Panasonic of North America 96NKX-HNL200 DECT Smart Light Switch User Manual Installation Manual English
Panasonic Corporation of North America DECT Smart Light Switch Installation Manual English
Users Manual
Installation Guide
Home Network System
Smart On/Off Light Switch
Model No. KX-HNL200
TEMP
Thank you for purchasing a Panasonic product.
This document explains how to install the switch properly.
For details about how to use the system, refer to the User’s Guide
(page 13).
Please read this document before using the unit and save it for future
reference.
For assistance, please contact us at 1-800-272-7033 or visit our Web
site: http://shop.panasonic.com/support for customers in the U.S.A.
Please register your product: http://shop.panasonic.com/support
Printed in China
Introduction
Accessory information ...............3
Important Information
About this system ......................4
For your safety ...........................4
Important safety instructions ......5
For best performance ................5
Other information .......................6
Setup
Part names and functions ..........7
LED indicator .............................7
Setup overview ..........................7
Confirming the usage
conditions ..................................8
Installation ...............................10
Registering the switch .............11
Appendix
Testing the motion sensor .......13
Using the switch (manual
control) .....................................13
Features available when using the
[Home Network] app ................13
Accessing the User’s Guide ....13
Specifications ..........................14
FCC and other information ......15
Customer services ...................16
Limited Warranty (ONLY FOR
U.S.A.) .....................................17
2
Table of Contents
Accessory information
Supplied accessories
No. Accessory item/Part number Quantity
Axx/xx*1 xx
Bxx/xx*2 xx
Cxx/xx xx
*1 xx
*2 xx
A
TEMP
B
TEMP
C
TEMP
Other information
RDesign and specifications are subject to change without notice.
RThe illustrations in these instructions may vary slightly from the actual product.
Trademarks
RiPhone and iPad are registered trademarks of Apple Inc.
RAndroid is a trademark of Google Inc.
RMicrosoft, Windows, and Internet Explorer are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
RAll other trademarks identified herein are the property of their respective owners.
For assistance, please visit http://shop.panasonic.com/support 3
Introduction
About this system
RThis system is an auxiliary system; it
is not designed to provide complete
protection from property loss.
Panasonic will not be held
responsible in the event that
property loss occurs while this
system is in operation.
RThe system’s wireless features are
subject to interference, therefore
functionality in all situations cannot
be guaranteed. Panasonic will not
be held responsible for injury or
damage to property that occurs in
the event of wireless communication
error or failure.
For your safety
To prevent severe injury and loss of life/
property, read this section carefully
before using the product to ensure
proper and safe operation of your
product.
WARNING
Power connection
RUse only the power source marked
on the product.
RDo not connect non-specified
devices.
Installation
RTo prevent the risk of fire or
electrical shock, do not expose the
product to rain or any type of
moisture.
RDo not place or use this product
near automatically controlled
devices such as automatic doors
and fire alarms. Radio waves
emitted from this product may cause
such devices to malfunction
resulting in an accident.
RKeep small parts (screws, etc.) out
of the reach of children. There is a
risk of swallowing. In the event they
are swallowed, seek medical advice
immediately.
Operating safeguards
RDo not disassemble the product.
Medical
RConsult the manufacturer of any
personal medical devices, such as
pacemakers or hearing aids, to
determine if they are adequately
shielded from external RF (radio
frequency) energy. DECT features
operate between 1.92 GHz and
1.93 GHz with a peak transmission
power of 115 mW.
RDo not use the product in health
care facilities if any regulations
posted in the area instruct you not to
do so. Hospitals or health care
facilities may be using equipment
that could be sensitive to external
RF energy.
CAUTION
Battery
RThe batteries should be used
correctly, otherwise the product may
be damaged due to battery leakage.
RDo not charge, short-circuit,
disassemble, or heat the batteries.
RDo not dispose of batteries in a fire.
RRemove all the batteries when
replacing.
4For assistance, please visit http://shop.panasonic.com/support
Important Information
RDo not mix old, new or different
types of batteries.
RIt is recommended that batteries are
replaced annually.
