Contents
Users Manual 2
ANSWERING CALLS
1. Press the SEND Key to answer the incoming call.
Depending on your phone’s settings, you may also answer incoming calls
by opening the phone or by pressing any key.
2. To ignore incoming calls, press the Right Soft Key [Ignore].
With Auto w/ Hands-free, a call is automatically answered after a preset
number of ring tones. For more details, see page 63.
ENDING A CALL
1. Press the END Key.
MISSED CALL NOTIFICATION
When an incoming call is not answered, the Missed Call icon appears on the
display.
DISPLAY THE MISSED CALL FROM THE NOTIFICATION
1. Select View Now and press the OK Key.
2. To dial the phone number, press the SEND Key.
DISPLAY A MISSED CALL FROM IDLE MODE
1. Press the OK Key [MENU], scroll to Recent Calls and press the OK
Key.
2. Select Missed and press the OK Key.
3. Select the missed call and press the OK Key [OPEN].
4. To dial the phone number, press the SEND Key.
WAIT/PAUSE
Pauses are used for automated systems (i.e., voice mail or calling cards). The
numbers entered after the pause will automatically be dialed after the pause.
It is useful for dialing into systems that require a code.
Wait (W)
The phone stops dialing until you press the Send Key to dial the next number.
1. Enter the phone number.
2. Press the Right Soft Key [Options].
3. Scroll to select Add Wait and press the OK Key.
4. Enter additional next number(s).
5. Press the SEND Key to dial.
20
Chapter 2 − Basic Operation
Basic Operation
2-Sec Pause (P)
The phone waits 2 seconds before sending the next digits automatically.
1. Enter the phone number.
2. Press the Right Soft Key [Options].
3. Select Add 2-Sec Pause and press the OK Key.
4. Enter additional number(s) (pin number or credit card number).
5. Press the SEND Key to dial.
MAKING AN INTERNATIONAL CALL
MAKING AN GSM INTERNATIONAL CALL THE U.S. FROM
ANOTHER COUNTRY
The United States is the default on your phone. When both Assisted Dialing is set to
ON, and the reference country is United States of America; you can place a call to the
U.S. from another country by using an existing number from you contact list (as if
you were in the U.S.). In this scenario, there is no need to add your current country’s
exit code when you are dialing contacts with these settings.
1. Press and hold the International Dial Key to display the “+” symbol.
The “+” symbol automatically inserts the exit code for the country
from which you are calling.
2. Press to insert the U.S. country code, then enter the area code
and number.
3. Press the SEND Key.
MAKING AN GSM INTERNATIONAL CALL FROM ANOTHER
COUNTRY GSM ONLY
1. Press and hold the International Dial Key to display the “+” symbol.
The “+” symbol automatically inserts the exit code for the country
from which you are calling.
2. Enter the country code of the person you are calling. Enter the area
code, without the leading zero, followed by the number of the person
you are calling.
3. Press the SEND Key.
There are some exceptions for leaving out the leading zero such as Italy,
Finland and Spain.
The SIM card must be installed in order to make calls in GSM mode.
Basic Operation − Chapter 2
21
Basic Operation
3 WAY CALLING
You can talk to two participants at the same time. During the call, the normal
airtime rates will be applied for each of the two calls.
1. Enter the phone number and press the SEND Key.
2. When you have connected, enter the second phone number to call
and press the SEND Key.
3. When you’re connected to the second party, press the SEND Key again
to begin your 3-Way call.
If one of the participants hangs up during the call, you and the remaining
participant stay connected. If you initiated the call and are the first one to
hang up, all three calls are disconnected.
CALL WAITING
If you are on a call and you receive another incoming call, you will hear two
beeps and the caller’s phone number will appear on the display. With Call
Waiting, you may put the active call on hold while you answer the other
incoming call.
1. Press the SEND Key to answer the other call. The first call will
automatically be placed on hold. To switch back, press the SEND
Key again.
CALLING A NUMBER FROM CONTACTS
1. Press the Right Soft Key [Contacts].
2. Scroll to the contact and press the OK Key [VIEW].
3. Scroll to the phone number.
4. Press the SEND Key to place the call.
Dialing from the contact will dial the default number automatically. If the
contact has multiple numbers saved, scroll to the number to dial and press
the Send Key.
ADJUSTING THE VOLUME
ADJUSTING THE MASTER VOLUME
1. Press the Volume Keys / up or down to select All Sounds
Off, Alarm Only, Vibrate Only, Low, Medium Low, Medium,
Medium High and High.
2. Press the OK Key [SET] to save.
3. To check the ringtone’s volume, press the Left Soft Key [Play].
22
Chapter 2 − Basic Operation
Basic Operation
ADJUSTING THE VOLUME DURING A CALL
1. To increase the volume, press the Volume Keys up.
2. To decrease the volume, press the Volume Keys down.
CALLER ID
Caller ID displays the name and the phone number of the person calling.
If the caller’s information is not stored in your Contacts List, only the
phone number is displayed.
TURNING VIBRATE MODE ON OR OFF
Vibrate Mode mutes the tones and activates an alert for an incoming call or
message.
1. To activate, press and hold the Vibrate Mode Key .
2. To deactivate, press and hold the Vibrate Mode Key again.
SPEAKERPHONE
The Speakerphone feature lets you hear audio through the speaker and talk
without holding the phone. With the flip open, press to turn speakerphone on
or off. With the flip closed, press and hold to lock or unlock the key.
1. To activate, with the flip open, press the Speakerphone Key .
If you activate Speakerphone when you are not on a call, it will deactivate
automatically after one minute.
AVAILABLE OPTIONS DURING A CALL
During a phone call, you can access the following features by pressing the
Right Soft Key [Options]. Press the OK Key to select any of the following
options:
•
New Message
•
Contact List
•
Recent Calls
•
Bluetooth Menu
•
Main Menu
•
Notepad
•
Voice Privacy
MAKING AN EMERGENCY CALL
The 911 feature automatically places the phone in Emergency Call Mode when
you dial the preprogrammed emergency number, 911. It also operates in Lock
Mode and out of the service area.
Basic Operation − Chapter 2
23
Basic Operation
MEMORY FUNCTION
CHAPTER 3
MEMORY FUNCTION
This chapter addresses memory functions including:
Storing a phone number
Entering letters, numbers & symbols
One, Two, Three touch dialing
911 IN LOCK MODE
1. Enter 911 and press the SEND Key.
The phone maintains Emergency Mode for 5 minutes. When the call ends,
the phone returns to Lock Mode.
MAKING CALL TO 911 USING ANY AVAILABLE SYSTEM
1. Enter 911 and press the SEND Key.
The phone will stay in Emergency Mode for 5 minutes. While the phone is
in the Emergency Mode for 5 minutes, the phone can receive an incoming
call from any available system or you can make outgoing calls even in the
Emergency Callback Mode. In this case, making a call can automatically end
the Emergency Callback Mode.
The 911 call does not appear in the recent call list.
MAKING AN EMERGENCY CALL IN GSM MODE
1. If your phone has the PIN lock enabled, press the Left Soft Key [SOS].
2. The “EMERGENCY CALL?” screen will display. Press the Left Soft
Key [Yes].
You can make an emergency call while in GSM Mode, even if the SIM Lock
or PIN Lock is enabled. Emergency call is always supported.
24
Chapter 2 − Basic Operation
Basic Operation
STORING A PHONE NUMBER
The Contact List stores up to 500 entries.
ADDING A NEW CONTACT
1. Enter the phone number you want to save.
2. Press the Left Soft Key [Save].
3. Scroll to Add New Contact and press the OK Key.
4. Scroll to Mobile 1, Mobile 2, Home, Work or Fax. Press the OK Key.
5. Enter the remaining contact information (Name, Mobile 1, Home,
Work, E-mail 1, Group, Picture, Ringtone, Mobile 2, IM Screen
Name, Fax, E-mail 2, Street, City, State, Zip code, Country) and
press the OK Key [SAVE]. The number reappears after saving. Press
the End Key to exit or the Send Key to dial the number.
Select Update Existing to add another phone number to a contact already
stored in memory.
OPTIONS TO CUSTOMIZE YOUR CONTACTS
Once the basic phone number and name information is stored in your Contacts, you
can edit and/or customize the entries.
1. Press the Right Soft Key [Contacts] and select the Contact you
would like to edit.
2. Press the Left Soft Key [Edit].
3. Edit the information and press the OK Key [SAVE] to save.
ADDING OR CHANGING GROUPS
To organize your Contacts into groups:
1. Press the Right Soft Key [Contacts], then select the Contact you
want to add to a group.
2. Press the Left Soft Key [Edit].
3. Scroll to Group, press the Left Soft Key [Set].
4. Select either Family or Work and press the OK Key [MARK], then
press the Left Soft Key [Done].
5. To create a new group, press the Left Soft Key [New]. Enter the group
name and press the OK Key [SAVE].
6. Enter the remaining contact information and press the OK Key
[SAVE].
26
Chapter 3 − Memory Function
Memory Function
CHANGING THE CALL RINGTONE
To identify who is calling by setting different ringtones for different phone numbers
in your Contacts.
1. Press the Right Soft Key [Contacts] and scroll to the contact to edit
ringtone.
2. Press the Left Soft Key [Edit].
3. Scroll to Ringtone and press the Left Soft Key [Set].
4. To listen to the selected ringtone, press the Left Soft Key [Play].
To stop press the Left Soft Key [Stop]. To select, press the OK Key.
5. Press the OK Key [SAVE] to save.
ADDING OR CHANGING THE PICTURE ID
To select a picture or graphic to assign to a Caller ID:
1. Press the Right Soft Key [Contacts], then select the Contact you
want to edit.
2. Press the Left Soft Key [Edit].
3. Scroll to the Picture and press the Left Soft Key [Set].
4. Scroll to and select the picture to set.
5. To view the selected picture press the Left Soft Key [View].
6. Press the OK Key to select the image.
7. Press the OK Key [SAVE] to save.
ADDING OR CHANGING AN EMAIL ADDRESS
To add or change an email address:
1. Press the Right Soft Key [Contacts], then select the Contact you
want to edit.
2. Press the Left Soft Key [Edit].
3. Scroll to E-mail1 or E-mail2 to edit.
4. Enter the new email address and press the OK Key [SAVE] to save.
ADDING A SPEED DIAL ENTRY
To add a Speed Dial entry:
1. Press the Right Soft Key [Contacts], then select the Contact you
want to add to Speed Dial.
2. Press the Left Soft Key [Edit].
3. Select the phone number you want to add to Speed Dial and press
the Right Soft Key [Options].
Memory Function − Chapter 3
27
Memory Function
4. Select Set Speed Dial and press the OK Key, choose a Speed Dial
location then press the OK Key [SET].
5. To save the entry select Yes then press the OK Key.
6. Press the OK Key [SAVE] to save.
ADDING OR CHANGING A IM SCREEN NAME
To add or change a IM Service server:
1. Press the Right Soft Key [Contacts], then select the Contact you
want to edit.
