Contents

User manual 1 of 2

2
E
ThankyouforpurchasingthisPanasonicproduct.Foroptimumperformanceand
safety,pleasereadtheseinstructionscarefully.
n Terms and illustrations in these instructions
NOTE :Usefulandhelpfulinformation.
l Someillustrationsaresimpliedtohelpyourunderstandingandmaylookdif-
ferentfromtheactualunit.
l Referforthelatestinformationaboutoptionalproductstothecatalogs,etc.
n Disclaimer
Computerspecicationandmanualsaresubjecttochangewithoutnotice.
PanasonicCorporationassumesnoliabilityfordamageincurreddirectlyorin-
directlyfromerrors,omissionsordiscrepanciesbetweenthecomputerandthe
manuals.
Introduction
3
E
YoucanreadthedatafromHF-RFID(High-FrequencyRadioFrequencyIdenti-
cation)tags.
NOTE
l HF-RFIDReaderistypicallyusedwithspecializedapplications.Forfurther
information,askthesystemadministrator.
A
1 Align the HF-RFID device with the (A) mark and wave the
HF-RFID device.
NOTE
l OperationdistancedependsonHF-RFIDtag.
HF-RFID reader ×1(ISO14443type-A/B,ISO15693Support)
Reading HF-RFID Tag
Specications
Regulatory Information
USA-Federal Communications Commission (FCC)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Caution
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
Labeling
System integrators must include the FCC ID on the end product.
Canada-Industry Canada (IC)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the
following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Labeling
System integrators must include the IC ID on the end product.
Important Notice
Panasonic will not sell radio modules to any third party; and will not allow aftermarket
installation by any third party or end user. Instead, they will only be installed within Panasonic
Notebooks, Laptops, Tablets and Ultra Mobile Toughbook PCs. Panasonic confirms that the
provided operating instruction to user will not include any instructions how to add or remove any
of the transmitter modules.
PrintedinTaiwan
パナソニック株式会社 IT プロダクツ事業部
〒 570-0021　大阪府守口市八雲東町一丁目 10 番 12 号
© Panasonic Corporation 2013
Panasonic Corporation
Osaka,Japan
Panasonic System Communications Company of North America
TwoRiverfrontPlaza
Newark,NJ07102
Panasonic Canada Inc.
5770AmblerDrive,Mississauga,
OntarioL4W2T3
Panasonic Australia Pty. Limited
ACN001592187ABN83001592187
1InnovationRoad,MacquarieParkNSW2113
Importer’sname&addresspursuanttotheEUlegislation
Panasonic System Communications Company Europe, Panasonic
Marketing Europe GmbH
HagenauerStraße43
65203Wiesbaden
Germany