RKeep out of the reach of small
children. There is a risk of
swallowing. If the battery is
swallowed, seek medical attention
immediately.
RRemove the battery if it becomes
unusable. There is a risk of leakage,
overheating, and rupture. Do not
attempt to use a battery if it is
leaking.
RDo not intentionally pour water on
the battery or allow it to get wet.
There is a risk of fire and smoke. If
the battery becomes wet, remove it
immediately and contact an
authorized service center.
Important safety
instructions
When using your product, basic safety
precautions should always be followed
to reduce the risk of fire, electric shock,
and injury to persons, including the
following:
1. Do not use this product near water
for example, near a bathtub,
washbowl, kitchen sink, or laundry
tub, in a wet basement or near a
swimming pool.
2. Use only the batteries indicated in
this document. Do not dispose of
batteries in a fire. They may
explode. Check with local codes for
possible special disposal
instructions.
SAVE THESE INSTRUCTIONS
For best performance
Hub location/avoiding noise
The hub and other compatible
Panasonic devices use radio waves to
communicate with each other.
RFor maximum coverage and
noise-free communications, place
your hub:
– at a convenient, high, and central
location with no obstructions
between the product and hub in
an indoor environment.
– away from electronic appliances
such as TVs, radios, personal
computers, wireless devices, or
other phones.
– facing away from radio frequency
transmitters, such as external
antennas of mobile phone cell
stations. (Avoid putting the hub
on a bay window or near a
window.)
RIf the reception for a hub location is
not satisfactory, move the hub to
another location for better reception.
Environment
RKeep the product away from
electrical noise generating devices,
such as fluorescent lamps and
motors.
RThe product should be kept free
from excessive smoke, dust, high
temperature, and vibration.
RThe product should not be exposed
to direct sunlight.
RDo not place heavy objects on top of
the product.
RThe product should be kept away
from heat sources such as heaters,
kitchen stoves, etc. It should not be
placed in rooms where the
For assistance, please visit http://shop.panasonic.com/support 5
Important Information
temperature is less than 0 °C (32 °F)
or greater than 40 °C (104 °F).
Damp basements should also be
avoided.
ROperating the product near electrical
appliances may cause interference.
Move away from the electrical
appliances.
Other information
CAUTION: Risk of explosion if battery
is replaced by an incorrect type.
Dispose of used batteries according to
the instructions.
Routine care
RWipe the outer surface of the
product with a soft moist cloth.
RDo not use benzine, thinner, or any
abrasive powder.
Information on Disposal in other
Countries outside the European
Union
These symbols are only valid in the
European Union. If you wish to discard
these items, please contact your local
authorities or dealer and ask for the
correct method of disposal.
Note for the battery removal
procedure
Refer to “xx” on xx.
Notice
6For assistance, please visit http://shop.panasonic.com/support
Important Information
Part names and
functions
TEMP
A
C
D
E
B
On/off switch
LED indicator
Motion sensor
Maintenance button
Press this button to disable the
switch while replacing light bulbs.
When finished, press the button
again.
M N
Used to confirm the status of the
switch or register the switch to the
hub.
LED indicator
During normal operation, the LED
indicator lights in blue when the
surrounding environment is dark,
allowing you to use the LED indicator
as a night light.
You can also press M N and check
the LED indicator to confirm the
switch’s status.
Indicator Status
Off Switch is off, no power
supplied to switch
Green, lit Switch is on
Green,
blinking
slowly
Registration mode
(You pressed and held
M N)
Red,
blinking
very quickly
Motion was detected
Red,
blinking
Switch is out of range
of the hub
Note:
RThe LED indicator does not indicate
the status of the switch if the switch
has not been registered to a hub
(page 11).
Setup overview
1Initial setup
Make sure you can access the
system using your mobile device.
For details, refer to the System
Setup Guide included with your
hub.
2Confirm the installation
conditions
Read the information in this
document to confirm that the
installation conditions are suitable
to proper operation.
3Installation
Install the switch in the desired
location.
4Registration
Required only if the switch was
purchased separately (i.e., not as
part of a bundle).
