Pantech Co BLADE Dual-Band CDMA Phone with Bluetooth User Manual Masnual II

Pantech Co Ltd Dual-Band CDMA Phone with Bluetooth Masnual II

Masnual II

CDM8992
CHAPTER 2. BASIC OPERATION
20
2
This chapter addresses and explains the basic features for
CDM8992 including:
BASIC OPERATION
BATTERY HANDLING INFORMATION
DO’S
•
Only use the battery and charger approved for use with the CDM8992.
• Only use the battery for the system for which it is specified.
• Only use or replace the battery with a charging system or another battery that has been qualified with the
system per this standard, IEEE-Std-1725-2006. Use of an unqualified battery or charger may present a risk of
fire, explosion, leakage, or other hazard.
• Only use the battery for its original purpose. As an improper battery use may result in a fire, explosion or
other hazard.
• Try to keep batteries in a temperature between 41°F (5°C) and 95°F (35°C). If the battery is stored in
temperatures above or below the recommended range, give it time to warm up or cool down before using.
• Store the discharged battery in a cool, dark, and dry place.
• Purchase a new battery when its operating time gradually decreases after fully charging.
• Properly and promptly dispose of the battery according to local laws.
• Battery usage by children should be supervised.
DON’TS
•
Don’t attempt to disassemble or open the battery – it is a sealed unit with no serviceable parts.
•
Don’t crush, bend or deform, puncture or shred the battery.
•
Don’t drop the phone or battery. If the phone or battery is dropped, especially on a hard surface, and the user
suspects damage, take it to a service center for inspection.
•
Don’t leave the battery in extremely hot or cold temperatures. Otherwise, it could significantly reduce the
capacity and lifetime of the battery.
•
Don’t modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water
or other liquids, expose to fire, explosion or other hazard.
•
Don’t accidentally short-circuit the battery by carrying it in your pocket or purse with other metallic objects
such as coins, clips and pens. This may critically damage the battery.
•
Don’t short-circuit a battery or allow metallic conductive objects to contact battery terminals.
•
Don’t dispose of the battery by placing into a fire.
BASIC OPERATION
TURNING THE PHONE ON AND OFF
USING THE TOUCH SCREEN
USING THE HOME SCREEN
LOCKING OR UNLOCKING THE TOUCH SCREEN AND KEYS
USING THE TASK MANAGER
MENU SUMMARY
MAKING A CALL
ANSWERING A CALL
MISSED CALL NOTIFICATION
WAIT/PAUSE FEATURE
MAKING AN INTERNATIONAL CALL
3-WAY CALLING
CALL WAITING FUNCTION
CALLING A NUMBER FROM CONTACTS
ADJUSTING THE MASTER VOLUME
SPEAKERPHONE MODE
AVAILABLE OPTIONS DURING A CALL
MAKING AN EMERGENCY CALL
USING THE DIRECTORY SERVICE
22
02
03
01
04
05
06
07
08
23
TURNING THE PHONE ON AND OFF
TURNING THE PHONE ON
1. Press and hold the Power Key until the touch screen turns on.
2. Enter your 4-digit lock code if the phone is locked.
The default lock code is the last 4 digits of your phone number.
TURNING THE PHONE OFF
1. Press and hold the Power Key .
2. Tab
Yes
.
•
Immediately change or recharge the battery when “BATTERY LOW” appears on the
display. Memory may possibly be damaged if the phone turns off due to the battery
completely draining.
•
Turn the phone off before removing or replacing the battery. If the phone is on,
unsaved data may be lost.
USING THE TOUCH SCREEN
The touch screen of your phone allows you to select items and perform functions. The
following finger actions help you easily understand how to use the touch screen.
CAUTION
:
•
Do not use sharp tools to avoid scratching the touch screen.
•
Do not allow the touch screen to come in contact with water or chemicals. The touch
screen may malfunction in humid conditions or in chemicals.
•
Do not sit on your phone to prevent from damaging the touch screen.
Tap
: Tap once to select or access a menu or an
option.
Tap and hold
: Tap an item and hold it for more
than 2 seconds to perform functions.
Scroll
: Tap and drag your finger up, down, left, or
right to scroll through items on lists.
Drag
: Tap and hold your finger on an item
and move your finger without losing
contact with the screen to move
the item.
