Panasonic of North America 96NKX-TG2356 2.4GHz FHSS Cordless Telephone System User Manual KX TG2356S
Panasonic Corporation of North America 2.4GHz FHSS Cordless Telephone System KX TG2356S
Users manual
2.4GHz Digital Cordless Answering System
Pulse-or-tone dialing capability
Model No. KX-TG2356S
PLEASE READ BEFORE USE AND SAVE.
Charge the battery for about 6 hours before initial use.
Contents:
Location of Controls 2
Connections 4
Battery Installation/Battery Charge 5
Recording a Greeting Message 6
Making/Answering Calls with the Handset 7
Making/Answering Calls with the Base Unit 8
Caller ID Service 10
Phone Book 10
Automatic Answering Operation 11
Listening to Messages 11
openLCR Service for Caller IQ Feature 12
Important Safety Instructions 13
FCC and Other Information 15
Operating Instructions
Caller ID Compatible
– 2 –
Location of Controls
Please read IMPORTANT SAFETY
INSTRUCTIONS on pages 13 before use.
Read and understand all instructions.
∫Base unit
[SP-PHONE] (Speakerphone)
and Indicator
[REDIAL]
[FLASH/CALL WAIT]
[MUTE]
VOLUME [ ], [ ]
[HOLD/CONF] (Conference)
CHARGE Indicator
[LOCATOR/INTERCOM]
Antenna
Display
Charge Contacts
[ ] (TONE)
[MESSAGE]
[STOP]
[SKIP]
[MEMO]
[ERASE]
[GREETING CHECK]
[REPEAT]
[ANSWER ON] and Indicator
MIC (Microphone)
NEW MESSAGE
Indicator
[GREETING REC]
(Record)
Hook
– 3 –
∫Handset
[OFF]
Display
[MENU]
[HOLD/INTERCOM]
[ ] (TALK)
[FLASH/CALL WAIT]
[ ] (Speakerphone)
Antenna
Headset Jack
[REDIAL]
Charge Contacts
[ ] (TONE)
Receiver
Ringer Indicator
Soft Keys
Back side
Speaker
Microphone
Navigator Key
([ ], [ ])
– 4 –
Connections
≥Use only with Panasonic AC adaptor PQLV1 (Order No. PQLV1Z).
≥The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel
warm during use.)
≥If your unit is connected to a PBX which does not support Caller ID services, you
cannot access those services.
≥The unit will not work during a power failure. If you want to connect a standard
telephone to the same telephone jack, use the Panasonic KX-J66 T-adaptor.
Single-Line Telephone Jack (RJ11C)
Power Outlet
(AC 120 V, 60 Hz)
AC Adaptor
Telephone Line Cord
Fasten the cords.
Hook Hooks
∫Connect the AC adaptor and the telephone line cord.
– 5 –
Battery Installation/Battery Charge
∫Battery installation
1 Install the battery in the handset.
2 Close the handset cover.
∫Battery Charge
To power the handset, charge the battery.
Place the handset on the base unit and charge for about 6 hours before initial
use.
≥The unit beeps once, the CHARGE indicator lights, and “Charging” is displayed.
≥When the battery is fully charged, “Charge completed” is displayed.
∫Recharge
Recharge the battery when:
—“Recharge battery” is displayed on the handset,
—“ ” flashes, or
—the handset beeps intermittently while it is in use.
≥Clean the handset and the base unit charge contacts with a soft, dry cloth once a
month. Clean more often if the unit is subject to grease, dust or high humidity. If
not, the battery may not charge properly.
≥If the battery is fully charged, you do not have to place the handset on the base unit
until “Recharge battery” is displayed and/or “” flashes. This will maximize the
battery life.
≥The battery cannot be overcharged.
A nickel metal hydride battery that is recyclable powers the
product you have purchased. Please call 1-800-8-BATTERY for
information on how to recycle this battery.
1
2
– 6 –
Recording a Greeting Message
1 Press [GREETING REC].
≥“To record greeting, press RECORD again” is heard.
2 Within 10 seconds, press [GREETING REC] again to record your greeting.
3 After the long beep, talk clearly, about 20 cm (8 inches) away from the MIC
(microphone).