2. Press the Left Soft Key [Edit].
3. Scroll to IM Screen Name, press the Left Soft Key [Set].
4. Select either AOL, Yahoo or Microsoft and press the OK Key.
5. Enter user’s name and press the OK Key to save.
6. Enter the remaining contact information and press the OK Key
[SAVE].
EDITING CONTACTS ENTRIES
ADDING A PHONE NUMBER FROM IDLE MODE
To add a phone number to Contacts from Idle mode:
1. Enter the phone number you want to save (up to 32 digits).
2. Press the Left Soft Key [Save].
3. Scroll to Update Existing and press the OK Key.
4. Select the contact to update and press the OK Key.
5. Select Mobile 1, Mobile 2, Home, Work or Fax and press the
OK Key.
6. If a phone number is already assigned to the category you selected,
select Yes or No to update then press the OK Key.
ADDING A PHONE NUMBER FROM THE CONTACT LIST SCREEN
1. Press the Right Soft Key [Contacts]. Your Contacts display
alphabetically.
2. Scroll to the contact to update and press the Left Soft Key [Edit].
3. Enter the phone number in the appropriate field.
4. Press the OK Key [SAVE].
28
Chapter 3 − Memory Function
Memory Function
DEFAULT NUMBERS
The phone number saved when a Contact is created is the Default Number. If more
than one number is saved in a Contact entry, another number can be set as the
Default Number.
The Default Number cannot be deleted. The entire Contact entry can be
deleted or another number can be assigned as the Default Number
allowing you to delete the original number and keep the Contact entry.
CHANGING THE DEFAULT NUMBER
1. Press the Right Soft Key [Contacts]. Your Contacts display
alphabetically.
2. Scroll to the contact to update and press the Left Soft Key [Edit].
3. Scroll to the number to assign as the default number and press the
Right Soft Key [Options].
4. Select Set As Default and press the OK Key.
5. Select Yes then press the OK Key to set as default number.
6. Press the OK Key [SAVE] to save.
EDITING STORED PHONE NUMBERS
1. Press the Right Soft Key [Contacts]. Your Contacts display
alphabetically.
2. Select the Contact entry you want to edit and press the Left Soft
Key [Edit].
3. Select and edit the phone number as necessary and press the
OK Key [SAVE].
DELETING
DELETING A PHONE NUMBER FROM A CONTACT
1. Press the Right Soft Key [Contacts]. Your Contacts display
alphabetically.
2. Scroll to the contact to update and press the Left Soft Key [Edit].
3. Scroll to the number to delete.
4. Press and hold the Clear Key to delete.
5. Press the OK Key [SAVE] to save.
Memory Function − Chapter 3
29
Memory Function
DELETING A CONTACT ENTRY
1. Press the Right Soft Key [Contacts] and scroll to the contact to
delete.
2. Press the Right Soft Key [Options], scroll to Erase and press the
OK Key.
3. Scroll to Yes and press the OK Key to erase.
DELETING A SPEED DIAL
1. Press the Right Soft Key [Contacts] and scroll to the contact to edit.
2. Press the Left Soft Key [Edit].
3. Scroll to the phone number which has speed dial and press the Right
Soft Key [Options].
4. Select Remove Speed Dial and press the OK Key.
5. Scroll to Yes and press the OK Key to erase.
6. Press the OK Key [SAVE] to save.
ENTERING LETTERS, NUMBERS & SYMBOLS
The text entering mode (Alpha editor) allows you to input text, numbers
and symbols. The default mode is [Abc] mode.
Key Key Functions
Abc: Press to change mode. [T9 Word][Abc][ABC][123][Symbols]
Next: Press to view the next matching word in the predictive mode.
Space: Press to select the word in predictive mode and to add a space.
Caps Lock: Press to select a letter case of the standard text input or
text input mode. [Abc], [ABC] and [abc] indicate the standard text
input. [T9 Word], [T9 WORD] and [T9 word] indicate the predictive
text input. Press and hold to change mode.[Abc] -> [123] -> [T9
Word] -> [Abc].
Clear: Press to delete a character to the left of the cursor. Press and
hold to delete an entire word.
MULTITAP MODE
Use the digit keys to enter letters, numbers and characters.
Each of the following keys will scroll through these sequential options
listed by language. The limitation is 160 characters. Press the key labeled
30
Chapter 3 − Memory Function
Memory Function
with the target letter once for the first letter press twice for the second
letter and so on. Press and hold the key labeled with the target number
for that number.
Key English Spanish
. @ ? ! - , & : ' / and 1
a b c 2 a á b c 2
d e f 3 d e é f 3
g h i 4 g h i í 4
j k l 5
m n o 6 m n ñ o ó 6
p q r s 7
t u v 8
w x y z 9
PREDICTIVE MODE
The predictive mode automatically compares your keystrokes with an internal
linguistic dictionary to determine the correct word. It will display the most
commonly used word first.
1. Press the OK Key [MENU], scroll to Messaging and press the OK Key,
select New Message and press the OK Key.
2. Scroll to TXT Message, Picture Message or Voice Message and
press the OK Key.
3. Enter the phone number or email address in “To” field and press the
OK Key. In the Text field, press the Left Soft Key [Abc] and select
T9 Word and press the OK Key.
4. Press the number keys to input the sequential characters. Press the
Key to view the matching word.
For example, to write “Hello”, press , , , ,
.
5. To select the word press the Key.
NUMERIC MODE
Allows you to enter numbers.
1. From the text entry screen, press the Left Soft Key [Abc], select 123
and press the OK Key.
2. Press the corresponding keys to input numbers. For example,
: 2.
Memory Function − Chapter 3
31
Memory Function
MENU FUNCTIONS
CHAPTER 4
MENU FUNCTION
This chapter addresses accessing the menu and using its functions
and features to customize your phone.
32
Chapter 3 − Memory Function
Memory Function
New contact
Contact list
Backup assistant
Groups
Speed dials
In case of emergency
My name card
Recent calls
Missed
Received
Dialed
Blocked
All
View timers
Bluetooth menu
Sounds settings
Display settings
Phone settings
Call settings
Memory
Phone info
Set up wizard
Voice commands
Calculator
Tip calculator
Calendar
Alarm clock
Stop watch
World clock
Unit converter
Notepad
My Verizon
SYMBOL MODE
Allows you to enter symbols.
1. From the text entry screen, press the Left Soft Key [Abc], select
Symbols and press the OK Key.
2. Scroll to the symbol to enter by using the Directional Key .
Press the OK Key to select.
ONE, TWO, THREE TOUCH DIALING
Ideal for frequently dialed numbers, this feature allows contact entries to be
dialed via the keypad with only one, two or three key presses. For details on
assigning to Speed Dial, see page 36.
ONE TOUCH DIALING:
Press and hold the number you wish to connect to for more than
1 second.
Speed Dial 1 has been preprogrammed to dial your voicemail and cannot
be changed.
TWO TOUCH DIALING:
Press the first digit and press and hold the second digit of the number
to dial.
95, 96, 97, 98 and 99 : Speed Dial entries 95(#Warranty Center),
96(#DATA), 97(#BAL), 98(#MIN) and 99(#PMT) are already assigned to
Verizon Wireless Account Information.
THREE TOUCH DIALING:
Press the first and second digits and press and hold the third digit of the
number to dial.
411 : Speed Dial entry 411 (Directory Assistance) is already assigned
to Directory Assistance.
For details on Restrictions, see page 59.
Before using, One Touch Dial must first be turned on. For more information,
see page 64.
Entries can be retrieved by name or group.
NEW CONTACT
TO ADD A NEW NUMBER TO YOUR CONTACTS
For details on adding a new contact, see page 26.
CONTACT LIST
You can review all the entries stored in your Contact List or quickly find an
entry by entering a name or its character.
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to Contact List then press the OK Key.
2. Enter a name in the Go To field or scroll to the contact.
3. To edit the contact, press the Left Soft Key [Edit]. To view the details,
press the OK Key [VIEW].
Shortcut: Access the Contact List by pressing the Right Soft Key.
BACKUP ASSISTANT
Backup Assistant is a wireless service that saves a copy of your phone’s address
book to a secure web site. If your phone is lost, stolen or damaged, Backup
Assistant restores your saved address book to a new phone - wirelessly!
Schedule daily automatic backups or manually backup your phone book
at your convenience. Login to your web account and get full access to your
address book. You can view, print, add, delete and edit contacts. Changes are
sent to your phone with one click!
Visit Web site: https://www.verizonwireless.com/backupassistant/.
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to Backup Assistant then press the OK Key.
2. To launch Backup Assistant application.
GROUPS
Allow you to classify phone entries into groups with up to 10 contacts in each
group. The default groups - Family and Work - cannot be erased or renamed.
TO ADD NEW GROUP
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to Groups then press the OK Key.
2. Press the Left Soft Key [New].
3. Enter a new group name and press the OK Key [SAVE].
34
Chapter 4 − Menu Function
Contacts
TO ASSIGN PHONE NUMBER TO GROUP
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to Groups then press the OK Key.
2. Scroll to the group to add the contact to and press the OK Key
[VIEW].
3. To add a contact, press the OK Key [ADD]. Scroll to the contact to add
and press the OK Key [MARK] then press the Left Soft Key [Done]
to add.
TO CHANGE GROUP NAME
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to Groups then press the OK Key.
2. Scroll to the group to rename, press the Right Soft Key [Options],
select Rename, then press the OK Key.
3. Enter the new group name and press the OK Key [SAVE].
ERASE GROUP
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to Groups then press the OK Key.
2. Scroll to the group to erase then press the Right Soft Key [Options],
select Erase and press the OK Key.
3. Scroll to Yes and press the OK Key to erase the group.
TO SEND A TXT MESSAGE TO A GROUP
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to Groups then press the OK Key.
2. Select the group you want to send a message to and press the Right
Soft Key [Options].
3. Scroll to New TXT Message and press the OK Key, then write the
message.
4. To send, press the OK Key [SEND] or press the SEND Key.
For detail on writing text messages, see page 92.
TO SEND A PICTURE MESSAGE TO A GROUP
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to Groups then press the OK Key.
2. Select the group you want to send a message to and press the Right
Soft Key [Options].
Menu Function − Chapter 4
35
Contacts
3. Scroll to New Picture Message and press the OK Key.
4. Scroll to Picture and press the Left Soft Key [My Pics]. Scroll to the
picture and press the OK Key to select.
5. Enter the remaining message information and press the OK Key
[SEND] or press the SEND Key.
For detail on writing picture message, see page 92.
TO SEND A VOICE MESSAGE TO A GROUP
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to Groups then press the OK Key.
2. Scroll to the group to send a voice message to and press the Right
Soft Key [Options].
3. Scroll to New Voice Message and press the OK Key.
4. Press the OK Key to being recording. Press the OK Key [STOP] to end
recording.
5. Enter any additional message information. To send, press the OK Key
[SEND] or press the SEND Key. For detail on writing voice message,
see page 93.
SPEED DIALS
Calls can be placed to numbers stored in speed dial by pressing & hold-
ing the location number on the key pad. For a 2-digit location number,
press the first number and press and hold the second number. For a
3-digit location number, press the first number and second numbers and
press and hold the third number. Speed Dial 1 is assigned to Voice Mail
and cannot be changed. Speed Dial entries 95(#Warranty Center),
96(#DATA), 97(#BAL), 98(#MIN), 99(#PMT) and 411 (Directory
Assistance) are already assigned to Verizon.