Drag and drop
: Tap and drag your
finger on an item to select and move
it, then lift your finger to drop the
item into place.
Swipe
: Tap and drag your finger
repeatedly to quickly move to a list
or screen.
24
02
03
01
04
05
06
07
08
25
USING THE HOME SCREEN
Your phone’s home screen has three different screens which allow you to access
main menus, multimedia shortcuts and favorite contacts.
To access the home screen unlock the screen and tap the Home Key.
To access another screen, tap the desired screen.
ACCESSING MENUS
1. To access Menu mode from the idle screen, unlock the screen. The Menu mode
screen automatically appears.
2. Tap the menu you want.
3. Tap
Back
to move back one level. Tap the Home Key to return to the Menu
mode screen.
USING FAVORITE CONTACTS
With widgets, you can conveniently use web services, such as social network and
messenger services.
1. Unlock the screen.
2. From the Menu mode screen, swipe the screen left to move to the widget
screen.
3. Drag your finger up or down to view more widgets.
4. Tap the widget icon you want to access.
5. When the phone is connected to the corresponding website, follow the
on-screen prompts.
For service availability, contact your service provider.
USING MULTIMEDIA SHORTCUTS
Multimedia shortcuts allow you to quickly access your favorite items such as
music, pictures, and videos.
ACCESSING A SHORTCUT ITEM
1. Unlock the screen.
2. From the Menu mode screen, swipe the screen right to move to the
multimedia shortcut screen.
3. Tap the item you want to access.
ADDING AN ITEM
1. From the multimedia shortcut screen, tap .
2. Tap
Add
and then tap either
My Music
,
My Picture
,
My Video
or
Shortcuts
.
3. Select an item and tap
Add
. The selected item is shown on the screen.
4. Tap
Done
.
26
02
03
01
04
05
06
07
08
27
DELETING AN ITEM
1. From the multimedia shortcut screen, tap .
2. Tap
Remove
.
3. Tap the item to delete and then tap
Remove
.
4. Tap
Yes
to confirm.
LOCKING OR UNLOCKING THE TOUCH SCREEN AND KEYS
When your phone is closed or idle, the touch screen and keys are automatically
locked to prevent any unwanted phone operations. To unlock, drag [ICON] to up if
the phone is open and idle.
USING THE TASK MANAGER
You can manage multiple applications that are running at the same time. Switch to
other applications without closing the current application you are using.
1. Unlock the screen.
2. Tap and hold the Home Key to open the Task Manager screen. The list of
applications appears.
3. Use the following functions to control applications:
•
To switch to another application, tap the desired application from the list.
•
To close all applications, tap
Close All
.
•
To return to Menu mode, tap
Main Menu
.
•
To return to the previous menu, tap
Back
.
MENU SUMMARY
Main Menu 2ND Depth 3RD Depth 4TH Depth
1. Media Center
1. Apps
2. Search
3. Browser
4. Music & Tones
1. My Ringtones 1. Ringtones
2. My Music
1. Play All Songs
2. All Songs
3. Playlists
4. Artists
5. Genres
6. Albums
7. Manage My Music
8. Sync Music
9. Music Alert
10. Sound Effects
11. Airplane Mode
12. Music Only Mode
3. My Sounds 1. Sounds
4. Sync Music
5. Picture & Video
1. V CAST Vidoes
2. My Pictures
3. My Video
4. Take Picture
5. Record Videos
6. Online Album
2. Messaging
1. New Message
1. Text Message
2. Picture Message
3. Video Message
4. Voice Message
2. Inbox
3. Sent
4. Drafts
28
02
03
01
04
05
06
07
08
29
Main Menu 2ND Depth 3RD Depth 4TH Depth
5. Voicemail
1. Call Voicemail
2. Clear Counter
3. Visual Voicemail
6. Visual Voicemail
7. Mobile IM
8. Email 1. Mobile Email
2. Mobile Web Mail
3. Contacts
1. In Case of Emergency 1. Persinal Info
2. Contact Detail
3. Edit Contacts
4. My Name Card
5. New Contacts
4. Recent Calls
1. All Calls
2. Missed Calls
3. Received Calls
4. Dailed Calls
