Pantech IM Single Band Phone with Bluetooth User Manual 080325 CDM8964 IM indd
Pantech Co., Ltd. Single Band Phone with Bluetooth 080325 CDM8964 IM indd
Pantech >
Users Manual
![](/img.php?id=934425&img=bg1.png)
Contents 1
GETTING STARTED .................................... 03
Phone overview ............................................04
Menu overview .............................................06
Charging the battery ...................................07
Install/Remove the microSD card ................08
Using sensitive touch keys ...........................08
Turn on/off the phone .................................08
Display icons .................................................08
Entering text .................................................09
Activating your Virgin Mobile account ......10
Finding your phone’s serial number ...........10
Programming your phone ...........................10
MY ACCOUNT ........................................... 13
Top-Up your account ....................................14
For more information ..................................14
CALLS & CONTACTS .................................15
Making, receiving & ending a call ..............16
Caller identification .....................................17
Call waiting function ...................................17
Speaker phone .............................................17
Vibrate on/off mode ....................................17
Using auto keypad lock function ................17
Making an emergency call ..........................17
Options during a call ...................................17
Call setting ....................................................18
Checking all calls ..........................................19
Speed dialing ................................................19
Using contacts ..............................................20
Voice commands (VR) ...................................21
Using your headset ......................................22
MESSAGING .............................................. 23
Messaging .....................................................24
Received message .........................................24
Voicemail ....................................................... 24
Sent message ................................................25
Creating and send new message ................26
Message templates .......................................26
Create and send new picture message .......26
Create and send new video message .........27
Create and send new email message .........28
Create and send new instant message .......28
Virgin alerts ..................................................28
Erase messages .............................................28
Message setting ............................................28
MULTIMEDIA ............................................31
Camera ..........................................................32
Video camera ................................................33
Pictures and image album ...........................35
Video album .................................................35
Music and sound album ...............................36
Themes album ..............................................36
Other files .....................................................36
Playing game ................................................37
Media player .................................................37
![](/img.php?id=934425&img=bg2.png)
USEFUL FEATURES .................................... 39
Calendar ........................................................40
Alarm clock ...................................................40
Calculator, Tip calculator, Stopwatch &
World clock ...................................................41
Voice memo ..................................................41
SETTINGS .................................................. 43
Ringtones, Alerts & Tones ............................44
Decorate the display ....................................45
Call options ...................................................46
Security ..........................................................46
Msg settings ..................................................47
Game settings ...............................................47
Bluetooth ......................................................47
Memory .........................................................47
To set other options .....................................47
Phone info ....................................................48
CONNECTIVITY .........................................49
Bluetooth ......................................................50
Using the internet ........................................52
VirginXL ........................................................53
My stuff .........................................................54
APPENDIX ................................................. 55
12 Month limited warranty .........................56
Safety information for wireless handheld
phones ...........................................................57
Safety information for FCC RF exposure ....60
SAR information ...........................................60
FDA consumer update .................................61
Emergency calls ............................................66
Compliance with other FCC regulations .....67
General safety ..............................................67
Antenna ........................................................67
Battery ...........................................................68
Adapter/Charger ...........................................69
Recycle your cell phone! ..............................69
FCC Hearing-Aid Compatibility (HAC)
regulations for wireless devices ..................70
U.S.Federal Communications Commission
radio frequency interference statement ....71
FCC compliance information .......................72
2 Contents
CHAPTER 1
GETTING
STARTED
Phone overview
Menu overview
Charging the battery
Install/Remove the microSD card
Using sensitive touch keys
Turn on/off the phone
Display icons
Entering text
Activating your Virgin Mobile account
Finding your phone’s serial number
Programming your phone
CHAPTER 1 GETTING STARTED
![](/img.php?id=934425&img=bg3.png)
Getting Started 5
Left soft key
Perform the functions shown at the
Left bottom of the display.
Microphone
Allows the other caller to hear you
clearly when you are speaking to them.
VR key
Press to enable VoiceSignal
TM
Headset jack
Plug in the Headset Interface Connector.
Side volume key
•
Adjusts the earpiece volume.
When phone is closed:
•
Press Up to turn the
backlight on.
•
Press and hold Down to turn the
melody off when receiving an
incoming call.
•
Press and hold to reject the
incoming call.
Strap hole
Accessory eyelet (for optional straps and lanyards).
H
PHONE OVERVIEW
Open view of your phone
4 Getting Started
SEND key
Press to make or receive a call.
Speaker key
Press to turn Speaker Phone On/-Off.
Earpiece
The earpiece allows you to hear
the other caller.
CLR key
Press to clear a digit from the display or to
return to the previous page.
END key/Power on and off key
Press to end a call or to return to idle mode.
Press and hold to turn phone On/Off.
Right soft key
Perform the functions shown at the
Right bottom of the display.
Manner mode key
Press and hold to turn Manner
mode On/Off.
Navigation and shortcuts keys
Scroll through the menu options.
Left : Access VirginXL menu
Up : Access My Account menu
Right : Access Send Text Msg menu
Down : Access My Stuff menu
Speaker
Music, Ringtones, and
Sounds are played
through the speaker.
Camera lens
Lets you take pictures.
Camera mirror
Displays your reflection while taking
a picture or recording video.
Closed view of your phone
microSD card slot
To insert a microSD card for
use in data and media storage.
Main LCD display
To display the phone's main menu,
features, modes, etc.
Travel charger jeck
Plug in the Travel Charger Interface Connector.
Media Player key
Press for quick access to media player function.
Camera key
Press for quick access to camera function.
Intenna area
![](/img.php?id=934425&img=bg4.png)
H
MENU OVERVIEW
6 Getting Started Getting Started 7
H
CHARGING THE BATTERY
To install/remove your battery
1
.
Remove the battery cover from the unit.
2
.
Slide the battery into the slot located at the
bottom of the unit and press until you hear
the “click”.
3
.
To remove the battery, push down on the top
of the battery and slide it out.
4
.
Slide the battery cover back into the unit.
To charge your battery
1
.
Open the protective cover on the bottom and
connect the charger adapter. Plug the other
end into a standard outlet.
2
.
To remove the adapter connection press the
adapter’s side buttons (1) and pull.
MAIN MENU 2ND DEPTH 3RD DEPTH
8. Surf the Web
9. Tools&Settings 1. Tools
2. Display settings
3. Sound settings
4. Call options
5. Security
6. Msg settings
1. Calendar
2. Alarm clock
3. Tip calculator
4. Calculator
5. World clock
6. Stopwatch
7. Voice commands
8. Voice memo
1. Graphics
2. Menu style
3. Greeting banner
4. Contrast
5. Backlight
6. Themes
1. My ringtones
1. Msg tones
5. Service alerts
3. Volume
2. Dial sounds
4. Power tone
6. Flip tone
7. Key tone
1. Call reminder
2. Call answer
3. Auto answer
1. Lock phone
2. Change lock code
3. Special numbers
4. Erase contacts
5. Erase downloads
6. Reset Phone
1. Msg tones
2. Reminder
3. Text entry
4. Auto text
5. Save to sent
6. Signature
7. Group
8. Auto erase
MAIN MENU 2ND DEPTH 3RD DEPTH
1. Messaging
2. Contacts
3. Media Player
4. My Account
5. VirginXL
6. My Stuff
7. Pictures &
Videos
1. Send text msg
2. Send picture msg
3. Send video msg
4. Send IM
5. Send email msg
6. Inbox
7. Virgin Alerts
8. Voicemail
9. Sent
0. Saved
*. Msg settings
#. Erase msgs
1. Find name
2. Add new
3. Groups
4. Speed dial
1. My music
2. My videos
3. Settings
1. My ringtones
2. My music
3. My videos
4. My graphics
5. My games
6. My themes
7. My other stuff
1. Take a picture
2. Take a video
3. Send picture msg
4. Send video msg
5. My pictures
6. My videos
7. Help
MAIN MENU 2ND DEPTH 3RD DEPTH
9. Tools&Settings 7. Game settings
8. Bluetooth
9. Memory
0. Others
*. Phone info
1. Volume
2. Backlight
3. Messaging
1. Save Options
2. Internal memory
3. External memory
1. Language
2. Airplane mode
3. TTY mode
4. Location
5. Touch key
6. Media Player
1. My phone number
2. Version info
![](/img.php?id=934425&img=bg5.png)
H �
INSTALL/REMOVE THE microSD CARD
The microSD card stores sounds, images, photos and
videos, music, and other files.
1
.
With the microSD card slot
opened, and the gold con-
tacts facing down, insert the
microSD card into the slot.
Push the card in until it it
clicks into place. Close the
microSD card slot.
2
.
To remove the microSD card,
open the microSD card slot.
Use your thumb to press and
release the microSD card. It
will pop-out to allow you to
remove the card. Remove the
card and close the microSD card slot.
H
USING SENSITIVE TOUCH KEYS
Press
,
,
,
touch key sensors are
sensitive to y
our light touch. When press
touch key
sensors, use the tip of your finger to touch the center of
a t
ouch key. If you touch off-center, it may a activate the
nearby function instead.
Note:
The touch sensor level can be adjusted to your preference.
For Touch key, see page 48.
H
TURN ON/OFF THE PHONE
To turn on
1
.
Press and hold [
].
To turn off
1
.
Press and hold [
].
H
DISPLAY ICONS
Display indicators
Icon
Name
Signal Strength
Current signal strength: the more
lines, the stronger the signal.
Phone Status (Normal Voice
Call/No Service/Emergency
Mode/Speakerphone Mode/1X
data call/EVDO data call)
Normal Ring/Ring and Vibrate/
Silence All/Vibrate only/Manner
mode
Text, Voice, Picture, WAP, Multi,
Email, IM (Instant Message)
Alarm/Schedule is set
Bluetooth (On/Connected/Pairing)
TTY/GPS (Location)/Lock Mode
Battery (Strength/Charging)
* Network dependent
8 Getting Started Getting Started 9
H
ENTERING TEXT
The input mode (Alpha editor) will automatically
be activated when necessary to enter letters and
numbers. As shown below, there are 4 available
modes ; Standard input mode (Abc), Input mode
(T9Word), Numeric mode (123) and Symbols. The
input mode indicator appears on the upper right
of the display when letters and numbers are
entered. To select the desired input mode among
the 4 modes below, press
Options
and then select
input mode.
Useful keys
Key
Function
Press to accept a word and add
a space.
In T9Word Mode, press to view
the next matching word if the
highlighted word is not the word
you intended.
Press to delete a character to the
left of the cursor.
Confirm the letters and numbers
you entered.
Press to select a letter case of the
standard text input or text input
mode. and
indicate the standard text input.
and
indicate the predictive text input.
To enter text using the keypad
Key
English
Spanish
1 Key . @ ? ! - , & : ’ / 1
2 Key a b c 2 a á b c 2
3 Key d e f 3 d e é f 3
4 Key g h i 4 g h i í 4
5 Key j k l 5
6 Key m n o 6 m n ñ o ó 6
7 Key p q r s 7
8 Key t u v 8
9 Key w x y z 9
0 Key 0
Predictive mode (T9Word)
T9 mode automatically compares your keystrokes with an
internal dictionary to determine the correct word. The
most commonly used word will appear first. To use T9Abc
mode, press Options
>
T9Word.
1
.
Press
Options
> change the mode to
Options > change the mode to Options
T9Word
.
2
.
Press [
] to [
] to input text.
For example, to write ‘hello’ press [
]
[
] [
] [
] [
].
3
.
Press [
] to search for the word.
![](/img.php?id=934425&img=bg6.png)
Multi-tap input mode
Press the key labeled with the target letter once for the
first letter; press it twice for the second letter, and so on.
1
.
Press
Options
> change the mode to
Options > change the mode to Options
Abc
.
2
.
Press [
] to [
] to input text repeatedly.
For example, to write the letter “C”,
press [
] 3 times.
Numeric mode
Number mode allows you to enter numbers.
1
.
Press
Options
> change the mode to
Options > change the mode to Options
123
.
2
.
Press [
] to [
] to input numbers.
Symbol mode
Allows you to enter symbols.
1
.
Press
Options
> change the mode to
Options > change the mode to Options
Symbols
.
2
.
Press the number for the symbol, and the
symbol appears in the text input screen.
3
.
To display more symbols, press [
/
].
H �
ACTIVATING YOUR VIRGIN MOBILE
ACCOUNT
Before you can start talking, messaging, or
downloading, you need to activate service with
Virgin Mobile. You need your phone’s serial
number to activate your Virgin Mobile account.
To activate your account online go to
www.virgin‐
www.virgin‐
mobileusa.com
and click on Activate. Or call Virgin
Mobile at
1‐888‐322‐1122
.
H �
FINDING YOUR PHONE’S SERIAL
NUMBER
To activate your Virgin Mobile account, you need your
phone’s serial number.
