Pantech TX-50C Tri-Mode Dual Band Cellular Phone User Manual
Pantech Co., Ltd. Tri-Mode Dual Band Cellular Phone
Pantech >
User Manual
AUDIOVOX
AUDIOVOX
[CDM-8500]
[CDM-8500]
[Dual/Tri Mode] Digital [CDMA/Amps]
Handheld Portable Telephone
In today’s fast paced world, it has become a necessity to
have access to real time information. Your communications
tools must provide you with this access from anywhere
at anytime. With that in mind, Audiovox developed the
[CDM-8500], a [dual/tri mode] handset with [web brows-
ing and voice activated dialing] features.
Operating on the [800 MHz Amps/CDMA and 1900 MHz
PCS] frequencies, the [CDM-8500] allows for seamless
nationwide coverage as well as offering state-of-the-art,
user-friendly features. [Voice activated dialing and 2-way
speakerphone] are great for enhancing [hands-free use]
of this phone. [T9TM Text Input, vibrating alert and a 7-line
LCD display] make the [CDM-8500] easier to use.
Several optional accessories are available for the [CDM-
8500], including: [hands-free devices (installed, earphone
microphone, cigarette lighter charger), charging devices
(vehicle, travel, desktop, AC), data interface cables, belt
clips, and of course user-changeable faceplates.]
Your new [CDM-8500] provides you with something only
an Audiovox phone can: the proven reliability that has
made us a leading wireless handset provider. Please
take a few moments to read the following pages of the
owner’s manual. It will help you make the most efficient
use of this valuable communications tool.
Preface
50Bmanual template7/26 2002.7.26 5:35 PM Page 1
TABLE OF CONTENTS
CHAPTER 1 BEFORE USING YOUR PHONE..........7
Package Contents...................................................8
Handset Description...............................................9
Function Keys .......................................................10
Display Indicators .................................................11
Using the Battery ..................................................13
Installing the Battery............................................13
Removing the Battery..........................................13
Charging the Battery ............................................14
Power Connection ...............................................14
Charging the Battery Only ...................................14
Battery Charging Time.........................................15
Battery Talk and Standby Times..........................15
Battery Information...............................................16
CHAPTER 2 BASIC OPERATION ...........................17
Using the Phone ...................................................18
Turning the Phone On .........................................18
Turning the Phone Off .........................................18
Using the Menu .....................................................19
Menu Summary .....................................................20
Basic Functions ....................................................23
Making a Call.......................................................23
Pause Feature .....................................................24
Speaker Phone....................................................25
Answering Calls ...................................................25
Caller ID...............................................................25
Call Waiting..........................................................26
Answering Machine Display.................................26
Adjusting the Volume...........................................27
Lock .....................................................................27
Vibrate .................................................................28
Manner Mode ......................................................28
Functions During a Call .......................................29
Mute.....................................................................29
Silent(Quit)...........................................................29
Sending Your Number to a Pager .......................29
Table of Contents - Page 1
50Bmanual template7/26 2002.7.26 5:35 PM Page 2
TABLE OF CONTENTS TABLE OF CONTENTS
Force Analog .......................................................50
NAM Setting ........................................................51
Call Prompt..........................................................52
PRL ID .................................................................52
Sounds.................................................................53
Display.................................................................58
Others..................................................................52
UP Proxy IP.........................................................67
VR Mode ................................................................68
Name ...................................................................68
Dial.......................................................................69
Redial...................................................................69
Voice Memo.........................................................70
Phone Book .........................................................70
Cancel..................................................................71
VR Menu ................................................................72
Voice Memo.........................................................72
Call Answer..........................................................73
Voice Command ..................................................74
Voice Dial.............................................................78
Voice Alert............................................................80
Voice Setting........................................................82
CHAPTER 5 SECURITY FEATURES.......................85
Security Features..................................................86
Security................................................................86
CHAPTER 6 SUPPLEMENTARY FUNCTIONS.......93
Schedule ................................................................94
Event....................................................................94
Alarm....................................................................95
Calculator ..............................................................96
Calculator.............................................................96
World Clock ...........................................................97
World Clock .........................................................97
Stopwatch..............................................................98
Stopwatch............................................................98
My Profile.............................................................30
Voice Privacy .......................................................30
Location ...............................................................30
CHAPTER 3 MEMORY FUNCTION ........................31
Storing Phone Numbers.......................................32
Text Input Methods ...............................................33
Entering Characters.............................................33
Alpha Mode..........................................................33
T9TM Predictive Text Mode ...................................34
Numeric Mode .....................................................36
Symbol Mode.......................................................36
Speed Dialing ........................................................37
One-Touch/Two-Touch Dialing.............................37
Call Logs................................................................38
Outgoing Calls .....................................................38
Incoming Calls .....................................................39
Missed Calls ........................................................40
Call Times ..............................................................41
Last Call...............................................................41
All Calls................................................................41
Home Calls ..........................................................41
Roam Calls ..........................................................41
Accumulate Calls .................................................41
Using Your Phonebook.........................................42
Recalling by Group..............................................42
Recalling by Name ..............................................42
Recalling by Location Number ............................43
Editing Your Phonebook ......................................43
Edit Group ...........................................................44
Speed Dial ...........................................................46
My Profile.............................................................47
CHAPTER 4 SETTINGS...........................................49
Setting....................................................................50
Set Mode .............................................................50
Page 2 - Table of Contents Table of Contents - Page 3
50Bmanual template7/26 2002.7.26 5:35 PM Page 4
TABLE OF CONTENTSTABLE OF CONTENTS
Restart Up.Browser ...........................................119
Encryption ..........................................................119
CHAPTER 10 DATA SERVICE ...............................121
Data SVC..............................................................122
Connection.........................................................122
Data Speed........................................................123
Location ...............................................................124
Setting................................................................124
CHAPTER 11 SAFETY INFORMATION .................125
Safety Information for Wireless Handheld Phones
................................................................................126
Safety Information for FCC RF Exposure.........133
SAR Information..................................................134
FDA Consumer Update ......................................136
CHAPTER 12 WARRANTY...................................145
Protect Your Warranty........................................146
12 Month Limited Warranty ...............................147
Page 4 - Table of Contents
CHAPTER 7 VOICE MAIL AND TEXT MESSAGES.99
Two-Way SMS .....................................................100
Message Indicators ...........................................100
Received Message Notification .........................100
Checking Messages ...........................................101
Checking Received Voice Mail Message ..........101
Checking Received Text Message ....................101
Sending Text Messages .....................................102
Sending New Text Messages ............................102
Inbox ....................................................................104
Inbox Menu........................................................104
Outbox .................................................................106
Outbox Menu .....................................................106
Settings................................................................108
Settings Menu....................................................108
Filed......................................................................110
Erase All...............................................................111
CHAPTER 8 MAKING AN EMERGENCY CALL...113
Emergency Calling..............................................114
E911 Calling.......................................................114
CHAPTER 9 INTERNET BROWSER .....................115
Start Internet Browser........................................116
Wireless Internet................................................116
Browser Menu.....................................................117
Reload................................................................117
Home .................................................................117
Bookmarks .........................................................117
Mark Site............................................................117
About Openwave ...............................................118
Advanced ...........................................................118
Show URL..........................................................118
Homepage .........................................................118
Set UP.Link ........................................................118
Offline Services..................................................119
Outbox ...............................................................119
Table of Contents - Page 5
50Bmanual template7/26 2002.7.26 5:35 PM Page 6
Please read this manual before using your phone.
This chapter describes your phone, its keys and its
display icons. It also covers charging and proper use of
the battery.
Once you have read this chapter, you can move on to
the basic and advanced features of your phone.
1. Package Contents
2. Handset Description
3. Function Keys
4. Display Indicators
5. Using the Battery
6. Charging the Battery
7. Battery Information
CHAPTER 1
CHAPTER 1
BEFORE USING YOUR PHONE
Chapter 1 - Page 7Page 6
50Bmanual template7/26 2002.7.26 5:35 PM Page 8
HANDSET DESCRIPTION
HANDSET DESCRIPTION
Volume
Button
Adjusts the
earpiece
and ringer
volume.
Earpiece
Function
Keys
Keypad
Microphone
This phone is a [dual] mode [(800 Amps/800CDMA)]
[CDMA] digital phone [with data and web browsing
capabilities]. The [CDM-8500] weighs ___ oz. and the
dimensions are ___ x ___ x ___.
Chapter 1 - Page 9
P
PACKAGE CONTENTS
ACKAGE CONTENTS
Thank you for purchasing the [CDM-8500] wireless hand-
set. The phone’s giftbox contains all of the items listed
below.
NOTE: Report any product defects to the place of
purchase immediately.
User Manual Desktop Charger
Hand strap
Handset
Standard Battery
Page 8 - Chapter 1
Antenna
For best call
quality, extend
the antenna
during the call.
LCD
Display
50Bmanual template7/26 2002.7.26 5:35 PM Page 10
DISPLA
DISPLAY INDICA
Y INDICATORS
TORS
Signal Strength
Indicates current signal strength. The more
lines, the stronger the signal.
Roaming
Indicates the phone is outside of its home
area.
Service Indicator
When a call is in progress, is displayed.
When is displayed, the phone is in idle
mode. When is displayed, the phone is
not receiving a signal from the system.
Message
Indicates a text or voice mail message is
waiting.
Digital Mode
Indicates the phone is operating in digital
mode.
Battery
Indicates charge level status. The more
black lines the greater the charge.
Mute
Phone is mute during a call.
Chapter 1 - Page 11
FUNCTION KEYS
FUNCTION KEYS
END KEY: Use to turn the handset
on or off. Also terminates a call or
exits the current menu.
SEND KEY: Use to make or receive
a call.
NAVIGATION KEY: Use to scroll
through the menu.
SOFT KEYS: Use to perform the
functions displayed above them on
the LCD Display. (e.g. When REDIAL
is displayed on the bottom left of the
display, press to redial the last
phone number dialed.
WEB KEY: Use to access the web.
CLEAR KEY: Use to clear characters
or enable the speaker phone mode.
LOCK KEY: Press and hold it to enter
the Lock mode.
ETIQUETTE MODE KEY: Press and
hold it to enter the Etiquette mode.
This mode disables the keypad tone
and enables the vibrator
Page 10 - Chapter 1
50Bmanual template7/26 2002.7.26 5:35 PM Page 12
CHARGING THE BA
CHARGING THE BATTER
TTERY
Y
Chapter 1 - Page 13
DISPLA
DISPLAY INDICA
Y INDICATORS
TORS
INSTALLING THE BATTERY
1. Insert the bottom of battery into groove at bottom of
the handset.
2. Press in the top of the battery until it clicks.
REMOVING THE BATTERY
1.
Push the tab with one hand and lift the top of the
battery
to separate.
NOTE: The battery must be correctly placed in the
battery compartment. If it is incorrectly inserted,
the handset will not turn on and/or the battery
may detach during use.
Page 12 - Chapter 1
Silent
Silent key beep during call.
Emergency call
Blinks when an emergency call is in progress.
Answering machine memo
Shows that there are some voice memos
not checked yet.
Answering machine
Shows that the phone is in answering
machine mode.
Etiquette
Appears when phone is the etiguette mode
that there are some voice memos not
checked yet.
Schedule
Appears when either an event or an alarm
is set.
Ring Mode
Appears when a ringer is set as a ringer
mode.
GPS Icon
Location Off
Location On
50Bmanual template7/26 2002.7.26 5:35 PM Page 14
CHARGING THE BA
CHARGING THE BATTER
TTERY
Y
NOTE: Charging time applies only when your phone is
turned off. Charging time may vary if your phone
is turned on.
NOTE: These times are for a new battery. Talk and
standby time may decrease over time.
BATTERY TALK & STANDBY TIMES
Battery Type BTR-
( mAh)
minutes
BTE-
( mAh)
minutes
Charging Time
Status
Type PCS CDMA AMPS
157 150 103
113 103 25
Talk (min)
Standby (hrs)
BATTERY CHARGING TIME
Chapter 1 - Page 15
CHARGING THE BA
CHARGING THE BATTER
TTERY
Y
NOTE: 1. It is more efficient to charge the battery with
the handset off.
2. The battery must be connected to the phone in
order to charge it.
3. If the LED flickers while charging, the battery
contacts may need cleaning.
4.
Once fully charged, the LED may change from
red to green. This does not indicate a problem
with the battery.
5.
Battery operating time gradually decreases over
time.
6. If the battery fails to perform normally, you may
need to replace the battery.
Page 14 - Chapter 1
POWER CONNECTION
Connect the charger to a standard 110V AC outlet. This
charger can charge the phone with the battery attached
or just the battery.
NOTE: 1.
The battery is not charged at the time of
purchase.
2. Fully charge the battery before use.
CHARGING THE BATTERY ONLY
To charge the battery only, insert the battery pack into
the charging slot on the charger.
The LED will indicate charging status.
-Red indicates charging is in progress.
-Green indicates charging is complete.
50Bmanual template7/26 2002.7.26 5:35 PM Page 16
1. Using the Phone
2. Using the Menu
3. Menu Summary
4. Basic Functions
5. Functions During a Call
CHAPTER 2
CHAPTER 2
BASIC OPERATION
This chapter describes the basic functions of your
phone. It also outlines the phone’s menu, adjusting volume
levels and functions available while you are on a call.
Chapter 2 - Page 17
Use only manufacturer approved batteries.
Never use a damaged or worn out battery.
Use the battery only for its intended purpose.
Never expose the battery terminals to any other metal
object. This can short circuit the battery.
