Lighting

LIGHTING

Corrosive elements. Combustible dusts.

Flammable gases and vapors. For proper

illumination in extreme conditions, you

need a company that pushes safety to

the extreme. Appleton has expanded

the boundaries of technology, efﬁ ciency

and performance to ensure your lighting

stays on – and safe. Because failure just

isn’t an option.

LIGHTING

Description Page

Enclosed and Gasketed — Area — HID

Mercmaster™ III Luminaires Family Tree 920

Mercmaster™ III Low Profile Luminaires 922

Mercmaster™ III HID 50—250 Watt Luminaires 941

Mercmaster™ III 400 Luminaire for Hazardous

and Wet Locations 976 MMIII Low Profile MMIII 50-250 MMIII 400

ATX LN Series Wellglass Luminaires 995

Mercmaster™ II HID Luminaires 1005

Mercmaster™ Jr. Luminaires 1021

Enclosed and Gasketed — Area — LED/Induction

Mercmaster™ LED Luminaires 1028

Mercmaster™ III Induction Luminaires 1037 LN Series MMII MM Jr.

Enclosed and Gasketed — Area — Fluorescent

Mercmaster™ III Low Profile Compact

Fluorescent Luminaires 1055

FV™ Series Nonmetallic Fluorescent Luminaires 1070

FR™ Enclosed and Gasketed; FZ™ and FD™

Hazardous Locations Luminaires 1075 MM LED MMIII Induction MMIII Low Profile

ATX FE Series Nonmetallic Fluorescent

Luminaires 1081

ATX FL Series Light Duty Nonmetallic

Fluorescent Luminaires 1095

ATX FN Series Heavy Duty Nonmetallic

Fluorescent Luminaires 1100

RigMaster™ Metallic Fluorescent Luminaires 1106 FV Series FR Series

RigMaster™ 304 Stainless Steel Fluorescent

Luminaires 1111 V

VRS™ and DRS™ Fluorescent Luminaires 1113

FL Series FN Series

Enclosed and Gasketed — Area — Recessed Fluorescent

RE Series Recessed Fluorescent Luminaires 1119

RigMaster™ Metallic RigMaster™ 304 Stainless Steel — V

VRS/DRS

Lighting Lighting

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

913

Lighting

Description Page

Enclosed and Gasketed — Area — Incandescent

Stylmaster™ Incandescent Luminaires 1126

V—51® Incandescent Luminaires 1135

REA™ 150 W Incandescent Luminaires 1147

Stylmaster V—51 REA

Enclosed and Gasketed — Floodlight

Areamaster™ 100 Wide—Beam Floodlights 1149

Areamaster™ 250/400 Integrally Ballasted

Floodlights 1155

Areamaster™ 1000 Floodlights 1162

ATX PN Series Floodlights – Zone 2, 21 and 22 1166

Corroflood™ 250/400 Stainless Steel Floodlights 1171 Areamaster 100 Areamaster 250/400 Areamaster 1000

Wallmaster I/2 for Hazardous and Wet Locations

— Class I, Division 2/Zone 2 1174 V

Enclosed and Gasketed — Visual Signal

TVA Obstruction, Approach and Boundary

Luminaires 1176 V

Stylmaster™ Strobe Luminaires 1180

PN Series Corroflood Wallmaster — V

Enclosed and Gasketed — Emergency

Mercmaster™ III Emergency Battery Pack 1184

N2LS™ Series Emergency Luminaires 1200

Explosionproof — Area — HID

Code•Master Jr.™ HID Factory Sealed

Luminaires 1205 TVA — VStylmaster Strobe MMIII Emergency

Battery Pack

N2LS

Code•Master 2™ HID Factory Sealed Luminaires 1216

Explosionproof — Area — Induction

Code•Master 2™ Induction Lighting System 1231

Code•Master Jr Code•Master 2™ Code•Master 2 Induction

Lighting

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

914

Lighting

Description Page

Explosionproof — Area — Fluorescent

Code•Master™ PLT Factory Sealed Luminaires 1240

APL Two and Four Lamp Fluorescent Factory

Sealed Luminaires 1252

EFU Fluorescent Factory Sealed Luminaires 1256

PAPL Portable Two and Four Lamp Fluorescent

Factory Sealed Luminaire 1260 Code•Master PLT APL EFU

ATX FD Series Cylindrical Fluorescent

Luminaires 1262

Explosionproof — Area — Incandescent

Code•Master™ Incandescent Factory Sealed

Luminaires 1269 PAPL FD Series

A—51® Incandescent Factory Sealed Luminaires 1274

EDT Incandescent Luminaires 1288

Explosionproof — Floodlight

Code•Master 2™ HID Factory Sealed Floodlights 1289

EFL Series HID and Quartz Floodlights 1297 VCode•Master A-51 EDT

PB, PC & PL Series 1300

Explosionproof Floodlights 1306

Explosionproof — Visual Signal

Code•Master™ Factory Sealed Strobe

Luminaires 1308

Explosionproof — Portable Code•Master 2 EFL/PB/PC/PL Explosionproof

TCH Series Safety Flashlights 1314

AHL and EHL Incandescent Factory Sealed

Luminaires and Handlamps 1316

Code•Master Strobe TCH Series AHL

Lighting Lighting

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

915

Description Page

Explosionproof — Emergency

Code•Master 2™ Emergency PLT Factory

Sealed Luminaires 1318

ELS Series Emergency Lighting System 1327

Increased Safety/Flameproof — Bulkhead

ATX HBE Series Round Bulkhead Luminaires 1133 Code•Master 2 Emergency PLT ELS Series

ATX HBD Series Bulkhead Luminaires 1336

ATX HBN Series Round Bulkhead Luminaires 1341

ATX HBDC Series Cylindrical Bulkhead

Luminaires 1344

General Lighting — Area — High Bay HBE/HBN Series HBD Series HBDC Series

Baymaster 250/400™ High Bay Luminaires 1347

Baymaster Prismatic 250/400™ High Bay

Luminaires 1353

Super-Baymaster High Bay Luminaires 1358 V

Baymaster 1000™ High Bay Luminaires 1361

General Lighting — Area — Low Bay

Lumenmaster 250™ Low Bay HID Prismatic

Luminaires 1365 Baymaster

250/400

Baymaster

Prismatic 250/400

Super-

Baymaster — VBaymaster 1000

Lumenmaster 400™ Low Bay HID Prismatic

Luminaires 1370

General Lighting — Area — Floodlights

Quartzlite™ 50 Floodlight 1375

Quartzlite™ 500/1500 Floodlight 1376

Areamaster Jr.™ HID Wide-Beam Floodlights 1379 Lumenmaster 250 Lumenmaster 400

Beam-Master™ Floodlights 1383

Quartzlite 50/500 Areamaster Jr Beam-Master

Lighting

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

916

Lighting

Description Page

General Lighting — Area — Architectural

Wallmaster™ HPS/PSMH Luminaires 1386

Wallmaster™ 400 HPS/PSMH Luminaires 1390

Areamaster Squarelite™ 400 Sharp Cutoff

Luminaires 1395

Wallmaster Wallmaster 400 Areamaster Squarelite

General Lighting — Area — Poles and Hangers

Round Tapered Steel Poles 1499

Hinged Steel Poles 1400

Square Tapered Steel Poles 1401

Square Steel Poles 1402

Floodlight Mounting Brackets 1403 UNJ AL

Flexible Fixture Hangers — Ordinary Location

AHG and UNJ Flexible Fixture Hangers 1407

AL Ball and Cushion Flexible Fixture Hangers 1408 Mounting Poles JB SSH

JB and GS Flexible Fixture Hangers 1412

SSH Flexible Fixture Hangers 1414

SHC Flexible Fixture Hangers 1416

Flexible Fixture Hangers — Hook and Loop 1417

Flexible Fixture Hangers — Receptacle and

Hook and Loop 1420 SHC Hook and Loop Receptacle and

Hook and Loop Power Hook — V

Power Hook for Industrial High Bay Luminaires 1421 V

Flexible Fixture Hangers — Explosionproof

BKX Rigid Fixture Hangers 1422 V

CPU and EFHU Fixture Hangers 1424 BKX CPU ESD

Flexible Fixture Hangers, EXJF Couplings, ESD

and ESS Swivels 1427

EFHC and EFHCA Fixture Hangers and

Accessories 1430

GRF Conduit Outlet Boxes and Fixture Hanger

Covers and Canopies 1432

EFHC GRF Bracket

Fixture Hanger Bracket and Accessories 1434

Lighting Lighting

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

917

Description Page

McGill Temporary

HID Temporary Lighting 1436

String-O-Lights 1437

7000 Series Industrial Extension Lights 1439

7000-38 Series Industrial Extension Lights 1442

6000 Series Commercial-Duty Extension Lights 1443

5000 Series Industrial Extension Lights 1444 HID Temp String-O-Lights 7000/6000/5000

Extension Lights

Industrial Extension Lights 1446

Handy Compact Fluorescent Work Light 1447

Rough Service Fluorescent Lamp 1448

Fluorescent Work Lights 1449

Battery Pack with Charger 1450

Fluorescent Industrial Extension Lights 1451

High Intensity Low-Voltage Extension Lights 1452

Mini-Powerpak Low-Voltage Extension Lights 1453 Handy Compact Rough Service Fluorescent Work

Fluorescent Hand Lamps — Explosionproof 1454

Tubular Fluorescent Inspection Light —

Explosionproof 1455

Industrial Extension Lights — Explosionproof 1456

Low-Voltage, High Intensity Hand Lamp —

Explosionproof 1457

Battery Pack Industrial Extension

Lights

High Intensity

Mini-Powerpak Hand Lamp Tubular Inspection Light

Industrial Extension Lights Low-Voltage,

High Intensity Hand Lamp

Lighting

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

918

Description Page

McGill General

Incandescent Utility Lights 1458

Fluorescent Utility Lights 1460

McGill Lamp Protection

Protect-O-Sleeves 1461 Utility Lights Protect-O-Sleeves Protect-O-Tubes

Protect-O-Tubes 1463

Tubeloc Holders 1464

Protect-O-Globes 1465

Wire Lamp Guards and Wire Lamp Guard

Grounding Kit 1466

Tubeloc Holders Protect-O-Globes Wire Lamp Guard

McGill Lamp Changers

Fluorescent Lamp Changers 1467

Incandescent Lamp Changers 1468

Lamp Changer Accessories and Replacement

Parts 1470

Lamp Changers

Lighting

Lighting Lighting

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

919

Cone

Pendant Mount

KPCH75

KPCH100

Ceiling Mount

KPC75

KPC100

Pendant Mount

KPA75

KPA100

90° Stanchion Mount

KPST125

KPST150

Wall Mount

KPWB75

KPWB100

25° Stanchion Mount

KPS125

KPS150

Flexible

Pendant Mount

KPAF75

KPAF100

Standard Dome

KR2-ST

Deep Dome

KR2-DD

Standard Dome

KR2-ST

Deep Dome

KR2-DD

Standard Dome

CMR-4ST *

Deep Dome

CMR-4DD *

Standard Dome

CMR-4ST *

Deep Dome

CMR-4DD *

Standard Dome

CMR-4ST*

16” Lens

Enclosed Reflector

KPR-4HB

Metal Halide

100W Max

Lamp Extender

30° Angle

KR2-AN

30° Angle

KR2-AN

KGU2

Fluorescent

Globe Guard

KGU2

Globe Guard

KRG2

Refractor Guard

KPGU400

Globe Guard

KPBG-12

12” Wire Guard GHB7000-NG

16” Wire Guard

KRG2

Refractor Guard

Three-Way Exit Sign

CJEXRN

KGU1

HID

GlobeGuard

KRG2

Refractor Guard

30° Angle

CMR-4AN

30° Angle

CMR-4AN 30° Angle

CMR-4AN

POLYMERIC

REFRACTORS

NEMA 2 LPRF-2CP

NEMA 3 LPRF-3CP

NEMA 4 LPRF-4CP

NEMA 5 LPRF-5CP

GLASS REFRACTORS

NEMA 1 LPG-R1

NEMA 3 LPG-R3

NEMA 5 LPG-R5

GLASS REFRACTORS

NEMA 1 LPG-R1

NEMA 3 LPG-R3

NEMA 5 LPG-R5

GLASS GLOBE

Clear VPGL-3HR

(for 100 W HPS only)

GLASS REFRACTORS

NEMA 2 KPRF-400-2

NEMA 3 KPRF-400-5

HID GLASS GLOBE

Clear VPGL-1HR

Amber VPGL-1AM

Blue VPGL-1BL

Green VPGL-1GR

Red VPGL-1RE

GLASS GLOBE

Fluorescent

Clear VPGL-2HR

Amber VPGL-2AM

Blue VPGL-2BL

Green VPGL-2GR

Red VPGL-2RE

GLASS GLOBE

Clear VPGL-2HR

Amber VPGL-2AM

Blue VPGL-2BL

Green VPGL-2GR

Red VPGL-2RE

GLASS GLOBE

Clear VPGL-4HR

5.50"/

139.7mm 5.50"/

139.7mm

7.75"/

196.9mm

7.75"/

196.9mm

7.75"/

196.9mm

• Fluorescent

• Metal Halide

100W Max.

(Lamp Extender

not required)

9.25"/

235.0 mm

5.63"/

143.0mm

6.75"/171.5mm

8.00"/

203.2mm

8.50"/

215.9mm

5.75"/146.1mm

DIA.

6.63”/

168.4mm

13.25"/336.6mm

11.38"/

289.1mm

5.69”/

144.5mm

EXIT

KPB SERIES

50 W-150 W HPS

100 W, 175 W,

200 W

, 250 W PSMH (KPBG)

Mogul Base

KPBR SERIES

50 W-150 W HPS

100 W, 175 W,

200 W, 250 W PSMH

Mogul Base

KPB400 SERIES

250 W-400 W HPS

250 W, 320 W, PSMH

350 W, 400 W PSMH

Mogul Base

MLBR SERIES

50 W-150 W HPS

50 W-175 W PSMH

Med. Base

26-84 W Fluorescent

MLBG SERIES

50 W-150 W HPS

50 W-175 W PSMH

Med. Base

26-84 W Fluorescent

POLYMERIC

REFRACTORS

NEMA 2 LPRF-2CP

NEMA 3 LPRF-3CP

NEMA 4 LPRF-4CP

NEMA 5 LPRF-5CP

* Standard and deep dome reflectors may interfere with bottom conduit entry if used with KPST and KPWB mounting hoods.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

920

Mercmaster™ III Luminaires Family Tree

Cone

Pendant Mount

KPCH75

KPCH100

Ceiling Mount

KPC75

KPC100

Pendant Mount

KPA75

KPA100

90° Stanchion Mount

KPST125

KPST150

Wall Mount

KPWB75

KPWB100

25° Stanchion Mount

KPS125

KPS150

Flexible

Pendant Mount

KPAF75

KPAF100

Standard Dome

KR2-ST

Deep Dome

KR2-DD

Standard Dome

KR2-ST

Deep Dome

KR2-DD

Standard Dome

CMR-4ST *

Deep Dome

CMR-4DD *

Standard Dome

CMR-4ST *

Deep Dome

CMR-4DD *

Standard Dome

CMR-4ST*

16” Lens

Enclosed Reflector

KPR-4HB

Metal Halide

100W Max

Lamp Extender

30° Angle

KR2-AN

30° Angle

KR2-AN

KGU2

Fluorescent

Globe Guard

KGU2

Globe Guard

KRG2

Refractor Guard

KPGU400

Globe Guard

KPBG-12

12” Wire Guard GHB7000-NG

16” Wire Guard

KRG2

Refractor Guard

Three-Way Exit Sign

CJEXRN

KGU1

HID

GlobeGuard

KRG2

Refractor Guard

30° Angle

CMR-4AN

30° Angle

CMR-4AN 30° Angle

CMR-4AN

POLYMERIC

REFRACTORS

NEMA 2 LPRF-2CP

NEMA 3 LPRF-3CP

NEMA 4 LPRF-4CP

NEMA 5 LPRF-5CP

GLASS REFRACTORS

NEMA 1 LPG-R1

NEMA 3 LPG-R3

NEMA 5 LPG-R5

GLASS REFRACTORS

NEMA 1 LPG-R1

NEMA 3 LPG-R3

NEMA 5 LPG-R5

GLASS GLOBE

Clear VPGL-3HR

(for 100 W HPS only)

GLASS REFRACTORS

NEMA 2 KPRF-400-2

NEMA 3 KPRF-400-5

HID GLASS GLOBE

Clear VPGL-1HR

Amber VPGL-1AM

Blue VPGL-1BL

Green VPGL-1GR

Red VPGL-1RE

GLASS GLOBE

Fluorescent

Clear VPGL-2HR

Amber VPGL-2AM

Blue VPGL-2BL

Green VPGL-2GR

Red VPGL-2RE

GLASS GLOBE

Clear VPGL-2HR

Amber VPGL-2AM

Blue VPGL-2BL

Green VPGL-2GR

Red VPGL-2RE

GLASS GLOBE

Clear VPGL-4HR

5.50"/

139.7mm 5.50"/

139.7mm

7.75"/

196.9mm

7.75"/

196.9mm

7.75"/

196.9mm

• Fluorescent

• Metal Halide

100W Max.

(Lamp Extender

not required)

9.25"/

235.0 mm

5.63"/

143.0mm

6.75"/171.5mm

8.00"/

203.2mm

8.50"/

215.9mm

5.75"/146.1mm

DIA.

6.63”/

168.4mm

13.25"/336.6mm

11.38"/

289.1mm

5.69”/

144.5mm

EXIT

KPB SERIES

50 W-150 W HPS

100 W, 175 W,

200 W, 250 W PSMH (

KPBG)

Mogul Base

KPBR SERIES

50 W-150 W HPS

100 W, 175 W,

200 W, 250 W PSMH

Mogul Base

KPB400 SERIES

250 W-400 W HPS

250 W, 320 W, PSMH

350 W, 400 W PSMH

Mogul Base

MLBR SERIES

50 W-150 W HPS

50 W-175 W PSMH

Med. Base

26-84 W Fluorescent

MLBG SERIES

50 W-150 W HPS

50 W-175 W PSMH

Med. Base

26-84 W Fluorescent

POLYMERIC

REFRACTORS

NEMA 2 LPRF-2CP

NEMA 3 LPRF-3CP

NEMA 4 LPRF-4CP

NEMA 5 LPRF-5CP

* Standard and deep dome reflectors may interfere with bottom conduit entry if used with KPST and KPWB mounting hoods.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

921

Mercmaster™ III Luminaires Family Tree

Applications

• Enclosedandgasketedxturessuitableforusein:

—Marineandwetlocations

—Awiderangeofindustrial,chemicalprocessingandother

areaswhereammablegasesandvaporsorcombustible

dustsarepresentunderconditionsdenedbytheNational

ElectricalCodeasClassI,Division2;ClassII,Division1and

2;andClassIII

—Areasoflowclearance,lowceilingheightsorwherexture

weightsmustbeminimized

—ForZone2,themethodofprotectionisAExnAnR–

RestrictedBreathing/NonsparkingorAExnR–Restricted

Breathing

—Non-hazardouslocationswheresevereweatherconditions,

excessivemoisture,dirt,dust,corrosiveatmosphereorhigh

ambienttemperaturesareencountered

• Typicalapplicationsinclude:

—Pulpandpapermills

—Processingplants

—Chemicalplants

—Oilreneries

—Foundries

—Manufacturingplants

—Storageareas

—Wasteandsewagetreatment

—Parkinggarages

—Otherareaswheredust,water,dirtandroughusagearea

problem

Features

• Compactlightweightlowproledesignissuitedforlow

mountingheightsinconjunctionwithlowerwattagextures.

