OPERATING INSTRUCTIONS
Read Me First
Personal Computer
Model No. CF-20 series
Please read these instructions carefully before using this product, and save this manual for future use.
The above illustration is that is attached the keyboard base.
Getting Started
In these instructions, the names and terms are referred as follows.
: Conditions that may result in minor or moderate injury.
: Useful and helpful information.
“Windows 10 Pro 64-bit” as “Windows” or “Windows 10”
This manual explains operation procedures using the touchpad or mouse as typical exam-
ples. In addition, you can touch the display screen to operate the computer.
When using the touch operation, please replace the terms as described below, and read the
instructions.
Operation terms to be replaced:
-Click → Touch
- (Settings): Click (Start) and then click (Settings).
è: Page in these Operating Instructions.
: Reference to the on-screen manuals.
Getting Started
First-time Operation .....................................15
Detaching the tablet from the keyboard base
.... 20
Attaching the tablet to the keyboard base
....22
Read Me First
Safety Precautions .........................................2
Regulatory Information ...................................7
nTerms and illustrations in these instructions
CAUTION
NOTE
Read Me First
2
Read Me First
Safety Precautions
To reduce the risk of injury, loss of life, electric
shock, re, malfunction, and damage to equipment
or property, always observe the following safety
precautions.
Explanation of symbol word panels
The following symbol word panels are used to clas-
sify and describe the level of hazard, injury, and
property damage caused when the denotation is
disregarded and improper use is performed.
DANGER
Denotes a potential hazard that will result
in serious injury or death.
WARNING
Denotes a potential hazard that could re-
sult in serious injury or death.
CAUTION
Denotes a hazard that could result in mi-
nor injury.
NOTICE
Denotes a hazard that could result in
property damage.
The following symbols are used to classify
and describe the type of instructions to be
observed.
This symbol is used to alert users to a
specic operating procedure that must
not be performed.
This symbol is used to alert users to a
specic operating procedure that must
be followed in order to operate the unit
safety.
DANGER
Precautions on the Battery Pack
Electrolyte leakage, generation of heat, ig-
nition or rupture of the Battery Pack may
result.
nDo Not Throw the Battery Pack
into a Fire or Expose It to Exces-
sive Heat
nDo Not Deform, Disassemble, or
Modify the Battery Pack
nDo Not Short the Positive (+) and
Negative (-) Contacts
ÖDo not place the battery pack
together with articles such as
necklaces or hairpins when car-
rying or storing.
nDo Not Apply Shocks to the
Product by Dropping It, Applying
Strong Pressure to It, etc.
ÖIf this product is subjected to
a strong impact, damaged or
deformed, stop using it immedi-
ately.
nDo Not Charge the Battery Us-
ing Methods Other Than Those
Specied
nDo Not Use the Battery Pack
with Any Other Product
• The battery pack is rechargeable
and was intended for the speci-
ed product.
nDo Not Use This Product with a
Battery Pack Other Than the One
Specied
ÖUse only the specied battery
pack with your product.
nDo not use battery pack if wet
nAvoid Extreme Heat (Near the
Fire, in Direct Sunlight, for Ex-
ample)
nWhen the Battery Pack Has Dete-
riorated or If Abnormal Swelling
Occur, Replace It with New One
ÖDo not continue to use a damaged
battery pack.
3
Read Me First
DANGER
Precautions on the Built-in Bridge
Battery (for disposal)
<Only for model with Built-in Bridge Bat-
tery>
When disposing the battery, generation
of heat, ignition or rupture of the Built-in
Bridge Battery may result.
(èOPERATING INSTRUCTIONS - Basic
Guide)
Handling This Computer
nDo Not Disassemble the Comput-
er Except When Disposing
Handling the Built-in Bridge Battery
nDo Not Short the Positive (+) and
Negative (-) Contacts
nDo Not Throw the Battery into a
Fire or Expose It to Excessive
Heat
nDo Not Apply Shocks to the
Built-in Bridge Battery by Drop-
ping It, Applying Strong Pres-
sure to It, etc.
nDo Not Charge
nDo Not Use
nDo Not Deform, Disassemble, or
Modify the Built-in Bridge Bat-
tery
nAvoid Extreme Heat (Near the
Fire, in Direct Sunlight, for Ex-
ample)
WARNING
<Only for model with Built-in Bridge Bat-
tery>
Generation of heat, ignition or rupture of
the Built-in Bridge Battery may result.
nDo Not Throw This Product Into a
Fire or Expose It to Excessive Heat
nDo Not Insert Sharp Objects Into
This Product, Disassemble, or
Modify It
nDo Not Apply Shocks to the Prod-
uct by Dropping It, Applying Strong
Pressure to It, etc.
nDo Not Charge the Battery Using
Methods Other Than Those Speci-
ed
nAvoid Extreme Heat (Near the Fire,
In Direct Sunlight, for Example)
nWhen the Built-in Bridge Battery Has
Deteriorated or If Abnormal Swelling
Occur, Contact Your Technical Sup-
port Oce to Replace the Battery
Fire or electric shock may result.
nDo Not Do Anything That May Dam-
age the AC Cord, the AC Plug, or the
AC Adaptor
Do not damage or modify the cord,
place it near hot tools, bend, twist,
or pull it forcefully, place heavy ob-
jects on it, or bundle it tightly.
ÖDo not continue to use a dam-
aged AC cord, AC plug and AC
adaptor.