Avoid exposure to temperature extremes. A phone with
a hot or cold battery may temporarily not work (or
charge), even if the battery is fully charged. Always allow
it to cool down or warm up first and keep the battery
between 41oF and 95oF (5oC and 35oC).
When not in use, store the battery uncharged in a cool,
dark, dry place.
The battery is a self-contained unit. Do not attempt to
open its case.
Battery operating time gradually decreases. You may
need to buy a new battery.
Never dispose of a battery in a fire!
Dispose of used batteries in accordance with local
regulations.
Recycle!
BA
BATTER
TTERY INFORMA
Y INFORMATION
TION
Page 16 - Chapter 1
50Bmanual template7/26 2002.7.26 5:35 PM Page 18
USING THE MENU
USING THE MENU
USING THE MENU
1. Press in the standby screen to enter the main menu.
2. Use the navigation key to view menu selections.
3. To go back to previous screen, press .
4. To the exit menu, press .
5. To go into submenu, press the corresponding number
or select the desired item using the navigation key.
6. , , and can be used for scrolling through the
menu.
Chapter 2 - Page 19
USING THE PHONE
USING THE PHONE
TURNING THE PHONE ON
1. Press .
-
If “PASSWORD” is displayed, the phone
is locked. To
unlock, enter your 4-digit password.
NOTE: 1.
If “LOW BATTERY WARNING POWER OFF”
is
displayed and the power goes off, there is a
possibility of damaging your phone’s memory.
Change or
charge the battery immediately.
2.
If the battery is removed while the phone is on,
information about the last call may be erased.
NOTE: The default password is the last 4 digits of your
phone number.
TURNING THE PHONE OFF
1. Press and hold until “Power Off” is displayed.
Page 18 - Chapter 2
50Bmanual template7/26 2002.7.26 5:35 PM Page 20
5 : SETTING u
MENU SUMMAR
MENU SUMMARY
Y
6 : TOOLS u
8 : LOCATION
1 : Sounds
2 : Display
3 : Security
4 : Others
5 : UP Proxy IP
1 : Calculator
2 : World Clock
3 : Stopwatch
1 : Connection
2 : Data Speed
1 : Setting
u
7 : DATA SVC. u
1 : Ringer Type
2 : Ringer Mode
3 : Volume
4 : Alert
5 : Roam Ringer
6 : Tone Length
1 : Animation Setting
2 : Main Display Setting
3 : LCD Setting
4 : Sub LCD Setting
1 : Restrict
2 : Special #’s
3 : Clear Phonebook
4 : Reset Phone
5 : Change Password
1 : Answer Mode
2 : Active Flip
3 : Auto Retry
4 : Auto Answer
5 : Voice Privacy
6 : Key Guard
7 : Language
8 : Web Idle Time
9 : S/W Version
Chapter 2 - Page 21
MENU SUMMAR
MENU SUMMARY
Y
1 : CALL
HISTORY
2 : PHONE
BOOK
3 : SCHEDULE
4 : ROAMING u
u
u
u
1 : Last Call
2 : All Calls
3 : Home Calls
4 : Roam Calls
5 : Accumulate Calls
1 : By Group
2 : BY NAME
3 : BY NUMBER
1 : Add New Entry
2 : Edit Existing Entry
1 : Add New Group
2 : Change Group Name
3 : Change Group Bell
4 : Change Group Color
5 : Clear Group
1 : New Event
2 : View Event List
1 : Auto NAM
2 : Change NAM
1 : OFF
2 : ON
3 : 7 SECS
1 : Outgoing Calls
2 : Incoming Calls
3 : Missed Calls
4 : Call Times
1 : Find
2 : Edit Phone Book
3 : Edit Group
4 : Speed Dial
5 : My Profile
1 : Event
2 : Alarm
1 : Set Mode(System)
2 : Force Analog
3 : NAM Setting
4 : Call Prompt
5 : PRL ID
Page 20 - Chapter 2
50Bmanual template7/26 2002.7.26 5:35 PM Page 22
Chapter 2 - Page 23
BASIC FUNCTIONS
BASIC FUNCTIONS
MAKING A CALL
1. Enter the phone number.
2. Press to place the call.
3. When you have completed your conversation,
press
to end the call.
- To erase the last number entered, press .
- To erase all numbers entered and start again,
press and hold .
-
“CALL FAILED” will display if the call did not
connect.
- If the line is busy, press .
- Retry by pressing .
- Selecting AUTO RETRY will automatically redial
the number for the time you have selected. (Refer to
page XX)
Page 22 - Chapter 2
MENU SUMMAR
MENU SUMMARY
Y
9 : VOICE SVC
u
1.On/Off
2.Inbox
3.Greeting
4.Call Speaker
5.Wait Time
1.Yes/No
2.Wake-Up
3.Top Level
4.Digit Dial
1.List
2.Add
3.Clear All
1.On/Off
2.Record
3.Play
4.Clear
1.Untrain All
2.Prompt Mode
3.Digit Mode
4.HFK Mode
5.Set Active
1. Voice Memo
2. Call Answer
3. Voice Command
4. Voice Dial
5. Voice Alert
6. Voice Setting
50Bmanual template7/26 2002.7.26 5:35 PM Page 24
The phone resets to Speaker Phone Off when it turns off
and back on.
Chapter 2 - Page 25
BASIC FUNCTIONS
BASIC FUNCTIONS
SPEAKER PHONE
1. Press and hold to activate the feature of speaker
phone when the phone is in idle mode, answering mode,
and calling mode.
2. The phone returns to normal (speaker phone off) after
a call.
Page 24 - Chapter 2
ANSWERING CALLS
1. To answer a call, press any key except .
2. To end the call, press .
NOTE: Calls can be automatically answered by activating
the AUTO ANSWER function. (Refer to page XX)
NOTE: The Caller ID numbers are saved in the call log.
Caller ID is a system dependent feature. Please
contact your service provider for details.
CALLER ID
This function notifies you of who’s calling by displaying that
person’s phone number. If the caller’s name and number are
stored in your phonebook, the name and number from the
memory location are displayed.
BASIC FUNCTIONS
BASIC FUNCTIONS
DURING CALL MENU
1 : MUTE
2 : SILENT(QUIT)
3 : SENDING YOUR
NUMBER TO A
PAGER
4 : MY PROFILE
5 : VOICE PRIVACY
6 : LOCATION
STANDBY MENU
PAUSE INPUT:
1 : HARD PAUSE
2 : TIMED PAUSE
PAUSE FEATURE
Pauses are used for automated systems (i.e., voice mail
and calling cards). Insert a pause
after a phone number,
then enter another group of numbers
. The second set of
numbers is dialed automatically after the pause. This
feature is useful for dialing into systems that require a
code.
1. Enter the phone number, then press .
2. Select desired pause. A “P” will appear after the
number
to represent the pause.
3. Press to dial or press then to store.
HARD PAUSE: If you enter the pause character (P), the
number entered after the pause character will be sent
after the number dialed.
STO FIND PSE
50Bmanual template7/26 2002.7.26 5:35 PM Page 26
ADJUSTING THE VOLUME
You can adjust the volume in two ways: by using the volume
control keys on the side of the handset, or by using the menu.
The volume control keys will adjust the volume of the
earpiece and ringer at different times.
- During a Call : Adjusts earpiece volume.
- Standby Status : Adjusts ringer volume.
- When the Phone Rings : Adjusts ringer volume.
LOCK
Locks up your phone and allows you to use the phone only
after the password input.
1. Press and hold to lock the phone.
2. Input the password to unlock the phone.
Chapter 2 - Page 27
BASIC FUNCTIONS
BASIC FUNCTIONS
Page 26 - Chapter 2
BASIC FUNCTIONS
BASIC FUNCTIONS
CALL WAITING
This function notifies you of an incoming call when you
are on another call by sounding a beep tone.
1. When you hear the beep, press to answer the call.
2. To switch back to the first caller, press again.
NOTE:
Call Waiting is a system dependent feature.
Please
contact your service provider for details.
ANSWERING MACHINE DISPLAY
Notifies you that there are some recorded memos not
checked yet in the answering machine.
1. Displays the number of stored memos that are record-
ed in the answering machine.
Press to play the recorded voice memos.
50Bmanual template7/26 2002.7.26 5:35 PM Page 28
Chapter 2 - Page 29
NOTE: To turn mute off, press , then “Mute” again.
FUNCTIONS DURING A CALL
FUNCTIONS DURING A CALL
SENDING YOUR NUMBER TO A PAGER
This function enables your phone number to be
automatically
transmitted to a pager. (Dependent on
pager service.)
After calling a pager, when you are asked to enter your
number, press “SEND PHONE #”.
MUTE
You can mute the microphone while you are on a call so
the other party can not hear you if you speak.
1. Press “MUTE”.
Page 28 - Chapter 2
SILENT(QUIT)
Keeps the other end from hearing DTMF tone when
you press any key during a call.
Press “SILENT”.
- Press to deactivate it.
BASIC FUNCTIONS
BASIC FUNCTIONS
VIBRATE
This function disables the ringer and vibrates the phone
any time an incoming call is in process. To enable this
function press , and select SOUND and press
and select VIBRATE or by pressing the up and
down keys at the left upper side of the phone.
MANNER MODE
This function allows you to silence all phone sounds
while attending a meeting, a movie, or any other time
you do not want your phone to be heard. All phone
sounds include the ringer, key beeps and notifications.
Your phone will vibrate to notify you of an incoming call.
To enable this function, press and hold .
50Bmanual template7/26 2002.7.26 5:35 PM Page 30
CHAPTER 3
CHAPTER 3
MEMORY FUNCTION
1. Storing Phone Numbers
2. Text Input Methods
3. Speed Dialing
4. Call Logs
5. Call Times
6. Using Your Phonebook
This chapter describes how to save a phone number into
the internal phonebook, entering characters using standard
and T9TM text inputs, as well as accessing your call logs.
Chapter 3 - Page 31Page 30 - Chapter 2
FUNCTIONS DURING A CALL
FUNCTIONS DURING A CALL
LOCATION
Enablas the verizon network to locate your current
location through GPS. It is the same as the Location
to be specified in the Menu chapter. Please refer to
page77.
1. Press “LOCATION”.
MY PROFILE
Enablas to review and edit your profile, entered through
the phonebook entry. Please refer to page 49 for more
details.
1. Press “MY PROFILE”.
VOICE PRIVACY
Enhances voice privacy during a call.
1. Press “VOICE PRIVACY”.
2. Select “STANDARD” or “ENHANCED” with the joy-
stick key.
50Bmanual template7/26 2002.7.26 5:35 PM Page 32
TEXT INPUT METHODS
TEXT INPUT METHODS
Key Pad
1
2ABC
3DEF
4GHI
:
9WXYZ
1 Repetition
1
A
D
G
:
W
2 Repetitions
B
E
H
:
X
3 Repetitions
C
F
I
:
Y
4 Repetitions
2
3
4
:
Z
5 Repetitions
:
9
ENTERING CHARACTERS
Your phone offers several text input methods for convenient
text entry of memory location names and message
composition. Alpha mode [ABC] allows you to enter
words by tapping the corresponding key repeatedly until
the desired character is displayed. T9TM mode [T9ABC]
allows you to tap each key only once and predicts the
word you are entering. Numeric mode [123] allows you
to enter numbers only and Symbol mode [SYM] allows
you to enters symbols like @, #, %.
- Cursor moves to the next column automatically two
seconds after character input.
- To erase one letter, press .
- To erase the entire entry, press and hold .
-
To switch between lowercase to uppercase letters,
press .
Alpha Mode [ABC]
To choose Alpha mode, press then choose [ABC]. The
chart below outlines the key presses needed to display
each letter or number in this mode.
Chapter 3 - Page 33
2. Enter the person’s name and press .
3. To mark the phone number as Secret, select Yes.
-
Marking a phone number as Secret means that the
number can only be displayed after the lock code has
been entered.
STORING PHONE NUMBERS
STORING PHONE NUMBERS
You can store up to XX frequently used phone numbers
into your phone’s memory.
1. Enter the phone number, including area code and
press .
- The next available empty memory location number
is
displayed. If there are no empty locations, “MEMORY
IS
FULL!” is displayed with a warning sound.
- If you wish to save the phone number into a specific
memory location, enter that number when the location
number is highlighted.
NOTE:
If “XX LOCATION IS USED” appears on the display
after
entering the memory location number, it
means
there is another stored phone number in that
location already.
Page 32 - Chapter 3
50Bmanual template7/26 2002.7.26 5:35 PM Page 34
1. Press each key once for each letter of the word you
are writing.
-To write John with the English dictionary selected:
1. Press 5 once - (for J)
2. Press 6 once - (for o)
3. Press 4 once - (for h)
4. Press 6 once - (for n)
2. Press until the correct word is displayed.
3. Press to select the correct word.
TEXT INPUT METHODS
TEXT INPUT METHODS
NOTE:
The display shows the above words for each key
pressed.
Chapter 3 - Page 35
TEXT INPUT METHODS
TEXT INPUT METHODS
Mode
[0]
Next
[#]
Space
Clear
Left, Right
Press to change text input mode:
[T9Abc][Abc][123][Sym]
Select [T9Abc] for predictive text
input.
Press to view the next matching
word if the underlined word is not
the word you intended.
Press once to accept a word and
add a space.
Press once to delete the character
to the left of the cursor.
To move cursor.
KEY FUNCTION
T9TM Predictive Text Mode [T9ABC]
To choose T9 mode, press then choose [T9ABC].
This mode predicts the words you are entering using a
built-in dictionary. With T9 predictive text input, you press
each key only once for each letter. The chart below outlines
how to use T9TM text input.