•
#Warranty Center is a VZW Customer Service VRU number (Free call)
that connects to the Verizon Wireless warranty center.
•
#DATA is a VZW Customer Service VRU number (Free call) that provides
customers information about their Verizon Wireless data balance.
•
#BAL is a VZW Customer Service VRU number (Free call) that provides
customers information about their Verizon Wireless billing balance.
•
#MIN is a VZW Customer Service VRU number (Free call) that provides
customers information about their Verizon Wireless usage.
•
#PMT is a VZW Customer Service VRU number (Free call) that allows a
user to make a bill payment, either with a payment option they have
already set up or using a new, one time payment option.
36
Chapter 4 − Menu Function
Contacts
•
411 Directory Assistance is the information about directory listing
database.
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to Speed Dials then press the OK Key.
2. Scroll to the Speed Dial position or enter the Speed Dial digit and
press the OK Key [SET].
3. Scroll to the Contact and press the OK Key.
4. Scroll to the number to assign the speed dial to and press the OK Key.
5. Scroll to Yes and press the OK Key.
Unassigned appears if the location is available.
TO ERASE A SAVED SPEED DIAL
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to Speed Dials then press the OK Key.
2. Scroll to select the Speed Dial entry to erase.
3. Press the Right Soft Key [Remove].
4. Scroll to Yes and press the OK Key.
IN CASE OF EMERGENCY
Your phone has a special menu to organize your emergency contacts and
personal information.
TO ASSIGN EMERGENCY CONTACTS
Follow the procedures below to register a Contact to be contacted in case of emer-
gency or to register a medical record number or other personal information.
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to In Case of Emergency then press the OK Key.
2. Scroll to Contact 1, Contact 2 or Contact 3 and press the OK Key
[ADD].
3. When selecting from Add Contact, scroll to From Contacts and press
the OK Key.
4. Scroll to the contact entry and press the OK Key.
5. When adding a new contact, scroll to New Contact and press the
OK Key.
6. Enter the information and press the OK Key [SAVE].
7. The contact name will be displayed in place of Contact 1,
Contact 2 or Contact 3.
Menu Function − Chapter 4
37
Contacts
TO REASSIGN EMERGENCY CONTACTS
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to In Case of Emergency then press the OK Key.
2. Select the contact to re-assign and press the Right Soft Key
[Options].
3. Scroll to Re-assign and press the OK Key.
4. Scroll to From Contacts and press the OK Key. Select a contact
from your Contact List. When adding a new contact, scroll to New
Contact and press the OK Key.
5. Press the OK Key.
TO ERASE ASSIGNED EMERGENCY CONTACTS
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to In Case of Emergency then press the OK Key.
2. Select the contact to erase and press the Right Soft Key [Options].
3. Scroll to Unassign and press the OK Key.
TO CALL AN ASSIGNED EMERGENCY CONTACT
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to In Case of Emergency then press the OK Key.
2. Select the contact to call and press the Left Soft Key [Call] or press
the SEND Key.
TO ADD PERSONAL INFO
To store a Medical Record Number or other information that may be useful in case
of an emergency:
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to In Case of Emergency then press the OK Key.
2. Scroll to Personal Info and press the OK Key [VIEW].
3. Scroll to Note 1, Note 2 or Note 3 and press the OK Key [ADD].
4. Enter the information and press the OK Key [SAVE].
5. The information you entered now appears in place of Note 1,
Note 2 or Note 3.
TO EDIT SAVED PERSONAL INFO
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
38
Chapter 4 − Menu Function
Contacts
scroll to In Case of Emergency then press the OK Key.
2. Scroll to Personal Info and press the OK Key [VIEW].
3. Select the note to edit and press the OK Key [VIEW].
4. Press the OK Key [EDIT]. Edit the note and press the OK Key [SAVE].
TO ERASE SAVED PERSONAL INFO
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to In Case of Emergency then press the OK Key.
2. Scroll to Personal Info and press the OK Key [VIEW].
3. Select the note to erase and press the Right Soft Key [Erase].
4. Scroll to Yes and press the OK Key.
MY NAME CARD
A Name Card with the handset’s mobile number automatically appears.
EDIT MY NAME CARD
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to My Name Card then press the OK Key.
2. Press the Left Soft Key [Edit].
3. Edit the My Name Card options and press the OK Key [SAVE]
to save your changes.
SEND MY NAME CARD
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
scroll to My Name Card then press the OK Key.
2. Press the Right Soft Key [Send].
3. Scroll to New Message and press the OK Key.
4. Scroll to TXT Message, Picture Message or Voice Message and
press the OK Key.
5. Enter the recipient’s contact information in the To field and press
the OK Key.
6. Enter any additional message information and press the OK Key
[SEND].
SEND MY NAME CARD TO ANOTHER BLUETOOTH DEVICE
Turn on Bluetooth on both devices (steps 1-4) and turn Discovery Mode
to On.
1. Press the OK Key [MENU], scroll to Contacts and press the OK Key,
Menu Function − Chapter 4
39
Contacts
scroll to My Name Card then press the OK Key.
2. Press the Right Soft Key [Send].
3. Scroll to Send by Bluetooth and press the OK Key.
4. With Add New Device selected, press the OK Key. The handset will
prompt you with the following message on the LCD screen: PLACE
DEVICE YOU ARE CONNECTING TO IN DISCOVERABLE MODE.
Press the OK Key.
5. Scroll to the desired device and press the OK Key [PAIR].
6. If applicable, the device may prompt you for the Passkey. Consult the
Bluetooth® accessory (sold separately) instructions for the appropri-
ate password (typically 0000 - 4 zeroes). Enter the passkey and press
the OK Key.
7. The screen displays Before Connecting To [Device Name], select
either Always Ask or Always Connect and press the OK Key.
8. The information is then sent via Bluetooth to the receiving device.
RECENT CALLS
The Recent Calls menu is a list of the last phone numbers or Contact
entries for calls you placed, accepted, missed or blocked. It is continually
updated as new numbers are added to the beginning of the list and the
oldest entries are removed from the bottom of the list.
MISSED
Displays information about the 90 most recently missed calls. Place a call to a
missed call by simply pressing the SEND Key.
1. Press the OK Key [MENU], scroll to Recent Calls and press the OK
Key, scroll to Missed and press the OK Key.
2. Scroll to an entry and press the OK Key [OPEN] to view the entry.
3. Press the Right Soft Key [Options] to access the following options.
Save to Contacts: Store the phone number in your Contacts.
•
Details: View contact information stored in your Contact List.
•
Erase: Erase a call listing.
•
Lock/Unlock: To lock or unlock a call listing.
•
Erase All: Erase all Missed call entries.
•
View Timers: Display usage time.
4. Press the Left Soft Key [Message] to access the following options.
40
Chapter 4 − Menu Function
Recent Calls
•
TXT Message: Send a TXT message to the contact.
•
Picture Message: Send a Picture message to the contact.
•
Voice Message: Send a Voice message to the contact.
RECEIVED
Displays information about the 90 most recently received calls. Place a call to a
received call by simply pressing the SEND Key.
1. Press the OK Key [MENU], scroll to Recent Calls and press the OK
Key, scroll to Received and press the OK Key.
2. Scroll to an entry and press the OK Key [OPEN] to view the entry.
3. Press the Right Soft Key [Options] to access the following options.
•
Save to Contacts: Store the phone number in your Contacts.
•
Details: View contact information stored in your Contact List.
•
Erase: Erase a call listing.
•
Lock/Unlock: To lock or unlock a call listing.
•
Erase All: Erase all Received call entries.
•
View Timers: Display usage time.
4. Press the Left Soft Key [Message] to access the following options.
•
TXT Message: Send a TXT message to the contact.
•
Picture Message: Send a Picture message to the contact.
•
Voice Message: Send a Voice message to the contact.
DIALED
Displays information about the 90 most recently dialed numbers. Place a call
to a dialed call by simply pressing the SEND Key.
1. Press the OK Key [MENU], scroll to Recent Calls and press the OK
Key, scroll to Dialed and press the OK Key.
2. Scroll to an entry and press the OK Key [OPEN] to view the entry.
3. Press the Right Soft Key [Options] to access the following options.
•
Save to Contacts: Store the phone number in your Contacts.
•
Details: View contact information stored in your Contact List.
•
Erase: Erase a call listing.
•
Lock/Unlock: To lock or unlock a call listing.
•
Erase All: Erase all Dialed call entries.
•
View Timers: Display usage time.
4. Press the Left Soft Key [Message] to access the following options.
•
TXT Message: Send a TXT message to the contact.
•
Picture Message: Send a Picture message to the contact.
•
Voice Message: Send a Voice message to the contact.
Menu Function − Chapter 4
41
Recent Calls
42
Chapter 4 − Menu Function
Recent Calls
2. Scroll to Last Call, All Calls, Received Calls, Dialed Calls,
Roaming Calls, Transmit Data, Received Data, Total Data,
Last Reset, Lifetime Calls and Lifetime Data Counter to view
the information.
3. Press the Left Soft Key [Reset] to reset the highlighted timer.
4. Press the Right Soft Key [Reset All] to reset all timers.
BLUETOOTH MENU
Bluetooth technology connectivity enables wireless connections between
electronic devices. If connected with a Bluetooth Handsfree device, you can
use your phone more freely. Since devices with Bluetooth connectivity com-
municate using radio waves, your phone and the other device do not need to
be in direct line-of-sight. The two devices only need to be within 10 meters
(30 feet) of each other. The connection can be subject to interference from
obstructions such as walls or other electronic devices. This device is compliant
with Bluetooth specification 2, supporting the following profiles: Headset,
Handsfree, Phonebook Access and Object Push. To ensure interoperability
between other devices supporting Bluetooth technology, use approved
enhancements for this model. Check with the manufacturers of other devices
to determine their compatibility with this phone. There may be restrictions on
using Bluetooth technology in some locations. Check with your local authori-
ties or Verizon Wireless. If you want more information on this function, visit
the Bluetooth Technology organization Web site: https://www.bluetooth.org/.
Features using Bluetooth technology or allowing such features to run in the
background while using other features, increase the demand on battery
power and reduce the battery life.
BLUETOOTH ON/OFF
To activate Bluetooth:
1. Press the OK Key [MENU], scroll to Bluetooth Menu and press the
OK Key.
2. Press the Left Soft Key [Turn On/Turn Off].
ADD NEW DEVICE
Pairing is the process that allows the handset to locate, establish and register a
1-to-1 connection with the target device.
1. Press the OK Key [MENU], scroll to Bluetooth Menu and press the
OK Key.
2. Scroll to Add New Device and press the OK Key.
3. If the Bluetooth® power is switched off, the following message will
appear on the screen: TURN BLUETOOTH POWER ON? Press the OK
Menu Function − Chapter 4
43
Settings
BLOCKED
This menu appears only when Incoming Call Restriction is set.
1. Press the OK Key [MENU], scroll to Recent Calls and press the OK
Key, scroll to Blocked and press the OK Key.