1
.
In standby mode, select
Menu
>
Tools&Settings
>
Phone Info
>
My Number
.
2
.
The serial number is under the letters MEID. It
has 18 digits.
H �
PROGRAMMING YOUR PHONE
Once your account is active, you’ll receive your Virgin
Mobile phone number. When you are ready, follow these
steps to program it into your phone:
1
.
Turn on your phone and wait for it to power
up.
2
.
Dial
##VIRGIN#
(that’s #-#-8-4-7-4-4-6-#)
##VIRGIN# (that’s #-#-8-4-7-4-4-6-#)##VIRGIN#
3
.
You are now in the Programming menu. Scroll
down to
Activate Phone
>
Select
.
4
.
Your screen will say, “Do you want to activate
your phone ?” >
Yes
.
5
.
Your phone will connect to the network, and
then the screen will say “Hi. Press Start to
continue the activation process”. Scroll down
to
Start
>
Start > Start
OK
.
6
.
Your phone will say “We’re getting your phone
number for you,” then your phone will display
your new Virgin Mobile phone number. Write
it down.
10 Getting Started Getting Started 11
7
.
Scroll down to
Finish
>
OK
to complete the
OK to complete the OK
activation process. Your phone will turn off and
back on by itself.
That's it:
It might take a couple of hours to get you set up on our
network, but we’ll send a text message to your phone to
let you know you can start talking. Also, it may take up
to 4 hours for VirginXL, voicemail, and Top-Up features to
come online. But it will be worth the wait. Enjoy!
![](/img.php?id=934425&img=bg7.png)
12 Getting Started
CHAPTER 2
MY ACCOUNT
Top-Up your account
For more information
CHAPTER 2 MY ACCOUNT
![](/img.php?id=934425&img=bg8.png)
14 My Account
CHAPTER 3
CALLS &
CONTACTS
Making, receiving & ending a call
Caller identification
Call waiting function
Speaker phone
Vibrate on/off mode
Using auto keypad lock function
Making an emergency call
Options during call
Call setting
Checking all calls
Speed dialing
Using contacts
Voice commands (VR)
Using your headset
CHAPTER 3 CALLS & CONTACTS
H
TOP-UP YOUR ACCOUNT
When you balance is low, you can Top-Up your
account from your phone:
Top-Up with a Top-Up Card
1
.
In standby mode, press
Menu
>
My Account
.
2
.
Scroll down to the
Top‐Up
link and press
OK
key.
3
.
Enter your Account Pin (vKey) and press
OK
key.
OK key.OK
4
.
Scroll down to select
Login
and press
OK
key.
OK key.OK
5
.
Enter your Top-Up card’s PIN number and press
OK
key.
OK key.OK
6
.
Scroll down to select
Top‐Up Now
and press
Top‐Up Now and press Top‐Up Now
OK
key.
OK key.OK
7
.
You are now topped up. Press [
]
to exit.
Top-Up with a Debit Card, Credit Card, or
PayPal Account
Before you can Top-Up from your phone with a debit card,
credit card, or PayPal account, you need to register the
card or PayPal account at www.virginmobileusa.com.
1
.
In standby mode, press
Menu
>
My Account
.
2
.
Scroll down to the
Top‐Up
link and press
OK
key.
3
.
Enter your Account Pin (vKey) and press
OK
key.
OK key.OK
4
.
Scroll down to select
Login
and press
OK
key.
OK key.OK
5
.
Scroll down and select
Credit Card
or
Credit Card or Credit Card
PayPal
.
6
.
Enter the amount you want to Top-Up and
press
OK
key. You can
OK key. You can OK
Top‐Up
in amounts of
$20, $30, $50, or $90.
7
.
Scroll down to select
Top‐Up Now
and press
Top‐Up Now and press Top‐Up Now
OK
key.
OK key.OK
8
.
At the confirmation screen, select
Yes
.
9
.
You are now topped up. Press [
]
to exit.
Note:
You can also Top-Up at www.virginmobileusa.com.
H
FOR MORE INFORMATION
For more information about your Virgin Mobile
account or Virgin Mobile service, visit
www.virgin‐
www.virgin‐
mobileusa.com
.
![](/img.php?id=934425&img=bg9.png)
Calls & Contacts 17
H
MAKING, RECEIVING & ENDING A CALL
To make a call
1
.
Enter the area code and phone number.
2
.
Press [
].
To answer a call
1
.
Press [
].
To end a call
1
.
Press [
].
Once the call is completed, a call summary is
displayed.
To reject a call
1
.
Press [
] or
Ignore
.
To make a call using call list
Your phone logs up to 270 dialed, received and missed
call numbers.
1
.
In standby mode, press [
] to display the
Recent Calls
list.
Recent Calls list.Recent Calls
2
.
Select a number.
3
.
Press [
] to dial the selected number.
Note:
•
To redial the last number in the Recent Calls list, press
[
].
•
After 270 received, dialed or missed calls, the oldest call
will automatically be erased from the history.
To make a call using contacts
1
.
In standby mode, press
Contacts
to access the
contacts list. Select the desired phone number
and press [
].
To adjusting the call volume
1
.
In call, press
Side volume
key up or down to
adjust the earpiece volume.
To insert a Time/Hard Pause feature
Insert a pause after a phone number and then enter
another group of numbers. The second set of numbers is
dialed automatically after the pause.
1
.
Enter a phone number and then press
Options
.
Select either
Hard pause (“P”)
or
Time pause
(“T”)
.
To switch between two calls
1
.
Press [
To reply to a missed call**
1
.
Press
View
to display the list of missed calls.
View to display the list of missed calls.View
2
.
Select a number to call by pressing the [
/
].
3
.
Press [
To answer a second call**
1
.
Press [
]. The first call is automatically put
on hold.
2
.
Press [
] to end the second call.
16 Calls & Contacts
The call on hold is automatically reconnected.
H
CALLER IDENTIFICATION
Identifies caller by displaying their phone number.
If the caller’s name and number are already stored in your
contact list, name will appear. The caller ID is stored in the
Recent Calls Menu.
H
CALL WAITING FUNCTION
Notifies you of an incoming call when you are already on
a call by sounding a beep tone and displaying the caller’s
phone number.
To answer another call while on the phone,
press [
]. This places the first call on hold. To
switch back to the first caller, press [
] again.
H
SPEAKER PHONE
The Speaker Phone feature lets you hear audio through
the speaker and talk without holding the phone.
To activate the Speaker Phone in idle mode or
while on a call, press [
].
H
VIBRATE ON/OFF MODE
In standby mode, press and hold
to turn
vibrate mode On/Off.
H
USING AUTO KEYPAD LOCK FUNCTION
The slide is closed, touch keypad and navigation
key are automatically locked. If you want to use
touch keypad and navigation key, press and hold
side any keys.
H
MAKING AN EMERGENCY CALL
The 911 feature automatically places the phone in
Emergency Call Mode when you dial the preprogrammed
emergency number, 911.
To making an call 911 in lock mode
1
.
Enter “911” and then press [
].
2
.
The phone maintains the Emergency Mode for
until press
Exit
.
To making an call 911 using any available
system
1
.
Enter “911” and then press [
].
2
.
The phone will stay in Emergency Mode for
until pess [
]. While the phone is in
Emergency Mode for until pess [
], the
phone can receive an incoming call from any
available system or you can make outgoing calls
even in the Emergency Callback Mode.
H
OPTIONS DURING A CALL
Microphone off and on
To switch your phone’s microphone off
1
.
Press
Mute
.
To switch your phone’s microphone back on
1
.
Press
Unmute
.
![](/img.php?id=934425&img=bga.png)
18 Calls & Contacts Calls & Contacts 19
To talk on speaker
1
.
Press
Speaker
.
To put a call on hold and return**
To put a call on hold
1
.
Press [
].
To return to a held call
1
.
Press [
] again.
To save a number in contacts list during a
call
1
.
Press
Options
>
Options > Options
Save
.
To search a number in contact list during a
call
1
.
Press
Options
>
Options > Options
Contacts
>
Contacts > Contacts
Contact List
.
To search for a name or group in contact list
Enter the first letters of the name for Name
Search. The entries are displayed starting with
the first entry matching your input.
To find a name manually in contact list
1
.
Press the [
/
] key.
To view the details of highlighted entry in
contact list
1
.
Press
OK
.
For contacts, see page 20.
To search a number in recent calls during
a call
1
.
Press
Options
>
Options > Options
Recent Calls
.
To read a message during a call
1
.
Press
Options
>
Options > Options
Messaging
>
Inbox
> select a
Inbox > select a Inbox
message.
To write a text message during a call
1
.
Press
Options
>
Options > Options
Messaging
>
Send Text Msg
.
For creating message, see page 26.
Note:
During the call, you can only send text messages.
Multimedia messages cannot be sent or saved.
H
CALL SETTING
To set call reminder
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Call options
>
Call reminder
.
2
.
Select
Every 2 Minutes
,
Every 15 Minutes
or
Off
>
Select
.
To set auto answer
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Call options
>
Auto answer
.
2
.
Select
5 Seconds
,
10 Seconds
,
20 Seconds
or
20 Seconds or 20 Seconds
Off
>
Select
.
To answer with any key press
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Call options
>
Call answer
.
2
.
Select
Slide open + any key
>
Slide open + any key > Slide open + any key
Select
.
Note:
You can answer with any key except [ ] and Ignore.
H
CHECKING ALL CALLS
You can view information about all Recent Calls. For more
options for all, missed, received and outgoing calls press
Options.
To view all calls
1
.
In standby mode, press [
]
>
ALL CALLS
.
2
.
Select the call list and press
OK
to view the
OK to view the OK
details.
To view missed calls
1
.
In standby mode, press [
]
>
MISSED
CALLS
.
2
.
Select the missed call and press
OK
to view the
OK to view the OK
details.
To view received calls
1
.
In standby mode, press [
]
>
RECEIVED
CALLS
.
2
.
Select the received call and press
OK
to view
OK to view OK
the details.
To view dialed calls
1
.
In standby mode, press [
DIALED
CALLS
.
2
.
Select the dialed call and press
OK
to view the
OK to view the OK
details.
To send a message from the recent call list
1
.
Select the call then press
Options
.
2
.
Select
Send txt msg
,
Send pic msg
or
Send video
msg
.
3
.
Write the message
>
Send
.
To delete call logs
1
.
Select the call then press
Options
.
2
.
Select
Erase
>
Yes
.
Note:
If no logs exist, the message “All calls empty” appears.
H
SPEED DIALING
You can dial quickly using speed dialing. Nineteen
numbers from 2 to 10 can be saved.
To set speed dial
1
.
In standby mode, press
Menu
>
Contacts
>
Speed dial
.
2
.
Select an empty entry
>
Assign
.
3
.
Select a person > Select phone number >
Done
.
![](/img.php?id=934425&img=bgb.png)
20 Calls & Contacts Calls & Contacts 21
To update speed dial
1
.
Select a number >
Reassign
>
Yes
.
2
.
Select a person > Select phone number >
Done
.
To remove from speed dial
1
.
Select a number and press
Erase
>
Yes
.
H
USING CONTACTS
You can save names, phone numbers, and up to 500
contacts in the phone.
To add a contact
1
.
In standby mode, press
Menu
>
Contacts
>
Add
new
.
2
.
To save a new contact >
SAVE
.
To view contact list
1
.
In standby mode, press
Menu
>
Contacts
>
Find
name
.
To search for a phone number
1
.
In standby mode, press
Menu
>
Contacts
>
Find
name
.
2
.
Input a name.
3
.
Press
OK
to view the details.
OK to view the details.OK
To call from contact list
1
.
In standby mode, press
Menu
>
Contacts
>
Find
name
.
2
.
Select a contact > [
].
To send contacts information
1
.
In standby mode, press
Menu
>
Contacts
>
Find
name
.
2
.
Select a contact >
Send msg
.
3
.
You can send the information via
Send text
msg
,
Send pic msg
or
Send video msg
.
4
.
Write the message >
Send
.
To delete a contact
1
.
In standby mode, press
Menu
>
Contacts
>
Find
name
.
2
.
Select a contact >
Options
>
Options > Options
Erase
>
Yes
.
To make groups
1
.
In standby mode, press
Menu
>
Contacts
>
Groups
.
2
.
Select an empty entry >
Edit
.
3
.
To save a group options >
SAVE
.
To send a group message
1
.
In standby mode, press
Menu
>
Contacts
>
Groups
.
2
.
Select an existing group and press
Options
>
Options > Options
Send text msg
,
Send pic msg
or
Send video
msg
>
OK
.
3
.
Write the message >
Send
.
To add member in group
1
.
In standby mode, press
Menu
>
Contacts
>
Groups
.
2
.