For assistance, please visit http://shop.panasonic.com/support 7
Setup
Confirming the
usage conditions
Confirming the usage area
Wireless communication range
In optimal conditions, the wireless
communication range of each device in
the system from the hub is
approximately 50 m (160 feet) indoors
and approximately 300 m (1,000 feet)
outdoors.
RWireless communication may be
reduced or unreliable when the
following obstacles are located
between the hub and other devices.
– Metal doors or screens
– Walls containing aluminum-sheet
insulation
– Walls made of concrete or
corrugated iron
– Double-pane glass windows
– Multiple walls
– When using each device on
separate floors or in different
buildings
RWireless communication is reduced
by approximately xx% if the switch is
installed in a metal junction box.
RWireless communication is reduced
by approximately xx% for each wall
located between the hub and the
switch.
RAfter the switch is installed and
registered to the hub, you can check
the switch’s communication status
by pressing MN (page 7).
Usage area cautions
Using the switch in the following areas
may cause deformation, malfunction, or
operational failure.
RIn direct sunlight
RAreas exposed to grease or steam,
such as kitchens
RNear fire or heating devices
RNear magnetic fields (such as near
microwaves and magnets)
RAreas subject to extreme
temperature changes, such as next
to air conditioners
RAreas with reflective objects, such
as glass, that can interfere with
detection of temperature variation
RAreas where the temperature is
affected by strong illuminating
objects (such as fluorescent lights)
RNear devices that emit strong radio
waves, such as mobile phones
Information about motion
sensor features
The switch utilizes an infrared sensor
(i.e., heat sensor) to detect motion. In
this document, this sensor is referred to
as a "motion sensor".
Please read the following information
before deciding where to install the
switch.
Note:
RThe switch’s motion sensor features
are not designed to be used in
situations that require high reliability.
We do not recommend use of the
switch’s motion sensor features in
these situations.
RPanasonic takes no responsibility for
any injury or damage caused by the
use of the switch.
Using heat to detect motion
The switch’s motion sensor can detect
motion by recognizing temperature
differences that occur within the range
of the sensor. It does this by detecting
8For assistance, please visit http://shop.panasonic.com/support
Setup
the infrared rays that are emitted
naturally by people, animals, etc.,
which correlate to the object’s
temperature. The detection range is
indicated in the illustration by the gray
area in front of the switch.
Detection range when looking from
above
AB
TEMP
Horizontal detection range
Approx. 120°
Distance of detectable motion
Approx. 10 m (32.8 feet)
Detection range when looking from
the side
A
B
TEMP
Vertical detection range
Approx. 40° (pitched upward by
1.5°)
Distance of detectable motion
Approx. 10 m (32.8 feet)
Note:
RDetection becomes difficult when
there is little difference between the
temperatures of objects and the
surrounding environment, such as
during summer. Conversely,
detection becomes easier when
there is a large difference between
the temperatures of objects and the
surrounding environment, such as
during winter or at night.
Direction of motion
It is easier to detect objects that move
sideways in front of the switch, and
more difficult to detect objects that
move directly toward the front of the
switch.
AB
C
TEMP
Difficult to detect
People approach the switch from
the front
Easy to detect
People pass in front of the switch
from side to side
Detection range
Compatible lighting
The switch can be used to control the
following types of lighting.
– Incandescent or halogen bulbs Total
maximum output of all connected
bulbs: 600 W
– LED or CFL bulbs Total maximum
output of all connected bulbs: 150 W
For assistance, please visit http://shop.panasonic.com/support 9
Setup
Installation
Important:
RSwitch off the power of the
corresponding circuit before
performing any electrical work.
RFollow all local codes and
regulations.
RInstallation should be performed by
a licensed electrician.
RThe switch cannot be used in 3-way
circuits, i.e., situations where two
light switches control the same light
fixture, such as at the top and
bottom of a stairway.
Preparation
These steps are necessary when
replacing a switch.
1Turn off the power to the circuit at
the circuit breaker or fuse panel.
TEMP
2Remove the existing wall plate,
then remove the existing switch
from the junction box.
TEMP
RBe careful not to touch any
wires connected to the existing
switch.
3Use a non-contact circuit tester to
confirm that the wires connected
to the existing switch are not
carrying power.