2. Scroll to an entry and press the OK Key [OPEN] to view the entry.
3. Press the Right Soft Key [Options] to access the following options.
•
Erase: Erase a call listing.
•
Lock/Unlock: To lock or unlock a call listing.
•
Erase All: Erase all Blocked call entries.
•
View Timers: Display usage time.
4. Press the Left Soft Key [Message] to access the following options.
•
TXT Message: Send a TXT message to the contact.
•
Picture Message: Send a Picture message to the contact.
•
Voice Message: Send a Voice message to the contact.
For details on Restrictions, see page 59.
ALL
Displays information about the most recently received, dialed and missed calls.
To view a quick list of all your calls, press Send Key from idle mode.
1. Press the OK Key [MENU], scroll to Recent Calls and press the OK
Key, scroll to All and press the OK Key.
2. Scroll to an entry and press the OK Key [OPEN] to view the entry.
3. Press the Right Soft Key [Options] to access the following options.
•
Save to Contacts: Store the phone number in your Contacts.
•
Details: View contact information stored in your Contact List.
•
Erase: Erase a call listing.
•
Lock/Unlock: To lock or unlock a call listing.
•
Erase All: Erase all All call entries.
•
View Timers: Display usage time.
4. Press the Left Soft Key [Message] to access the following options.
•
TXT Message: Send a TXT message to the contact.
•
Picture Message: Send a Picture message to the contact.
•
Voice Message: Send a Voice message to the contact.
VIEW TIMERS
Timers allow you to check you usage time and manage your calls. Checks the
usage time and manages your calls within the limit you set.
1. Press the OK Key [MENU], scroll to Recent Calls and press the OK
Key, scroll to View Timers and press the OK Key.
44
Chapter 4 − Menu Function
Settings
•
Remove Device: Removes a device from the pairing list.
•
Rename Device: Renames a paired device.
•
Incoming Security: Sets permissions for connecting to an incoming device.
•
Service Discovery: Search for the services that the selected device
supports.
•
Send Name Card: Send the stored phonebook to a selected device.
•
Get Name Card: Request and receive the Name card information of the
other side.
•
Device Info: Displays device information.
SETTINGS
MY PHONE NAME
To edit the Bluetooth® name of your phone:
1. Press the OK Key [MENU], scroll to Bluetooth Menu and press the
OK Key.
2. Press the Right Soft Key [Options].
3. Select My Phone Name and press the OK Key.
4. Enter a new custom name.
5. Press the OK Key to save.
DISCOVERY MODE
Set your device to able to be searched for by other Bluetooth® devices in the area.
1. Press the OK Key [MENU], scroll to Bluetooth Menu and press the
OK Key.
2. Press the Right Soft Key [Options].
3. Scroll to Discovery Mode and press the OK Key.
If Bluetooth power is not on, you will be prompted to turn it on in order
to proceed.
4. Scroll to select On or Off and press the OK Key.
SUPPORTED PROFILES
To view brief descriptions of the profiles supported by the phone:
1. Press the OK Key [MENU], scroll to Bluetooth Menu and press the
OK Key.
2. Press the Right Soft Key [Options].
3. Scroll to Supported Profiles and press the OK Key.
4. Scroll to a profile and press the OK Key [VIEW] for further details.
Menu Function − Chapter 4
45
Settings
Key to select Yes.
4. The handset will prompt you with the following message on the
screen: PLACE DEVICE YOU ARE CONNECTING TO IN DISCOVERABLE
MODE. Press the OK Key.
5. The device will appear in the Add New Device menu. Scroll to the
device to pair to and press the OK Key [PAIR].
6. If applicable, the handset may prompt you for the password. Consult
the Bluetooth® accessory (sold separately) instructions for the
appropriate passkey (typically 0000. 4 zeroes). Enter the passkey and
press the OK Key.
You do not need to input the passkey for pairing when the passkey of the
Bluetooth® Headset or hands-free kit is 0000.
7. Connect to: (device name) will appear on screen. Select Yes and
press the OK Key.
8. Once connected, you will see the device listed in the Bluetooth
menu and the Bluetooth® device connected icon
will appear at
the top of the screen when connected to the Bluetooth® device.
•
In the Bluetooth menu, you can disconnect the connected device with an
icon by pressing the OK Key [Drop]. Conversely, you can reconnect by
pressing the OK Key again.
•
When an audio device is connected, you can select another device and the
connection is automatically transferred from that audio device to the other
one.
•
If multiple devices are displayed, select the device you want to connect.
OPTIONS
1. Press the OK Key [MENU], scroll to Bluetooth Menu and press the
OK Key.
2. Scroll to the paired device.
3. If an audio device is connected, press the Right Soft Key [Options],
to choose from the following options:
•
Remove Device: Removes a device from the pairing list.
•
Rename Device: Renames a paired device.
•
Service Discovery: To search for the services that the selected device
supports.
•
Send Name Card: Send the stored phonebook to a selected device
(If selected device is HFK and supports OPP).
•
Device Info: Displays device information.
4. If a PC or other device is connected, press the Right Soft Key
[Options], you can choose from the following options:
AUTO PAIR HANDSFREE
1. Press the OK Key [MENU], scroll to Bluetooth Menu and press the
OK Key.
2. Press the Right Soft Key [Options].
3. Scroll to Auto Pair Handsfree and press the OK Key.
4. Scroll to select On or Off and press the OK Key.
SOUNDS SETTINGS
EASY SET UP
To set up phone sounds using the Easy Set Up Wizard:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Sounds Settings and press the OK Key, scroll to
Easy Set Up and press the OK Key.
2. Select the ringer type and press the OK Key [SET]. To skip the step,
press the Right Soft Key [Skip].
3. Select the ringtone and press the OK Key [SET]. To listen to the
ringtone, press the Left Soft Key [Play].
4. Select the volume of the keypad and press the OK Key [SET].
5. Select the alerts ringer type for text messaging and press the OK
Key [SET].
6. Select the alerts ringtone for text messaging and press the OK Key
[SET]. To listen to the ringtone, press the Left Soft Key [Play].
7. Select the ringer type for multimedia messaging and press the OK
Key [SET].
8. Select the ringtone for multimedia messaging and press the OK Key
[SET]. To listen to the ringtone, press the Left Soft Key [Play].
9. Select the alerts ringer type for voicemail messaging and press the
OK Key [SET].
10. Select the alerts ringtone for voicemail messaging and press the OK
Key [SET]. To listen to the ringtone, press the Left Soft Key [Play].
CALL SOUNDS
Set ringtones for types of incoming calls.
CALL RINGTONE
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Sounds Settings and press the OK Key, scroll to
Call Sounds and press the OK Key.
46
Chapter 4 − Menu Function
Settings
2. Scroll to Call Ringtone and press the OK Key.
3. Scroll to a ringtone and press the OK Key to save the sound.
To listen to the ringtone, press the Left Soft Key [Play].
CALL VIBRATE
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Sounds Settings and press the OK Key, scroll to
Call Sounds and press the OK Key.
2. Scroll to Call Vibrate and press the OK Key.
3. Scroll to On or Off and press the OK Key.
CALL ALERT
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Sounds Settings and press the OK Key, scroll to
Call Sounds and press the OK Key.
2. Scroll to Call Alert and press the OK Key.
3. Scroll to Ring Only, Caller ID + Ring or Name Repeat and press
the OK Key.
ALERT SOUNDS
To select the alert type for a new message:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Sounds Settings and press the OK Key, scroll to
Alert Sounds and press the OK Key.
2. Scroll to TXT Message, Pic/Voice Message, Voicemail or Missed
Call and press the OK Key.
3. Scroll to access the following options and press the OK Key.
•
Tone: Alerts you with the ringtone. Select the ringtone and press the OK Key.
•
Vibrate: Alerts you with the vibration. Select On or Off and press the OK Key.
•
Reminder: Alerts you with time interval. Select Once, Every 2 Minutes,
Every 15 Minutes or Off and press the OK Key.
EMERGENCY TONE
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Sounds Settings and press the OK Key, scroll to
Alert Sounds and press the OK Key.
2. Scroll to Emergency Tone and press the OK Key.
3. Scroll to Alert, Vibrate or Off and press the OK Key.
Menu Function − Chapter 4
47
Settings
KEYPAD SOUNDS
To set the sound of keypad when pressed key button:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Sounds Settings and press the OK Key, scroll to
Keypad Sounds and press the OK Key.
2. Scroll to DTMF, Cloud or Simple and press the OK Key.
DIGIT DIAL READOUT
The Digit Dial Readout setting controls if digits are read out when you type in a
phone number with the keypad.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Sounds Settings and press the OK Key, scroll to
Digit Dial Readout and press the OK Key.
2. Scroll to On or Off and press the OK Key.
KEYPAD VOLUME
To set the keypad volume:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Sounds Settings and press the OK Key, scroll to
Keypad Volume and press the OK Key.
2. Adjust the volume by pressing the Directional Key up or down and
press the OK Key.
SERVICE ALERTS
To set any of the three Alert options to either On or Off:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Sounds Settings and press the OK Key, scroll to
Service Alerts and press the OK Key.
2. Scroll to access the following options and press the OK Key.
•
ERI: The Enhanced Roaming Indicator (ERI) feature displays a text banner on
the display screen informing the handset user of which systems the
wireless device is using as compared to the service plan they purchased.
The ERI Banner text changes to tell a customer if they are using the:
Verizon Wireless Network, Extended Network or Roaming.
•
Minute Beep: Alerts you every minute during a call.
•
Call Connect: Alerts you when the call is connected.
3. Scroll to On or Off and press the OK Key.
DEVICE CONNECT
Allows you to turn the Device Connect On or Off:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
48
Chapter 4 − Menu Function
Settings
OK Key, scroll to Sounds Settings and press the OK Key, scroll to
Device Connect and press the OK Key.
2. Scroll to On or Off and press the OK Key.
POWER ON/OFF
To set the phone to sound a tone when the phone is powered on/off:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Sounds Settings and press the OK Key, scroll to
Power On/Off and press the OK Key.
2. Scroll to Power On or Power Off and press the OK Key.
3. Scroll to On or Off and press the OK Key.
OPEN/CLOSE SOUNDS
To set the phone to sound a tone when the phone is flip open/close:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Sounds Settings and press the OK Key, scroll to
Open/Close Sounds and press the OK Key.
2. Scroll to Music, Simple, Beep or Off and press the OK Key.
DISPLAY SETTINGS
EASY SET UP
To set up display options using the Easy Set-Up Wizard:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Easy Set Up and press the OK Key.
2. Enter the text to be displayed on your main screen and press the OK
Key [SET]. To skip the step, press the Right Soft Key [Skip].
3. Select the duration for backlight and press the OK Key [SET].
4. Select the duration for backlight of the keypad and press the OK Key
[SET].
5. Select the theme for displaying and press the OK Key [SET].
To preview the theme, press the Left Soft Key [Preview].
6. Select the image for the main screen and press the OK Key [SET].
To preview the image, press the Left Soft Key [View].
7. Select the image for front screen and press the OK Key [SET].
To preview the image, press the Left Soft Key [View].