Page 34 - Chapter 3
50Bmanual template7/26 2002.7.26 5:35 PM Page 36
SPEED DIALING
SPEED DIALING
ONE-TOUCH/TWO-TOUCH DIALING
This feature allows phone book entries to be dialed via
the keypad with only one or two key presses. This feature
is good for frequently used phone numbers.
ONE-TOUCH DIALING:
1-9 : Press the corresponding memory number and hold
for more than 1 second.
TWO-TOUCH DIALING:
00, 10-20 : Press the first digit and second digits of the
memory number short and long respectively.
- If no phone number is stored in the location entered,
“Empty Location” will appear on the screen.
- If a phone number is stored in secret, the number is not
displayed when making the call.
NOTE:
One-touch dialing must be turned on in the handset.
See page XX.
Chapter 3 - Page 37
Numeric Mode [123]
Numeric mode allows you to add a number to your
entry/message. To choose numeric mode, press then
choose [123].
TEXT INPUT METHODS
TEXT INPUT METHODS
Symbol Mode [SYM]
Symbol mode allows you to add various symbols to your
entry. Whether you are adding an email address to your
phonebook or sending an expressive message, symbols
make these entries easier. To choose symbol mode,
press then choose [SYM]. The symbols will appear
on the display. The corresponding key number for that
symbol will appear with as well. You can press the key
to select the symbol or use the navigation key to highlight
the symbol, then press . Press to move to
the next screen of symbols.
Page 36 - Chapter 3
50Bmanual template7/26 2002.7.26 5:35 PM Page 38
INCOMING CALLS
1. Press , then [1], then [2].
The list of the 10 most recent answered calls will be dis-
played with the most recent call being listed first.
2. Scroll through the list of answered calls using the
navigation key. Select the desired phone number then
press to check the detail information about the
selected phone number.
- Detail information includes the phone number, its log
number, time and date of the call.
3. Press to dial desired missed call number.
CALL LOGS
CALL LOGS
OUTGOING CALLS
1. Press , then [1], then [1].
The list of the 10 most recent dialed calls will be dis-
played with the most recent call being listed first.
2. Scroll through the list of dialed calls using the navigation
key. Select the desired phone number then press to
check the detail information about the selected phone
number.
- Detail information includes the phone number, its log
number, time and date of the call.
3. Press to dial desired missed call number.
Chapter 3 - Page 39
CALL LOGS
CALL LOGS
Your phone keeps a log of the 10 most recent missed,
answered (incoming), and dialed (outgoing) calls. You can
recall them, view time and date information about each log
and call each number without having to dial the number.
Page 38 - Chapter 3
50Bmanual template7/26 2002.7.26 5:35 PM Page 40
Chapter 3 - Page 41Page 40 - Chapter 3
CALL LOGS
CALL LOGS
MISSED CALLS
1. Press , then [1], then [3].
The list of the 10 most recent missed calls will be dis-
played with the most recent call being listed first.
2. Scroll through the list of missed calls using the
navigation key. Select the desired phone number then
press to check the detail information about the
selected phone number.
- Detail information includes the phone number, its log
number, time and date of the call.
3. Press to dial desired missed call number.
CALL TIMES
CALL TIMES
LAST CALL
This function displays the total amount of time of your
last call.
1. Press , then [1], then [4]. then [1].
ALL CALLS
This function displays the total amount of time of all your
calls.
1. Press , then [1], then [4]. then [2].
HOME CALLS
This function displays the total amount of time of all your
calls from within your home area.
1. Press , then [1], then [4]. then [3].
ROAM CALLS
This function displays the total amount of time of all your
calls from outside your home area.
1. Press , then [1], then [4]. then [4].
ACCUMULATE CALLS
Displays talk time of cumulate calls
1. Press , then [1], then [4]. then [5].
50Bmanual template7/26 2002.7.26 5:35 PM Page 42
Chapter 3 - Page 43Page 42 - Chapter 3
USING YOUR PHONEBOOK
USING YOUR PHONEBOOK
EDITING YOUR PHONEBOOK
After you have searched and found a memory location
number, you can edit or erase that location number and
its contents.
RECALLING BY LOCATION NUMBER
You can recall phone numbers saved in your phonebook
by searching for the location number. Search results will
show you the name and phone number saved to that
memory location number.
1. Press , then [2], then [1], then [3].
2. Enter the memory location number.
3. Press to dial the phone number.
ADD NEW ENTRY
1. Press , then [2], then [2], then [1] to add a new
entry to the phonebook.
2. Move to a field of phonebook entry with the joystick
key and enter a name or a number as required in the
field.
3. Press to save it or to return to the previ-
ous page.
RECALLING BY GROUP
1. Press , then [2], then [1], then [1].
2. Select one of the following options(Family, Friends,
Work, Etc, All) with the joystick key.
3. Press to retrieve the phonebook by the group.
4. All the entries under the group are to be displayed.
You can either delete or view an entry by pressing or
respectively when it is selected.
5. Press to make a call when a phone number is
selected.
RECALLING BY NAME
1. Press , then [2], then [1], then [2].
2. Enter a name or its character string and press
to sort out the phonebook and display names in an
alphabetical order regardless of letter case.
(Please refer to page 31 about the usage of Alpha
Editor)
3. All the related entries are to be displayed. You can
either delete or view an entry by pressing or
respectively when it is selected.
4. Press to make a call when a phone number is
selected.
USING YOUR PHONEBOOK
USING YOUR PHONEBOOK
50Bmanual template7/26 2002.7.26 5:35 PM Page 44
Chapter 3 - Page 45Page 44 - Chapter 3
USING YOUR PHONEBOOK
USING YOUR PHONEBOOK
CHANGE GROUP BELL
1. Press , then [2], then [3], then [3] to change a group
bell.
2. Select the group, the bell of which to change.
3. Select one of the bell options with the joystick key.
4. Press to save it.
CHANGE GROUP COLOR
1. Press , then [2], then [3], then [4] to delete an exist-
ing group.
2. Select a group to delete with the joystick key.
3. Select one of the group color with the joystick key.
4. Press to save it.
CHANGE GROUP NAME
1. Press , then [2], then [3], then [2] to change a
group name.
2. Select an existing group name with the joystick key
3. Input a new name.
4. Press to save it.
5. Press to confirm it.
EDIT GROUP
Adds, changes and deletes a group.
USING YOUR PHONEBOOK
USING YOUR PHONEBOOK
ADD NEW GROUP
1. Press , then [2], then [3], then [1] to add a new
group to the 5 existing groups.
You are to have the maximum 7 groups.
2. Input a new group name.
3. Press to save it.
EDIT EXISTING ENTRY
1. Press , then [2], then [2], then [2] to edit an exist-
ing entry.
- You are to see 5 groups, by which all the entries are
divided.
2. Select one of the following groups with the joystick
key.
- Family, Friends, Work, Etc, All
3. Select an entry under the group with the joystick
key. And press to view and edit the entry or
to delete the entry.
50Bmanual template7/26 2002.7.26 5:35 PM Page 46
Chapter 3 - Page 47Page 46 - Chapter 3
SPEED DIAL
Links a phone number of phonebook entry to a location
number and enables you to make a call simply by press-
ing its location number in the idle mode.
1. Press , then [2], then [4].
2. Select a location and press to link a phone
number to the location.
- Press and the joystick key to delete it when a
phone number already exists in the location.
3. Select the group, under which you have the phone-
book entry where the phone number is saved. And
press .
4. Select the entry and press .
5. Select the phone number and press .
USING YOUR PHONEBOOK
USING YOUR PHONEBOOK
MY PROFILE
Saves and edits your personal information.
1. Press , then [2], then [5] to review and edit your
personal information as follows. (Name, My Phone num-
ber, Birthday, Blood Type, Address, Home, E-Mail, Work
Phone #, Meno, Set Secret).
2. Press to edit on item when selected.
3. Press to confirm and save it.
USING YOUR PHONEBOOK
USING YOUR PHONEBOOK
CLEAR GROUP
1. Press , then [2], then [3], then [5] to delete an exist-
ing group.
2. Select a group to delete with the joystick key.
3. Press to delete it.
4. Press again to confirm it.
50Bmanual template7/26 2002.7.26 5:35 PM Page 48
This chapter describes how to adjust your phone to best
suit your needs and wants. You can adjust the backlighting,
volume, ring tones, and other user-friendly features.
1. Setting
2. VR Mode
3. VR Menu
CHAPTER 4
CHAPTER 4
SETTINGS
Chapter 4 - Page 49Page 48 - Chapter 3
MEMO
MEMO
50Bmanual template7/26 2002.7.26 5:35 PM Page 50
Chapter 4 - Page 51Page 50 - Chapter 4
Scans the channels to stay connected to any available
system of VERIZON.
SET MODE
Selects the Preferred System.
1. Press , then [4], then [1].
2. Select one of the following options(Automatic
A/Automatic B/Home only) with the joystick key and
press .
- Auto A : Scan the radio channels based on the
Automatic A setting.
- Auto B : Scan the radio channels based on the
Automatic B setting.
- Home only : Only within your home area or home
affiliated area.
FORCE ANALOG
Temporarily forces phone to use Analog mode – mode
automatically ends in 10 minutes.
1. Press , then [4], then [2].
2. Select “Yes” or “No” with the joystick key and
press to activate it.
SETTING
SETTING
NAM SETTING
Enables Auto NAM or changes a NAM manually.
SETTING
SETTING
AUTO NAM
Automatically switches phone to proper NAM when you
have multiple NAM registrations.
1. Press , then [4], then [3], then [1].
2. Select “Yes” or “No”, then press to save it.
CHANGE NAM
Changes the NAM (Number Assignment Modules) used
by the phone when you have multiple registrations.
1. Press , then [4], then [3], then [2].
2. Select a NAM(NAM1,NAM2) with the joystick key
and press to save it.
50Bmanual template7/26 2002.7.26 5:35 PM Page 52
Page 52 - Chapter 4
SETTING
SETTING
CALL PROMPT
Natifies you whether you are to be charged for an
incoming call in roaming service area.
1. Press , then [4], then [4].
2. Select one of the following options and press to
confirm it.
- Off : Not display [TO BE CHARGED].
- On : Display [TO BE CHARGED] until the user
answer an incoming call.
- 7 seconds : Display [TO BE CHARGED] for only 7
seconds and return to normal.
PRL ID
Displays the phone’s PRL (Preferred Roaming List).
1. Press , then [4], then [5].
ERI (Enhanced Roaming Indicator)
Cellular systems are identified by a
number called the System Identification
Number or SID. Your phone is equipped
with a Preferred Roaming LIst (PRL) which
can be programmed by your Carrier to
take advantage of the families of cellular
systems (SIDs) that your Carrier owns or
has special billing arrangements with in
various cities.
Chapter 4 - Page 53
SETTING
SETTING
SOUNDS
You are to set Ringer type, Ringer mode, Volume, Alert,
Roam Ringer and Tone length.
RINGER TYPE
Selects a ringer type to alert you of an incoming call.
1. Press , then [5], then [1], then [1].
2. Select one ringer type that best fits your favor.
There are 40 melodies and 10 ringer types available.
3. Press to confirm it.
RINGER MODE
Alerts you to incoming calls in the following modes:
1. Press , then [5], then [1], then [2].
2. Select one of the following options with the joystick
key.
- Ringer
- Ringer after Vibrate – The ringer sounds off after
vibration.
- Vibrator
- Silent – Mute the ringer
3. Press to confirm it.
PRL ID
1
ERI VERSION
00000
50Bmanual template7/26 2002.7.26 5:35 PM Page 54
SETTING
SETTING
VOLUME
Controls the volume of the following items. The volume
can be adjusted in 5 steps.
RINGER
Controls the Ringer volume.
1. Press , then [5], then [1], then [3], then [1].
2. Adjust the ringer volume with the joystick key.
3. Press to save it.
KEY
Controls the keypad tone.
1. Press , then [5], then [1], then [3], then [2].
2. Adjust the keypad tone with the joystick key.
3. Press to save it.
VOICE CALL
Controls the earpiece volume
1. Press , then [5], then [1], then [3], then [3].
2. Adjust the earpiece volume with the joystick key..
3. Press to save it.
Chapter 4 - Page 55Page 54 - Chapter 4
SETTING
SETTING
ALERT
Gives you an alert to any change occurring on the
phone.
MINUTE ALERT
Sounds an alert every minute of a phone call.
1. Press , then [5], then [1], then [4], then [1].
2. Select “OFF” or “ON” with the joystick key and
press to save it.
ROAM ALERT
Sounds an alert when leaving a service area and
entering a roaming service area.
1. Press , then [5], then [1], then [4], then [2].
2. Select “OFF” or “ON” with the joystick key and
press to save it.
CONNECT ALERT
Notifies you that a call has been successfully placed.
1. Press , then [5], then [1], then [4], then [3].
2. Select “OFF” or “ON” with the joystick key and
press to save it.
50Bmanual template7/26 2002.7.26 5:35 PM Page 56
SETTING
SETTING
FADE ALERT
Sounds an alert entering an area where calls cannot
be made due to weak signal strength. The alert sounds
in standby mode.
1. Press , then [5], then [1], then [4], then [4].
2. Select “OFF” or “ON” with the joystick key and
press to save it.
LOW SIGNAL ALERT
Sounds an alert when you encounter low signal
strength during a call.
1. Press , then [5], then [1], then [4], then [5].
2. Select “OFF” or “ON” with the joystick key and
press to save it.