TEMP
10 For assistance, please visit http://shop.panasonic.com/support
Setup
4Disconnect the wires from the
existing switch.
Wiring
1Loosen each of the 3 screws on
the switch.
2Prepare the wires to be connected
to the switch.
RStrip each black wire as shown
below. Snip any excess bare
wire if necessary.
A
xx mm (xx inches)
RStraighten the bare copper wire
if it is bent.
3Insert the ends of 2 black wires
and 1 ground wire into the holes
on the back of the switch as
shown below, then tighten each
screw.
RPull slightly on each wire to
make sure it is firmly connected.
RInsert the wires fully into the
switch. Make sure there is no
bare wire exposed on the 2
black wires.
RIf the existing switch (the switch
you are replacing) did not have
a ground wire connected to it,
use a piece of bare copper wire
to ground the new switch as
shown.
Finishing the installation
1Carefully insert the switch into the
junction box.
RBend the wires as necessary.
Make sure there are no bare
wires exposed (except for
ground wires).
2Use the xx-included screws to
secure the switch to the junction
box.
3Attach the included face plate.
4Turn on the power to the circuit at
the circuit breaker or fuse panel.
5Press the on/off switch to turn the
lights on and off.
RIf the lights turn on and off, you
are ready to register the switch
to the hub.
Registering the
switch
This procedure is not required for
devices that were included as part of
a bundle.
Before you can use the switch as part
of the system, it must be registered to
the hub.
If you purchased devices separately
(i.e., not as part of a bundle), you must
register each device to the hub.
You can register each device by using
the registration buttons or the [Home
Network] app.
Using registration buttons
1Hub:
Press and hold M OTHER
DEVICEN until the LED indicator
blinks slowly in green.
2Switch:
Press and hold M N until the
LED indicator blinks slowly in
green (page 7).
For assistance, please visit http://shop.panasonic.com/support 11
Setup
RWhen registration is complete,
the hub sounds one long beep.
Note:
RTo cancel without registering the
switch, press M N on the hub and
on the switch again.
RIf registration fails, the hub sounds
several short beeps.
Using the app
When you register the switch by using
the [Home Network] app, you can
assign a name to your devices and
group them by location. For more
information, refer to the User’s Guide
(page 13).
12 For assistance, please visit http://shop.panasonic.com/support
Setup
Testing the motion
sensor
You can observe the switch’s LED
indicator and test the performance of
the motion sensor.
1Press MN.
2Move to an area near the switch.
3While moving near the switch,
observe the LED indicator.
RWhen motion is detected, the
LED indicator blinks very
quickly in red.
4Note the areas where movement
is detected.
RYou can use the [Home
Network] app to adjust the
sensitivity of the motion sensor.
For more information, refer to
the User’s Guide (page 13).
5Press MN again.
Using the switch
(manual control)
RTurn on the lights by pressing the on/
off switch.
RTurn off the lights by pressing the on/
off button.
RBy default, the lights turn on when
motion is detected, and turn off if no
motion is detected for xx minutes.
You can use the [Home Network]
app to adjust these settings. For
more information, refer to the User’s
Guide (page 13).
Features available
when using the
[Home Network] app
Some of the switch’s features that are
available when using the [Home
Network] app are listed below. For
more information, refer to the User’s
Guide (page 13).
–Turning the switch on and off
You can use the app to turn the
lights on and off manually, or
program a schedule and turn the
lights on and off automatically.
–System integration
You can configure the switch to turn
on when another device is triggered,
such as a window or door sensor, a
sound sensor of an indoor camera,
etc. (Appropriate device required.)
–Motion switch details
You can adjust the motion sensor’s
sensitivity, change how long the
lights stay on when motion is
detected, etc.
Accessing the User’s
Guide
The User’s Guide is a collection of
online documentation that helps you
get the most out of the [Home
Network] app.
1iPhone®/iPad®
Tap in the app’s home screen.
Android™ devices
Tap or press your mobile
device’s menu button in the app’s
home screen.
2Tap [User’s Guide].