Menu Function − Chapter 4
49
Settings
8. Select the layout for displaying main menu and press the OK Key
[SET]. To preview the layout style, press the Left Soft Key [Preview].
9. Select the type for displaying the main menu and press the OK Key
[SET]. To preview the layout type, press the Left Soft Key [Help].
Step 9 appears only when List or Grid main menu selected.
10. Select the size of font for dialing and press the OK Key [SET].
To preview the font size, press the Left Soft Key [Preview].
11. Select the style of the clock for main screen and press the OK Key
[SET]. To preview the style of the clock, press the Left Soft Key
[Preview].
12. Select the style of the clock for front screen and press the OK Key
[SET]. To preview the style of the clock, press the Left Soft Key
[Preview].
BANNER
PERSONAL BANNER
The Personal Banner can be up to 16 characters and is displayed on your phone’s screen
in idle mode.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Banner and press the OK Key.
2. Scroll to Personal Banner and press the OK Key.
3. Enter the banner text (up to 16 characters) and press the OK Key.
ERI BANNER
If you use ERI Service, ERI Text is shown on the sub banner.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Banner and press the OK Key.
2. Scroll to ERI Banner and press the OK Key.
3. Scroll to select On or Off and press the OK Key.
BACKLIGHT
To set the duration for backlight illumination for the Main Screen and Keypad:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Backlight and press the OK Key.
2. Scroll to Display or Keypad and press the OK Key.
50
Chapter 4 − Menu Function
Settings
3. Scroll to 7 Seconds, 15 Seconds, 30 Seconds or Always On and
press the OK Key.
Even if Always On is selected for the Backlight setting, the backlight will
turn off when the phone is closed.
WALLPAPER
To choose the kind of Main LCD or Front LCD background to be displayed on the
phone:
MAIN SCREEN
To choose the kind of Main LCD background to be displayed on the phone:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Wallpaper and press the OK Key.
2. Scroll to Main Screen and press the OK Key.
3. Select the image and press the OK Key. To view the image, press the
Left Soft Key [View].
4. Press the Right Soft Key [Get New] scroll to Get New Applications
to download other available selections.
FRONT SCREEN
To choose the Front LCD background to be displayed on the phone:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Wallpaper and press the OK Key.
2. Scroll to Front Screen and press the OK Key.
3. Select the image and press the OK Key. To view the image, press the
Left Soft Key [View].
4. Press the Right Soft Key [Get New] scroll to Get New Applications
to download other available selections.
GLOBAL TRAVELER
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Wallpaper and press the OK Key.
2. Scroll to Global Traveler and press the OK Key.
3. Scroll to select On or Off and press the OK Key.
Menu Function − Chapter 4
51
Settings
DISPLAY THEMES
To choose the background screen:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Display Themes and press the OK Key.
2. Scroll to select either Business Diary, The World, Water or White
and press the OK Key [SET]. To preview the themes, press the Left
Soft Key [Preview].
The default setting is Water.
3. To view help for the themes, press the Right Soft Key [Help].
If you change this setting, you will not be able to follow the instructions as
written in the manual.
MAIN MENU SETTINGS
To change the Main Menu layout and type:
TO SET LIST MENU LAYOUT
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Main Menu Settings and press the OK Key.
2. Scroll to Menu Layout and press the OK Key.
3. Scroll to select List and press the OK Key.
4. Scroll to Communicator or Messaging and press the OK Key.
If you change this setting, you will not be able to follow the instructions as
provided in the manual.
The default setting is List.
REPLACE LIST MENU ITEMS
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Main Menu Settings and press the OK Key.
2. Scroll to Replace Menu Items and press the OK Key.
3. If using Communicator profile, scroll to My Ringtones, My
Pictures, Bluetooth Menu or VZ Navigator and select the item to
replace and press the OK Key [EDIT]. Scroll to Email or Mobile IM
and press the OK Key [SET].
4. If using Messaging profile, scroll to Email, Mobile IM, My
Ringtones or VZ Navigator and select the item to replace and press
the OK Key [EDIT]. Scroll to My Pictures or Bluetooth Menu and
52
Chapter 4 − Menu Function
Settings
press the OK Key [SET].
5. To view help for the replace menu item, press the Right Soft Key
[Help].
6. Press the Left Soft Key [Done] to save your changes.
POSITION LIST MENU ITEMS
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Main Menu Settings and press the OK Key.
2. Scroll to Position Menu Items and press the OK Key.
3. Scroll to select the item to move and press the OK Key [MOVE].
4. Scroll to change the position and press the OK Key [SET].
RESET LIST MENU SETTINGS
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Main Menu Settings and press the OK Key.
2. Scroll to Reset Menu Settings and press the OK Key.
3. Scroll to access the following options and press the OK Key.
•
Menu Layout: Restore menu layout to the initial menu layout.
•
Menu Items: Restore menu items to the initial content of the menu.
•
Item Positions: Restore menu items to their initial positions.
•
All: Restore all to your initial menu settings.
If you change this setting, you will not be able to follow the instructions as
provided in the manual.
DIAL FONTS
To set the font size:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Dial Fonts and press the OK Key.
2. Scroll to Normal or Large Only and press the OK Key.
To preview the font size, press the Left Soft Key [Preview].
MENU FONT SIZE
To set the menu font size:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Menu Font Size and press the OK Key.
Menu Function − Chapter 4
53
Settings
2. Scroll to Normal or Large and press the OK Key.
TIME & DATE
To set the time and date for your phone:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Time & Date and press the OK Key.
2. Scroll to time field to enter the time.
3. Scroll to date field to enter the date and press the OK Key to save.
This menu appears only GSM mode.
CLOCK FORMAT
To choose the kind of clock to be displayed on the Main LCD or Front LCD screen:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Display Settings and press the OK Key, scroll to
Clock Format and press the OK Key.
2. Scroll to Main Clock or Front Clock and press the OK Key.
3. Scroll to access the following options and press the OK Key.
•
Main Clock: Set the type of the clock in the main screen. Large Digital12 is
the default setting.
•
Front Clock: Set the type of the clock in the front screen. Digital is the
default setting.
PHONE SETTINGS
AIRPLANE MODE
In Airplane Mode, all menu functions can be accessed except making calls, receiving
calls, data connection and Bluetooth®. Activating Airplane Mode will disable all
wireless communications. In Airplane Mode, services that support location on
functions like chaperone are temporarily disabled.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Airplane Mode and press the OK Key.
2. Scroll to On or Off and press the OK Key.
SET SHORTCUTS
Your phone offers you the option of assigning a shortcut key (Directional Key left,
right, up and down) to a favorite or often-used function. In addition, choose menu
settings for each of the shortcut options under Set Directional Keys (Directional
Key right).
54
Chapter 4 − Menu Function
Settings
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to Set
Shortcuts and press the OK Key.
2. Scroll to Set My Shortcuts and press the OK Key.
3. Scroll to select Shortcut 1, Shortcut 2, Shortcut 3 or Shortcut 4
and press the OK Key [SET].
4. Scroll to select the desired option and press the OK Key.
The Download Application Alphabet option only appears when you have
downloaded Brew Applications. In idle mode, pressing the Directional Key
right will display the My Shortcuts screen. On the My Shortcuts
screen, you can Scroll to select a function and press the OK Key to access the
function. On the My Shortcuts screen, you can relocate a function by press-
ing the Right Soft Key [Move], pressing the Directional Key up or down and
pressing the OK Key [SAVE]. Or you can press the Left Soft Key [Settings] to
Set My Shortcuts or Set Directional Keys.
RESETTING MY SHORTCUTS
To restore My Shortcuts to their original defaults:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to Set
Shortcuts and press the OK Key.
2. Scroll to Set My Shortcuts and press the OK Key.
3. Scroll to Shortcut 1, Shortcut 2, Shortcut 3 or Shortcut 4 and
press the Right Soft Key [Options].
4. Scroll to Reset Shortcut (1, 2, 3 or 4) or Reset My Shortcuts and
press the OK Key.
5. Scroll to Yes and press the OK Key.
SET DIRECTIONAL KEYS
1. Press the OK Key [MENU], scroll to Settings & Tools and
press the OK Key, scroll to Phone Settings and press the
OK Key, scroll to Set Shortcuts and press the OK Key.
2. Scroll to Set Directional Keys and press the OK Key.
3. Scroll to select UP Directional Key, LEFT Directional Key or
DOWN Directional Key and press the OK Key [SET].
4. Scroll to select the desired option and press the OK Key.
RESETTING THE DIRECTIONAL KEY SETTINGS
Use the following procedure to specify the default directional key settings.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
Menu Function − Chapter 4
55
Settings
OK Key, scroll to Phone Settings and press the OK Key, scroll to Set
Shortcuts and press the OK Key.
2. Scroll to Set Directional Keys and press the OK Key.
3. Scroll to UP Directional Key, LEFT Directional Key or DOWN
Directional Key and press the Right Soft Key [Options].
4. Scroll to Reset (UP, LEFT or DOWN) Key or Reset Directional
Keys and press the OK Key.
5. Scroll to Yes and press the OK Key.
VOICE COMMANDS SETTINGS
You can use voice commands to control your device.
CONFIRMATION
When voice recognition is not confident it has recognized a name or number correctly, it
will show you a list of up to three choices. You can control when choice lists appear.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Voice Commands Settings and press the OK Key.
2. Scroll to Confirmation and press the OK Key.
3. Scroll to select Automatic, Always Confirm or Never Confirm and
press the OK Key.
SENSITIVITY
The Sensitivity setting controls how the voice recognition software determines when a
spoken word is a match. If you frequently experience the messages Please Repeat or No
Match Found, adjust the sensitivity toward Reject Less. If you frequently experience false
activations (when the phone recognizes a name you didn’t say), adjust the sensitivity
toward Most Sensitive.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Voice Commands Settings and press the OK Key.
2. Scroll to Sensitivity and press the OK Key.
3. Scroll to select Most Sensitive, Recommended or Least
Sensitive and press the OK Key.
ADAPTATION
Voice Command is speaker independent, which means that no training or adaptation
is required. Some users with heavy accents or unusual voice characteristics may find
difficulty in achieving high accuracy with speaker independent Voice Command, so the
Adapt Voice feature allows users to dramatically improve the recognition accuracy through
adaptation. Users who get acceptable recognition accuracy will find no additional benefit
to performing the Adapt Voice adaptation.
56
Chapter 4 − Menu Function
Settings
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Voice Commands Settings and press the OK Key.
2. Scroll to Adaptation and press the OK Key.
3. Scroll to select Adapt Voice or Reset Voice and press the OK Key.
To activate press the OK Key.
•
Adapt Voice: Requires that you make recordings of your voice to customize
the voice recognitions system. It will take a few minutes.
•
Reset Voice: Once you finish the adaptation process, you can reset the
adaptation to the factory default settings.
Reset Voice menu option only appears after you finish the Adapt Voice
process.
4. Wait for the beep and then repeat the sentences using a normal
tone of voice.
5. Repeat steps 1 - 4 when you are finished with a full session, you will
reach a screen that reads Adaptation Complete.
PROMPTS
Allows you to select the voice command system characteristics.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Voice Commands Settings and press the OK Key.
