Thank you for purchasing a Panasonic product.

Please read these operating instructions before using the unit and save

them for future reference.

This unit is compatible with Caller ID. You must subscribe to the appropriate

service offered by your service provider/telephone company.

For assistance, visit our website:

http://www.panasonic.com/help for customers in the U.S.A. or Puerto

Rico.

Operating Instructions

Expandable Digital Cordless

Answering System

Model shown is KX-TG6511.

KX-TG6573

KX-TG6531

KX-TG6532

KX-TG6533

KX-TG6534

KX-TG6541

KX-TG6542

KX-TG6543

KX-TG6544

KX-TG6545

Model No.

KX-TG6521

KX-TG6522

KX-TG6523

Expandable Digital Cordless Phone

Model No.

KX-TG6511

KX-TG6512

KX-TG6513

Before initial use, see "Getting

Started" on page 5 .

Please register your product: http://www.panasonic.com/prodreg

For your safety

To prevent severe injury and loss of life/

property, read this section carefully before

using the product to ensure proper and safe

operation of your product.

WARNING

Power connection

LUse only the power source marked on the

product.

LDo not overload power outlets and

extension cords. This can result in the risk

of fire or electric shock.

LCompletely insert the AC adaptor/power

plug into the power outlet. Failure to do so

may cause electric shock and/or excessive

heat resulting in a fire.

LRegularly remove any dust, etc. from the

AC adaptor/power plug by pulling it from the

power outlet, then wiping with a dry cloth.

Accumulated dust may cause an insulation

defect from moisture, etc. resulting in a fire.

LUnplug the product from power outlets if it

emits smoke, an abnormal smell, or makes

an unusual noise. These conditions can

cause fire or electric shock. Confirm that

smoke has stopped emitting and contact

the Panasonic Call Center at 1-800-211-

PANA (1-800-211-7262).

LUnplug from power outlets and never touch

the inside of the product if its casing has

been broken open.

LNever touch the plug with wet hands.

Danger of electric shock exists.

Installation

LTo prevent the risk of fire or electrical shock,

do not expose the product to rain or any

type of moisture.

LDo not place or use this product near

automatically controlled devices such as

automatic doors and fire alarms. Radio

waves emitted from this product may cause

such devices to malfunction resulting in an

accident.

LDo not allow the AC adaptor or telephone

line cord to be excessively pulled, bent or

placed under heavy objects.

Operating safeguards

LUnplug the product from power outlets

before cleaning. Do not use liquid or

aerosol cleaners.

LDo not disassemble the product.

LDo not spill liquids (detergents, cleansers,

etc.) onto the telephone line cord plug, or

allow it to become wet at all. This may

cause a fire. If the telephone line cord plug

becomes wet, immediately pull it from the

telephone wall jack, and do not use.

Medical

LConsult the manufacturer of any personal

medical devices, such as pacemakers or

hearing aids, to determine if they are

adequately shielded from external RF

(radio frequency) energy. (The product

operates in the frequency range of 1.92

GHz to 1.93 GHz, and the RF transmission

power is 115 mW (max.).)

LDo not use the product in health care

facilities if any regulations posted in the

area instruct you not to do so. Hospitals or

health care facilities may be using

equipment that could be sensitive to

external RF energy.

CAUTION

Installation and location

LNever install telephone wiring during an

electrical storm.

LNever install telephone line jacks in wet

locations unless the jack is specifically

designed for wet locations.

LNever touch uninsulated telephone wires or

terminals unless the telephone line has

been disconnected at the network interface.

LUse caution when installing or modifying

telephone lines.

LThe AC adaptor is used as the main

disconnect device. Ensure that the AC

outlet is installed near the product and is

easily accessible.

LThis product is unable to make calls when:

– the handset batteries need recharging or

have failed.

– there is a power failure.

Battery

LWe recommend using the batteries.

USE ONLY rechargeable

Ni-MH batteries AAA (R03) size.