≥The base unit display shows the elapsed recording time.
≥If you record for over 2 minutes, the unit will automatically stop recording.
4 When finished, press [GREETING REC] or [STOP].
≥To change the message, start again from step 1.
You can record a personal greeting message of up to 2 minutes. If you do not
record your own message, one of two pre-recorded greetings will be played for
callers.
All messages (greeting, incoming and voice memo) are stored in digital
memory. The total recording time is about 16 minutes. We recommend you
record a brief greeting message in order to leave more time for recording new
messages.
– 7 –
∫To make a call
1 Press [].
2 Dial a telephone number.
≥After a few seconds, the display will show the length of the call.
3 To hang up, press [OFF] or place the handset on the base unit.
To have a hands-free phone conversation
1 Press [].
2 Dial a telephone number.
≥After a few seconds, the display will show the length of the call.
3 When the other party answers, talk into the microphone.
4 To hang up, press [OFF] or place the handset on the base unit.
To dial after confirming the entered number
1 Dial a phone number.
≥If you misdial, press Clear. Enter the correct number.
≥If a pause is required when dialing, press Pause where needed.
≥To cancel, press [OFF].
2 Press []or [].
3 To hang up, press [OFF] or place the handset on the base unit.
To redial the last number dialed on the handset, press []or [] and
press [REDIAL].
Making/Answering Calls with the Handset
– 8 –
To redial using the redial list (Memory Redial)
The last 5 phone numbers dialed with the handset are stored in the redial list.
1 Press [REDIAL].
≥The last number dialed is displayed.
2 Scroll to the desired number by pressing []or [].
≥You can also scroll through the list by pressing [REDIAL].
≥To exit the list, press [OFF].
3 Press []or [].
≥To erase an item, scroll to the desired item then press Erase.
≥If “No items stored” is displayed, the list is empty.
To adjust the receiver volume (HIGH, MEDIUM or LOW) or speaker volume
(6 levels) while talking:
To increase, press []. To decrease, press [].
To put a call on hold, press [HOLD/INTERCOM] twice during a conversation.
To return to the hold;
From the handset, press [] or [].
From the base unit, press [SP-PHONE].
∫To answer a call
If the handset is off the base unit, press [].
OR
Press [], and when the other party answers, talk into the microphone.
– 9 –
∫To make a call
1 Press [SP-PHONE].
≥The SP-PHONE indicator lights.
2Dial a telephone number.
3 When the other party answers, talk into the MIC (microphone).
4 To hang up, press [SP-PHONE].
≥The indicator light goes out.
To redial the last number dialed on the base unit, press [SP-PHONE] and
press [REDIAL].
To adjust the speaker volume:
To increase, press VOLUME [ ]. To decrease, press VOLUME [ ].
To put a call on hold, press [HOLD/CONF] during a conversation.
To return to the hold;
From the base unit, press [SP-PHONE].
From the handset, press [] or [].
∫To answer a call
1 Press [SP-PHONE].
2 Talk into the MIC (microphone).
3 To hang up, press [SP-PHONE].
Making/Answering Calls with the Base Unit
– 10 –
Caller ID Service
This unit is compatible with a Caller ID service offered by your telephone
company. If you subscribe to a Caller ID service, the calling party’s information
will be shown on the handset display after the first ring. After the second ring
the handset and the base unit will announce the displayed name following every
ring (Talking Caller ID feature). You will audibly be informed of whom is calling
you. Name and telephone number Caller ID service is required for this feature.
≥Only the name will be announced.
The unit can record information of up to 50 different callers in the Caller List.
The Caller List information is sorted by the most recent to the oldest call. When
the 51st call is received, the first call is deleted.
Using the list, you can automatically call back a caller. You can store the callers’
names and numbers from the Caller List into the phone book.
If you subscribe to both Caller ID and Call Waiting with Caller ID services
(CWID), when a second call is received while talking, the second caller's
information will be displayed.
Phone Book
The handset can store up to 50 names and phone numbers in its phone book.
You can make a call by selecting a name or number from the phone book.