Select an existing group and press
Options
>
Options > Options
Add member
.
3
.
Select to the entry you wish to add
>
Select
.
To erase a group
1
.
In standby mode, press
Menu
>
Contacts
>
Groups
.
2
.
Select an existing group and press
Options
>
Options > Options
Erase
>
Yes
.
H
VOICE COMMANDS (VR)
Your phone is equipped with an VR (Voice Recognition)
feature. This feature allows you to make calls or use the
phone’s functions by simply using your voice.
All you have to do is talk into the phone, and the phone
will recognize your voice and complete tasks by itself.
To using VR (Voice Recognition)
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Voice commands
. Or, in standby
mode, press the
Side VR
Key.
2
.
The phone displays the Command menu and
prompts you to say the name of the command
you want to use. To complete your task, simply
follow the voice prompts. You can say the
name of the command after you hear a beep.
Call
<Name or #>
1
.
Say
Call <Name>
. Your phone will ask you
to confirm the name you said. Say “Yes“ if it
was repeated correctly. That phone number
will be dialed. If there is more than one
number saved for that contact, you will be
asked to confirm which number to dial.
Send text <Name or #>
1
.
Say
Send Text <Name>
.
(Examples: - Send Text Tom Smith)
Follow instructions for sending a new message
on page 26.
Send picture <Name or #>
Send picture <Name or #>
1
.
Say
Send Picture <Name>
.
(Examples: - Send Picture Tom Smith)
Follow instructions for sending a new message
on page 26.
Lookup <Name>
Lookup <Name>
1
.
Say
Lookup <Name>
.
(Examples: - Lookup Tom Jones)
2
.
The View Contact page will be displayed for
that contact name.
Go to <Menu>
1
.
Say
Go To
followed immediately by one
of the items: (Messaging, Contacts, Media
Player, My account, Virgin XL, My stuff,
PicturesVideos, Surf the Web, Tools&Settings)
![](/img.php?id=934425&img=bgc.png)
22 Calls & Contacts
Check <Item>
1
.
Say
Check
followed immediately by one
Check followed immediately by one Check
of the items: (Status, Voicemail, Messages,
Missed Calls, Time, Signal Strength, Network,
Battery, My Phone Number, Volume)
Tutorial
1
.
Press
Tutorial
. Tutorial will provide you
with additional information on using Voice
Recognition (VR).
To set VR settings
To set VR confirmation
1
.
Press
Settings
>
Settings > Settings
Confirmation
.
2
.
You can control when the system asks you to
confirm a name or number.
3
.
Select
Automatic
,
Always Confirm
or
Never
Confirm
>
OK
.
To set VR adaptation
To set VR adaptation
1
.
Press
Settings
>
Settings > Settings
Adaptation
>
Adapt Voice
.
2
.
Adaptation will take a couple of minutes to
complete. Adapt in a quiet room. Press Start
to begin.
3
.
Press
Start
.
To set VR modes
1
.
Press
Settings
>
Settings > Settings
Modes
.
2
.
Use modes to set the level of audio
assistance.
3
.
Select
Expert Mode
,
Prompt Mode
or
Readout
Mode
>
OK
.
To set VR speakerphone
To set VR speakerphone
1
.
Press
Settings
>
Settings > Settings
Speakerphone
.
2
.
You can control the speakerphone behavior
when voice recognition is started.
3
.
Select
Automatic
,
Always On
or
Always Off
>
OK
.
To set VR about
1
.
Press
Settings
>
Settings > Settings
About
.
2
.
The VSuite version appears.
H
USING YOUR HEADSET
To send or receive a call using your headset, connect the
headset to the jack on your phone. Once connected, the
button on the headset controls the following:
While in standby mode
1
.
Press the button once to list recent calls.
2
.
Press the button twice to redial the last call.
While the phone is closed
1
.
Press the button once to receive a call.
2
.
Press the button once to end the call.
CHAPTER 4
MESSAGING
Messaging
Receive message
Voicemail
Sent message
Creating and send new message
Message templates
Create and send new picture message
Create and send new video message
Create and send new email message
Create and send new instant message
Virgin alerts
Erase messages
Messaging setting
CHAPTER 4 MESSAGING
![](/img.php?id=934425&img=bgd.png)
Messaging 25
H
MESSAGING
The messaging feature is an integrated messaging
application that lets you send and receive Text, Picture,
Email, and Instant Messaging (IM) messages.
To delete a message
1
.
Select a message >
Options
>
Erase
>
Yes
.
To reply to a message
1
.
Select a message >
Select
>
View
>
Reply
.
H
RECEIVED MESSAGE
To view new received messages
1
.
Press
View
.
To read message using Inbox
1
.
In standby mode, press
Menu
>
Messaging
>
Inbox
.
2
.
Select a received message >
OK
.
To save new numbers from received
message
1
.
In standby mode, press
Menu
>
Messaging
>
Inbox
.
2
.
Select a received message >
View
>
View > View
Options
>
Save Contact
.
3
.
Select
Add new
or
Add new or Add new
Existing Entry
.
4
.
Edit contacts list >
Save
.
To launch URL address from a received
message
1
.
Open the message with URL address is in.
2
.
Press
Options
>
Options > Options
Launch URL
.
3
.
Select the URL address in the message.
To save an object in a received multimedia
message
1
.
Open the multimedia message.
2
.
Select the object >
Options
>
Save attached
.
Note:
If image file saved, It will be saved in one of the categories
in My Stuff. If sound file saved, It will be saved in Voice
Memo.
For My Stuff, see page 35.
To listen to voice messages
1
.
In standby mode, press
Menu
>
Messaging
>
Voicemail
.
It will automatically call the voicemail center.
H
VOICEMAIL
New voicemail alerts are sent via an SMS text message.
These messages indicate how many new and urgent
voicemails are in your voicemail box. Open the text
message to view the number of new voice messages in
your voicemail. If a caller leaves a callback number, this
number will also be sent via an SMS text message. Displays
the number of voice mails and accesses them by pressing
and holding the [ ].
24 Messaging
To setup your voicemail
Before your phone can receive voicemail messages, you
must set up a 4-10 digit passcode and record a personal
voicemail greeting. When you have set up your voicemail,
all unanswered calls to your phone are automatically
transferred to voicemail, even if your phone is in use or
turned off.
1
.
In standby mode, press
Menu
>
Messaging
>
Voicemail
or press and hold
Voicemail or press and holdVoicemail
[
].
2
.
Follow the system prompts to setup your
password and record a greeting.
To access your voicemail box
1
.
In standby mode, press
Menu
>
Messaging
>
Voicemail
or press and hold
Voicemail or press and holdVoicemail
[
].
2
.
Follow the system prompts to enter your
password and retrieve your messages.
H
SENT MESSAGE
To edit a sent message
1
.
In standby mode, press
Menu
>
Messaging
>
Sent
.
2
.
Select a sent message >
View
>
View > View
Options
>
Options > Options
Edit
.
3
.
To send the edited message >
Send
.
Note:
In case of pening or failed msg, this option is displayed.
To call a number in a sent message
1
.
In standby mode, press
Menu
>
Messaging
>
Sent
.
2
Select a sent message >
View
>
Options
>
Call
]
.
To forward message to another recipient
1
.
In standby mode, press
Menu
>
Messaging
>
Sent
.
2
.
Select a sent message >
View
>
View > View
Options
>
Options > Options
Forward
.
3
.
Enter phone number >
Done
>
Send
.
To save sent message
1
.
In standby mode, press
Menu
>
Messaging
>
Sent
.
2
.
Select a sent message >
View
>
Options
>
Save
msg.
Note:
It will be saved in Saved folder.
To save new numbers from sent message
1
.
In standby mode, press
Menu
>
Messaging
>
Sent
.
2
.
Select a sent message >
View
>
View > View
Options
>
Options > Options
Save
Contact
.
3
.
Select
Add new
or
Add new or Add new
Existing Entry
.
4
.
Edit contacts list >
SAVE
.
![](/img.php?id=934425&img=bge.png)
26 Messaging Messaging 27
H
CREATING AND SEND NEW MESSAGE
To send new text message
1
.
In standby mode, press
Menu
>
Messaging
>
Send text msg
.
2
.
Enter phone number or press
Options
>
Contacts
.
3
.
Find the recipient and check the box by
pressing
Mark
>
Mark > Mark
OK
>
Done
.
4
.
Write the message >
Send
.
5
.
To view sent message press
Menu
>
Messaging
>
Sent
.
Note:
All successful or failed messages will be saved in Sent
folder.
To view all sent messages
1
.
In standby mode, press
Menu
>
Messaging
>
Sent
.
H
MESSAGE TEMPLATES
When you often use same phrases you can save the
message as a template message.
To save the message as a template
1
.
In standby mode, press
Menu
>
Messaging
>
Msg settings
>
Msg settings > Msg settings
Auto text
>
Auto text > Auto text
Options
>
Options > Options
New
.
2
.
Write a message >
Save
.
To edit the saved template message
1
.
In standby mode, press
Menu
>
Messaging
>
Msg settings
>
Msg settings > Msg settings
Auto text
.
2
.
Select the message.
3
.
Press
Options
>
Options > Options
Edit
.
4
.
Edit a message >
Save
.
H �
CREATE AND SEND NEW PICTURE
MESSAGE
You can add picture and sound file to picture message.
If message exceeds 200Kb an error message will pop up.
To send new picture message
1
.
In standby mode, press
Menu
>
Messaging
>
Send picture msg
.
2
.
Enter phone number or press
Options
>
Contacts
.
3
.
Find the recipient and check the box by
pressing
Mark
>
Mark > Mark
OK
>
Done
.
4
.
Write the
Subject
>
Text
>
>
Audio
>
Send
.
5
.
To view sent message press
Menu
>
Messaging
>
Sent
.
Note:
All successful or failed messages will be saved in Sent
folder.
To add saved picture in the message
1
.
Press Navigation Key down to select
window.
2
.
Press
Pictures
.
3
.
Select a saved image >
Select
.
To add new picture to a message
1
.
Press Navigation Key down to select
window.
2
.
Press
Pictures
>
Camera
.
3
.
Take the picture.
To add saved sound to the message
1
.
Press Navigation Key down to select
Audio
window.
2
.
Press
Sounds
.
3
.
Select a saved sound >
Select
.
To add new sound to the message
1
.
Press Navigation Key down to select
Audio
window.
2
.
Press
Sounds
>
Record
>
New
.
3
.
Record the sound
>
Save
.
4
.
Select a recorded sound >
Select
.
H �
CREATE AND SEND NEW VIDEO
MESSAGE
You can add picture and sound file to video message.
To send new video message
1
.
In standby mode, press
Menu
>
Messaging
>
Send video msg
.
2
.
Enter phone number or press
Options
>
Contacts
.
3
.
Find the recipient and check the box by
pressing
Mark
>
Mark > Mark
OK
>
Done
.
4
.
Write the
Subject
>
Text
>
Video
>
Send
.
5
.
To view sent message press
Menu
>
Messaging
>
Sent
.
Note:
All successful or failed messages will be saved in Sent.
To add saved video in the message
1
.
Press Navigation Key down to select
Video
window.
2
.
Press
Videos
.
3
.
Select a saved video >
Select
.
To add new video to a message
1
.
Press Navigation Key down to select
window.
2
.
Press
Videos
>
Camera
.
3
.
Record a video clip
>
Stop
>
Save
.
![](/img.php?id=934425&img=bgf.png)
28 Messaging
H �
CREATE AND SEND NEW EMAIL
MESSAGE
You can send and receive email messages from your
phone. Check Virgin Mobile’s web site at www.virginmobi‐
leusa.com for availability and pricing.
To launch mobile email
1
.
In standby mode, press
Menu
>
My Stuff
>
My other stuff
>
Mobile Email
.
Or,
in standby
mode, press
Menu
>
Messaging
>
Send email
msg
.
H �
CREATE AND SEND NEW INSTANT
MESSAGE
You can send and receive instant messages (IMs) from your
phone. Check Virgin Mobile’s Web site at www.virginmobi‐
leusa.com for availability and pricing.
To launch instant message
1
.
In standby mode, press
Menu
>
My Stuff
>
My other stuff
>
Mobile IM
.
Or,
in standby
mode, press
Menu
>
Messaging
>
Send IM
.
H �
VIRGIN ALERTS
To review the Virgin Alerts you’ve received
1
.
In standby mode, press
Menu
>
Messaging
>
Virgin Alerts
>
View
.
H �
ERASE MESSAGES
Erase old messages to free up memory in your phone.
To erase all messages in each folders
1
.
In standby mode, press
Menu
>
Messaging
>
Erase msgs
.
2
.
Select
Inbox
,
Inbox,Inbox
Saved
,
Saved, Saved
Sent
or
All
>
Yes
.
