OPERATING INSTRUCTIONS
Personal Computer
Model No. CF-S9 series
Introduction.................................................2
Read Me First ..............................................3
(Precautions)
Description of Parts .....................................11
First-time Operation .....................................13
On-screen Manual.......................................16
Handling and Maintenance.............................17
Reinstalling Software....................................20
Troubleshooting (Basic) ................................22
LIMITED USE LICENSE AGREEMENT..............25
Specifications ............................................27
LIMITED WARRANTY ..................................30
For further information about the com-
puter, you can refer to the on-screen
manual.
To access the on-screen manual
Îpage 16 “On-screen Manual”
For your technical support office, refer to
“LIMITED WARRANTY.”
2
Getting StartedUseful InformationTroubleshootingAppendix
Introduction
Thank you for purchasing this Panasonic product. For optimum performance and safety, please read these instructions
carefully.
Terms and illustrations in these instructions
zSome illustrations are simplified to help your understanding and may look different from the actual unit.
zIf you do not log on as an administrator, you cannot use some functions or cannot display some screens.
zRefer for the latest information about optional products to the catalogs, etc.
zIn these instructions, the names and terms are referred as follows.
• “Genuine Windows® 7 Professional (32-bit)” and “Genuine Windows® 7 Professional (64-bit)” as “Windows” or
“Windows 7”
• “WinDVD™ 8 (OEM Version)” as “WinDVD”
zThe display modes are referred as follows. ( ) indicates the terms in [Intel® Graphics and Media Control Panel]
screen. To display the screen, right-click the desktop and click [Graphics Properties].
• Internal LCD (Built-in Display): The computer’s display
• External display: External display
• Simultaneous display (Clone Displays):
The same screen is displayed on the internal LCD and the external display.
• Extended Desktop: The extended working area across the internal LCD and the external display.
Disclaimer
Computer specifications and manuals are subject to change without notice. Panasonic Corporation assumes no liability
for damage incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manu-
als.
Trademarks
Microsoft®, Windows® and the Windows logo are registered trademarks of Microsoft Corporation of the United States
and/or other countries.
Intel, Core and PROSet are either registered trademarks or trademarks of Intel Corporation.
SDHC Logo is a trademark of SD-3C, LLC.
Adobe, the Adobe logo and Adobe Reader are either registered trademarks or trademarks of Adobe Systems Incorpo-
rated in the United States and/or other countries.
Bluetooth™ is a trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to Panasonic Corporation.
Corel, InterVideo, WinDVD™, the InterVideo logo and the Corel logo are trademarks or registered trademarks of Corel
Corporation and/or its subsidiaries in Canada, the United States and/or other countries.
Sonic and Roxio are trademarks or registered trademarks of Sonic in the United States and/or other countries.
Computrace® is a registered trademark of Absolute® Software Corp.
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
Names of products, brands, etc., appearing in this manual are trademarks or registered trademarks of their respective
own companies.
: Conditions that may result in minor or moderate injury.
: Useful and helpful information.
Enter
: Press [Enter] key.
Fn
+
F5
: Press and hold [Fn] key, and then press [F5] key.
(Start) - [All Programs]: Click (Start), and then click [All Programs]. You may need to double-click in some
cases.
Î : Page in these Operating Instructions.
Î : Reference to the on-screen manuals of the computer.
CAUTION
NOTE
3
Getting StartedUseful InformationTroubleshootingAppendix
Read Me First
<Only for model with a “ ” mark on the bottom of the computer>
Federal Communications Commission Radio Fre-
quency Interference Statement
Note: This equipment has been tested and found to com-
ply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interfer-
ence in a residential installation. This equipment gener-
ates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
zReorient or relocate the receiving antenna.
zIncrease the separation between the equipment and
receiver.
zConnect the equipment into an outlet on a circuit differ-
ent from that to which the receiver is connected.
zConsult the Panasonic Service Center or an experi-
enced radio/TV technician for help.
Warning
To assure continued compliance, use only shielded inter-
face cables when connecting to a computer or peripheral.
Also, any changes or modifications not expressly
approved by the party responsible for compliance could
void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2)
This device must accept any interference received, includ-
ing interference that may cause undesired operation.
FCC RF Exposure Warning:
z
This equipment is provided with PC Card slot that could
be used with wireless transmitters, which will be specif-
ically recommended when they become available.
Other third-party wireless transmitters have not been
RF exposure evaluated for use with this computer and
may not comply with FCC RF exposure requirements.
<Only for model with wireless LAN/wireless WAN/
Bluetooth>
zThis equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.
zThis equipment has been approved for mobile opera-
tion, and unless otherwise advised in separate supple-
mental instructions for individual wireless
transmitter(s), requires minimum 20 cm spacing be
provided between antenna(s) and all person’s body
(excluding extremities of hands, wrist and feet) during
wireless modes of operation.
zThis equipment may not be co-located or operated
with any other antenna or transmitter.
25-M-6
<Only for model with wireless WAN>
zThis product is restricted to indoor use due to its oper-
ation in the 5.15 to 5.25 GHz frequency range.
FCC requires this product to be used indoors for the
frequency range 5.15 to 5.25 GHz to reduce the poten-
tial for harmful interference to co-channel Mobile Satel-
lite systems. High power radars are allocated as
primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85
GHz bands. These radar stations can cause interfer-
ence with and /or damage this product.
25-M-W-3
Responsible Party: Panasonic Corporation of North America
One Panasonic Way
Secaucus, NJ 07094
Tel No:1-800-LAPTOP5 (1-800-527-8675)
6-M-1
FCC Regulation Notice for modem
This equipment contains a FCC approved modem.
1. This equipment complies with CFR47 Part 68 rules.
On the computer is a label that contains, among other
information, the FCC registration number and ringer
equivalence number (REN) for this equipment. If
required, this information must be provided to the tele-
phone company.
2. An FCC compliant telephone cord and modular plug is
provided with this equipment. This equipment is
designed to be connected to the telephone network or
premises wiring using a compatible modular jack
which is Part 68 compliant. See Installation Instruc-
tions for details.
3.
The REN is used to determine the quantity of devices
which may be connected to the telephone line. Exces-
sive RENs on the telephone line may result in the
devices not ringing in response to an incoming call. In
most, but not all area, the sum of RENs should not
exceed five (5.0). To be certain of the number of
devices that may be connected to a line, as determined
by the total RENs, contact the local telephone company.
4. If your telephone equipment cause harm to the tele-
phone network, the telephone company will notify you
in advice that temporary discontinuance of service
may be required. But if advice notice isn’t practical, the
telephone company will notify the customer as soon as
possible. Also, you will be advised of your right to file a
complaint with the FCC if you believe it is necessary.
5. The telephone company may take changes in its facili-
ties, equipment, operations or procedures that could
affect the operation of the equipment. If this happens
the telephone company will provide advance notice in
order for you to make necessary modifications to
maintain uninterrupted service.
6. If trouble is experienced with this equipment, for repair
or warranty information, please contact Panasonic
Corporation of North America at DIAL TOLL FREE 1-
800-LAPTOP5 (1-800-527-8675). If the equipment is
causing harm to the telephone network, the telephone
company may request that you disconnect the equip-
ment until the problem is resolved.
7. There are no user serviceable parts contained in this
equipment.
Models for U.S.A.
4
Read Me First
Getting StartedUseful InformationTroubleshootingAppendix
8. This equipment may not be used on coin service pro-
vided by the telephone company. Connection to party
lines is subject to state tariffs.
9. The Telephone Consumer Protection Act of 1991
makes it unlawful for any person to use a computer or
other electronic device to send any message via a
telephone fax machine unless such message clearly
contains in a margin at the top or bottom of each trans-
mitted page or on the first page of the transmission,
the date and time it is sent and an identification of the
business or other entry, or other individual sending the
message and the telephone number of the sending
machine or such business, other entity, or individual. In
order to program this information into your fax soft-
ware, you should refer to the manual of the Fax soft-
ware being used.
10.According to the FCC’s electrical safety advisory, we
recommend that you may install an AC surge arrestor
in the AC outlet to which this equipment is connected.
Telephone companies report that electrical surges,
typically lightning transients, are very destructive to
customer terminal equipment connected to AC power
sources and that this is a major nationwide problem.
“Caution : To reduce the risk of fire, use only No.26 AWG or
larger (e.g., 24 AWG) UL listed or CSA certified telecommu-
nication line cord”
“ATTENTION : Pour reduire le risque d’fincendie, utiliser
uniquement des conducteurs de telecommunications 26
AWG ou de section superieure (p.ex. 24 AWG) UL
énumérés ou CSA certifié.”
16-M-1
<For USA-California Only>
<Only for model with wireless WAN>
The following safety precautions must be observed during all phases of the operation, usage, service or repair of any
Personal Computer or Handheld Computer incorporating Wireless WAN modem. Manufacturers of the cellular terminal
are advised to convey the following safety information to users and operating personnel and to incorporate these
guidelines into all manuals supplied with the product. Failure to comply with these precautions violates safety standards
of design, manufacture and intended use of the product. Panasonic assumes no liability for customer failure to comply
with these precautions.
When in a hospital or other health care facility, observe the restrictions on the use of mobiles. Switch
Personal Computer or Handheld Computer incorporating Wireless WAN modem off, if instructed to do so by
the guidelines posted in sensitive areas. Medical equipment may be sensitive to RF energy. The operation of
cardiac pacemakers, other implanted medical equipment and hearing aids can be affected by interference
from Personal Computer or Handheld Computer incorporating Wireless WAN modem placed close to the
device. If in doubt about potential danger, contact the physician or the manufacturer of the device to verify
that the equipment is properly shielded. Pacemaker patients are advised to keep their Personal Computer or
Handheld Computer incorporating Wireless WAN modem away from the pacemaker, while it is on.
Switch off Personal Computer or Handheld Computer incorporating Wireless WAN modem before boarding
an aircraft. Make sure it cannot be switched on inadvertently. The operation of wireless appliances in an
aircraft is forbidden to prevent interference with communications systems. Failure to observe these
instructions may lead to the suspension or denial of cellular services to the offender, legal action, or both.
For details on usage of this unit in aircrafts please consult and follow instruction provided by the airline.
Do not operate Personal Computer or Handheld Computer incorporating Wireless WAN modem in the
presence of flammable gases or fumes. Switch off the cellular terminal when you are near petrol stations, fuel
depots, chemical plants or where blasting operations are in progress. Operation of any electrical equipment
in potentially explosive atmospheres can constitute a safety hazard.
Your Personal Computer or Handheld Computer incorporating Wireless WAN modem receives and transmits
radio frequency energy while switched on. Remember that interference can occur if it is used close to TV
sets, radios, computers or inadequately shielded equipment. Follow any special regulations and always
switch off Personal Computer or Handheld Computer incorporating Wireless WAN modem wherever
forbidden, or when you suspect that it may cause interference or danger.
Road safety comes first! Do not use a Personal Computer or Handheld Computer incorporating Wireless
WAN modem while driving a vehicle. Do not place the computer with Wireless WAN modem in an area where
it could cause personal injury to the driver or passengers. It is recommended to stow the unit in the boot or
secure stowage area while driving. Do not place the computer with Wireless WAN modem in an area over an
air bag or in the vicinity where an air bag may deploy. Air bags inflate with great force and if the computer with
Wireless WAN modem is placed in the air bag deployment area may be propelled with great force and cause
serious injury to occupants of the vehicle.
This product contains a Coin Cell Lithium Battery
which contains Perchlorate Material- special han-
dling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate/
38-M-1
Safety Precautions
5
Getting StartedUseful InformationTroubleshootingAppendix
IMPORTANT!
Personal Computer or Handheld Computer incorporating Wireless WAN modem operate using radio signals
and cellular networks cannot be guaranteed to connect in all conditions. Therefore, you should never rely
solely upon any wireless device for essential communications, for example emergency calls.
Remember, in order to make or receive calls, Personal Computer or Handheld Computer incorporating
Wireless WAN modem must be switched on and in a coverage area with adequate cellular signal strength.
Some networks do not allow for emergency calls if certain network services or phone features are in use (e.g.
lock functions, fixed dialing etc.). You may need to deactivate those features before you can make an
emergency call.
Some networks require that a valid SIM card be properly inserted in Personal Computer or Handheld
Computer incorporating Wireless WAN modem.
27-1-2
<Only for model with modem>
Industry Canada (IC) Notice for modem
This equipment contains an Industry Canada approved
modem unit.
The Industry Canada label is affixed on the modem unit.
EQUIPMENT ATTACHEMENT LIMITATIONS
“NOTICE: The Industry Canada label identifies certified equip-
ment. This certification means that the equipment meets tele-
communications network protective, operational and safety
requirements as prescribed in the appropriate Terminal Equip-
ment Technical Requirements document(s). The Department
does not guarantee the equipment will operate to the user’s
satisfaction.
Before installing this equipment, users should ensure that it is
permissible to be connected to the facilities of the local tele-
communications company. The equipment must also be
installed using an acceptable method of connection. The cus-
tomer should be aware that compliance with the above condi-
tions may not prevent degradation of service in some
situations.
Repairs to certified equipment should be coordinated by a rep-
resentative designated by the supplier. Any repairs or alter-
ations made by the user to this equipment, or equipment
malfunctions, may give the telecommunications company
cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical
ground connections of the power utility, telephone lines and
internal metallic water pipe system, if present, are connected
together. This precaution may be particularly important in rural
areas. Caution: Users should not attempt to make such con-
nections themselves, but should contact the appropriate elec-
tric inspection authority, or electrician, as appropriate.”
“NOTICE: The Ringer Equivalence Number (REN) assigned to
each terminal device provides an indication of the maximum
number of terminals allowed to be connected to a telephone
interface. The termination on an interface may consist of any
combination of devices subject only to the requirement that the
sum of the Ringer Equivalence Numbers of all the devices
does not exceed 5.”
REN: See bottom of the computer
RESTRICTIONS CONCERNANT LE RACCORDEMENT
DE MATÉRIEL
“AVIS: L’étiquette d’Industrie Canada identifie le matériel
homologué. Cette étiquette certifie que le matériel est con-
forme aux normes de protection, d’exploitation et de sécurité
des réseaux de télécommunications, comme le prescrivent les
documents concernant les exigences techniques relatives au
matériel terminal. Le Ministère n’assure toutefois pas que le
matériel fonctionnera à la satisfaction de l’utilisateur.
Avant d’installer ce matériel, l’utilisateur doit s’assurer qu’il est
permis de le raccorder aux installations de l’entreprise locale
de télécommunication. Le matériel doit également être installé
en suivant une méthode acceptée de raccordement.
L’abonné ne doit pas oublier qu’il est possible que la confor-
mité aux conditions énoncées ci-dessus n’empêche pas la
dégradation du service dans certaines situations.
Les réparations de matériel homologué doivent être coordon-
nées par un représentant désigné par le fournisseur.
L’entreprise de télécommunications peut demander à l’utili-
sateur de débrancher un appareil à la suite de réparations ou
de modifications effectuées par l’utilisateur ou à cause de
mauvais fonctionnement.