5. Tools
1. Voice Commands
2. Calculator
3. Tip Calculator
4. Calendar
5. Alarm Clock
6. Stop Watch
7. World Clock
8. Unit Converter
9. Notepad
10.USB Mass Storage
Main Menu 2ND Depth 3RD Depth 4TH Depth
6. Settings
1. Bluetooth Settings 1. Add New Device
2. Device Name
2. Sounds Settings
1. Master Volume
2. Ringtones
3. Caller ID Readout
4. Emergency Tone
5. Alert Vibrate
6. Alert Reminder
7. Power On/Off Sound
8. Service Alerts
9. Touch Audio Feedback
10. Digit Dial Readout
11. Device Connect
3. Display Settings
1. Wallpapers
2. Banners
3. Main Menu Settings
4. Backlight Timer
5. Backlight Brightness
6. Display Theme
7. Font Type
8. Dial Fonts
9. Menu Font Size
10. Clock Format
4. Touch Settings 1. Touch Vibrate
1. Touch Vibrate
Feedback
2. Vibrate Level
5. Phone Settings 1. Voice Commands
Settings
2. Language
3. Location
4. Current Country
5. Security
1. Edit Codes
2. Restrictions
3. Phone Lock Setting
4. Lock Phone Now
5. Restore Phone
30
02
03
01
04
05
06
07
08
31
Main Menu 2ND Depth 3RD Depth 4TH Depth
6. System Select
7. NAM Select 1. Auto NAM
2. Change NAM
6. Call Settings
1. Home Key to Answer
2. Auto Answer with
Handsfree
3. Auto Retry
4. TTY Mode
5. Voice Privacy
6. DTMF Tones
7. Assisted Dialing
7. Memory 1. Save Options
1. Pictures
2. Videos
3. Sounds
2. Phone Memory
1. Phone Memory Usage
2. My Pictures
3. My Videos
4. My Ringtones
5. My Music
6. My Sounds
7. My Contacts
8. Move All to Card
3. Card Memory
1. Card Memory Usage
2. My Pictures
3. My Videos
4. My Ringtones
5. My Music
6. My Sounds
7. My Contacts
8. Move All to Phone
8. USB Mode
9. Phone Info
1. My Number
2. SW/HW Version
3. Icon Glossay
4. Software Update
5. Operating System
MAKING A CALL
1. Unlock the screen and tap
Keypad
.
2. Enter an area code and a phone number.
•
To erase one digit at a time, tap .
•
To erase the entire number, tap and hold .
3. Tap
Call
to dial the number.
To access menus during a call, tap the Home Key.
4. To end the call, tap
END
.
•
If Auto Retry is set to on, the phone will automatically re-dial the number (Refer
to page 75).
•
You can also make a call by using the Voice Commands feature. Please refer to page
50 for more details.
ANSWERING A CALL
1. When a call comes in, unlock the screen and tap
ANSWER
.
•
To ignore the incoming call, tap
IGNORE
.
•
To silence the call ringtone, tap
QUIET
.
2. To end the call, tap
END
or slide the phone down.
If Auto Answer with Handsfree is set to on, an incoming call is answered automatically
after about a few seconds (Refer to page 75).
MISSED CALL NOTIFICATION
When an incoming call is not answered, the missed call icon appears on the touch
screen.
TO DISPLAY THE MISSED CALL ENTRY FROM THE NOTIFICATION
SCREEN:
1. Tap
View Now
.
2. To check the missed call notification at another time, tap
View Later
.
32
02
03
01
04
05
06
07
08
33
TO DISPLAY A MISSED CALL ENTRY FROM RECENT CALLS:
1. Unlock the screen and tap
Recent Calls
.
2. Tap
Missed Calls
.
3. Select an entry from the list.
4. To dial the phone number, tap
Call
. Or, to send a Text, Picture, Video or Voice
Message to the caller, tap
Send Message
.
WAIT/PAUSE FEATURE
Pauses are used for automated systems (i.e., voice mail or calling cards). Insert
a pause after a phone number and then enter another group of numbers. The
second set of numbers is dialed automatically after the pause. This feature is
useful for dialing into systems that require a code.
Wait (W)
The phone pauses dialing and resumes dialing the next number when you tap
CALL
.
1. Unlock the screen and tap
Keypad
.
2. Enter a phone number.
3. Tap
More
and then tap
Wait
.
4. Enter the additional number(s).
5. Tap
Call
to dial or
Save
to save the number.
2-Sec Pause (P)
The phone waits 2 seconds before sending the next string of digits automatically.