∫Chain Dialing
Chain dialing allows you to dial numbers stored in the phone book while you are
on a call. This feature can be used, for example, to dial a calling card access
number that you have stored in the phone book, without having to dial manually.
– 11 –
Automatic Answering Operation
∫Setting the unit to answer calls
Press [ANSWER ON] to turn on the answering system.
≥The indicator lights and “Answer set” is heard.
≥The unit will announce the remaining recording time if it is less than 3 minutes.
≥If you hear “Memory full”, “” is displayed on the base unit and the ANSWER ON
indicator flashes rapidly, erase some, or all, of the messages.
≥If you do not want the unit to answer calls, press [ANSWER ON] again to turn off the
answering system. The indicator light goes out and “Answer off” is heard.
≥You can also turn on the answering system remotely using any other phone.
FULL
Listening to Messages
You can see the total number of recorded messages on the base unit display. If
MESSAGE indicator flashes on the base unit and “New message” is displayed
on the handset, new messages have been recorded.
To play back messages, press [MESSAGE].
When you have new messages;
the unit announces the number of new messages and only new messages are
played back.
When you have no new messages;
the unit announces “No new messages. All message playback” and plays back all
messages.
When you have no messages;
the unit announces “No messages”.
– 12 –
openLCR Service for Caller IQ Feature
This unit is compatible with service provided by openLCR.
To activate the Caller IQ features, you will need to register with the openLCR
service and download the carrier table to your unit. The carrier table is based on
your telephone number, address and your long distance calling plan when you
register.
No extra steps are necessary to place a long distance call with Caller IQ
feature.
≥The openLCR service does not apply for local area calls.
Important:
≥If you have any questions regarding the openLCR service, call
openLCR’s customer service department at 1-866-openLCR (1-866-673-
6527).
≥NEITHER PANASONIC COMMUNICATIONS CO., LTD. (PCC) NOR
MATSUSHITA ELECTRIC CORPORATION OF AMERICA (MECA) IS IN ANY
WAY AFFILIATED WITH, OR RESPONSIBLE FOR THE ACTS OR
OMISSIONS OF, OPENLCR.COM, INC. (OPENLCR). NEITHER PCC NOR
MECA NOR ANY OF THEIR EMPLOYEES OR AFFILIATES OR
CUSTOMERS MAKE ANY WARRANTIES OR REPRESENTATIONS, EITHER
EXPRESS OR IMPLIED, TO ANY CUSTOMER OR ANY OTHER THIRD
PARTY WITH RESPECT TO ANY OF THE SERVICES PROVIDED BY
OPENLCR, NOR ASSUME NOR CREATE ANY OTHER OBLIGATION OF
ANY KIND ON BEHALF OF OPENLCR.
– 13 –
Important Safety Instructions
When using this unit, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, or personal injury.
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on this unit.
3. Unplug this unit from AC outlets before cleaning. Do not use liquid or
aerosol cleaners. Use a damp cloth for cleaning.
4. Do not use this unit near water, for example, near a bathtub, washbowl,
kitchen sink, or the like.
5. Place this unit securely on a stable surface. Serious damage and/or injury
may result if the unit falls.
6. Do not cover slots and openings on the unit. They are provided for
ventilation and protection against overheating. Never place the unit near
radiators, or in a place where proper ventilation is not provided.
7. Use only the power source marked on the unit. If you are not sure of the
type of power supplied to your home, consult your dealer or local power
company.
8. Do not place objects on the power cord. Install the unit where no one can
step or trip on the cord.
9. Do not overload wall outlets and extension cords. This can result in the risk
of fire or electric shock.
10. Never push any objects through slots in this unit. This may result in the risk
of fire or electric shock. Never spill any liquid on the unit.
11. To reduce the risk of electric shock, do not disassemble this unit. Take the
unit to an authorized servicenter when service is required. Opening or
removing covers may expose you to dangerous voltages or other risks.
Incorrect reassembly can cause electric shock when the unit is
subsequently used.
12. Unplug this unit from the wall outlet and refer servicing to an authorized
servicenter when the following conditions occur:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled into the unit.