Pour sa propre protection, l’utilisateur doit s’assurer que tous
les fils de mise à la terre de la source d’énergie électrique, des
lignes téléphoniques et des canalisations d’eau métalliques,
s’il y en a, sont raccordés ensemble. Cette précaution est par-
ticulièrement importante dans les régions rurales. Avertisse-
ment: L’utilisateur ne doit pas tenter de faire ces
raccordements lui-même; il doit avoir recours à un service
d’inspection des installations électriques, ou à un électricien,
selon le cas.”
“AVIS: L’indice d’équivalence de la sonnerie (IES) assigné à
chaque dispositif terminal indique le nombre maximal de ter-
minaux qui peuvent être raccordés à une interface. La termi-
naison d’une interface téléphonique peut consister en une
combinaison de quelques dispositifs, à la seule condition que
la somme d’indices d’équivalence de la sonnerie de touts les
dispositifs n’excède pas 5.”
IES: Voir sous le fond de l’ordinateur
17-Ca-1
Canadian ICES-003
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à la
norme NMB-003 du Canada.
7-M-2
<Only for model with wireless LAN/Bluetooth>
Industry Canada
This product complies with RSS-210 Industry Canada.
Operation is subject to the following two conditions;
(1) this device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation of
the device.
Models for Canada
6
Read Me First
Getting StartedUseful InformationTroubleshootingAppendix
<Ne s’applique qu’aux modeles avec technologie Bluetooth/
LAN sans fil>
Industrie Canada
Cet equipement est conforme a la norme CNR-210
d’Industrie Canada. Son fonctionnement est soumis aux
deux conditions suivantes :
(1) ce dispositif ne peut produire de brouillage, et
(2) ce dispositif doit accepter le brouillage, y compris le
brouillage pouvant entrainer le fonctionnement non
desire de l’appareil.
30-Ca-1-1
<Only for model with wireless LAN>
This product (local network devices) for the band 5150-
5250 MHz is only indoor usage to reduce potential for
harmful interference to co-channel Mobile Satellite sys-
tems.
High power radars are allocated as primary users (mean-
ing they have priority) of 5250-5350 MHz and 5650-
5850 MHz and these radars could cause interference
and/or damage to LELAN devices.
<Ne s’applique qu’aux modeles avec technologie LAN sans fil>
Cet appareil (pour reseaux locaux radioelectriques) dans
les bandes de frequences 5150-5250 MHz est reserve a
une utilization a l’interieur afi n de reduire le risque d’nter-
ference avec les systemes satellites mobiles bicanaux.
Les radars forte puissance sont designes comme etant
les premiers utilisateurs (c’est-a-dire qu’ils ont la priorite)
des bandes de frequences 5250-5350 MHz et 5650-
5850 MHz. Ces stations radars peuvent provoquer des
interferences et/ou des dommages a ce peripherique.
30-Ca-2-1
<Only for model with wireless LAN/wireless WAN/Bluetooth>
zThis equipment complies with Industry Canada radia-
tion exposure limits set forth for an uncontrolled envi-
ronment.
zThis equipment has been approved for mobile opera-
tion, and unless otherwise advised separate supple-
mental instructions for individual wireless
transmitter(s), requires minimum 20 cm spacing be
provided between antenna(s) and all person’s body
(excluding extremities of hands, wrist and feet) during
wireless modes of operation.
<Ne s’applique qu’aux modèles avec technologie Bluetooth/
LAN sans fil/WAN sans fil>
zCet équipement est conforme aux limites d’exposition
aux rayonnements d’Industrie Canada établies pour un
environnement non contrôlé.
zCet équipement a été approuvé à des fins d’opération
mobile et, sauf indication contraire, dans une notice
supplémentaire concernant les émetteurs sans fil indi-
viduels, doit être utilisé en veillant qu’il y ait une dis-
tance d’au moins 20 cm entre son(ses) antenne(s) et
le corps de l’utilisateur (sauf les extrémités : mains,
poignets et pieds) dans les modes d’opération sans fil.
<Only for model with a “CE” mark on the bottom of the computer>
Declaration of Conformity (DoC)
“Hereby, Panasonic declares that this Personal Computer is in compliance with the essential
requirements and other relevant provisions of the Directive 1999/5/EC.”
Hint:
If you want to get a copy of the original DoC of our above mentioned products, please contact our
web address: http://www.doc.panasonic.de
Authorised Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
Network connection of Wired Modem.
The terminal equipment is intended for connection to the following public network;
In all the countries of European Economical Area and Turkey;
- Public Switched Telephony Networks
Technical Features of Wired Modem.
The terminal equipment includes the following features;
- DTMF dialing
- Maximum bitrate receiving mode: 56 kbit/s
- Maximum bitrate sending mode: 33.6 kbit/s
18-E-1
<Only for model with modem>
When using your telephone equipment, basic safety precau-
tions should always be followed to reduce the risk of fire,
electric shock and injury to persons, including the following:
1. Do not use this product near water, for example, near
a bath tub, wash bowl, kitchen sink or laundry tub, in a
wet basement or near a swimming pool.
2. Avoid using a telephone (other than a cordless type)
during an electrical storm. There may be a remote risk
of electric shock from lightning.
3. Do not use the telephone to report a gas leak in the
vicinity of the leak.
4. Use only the power cord and batteries indicated in this
manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special
disposal instructions.
SAVE THESE INSTRUCTIONS
19-E-1
Models for Europe
Important Safety Instructions / Importantes Mesures De Sécurité
7
Getting StartedUseful InformationTroubleshootingAppendix
<Pour modèles avec modem uniquement>
Certaines mesures de sécurité doivent être prises pen-
dant l’utilisation de matérial téléphonique afin de réduire
les risques d’incendie, de choc électrique et de blessures.
En voici quelquesunes:
1. Ne pas utiliser l’appareil près de l’eau, p.ex., près d’une
baignoire, d’un lavabo, d’un évier de cuisine, d’un bac à
laver, dans un sous-sol humide ou près d’une piscine.
2. Éviter d’utiliser le téléphone (sauf s’il s’agit d’un appareil
sans fil) pendant un orage électrique. Ceci peut présenter
un risque de choc électrique causé par la foudre.
3. Ne pas utiliser l’appareil téléphonique pour signaler
une fuite de gaz s’il est situé près de la fuite.
4. Utiliser seulement le cordon d’alimentation et le type de
piles indiqués dans ce manual. Ne pas jeter les piles
dans le feu: elles peuvent exploser. Se conformer aux
règlements pertinents quant à l’élimination des piles.
CONSERVER CES INSTRUCTIONS
19-F-1
<Only for model with wireless LAN/wireless WAN/Bluetooth>
This product and your Health
This product, like other radio devices, emits radio fre-
quency electromagnetic energy. The level of energy emit-
ted by this product however is far much less than the
electromagnetic energy emitted by wireless devices like
for example mobile phones.
Because this product operates within the guidelines found
in radio frequency safety standards and recommendations,
we believe this product is safe for use by consumers. These
standards and recommendations reflect the consensus of
the scientific community and result from deliberations of
panels and committees of scientists who continually review
and interpret the extensive research literature.
In some situations or environments, the use of this prod-
uct may be restricted by the proprietor of the building or
responsible representatives of the organization. These sit-
uations may for example include:
zUsing this product on board of airplanes, or
zIn any other environment where the risk of interference
to other devices or services is perceived or identified
as harmful.
If you are uncertain of the policy that applies on the use of
wireless devices in a specific organization or environment
(e.g. airports), you are encouraged to ask for authoriza-
tion to use this product prior to turning on the product.
Regulatory Information
We are not responsible for any radio or television interfer-
ence caused by unauthorized modification of this product.
The correction of interference caused by such unautho-
rized modification will be the responsibility of the user. We
and its authorized resellers or distributors are not liable for
damage or violation of government regulations that may
arise from failing to comply with these guidelines.
26-M-1
<Uniquement les modèles avec réseau local sans fil,
r
é
seau large sans fil et/ou Bluetooth>
Ce produit et votre santé
Ce produit, comme tout autre appareil radio, émet de l’énergie
radioélectrique. Toutefois, la quantité d’énergie émise par ce
produit est beaucoup moins importante que l’énergie radioélec-
trique émise par des appareils sans fil tels que les téléphones
portables. L’utilisation de ce produit ne comporte aucun risque
pour le consommateur du fait que cet appareil opère dans les
limites des directives concernant les normes et les recomman-
dations de sécurité sur les fréquences radio. Ces normes et
recommandations reflètent le consensus de la communauté sci-
entifique et résultent de délibérations de jurys et comités de sci-
entifiques qui examinent et interprètent continuellement les
nouveautés de la vaste littérature sur les recherches effectuées.
Dans certaines situations ou environnements, l’utilisation de ce
produit peut être restreinte par le propriétaire du bâtiment ou par
les représentants responsables de l’organisation. Ces situations
peuvent être les suivantes par exemple :
zA bord d’un avion, ou
zDans tout autre environnement où les risques d’inter-
férence sur d’autres appareils ou services sont perçus
ou identifiables comme dangereux.
Si vous n’êtes pas sûr de la réglementation applicable à
l’utilisation d’appareils sans fil dans une organisation ou
un environnement spécifique, (par exemple dans un
aéroport) nous vous invitons à demander l’autorisation
d’utiliser ce produit avant sa mise en marche.
Informations concernant la réglementation
Nous déclinons toute responsabilité pour toute interférence
radio ou télévision causée par des modifications non
autorisées apportées à ce produit. La correction d’inter-
férences causées par de telles modifications non autorisées
sera la seule responsabilité de son utilisateur. Nousmêmes, les
revendeurs officiels et les distributeurs ne sommes pas respon-
sable de tout dégât ou de toute violation des règlements de
l’État pouvant découler du non-respect de ces directives.
26-F-1
Lithium Battery!
This computer contains a lithium battery to enable the
date, time, and other data to be stored. The battery should
only be exchanged by authorized service personnel.
Warning!
A risk of explosion from incorrect installation or misappli-
cation may possibly occur.
15-E-1
Pile au lithium!
Le micro-ordinateur renferme une pile au lithium qui per-
met de sauvegarder certaines données, notamment la
date et l’heure. La pile ne doit être remplacée que par un
technicien qualifié.
Danger !
Risque d’explosion en cas de non respect de cette mise
en garde!
15-F-1
Information to the User / Informations destinées aux utilisateurs
Lithium Battery / Pile au lithium
8
Read Me First
Getting StartedUseful InformationTroubleshootingAppendix
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
12-E-1
The following label is put on the bottom of the computer.
AVERTISSEMENT!
CET APPAREIL UTILISE UN LASER.
L’UTILISATION DE COMMANDES OU DE RÉGLAGES OU L’EXÉCU-
TION DE PROCÉDURES AUTRES QUE CELLES SPÉCIFIÉES ICI PEU-
VENT PROVOQUER UNE EXPOSITION À DES RADIATIONS
DANGEREUSES.
NE PAS OUVRIR LES COUVERCLES NI ESSAYER DE RÉPARER
SOIMÊME.
CONFIER TOUT TRAVAIL D’ENTRETIEN À UN PERSONNEL QUALIFIÉ.
12-F-1
L’étiquette suivante se trouve en-dessous de l’ordinateur.
These symbols are only valid in the European Union.
If you wish to discard this product, please contact your local authorities or dealer and ask
for the correct method of disposal.
53-M-1
If a Malfunction or Trouble Occurs, Immediately Stop
Use
If a Malfunction Occurs, Immediately Unplug the AC
Plug and the Battery Pack
• This product is damaged
• Foreign object inside this product
• Smoke emitted
• Unusual smell emitted
• Unusually hot
Continuing to use this product while any of the above con-
ditions are present may result in fire or electric shock.
• If a malfunction or trouble occurs, immediately turn the
power off and unplug the AC plug, and then remove the
battery pack. Then contact your technical support office
for repair.
Do Not Touch This Product and Cable When It Starts
Thundering
Electric shock may result.
Do Not Connect the AC Adaptor to a Power Source
Other Than a Standard Household AC Outlet
Otherwise, a fire due to overheating may result. Connect-
ing to a DC/AC converter (inverter) may damage the AC
adaptor. On an airplane, only connect the AC adaptor/
charger to an AC outlet specifically approved for such
use.
CD/DVD Drive Caution
Information on Disposal in other Countries outside the European Union
Precautions
THIS PRODUCT IS NOT INTENDED FOR USE AS,
OR AS PART OF, NUCLEAR EQUIPMENT/SYSTEMS,
AIR TRAFFIC CONTROL EQUIPMENT/SYSTEMS,
AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS*1,
MEDICAL DEVICES OR ACCESSORIES*2, LIFE
SUPPORT SYSTEMS OR OTHER EQUIPMENTS/
DEVICES/SYSTEMS THAT ARE INVOLVED WITH
ENSURING HUMAN LIFE OR SAFETY. PANASONIC
WILL NOT BE RESPONSIBLE FOR ANY LIABILITY
RESULTING FROM THE USE OF THIS PRODUCT
ARISING OUT OF THE FOREGOING USES.
*1 AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS
include Class2 Electrical Flight Bag (EFB) Systems
and Class1 EFB Systems when used during critical
phases of flight (e.g., during take-off and landing)
and/or mounted on to the aircraft. Class1 EFB Sys-
tems and 2 EFB Systems are defined by FAA: AC
(Advisory Circular) 120-76A or JAA: JAA TGL (Tem-
porary Guidance Leaflets) No.36.
*2 As defined by the European Medical Device Direc-
tive (MDD) 93/42/EEC.
Panasonic cannot guarantee any specifications, tech-
nologies, reliability, safety (e.g. Flammability/Smoke/
Toxicity/Radio Frequency Emission, etc) requirements
related to aviation standards and medical equipment
standards that differ from the specifications of our
COTS (Commercial-Off-The-Shelf) products.
9
Getting StartedUseful InformationTroubleshootingAppendix
Do Not Do Anything That May Damage the AC Cord,
the AC Plug, or the AC Adaptor
Do not damage or modify the cord, place it near hot tools,
bend, twist, or pull it forcefully, place heavy objects on it,
or bundle it tightly.
Continuing to use a damaged cord may result in fire, short
circuit, or electric shock.
Do Not Pull or Insert the AC Plug If Your Hands Are Wet
Electric shock may result.
Clean Dust and Other Debris of the AC Plug Regularly
If dust or other debris accumulates on the plug, humidity,
etc. may cause a defect in the insulation, which may result
in a fire.
• Pull the plug, and wipe it with a dry cloth.
Pull the plug if the computer is not being used for a long
period of time.
Insert the AC Plug Completely
If the plug is not inserted completely, fire due to overheat-
ing or electric shock may result.
• Do not use a damaged plug or loose AC outlet.
Do Not Place Containers of Liquid or Metal Objects on
Top of This Product
If water or other liquid spills, or if paper clips, coins, or for-
eign matter get inside this product, fire or electric shock
may result.
• If water spills in the keyboard, refer to page 19. If other
foreign matter has found its way inside, immediately turn
the power off and unplug the AC plug and remove the
battery pack. Then contact your technical support office.
