmental conditions.
6For assistance, please visit http://www.panasonic.com/help
Important Information
RIf the reception for a base unit location is
not satisfactory, move the base unit to
another location for better reception.
Environment
RKeep the product away from electrical noise
generating devices, such as fluorescent
lamps and motors.
RThe product should be kept free from
excessive smoke, dust, high temperature,
and vibration.
RThe product should not be exposed to
direct sunlight.
RDo not place heavy objects on top of the
product.
RWhen you leave the product unused for a
long period of time, unplug the product from
the power outlet.
RThe product should be kept away from heat
sources such as heaters, kitchen stoves,
etc. It should not be placed in rooms where
the temperature is less than 0 °C (32 °F) or
greater than 40 °C (104 °F). Damp
basements should also be avoided.
RThe maximum calling distance may be
shortened when the product is used in the
following places: Near obstacles such as
hills, tunnels, underground, near metal
objects such as wire fences, etc.
ROperating the product near electrical
appliances may cause interference. Move
away from the electrical appliances.
Routine care
RWipe the outer surface of the product
with a soft moist cloth.
RDo not use benzine, thinner, or any
abrasive powder.
Other information
CAUTION: Risk of explosion if battery is
replaced by an incorrect type. Dispose of used
batteries according to the instructions.
Notice for product disposal, transfer,
or return
RThis product can store your private/
confidential information. To protect your
privacy/confidentiality, we recommend that
you erase information such as phonebook
or caller list entries from the memory before
you dispose of, transfer, or return the
product.
Notice
Specifications
RCommunication standards
DECT 6.0 (Digital Enhanced Cordless
Telecommunications 6.0)
Wi-Fi (IEEE 802.11 b/g/n)
RFrequency range
DECT:
1.92 GHz to 1.93 GHz
Wi-Fi:
2.412 GHz to 2.462 GHz (channels 1 to 11)
RRF transmission power
DECT:
115 mW (max.)
Wi-Fi:
For assistance, please visit http://www.panasonic.com/help 7
Important Information
100 mW (peak transmission power)
REncryption
WPA2-PSK (TKIP/AES), WPA-PSK (TKIP/
AES), WEP (128/64 bit)
RSimplified configuration
WPS (PBC)
RPower source
Charger:
120 V AC, 60 Hz
Handset:
AAA (R03) Ni-MH battery (2 ´ 1.2 V,
550 mAh)
ROperating conditions
0 °C – 40 °C (32 °F – 104 °F), 20 % – 80 %
relative air humidity (dry)
8For assistance, please visit http://www.panasonic.com/help
Important Information
Setting up
Connections
Connect the AC adaptor to the power
outlet.
1
Battery installation
RUSE ONLY rechargeable Ni-MH batteries
AAA (R03) size (
1
).
RDo NOT use Alkaline/Manganese/Ni-Cd
batteries.
RConfirm correct polarities ( , ).
1
RFollow the directions on the display to set
up the unit.
Battery charging
Charge for about 7 hours.
RConfirm “Charging” is displayed (
1
).
RWhen the batteries are fully charged,
“Fully charged” is displayed.
1
For assistance, please visit http://www.panasonic.com/help 9
Getting Started
Controls
Handset
A
B
C
D
EJ
K
H
G
F
I
Speaker
M N (TALK)
Dial keypad (*: TONE)
MZN (SP-PHONE: Speakerphone)
Microphone
Receiver
Display
MOFFN
MFLASHNMCALL WAITN
M NMDISARMN
Charge contacts
nControl type
Soft keys
By pressing a soft key, you can select the
feature shown directly above it on the
display.
Navigator key
–MDN, MCN, MFN, or MEN: Scroll through
various lists and items.
– VOL. (Volume): MDN or MCN): Adjust the
receiver or speaker volume while talking.
–MCN CID (Caller ID): View the caller list.
–MFN W : View the phonebook entry.
–MEN REDIAL: View the redial list.
Registering a unit
Registering a handset to the
base unit
If for some reason the handset is not
registered to the base unit (for example, is
displayed even when the handset is near the
base unit), re-register the handset.