• Contact your technical support
oce for repair.
nDo Not Connect the AC Adaptor to
a Power Source Other Than a Stan-
dard Household AC Outlet
ÖConnecting to a DC/AC converter
(inverter) may damage the AC adap-
tor. On an airplane, only connect the
AC adaptor/charger to an AC outlet
specically approved for such use.
nDo Not Pull or Insert the AC Plug If
Your Hands Are Wet
nDo Not Disassemble This Product
nDo Not Touch This Product In a
Thunderstorm If Connected with the
AC Cable or Any Other Cables
nDo Not Place Containers of Liquid or
Metal Objects on Top of This Prod-
uct
ÖIf foreign matter has found its
way inside, immediately turn the
power o and unplug the AC
plug (and remove the battery
pack). Then contact your techni-
cal support oce.
Read Me First
4
Safety Precautions
WARNING
nIf a Malfunction or Trouble Occurs,
Immediately Stop Use
If the Following Malfunction Occurs,
Immediately Unplug the AC Plug
and the Battery Pack
• This product is damaged
• Foreign object inside this
product
• Smoke emitted
• Unusual smell emitted
• Unusually hot
ÖAfter the above procedure, con-
tact your technical support oce
for repair.
nClean Dust and Other Debris of the
AC Plug Regularly
• If dust or other debris accumu-
lates on the plug, humidity, etc.
may cause a defect in the insula-
tion.
nInsert the AC Plug Completely
ÖDo not use a damaged plug or
loose AC outlet.
nClose the Connector Cover Tightly
When Using This Product Where
Is a Lot of Water, Moisture, Steam,
Dust, Oily Vapors, etc.
ÖIf foreign matter has found its
way inside, immediately turn
the power o and unplug the
AC cord, and then remove the
battery pack. Then contact your
technical support oce.
Burns or low-temperature burns may result.
nDo Not Use This Product in Close
Contact With Your Body For a Long
Period of Time
ÖDo not use this product with
its heat-emitting parts in close
contact with your body for a long
period of time.
• Low-temperature burns may
result.
nDo Not Touch The Surface of The
AC Adaptor Continuously While
Using/Charging
• Burns may result.
nDo Not Place the Product in a Bag
or Case While It is Turned On
• Doing so may cause the product
to overheat and result in burns.
Detrimental health eects on your body
may result.
nDo Not Turn the Volume Up Too
Loud When Using Headphones
• Listening at high volumes that
overstimulate the ear for long
periods of time may result in loss
of hearing.
CAUTION
Fire or electric shock may result.
nDo Not Move This Product While the
AC Plug Is Connected
ÖIf the AC cord is damaged, un-
plug the AC plug immediately.
nDo Not Connect a Telephone Line,
or a Network Cable Other Than the
One Specied, Into the LAN Port
ÖDo not connect to a network
such as the ones listed below.
• Networks other than 1000BASE-T,
100BASE-TX or 10BASE-T
• Phone lines (IP phone (Internet
Protocol Telephone), Telephone
lines, internal phone lines (on-
premise switches), digital public
phones, etc.)
nDo Not Subject the AC Adaptor To
Any Strong Impact
ÖDo not continue to use the AC
adaptor after a strong impact
such as being dropped.
ÖContact your technical support
oce for repair.
nDo Not Leave This Product in High
Temperature Environment for a
Long Period of Time
• Leaving this product where it will
be exposed to extremely high
temperatures such as near re or
in direct sunlight may deform the
cabinet and/or cause trouble in
the internal parts.
5
Read Me First
Fire or electric shock may result.
nHold the Plug When Unplugging the
AC Plug
nUse Only the Specied AC Adaptor
With This Product
ÖDo not use an AC adaptor other
than the one supplied (supplied
with the unit or one sold sepa-
rately as an accessory).
This product may fall over or drop, result-
ing in an injury.
nDo Not Place This Product on Un-
stable Surfaces
nAvoid Stacking
nWhen Carrying the Computer, Attach
the Main Unit To the Keyboard Base
Tightly Until Red Signs Under the
Detach Lock And Release Lever Are
Concealed.
Detrimental health eects on your body
may result.
nTake a Break Of 10-15 Minutes Every
Hour
• Using this product for long peri-
ods of time may have detrimen-
tal health eects on the eyes or
hands.
Burns, low-temperature burns, or frostbite
may result.
nDo Not Expose the Skin To This
Product When Using the Product In
A Hot Or Cold Environment
ÖWhen it is necessary to expose
the skin to this product such as
to scan a ngerprint, perform the
operation in the shortest time
possible.
NOTICE
lDo not place the computer near a television or
radio receiver.
lKeep the computer away from magnets. Data
stored on the ash memory may be lost.
lThis computer is not intended for the display of
images for use in medical diagnosis.
lThis computer is not intended for a use with
connection of medical equipment for the pur-
pose of medical diagnosis.
lPanasonic shall not be liable for loss of data
or other incidental or consequential damages
resulting from the use of this product.
lDo not touch the terminals on the battery pack.
The battery pack may no longer function prop-
erly if the contacts are dirty or damaged.
lDo not expose the battery pack to water, or al-
low it to become wet.
lIf the battery pack will not be used for a long
period of time (a month or more), charge or
discharge (use) the battery pack until the re-
maining battery level becomes 30% to 40% and
store it in a cool, dry place.
lThis computer prevents overcharging of the
battery by recharging only when the remaining
power is less than approx. 95% of capacity.
lThe battery pack is not charged when the
computer is rst purchased. Be sure to charge
it before using it for the rst time. When the AC
adaptor is connected to the computer, charging
begins automatically.
lShould the battery leak and the uid get into
your eyes, do not rub your eyes. Immediately
ush your eyes with clear water and see a doc-
tor for medical treatment as soon as possible.