H �
MESSAGE SETTING
Before you can send or receive messages using your
phone, you must configure their settings first.
This information is normally pre-configured in the phone
by your service provider.
To set Message Tones
1
.
In standby mode, press
Menu
>
Messaging
>
Msg settings
>
Msg tones
.
2
.
Select
My ringtones
or
My ringtones or My ringtones
Vibrate mode
.
•
My ringtones:
Select desired ringtone
>
Assign
.
Note:
To play ringtone, press Play.
•
Vibrate mode:
Select
On
or
Off
>
OK
.
To set Reminder Message
1
.
In standby mode, press
Menu
>
Messaging
>
Msg settings
>
Reminder
.
2
.
Select
On
or
Off
>
Off > Off
OK
.
Messaging 29
To set Text Entry Mode
1
.
In standby mode, press
Menu
>
Messaging
>
Msg settings
>
Text entry
.
2
.
Select
T9Word
,
T9Word, T9Word
Abc
,
ABC
or
ABC or ABC
123
>
OK
.
To set Save to Sent message
1
.
In standby mode, press
Menu
>
Messaging
>
Msg settings
>
Save to sent
.
2
.
Select
Auto
,
Off
or
Off or Off
User Confirmation
>
OK
.
To create a signature for a messages
1
.
In standby mode, press
Menu
>
Messaging
>
Msg settings
>
Signature
.
2
.
To check
Use signature
> Enter your signature
in the text field >
OK
.
To create and edit the contacts group
1
.
In standby mode, press
Menu
>
Messaging
>
Msg settings
>
Group
.
2
.
For instructions on how to create a group, see
page 20.
To set Auto Erase Message
1
.
In standby mode, press
Menu
>
Messaging
>
Msg settings
>
Auto erase
.
2
.
Select
Auto
or
Off
>
Off > Off
OK
.
![](/img.php?id=934425&img=bg10.png)
30 Messaging
CHAPTER 5
MULTIMEDIA
Camera
Video camera
Pictures and image album
Video album
Music and sound album
Themes album
Other files
Playing game
Media player
CHAPTER 5 MULTIMEDIA
![](/img.php?id=934425&img=bg11.png)
Multimedia 33
H
CAMERA
You can take pictures using built-in camera.
The photos can be saved and sent using
multimedia messages.
To set camera settings
1
.
In standby mode, press
Menu
>
Pictures &
Videos
>
Take a picture
.
2
.
Press
Options
before you take a picture.
Options before you take a picture.Options
Icons for camera
Icon
Menu
Options
Resolution
Display photo resolution
1280x960, 1024x768,
640x480, 320x240,
176x144, 160x120
Zoom 1x, 2x, 4x, 8x
Brightness +2, +1 0 -1, -2
Settings for camera
Menu
Sub Menu
Options
Take video To switch video mode.
Self timer Off, 5 Seconds,
10 Seconds, 15 Seconds
Fun frames
Normal, I love you,
Clown, Mona Lisa, I miss
you, Punch, Happy bus,
Frame, Happy birthday,
Monkey, Rabbit
controls
White
balance
Auto, Sunny, Cloudy,
Tungsten, Fluorescent
Color effect Normal, Gray, Sepia,
Negative
Settings
Resolution
1280x960, 1024x768,
640x480, 320x240,
176x144, 160x120
Quality High, Medium, Low
Shutter
sound
Off, Default, Say
“Cheese”, “Ready! 123”
To increase or decrease the brightness
1
.
Press [
/
].
To zoom in and out
1
.
Press [
/
].
To take a picture
1
.
In standby mode, press
Menu
>
Pictures &
Picture mode
Zoom
Resolusion
Self timer
32 Multimedia
Videos
>
Take a picture
.
2
.
Focus on the object >
OK
.
Note:
Your picture will be saved automatically to My Stuff > My
graphics > My pictures or Menu > Pictures & Videos > My
pictures.
To view the taken picture
1
.
In standby mode, press
Menu
>
Pictures &
Videos
>
My pictures
.
2
.
Select the picture >
View
.
3
.
To use options >
Options
.
My pictures option
Functions
Process
To send picture
message Options > Send
Set a photo for a
specific contact Options > Assign > Caller ID
Set as standby screen Options > Assign > Wallpaper
Set as screensaver Options > Assign >
Screensaver
To upload web site Options > Upload to My Pix
To move the picture to
the miniSD card Options > Move to card
Delete the picture Options > Erase
Take a new picture Options > Take pic
Rename the picture Options > Rename
Lock/Unlock the picture Options > Lock/Unlock
View the information Options > File info
Delete all pictures Options > Erase all
To send pictures using multimedia message
1
.
In standby mode, press
Menu
>
Pictures &
Videos
>
Send picture msg
.
2
.
Write the message
>
Send
.
H
VIDEO CAMERA
You can record videos using built-in camera.
The videos can be saved and sent using
multimedia message.
To set video camera settings
1
.
In standby mode, press
Menu
>
Pictures &
Videos
>
Take a video
.
2
.
Press
Options
before you take a picture.
Options before you take a picture.Options
Brightness
Video mode
Zoom
File size
Self timer
Brightness
![](/img.php?id=934425&img=bg12.png)
34 Multimedia Multimedia 35
Icons for video
Icon
Menu
Options
Resolution Display photo resolution
176x144
Zoom 1x, 2x, 4x, 8x
Brightness +2, +1 0 -1, -2
Settings for video
Menu
Sub Menu
Options
Take pic To switch camera mode.
Self timer Off, 5 Seconds,
10 Seconds, 15 Seconds
controls
White
balance
Auto, Sunny, Cloudy,
Tungsten, Fluorescent
Color effect Normal, Gray, Sepia,
Negative
Settings
Quality High, Medium, Low
Cue sound Off, Default, “Action”/
“Cut”, “Ready”/“Stop”
Mute/
Unmute To set mute On/Off
To increase or decrease the brightness
1
.
Press [
/
].
To zoom in and out
1
.
Press [
/
].
To take a video
1
.
In standby mode, press
Menu
>
Pictures &
Videos
>
Take a video
.
2
.
Focus on the object >
Record
.
Note:
Your picture will be saved automatically to My Stuff >
My videos > All videos or Menu > Pictures & Videos > My
videos.
To view the recorded video
1
.
In standby mode, press
Menu
>
Pictures &
Videos
>
My videos
.
2
.
Select the video clip >
Play
.
3
.
To use options >
Options
.
My videos option
Functions
Process
To send video message Options > Send
Delete the video clip Options > Erase
Set as standby screen Options > Assign > Wallpaper
Set as screensaver Options > Assign >
Screensaver
To move the video clip
to the miniSD card Options > Move to card
Record a new video clip Options > Take video
Rename the video clip Options > Rename
Lock/Unlock the
video clip Options > Lock/Unlock
View the information Options > File info
Delete all video clips Options > Erase all
To send videos using multimedia message
1
.
In standby mode, press
Menu
>
Pictures &
Videos
>
Send video msg
.
2
.
Write the message, press
Send
.
H
PICTURES AND IMAGE ALBUM
You can view, assign, delete, moves to external memory
or to phone the saved pictures. The supported formats are
JPEG, GIF, BMP and PNG.
To view the downloaded or saved image
and pictures
1
.
In standby mode, press
Menu
>
My Stuff
>
My
graphics
>
My pictures
.
2
.
Select the picture >
View
.
To set as wallpaper in the display
1
.
In standby mode, press
Menu
>
My Stuff
>
My
graphics
>
Wallpapers
.
2
.
Select a picture >
Assign
.
3
.
Select
Wallpaper
or
Screensaver
>
Select
.
To set as screensaver in the display
1
.
In standby mode, press
Menu
>
My Stuff
>
My
graphics
>
Screensaver
.
2
.
Select a picture >
Assign
.
3
.
Select
Wallpaper
or
Screensaver
>
Select
.
H
VIDEO ALBUM
You can play, delete, moves to external memory or to
phone the saved videos.
To play the downloaded or saved video clip
1
.
In standby mode, press
Menu
>
My Stuff
>
My
graphics
>
My videos
.
2
.
Select
All videos
> Select the video >
Play
.
To move videos to external memory
1
.
In standby mode, press
Menu
>
My Stuff
>
My
graphics
>
My videos
.
2
.
Select
All videos
> Select the video >
Options
>
Move to card
>
Move to card >Move to card
Yes
.
Video player fuction key
Key
Description
Press Fast forward
Press Play next video clip
Press Fast rewind
Press Play previous video clip
![](/img.php?id=934425&img=bg13.png)
36 Multimedia
OK Play/Pause
Left Soft Key Mute/Unmute
Right Soft Key
(Options Menu) Full screen/Repeat
Side Volume Key Volume Up/Down
H
MUSIC AND SOUND ALBUM
Saved sounds can be played, set, deleted or moved
to external memory or the phone. Supported formats
MIDI, SMAF, iMelody and MP3.
To listen the saved music file
1
.
In standby mode, press
Menu
>
My Stuff
>
My music
.
2
.
Select
All songs
> Select a music >
Play
.
Music player fuction key
Key
Description
Press Play next music file
Press Fast forward
Press Play previous music file
Press Fast rewind
OK Play/Pause
Left Soft Key Mute/Unmute
Right Soft Key
(Options Menu)
Play all/Shuffle/Repeat/
Full screen/Hide
Side Volume Key Volume Up/Down
To listen the recorded sound
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Voice memo
.
2
.
Select a sound >
OK
.
To set as a ringtone
1
.
In standby mode, press
Menu
>
My Stuff
>
My ringtones
.
2
.
Select a sound >
Assign
.
3
.
Select
Contact
,
Contact, Contact
Group
,
All contacts
or
All callers
>
Select
.
H
THEMES ALBUM
To set as the theme
1
.
In standby mode, press
Menu
>
My Stuff
>
My themes
.
2
.
Select an image >
Set
.
H
OTHER FILES
To view the list of the files
1
.
In standby mode, press
Menu
>
My Stuff
>
My other stuff
.
My other stuff.My other stuff
Multimedia 37
H
PLAYING GAME
Your phone contains game to play.
To play the game
1
.
In standby mode, press
Menu
>
My Stuff
>
My
games
.
2
.
Select a game
>
Play
.
To end the game
1
.
Press [
] >
Yes
.
To set the game options
To set the game volume
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Game settings
>
Volume
.
2
.
Select
Silent
or
Silent orSilent
Level 1 ~ Level 5
>
OK
.
To set the game backlight
To set the game backlight
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Game settings
>
Backlight
.
2
.
Select
5 Seconds
,
10 Seconds
,
30 Seconds
,
Always On
or
Disable
>
Select
.
To display incoming messages while playing
To display incoming messages while playing
a game
a game
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Game settings
>
Messaging
.
2
.
Select
Icon & Message
or
Icon only
>
Select
.
H
MEDIA PLAYER
You can easy to use playback feature with a Media Player.
It allows you to play video clip or music file.
To play music file in my music folder
1
.
In standby mode, press
Menu
>
Media Player
>
My music
.
2
.
Select music play mode >
Select
.
For music and sound album, see page 36.
To create a playlist (Artist/Album/Genre)
1
.
In standby mode, press
Menu
>
Media Player
>
My music
>
My music >My music
Playlists
.
2
.
Press
Options
>
Create new
>
OK
.
To add a music in playlist (Artist/Album/
Genre)
1
.
In standby mode, press
Menu
>
Media Player
>
My music
>
My music >My music
Playlists
.
2
.
Press
Options
>
Add song
> Select a music file
>
Mark
>
OK
.
To play video clip in my videos folder
1
.
In standby mode, press
Menu
>
Media Player
>
My videos
.
2
.
Select
Play all
or
All videos
>
All videos > All videos
Select
.
For video album, see page 35.
![](/img.php?id=934425&img=bg14.png)
38 Multimedia
CHAPTER 6
USEFUL
FEATURES
Calendar
Alarm clock
Calculator, Tip calculator, Stopwatch & World Clock
Voice memo
CHAPTER 6 USEFUL FEATURES
To set the play mode
1
.
In standby mode, press
Menu
>
Media Player
>
Settings
.
2
.
Select
Repeat All
,
Shuffle
or
Auto off
>
Auto off > Auto off
Select
.
![](/img.php?id=934425&img=bg15.png)
H
CALENDAR
Calendar helps you manage your schedule including your
time for calls or special days. You can set alarm service on
a set date with this function.
To view calendar
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Calendar
.
Note:
Monthly view is displayed as default.
In the monthly view
To
Press
Move to another day
[
]
for Previous
[
]
for Next
Move to another week
[
]
for Previous
[
]
for Next
To create a new event
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Calendar
.
2
.
Select a day
>
New
.
3
.
On the
Edit schedule
screen, select and input an
event item by item for registration >
Save
.
To edit a event
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Calendar
.