• Modulardesignallowsscoresofxturecomponentcombinations

tomeetinstallationandlightingneeds.Usessamemounting

hoodsandopticalaccessoriesasMercmasterIII.

• Achoiceofheat-resistantprismaticglassrefractors(NEMAI,III

orV)orheat-resistantglobeswhichthreaddirectlyintoballast

housing.Photometricsavailableuponrequest–contactyour

localsalesrepresentative.

• Standarddomeor30°anglereectorsmadeofberglass

reinforcedwhitepolyester.Highlyresistanttocorrosive

atmospheres.

• Accommodatesmediumbaselamps.

• Awiderangeofvoltagesavailable(120to600Volt)andballast

types(Reactor,CWA,CWIandSuperCWA).

• Mediumbaselamptypeandwatts:

 —HPS50W-150W

 —PSMH50W-175W

• Hingehashighlipforaddedsafetyduringinstallation

andservicing.Hingeandboltconstructionassures360º

compressionatallpointsonballasthousinggasketforpositive

sealing.Swingawaydesignofcaptiveboltandnutsimplies

servicing.

• AllMercmasterIIImountinghoodshaveprovisionforeasyeld

installationoffusesinxtures(seefusekits).

• FixturesareforuseinClassI,Zone2hazardouslocations.

• TheAExnAnR/ExnR(V)factorysealedMercmasterIII

preventsvaporsandgasesfromenteringtheglobechamber.

Therearenosealsorputtyrequiredwhichwillreduce

installationtimeandinstallationerrors.

Standard Materials

• Mountinghoods,bodiesandguard:castcopperfree

(4/10of1%max.)aluminum

• Allhardwareandcatchassemblies:stainlesssteel

• Reectors:Fiberglassreinforcedwhitepolyester

• GlobesandRefractors:heat-resistantprismaticglass

Standard Finishes

• Mountinghoods,bodiesandguards:bakedgrayepoxy-clad

nish,electrostaticallyappliedforcompleteuniformprotection

Options

• QuartzAuxiliarycomestofullbrightnessimmediatelyand

remainslituntiltheHIDlampattains60-70%offullillumination.

QuartzAuxiliarysuppliedwithrelayswitchandsockettoaccept

120Vquartzdouble-contactbayonetbaselamp(notincluded).

Addsufx-E†.

• Guardswithgrayepoxypaintedtomatchxtures,suppliedwith

stainlesssteelscrews.Addsufx-Gbeforevoltagesufx.

• HotRestriketorestrikeHPSlampimmediatelywhenpoweris

restoredafteramomentarypowerinterruption.Addsufx-R.

• SmartStarterincorporatesa1-1/2minutetimerandperforms

asaconventionalstartertonormallystartlamp.Removes

itselffromcircuitiflampburnsoutorisremovedfromsocket.

Eliminatesstarterfailurescausedbyprolongedoperationwith

cyclingorfailinglampsandsimpliesndingtheirlocation,

reducingmaintenanceandrepaircosts.Availableforallxtures.

Addsufx-S.

• SmartHotRestrikewillimmediatelyrestrikeHPSlampwhen

powerisrestoredafteramomentarypowerinterruption.The

smartfunctionremovesthehotrestrikeignitorfromthecircuit

ifthelampburnsoutorisremovedfromthesocket.Eliminates

starterfailurescausedbyprolongedoperationwithcyclingor

failinglamps.Addsufx-SR.

• AExnAnRxtures,addsufx-Z2.

• AExnRxtures,addsufx-ZB.

• ExnRxtures,addsufx-Z V.

• Reectorsareavailableasstandarddomeand30°angle

polyester.Orderseparately.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Low Profile Mercmaster III with Prismatic Globe and Guard

† Fixtures equipped with quartz auxiliary lamp do not comply with NEC/CEC V requirements and are not suitable for use in classified locations.

V CSA Certification Only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

922

Mercmaster™ III Low Profile Luminaires

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Orderusingcatalognumberingguidebeloworselectcatalognumberfromtablesonfollowingpages.

Catalog Numbering Guide

ML A L 15 2 G1 G MT R Z2

Series:

ML-

MercmasterIII

LowProfile

LampType:

I-Incandescent

L-HighPressure

 Sodium

HorP-PulseStart

MetalHalide

H-175WMetal

Halide(available

withTTvoltage

only)V

HubSize:

2-3/4”NPT

3-1”NPT

4-1-1/4”NPT

stanchion

5-1-1/2”NPT

stanchion

GuardOptions:

G-CastGuard

N-NoGuard

Options:

E-EmergencyQuartz➎

F-FuseKit(Specify

Voltage)➏

R-HotRestrike➌

S-SmartStarter➍

SR-SmartHot

Restrike➌

H1-Photocontrol120V

H2-Photocontrol208V

H3-Photocontrol240V

H4-Photocontrol277V

C-SafetyCable

AdaptedV

D-E-27ExportSocket

T-TerminalBlocksV

V-Anti-Vibration

ModificationsV

X-Appledapter➐

MountingHood

AdapterV

Mounting:

A-Pendant(rigid

mounting)

C-Ceiling

D-PendantConeHood

F-Pendant(flexible

mounting)

R-90°Stanchion

S-25°Stanchion

W -Wall

Wattage:

10-100WHPS,PSMH

15-150WHPS,PSMH

and60-150Wmax.

Incandescent

17-175WPSMH

17-175WMHV

50-50WHPS,PSMH

70-70WHPS,PSMH

OpticalAssembly:➋

G1-Globe

J1-NEMAIGlass

Refractor

J3-NEMAIIIGlass

Refractor

J5-NEMAVGlass

Refractor

P2-NEMAIIPolymeric

Refractor

P3-NEMAIIIPolymeric

Refractor

P4-NEMAIVPolymeric

Refractor

P5-NEMAVPolymeric

Refractor

Voltage:➊

LB-Incandescent,120,

60Hz

MT-120/208/240/277,

60Hz

5MT-120/208/240/

277/480,60Hz

48-480,60Hz

125-120,50Hz

225-225,50Hz

226-220,60Hz

245-240,50Hz

C2-208,60Hz,CWIV

C3-240,60Hz,CWIV

C6-480,60Hz,CWIV

C7-600,60Hz,CWIV

TT-120/277/347,60Hz,

CWAV

Suffix:

Z2-Zone2suffix

(requiredfor

AExnAnR

rating)

ZB-Zone2suffix

(requiredfor

AExnR)

Z-Zone2suffix

(requiredfor

ExnR)V

* Compliance data varies for specific fixtures. Consult Appleton regarding suitability of specific fixtures for a particular application.

➊ Other voltages, frequencies available – contact your local sales representative. Voltages shown are limited to specific combinations; refer to following pages.

➋ Polymeric Refractor suitable for Class II, Groups F and G, NEMA 4X and Marine Type Electric Fixtures Outside Type (Salt Water) only (100 W PSMH Max.).

Reflectors ordered separately.

➌ Available for 50-150 W HPS fixtures only.

➍ Available for HPS or PSMH fixtures.

➎ Not suitable for hazardous location per NEC/CEC V.

➏ Canadian Electrical Code does NOT allow fusing in hazardous locations V.

➐ Appledapter is available for use with the pendant, ceiling and angled stanchion mounting only.

V CSA Certification Only.

Certifications and Compliances *

• ULListed:60079-15

• ULStandard:1598A,UL844,MarineTypeElectricFixtures

OutsideType(SaltWater)

• CSACertied:LR25428

Related Products

• Photocellsforclassieduseareavailable,seePCD2 Series.

Mercmaster™ III Low Profile Luminaires

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

923

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Mercmaster™ III Low Profile Luminaires

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

V CSA Certification Only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

924

Illustrated Features

Vented Reflectors

Reflectorsarethick,toughfiberglass-

reinforcedwhitepolyester,ventedfor

cooleroperation.Quicklyattachwith

furnishedstainlesssteelscrews. Ballast Assembly

Utilizingnon-sparkingcomponents

avoidingtheignitionofgasesorvapors

thatmaybepresent(nA).

Mounting Hood and Globe Gaskets

Siliconerubbergasketssealsout

moisture,dirtanddust.Staysflexible,

withstandshightemperatures.Closure

designassuresuniformgasket

compression.

Terminal Blocks (Zone 2)

Aseven-pointterminalblockisprovided

tofacilitatewiring.Terminalblock

accommodateswiresizerangingfrom#8

to#24AWG.

High Temperature Sockets

Mediumbasehigh-temperatureporcelain

sockets.

Aluminum Inner Reflector

Solidaluminuminnerreflector(for

refractorballasthousingsonly)improves

photometricefficiency.

Globe Chamber

Completelysealedfromtheballast

housingandoutsidevapors/air(nR).

Electrical Protection

Groundwireprovidedtobondmounting

hoodtoballasthousing.

Stainless Steel Inserts

Ballastbodieshavestainlesssteel

threadedinsertstoreceivestainlesssteel

screwsforreflectorsandguard.Prevents

"freezing”,allowingguardsandreflectors

tobeeasilyremovedandreplacedatany

time,withoutdamagetothehousing.

Epoxy Finish

Ballasthousing,hoodsandguardsare

copperfreealuminumwithepoxypowder

coatfinish.

Prismatic Glass Globes and Refractors

Heat-resistantglobesandrefractors

threaddirectlyintoballasthousingand

sealagainstahigh-temperature

siliconerubbergasket.

Cooler Operating Cone Hood

Largerslopedsurfaceshedsdusts,dirt

andcombustiblefibersprovidingbetter

heatdissipation.

Fuses

Twoscrewssecurefusekittomounting

bossinanyMercmastermountinghood.

Fuseincluded.

"Safety" High

Hinge

Extra-highhinge

providesadditional

protectionagainst

accidental

ballasthousing

disengagement

duringinstallationor

maintenance.

Stainless Steel

Latch Assembly

Captive,stainless

steellatch

assemblybolt

andnutcloses

securely,resists

attackofcorrosive

atmospheres.

Swing-awaydesign

simplifiesservicing.

Photocell

Availableforallfixturesexceptconeand

ceilingmount.Installsthroughknock-out

inmountinghood.Providescontinuous

ON-OFFdusk-to-dawncontrol.

Lamp Supply

Wire

Temp.

(°F/°C)

Ambient

Temp.

(°F/°C)

Class I, Division 2

Class II, Division 1

Groups E, F and G

Simultaneous Exposure

Class I, Division 2 / Class II, Division 1

Watts Type Globe

Globe &

Reflector Refractor Globe

Globe &

Reflector Refractor Globe

Globe &

Reflector Refractor

50 HPS

194/90 104/40 T3 T3 T3B T4A T4A T5 T3 T3 T3

194/90 131/55 T3 T3 T3A T4A T4A T4A T2D T2D T2D

194/90 149/65 T3 T3 T3A T4 T4 T4A T2C T2C T2C

70 HPS

194/90 104/40 T3 T3 T3 T4 T4 T5 T2B T2B T2D

194/90 131/55 T2D T2D T3 T3C T3C T4A T2B T2B T2C

194/90 149/65 — — T3 — — T4 — — T2B

100 HPS

194/90 104/40 T2C T2C T2D T4 T4 T4A T2B T2B T2B

194/90 131/55 T2B T2B T2C T3C T3C T4 T2A T2A T2A

194/90 149/65 — — — — — — — — —

150 HPS 194/90 104/40 T2A T2A T2B T3A * —T4 325 —T2

50 PSMH

194/90 104/40 T3 T3 T3A T4A T4A T6 T2D T2D T3

194/90 131/55 T3 T3 T3 T4 T4 T5 T2C T2C T2D

194/90 149/65 T3 T3 T3 T4 T4 T4A T2B T2B T2D

70 PSMH

194/90 104/40 T3 T3 T3 T3C T3C T4A T2B T2B T2C

194/90 131/55 T2D T2D T3 T3C T3C T4A T2A T2A T2B

230/110 149/65 — — T3 — — T4 — — T2B

100 PSMH 194/90 104/40 T2A T2A T2B T3B T3B T4A T2 T2 T2A

194/90 131/55 T2A T2A T2B T3A * T3A * T4 T1 T1 T2

150 PSMH 230/110 104/40 350 350 325 — — T3B — — T1

175 PSMH 230/110 104/40 350 350 325 — — T3B — — T1

175 MHV230/110 104/40 — — 325 — — T3B — — —

60 Inc.

194/90 104/40 T3B T3B T3C — — — — — —

194/90 131/55 T3A T3A T3C — — — — — —

194/90 149/65 T3A T3A T3C — — — — — —

100 Inc.

194/90 104/40 T3 T3 T3 — — — — — —

194/90 131/55 T3 T3 T3 — — — — — —

194/90 149/65 T2D T2D T3 — — — — — —

150 Inc.

194/90 104/40 T2D T2D T3 — — — — — —

194/90 131/55 T2B T2B T2D — — — — — —

194/90 149/65 T2B T2B T2D — — — — — —

“T” Numbers Represent the Maximum Lamp Temperature for Class I, Division 2 Locations and

Maximum Surface Temperature Under Dust Blanket for Class II, Division 1 Locations.

“T” # T1 350 325 T2 T2A T2B T2C T2D T3 T3A T3B T3C T4 T4A T5 T6

Temp.

Range

(˚ºF)

664-

842

619-

662

574-

617

538-

572

502-

536

448-

500

421-

446

394-

419

358-

392

331-

356

322-

329

277-

320

250-

275

214-

248

187-

212 185

Temp.

Range

(°C)

351-

450

326-

350

301-

325

281-

300

261-

280

231-

260

216-

230

201-

215

181-

200

166-

180

161-

165

136-

160

121-

135

101-

120

86-

100 85

* “T” numbers are for Groups E and F only.

V CSA Certification only.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

925

Mercmaster™ III Low Profile Luminaire Thermal Performance

Class I, Division 2; Class II, Division 1; Simultaneous exposure to hazardous conditions in both classifications

Temperature identification numbers of Mercmaster III Low Profile High Pressure Sodium and Pulse Start Metal Halide

Lamp

Supply Wire

Temp. (°F/°C)

Ambient

Temp. (°F/°C)

Class I, Zone 2 AEx nA nR IIC / Ex nR IIC Class I, Zone 2 AEx nR IIC

Watts Type Globe

Globe w/

Reflector Refractor Globe

Globe w/

Reflector Refractor

50 HPS

194/90 104/40 T6 T6 T6 T6 T6 T6

194/90 131/55 T5 T5 T5 T5 T5 T5

194/90 149/65 T4 T4 T5 T4 T4 T5

70 HPS

194/90 104/40 T5 T5 T5 T5 T5 T5

194/90 131/55 T4 T4 T4 T4 T4 T4

194/90 149/65 — — T4 — — T4

100 HPS 194/90 104/40 T4 T4 T4 T4 T4 T4

194/90 131/55 T4 T4 T4 T4 T4 T4

150 HPS 194/90 104/40 T4 T4 T4 T4 T4 T4

50 PSMH

194/90 104/40 T5 T5 T6 T5 T5 T6

194/90 131/55 T5 T5 T6 T5 T5 T6

194/90 149/65 T4 T4 T5 T4 T4 T5

70 PSMH

194/90 104/40 T5 T5 T6 T5 T5 T6

194/90 131/55 T4 T4 T6 T4 T4 T6

230/110 149/65 — — T4 — — T4

100 PSMH 194/90 104/40 T4 T4 T6 T4 T4 T6

194/90 131/55 T4 T4 T4 T4 T4 T4

150 PSMH 221/105 104/40 T3 T3 T4 T3 T3 T4

175 PSMH 221/105 104/40 T3 T3 T4 T3 T3 T4

175 MHV230/110 104/40 — — T3 ———

“T” Numbers represent the maximum surface temperature for luminaries with AEx nA nR, Ex nR and AEx nR rating:

The “T” number is established by separately determining the maximum temperature of the globe surface and ballast compartment. The hotter of the two is taken

to determine the “T” number for the overall fixture.

“T” Number T1 T2 T3 T4 T5 T6

Temp. Range (°F) 547-842 394-572 277-392 214-275 187-212 185

Temp. Range (°C) 301-450 201-300 136-200 101-135 86-100 85

V CSA Certification Only.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

926

Mercmaster™ III Low Profile Luminaire Thermal Performance

Class I, Zone 2, AEx nA nR IIC, AEx nR IIC IP66, NEMA 4X

Temperature identification numbers of Mercmaster III Zone 2 Low Profile High Pressure Sodium and Pulse Start Metal Halide.

Lamp Type Lamp Watts

Hub Size

(Inches)

Catalog Numbers ➌➍➎➏

With Globe With Type V 8” Refractor ➋

Pendant — One Hub, Rigid Mounting 

Shown with Globe and Optional Guard

HPS 50 3/4 MLAL502G1N MLAL502J5N

1MLAL503G1N MLAL503J5N

HPS 70 3/4 MLAL702G1N MLAL702J5N

1MLAL703G1N MLAL703J5N

HPS 100 3/4 MLAL102G1N MLAL102J5N

1MLAL103G1N MLAL103J5N

HPS 150 3/4 MLAL152G1N ➐MLAL152J5N ➐

1MLAL153G1N ➐MLAL153J5N ➐

Pendant Cone — One Hub, Rigid Mounting

Shown with Refractor

HPS 50 3/4 MLDL502G1N MLDL502J5N

1MLDL503G1N MLDL503J5N

HPS 70 3/4 MLDL702G1N MLDL702J5N

1MLDL703G1N MLDL703J5N

HPS 100 3/4 MLDL102G1N MLDL102J5N

1MLDL103G1N MLDL103J5N

HPS 150 3/4 MLDL152G1N ➐MLDL152J5N ➐

1MLDL153G1N ➐MLDL153J5N ➐

Ceiling — Five Hubs, Four Close-up Plugs

Shown with Globe

HPS 50 3/4 MLCL502G1N MLCL502J5N

1MLCL503G1N MLCL503J5N

HPS 70 3/4 MLCL702G1N MLCL702J5N

1MLCL703G1N MLCL703J5N

HPS 100 3/4 MLCL102G1N MLCL102J5N

1MLCL103G1N MLCL103J5N

HPS 150 3/4 MLCL152G1N ➐MLCL152J5N ➐

1MLCL153G1N ➐MLCL153J5N ➐

➊ For Flexible Pendant Mount, change A to F in catalog number (except 50 W HPS).

➋ To order fixture with NEMA Type I or NEMA Type III refractor, change final digit 5 in catalog number to 1 or 3.

➌ For fixtures with guards, substitute a G for the N before adding voltage suffix. See following pages for accessory ordering information.