For assistance, please visit http://shop.panasonic.com/support 13
Appendix
Note:
RMicrosoft® Windows® Internet
Explorer® 8 and earlier versions are
not supported.
RAndroid 4.1 or later versions are
recommended.
RYou can also access the User’s
Guide at the web page listed below.
www.panasonic.net/pcc/support/tel/
homenetwork/manual/
Specifications
RStandards
DECT (Digital Enhanced Cordless
Telecommunications)
RFrequency range
DECT: 1.92 GHz – 1.93 GHz
RRF transmission power
DECT: 115 mW (max.)
RPower source
xx
ROperating conditions
0 °C – 40 °C (32 °F – 104 °F)
RMotion detection method
Pyroelectric infrared sensor (heat
sensor)
RInfrared sensor detection range
Horizontal: approx. 120°
Vertical: approx. 40°
Distance*1: approx. 10 m (32.8 feet)
RDimensions (height ´ width ´
depth)
– Switch:
Approx. xx mm ´ xx mm ´ xx mm
(x xx/xx inches ´ x xx/
xx inches inches ´ x xx/
xx inches inches)
– Face plate:
Approx. xx mm ´ xx mm ´ xx mm
(x xx/xx inches ´ x xx/
xx inches inches ´ x xx/
xx inches inches)
RMass (weight)
– Approx. xx g (0.xx lb), including
the face plate
*1 When the surrounding
temperature is approx. 25 °C
(77 °F) and the motion sensor’s
sensitivity is set to the highest
setting.
14 For assistance, please visit http://shop.panasonic.com/support
Appendix
FCC and other
information
This device complies with Part 15 of
the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received,
including interference that may cause
undesired operation.
Privacy of communications may not be
ensured when using this device.
CAUTION:
Any changes or modifications not
expressly approved by the party
responsible for compliance could void
the user’s authority to operate this
device.
NOTE:
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are
designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses, and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause
harmful interference to radio
communications. However, there is no
guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct the
interference by one or more of the
following measures:
– Reorient or relocate the receiving
antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an
outlet on a circuit different from that
to which the receiver is connected.
– Consult the dealer or an
experienced radio/TV technician for
help.
Some devices operate at frequencies
that may cause interference to nearby
TVs and VCRs. To minimize or prevent
such interference, this device should
not be placed near or on top of a TV or
VCR. If interference is experienced,
move this device further away from the
TV or VCR. This will often reduce or
eliminate interference.
FCC RF Exposure Warning:
RThis product complies with FCC
radiation exposure limits set forth for
an uncontrolled environment.
RTo comply with FCC RF exposure
requirements, the device must be
installed and operated 20 cm
(8 inches) or more between the
product and all person’s body.
RThis product may not be collocated
or operated in conjunction with any
other antenna or transmitter.
RFor body-worn operation, the device
must be used only with a
non-metallic accessory. Use of other
accessories may not ensure
compliance with FCC RF exposure
requirements.
Notice:
RFCC ID can be found on the rear of
the product.
For assistance, please visit http://shop.panasonic.com/support 15
Appendix
Customer services
You may also contact us directly at: 1-800-272-7033,
Monday - Friday 9 am to 9 pm;
Saturday - Sunday 10 am to 7 pm, EST.
Accessories!
http://shop.panasonic.com/support
Customer Services Directory
Shop
for all your Panasonic gear
Go to
Get everything you need to get the most out of
your Panasonic products
Accessories & Parts for your Camera, Phone, A/V
products, TV, Computers & Networking, Personal
Care, Home Appliances, Headphones, BaƩeries,
Backup Chargers & more…
For Product InformaƟon, OperaƟng Assistance,
Parts, Owner’s Manuals, Dealer and Service info
go to http://shop.panasonic.com/support
For the hearing or speech impaired TTY: 1- 877-833-8855
As of June 2015
16 For assistance, please visit http://shop.panasonic.com/support
Appendix
Limited Warranty (ONLY FOR U.S.A.)