Do Not Disassemble This Product
The high-voltage areas inside may give you an electric
shock, or foreign matter may enter and result in a fire.
Keep SD Memory Cards Away from Infants and Small
Children
Accidental swallowing will result in bodily injury.
• In the event of accidental swallowing, see a doctor
immediately.
Do Not Place This Product on Unstable Surfaces
If balance is lost, this product may fall over or drop, result-
ing in an injury.
Avoid Stacking
If balance is lost, this product may fall over or drop, result-
ing in an injury.
Do Not Keep This Product Wherever There is a Lot of
Water, Moisture, Steam, Dust, Oily Vapors, etc.
Otherwise, possibly resulting in fire or electric shock.
Do Not Leave This Product in High Temperature Envi-
ronment for a Long Period of Time
Leaving this product where it will be exposed to extremely
high temperatures such as near fire or in direct sunlight
may deform the cabinet and/or cause trouble in the inter-
nal parts. Continued use in such a resulting condition may
lead to short-circuiting or insulation defects, etc. which
may in turn lead to a fire or electric shocks.
Do Not Block the Ventilation Hole
Otherwise, heat will build up inside, possibly resulting in a fire.
Hold the Plug When Unplugging the AC Plug
Pulling on the cord may damage the cord, resulting in a
fire or electric shock.
Do Not Move This Product While the AC Plug Is Con-
nected
The AC cord may be damaged, resulting in fire or electric
shock.
• If the AC cord is damaged, unplug the AC plug immedi-
ately.
Use Only the Specified AC Adaptor With This Product
Using an AC adaptor other than the one supplied (sup-
plied with the unit or one sold separately as an accessory)
may result in a fire.
Do Not Subject the AC Adaptor to Any Strong Impact
Using the AC adaptor after a strong impact such as being
dropped may result in electric shock, short circuit, or fire.
Take a Break of 10-15 Minutes Every Hour
Using this product for long periods of time may have detri-
mental health effects on the eyes or hands.
Do Not Look into the CD/DVD Drive
Looking directly at the internal laser light source may
result in damage to eyesight.
Do Not Use Discs That Are Cracked or Deformed
Because the discs rotate at high speeds, damaged discs
may break apart causing injury.
• Discs that are not round and discs that have been
repaired using adhesives are similarly dangerous, and
so should not be used.
Do Not Turn the Volume Up to Loud When Using
Headphones
Listening at high volumes that overstimulate the ear for
long periods of time may result in loss of hearing.
<Only for model with modem>
Use the Modem with a Regular Telephone Line
Connection to an internal phone line (on-premise
switches) of a company or business office, etc. or to a dig-
ital public phone or use in a country or area not supported
by the computer may result in a fire or electric shocks.
Do Not Connect a Telephone Line, or a Network Cable
Other Than the One Specified, into the LAN Port
If the LAN port is connected to a network such as the
ones listed below, a fire or electric shock may result.
• Networks other than 1000BASE-T, 100BASE-TX or
10BASE-T
• Phone lines (IP phone (Internet Protocol Telephone),
Telephone lines, internal phone lines (on-premise
switches), digital public phones, etc.)
Do Not Use with Exposing the Skin to This Product
for a Long Period of Time
Using this product with exposing the skin to the heat
source of this product or AC adaptor for a long period of
time can cause a low-temperature burn.
zDo not place the computer near a television or radio
receiver.
zKeep the computer away from magnets. Data stored
on the hard disk may be lost.
zThis computer is not intended for the display of images
for use in medical diagnosis.
z
This computer is not intended for a use with connection of
medical equipment for the purpose of medical diagnosis.
zPanasonic shall not be liable for loss of data or other
incidental or consequential damages resulting from the
use of this product.
10
Read Me First
Getting StartedUseful InformationTroubleshootingAppendix
Do Not Use with Any Other Product
The battery pack is rechargeable and was intended for
the specified product. If it is used with a product other
than the one for which it was designed, electrolyte leak-
age, generation of heat, ignition or rupture may result.
Do Not Charge the Battery Using Methods Other Than
Those Specified
If the battery is not charged using one of the specified
methods, electrolyte leakage, generation of heat, ignition
or rupture may result.
Do Not Throw the Battery Pack into a Fire or Expose It
to Excessive Heat
Generation of heat, ignition or rupture may result.
Avoid Extreme Heat (Near the Fire, in Direct Sunlight,
for Example)
Electrolyte leakage, generation of heat, ignition or rupture
may result.
Do Not Insert Sharp Objects into the Battery Pack,
Expose It to Bumps or Shocks, Disassemble, or Modify It
Electrolyte leakage, generation of heat, ignition or rupture
may result.
• If this product is subjected to a strong impact, stop using
it immediately.
Do Not Short the Positive (+) and Negative (-) Contacts
Generation of heat, ignition or rupture may result.
• Do not place the battery pack together with articles such as
necklaces or hairpins when carrying or storing.
Do Not Use This Product with a Battery Pack Other
Than the One Specified
Use only the specified battery pack (CF-VZSU61U) with
your product. Use of battery packs other than those man-
ufactured and supplied by Panasonic may present a
safety hazard (generation of heat, ignition or rupture).
When the Battery Pack Has Deteriorated, Replace It
with a New One
Continued use of a damaged battery pack may result in
heat generation, ignition or battery rupture.
zDo not touch the terminals on the battery pack. The
battery pack may no longer function properly if the
contacts are dirty or damaged.
zDo not expose the battery pack to water, or allow it to
become wet.
zIf the battery pack will not be used for a long period of
time (a month or more), charge or discharge (use) the
battery pack until the remaining battery level becomes
30% to 40% and store it in a cool, dry place.
zThis computer prevents overcharging of the battery by
recharging only when the remaining power is less than
approx. 95% (when Economy Mode (ECO) is enabled:
75%) of capacity.
zThe battery pack is not charged when the computer is
first purchased. Be sure to charge it before using it for
the first time. When the AC adaptor is connected to
the computer, charging begins automatically.
zShould the battery leak and the fluid get into your
eyes, do not rub your eyes. Immediately flush your
eyes with clear water and see a doctor for medical
treatment as soon as possible.
NOTE
z
The battery pack may become warm during recharg-
ing or normal use. This is completely normal.
z
Recharging will not commence if internal temperature
of the battery pack is outside of the allowable temper-
ature range (0 °C to 55 °C {32 °F to 131 °F}). (
Î
Reference Manual “Battery Power”)
Once the allowable range requirement is satisfied,
charging begins automatically. Note that the recharg-
ing time varies based on the usage conditions.
(Recharging takes longer than usual when the tem-
perature is 10 °C {50 °F} or below.)
z
In high-temperature environments, the battery takes
longer to fully recharge. In low-temperature environ-
ments, the battery takes longer to fully recharge and
the operating time is shorter. Only use the computer
within the allowable temperature range.
z
The battery pack is a consumable item. If the amount
of time the computer can be run by using a particular
battery pack becomes dramatically shorter and
repeated recharging does not restore its performance,
the battery pack should be replaced with a new one.
z
When transporting a spare battery inside a package,
briefcase, etc., it is recommended that it be placed in
a plastic bag so that its contacts are protected.
z
Always power off the computer when it is not in use.
Leaving the computer on when the AC adaptor is not
connected will exhaust the remaining battery capacity.
Precautions (Battery Pack)
CAUTION:
Risk of Explosion if Battery is replaced by an Incorrect Type.
Dispose of Used Batteries According to the Instructions.
58-E-1
A lithium ion battery that is recy-
clable powers the product you
have purchased.
Please call 1-800-8-BATTERY
for information on how to recycle
this battery.
L’appareil que vous vous êtes
procuré est alimenté par une bat-
terie au lithium-ion.
Pour des renseignements sur le
recyclage de la batterie, veuillez
composer le 1-800-8-BATTERY.
48-M-1
11
Getting StartedUseful InformationTroubleshootingAppendix
Description of Parts
A :Speakers
B :Function Key
Î Reference Manual “Key Combinations”
C :Keyboard
D :LED Indicator
: Caps lock
: Numeric key (NumLk)
: Scroll lock (ScrLk)
: Hard disk and CD/DVD drive status
: SD/SDHC/SDXC Memory Card status
ECO
: Economy Mode (ECO) status
Î Reference Manual “Battery Power”
: Battery status
Î Reference Manual “Battery Power”
E : Power Switch
Îpage 14
Power Indicator
• Off: Power off/Hibernation
• Green: Power on
• Blinking green: Sleep/Standby
F : Wireless Switch
Switch the wireless devices to on (right side) or to off
(left side).
<Only for model with wireless LAN/wireless WAN/Bluetooth>
Î Reference Manual “Disabling/Enabling Wire-
less Communication”
G :Fingerprint Reader
<Only for model with Fingerprint Reader>
Î Reference Manual “Fingerprint Reader”
H :LCD
I : Security Lock
You can connect a Kensington cable. Refer to the instruc-
tion manual of the cable. The security lock and cable is a
theft prevention device. Panasonic Corporation will bear
no responsibility in the event of theft.
J : External Display Port
Connect the cable of external display.
K :USB Ports
Î Reference Manual “USB Devices”
L : PC Card Slot
Î Reference Manual “PC Card”
M :SD Memory Card Slot
Î Reference Manual “SD/SDHC Memory Card”*1
N :CD/DVD Drive Power/Open Switch
• Slide the switch to the right to open the disc cover.
• Slide the switch to the left to turn on/off the drive power.
CD/DVD Drive Indicator
• Off: Drive power is off or the disc cover is opened.
• Green: Drive power is on.
O :CD/DVD Drive
Î Reference Manual “CD/DVD Drive”
*1 SD/SDHC/SDXC Memory Cards are supported.
I
J
K
L
H
A
B
C
D
E
F
G
M
N
O
12
Description of Parts
Getting StartedUseful InformationTroubleshootingAppendix
B
A
G
H
K
J
I
C
D
E
F
A :Modem Port
<Only for model with modem>
Î Reference Manual “Modem”
B :LAN Port
Î Reference Manual “LAN”
C :DC-IN Jack
D :Ventilation Hole (Exhaust)
E :HDMI Port
Î Reference Manual “External Display”
F : USB Ports
Î Reference Manual “USB Devices”
G :Wireless LAN Antenna
<Only for model with wireless LAN>
Î Reference Manual “Wireless LAN”
H :Touch Pad
Î Reference Manual “Using the Touch Pad”
I : Bluetooth Antenna
<Only for model with Bluetooth>
Î Reference Manual “Bluetooth”
J : Microphone Jack
• When recording in stereo using a stereo microphone:
Click (Start) - [Control Panel] - [Hardware and Sound] - [Sound]-
[Recording] - [Microphone] - [Properties], and then remove a check
mark of [Enable audio enhancements] in [Advanced].
•
When using a monaural microphone with a 2-terminal plug:
Click (Start) - [Control Panel] - [Hardware and Sound] -
[Sound] - [Recording] - [Microphone] - [Properties], and then add
a check mark for [Enable audio enhancements] in [Advanced].
K :Headphone Jack
You can connect headphones or amplified speakers.
When they are connected, audio from the internal
speakers is not heard.
L : Battery Pack
Îpage 13
M :RAM Module Slot
Î Reference Manual “Expanding Memory”
N :Î Emergency Hole
Î Reference Manual “CD/DVD Drive”
O :Battery Latches
Îpage 13
N
L
M
O
SIM Card Slot
Wireless WAN Antenna
<Only for model with wireless WAN>
SIM Card
Bottom
SIM card slot is located in the battery
compartment on the bottom of the
computer. Remove the battery pack to
insert the SIM card.
Insert the SIM card into the
SIM Card Slot with the contact
side facing upward and with
the cut corner oriented as
shown in the illustration.
Do not insert the SIM card
upside down.
13
Getting StartedUseful InformationTroubleshootingAppendix
First-time Operation
Preparation
ACheck and identify the supplied accessories.
If you do not find the described accessories, contact your technical support office.
BRead the LIMITED USE LICENSE AGREEMENT before breaking the seal on the computer’s packaging
(Îpage 25).
Slide the battery pack in parallel with the arrow direction and attach it so that the
left and right dents (A) on the new battery pack match the projections (B) of the
computer.
In case that the dents does not match the projections of the computer, detach the
battery pack once, then slide it while pushing it lightly to avoid floating.
zTo remov e
Slide both the left and right latches
to the unlocked position, and push
out the battery pack in parallel with
the computer.
CAUTION
zMake sure the battery latches are securely locked. Otherwise the battery pack
may fall when you carry the computer.
zDo not touch the terminals of the battery pack and the computer. Doing so can
make the terminals dirty or damaged, and may cause malfunction of the battery
pack and the computer.
Hold the side of the computer with either of your hands and then hold and lift the
(A) part to open the display.
CAUTION
zDo not open the display wider than necessary (140° or more), and do not apply
excessive pressure to the LCD. Do not open or close the computer holding the
edge of the LCD segment.
• AC Adaptor . . . . 1
Model No: CF-AA6373A
• AC Cord . . . . . . .1 • Battery Pack. . . 1
Model No: CF-VZSU61U
• Operating Instructions (This book) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
• Product Recovery DVD-ROM Windows® 7 Professional (32-bit)*1 . . . . . . 1
• Product Recovery DVD-ROM Windows® 7 Professional (64-bit)*1 . . . . . . 1
*1 “This disc contains 32-bit software” or similar is printed on the label.
1 Insert the battery pack.
1
AA
B
2 Open the display.
2
A
14
First-time Operation
Getting StartedUseful InformationTroubleshootingAppendix
The battery charging starts automatically.
CAUTION
zDo not disconnect the AC adaptor and do not switch the wireless switch to
on until the first-time operation procedure is completed.
zWhen using the computer for the first time, do not connect any peripheral device
except the battery pack and AC adaptor.
zHandling the AC adaptor
• Problems such as sudden voltage drops may arise during periods of thunder
and lightning. Since this could adversely affect your computer, an uninterrupt-
ible power source (UPS) is highly recommended unless running from the bat-
tery pack alone.
Slide and hold the power switch for approximately one second until the
power indicator lights.
CAUTION
zDo not slide the power switch repeatedly.
zThe computer will forcibly be turned off if you slide and hold the power switch for
four seconds or longer.
zOnce you turn off the computer, wait for ten seconds or more before you turn on
the computer again.
z
Do not perform the following operation until the hard disk CD/DVD drive indicator
turns off.
• Connecting or disconnecting the AC adaptor
• Sliding the power switch or CD/DVD drive power/open switch
• Touching the keyboard or touch pad
• Closing the display
zDo not change the Setup Utility until completing step 5. If you do so, Windows
setup may not operate properly.
Follow the on-screen instructions.
zThe computer restarts several times. Do not touch the keyboard or touch pad,
and wait until the hard disk CD/DVD drive indicator has turned off.
zAfter the computer is turned on, the screen remains black or unchanged for a
while, but this is not a malfunction. Wait for a moment until the Windows
setup screen appears.
zDuring setup of Windows, use the touch pad and clicking to move the cursor
and to click an item.
zSetup of Windows will take approximately 20 minutes.