➍ AddthefollowingvoltageandfrequencydesignationbeforeZ2suffix:

Lamp Type Lamp Watts

Voltage Suffixes

LB MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

Inc. 150 Max. X — — — — — — — — — — — — —

HPS 50 — X — — — X X — X — — — — X

HPS 70 — X — X X X X — X — — — — X

HPS 100 — X — X X X X — X — — — — X

HPS 150 — X — X X X X — X X X X X X

PSMH 50 — X — X — — — — — — — — — X

PSMH 70 — X — X X X — — X — — — — X

PSMH 100 — X — X X X — — X — — — — X

PSMH 150 — X — X — — — — X — — — — X

PSMH 175 — X X X — — — — X — — — — X

MH V175 — X — — — — — — — X X X X X

Voltages:

LB - Incandescent, 120 V 60 Hz

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➎ Add Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add ZB suffix for restricted breathing protection (AEx nR).

➏ Add Z for factory sealed restricted breathing protection (Ex nR) V.

➐ For 150 W HPS xtures, use S-55 lamp type only.

V CSA Certification Only.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

927

Mercmaster™ III Low Profile Luminaires

50 W – 150 W HPS

High Power Factor (min. P.F. 90%). Medium base lamps.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lamp Type Lamp Watts

Hub Size

(Inches)

Catalog Numbers ➌➍➎➏

With Globe With Type V 8” Refractor ➋

Wall — Five Hubs, Four Close-Up Plugs

Shown with Refractor and Optional Guard

HPS 50 3/4 MLWL502G1N MLWL502J5N

1MLWL503G1N MLWL503J5N

HPS 70 3/4 MLWL702G1N MLWL702J5N

1MLWL703G1N MLWL703J5N

HPS 100 3/4 MLWL102G1N MLWL102J5N

1MLWL103G1N MLWL103J5N

HPS 150 3/4 MLWL152G1N ➐MLWL152J5N ➐

1MLWL153G1N ➐MLWL153J5N ➐

25° Stanchion — One Hub

Shown with Globe and Optional Guard

HPS 50 1-1/4 MLSL504G1N MLSL504J5N

1-1/2 MLSL505G1N MLSL505J5N

HPS 70 1-1/4 MLSL704G1N MLSL704J5N

1-1/2 MLSL705G1N MLSL705J5N

HPS 100 1-1/4 MLSL104G1N MLSL104J5N

1-1/2 MLSL105G1N MLSL105J5N

HPS 150 1-1/4 MLSL154G1N ➐MLSL154J5N ➐

1-1/2 MLSL155G1N ➐MLSL155J5N ➐

90° Stanchion — One Hub

Shown with Refractor and Optional Guard

HPS 50 1-1/4 MLRL504G1N MLRL504J5N

1-1/2 MLRL505G1N MLRL505J5N

HPS 70 1-1/4 MLRL704G1N MLRL704J5N

1-1/2 MLRL705G1N MLRL705J5N

HPS 100 1-1/4 MLRL104G1N MLRL104J5N

1-1/2 MLRL105G1N MLRL105J5N

HPS 150 1-1/4 MLRL154G1N ➐MLRL154J5N ➐

1-1/2 MLRL155G1N ➐MLRL155J5N ➐

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

➊ For Flexible Pendant Mount, change A to F in catalog number (except 50 W HPS).

➋ To order fixture with NEMA Type I or NEMA Type III refractor, change final digit 5 in catalog number to 1 or 3.

➌ For fixtures with guards, substitute a G for the N before adding voltage suffix. See following pages for accessory ordering information.

➍ AddthefollowingvoltageandfrequencydesignationbeforeZ2suffix:

Lamp Type Lamp Watts

Voltage Suffixes

LB MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

Inc. 150 Max. X — — — — — — — — — — — — —

HPS 50 — X — — — X X — X — — — — X

HPS 70 — X — X X X X — X — — — — X

HPS 100 — X — X X X X — X — — — — X

HPS 150 — X — X X X X — X X X X X X

PSMH 50 — X — X — — — — — — — — — X

PSMH 70 — X — X X X — — X — — — — X

PSMH 100 — X — X X X — — X — — — — X

PSMH 150 — X — X — — — — X — — — — X

PSMH 175 — X X X — — — — X — — — — X

MH V175 — X — — — — — — — X X X X X

Voltages:

LB - Incandescent, 120 V 60 Hz

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➎ Add Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add ZB suffix for restricted breathing protection (AEx nR).

➏ Add Z for factory sealed restricted breathing protection (Ex nR) V.

➐ For 150 W HPS xtures, use S-55 lamp type only.

V CSA Certification Only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

928

Mercmaster™ III Low Profile Luminaires

50 W – 150 W HPS

High Power Factor (min. P.F. 90%). Medium base lamps.

Lamp Type Lamp Watts

Hub Size

(Inches)

Catalog Numbers ➌➍➎➏

With Globe With Type V 8” Refractor ➋

Pendant — One Hub, Rigid Mounting 

Shown with Globe and Optional Guard

PSMH 50 3/4 MLAH502G1N MLAH502J5N

1MLAH503G1N MLAH503J5N

PSMH 70 3/4 MLAH702G1N MLAH702J5N

1MLAH703G1N MLAH703J5N

PSMH 100 3/4 MLAH102G1N MLAH102J5N

1MLAH103G1N MLAH103J5N

PSMH 150 3/4 MLAP152G1N MLAP152J5N

1MLAP153G1N MLAP153J5N

PSMH 175 3/4 MLAP172G1N MLAP172J5N

1MLAP173G1N MLAP173J5N

Pendant Cone — One Hub, Rigid Mounting

Shown with Refractor

PSMH 50 3/4 MLDH502G1N MLDH502J5N

1MLDH503G1N MLDH503J5N

PSMH 70 3/4 MLDH702G1N MLDH702J5N

1MLDH703G1N MLDH703J5N

PSMH 100 3/4 MLDH102G1N MLDH102J5N

1MLDH103G1N MLDH103J5N

PSMH 150 3/4 MLDP152G1N MLDP152J5N

1MLDP153G1N MLDP153J5N

PSMH 175 3/4 MLDP172G1N MLDP172J5N

1MLDP173G1N MLDP173J5N

Ceiling — Five Hubs, Four Close-up Plugs

Shown with Globe

PSMH 50 3/4 MLCH502G1N MLCH502J5N

1MLCH503G1N MLCH503J5N

PSMH 70 3/4 MLCH702G1N MLCH702J5N

1MLCH703G1N MLCH703J5N

PSMH 100 3/4 MLCH102G1N MLCH102J5N

1MLCH103G1N MLCH103J5N

PSMH 150 3/4 MLCP152G1N MLCP152J5N

1MLCP153G1N MLCP153J5N

PSMH 175 3/4 MLCP172G1N MLCP172J5N

1MLCP173G1N MLCP173J5N

➊ For Flexible Pendant Mount, change A to F in catalog number (except 50 W HPS).

➋ To order fixture with NEMA Type I or NEMA Type III refractor, change final digit 5 in catalog number to 1 or 3.

➌ For fixtures with guards, substitute a G for the N before adding voltage suffix. See following pages for accessory ordering information.

➍ AddthefollowingvoltageandfrequencydesignationbeforeZ2suffix:

Lamp Type Lamp Watts

Voltage Suffixes

LB MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

Inc. 150 Max. X — — — — — — — — — — — — —

HPS 50 — X — — — X X — X — — — — X

HPS 70 — X — X X X X — X — — — — X

HPS 100 — X — X X X X — X — — — — X

HPS 150 — X — X X X X — X X X X X X

PSMH 50 — X — X — — — — — — — — — X

PSMH 70 — X — X X X — — X — — — — X

PSMH 100 — X — X X X — — X — — — — X

PSMH 150 — X — X — — — — X — — — — X

PSMH 175 — X X X — — — — X — — — — X

MH V175 — X — — — — — — — X X X X X

Voltages:

LB - Incandescent, 120 V 60 Hz

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➎ Add Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add ZB suffix for restricted breathing protection (AEx nR).

➏ Add Z for factory sealed restricted breathing protection (Ex nR) V.

➐ For 150 W HPS xtures, use S-55 lamp type only.

V CSA Certification Only.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

929

Mercmaster™ III Low Profile Luminaires

50 W - 175 W PSMH

High Power Factor (min. P.F. 90%). Medium base lamps.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lamp Type Lamp Watts

Hub Size

(Inches)

Catalog Numbers ➌➍➎➏

With Globe With Type V 8” Refractor ➋

Wall — Five Hubs, Four Close-Up Plugs

Shown with Refractor and Optional Guard

PSMH 50 3/4 MLWH502G1N MLWH502J5N

1MLWH503G1N MLWH503J5N

PSMH 70 3/4 MLWH702G1N MLWH702J5N

1MLWH703G1N MLWH703J5N

PSMH 100 3/4 MLWH102G1N MLWH102J5N

1MLWH103G1N MLWH103J5N

PSMH 150 3/4 MLWP152G1N MLWP152J5N

1MLWP153G1N MLWP153J5N

PSMH 175 3/4 MLWP172G1N MLWP172J5N

1MLWP173G1N MLWP173J5N

25° Stanchion — One Hub

Shown with Globe and Optional Guard

PSMH 50 1-1/4 MLSH504G1N MLSH504J5N

1-1/2 MLSH505G1N MLSH505J5N

PSMH 70 1-1/4 MLSH704G1N MLSH704J5N

1-1/2 MLSH705G1N MLSH705J5N

PSMH 100 1-1/4 MLSH104G1N MLSH104J5N

1-1/2 MLSH105G1N MLSH105J5N

PSMH 150 1-1/4 MLSP154G1N MLSP154J5N

1-1/2 MLSP155G1N MLSP155J5N

PSMH 175 1-1/4 MLSP174G1N MLSP174J5N

1-1/2 MLSP175G1N MLSP175J5N

90° Stanchion — One Hub

Shown with Refractor and Optional Guard

PSMH 50 1-1/4 MLRH504G1N MLRH504J5N

1-1/2 MLRH505G1N MLRH505J5N

PSMH 70 1-1/4 MLRH704G1N MLRH704J5N

1-1/2 MLRH705G1N MLRH705J5N

PSMH 100 1-1/4 MLRH104G1N MLRH104J5N

1-1/2 MLRH105G1N MLRH105J5N

PSMH 150 1-1/4 MLRP154G1N MLRP154J5N

1-1/2 MLRP155G1N MLRP155J5N

PSMH 175 1-1/4 MLRP174G1N MLRP174J5N

1-1/2 MLRP175G1N MLRP175J5N

➊ For Flexible Pendant Mount, change A to F in catalog number (except 50 W HPS).

➋ To order fixture with NEMA Type I or NEMA Type III refractor, change final digit 5 in catalog number to 1 or 3.

➌ For fixtures with guards, substitute a G for the N before adding voltage suffix. See following pages for accessory ordering information.

➍ AddthefollowingvoltageandfrequencydesignationbeforeZ2suffix:

Lamp Type Lamp Watts

Voltage Suffixes

LB MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

Inc. 150 Max. X — — — — — — — — — — — — —

HPS 50 — X — — — X X — X — — — — X

HPS 70 — X — X X X X — X — — — — X

HPS 100 — X — X X X X — X — — — — X

HPS 150 — X — X X X X — X X X X X X

PSMH 50 — X — X — — — — — — — — — X

PSMH 70 — X — X X X — — X — — — — X

PSMH 100 — X — X X X — — X — — — — X

PSMH 150 — X — X — — — — X — — — — X

PSMH 175 — X X X — — — — X — — — — X

MH V175 — X — — — — — — — X X X X X

Voltages:

LB - Incandescent, 120 V 60 Hz

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➎ Add Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add ZB suffix for restricted breathing protection (AEx nR).

➏ Add Z for factory sealed restricted breathing protection (Ex nR) V.

➐ For 150 W HPS xtures, use S-55 lamp type only.

V CSA Certification Only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

930

Mercmaster™ III Low Profile Luminaires

50 W - 175 W PSMH

High Power Factor (min. P.F. 90%). Medium base lamps.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Mounting Hoods

Description Hub Size (Inches) Catalog Number

Pendant

OneHub,RigidMounting

3/4 KPA-75

1KPA-100

Pendant — Flexible

OneHub,FlexibleMounting

3/4 KPAF-75

1KPAF-100

Pendant Cone

OneHub,RigidorFlexibleMounting

3/4 KPCH-75

1KPCH-100

Ceiling

FiveHubs,FourClose-UpPlugs

3/4 KPC-75

1KPC-100

Wall

FiveHubs,FourClose-UpPlugs

3/4 KPWB-75

1KPWB-100

25° Stanchion

OneHub 1-1/4 KPS-125

1-1/2 KPS-150

90° Stanchion

OneHub 1-1/4 KPST-125

1-1/2 KPST-150

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

931

Mercmaster™ III Low Profile Luminaire Mounting Hoods

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Ballast Bodies

Ballast Body for Glass Refractor Ballast Body for Glass Globe or Polymeric Refractor

HighPressureSodium

HighPowerFactor(Min.P.F.90%)

PulseStartMetalHalide

SuperConstantWattageAutotransformer(Min.P.F.90%)

Lamp

Type

Lamp

Watts

Catalog Number ➍➎ Voltage Suffixes

For Globe For Refractor LB MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

Inc. 150Max. MLBG15I MLBR15I X —————————————

HPS 50 MLBG50L ➊➋ MLBR50L ➊➋ — X — — — X X — X — — — — X

HPS 70 MLBG70L ➊➋ MLBR70L ➊➋ — X — X X X X — X — — — — X

HPS 100 MLBG10L ➊➋ MLBR10L ➊➋ — X — X X X X — X — — — — X

HPS 150 MLBG15L ➊➋ MLBR15L ➊➋ —X—XXXX—XXXXXX

PSMH 50 MLBG50H ➋➌ MLBR50H ➋➌ — X — X ————————— X

PSMH 70 MLBG70H ➋➌ MLBR70H ➋➌ — X — X X X — — X — — — — X

PSMH 100 MLBG10H ➋➌ MLBR10H ➋➌ — X — X X X — — X — — — — X

PSMH 150 MLBG15P ➋➌ MLBR15P ➋➌ — X — X — — — — X — — — — X

PSMH 175 MLBG17P ➋➌ MLBR17P ➋➌ — X X X — — — — X — — — — X

MHV175 MLBG17H ➋ MLBR17H ➋ — X — — — — — — — X X X X X

Voltages:

LB-Incandescent,120V60Hz

MT-120/208/240/277V60Hz

5MT-120/208/240/277/480V60Hz

48-480V60Hz

125-120V50Hz

225-225V50Hz

226-220V60Hz

235-230V50Hz

245-240V50Hz

C2-208V60Hz,CWIV

C3-240V60Hz,CWIV

C6-480V60Hz,CWIV

C7-600V60Hz,CWIV,

TT-120/277/347V60Hz,CWAV

➊ After voltage suffix add: -S for Smart Starter, -SR for Smart Hot Restrike, -R for ballast body with Hot Restrike Ignitor.

➋ Add -E after voltage suffix for ballast body with provision for Quartz Emergency Light. Not suitable for hazardous locations.

➌ After voltage suffix add: -S for Smart Starter.

➍ Add Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add ZB suffix for restricted breathing protection (AEx nR).

➎ Add Z for factory sealed restricted breathing protection (Ex nR) V.

V CSA Certification Only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

932

Mercmaster™ III Low Profile Luminaire Ballast Bodies

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Description Catalog Number

Prismatic Glass Globes — Heat-Resistant

Glass Globe

Clear VPGL-1HR

Amber VPGL-1AM

Blue VPGL-1BL

Green VPGL-1GR

Red VPGL-1RE

Light Distribution IES/NEMA Distribution Curves Catalog Number

Closed Prismatic Glass Refractors — All Heat-Resistant

Glass Refractor

NEMATypeI LPG-R1

NEMATypeIII LPG-R3

NEMATypeV LPG-R5

Closed Prismatic Polymeric Refractors — For Use with PSMH Lamps

100 W max. 104 °F/40 °C max. ambient temperature. Suitable for Class II, Division 1 and 2, Groups F, G;

NEMA 4X, UL 1598A Marine Type Electric Fixtures Outside Type (Salt Water)

Polymeric Refractor

NEMATypeII LPRF-2CP

NEMATypeIII LPRF-3CP

NEMATypeIV LPRF-4CP

NEMATypeV LPRF-5CP

Description Catalog Number

White Polyester Reflectors — Furnished with stainless steel screws

ForGlobeFixtures

StandardDome KR2-ST

DeepDome KR2-DD ➊

30°Angle KR2-AN

ForGlassRefractorFixtures

StandardDome CMR-4ST ➋

DeepDome CMR-4DD ➊

Standard Dome 30° Angle 30°Angle CMR-4AN

Guards

GlobeGuard KGU1

RefractorGuard KRG2

Globe Guard Refractor Guard

Replacement Globe Gaskets — Silicone Rubber

GlobeGasket VPGL-GK

RefractorGasket KRF-GK

Globe Gaskets

➊ Dark Skies Compliant.

➋ Standard and deep dome reflectors may interfere with bottom conduit entry if used with KPST and KPWB mounting hoods.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

933

Mercmaster™ III Low Profile Luminaire Accessories and Replacement Parts

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Electrical Specifications

Line

Voltage

Type of

Ballast ➊

Starting

Amps

Operating

Amps

Total

Watts

50 Watt High Pressure Sodium

120 HX-HPF 0.58 0.58 64

208 HX-HPF 0.35 0.33 64

240 HX-HPF 0.31 0.29 64

277 HX-HPF 0.25 0.25 64

347VHX-HPF 0.26 0.21 68

70 Watt High Pressure Sodium

120 HX-HPF 0.90 0.82 94

208 HX-HPF 0.50 0.48 94

240 HX-HPF 0.44 0.41 94

277 HX-HPF 0.35 0.36 94

347VHX-HPF 0.30 0.30 94

480 HX-HPF 0.21 0.21 94

100 Watt High Pressure Sodium

120 HX-HPF 1.30 1.15 130

208 HX-HPF 0.76 0.67 130

240 HX-HPF 0.66 0.60 130

277 HX-HPF 0.60 0.52 130

347VHX-HPF 0.45 0.39 130

480 HX-HPF 0.33 0.31 135

480 C.W.I. 0.17 0.30 130

600 C.W.I. 0.14 0.24 130

150 Watt High Pressure Sodium ➋

120 HX-HPF 2.00 1.70 188

208 HX-HPF 1.15 0.95 188

240 HX-HPF 1.00 0.85 188

277 HX-HPF 0.85 0.72 188

347VHX-HPF 0.52 0.56 188

480 HX-HPF 0.50 0.47 189

480 C.W.I. 0.25 0.42 190

600 C.W.I. 0.19 0.35 190

50 Watt Pulse Start Metal Halide

120 HX-HPF 0.87 0.62 67

208 HX-HPF 0.51 0.40 67

240 HX-HPF 0.47 0.35 67

277 HX-HPF 0.32 0.32 67

347VHX-HPF 0.15 0.20 67

70 Watt Pulse Start Metal Halide

120 HX-HPF 0.80 0.85 95

208 HX-HPF 0.50 0.52 95

240 HX-HPF 0.43 0.44 95

277 HX-HPF 0.39 0.39 95

347VHX-HPF 0.20 0.28 88

480 HX-HPF 0.26 0.23 95

100 Watt Pulse Start Metal Halide

120 HX-HPF 1.20 1.15 130

208 HX-HPF 0.70 0.70 130

240 HX-HPF 0.61 0.58 130

277 HX-HPF 0.55 0.50 130

347VHX-HPF 0.40 0.40 129

480 HX-HPF 0.30 0.35 140

Electrical Specifications

Line

Voltage

Type of

Ballast ➊

Starting

Amps

Operating

Amps

Total

Watts

150 Watt Pulse Start Metal Halide

120 HX-HPF 1.75 1.60 188

208 HX-HPF 1.30 1.00 188

240 HX-HPF 0.85 0.80 188

277 HX-HPF 0.77 0.70 188

347VSuperC.W.A. 0.65 0.55 185

480 SuperC.W.A. 0.45 0.42 185

175 Watt Pulse Start Metal Halide

120 SuperC.W.A. 0.90 1.78 199

208 SuperC.W.A. 0.50 1.08 199

240 SuperC.W.A. 0.35 0.89 199

277 SuperC.W.A. 0.30 0.76 199

347VSuperC.W.A. 0.25 0.65 208

480 SuperC.W.A. 0.25 0.50 213

175 Watt Metal Halide V

120 C.W.A. 1.30 1.80 210

208 C.W.A. 0.75 1.04 210

240 C.W.A. 0.65 0.90 210

277 C.W.A. 0.55 0.80 210

347 C.W.A. 0.50 0.65 210

480 C.W.I. 0.20 0.45 215

600 C.W.I. 0.16 0.37 215

Fuse Kit for Field Installation

Lamp

Watts

Fuse Quantity

Required

Fuse Kit Catalog Number

Volts HPS PSMH

50W

120 1 F5 F3

208 2 F3 F3

240 2 F3 F2

277 1 F2 F2

347V1F1 F1

70W

120 1 F5 F4

208 2 F3 F3

240 2 F3 F3

277 1 F2 F2

347V1F1 F2

480 2 F2 F1

100W

120 1 F8 F6

208 2 F5 F4

240 2 F5 F3

277 1 F3 F3

347V1F1 F2

480 2 F3 F2

150W

120 1 F10 F10

208 2 F5 F5

240 2 F5 F5

277 1 F5 F4

347V1F2 F2

480 2 F3 F3

175W

120 1 —F5

208 2 —F3

240 2 —F3

277 1 —F2

347V1F2 F2

480 2 —F2

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

➊ C.W.A. – Constant Wattage Autotransformer. HX-HPF – High Reactance High Power Factor Autotransformer. Super C.W.A. – Super Constant Wattage Autotransformer.