Read Me First
6
Safety Precautions
NOTE
lThe battery pack may become warm during
recharging or normal use. This is completely
normal.
lRecharging will not commence if internal tem-
perature of the battery pack is outside of the al-
lowable temperature range (0 °C to 50 °C {32 °F
to 122 °F}). (è OPERATING INSTRUC-
TIONS - Reference Manual “Basic Operation”
“Battery Power”) Once the allowable range
requirement is satised, charging begins auto-
matically. Note that the recharging time varies
based on the usage conditions. (Recharging
takes longer than usual when the temperature
is 10 °C {50 °F} or below.)
lIf the temperature is low, the operating time is
shortened. Only use the computer within the
allowable temperature range.
lThis computer has a high temperature mode
function that prevents the degradation of the
battery in high temperature environments. (è
OPERATING INSTRUCTIONS - Reference
Manual “Basic Operation” “Battery Power”) A
level corresponding to a 100% charge for high
temperature mode is approximately equivalent
to an 80% charge level for normal temperature
mode.
lThe battery pack is a consumable item. If the
amount of time the computer can be run by us-
ing a particular battery pack becomes dramati-
cally shorter and repeated recharging does not
restore its performance, the battery pack should
be replaced with a new one.
lWhen transporting a spare battery inside a
package, briefcase, etc., it is recommended that
it be placed in a plastic bag so that its contacts
are protected.
lAlways power o the computer when it is not
in use. Leaving the computer on when the
AC adaptor is not connected will exhaust the
remaining battery capacity.
l<Only for model with Built-in Bridge Battery>
To minimize deterioration of the built-in bridge
battery, connect the computer to the AC adap-
tor and recharge it for approximately 2 hours
about once every year.
THIS PRODUCT IS NOT INTENDED FOR USE
AS, OR AS PART OF, NUCLEAR EQUIPMENT/
SYSTEMS, AIR TRAFFIC CONTROL EQUIP-
MENT/SYSTEMS, AIRCRAFT COCKPIT EQUIP-
MENT/SYSTEMS*1, MEDICAL DEVICES OR
ACCESSORIES*2, LIFE SUPPORT SYSTEMS
OR OTHER EQUIPMENTS/DEVICES/SYSTEMS
THAT ARE INVOLVED WITH ENSURING HU-
MAN LIFE OR SAFETY. PANASONIC WILL NOT
BE RESPONSIBLE FOR ANY LIABILITY RE-
SULTING FROM THE USE OF THIS PRODUCT
ARISING OUT OF THE FOREGOING USES.
*1 AIRCRAFT COCKPIT EQUIPMENT/SYSTEMS
include Class2 Electrical Flight Bag (EFB) Sys-
tems and Class1 EFB Systems when used dur-
ing critical phases of ight (e.g., during take-o
and landing) and/or mounted on to the aircraft.
Class1 EFB Systems and 2 EFB Systems are
dened by FAA: AC (Advisory Circular) 120-76A
or JAA: JAA TGL (Temporary Guidance Leaets)
No.36.
*2 As dened by the European Medical Device
Directive (MDD) 93/42/EEC.
Panasonic cannot guarantee any specications,
technologies, reliability, safety (e.g. Flammability/
Smoke/Toxicity/Radio Frequency Emission, etc.)
requirements related to aviation standards that
exceed the specications of our COTS (Commer-
cial-O-The-Shelf) products.
This computer is not intended for use in medical
equipment including life-support systems, air trac
control systems, or other equipment, devices or
systems that are involved with ensuring human life
or safety. Panasonic cannot be held responsible
in any way for any damages or loss resulting from
the use of this unit in these types of equipment,
devices or systems, etc.
As with any portable computer device precautions
should be taken to avoid any damage. The follow-
ing usage and handling procedures are recom-
mended.
Before putting the computer away, be sure to
wipe o any moisture.
7
Read Me First
Regulatory Information
Information to the User / Informations destinées aux utilisateurs
<Only for model with wireless LAN/Bluetooth>
This product and your Health
This product, like other radio devices, emits radio frequency electromagnetic energy. The level of energy
emitted by this product however is far much less than the electromagnetic energy emitted by wireless de-
vices like for example mobile phones.
Because this product operates within the guidelines found in radio frequency safety standards and recom-
mendations, we believe this product is safe for use by consumers. These standards and recommendations
reect the consensus of the scientic community and result from deliberations of panels and committees of
scientists who continually review and interpret the extensive research literature.
In some situations or environments, the use of this product may be restricted by the proprietor of the building or
responsible representatives of the organization. These situations may for example include:
lUsing this product on board of airplanes, or
l
In any other environment where the risk of interference to other devices or services is perceived or identi-
ed as harmful.
If you are uncertain of the policy that applies on the use of wireless devices in a specic organization or environ-
ment (e.g. airports), you are encouraged to ask for authorization to use this product prior to turning on the product.
Regulatory Information
We are not responsible for any radio or television interference caused by unauthorized modication of this product.
The correction of interference caused by such unauthorized modication will be the responsibility of the user. We
and its authorized resellers or distributors are not liable for damage or violation of government regulations that may
arise from failing to comply with these guidelines.