Go to the next step, confirming each message on the display.
z“Join a wireless network” screen may not appear.
You can set the Wireless Network after the setup of Windows is complete.
CAUTION
zDo not turn off the computer until completing the first-time operation procedure.
zDo not use the following words for user name: CON, PRN, AUX, CLOCK$, NUL,
COM1 to COM9, LPT1 to LPT9, @. In particular, if you create a user name
(account name) that includes the “@” mark, a password will be requested at the
log-on screen, even if no password has been set. If you try to log on without
en-tering a password, “The user name or password is incorrect.” may be dis-
played and you will not be able to log on to Windows (Îpage 23).
zYou can change the user name, password, image and security setting after
setup of Windows.
zRemember your password. If you forget the password, you cannot use the Win-
dows. Creating a password reset disk beforehand is recommended.
Î Reference Manual “CD/DVD Drive”
3 Connect your computer to a power outlet.
4 Turn on the computer.
5 Setup Windows.
6 Change the internal CD/DVD drive letter if necessary.
3
4
15
Getting StartedUseful InformationTroubleshootingAppendix
NOTE
zPC Information Viewer
This computer periodically records the management information of the hard disk, etc. The maximum data volume for
each record is 1024 bytes.
This information is only used for estimating the cause when the hard disk goes down by any possibility. They are
never sent to outside via network nor used for any other purpose except for the purpose described the above.
To disable the function, add the check mark for [Disable the automatic save function for management information
history] in [Hard Disk Status] of PC Information Viewer, and click [OK]. When you disable the function, information on
how to use the hard disk of PC Information Popup is not displayed.
(Î Reference Manual “Check the Computer’s Usage Status” and “PC Information Popup”)
zIf you hear the sounds from CD/DVD drive
In the following situations, the sounds from the CD/DVD drive can be heard.
• Immediately after the CD/DVD drive is turned on
• Just after turning on the computer with [Optical Drive Power] set to [On] in the Setup Utility
• When a CD or DVD is playing
The sounds you hear are normal operating sounds created by the motor in the CD/DVD drive operating; it is not a
malfunction.
zTo conserve power, the following power saving methods are set at the time of purchase. (When AC adaptor
is connected)
• The screen automatically turns off after 15 minutes of inactivity.
• The computer automatically enters sleep*1 after 20 minutes of inactivity.
*1 Refer to Reference Manual “Sleep/Standby or Hibernation Functions” about resuming from sleep/standby.
zEven when the AC adaptor is not connected to the computer, power is consumed (Max. 0.3 W) simply by
having the AC adaptor plugged into an AC outlet. (When using with 115 V AC)
zNote that the computer consumes electricity even when the computer power is off. If the battery pack is fully
charged, the battery will be fully discharged in the following period of time:
• In sleep: Approx. 7 days (If “Wake Up from wired LAN” is enabled: 4.5 days)*2
• In hibernation: Approx.40 days (If “Wake Up from wired LAN” is enabled: 9 days)*2
• When power is off: Approx. 40 days (If “Power On by wired LAN” is enabled: 9 days)
*2 Even if “Wake Up from wired LAN” is enabled, the battery will discharge at a slightly slower rate if the LAN cable is not con-
nected.
z
When the CD/DVD drive power is turned off, the message “The ‘
MATSHITA DVDXXXXXXXXX
’ device can now be
safely removed from ...” will appear, but the CD/DVD drive is an internal device, so it cannot be removed.
When Starting Up/Shutting Down
zDo not do the following
• Connecting or disconnecting the AC adaptor
• Sliding the power switch or CD/DVD drive power/open switch
• Touching the keyboard, touch pad or external mouse
• Closing the display
To change the partition structure
You can shrink a part of an existing partition to create unallocated disk space, from which you can create a new partition.
This computer has a single partition in the default setting.
AClick
(Start) and right-click [Computer], then click [Manage].
zA standard user needs to enter an administrator password.
BClick [Disk Management].
CRight-click the partition for Windows (“c” drive in the default setting), and click [Shrink Volume].
zThe partition size depends on the computer specifications.
zTo select [Reinstall to the first 2 partitions.] in reinstalling Windows 7 (Îpage 20), 30000 MB or more is nec-
essary for [Total size after shrink in MB].
DInput the size in [Enter the amount of space to shrink in MB] and click [Shrink].
zYou cannot input a larger number than the displayed size.
ERight-click [Unallocated] (the shrunk space in the step D) and click [New Simple Volume].
FFollow the on-screen instructions to make the settings, and click [Finish].
Wait until formatting is completed.
NOTE
zYou can create an additional partition using remaining unallocated space or newly creating unallocated space.
zTo delete a partition, right-click the partition and click [Delete Volume] in the step C.
16
Getting StartedUseful InformationTroubleshootingAppendix
On-screen Manual
You can access the following manuals on the computer screen after completing the “First-time Operation”.
When you access the on-screen manual for the first time, the License Agreement of the Adobe Reader may be dis-
played. Read it carefully and select [Accept] to proceed.
Reference Manual
The Reference Manual contains the practical information to help you fully enjoy the computer’s performance.
To access the Reference Manual:
Double-click on the desktop.
Alternatively click (Start) - [All Programs] - [Panasonic] - [On-Line Manuals] - [Reference Manual].
Important Tips
The Important Tips will provide you with the helpful information about the battery. Read to use the battery pack in the
optimum condition to obtain longer operation time.
To access the Important Tips:
Double-click on the desktop.
zAlternatively click (Start) - [All Programs] - [Panasonic] - [On-Line Manuals] - [Important Tips].
Hard Disk Handling
The Hard Disk Handling will provide you with the helpful information on how to use the hard disk.
To access the Hard Disk Handling:
Click (Start) - [All Programs] - [Panasonic] - [On-Line Manuals] - [Hard Disk Handling].
NOTE
zWhen Adobe Reader update notice is displayed, we recommend you follow the on-screen procedure to update.
See http://www.adobe.com/ for the latest version of Adobe Reader.
17
Getting StartedUseful InformationTroubleshootingAppendix
Handling and Maintenance
zPlace the computer on a flat stable surface. Do not place the computer upright. If the computer is exposed to an
extremely strong impact, it may become inoperable.
zTemperature: Operation: 5 °C to 35 °C {41 °F to 95 °F}
Storage: -20 °C to 60 °C {- 4 °F to 140 °F}
Humidity: Operation: 30% to 80% RH (No condensation)
Storage: 30% to 90% RH (No condensation)
Even within the above temperature/humidity ranges, using for a long time in an extreme environment will result in
the product deterioration and will shorten the product life.
• Be sure to use the computer in an environment with sufficient heat ventilation.
- Avoid using the computer on a highly heat retentive surfaces (e.g., rubber pads and blankets). If possible, use
the computer on surfaces that can dissipate heat, such as a steel desk.
- Do not cover the computer with towels, keyboard covers, etc., as this prevents heat dissipation.
- When using the computer, always keep the display open. (Note, however, that closing the display while the com-
puter is in use does not cause generation of heat, ignition, or other malfunctions.)
zDo not place the computer in the following areas, otherwise the computer may be damaged.
• Near electronic equipment. Image distortion or noise may occur.
• Near magnets or in magnetic fields.
• In extremely high or low temperature.
zAs the computer can become hot during operation, keep it away from items that are sensitive to heat.
This computer is designed to minimize shock to parts such as the hard disk drive, but no warranty is provided against
any trouble caused by shock. Be extremely careful when handling the computer.
zWhen carrying the computer:
• Turn off the computer.
• Remove all external devices, cables, cards and other protruding things.
• Remove a disc in the CD/DVD drive.
• Do not drop or hit the computer against solid objects.
• Do not leave the display open.
• Do not pick up or hold the computer by the display part.
• Do not put anything (e.g., a piece of paper) between the display and
keyboard.
zWhen flying on an airplane:
• Carry the computer with you, and never put it in checked baggage.
• Obey the airline's instructions when using the computer on the air-
plane.
zWhen carrying a spare battery, put it in a plastic bag to protect its ter-
minals.
z
This computer contains a magnet and magnetic products at the locations circled in the illus-
tration at right. Avoid leaving metallic object or magnetic media in contact with these areas.
zThe touch pad is designed to be used with a finger tip. Do not place any object on its sur-
face and do not press down strongly with sharp-pointed or hard objects that may leave
marks (e.g., nails, pencils and ball point pens).
zAvoid any harmful substances such as oil from getting into the touch pad. The cursor
may not work correctly.
z
If the computer is being carried in a soft bag with the battery pack removed, avoid undue pressure
on the body of the computer in a crowded place, etc., as this may result in damage to the LCD.
When the battery indicator does not light on
The AC adaptor’s protection function may be working when the battery indicator does not light on even if the AC adap-
tor and the battery pack are correctly connected with the computer.
zPull out the AC cord and wait for more than 1 minute to reconnect the AC cord.
zIf the problem persists, contact your technical support office.
If the computer becomes warm during usage
zCheck the following
• If you are not using a wireless LAN, turn the wireless LAN off.
• Use recommended RAM module products. Non-recommended RAM modules may not operate properly, and may
cause damage to your computer.
Operation Environment
Handling Cautions
NG NGOK
18
Handling and Maintenance
Getting StartedUseful InformationTroubleshootingAppendix
z
Click on the notification area and click . Then select [Panasonic Power management (Better Heat Dispersion)]
• When changing to [Panasonic Power management (Better Heat Dispersion)], the following settings will change.
- Change to [High Speed] from [Standard] in [Fan control mode].
Rotation of the cooling fan will become faster and the computer can be cooled down. Note that the battery oper-
ating time will be shorter.
- Switch the screen saver to [Prohibited].
- Other setting changes such as the lowering of the internal LCD brightness and disabling of Windows Aero will
take place.
• When you do not frequently use CPU or the rotation noise of the fan bothers you, set [Standard] or [Low Speed] in
[Fan control mode].
A
Click on the notification area and click .
BSelect [Standard] or [Low Speed] in [Fan control mode].
Î Reference Manual “Customizing the Power Setting”
When using peripheral devices
Follow these instructions and the Reference Manual to avoid any damage to the devices. Carefully read the instruction
manuals of the peripheral devices.
zUse the peripheral devices conforming to the computer’s specifications.
zConnect to the connectors in the correct direction.
zIf it is hard to insert, do not try forcibly but check the connector’s shape, direction, alignment of pins, etc.
zIf screws are included, fasten them securely.
zRemove the cables when you carry the computer. Do not pull the cables forcibly.
Preventing your computer from unauthorized use via wireless LAN
/wireless WAN
/
Bluetooth
<Only for model with wireless LAN/wireless WAN
/Bluetooth
>
zBefore using wireless LAN/wireless WAN
/Bluetooth
, make the appropriate security settings such as data encryption.
To clean the LCD panel and touch pad
Wipe lightly with a gauze or other dry, soft cloth.
To clean areas other than the LCD panel and touch pad
Wet a soft cloth with water or a diluted kitchen cleanser (neutral), wring the cloth out thoroughly, and wipe the dirty area
gently. Using a detergent other than a neutral kitchen cleanser (e.g., a weak alkali cleanser) may adversely affect
painted surfaces.
CAUTION
zDo not use benzene, thinner, or rubbing alcohol since it may adversely affect the surface causing discoloration, etc.
Do not use commercially-available household cleaners and cosmetics, as they may contain components harmful to
the surface.
zDo not apply water or detergent directly to the computer, since liquid may enter inside of the computer and cause
malfunction or damage.
When setting the screen resolution to a resolution below the LCD’s resolution, the images appearing on the screen will
be stretched. As a result, the characters displayed may appear blurred. This is normal, and not indicative of a malfunc-
tion.
To display large characters with no blurring
Try the following steps while keeping the LCD in its resolution.
zClick (Start) - [Control Panel] - [Appearance and Personalization] - [Display], select except for [Smaller - 100%]
and then click [Apply].
(This function will be enabled after log off the computer.)
zTo display enlarged font sizes in applications such as Internet Explorer:
Use the display enlargement function provided by the specific software application.
zTo display enlarged desktop icons, title bar and cursor or magnify the specific part of the screen:
Use “Icon Enlarger” or “Loupe Utility”.
Maintenance
When Using the Computer with a Reduced Screen Resolution
19
Getting StartedUseful InformationTroubleshootingAppendix
The keyboard on this computer incorporate a drain system (a moisture protection mechanism) that minimizes the
amount of liquid reaching the inside of the computer even if water is spilled on the keyboard.
Any water that comes in contact with the keyboard is drained off through holes in the bottom of the computer, so that vir-
tually no water is left inside the computer. However, this is not a guarantee against damage to the hard disk or other
internal parts, or against the loss or deletion of data.
The drain system is incorporated into only the keyboard. It does not apply to any other components.
zIf you spill water or any other liquid on the keyboard, even a small amount, be sure to perform the following steps.
Failure to perform these steps may result in damage to the computer. The drain system will not provide complete
protection against water entering the computer.
1 Immediately turn off the computer, and remove the AC adaptor.
2 Wipe any water droplets off of the top of the keyboard using a
soft, dry cloth.
3 Slowly lift up the computer, keeping it level,
and wipe any water coming out of the holes
on the bottom using a soft, dry cloth.
If the computer is tilted during this step, liquid may seep
inside the computer resulting in damage.
4 Keeping the computer level, move
the computer to a dry place.
If the computer is placed back on the wet
surface, water may seep inside the computer
from the bottom.
5 Insert the tip of a ball-point pen or other object into the emer-
gency hole on the bottom of the computer, and move it in the
direction of the arrow to open the disc cover.
The computer should be kept level, without tilting, while the disc cover is being
opened. Move the computer to the edge of the desk or table to perform this oper-
ation.
6 Check to see whether there is any water inside the CD/DVD drive.
If there is water inside, wipe it using a soft, dry cloth.
7 Remove the battery pack.
8 Be sure to contact your technical support office to have the computer checked for any
malfunctions.
If You Spill Water on the Keyboard
Note that repairs resulting from liquids being spilled on the computer are not free of charge, and not covered by war-
ranty.
NG
NG
20
Getting StartedUseful InformationTroubleshootingAppendix
Reinstalling Software
CAUTION
Do not delete the partition with boot files on the hard disk.
The disk space in the partition is not available to store data.
Preparation
zPrepare the Product Recovery DVD-ROM (included).
zRemove all peripherals.
zConnect the AC adaptor and do not remove it until installation is complete.
NOTE
zEven if reinstallation is performed, the number of times of DVD’s region code setting will not be reset.
1 Turn on the computer, and press
F2
or
Del
while [Panasonic] boot screen is displayed.
The Setup Utility starts up.
zIf the password is requested, enter the Supervisor Password.
2 Write down all of the contents of the Setup Utility and press
F9
.
At the confirmation message, select [Yes] and press
Enter
.
3 Select the [Main] menu, then select [Optical Drive Power] and press
Enter
.
4 Select [On] and press
Enter
.
5 Press
F10
.
At the confirmation message, select [Yes] and press
Enter
.
The computer will restart.
6 Press
F2
or
Del
while [Panasonic] boot screen is displayed.
The Setup Utility starts up.
zIf the password is requested, enter the Supervisor Password.