2
.
Select a saved event
>
Edit
.
3
.
On the
Edit schedule
screen, select and edit an
event item by item for registration >
Save
.
To erase a saved event
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Calendar
.
2
.
Select a saved event
>
Erase
>
Yes
.
H
ALARM CLOCK
To set an alarm
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Alarm clock
.
2
.
Select location >
Select
> Edit a new alarm >
Select > Edit a new alarm > Select
Save
.
To view the saved alarms
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Alarm clock
.
To edit existing alarms
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Alarm clock
.
2
.
Select an existing alarm >
Select
> Edit an alarm
Select > Edit an alarm Select
>
Save
.
40 Useful Features Useful Features 41
H �
CALCULATOR, TIP CALCULATOR,
STOPWATCH & WORLD CLOCK
To use the calculator
Use the Calculator for basic mathematical equations.
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Calculator
.
2
.
Enter the first number and use [
/
/
/
].
3
.
Enter the second number and press
OK
to
OK to OK
calculate.
Use [
] to use the decimal point and [
]
to change the number from positive or negative.
To use tip calculator
The Tip Calculator helps you calculate how much tip to
include with a bill.
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Tip calculator
.
2
.
Enter the amount of your bill and move the
next field
Tip(%)
.
3
.
Enter the percentage amount to tip and move
the next field
Split
.
4
.
Enter the amount of split number. The new bill
amount is shown.
To use the stopwatch
The Stopwatch counts the time your spend for an activity.
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Stopwatch
.
2
.
Press
Start
to start stopwatch.
Start to start stopwatch.Start
3
.
Press
Cont
to save Lap time (Max eight Lap
Cont to save Lap time (Max eight Lap Cont
time).
4
.
Press
Stop
to stop stopwatch.
5
.
Press
Reset
to reset stopwatch.
Reset to reset stopwatch.Reset
To use world clock
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
World clock
.
2
.
Use [
/
/
/
] to select different
cities.
3
.
To set daylight saving, press
DST
.
DST.DST
4
.
Edit a DST item by item for registration >
Save
.
H
VOICE MEMO
To record voice memo
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Voice memo
>
New
.
2
.
To stop recording and save voice memo, press
Save
.
To listen to the recording voice memo
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Voice memo
.
2
.
Select recorded voice memo >
OK
.
![](/img.php?id=934425&img=bg16.png)
42 Useful Features
CHAPTER 7
SETTINGS
Ringtones, Alerts & Tones
Decorating the display
Call options
Security
Msg settings
Game settings
Bluetooth
Memory
To set other options
Phone info
CHAPTER 7 SETTINGS
To send voice memo using multimedia
message
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Voice memo
.
2
.
Select a voice memo >
Options
>
Send message
.
3
.
Write the message
>
Send
.
To rename saved voice memo
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Voice memo
.
2
.
Select a voice memo >
Options
>
Rename
.
3
.
Edit name >
Save
.
To erase saved voice memo
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Tools
>
Voice memo
.
2
.
Select a voice memo >
Options
>
Erase
>
Yes
.
![](/img.php?id=934425&img=bg17.png)
Settings 45
H
RINGTONES, ALERTS & TONES
To set call ringtones
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Sound settings
>
My ringtones
.
2
.
Select a ringtones >
Assign
.
Note:
To play/stop sound, press Play or Stop.
To set msg tones
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Sound settings
>
Msg tones
.
2
.
Select
My ringtones
or
My ringtones or My ringtones
Vibrate mode
>
Select
.
•
My ringtones:
Select desired Msg tones >
Assign
.
Note:
To play/stop sound, press Play or Stop.
•
Vibrate mode:
Select
On
or
Off
>
Off > Off
Select
.
To set service alerts
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Sound settings
>
Service alerts
.
2
.
Select
Minute beep
or
Call Connect
>
Call Connect > Call Connect
On
or
Off
>
Select
.
To set the ringer volume
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Sound settings
>
Volume
.
2
.
Select
Ringer volume
,
Voice call
or
Voice call or Voice call
Speaker
phone
>
Select
.
•
Ringer volume:
Select
Silent
,
Silent,Silent
Vibrate On
,
Low
,
Low, Low
Medium
or
High
>
SET
or
OK
.
Note:
To play/stop ringer, press Play or Stop.
•
Voice call:
Select
Level 1
~
Level 5
>
Level 5 > Level 5
OK
.
•
Speaker phone:
Select
Level 1
~
Level 5
>
OK
.
To set dial sounds
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Sound settings
>
Dial sounds
.
2
.
Select
DTMF
or
DTMF orDTMF
Instrument
>
Select
.
To set power tone on/off
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Sound settings
>
Power tone
.
2
.
Select
Power on tone
or
Power off tone
>
On
or
Off
>
Off > Off
Select
.
To set flip tone
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Sound settings
>
Flip tone
.
2
.
Select
On
or
Off
>
Off > Off
Select
.
To set key tone
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Sound settings
>
Key tone
.
2
.
Select
Silent
,
Silent,Silent
Level 1
~
Level 5
>
Level 5 > Level 5
OK
.
44 Settings
H
DECORATE THE DISPLAY
To set the graphics
To set the wall
paper
paper
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Display settings
>
Graphics
>
Wallpapers
.
2
.
Select
or
Video
.
3
.
Select wallpaper image >
Select
or
Select or Select
OK
.
To set the screensaver timeout
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Display settings
>
Graphics
>
Screensaver
>
Timeout setting
.
2
.
Select
Off
,
Off,Off
5 Seconds
,
10 Seconds
,
20 Seconds
or
30 Seconds
>
Select
.
To set the screensaver image
To set the screensaver image
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Display settings
>
Graphics
>
Screensaver
>
Screensaver
.
2
.
Select screensaver image
>
Select
.
Note:
To preview image, press OK.
To set the clock format
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Display settings
>
Graphics
>
Clock format
.
2
.
Select
Digital
,
Analog
,
Digital+Analog
or
Off
>
Select
.
To view the menu style
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Display settings
>
Menu style
.
2
.
Select
Graphic type
or
List type
>
Select
.
To enter greeting message
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Display settings
>
Greeting banner
.
2
.
Edit greeting banner message, press Navigation
Key down, select
Font
color, then press
Font color, then press Font
Navigation Key down and select
Outline
color
>
Save
.
To set contrast display
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Display settings
>
Contrast
.
2
.
Select
Highest
,
Highest,Highest
High
,
Medium
,
Low
or
Lowest
>
Select
.
To set time for backlight
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Display settings
>
Backlight
.
2
.
Select
Display
or
Display or Display
Keypad
>
Keypad > Keypad
5 Seconds
,
10 Seconds
,
30 Seconds
,
Always On
or
Disable
>
Select
.
![](/img.php?id=934425&img=bg18.png)
46 Settings Settings 47
To set background image
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Display settings
>
Themes
.
2
.
Select background image
>
Select
.
H
CALL OPTIONS
In standby mode, press
Menu
>
Tools&Settings
>
Call options
.
For Call Options, see page 18.
H
SECURITY
To access security menus
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Security
.
2
.
Enter your password.
Note:
The default lock code must be the last 4 digits of user’s
phone number.
To lock your
phone
phone
1
.
Press
Lock phone
.
2
.
Select
Lock Now
,
Lock Now,Lock Now
Unlock
or
On Power Up
>
Select
.
To change the password
To change the password
1
.
Press
Change lock code
.
2
.
Enter
New Code
>
Enter again
Confirm Code
>
Save
.
To set special numbers
To set special numbers
1
.
Press
Special numbers
.
2
.
Select an entry number. (Special #1, Special
#2, Special #3) >
Set
.
3
.
Enter your desired phone number.
>
Save
.
To edit special numbers
To edit special numbers
1
.
Press
Special numbers
.
2
.
Select an existing special number.
>
Edit
>
Edit special phone number.
>
Save
.
To erase special numbers
To erase special numbers
1
.
Press
Special numbers
.
2
.
Select an existing special number.
>
Erase
>
Yes
.
To erase all contact lists
1
.
Press
Erase contacts
>
Yes
.
To erase all downloaded contents
1
.
Press
Erase downloads
>
Yes
.
To reset your phone
To reset your phone
1
.
Press
Reset Phone
>
Yes
.
H
MSG SETTINGS
In standby mode, press
Menu
>
Tools&Settings
>
Msg settings
.
For Msg Settings, see page 28.
H
GAME SETTINGS
In standby mode, press
Menu
>
Tools&Settings
>
Game settings
.
For Game Settings, see page 37.
H
BLUETOOTH
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
.
For Bluetooth, see page 50.
H
MEMORY
Save options
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Memory
>
Save Options
.
2
.
Select
Sounds
,
Pictures
or
Pictures or Pictures
Videos
>
Select
.
3
.
Select
Internal memory
or
Internal memory or Internal memory
External memory
>
Select
.
Internal memory
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Memory
>
Internal memory
.
2
.
To view Internal memory information. >
OK
.
External memory
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Memory
>
External memory
.
2
.
To view External memory information. >
OK
.
H
TO SET OTHER OPTIONS
Language
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Others
>
Language
.
2
.
Select
English
or
Español
>
Select
.
Airplane mode
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Others
>
Airplane mode
.
2
.
Select
On
or
Off
>
Off > Off
Select
.
TTY mode
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Others
>
TTY mode
.
2
.
Select
TTY Full
,
TTY + Talk
,
TTY + Hear
or
TTY
Off
>
Off > Off
Select
.
Location
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Others
>
Location
.
2
.
Select
E911 only
or
E911 only or E911 only
Location on
>
Select
.
![](/img.php?id=934425&img=bg19.png)
48 Settings
CHAPTER 8
CONNECTIVITY
Bluetooth
Using the Internet
VirginXL
My stuff
CHAPTER 8 CONNECTIVITY
Touch
key
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Others
>
Touch key
.
2
.
Select
Touch sensor level
or
Touch sensor level or Touch sensor level
Vibration
.
•
Touch sensor level:
Select
Level 1
~
Level 5
.
•
Vibration:
Select
On
or
Off
.
Off. Off
3
.
Press
Select
.
Media player
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Others
>
Media Player
.
2
.
Select
Call ringtone
or
Slide
.
•
Call ringtone:
Select
Resume
or
Exit
.
•
Slide:
Select
Keep Play
or
Keep Play or Keep Play
Exit
.
3
.
Press
Select
.
H
PHONE INFO
To view my phone number
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Phone info
>
My phone number
.
To view SW version info
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Phone info
>
Version info
.
![](/img.php?id=934425&img=bg1a.png)
H
BLUETOOTH
Bluetooth technology connectivity enables wire-
less connections between electronic devices. If
connected with a Bluetooth Handsfree device,
you can use your phone more freely. It can also
be used to connect wirelessly to products that use
Bluetooth wireless technology, such as comput-
ers. You can synchronize your phone and your
PC using Bluetooth connectivity. Since devices
with Bluetooth connectivity communicate using
radio waves, your phone and the other device
do not need to be in direct line-of-sight. The two
devices only need to be within 10 meters (30 feet)
of each other. The connection can be subject to
interference from obstructions such as walls or
other electronic devices. This device is compliant
with Bluetooth specification 1.1, supporting the
following profiles: HSP V1.1 (headset profile) and
HFP V1.0 (handsfree car kit profile). To ensure
interoperability between other devices supporting
Bluetooth technology, use UTStarcom approved
enhancements for this model. Check with the
manufacturers of other devices to determine
their compatibility with this phone. There may be
restrictions on using Bluetooth technology in some
locations. Check with your local authorities or
Virgin. If you want more information on this func-
tion, visit the Bluetooth Technology organization
Web site:
https://www.bluetooth.org/
.
To access the Bluetooth menu
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
.
To activate Bluetooth
The Power feature allows you to turn the Bluetooth
function on and off.
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
.
2
.
Press
On
/
Off
.
Off.Off
To add a device
Pairing is the process that allows the handset to locate,
establish and register 1-to-1 connection with the target
device.
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
>
New device
>
OK
.
Note:
If Bluetooth is set to off, “Please device power on” will
appear. Press On.
2
.
Instructions (Place device you are connecting
to in discoverable mode) will be displayed.
Highlight the device and press
Pair
.
3
.
The handset will prompt you for the passkey.
Consult the Bluetooth accessory instructions
for the appropriate passkey (typically “0000”
- 4 zeroes).
4
.
Enter the passkey and press
Save
.
50 Connectivity Connectivity 51
Note:
The default PIN code may differ depending on Bluetooth
devices. Please refer to the user guide of the Bluetooth
device that you wish to use.
5
.
Once pairing is successful, select
Yes
and press
OK
to connect with the device.
6
.
Once paired, you will see the device listed in
the “New Device” menu.
To turn on Discovery Mode
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
>
Options
>
Discovery mode
.