1Handset:
MMENUN#130
2Base unit:
Press and hold MN for about 5 seconds.
RIf all registered handsets start ringing,
press MN again to stop, then repeat
this step.
3Handset:
Press MOKN, then wait until a long beep
sounds.
Deregistering a handset
A handset can cancel its own registration to
the base unit, or other handsets registered to
the same base unit. This allows the handset to
end its wireless connection with the system.
1MMENUN#131
RAll handsets registered to the base unit
are displayed.
2MbN: Select the handset you want to
cancel. a MSELECTN
3MbN: “Yes” a MSELECTN
4MOFFN
10 For assistance, please visit http://www.panasonic.com/help
Getting Started
Network settings
Before you begin
Confirm the following before you configure the
base unit to connect wirelessly to your home
network.
RMake sure your wireless router is turned on
and functioning.
RMake sure that you know your wireless
router’s Wi-Fi settings, including its SSID
(wireless network name), security
password, etc. In some situations, you may
also need to know the IP-related settings
required in order for the base unit to
connect to your wireless router, including
your wireless router’s IP address, subnet
mask, etc.
RMake sure you have the operating
instructions included with your wireless
router handy.
Typical configuration (DHCP)
1MMENUN #523
2MbN: “Wi-Fi setting” a MSELECTN
RThe base unit searches for available
wireless networks and
“Searching...” is displayed.
RWhen searching is complete, a list of
available wireless networks is
displayed, including the SSID, security
setting, and signal strength.
RThe base unit cannot find your wireless
router if the wireless router does not
broadcast its SSID. If there is a “stealth
mode” setting, turn it off; if there is a
“SSID broadcast” setting, turn it on.
Change the appropriate setting before
performing this procedure, and then
change it back when finished.
3MbN: Select your wireless router’s SSID.
a MSELECTN
4Confirm the SSID and then press MOKN.
5Enter the password required to access
the wireless network. a MOKN
RAfter the base unit connects to the
wireless router, “Connected to” and
your wireless router’s SSID is
displayed.
6MOFFN
For assistance, please visit http://www.panasonic.com/help 11
Getting Started
Making calls
1Lift the handset and dial the phone
number.
RTo correct a digit, press MCLEARN.
2Press MN.
3When you finish talking, press MOFFN or
place the handset on the charger.
Using the speakerphone
1Dial the phone number and press MZN.
2When you finish talking, press MOFFN.
Note:
RTo switch back to the receiver, press MZN/
MN.
Adjusting the receiver or speaker
volume
Press MDN or MCN repeatedly while talking.
Answering calls
1Lift the handset and press MN or MZN
when the unit rings.
2When you finish talking, press MOFFN or
place the handset on the charger.
Any key answer: You can answer the call by
pressing any dial key.
Auto talk: You can answer calls simply by
lifting the handset.
Temporary ringer off: You can turn the ringer
off temporarily by pressing MN.
Adjusting the handset ringer volume
Press MDN or MCN repeatedly to select the
desired volume while ringing.
Caller ID features
When an outside call is being received, the
caller information is displayed.
Caller information for the last 50 callers is
logged in the caller list from the most recent
call to the oldest.
Important:
RThis unit is Caller ID compatible. To use
Caller ID features, you must subscribe to a
Caller ID service. Contact your service
provider/telephone company for details.
Missed calls
If a call is not answered, the unit treats it as a
missed call and “Missed call” is displayed.
This lets you know if you should view the
caller list to see who called while you were
away.
Even if only one missed call in the caller list is
viewed, “Missed call” disappears from the
display. When you receive another new call,
“Missed call” is displayed again.
Note:
REven when there are unviewed missed
calls, “Missed call” disappears from the
standby display if the following operation is
performed by one of the registered
handsets:
– Being replaced on the charger.
– Pressing MOFFN.
12 For assistance, please visit http://www.panasonic.com/help
Making/Answering Calls
Call logs
Important:
RMake sure the unit’s date and time setting
is correct.
Viewing the caller list and calling
back
1MCN CID
2Press MCN to search from the most recent
call, or press MDN to search from the
oldest call.