7 Set the Product Recovery DVD-ROM for Windows which you install into the CD/DVD
drive.
8 Select the [Exit] menu, then select [MATSHITA XXXXX] in [Boot Override].
9 Press
Enter
.
The computer will restart.
10 Click [Reinstall Windows] and click [Next].
The License Agreement screen appears.
11 Click [Yes, I agree to the provisions above and wish to continue!] and click [Next].
12 Select the settings and click [Next].
z[Reinstall Windows to the whole Hard Disk to factory default.].
You will have two partitions.
z[Reinstall to the first 2 partitions.]*1.
Select this option when the hard disk has already been divided into several partitions. For how to create a new
partition, refer to “To change the partition structure” (Îpage 15).
You can keep the partition structure.
*1 This does not appear if Windows cannot be reinstalled to the partition containing boot files and the area
usable by Windows.
13 At the confirmation message, click [YES].
Reinstallation starts automatically. (It will take approximately 25 - 35 minutes.)
zDo not interrupt reinstallation, for example by turning off the computer. Otherwise reinstallation may become
unavailable as Windows may not start up or the data may be corrupted.
14 Remove the Product Recovery DVD-ROM, and then click [OK] to turn off the computer.
Reinstalling software will return the computer to the default condition. When you reinstall the software, the hard disk
data will be erased.
Back up important data to other media or an external hard disk before reinstallation.
Area usable by Windows
Hard disk Partition with boot files
21
Getting StartedUseful InformationTroubleshootingAppendix
15 Turn on the computer.
zIf the password is requested, enter the Supervisor Password.
16 Perform the “First-time Operation” (Î page 14).
17 Start the Setup Utility and change the settings as necessary.
18 Perform Windows Update.
Confirming kind of Operating System
The kind of the system can be confirmed, click (Start) - [Computer], and then click [System Properties].
22
Getting StartedUseful InformationTroubleshootingAppendix
Troubleshooting (Basic)
Follow the instructions below when a problem has occurred. There is also an advanced troubleshooting guide in the
“Reference Manual”. For a software problem, refer to the software’s instruction manual. If the problem persists, contact
your technical support office. You can also check the computer’s status in the PC Information Viewer (Î Reference
Manual “Check the Computer’s Usage Status”).
Starting Up and Sleep and Hibernation Mode
The computer does not
power on/
The power indicator or bat-
tery indicator is not lit.
zConnect the AC adaptor.
zInsert a fully charged battery.
zRemove the battery pack and the AC adaptor, then connect them again.
z
When the CPU temperature is high, the computer may not start up to prevent overheating of
the CPU. Wait until the computer cools down, and then turn the power on again. If the com-
puter does not power on even after cooling down, contact your technical support office.
z
Pull out the AC cord and wait for more than 1 minute to reconnect the AC cord.
Windows does not start up. zRemove all peripheral devices (e.g. USB memory).
zIf the power indicator is lit, slide the power switch for four seconds or longer to turn off,
then turn on again.
zUsing the following procedure, start up in Safe Mode, and check the error details.
ATurn on the computer, and when the [Panasonic] boot screen disappears (after enter-
ing the password*1 if one is set) hold down
F8
.
BRelease your finger when [Windows Advanced Options Menu] is displayed, and with
Ï or Ð, select [Safe Mode], then press
Enter
.
Follow the on-screen instructions.
*1 Supervisor Password or User Password set with the Setup Utility
zPress
F9
in the Setup Utility to return the Setup Utility settings (excluding the pass-
words) to the default values. Start the Setup Utility and make the settings again.
After adding or changing the
RAM module, the power is
turned on but nothing is dis-
played on the screen.
zTurn off the computer and remove the RAM module, then confirm whether the RAM
module has compliant to specification. When the RAM module has conformed to specifi-
cation, install it again.
Cannot boot from internal
CD/DVD drive.
zMake sure that the bootable CD/DVD is set properly.
zStart the Setup Utility, and confirm the following settings.
• [Optical Drive] is set to [Enabled] in the [Advanced] menu.
• [Optical Drive Power] is set to [On] in the [Main] menu.
• [Boot Option #1] is set to [CD/DVD Drive] in the [Boot] menu.
zWhen an external CD/DVD drive is connected, you cannot boot from the internal CD/
DVD drive.
You have forgotten the
password.
zSupervisor Password or User Password: Contact your technical support office.
zAdministrator password:
• If you have another account with Administrator authority, log-on with it, then delete the
password for the problem account.
• If you have a password reset disk, click [Reset password] displayed after the password
input error, then follow the on-screen instructions to set a new password.
• If you cannot do either of the above, you will need to reinstall (Îpage 20) and setup
Windows.
“Remove disks or other
media. Press any key to
restart” or a similar mes-
sage appears.
zA floppy disk is in the floppy disk drive and it does not contain system startup informa-
tion. Remove the floppy disk and press any key.
z
This message may appear with some devices connected to
the USB port
. Remove the
device or set [Legacy USB Support] to [Disabled] in the [Advanced] menu of the Setup Utility.
z
If the problem persists after removing the disk, it may be a hard disk failure. Perform the rein-
stallation and return the hard disk to its condition at the time of purchase.
(Î
page 20
)
If the
problem persists even after the reinstallation, contact
your technical support office
.
[Executing Battery Recali-
bration] screen appears.
zThe Battery Recalibration was canceled before Windows was shut down last time. To
start up Windows, turn off the computer by the power switch, and then turn on.
The computer will not auto-
matically enter sleep or
hibernation.
zIf you connect to a network using wireless LAN function, perform access point settings.
(Î Reference Manual “Wireless LAN”)
zIf you do not use wireless LAN function, turn off wireless LAN function. (Î Refer-
ence Manual “Disabling/Enabling Wireless Communication”)
zMake sure that you are not using any software that regularly accesses the hard disk.
23
Getting StartedUseful InformationTroubleshootingAppendix
[Enter Password] does not
appear when resuming from
sleep hibernation.
zSelect [Enabled] in [Password On Resume] in the [Security] menu of the Setup Utility
(Î Reference Manual “Setup Utility”).
zThe Windows password can be used instead of the password set in the Setup Utility.
AClick
(Start) - [Control Panel] - [User Accounts and Family Safety] - [Add or
remove user accounts] and select the account, and set the password.
BClick
(Start) - [Control Panel] - [System and Security] - [Power Options] - [Require
a password on wakeup] and a check mark for [Require a password].
When logging on (e.g.,
resuming the computer),
audio is distorted.
zPerform the following steps to change the audio settings to prevent audio output.
ARight-click the desktop and click [Personalize] - [Sounds].
BRemove the check mark from [Play Windows Startup sound], and click [OK].
Cannot resume. zOne of the following operations may have been carried out.
• In sleep mode, the AC adaptor or battery pack was disconnected, or a peripheral was
connected or disconnected.
• The power switch was slid for four seconds or longer to forcibly turn off the computer.
Slide the power switch to turn on the computer. Data not saved will be lost.
Other startup problems. zCheck to see if there was a disk error.
ARemove all peripheral devices including an external display.
BClick
(Start) - [Computer] and right-click [Local Disk (C:)], and click [Properties].
CClick [Tools] - [Check Now…].
• A standard user needs to enter an administrator password.
DSelect the option in [Check disk options] and click [Start].
EClick [Schedule disk check] and restart the computer.
zStart the computer in Safe Mode and check the error details. (
Î
page 22 “Windows
does not start up”.)
Shutting Down
Windows does not shut
down.
zRemove all peripheral devices.
zWait one or two minutes. It is not a malfunction.
Password
Even after entering the pass-
word, a message appears
requesting to type it again.
zIf lights up, press
NumLk
to disable the ten-key mode, and then input.
zIf lights up, press
Caps Lock
to disable the Caps Lock mode, and then input.
Cannot log on to Windows.
(“The user name or password
is incorrect.” is displayed.)
zThe user name (account name) includes an “@” mark.
If another user account exists:
Log on to Windows using another user account, and delete the account that
includes “@”. Then create a new account.
If no other account exists:
You need to reinstall Windows (Îpage 20).
Display
When the screen becomes
black for a moment.
zWhen you set [Intel(R) video driver power saving function] - [Intel(R) Display Power Sav-
ing Technology] of Power Plan Extension Utility to [Enabled], if you do the following oper-
ations, the screen becomes black for a moment, but this is not a malfunction. You can
use it.
• Adjust the brightness of the screen with
Fn
+
F1
/
Fn
+
F2
.
• Remove and insert the AC adaptor.
While you are using motion video playback software, benchmark software for graphic, if error
screen is displayed or application software does not function normally, set [Intel(R) video
driver power saving function] - [Intel(R) Display Power Saving Technology] to [Disabled].
No display. zThe external display is selected. Press
Fn
+
F3
(or
+
P
) to switch the display. Wait
until the display has been switched completely before pressing
Fn
+
F3
(or
+
P
)
again.
zThe display is turned off by the power-saving function. To resume, do not press the direct
selection keys, but press any other key like
Ctrl
.
zThe computer entered sleep or hibernation by the power-saving function. To resume,
slide the power switch.
zThe screen may become darker. Press
Fn
+
F2
to make the screen brighter.
Starting Up and Sleep and Hibernation Mode
24
Troubleshooting (Basic)
Getting StartedUseful InformationTroubleshootingAppendix
The screen is disordered. zChanging the number of display colors and resolution may affect the screen. Restart the
computer.
zThe refresh rate of the internal LCD may be 40 hertz. Change the refresh rate of the
internal LCD.
ARight-click on the desktop, and click [Graphics Properties].
BClick [General Settings].
CIf [Refresh Rate] of the Notebook is [40 Hz], change to [60 Hz] and click [OK].
The external display does
not work normally.
zIf the external display does not support the power saving function, it may not work nor-
mally when the computer enters the power saving mode. Turn off the external display.
Battery
The battery indicator is
lights red.
zThe battery level is very low (the charge is approx. 9% or less).
zConnect the AC adaptor. You can use the computer when the indicator light is orange. If
you do not have an AC adaptor, save your data and power off your computer. After
replacing the battery pack with a fully charged one, turn your computer on again.
The battery indicator is
blinking.
zIf blinking red:
Quickly save your data and power off your computer. Remove the battery pack and dis-
connect the AC adaptor, then connect them again. If the problem persists, contact your
technical support office. The battery pack or charging circuit may be defective.
zIf blinking orange:
• Battery cannot be recharged temporarily because the internal temperature of the bat-
tery pack is outside the acceptable temperature range for recharging. Your computer
can be used normally in this state. Once the range requirement is satisfied, charging
begins automatically.
• Software applications and peripheral devices (USB devices, etc.) are consuming too
much power. Exit the software applications currently running, and remove all peripher-
als. Once the range requirement is satisfied, charging begins automatically.
The battery indicator is
flashing.
zThe battery is recharging.
If [Battery Charging Indicator] in [Main] menu of the Setup Utility is set to [Flashing], the
indicator will alternately become lighter and darker.
Touch Pad
The cursor does not work. zWhen using the external mouse, connect it correctly.
zRestart the computer by using the keyboard.
Press
and press Î two times, and press Ï to select [Restart] and press
Enter
.
z
If the computer does not respond to keyboard commands, read “No response” (
Îbelow
)
.
Cannot input using the
touch pad.
zSet [Touch Pad] to [Enabled] in the [Main] menu of the Setup Utility.
z
The drivers for some mice may disable the touch pad. Check your mouse’s operating instructions.
Reference Manual
The Reference Manual is not
displayed.
zInstall Adobe Reader.
ALog on to Windows as an administrator.
BClick (Start) and input “c:\util\reader\Setup.exe” in [Search programs and files]
then press
Enter
.
CUpdate Adobe Reader to its latest version.
DIf your computer is connected to the internet, start up Adobe Reader and click [Help] -
[Check for Updates…].
Others
No response. zPress
Ctrl
+
Shift
+
Esc
to open Task Manager and close the software application that
is not responding.
zAn input screen (e.g., password input screen at startup) may be hidden behind another
window. Press
Alt
+
Tab
to check.
zSlide the power switch for four seconds or longer to shut down the computer, and then
slide the power switch to turn it on. If the application program does not work normally,
uninstall and reinstall the program. To uninstall, click (Start) - [Control Panel] -
[Programs] - [Uninstall a program].
The computer does not rec-
ognize the CD/DVD drive.
zRestart the computer.
After the computer restarts, it may recognize a CD/DVD drive.
Display
25
Getting StartedUseful InformationTroubleshootingAppendix
LIMITED USE LICENSE AGREEMENT
THE SOFTWARE PROGRAM(S) (“PROGRAMS”) FURNISHED WITH THIS PANASONIC PRODUCT (“PRODUCT”)
ARE LICENSED ONLY TO THE END-USER (“YOU”), AND MAY BE USED BY YOU ONLY IN ACCORDANCE WITH
THE LICENSE TERMS DESCRIBED BELOW. YOUR USE OF THE PROGRAMS SHALL BE CONCLUSIVELY
DEEMED TO CONSTITUTE YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE.
Panasonic Corporation has developed or otherwise obtained the Programs and hereby licenses their use to you. You
assume sole responsibility for the selection of the Product (including the associated Programs) to achieve your intended
results, and for the installation, use and results obtained therefrom.
LICENSE
A. Panasonic Corporation hereby grants you a personal, non-transferable and non-exclusive right and license to use
the Programs in accordance with the terms and conditions stated in this Agreement. You acknowledge that you are
receiving only a LIMITED LICENSE TO USE the Programs and related documentation and that you shall obtain no
title, ownership nor any other rights in or to the Programs and related documentation nor in or to the algorithms, con-
cepts, designs and ideas represented by or incorporated in the Programs and related documentation, all of which
title, ownership and rights shall remain with Panasonic Corporation or its suppliers.
B. You may use the Programs only on the single Product which was accompanied by the Programs.
C. You and your employees and agents are required to protect the confidentiality of the Programs. You may not distrib-
ute or otherwise make the Programs or related documentation available to any third party, by time-sharing or other-
wise, without the prior written consent of Panasonic Corporation.
D. You may not copy or reproduce, or permit to be copied or reproduced, the Programs or related documentation for
any purpose, except that you may make one (1) copy of the Programs for backup purposes only in support of your
use of the Programs on the single Product which was accompanied by the Programs. You shall not modify, or
attempt to modify, the Programs.
E. You may transfer the Programs and license them to another party only in connection with your transfer of the single
Product which was accompanied by the Programs to such other party. At the time of such a transfer, you must also
transfer all copies, whether in printed or machine readable form, of every Program, and the related documentation,
to the same party or destroy any such copies not so transferred.
F. You may not remove any copyright, trademark or other notice or product identification from the Programs and you
must reproduce and include any such notice or product identification on any copy of any Program.
YOU MAY NOT REVERSE ASSEMBLE, REVERSE COMPILE, OR MECHANICALLY OR ELECTRONICALLY TRACE
THE PROGRAMS, OR ANY COPY THEREOF, IN WHOLE OR IN PART.