1. Unlock the screen and tap
Keypad
.
2. Enter a phone number.
3. Tap
More
and then tap
2-Sec Pause
.
4. Enter additional number(s) (pin number or credit card number).
5. Tap
Call
to dial or
Save
to save the number.
MAKING AN INTERNATIONAL CALL
1. Unlock the phone and tap
Keypad
.
2. Tap and hold . The + required for international calls appears.
3. Enter the country code, area code, and phone number, then tap
Call
.
4. To end the call, tap
END
.
3-WAY CALLING
With 3-Way Calling, you can talk to two people at the same time. When using this
feature, normal airtime rates will be applied for each of the two calls.
1. Unlock the phone and tap
Keypad
.
2. Enter a phone number and tap
Call
.
3. Once you have established the connection, tap
Keypad
and enter the second
phone number you wish to call, and tap
Call
.
4. When you’re connected to the second party, tap
MERGE CALLS
to begin your
3-way call.
5. To end the last dialed call, tap
END LAST DIALED CALL
.
To end all calls, tap
END ALL CALLS
.
If one of the people you called hangs up during your call, you and the remaining caller
stay connected. If you initiated the call and are the first to hang up, all three calls will
be disconnected.
CALL WAITING FUNCTION
If you are on a call and you receive another incoming call, you will hear a beep and the
caller’s phone number will appear on the display. With Call Waiting, you may put the
active call on hold while you answer the other incoming call.
1. To answer another call while on the phone, tap
HOLD CALL AND ANSWER
INCOMING
.
This places the first call on hold.
34
02
03
01
04
05
06
07
08
35
2. To switch back to the first caller, tap
SWAP CALLS
.
3. To end all calls, tap
END ALL CALLS
.
CALLING A NUMBER FROM CONTACTS
1. With the phone in the unlocked, from the Menu mode, tap
Contacts
.
2. Tap the first letter of the contact name you want, or tap and scroll to a
contact from the contact list.
3. Tap to dial the contact number.
If the contact has more than two numbers, the default number of the contact will
be dialed.
ADJUSTING THE MASTER VOLUME
1. With the phone in the unlocked position, from the Menu mode, press the
Volume Keys up or down .
2. Tap or , or press the Volume Keys up or down to adjust the volume
level.
To hear the phone’s volume, tap
Play
on the Master Volume menu.
3. Tap
Set
to save the setting.
Press the Volume Keys up or down
/
to adjust the earpiece volume during a call.
SPEAKERPHONE MODE
The Speakerphone feature lets you hear audio through the phone speaker and talk
without holding the phone.
1. During a call, tap
Speaker
to activate Speakerphone mode.
2. To switch back to Phone mode, tap
Speaker
again.
AVAILABLE OPTIONS DURING A CALL
During a phone call, you can access the following options:
•
Mute
: Allows you to turn off your phone’s microphone so that the other person cannot
hear you.
•
Speaker
: Allows you to talk and hear through the phone’s speaker.
•
Bluetooth
: Allows you to use the Bluetooth feature.
•
Keypad
: Opens the dial screen.
MAKING AN EMERGENCY CALL
The E911 feature automatically places the phone in Emergency call mode when you
dial the preprogrammed emergency number, “911.“ It also operates in Lock mode and
out of the service area.
E911 IN LOCK MODE
When you lock the phone by using the
Lock Phone Now
setting (refer to page 73) or you
are out of the service area, to make an emergency call:
1. When “
Enter Code
” appears, tap
E911
.
2. Tap
Yes
to dial.
The phone maintains Emergency mode for about 5 minutes. When the call
ends, the phone returns to Lock mode.
E911 USING ANY AVAILABLE SYSTEM
To make an emergency call using any available system:
1. With the phone in the unlocked position, from the Menu mode, tap
Keypad
.
2. Enter “
911
” and tap
Call
.
3. The phone will stay in Emergency mode for about 5 minutes. While the phone
is in Emergency mode you can receive an incoming call from any available
system or you can make outgoing calls even in Emergency callback mode.
CDM8992
36
3
This chapter addresses memory functions including:
USING THE DIRECTORY SERVICE
You can make a call to the directory service to find out your local numbers.
1. With the phone in the unlocked position, from the Menu mode, tap
Keypad
.
2. Enter “
411
” and tap
Call
.