➋ 150 W HPS units equipped with ballasts to operate 55 V lamps only.

V CSA Certification Only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

934

Mercmaster™ III Low Profile Luminaire Electrical Specifications and Fuse Kits

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Mercmaster III Low Profile Ballast and Accessory Weights ➊

Globe Housing Ballast (Wt. Lbs/Kg) Refractor Housing Ballast (Wt. Lbs/Kg) Mounting

Hoods

Wt.

Lbs/Kg

Refractors, Globes,

Guards and Reflectors

Wt.

Lbs/KgWatts HPS PSMH HPS PSMH

50 7.25/3.3 7.00/3.2 7.75/3.5 7.50/3.4 Pendant 2.25/1.0 8”GlassRefractor 5.25/2.4

70 8.25/3.7 7.75/3.5 8.75/4.0 8.25/3.7 PendantCone 2.50/1.1 GlassGlobe 3.75/1.7

100 9.75/4.4 9.25/4.2 10.25/4.6 9.75/4.4 Ceiling 3.00/1.4 RefractorGuard 1.00/0.5

150 10.75/4.9 10.75/4.9 11.25/5.1 11.25/5.1 Wall 4.00/1.8 GlobeGuard 1.00/0.5

175 —11.00/5.0 —11.50/5.2 25°Stanchion 3.25/1.5 StandardDome 2.50/1.1

90°Stanchion 3.75/1.7 DeepDome 5.00/2.3

30°Angle 2.50/1.1

PolymericRefractor 2.43/1.1

➊ Weights are approximate. Add 0.25 lbs/0.1 kg for Quartz option.

Pendant (Rigid or Flex) Pendant Cone Ceiling 25º Stanchion

12.06”/306.0 mm

1.17”/

30.0 mm

12.06”/306.0 mm

5.59”/

142.0 mm

12.06”/306.0 mm

13.62”/346.0 mm

1.75”/

45.0 mm

7.60”/

193.0 mm

12.05”/

306.0 mm

2.00”/

51.0 mm

15.28”/

388.0 mm

9.25”/

235.0 mm

Wall Mount 90º Stanchion

17.01”/

432.0 mm

10.94”/

278.0 mm

12.05”/

306.0 mm

3.38”/

85.8 mm

4.06”/

103.0 mm

(4) Mounting Holes

0.31”/8.0 mm

12.06”/306.0 mm

17.23”/438.0 mm

9.79”/249.0 mm

Globe or Polymeric Refractor Ballast

Housing

8" Glass Refractor Ballast Housing Standard Polyester Reflector 30º Angle Polyester Reflector

Globe, Guard and Refractors Refractor Body, Refractor and Guard Polymeric Refractor Deep Dome

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

935

Mercmaster™ III Low Profile Luminaire Dimensions and Weights

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Class I, Division 2, Groups A, B, C, D

NEMA 4X

PCD2 Series Factory Sealed Hazardous Location Photocontrol

For use in Class I, Division 2, Groups A, B, C, D locations

Maintains Class I, Division 2 rating for Mercmaster III – Low Profile, Mercmaster III, and Mercmaster III – 400 Series Luminaires, Mercmaster LED

Applications

• Encapsulatedphotocontrolprovidesautomaticdusk-to-dawn

lightingcontrolinClassI,Division2locations.

• Typicalapplicationsincludewalkways,securityareasandany

otheroutdoorlightingapplication.

• ForusewithMercmasterIII–LowProle,MercmasterIII,and

MercmasterIII–400SeriesLuminaires.

• ForremotemountinginFSBoxes.

Features

• Factorysealeddesigneliminatestheneedforanexplosionproof

enclosure.

• Canbeeasilyinstalledintheeld.

• Solidstatedesignforperformanceandreliability.

• Availablefor120,208,240,or277volts.

• 50-400WHID,incandescentoruorescent,50/60Hz.

• 1000V.A.Voltage/Ampere

• Minimumtimedelay:15secondstoeliminatenuisiancetripping.

• Providedwith(3)18AWGstrandedleads6”/152.4mminlength.

• Willtthroughstandard1/2”knockout.

Materials

• Encapsulatedwithepoxysealingcompound

• FS:aluminum

Certifications and Compliances

• ULStandard:1604–Hazardous(Classied)Locations

• cULusRecognized

Factory-Installed Photocontrol

Add to fixture catalog after voltage; i.e.: KPWBL1075MTH1.Dimensions

Voltage Range Suffix Designation

0.69”

17.5 mm

1.13”

28.7 mm

1.375”

34.9 mm

2.56”

65.0 mm

1.19”

30.2 mm 1.94”

49.2 mm

0.69”

17.5 mm

1.13”

28.7 mm

1.375”

34.9 mm

2.56”

65.0 mm

1.19”

30.2 mm 1.94”

49.2 mm

0.69”

17.5 mm

1.13”

28.7 mm

1.375”

34.9 mm

2.56”

65.0 mm

1.19”

30.2 mm 1.94”

49.2 mm

Mercmaster III wall mounting hood

with photocontrol installed shown

120V,50/60Hz H1

208V,50/60Hz H2

240V,50/60Hz H3

277V,50/60Hz H4

Photocontrol in FS Cover for Use with FS/FD Box

Supplied with two stainless steel screws. For neoprene gasket, order catalog number FS-GKR-1N.

Voltage Range Catalog Number

120V,50/60Hz FSKA-PC120D2

208-277V,50/60Hz FSKA-PC247D2

Photocontrol for Field Installation

Voltage Range Max. Current Catalog Number

120V,50/60Hz 8.3Amp PC120D2

208-277V,50/60Hz 3.5Amp PC247D2

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

936

Zone Lumens Total Luminaire Efficiency = 83%

REPORT NUMBER: ML15LG

0-10 28.58 CIE Type – Semi-Direct

10-20 123.97

Plane

Spacing

Criteria

Lamps: 150 W High Pressure Sodium with Globe only *

20-30 304.16

30-40 513.64 0-180 3.9 Coefficients of Utilization – Zonal Cavity Method

40-50 889.19 90-270 3.9 Effective Floor Cavity Reflectance 0.20

50-60 1299.53 Diagonal 3.7 % Ceiling Rcc 80 70 50 30 10 0

60-70 1506.73 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 1706.16 Zonal Lumen Summary 0 91 91 91 91 85 85 85 85 75 75 75 65 65 65 55 55 55 51

80-90 1800.53 Zone Lumens % Lamp % Fixture 1 77 71 66 61 72 66 61 57 57 53 49 48 45 42 40 37 35 31

90-100 1791.58 0-30 4563.72 2.9 3.4 2 68 59 51 45 63 55 48 42 46 41 36 39 34 31 32 28 25 21

100-110 1652.69 0-40 970.35 6.1 7.3 3 61 50 42 35 56 46 39 33 39 33 28 32 27 23 26 22 19 16

110-120 1311.22 0-60 3159.07 19.7 23.8 4 55 43 35 28 50 40 32 26 34 27 22 28 23 18 22 18 15 12

120-130 351.25 0-90 8172.49 51.1 61.5 5 50 38 29 23 46 35 27 21 29 23 18 24 19 15 19 15 12 9

130-140 5.14 90-120 4755.49 29.7 35.8 6 46 33 25 19 42 31 23 18 26 20 15 21 16 12 17 13 10 7

140-150 0.00 90-130 5106.74 31.9 38.4 7 42 30 22 16 38 27 20 15 23 17 13 19 14 10 15 11 8 6

150-160 0.00 90-150 5111.87 31.9 38.4 8 39 27 19 14 36 25 18 13 21 15 11 17 12 9 14 10 7 5

160-170 0.00 90-180 5111.87 31.9 38.5 9 36 24 17 12 33 22 16 11 19 13 9 16 11 8 13 9 6 4

170-180 0.00 0-180 13284.37 83.0 100.0 10 33 22 15 11 31 20 14 10 17 12 8 15 10 7 12 8 5 4

Zone Lumens Total Luminaire Efficiency = 73.2%

REPORT NUMBER: ML15LST0-10 219.96 CIE Type – Direct

10-20 683.41

Plane

Spacing

Criteria

Lamps: 150 W High Pressure Sodium with

Standard Dome Reflector *

20-30 1267.92

30-40 1613.68 0-180 1.64 Coefficients of Utilization – Zonal Cavity Method

40-50 1967.79 90-270 1.64 Effective Floor Cavity Reflectance 0.20

50-60 2333.86 Diagonal 1.88 % Ceiling Rcc 80 70 50 30 10 0

60-70 2328.33 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 1118.52 Zonal Lumen Summary 0 87 87 87 87 85 85 85 85 81 81 81 78 78 78 75 75 75 73

80-90 174.91 Zone Lumens % Lamp % Fixture 1 79 75 71 68 77 73 70 67 70 67 65 67 65 63 64 62 61 59

90-100 1.23 0-30 2171.29 13.6 18.5 2 70 63 58 53 68 62 57 52 59 55 51 57 53 50 55 52 49 47

100-110 0.00 0-40 3784.97 23.7 32.3 3 63 54 48 42 61 53 47 42 51 46 41 49 44 40 47 43 40 38

110-120 0.00 0-60 8086.62 50.5 69.1 4 57 47 40 35 55 46 39 34 44 38 34 42 37 33 41 36 33 31

120-130 0.00 0-90 11708.37 73.2 100.0 5 52 41 34 29 50 41 34 29 39 33 28 37 32 28 36 31 28 26

130-140 0.00 90-120 1.23 0.0 0.0 6 48 37 30 24 46 36 29 24 35 29 24 33 28 24 32 27 24 22

140-150 0.00 90-130 1.23 0.0 0.0 7 44 33 26 21 42 32 26 21 31 25 21 30 25 21 29 24 20 19

150-160 0.00 90-150 1.23 0.0 0.0 8 41 30 23 18 39 29 23 18 28 22 18 27 22 18 26 22 18 16

160-170 0.00 90-180 1.23 0.0 0.0 9 38 27 21 16 37 27 20 16 26 20 16 25 20 16 24 19 16 14

170-180 0.00 0-180 11709.6 73.2 100.0 10 35 25 19 15 34 24 18 14 24 18 14 23 18 14 22 18 14 13

* Photometric data is based on a xture with

a 150-watt clear High Pressure Sodium lamp

(16,000 lumen).

For candlepower values of xtures with other

HPS lamps, use the following multipliers: for

a 100 W (9,500 lumen) HPS lamp – 0.594; for a

70 W (6,400 lumen) HPS lamp – 0.40; for a 50 W

(4,000 lumen) HPS lamp – 0.25. For candlepower

values of xture with guard, multiply by – 0.95.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

937

Mercmaster™ III Low Profile Luminaire Photometric Data

150 W HPS

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

* Photometric data is based on a xture with

a 150-watt clear High Pressure Sodium lamp

(16,000 lumen).

For candlepower values of xtures with other

HPS lamps, use the following multipliers: for

a 100 W (9,500 lumen) HPS lamp – 0.594; for a

70 W (6,400 lumen) HPS lamp – 0.40; for a 50 W

(4,000 lumen) HPS lamp – 0.25. For candlepower

values of xture with guard, multiply by – 0.95.

Zone Lumens Total Luminaire Efficiency = 68.4%

REPORT NUMBER: ML15LAN0-10 168.01 CIE Type – Direct

10-20 536.92

Plane

Spacing

Criteria

Lamps: 150 W High Pressure Sodium with

30° Angle Dome Reflector *

20-30 972.38

30-40 1342.99 0-180 2.3 Coefficients of Utilization – Zonal Cavity Method

40-50 1625.08 90-270 2.0 Effective Floor Cavity Reflectance 0.20

50-60 1721.88 Diagonal 1.8 % Ceiling Rcc 80 70 50 30 10 0

60-70 1586.98 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 1369.71 Zonal Lumen Summary 0 80 80 80 80 78 78 78 78 74 74 74 70 70 70 66 66 66 64

80-90 995.76 Zone Lumens % Lamp % Fixture 1 70 66 62 58 68 64 60 57 60 57 54 57 54 52 54 52 50 48

90-100 461.94 0-30 1677.30 10.5 15.3 2 63 56 50 45 60 54 49 44 51 46 42 48 44 41 45 42 39 37

100-110 127.24 0-40 3020.29 18.9 27.6 3 56 48 41 36 54 46 40 35 44 38 34 41 37 33 39 35 32 30

110-120 27.54 0-60 6367.25 39.8 58.2 4 51 42 35 29 49 40 34 29 38 32 28 36 31 27 34 30 26 24

120-130 4.31 0-90 10319.70 64.5 94.3 5 47 37 30 24 45 36 29 24 34 28 23 32 27 23 30 26 22 20

130-140 2.68 90-120 616.71 3.9 5.6 6 43 33 26 21 41 32 25 20 30 24 20 28 23 19 27 22 19 17

140-150 0.00 90-130 621.02 3.9 5.7 7 39 29 23 18 38 28 22 18 27 21 17 26 21 17 24 20 16 15

150-160 0.00 90-150 623.70 3.9 5.7 8 37 26 20 16 35 26 20 15 24 19 15 23 18 15 22 18 14 13

160-170 0.00 90-180 623.70 3.9 5.7 9 34 24 18 14 33 23 18 14 22 17 13 21 17 13 20 16 13 11

170-180 0.00 0-180 10943.41 68.4 100.0 10 32 22 16 12 31 22 16 12 21 15 12 20 15 12 19 15 11 10

Zone Lumens Total Luminaire Efficiency = 77.6%

REPORT NUMBER: ML15LJ50-10 16.51 CIE Type – Semi-Direct

10-20 135.03

Plane

Spacing

Criteria

Lamps: 150 W High Pressure Sodium with

8” Prismatic Glass Refracter – NEMA Type V *

20-30 274.24

30-40 463.44 0-180 2.22 Coefficients of Utilization – Zonal Cavity Method

40-50 1125.38 90-270 2.20 Effective Floor Cavity Reflectance 0.20

50-60 1688.89 Diagonal 3.50 % Ceiling Rcc 80 70 50 30 10 0

60-70 3137.76 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 2421.27 Zonal Lumen Summary 089 89 89 89 86 86 86 86 79 79 79 73 73 73 68 68 68 65

80-90 1145.98 Zone Lumens % Lamp % Fixture 1 76 70 65 60 72 67 62 58 61 57 54 56 53 50 51 48 46 43

90-100 411.16 0-30 425.77 2.7 3.4 2 66 56 49 42 62 54 47 41 49 43 38 44 39 35 40 36 32 29

100-110 632.32 0-40 889.22 5.6 7.2 3 58 46 38 31 54 44 36 30 40 33 27 36 30 25 32 27 23 21

110-120 448.30 0-60 3703.50 23.1 29.8 4 51 39 30 23 48 37 29 22 33 26 21 30 24 19 27 22 17 15

120-130 293.08 0-90 10408.50 65.1 83.8 5 46 34 25 18 43 32 24 18 29 22 16 26 20 15 23 18 13 11

130-140 154.61 90-120 1491.78 9.3 12.0 6 42 29 21 15 40 28 20 14 25 18 13 22 16 12 20 15 11 8

140-150 59.30 90-130 1784.86 11.2 14.4 7 39 26 18 12 36 25 17 12 22 15 11 20 14 10 18 13 9 7

150-160 9.99 90-150 1998.77 12.5 14.4 8 36 23 15 10 33 22 15 10 20 13 9 18 12 8 16 11 7 5

160-170 0.49 90-180 2009.26 12.6 16.2 9 33 21 14 9 31 20 13 8 18 12 8 16 11 7 15 10 6 4

170-180 0.00 0-180 12417.76 77.6 100.0 10 31 19 12 8 29 18 12 7 17 11 7 15 10 6 13 9 5 4

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

938

Mercmaster™ III Low Profile Luminaire Photometric Data

150 W HPS

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

* Photometric data is based on a xture with

a 100-watt clear Pulse Start Metal Halide lamp

(8,500 lumen).

For candlepower values of xtures with other

PSMH lamps, use the following multipliers:

for a 50 W (3400 lumen) PSMH lamp – 0.40; for

a 70 W (5600 lumen) PSMH lamp – 0.66; for a

150 W (10,500 lumen) PSMH lamp – 1.24; for

a 175 W (17,500 lumen) PSMH lamp – 2.06.

For candlepower values of xture with guard,

multiply by – 0.95.