C. If the unit has been exposed to rain or water.
D. If the unit does not work normally by following the operating instructions.
Adjust only controls covered by the operating instructions. Improper
adjustment may require extensive work by an authorized servicenter.
E. If the unit has been dropped or physically damaged.
F. If the unit exhibits a distinct change in performance.
13. During thunderstorms, avoid using telephones except cordless types. There
may be a remote risk of an electric shock from lightning.
14. Do not use this unit to report a gas leak, when in the vicinity of the leak.
SAVE THESE INSTRUCTIONS
– 14 –
CAUTION:
To reduce the risk of fire or injury to persons, read and follow these instructions.
1. Use only the battery(ies) specified.
2. Do not dispose of the battery(ies) in a fire. They may explode. Check with
local waste management codes for special disposal instructions.
3. Do not open or mutilate the battery(ies). Released electrolyte is corrosive
and may cause burns or injury to the eyes or skin. The electrolyte may be
toxic if swallowed.
4. Exercise care in handling batteries in order not to short the battery to
conductive materials such as rings, bracelets, and keys. The battery and/or
conductor may overheat and cause burns.
5. Charge the battery(ies) provided with or identified for use with this product
only in accordance with the instructions and limitations specified in this
manual.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR ANY TYPE OF MOISTURE.
≥The AC adaptor is used as the main disconnect device, ensure that the AC
outlet is located/installed near the unit and is easily accessible.
FCC and Other Information
– 15 –
This equipment complies with Part 68 of the FCC rules and the requirements
adopted by the ACTA. On the bottom of this equipment is a label that contains,
among other information, a product identifier in the format US:ACJ-----.
If requested, this number must be provided to the telephone company.
Registration No. . . . . . . . . . . . . . . . . . . . . . .(found on the bottom of the unit)
Ringer Equivalence No. (REN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.1B
A plug and jack used to connect this equipment to the premises wiring and
telephone network must comply with the applicable FCC Part 68 rules and
requirements adopted by the ACTA. A compliant telephone cord and modular
plug is provided with this product. It is designed to be connected to a compatible
modular jack that is also compliant.
The REN is used to determine the number of devices that may be connected to
a telephone line. Excessive RENs on a telephone line may result in the devices
not ringing in response to an incoming call. In most but not all areas, the sum of
RENs should not exceed five (5.0). To be certain of the number of devices that
may be connected to a line, as determined by the total RENs, contact the local
telephone company. For products approved after July 23, 2001, the REN for this
product is part of the product identifier that has the format US:AAAEQ##TXXXX.
The digits represented by ## are the REN without a decimal point (e.g., 03 is a
REN of 0.3).
If this equipment causes harm to the telephone network, the telephone
company will notify you in advance that temporary discontinuance of service
may be required. But if advance notice isn’t practical, the telephone company
will notify the customer as soon as possible. Also, you will be advised of your
right to file a complaint with the FCC if you believe it is necessary.
The telephone company may make changes in its facilities, equipment,
operations or procedures that could affect the operation of the equipment. If this
happens the telephone company will provide advance notice in order for you to
make necessary modifications to maintain uninterrupted service.
If trouble is experienced with this equipment, for repair or warranty information,
please contact a Factory Servicenter or other Authorized Servicer. If the
equipment is causing harm to the telephone network, the telephone company
may request that you disconnect the equipment until the problem is resolved.
Connection to party line service is subject to state tariffs. Contact the state
public utility commission, public service commission or corporation commission
for information.
If your home has specially wired alarm equipment connected to the telephone
line, ensure the installation of this equipment does not disable your alarm
equipment. If you have questions about what will disable alarm equipment,
consult your telephone company or a qualified installer.
– 16 –
WHEN PROGRAMMING EMERGENCY NUMBERS AND(OR) MAKING TEST
CALLS TO EMERGENCY NUMBERS:
1)Remain on the line and briefly explain to the dispatcher the reason for the
call.
2)Perform such activities in the off-peak hours, such as early morning or late
evenings.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Privacy of communications may not be ensured when using this phone.
CAUTION:
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this device.
