Users manual
®
Handheld Computer
Supplementary Instructions
This Supplementary Instructions manual explains how
to get started with a wireless LAN and point out cases
where the operation of the computer will differ from
that in the Operating Instructions.
Wireless LAN
Antenna
Wireless LAN communications are done via an antenna. Do not shield this antenna with
the hand, etc. This will negatively effect the performance of your wireless LAN commu-
nications.
CF-P1 with Wireless LAN
NOTE
Information to the User
This product and your Health
This product, like other radio devices, emits radio frequency electromagnetic energy. The
level of energy emitted by this product however is far much less than the electromagnetic
energy emitted by wireless devices like for example mobile phones.
Because this product operates within the guidelines found in radio frequency safety standards
and recommendations, we believe this product is safe for use by consumers. These standards
and recommendations reflect the consensus of the scientific community and result from de-
liberations of panels and committees of scientists who continually review and interpret the
extensive research literature.
In some situations or environments, the use of this product may be restricted by the proprietor
of the building or responsible representatives of the organization. These situations may for
example include:
Using this product on board of airplanes, or
In any other environment where the risk of interference to other devices or services is
perceived or identified as harmful.
If you are uncertain of the policy that applies on the use of wireless devices in a specific
organization or environment (e.g. airports), you are encouraged to ask for authorization to
use this product prior to turning on the product.
Regulatory Information
We are not responsible for any radio or television interference caused by unauthorized modi-
fication of this product. The correction of interference caused by such unauthorized modifi-
cation will be the responsibility of the user. We and its authorized resellers or distributors are
not liable for damage or violation of government regulations that may arise from failing to
comply with these guidelines.
2
Supplementary Instructions
Read Me First - For U.S.A.
Replace as follows.
Federal Communications Commission Radio Frequency Interference
Statement
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equip-
ment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consult the Panasonic Service Center or an experienced radio/TV technician for help.
Safety Notice
Do not touch or move antenna while the unit is transmitting or receiving.
Do not hold any component containing the radio such that the antenna is very close or
touching any exposed parts of the body, especially the face or eyes, while transmitting.
Do not operate a portable transmitter near unshielded blasting caps or in an explosive
environment unless it is type especially qualified for such use.
Warning
To assure continued compliance, use only shielded interface cables when connecting to a
computer or peripheral. Also, any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference that may cause
undesired operation.
Responsible Party: Matsushita Electric Corporation of America
One Panasonic Way
Secaucus, NJ 07094
Tel No:1-800-LAPTOP-5
(1-800-527-8675)
FCC Radiation Exposure Statement:
In order to comply with FCC RF exposure limits, it is recommended, when emitting radiated
power, that the integrated antenna should not be positioned closer than 2 inches (5 cm) from
your body or nearby persons for extended periods of time while it is transmitting (or operat-
ing). If the antenna is positioned less than 2 inches (5cm) from the user, it is recommended
that user exposure time be limited.
3
First-time Operation
After finishing the first-time operation, install the driver for Wireless LAN using the
following procedure.
Install the driver for Wireless LAN
(1)When the computer recognizes the internal Wireless LAN card, a screen will be displayed
designating the driver name. Tap to close this screen.
(2)Tap [Start]-[Run] in order, then input “ffrestore.exe r”, and then tap [OK].
The driver for Wireless LAN will be copied from the Flash memory to the [Options]
folder in [My Computer].
(3)When [Complete] is displayed, press .
(4)Install the driver for Wireless LAN.
1) Double-tap [My Computer], and then double-tap the [Options] folder.
2) Double-tap [Wireless LAN].
3) A screen will be displayed specifying the install destination folder. Tap [OK].
4) When [Setup Complete] is displayed, tap [OK].
5) Push the reset switch using the stylus.
When the computer is started up and the internal Wireless LAN card is correctly recognized,
the [Symbol Status] screen will be displayed.
When installation is complete, [Wireless LAN] will be automatically deleted from [My Com-
puter].
(5)Setting for Wireless LAN.
Input the necessary information on the [Symbol
Status] screen.
(ESSID and Operating Mode for the [Mode] tab,
IP address for the [IP Config] tab, etc.)
(6)Tap [OK].
(7)Press the reset switch using the stylus.
NOTE
The size of the [Symbol Status]
screen cannot be changed. If part
of this screen extends off of the
screen, drag the title bar to reposi-
tion the window.
Dealing with Problems
When reinstalling the
driver for Wireless
LAN, “File Write
Error” is displayed.
Check if the computer memory is full. If it is full, delete
unnecessary files.
Check if the [Options] folder in [My Computer] has been
deleted. If it has been deleted, recreate the [Options] folder
in [My Computer] as follows:
(1)Double tap [My Computer], tap [File], and then tap [New
Folder].
(2)Input “Options” for new folder name.
© 2002 Matsushita Electric Industrial Co., LTD. All Rights Reserved.
Printed in Japan
FJ0202-0
DFQX5299ZA
Panasonic Computer Solution Company,
50 Meadowlands Parkway, Panazip 2F-5,
Secaucus, NJ 07094
Panasonic Canada Inc.
5770 Ambler Drive Mississauga,
Ontario L4W 2T3
Specifications
Add the following information.
Wireless LAN IEEE 802.11b compliant, Frequency 2.4GHz band
Physical Dimensions 98 mm x 41 mm x 203 mm {3.9 " x 1.6 " x 8.0 "}
(W x H x D) (excluding the strap)
Weight Approx. 552 g {Approx. 1.2 lb.} (excluding the strap)