LDo not mix old and new batteries.

LDo not open or mutilate the batteries.

Released electrolyte from the batteries is

corrosive and may cause burns or injury to

the eyes or skin. The electrolyte is toxic and

may be harmful if swallowed.

LExercise care when handling the batteries.

Do not allow conductive materials such as

rings, bracelets, or keys to touch the

batteries, otherwise a short circuit may

cause the batteries and/or the conductive

material to overheat and cause burns.

LCharge the batteries provided with or

identified for use with this product only, in

accordance with the instructions and

limitations specified in this manual.

LOnly use a compatible base unit (or

charger) to charge the batteries. Do not

tamper with the base unit (or charger).

Failure to follow these instructions may

cause the batteries to swell or explode.

Attention:

A nickel metal hydride battery that is

recyclable powers the product you have

purchased.

Please call 1-800-8-BATTERY (1-800-822-

8837) for information on how to recycle this

battery.

Important safety

instructions

When using your product, basic safety

precautions should always be followed to

reduce the risk of fire, electric shock, and

injury to persons, including the following:

1. Do not use this product near water for

example, near a bathtub, washbowl,

kitchen sink, or laundry tub, in a wet

basement or near a swimming pool.

2. Avoid using a telephone (other than a

cordless type) during an electrical storm.

There may be a remote risk of electric

shock from lightning.

3. Do not use the telephone to report a gas

leak in the vicinity of the leak.

4. Use only the power cord and batteries

indicated in this manual. Do not dispose of

batteries in a fire. They may explode.

Check with local codes for possible special

disposal instructions.

SAVE THESE INSTRUCTIONS

For best performance

Base unit location/avoiding noise

The base unit and other compatible Panasonic

units use radio waves to communicate with

each other.

LFor maximum coverage and noise-free

communications, place your base unit:

– at a convenient, high, and central

location with no obstructions between

the handset and base unit in an indoor

environment.

– away from electronic appliances such as

TVs, radios, personal computers,

wireless devices, or other phones.

– facing away from radio frequency

transmitters, such as external antennas

of mobile phone cell stations. (Avoid

putting the base unit on a bay window or

near a window.)

LCoverage and voice quality depends on the

local environmental conditions.

LIf the reception for a base unit location is not

satisfactory, move the base unit to another

location for better reception.

Environment

LKeep the product away from electrical noise

generating devices, such as fluorescent

lamps and motors.

LThe product should be kept free from

excessive smoke, dust, high temperature,

and vibration.

LThe product should not be exposed to direct

sunlight.

LDo not place heavy objects on top of the

product.

LWhen you leave the product unused for a

long period of time, unplug the product from

the power outlet.

LThe product should be kept away from heat

sources such as heaters, kitchen stoves,

etc. It should not be placed in rooms where

the temperature is less than 0 °C (32 °F) or

greater than 40 °C (104 °F). Damp

basements should also be avoided.

LThe maximum calling distance may be

shortened when the product is used in the

following places: Near obstacles such as

hills, tunnels, underground, near metal

objects such as wire fences, etc.

LOperating the product near electrical

appliances may cause interference. Move

away from the electrical appliances.

Routine care

LWipe the outer surface of the product

with a soft moist cloth.

LDo not use benzine, thinner, or any

abrasive powder.

Other information

CAUTION: Risk of explosion if battery is

replaced by an incorrect type. Dispose of used

batteries according to the instructions.

Notice for product disposal, transfer, or

return

LThis product can store your private/

confidential information. To protect your

privacy/confidentiality, we recommend that

you erase information such as phonebook

or caller list entries from the memory before

you dispose of, transfer, or return the

product.

Notice

ENERGY STAR

As an ENERGY STAR® Partner,

Panasonic has determined that this product

meets the ENERGY STAR guidelines for

energy efficiency. ENERGY STAR is a U.S.

registered mark.

