Paxton Access 6902M2 Net2 Hands Free Keyfob - mk2 User Manual INSTRUCTION Hands free keyfob for Net2
Paxton Access Ltd Net2 Hands Free Keyfob - mk2 INSTRUCTION Hands free keyfob for Net2
User Manual
Ins-30099-US Hands free keyfob for Net2
23/04/2009
Technical Support
Technical help is available: Monday - Friday from 12:00 AM - 5:00 PM (PST)
Saturday from 1:00 AM - 5:00 AM (PST)
1.800.672.PAXT support@paxton-access.com
Suitability
Compatible with Hands Free readers Compatible with non Hands Free readers
Documentation on all Paxton Access products can be found on our web site - http://www.paxton-access.com/
1 in
1/2 in
2 in
EM 4100 125 kHz
2.4 GHz
0 °C (32 °F) 55 °C (131 °F)
P38 3 ft
P50 4 ft
P75 5 ft
P200 8 ft
6 ft
16 ft
CR 2032
Specications
Carrier frequency
Operating temperature - Battery limits
Electrical
Environment
Dimensions
Min Max
Width
Height
Depth
P200E metal mount
Read range with Hands Free token
System Specication
Typical Battery Life
Battery Type
5 years
Token type
The term ‘Hands free access control’ means the token that
identies a user is read from within a pocket or handbag
- No hands required. This is useful for gates and barriers,
loading doors and where disabled or elderly people require
access. The hands free keyfobs, in conjunction with a
hands free interface, achieve this using unique Net2Air
wireless technology.
They also work in passive mode with all other Paxton
Access proximity readers. The tokens are enrolled onto the
Net2 system using the standard desktop reader.
Long range reader
Remove the small retaining screw. Insert a at head screw driver into the groove in the corner below the screw
position (see diagram) and gently twist to pry the case open.
Replace the battery, clip the cover closed and secure with the retaining screw.
Battery life is approximately 3 years.
Battery replacement
The token’s battery life is approximately 3 years
The keyfob has been designed with features to extend battery life. This includes the prevention of repeated
access requests to the same door while the keyfob remains in the eld of the reader. However, keeping the
keyfob in the eld of a reader will reduce battery life.
SAFETY WARNING
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Changes or modications not expressly approved by
the party responsible for compliance could void the user’s authority to operate the equipment.
We hereby declare that the Net2 Hands Free Keyfob mk2 FCC ID: USE6902M2 is a portable device which has a
maximum transmit power of 0.18 mW and is not subject to the routine RF exposure evaluation as per Section
2.1093 of the FCC rules.