26-M-1
<Uniquement les modèles avec réseau local sans l et/ou Bluetooth>
Ce produit et votre santé
Ce produit, comme tout autre appareil radio, émet de l’énergie radioélectrique. Toutefois, la quantité d’énergie
émise par ce produit est beaucoup moins importante que l’énergie radioélectrique émise par des appareils sans l
tels que les téléphones portables. L’utilisation de ce produit ne comporte aucun risque pour le consommateur du
fait que cet appareil opère dans les limites des directives concernant les normes et les recommandations de sécuri-
té sur les fréquences radio. Ces normes et recommandations reètent le consensus de la communauté scientique
et résultent de délibérations de jurys et comités de scientiques qui examinent et interprètent continuellement les
nouveautés de la vaste littérature sur les recherches eectuées. Dans certaines situations ou environnements, l’uti-
lisation de ce produit peut être restreinte par le propriétaire du bâtiment ou par les représentants responsables de
l’organisation. Ces situations peuvent être les suivantes par exemple :
lA bord d’un avion, ou
lDans tout autre environnement où les risques d’interférence sur d’autres appareils ou services sont per-
çus ou identiables comme dangereux.
Si vous n’êtes pas sûr de la réglementation applicable à l’utilisation d’appareils sans l dans une organisa-
tion ou un environnement spécique, (par exemple dans un aéroport) nous vous invitons àdemander l’auto-
risation d’utiliser ce produit avant sa mise en marche.
Informations concernant la réglementation
Nous déclinons toute responsabilité pour toute interférence radio ou télévision causée par des modications non auto-
risées apportées à ce produit. La correction d’interférences causées par de telles modications non autorisées sera la
seule responsabilité de son utilisateur. Nousmêmes, les revendeurs ociels et les distributeurs ne sommes pas respon-
sable de tout dégât ou de toute violation des règlements de l’État pouvant découler du non-respect de ces directives.
26-F-1
Camera Light / Lumière de la caméra
<For model with rear camera>
CAUTION
- The light from the LED is strong and can injure human eyes.
Do not look directly at the LEDs with naked eyes.
57-E-1
<Pour les modèles munis d’une caméra arrière>
ATTENTION
- La lumière de la diode LED est forte et peut blesser l’oeil humain.
Ne regardez pas directement les LED avec les yeux non protégés.
57-F-1
Read Me First
8
Regulatory Information
Lithium Battery / Pile au lithium
Lithium Battery!
This computer contains a lithium battery to enable
the date, time, and other data to be stored. The
battery should only be exchanged by authorized
service personnel.
Warning!
A risk of explosion from incorrect installation or
misapplication may possibly occur.
15-E-1
Pile au lithium!
Le micro-ordinateur renferme une pile au lithium
qui permet de sauvegarder certaines données,
notamment la date et l’heure. La pile ne doit être
remplacée que par un technicien qualié.
Danger ! Risque d’explosion en cas de non respect
de cette mise en garde!
15-F-1
<Only for model with Barcode Reader>
Laser Devices
This equipment is using lasers that comply with US21CFR1040.10, 1040.11, EN
60825-1:1994+A2:2001+A1:2002 and IEC60825-1:1993+A1:1997+A2:2001 regulations.
The laser is a “Class 2” laser which is indicated on the label for this product.” Class 2 laser readers use a
low power, visible light diode. As with any very bright light source, such as the sun, the user should avoid
staring directly into the light beam. Momentary exposure to a Class 2 laser is not known to be harmful.
Caution-Use of controls or adjustments or performance of procedures other than those specied herein may
result in hazardous radiation exposure.
nLabeling/Marking
Location of aperture
Beam Divergence
- Vertical angle: 30 degree
- Horizontal angle: 36 degree
13-E-1
Battery Pack / Batterie
CAUTION:
Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries According to the
Instructions.
58-E-1
ATTENTION:
Il y a risque d’explosion si la batterie est remplacée par une batterie de type incorrect.
Mettre au rebut les batteries usagées conformément aux instructions.
58-F-1
Battery pack model number CF-VZSU0Q Series
Recommended charging condition 13.05 V / 1820 mA (Constant voltage/current)
Notice Dispose of used batteries according to local ordi-
nances and/or regulations.
lDispose of used built-in battery according to local ordinances and/or regulations.
lDo not expose this computer to temperatures greater than 60°C {140°F}.
9
Read Me First
Information for Users on Collection and Disposal of Old Equip-
ment and used Batteries
These symbols are only valid in the European Union.
If you wish to discard this product, please contact your local authorities or dealer
and ask for the correct method of disposal.
53-M-1
<Only for model with wireless WAN>
The following safety precautions must be observed during all phases of the operation, usage, service or
repair of any Personal Computer or Handheld Computer incorporating wireless WAN modem. Manufacturers
of the cellular terminal are advised to convey the following safety information to users and operating person-
nel and to incorporate these guidelines into all manuals supplied with the product. Failure to comply with
these precautions violates safety standards of design, manufacture and intended use of the product.
Panasonic assumes no liability for customer failure to comply with these precautions.
When in a hospital or other health care facility, observe the restrictions on the use of mobiles.
Switch Personal Computer or Handheld Computer incorporating wireless WAN modem o, if in-
structed to do so by the guidelines posted in sensitive areas. Medical equipment may be sensitive
to RF energy.
The operation of cardiac pacemakers, other implanted medical equipment and hearing aids can
be aected by interference from Personal Computer or Handheld Computer incorporating wire-
less WAN modem placed close to the device. If in doubt about potential danger, contact the phy-
sician or the manufacturer of the device to verify that the equipment is properly shielded. Pace-
maker patients are advised to keep their Personal Computer or Handheld Computer incorporating
wireless WAN modem away from the pacemaker, while it is on.