Zone Lumens Total Luminaire Efficiency = 85.7%

REPORT NUMBER: ML10HG

0-10 21.19 CIE Type – Semi-Direct

10-20 93.55

Plane

Spacing

Criteria

Lamps: 100 W Pulse Start Metal Halide with Globe only *

20-30 201.68

30-40 291.92 0-180 3.20 Coefficients of Utilization – Zonal Cavity Method

40-50 523.42 90-270 3.20 Effective Floor Cavity Reflectance 0.20

50-60 637.38 Diagonal 3.08 % Ceiling Rcc 80 70 50 30 10 0

60-70 732.34 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 845.58 Zonal Lumen Summary 0 95 95 95 95 89 89 89 89 78 78 78 68 68 68 58 58 58 54

80-90 874.42 Zone Lumens % Lamp % Fixture 1 81 74 69 64 75 69 64 60 60 56 52 51 48 45 43 40 38 34

90-100 870.80 0-30 316.42 4.1 4.7 2 71 62 54 48 66 57 50 45 49 43 39 41 37 33 34 31 28 24

100-110 809.33 0-40 608.33 7.8 9.1 3 64 52 44 37 59 49 41 35 41 35 30 35 30 26 29 25 21 18

110-120 643.44 0-60 1769.13 22.7 26.5 4 57 45 37 30 53 42 34 28 36 29 24 30 25 20 25 20 17 14

120-130 139.00 0-90 4221.46 54.1 63.2 5 52 40 31 25 48 37 29 23 31 25 20 26 21 17 21 17 14 11

130-140 0.71 90-120 2323.56 29.8 34.8 6 48 35 27 21 44 33 25 19 28 21 17 23 18 14 19 15 11 9

140-150 0.00 90-130 2462.56 31.6 36.8 7 44 31 23 17 40 29 22 16 25 19 14 21 16 12 17 13 10 7

150-160 0.00 90-150 2463.27 31.6 36.8 8 41 28 20 15 37 26 19 14 22 16 12 19 14 10 16 11 8 6

160-170 0.00 90-180 2463.27 31.6 36.8 9 38 26 18 13 35 24 17 12 20 15 11 17 12 9 14 10 7 5

170-180 0.00 0-180 6684.73 85.7 100.0 10 35 23 16 12 32 22 15 11 19 13 9 16 11 8 13 9 6 5

Zone Lumens Total Luminaire Efficiency = 75.8%

REPORT NUMBER: ML10HST

0-10 116.29 CIE Type – Direct

10-20 371.61

Plane

Spacing

Criteria

Lamps: 100 W Pulse Start Metal Halide with

Standard Dome Reflector *

20-30 692.88

30-40 821.73 0-180 1.70 Coefficients of Utilization – Zonal Cavity Method

40-50 1064.03 90-270 1.70 Effective Floor Cavity Reflectance 0.20

50-60 1154.58 Diagonal 1.84 % Ceiling Rcc 80 70 50 30 10 0

60-70 1134.19 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 470.22 Zonal Lumen Summary 0 90 90 90 90 88 88 88 88 84 84 84 81 81 81 77 77 77 76

80-90 83.66 Zone Lumens % Lamp % Fixture 1 82 78 74 71 80 76 73 70 73 70 68 70 68 66 67 65 64 62

90-100 0.82 0-30 1180.78 15.1 20.0 2 73 66 61 56 71 65 60 55 62 58 54 60 56 53 57 54 51 50

100-110 0.00 0-40 2002.50 25.7 33.9 3 66 57 50 45 64 56 50 45 54 48 44 51 47 43 49 46 42 40

110-120 0.00 0-60 4221.11 54.1 71.4 4 60 50 43 37 58 49 42 37 47 41 36 45 40 36 43 39 35 33

120-130 0.00 0-90 5909.17 75.8 100.0 5 54 44 36 31 53 43 36 31 41 35 30 40 34 30 38 33 30 28

130-140 0.00 90-120 0.82 0.0 0.0 6 50 39 32 26 48 38 31 26 37 31 26 35 30 26 34 29 25 24

140-150 0.00 90-130 0.82 0.0 0.0 7 46 35 28 23 45 34 27 23 33 27 22 32 26 22 31 26 22 20

150-160 0.00 90-150 0.82 0.0 0.0 8 43 32 25 20 41 31 24 20 30 24 20 29 24 20 28 23 19 18

160-170 0.00 90-180 0.82 0.0 0.0 9 40 29 22 18 38 28 22 18 27 22 17 27 21 17 36 21 17 16

170-180 0.00 0-180 5910.00 75.8 100.0 10 37 26 20 16 36 26 20 16 25 20 16 24 19 16 24 19 15 14

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

939

Mercmaster™ III Low Profile Luminaire Photometric Data

100 W PSMH

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

* Photometric data is based on a xture with

a 100-watt clear Pulse Start Metal Halide lamp

(8,500 lumen).

For candlepower values of xtures with other

PSMH lamps, use the following multipliers:

for a 50 W (3400 lumen) PSMH lamp – 0.40; for

a 70 W (5600 lumen) PSMH lamp – 0.66; for a

150 W (10,500 lumen) PSMH lamp – 1.24; for

a 175 W (17,500 lumen) PSMH lamp – 2.06.

For candlepower values of xture with guard,

multiply by – 0.95.

Zone Lumens Total Luminaire Efficiency = 71.3%

REPORT NUMBER: ML10HAN

0-10 91.83 CIE Type – Direct

10-20 301.65

Plane

Spacing

Criteria

Lamps: 100 W Pulse Start Metal Halide with

30° Angle Dome Reflector *

20-30 543.23

30-40 703.02 0-180 2.08 Coefficients of Utilization – Zonal Cavity Method

40-50 877.11 90-270 2.06 Effective Floor Cavity Reflectance 0.20

50-60 850.33 Diagonal 1.76 % Ceiling Rcc 80 70 50 30 10 0

60-70 7753.51 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 667.27 Zonal Lumen Summary 0 84 84 84 84 82 82 82 82 77 77 77 73 73 73 69 69 69 68

80-90 471.44 Zone Lumens % Lamp % Fixture 1 74 69 65 62 71 67 64 60 63 60 58 60 57 55 57 55 53 51

90-100 200.90 0-30 936.72 12.0 16.8 2 66 59 53 48 64 57 51 47 54 49 45 51 47 43 48 45 42 40

100-110 62.89 0-40 1639.74 21.0 29.5 3 59 51 44 38 57 49 43 38 46 41 36 44 39 35 41 37 34 32

110-120 14.42 0-60 3367.18 43.2 60.6 4 54 44 37 31 52 43 36 31 40 35 30 38 33 29 36 32 28 27

120-130 1.07 0-90 5281.39 67.7 95.0 5 49 39 32 26 47 38 31 26 36 30 25 34 29 25 32 28 24 22

130-140 0.00 90-120 278.21 3.6 5.0 6 45 35 28 23 43 34 27 22 32 26 22 30 25 21 29 24 21 19

140-150 0.00 90-130 279.28 3.6 5.0 7 42 31 24 20 40 30 24 19 29 23 19 27 22 18 26 22 18 16

150-160 0.00 90-150 279.28 3.6 5.0 8 39 28 22 17 37 28 21 17 26 21 17 25 20 16 24 19 16 14

160-170 0.00 90-180 279.28 3.6 5.0 9 36 26 19 15 35 25 19 15 24 19 15 23 18 14 22 17 14 13

170-180 0.00 0-180 5560.68 71.3 100.0 10 34 24 18 14 32 23 17 13 22 17 13 21 16 13 20 16 13 11

Zone Lumens Total Luminaire Efficiency = 76.6%

REPORT NUMBER: ML10HJ50-10 9.17 CIE Type – Semi-Direct

10-20 75.43

Plane

Spacing

Criteria

Lamps: 100 W Pulse Start Metal Halide with

8” Prismatic Glass Refracter – NEMA Type V *

20-30 154.76

30-40 266.34 0-180 2.06 Coefficients of Utilization – Zonal Cavity Method

40-50 632.54 90-270 2.20 Effective Floor Cavity Reflectance 0.20

50-60 1155.59 Diagonal 3.26 % Ceiling Rcc 80 70 50 30 10 0

60-70 1665.76 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 693.73 Zonal Lumen Summary 0 89 89 89 89 85 85 85 85 79 79 79 73 73 73 68 68 68 65

80-90 449.28 Zone Lumens % Lamp % Fixture 1 77 71 67 62 73 68 64 60 63 59 56 58 55 52 53 51 49 46

90-100 177.44 0-30 239.35 3.1 4.0 2 67 58 51 45 64 56 49 44 51 46 41 47 42 38 43 39 36 33

100-110 288.25 0-40 505.69 6.5 8.5 3 59 48 40 34 56 46 39 32 42 36 30 38 33 28 34 30 26 24

110-120 208.52 0-60 2293.81 29.4 38.4 4 52 41 32 26 49 39 31 25 35 28 23 32 26 21 29 24 20 18

120-130 128.19 0-90 5102.58 65.4 85.4 5 47 35 26 20 44 33 25 19 30 23 18 27 21 17 25 20 15 13

130-140 56.80 90-120 674.20 8.6 11.3 6 43 30 22 16 40 29 21 15 26 19 14 24 18 13 21 16 12 10

140-150 14.94 90-130 802.38 10.3 13.4 7 39 27 19 13 37 25 18 13 23 16 12 21 15 11 19 14 10 8

150-160 0.10 90-150 874.12 11.2 13.4 8 36 24 16 11 34 23 15 10 21 14 10 19 13 9 17 12 8 6

160-170 0.00 90-180 874.22 11.2 14.6 9 33 21 14 9 31 20 14 9 19 12 8 17 11 8 15 10 7 5

170-180 0.00 0-180 5976.80 76.6 100.0 10 31 19 12 8 29 19 12 8 17 11 7 15 10 6 14 9 6 4

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

940

Mercmaster™ III Low Profile Luminaire Photometric Data

100 W PSMH

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Applications

• Enclosedandgasketedxturessuitableforusein:

—Marineandwetlocations

—Awiderangeofindustrial,chemicalprocessingandother

areaswhereammablegasesandvaporsorcombustible

dustsarepresentunderconditionsdenedbytheNational

ElectricalCodeasClassI,Division2;ClassII,Division1and

2;andClassIII

—ForZone2,themethodofprotectionisAExnAnR–

RestrictedBreathing/NonsparkingorAExnR–Restricted

Breathing

—Non-hazardouslocationswheresevereweatherconditions,

excessivemoisture,dirt,dust,corrosiveatmosphereor

highambienttemperaturesareencountered.18%cooler

operationallowsuseinambienttemperaturesupto

149°F/65°Cdependingonxturecomponentcombinations

• Typicalapplicationsinclude:

—Pulpandpapermills

—Processingplants

—Chemicalplants

—Oilreneries

—Foundries

—Manufacturingplants

—Storageareas

—Marineapplications

• FixtureshaveNEMA4Xlisting.

• Suitabilityincludeslistingforusewheretheremaybe

simultaneousexposuretocombustibledustsandammable

gasesandvapors.Seelistingpagesforcompliancedataon

specicxturecomponentcombinations.

Features

• Modulardesignallowsscoresofxturecomponent

combinationstomeetinstallationandlightingneeds.Many

most-usedcombinationsareofferedprewiredandassembled,

completewithlamp,packagedinasinglecartonandreadyto

install.

• Mogullamptypesandwattages:

HPS50W-150W

PSMH70W-250W

• Choiceofheat-resistantprismaticglassrefractors(NEMA

distributionsI,IIIandV),orheat-resistantprismaticglassglobes

forhazardousareaxtures.Coloredandclearpolycarbonate

globesandTuff-skin®†coatedglassglobesareavailablebutare

NOTapprovedforuseinclassiedareas.Fixtureswiththese

globesdoNOTcomplywithcoderequirements,andshouldbe

usedinnon-classiedareasonly.Globesandrefractorsthread

directlyintoballasthousing.

• Mountinghoodsincludecone-shapedpendanthood,standard

pendant,exiblependant,ceilingandwallpendants(tapped

for3/4”or1”NPT),25°anglestanchion,and90°(straight)

stanchion(bothtappedfor1-1/4”or1-1/2”NPT).

• Conehoodxturesforpendantmountingsheddust,dirtand

combustiblebers.Conehoodinhibitsbuild-upthat“insulates”

xtureandslowsheattransfer,andprovidesincreasedsurface

areaformoreeffectiveheatdissipation.

• Reectorchoiceincludesstandarddomeand30º angletypes,

bothmadeofFiberglassreinforcedwhitepolyester.Highly

resistanttounusuallycorrosiveapplications.Reectorsare

ventedforcooler,dirt-freeoperationandmaintainedlumen

output.Theysecuretoballasthousingwithstainlesssteel

screwsthreadingintostainlesssteelinserts.

• Forhighcorrosionresistance,xturehousing,mountinghoods

andguardsarecopperfreecastaluminumwithbakedepoxy

nish,electrostaticallyappliedforuniformity.Allexposed

hardwareisstainlesssteel.

• Hingehashighlipforaddedsafetyduringinstallation

andservicing.Hingeandboltconstructionassures360º

compressionatallpointsonballasthousinggasketforpositive

sealing.Swing-awaydesignofcaptiveboltandnutsimplies

servicing.

• Bodygasketsandglobegasketsarehigh-temperaturesilicone

rubber.

• Capacitorsarenon-PCBtype,thermallyisolatedfromballast.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

† Tuff-skin is a registered trademark of Thomas Manufacturing Corp., Parkton, Maryland.

V CSA Certification Only.

Pendant Mount Fixture

with Prismatic Glass Refractor

Straight Stanchion-Mount Fixture

with Prismatic Glass Refractor and

Guard

Pendant Cone Fixture with

Prismatic Glass Globe and Guard

Ceiling Mount Fixture

with Prismatic Glass Globe, Guard

and Polyester 30° Angle Reflector

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

941

Mercmaster™ III HID 50-250 Watt Luminaires

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

• Mogulbaseporcelainsocketwithnickel-platedcontactshas

392°C/200°Cweldedleads,prewiredtotheballast.Assures

trouble-freeoperationininstallationswherehighambient

temperaturesareencountered.

• HPSballastsareHighPowerFactor(min.P.F.90%).

• Awiderangeofvoltagesavailable(120to600Volt)andballast

types(Reactor,CWA,CWIandSuperCWA).

• AllMercmasterIIImountinghoodshaveprovisionforeasyeld

installationoffusesinxtures(seefusekitlistingsinthiscatalog

section).

• Forelectricalprotection,agroundwireisprovidedoneach

Mercmastertobondhoodandballasthousing.

• TheAExnAnR/ExnR(V)factorysealedMercmasterIII

preventsvaporsandgasesfromenteringtheglobechamber.

Therearenosealsorputtyrequiredwhichwillreduce

installationtimeandinstallationerrors.

• TheAExnRMercmasterIIIxturerequiresallwiringentriesto

besealed.

Standard Materials

• Mountinghoods,ballastbodiesandguards:copperfreecast

aluminum(lessthan4/10of1%)

• Exposedhardware:stainlesssteel;latchassemblieshave

stainlesssteelboltandcaptivenut;reectorsandguardsattach

withstrainlesssteelscrewsthreadingintostainlesssteelinserts.

• Reectors:Fiberglassreinforcedwhitepolyester

• Globes:heat-resistantprismaticglass

• Refractors:heat-resistantprismaticglass

Standard Finishes

• Mountinghoods,ballastbodies,guards:epoxypowdercoat

nish,electrostaticallyappliedforcomplete,uniformsurface

protection

• Reectors:whitepolyesternish

Options

• AExnAnRxturesareavailablewithaClassI,Zone2rating.

Addsufx-Z2.

• AExnRxturesareavailablewithaClassI,Zone2rating.Add

sufx-ZB.

• ExnRxtures,addsufx-Z V.

• Fusescanbeeld-installedonMercmasterIIIxtures.Kits

includefuseblock,wireconnectorsandscrewsforattachingto

mountinghood.FixtureswithfusesdonotcomplywithMarine

TypeElectricFixturesOutsideType(SaltWater)requirements

formarinelisting.Forfusekits,seeElectrical Specications and

Fuse Kitspage.

• HotRestrikewillrestrikeHPSlampimmediatelywhenpoweris

restoredafteramomentarypowerinterruption.Addsufx-R.

• SmartHotRestrikewillimmediatelyrestrikeHPSlampwhen

powerisrestoredafteramomentarypowerinterruption.The

smartfunctionremovesthehotrestrikeignitorfromthecircuit

ifthelampburnsoutorisremovedfromthesocket.Eliminates

starterfailurescausedbyprolongedoperationwithcyclingor

failinglamps.Addsufx-SR.

• SmartStarterincorporatesa1-1/2-minutetimerandperforms

asaconventionalstartertonormallystartlamp.Removes

itselffromcircuitiflampburnsoutorisremovedfromsocket.

Eliminatesstarterfailurescausedbyprolongedoperationwith

cyclingorfailinglampsandsimpliesndingtheirlocation,

reducingmaintenanceandrepaircosts.AvailableforallHPS

andPSMHxtures.Addsufx-S.

• Optionalphotocellforallxturesexceptconeandceilingmount

providesautomatic“on-off”control.

• QuartzAuxiliarycomestofullbrightnessimmediatelyand

remainslituntiltheHIDlampattains60-70%offullillumination.

QuartzAuxiliarysuppliedwithrelayswitchandsockettoaccept

120Vquartzdoublecontactbayonetbaselamp(notincluded).

Addsufx-Etoxturecatalognumber.‡

Certifications and Compliances

• ULStandard:UL1598,UL1598A,UL844,UL60079-0,UL

60079-15

• ULListed:E10444

Related Products

• Classiedareaphotocontrolsarealsoavailable.

‡ Fixtures equipped with a quartz auxiliary lamp do not comply with UL requirements and are not suitable for use in classified locations.

V CSA Certification Only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

942

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Mercmaster™ III HID 50-250 Watt Luminaires

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

V CSA Certification Only.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

943

Mercmaster™ III HID 50-250 Watt Luminaires

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Illustrated Features

Vented Reflectors

Reflectorsarethick,toughfiberglass-

reinforcedwhitepolyester,ventedfor

cooleroperation.Quicklyattachwith

furnishedstainlesssteelscrews. Ballast Assembly (Zone 2)

Utilizingnon-sparkingcomponents

avoidingtheignitionofgasesorvapors

thatmaybepresent(nA).

Mounting Hood and Globe Gaskets

Siliconerubbergasketsealsoutmoisture,

dirtanddust.Staysflexible,withstands

hightemperatures.Closuredesign

assuresuniformgasketcompression.

Electrical Protection

Groundwireprovidedtobondmounting

hoodtoballasthousing.

High Temperature Sockets

Mogulbasehigh-temperatureporcelain

sockets.

Aluminum Inner Reflector

Solidaluminuminnerreflector(for

refractorballasthousingsonly)improves

photometricefficiency.

Globe Chamber (Zone 2)

Completelysealedfromtheballast

housingandoutsidevapors/air(nAnR).

Terminal Blocks (Zone 2)

Aseven-pointterminalblockisprovided

tofacilitatewiring.Terminalblock

accommodateswiresizerangingfrom#8

to#24AWG.

Stainless Steel Inserts

Ballastbodieshavestainlesssteel

threadedinsertstoreceivestainlesssteel

screwsforreflectorsandguard.Prevents

"freezing”,allowingguardsandreflectors

tobeeasilyremovedandreplacedatany

time,withoutdamagetothehousing.

"Safety" High

Hinge

Extra-highhinge

providesadditional

protectionagainst

accidental

ballasthousing

disengagement

duringinstallation

ormaintenance.

Epoxy Finish

Ballasthousing,hoodsandguardsare

copperfreealuminumwithepoxypowder

coatfinish.