Chapter 4 - Page 57Page 56 - Chapter 4
SETTING
SETTING
ROAM RINGER
Sounds a different ringer from what is set in ringer
type, when you have a call in roaming service area.
This function reminds you that you are in a roaming
service area, by sounding a different ringer from what
you set as voice call in Ringer type.
1. Press , then [5], then [1], then [5].
2. Select “Distinctive” or “Normal” with the joystick
key and press to save it.
- Distinctive – Sounds a different ringer type
- Normal – Sounds the same ringer type as used in
Home area.
TONE LENGTH
With this function, you are to adjust the tone length.
1. Press , then [5], then [1], then [6].
2. Select “Normal” or “Long” with the joystick key
and press to save it.
50Bmanual template7/26 2002.7.26 5:35 PM Page 58
SETTING
SETTING
DISPLAY
With this function, you will customize the display to best
fit your favor.
ANIMATION SETTING
Selects your favorite LCD display in the following
modes
IDLE DISPLAY
1. Press , then [5], then [2], then [1], then [1].
2. Select one from the Animation List to use in the
idle mode by moving the joystick key up, down, left
and right.
3. Press to save it.
POWER ON
1. Press , then [5], then [2], then [1], then [2].
2. Select one from the Animation List to display
when you turn on the handset by moving the joystick
key up, down, left, and right.
3. Press to save it.
Chapter 4 - Page 59Page 58 - Chapter 4
SETTING
SETTING
POWER OFF
1. Press , then [5], then [2], then [1], then [3].
2. Select one from the Animation List to display
when you turn off the handset by moving the joystick
key up, down, left, and right.
3. Press to save it.
MAIN DISPLAY SETTING
Selects your favorite LCD display in the following
modes
GREETING INPUT
Inputs a personal greeting on edits an existing one.
1. Press , then [5], then [2], then [2], then [1].
2. Press the joystick key to edit the greeting.
3. Input your personal greeting, using the Alpha
Editor.
4. Press to save it.
50Bmanual template7/26 2002.7.26 5:35 PM Page 60
SETTING
SETTING
IDLE CLOCK
Displays a clock on the LCD in four different types.
1. Press , then [5], then [2], then [2], then [2].
2. Select one of the following options and
press to save it.
- Digital Clock
- Analog Clock
- Greeting Clcok
- Animation Clock
LCD SETTING
Controls backlight and LCD contrast for better view and
efficient use.
BACKLIGHTING
Backlights the display and keypad for easy viewing in
dark places.
1. Press , then [5], then [2], then [3], then [1].
2. Select one of the following options; 5sec, 10 sec,
20 sec, Off.
Press to save it.
- Off : Turn the backlight off.
- 5 sec, 10 sec, 20 sec : Backlight on for 5, 10, or
20seconds respectively after a touch of the keypad.
Chapter 4 - Page 61Page 60 - Chapter 4
SETTING
SETTING
CONTRAST
The LCD display contrast can be controlled in 7 levels.
1. Press , then [5], then [2], then [3], then [2].
2. Adjust the LCD contrast for better view.
3. Press to save it.
LCD COLOR
Backlights the display and keypad for easy viewing in
dark places.
1. Press , then [5], then [2], then [3], then [3].
2. Select one of the following options; Automatic,
Red, Green, Deep Green, Purple, White.
Press to save it.
- Automatic
- Red
- Green
- Deep Green
- Purple
- White
50Bmanual template7/26 2002.7.26 5:35 PM Page 62
SETTING
SETTING SETTING
SETTING
SUB LCD SETTING
Controls backlight and SUb LCD contrast for better
view and efficient use.
SUB LCD CLOCK
Backlights the display and keypad for easy viewing in
dark places.
1. Press , then [5], then [2], then [4], then [1].
2. Select one of the following options; Analog Clock,
Digital Clock.
Press to save it.
- Analog Clock
- Digital Clock
SUB LCD CONTRAST
The Sub LCD display contrast can be controlled in 5 lev-
els.
1. Press , then [5], then [2], then [4], then [2].
2. Adjust the Sub LCD contrast for better view.
3. Press to save it.
Chapter 4 - Page 63Page 62 - Chapter 4
OTHERS
Includes all the useful functions for optimum use of the
handset.
ANSWER MODE
Selects an Answer mode as follows.
1. Press , then [5], then [4], then [1].
2. Select “Any Key” or “Send Key” with the joystick
key
- Any Key – Press any key to answer an incoming call
except , , and .
- Send Key – Press only to answer a call.
3. Press to save it.
ACTIVE FLIP
Selects an Answer mode as follows.
1. Press , then [5], then [4], then [2].
2. Select “On” or “Off” with the joystick key
3. Press to save it.
50Bmanual template7/26 2002.7.26 5:35 PM Page 64
SETTING
SETTING
AUTO ANSWER
Automatically answers a call after a preset number of
rings. An ideal setting for the hands-free car kit.
1. Press , then [5], then [4], then [4].
2. Select one from the following items with the joy-
stick key.
- Off/5/10/18 seconds.
3. Press to save it.
VOICE PRIVACY
Enhances voice privacy and avoids tapping during a
call.
1. Press , then [5], then [4], then [5].
2. Select “Standard” or “Enhanced”, if available.
- “Enhanced” - Make it more difficult to wire tap.
3. Press to save it.
Chapter 4 - Page 65
SETTING
SETTING
AUTO RETRY
Automatically retries a call up to 5 times after a set
time interval.
RETRY TIME
1. Press , then [5], then [4], then [3], then [1].
2. Select a time interval option (Off,3,5,7,10 sec-
onds) with the joystick key.
Press to save it.
REPEAT
Prevents others from using your phone without permis-
sion. When locked, the menu can not be accessed with-
out password.
1. Press , then [5], then [4], then [3], then [2].
2. Select one of the options (1 time,3 times,5 times)
with the joystick key.
Press to save it.
Page 64 - Chapter 4
NOTE: This function will not be activated when you
select Vibrate, Silent,or Ringer after vib as a ringer mode.
50Bmanual template7/26 2002.7.26 5:35 PM Page 66
SETTING
SETTING
WEB IDLE TIME
This function disconnects your phone from a network
when there is no key input for a certain time period.
1. Press , then [5], then [4], then [8].
2. Use the joystick key to set the web idle timer or
press digit keys one by one to enter the time.
- Not exceed three digits.
3. Press to save it.
S/W VERSION
Displays the version of your phone.
1. Press , then [5], then [4], then [9].
2. You are to see the version of software and hard-
ware.
UP PROXY IP
The phone can have up to 3 sets of the server IP
(Internet Protocal) addresses and Port numbers to
access your service provider’s website. These may
already be preset or be separately programmed by
your service provider. Please noted that any change to
these settings may disable the Web access capability.
1. Press , then [5], then [5].
Chapter 4 - Page 67
SETTING
SETTING
KEY GUARD
1. Press , then [5], then [4], then [6].
2. Select “On” or “Off” with the joystick key.
- On – Prevent unintended press of the keypad. To
unlock the key guard, please press , , .
- Off – Not set the key guard.
3. Press to save it.
LANGUAGE
Selects the language in which letters are displayed on
screen.
1. Press , then [5], then [4], then [7].
2. Select either “English” or “Spanish”.
3. Press to save it.
Page 66 - Chapter 4
50Bmanual template7/26 2002.7.26 5:35 PM Page 68
VR MODE
VR MODE
DIAL
1. Press and hold and wait until your phone turns
to VR mode.
2. Say “Dial” in the VR mode and you will see the
display on the right.
3. Press or say the digits of the phone number.
4. Say “Call” after you enter the entire number.
REDIAL
1. Press and hold and wait until your phone turns
to VR mode.
2. Say “Redial” in the VR mode to dial the last dialed
number.
Chapter 4 - Page 69
VR MODE
VR MODE
The VR(Voice Recognition) enables you to call in vari-
ous ways through your voice and record your voice
memos.
1. Press and hold and wait until your phone turns
to VR mode.
2. The display on the right will appear when the
phone turns to VR mode.
NAME
1. Press and hold and wait until your phone turns
to VR mode.
2. Say a recorded name or tag in the VR mode and
you will see a number dialed with a name on the dis-
play and also hear “calling<name>”when there is the
matched voice tag in the phonebook entry.
Page 68 - Chapter 4
NOTE: Depending on the prompt mode, expert or begin-
ner,you will hear a different set of prompts that follows.
You can hear the second prompt when nothing is said.
Beginner Mode
- 1st : “Main Menu”
- 2nd : “Speak a name to call, or say dial, redial, voice
memo, phonebook or cancel”.
Expert Mode
- 1st : “Main Menu”
- 2nd : “Main Menu”
Once you say one of the following menus, you will go
through each of the procedures.(name, dial, redial, voice
memo, phonebook, cancel)
NOTE:
Beginner mode
- 1st prompt :“Digit menu”
- 2nd prompt :“Say digits or verify, cancel, clear,or call”.
Expert mode
- 1st prompt :“Doo-doo”,a sequence of high tone and low
tone.
- 2nd prompt :“Digit menu”
Depending on the prompt mode, expert or beginner,you
will hear a different set of prompts that follows. You can
hear the second prompt when nothing is said.
50Bmanual template7/26 2002.7.26 5:35 PM Page 70
VR MODE
VR MODE
CANCEL
1. Press and hold and wait until your phone turns
to VR mode.
2. Say “Cancel” in the VR mode to exit the VR mode
or return to the standby mode.
Chapter 4 - Page 71
VR MODE
VR MODE
VOICE MEMO
1. Press and hold and wait until your phone turns
to VR mode.
2. Say “Voice Memo” in the VR mode and follow the
steps as instructed in the display.
3. Press to stop recording a memo.
4. You could REVIEW, RE-RECORD, or SAVE it
after recording a voice memo.
PHONE BOOK
1. Press and hold and wait until your phone turns
to VR mode.
2. Say “Phone book” in the VR mode.
Page 70 - Chapter 4
NOTE: Press to pause, then press to resume.
The list of phonebook entries with voice tag will be dis-
played, each voice tag deing played.
NOTE: You can make a call to a phone number if you
have attached a voice tag to the phone number by saying
“Yes” while the voice tag is being played.
50Bmanual template7/26 2002.7.26 5:35 PM Page 72
VS MENU
VS MENU
CALL ANSWER
Sets and operates the answering machine.
1. Press .
2. Press [2].
3. Select one of the following options with the joy-
stick key and press .
Chapter 4 - Page 73
VS MENU
VS MENU
VOICE MEMO
1. Press to start VS menu.
2. Press [1] to enter the voice memo menu.
3. Press [1] to record a voice memo and you will see
the instruction displayed and hear “Please record it
at the tone”.
4. Press to stop recording a memo.
5. You could PEVIEW, RE-RECORD, or SAVE it after
recording a voice memo.
Page 72 - Chapter 4
Press [2] to view and play voice memos.
Press [3] to erase all the voice memos. ON/OFF : Turns the Auto Answering machine on/off.
INBOX : Play or erase a recorded memo.
GREETING : Recoras, Plays and Erases your personalized
greeting. You have the maximum 30 seconds to record a
greeting.
CALL SPEAKER ON (OFF) : You can(not)hear the caller’s
voice being recorded in the answering machine.
WAIT TIME : No Ringer, 5s, 10s, 18s. The answering
machine will be operated in a specific time.
ICONS IN THE STORED MEMO LIST
: A recorded memo in Answering machine that you have
not checked yet.
: A recorded memo in Answering machine that you have
already checked.
✓
NOTE: Press to pause, then press to resume.
NOTE:
RECORDING LIMITATION :
You have a limit of 10 voice memos including those in
Answering Machine. Each voice memo has the time limit of
60 seconds.
50Bmanual template7/26 2002.7.26 5:35 PM Page 74
VS MENU
VS MENU
WAKE UP
Use the Wake-Up to train or untrain the VR with the
control word, wake up.
1. Press .
2. Press [3][2].
3. Select one of the following options with the joy-
stick key and press .
Chapter 4 - Page 75Page 74 - Chapter 4
LIST WORDS : Display the list of control words in the wake
up set.You will select a control word from the list, press
. You are to either train, untrain or view the status of
control word. To train with a word, press [1] and follow the
voice prompts.
TRAIN ALL : Train Wake-up set to recognize your voice.
UNTRAIN ALL : Untrain Wake-up set not to recognize
trained control words.
VS MENU
VS MENU
VOICE COMMAND
Trains the VR with a category of control words as fol-
lows.
YES/NO
1. Press .
2. Press [3][1].
3. Select one of the following options with the joy-
stick key and press .
LIST WORDS : Display the list of control words in the
Yes/No set.You will select a control word from the list,
press . You are to either train, untrain or view the sta-
tus of control word. To train with a word, press [1] and fol-
low the voice prompts.
TRAIN ALL : Train Yes/No set to recognize your voice.
UNTRAIN ALL : Untrain Yes/No set not to recognize trained
control words.
50Bmanual template7/26 2002.7.26 5:35 PM Page 76
VS MENU
VS MENU
DIGIT DIAL
Use the Digit dial to train or untrain the VR with the
control words (1 to 9, Zero, Oh, Verify, Clear, Call).
1. Press .
2. Press [3][4].
3. Select one of the following options with the joy-
stick key and press .
Chapter 4 - Page 77Page 76 - Chapter 4
LIST WORDS 1,2 : Display the list of control words in the
digit dial set.You will select a control word from the list,
press . You are to either train, untrain or view the sta-
tus of control word. To train with a word, press [1] and fol-
low the voice prompts.
TRAIN ALL : Train Digit dial set to recognize your voice.
UNTRAIN ALL : Untrain Digit dial set not to recognize
trained control words.