Switch o Personal Computer or Handheld Computer incorporating wireless WAN modem before
boarding an aircraft. Make sure it cannot be switched on inadvertently. The operation of wireless
appliances in an aircraft is forbidden to prevent interference with communications systems. Fail-
ure to observe these instructions may lead to the suspension or denial of cellular services to the
oender, legal action, or both.
For details on usage of this unit in aircrafts please consult and follow instruction provided by the
airline.
Safety Precautions
Energy Star
As an ENERGY STAR® Partner, Panasonic Corporation has determined that this
product meets ENERGY STAR® guidelines for energy eciency. By enabling available
power management settings, Panasonic computers enter a low-power sleep mode
after a period of inactivity, saving the user energy.
<For U.S.A.>
To learn more about power management, please visit the web site:
www.energystar.gov/index.cfm?c=power_mgt.pr_power_management
Outline of the International ENERGY STAR® Oce Equipment Program
The international ENERGY STAR® Oce Equipment Program is an international
program that promotes energy saving through the use of computers and other oce
equipment. The program backs the development and dissemination of products with
functions that eectively reduce energy consumption. It is an open system in which
business proprietors can participate voluntarily. The targeted products are oce equip-
ment such as computers, displays, printers, facsimiles, and copiers. Their standards
and logos are uniform among participating nations.
<For U.S.A.>
For information about ENERGY STAR®, refer to the following web site:
Web Site: www.energystar.gov
22-M-1
Read Me First
10
Regulatory Information
Do not operate Personal Computer or Handheld Computer incorporating wireless WAN modem
in the presence of ammable gases or fumes. Switch o the cellular terminal when you are near
petrol stations, fuel depots, chemical plants or where blasting operations are in progress. Op-
eration of any electrical equipment in potentially explosive atmospheres can constitute a safety
hazard.
Your Personal Computer or Handheld Computer incorporating wireless WAN modem receives
and transmits radio frequency energy while switched on. Remember that interference can occur
if it is used close to TV sets, radios, computers or inadequately shielded equipment. Follow any
special regulations and always switch o Personal Computer or Handheld Computer incorporat-
ing wireless WAN modem wherever forbidden, or when you suspect that it may cause interfer-
ence or danger.
Road safety comes rst! Do not use a Personal Computer or Handheld Computer incorporat-
ing wireless WAN modem while driving a vehicle. Do not place the computer with wireless WAN
modem in an area where it could cause personal injury to the driver or passengers. It is recom-
mended to stow the unit in the boot or secure stowage area while driving.
Do not place the computer with wireless WAN modem in an area over an air bag or in the vicinity
where an air bag may deploy.
Air bags inate with great force and if the computer with wireless WAN modem is placed in the air
bag deployment area may be propelled with great force and cause serious injury to occupants of
the vehicle.
IMPORTANT!
Personal Computer or Handheld Computer incorporating wireless WAN modem operate using
radio signals and cellular networks cannot be guaranteed to connect in all conditions. Therefore,
you should never rely solely upon any wireless device for essential communications, for example
emergency calls.
Remember, in order to make or receive calls, Personal Computer or Handheld Computer incor-
porating wireless WAN modem must be switched on and in a service area with adequate cellular
signal strength.
Some networks do not allow for emergency calls if certain network services or phone features are
in use (e.g. lock functions, xed dialing etc.). You may need to deactivate those features before
you can make an emergency call.
Some networks require that a valid SIM card be properly inserted in Personal Computer or Hand-
held Computer incorporating wireless WAN modem.
For U.S.A.
Federal Communications Commission Radio Frequency Interference Statement
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursu-
ant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular installa-
tion. If this equipment does cause harmful interference to radio or television reception, which can be deter-
mined by turning the equipment o and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
lReorient or relocate the receiving antenna.
l
Increase the separation between the equipment and receiver.
lConnect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
lConsult the Panasonic Service Center or an experienced radio/TV technician for help.
Warning
To assure continued compliance, use only shielded interface cables when connecting to a computer or pe-
ripheral. Also, any changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
11
Read Me First
FCC RF Exposure Warning:
lThis equipment is provided with PC Card slot that could be used with wireless transmitters, which will be
speci cally recommended when they become available.
Other third-party wireless transmitters have not been RF exposure evaluated for use with this computer
and may not comply with FCC RF exposure requirements.
<Only for model with wireless LAN/wireless WAN/Bluetooth>
lThis equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
lThis equipment may not be collocated or operated with any other antenna or transmitter.
lThis device meets the government’s requirements for exposure to radio waves.
This device is designed and manufactured not to exceed the emission limits for exposure to radio fre-
quency (RF) energy set by the Federal Communications Commission of the U.S. Government.
lThe exposure standard for wireless device employs a unit of measurement known as the Speci c Ab-
sorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.
* Tests for SAR are conducted using standard operating positions accepted by the FCC with the device trans-
mitting at its highest certi ed power level in all tested frequency bands.
Although the SAR is determined at the highest certi ed power level, the actual SAR level of the device while
operating can be well below the maximum value. This is because the device is designed to operate at mul-
tiple power levels so as to use only the poser required to reach the network. In general, the closer you are to
a wireless base station antenna, the lower the power output.