MEMORY FUNCTION
CHAPTER 3. MEMORY FUNCTION
ENTERING TEXT
STORING A PHONE NUMBER
EDITING CONTACT ENTRIES
DEFAULT NUMBERS
BACKUP ASSISTANTTM
SENDING A NAME CARD
SPEED DIALING
38
39
02
03
01
04
05
06
07
08
ENTERING TEXT
Learn to enter text by using the virtual keypad on your touch screen.
CHANGING THE TEXT INPUT MODE
1. In text entry mode, tap the
Add Text
field to display the virtual keypad.
2. Change the text input mode - see the chart below.
3. Tap the virtual keys to enter text.
51
6
2
4
3
Number Function
1
Switches to T9 Word or ABC mode. When T9
Word mode is activated, the key turns to show
the line in a red color.
2 Switches to Number mode.
3 Inserts a space.
4 Changes case.
5 Switches to Symbol mode.
6 Clears the entered characters.
ENTERING TEXT USING INPUT MODES
When entering text with the keypad, you can use the following modes:
Mode Function
T9 Word
1. Tap the appropriate virtual keys to enter an entire word.
2. When the word displays correctly, tap Space to insert a space and
enter the next word. If the correct word does not display, tap the
pop-up window and select an alternate word.
abc Tap the appropriate virtual keys until the character you want
appears on the display.
123 Tap the appropriate virtual keys to enter a number.
Symbol Tap the appropriate virtual keys to enter a symbol.
ENTERING TEXT USING THE QWERTY KEYBOARD
You can enter text by using the virtual QWERTY Keyboard.
1. Tap the
Add Text
field.
2. Rotate the phone counter-clockwise to landscape view. The QWERTY Keyboard
screen appears.
3. Enter text as you would use your computer’s keyboard.
1
2 5
4
3
Number Function
1 Changes case.
2 Switches to Number mode.
3 Clears the entered characters.
4 Starts a new line.
5 Inserts a space.
40
41
02
03
01
04
05
06
07
08
STORING A PHONE NUMBER
The Contact list stores up to 1000 entries.
ADDING A NEW CONTACT
1. With the phone in the unlocked position, from the Menu mode, tap
Keypad
.
2. Enter a phone number and tap
Save
.
3. Tap
Add New Contact
.
Use Update Existing to add another phone number to a contact that is already stored
in memory.
4. Select a number type (
Mobile
/
Home
/
Business
/
Mobile 2
/
Fax
).
5. Tap the
Name
field.
6. Enter the contact name and tap
Done
.
7. Enter additional contact information, if necessary.
8. Tap
Save
to save the contact.
9. The contact number re-appears on the screen, tap
Call
to dial the number.
EDITING A CONTACT
Once the basic phone number and name information is stored in your Contacts, you can
edit the contact information.
1. Unlock the screen and tap
Contacts
.
2. Tap the desired contact and then tap
Edit
.
3. Tap the information field you want to edit.
4. Change the data as necessary, then tap
Save
to update the contact entry.
ADDING OR CHANGING GROUPS
To organize your Contacts into groups:
1. Unlock the screen and tap
Contacts
.
2. Tap the desired contact and then tap
Edit
.
3. Scroll down and tap the
Group
field.
4. Tap a group and then tap
Done
.
To create a new group, tap
New Group
and
then enter the name and tap
Done
.
5. Tap
Save
to update the contact entry.
CHANGING THE CALL RINGTONE
To identify who is calling by setting different ringtones for different phone numbers in
your Contacts:
1. Unlock the screen and tap
Contacts
.
2. Tap the desired contact and then tap
Edit
.
3. Scroll down and tap the
Ringtone
field.
4. Select a ringtone by tapping the ringtone name in the
Change to
field.
5. Tap
Save
to update the contact entry.
SETTING A PICTURE CALLER ID
Picture caller ID displays the picture of the person calling when your phone rings. If the
caller’s identity is stored with a picture in Contacts, the name and picture appear on
the screen.
To select a picture to assign to a contact:
1. Unlock the screen and tap
Contacts
.
2. Tap the desired contact and then tap
Edit
.
3. Tap the picture frame on the
Name
field.
4. Tap a picture.
5. Tap
Change
.
6. Tap
Save
to update the contact entry.