Limited Warranty Coverage (For USA Only)
Labor
One (1) Year
Parts
One (1) Year
To submit a new repair request and for quick repair status visit our Web Site at
http://shop.panasonic.com/support
Panasonic Products Limited Warranty
Online Repair Request
Mail-In Service--Online Repair Request
If your product does not work properly because of a defect in materials or workmanship,
Panasonic Corporation of North America (referred to as “the warrantor”) will, for the length
of the period indicated on the chart below, which starts with the date of original purchase
(“warranty period”), at its option either (a) repair your product with new or refurbished parts,
(b) replace it with a new or a refurbished equivalent value product, or (c) refund your
purchase price. The decision to repair, replace or refund will be made by the warrantor.
During the “Labor” warranty period there will be no charge for labor. During the “Parts”
warranty period, there will be no charge for parts. This Limited Warranty excludes both
parts and labor for non-rechargeable batteries, antennas, and cosmetic parts (cabinet).
This warranty only applies to products purchased and serviced in the United States.
This warranty is extended only to the original purchaser of a new product which was
not sold “as is”.
Home Network System Products
microSD card (Included model only) 90 days N/A
When shipping the unit, carefully pack, include all supplied accessories listed in the
Owner’s Manual, and send it prepaid, adequately insured and packed well in a carton box.
When shipping Lithium Ion batteries please visit our Web Site at
http://shop.panasonic.com/support as Panasonic is committed to providing the most up to
date information. Include a letter detailing the complaint, a return address and provide a
daytime phone number where you can be reached. A valid registered receipt is required
under the Limited Warranty.
IF REPAIR IS NEEDED DURING THE WARRANTY PERIOD, THE PURCHASER WILL
BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF OF PURCHASE INDICATING
DATE OF PURCHASE, AMOUNT PAID AND PLACE OF PURCHASE. CUSTOMER WILL
BE CHARGED FOR THE REPAIR OF ANY UNIT RECEIVED WITHOUT SUCH PROOF
OF PURCHASE.
Product or Part Name
For assistance, please visit http://shop.panasonic.com/support 17
Appendix
Limited Warranty Limits and Exclusions
(As examples, this excludes damages for lost time, travel to and from the servicer,
loss of or damage to media or images, data or other memory or recorded content.
The items listed are not exclusive, but for illustration only.)
This warranty ONLY COVERS failures due to defects in materials or workmanship,
and DOES NOT COVER normal wear and tear or cosmetic damage. The warranty
ALSO DOES NOT COVER damages which occurred in shipment, or failures which
are caused by products not supplied by the warrantor, or failures which result from
accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty
installation, set-up adjustments, misadjustment of consumer controls, improper
maintenance, power line surge, lightning damage, modification, introduction of sand,
humidity or liquids, commercial use such as hotel, office, restaurant, or other business
or rental use of the product, or service by anyone other than a Factory Service Center
or other Authorized Servicer, or damage that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
“LIMITED WARRANTY COVERAGE”.
THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT
OF ANY BREACH OF THIS WARRANTY.
ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF
MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY,
ARE YOUR RESPONSIBILITY.
Some states do not allow the exclusion or limitation of incidental or consequential damages,
or limitations on how long an implied warranty lasts, so the exclusions may not apply to you.
This warranty gives you specific legal rights and you may also have other rights which vary
from state to state. If a problem with this product develops during or after the warranty period,
you may contact your dealer or Service Center. If the problem is not handled to your
satisfaction, then write to:
Consumer Affairs Department
Panasonic Corporation of North America
661 Independence Pkwy
Chesapeake, VA 23320
As of June 2015
18 For assistance, please visit http://shop.panasonic.com/support
Appendix
19
Notes
1
2
Make sure the product is wired properly.
(Consult a licensed electrician.)
Use the Home Network app to access the User’s Guide
and refer to the Troubleshooting section.
IMPORTANT!
If your product is not working properly. . .
Visit our Web site: http://shop.panasonic.com/support
LFAQ and troubleshooting hints are available.
For your future reference
We recommend keeping a record of the following information to assist
with any repair under warranty.
Serial No. Date of purchase
(found on the rear of the product)
Name and address of dealer
Attach your purchase receipt here.
Two Riverfront Plaza, Newark, NJ 07102-5490
© Panasonic System Networks Co., Ltd. 2016