2
.
Select
On
or
Off
>
Off > Off
Select
.
To name the phone
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
>
Options
>
My phone name
.
To set the supported profiles
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
>
Options
>
Supported Profiles
.
2
.
Select
Headset
,
Headset,Headset
Handsfree
,
Dial up networking
,
Object push
or
File transfer
>
File transfer > File transfer
Select
.
To remove a device from the paired list
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
>
Select device
>
Options
>
Remove
Device
.
To rename the paired device
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
>
Select device
>
Options
>
Rename Device
.
To search the service discovery about the
paired device
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
>
Select device
>
Options
>
Service
Discovery
.
To send my name card
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
>
Select device
>
Options
>
Send
Name Card
.
To send a saved pictures
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
>
Select device
>
Options
>
Send
.
To send a saved videos
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
>
Select device
>
Options
>
Send
Video
.
To getting the name card about the paired
device
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
>
Select device
>
Options
>
Get
Name Card
.
![](/img.php?id=934425&img=bg1b.png)
To reviewe informati
on about the paired
device
1
.
In standby mode, press
Menu
>
Tools&Settings
>
Bluetooth
>
Select device
>
Options
>
Device
Info
.
To call using a hands-fre
e headset
1
.
Press the button once to call the last person.
To answer a call using a hands-free headset
1
.
Press the button once to receive the call.
H
USING THE INTERNET
To access internet
1
.
In standby mode, press
Menu
>
Surf the Web
.
Note:
This will access your Wireless Web service provider’s
homepage.
To view visited sites
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
History
.
2
.
Move the cursor up and down >
Select
.
To set new bookmarks
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
Mark Page
.
2
.
Press
Save
.
3
.
To edit, press
Menu
>
Edit
.
To view bookmarks
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
.
2
.
Move Bookmarks Tab with Navigation Key left
or right.
To search web site
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
Search
.
To refresh the current page
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
Reload
.
To show the URL on the current page
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
Show Link
.
To access the web site directly by entering
the address
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
Goto Page
.
2
.
Enter the web address >
GO
.
To go to the homepage
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
Home
.
52 Connectivity Connectivity 53
To send the current page's URL information
using the text message
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
Send Link
.
To set enable/disable download objects
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
Settings
>
Downloads
.
To restart web browser
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
Settings
>
Restart Browser
.
To clear cache memory
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
Settings
>
Clear
>
Check
Clear Cache
>
Clear
.
To clear saved history
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
Settings
>
Clear
>
Check
Clear History
>
Clear
.
To clear saved cookies
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
Settings
>
Clear
>
Check
Clear Cookies
>
Clear
.
To clear autofill
1
.
In standby mode, press
Menu
>
Surf the Web
>
Menu
>
Settings
>
Clear
>
Check
Autofill
>
Clear
.
H
VirginXL
To access VirginXL
1
.
In standby mode, press
Menu
>
VirginXL
.
VirginXL is a fun collection of features which you
can access directly from your phone - download
ringtones, games, graphics, and more. Charges
apply. Visit
www.virginmobileusa.com
for details.
Note:
You cannot receive incoming calls when a VirginXL session
is in progress. All incoming calls will be automatically for-
warded to voicemail.
Note:
A scroll bar on the right side of the screen indicates that
there is more text. Scroll down to go to the next screen of
text. Press the CLR key to move back one screen.
Ending a VirginXL session
1
.
Press [
]
.
![](/img.php?id=934425&img=bg1c.png)
54 Connectivity
CHAPTER 9
APPENDIX
12 Month limited warranty
Safety information for wireless handheld phones
Safety information for FCC RF exposure
SAR information
FDA consumer update
Emergency calls
Compliance with other FCC regulations
General safety
Antenna
Battery
Adapter/Charger
Recycle your cell phone!
FCC Hearing-Aid Compatibility (HAC) regulations for wireless devices
FCC compliance information
CHAPTER 9 APPENDIX
H
MY STUFF
To access My Ringtones
1
.
In standby mode, press
Menu
>
My Stuff
>
My ringtones
>
Get more ringtone
>
Go
.
To access My Music
1
.
In standby mode, press
Menu
>
My Stuff
>
My music
>
Get more music
>
Go
.
To access My Videos
1
.
In standby mode, press
Menu
>
My Stuff
>
My videos
>
Get more videos
>
Go
.
To access My Graphics
1
.
In standby mode, press
Menu
>
My Stuff
>
My graphics
>
Get more graphics
>
Go
.
To access My Games
1
.
In standby mode, press
Menu
>
My Stuff
>
My games
>
Get more game
>
Go
.
To download other stuff
1
.
In standby mode, press
Menu
>
My Stuff
>
My other stuff
>
Get more stuff
>
Go
.
![](/img.php?id=934425&img=bg1d.png)
Appendix 57
H
12 MONTH LIMITED WARRANTY
UTStarcom Personal Communications (the
Company) warrants to the original retail purchaser
of this UTStarcom handheld portable cellular
telephone, that should this product or any part
thereof during normal consumer usage and condi-
tions, be proven defective in material or workman-
ship that results in product failure within the first
twelve (12) month period from the date of pur-
chase, such defect(s) will be repaired or replaced
(with new or rebuilt parts) at the Company’s
option, without charge for parts or labor directly
related to the defect(s).
The antenna, keypad, display, rechargeable bat-
tery and battery charger, if included, are similarly
warranted for twelve (12) months from date of
purchase.
This Warranty extends only to consumers who pur-
chase the product in the United States or Canada
and it is not transferable or assign-able.
This Warranty does not apply to:
(a) Product subjected to abnormal use or condi-
tions, accident, mishandling, neglect, unau-
thorized alteration, misuse, improper installa-
tion or repair or improper storage;
(b) Product whose mechanical serial number or
electronic serial number has been removed,
altered or defaced.
(c) Damage from exposure to moisture, humidity,
excessive temperatures or extreme environmen-
tal conditions;
(d) Damage resulting from connection to, or use of
any accessory or other product not approved or
authorized by the Company;
(e) Defects in appearance, cosmetic, decorative or
structural items such as framing and non-opera-
tive parts;
(f) Product damaged from external causes such as
fire, flooding, dirt, sand, weather conditions,
battery leakage, blown fuse, theft or improper
usage of any electrical source.
The Company disclaims liability for removal or
reinstallation of the product, for geographic
coverage, for inadequate signal reception by the
antenna or for communications range or operation
of the cellular system as a whole.
When sending your wireless device to UTStarcom
Personal Communications for repair or service,
please note that any personal data or software
stored on the device may be inadvertently erased
or altered. Therefore, we strongly recommend
you make a back up copy of all data and software
contained on your device before submitting it
for repair or service. This includes all contact lists,
downloads (i.e. third-party software applications,
ringtones, games and graphics) and any other data
added to your device. In addition, if your wireless
device utilizes a SIM or Multimedia card, please
remove the card before submitting the device and
store for later use when your device is returned,
UTStarcom Personal Communications is not respon-
sible for and does not guarantee restoration of
any third-party software, personal information
56 Appendix
or memory data contained in, stored on, or inte-
grated with any wire-less device, whether under
warranty or not, returned to UTStarcom Personal
Communications for repair or service.
To obtain repairs or replacement within the terms
of this Warranty, the product should be delivered
with proof of Warranty coverage (e.g. dated bill
of sale), the consumer’s return address, daytime
phone number and/or fax number and complete
description of the problem, transportation pre-
paid, to the Company at the address shown below
or to the place of purchase for repair or replace-
ment processing. In addition, for reference to an
authorized Warranty station in your area, you may
telephone in the United States (800) 229-1235,
and in Canada (800) 465-9672 (in Ontario call 416-
695-3060).
THE EXTENT OF THE COMPANY’S LIABILITY UNDER
THIS WARRANTY IS LIMITED TO THE REPAIR OR
REPLACEMENT PROVIDED ABOVE AND, IN NO
EVENT, SHALL THE COMPANY’S LAIBILITY EXCEED
THE PURCHASE PRICE PAID BY PURCHASER FOR
THE PRODUCT.
ANY IMPLIED WARRANTIES, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, SHALL BE
LIMITED TO THE DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR BREACH OF
ANY WARRANTY MUST BE BROUGHT WITHIN A
PERIOD OF 18 MONTHS FROM DATE OF ORIGINAL
PURCHASE. IN NO CASE SHALL THE COMPANY
BE LIABLE FOR AN SPECIAL CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS OR
ANY OTHER WARRANTY, EXPRESS OR IMPLIED,
WHATSOEVER.
THE COMPANY SHALL NOT BE LIABLE FOR THE
DELAY IN RENDERING SERVICE UNDER THIS
WARRANTY OR LOSS OF USE DURING THE TIME
THE PRODUCT IS BEING REPAIRED OR REPLACED.
No person or representative is authorized to
assume for the Company any liability other than
expressed herein in connection with the sale of
this product.
Some states or provinces do not allow limitations
on how long an implied warranty lasts or the
exclusion or limitation of incidental or consequen-
tial damage so the above limitation or exclusions
may not apply to you. This Warranty gives you
specific legal rights, and you may also have other
rights, which vary from state to state or province
to province.
IN USA: UTStarcom Personal Communications
555 Wireless Blvd.
Hauppauge, NY 11788
(800) 229-1235
IN CANADA: UTStarcom Canada Company
5535 Eglinton Avenue West
Suite# 234 Toronto, ON M9C 5K5
(800) 465-9672
H �
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
Read This Information Before Using Your
Handheld Portable Cellular Telephone
![](/img.php?id=934425&img=bg1e.png)
58 Appendix Appendix 59
Driving safety
Talking on the phone while driving is extremely
dangerous and is illegal in some states. Remember,
safety comes first. Check the laws and regulations
on the use of phones in the areas where you drive.
Always obey them. If you must use your phone
while driving, please:
•
Give full attention to driving. Driving safely is
your first responsibility.
•
Use hands-free operation and/or one-touch,
speed dialing, and auto answer modes.
•
Pull off the road and park before making or
answering a call.
An air bag inflates with great force. DO NOT place
objects, including either installed or portable wire-
less equipment, in the area over the air bag or in
the air bag deployment area. If in-vehicle wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
WARNING!:
Failure to follow these instructions could lead to serious
personal injury and possible property damage.
Electronic devices
Your wireless handheld portable telephone is a
low power radio transmitter and receiver. When
it is ON, it receives and also sends out radio fre-
quency (RF) signals.
Most modern electronic equipment is shielded
from RF energy. However, certain electronic equip-
ment may not be shielded against the RF signals
from your wireless phone. Therefore, use of your
phone must be restricted in certain situations.
Pacemakers
The Health Industry Manufacturers Association
recommends that a minimum separation of six
(6”) inches be maintained between a handheld
wireless phone and a pacemaker to avoid poten-
tial interference with the pacemaker.
These recommendations are consistent with the
independent research by and recommendations
of Wireless Technology Research.
Never come closer than six (6) inches to a person
with a heart pacemaker implant when using
your phone. Doing so could result in interference
with the function of the pacemaker.
Persons with pacemakers :
•
ALWAYS keep the phone more than six inches
from your pacemaker when the phone is
turned on.
•
Do not carry the phone in a breast pocket.
•
Use the ear opposite the pacemaker to mini-
mize the potential for interference.
•
If you have any reason to suspect that inter-
ference is taking place, turn your phone OFF
immediately.
Hearing aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such interfer-
ence, you may want to consult your service pro-
vider (or call the customer service line to discuss
alternatives).
Other medical devices
If you use any other personal medical device,
consult the manufacturer of your device to
determine if they are adequately shielded from
external RF energy. Your physician may be able
to assist you in obtaining this information.
Hospitals and health care facilities
Turn your phone OFF in health care facilities
when any regulations posted in these areas
instruct you to do so.
Hospitals or healthcare facilities may be using
equipment that could be sensitive to external
RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in
motor vehicles. Check with the manufacturer or
its representative regarding your vehicle. You
should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted facilities
Turn your phone OFF where posted notices so
require.
Aircraft
FCC regulations prohibit using your phone while
in the air. Turn your phone OFF before boarding
an aircraft.
Always request and obtain prior consent and
approval of an authorized airline representative
before using your phone aboard an aircraft.
Always follow the instructions of the airline
representative whenever using your phone
aboard an aircraft, to prevent any possible
interference with airborne electronic equipment.
Blasting areas
To avoid interfering with blasting operations,
turn your phone OFF when in a “blasting area”
or in areas posted “Turn off two-way radio”.
Obey all signs and instructions.
Potentially explosive atmospheres
Turn your phone OFF when in any area with a
potentially explosive atmosphere and obey all
signs and instructions. Sparks in such areas could
cause an explosion or fire resulting in bodily
injury or even death.
