Panasonic of North America 9TGCF-188A Notebook Computer CF-18mk3 Family User Manual Addendum
Panasonic Corporation of North America Notebook Computer CF-18mk3 Family Addendum
Contents
- 1. User Manual CF18 Supplement for X Strap
- 2. User Manual CF18
- 3. User Manual BT Supplement
- 4. User Mannul CF18 Supplement for X Strap
- 5. User Manual CF18
- 6. User Manual WLAN
- 7. User Manual CF18 Supplement X Strap
- 8. User Manul CF18
- 9. User Manual CF18 Supplement for X Strap
- 10. User Manual Supplement for EVDO
User Mannul CF18 Supplement for X Strap
ADDENDUM
Operating In Tablet Mode
FCC RF Exposure Warning: In Tablet Mode, the computer can be operated in wireless
transmitter mode of operation. User must use X-Strap to assure that minimum 1.5cm spacing is
provided between person’s body and internal antenna(s) located on the side edges of LCD.
Refer to safety instructions on page 3 of the Operating Instructions for details.
CF-18 X-Strap Installation Instructions
1. Begin installation by removing
screws from corners of you
Toughbook 18.
2. Position the strap on the
base of the Toughbook 18.
Make sure that the clips
are towards the front of
the machine to allow
quick and easy desk use.
3. Place the attachment brackets
over the screw holes from step 1.
Screw onto machine with screws
provided in X-Strap kit.
4. Now you are ready to
use your CF-18 X-Strap.
While using, slide hand
between strap and
machine for a comfort-
able, safe grip.
5. While not in use, carry the
machine at your side using
the removable shoulder strap.
Please hold the CF-18 as instructed. Please do not put the palm of your hand on the bottom of the machine.
Your palm slips easily, if the CF-18 turns over you could injure your hand or arm.