3To call back, press MN.
To exit, press MOFFN.
Note:
RIf the entry has already been viewed or
answered, “ ” is displayed.
For assistance, please visit http://www.panasonic.com/help 13
Making/Answering Calls
Answering system
The answering system can answer and record
calls for you when you are unavailable to
answer the phone.
You can also set the unit to play a greeting
message but not to record caller messages by
selecting “Greeting only” as the recording
time setting.
Important:
RMake sure the unit’s date and time setting
is correct.
Turning the answering
system on/off
The answering system is preset to on.
1To turn on:
MMENUN#327
To turn off:
MMENUN#328
2MOFFN
Note:
RWhen the answering system is turned on,
is displayed.
14 For assistance, please visit http://www.panasonic.com/help
Answering System
Security features
Security features overview
You can use motion sensors, door/window
sensors, and even the sensor features built in
to indoor and outdoor cameras to receive
sensor trigger alerts on the handset.
RThe compatible Panasonic sensor devices
are listed on page 2.
Arming and disarming the system
You can select the 3 types of security modes.
–“Home arm”: Door/window sensors are
activated.
–“Out arm”: All the censor devices are
activated.
–“Disarm”: All the censor devices are
deactivated.
n To arm the system:
1MN
2MbN: “Home arm” or “Out arm” a
MSELECTN
3Enter the password when prompted.
RWhen you select “Out arm”, you
need to press MOKN to activate the
mode. All the security devices are
activated after 300 seconds.
n To disarm the system:
1M N
2MbN: “Disarm” a MSELECTN
3Enter the password. a MOKN
For assistance, please visit http://www.panasonic.com/help 15
Security Features
FCC and other information
This equipment complies with Part 68 of the
FCC rules and the requirements adopted by
the ACTA. On the bottom of this equipment
is a label that contains, among other
information, a product identifier in the
format US:ACJ----------.
If requested, this number must be provided
to the telephone company.
L Registration No.............(found on the
bottom of the unit)
L Ringer Equivalence No. (REN).......0.1B
A plug and jack used to connect this
equipment to the premises wiring and
telephone network must comply with the
applicable FCC Part 68 rules and
requirements adopted by the ACTA. A
compliant telephone cord and modular plug
is provided with the product. It is designed
to be connected to a compatible modular
jack that is also compliant.
The REN is used to determine the number
of devices that may be connected to a
telephone line. Excessive RENs on a
telephone line may result in the devices not
ringing in response to an incoming call. In
most but not all areas, the sum of RENs
should not exceed five (5.0). To be certain
of the number of devices that may be
connected to a line, as determined by the
total RENs, contact the local telephone
company. For products approved after July
23, 2001, the REN for the product is part of
the product identifier that has the format
US:AAAEQ##TXXXX. The digits
represented by ## are the REN without a
decimal point (e.g., 03 is a REN of 0.3).
If this equipment causes harm to the
telephone network, the telephone company
will notify you in advance that temporary
discontinuance of service may be required.
But if advance notice isn't practical, the
telephone company will notify the customer
as soon as possible. Also, you will be
advised of your right to file a complaint with
the FCC if you believe it is necessary.
The telephone company may make changes
in its facilities, equipment, operations or
procedures that could affect the operation of
the equipment. If this happens the
telephone company will provide advance
notice in order for you to make necessary
modifications to maintain uninterrupted
service.
If trouble is experienced with this
equipment, for repair or warranty
information, please contact a Factory
Service Center or other Authorized Servicer.
If the equipment is causing harm to the
telephone network, the telephone company
may request that you disconnect the
equipment until the problem is resolved.
Connection to party line service is subject to
state tariffs. Contact the state public utility
commission, public service commission or
corporation commission for information.
If your home has specially wired alarm
equipment connected to the telephone line,
ensure the installation of this equipment
does not disable your alarm equipment. If
you have questions about what will disable
alarm equipment, consult your telephone
company or a qualified installer.
This equipment is hearing aid compatible as
defined by the FCC in 47 CFR Section
68.316.