VS MENU
VS MENU
TOP LEVEL
Use the Top Level to train or untrain the VR with your
control words. (Dial, Redial, Voice memo, Phonebook,
Cancel).
1. Press .
2. Press [3][3].
3. Select one of the following options with the joy-
stick key and press .
LIST WORDS : Display the list of control words in the top
level set.You will select a control word from the list, press
. You are to either train, untrain or view the status of
control word. To train with a word, press [1] and follow the
voice prompts.
TRAIN ALL : Train Top level set to recognize your voice.
UNTRAIN ALL : Untrain Top level set not to recognize
trained control words.
50Bmanual template7/26 2002.7.26 5:35 PM Page 78
VS MENU
VS MENU
ADD
1. Press .
2. Press [4][2] to add a voice tag to phonebook entry.
3. Select one group with the joystick key and press .
4. Select a phone number with the joystick key and
press .
5. Speak a name to add a voice tag to the number.
CLEAR ALL
1. Press .
2. Press [4][3] to erase all voice tags in the list.
3. You will see “Removing all voice tags proceed?”.
4. Press and you will see a message.
5. Press to clear all voice tags.
Chapter 4 - Page 79Page 78 - Chapter 4
OK : Proceed to erase all the voice tags.
CNCL : Return to the previous page.
VS MENU
VS MENU
VOICE DIAL
Lists, adds and erases voice tags of phonebook entry
LIST
1. Press .
2. Press [4][1] to list phonebook entries that have
voice tags attached.
3. Select one with the joystck key and press .
4. Press to play a voice tag or to edit an
existing voice tag.
5. Select one of the following options and press .
EDIT : Retrain / Voice Setting / Clear
PLAY : Voice tag play.
1) Retrain - You will see “Retrain Voice Name?” displayed.
Press , then speak a neme.
2) Voice Setting - You will see “Change?”.
Press , and select a phone number,
then press again.
3) Clear - You will see “Removing Voice Names Proceed?”
Press and all voice tags were deleted successfully.
50Bmanual template7/26 2002.7.26 5:35 PM Page 80
VS MENU
VS MENU
PLAY
1. Press .
2. Press [5][3].
3. You could PEVIEW it after recording a voice alert
message.
Chapter 4 - Page 81Page 80 - Chapter 4
CLEAR
1. Press .
2. Press [5][4] to erase voice alert message.
3. Select “No” or “Yes” with the joystick key and
press .
VS MENU
VS MENU
VOICE ALERT
Sets the voice alert in a way that you feel comfortable
ON/OFF
1. Press .
2. Press [5][1].
3. Select “On” or “Off” with the joystick key and
press .
RECORD
1. Press .
2. Press [5][2].
3. You will see the instruction displayed and record
a voice alert message.
4. Press to stop recording a memo.
50Bmanual template7/26 2002.7.26 5:35 PM Page 82
VS MENU
VS MENU
Chapter 4 - Page 83Page 82 - Chapter 4
VS MENU
VS MENU
VOICE SETTING
Sets the voice service menu in a way that you feel comfortable
UNTRAIN ALL
1. Press .
2. Press [6][1].
3.
Select “Yes” or “No” with the joystick key and press .
PROMPT MODE
Use the prompt mode to select either beginner or expert mode.
The expert mode consists of shorter texts and just beeps as
opposed to the beginner mode that gives full instructions.
1. Press .
2. Press [6][2].
3. Select one from Beginner/Expert with the joystick
key. Press .
<Beginner mode>
1st prompt : “Main menu ”followed by a short beep.
2nd prompt : “Speak a name to call, or say dial, redial, voice
memo, phone book, or cancel”, followed by a short beep.
<Expert mode>
1st prompt : A sequence of low tone and high tone.
2nd prompt : “Main menu”.
NOTE:
The VR times out and the phone returns to the standby
mode after the 1st and 2nd prompts are heard, and
nothing said.
DIGIT MODE
Use the digit mode to select one of the following
options ; ECHO, BEEP, ECHO+BEEP.
1. Press .
2. Press [6][3].
3. Select one option with the joystick key and
press .
HFK MODE
HFK stands for hands-Free car kit. With this function,
you can activate and utilize the VR feature when the
phone is in hands free car kit.
1. Press .
2. Press [6][4].
3. Select “Off” or “On” with the joystick key and
press .
ECHO : A digit echoes back when you enter the digit in the
VR mode.
BEEP : A digit just beeps when you enter the digit in the
VR mode.
ECHO+BEEP : A digit echoes and beeps when you enter
the digit in the VR mode.
NOTE: Once you speak”Wake Up” and the phone recog-
nizes your voice, you will hear a beep.
The second time you say “Wake Up”, your phone turns to
VR mode.
50Bmanual template7/26 2002.7.26 5:35 PM Page 84
This chapter describes how to lock and unlock you
phone, restrict calls to certain types of phone numbers,
and clear your phonebook’s memory.
1. Security Features
CHAPTER 5
CHAPTER 5
SECURITY FEATURES
Chapter 5 - Page 85Page 84 - Chapter 4
VS MENU
VS MENU
SET ACTIVE
1. Press .
2. Press [6][5].
3. Select “VR Key” or “Active Flip” with the joystick
key and press .
50Bmanual template7/26 2002.7.26 5:35 PM Page 86
SECURITY FEA
SECURITY FEATURES
TURES
Chapter 5 - Page 87
SECURITY FEA
SECURITY FEATURES
TURES
Page 86 - Chapter 5
INCOMING CALL
Blocks all incoming calls but allows outgoing calls to be
placed.
1. Press , then [5], then [3] and enter “PASSWORD”.
2. Press and select “Allow” or “Restrict” with
the joystick key.
- Restrict : Restrict an incoming call
- Allow : Allow an incoming call
3. Press to save it.
OUTGOING CALL
Blocks all outgoing calls except emergency calls from
being placed, but allows incoming calls to be answered.
1. Press , then [5], then [3] and enter “PASSWORD”.
2. Press and select “Allow” or “Restrict” with
the joystick key.
- Restrict : Restrict an outgoing calls.
- Allow : Allow an outgoing calls.
3. Press to save it.
SECURITY
Prevents others from using the phone without permis-
sion and allows an access to a security features only
after pasword input.
RESTRICT
This function enables you to restrict a certain features
with the password. You are to unlock it to use the fea-
tures.
AUTOMATIC LOCK
Prevents others from using your phone without permis-
sion. When locked, the menu can not be accessed with-
out password.
1. Press , then [5], then [3] and enter “PASSWORD”.
2. Press and select “Off”, “Lock Now” or
“Power Up”.
- Off – Do not lock the phone
- Lock Now – Lock the phone now
- Lock On Power Up – Lock the phone whenever it is
turned on.
3. Press to save it.
50Bmanual template7/26 2002.7.26 5:35 PM Page 88
SECURITY FEA
SECURITY FEATURES
TURES
Chapter 5 - Page 89
SECURITY FEA
SECURITY FEATURES
TURES
Page 88 - Chapter 5
PHONEBOOK
Blocks access to, and protects data in your phonebook.
1. Press , then [5], then [3] and enter “PASSWORD”.
2. Press and select “Allow” or “Restrict” with
the joystick key.
- Restrict : Restrict access to the phonebook
- Allow : Allow access to the phonebook.
3. Press to save it.
DATA CALL
Restricts data calls from being placed.
1. Press , then [5], then [3] and enter “PASSWORD”.
2. Press and select “Allow” or “Restrict” with
the joystick key.
- Restrict : Restrict a data call
- Allow : Allow a data call
3. Press to save it.
INCOMING CALL HISTORY
1. Press , then [5], then [3] and enter “PASSWORD”.
2. Press and select “Allow” or “Restrict” with
the joystick key.
- Restrict : Restrict an incoming call history
- Allow : Allow an incoming call history
3. Press to save it.
OUTGOING CALL HISTORY
1. Press , then [5], then [3] and enter “PASSWORD”.
2. Press and select “Allow” or “Restrict” with
the joystick key.
- Restrict : Restrict access to the outgong call history.
- Allow : Allow access to the outgong call history.
3. Press to save it.
MENU
Blocks access to the menu to prevent any change.
1. Press , then [5], then [3] and enter “PASSWORD”.
2. Press and select “Allow” or “Restrict” with
the joystick key.
- Restrict : Restrict access to the menu
- Allow : Allow access to the menu
3. Press to save it.
50Bmanual template7/26 2002.7.26 5:35 PM Page 90
SECURITY FEA
SECURITY FEATURES
TURES
Chapter 5 - Page 91
SECURITY FEA
SECURITY FEATURES
TURES
Page 90 - Chapter 5
SPECIAL#’s
Stores 3 phone numbers to allas to be dialed even in
rock mode.
1. Press , then [5], then [3] and enter “PASSWORD”.
2. Press and select one from three blanks with
the joystick key
3. Press and input a phone number
4. Press again to save it.
CLEAR PHONEBOOK
Clears all phonebook entries.
1. Press , then [5], then [3] and enter “PASSWORD”.
2. Press .
3. Select “Yes” or “No” with the joystick key.
Press .
900#S
Restricts calling 900 dial service numbers.
1. Press , then [5], then [3] and enter “PASSWORD”.
2. Press and select “Allow” or “Restrict” with
the joystick key.
- Restrict : Restrict a 900-dial service
- Allow : Allow a 900-dial service
3. Press to save it.
LONG DISTANCE CALLS
Restricts calling long distance numbers – the phone is
limited to calling numbers within the area.
1. Press , then [5], then [3] and enter “PASSWORD”.
2. Press and select “Allow” or “Restrict” with
the joystick key.
- Restrict : Restrict a long distance call
- Allow : Allow a long distance call
3. Press to save it.
NOTE: “This phone is restricted” appears on the display
when you attempt to make a restricted call.
NOTE: The default password is the last 4 digits of your
phone number.
NOTE: A phone number over 7 digits is to be restricted.
50Bmanual template7/26 2002.7.26 5:35 PM Page 92
SECURITY FEA
SECURITY FEATURES
TURES
Page 92 - Chapter 5
RESET PHONE
Resets phone to default settings.
1. Press , then [5], then [3]and enter “PASSWORD”.
2. Press .
3. Select “Yes” or “No” with the joystick key.
Press .
- When you select “Yes”, you will see “Wait a
moment” on the display and the phone will return to
idle mode.
CHANGE PASSWORD
Clears all phonebook entries.
1. Press , then [5], then [3]and enter “PASSWORD”.
2. Press .
3. Enter a new password and press .
4. Enter the new password again and press .
NOTE: The default password is the last 4 digits of your
phone number.
This chapter describes how to use the phone’s schedule
to alert you of upcoming appointments, how to use the
stopwatch and other addition features.
1. Schedule
2. Calculator
3. World Clock
4. Stopwatch
CHAPTER 6
CHAPTER 6
SUPPLEMENTARY FUNCTIONS
Chapter 6 - Page 93
50Bmanual template7/26 2002.7.26 5:35 PM Page 94
Chapter 6 - Page 95Page 94 - Chapter 6
Sets an event or anniversary in the phone and reminds
you through time setting when the time comes.
EVENT
1. Press , then [3], then [1] to display a calendar.
2. Move the joystick key to choose a date in the calen-
dar and press .
- Day to Day movement –
move the joystick key leftward and rightward.
- Week to Week movement –
move the joystick key downward and upward.
3.1. Press to set a time for an event.
- You are choose one of the followings in the first line
(On time, 10 Min before, 30 Min before, 1 Hour before,
No alarm)
- You are to change the date and time also in the sec-
ond line by moving to year, month, day, time input with
the joystick key.
3.2. Press to set a melody for the event.
Choose one of the best melodies with the joystick
key.
4. Press to save it or to return to the calen-
dar.
SCHEDULE
SCHEDULE
5. You will see “Save complete” displayed.
- You will also see a day marked to indicate an event
when you return to the calendar.
ALARM
1. Press , then [3], then [2] to display three alarm
entries.
2. Select one of the entries with the joystick key.
3. Press to edit the existing alarm or set a new
alarm.
- To delete the existing one, press .
4.1. Press to set a time.
- You are to choose an alarm freguency.(Once, Daily,
Weekly, Monthly, Yearly) with the joystick movement.
press to save it.
4.2. Press to set a melody.
- Select one and press .
4.3. Press to set a snooze.
- Select one of the following and press .
(No use, 1Time after 3minutes~)
SCHEDULE
SCHEDULE
NOTE: It doesn’t snooze if an alarm is stopped within a
minute, but it will snooze in a minute an alarm goes off.
50Bmanual template7/26 2002.7.26 5:35 PM Page 96
WORLD CLOCK
WORLD CLOCK
WORLD CLOCK
Shows what time it is in a specific city that is already pre-
programmed.
1. Press , then [6], then [2] for WORLD CLOCK.
2. Select a city with the joystick key and press .
3. The world map is to be displayed with the city, its
date and time.
- You are to move to another city using the joystick key.
Chapter 6 - Page 97Page 96 - Chapter 6
CALCULA
CALCULATOR
TOR
CALCULATOR
This function allows you to use your phone as a calculator.
This calculator will perform basic mathematic functions
(addition, subtraction, multiplication, division).
1. Press , then [6], then [1] for CALCULATOR.
2. Use the keypad to enter the numbers to be calculated.
3. Follow the instructions below to calculate (8*6)/4-2.5
- Input 8
Move the joystick key leftward
Input 6 and press the joystick key
Move it rightward
Input 4 and press the joystick key
Move it downward
Input 2 and press the to input(.)
Press 5, then .