Photocell

Availableforallfixturesexceptconeand

ceilingmount.Installsthroughknock-out

inmountinghood.Providescontinuous

ON-OFFdusk-to-dawncontrol.

Stainless Steel

Latch Assembly

Captive,stainless

steellatchassembly

boltandnutcloses

securely,resists

attackofcorrosive

atmospheres.

Swing-awaydesign

simplifiesservicing.

Heat-Resistant Globes and Refractors

Prismaticglassglobesandrefractorsare

heat-resistant.Theythreaddirectlyintothe

ballasthousingandsealagainstahigh-

temperaturesiliconerubbergasket.

Cooler Operating Cone Hood

Largerslopedsurfaceshedsdusts,dirt

andcombustiblefibersprovidingbetter

heatdissipation.

Fuses

Twoscrewssecurefusekittomounting

bossinanyMercmastermountinghood.

Fuseincluded.

Quartz Emergency Light for Pulse Start Metal Halide or High Pressure Sodium Fixtures *

Smart

Hot

Restrike

Quartz Emergency Light for Pulse Start Metal Halide or

High Pressure Sodium Fixtures

HPS Smart Hot Restrike Accessory for HPS Fixtures

Quartz Emergency Light

Quartz Emergency Light for

PSMH or HPS Fixtures

Mercmasterfixturesforormetalhalideandhighpressuresodiumlampscanbesuppliedwitha

sockettoaccepta150Wor250W,120Vquartzlamp.ThisD.C.bayonetbasesocketisinaddition

tothestandardlampsocket.Intheeventofamomentarypowerinterruption,thequartzlampis

automaticallyswitchedon.ThesingleendedquartzlampremainsenergizeduntiltheHIDrestrikes

andreachesabout60%output.

Thequartzemergencylampsocketiswiredtoa120Vtapontheballastandistherefore

independentofthelightingfixturevoltage.Nospecialfieldwiringisnecessary.

Description Catalog Suffix

Forfixturevoltsof120,208,240or277 -MTE

Forfixturevoltsof480 -48E

HPS Smart Hot Restrike Accessory for HPS Fixtures

Smart

Hot

Restrike

Quartz Emergency Light for Pulse Start Metal Halide or

High Pressure Sodium Fixtures

HPS Smart Hot Restrike Accessory for HPS Fixtures

Quartz Emergency Light

HPS Smart Hot Restrike Accessory

for HPS Fixtures

Mercmasterfixturesforhighpressuresodiumlampscanbesuppliedwithaspecialignitor(starter

board).Itinstantlyrestrikesahothighpressuresodiumlampwhenamomentarypowerinterruption

occurs.Thisspecialignitor,suppliedinplaceofthestandardignitor,isapottedsolidstatedevice,

totallyfactoryinstalled.Itisnotsuitableforfieldinstallation.

Thehotlamprestartoptionprovidesinstantrestartof50,70,100and150WHPSlampsafter

poweroutagesofupto10seconds.Thelampsrestrikeinstantlyatalmostfulllumens.Forpower

interruptionsofupto30seconds,therestartofthehighpressuresodiumlampisalsoinstantbut

atlessthanfulllumens.Thehotlamprestartaccessorydoesnotacceleratecoldlampstartupor

startingwherethepoweroutageisofadurationwhichhasallowedtheHPSlamptocool.

AdditionalAdvantagesoftheSmartHotRestrike:

• Protectsagainstselfdestructionintheeventoffailed,missingorbrokenlamps,orsocketor

leadwirefailure.

• Prevents“EndofLife”lampsfromcontinuouscyclingoverlongperiodsoftime.

• Remainsunaffectedbystrayvoltages,moderateovervoltages,aswellasundervoltage

conditions.

• Dropsintothebackgroundduringnormallampoperationwithexceptionallylowinsertionloss.

• Fullyencapsulatedconstructionassureselectricalintegrityandmechanicalvibrationprotection.

• ULrecognizedcomponent.

Description Catalog Suffix

Forfixturewattsof50,70,100or150(HPSonly) -SR

Accessory Options

➊ Guards: Guardsaredie-castcopperfreealuminumwithbakedepoxyfinishtomatchfixtures.

Fixturesuppliedwithstainlesssteelmountingscrewswhichthreadintostainlesssteelinsertson

fixturehousingtoattachguard.Toorderfixturewithguard,addsuffix-Gtocatalognumberbefore

addingvoltagesuffix.

➋ Reflectors: Standarddomeand30°anglepolyesterreflectorsareshownelsewhereinthis

catalogsection.

➌ Hot Restrike: InstantlyrestrikesahotHPSlampwhenpowerisrestoredafteramomentary

outage.Availablefactory-installedonly.Toorder,addsuffix-Rtocatalognumber.

➍ Quartz Emergency Light: Whenordered,HPSfixtureswillbesuppliedwithaprewiredspecial

DCbayonetbasesockettoaccepta150W,120Vquartzlamp(notfurnished)thatautomatically

switchesonwhenapoweroutageoccurs.Fixturesorderedwiththisquartzemergencylampfeature

doNOTcomplywithrequirementsforclassifiedareasandshouldbeusedonlyinnon-classified

locations.Toorder,addsuffix-Etocatalognumberandspecifyifarelayswitchisdesired.

➎ Photocell and Fuses: PhotocontrolareavailablewithintheLighting Section.

➏ Smart Starter: Performsasaconventionalstarterinlampstart-up.Removesitselffromcircuitat

endoflamplifeoriflampisoutofsocket.Addsuffix-Stocatalognumber.

➐ Smart Hot Restrike (HPS only): WillimmediatelyrestrikeHPSlampwhenpowerisrestoredafter

amomentarypowerinterruption.Thesmartfunctionremovesthehotrestrikeignitorfromthecircuit

ifthelampburnsoutorisremovedfromthesocket.Eliminatesstarterfailurescausedbyprolonged

operationwithcyclingorfailinglamps.Addsuffix-SRtocatalognumber.

*NOTE: Fixtures equipped with quartz emergency light do not comply with UL requirements and are not suitable for use in classified locations.

V CSA Certification Only.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

944

Mercmaster™ III HID 50-250 Watt Emergency Luminaires Accessories and Options

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Orderusingcatalognumberingguidebeloworselectcatalognumberfromtablesonfollowingpages.

Catalog Numbering Guide

KP A L 70 10 J5 G MT R Z2

Series:

KP-

MercmasterIII

250

LampType:

L-HighPressure

Sodium

HorP-PulseStart

MetalHalide➊

HubSize:

75-3/4”NPT

10-1”NPT

125-1-1/4”NPT

stanchion

150-1-1/2”NPT

stanchion

GuardOptions:

G-Guard

Blank-NoGuard

Options:

E-EmergencyQuartz

F-FuseKit(Specify

Voltage)

R-HotRestrike

(50-150WHPS

only)

S-SmartStarter

SR-SmartHot

Restrike

K-KynarCoating

H1-Photocontrol

120V

H2-Photocontrol

208V

H3-Photocontrol

240V

H4-Photocontrol

277V

C-SafetyCable

AdaptedV

E40-ExportSocket

D-E-40Export

SocketV

T-TerminalBlocksV

V-Anti-Vibration

ModificationsV

X-Appledapter➌

MountingHood

AdapterV

Mounting:

A-Pendant(rigid

mounting)

C-Ceiling

CH-PendantConeHood

F-Pendant(flexible

mounting)

ST-90°Stanchion

S-25°Stanchion

WB-Wall

Wattage:

10-100WHPS,PSMH

15-150WHPS,PSMH

17-175WPSMH

20-200WPSMH

25-250WPSMH

50-50WHPS

(MT-VoltageOnly)

70-70WHPS,PSMH

17-175WMHV

25-250WMHV

OpticalAssembly:

Blank-GlassGlobe

J1-NEMAIGlass

Refractor

J3-NEMAIIIGlass

Refractor

J5-NEMAVGlass

Refractor

G3-LargeGlassGlobe

Voltage:➋

MT-120/208/240/277,

60Hz

5MT-120/208/240/

277/480,60Hz

48-480,60Hz

125-120,50Hz

225-225,50Hz

226-220,60Hz

235-230,50Hz

245-240,50Hz

C2-208,60Hz,CWIV

C3-240,60Hz,CWIV

C6-480,60Hz,CWIV

C7-600,60Hz,CWIV

TT-120/277/347,60Hz,

CWAV

Suffix:

Z2-Zone2suffix

(requiredfor

AExnAnR

rating)

ZB-Zone2suffix

(requiredfor

AExnRrating)

Z-Zone2suffix

(requiredfor

ExnR)V

Reflectors are ordered separately – see Accessories page.

➊ H - Lamp type is for 70W and 100W fixtures only.

P - Lamp type is for 175W, 200W and 250W fixtures only.

➋ Voltages shown are limited to specific combinations.

➌ Appledapter is available for use with the pendant, ceiling and angled stanchion mounting only.

V CSA Certification Only.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

945

Mercmaster™ III HID 50-250 Watt Luminaires

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

MercmasterIIIfixturesarelistedfor“SimultaneousExposure”tocombinationsofClassI,Division2andClassII,Division1hazardous

conditions.

“T” Numbers for Mercmaster III Fixtures

Lamp

Supply

Wire

Temp.

(°F/°C)

Ambient

Temp.

(°F/°C)

Class I, Division 2 Class II, Division 1 Groups E, F and G ➊

Simultaneous Exposure

Class I, Division2 / Class II, Division 1

Watts Type Globe

Globe &

Reflector

Globe

8”

Refractor Globe

Globe &

Reflector

Globe

8”

Refractor Globe

Globe &

Reflector

Globe

8”

Refractor

194/90 104/40 T3C T3B —T3C T4A T4 —T6 T3A T3 —T3C

50 HPS 194/90 131/55 T3A T3A —T3A T4 T3B —T5 T3 T3 —T3A

194/90 149/65 T3A T3 —T3A T3C T3C —T4A T2D T2D —T3

194/90 104/40 T3B T3A —T3C T4 T3C —T6 T3 T3 —T3A

70 HPS 194/90 131/55 T3A T3A —T3B T3C T3C —T5 T2D T2D —T3

194/90 149/65 T3 T3A —T3A T3C T3B —T4A T2C T2C —T3

194/90 104/40 T2D T2D T3 T3 —T3A (EF) T3 (EF) —————

100 HPS 194/90 104/40 ————T3B —T4A T4A T2B T2B T2C T2C

194/90 131/55 T2D T2D T3 T3 — — T4 T4 — — T2B T2B

194/90 149/65 T2D T2D T2D T2D ————————

194/90 104/40 T2B T2B —T2C ———T3C T2 — — T2B

150 HPS 194/90 104/40 ————T3 (EF) ———————

194/90 131/55 T2B T2A —T2B ————————

70 PSMH

194/90 104/40 T3A T3A —T3A ———T3C — — — —

194/90 131/55 T3A T3A —T3A ———T3C — — — —

194/90 149/65 T3 T2 —T3 ———T3C — — — —

100 PSMH

194/90 104/40 T3 T3 —T3 ———T3C ———T2B

194/90 131/55 T3 T3 —T3 ———T3C ———T2A

194/90 149/65 T2D T2D —T2D ———T3C — — — —

150 PSMH

194/90 104/40 T2B T2B —T2B ———T3C ———T2B

194/90 131/55 T2A T2A —T2B ———T3C ———T2A

257/125 149/65 T2A T2 —T2B ———T3C — — — —

175 PSMH

194/90 104/40 T2B T2B —T2B ———T3C ———T2B

194/90 131/55 T2A T2A —T2B ———T3C ———T2A

221/105 149/65 T2A T2 —T2B ————————

200 PSMH 194/90 104/40 T2B T2B —T2B ———T3B — — — —

194/90 131/55 T2B T2B —T2B ————————

250 PSMH 194/90 104/40 T2 T2 —T2 — — — — — — — —

194/90 131/55 T2 T2 —T2 — — — — — — — —

175 MH V194/90 104/40 T2B T2B —T2B — — — T3C — — — —

194/90 131/55 T2A T2A —T2B — — — T3C — — — —

250 MH V194/90 104/40 325 325 —T2 — — — T3B — — — —

“T” Numbers Represent the Maximum Lamp Temperature for Class I, Division 2 Locations and

Maximum Surface Temperature Under Dust Blanket for Class II, Division 1 Locations.

“T”

Number T1 350 325 T2 T2A T2B T2C T2D T3 T3A T3B T3C T4 T4A T5 T6

Temp.

Range

(˚ºF)

664-

842

619-

662

574-

617

538-

572

502-

536

448-

500

421-

446

394-

419

358-

392

331-

356

322-

329

277-

320

250-

275

214-

248

187-

212 185

Temp.

Range

(°C)

351-

450

326-

350

301-

325

281-

300

261-

280

231-

260

216-

230

201-

215

181-

200

166-

180

161-

165

136-

160

121-

135

101-

120

86-

100 85

➊ All Class II T Numbers are E, F, G unless otherwise indicated.

V CSA Certification Only.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

946

Mercmaster™ III HID 50-250 Watt Luminaire Thermal Performance

Class I, Division 2; Class II, Division 1; Simultaneous Exposure to Hazardous Conditions of Both Classifications

Temperature Identification Numbers of Mercmaster III fixtures.

Operating Temperatures: “T” Numbers for Zone 2 Mercmaster III Fixtures

The “T” number is established by separately determining the maximum temperature of the globe surface and ballast compartment. The hotter of the two is taken

to determine the “T” number for the overall fixture.

Lamp Supply

Wire

Temp.

(°F/°C)

Ambient

Temp.

(°F/°C)

Class I, Zone 2 AEx nA nR IIC Class I, Zone 2 AEx nR IIC

Watts Type Globe

Globe &

Reflector

Refractor

Only

G3/Refractor

& Reflector Globe

Globe &

Reflector

Refractor

Only

G3/Refractor

& Reflector

50 HPS

194/90 104/40 T4 T4 T6 T4 T4 T4 T6 T4

194/90 131/55 T4 T3 T5 T3 T4 T3 T5 T3

194/90 149/65 T3 T3 T4 T3 T3 T3 T4 T3

70 HPS

194/90 104/40 T4 T4 T4 T4 T6 T5 T6 T4

194/90 131/55 T4 T4 T4 T3 T5 T4 T5 T3

194/90 149/65 T4 T4 T3 T3 T4 T4 T5 T3

100 HPS

194/90 104/40 T4 T4 T4 T4 T5 T4 T6 T4

194/90 131/55 T4 T4 T3 T3 T4 T4 T5 T3

194/90 149/65 T4 T4 T3 T3 T4 T4 T4 T3

150 HPS

194/90 104/40 T4 T3 T3 T3 T4 T4 T5 T4

194/90 131/55 T3 T3 T3 T3 T4 T4 T4 T3

221/105 65 T3 T3 T3 T3 T4 T3 T4 T3

70 PSMH

194/90 104/40 T4 T4 T4 —T5 T4 T6 —

194/90 131/55 T3 T3 T3 —T4 T4 T5 —

194/90 149/65 T3 T3 T3 —T4 T3 T4 —

100 PSMH

194/90 104/40 T3 T3 T3 —T5 T4 T6 —

194/90 131/55 T3 T3 T3 —T4 T4 T5 —

194/90 149/65 T3 T3 T3 —T4 T3 T4 —

150 PSMH

194/90 104/40 T4 T4 T4 —T4 T4 T5 —

194/90 131/55 T3 T3 T3 —T4 T3 T4 —

221/105 149/65 T3 T3 T3 —T4 T3 T4 —

175 PSMH

194/90 104/40 T3 T3 T4 —T3 T3 T4 —

194/90 131/55 T3 T3 T3 —T3 T3 T4 —

221/105 149/65 T3 T3 T3 —T3 T3 T4 —

200 PSMH

194/90 104/40 T3 T3 T4 —T3 T3 T4 —

221/105 131/55 T3 T3 T3 —T3 T3 T4 —

221/105 149/65 T3 T3 T3 —T3 T3 T4 —

250 PSMH 194/90 104/40 T3 T3 T3 —T3 T3 T3 —

194/90 131/55 T3 T3 T3 —T3 T3 T3 —

“T” Numbers Represent the Maximum Surface Temperature for Luminaries with AEx nA nR or AEx nR rating

“T” Number T1 T2 T3 T4 T5 T6

Temp. Range (°F) 547-842 394-572 277-392 214-275 187-212 185

Temp. Range (°C) 301-450 201-300 136-200 101-135 86-100 85

V CSA Certification Only.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

947

Mercmaster™ III HID 50-250 Watt Luminaire Thermal Performance

Class I, Zone 2, AEx nA nR IIC; Class 1 Zone 2, AEx nR IIC; IP66; and NEMA 4X

Temperature Identification Numbers of Mercmaster III Fixtures.

Fixture Selection Guide Indicates atmosphere for which fixture is suitable

➊

DenotesfixturewithGlobeOnly.

➋

DenotesfixturewithGlobeandReflector.

➌

Denotesfixturewith8”Refractor/G3Globe

Class I, Division 2 Chemical

Ignition

°F/°C ➍

Minimum Fixture

“T” Number for

Chemical

HPS (Watts) PSMH (Watts)

50 70 100 150 70 100 175 200 250

Group A Atmospheres

acetylene 581/305 T2

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊ ➌ ➊➋

Group B Atmospheres

acrolein(inhibited) 428/220 T2D

➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋

arsine NA

➋

butadiene 788/420 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

ethyleneoxide 804/429 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

hydrogen 932/500 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

propyleneoxide 840/449 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

propylnitrate 347/175 T3B

➊➋➌ ➊➋➌ ➊➋

Group C Atmospheres

acetaldehyde 347/175 T3B

➊➋➌ ➊ ➌ ➊➋

allylalcohol 712/378 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

n-butyraldehyde 424/218 T2D

➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋

carbonmonoxide 1128/609 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

crotonaldehyde 450/232 T2C

➊➋➌ ➊➋➌ ➊➋➌ ➌ ➊➋ ➊➋➌ ➊➋

cyclopropane 928/498 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

diethylether(ethylether) 320/160 T3C

➊ ➌ ➌ ➊➋

diethylamine 594/312 T2

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊ ➌ ➊➋

ethylene 842/450 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

ethylenimine 608/320 T2

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊ ➌ ➊➋

ethlymercaptan 572/300 T2

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊ ➌ ➊➋

ethylsulde NA

➎

hydrogencyanide 1000/538 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

hydrogensulde 500/260 T2B

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊ ➊➋

morpholine 590/310 T2

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊ ➌ ➊➋

2-nitropropane 802/428 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

tetrahydrofuran 610/321 T2

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊ ➌ ➊➋

unsymmetricaldimethylhydrazine 480/249 T2C

➊➋➌ ➊➋➌ ➊➋➌ ➌ ➊➋ ➊➋➌ ➊➋

Group D Atmospheres

aceticacid(glacial) 867/464 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

acetone 869/465 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

acrylonitrile 898/481 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

ammonia 1204/651 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

benzene 928/498 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

butane 549/287 T2A

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊ ➊➋

1-butanol(butylalcohol) 649/343 325

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

This classified area suitability chart is based on NEC requirements and Appleton and UL testing. However, the ultimate decision on suitability of these fixtures for

classified areas depends solely on the judgement of the owner, insurance company, inspector and/or authority having jurisdiction.