When you hold the phone to your ear, noise
might be heard in your Hearing Aid. Some
Hearing Aids are not adequately shielded
from external RF (radio frequency) energy. If
noise occurs, use an optional headset
accessory or the speakerphone option (if
applicable) when using this phone. Consult
with your audiologist or Hearing Aid
16 For assistance, please visit http://www.panasonic.com/help
Useful Information
manufacturer about the availability of
Hearing Aids which provide adequate
shielding to RF energy commonly emitted
by digital devices.
WHEN PROGRAMMING EMERGENCY
NUMBERS AND(OR) MAKING TEST
CALLS TO EMERGENCY NUMBERS:
1) Remain on the line and briefly explain to
the dispatcher the reason for the call.
2) Perform such activities in the off-peak
hours, such as early morning or late
evenings.
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
Privacy of communications may not be
ensured when using this phone.
CAUTION:
Any changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate this device.
NOTE:
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the
instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
– Reorient or relocate the receiving
antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced
radio/TV technician for help.
Some cordless telephones operate at
frequencies that may cause interference to
nearby TVs and VCRs. To minimize or
prevent such interference, the base of the
cordless telephone should not be placed
near or on top of a TV or VCR. If
interference is experienced, move the
cordless telephone further away from the TV
or VCR. This will often reduce or eliminate
interference.
FCC RF Exposure Warning:
LThis product complies with FCC radiation
exposure limits set forth for an
uncontrolled environment.
LTo comply with FCC RF exposure
requirements, the base unit must be
installed and operated 20 cm (8 inches)
or more between the product and all
person’s body.
LThis product may not be collocated or
operated in conjunction with any other
antenna or transmitter.
L For body-worn operation, the handset
must be used only with a non-metallic
accessory. Use of other accessories may
not ensure compliance with FCC RF
exposure requirements.
Notice:
L FCC ID can be found inside the battery
compartment or on the bottom of the
units.
For assistance, please visit http://www.panasonic.com/help 17
Useful Information
18 For assistance, please visit http://www.panasonic.com/help
Useful Information
Customer services
Customer Services Directory (United States and Puerto Rico)
Obtain Product Information and Operating Assistance; locate your nearest
Dealer or Service Center; purchase Parts and Accessories; or make Customer
Service and Literature requests by visiting our Web Site at:
http://www.panasonic.com/help
or, contact us via the web at:
http://www.panasonic.com/contactinfo
You may also contact us directly at: 1-800-211-PANA (1-800-211-7262),
Monday - Friday 9 am to 9 pm; Saturday - Sunday 10 am to 7 pm, EST.
For hearing or speech impaired TTY users, TTY: 1-877-833-8855
For hearing or speech impaired TTY users, TTY: 1-866-605-1277
Purchase Parts, Accessories and Owner’s Manual online for all
Panasonic Products by visiting our Web Site at:
http://www.pstc.panasonic.com
or, send your request by E-mail to:
npcparts@us.panasonic.com
You may also contact us directly at:
1-800-332-5368 (Phone) 1-800-237-9080 (Fax Only)
(Monday - Friday 9 am to 9 pm, EST.)
Panasonic National Parts Center
20421 84th Avenue S., Kent, WA 98032
(We accept Visa, MasterCard, Discover Card, American Express.)
Accessory Purchases (United States and Puerto Rico)
For assistance, please visit http://www.panasonic.com/help 19
Appendix
1 Reconnect AC adaptor to the base unit.
2 Check if telephone line cord is connected.
3 Use rechargeable Ni-MH batteries.
(Alkaline/Manganese/Ni-Cd batteries CANNOT be used.)
4 Read troubleshooting page in the Operating Instructions.
If your product is not working properly. . .
IMPORTANT!
Visit our Web site: http://www.panasonic.com/help
LFAQ and troubleshooting hints are available.
Two Riverfront Plaza, Newark, NJ 07102-5490
© Panasonic System Networks Co., Ltd. 2014
Printed in China *TG6611E*
*TG6611E*
PNQX3106ZA TC1210YK0 (A)

Navigation menu