ADDING AN EMAIL ADDRESS
To add an email address to a contact entry:
1. Unlock the screen and tap
Contacts
.
2. Tap the desired contact and then tap
Edit
.
3. Scroll down, and tap
Personal Email
or
Business Email
.
42
43
02
03
01
04
05
06
07
08
4. Enter an email address and tap
Done
.
5. Tap
Save
to update the contact entry.
ADDING A SPEED DIAL ENTRY
To add an entry to speed dial:
1. Unlock the screen and tap
Contacts
.
2. Tap the desired contact and then tap
Edit
.
3. Scroll down and tap the
Speed Dials
field.
4. Tap the contact’s number you would like to assign, if applicable.
5. Enter the speed dial number you want to set and tap the entered number
from the list.
You can also tap
and select a speed dial number directly from the list.
6. Tap
Save
update the contact entry.
EDITING CONTACT ENTRIES
You can edit a contact by changing or deleting a phone number, name, and speed dial
number.
EDITING A PHONE NUMBER FROM THE DIAL SCREEN
1. Unlock the screen and tap
Keypad
.
2. Enter the phone number you want to save (up to 32 digits) and tap
Save
.
3. Tap
Update Existing
.
4. Tap an existing contact entry.
5. Tap a number type.
6. If the number is already assigned to the type you selected, tap
Yes
to overwrite
the existing entry.
ADDING A PHONE NUMBER FROM THE CONTACT LIST
1. Unlock the screen and tap
Contacts
.
2. Tap the desired contact and then tap
Edit
.
3. Tap the number type you want to add.
4. Enter a phone number and tap
Done
.
5. Tap
Save
to update the contact entry.
EDITING A STORED PHONE NUMBER
1. Unlock the screen and tap
Contacts
.
2. Tap the desired contact and then tap
Edit
.
3. Tap the number type you want to edit.
4. Tap and enter a new number, and tap
Done
.
5. Tap
Save
to update the contact entry.
EDITING A STORED NAME
1. Unlock the screen and tap
Contacts
.
2. Tap the desired contact and then tap
Edit
.
3. Tap the
Name
field.
4. Tap and enter a new name, and tap
Done
.
5. Tap
Save
to update the contact entry.
DELETING A PHONE NUMBER FROM A CONTACT
1. Unlock the screen and tap
Contacts
.
2. Tap the desired contact and then tap
Edit
.
3. Select a number type to be deleted.
4. Tap and hold and tap
Done
to delete the number.
5. Tap
Save
to update the contact entry.
DELETING A CONTACT ENTRY
1. Unlock the screen and tap
Contacts
.
2. Tap the contact to be deleted.
3. Tap
Erase
and then tap
Yes
.
3. Select one of the following sending options:
•
Send
via Bluetooth
: Allows you to send a name card via Bluetooth.
•
Send via Text Msg
: Allows you to send a name card via Text Message.
•
Send via Picture Msg
: Allows you to send a name card via Picture Message.
•
Send via Video Msg
: Allows you to send a name card via Video Message.
•
Send via Voice Msg
: Allows you to send a name card via Voice Message.
4. Tap the desired contact(s) and then tap
Done
.
5. Tap
Add Recipient
and select one of the following sending options:
•
From Contacts
•
From Favorites
•
From Recent Calls
•
Enter Number
•
Groups
6. Tap the desired recipient(s) and then tap
Done
.
7. Tap
Send
to send the contact as a name card via the selected sending option.
SPEED DIALING
Ideal for frequently dialed numbers, this feature allows contact entries to be dialed via
the virtual keypad with only one or two key tapping.
To open the dial screen from Menu mode, tap
Keypad
.
•
2-9:
Tap and hold the number you wish to connect to for more than 1 second.
1
is already assigned for your voicemail box.
•
10-94:
Tap the first digit and tap and hold the second digit of the number to dial.
•
95, 96, 97, 98 and 99:
Speed Dial entries
95 (#Warranty Center)
,
96 (#DATA)
,
97 (#BAL)
,
98 (#MIN)
and
99 (#PMT)
are already assigned for Verizon Wireless
Account Information.
44
45
02
03
01
04
05
06
07
08
DELETING A SPEED DIAL NUMBER
1. Unlock the screen and tap
Contacts
.
2. Tap
More
and then tap
Speed Dials
.
3. Tap the speed dial number to be deleted.
4. Tap
Remove
and then tap
Yes
.