YOU MAY NOT USE, COPY, MODIFY, ALTER, OR TRANSFER THE PROGRAMS OR ANY COPY THEREOF, IN
WHOLE OR IN PART, EXCEPT AS EXPRESSLY PROVIDED IN THE LICENSE.
IF YOU TRANSFER POSSESSION OF ANY COPY OF ANY PROGRAM TO ANOTHER PARTY, EXCEPT AS PER-
MITTED IN PARAGRAPH E ABOVE, YOUR LICENSE IS AUTOMATICALLY TERMINATED.
TERM
This license is effective only for so long as you own or lease the Product, unless earlier terminated. You may terminate
this license at any time by destroying, at your expense, the Programs and related documentation together with all cop-
ies thereof in any form. This license will also terminate effective immediately upon occurrence of the conditions thereof
set forth elsewhere in this Agreement, or if you fail to comply with any term or condition contained herein. Upon any
such termination, you agree to destroy, at your expense, the Programs and related documentation together with all cop-
ies thereof in any form.
YOU ACKNOWLEDGE THAT YOU HAVE READ THIS AGREEMENT, UNDERSTAND IT AND AGREE TO BE BOUND
BY ITS TERMS AND CONDITIONS. YOU FURTHER AGREE THAT IT IS THE COMPLETE AND EXCLUSIVE STATE-
MENT OF THE AGREEMENT BETWEEN US, WHICH SUPERSEDES ANY PROPOSAL OR PRIOR AGREEMENT,
ORAL OR WRITTEN, AND ANY OTHER COMMUNICATIONS BETWEEN US, RELATING TO THE SUBJECT MAT-
TER OF THIS AGREEMENT.
GOVERNMENT RESTRICTED RIGHTS.
The Software is provided with “RESTRICTED RIGHTS.” Use duplication or disclosure by the government is subject to
restrictions as set forth in FAR52.227-14 and DFAR252. 227-7013 et seq. or their successors.
Use of the Software by the government constitutes acknowledgement of Intel’s proprietary rights therein.
Contractor or Manufacturer is Intel Corporation, 2200 Mission College Blvd., Santa Clara, CA 95052.
26
Getting StartedUseful InformationTroubleshootingAppendix
Contrat de licence d’usage limité
Le(s) logiciel(s) (les “Logiciels”) fournis avec ce produit Panasonic (le “Produit”) sont exclusivement concédés en
licence à l’utilisateur ultime (“vous”), et ils ne peuvent être utilisés que conformément aux clauses contractuelles
cidessous. En utilisant les logiciels, vous vous engagez de manière définitive à respecter les termes, clauses et
conditions des présentes.
Panasonic Corporation a mis au point ou obtenu les Logiciels et vous en concède l’utilisation par les présentes. Vous
assumez l’entière responsabilité du choix de ce Produit (y compris des Logiciels associés) pour obtenir les résultats
escomptés, ainsi que de l’installation, de l’utilisation et des résultats obtenus.
Licence
A. Panasonic Corporation vous octroie par les présentes le droit et la licence personnels, non cessibles et non
exclusifs d’utiliser les Logiciels conformément aux termes, clauses et conditions de ce contrat. Vous reconnaissez
ne recevoir qu’un droit limité d’utiliser les Logiciels et la documentation les accompagnant et vous vous engagez à
n’obtenir aucun droit de titre, propriété ni aucun autre droit vis-à-vis des Logiciels et de la documentation les
accompagnant ni vis-à-vis des algorithmes, concepts, dessins, configurations et idées représentés par ou
incorporés dans les Logiciels et la documentation les accompagnant, dont les titres, propriété et droits resteront tous
à Panasonic Corporation ou à leurs propriétaires.
B. Vous ne pouvez utiliser les Logiciels que sur le Produit unique qui est accompagné par les Logiciels.
C. Vous et vos employés ou agents êtes requis de protéger la confidentialité des Logiciels. Vous ne pouvez ni
distribuer ni mettre les Logiciels et la documentation les accompagnant à la disposition d’un tiers, par partage de
temps ou de quelque autre manière que ce soit, sans l’autorisation écrite préalable de Panasonic Corporation.
D. Vous ne pouvez ni copier ni reproduire ni permettre la copie ni la reproduction des Logiciels ni de la documentation
les accompagnant pour quelque fin que ce soit, à l’exception d’une (1) copie des Logiciels à des fins de sauvegarde
uniquement pour soutenir votre utilisation des Logiciels sur le Produit unique qui est accompagné par les Logiciels.
Vous ne pouvez ni modifier ni tenter de modifier les Logiciels.
E. Vous ne pouvez céder les Logiciels et en octroyer la licence à une autre partie qu’en rapport avec votre cession du
Produit unique qui est accompagné par les Logiciels à cette autre partie. Au moment de cette cession, vous devez
céder également toutes les copies, que ce soit sous forme imprimée ou lisible par la machine, de tous les Logiciels
ainsi que de la documentation les accompagnant, à la même partie ou détruire les copies non cédées.
F. Vous ne pouvez retirer aucune marque de droits d’auteur, marque de commerce ou autre ni aucune identification de
produit des Logiciels et vous devez reproduire et inclure toutes ces notices ou identifications de produit sur toutes
les copies des Logiciels.
Vous ne pouvez assembler en sens inverse, compiler en sens inverse ni retracer les Logiciels ni aucune de leurs
copies, de façon électronique ou mécanique, en tout ou en partie.
Vous ne pouvez utiliser, copier, modifier, altérer ni céder les Logiciels ni aucune de leurs copies, en tout ou en partie, à
l’exception de ce qui est expressément stipulé dans ce contrat.
Si vous cédez la possession de toute copie ou de tout Logiciel à une autre partie, à l’exception de ce qui est autorisé au
paragraphe E ci-dessus, votre licence est automatiquement résiliée.
Termes, clauses et conditions
Cette licence n’est effective que pour la durée de possession ou de crédit-bail du Produit, à moins d’une résiliation
antérieure. Vous pouvez résilier cette licence à tout moment en détruisant, à vos frais, les Logiciels et la documentation
les accompagnant avec toutes leurs copies, sous quelque forme que ce soit. Cette licence sera également résiliée,
avec application immédiate, si les conditions de résiliation définies ailleurs dans ce contrat se sont réalisées ou si vous
ne respectez pas les termes, clauses et conditions qui y sont contenues. Au moment de la résiliation, vous acceptez de
détruire, à vos frais, les Logiciels et la documentation les accompagnant avec toutes leurs copies, sous quelque forme
que ce soit.
Vous reconnaissez avoir lu ce contrat, en avoir compris toute la substance et avoir accepté de respecter ses termes,
clauses et conditions. Vous reconnaissez en outre qu’ils sont la description complète et exclusive du contrat conclu
entre nous, contrat qui remplace et annule toute proposition ou contrat précédent, écrit ou oral, et toute autre
communication entre nous, relativement à l’objet du présent contrat.
27
Getting StartedUseful InformationTroubleshootingAppendix
Specifications
To check CPU speed, memory size and the hard disk drive (HDD) size:
Start the Setup Utility (Î Reference Manual “Setup Utility”) and select [Information] menu.
[Processor Speed]: CPU speed, [Memory Size]: Memory size, [Hard Disk]: Hard disk drive size
Main Specifications
Model No. CF-S9KWAZZDM CF-S9KWNZZDM
CPU Intel® vPro™ Technology *1
Intel® Core™ i5-520M vPro™ processor (2.40 GHz with Turbo Boost up to 2.93 GHz,
Intel® Smart Cache 3 MB*2)
Chip Set Mobile Intel® QM57 Express Chipset
Main Memory*2*3 2 GB, DDR3 SDRAM (6 GB Max.)
Video Memory*2*4
UMA 763
MB
Max. (When Memory is 2
GB
) / UMA 1563
MB
Max. (When Memory is
4or6
GB
)
Video Controller Intel® HD Graphics (Built-in CPU)
Hard Disk Drive*5 320 GB
Approx. 300
MB
is used as a partition with recovery tools. (Users cannot use this partition.)
CD/DVD Drive DVD MULTI Drive built-in, Buffer underrun error prevention function: Supported
Continuous Data Trans-
fer Speed*6*7 Reading*8 zDVD-RAM*10: 5X (Max.)(4.7 GB)*5 zDVD-R*11: 8X (Max.) zDVD-RW: 8X (Max.)
z
DVD-R DL: 8X (Max.)
z
DVD-ROM: 8X (Max.)
z
CD-ROM: 24X (Max.)
z
CD-R: 24X
(Max.)
z
CD-RW: 24X (Max.)
z
+R: 8X (Max.)
z
+R DL: 8X (Max.)
z
+RW: 8X (Max.)
z
High Speed +RW: 8X(Max.)
z
High-Speed CD-RW: 24X(Max.)
z
Ultra-Speed CD-RW:
24X(Max.)
Writing*9 zDVD-RAM*10: 2X/3X/3-5X (4.7 GB)*5 zDVD-R: 2X/3.3-4X/3.3-6X/3.3-8X zDVD-RW:
1X/2X/2-4X/2-6X z+R: 2.4X/3.3-4X/3.3-6X/3.3-8X z+RW: 2.4X/2.4-4X zHigh Speed
+RW: 3.3X/3.3-6X zCD-R: 8X/8-12X/8-16X/10.8-24X zCD-RW: 4X zHigh-Speed CD-
RW: 4X/8X/10X
Supported Discs/For-
mat*7 Reading zDVD-ROM (Single Layer, Dual Layer) zDVD-Video zDVD-R*11 (1.4 GB, 2.8 GB,
4.7 GB)*5 zDVD-RW (Ver.1.1/1.2 1.4 GB, 2.8 GB, 4.7 GB, 9.4 GB)*5 zDVD-R DL
(8.5 GB)*5 zDVD-RAM*10 (1.4 GB, 2.8 GB, 4.7 GB, 9.4 GB)*5 z+R (4.7 GB)*5 z+R DL
(8.5 GB)*5 z+RW (4.7 GB)*5 zCD-Audio zCD-ROM (XA compatible) zCD-R zPhoto
CD (multiple session compatible) zVideo CD zCD EXTRA zCD-RW zCD-TEXT
zHigh Speed +RW (4.7 GB)*5 zHigh-Speed CD-RW zUltra-Speed CD-RW
Writing zDVD-RAM*10 (1.4 GB, 2.8 GB, 4.7 GB, 9.4 GB)*5 zDVD-R (1.4 GB, 2.8 GB, 4.7 GB for
General)*5 zDVD-RW (Ver.1.1/1.2 1.4 GB, 2.8 GB, 4.7 GB, 9.4 GB)*5 z+R (4.7 GB)*5
z+RW (4.7 GB)*5
z
CD-R
z
CD-RW
zHigh Speed +RW (4.7 GB)*5 zHigh-Speed CD-RW
Display Method 12.1 WXGA type (TFT) (1280 × 800 dots)
Internal LCD 65,536/16,777,216 colors (1280 × 800 dots)*12
External Display*13 65,536/16,777,216 colors (800 × 600 dots/1024 × 768 dots/1280 × 720 dots/1280 ×
768 dots/1280 × 1024 dots/1400 × 1050 dots/1680 × 1050 dots/1600 × 1200 dots/
1920 × 1080 dots/1920 × 1200 dots)
Simultaneous Display on LCD + Exter-
nal Display*13 65,536/16,777,216 colors (800 × 600 dots/1024 × 768 dots/1280 × 720 dots/1280 ×
768 dots/1280 x 800 dots)*12
Wireless LAN Intel® Centrino® Advanced-N 6200*14 (Îpage 28)
Bluetooth*15 Îpage 28
LAN*16 IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T
Modem*17 Data: 56 kbps (V.92) FAX: 14.4 kbps
Fingerprint Reader*18 -Array Size: 192 × 4 pixels, Image Size:
192 × 512 pixels, Image Resolution: 508
DPI
Sound WAVE and MIDI playback, Intel® High Definition Audio subsystem support, Stereo
Speakers (built in)
Security Chip TPM (TCG V1.2 compliant)*19
Card Slots PC Card Slot × 1, Type I or Type II, Allowable current 3.3 V: 400 mA, 5 V: 400 mA
SD Memory Card Slot*20 × 1
RAM Module Slot × 1, DDR3 SDRAM, 204-pin, 1.5 V, SO-DIMM, PC3-6400 Compliant
28
Specifications
Getting StartedUseful InformationTroubleshootingAppendix
Interface USB Ports × 3 (USB2.0 × 3)*21 / Modem Port (RJ-11) / LAN Port (RJ-45)*16 /
External Display Port: Mini Dsub 15-pin female / HDMI Port (Type A)*22 / Microphone
Jack*23: Miniature jack, 3.5 DIA / Headphone Jack: Miniature jack, 3.5 DIA
Keyboard/Pointing Device 85 keys/Touch Pad
Power Supply AC adaptor or Battery pack
AC Adaptor*24 Input: 100 V - 240 V AC, 50 Hz/60 Hz
Output: 16 V DC, 3.75 A
Battery Pack Li-ion 7.2 V, 12.4 Ah (typ.), 11.6 Ah (min.)
Operating Time*25 Approx. 11 hours (Economy Mode (ECO) - Disable)
Charging Time*26 Approx. 3.5 hours (Power off)/Approx. 6.5 hours (Power on)
Power Consumption*27 Approx. 30 W*28 / Approx. 60 W (maximum when non-recharging in the ON state)
Physical Dimensions (W × D × H)*29 282.8 mm × 209.6 mm × 23.4 mm (at the front)/38.7 mm (at the rear) {11.1 " × 8.3 " ×
0.9 " / 1.5 "} (excluding protrusion)
Weight*30 Approx. 1.36 kg {3.0 lb.} Approx. 1.365 kg {3.0 lb.}
Environment Operation Temperature 5°C to 35°C {41°F to 95°F}
Humidity 30% to 80% RH (No condensation)
Storage Temperature -20°C to 60°C {-4°F to 140°F}
Humidity 30% to 90% RH (No condensation)
OS*31
Genuine Windows
®
7 Professional (32-bit)
Pre-installed Software*31
Adobe Reader
*32
/ Loupe Utility / Touch Pad Utility / PC Information Viewer / PC
Information Popup / Hotkey Settings / Wireless Switch Utility / Intel
®
Rapid Storage
Technology / Bluetooth™ Stack for Windows by TOSHIBA
*15
/ Battery Recalibration
Utility / Intel
®
PROSet/Wireless Software / WinDVD™ 8 (OEM Version) / Roxio Creator
LJB / Optical Disc Drive Letter-Setting Utility / Microsoft
®
Internet Explorer 8.0 / DirectX
11
*33
/ Microsoft
®
Windows
®
Media Player 12 / Microsoft
®
.NET Framework 3.5.1 /
Infineon TPM Professional Package V3.6
*19*32 / Power Plan Extension Utility
-
Protector Suite*18*32
Aptio Setup Utility / Hard Disk Data Erase Utility*34 / PC-Diagnostic Utility
Wireless LAN <Only for model with wireless LAN>
Data Transfer Rates IEEE802.11a : 54/48/36/24/18/12/9/6 Mbps (automatically switched)*35
IEEE802.11b : 11/5.5/2/1 Mbps (automatically switched)*35
IEEE802.11g : 54/48/36/24/18/12/9/6 Mbps (automatically switched)*35
IEEE802.11n : (HT20) GI = 400 ns:144/130/115/86/72/65/57/43/39/28/21/14/7 GI = 800ns:130/117/
104/78/65/58/52/39/26/19/13/6 Mbps (automatically switched)*35
(HT40) GI = 400ns:300/270/240/180/150/135/120/90/60/30/15 GI = 800ns:270/243/
216/162/135/121/108/81/54/40/27/13 Mbps (automatically switched)*35
Standard Supported IEEE802.11a / IEEE802.11b / IEEE802.11g / IEEE802.11n
Transmission Method OFDM system, DS-SS system
Wireless Channels Used IEEE802.11a : Channels 36/40/44/48/52/56/60/64/100/104/108/112/116/132/136/140/149/153/157/
161/165
IEEE802.11b/IEEE802.11g : Channels 1 to 11
IEEE802.11n : Channels 1-11/36/40/44/48/52/56/60/64/100/104/108/112/116/132/136/140/149/153/
157/161/165
RF Frequency Band IEEE802.11a : 5.18 GHz - 5.32 GHz, 5.5 GHz - 5.7 GHz, 5.745 GHz - 5.825 GHz
IEEE802.11b/IEEE802.11g : 2.412 GHz - 2.462 GHz
IEEE802.11n : 2.412 GHz - 2.462 GHz, 5.18 GHz - 5.32 GHz, 5.5 GHz - 5.7 GHz, 5.745 GHz -
5.825 GHz
Bluetooth™ <Only for model with Bluetooth>
Bluetooth Version 2.1 + EDR
Transmission Method FHSS system
Wireless Channels Used Channels 1 to 79
RF Frequency Band 2.402 GHz - 2.48 GHz
Model No. CF-S9KWAZZDM CF-S9KWNZZDM
29
Getting StartedUseful InformationTroubleshootingAppendix
*1 The Intel® Active Management Technology (Intel® AMT)
function must be set before use.