Getting Started

Setting up

Connections

LUse only the supplied Panasonic AC

adaptor PQLV219.

■Base unit

*DSL/ADSL filter (not supplied) is

required if you have DSL/ADSL service.

■Charger

Battery installation

LUSE ONLY Ni-MH batteries AAA

(R03) size.

LDo NOT use Alkaline/Manganese/Ni-

Cd batteries.

LConfirm correct polarities (S, T).

Battery charge

Charge for about 7 hours.

(120 V AC, 60 Hz)

Hooks

Rechargeable Ni-MH ONLY

DSL/ADSL filter*

Hook

“Click”

Press plug firmly.

Correct Wrong

(120 V AC, 60 Hz)

To single-line

telephone jack

(RJ11C)

“Click”

LWhen the batteries are fully charged,

the charge indicator goes off.

Confirm "Charging" is displayed.

Charge indicator

Getting Started

Note when setting up

Note for connections

LThe AC adaptor must remain

connected at all times. (It is normal for

the adaptor to feel warm during use.)

LThe AC adaptor should be connected

to a vertically oriented or floor-

mounted AC outlet. Do not connect

the AC adaptor to a ceiling-mounted

AC outlet, as the weight of the adaptor

may cause it to become disconnected.

During a power failure

The unit will not work during a power

failure. We recommend connecting a

corded-type telephone (without AC

adaptor) to the same telephone line or to

the same telephone line jack using a

Panasonic T-adaptor.

Emergency power can be supplied to the

unit by connecting a Panasonic battery

back-up power supply.

Note for battery installation

LUse the supplied rechargeable

batteries. For replacement, we

recommend using the Panasonic

rechargeable batteries.

LWipe the battery ends (S, T) with a

dry cloth.

LAvoid touching the battery ends (S,

T) or the unit contacts.

Note for battery charge

LIt is normal for the handset to feel

warm during charging.

LClean the charge contacts of the

handset, base unit, and charger with a

soft and dry cloth once a month. Clean

more often if the unit is exposed to

grease, dust, or high humidity.

Battery level

Note:

LThe batteries need to be charged if

the handset beeps while you are

engaged in a call or operating the

answering system remotely.

Panasonic Ni-MH battery

performance (supplied batteries)

Icon Battery level

&High

(Medium

)Low

0)4Needs charging.

0Empty

Operation Operating time

In continuous

use

5 hours max.*1

Not in use

(standby)

11 days max.

*1 When the clarity booster feature is

turned on: 3 hours max.

Note:

LActual battery performance depends

on a combination of how often the

handset is in use and how often it is

not in use (standby).

LEven after the handset is fully

charged, the handset can be left on

the base unit or charger without any ill

effect on the batteries.

LThe battery level may not be

displayed correctly after you replace

the batteries. In this case, place the

handset on the base unit or charger

and let it charge for at least 7 hours.

Getting Started

Controls

Base unit

■KX-TG6511 series

ACharge contacts

B{LOCATOR}

CBracket

■KX-TG6521/KX-TG6531 series

ACharge contacts

BSpeaker

C{ERASE}

D{■} (STOP)

E{^}/{V} (VOL.: Volume up/down)

{7}/{8} (Repeat/Skip)

F{6} (Play)

Message indicator

G{LOCATOR}

H{ANSWER ON}

ANSWER ON indicator

IBracket

A B

DC E F G HI

A B

Getting Started

ACharge contacts

BSpeaker

C{■} (STOP)

D{ERASE}

E{^}/{V} (VOL.: Volume up/down)

{7}/{8} (Repeat/Skip)

F{6} (Play)

Message indicator

G{ANSWER ON}

ANSWER ON indicator

H{LOCATOR} {INTERCOM}

I Microphone

JDial keypad ({*}: TONE)

K{REDIAL} {PAUSE}

L{HOLD}

M{SP-PHONE} (Speakerphone)

SP-PHONE indicator

N{FLASH} {CALL WAIT}

O{MUTE}

P{CONF} (Conference)

Q{MEMO}

RBracket

Handset (KX-TGA652)

ACharge indicator

Ringer indicator

Message indicator

BNon-slip pad

LNon-slip pad offers support when

you cradle the handset between

your shoulder and ear.