4. Press to reset.
NOTE: 1. Up to 7 integer digits and up to 2 decimals can
be displayed. If the calculated result has more
than 7 digits, the result is displayed in 7 digit
logarithm.
2. There is no (-)sign. To express a negative number,
use ‘0-value’.
50Bmanual template7/26 2002.7.26 5:35 PM Page 98
STOPW
STOPWA
ATCH
TCH
STOPWATCH
This function allows you to use your phone as a stopwatch.
The stopwatch displays time in hours, minutes, seconds,
and 1/100 of a second.
1. Press , then [6], then [3] for STOPWATCH.
2. To measure a time period.
- Press to start the stopwatch.
- Press to pause it.
- Press to resume it or to return to the previous
page.
3. To measure more than one,
- Press to start.
- Press to stop a time period and continue meas-
uring another one.
- Press to stop the second and continue measur-
ing a third one.
- And keep repeating the above to measure up to 6
time periods.
- Press to stop it and to view the results.
- Press or to return to the stopwatch.
- Press to reset it.
Page 98 - Chapter 6
VOICE MAIL AND TEXT MESSAGES
This chapter describes how to check voice mail messages
as well as send and receive text messages with the
handset.
1. Two-Way SMS
2. Checking Messages
3. Sending Text Messages
4. Inbox
5. Outbox
6. Settings
7. Filed
8. Erase All
CHAPTER 7
CHAPTER 7
Chapter 7 - Page 99
50Bmanual template7/26 2002.7.26 5:35 PM Page 100
CHECKING MESSAGES
CHECKING MESSAGES
CHECKING RECEIVED VOICE MAIL MESSAGE
1. Press , then press [1] for Voice Mail.
2. The number of voice mail messages currently
received in your mailbox is displayed. To access your
voice mailbox, press .
CHECKING RECEIVED TEXT MESSAGE
1. Press , then press [3] “Inbox”.
2. Highlight the message you want to view and press
. The text message is displayed.
3. Press to view the inbox message menu. You can
reply, erase, save, or forward the message.
Chapter 7 - Page 101
RECEIVED MESSAGE NOTIFICATION
When your phone has received a message, the screen
displays the number of new text messages and voice
mail messages.
1. Press the key under to display the received mes-
sage.
TWO-W
TWO-WA
AY SMS
Y SMS
Your Audiovox wireless handset features Two-Way
Short Message Service (SMS). This feature sends and
receives text messages through your phone. Voice mail
notification is also supported.
: Urgent New Msg
: Urgent Read Msg
: New Msg (unread)
: Old Msg (read)
: Lock (read)
MESSAGE INDICATORS
The following symbols indicate the status of message
received by your phone. These symbols appear for
voice mail and text messages.
Page 100 - Chapter 7
50Bmanual template7/26 2002.7.26 5:35 PM Page 102
EDIT MESSAGE
1. To change the text message, press [3] EDIT
MESSAGE.
2. Input text message, then press .
PRIORITY
1. To send an urgent message, press [4] PRIORITY.
2. Select the priority (NORMAL/URGENT) by using the
navigation key then press .
CALL BACK NUMBER
1. To change the call back number, press [5] CALL
BACK.
2. Input call back number, then press .
SAVE
1. To save the text message, press [6] SAVE.
SENDING TEXT MESSAGES
SENDING TEXT MESSAGES
DELIVERY ACKNOWLEDGEMENT
1. To confirm the message was sent, press [7]
DELIVERY ACK.
2. Select the parameter (YES/NO) by using the navigation
key, then press .
Chapter 7 - Page 103
SENDING TEXT MESSAGES
SENDING TEXT MESSAGES
SENDING NEW TEXT MESSAGES
1. Press then press [2] SEND NEW.
2. Input text message, then press .
3. Input the phone number, then press to display the
outbox message menu.
NOTE:
If the message failed to reach the other party,
the display will read “Delivery Failed. Retry
in
3 seconds?”. Press YES to have the phone
send
the message again automatically.
SEND
1. To send the text message, press or [1] SEND.
EDIT RECIPIENT
1. To change the recipient, press [2] EDIT RECIPIENT.
2. Input the phone number, then press .
3. Input new text message (if necessary), then press .
Page 102 - Chapter 7
50Bmanual template7/26 2002.7.26 5:35 PM Page 104
LOCK/UNLOCK MESSAGE
1. To lock or unlock the text message, press [6]
MESSAGE LOCK.
2. Then select LOCK to lock the message or UNLOCK
to unlock the message, then press .
SAVE CALLBACK NUMBER
1. To save the Callback number from the text message,
press [5] SAVE CALLBACK.
2. Follow procedure for STORING PHONE NUMBERS
on page 28 to save the call back number into a memory
location.
INBOX
INBOX
Chapter 7 - Page 105
ERASE
1. To erase the text message, press [2] ERASE.
2. Press to erase the message from your Inbox.
SAVE MESSAGE
1. To save the text message in your phone, press [4]
SAVE.
2. Press .
INBOX MENU
Follow procedure for CHECKING RECEIVED TEXT
MESSAGES on page XX to enter the INBOX menu.
REPLY
1. To reply to the text message, press [1] REPLY.
2. Enter your message then press .
INBOX
INBOX
FORWARD
1. To forward the text message, press [3] FORWARD.
2. Input the phone number of the person you are sending
the message to and press .
3. Enter the text message and press .
Page 104 - Chapter 7
50Bmanual template7/26 2002.7.26 5:35 PM Page 106
OUTBOX
OUTBOX
SAVE
1. To save the message, press [4] SAVE.
2. Press .
STATE
1. Press [5] to display the state of the sent message.
3. Input any text message to go along with the forwarded
message then press .
Chapter 7 - Page 107
OUTBOX
OUTBOX
RESEND
1. To reply to the message, press [1] RESEND.
2. Press , then write your reply message and press
.
ERASE
1. To erase the message, press [2] ERASE.
2. Press .
FORWARD
1. To forward the message to another recipient, press
[3] FORWARD.
2. Input the phone number of the person to receive the
message then press .
OUTBOX MENU
1. To enter the OUTBOX menu, press then [4] OUT-
BOX.
2. Select the stored message then press . The text
message will be displayed.
3. Press to enter the OUTBOX menu. You can
resend, erase, forward, save, display the sent message
status.
Page 106 - Chapter 7
50Bmanual template7/26 2002.7.26 5:35 PM Page 108
SETTINGS
SETTINGS
AUTO ERASE
1. Press [5] AUTO ERASE.
AUTO ERASE INBOX
1. Press [1].
2. Select (OLD INBOX/DISABLED) using the navigation
key, then press .
AUTO ERASE OUTBOX
1. Press [2].
2. Select (OLD OUTBOX/DISABLED) using the navigation
key, then press .
ENTRY MODE
1. Press [6] ENTRY MODE.
2. Select (ALPHA MODE/T9 MODE) using the navigation
key, then press .
Chapter 7 - Page 109
SETTINGS
SETTINGS
SETTINGS MENU
1. To enter the SETTINGS menu, press then [5]
SETTINGS.
SAVE SENT MESSAGE
1. Press [1] SAVE SENT MSG?.
2. Select (NO/YES/PROMPT) using the navigation key,
then press .
DISPLAY DELIV. ACK
1. Press [4] DELIVERY ACK.
2. Select (NO/YES) using the navigation key, then press
.
DEFAULT CALL BACK NUMBER
1. Press [2] DEFAULT CB#.
2. Input the call back number, then press .
ALERT
1. Press [3] MESSAGE ALERT.
2. Select the alert type (RINGER/VIBRATE/SILENT/
RINGER & REMIND/VIBRATE & REMIND) using the
navigation key, then press .
Page 108 - Chapter 7
50Bmanual template7/26 2002.7.26 5:35 PM Page 110
ERASE ALL
ERASE ALL
ERASE MESSAGES
1. Press and [7].
2.1. Press
[1]
to erase the inbox messages.
2.2. Press
[2]
to erase the outbox messages.
2.3. Press
[3]
to erase the filed messages.
3. Select “Yes” or “No” with or .
Chapter 7 - Page 111
FILED
FILED
FILED
Manages saved messages from the Inbox/Outbox.
1. Press and [6].
Select a text message with the
navigation
key.
Press .
2. The text message is displayed.
Press .
3. If the text message is saved from “Inbox” menu, this
screen will be displayed.
If the text message is saved from “Outbox ” menu, this
screen will be displayed.
4. Select one by pressing .
Page 110 - Chapter 7
NOTE:
You are to erase “Entire inbox” or “Old inbox”.
50Bmanual template7/26 2002.7.26 5:35 PM Page 112
CHAPTER 8
CHAPTER 8
MAKING AN EMERGENCY CALL
Chapter 8 - Page 113Page 112 - Chapter 7
MEMO
MEMO
1. Emergency Calling
50Bmanual template7/26 2002.7.26 5:35 PM Page 114
INTERNET BROWSER
CHAPTER 9
CHAPTER 9
This chapter describes convenient functions that allow
you to access the Wireless internet with the handset.
1. Start Internet Browser
2. Browser Menu
Chapter 9 - Page 115
E911 CALLING
This function allows you to place emergency calls, even
when the phone is locked. Emergency calls are placed
on any available system.
1. Enter 911 and press [ ].
2. The call will connect.
- When a call ends, the phone returns to the Emergency
Mode for 5 minutes.
EMERGENCY CALLING
EMERGENCY CALLING
Page 114 - Chapter 8
50Bmanual template7/26 2002.7.26 5:35 PM Page 116
BROWSER MENU
BROWSER MENU
BROWSER MENU
The browser menu is a list of actions necessary for full
operation of the browser.
1. To enter the browser menu, press .
RELOAD
When Reload is selected from the browser menu, the
current page is reloaded.
1. Press to select Reload.
HOME
When Home is selected from the browser menu, the
Home Page is displayed.
1. Press to select Home.
BOOKMARKS
When Bookmarks is selected from the browser menu,
your bookmark list is displayed.
1. Press to select Bookmarks.
MARK SITE
When Mark Site is selected from the browser menu, the
current web page is added to your bookmark list.
1. Press to select Mark Site.
Chapter 9 - Page 117
WIRELESS INTERNET
Your [CDM-8500] wireless handheld telephone allows
you to visit various Internet websites directly from your
phone. This gives you access to up-to-date information
such as news, sports, weather and stock quotes when
you subscribe to Internet service with your service
provider. Please contact your service provider for a list
of available websites and service details.
1. To access wireless internet network, press .
- You can access the Internet from your phone when it
is in digital mode, as indicated by the Nsymbol on
your phone’s display.
2. The Internet browser will launch.
3. To access the Internet, press . Your service provider’s
home page will be displayed.
4. You can scroll the page using .
5.
Press or to select the options at the bottom
of the display.
6. To return to the previous page, press .
7. To exit the Internet, press .
ST
STAR
ART INTERNET BROWSER
T INTERNET BROWSER
Page 116 - Chapter 9
50Bmanual template7/26 2002.7.26 5:35 PM Page 118
BROWSER MENU
BROWSER MENU
- OFFLINE SERVICES
Offline Services navigates you to a list of installed
channel applications. Selecting a particular application
navigates you to the entry point of the application.
1. Press to select Offline Services.
- OUTBOX
Outbox displays how many items are pending delivery
and the age of the oldest item.
1. Press to select Outbox.
- RESTART UP BROWSER
Restart UP Browser causes the deck history and deck
cache to be cleared and a new session with the UP.Link
to be started.
1. Press to select Restart UP Browser.
- ENCRYPTION
Encryption displays a list of security-related items.
1. Press to select Encryption.
Chapter 9 - Page 119
Selecting the encryption item from the browser menu
displays a list of security-related items.
ABOUT OPENWAVE
When About Openwave is selected from the browser
menu, the browser version and copyright information is
displayed. The device layer version is also displayed.
1. Press to select About Openwave.
ADVANCED
When Advanced is selected from the browser menu, the
Advanced Menu options are displayed.
1. Press to select Advanced.
- SHOW URL
Show URL displays the URL (Uniform Resource
Locator) of the current page.
1. Press to select Show URL.
- HOMEPAGE
Homepage enables you to change the homepage.
1. Press to select Homepage.
- SET UP.LINK
Set UP.Link enables you to select another Up.Link.
1. Press to select Set UP.Link.
BROWSER MENU
BROWSER MENU
Page 118 - Chapter 9
50Bmanual template7/26 2002.7.26 5:35 PM Page 120
DATA SERVICE
Your phone will work as a wireless modem when connected
to a PC computer via the data interface cable. This
chapter shows you how to choose the correct settings
for this to function properly.
1. Data SVC
2. Location
CHAPTER 10
CHAPTER 10
Chapter 10 - Page 121Page 120 - Chapter 9
MEMO
MEMO
50Bmanual template7/26 2002.7.26 5:35 PM Page 122
DA
DAT
TA SVC
A SVC
DATA SPEED
You are to choose a connection speed depending on the
usage of handset.
1. Press then [7] then [2].
2. Select one of the following connection modes with the
joystick key.
- 19200 BPS
- 115200 BPS
- 230400 BPS
3. Press to save it.
NOTE:
This function is available only when the phone is
connected to data cable.
Chapter 10 - Page 123
DA
DAT
TA SVC
A SVC
Page 122 - Chapter 10
CONNECTION
You are to choose a connection mode depending on the
usage of handset.
1. Press then [7] then [1].
2. Select one of the following connection modes with the
joystick key.
- Voice Call : To receive a voice call
- Data Only : To receive data when connected to PC.
- Fax Only : To function as a fax when connected to
PC.