Areas with a potentially explosive atmosphere
are often, but not always, clearly marked. They
include fueling areas such as gas stations; below
deck on boats; fuel or chemical transfer or stor-
age facilities; vehicles using liquefied petroleum
gas (such as propane or butane); areas where the
air contains chemicals or particles, such as grain,
dust, or metal powders; and any other area
where you would normally be advised to turn
off your vehicle’s engine.
![](/img.php?id=934425&img=bg1f.png)
60 Appendix Appendix 61
H �
SAFETY INFORMATION FOR FCC RF
EXPOSURE
WARNING! Read this Information before Using
Cautions
In August 1996 the Federal Communications
Commission (FCC) of the United States with its
action in Report and Order FCC 96-326 adopted an
updated safety standard for human exposure to
radio frequency electromagnetic energy emitted
by FCC regulated transmitters. Those guidelines are
consistent with the safety standard previously set
by both U.S. and international standards bodies.
The design of this phone complies with the FCC
guidelines and these international standards.
Body-Worn operation
This device was tested for typical body-worn
operations with the back of the phone kept 2
cm. from the body with a beltclip that contains
metallic components. To maintain compliance with
FCC RF exposure requirements, use only belt-clips,
holsters or similar accessories with which this
device was tested.
The use of accessories that do not satisfy these
requirements may not comply with FCC RF
exposure requirements, and should be avoided.
For more information about RF exposure, please
visit the FCC website at www.fcc.gov.
H �
SAR INFORMATION
This model phone meets the government’s
requirements foe exposure to radiowaves.
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not
to exceed the emission limits for exposure to
radiofrequency (RF) energy set by the Federal
Communications Commission of the U.S.
Government. These limits are part of comprehen-
sive guidelines and establish permitted levels of RF
energy for the general population. The guidelines
are based on standards that were developed by
independent scientific organizations through peri-
odic and thorough evaluation of scientific studies.
The standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit
set by the FCC is 1.6 W/kg. * Tests for SAR are con-
ducted with the phone transmitting at its highest
certified power level in all tested frequency bands.
Although the SAR is determined at the highest
certified power level, the actual SAR level of the
phone while operating can be well below the max-
imum value. This is because the phone is designed
to operate at multiple power levels so as to use
only the power required to reach the network. In
general, the closer you are to a wireless base sta-
tion antenna, the lower the power output. Before
a phone model is available for sale to the public, it
must be tested and certified to the FCC that it does
not exceed the limit established by the govern-
ment adopted requirement for safe exposure. The
tests are performed in positions and locations (e.g.,
at the ear and worn on the body) as required by
the FCC for each model.
The highest SAR value for this model phone
when tested for use at the ear is 1.26 W/kg PCS
CDMA Head SAR and when worn on the body,
as described in this user guide, is 0.243 W/kg PCS
CDMA Body SAR. (Body-worn measurements differ
among phone models, depending upon available
accessories and FCC requirements).
While there may be differences between the SAR
levels of various phones and at various positions,
they all meet the government requirement for safe
exposure.
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF expo-
sure guidelines. SAR information on this model
phone is on file with the FCC and can be found
under the Display Grant section of http://www.fcc.
gov/oet/fccid after searching on PP4IM.
Additional information on Specific Absorption
Rates (SAR) can be found on the Cellular
Telecommunications & Internet Association (CTIA)
web-site at
http://www.phonefacts.net
.
* In the United States and Canada, the SAR limit
for mobile phones used by the public is 1.6 watts/
kg (W/kg) averaged over one gram of tissue. The
standard incorporates a substantial margin of safe-
ty to give additional protection for the public and
to account for any variations in measurements.
H �
FDA CONSUMER UPDATE
U.S. Food and Drug Administration
Cell Phone Facts Consumer
Information on Wireless Phones
1. What kinds of phones are the subject of this
update?
The term “wireless phone” refers here to handheld
wireless phones with built-in antennas, often
called “cell,” “mobile,” or “PCS” phones. These
types of wireless phones can expose the user to
measurable radiofrequency energy (RF) because
of the short distance between the phone and
the user’s head. These RF exposures are limited
by Federal Communications Commission safety
guidelines that were developed with the advice of
FDA and other federal health and safety agencies.
When the phone is located at greater distances
from the user, the exposure to RF is drastically
lower because a person’s RF exposure decreases
rapidly with increasing distance from the source.
The so-called “cordless phones,” which have a base
unit connected to the telephone wiring in a house,
typically operate at far lower power levels, and
thus produce RF exposures well within the FCC’s
compliance limits.
2. Do wireless phones pose a health hazard?
The available scientific evidence does not show
that any health problems are associated with
![](/img.php?id=934425&img=bg20.png)
62 Appendix Appendix 63
using wireless phones. There is no proof, however,
that wireless phones are absolutely safe. Wireless
phones emit low levels of radiofrequency energy
(RF) in the microwave range while being used.
They also emit very low levels of RF when in the
standby mode. Whereas high levels of RF can pro-
duce health effects (by heating tissue), exposure to
low level RF that does not produce heating effects
causes no known adverse health effects. Many
studies of low level RF exposures have not found
any biological effects. Some studies have suggest-
ed that some biological effects may occur, but such
findings have not been confirmed by additional
research. In some cases, other researchers have had
difficulty in reproducing those studies, or in deter-
mining the reasons for inconsistent results.
3. What is FDA’s role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wire-
less phones before they can be sold, as it does with
new drugs or medical devices. However, the agen-
cy has authority to take action if wireless phones
are shown to emit radiofrequency energy (RF) at a
level that is hazardous to the user. In such a case,
FDA could require the manufacturers of wireless
phones to notify users of the health hazard and
to repair, replace or recall the phones so that the
hazard no longer exists.
Although the existing scientific data do not justify
FDA regulatory actions, FDA has urged the wireless
phone industry to take a number of steps, includ-
ing the following:
•
Support needed research into possible biologi-
cal effects of RF of the type emitted by wireless
phones;
•
Design wireless phones in a way that minimizes
any RF exposure to the user that is not neces-
sary for device function; and
•
Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health
FDA belongs to an interagency working group
of the federal agencies that have responsibil-
ity for different aspects of RF safety to ensure
coordinated efforts at the federal level. The fol-
lowing agencies belong to this working group:
•
National Institute for Occupational Safety and
Health
•
Environmental Protection Agency
•
Federal Communications Commission
•
Occupational Safety and Health
Administration
•
National Telecommunications and
Information Administration
The National Institutes of Health participates in
some interagency working group activities, as well.
FDA shares regulatory responsibilities for wire-
less phones with the Federal Communications
Commission (FCC).
All phones that are sold in the United States must
comply with FCC safety guidelines that limit RF
exposure.
FCC relies on FDA and other health agencies for
safety questions about wireless phones.
FCC also regulates the base stations that the wire-
less phone networks rely upon. While these base
stations operate at higher power than do the
wireless phones themselves, the RF exposures that
people get from these base stations are typically
thousands of times lower than those they can get
from wireless phones. Base stations are thus not
the primary subject of the safety questions dis-
cussed in this document.
4. What are the results of the research done
already?
The research done thus far has produced conflict-
ing results, and many studies have suffered from
flaws in their research methods. Animal experi-
ments investigating the effects of radiofrequency
energy (RF) exposures characteristic of wireless
phones have yielded conflicting results that often
cannot be repeated in other laboratories. A few
animal studies, however, have suggested that low
levels of RF could accelerate the development of
cancer in laboratory animal.
5. What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and epide-
miological studies of people actually using wireless
phones would provide some of the data that are
needed. Lifetime animal exposure studies could be
completed in a few years.
However, very large numbers of animals would
be needed to provide reliable proof of a cancer
promoting effect if one exists. Epidemiological
studies can provide data that is directly applicable
to human populations, but 10 or more years’ fol-
low-up may be needed to provide answers about
some health effects, such as cancer. This is because
the interval between the time of exposure to a
cancer-causing agent and the time tumors develop
- if they do - may be many, many years. The inter-
pretation of epidemiological studies is hampered
by difficulties in measuring actual RF exposure
during day-to-day use of wireless phones. Many
factors affect this measurement, such as the angle
at which the phone is held, or which model of
phone is used.
6. What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around
the world to ensure that high priority animal stud-
ies are conducted to address important questions
about the effects of exposure to radiofrequency
energy (RF).
FDA has been a leading participant in the World
Health Organization International Electromagnetic
Fields (EMF) Project since its inception in 1996. An
influential result of this work has been the devel-
opment of a detailed agenda of research needs
that has driven the establishment of new research
programs around the world. The Project has also
![](/img.php?id=934425&img=bg21.png)
64 Appendix Appendix 65
helped develop a series of public information
documents on EMF issues.
FDA and the Cellular Telecommunications
& Internet Association (CTIA) have a formal
Cooperative Research and Development
Agreement (CRADA) to do research on wireless
phone safety. FDA provides the scientific oversight,
obtaining input from experts in government,
industry, and academic organizations. CTIA-
funded research is conducted through contracts
to independent investigators. The initial research
will include both laboratory studies and studies of
wireless phone users. The CRADA will also include
a broad assessment of additional research needs
in the context of the latest research developments
around the world.
7. What steps can I take to reduce my exposure to
radiofrequency energy from my wireless phone?
If there is a risk from these products--and at this
point we do not know that there is--it is probably
very small.
But if you are concerned about avoiding even
potential risks, you can take a few simple steps
to minimize your exposure to radiofrequency
energy (RF). Since time is a key factor in how much
exposure a person receives,reducing the amount
of time spent using a wireless phone will reduce
RF exposure.
•
If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of
the RF, since the exposure level drops off dra-
matically with distance. For example, you could
use a headset and carry the wireless phone
away from your body or use a wireless phone
connected to a remote antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are con-
cerned about the RF exposure from these products,
you can use measures like those described above
to reduce your RF exposure from wireless phone
use.
8. What about children using wireless phones?
The scientific evidence does not show a danger
to users of wireless phones, including children
and teenagers. If you want to take steps to lower
exposure to radiofrequency energy (RF), the
measures described above would apply to children
and teenagers using wireless phones. Reducing
the time of wireless phone use and increasing the
distance between the user and the RF source will
reduce RF exposure.
Some groups sponsored by other national govern-
ments have advised that children be discouraged
from using wireless phones at all. For example,
the government in the United Kingdom distrib-
uted leaflets containing such a recommendation
in December 2000. They noted that no evidence
exists that using a wireless phone causes brain
tumors or other ill effects. Their recommendation
to limit wireless phone use by children was strictly
precautionary; it was not based on scientific evi-
dence that any health hazard exists.
9. Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to
RF emissions from wireless phones, there is no
reason to believe that hands-free kits reduce risks.
Hands-free kits can be used with wireless phones
for convenience and comfort. These systems reduce
the absorption of RF energy in the head be believe
that accessories that claim to shield the head from
those emissions reduce risks. Some products that
claim to shield the user from RF absorption use
special phone cases, while others involve nothing
more than a metallic accessory attached to the
phone. Studies have shown that these products
generally do not work as advertised. Unlike “hand-
free” kits, these so-called “shields” may interfere
with proper operation of the phone.
The phone may be forced to boost its power
to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that
sold devices that claimed to protect wireless
phone users from radiation with making false and
unsubstantiated claims. According to FTC, these
defendants lacked a reasonable basis to substanti-
ate their claim.
10. What about wireless phone interference with
medical equipment?
Radiofrequency energy (RF) from wireless phones
can interact with some electronic devices. For
this reason, FDA helped develop a detailed test
method to measure electromagnetic interfer-
ence (EMI) of implanted cardiac pacemakers and
defibrillators from wireless telephones. This test
method is now part of a standard sponsored by
the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000.
This standard will allow manufacturers to ensure
that cardiac pacemakers and defibrillators are safe
from wireless phone EMI.
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop
a voluntary standard sponsored by the Institute
of Electrical and Electronic Engineers (IEEE). This
standard specifies test methods and performance
requirements for hearing aids and wireless phones
so that that no interference occurs when a person
uses a “compatible” phone and a “compatible”
hearing aid at the same time. This standard was
approved by the IEEE in 2000.
FDA continues to monitor the use of wireless
phones for possible interactions with other medical
devices. Should harmful interference be found to
occur, FDA will conduct testing to assess the inter-
ference and work to resolve the problem.
Updated July 29, 2003
For more information, please visit the FDA website
at
http://www.fda.gov/cellphones
.
![](/img.php?id=934425&img=bg22.png)
66 Appendix Appendix 67
H �
EMERGENCY CALLS
Never rely solely upon your wireless phone for
essential communications (e.g., medical emergen-
cies), if it can be avoided, since a wireless phone
requires a complex combination of radio signals,
relay stations and landline networks for its
operation. Consequently, emergency calls may not
always be possible under all conditions on all wire-
less phone systems. Your wireless phone, however,
may sometimes be the only available means of
communication at the scene of an accident. When
making an emergency call, always give the recipi-
ent all necessary information as accurately as pos-
sible. Never terminate an emergency call until you
have received clearance to do so.