2. Scroll to Prompts and press the OK Key.
3. Scroll to select Mode or Audio Playback and press the OK Key.
•
Mode: Select the voice command system mode from the following:
- Prompts: Read out voice command prompts.
- Readout+Alerts: Read out and Alert tone prompts, dialing digits and
menus at the same time.
- Readout: Read out prompts, dialing digits and menus.
- Tones Only: Prompt you with a tone only.
•
Audio Playback: Allows audio playback to play through the speakerphone
or through the earpiece. Scroll to select Automatic, Speakerphone or Earpiece
and press the OK Key.
ABOUT
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Voice Commands Settings and press the OK Key.
2. Scroll to About and press the OK Key.
3. The Nuance version appears.
Menu Function − Chapter 4
57
Settings
4. Press the OK Key to return to the previous screen.
LANGUAGE
To set the bilingual feature to either English or Spanish:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Language and press the OK Key.
2. Scroll to English or Español and press the OK Key.
LOCATION
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Location and press the OK Key.
2. Scroll to access the following options and press the OK Key.
•
Location On: Your location is now available to the network.
•
E911 Only: Your location will be hidden from the network and applications,
except for 911.
When the Lock Setting is selected for Location Settings under Restrictions
on the Security Menu, you will need to enter a Lock Code. The default Lock
Code is 0000.
Your wireless device can determine its (and your) physical, geographical
location (“Location Information”). Certain software applications are capable
of accessing, collecting and using Location Information and disclosing
the information to the application provider and other people. You should
use caution and discretion when determining whether or not Location
Information should be made available to them. To limit potential unauthor-
ized access to your Location Information, Verizon Wireless devices are preset
to “E911 ONLY” which will only allow authorized emergency response
personnel to locate you if you dial 9-1-1 from your wireless device. By
changing the setting on the device to “LOCATION ON” you are enabling third
party access to Location Information through software, widgets or periph-
eral components you choose to download, add or attach to your wireless
device. Verizon Wireless encourages you to check your wireless device
periodically and only use software, widgets and peripheral components
that are obtained from reliable sources. When you use your mobile browser
or other services and applications, you authorize Verizon Wireless to collect,
use and disclose your Location Information as appropriate to provide you
with any location services that you enabled. Verizon Wireless does not
retain Location Information longer than necessary to provide the services
to you. We will not knowingly disclose your Location Information to third
parties without your consent. You should carefully review the privacy poli-
cies of application providers and third parties who you allow access to your
Location Information, and you should know that significant risks can be
associated with disclosing your Location Information to others.
58
Chapter 4 − Menu Function
Settings
CURRENT COUNTRY
The Current Country menu allows you to select your current location.
If you travel to a different country, the network may not report the correct
location. In that case, you will see a pop-up message that states “PLEASE
VERIFY YOUR CURRENT LOCATION”. Press the OK Key to access the country
selection list.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Current Country and press the OK Key.
2. Enter a country name in the Go To field or scroll to select the
appropriate country and press the OK Key.
PHONE SECURITY
The Security menu allows you to electronically secure the phone. The default lock
code is the last 4 digits of your Mobile Telephone Number.
EDIT CODES
To set a new Lock Code:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Phone Security and press the OK Key.
2. Enter the four-digit lock code and press the OK Key. The default lock
code is last 4 digits of your mobile telephone number.
3. Scroll to Edit Codes and press the OK Key.
4. Scroll to access the following options and press the OK Key.
•
Phone Only: Allows you to edit the lock code for Phone Security. The default
lock code is the last 4 digits of your mobile telephone number.
•
Calls & Services: Allows you to edit the lock code for Restrictions. The
default lock code is 0000.
5. If Phone Only is selected, enter the new four-digit code in the
Enter New Code field. Enter the new four-digit code again in the
Re-enter New Code field and press the OK Key.
6. If Calls & Services is selected, enter the current lock code in the
Enter Current Code field. Enter the new four-digit code in the
Enter New Code field. Enter the new four-digit code again in the
Re-enter New Code field and press the OK Key.
RESTRICTIONS
Use the following procedure to configure Location Setting, Calls and Messages restrictions.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Menu Function − Chapter 4
59
Settings
Phone Security and press the OK Key.
2. Enter the four-digit lock code and press the OK Key. The default lock
code is last 4 digits of your mobile telephone number.
3. Scroll to Restrictions and press the OK Key.
4. Enter the four-digit lock code again and press the OK Key. The default
lock code is 0000.
5. Select one of the following settings:
•
Location Setting: Locks or unlock the setting.
•
Calls: Set the restriction for incoming and outgoing calls.
•
Messages: Set the restriction for incoming and outgoing messages.
PHONE LOCK SETTING
This setting specifies whether the phone should be locked whenever it is turned on. Lock
Mode prevents the unauthorized use of your phone. Once the phone is locked, it is in
restricted mode until the Lock Code is entered. You can still make emergency calls. You can
modify the Lock Code using the new Lock code within the Security menu.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Phone Security and press the OK Key.
2. Enter the four-digit lock code and press the OK Key. The default lock
code is last 4 digits of your mobile telephone number.
3. Scroll to Phone Lock Setting and press the OK Key.
4. Scroll to access the following options and press the OK Key.
•
Unlocked: Phone is unlocked.
•
On Power Up: Phone will lock when it is turned on.
LOCK PHONE NOW
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Phone Security and press the OK Key.
2. Enter the four-digit lock code and press the OK Key. The default lock
code is the last 4 digits of your mobile telephone number.
3. Scroll to Lock Phone Now and press the OK Key.
4. To unlock the phone in idle mode, press the Right Soft Key [Unlock]
and enter the four-digit lock code and press the OK Key.
60
Chapter 4 − Menu Function
Settings
RESTORE PHONE
To delete all User Data and restore all settings to their initial defaults:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Phone Security and press the OK Key.
2. Enter the four-digit lock code and press the OK Key. The default lock
code is the last 4 digits of your mobile telephone number.
3. Scroll to Restore Phone and press the OK Key.
4. Scroll to Yes and press the OK Key.
5. Follow the on-screen prompt and press the OK Key. The phone will
turn off and then back on again automatically.
SIM SECURITY
The SIM Security menu allows you to select the security settings for your SIM card.
PIN CODE
Allows you to edit/lock PIN code:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to SIM
Security and press the OK Key.
2. Enter the four-digit SIM lock code and press the OK Key. The default
SIM lock code is last 4 digits of your mobile telephone number.
3. Scroll to PIN Code and press the OK Key.
4. Scroll to access the following options and press the OK Key.
•
PIN Lock: Allows you to lock/unlock the PIN code.
•
Edit PIN Code: Allows you to edit the PIN code. (PIN number must be
locked before editing.)
SIM LOCK
Allows you to lock/unlock the SIM code.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to SIM
Security and press the OK Key.
2. Enter the four-digit SIM lock code and press the OK Key. The default
SIM lock code is last 4 digits of your mobile telephone number.
3. Scroll to SIM Lock and press the OK Key.
4. To unlock SIM card, enter the SIM lock code and press the OK Key.
Menu Function − Chapter 4
61
Settings
NETWORK MODE
Your phone is capable of operating in a number of countries on both CDMA (Code
Division Multiple Access) and GSM (Global Systems for Mobile) networks. While in
the United States or on other CDMA roaming networks, use your phone in Verizon
CDMA Mode. Use your phone in Global Mode while in countries serviced by GSM
network. You must have a SIM card in order to select GSM and Global Mode. For a
complete list of countries, please visit: www.verizonwireless.com/vzglobal. Network
mode allows you to select from CDMA, GSM or Global network modes.
When your phone is in Verizon (CDMA) mode, it does not necessarily mean
that you are on the Verizon Wireless Network. You may roam on certain
other carrier’s CDMA networks domestically and internationally when your
phone is in Verizon (CDMA) mode. For more information,
visit: www.verizonwireless.com.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
Network Mode and press the OK Key.
2. Scroll to select either CDMA Mode, GSM Mode or Global Mode and
press the OK Key.
SYSTEM SELECT
You can set your phone to search or roam on another network when you are not in
your home area. Leave this setting as default unless you want to alter the system
selection as instructed by your service provider.
CDMA SETTINGS
To set CDMA system mode:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
System Select and press the OK Key.
2. Scroll to CDMA Settings and press the OK Key.
3. Scroll to select either Automatic B, Automatic A or Home Only
and press the OK Key.
GSM SETTINGS
To set GSM system mode:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Settings and press the OK Key, scroll to
System Select and press the OK Key.
2. Scroll to GSM Settings and press the OK Key.
3. Scroll to select Automatic or Manual and press the OK Key.
62
Chapter 4 − Menu Function
Settings
CALL SETTINGS
ANSWER OPTIONS
To determine how to handle an answered call:
1. Press the OK Key [MENU], scroll to Settings & Tools and press
the OK Key, scroll to Call Settings and press the OK Key, scroll to
Answer Options and press the OK Key.
2. Scroll to select either Flip Open, Any Key or Auto w/ Hands-free
and press the OK Key [MARK].
3. Press the Left Soft Key [Done].
•
Flip Open is the default setting for this device.
•
When the phone is closed, the Auto w/ Hands-free Mode will not
function, except when a headset is connected.
•
The Auto w/ Hands-free will function after about five seconds.
•
Auto w/ Hands-free is available only when connected to a headset or
hands-free device.
•
The three functions can be used at the same time.
•
To answer all incoming calls, press the SEND Key.
AUTO RETRY
Set the length of time the phone waits before automatically redialing a number
when the attempted call fails.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Call Settings and press the OK Key, scroll to Auto
Retry and press the OK Key.
2. Scroll to select either 10 Seconds, 30 Seconds, 60 Seconds or Off
and press the OK Key.
TTY MODE
You can attach a TTY device to your phone enabling you to communicate with
parties also using a TTY device. A phone with TTY support is able to translate typed
characters to voice. Voice can also be translated into characters and then displayed
on the TTY.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Call Settings and press the OK Key, scroll to TTY
Mode and press the OK Key.
2. Scroll to select either TTY Full, TTY + Talk, TTY + Hear or TTY Off
and press the OK Key.
Menu Function − Chapter 4
63
Settings
ONE TOUCH DIAL
To initiate a speed dial call by holding down the speed dial digit:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Call Settings and press the OK Key, scroll to One
Touch Dial and press the OK Key.
2. Scroll to select On or Off and press the OK Key.
If One Touch Dial is disabled, speed dial numbers designated in your
contacts will not function.
VOICE PRIVACY
Turn the voice privacy feature On or Off.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Call Settings and press the OK Key, scroll to Voice
Privacy and press the OK Key.
2. Scroll to select On or Off and press the OK Key.
DTMF TONES
To set the Key Tone length and touch tone playback speed:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Call Settings and press the OK Key, scroll to DTMF
Tones and press the OK Key.
2. Scroll to access the following options and press the OK Key.
•
Normal: Sends out a tone for a fixed period of time even if you continue
to press the key.
•
Long: Sends out a continuous tone for the duration the key is pressed
and held.
ASSISTED DIAL
This menu allows you to select Assisted Dialing for a country where you are
making a call.