➍ Ignition temperatures shown should be regarded as approximations only. Per NFPA Bulletin 325M, ignition temperatures may vary according to such factors

as vapor/air mixture, size and space where ignition may occur, rate and duration of heating, oxygen concentration and other materials present.

➎ Not Available.

➏ A saturated hydrocarbon mixture. Also known by synonyms benzine, ligroin, petroleum, ether and naptha.

V CSA Certification Only.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

948

Mercmaster™ III HID 50-250 Watt Luminaire Classified Area Suitability

Class I, Division 2; Class II, Division 1; Simultaneous Exposure to Hazardous Conditions of Both Classifications

Maximum Temperatures in °F/°C Obtained from Tests in a 104 °F/40 °C Ambient, Vertical Position, Lamp Base Up, as per NEC.

Fixture Selection Guide Indicates atmosphere for which fixture is suitable

➊

DenotesfixturewithGlobeOnly.

➋

DenotesfixturewithGlobeandReflector.

➌

Denotesfixturewith8”Refractor/G3Globe

Class I, Division 2 Chemical

Ignition

°F/°C ➍

Minimum Fixture

“T” Number for

Chemical

HPS (Watts) PSMH (Watts)

50 70 100 150 70 100 175 200 250

Group D Atmospheres

2-butanol(secondarybutylalcohol) 761/405 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

n-butylacetate 797/425 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

isobutylacetate 790/421 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

sec-butylalcohol 649/343 325

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

di-isobutylene 736/391 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

ethane 882/472 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

ethanol(ethylalcohol) 685/363 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

ethylacetate 799/426 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

ethylenediamine(anhydrous) 725/385 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

ethylenedichloride 775/413 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

gasoline(56-60octane) 536/280 T2A

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊ ➊➋

heptanes 399/204 T3

➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌

hexanes 433/223 T2D

➊➋➌ ➊➋➌ ➊ ➊➋ ➊➋➌

isoprene 743/395 350

➊➋➌ ➊➋➌ ➊ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

isopropylether 829/443 350

➊➋➌ ➊➋➌ ➊ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

mesityloxide 651/344 325

➊➋➌ ➊➋➌ ➊ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

methane(naturalgas) 999/537 T1

➊➋➌ ➊➋➌ ➊ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

methanol(methylalcohol) 725/385 350

➊➋➌ ➊➋➌ ➊ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

3-methyl-l-butanol(isoamylalcohol) 662/350 350

➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

methylethylketone 759/404 350

➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

methylisobutylketone 838/448 350

➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

2-methyl-1-propanol(isobutylalcohol) 779/415 350

➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

2-methyl-1-propanol(tertiarybutylalcohol) 892/478 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

petroleumnaphtha➏550/288 T2A

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊ ➊➋

pyridine 900/482 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

octanes 403/206 T3

➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌

pentanes 500/260 T2B

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊ ➊➋

1-pentanol(amylalcohol) 572/300 T2

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊  ➊➋

propane 810/432 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

1-propanol(propylalcohol) 774/412 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

2-propanol(isopropylalcohol) 750/399 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊ ➊➋

propylene 851/455 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

styrene 914/490 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

toluene 896/480 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

vinylacetate 756/402 350

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

vinylchloride 882/472 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

xylenes(o-xylene) 865/463 T1

➊➋➌ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋ ➊➋➌ ➊➋➌ ➊➋➌ ➊➋

This classified area suitability chart is based on NEC requirements and Appleton and UL testing. However, the ultimate decision on suitability of these fixtures for

classified areas depends solely on the judgement of the owner, insurance company, inspector and/or authority having jurisdiction.

➍ Ignition temperatures shown should be regarded as approximations only. Per NFPA Bulletin 325M, ignition temperatures may vary according to such factors

as vapor/air mixture, size and space where ignition may occur, rate and duration of heating, oxygen concentration and other materials present.

➎ Not Available.

➏ A saturated hydrocarbon mixture. Also known by synonyms benzine, ligroin, petroleum, ether and naptha.

V CSA Certification Only.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

949

Mercmaster™ III HID 50-250 Watt Classified Area Suitability

Class I, Division 2; Class II, Division 1; Simultaneous Exposure to Hazardous Conditions of Both Classifications

Maximum Temperatures in °F/°C Obtained from Tests in a 104 °F/40 °C Ambient, Vertical Position, Lamp Base Up, as per NEC.

Fixture Selection Guide Indicates atmosphere for which fixture is suitable

➋DenotesfixturewithGlobeandReflector.➌Denotesfixturewith8”Refractor.

Class I, Division 2 Chemical

Ignition

°F/°C ➍

Minimum Fixture

“T” Number for

Chemical

HPS (Watts) PSMH (Watts)

50 70 100 150 70 100 175 200 250

Group IIC

acetylene 581/305 T2 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

acetylene 572/300 T2 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

hydrogen 932/500 T1 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

Group IIB

ethylene 914/490 T1 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

butadiene1.3 797/425 T2 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

carbonmonoxidecokeovengas 1040/560 T1 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

diethylether(ethylether) 320/160 T4 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

ethylene 842/450 T1 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

ethylenimineethyleneoxide 797/425 T2 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

Group IIA

acetone 869/465 T1 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

amylacetate 707/375 T2 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

ammonia 1204/651 T1 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

benzene 928/498 T1 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

butane 549/287 T3 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

1-butanol(butylalcohol) 649/343 T2 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

n-butylacetatecyclohexane 500/260 T3 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

ethylmethylketone 959/515 T1 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

ethanol(ethylalcohol) 685/363 T2 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

ethylacetate 799/426 T1 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

heptanes 399/204 T3 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

hexanes 433/223 T3 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

isopreneisobutanol 806/430 T2 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

mesityloxidemethylacetate 932/500 T1 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

methanol(methylalcohol) 725/385 T2 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

n-propylacetate 932/500 T1 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

n-butulacetate 788/420 T2 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

pentanes 500/260 T3 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

propane 810/432 T2 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

xylenes(o-xylene) 865/463 T1 ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌ ➋➌

This classified area suitability chart is based on NEC requirements and Appleton and UL testing. However, the ultimate decision on suitability of these fixtures for

classified areas depends solely on the judgement of the owner, insurance company, inspector and/or authority having jurisdiction.

➍ Ignition temperatures shown should be regarded as approximations only. Per NFPA Bulletin 325M, ignition temperatures may vary according to such factors

as vapor/air mixture, size and space where ignition may occur, rate and duration of heating, oxygen concentration and other materials present.

V CSA Certification Only.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

950

Mercmaster™ III HID 50-250 Watt Luminaire Classified Area Suitability

Class I, Zone 2, AEx nA nR IIC; Class 1 Zone 2, AEx nR IIC; IP66; and NEMA 4X

Maximum Temperatures in ºF/ºC Obtained from Tests in a 104 ºF/40 ºC Ambient, Vertical Position, Lamp Base Up.

Lamp Type Lamp Watts

Hub Size

(Inches)

Catalog Numbers ➌➍➎

with Globe

with Type V 8” Refractor

or G3 Globe ➋

Pendant — One Hub, Rigid Mounting ➊

HPS 50 3/4 KPAL5075 KPAL5075J5

1KPAL5010 KPAL5010J5

HPS 70 3/4 KPAL7075 KPAL7075J5

1KPAL7010 KPAL7010J5

HPS 100 3/4 KPAL1075 KPAL1075J5

1KPAL1010 KPAL1010J5

HPS 150 3/4 KPAL1575 KPAL1575J5

1KPAL1510 KPAL1510J5

Pendant Cone — One Hub, Rigid Mounting

HPS 50 3/4 KPCHL5075 KPCHL5075J5

1 KPCHL5010 KPCHL5010J5

HPS 70 3/4 KPCHL7075 KPCHL7075J5

1 KPCHL7010 KPCHL7010J5

HPS 100 3/4 KPCHL1075 KPCHL1075J5

1 KPCHL1010 KPCHL1010J5

HPS 150 3/4 KPCHL1575 KPCHL1575J5

1 KPCHL1510 KPCHL1510J5

Ceiling — Five Hubs, Four Close-Up Plugs

HPS 50 3/4 KPCL5075 KPCL5075J5

1KPCL5010 KPCL5010J5

HPS 70 3/4 KPCL7075 KPCL7075J5

1KPCL7010 KPCL7010J5

HPS 100 3/4 KPCL1075 KPCL1075J5

1KPCL1010 KPCL1010J5

HPS 150 3/4 KPCL1575 KPCL1575J5

1KPCL1510 KPCL1510J5

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

➊ For Flexible Pendant Mount, change A to F in catalog number (except 50 W HPS).

➋ To order fixtures with large globe change J5 to G3; for fixture with NEMA Type I or NEMA Type III refractor, change final digit 5 in catalog number to 1 or 3.

➌ AddthefollowingvoltageandfrequencydesignationbeforeZ2suffix:

Lamp Type Lamp Watts

Voltage Suffixes

MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 50 X — — — X X — X — — — — X

HPS 70 X — X X X X — X — — — — X

HPS 100 X — X X X X — X — — X X X

HPS 150 X — X X X X — X — — X X X

PSMH 70 X — X X X — — X — — — — X

PSMH 100 X — X X X — — X — — — — X

PSMH 150 X — X X X — — X — — — — X

PSMH 175 X X X — — — — — — — — — X

PSMH 200 X — X — — — — — — — — — X

PSMH 250 X — — — — — — — — — — — X

MH V175 X — — X X — — X X X X X X

MH V250 X — — X X — — X X X X X X

Voltages:

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➍ Add -Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add -ZB suffix for restricted breathing protection (AEx nR).

➎ For fixtures with guards, add letter G before adding voltage designation.

V CSA Certification only.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

951

Mercmaster™ III HID 50-250 Watt Luminaires

50 W, 70 W, 100 W, 150 W HPS

High Reactance, High Power Factor (min. P.F. 90%). Heat-Resistant Prismatic Glass Globe or Closed Prismatic Glass Refractor. Mogul Base Lamps.

Lamp Type Lamp Watts

Hub Size

(Inches)

Catalog Numbers ➌➍➎

with Globe

with Type V 8” Refractor

or G3 Globe ➋

Wall — Five Hubs, Four Close-Up Plugs

HPS 50 3/4 KPWBL5075 KPWBL5075J5

1KPWBL5010 KPWBL5010J5

HPS 70 3/4 KPWBL7075 KPWBL7075J5

1KPWBL7010 KPWBL7010J5

HPS 100 3/4 KPWBL1075 KPWBL1075J5

1KPWBL1010 KPWBL1010J5

HPS 150 3/4 KPWBL1575 KPWBL1575J5

1KPWBL1510 KPWBL1510J5

25° Stanchion — One Hub

HPS 50 1-1/4 KPSL50125 KPSL50125J5

1-1/2 KPSL50150 KPSL50150J5

HPS 70 1-1/4 KPSL70125 KPSL70125J5

1-1/2 KPSL70150 KPSL70150J5

HPS 100 1-1/4 KPSL10125 KPSL10125J5

1-1/2 KPSL10150 KPSL10150J5

HPS 150 1-1/4 KPSL15125 KPSL15125J5

1-1/2 KPSL15150 KPSL15150J5

90° Stanchion — One Hub

HPS 50 1-1/4 KPSTL50125 KPSTL50125J5

1-1/2 KPSTL50150 KPSTL50150J5

HPS 70 1-1/4 KPSTL70125 KPSTL70125J5

1-1/2 KPSTL70150 KPSTL70150J5

HPS 100 1-1/4 KPSTL10125 KPSTL10125J5

1-1/2 KPSTL10150 KPSTL10150J5

HPS 150 1-1/4 KPSTL15125 KPSTL15125J5

1-1/2 KPSTL15150 KPSTL15150J5

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

➊ For Flexible Pendant Mount, change A to F in catalog number (except 50 W HPS).

➋ To order fixtures with large globe change J5 to G3; for fixture with NEMA Type I or NEMA Type III refractor, change final digit 5 in catalog number to 1 or 3.

➌ AddthefollowingvoltageandfrequencydesignationbeforeZ2suffix:

Lamp Type Lamp Watts

Voltage Suffixes

MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 50 X — — — X X — X — — — — X

HPS 70 X — X X X X — X — — — — X

HPS 100 X — X X X X — X — — X X X

HPS 150 X — X X X X — X — — X X X

PSMH 70 X — X X X — — X — — — — X

PSMH 100 X — X X X — — X — — — — X

PSMH 150 X — X X X — — X — — — — X

PSMH 175 X X X — — — — — — — — — X

PSMH 200 X — X — — — — — — — — — X

PSMH 250 X — — — — — — — — — — — X

MH V175 X — — X X — — X X X X X X

MH V250 X — — X X — — X X X X X X

Voltages:

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➍ Add -Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add -ZB suffix for restricted breathing protection (AEx nR).

➎ For fixtures with guards, add letter G before adding voltage designation.

V CSA Certification only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

952

Mercmaster™ III HID 50-250 Watt Luminaires

50 W, 70 W, 100 W, 150 W HPS

High Reactance, High Power Factor (min. P.F. 90%). Heat-Resistant Prismatic Glass Globe or Closed Prismatic Glass Refractor. Mogul Base Lamps.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lamp Type Lamp Watts

Hub Size

(Inches)

Catalog Numbers ➌➍➎

with Globe with Type V 8” Refractor ➋

Pendant — One Hub, Rigid Mounting ➊

PSMH 70 3/4 KPAH7075 KPAH7075J5

1KPAH7010 KPAH7010J5

PSMH 100 3/4 KPAH1075 KPAH1075J5

1KPAH1010 KPAH1010J5

PSMH 150 3/4 KPAP1575 KPAP1575J5

1KPAP1510 KPAP1510J5

PSMH 175 3/4 KPAP1775 KPAP1775J5

1KPAP1710 KPAP1710J5

PSMH 200 3/4 KPAP2075 KPAP2075J5

1KPAP2010 KPAP2010J5

PSMH 250➏3/4 KPAP2575 KPAP2575J5

1KPAP2510 KPAP2510J5

Pendant Cone — One Hub, Rigid Mounting

PSMH 70 3/4 KPCHH7075 KPCHH7075J5

1KPCHH7010 KPCHH7010J5

PSMH 100 3/4 KPCHH1075 KPCHH1075J5

1 KPCHH1010 KPCHH1010J5

PSMH 150 3/4 KPCHP1575 KPCHP1575J5

1KPCHP1510 KPCHP1510J5

PSMH 175 3/4 KPCHP1775 KPCHP1775J5

1KPCHP1710 KPCHP1710J5

PSMH 200 3/4 KPCHP2075 KPCHP2075J5

1KPCHP2010 KPCHP2010J5

PSMH 250➏3/4 KPCHP2575 KPCHP2575J5

1KPCHP2510 KPCHP2510J5

Ceiling — Five Hubs, Four Close-Up Plugs

PSMH 70 3/4 KPCH7075 KPCH7075J5

1KPCH7075 KPCH7010J5

PSMH 100 3/4 KPCH1075 KPCH1075J5

1KPCH1010 KPCH1010J5

PSMH 150 3/4 KPCP1575 KPCP1575J5

1KPCP1510 KPCP1510J5

PSMH 175 3/4 KPCP1775 KPCP1775J5

1KPCP1710 KPCP1710J5

PSMH 200 3/4 KPCP2075 KPCP2075J5

1KPCP2010 KPCP2010J5

PSMH 250➏3/4 KPCP2575 KPCP2575J5

1KPCP2510 KPCP2510J5

➊ For Flexible Pendant Mount, change A to F in catalog number (except 50 W HPS).

➋ To order fixtures with large globe change J5 to G3; for fixture with NEMA Type I or NEMA Type III refractor, change final digit 5 in catalog number to 1 or 3.

➌ AddthefollowingvoltageandfrequencydesignationbeforeZ2suffix:

Lamp Type Lamp Watts

Voltage Suffixes

MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 50 X — — — X X — X — — — — X

HPS 70 X — X X X X — X — — — — X

HPS 100 X — X X X X — X — — X X X

HPS 150 X — X X X X — X — — X X X

PSMH 70 X — X X X — — X — — — — X

PSMH 100 X — X X X — — X — — — — X

PSMH 150 X — X X X — — X — — — — X

PSMH 175 X X X — — — — — — — — — X

PSMH 200 X — X — — — — — — — — — X

PSMH 250 X — — — — — — — — — — — X

MH V175 X — — X X — — X X X X X X

MH V250 X — — X X — — X X X X X X

Voltages:

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➍ Add -Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add -ZB suffix for restricted breathing protection (AEx nR).

➎ For fixtures with guards, add letter G before adding voltage designation.

V CSA Certification only.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

953

Mercmaster™ III HID 50-250 Watt

70 W, 100 W, 150 W, 175 W, 200 W, 250 W PSMH

High Reactance, High Power Factor (min. P.F. 90%). Heat-Resistant Prismatic Glass Globe or Closed Prismatic Glass Refractor. Mogul Base Lamps

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lamp Type Lamp Watts

Hub Size

(Inches)

Catalog Numbers ➌➍➎

with Globe with Type V 8” Refractor ➋

Wall — Five Hubs, Four Close-Up Plugs

PSMH 70 3/4 KPWBH7075 KPWBH7075J5

1KPWBH7010 KPWBH7010J5

PSMH 100 3/4 KPWBH1075 KPWBH1075J5

1KPWBH1010 KPWBH1010J5

PSMH 150 3/4 KPWBP1575 KPWBP1575J5

1KPWBP1510 KPWBP1510J5

PSMH 175 3/4 KPWBP1775 KPWBP1775J5

1KPWBP1710 KPWBP1710J5

PSMH 200 3/4 KPWBP2075 KPWBP2075J5

1KPWBP2010 KPWBP2010J5

PSMH 250➏3/4 KPWBP2575 KPWBP2575J5

1KPWBP2510 KPWBP2510J5

25° Stanchion — One Hub

PSMH 70 1-1/4 KPSH70125 KPSH70125J5

1-1/2 KPSH70150 KPSH70150J5

PSMH 100 1-1/4 KPSH10125 KPSH10125J5

1-1/2 KPSH10150 KPSH10150J5

PSMH 150 1-1/4 KPSP15125 KPSP15125J5

1-1/2 KPSP15150 KPSP15150J5

PSMH 175 1-1/4 KPSP17125 KPSP17125J5

1-1/2 KPSP17150 KPSP17150J5

PSMH 200 1-1/4 KPSP20125 KPSP20125J5

1-1/2 KPSP20150 KPSP20150J5

PSMH 250➏1-1/4 KPSP25125 KPSP25125J5

1-1/2 KPSP25150 KPSP25150J5

90° Stanchion — One Hub

Shown with Globe and Optional Guard

PSMH 70 1-1/4 KPSTH70125 KPSTH70125J5

1-1/2 KPSTH70150 KPSTH70150J5

PSMH 100 1-1/4 KPSTH10125 KPSTH10125J5

1-1/2 KPSTH10150 KPSTH10150J5

PSMH 150 1-1/4 KPSTP15125 KPSTP15125J5

1-1/2 KPSTP15150 KPSTP15150J5

PSMH 175 1-1/4 KPSTP17125 KPSTP17125J5

1-1/2 KPSTP17150 KPSTP17150J5

PSMH 200 1-1/4 KPSTP20125 KPSTP20125J5

1-1/2 KPSTP20150 KPSTP20150J5

PSMH 250➏1-1/4 KPSTP25125 KPSTP25125J5

1-1/2 KPSTP25150 KPSTP25150J5

➊ For Flexible Pendant Mount, change A to F in catalog number (except 50 W HPS).