CSpeaker

D{C} (TALK)

E{s} (SP-PHONE: Speakerphone)

FHeadset jack (KX-TG6511/

KX-TG6531/KX-TG6541 series)

GDial keypad ({*}: TONE)

HReceiver

IDisplay

B C

■KX-TG6541 series

ABCDEFG H

NJOP

QRIKLM

Getting Started

J{OFF}

K{FLASH} {CALL WAIT}

LMicrophone

MCharge contacts

■Control type

A Soft keys

The handset features 3 soft keys. By

pressing a soft key, you can select the

feature shown directly above it on the

display.

B Navigator key

–? VOL. (Volume: {^} or {V}):

You can adjust the receiver or

speaker volume

while talking.

– {<} CID:You can enter the

caller list.

{>} REDIAL:You can enter

the redial list.

– {^}, {V}, {<}, or {>}: You can

scroll through various lists or items.

–

Making calls

Using the handset

1Lift the handset and dial the phone

number.

LTo correct a digit, press {CLEAR}.

2Press {C} or {CALL}.

3When you finish talking, press

{OFF} or place the handset on the

base unit or charger.

Using the speakerphone

1Dial the phone number and press

{s}.

LSpeak alternately with the other

party.

2When you finish talking, press

{OFF}.

Note:

LFor best performance, use the

speakerphone in a quiet environment.

LTo switch back to the receiver, press

{C}.

Adjusting the receiver or speaker

volume

Press {^} or {V} repeatedly while

talking.

Making a call using the redial list

The last 5 phone numbers dialed are

stored in the redial list (each 48 digits

max.).

1{REDIAL}

2{V}/{^}: Select the desired phone

number.

3{C}

Using the base unit

1{SP-PHONE}

2Dial the phone number.

3When the other party answers,

speak into the MIC.

LSpeak alternately with the other

party.

4When you finish talking, press {SP-

PHONE}.

Note:

LUse the speakerphone in a quiet

environment.

Available for:

KX-TG6541 series

LWhile on a call, you can switch from

the base unit to the handset:

– Press {C} on the handset, then

press {SP-PHONE} on the base

unit.

– If the handset is on the base unit,

simply lift it.

Adjusting the speaker volume

Press {^} or {V} repeatedly while

talking.

Redialing the last number dialed

{SP-PHONE} i {REDIAL}

Answering calls

Using the handset

When a call is being received, the ringer

indicator flashes rapidly.

1Lift the handset and press {C} or

{s} when the unit rings.

LYou can also answer the call by

pressing any dial key from {0} to

{9}, {*}, or {#}. (Any key

answer feature)

2When you finish talking, press

{OFF} or place the handset on the

base unit or charger.

Auto talk

You can answer calls simply by lifting the

handset off the base unit or charger. You

do not need to press {C}. To turn this

feature on.

Adjusting the handset ringer volume

Press {^} or {V} repeatedly to select the

desired volume while the handset is

ringing for an incoming call.

Note:

LYou can also program the handset

ringer volume beforehand.

Temporary handset ringer off

While the handset is ringing for a call,

you can turn the ringer off temporarily by

pressing {~}.

Adjusting the base unit ringer

volume

Press {^} or {V} repeatedly to select the

desired volume.

LTo turn the ringer off, press and hold

{V} until the unit beeps 2 times.

Note:

LWhen the ringer volume is set to off,

the base unit rings at the low level for

intercom calls. (KX-TG6541 series)

Using the base unit

When a call is being received, the SP-

PHONE indicator flashes rapidly.

1Press {SP-PHONE} when the unit

rings.

2Speak into the MIC.

3When you finish talking, press {SP-

PHONE}.