25-M-9
<Only for model with wireless LAN>
About FCC ID Number
SAR information on this product is on le with the FCC and can be found by searching for the product’s FCC
ID Number at http://www.fcc.gov/oet/ea/fccid. To nd the FCC ID number for your product, rst remove the
battery pack from the tablet.
The FCC ID number is printed on the nameplate underneath.
Responsible Party: Panasonic Corporation of North America
Two Riverfront Plaza
Newark, NJ 07102
Support Contact: http://business.panasonic.com/support-computerstablets
6-M-1
USA Only: Disposal may be regulated in your community due to environmental considerations. For
disposal or recycling information, please visit Panasonic website:
http://www.panasonic.com/environmental or call 1-888-769-0149 65-M-2
<US & Canada Only>
A lithium ion battery that is recyclable powers the product you have purchased.
Please call 1-800-8-BATTERY for information on how to recycle this battery.
<É.-U. et Canada seulement>
L’appareil que vous vous êtes procuré est alimenté par une batterie au lithium-ion.
Pour des renseignements sur le recyclage de la batterie, veuillez composer le
1-800-8-BATTERY.
48-M-1
For Used in Motor Vehicle / Pour L’utilisation Dans Un Véhicule Motorisé
Warning: Notebook Computer may be installed in a motor vehicle and visible to the driver only if used to support
vehicle related functions such as vehicle information, system control, rear or side observation and navigation.
If used for entertainment purpose, such as television reception or video play, it must be installed to the rear of
the driver’s seat where it will not be visible, directly or indirectly, to the operator of the motor vehicle. Check with
individual state/provincial laws to determine lawful use of this product while operating within a motor vehicle.
Avertissement : L’ordinateur bloc-notes peut être installé dans un véhicule motorisé et dans le champ de vi-
sion du conducteur uniquement en tant que dispositif d’aide aux fonctions du véhicule, comme par exemple
pour fournir des informations sur le véhicule, comme dispositif de contrôle de système, pour l’observation à
l’arrière ou sur les côtés du véhicule, ainsi que pour fournir de l’information routière. Pour toute utilisation à
n de divertissement, comme par exemple pour regarder la télévision ou jouer à des jeux vidéo, il doit être
installé à l’arrière du siège du conducteur, en un emplacement où il ne sera pas visible, ni directement ni
indirectement, pour le conducteur du véhicule motorisé. Vériez les lois fédérales et nationales qui régissent
l’utilisation légale de cet appareil à l’intérieur d’un véhicule motorisé.
35-M-1
Read Me First
12
Regulatory Information
This product contains a Coin Cell Lithium Battery which contains Perchlorate Material -
special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate/ 38-M-1
For Canada
Canadian ICES-003
CAN ICES-3(B)/NMB-3(B)
7-M-2
<Only for model with wireless LAN/Bluetooth>
ISED Canada
This product complies with ISED Canada’s licence-exempt RSSs.
Operation is subject to the following two conditions;
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of
the device.
<Ne s’applique qu’aux modèes avec technologie Bluetooth/LAN sans l/WAN sans l>
ISED Canada
Cet équipement est conforme aux normes sans licence RSS ISED Canada.
Son fonctionnement est soumis aux deux conditions suivantes :
(1) ce dispositif ne peut produire de brouillage, et
(2) ce dispositif doit accepter le brouillage, y compris le brouillage pouvant entraîner le fonctionnement non
désiré de l’appareil.
30-Ca-1-1
<Only for model with wireless LAN>
This product (local network devices) for the band 5150-5250 MHz is only indoor usage to reduce potential
for harmful interference to co-channel Mobile Satellite systems.
High power radars are allocated as primary users (meaning they have priority) of 5250-5350 MHz and 5650-
5850 MHz and these radars could cause interference and/or damage to LELAN devices.
<Ne s’applique qu’aux modèes avec technologie LAN sans l>
Cet appareil (pour réseaux locaux radioélectriques) dans les bandes de fréquences 5150-5250 MHz est
réervéàune utilisation àl’intéieur an de réuire le risque d’interféence avec les systèmes satellites mobiles
bicanaux.
Les radars forte puissance sont désignés comme étant les premiers utilisateurs (c’st-à-dire qu’ls ont la prio-
rité) des bandes de fréquences 5250-5350 MHz et 5650-5850 MHz. Ces stations radars peuvent provoquer
des interférences et/ou des dommages à ce périphérique.
30-Ca-2-1
13
Read Me First
<Only for model with wireless LAN/wireless WAN/Bluetooth>
lThis computer complies with ISED Canada radiation exposure limits set forth for an uncontrolled envi-
ronment.
lThis PC with WLAN and/or Bluetooth transmitters installed, has been approved for portable operation
and does not require any minimum spacing be provided between antennas and all person’s body.
<Ne s’applique qu’aux modèles avec technologie Bluetooth/LAN sans l/WAN sans l>
lCet équipement est conforme aux limites d’exposition aux rayonnements ISED Canada établies pour un
environnement non contrôlé.
lCe PC avec émetteurs WLAN et/ou Bluetooth a été approuvé à des fins d’opération mobile ; aucun
espace minimum entre les antennes et le corps de l’utilisateur n’est requis.
FOR USE WITH MODEL NO. : CF-AA6413C, CF-AA5713A
POUR UTILISER AVEC MODÈLE : CF-AA6413C, CF-AA5713A 20-Ca-1
Read Me First
14
Regulatory Information
For Europe
<Only for model with a “CE” mark on the bottom of the computer>
Declaration of Conformity (DoC)
“Hereby, Panasonic declares that this Personal Computer is in compliance with the es-
sential requirements and other relevant provisions of the Directive 1999/5/EC.”