*2 1 MB = 1,048,576 bytes / 1 GB = 1,073,741,824 bytes
*3 You can physically expand the memory up to 4 GB, but the
total amount of usable memory available will be less depend-
ing on the actual system configuration.
*4 A segment of the main memory is allotted automatically
depending on the computer’s operating status. The size of
the Video Memory cannot be set by the user.
The size of Video memory is allotted depending on the oper-
ating system.
For Windows 7 (64-bit), UMA 1696 MB Max. (When Memory
is 4 or 6 GB)
*5 1 GB = 1,000,000,000 bytes. Your operating system or some
application software will report as fewer GB.
*6 Data transfer speeds indicate values measured by
Panasonic Corporation. The data transfer rate of DVD per 1X
speed is 1,350 KB/s. The data transfer rate of CD per 1X
speed is 150 KB/s.
*7 Performance of CD-R, CD-RW, DVD-RAM, DVD-R, DVD-R
DL, DVD-RW, +R, +R DL, and +RW cannot be guaranteed
depending on writing status and recording format. Also,
some data cannot be played back depending on the disc,
settings, and environment being used.
Does not support writing to DVD-R DL/+R DL (dual layer
discs) and Ultra-Speed CD-RW. Does not support 2.6 GB
DVD-RAM.
*8
If an unbalanced disc (e.g., a disc with which the balance has been
displaced from the center) is inserted, the speed may become
slower if there are large vibrations while the disc is rotating.
*9
Depending on the disc, the writing speed may become slower.
*10
Only non-cartridge type or removable cartridge type can be used.
*11 DVD-R is compatible with 4.7 GB (for General) playback.
DVD-R (for Authoring) playback is compatible with discs
recorded using Disc-at-Once recording.
*12 A 16,777,216 color display is achieved by using the dithering
function.
*13 Display may be impossible using some connected external
displays.
*14 Only for model with wireless LAN.
*15 Only for model with Bluetooth.
*16 Some devices cannot be used depending on the port type.
*17 Only for model with modem.
*18 Only for model with Fingerprint Reader.
*19
Only for model that supports TPM.
For information on TPM, click (Start) and input
“c:\util\drivers\tpm\README.pdf” in [Search programs and
files] and press
Enter
, and refer to the Installation Manual
of “Trusted Platform Module (TPM)”.
*20 This slot is not compatible with the UHS-I high speed trans-
fer. Operation has been tested and confirmed using Pana-
sonic SD Memory Card with a capacity of up to 2 GB,
Panasonic SDHC Memory Card with a capacity of up to
32 GB, and Panasonic SDXC Memory Card with a capacity
of up to 64 GB. Operation on other SD equipment is not
guaranteed.
*21
Does not guarantee operation of all USB-compatible peripherals.
*22
Does not guarantee operation of all HDMI-compatible peripherals.
*23
Use a condenser-stereo microphone.
*24 <Only for North America>
The AC adaptor is compatible with power sources up to
240 V AC adaptor. This computer is supplied with a 125 V
AC compatible AC cord.
20-M-1-1
*25
Measured using MobileMark™ 2007 (LCD brightness :
60 cd/m2).
Varies depending on the usage conditions, or when an
optional device is attached.
When Economy Mode (ECO) is enabled, the operating time
becomes approximately 20
%
shorter than when it is disabled.
*26 When Economy Mode (ECO) is enabled, the charging time
becomes approx. 5.0 hours (Power on/off). Varies depending
on the usage conditions, CPU speed, etc.
It may take a long time to charge a fully discharged battery.
*27 Approx. 0.7 W when the battery pack is fully charged (or not
being charged) and the computer is off.
<When using with 115 V AC>
Even when the AC adaptor is not connected to the computer,
power is consumed (Max. 0.3 W) simply by having the AC
adaptor plugged into an AC outlet.
*28 Rated power consumption.
23-E-1
*29 41.4 mm at thickest point (excluding protrusions).
*30 Average value. May differ depending on models.
*31 Operations of this computer are not guaranteed except for
the pre-installed OS and the installed OS by using the Prod-
uct Recovery DVD-ROM (included).
Some parts of the software in the Product Recovery DVD-
ROM may not be installed depending on a model.
*32 Must be installed before use.
*33 The graphics accelerator of this computer supports up to
DirectX 10.
*34 The Product Recovery DVD-ROM is required.
*35 These are speeds specified in IEEE802.11a+b+g+n stan-
dards. Actual speeds may differ.
30
Getting StartedUseful InformationTroubleshootingAppendix
LIMITED WARRANTY
Panasonic Solutions Company - Worldwide Product Warranties
Section 1 - Limited Warranty - Hardware
Panasonic Solutions Company (referred to as “Panasonic”) will repair the products listed below with new or rebuilt parts, free of
charge in the U.S.A. or other Panasonic approved location for the period specified below from the date of original purchase in the
event of a defect in materials or workmanship. These warranties are extended solely to the original purchaser. A purchase receipt or
other proof of date of original purchase will be required before warranty performance is rendered.
• Laptop Computers - 3 Years
• PDRC - LCD and Keyboard Assemblies - 3 Years
• MDWD - Mobile Computer and Wireless Display Assemblies (CF-07/CF-08) - 3 Years
• Ultra-Mobile PC (CF-U1/CF-H1) - 3 Years
• Hand-held Computers (P1/P2) - 1 Year
• Arbitrator Video Camera - 1 Year
• Arbitrator Recorder Unit - 1 Year
• Arbitrator Remote Control Panel - 1 Year
• Arbitrator Wireless Receiver Unit - 1 Year
• Arbitrator P2 Card(s) (All Sizes) - 1 Year
• Arbitrator Wireless Microphone(s) / Transmitter - 90 Days
• Arbitrator System Component Interconnect Cables - 90 Days
Battery Warranty
The battery supplied with the product is covered under the warranty for one (1) year from date of purchase, except as excluded in
Section 3. Batteries purchased separately are covered under the warranty for one (1) year from the date of purchase. A battery fur-
nished under the warranty is covered for the remaining period of the one year warranty on the original or purchased battery.
Wireless Module Warranty
Panasonic approved wireless modems installed in Panasonic brand computers and integrated by Panasonic or an Authorized Pana-
sonic Wireless Integrator are covered under the warranty for the remaining warranty period of the computer in which the modem is
installed. For computers with less than three (3) months remaining on the unit warranty, the wireless modem will be covered for a
period of three (3) months from the date of installation of the modem, covering only modem replacement or modem installation
related issues.
All modems must be approved by the wireless carrier prior to use. Any use or attempted use of a wireless modem not approved and
activated by the carrier for use on their network is strictly prohibited and is not sanctioned or warranted by Panasonic and may result
in legal action. In addition, all modems must be approved by Panasonic as compatible with the computer hardware before installation
or use.
Panasonic’s sole responsibility for the warranty or technical support of the software required to install or operate the modem is
defined in Section 2 (Limited Software Warranty). Any attempted software installation by anyone other than a Panasonic Authorized
Wireless Integrator is not covered under warranty and may result in service charges to re-image or replace the hard drive.
Installation or attempted installation by any party other than Panasonic or an Authorized Panasonic Wireless Integrator is strictly not
covered under the warranty and may void the computer warranty if damage results.
Options and Accessories warranties
The below listed Panasonic brand or supplied options and accessories are covered under this limited warranty for the period speci-
fied from the date of purchase or as specifically stated:
• AC Adaptor / Power Cord - 3 Years
• Memory Card (Panasonic Brand) - 3 Years
• Car Mount Docking Station PCB or Complete Vehicle Docking Station - 3 Years
• Port Replicator / I-O Box / Device Cradle (like CF-08) - 3 Years
• Antenna Pass-through Cable - 3 Years
• Backlit or Full-sized keyboard - 3 Years or assumes warranty of the unit in which it is installed
• Integrated Panasonic supplied options and kits including, but not limited to Wireless WAN, Media Bay Drives (Floppy, CD/DVD,
Combo), Camera, GPS, Bluetooth, Smartcard Reader, Magnetic Card Reader, Barcode Scanner and Fingerprint readers - 3
Years or assumes warranty period of the unit in which it is installed provided the integration was performed by Panasonic or an
Authorized Options Integrator.
• Hard Drive (separately purchased) - 1 Year
• External USB Drives (CD / DVD / Floppy / Hard Drive) - 1 Year
• Optional Battery - 1 Year
• Battery Charger / Multi-Bay Battery Charger - 1 Year
• Digitizer pen or stylus - 90 Days (physical damage excluded)
For U.S.A.
31
Getting StartedUseful InformationTroubleshootingAppendix
Section 2 - Limited Warranty - Software
Panasonic Solutions Company (referred to as “Panasonic”) warrants to you only that the disk(s) or other media on which the Pro-
grams are furnished will be free from defects in material and workmanship under normal use for a period of sixty (60) days from the
date of delivery thereof to you, as evidenced by your purchase receipt.
This is the only warranty Panasonic makes to you. Panasonic does not warrant that the functions contained in the Programs will meet
your requirements or that the operation of the Programs will be uninterrupted or error free. Panasonic shall have no obligation for any
defects in the disk(s) or other media on which the Programs are furnished resulting from your storage thereof, or for defects that have
been caused by operation of the disk(s) or other media
Panasonic’s entire liability and your exclusive remedy under this warranty shall be limited to the replacement, in the United States or
other Panasonic designated location, of any defective disk or other media which is returned to Panasonic’s Authorized Service Cen-
ter, together with a copy of the purchase receipt, within the aforesaid warranty period. The customer is responsible for ensuring that
all data is backed up and made secure during normal use and before sending a unit for service.
Section 3 - Limited Warranty Exclusions
Specifically excluded from the warranty are:
• All consumable items; such as screen protection films, logo badges, labels, cleaning cloths, carry cases, manuals, cables,
straps, belts, holsters, tethers, and harnesses and any other options and accessories not listed above or covered under a sep-
arate warranty.
• Failures related to the product operating system, hard drive image, software setup, software program, virus, other program(s)
or file(s) on the hard drive or in any computer memory location.
• Failures due to BIOS settings or changes, as well as any cosmetic or physical damage to the unit.
• Any unit or device with a missing or altered model number or serial number label
• Damage which occurs in shipment
• Failures which are caused by products not supplied by Panasonic
• Failures which result from alteration, accident, misuse, introduction of liquid or other foreign matter into the unit, abuse, neglect,
installation, maladjustment of consumer controls, improper maintenance or modification, use not in accordance with product
use instructions
• Failures due to service by anyone other than a Panasonic Authorized Service Provider
• Failures caused by improper integration by any company other than Panasonic or a Panasonic Authorized Integrator.
• Damage, failure, or loss due to the unit being stolen, lost, misplaced, or used by anyone other than the original purchaser
• Damage that is attributable to acts of God
This warranty only covers failures due to defects in materials or workmanship which occur during normal use.
THIS PRODUCT IS NOT INTENDED FOR USE AS, OR AS PART OF, NUCLEAR EQUIPMENT/SYSTEMS, AIR TRAFFIC CON-
TROL EQUIPMENT/SYSTEMS, OR AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS*1. PANASONIC WILL NOT BE RESPONSIBLE
FOR ANY LIABILITY RESULTING FROM THE USE OF THIS PRODUCT ARISING OUT OF THE FOREGOING USES.
*1 AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include Class2 Electrical Flight Bag (EFB) Systems and Class1 EFB Systems
when used during critical phases of flight (e.g., during take-off and landing) and/or mounted on to the aircraft. Class1 EFB Sys-
tems and 2 EFB Systems are defined by FAA: AC (Advisory Circular) 120-76A or JAA: JAA TGL (Temporary Guidance Leaflets)
No.36
Other Limits and Exclusions: There are no other express warranties except as listed above.
PANASONIC SHALL NOT BE LIABLE FOR LOSS OF DATA OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. ALL EXPRESS
AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE. Some states do not allow the exclu-
sion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above limitations
or exclusions may not apply to you.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
For technical support or to arrange for service on your Panasonic computer product, call our toll-free hotline at 1-800-LAPTOP5.
DIAL TOLL FREE: 1-800-LAPTOP5 (1-800-527-8675)
Web Site : www.panasonic.com/toughbook
32
LIMITED WARRANTY
Getting StartedUseful InformationTroubleshootingAppendix
PANASONIC COMPUTER AND PERIPHERALS LIMITED WARRANTY
Coverage – Panasonic Canada Inc. (“PCI”) warrants to you, the first end user customer, this computer product (excluding software
media), when purchased from PCI or from a PCI authorized reseller, to be free from defects in materials and workmanship under nor-
mal use, subject to the terms set forth below, during the period of warranty coverage specified.
Remedy – In the event of a warranty claim, contact PCI’s representatives within the applicable warranty period, identifying the nature
of the defect claimed, at 1-800-668-8386 between 9:00 A.M. and 5:00 P.M., Eastern Time Zone, Mon. - Fri. (excluding holidays) for
instructions on how to obtain service. A purchase receipt or other proof of date of original purchase is required before warranty ser-
vice is performed. Defective parts covered by this Limited Warranty will be repaired or replaced with new or comparable rebuilt parts
on an exchange basis. Warranty replacement or repair is subject to the terms of this Limited Warranty for the balance of the original
period of warranty coverage.