Available for:

KX-TG6521/KX-TG6531/KX-TG6541

series

Available for:

KX-TG6541 series

Shared phonebook

The shared phonebook allows you to

make calls without having to dial

manually. Any handset registered to the

base unit can use the shared

phonebook. You can add 50 names and

phone numbers to the shared

phonebook, and assign each

phonebook entry to the desired

category.

Important:

LOnly 1 person can access the shared

phonebook at a time.

LCaller ID subscribers can use group

ringer tone features.

Adding entries

1{C}

2{ADD}

3Enter the party’s name (16

characters max.). i {OK}

4Enter the party’s phone number (24

digits max.). i {OK}

5{V}/{^}: Select the desired group.

i {SELECT} 2 times

LTo add other entries, repeat from

step 2.

6{OFF}

Character table for entering names

While entering characters, you can

switch between uppercase and

lowercase by pressing {*}.

LTo enter another character that is

located on the same dial key, first

press {>} to move the cursor to the

next space.

Note:

LIf you do not press any dial key within

5 seconds after entering a character,

the character is fixed and the cursor

moves to the next space.

Correcting a mistake

Press {<} or {>} to move the cursor to

the character or number you want to

erase, then press {CLEAR}. Enter the

appropriate character or number.

LPress and hold {CLEAR} to erase all

characters or numbers.

Key Character

{1}&’ ( ) ;,–

./1

{2}ABC2

abc2

{3}DEF3

def 3

{4}GHI 4

ghi 4

{5}JKL5

jkl5

{6}MNO6

mn o 6

{7}PQRS7

pqrs7

{8}TUV8

tuv8

{9}WX Y Z 9

wx yz9

{0}Space 0

{#} #

Finding and calling a

phonebook entry

Scrolling through all entries

1{C}

2{V}/{^}: Select the desired entry.

3{C}

Searching by first character

1{C}

2Press the dial key ({0} – {9}, {*},

or {#}) which contains the

character you are searching for.

LPress the same dial key

repeatedly to display the first

entry corresponding to each

character located on that dial key.

LIf there is no entry corresponding

to the character you selected, the

next entry is displayed.

3{V}/{^}: Scroll through the

phonebook if necessary.

4{C}

Registering a unit

Operating additional units

Additional handsets

Up to 6 handsets can be registered to

the base unit.

Registering a handset to the

base unit

The supplied handset and base unit are

pre-registered. If for some reason the

handset is not registered to the base

unit, re-register the handset.

1Handset:

{MENU} i {#}{1}{3}{0}

2Base unit:

Press and hold {LOCATOR} for

about 4 seconds until the

registration tone sounds.

LIf all registered handsets start

ringing, press the same button to

stop. Then repeat this step.

LThe next step must be completed

within 90 seconds.

3Handset:

Press {OK}, then wait until a long

beep sounds.

4{OFF}

Press and hold {LOCATOR} for

about 4 seconds. (No registration

tone)

■KX-TG6511 series

■KX-TG6521/KX-TG6531/

KX-TG6541 series

Using Caller ID service

Important:

LThis unit is Caller ID compatible. To

use Caller ID features, you must

subscribe to a Caller ID service.

Contact your service provider/

telephone company for details.

Caller ID features

When an outside call is being received,

the caller’s name and phone number are

displayed.

Caller information for the last 50 callers

is logged in the caller list from the most

recent call to the oldest.

LIf the unit cannot receive caller

information, the following is displayed:

–“Out of area”: The caller dials

from an area which does not

provide a Caller ID service.

–“Private caller”: The caller

requests not to send caller

information.

–“Long distance”: The caller

makes a long distance call.

LIf the unit is connected to a PBX

system, caller information may not be

properly received. Contact your PBX

supplier.

Answering system

The answering system can answer and

record calls for you when you are

unavailable to answer the phone.

You can also set the unit to play a

greeting message but not to record

caller messages by selecting

“Greeting only” as the recording

time setting.