1. Press the OK Key [MENU], scroll to Settings & Tools and press
the OK Key, scroll to Call Settings and press the OK Key, scroll to
Assisted Dial and press the OK Key. Press the Right Soft Key [Help],
to view the help menu.
2. Scroll to Assisted Dialing and press the Directional Key left or right
to select On or Off.
3. When selecting On, scroll to Reference Country field, and then
press the Left Soft Key [Set]. Enter a country name in the Go To field
or scroll to select the appropriate country and press the OK Key.
64
Chapter 4 − Menu Function
Settings
4. While on the screen with the list of Countries, press the Left Soft Key
[Details] to edit the following options:
•
Country Code
•
IDD Prefix
•
NDD Prefix
•
Area/City code
•
National Number Length
5. Press the OK Key to save.
When Assisted Dialing is On, the home screen will display “Assisted On”
when dialing an international number.
MEMORY
Select this option to display phone memory information and to delete in
phone memory.
PHONE MEMORY USAGE
Check the available phone memory.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Memory and press the OK Key, scroll to Phone
Memory and press the OK Key.
2. Scroll to Memory Usage and press the OK Key.
3. Press the OK Key to return to the previous screen.
DELETING FILES
To delete files stored in Phone Memory:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Memory and press the OK Key, scroll to Phone
Memory and press the OK Key.
2. Scroll to select either My Pictures, My Ringtones, My Sounds or
My Contacts and press the OK Key.
3. Press the Right Soft Key [Options].
4. Scroll to Erase and press the OK Key.
5. Scroll to select a file, press the OK Key [MARK] or the Right Soft Key
[Mark All] and press the Left Soft Key [Done].
6. Scroll to Yes and press the OK Key.
Menu Function − Chapter 4
65
Settings
PHONE INFO
MY NUMBER
To view your CDMA or GSM phone number:
1. Press the OK Key [MENU], scroll to Settings & Tools and press
the OK Key, scroll to Phone Info and press the OK Key, scroll to My
Number and press the OK Key.
2. Scroll to access the following options and press the OK Key.
•
CDMA Number: Display the MDN, MIN and service provider.
•
GSM Number: Display the MSISDN and service provider.
3. Press the OK Key to return to the previous screen.
SW/HW VERSION
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Info and press the OK Key, scroll to SW/HW
Version and press the OK Key.
2. Displays the Software Version, PRL Version, ERI Version,
Browser Version, Media Center Version, MSUI Version, HW
Version and MEID.
3. Press the OK Key to return to the previous screen.
ICON GLOSSARY
To view all the icons and their meanings:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Phone Info and press the OK Key, scroll to Icon
Glossary and press the OK Key.
2. Press the OK Key to return to the previous screen.
For details on icons, see page 9.
SOFTWARE UPDATE
The update phone firmware (software) option allows you to download and update
the software in your phone automatically. Only the internal software is updated; no
contacts entries or other information saved to your phone will be deleted.
STATUS
To check the latest software download or update status:
1. Press the OK Key [MENU], scroll to Settings & Tools and press
the OK Key, scroll to Phone Info and press the OK Key, scroll to
Software Update and press the OK Key.
2. Scroll to Status and press the OK Key.
66
Chapter 4 − Menu Function
Settings
CHECK NEW
To check Download Server for new Software updates:
1. Press the OK Key [MENU], scroll to Settings & Tools and press
the OK Key, scroll to Phone Info and press the OK Key, scroll to
Software Update and press the OK Key.
2. Scroll to Check New and press the OK Key.
SIM INFO
To view the SIM ID number for your phone.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to SIM Info and press the OK Key.
2. The SIM ID number is displayed.
3. Press the OK Key to return to the previous screen.
SET UP WIZARD
To set up options using the Set Up Wizard:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Set Up Wizard and press the OK Key.
2. Select the call sounds ringer type and press the OK Key [SET]. To skip
the step, press the Right Soft Key [Skip].
3. Select the ringtone and press the OK Key [SET]. To listen to the
selected ringtone, press the Left Soft Key [Play].
4. Select the theme of display and press the OK Key [SET].
To preview the theme, press the Left Soft Key [Preview].
5. Select the type for displaying main menu layout and press the OK
Key [SET]. To preview the style of the layout, press the Left Soft Key
[Preview].
6. Select the menu type by pressing the OK Key [SET].
For an explanation, press the Left Soft Key [Help].
Step 6 appears only when List or Grid main menu selected.
7. Select the type of clock for the main screen and press the OK
Key [SET]. To preview the type of clock, press the Left Soft Key
[Preview].
8. Select the type of clock for the front screen and press the OK
Key [SET]. To preview the type of clock, press the Left Soft Key
[Preview].
Menu Function − Chapter 4
67
Settings
VOICE COMMANDS
Your phone is equipped with an AVC (Advanced Voice Cognition) feature. This
feature allows you to make calls or use the phone’s functions by simply using
your voice. All you have to do is talk into the phone and the phone will recog-
nize your voice and complete tasks by itself.
1. Press the OK Key [MENU], scroll to Settings & Tools and press
the OK Key, scroll to Tools and press the OK Key, scroll to Voice
Commands and press the OK Key.
Shortcut: In idle mode, press the Voice Key down to access Voice
Commands.
2. The phone displays the Voice Commands menu and prompts you
to say the name of the command you want to use. To complete your
task, simply follow the voice prompts. You can speak the name of the
command after you hear a beep.
You can hear a beep in the Tone Only Mode (Settings & Tools > Phone
Settings > Voice Commands Settings > Mode > Tones Only) while you can
see a prompt without a beep sound in the Prompts or Readout.
3. Select either Call <Name or #>, Send <MSG Type>, Go
To <Shortcut>, Check <Item>, Contact <Name>, Play
<Playlist>, My Verizon or Help press the OK Key.
In Voice Commands mode, press the Side Volume Key / up or down to
adjust the voice commands volume.
4. When it recognizes one of these commands, the phone launches the
associated application. If the phone does not hear a command within
approximately eight seconds, AVC mode will turn itself off.
CALL <NAME OR #>
Use the Call command to voice dial a name from your contact list or a phone
number. When dialing a number, pronounce each digit, but do not pause noticeably
between the digits.
1. You will hear Please say a command and the Voice Commands
menu will be displayed.
2. If calling a contact from your list, say Call <Name>. Your phone
will ask you to confirm the name you said. Say Yes if it was repeated
correctly. That phone number will be dialed. If there is more than one
number saved for that contact, you will be asked to confirm which
number to dial.
Examples: - Call Tom Smith, - Call 617 555-1212, - Call Bob Carson’s
mobile, - Call Dee Harper at Home.
68
Chapter 4 − Menu Function
Voice Tools
SEND <MSG TYPE>
Use the Send command to send a text or other type of message to a specified name
or number.
1. You will hear Please say a command and the Voice Commands
menu will be displayed.
2. Say Send followed immediately by one of Text, Picture or Voice.
Examples: - Send Text Tom Smith, - Send Picture to Dee Harper’s
Mobile.
GO TO <SHORTCUT>
Use the Go To command to open an application on your phone. You can say Go To by
itself and be prompted to say the application name or you can skip the prompt by
saying Go To followed by the application name.
1. You will hear Please say a command and the Voice Commands
menu will be displayed.
2. Say Go To followed immediately by one of the Alarm Clock,
Bluetooth Menu, Bluetooth On/Off, Browse & Download,
Calculator, Calendar, Call Settings, Chat, Contacts, Contact
List, Display Settings, Extras, Games, Get New Browse &
Download, Get New Extra, Get new Game, Get new Pictures,
Get New Ringtones, Media Center, Messaging, Messaging
Inbox, Mobile Email, Mobile IM, Mobile Web Mail, My Pictures,
My Ringtones, My Sounds, My Verizon, New Contact, New
Picture Message, New Txt message, New Voice Message,
Notepad, Online Album, Phone Settings, Pictures, Recent
Calls, Settings & Tools, Sounds Settings, Tip Calculator, Tools,
Tunes & Tones, Unit Converter, VZ Navigator, Memory, Phone
Info.
CHECK <ITEM>
The Check command lets you check status information for your phone. You can say
Check or Check Status to see and hear all status information.
1. You will hear Please say a command and the Voice Commands
menu will be displayed.
2. Say Check followed immediately by one of the Status, Voicemail,
Messages, Missed Calls, Time, Signal Strength, Battery,
Volume, Balance, Minutes, Payment or My Number.
Menu Function − Chapter 4
69
Voice Tools
CONTACTS <NAME>
Use the Contacts command to retrieve and display information for any name stored
in your contact list.
1. You will hear Please say a command and the Voice Commands
menu will be displayed.
2. Say Contacts <Name>.
Examples: - Contacts Tom Jones.
3. The View Contact page will be displayed for that contact name.
REDIAL
Use the Redial command to redial with the directory number which talks over the
phone recentry.
1. You will hear Please say a command and the Voice Commands
menu will be displayed.
2. Say Redial.
MY VERIZON
1. You will hear Please say a command and the Voice Commands
menu will be displayed.
2. Say My Verizon.
3. Your phone will make a web connection.
HELP
1. You will hear Please say a command and the Voice Commands
menu will be displayed.
2. Say Help.
3. The Help guide will be displayed on your phone.
4. Press the OK Key to return to the previous screen.
VOICE COMMANDS SETTINGS
CONFIRMATION
When voice recognition is not confident it has recognized a name or number correctly, it
will show you a list of up to three choices. You can control when choice lists appear.
1. Press the OK Key [MENU], scroll to Settings & Tools and press
the OK Key, scroll to Tools and press the OK Key, scroll to Voice
Commands and press the OK Key.
2. Press the Right Soft Key [Settings], scroll to Confirmation and
press the OK Key.
70
Chapter 4 − Menu Function
Voice Tools
3. Scroll to select Automatic, Always Confirm or Never Confirm and
press the OK Key.
SENSITIVITY
The Sensitivity setting controls how the voice recognition software determines when a
spoken word is a match. If you frequently experience the messages Please Repeat or No
Match Found, adjust the sensitivity toward Reject Less. If you frequently experience false
activations (when the phone recognizes a name you didn’t say), adjust the sensitivity
toward Most Sensitive.
1. Press the OK Key [MENU], scroll to Settings & Tools and press
the OK Key, scroll to Tools and press the OK Key, scroll to Voice
Commands and press the OK Key.
2. Press the Right Soft Key [Settings], scroll to Sensitivity and press
the OK Key.
3. Scroll to select Most Sensitive, Recommended or Least
Sensitive and press the OK Key.
ADAPTATION
Voice Command is speaker independent, which means that no training or adaptation
is required. Some users with heavy accents or unusual voice characteristics may find
difficulty in achieving high accuracy with speaker independent Voice Command, so the
Adapt Voice feature allows users to dramatically improve the recognition accuracy through
adaptation. Users who get acceptable recognition accuracy will find no additional benefit
to performing the Adapt Voice adaptation.
1. Press the OK Key [MENU], scroll to Settings & Tools and press
the OK Key, scroll to Tools and press the OK Key, scroll to Voice
Commands and press the OK Key.