Hint:
If you want to get a copy of the original DoC of our above mentioned products, please contact our web ad-
dress:
http://www.ptc.panasonic.eu
Authorised Representative:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 11, 22525 Hamburg, Germany
18-E-0
For Australia
For Used in Motor Vehicle
Warning: Notebook Computer may be installed in a motor vehicle and visible to the driver only if used to
support vehicle related functions such as vehicle information, system control, rear or side observation and
navigation. If the Notebook Computer is to be used for work or entertainment purposes, such as television
reception, video play or other work programs, it must be installed in a position where it will NOT:
(a) be visible, directly or indirectly, to the operator of the motor vehicle; or
(b) cause distraction to drivers of other motor vehicles.
Check with individual state laws to determine lawful use of this product while operating within a motor ve-
hicle. If the visual display unit is, or is part of, a driver’s aid, above rule is not applied. “Driver’s aid” includes
closed-circuit television security cameras, dispatch systems, navigational or intelligent highway and vehicle
system equipment, rear view screens, ticket-issuing machines and vehicle monitoring devices.
35-A-1
For India
Declaration of Conformity with the requirements of the e-waste (Management and Handling) Rules, 2011.
(adopted by Notication S.O.1035(E) of Ministry of Environment and Forests)
The Product is in conformity with the requirements of Rule 13 of the e-waste Rules.
The content of hazardous substance with the exemption of the applications listed in SCHEDULE II of the
e-waste Rules:
1. Lead (Pb) - not over 0.1% by weight;
2. Cadmium (Cd) - not over 0.01% by weight;
3. Mercury (Hg) - not over 0.1% by weight;
4. Hexavalent chromium (Cr6+) - not over 0.1% by weight;
5. Polybrominated biphenyls (PBBs) - not over 0.1% by weight;
6. Polybrominated diphenyl ethers (PBDEs) - not over 0.1% by weight.
For the purpose of recycling to facilitate eective utilization of resources, please return this
product to a nearby authorized collection center, registered dismantler or recycler, or Panasonic
service center when disposing of this product.
Please see the Panasonic website for further information on collection centers, etc.
http://www.panasonic.com/in/corporate/sustainability/panasonic-india-i-recycle-program.html
68-M-2
15
Getting Started
First-time Operation
n Preparation
A Check and identify the supplied accessories.
If you do not nd the described accessories, contact your support oce.
• AC Adaptor .....1
Model No: CF-AA6413C,
CF-AA5713A
• AC Cord .......1 • Battery Pack ...1*1
Model No:
CF-VZSU0QW
• Soft Cloth ......1 • Tether .........1
<Only for model with digitizer> <Only for model with touchscreen>
• Digitizer pen ....1 • Stylus .........1
• OPERATING INSTRUCTIONS - Read Me First (This book) .............. 1
*1 Stored in the tablet at the time of packing.
n Latest Information on Windows 10
When Microsoft® Windows® 10 is updated, the screen display or operation procedures
may be changed.
For the latest information on Windows 10, see the following web page.
http://pc-dl.panasonic.co.jp/itn/addendum/
Getting Started
16
First-time Operation
A
1
Attaching the pen (included) to the computer
Use the tether to attach the pen (included) to the computer so
you will not lose it. There are holes (A) to attach it.
1 2 3 4
CAUTION
l Do not pull the tether with excessive force. The stylus may
hit the computer, person’s body or other objects when re-
leased.
2 Connect your computer to a power outlet
A Open the cover.
B Connect your computer to a power outlet.
The battery charging starts automatically.
CAUTION
l Do not disconnect the AC adaptor until the rst-time opera-
tion procedure is completed.
l When using the computer for the rst time, do not connect
any peripheral device except the battery pack and AC adap-
tor.
l Handling the AC adaptor
Problems such as sudden voltage drops may arise during
periods of thunder and lightning. Since this could adversely
aect your computer, an uninterruptible power source (UPS)
is highly recommended unless running from the battery pack
alone.
l When the DC plug is not connected to the computer, dis-
connect the AC cord from your electrical outlet. Power is
consumed simply by having the AC adaptor plugged into an
electrical outlet.
1
2
2
1
17
Getting Started
3 Open the display
A Pull out the handle.
l If you do not pull out the handle before opening the
display, the computer may fall over due to the weight
of the display.
B Push down on the latch (B), and pull it out to release it.
C Hold the corners with both hands, and lift the display
slightly.
D Hold the side of the computer with either of your hands
and then lift up the display to open.
CAUTION
l Do not open the display wider than necessary (180° or
more), and do not apply excessive pressure to the LCD. Do
not open or close the computer holding the edge of the LCD
segment.
4 Turn on the computer
Press and hold the power switch (C) until the power indicator
(D) lights.
CAUTION
l Do not press the power switch repeatedly.
l The computer will be forcibly turned o if you press and hold
the power switch for four seconds or longer.
l Do not perform the following operation until the First-time
Operation is completed.
Touching the release lever (E) and detach lock (F)
Detaching the tablet from keyboard base
Connecting or disconnecting the AC adaptor
Pressing the power switch
Closing the display
Any changes from the default setting of the Setup Utility
l Once you turn o the computer, wait for ten seconds or more
before you turn on the computer again.
l When the CPU temperature is high, the computer may not
start up to prevent overheating of the CPU. Wait until the
computer cools down, and then turn the power on again. If
the computer does not power on even after cooling down,
contact Panasonic Technical Support (è “OPERATING
INSTRUCTIONS - Reference Manual”).