Important:

LOnly 1 person can access the

answering system (listen to

messages, record a greeting

message, etc.) at a time.

LWhen callers leave messages, the

unit records the day and time of each

message. Make sure the date and

time have been set correctly.

Turning the answering

system on/off

Press {ANSWER ON} to turn on/off the

answering system.

■To turn on:

1{MENU} i {#}{3}{2}{7}

2{OFF}

■To turn off:

1{MENU} i {#}{3}{2}{8}

2{OFF}

Note for base unit and handset:

LWhen the answering system is turned

on, the ANSWER ON indicator on the

base unit lights up.

Available for:

KX-TG6521/KX-TG6531/KX-TG6541

series

Base unit

Handset

Greeting message

When the unit answers a call, a greeting

message is played to callers.

You can use either:

– your own greeting message

– a pre-recorded greeting message

Recording your greeting

message

1{MENU} i {#}{3}{0}{2}

2{V}/{^}: “Yes” i {SELECT}

3After a beep sounds, speak clearly

(2 minutes and 30 seconds max.).

4Press {STOP} to stop recording.

5{OFF}

Listening to messages

using the base unit

When new messages have been

recorded, the message indicator on the

base unit flashes.

Press {6}.

LIf new messages have been recorded,

the base unit plays back new

messages.

LIf there are no new messages, the

base unit plays back all messages.

FCC and other information

This equipment complies with Part 68 of the

FCC rules and the requirements adopted by

the ACTA. On the bottom of this equipment

is a label that contains, among other

information, a product identifier in the

format US:ACJ----------.

If requested, this number must be provided

to the telephone company.

L Registration No.............(found on the

bottom of the unit)

L Ringer Equivalence No. (REN).......0.1B

A plug and jack used to connect this

equipment to the premises wiring and

telephone network must comply with the

applicable FCC Part 68 rules and

requirements adopted by the ACTA. A

compliant telephone cord and modular plug

is provided with the product. It is designed

to be connected to a compatible modular

jack that is also compliant.

The REN is used to determine the number

of devices that may be connected to a

telephone line. Excessive RENs on a

telephone line may result in the devices not

ringing in response to an incoming call. In

most but not all areas, the sum of RENs

should not exceed five (5.0). To be certain

of the number of devices that may be

connected to a line, as determined by the

total RENs, contact the local telephone

company. For products approved after July

23, 2001, the REN for the product is part of

the product identifier that has the format

US:AAAEQ##TXXXX. The digits

represented by ## are the REN without a

decimal point (e.g., 03 is a REN of 0.3).

If this equipment causes harm to the

telephone network, the telephone company

will notify you in advance that temporary

discontinuance of service may be required.

But if advance notice isn't practical, the

telephone company will notify the customer

as soon as possible. Also, you will be

advised of your right to file a complaint with

the FCC if you believe it is necessary.

The telephone company may make changes

in its facilities, equipment, operations or

procedures that could affect the operation of

the equipment. If this happens the

telephone company will provide advance

notice in order for you to make necessary

modifications to maintain uninterrupted

service.

If trouble is experienced with this

equipment, for repair or warranty

information, please contact a Factory

Service Center or other Authorized Servicer.

If the equipment is causing harm to the

telephone network, the telephone company

may request that you disconnect the

equipment until the problem is resolved.

Connection to party line service is subject to

state tariffs. Contact the state public utility

commission, public service commission or

corporation commission for information.

If your home has specially wired alarm

equipment connected to the telephone line,

ensure the installation of this equipment

does not disable your alarm equipment. If

you have questions about what will disable

alarm equipment, consult your telephone

company or a qualified installer.

This equipment is hearing aid compatible as

defined by the FCC in 47 CFR Section

68.316.