3. Press to save it.
NOTE:
This function is available only when the phone is
connected to data cable.
50Bmanual template7/26 2002.7.26 5:35 PM Page 124
SAFETY INFORMATION
uSafety Information for Wireless Handheld Phones
vSafety Information for FCC RF Exposure
wSAR Information
xFDA Consumer Update
CHAPTER 11
CHAPTER 11
Chapter 11 - Page 125
LOCA
LOCATION
TION
SETTING
Decides whether you allow the network system to detect
your position or not.
1. Press then [8] then [2].
2. Press any key when you see a message.
3. Select “Location On” or “911 Only” with the joystick
key.
- 911 Only - Your location will be hidden from network
& application except 911
- Location On – Your location is now available to the
network.
Page 124 - Chapter 10
50Bmanual template7/26 2002.7.26 5:35 PM Page 126
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
ANTENNA CARE
Use only the supplied or an approved replacement
antenna. Unauthorized antennas, modifications, or
attachments could damage the phone and may violate
FCC regulations.
PHONE OPERATION
Normal Position: Hold the phone as you would any
other telephone
with the antenna pointed up and over
your shoulder.
Tips on efficient operation:
- Extend your antenna fully.
- Do not touch the antenna unnecessarily when the phone
is in use. Contact with the antenna affects call quality
and may
cause the phone to operate at a higher power
level than otherwise
needed.
DRIVING SAFETY
Talking on the phone while driving is extremely dangerous
and is illegal in some states. Remember, safety comes
first. Check the laws and regulations on the use of
phones in the areas where you drive. Always obey them.
Also, if using your phone while driving please:
- Give full attention to driving. Driving safely is your first
responsibility.
- Use hands-free operation, if available.
- Pull off the road and park before making or answering
a call, if driving conditions require.
Chapter 11 - Page 127
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
EXPOSURE TO RADIO FREQUENCY SIGNALS
Your wireless handheld portable telephone is a low
power radio transmitter and receiver. When it is ON, it
receives and also sends out radio frequency (RF) signals.
In August 1996, the Federal Communications
Commissions (FCC) adopted RF exposure guidelines
with safety levels for handheld wireless phones. Those
guidelines are consistent
with the safety standards
previously
set by both U.S. and international
standards bodies:
ANSI C95.1 (1992) *
NCRP Report 88 (1986) *
ICNIRP (1996) *
Those standards were based on comprehensive and
periodic evaluations of the relevant scientific literature.
For example, over 120 scientists, engineers, and physicians
from universities, government health agencies, and
industry reviewed the available body of research to
develop the ANSI Standard (C951).
The design of your phone complies with the FCC guidelines
(and those standards).
˙;
American National Standards Institute; National Council
on Radiation Protection and Measurements;
International Commission on Nonionizing Radiation
Protection.
Read This Information Before Using Your Handheld
Portable Cellular Telephone
Page 126 - Chapter 11
50Bmanual template7/26 2002.7.26 5:35 PM Page 128
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
ELECTRONIC DEVICES
Other Medical Devices
If you use any other personal medical device, consult
the manufacturer of your device to determine if they are
adequately shielded from external RF energy Your
physician may be able to assist you in obtaining this
information.
Turn your phone OFF in healthcare facilities when any
regulations posted in these areas instruct you to do so.
Hospitals or healthcare facilities may be using equipment
that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check
with the manufacturer or its representative regarding
your vehicle. You should also consult the manufacturer
of any equipment that has been added to your vehicle.
An airbag inflates with great force. DO NOT place
objects, including both installed or portable wireless
equipment, in the area over the airbag or in the air bag
deployment area. If in-vehicle wireless equipment is
improperly installed and the air bag inflates, serious
injury could result.
Posted Facilities
Turn your phone OFF where posted notices so require.
Chapter 11 - Page 129
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
ELECTRONIC DEVICES
Most modern electronic equipment is shielded from RF
energy. However, certain electronic equipment may not
be shielded against the RF signals from your wireless
phone.
Pacemakers
The Health Industry Manufacturers Association recommends
that a minimum separation of six (6”) inches be maintained
between a handheld wireless phone and a pacemaker to
avoid potential interference with the pacemaker. These
recommendations are consistent with the independent
research by and recommendations of Wireless
Technology Research.
If you have a pacemaker:
lALWAYS keep the phone more than six inches from
your pacemaker when the phone is turned on.
lDo not carry the phone in a breast pocket.
lUse the ear opposite the pacemaker to minimize the
potential for interference.
lIf you have any reason to suspect that interference
is taking place, turn your phone OFF immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you may
want to consult your service provider (or call the custome
r
service line to discuss alternatives).
Page 128 - Chapter 11
50Bmanual template7/26 2002.7.26 5:35 PM Page 130
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
PRECAUTIONS AND WARNINGS
Please read and understand all of the Precautions and
Warnings contained in this manual before attempting to
operate your phone.
1. DO NOT use this equipment in an extreme environment
where high temperature or high humidity exists, such
as near a heater or in a closed car parked in the sun.
2. DO NOT abuse the equipment. Avoid striking, shaking
or shocking. When not using the unit, lay down the
unit
to avoid possible damage due to instability.
3.
DO NOT expose this equipment to liquids such as
rain or spilled beverages.
4.
DO NOT use unauthorized accessories. Use of unauthorized
accessories may result in fire, electric shock or other
bodily injury.
5. DO NOT disassemble the phone or its accessories.
If service or repair is required, return the unit to an
authorized Audiovox service center. If unit is disassembled,
the risk of electric shock or fire may result.
6. DO NOT short-circuit the battery terminals with
metal items etc.
7. DO NOT use harsh chemicals, cleaning solvents or
strong detergents to clean this phone. Always clean
it with a soft, damp cloth.
8. DO NOT paint this phone. This can clog moving parts.
Chapter 11 - Page 131
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
OTHER SAFETY GUIDELINES
Aircraft
FCC Regulations prohibit using your phone while in the
air. Switch OFF your phone before boarding an aircraft.
Blasting Areas
To avoid interfering with blasting operations, turn your
phone
OFF when in a “blasting area” or in areas posted:
“Turn off two-way
radio.” Obey all signs and instructions.
Potentially Explosive Atmospheres
Turn your phone OFF when in any area with a potentially
explosive atmosphere and obey all signs and instructions.
Sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often,
but not always, clearly marked. They include fueling
areas such as gas stations; below deck on boats; fuel or
chemical transfer or storage facilities; vehicles using
liquefied petroleum gas (such as propane or butane);
areas where the air contains chemicals or particles,
such as grain, dust, or metal powders; and any other
area where you would normally be advised to turn off
your vehicle’s engine.
Page 130 - Chapter 11
50Bmanual template7/26 2002.7.26 5:35 PM Page 132
CAUTION
In August 1996, the Federal Communications Commission
(FCC)
of the United States with its action in Report and Order
FCC 96-326 adopted an updated safety standard for human
exposure to radio frequency electromagnetic energy emitted
by FCC regulated transmitters. Those guidelines are consistent
with the safety standard previously set by both U.S. and
international
standards bodies. The design of this phone
complies
with the FCC guidelines and these international
standards.
Use only the supplied or an approved antenna. Unauthorized
antennas, modifications, or attachments could impair call
quality,
damage the phone, or result in violation of FCC
regulations.
Do not use the phone with a damaged antenna. If a damaged
antenna comes into contact with the skin, a minor burn may
result. Please contact your local dealer for replacement antenna.
Body-worn Operation (Holster Part Number : 2H020665002)
This device was tested with holster (Part No:2H020665002) for
body-worn operation with the back of the phone kept 0.59
inchs (15mm) from the body. To comply with FCC RF exposure
requirements, a minimum separation distance of 0.59 inchs
(15mm) must be maintained between the user's body and the
back of the phone, including the antenna, whether extended or
retracted. All belt-clips, holsters and similar accessories used
by this device must not contain any metallic components.
Body-worn accessories that do not meet these requirements
may not comply with FCC RF exposure limits and should be
avoided.
Note: For more information about RF exposure, please visit
the FCC website at www.fcc.gov.
SAFETY INFORMATION FOR
FCC RF EXPOSURE
WARNING! Read this information before using
your phone
Chapter 11 - Page 133
SAFETY INFORMATION FOR
WIRELESS HANDHELD PHONES
OPERATING PROCEDURES
Never violate any of the following Rules and Regulations
of the FCC when using your phone. The following
offenses are punishable by fine, imprisonment, or both:
- Using obscene, indecent, or profane language.
- Using the unit to give off false distress calls.
- Wiretapping or otherwise intercepting a telephone
call, unless that person has first obtained the consent
of the parties participating in the call.
- Making anonymous calls to annoy, harass, or molest
other people.
- Charging to an account without authorization to
avoid payment for service.
- Refusing to yield a party line when informed that it is
needed for an emergency call (It is also unlawful to
take over a party line by stating falsely that it is
needed for an emergency).
Page 132 - Chapter 11
50Bmanual template7/26 2002.7.26 5:35 PM Page 134
SAR INFORMATION
the body, as described in this user guide, is 0.633 W/kg. (Body-
worn measurements differ among phone models, depending
upon available accessories and FCC requirements). While
there may be differences between the SAR levels of various
phones and at various positions, they all meet the government
requirement for safe exposure.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance
with the FCC RF exposure guidelines. SAR
information
on this model phone is on file with the FCC and
can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID PP4TX-
50C.
Additional information on Specific Absorption Rates (SAR) can
be found on the Cellular Telecommunications & Internet
Association (CTIA) web-site at http://phonefacts.net.
* In the United States and Canada, the SAR limit for mobile
phones used by the public is 1.6 watts/kg (W/kg) averaged
over one gram of tissue. The standard incorporates a substantial
margin of safety to give additional protection for the public and
to account for any variations in measurements.
Chapter 11 - Page 135
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the emission limits
for exposure to radiofrequency (RF) energy set by the Federal
Communications Commission of the U.S. Government. These
limits are part of comprehensive guidelines and establish
permitted levels of RF energy for the general population. The
guidelines are based on standards that were developed by
independent scientific organizations through periodic and
thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the
safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a
unit of measurement known as the Specific Absorption Rate,
or SAR. The SAR limit set by the FCC is 1.6 W/kg.* Tests for
SAR are conducted with the phone transmitting at its highest
certified power level in all tested frequency bands. Although
the SAR is determined at the highest certified power level, the
actual SAR level of the phone while operating can be well
below the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use only
the power required to reach the network. In general, the closer
you are to a wireless base station antenna, the lower the
power output.
Before a phone model is available for sale to the public, it must
be tested and certified to the FCC that it does not exceed the
limit established by the government-adopted requirement for
safe exposure. The tests are performed in positions and locations
(e.g., at the ear and worn on the body) as required by the FCC
for each model. The highest SAR value for this model phone
when tested for use at the ear is 1.15 W/kg and when worn on
SAR INFORMATION
Page 134 - Chapter 11
50Bmanual template7/26 2002.7.26 5:35 PM Page 136
• Design wireless phones in a way that minimizes any RF
exposure to the user that is not necessary for device function;
and
• Cooperate in providing users of wireless phones with the best
possible information on possible effects of wireless phone use
on human health.
FDA belongs to an interagency working group of the federal
agencies that have responsibility for different aspects of RF
safety to ensure coordinated efforts at the federal level. The
following agencies belong to this working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some interagency
working group activities, as well.
FDA shares regulatory responsibilities for wireless phones with
the Federal Communications Commission (FCC). All phones
that are sold in the United States must comply with FCC safety
guidelines that limit RF exposure. FCC relies on FDA and other
health agencies for safety questions about wireless phones.
FCC also regulates the base stations that the wireless phone
networks rely upon. While these base stations operate at higher
power than do the wireless phones themselves, the RF
exposures that people get from these base stations are typically
thousands of times lower than those they can get from wireless
phones. Base stations are thus not the subject of the safety
questions discussed in this document.
3. What kinds of phones are the subject of this update?
The term “wireless phone” refers here to hand-held wireless
phones with built-in antennas, often called “cell,” “mobile,” or
“PCS” phones. These types of wireless phones can expose
the user to measurable radiofrequency energy (RF) because
of the short distance between the phone and the user’s head.
These RF exposures are limited by Federal Communications
Chapter 11 - Page 137
U.S. Food and Drug Administration -
Center for Devices and Radiological
Health
Consumer Update on Mobile Phones
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless phones.
There is no proof, however, that wireless phones are absolutely
safe. Wireless phones emit low levels of radiofrequency energy
(RF) in the microwave range while being used. They also emit
very low levels of RF when in the stand-by mode. Whereas
high levels of RF can produce health effects (by heating tissue),
exposure to low level RF that does not produce heating effects
causes no known adverse health effects. Many studies of low
level RF exposures have not found any biological effects.
Some studies have suggested that some biological effects
may occur, but such findings have not been confirmed by
additional research. In some cases, other researchers have
had difficulty in reproducing those studies, or in determining
the reasons for inconsistent results.
2. What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new drugs or
medical devices. However, the agency has authority to take
action if wireless phones are shown to emit radiofrequency
energy (RF) at a level that is hazardous to the user. In such a
case, FDA could require the manufacturers of wireless phones
to notify users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory
actions, FDA has urged the wireless phone industry to take a
number of steps, including the following:
• Support needed research into possible biological effects of
RF of the type emitted by wireless phones;
Page 136 - Chapter 11
50Bmanual template7/26 2002.7.26 5:35 PM Page 138
5. What research is needed to decide whether RF exposure
from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological studies
of
people actually using wireless phones would provide some of the
data that are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large numbers of animals
would be needed to provide reliable proof of a cancer promoting
effect if one exists. Epidemiological studies can provide data that is
directly applicable to human populations, but 10 or more years’
follow-up may be needed to provide answers about some health
effects, such as cancer. This is because the interval between
the time of exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many years. The
interpretation of epidemiological studies is hampered by difficulties
in measuring actual RF exposure during day-to-day use of wireless
phones. Many factors affect this measurement, such as the angle
at which the phone is held, or which model of phone is used.