FCC ENHANCED 911 (E911) RULES
Background
The Federal Communications Commission (FCC)
requires wireless carriers to transmit specific lati-
tude and longitude location (Automatic Location
Identification = ALI) information as well as “911”
calls to Public Safety Answering Points (PSAPs)
to identify the location of the caller in case of
emergency.
Generally, the rules require that carriers identify
an E911 caller’s location within 50 meters of the
actual location for 67 percent of calls and within
150 meters of the actual location for 95 percent
of calls.
Super Slice’s ALI Capability.
The Super Slice is an ALI-capable phone equipped
with a GPS (Global Positioning System) receiver
supporting a satellite-based GPS ALI-capable net-
work to comply with the FCC’s ALI requirements.
The network compliance with the above FCC
requirements is dependent on: (a) the use of
digital technology by the wireless network; (b) GPS
satellite signals being able to reach the handset
(such transmissions do not always work indoors,
for example) ; and (c) handset signals reaching
wireless “base stations” (atmospheric and environ-
mental conditions may cause variations in handset
receiving signal strength).
Also the transmission of the ALI information is
subject, in part, to system constraints within the
wireless network to which the E911 signal is trans-
mitted and over which UTStarcom has no control.
Finally, customers are advised that the Super Slice
ALI capability is to be used for E911 purposes only.
This feature allows you to place an emergency call
even if your phone is in “Phone Lock” or “Restrict”
modewhen you dial the preprogrammed emer-
gency number, 911, #911, or *911. It also operates
in out-of-service areas.
The phone maintains emergency mode until you
press after disconnecting an emergency call. In
emergency call mode, the phone can receive an
incoming call from any available system.
To call “911” in “Phone Lock” or “Restrict” mode.
1. Enter
,
2. Press
. “911” and “Emergency” will appear
on the screen.
H �
COMPLIANCE WITH OTHER FCC
REGULATIONS
OPERATING PROCEDURES
Never violate any of the following Rules and
Regulations of the FCC when using your Cellular
Phone. Such violations are punishable by fine,
imprisonment or both.
•
Never use your Cellular Phone to send false
distress calls.
•
Never wiretap or otherwise intercept a phone
call, unless you have first obtained the consent
of the parties participating in the call.
•
Never make any anonymous calls to annoy,
harass, or molest other people.
•
Never charge another account without authori-
zation, to avoid payment for service.
•
Never willfully or maliciously interfere with any
other radio communications.
•
Never refuse to yield the line when informed
that it is needed for an Emergency Call. Also,
never take over a line by stating falsely that it
is needed for an emergency.
H �
GENERAL SAFETY
PRECAUTIONS
Your Handheld Portable Telephone is a high qual-
ity piece of equipment. Before operating, read all
instructions and cautionary markings on the prod-
uct, battery and adapter/charger.
Failure to follow the directions below could result
in serious bodily injury and/or property damage
due to battery liquid leakage, fire or rupture.
•
DO NOT use or store this equipment in a place
where it will be exposed to high temperatures,
such as near an open flame or heat-emitting
equipment.
•
DO NOT drop your device or subject it to severe
shock. When not using, lay down the unit to
avoid possible damage due to instability.
•
DO NOT expose this equipment to rain or
spilled beverages.
•
DO NOT use unauthorized accessories.
•
DO NOT disassemble the phone or its accesso-
ries. If service or repair is required, return unit
to an authorized UT Starcom cellular service
center. If unit is disassembled, the risk of elec-
tric shock or fire may result.
H �
ANTENNA
ANTENNA SAFETY
Use only the supplied or an approved replacement
antenna. Unauthorized antennas, modifications, or
attachments could impair call quality, damage the
phone, or result in violation of FCC regulations.
Please contact your local dealer for replacement
antenna.
Do not use the phone with a damaged antenna. If
a damaged antenna comes into contact with the
![](/img.php?id=934425&img=bg23.png)
68 Appendix Appendix 69
skin, a minor burn may result. Please contact your
local dealer for replacement antenna.
H �
BATTERY
BATTERY SAFETY
Your device uses a removable and rechargeable
lithium ion battery. Please contact customer service
for assistance should you need a replacement
battery.
DOs
•
Only use the battery and charger approved by
the manufacturer.
•
Only use the battery for its original purpose.
•
Try to keep batteries in a temperature between
41°F (5°C) and 95°F (35°C).
•
If the battery is stored in temperatures above
or below the recommended range, give it time
to warm up or cool down before using.
•
Completely drain the battery before recharg-
ing. It may take one to four days to completely
drain.
•
Store the discharged battery in a cool, dark,
and dry place.
•
Purchase a new battery when its operating time
gradually decreases after fully charging.
•
Properly dispose of the battery according to
local regulations.
DON’Ts
•
Don’t attempt to disassemble the battery – it is
a sealed unit with no serviceable parts.
•
Don’t expose the battery terminals to any other
metal object (e.g., by carrying it in your pocket
or purse with other metallic objects such as
coins, clips and pens). This can short circuit and
critically damage the battery.
•
Don’t leave the battery in hot or cold temps.
Otherwise, it could significantly reduce the
capacity and lifetime of the battery.
•
Don’t dispose of the battery into a fire.
Lithium ion batteries are recyclable. When you
replace your built-in battery, please request the
repair center to recycle the battery in accordance
with RBRC standards. When disposing of the bat-
tery by yourself, please call RBRC at (800) 822-8837
for proper disposal tips.
Never touch any fluid that might leak from the
built-in battery. Such liquid when in contact with
the eyes or skin, could cause injury to the skin or
eyes. Should the liquid come into contact with
the eyes, irrigate the eyes thoroughly with clean
water and immediately seek medical attention. In
the event the liquid comes into contact with the
skin or clothing, wash it away immediately with
clean water.
H �
ADAPTER/CHARGER
CHARGER
The charger designed by UTStarcom for this unit
requires the use of a standard 120 V AC power
source for its operation.
•
Never attempt to disassemble or repair a
charger.
•
Never use a charger if it has a damaged or
worn power cord or plug. Always contact a
UTStarcom authorized service center, if repair
or replacement is required.
•
Never alter the AC cord or plug on your char-
ger. If the plug will not fit into the available
outlet, have a proper outlet installed by a
qualified electrician.
•
Never allow any liquids or water to spill on the
charger when it is connected to an AC power
source. Always use the authorized UTStarcom
charger to avoid any risk of bodily injury or
damage to your cellular phone or battery.
•
Never attempt to connect or disconnect the
charger with wet hands. Always unplug the
charger from the power source before attempt-
ing any cleaning. Always use a soft cloth damp-
ened with water to clean the equipment, after
it has been unplugged.
Handling the cord on this product or cords associ-
ated with accessories sold with this product, will
expose you to lead, a chemical known to the State
of California to cause birth defects or other repro-
ductive harm. Wash hands after handling. Always
disconnect the charger from the power source
when it is not in use.
H �
RECYCLE YOUR CELL PHONE!
Carriers marketing this cell phone have an in-store
phone take-back program. Consumers can drop off
their used wireless devices to specified carrier retail
outlets for recycling purposes. For a list of carrier
members and collection sites, visit the cellular
industry’s recycling website
www.recyclewireless‐
phones.com
.
To mail in your old wireless device to UTStarcom
Personal Communications for recycling purposes,
simply package your old wireless device and any
accessories (including discharged batteries) in
appropriate shipping materials and mail to:
For Recycling UTStarcom Personal Communications
LLC 555 Wireless Blvd. Hauppauge, NY 11788
Wireless phones also can be donated to the
Wireless Foundation’s DONATE A PHONE
®
CALL TO
PROTECT
®
campaign. This charitable cause collects
wireless phones to benefit victims of domestic vio-
lence. All donated phones are tax deductible. You
may mail the phone to:
CALL TO PROTECT2555 Bishop Circle WestDexter,
MI 48130 -ORDrop the phone off at a local col-
lection center. For a list of collection centers, visit
www.wirelessfoundation.org/CalltoProtect/dropoff.
cfm
© 2008 UTStarcom Personal Communications
LLC. All rights reserved. UTStarcom is a registered
trademark and the UTStarcom logo is a trademark
![](/img.php?id=934425&img=bg24.png)
70 Appendix Appendix 71
of UTStarcom, Inc. and its subsidiaries.
VIRGIN and the Virgin Signature logo are
registered trademarks of Virgin Enterprises Limited
and are used under license.
Bluetooth is a trademark of Bluetooth SIG, Inc.
Trademarks are owned by Bluetooth SIG, Inc. All
other trademarks are the property of their
respective owners.
H �
FCC HEARING-AID COMPATIBILITY
(HAC) REGULATIONS FOR WIRELESS
DEVICES
THIS PHONE HAS A HAC RATING OF M3
On July 10, 2003, the U.S. Federal Communications
Commission (FCC) Report and Order in WT Docket
01-309 modified the exception of wireless phones
under the Hearing Aid Compatibility Act of 1988
(HAC Act) to require digital wireless phones be
compatible with hearing-aids. The intent of the
HAC Act is to ensure reasonable access to telecom-
munications services for persons with hearing
disabilities.
While some wireless phones are used near some
hearing devices (hearing aids and cochlear
implants), users may detect a buzzing, humming,
or whining noise. Some hearing devices are more
immune than others to this interference noise, and
phones also vary in the amount of interference
they generate.
The wireless telephone industry has developed a
rating system for wireless phones to assist hearing
device users find phones that may be compatible
with their hearing devices. Not all phones have
been rated. Phones that are rated have the rating
on their box or a label located on the box.
The ratings are not guarantees. Results will vary
depending on the user’s hearing device and hear-
ing loss. If your hearing device happens to be
vulnerable to interference, you may not be able to
use a rated phone successfully.
Trying out the phone with your hearing device
is the best way to evaluate it for your personal
needs.
M-Ratings:
Phones rated M3 or
M4 meet FCC requirements and
are likely to generate less inter-
ference to hearing devices than
phones that are not labeled.
M4 is the better/higher of the two ratings.
Hearing devices may also be rated. Your hearing
device manufacturer or hearing health profes-
sional may help you find this rating. Higher ratings
mean that the hearing device is relatively immune
to interference noise. The hearing aid and wireless
phone rating values are then added together. A
sum of 5 is considered acceptable for normal use.
A sum of 6 is considered for best use.
In the above example, if a hearing aid meets the
M2 level rating and the wireless phone meets the
M3 level rating, the sum of the two values equal
M5. This should provide the hearing aid user with
“normal usage” while using their hearing aid with
the particular wireless phone. “Normal usage” in
this context is defined as a signal quality that is
acceptable for normal operation.
The M mark is intended to be synonymous
with the U mark. The T mark is intended to
be synonymous with the UT mark. The M and
T marks are recommended by the Alliance for
Telecommunications Industries Solutions (ATIS). The
U and UT marks are referenced in Section 20.19 of
the FCC Rules. The HAC rating and measurement
procedure are described in the American National
Standards Institute (ANSI) C63.19 standard.
For information about hearing aids and digital
wireless phones
•
Fcc Hearing Aid Compatibility and Volume
Control
http://www.fcc.gov/cgb/dro/hearing.html
•
Gallaudet University, RERC
http://tap.gallaudet.edu/DigWireless.KS/
DigWireless.html
•
Self Help for Hard of Hearing People Inc.
[SHHH]
www.hearingloss.org/hat/TipsWirelessPhones.
htm
•
The Hearing Aid Compatibility FCC Order
http://hraunfoss.fcc.gov/edocs_public/attach‐
match/FCC‐03‐168A1.pdf
H �
U.S.FEDERAL COMMUNICATIONS
COMMISSION RADIO FREQUENCY
INTERFERENCE STATEMENT
INFORMATION TO THE USER
NOTE : This equipment has been tested and found
to comply with the limits for a Class B digital
device pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protec-
tion against harmful Interference in a residential
installation This equipment generates, uses, and
can radiate radio frequency energy and, if Not
installed and used in accordance with the instruc-
tions, may cause harmful Interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
Installation. If this equipment does cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off
and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
•
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
•
Connect the equipment into an outlet of a
circuit different from that to which the receiver
is connected.
•
Consult the dealer or an experienced radio/TV
technician for assistance.
Changes or modification not expressly approved
by the party responsible for Compliance could void
the user’s authority to operate the equipment.
Connecting of peripherals requires the use of
grounded shielded signal cables.
![](/img.php?id=934425&img=bg25.png)
72 Appendix
H �
FCC COMPLIANCE INFORMATION
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any interference
received. Including interference that may cause
undesired operation.