No Coverage – This Limited Warranty does not cover products purchased outside Canada. Neither does it cover damage to, failure
of, or defects in a product or accessory through mishandling, improper installation, abnormal use, misuse, neglect, accident, intro-
duction of liquid or other foreign matter into the product, alteration or servicing by anyone not authorized by PCI, or act of God.
THIS PRODUCT IS NOT INTENDED FOR USE AS, OR AS PART OF, NUCLEAR EQUIPMENT/SYSTEMS, AIR TRAFFIC CON-
TROL EQUIPMENT/SYSTEMS, OR AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS*2. PANASONIC WILL NOT BE RESPONSIBLE
FOR ANY LIABILITY RESULTING FROM THE USE OF THIS PRODUCT ARISING OUT OF THE FOREGOING USES.
*2 AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS include Class2 Electrical Flight Bag (EFB) Systems and Class1 EFB Systems
when used during critical phases of flight (e.g., during take-off and landing) and/or mounted on to the aircraft. Class1 EFB Sys-
tems and 2 EFB Systems are defined by FAA: AC (Advisory Circular) 120-76A or JAA: JAA TGL (Temporary Guidance Leaflets)
No.36
SOFTWARE MEDIA LIMITED WARRANTY
Coverage – PCI warrants to you, the first end user customer, that the disk(s) or other media on which software program(s) is/are
supplied will be free from defects in materials and workmanship under normal use in Canada for a period of sixty (60) days from date
of receipt as evidenced by your purchase receipt for your Panasonic Computer product.
THIS IS THE ONLY WARRANTY THAT PCI MAKES RESPECTING THE SOFTWARE MEDIA. PCI does not warrant the software.
Please refer to the software licensor’s written warranty (accompanying the copy of the software) for any software warranty claim.
Claim Procedure – In the event of a defect in material or workmanship in the media during the sixty (60) days warranty period, and
you return it, transportation costs prepaid, to Panasonic Canada Inc., Computer Products Marketing, 5770 Ambler Drive, Missis-
sauga, Ontario L4W 2T3, within the warranty period, together with a copy of your purchase receipt, and an explanation of the sus-
pected defect, PCI will replace in Canada the defective disk(s) or other media.
Remedy – PCI’s entire liability, and your only remedy for any breach of this software media warranty is limited to replacement of the
media only. It does not cover any other damages, including, but not limited to, loss of use or profit loss, or special, indirect or conse-
quential damages, or other claims, whether or not of similar character.
No Coverage – This limited warranty does not apply if the disk(s) or other media has been used in other than a Panasonic product,
or in environmental conditions other than those specified by PCI or the manufacturer, or if subjected to misuse, neglect, mishandling,
modification or attempted modification of the program, or if damaged by accident or act of God. PCI is not responsible for damage to
or loss of any program, data or removable storage media. GENERAL
NO OTHER WARRANTIES - PCI DISCLAIMS ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH
RESPECT TO THE SOFTWARE, SOFTWARE MEDIA, COMPUTER PRODUCT, OPTIONS AND ACCESSORIES.
NO LIABILITY FOR CONSEQUENTIAL DAMAGES - IN NO EVENT SHALL PCI BE LIABLE FOR ANY SPECIAL, INDIRECT OR
CONSEQUENTIAL DAMAGES ARISING FROM ANY BREACH OF THE LIMITED WARRANTIES SET OUT IN THIS DOCUMENT,
OR FROM THE USE OF THE COMPUTER PRODUCT, INCLUDING, WITHOUT LIMITATION, LOSS OF DATA, BUSINESS,
PROFIT OR GOODWILL.
IN ANY EVENT, PCI’S MAXIMUM LIABILITY FOR ANY BREACH SHALL NOT EXCEED THE AMOUNT ACTUALLY PAID BY YOU
FOR THE COMPUTER PRODUCT.
NO ACTION, REGARDLESS OF ITS BASIS, MAY BE BEGUN AGAINST PCI MORE THAN TWO (2) YEARS AFTER THE CAUSE
OF ACTION AROSE.
Statutory Warranties – Some jurisdictions do not allow these limitations or exclusions, so they may not apply to you.
For Canada
Scope of Coverage Period of Coverage Type of Failure Coverage
• Laptop Computers (except Battery) and AC Adaptor
• Factory/PCI installed options including Wireless WAN, GPS,
Bluetooth, Finger print reader, Backlit keyboard, Memory Card
and Media Bay Drives (Floppy, CD/DVD)
• Ultra-Mobile PC (CF-U1/CF-H1)
• Mobile Wireless Display oPDRC - LCD and Keyboard Assem-
blies
• Port Replicator
Three (3) Years from Date of
Original End User Customer
Purchase
Defective Materials or Workman-
ship
• Hand-held Computers
•Battery
• Battery charger
• Auto Adaptor
• External USB Drives
One (1) Year from Date of
Original End User Customer
Purchase
Defective Materials or Workman-
ship
• Digitizer pen or stylus Ninety (90) Days from Date of
Original End User Customer
Purchase
Defective Materials or Workman-
ship
• All consumable items including protection film, cleaning cloth,
carry case, tether and harness No Coverage
IF YOU SHIP THE PRODUCT FOR WARRANTY SERVICE
Carefully pack the product, preferably in the original carton. Include details of defect claimed and proof of date of original purchase.
No liability is assumed for loss or damage to the product while in transit, if you chose your own transportation carrier.
33
Getting StartedUseful InformationTroubleshootingAppendix
GARANTIE LIMITÉE
GARANTIE LIMITEE - ORDINATEURS ET PERIPHERIQUES PANASONIC
Couverture
– Panasonic Canada Inc. (« PCI ») garantit a l’acheteur original que ce produit informatique (a l’exclusion des supports des
logiciels) est, au moment de sa vente par PCI ou d’un revendeur agree par PCI, exempt de defauts de pieces et de fabrication dans les
conditions normales d’utilisation, et ce, pendant la periode de couverture de la garantie, sous reserve des modalites decrites ci-dessous.
Recours
– Pour obtenir des informations sur la marche a suivre dans le cas ou une reclamation en vertu de la garantie deviendrait nec-
essaire, communiquez par telephone avec un representant de PCI au 1-800-668-8386, entre 9h00 et 17h00 (heure de l’Est) du lundi au
vendredi (sauf les jours feries), avant l’echeance de la garantie applicable, en prenant soin d’identifier la nature de la defaillance.
Un recu ou toute autre piece justificative de la date d’achat original sera exige avant toute reparation. Toute piece defectueuse couverte
par la presente garantie limitee sera reparee ou remplacee par une piece neuve ou remise a neuf. Le remplacement ou la reparation sera
fait conformement aux modalites de la presente garantie limitee pendant la duree restante de la periode originale de la garantie.
Produits non couverts – La presente garantie limitee ne couvre pas les produits achetes a l’exterieur du Canada. Elle ne couvre
pas non plus les dommages, la defaillance ou les defauts attribuables a une manutention inadequate, une mauvaise installation, une
utilisation anormale ou abusive, de la negligence, un accident, un deversement ou la penetration d’un objet etranger, une modifica-
tion, un cas fortuit ou une reparation effectuee par une personne non agreee par PCI.
CE PRODUIT N’EST PAS DESTINE A ETRE UTILISE, EN TOUT OU EN PARTIE, COMME SYSTEME/EQUIPEMENT NUCLEAIRE, SYSTEME/
EQUIPEMENT DE CONTROLE DU TRAFFIC AERIEN OU SYSTEME/EQUIPEMENT DE POSTE DE PILOTAGE D’AVION
*3
. PANASONIC
DECLINE TOUTE RESPONSABILITE CONCERNANT L’UTILISATION DE CE PRODUIT DANS LES CAS SUSMENTIONNES.
*3 Les SYSTEMES/EQUIPEMENTS DE POSTE DE PILOTAGE D’AVION sont dotes de systemes OEPP (organiseur electronique
de poste de pilotage) de classe 2 et de classe 1 utilises pendant des phases critiques de vol (par exemple, pendant le decollage
et l’atterrissage) et(ou) montes sur l’avion. Les systemes OEPP de classe 1 et de classe 2 sont definis par le circulaire d’informa-
tion FAA: AC (Advisory Circular) 120-76A ou le feuilet nº 36 JAA: JAA TGL (Temporary Guidance Leaflets) No 36.
GARANTIE LIMITEE - SUPPORTS DES LOGICIELS
Couverture – Panasonic Canada Inc. (« PCI ») garantit a l’acheteur original que la ou les disquettes ou tout autre support sur lequel
le ou les programmes sont fournis sont exempts de defauts de pieces et de fabrication dans des conditions normales d’utilisation au
Canada, et ce, pour une periode de soixante (60) jours suivant la date de reception indiquee sur la preuve d’achat.
LA PRESENTE GARANTIE EST LA SEULE OFFERTE PAR PCI COUVRANT LES SUPPORTS DE LOGICIELS. PCI ne garantit
pas les logiciels. Reportez-vous a la garantie ecrite du concedant de licence d’utilisation du logiciel (qui accompagne la copie du
logiciel) pour toute reclamation en vertu de la garantie.
Réclamation – marche à suivre
– Panasonic Canada Inc. remplacera toute disquette ou support defectueux si l’article en question est
retourne, port paye, a son service de Marketing - produits informatiques, 5770 Ambler Drive, Mississauga (Ontario) L4W 2T3, dans les soix-
ante (60) jours suivant la date d’achat original. Joignez a votre envoi une piece justificative de votre achat et une description du probleme.
Recours
–La responsabilite de PCI - et votre seul recours - dans le cas de toute defaillance couverte par la garantie sur ce support de
logiciel est limitee au seul remplacement du support. Elle ne couvre aucun autre dommage, y compris, mais non exclusivement, la perte
d’usage ou de profits, ni aucun dommage special, indirect ou consecutif, ni aucune autre reclamation de nature similaire ou autre.
Produits non couverts
– La presente garantie limitee ne s’applique pas si la ou les disquettes ou autre support ont ete utilises dans
un produit d’une marque autre que Panasonic ou dans des conditions environnementales autres que celles specifiees par PCI ou le
fabricant, ou soumis a une mauvaise utilisation, a la negligence, a une manutention inadequate ou encore si le programme a ete mod-
ifie ou subi une tentative de modification ou des dommages attribuables a un accident ou a un cas fortuit. De plus, PCI n’assume
aucune responsabilite pour toute perte de, ou tout dommage a, un programme, des donnees ou un support de sauvegarde amovible.
GENERALITES
PCI NE RECONNAIT AUCUNE AUTRE GARANTIE, EXPLICITE OU IMPLICITE, Y COMPRIS, MAIS NON EXCLUSIVEMENT, LES
GARANTIES IMPLICITES DE VALEUR COMMERCIALE ET D’UTILITE A UNE FIN QUELCONQUE, A L’EGARD DU LOGICIEL,
SUPPORTS DE LOGICIELS, PRODUITS INFORMATIQUES, PERIPHERIQUES ET ACCESSOIRES.
SOUS AUCUNE CIRCONSTANCE PCI NE POURRA ETRE TENUE RESPONSABLE DES DOMMAGES SPECIAUX, INDIRECTS
OU CONSECUTIFS ATTRIBUABLES A UN MANQUEMENT AUX GARANTIES LIMITEES DECRITES DANS LE PRESENT DOCU-
MENT OU A L’UTILISATION DU PRODUIT INFORMATIQUE, Y COMPRIS, SANS RESTRICTION, LA PERTE DE DONNEES,
D’AFFAIRES, D’ACHALANDAGE OU DE PROFIT.
DANS TOUS LES CAS, LA RESPONSABILITE MAXIMALE DE PCI POUR TOUT MANQUEMENT NE POURRA EXCEDER LE
PRIX DE VENTE DU PRODUIT INFORMATIQUE.
AUCUNE RECLAMATION, SANS EGARD A SES MOTIFS, NE POURRA ETRE FAITE AUPRES DE PCI PLUS DE DEUX (2) ANS
APRES LES FAITS INVOQUES A LA BASE D’UNE TELLE RECLAMATION.
Garantie statutaires
– Certaines juridictions interdisent de telles limitations ou exclusions; aussi, pourraient-elles ne pas s’appliquer.
Pour le Canada
Elements couverts Duree de couverture Type de couverture
• Ordinateurs blocs-notes (sauf batteries) et adaptateur secteur
• Options installees en usine/par PCI incluant : WAN sans fil,
GPS, Bluetooth, lecteur d’empreintes digitales, clavier retroe-
claire, carte memoire et lecteurs (disquettes, CD/DVD)
• Ordinateurs personnels ultra-portables (CF-U1/CF-H1)
• Ecran mobile sans fil
• Ensembles PDRC - ACL et clavier
• Duplicateur de port
Trois (3) ans a partir de la date
d’achat original. Defauts de pieces et de fabrica-
tion
• Ordinateurs de poche
•Batterie
• Chargeur de batterie
• Adaptateur pour voiture
• Peripheriques USB
Un (1) an a partir de la date
d’achat original. Defauts de pieces et de fabrica-
tion
• Stylo pointeur standard ou pour numeriseur graphique
Quatre-vingt-dix (90) jours a
partir de la date d’achat original.
Defauts de pieces et de fabrica-
tion
• Tous les articles consommables incluant les pellicules protec-
trices, chiffons de nettoyage, etuis de transport, longes et sangles
Aucune couverture
EXPEDITION DU PRODUIT POUR SERVICE SOUS GARANTIE
Emballez soigneusement le produit, de preference dans son emballage d’origine. Joignez une description de la defaillance de
meme qu’une piece justificative de la date d’achat. Panasonic Canada Inc. ne peut etre tenue responsable pour tout dommage ou
perte subi pendant le transport si vous avez choisi le transporteur.
34
MEMO
35
MEMO
© Panasonic Corporation 2010
Printed in Japan
Panasonic Solutions Company
3 Panasonic Way, Panazip 2F-5,
Secaucus, NJ 07094
Panasonic Canada Inc.
5770 Ambler Drive Mississauga,
Ontario L4W 2T3
As an ENERGY STAR® Partner, Panasonic Corporation has determined that
this product meets ENERGY STAR® guidelines for energy efficiency. By
enabling available power management settings, Panasonic computers enter
a low-power sleep mode after a period of inactivity, saving the user
energy. To learn more about power management, please visit the web site:
www.energystar.gov/index.cfm?c=power_mgt.pr_power_management
Outline of the International ENERGY STAR® Office Equipment Program
The international ENERGY STAR® Office Equipment Program is an international program that promotes energy
saving through the use of computers and other office equipment. The program backs the development and dissem-
ination of products with functions that effectively reduce energy consumption. It is an open system in which busi-
ness proprietors can participate voluntarily. The targeted products are office equipment such as computers,
displays, printers, facsimiles, and copiers. Their standards and logos are uniform among participating nations.
For information about ENERGY STAR®, refer to the following web side:
Web Site: www.energystar.gov 22-M-1
SS0710-0
DFQW5426ZA