6. What is FDA doing to find out more about the possible
health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology Program and
with groups of investigators around the world to ensure that high
priority animal studies are conducted to address important questions
about the effects of exposure to radiofrequency energy (RF).
FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF)
Project since its inception in 1996. An influential result of this work
has been the development of a detailed agenda of research needs
that has driven the establishment of new research programs around
the world. The Project has also helped develop a series of public
information documents on EMF issues.
FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research and
Development Agreement (CRADA) to do research on wireless
phone safety. FDA provides the scientific oversight, obtaining
input from experts in government, industry, and academic
organizations. CTIA-funded research is conducted through
Chapter 11 - Page 139
Commission safety guidelines that were developed with the
advice of FDA and other federal health and safety agencies.
When the phone is located at greater distances from the user,
the exposure to RF is drastically lower because a person’s RF
exposure decreases rapidly with increasing distance from the
source. The so-called “cordless phones,” which have a base
unit connected to the telephone wiring in a house, typically
operate at far lower power levels, and thus produce RF
exposures far below the FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conflicting results,
and many studies have suffered from flaws in their research
methods. Animal experiments investigating the effects of
radiofrequency energy (RF) exposures characteristic of wireless
phones have yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies, however,
have suggested that low levels of RF could accelerate the
development of cancer in laboratory animals. However, many
of the studies that showed increased tumor development used
animals that had been genetically engineered or treated with
cancer-causing chemicals so as to be pre-disposed to develop
cancer in the absence of RF exposure. Other studies exposed
the animals to RF for up to 22 hours per day. These conditions
are not similar to the conditions under which people use wireless
phones, so we don’t know with certainty what the results of
such studies mean for human health.
Three large epidemiology studies have been published since
December 2000. Between them, the studies investigated any
possible association between the use of wireless phones and
primary brain cancer, glioma, meningioma, or acoustic neuroma,
tumors of the brain or salivary gland, leukemia, or other cancers.
None of the studies demonstrated the existence of any harmful
health effects from wireless phone RF exposures. However,
none of the studies can answer questions about long-term
exposures, since the average period of phone use in these
studies was around three years.
Page 138 - Chapter 11
50Bmanual template7/26 2002.7.26 5:35 PM Page 140
methodology for measuring the rate at which RF is deposited
in the heads of wireless phone users. The test method uses a
tissue-simulating model of the human head. Standardized
SAR test methodology is expected to greatly improve the
consistency
of measurements made at different laboratories
on the same phone. SAR is the measurement of the amount of
energy absorbed in tissue, either by the whole body or a small
part of the body. It is measured in watts/kg (or milliwatts/g) of
matter. This measurement is used to determine whether a
wireless phone complies with safety guidelines.
9. What steps can I take to reduce my exposure to
radiofrequency energy from my wireless phone?
If there is a risk from these products—and at this point we do
not know that there is—it is probably very small. But if you are
concerned about avoiding even potential risks, you can take a
few simple steps to minimize your exposure to radiofrequency
energy (RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent using a
wireless phone will reduce RF exposure.
• If you must conduct extended conversations by wireless
phone every day, you could place more distance between your
body and the source of the RF, since the exposure level drops
off dramatically with distance. For example, you could use a
headset and carry the wireless phone away from your body or
use a wireless phone connected to a remote antenna.
Again, the scientific data do not demonstrate that wireless phones
are harmful. But if you are concerned about the RF exposure from
these products, you can use measures like those described
above to reduce your RF exposure from wireless phone use.
10. What about children using wireless phones?
The scientific evidence does not show a danger to users of
wireless phones, including children and teenagers. If you want
to take steps to lower exposure to radiofrequency energy (RF),
the measures described above would apply to children and
teenagers using wireless phones. Reducing the time of wireless
Chapter 11 - Page 141
contracts to independent investigators. The initial research will
include both laboratory studies and studies of wireless phone
users. The CRADA will also include a broad assessment of
additional research needs in the context of the latest research
developments around the world.
7. How can I find out how much radiofrequency energy
exposure I can get by using my wireless phone?
All phones sold in the United States must comply with Federal
Communications Commission (FCC) guidelines that limit
radiofrequency energy (RF) exposures. FCC established
these guidelines in consultation with FDA and the other federal
health and safety agencies. The FCC limit for RF exposure
from wireless telephones is set at a Specific Absorption Rate
(SAR) of 1.6 watts per kilogram (1.6 W/kg). The FCC limit is
consistent with the safety standards developed by the Institute
of Electrical and Electronic Engineering (IEEE) and the
National Council on Radiation Protection and Measurement.
The exposure limit takes into consideration the body’s ability to
remove heat from the tissues that absorb energy from the wireless
phone and is set well below levels known to have effects.
Manufacturers of wireless phones must report the RF exposure
level for each model of phone to the FCC. The FCC website
(http://www.fcc.gov/oet/rfsafety) gives directions for locating
the FCC identification number on your phone so you can find
your phone’s RF exposure level in the online listing.
8. What has FDA done to measure the radiofrequency
energy coming from wireless phones ?
The Institute of Electrical and Electronic Engineers (IEEE) is
developing a technical standard for measuring the radiofrequency
energy (RF) exposure from wireless phones and other wireless
handsets with the participation and leadership of FDA scientists
and engineers. The standard, “Recommended Practice for
Determining the Spatial-Peak Specific Absorption Rate (SAR)
in the Human Body Due to Wireless Communications Devices:
Experimental Techniques,” sets forth the first consistent test
Page 140 - Chapter 11
50Bmanual template7/26 2002.7.26 5:35 PM Page 142
12. Where can I find additional information?
For additional information, please refer to the following
resources:
- FDA web page on wireless phones:
(http://www.fda.gov/cdrh/phones/index.html)
- Federal Communications Commission (FCC) RF Safety
Program: (http://www.fcc.gov/oet/rfsafety)
-
International Commission on Non-Ionizing Radiation Protection:
(http://www.icnirp.de)
- World Health Organization (WHO) International EMF Project:
(http://www.who.int/emf)
- National Radiological Protection Board (UK):
(http://www.nrpb.org.uk/)
Chapter 11 - Page 143
phone use and increasing the distance between the user and
the RF source will reduce RF exposure. Some groups sponsored
by other national governments have advised that children be
discouraged from using wireless phones at all. For example,
the government in the United
Kingdom distributed leaflets
containing such a recommendation
in December 2000. They
noted that no evidence exists that using a wireless phone
causes brain tumors or other ill effects. Their recommendation
to limit wireless phone use by children
was strictly precautionary;
it was not based on scientific evidence
that any health hazard
exists.
11. What about wireless phone interference with medical
equipment?
Radiofrequency energy (RF) from wireless phones can interact
with some electronic devices. For this reason, FDA helped
develop a detailed test method to measure electromagnetic
interference
(EMI) of implanted cardiac pacemakers and
defibrillators from wireless
telephones. This test method is
now part of a standard sponsored
by the Association for the
Advancement of Medical instrumentation
(AAMI). The final
draft, a joint effort by FDA, medical device
manufacturers, and
many other groups, was completed in late 2000.
This standard
will allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI.
FDA has tested hearing aids for interference from handheld
wireless phones and helped develop a voluntary standard
sponsored by the Institute of Electrical and Electronic
Engineers (IEEE). This standard specifies test methods and
performance requirements for hearing aids and wireless
phones so that that no interference occurs when a person uses
a “compatible” phone and a “compatible” hearing aid at the
same time. This standard was approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones for possible
interactions with other medical devices. Should harmful interference
be found to occur, FDA will conduct testing to assess the
interference
and work to resolve the problem.
Page 142 - Chapter 11
50Bmanual template7/26 2002.7.26 5:35 PM Page 144
CHAPTER 12
CHAPTER 12
WARRANTY
1. Protect Your Warranty
2. 12 Month Limited Warranty
Chapter 12 - Page 145Page 144 - Chapter 11
MEMO
MEMO
50Bmanual template7/26 2002.7.26 5:35 PM Page 146
12 MONTH LIMITED W
12 MONTH LIMITED WARRANTY
ARRANTY
AUDIOVOX COMMUNICATIONS CORP. (the Company)
warrants to the original retail purchaser of this Audiovox
Handheld Portable Cellular Telephone, that should this product
or any part thereof during normal consumer usage and
conditions, be proven defective in material or workmanship
that results in product failure within the first twelve (12) month
period from the date of purchase, such defect(s) will be
repaired or replaced (with new or rebuilt parts) at the
Company’s option, without charge for parts or labor directly
related to the defect(s).
The antenna, keypad, display, rechargeable battery and battery
charger, if included, are similarly warranted for twelve (12)
months from date of purchase.
This Warranty extends only to consumers who purchase the
product in the United States or Canada and it is not assignable
or transferable.
This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions, accident,
mishandling, neglect, unauthorized alteration, misuse, improper
installation or repair or improper storage;
(b) Product whose mechanical serial number or electronic serial
number has been removed, altered or defaced.
(c) Damage from exposure to moisture, humidity, excessive
temperatures or extreme environmental conditions;
(d) Damage resulting from connection to, or use of any accessory
or other product not approved or authorized by the Company;
Chapter 12 - Page 147
PROTECT YOUR W
PROTECT YOUR WARRANTY
ARRANTY
Read your Warranty carefully, with the special consideration
to paragraph seven of the Limited Warranty for your unit.
“Warranty does not apply to... or to any product or part
thereof which has suffered through alteration...
mishandling, misuse, neglect or accident”.
Many companies are making look alike accessories and
in some cases, promoting that their product is equal to
or better than the Audiovox product. Be careful. Some of
these products may not be compatible to use with your
Audiovox product and may damage the unit or cause it
to malfunction. If service is required on your unit and it is
determined that a non-Audiovox accessory has created
the problem with your unit, the Warranty will not apply. In
addition, if the unit has already suffered irreversible
damage by reason of a non-compatible accessory, the
Warranty will be voided. To protect your Warranty, use
only compatible
accessories which cannot damage or
interfere
with the functioning of your Audiovox product.
AUDIOVOX COMMUNICATIONS CORP.
555 Wireless Blvd., Hauppauge, New York 11788, 800-229-1235
16808 Marquardt Avenue, Cerritos, California 90703, 562-802-5100
Audiovox Canada
5155 Spectrum Way, Unit #5, Mississauga, Ontario
Canada L4W 5A1, 800-465-9672
Page 146 - Chapter 12
50Bmanual template7/26 2002.7.26 5:35 PM Page 148
12 MONTH LIMITED W
12 MONTH LIMITED WARRANTY
ARRANTY
WITHIN A PERIOD OF 18 MONTHS FROM DATE OF ORIGINAL
PURCHASE. IN NO CASE SHALL THE COMPANY BE
LIABLE FOR ANY SPECIAL CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER
WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. THE
COMPANY SHALL NOT BE LIABLE FOR THE DELAY IN
RENDERING SERVICE UNDER THIS WARRANTY OR LOSS
OF USE DURING THE TIME THE PRODUCT IS BEING
REPAIRED OR REPLACED.
No person or representative is authorized to assume for the
Company any liability other than expressed herein in connection
with the sale of this product.
Some states or provinces do not allow limitations on how long
an implied warranty lasts or the exclusion or limitation of incidental
or consequential damage, so the above limitation or exclusions
may not apply to you. This Warranty gives you specific legal
rights, and you may also have other rights which vary from
state to state or province to province.
IN U.S.A.: Audiovox Communications Corp.
555 Wireless Blvd.
Hauppauge, NY 11788
(800)229-1235
IN CANADA: Audiovox Canada Ltd.
5155 Spectrum Way, Unit #5
Mississauga, Ontario L4W 5A1
(800) 465-9672
Chapter 12 - Page 149
12 MONTH LIMITED W
12 MONTH LIMITED WARRANTY
ARRANTY
(e) Defects in appearance, cosmetic, decorative or structural
items such as framing and non-operative parts;
(f) Product damaged from external causes such as fire, flooding,
dirt, sand, weather conditions, battery leakage, blown fuse,
theft or improper usage of any electrical source.
The Company disclaims liability for removal or reinstallation of
the product, for geographic coverage, for inadequate signal
reception by the antenna or for communications range or
operation of the Cellular System as a whole.
To obtain repairs or replacement within the terms of this
Warranty, the product should be delivered with proof of
Warranty coverage (e.g. dated bill of sale), the consumer’s
return address, daytime phone number and/or fax number and
complete description of the problem, transportation prepaid, to
the Company at the address shown below or to the place or
purchase for repair or replacement processing. In addition, for
reference to an authorized Warranty station in your area, you
can telephone in the United States (800) 229-1235, and in
Canada (800) 465-9672 (in Ontario call 905-712-9299).
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS
WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT
PROVIDED ABOVE AND, IN NO EVENT, SHALL THE
COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE
PAID BY PURCHASER FOR THE PRODUCT.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE SHALL BE LIMITED TO THE
DURATION OF THIS WRITTEN WARRANTY. ANY ACTION
FOR BREACH OF ANY WARRANTY MUST BE BROUGHT
Page 148 - Chapter 12
50Bmanual template7/26 2002.7.26 5:35 PM Page 150
