Paxton Access 690222 690-222-US Net2 Hands Free Keyfob User Manual
Paxton Access Ltd 690-222-US Net2 Hands Free Keyfob
User manual
Ins-30028-US Hands free keyfob for Net2
28/03/2007
Technical Support
Technical help is available: Monday - Friday from 5am - 5pm PST / 8am - 8pm EST
Other documentation on Net2 can be found on our web site - http://www.paxton-access.com/
1 800 672 PAXT support@paxton-access.co.uk
Suitability
Compatible with Net2Air readers Compatible with non Net2Air readers
Dimensions
Length 3 1/4 ”
Width 1 1/4 ”
Depth 1/2 ”
System Specications
Wake up frequency 125 kHz
Communications frequency 2.4 GHz
Operating temperature 0 °C - 50 °C (110 °F) (Battery Specication)
Typical battery life 5 years
Battery type 1 x CR2430
Read range with Net2Air Keycard
With button - all readers up to 50 yards
P38 3 feet
P50 4 feet
P75 5 feet
P200 8 feet
P200 metal mount 6 feet
Specications
Peel back the label on the back of the keyfob to reveal a screw. Open the case by inserting a at head screw driver
into the groove below the keyring loop and gently prise case open.
Remove the circuit board, taking care not to touch any components by handling only the edges of the board, then
remove the batteries by prising them out from the retainers. Replace the batteries, avoiding direct handling, then
replace the circuit board, casing, screw and label. Battery life is approximately 5 years.
Battery replacement
The token’s battery life is approximately 5 years
The keyfob has been designed with features to extend battery life, these include a two second timeout once access
has been granted and a capability to prevent repeated access to the same door whilst the keyfob remains in the
eld of the reader. Leaving the keyfob in the eld of a reader will reduce battery life.
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