When you hold the phone to your ear, noise

might be heard in your Hearing Aid. Some

Hearing Aids are not adequately shielded

from external RF (radio frequency) energy. If

noise occurs, use an optional headset

accessory or the speakerphone option (if

applicable) when using this phone. Consult

with your audiologist or Hearing Aid

manufacturer about the availability of

Hearing Aids which provide adequate

shielding to RF energy commonly emitted

by digital devices.

WHEN PROGRAMMING EMERGENCY

NUMBERS AND(OR) MAKING TEST

CALLS TO EMERGENCY NUMBERS:

1) Remain on the line and briefly explain to

the dispatcher the reason for the call.

2) Perform such activities in the off-peak

hours, such as early morning or late

evenings.

This device complies with Part 15 of the

FCC Rules. Operation is subject to the

following two conditions:

(1) This device may not cause harmful

interference, and (2) this device must

accept any interference received, including

interference that may cause undesired

operation.

Privacy of communications may not be

ensured when using this phone.

CAUTION:

Any changes or modifications not expressly

approved by the party responsible for

compliance could void the user’s authority

to operate this device.

NOTE:

This equipment has been tested and found

to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide

reasonable protection against harmful

interference in a residential installation. This

equipment generates, uses, and can radiate

radio frequency energy and, if not installed

and used in accordance with the

instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does cause

harmful interference to radio or television

reception, which can be determined by

turning the equipment off and on, the user is

encouraged to try to correct the interference

by one or more of the following measures:

– Reorient or relocate the receiving

antenna.

– Increase the separation between the

equipment and receiver.

– Connect the equipment into an outlet on a

circuit different from that to which the

receiver is connected.

– Consult the dealer or an experienced

radio/TV technician for help.

Some cordless telephones operate at

frequencies that may cause interference to

nearby TVs and VCRs. To minimize or

prevent such interference, the base of the

cordless telephone should not be placed

near or on top of a TV or VCR. If

interference is experienced, move the

cordless telephone further away from the TV

or VCR. This will often reduce, or eliminate,

interference.

FCC RF Exposure Warning:

L This product complies with FCC radiation

exposure limits set forth for an

uncontrolled environment.

L To comply with FCC RF exposure

requirements, the base unit must be

installed and operated 20 cm (8 inches)

or more between the product and all

person’s body (excluding extremities of

hands, wrist and feet).

L This product may not be collocated or

operated in conjunction with any other

antenna or transmitter.

L The handset may be carried and operated

with only the specific provided belt-clip.

Other non-tested belt-clips or similar

body-worn accessories may not comply

and must be avoided.

Notice

L FCC ID can be found inside the battery

compartment or on the bottom of the

units.

Compliance with TIA-1083 standard:

Telephone handsets identified with this logo

have reduced noise and interference when

used with T-Coil equipped hearing aids and

cochlear implants.

Compatible with

Hearing Aid T-Coil

TIA-1083

For your future reference

We recommend keeping a record of the following information to assist with any repair

under warranty.

This material is copyrighted by Panasonic Communications Co., Ltd., and may be

reproduced for internal use only. All other reproduction, in whole or in part, is

prohibited without the written consent of Panasonic Communications Co., Ltd.

Serial No. Date of purchase

(found on the bottom of the base unit)

Name and address of dealer

1 Reconnect AC adaptor to the base unit.

2 Check if telephone line cord is connected.

3 Use rechargeable Ni-MH batteries.

(Alkaline/Manganese/Ni-Cd batteries CANNOT be used.)

4 Read troubleshooting page in the Operating Instructions.

If your product is not working properly. . .

IMPORTANT!

Visit our Web site: http://www.panasonic.com/help

LFAQ and troubleshooting hints are available.

Attach your purchase receipt here.

One Panasonic Way, Secaucus, New Jersey 07094

Panasonic of North America 96NKX-TGA651 DECT Cordless Telephone Handset User Manual

Panasonic Corporation of North America DECT Cordless Telephone Handset

user manual

Navigation menu

Namespaces

Views

Navigation