3
2
3
4
1
B
C
D
E
F
4
Getting Started
18
First-time Operation
5 Setup Windows
Follow the on-screen instructions.
l The computer restarts several times.
l After the computer is turned on, the screen remains black
or unchanged for a while, but this is not a malfunction. Wait
for a moment until the Windows setup screen appears.
l During setup of Windows, use the touchpad and clicking to
move the pointer and to click an item.
l Setup of Windows will take approximately 5 minutes.
Go to the next step, conrming each message on the display.
l You can set the Wireless Network after the setup of Win-
dows is complete.
If “Let’s get connected” is displayed, you can select [Skip
this step].
l We recommend that you set the password after the setup
of Windows in complete.
CAUTION
l You can change the user name, password, image and secu-
rity setting after setup of Windows.
l
Use standard characters as a computer name: numbers 0
through 9, uppercase and lowercase letters from A to Z, and
the hyphen (-) character. Do not use the following words and
characters for user name: CON, PRN, AUX, CLOCK$, NUL,
COM1 to COM9, LPT1 to LPT9, LPT, &, space.
If the error message “The computer name is not valid” ap-
pears, check if characters other than the above are not
entered. If the error message still remains on the display, set
the key entry mode to English (“ENG”) and enter characters.
6 Restart the computer
A Click (Start).
B Click (Power) - [Restart].
l A portion of the Panasonic PC Settings Utility functions will
be enabled after the computer restarts.
7 Update the on-screen manual
A Connect to the internet. Sign in to Windows as an admin-
istrator.
For further information, refer to Connect to a network.
B Update the on-screen manual.
Double-click [Manual Selector] on the desktop.
Double-click the [Panasonic PC Settings Utility] on the
desktop screen, and then click [Support] - [Manual] -
[Launch Manual Selector].
Follow the on-screen instructions.
Getting Started
19
8 Create a recovery disc
A recovery disc allows you to install OS and restore its factory
default condition, in case, the recovery partition of the SSD is
damaged.
We recommend creating a recovery disc before you begin using
the computer.
Refer to è OPERATING INSTRUCTIONS -
Reference
Manual
“Important Operation/Settings” “Create a Recovery Disc”
about creating the disc.
NOTE
l To set the password, proceed as follows.
A Click (Start) - (Settings) - [Accounts] - [Sign-in options].
B Click [Add] under “Password”.
l Set the key entry mode to English (“ENG”) and enter characters.
l Remember your password. If you forget the password, you cannot use Windows. Creating a
password reset disk beforehand is recommended.
20
Getting Started
Detaching the tablet from the keyboard base
When detaching the tablet from the keyboard base while it is turned on, note the following points.
CAUTION
l Before detaching the tablet, con rm the following things.
- Save the necessary data.
- Close  les you have opened from removable disks and network drives.
- Remove peripheral devices connecting to the tablet.
l Do not detach the tablet in the conditions below.
When the SD Memory Card indicator is on.
When playing/recording audio  les or displaying motion video such as MPEG  les.
When playing a DVD-Video.
When writing to a disc.
When using communication software or network functions.
A To detach the tablet while it is turned on, perform the following.
CAUTION
l
Before detaching the tablet, check the remaining battery power by pressing the
Fn
and
F9
keyboard keys at the same time.
When the battery status of the “Battery 1” becomes 5% or less, can not detach the tablet
from the keyboard base.
Click in the taskbar of the desktop screen, and then click - [Eject Keyboard Base De-
vice].
“Undock Complete” appears at the bottom right of the screen.
NOTE
l
A con rmation message may appear if an SD memory card is inserted in the keyboard
base. If “Undock Complete” appears, click [OK] in the con rmation message, and proceed
to step B.
The same operation can be performed by pressing the
Fn
and
1
keyboard keys at the
same time.
NOTE
l
To cancel detachment, press the
Fn
and
1
keyboard keys at the same time after the
above operation.
B Release the detach lock (A).
C Slide the release lever (B) in the direction of the arrow.
Getting Started
21
RELEASE
3
2
A B
D Detach the tablet from the keyboard base.
CAUTION
l
When detaching the tablet from the keyboard
base, hold the position at the locations dashed
line circled in the illustration.
The tablet can be attached facing the reverse direction.
CAUTION
l
Depending on the shape of the tablet’s rear, you may not be able to operate the unit with the
tablet attached in the direction illustrated. Be sure to verify this before actual use.
NOTE
l Do not attach/detach the tablet in the rain.
22
Getting Started
Attaching the tablet to the keyboard base
A Push the tablet at the locations dashed line circled in the illustration in a downward direction.
Release lever (B) will return to the direction of the arrow.
B Raise detach the lock (A) above.
NOTE
l
Conrm that the red signs near the detach lock and the release lever can not be seen.
RELEASE
A B
1
2
23
MEMO
Panasonic Corporation
Osaka, Japan
Panasonic System Communications Company of North America
Two Riverfront Plaza
Newark, NJ 07102
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga,
Ontario L4W 2T3
Panasonic Australia Pty. Limited
ACN 001 592 187 ABN 83 001 592 187
1 Innovation Road, Macquarie Park NSW 2113
Web Site : https://panasonic.net/cns/pc/
© Panasonic Corporation 2017
Printed in Japan
HS1217-0
DHQX1427ZA/J1

Navigation menu