Note:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which
—the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Some cordless telephones operate at frequencies that may cause interference
to nearby TVs and VCRs. To minimize or prevent such interference, the base of
the cordless telephone should not be placed near or on top of a TV or VCR. If
interference is experienced, move the cordless telephone further away from the
TV or VCR. This will often reduce, or eliminate, interference.
Operating near 2.4GHz electrical appliances may cause interference. Move
away from the electrical appliances.
– 17 –
FCC RF Exposure Warning:
To comply with FCC RF exposure requirements the base unit must be installed
and operated with its antenna located 20 cm or more between antenna and all
person’s body (excluding extremities of hands, wrist and feet). The handset unit
may be carried and operated with only the specific provided belt-clip. Other non-
tested belt-clips or similar body-worn accessories may not comply and must be
avoided. The base and handset units must not be co-located or operated in
conjunction with any other antenna or transmitter.
This equipment is hearing aid compatible as defined by the FCC in 47 CFR
Section 68.316.
A TIA/EIA-IS-968 compliant telephone cord and modular plug is provided with
this equipment. This equipment is designed to be connected to the telephone
network or premises wiring using a compatible modular jack that is also
TIA/EIA-IS-968 compliant.
The software contained in this equipment to allow user access to the network
must be ungraded to recognize newly established network area codes and
exchange codes as they are placed into service.
Failure to upgrade the premises systems or peripheral equipment to recognize
the new codes as they are established will restrict the customer and the
customer’s employees from gaining access to the network and to these codes.
≥Environment — do not place the unit in a room where the temperature is less
than 5°C (41°F) or greater than 40°C (104°F). Allow 10 cm (4") clearance
around the unit for proper ventilation. Avoid excessive smoke, dust,
mechanical vibration, shock, or direct sunlight.
≥Medical — consult the manufacturer of any personal medical devices, such as
pacemakers or hearing aids, to determine if they are adequately shielded from
external RF (radio frequency) energy. (The unit operates in the frequency
range of 2400MHz to 2481MHz, and the power output level can range 0.04 to
0.25 watts.) Do not use the unit in health care facilities if any regulations
posted in the area instruct you not to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to external RF (radio
frequency) energy.
≥Routine care — wipe the unit with a soft cloth. Do not use benzine, thinner, or
any abrasive powder. When you leave the unit unused for a long period of
time, unplug the AC adaptor from the outlet.
≥If there is any trouble — disconnect the unit from the telephone line and
connect a known working phone. If the known working phone operates
properly, have your unit repaired by one of the authorized Panasonic Factory
Service Centers. If the known working phone does not operate properly,
consult your telephone company.
When you hold the phone to your ear, noise might be heard in your Hearing
Aid. Some Hearing Aids are not adequately shielded from external RF (radio
frequency) energy. If noise occurs, use an optional headset accessory or the
speakerphone option (if applicable) when using this phone. Consult your
audiologist or Hearing Aid manufacturer about the availability of Hearing Aids
which provide adequate shielding to RF energy commonly emitted by digital
devices.
For product service
≥Call 1-800-211-PANA(7262) for the location of an authorized servicenter.
≥Panasonic’s e-mail address for customer inquiries:
consumerproducts@panasonic.com
for customers in the USA or Puerto Rico ONLY
When you ship the product
≥Carefully pack your unit, preferably in the original carton.
≥Attach a letter, detailing the symptom, to the outside of the carton.
Symptom
≥Send the unit to an authorized servicenter, prepaid and adequately insured.
≥Do not send your unit to the Panasonic Consumer Electronics Company listed
below or to executive or regional sales offices. These locations do not repair
consumer products.
Panasonic Consumer Electronics Company,
Division of Matsushita Electric Corporation of America
One Panasonic Way, Secaucus, New Jersey 07094
Panasonic Sales Company,
Division of Matsushita Electric of Puerto Rico, Inc.
Ave. 65 de Infantería,, Km. 9.5, San Gabriel Industrial Park
Carolina, Puerto Rico 00985
If you need assistance with the set-up or operation,
please call 1-800-211-PANA(7262)
For hearing or speech impaired TTY users, TTY : 1-877-833-8855