2. Press the Right Soft Key [Settings], scroll to Adaptation and press
the OK Key.
3. Scroll to select Adapt Voice or Reset Voice and press the OK Key.
To activate press the OK Key.
•
Adapt Voice: Requires that you make recordings of your voice to customize
the voice recognitions system. It will take a few minutes.
•
Reset Voice: Once you finish the adaptation process, you can reset the
adaptation to the factory default settings.
Reset Voice menu option only appears after you finish the Adapt Voice
process.
4. Wait for the beep and then repeat the sentences using a normal
tone of voice.
5. Repeat steps 1 - 4 when you are finished with a full session, you will
reach a screen that reads Adaptation Complete.
Menu Function − Chapter 4
71
Voice Tools
PROMPTS
Allows you to select the voice command system characteristics.
1. Press the OK Key [MENU], scroll to Settings & Tools and press
the OK Key, scroll to Tools and press the OK Key, scroll to Voice
Commands and press the OK Key.
2. Press the Right Soft Key [Settings], scroll to Prompts and press
the OK Key.
3. Scroll to select Mode or Audio Playback and press the OK Key.
•
Mode: Select the voice command system mode from the following:
- Prompts: Read out voice command prompts.
- Readout+Alerts: Read out and Alert tone prompts, dialing digits and
menus at the same time.
- Readout: Read out prompts, dialing digits and menus.
- Tones Only: Prompt you with a tone only.
•
Audio Playback: Allows audio playback to play through the speakerphone
or through the earpiece. Scroll to select Automatic, Speakerphone or Earpiece
and press the OK Key.
ABOUT
1. Press the OK Key [MENU], scroll to Settings & Tools and press
the OK Key, scroll to Tools and press the OK Key, scroll to Voice
Commands and press the OK Key.
2. Press the Right Soft Key [Settings], scroll to About and press the
OK Key.
3. The Nuance version appears.
4. Press the OK Key to return to the previous screen.
CALCULATOR
Allows you to perform simple mathematical calculations.
USING THE CALCULATOR
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Calculator and
press the OK Key.
2. Follow the instructions below to calculate 8×6÷4-2.5=9.5
Directional
Key
right
Directional
Key
down
Directional
Key
left
Directional
Key
up
OK Key
× ÷ + =
•
Input 8 and press the Directional Key right.
72
Chapter 4 − Menu Function
Tools
•
Input 6 and press the Directional Key left.
•
Input 4 and press the Directional Key down.
•
Input 2 and press the International Dial Key to input (.).
•
Input 5.
•
And press the OK Key and you will see the answer (9.5).
3. To change the displayed number from positive (+) to negative (-)
and vice versa, press the Vibrate Key .
4. Press the Right Soft Key [Operator] to use the following:
•
(
•
)
•
Exponent.
5. Press the Left Soft Key [Clear] to reset.
TIP CALCULATOR
Calculates the tip and determines how much each person should pay.
USING THE TIP CALCULATOR
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Tip Calculator
and press the OK Key.
2. Scroll to Total Bill field and enter the amount of the total bill.
3. Scroll to Tip(%) field and press the Directional Key left or right to
select Tip Percentage.
4. Scroll to Split field and press the Directional Key left or right to select
the amount of people paying.
5. In the area below, the calculator will automatically display the Tip,
and the share of the bill for each person.
6. Press the Left Soft Key [Reset] to reset.
CALENDAR
The Calendar tool provides easy and convenient access to your schedule.
Simply store your appointments and your phone will alert you to them.
SETTING THE SCHEDULE
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Calendar and
press the OK Key.
Shortcut: In idle mode, press the Directional Key down to access
Calendar.
2. Scroll to the scheduled day and press the Left Soft Key [Add].
Menu Function − Chapter 4
73
Tools
3. Scroll to Appointment field and enter the appointment.
4. Scroll to Start Time and enter the time. Press the Left Soft Key for
am/pm.
5. Scroll to End Time and enter the time. Press the Left Soft Key for
am/pm.
6. Scroll to Start Date and enter the date.
7. Scroll to Recurrence and press the Directional Key left or right to
select either Once, Daily, Weekly, Monthly or Yearly.
8. Scroll to End Date and enter the date.
9. Scroll to Time Zones and press the Left Soft Key [Set], scroll to the
time zone and press the OK Key.
10. Scroll to Alert and press the Left Soft Key [Set]. Scroll to the
ringtone and press the OK Key.
11. Scroll to Vibrate and press the Directional Key left or right to turn
Off or On.
12. Scroll to Reminder and press the Directional Key left or right
to select either Off, Once, Every 2 Minutes or Every 15 Minutes.
13. Scroll to Alert Time and press the Directional Key left or right to
select either On Time, 5 min before, 10 min before, 15 min
before, 30 min before, 1 hour before, 3 hour before, 5 hour
before or 1 day before.
14. Press the OK Key [SAVE] to save it. The date of the event will be
marked on your calendar.
VIEWING EVENT LIST
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Calendar and
press the OK Key.
2. Scroll to the event and press the OK Key [VIEW].
ERASING SAVED EVENT
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Calendar and
press the OK Key.
2. Scroll to the event and press the OK Key [VIEW].
3. Press the Left Soft Key [Erase], scroll to Yes and press the OK Key.
74
Chapter 4 − Menu Function
Tools
ERASING ALL PASSED EVENTS
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Calendar and
press the OK Key.
2. Scroll to the event and press the OK Key [VIEW].
3. Press the Right Soft Key [Options], scroll to Erase Passed and press
the OK Key, select Yes and press the OK Key.
ALARM CLOCK
The Alarm Clock tool allows you to set up to three alarms. When you set an
alarm, the current time is displayed at the top of the screen. When the alarm
goes off, Alarm 1 (or 2 or 3, as applicable) will be displayed on the LCD screen
and the alarm will sound.
SETTING THE ALARM
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Alarm Clock
and press the OK Key.
2. Scroll to Alarm 1, Alarm 2 or Alarm 3 and press the OK Key.
3. Scroll to Alarm and press the Directional Key left or right to turn
On or Off.
4. Scroll to Time and enter the time. Press the Left Soft Key for am/pm.
5. Scroll to Frequency and press the Directional Key left or right to
select either Once, Daily, Mon–Fri or Weekends.
6. Scroll to Ringer and press the Left Soft Key [Set]. Scroll to the ringer
and press the OK Key.
7. To save an alarm setting, press the OK Key [SAVE].
TURNING ON/OFF THE ALARM
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Alarm Clock
and press the OK Key.
2. Scroll to an Alarm 1, Alarm 2 or Alarm 3 and press the Right Soft
Key [Options].
3. Scroll to Turn On/Turn Off and press the OK Key.
Menu Function − Chapter 4
75
Tools
RESETTING THE ALARM
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Alarm Clock
and press the OK Key.
2. Scroll to an Alarm 1, Alarm 2 or Alarm 3 and press the Right Soft
Key [Options].
3. Scroll to Reset Alarm and press the OK Key. Scroll to Yes and press
the OK Key.
RESET ALL ALARM SETTINGS
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Alarm Clock
and press the OK Key.
2. Press the Right Soft Key [Options].
3. Scroll to Reset All and press the OK Key. Scroll to Yes and press the
OK Key.
STOP WATCH
Measures elapsed time for activities.
USING THE STOP WATCH
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Stop Watch
and press the OK Key.
2. Press the OK Key [START] to start.
3. Press the OK Key [STOP] to pause.
4. Press the Left Soft Key [Lap] to stop a time period and continue
measuring another one.
5. Press the Right Soft Key [Reset] to reset.
MEASURING MORE THEN ONE EVENT
1. Press the OK Key [START] to start.
2. Press the Left Soft Key [Lap] to stop a time period and continue
measuring another one.
3. Press the Left Soft Key [Lap] to stop the second and continue
measuring a third one.
76
Chapter 4 − Menu Function
Tools
4. Repeat the steps.
5. Press the OK Key [STOP] to pause.
6. Press the Left Soft Key [View] to review the results.
7. Press the OK Key to return to the stop watch.
You can measure up to 8 lap times.
WORLD CLOCK
To display the time and date in pre-programmed cities:
SETTING THE CLOCK
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to World Clock
and press the OK Key.
2. Press the Directional Key left or right to select the city.
3. Press the Left Soft Key [Cities] to access the CITIES LIST.
4. Scroll to the city and press the OK Key.
SETTING DST DAYLIGHT SAVING TIME
1. Press the Right Soft Key [DST] to set the DST options.
2. Scroll to City and press the Directional Key left or right to select
the city.
3. Scroll to DST and press the Directional Key left or right to turn
On or Off.
4. Scroll to Start Date and enter the start date.
5. Scroll to Start Time and enter the start time. Press the Left Soft Key
for am/pm.
6. Scroll to End Date and enter the end date.
7. Scroll to End Time and enter the end time. Press the Left Soft Key
for am/pm.
8. Press the OK Key [SAVE] to set.
Menu Function − Chapter 4
77
Tools
UNIT CONVERTER
This function converts any measurement into a unit you want. There are
5 types of units that can be converted: Length, Area, Volume, Weight and
Temperature.
USING THE UNIT CONVERTER
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Unit Converter
and press the OK Key.
2. Press the Directional Key left or right to select either either Length,
Area, Volume, Weight or Temperature.
3. Press the Directional Key up or down to select measure for the
quantity you want converted field.
4. In the same time when inputs a number the conversion price is
calculated in different all spaces and appears.
5. Press the Left Soft Key [Reset] to reset. Press the Right Soft Key [.] to
enter a decimal point.
NOTEPAD
Your phone includes an internal notepad that can be used to compose and
store reminders and notes.
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Notepad and
press the OK Key.
2. Press the Left Soft Key [New] to write a new note.
3. Enter the note.
4. Press the OK Key [SAVE].
VIEW SAVED MEMO
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Notepad and
press the OK Key.
2. Press the OK Key [VIEW] to view a selected note.
78
Chapter 4 − Menu Function
Tools
ERASE SAVED MEMO
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Notepad and
press the OK Key.
2. Scroll to select saved memo.
3. Press the Right Soft Key [Options], scroll to Erase and press the
OK Key.
4. Scroll to Yes and press the OK Key.
ERASE ALL SAVED MEMOS
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to Tools and press the OK Key, scroll to Notepad and
press the OK Key.
2. Scroll to select saved memo.
3. Press the Right Soft Key [Options], scroll to Erase All and press
the OK Key.
4. Scroll to Yes and press the OK Key.
MY VERIZON
To access your Verizon account information:
1. Press the OK Key [MENU], scroll to Settings & Tools and press the
OK Key, scroll to My Verizon and press the OK Key
Shortcut: In idle mode, press the Directional Key left to access
My Verizon.
2. Scroll to access the following options.
•
Balance: Information about your balance.
•
Usage: Information about your usage.
•
Payments: Information about your payments.
•
My Plan: Information about your plan.
•
My Features: Information about your service features.
•
Vmail Pswd: Resetting about your email password.
•
Find Store: Information about stores near you.
•
Gift Card: Information about gift card options.
•
FAQs: Frequently asked questions.
Menu Function − Chapter 4
79
My Verizon