DEFAULT NUMBERS
You can set each default number for your contacts.
SETTING THE DEFAULT NUMBER
1. Unlock the screen and tap
Contacts
.
2. Tap the desired contact and then tap
Edit
.
3. Scroll down and tap the
Default Number
field.
4. From the
Change to
field, tap the phone number to set as the default number.
5. Tap
Save
to update the contact entry.
BACKUP ASSISTANTTM
Backup AssistantTM is a wireless service that stores a copy of your Contact list to a
secured website.
1. Unlock the screen and tap
Contacts
.
2. Tap
More
and then tap
Backup Assistant
.
3. Follow the on-screen prompts.
SENDING A NAME CARD
You can send a contact as the name card via message or Bluetooth.
1. Unlock the screen and tap
Contacts
.
2. Tap
More
and then tap
Send Name Card
.
CDM8992
CDM8992
4
This chapter addresses accessing the menu and using its functions
and features to customize your CDM8992
MENU FUNCTION
CHAPTER 4. MENU FUNCTION
RECENT CALLS
MY VERIZON
TOOLS
VOICE COMMANDS
CALCULATOR
TIP CALCULATOR
CALENDAR
ALARM CLOCK
STOP WATCH
WORLD CLOCK
UNIT CONVERTER
NOTEPAD
USB MASS STORAGE
SETTINGS
AIRPLANE MODE
MUSIC ONLY MODE
BLUETOOTH
SOUND SETTINGS
DISPLAY SETTINGS
TOUCH SETTINGS
PHONE SETTINGS
CALL SETTINGS
MEMORY
USB MODE
PHONE INFO
MENU FUNCTION
48
49
02
03
01
04
05
06
07
08
RECENT CALLS
The
Recent Calls
menu is a list of the recent phone numbers or Contact entries for calls
you placed, accepted, missed, or blocked. It is continually updated as new numbers are
added to the beginning of the list and the oldest entries are removed from the bottom
of the list.
MISSED CALLS
Displays information about the most recently missed calls. Place a call to a missed call
by simply tapping .
1. Unlock the screen, tap
Recent Calls
and then tap
Missed Calls
.
2. Tap the desired call log to view details or tap
More
to access the options by
refering to
All Calls
.
3. Tap
Call
to dial, or tap
Send Message
to send a message to the number.
If the number is not stored in Contacts, tap
Save to Contacts
to save the
number.
RECEIVED CALLS
Displays information about the most recently received calls. Place a call to a received call
by simply tapping .
1. Unlock the screen, tap
Recent Calls
and then tap
Received Calls
.
2. Tap the desired call log to view details or tap
More
to access the options by
refering to
All Calls
.
3. Tap
Call
to dial, or tap
Send Message
to send a message to the number.
If the number is not stored in Contacts, tap
Save to Contacts
to save the
number.
DIALED CALLS
Displays information about the most recently dialed numbers. Place a call to a dialed
call by simply tapping .
1. Unlock the screen, tap
Recent Calls
and then tap
Dialed Calls
.
2. Tap the desired call log to view details or tap
More
to access additional options.
3. Tap
Call
to dial, or tap
Send Message
to send a message to the number.
If the number is not stored in Contacts, tap
Save to Contacts
to save the
number.
BLOCKED CALLS
This menu appears only when incoming calls are restricted in the
Restrictions
menu.
1. Unlock the screen and tap
Recent Calls
.
2. Tap
More
and then tap
Blocked Calls
.
3. Enter the 4-digit lock code.
The default lock code is the last 4 digits of your phone number.
4. Select a call log to view details.
ALL CALLS
Displays information about all of the most recent calls you have received, dialed, and
missed.
1. Unlock the screen, tap
Recent Calls
. The
All Calls
log is displayed.
2. Tap the desired call log to view details or tap
More
to access the following
options:
•
Sort by
: Changes the sort order of call logs.
•
Erase
: Deletes a call log or multiple call logs.
•
Erase All
: Deletes all call logs.
•
View Timers
: Allows you to view the call timers by call type.
•
Blocked Calls
: Allows you to view blocked calls, if applicable.
3. From the desired call log, tap
Call
to dial, or tap
Send Message
to send a
message to the number.
If the number is not stored in Contacts, tap
Save to Contacts
to save the
number.

Navigation menu