➋ To order fixtures with large globe change J5 to G3; for fixture with NEMA Type I or NEMA Type III refractor, change final digit 5 in catalog number to 1 or 3.

➌ AddthefollowingvoltageandfrequencydesignationbeforeZ2suffix:

Lamp Type Lamp Watts

Voltage Suffixes

MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 50 X — — — X X — X — — — — X

HPS 70 X — X X X X — X — — — — X

HPS 100 X — X X X X — X — — X X X

HPS 150 X — X X X X — X — — X X X

PSMH 70 X — X X X — — X — — — — X

PSMH 100 X — X X X — — X — — — — X

PSMH 150 X — X X X — — X — — — — X

PSMH 175 X X X — — — — — — — — — X

PSMH 200 X — X — — — — — — — — — X

PSMH 250 X — — — — — — — — — — — X

MH V175 X — — X X — — X X X X X X

MH V250 X — — X X — — X X X X X X

Voltages:

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➍ Add -Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add -ZB suffix for restricted breathing protection (AEx nR).

➎ For fixtures with guards, add letter G before adding voltage designation.

V CSA Certification only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

954

Mercmaster™ III HID 50-250 Watt Luminaires

70 W, 100 W, 150 W, 175 W, 200 W, 250 W PSMH

High Reactance, High Power Factor (min. P.F. 90%). Heat-Resistant Prismatic Glass Globe or Closed Prismatic Glass Refractor. Mogul Base Lamps.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lamp Type Lamp Watts

Hub Size

(Inches)

Catalog Numbers ➌➍➎

with Globe with Type V 8” Refractor ➋

Pendant — One Hub, Rigid Mounting ➊

MHV175 3/4 KPAH1775 KPAH1775J5

1KPAH1710 KPAH1710J5

MHV250➏

3/4 KPAH2575 KPAH2575J5

1KPAH2510 KPAH2510J5

Pendant Cone — One Hub, Rigid Mounting

MHV175 3/4 KPCHH1775 KPCHH1775J5

1 KPCHH1710 KPCHH1710J5

MHV250➏

3/4 KPCHH2575 KPCHH2575J5

1KPCHH2510 KPCHH2510J5

Ceiling — Five Hubs, Four Close-Up Plugs

MHV175 3/4 KPCH1775 KPCH1775J5

1KPCH1710 KPCH1710J5

MHV250➏

3/4 KPCH2575 KPCH2575J5

1KPCH2510 KPCH2510J5

Mercmaster™ III HID 50-250 Watt

175 W, 250 W MH V

High Reactance, High Power Factor (min. P.F. 90%). Heat-Resistant Prismatic Glass Globe or Closed Prismatic Glass Refractor. Mogul Base Lamps

➊ For Flexible Pendant Mount, change A to F in catalog number (except 50 W HPS).

➋ To order fixtures with large globe change J5 to G3; for fixture with NEMA Type I or NEMA Type III refractor, change final digit 5 in catalog number to 1 or 3.

➌ AddthefollowingvoltageandfrequencydesignationbeforeZ2suffix:

Lamp Type Lamp Watts

Voltage Suffixes

MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 50 X — — — X X — X — — — — X

HPS 70 X — X X X X — X — — — — X

HPS 100 X — X X X X — X — — X X X

HPS 150 X — X X X X — X — — X X X

PSMH 70 X — X X X — — X — — — — X

PSMH 100 X — X X X — — X — — — — X

PSMH 150 X — X X X — — X — — — — X

PSMH 175 X X X — — — — — — — — — X

PSMH 200 X — X — — — — — — — — — X

PSMH 250 X — — — — — — — — — — — X

MH V175 X — — X X — — X X X X X X

MH V250 X — — X X — — X X X X X X

Voltages:

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➍ Add -Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add -ZB suffix for restricted breathing protection (AEx nR).

➎ For fixtures with guards, add letter G before adding voltage designation.

V CSA Certification only.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

955

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lamp Type Lamp Watts

Hub Size

(Inches)

Catalog Numbers ➌➍➎

with Globe with Type V 8” Refractor ➋

Wall — Five Hubs, Four Close-Up Plugs

MHV175 3/4 KPWBH1775 KPWBH1775J5

1KPWBH1710 KPWBH1710J5

MHV250➏

3/4 KPWBH2575 KPWBH2575J5

1KPWBH2510 KPWBH2510J5

25° Stanchion — One Hub

MHV175 1-1/4 KPSH17125 KPSH17125J5

1-1/2 KPSH17150 KPSH17150J5

MHV250➏

1-1/4 KPSH25125 KPSH25125J5

1-1/2 KPSH25150 KPSH25150J5

90° Stanchion — One Hub

Shown with Globe and Optional Guard

MHV175 1-1/4 KPSTH17125 KPSTH17125J5

1-1/2 KPSTH17150 KPSTH17150J5

MHV250➏

1-1/4 KPSTH25125 KPSTH25125J5

1-1/2 KPSTH25150 KPSTH25150J5

Mercmaster™ III HID 50-250 Watt

175 W, 250 W MH V

High Reactance, High Power Factor (min. P.F. 90%). Heat-Resistant Prismatic Glass Globe or Closed Prismatic Glass Refractor. Mogul Base Lamps

➊ For Flexible Pendant Mount, change A to F in catalog number (except 50 W HPS).

➋ To order fixtures with large globe change J5 to G3; for fixture with NEMA Type I or NEMA Type III refractor, change final digit 5 in catalog number to 1 or 3.

➌ AddthefollowingvoltageandfrequencydesignationbeforeZ2suffix:

Lamp Type Lamp Watts

Voltage Suffixes

MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 50 X — — — X X — X — — — — X

HPS 70 X — X X X X — X — — — — X

HPS 100 X — X X X X — X — — X X X

HPS 150 X — X X X X — X — — X X X

PSMH 70 X — X X X — — X — — — — X

PSMH 100 X — X X X — — X — — — — X

PSMH 150 X — X X X — — X — — — — X

PSMH 175 X X X — — — — — — — — — X

PSMH 200 X — X — — — — — — — — — X

PSMH 250 X — — — — — — — — — — — X

MH V175 X — — X X — — X X X X X X

MH V250 X — — X X — — X X X X X X

Voltages:

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➍ Add -Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add -ZB suffix for restricted breathing protection (AEx nR).

➎ For fixtures with guards, add letter G before adding voltage designation.

V CSA Certification only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

956

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Thesepre-packagedfixturecomponentcombinationsaredeliveredfullyassembledandpackedinasinglecarton.Theyareavailablewith

orwithoutlamp,andwithchoiceofglobeorNEMATypeI,IIIorVrefractors–allwithorwithoutguards.PRE-PAKunitssimplifyordering,

stockingandshipping,andresultinsavingsonjob-siteassemblyandinstallationtimeandcosts.

Catalog numbers do not include mounting hood or reflector. For mounting hood and reflectors selection, see below and order

separately. Hood and Reflector will be packaged separately.

PRE-PAK Fixtures ➊➍

Lamp Type

and Watts

Ballast Assembly

with Globe Only

Ballast Assembly

with Globe and Guard

Ballast Assembly

with G3 Globe Only

Ballast Assembly

with Refractor Only ➌

Ballast Assembly

with Refractor and Guard

100WPSMH➋KPBU100H-MT KPBU100HG-MT —KPBU100HJ5-MT KPBU100HJ5G-MT

175WPSMH KPBU175P-MT KPBU175PG-MT —KPBU175PJ5-MT KPBU175PJ5G-MT

70WHPS KPBU70L-MT KPBU70LG-MT —KPBU70LJ5-MT KPBU70LJ5G-MT

100WHPS KPBU100L-MT KPBU100LG-MT KPBUG3100L-MT KPBU100LJ5-MT KPBU100LJ5G-MT

150WHPS KPBU150L-MT KPBU150LG-MT —KPBU150LJ5-MT KPBU150LJ5G-MT

175WMHVKPBU175H-TT KPBU175HG-TT —KPBU175HJ5-TT KPBU175HJ5G-TT

250WMHVKPBU250H-TT KPBU250HG-TT —KPBU250HJ5-TT KPBU250HJ5G-TT

Mounting Hoods

White Polyester Reflectors

Furnished with stainless steel screws

Description

Hub Size

(Inches)

Catalog

Number Description

Catalog

Number

Pendant

OneHub,RigidMounting

3/4 KPA-75

Standard Dome

ForGlobeFixtures KR2-ST1KPA-100

Pendant — Flexible

OneHub,FlexibleMounting

3/4 KPAF-75

1KPAF-100

30° Angle

ForGlobeFixtures KR2-AN

Pendant Cone

OneHub,Rigid

3/4 KPCH-75

1KPCH-100

Ceiling

FiveHubs,

FourClose-UpPlugs

3/4 KPC-75

Standard Dome

ForGlassRefractorFixtures CMR-4ST1KPC-100

Wall

FiveHubs,

FourClose-UpPlugs

3/4 KPWB-75

1KPWB-100

30° Angle

ForGlassRefractorFixtures CMR-4AN

25° Stanchion

OneHub

1-1/4 KPS-125

1-1/2 KPS-150

90° Stanchion

OneHub

1-1/4 KPST-125

1-1/2 KPST-150

➊ All catalog numbers above are fixtures without lamp. To order fixture complete with appropriate installed lamp, add suffix L to catalog number. All PRE-PAK fixtures

include multi-tap ballast for operation on 120 V, 208 V, 240 V or 277 V lines. Fixture component combinations listed are furnished completely assembled in a single

carton.

➋ 100 W fixtures use ED-28 mogul base lamps.

➌ Refractor catalog numbers listed are for NEMA Type V. To order fixture with Type III refractor, change J5 in catalog number to J3; for Type I refractor, change

J5 to J1.

➍ For CSA 120/277/347 Vac tri-tap ballast, change -MT to -TT V.

V CSA Certification only.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

957

Mercmaster™ III HID 50-250 Watt PRE-PAK™ Luminaires

Factory-Assembled Fixtures

For 70 W, 100 W or 150 W High Pressure Sodium Lamps, or 100 W or 175 W Pulse Start Metal Halide Lamps. Mogul Base Lamps.

Mounting Hoods

Description Hub Size (Inches) Catalog Number

Pendant

OneHub,RigidMounting

3/4 KPA-75

1KPA-100

Pendant — Flexible

OneHub,FlexibleMounting

3/4 KPAF-75

1KPAF-100

Pendant Cone

OneHub,Rigid

3/4 KPCH-75

1KPCH-100

Ceiling

FiveHubs,FourClose-UpPlugs

3/4 KPC-75

1KPC-100

Wall

FiveHubs,FourClose-UpPlugs

3/4 KPWB-75

1KPWB-100

25° Stanchion

OneHub

1-1/4 KPS-125

1-1/2 KPS-150

90° Stanchion

OneHub

1-1/4 KPST-125

1-1/2 KPST-150

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

958

Mercmaster™ III HID 50-250 Watt Luminaire Mounting Hoods

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Ballast Bodies

Ballast Body for Glass Globe (shown) Ballast Body for Glass Refractor or G3 Globe (shown)

HighPressureSodium

HighPowerFactor(Min.P.F.90%)

PulseStartMetalHalide

SuperConstantWattageAutotransformer(Min.P.F.90%)

Lamp

Type

Lamp

Watts

Catalog Number ➋➍➎➏ Voltage Suffixes

For Globe

For G3 Globe ➊/

Refractor MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 50➌KPB50L KPBR50L X — — — X X — X — — — — X

HPS 70➌KPB70L KPBR70L X — X X X X — X — — — — X

HPS 100➌KPB100L KPBR100L X — X X X X — X — — X X X

HPS 150➌KPB150L KPBR150L X — X X X X — X — — X X X

PSMH 70 KPB70H KPBR70H X — X X X — — X — — — — X

PSMH 100 KPB100H KPBR100H X — X X X — — X — — — — X

PSMH 150 KPB150P KPBR150P X — X X X — — X — — — — X

PSMH 175 KPB175P KPBR175P X X X ————————— X

PSMH 200 KPB200P KPBR200P X — X ————————— X

PSMH 250 KPBG250P KPBR250P X ——————————— X

MHV175 KPB175H KPBR175H X — — X X — — X X X X X X

MHV250 KPB250H KPBR250H X — — X X — — X X X X X X

Voltages:

LB-Incandescent,120V60Hz

MT-120/208/240/277V60Hz

5MT-120/208/240/277/480V60Hz

48-480V60Hz

125-120V50Hz

225-225V50Hz

226-220V60Hz

235-230V50Hz

245-240V50Hz

C2-208V60Hz,CWIV

C3-240V60Hz,CWIV

C6-480V60Hz,CWIV

C7-600V60Hz,CWIV,

TT-120/277/347V60Hz,CWAV

➊ For HPS version fixtures only.

➋ After voltage suffix add: -S for Smart Starter.

➌ After voltage suffix add: -SR for Smart Hot Restrike, -R for ballast body with Hot Restrike Ignitor.

➍ Add -E after voltage suffix for ballast body with provision for Quartz Emergency Light. Not suitable for hazardous locations.

➎ Add Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add ZB suffix for restricted breathing protection (AEx nR).

➏ Add Z for factory sealed restricted breathing protection (Ex nR) V.

V CSA Certification only.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

959

Mercmaster™ III HID 50-250 Watt Luminaire Ballast Bodies

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Description Catalog Number

Prismatic Glass Globes — Heat-Resistant

Foruseinareaswherefixtureissubjectto

extremethermalshock

Heat-Resistant

Clear VPGL-2HR

Amber VPGL-2AM

Blue VPGL-2BL

Green VPGL-2GR

Red VPGL-2RE

Glass Globe

Clear VPGL3HR

G3 Glass Globe

Tuff-Skin® Coated Prismatic Glass Globes — For Non-Classified Areas

Foruseinareaswherefixtureissubjectto

extremethermalshock

Heat-Resistant

Clear VPGL-2HRT

Tuff-Skin® Glass Globe

Polycarbonate Globes — Impact-Resistant ➊

Use100wattlampmax.Donotusein

ambientsexceeding77ºF/25ºC.

Clear VPGL-2PL

Amber VPGL-2AMPL

Green VPGL-2GRPL

Red VPGL-2REPL

Polycarbonate Globe

➊ Polycarbonate globes are shatter-resistant – for use in processing plants, canneries, dairies, bakeries or anywhere broken glass would prove a hazard. Ideally

suited for areas where vandalism, high replacement and high maintenance costs are a problem. Do not use in ambients exceeding 77 °F/25 °C. For burning in

vertical base-up positions only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

960

Mercmaster™ III HID 50-250 Watt Luminaire Optics

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Light Distribution IES/NEMA Distribution Curves Catalog Number

Closed Prismatic Glass Refractors — Heat-Resistant

Glass Refractor

NEMATypeI LPG-R1

NEMATypeIII LPG-R3

NEMATypeV LPG-R5

Closed Prismatic Polymeric Refractors

For use with PSMH lamps, 100 W max. 104 °F/40 °C max. ambient temperature.

Suitable for Class II, Division 1 and 2, Groups F, G; NEMA 4X, UL 1598A Marine Type Electric Fixtures Outside Type (Salt Water)

Polymeric Refractor

NEMATypeII LPRF-2CP

NEMATypeIII LPRF-3CP

NEMATypeIV LPRF-4CP

NEMATypeV LPRF-5CP

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

961

Mercmaster™ III HID 50-250 Watt Luminaire Optics

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Item Description Catalog Number

White Polyester Reflectors — Furnished with stainless steel screws

ForGlobeFixtures StandardDome KR2-ST

DeepDome KR2-DD ➊

30°Angle KR2-AN

ForGlassRefractorFixtures➋StandardDome CMR-4ST

DeepDome CMR-4DD ➊

30°Angle CMR-4AN

Standard Dome 30° Angle

Guards

GlobeGuard KGU2

G3Globe/Refractor

Guard KRG2

Globe Guard Refractor Guard

Replacement Globe Gaskets — Silicone Rubber

GlobeGasket VPGL-GK

G3Globe/Refractor

Gasket KRF-GK

Globe Gaskets

Retrofit Pendant Mounting Adapter

PermitsuseofMercmasterIIIpendanthood

with3/4”hubonexistingV-51mounting

hood.

LPAD-1

Mounting Adapter

➊ Dark Skies Compliant.

➋ Fixtures with refractors are not UL Listed when used with reflectors.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

962

Mercmaster™ III HID 50-250 Watt Luminaire Accessories and Replacement Parts

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Ballast Housing Weights Fuse Kits

Lamp Watts

HPS

(Wt. Lbs/Kg ➊➋)

PSMH

(Wt. Lbs/Kg ➊➋)

Lamp

Watts Volts

Fuse Quantity

Required

Fuse Kit Catalog Number

HPS PSMH

Globe Housing with Ballast

120 1 F5 —

50 12.5/5.7 —208 2 F3 —

70 15/6.8 15.25/6.9 240 2 F3 —

100 16/7.3 16.25/7.4 277 1 F2 —

150 17/7.7 16.75/7.6 347V1F1 F1

175 —17.25/7.8

120 1 F5 F4

200 —18/8.2 208 2 F3 F3

250 —18.5/8.4 240 2 F3 F3

Refractor Housing with Ballast 277 1 F2 F2

50 13/5.9 —347V1F1 F2

70 15.5/7.0 15.75/7.1 480 2 F2 F1

100 16.5/7.5 16.75/7.6

100

120 1 F8 F6

150 17.5/7.9 17.25/7.8 208 2 F5 F4

175 —17.75/8.1 240 2 F5 F3

200 —18.5/8.4 277 1 F3 F3

250 —19/8.6 347V1F1 F2

480 2 F3 F2

150

120 1 F10 —

Component and Accessory Weights 208 2 F5 —

Item Wt. Lbs/Kg ➊240 2 F5 —

Mounting Hoods 277 1 F5 —

Pendant 2.25/1.0 347V1F2 F2

PendantCone 2.5/1.1 480 2 F3 —

Ceiling 3/1.4

175

120 1 —F5

Wall 4/1.8 208 2 —F3

25°Stanchion 3.25/1.5 240 2 —F3

StraightStanchion 3.75/1.7 277 1 —F2

Refractors, Globes and Guards 347V1F2 F2

8”GlassRefractor/G3Globe 5.25/2.4 480 2 —F2

GlassGlobe 3.75/1.7

200

120 1 —F9

GlobeGuard 1/0.5 208 2 —F6

RefractorGuard 1/0.5 240 2 —F5

Reflectors 277 1 —F4

StandardDome 2.50/1.1 347V1—F2

30°Angle 2.50/1.1 480 2 —F2

250

120 1 —F8

208 2 —F5

240 2 —F5

277 1 —F3

347V1F3 F3

➊ Weights are approximate.

➋ Add 1 lbs/0.5 kg for HPS fixtures with Hot Restrike. Add 0.25 lbs/0.1 kg for Quartz Emergency Light.

V CSA Certification only.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

963

Mercmaster™ III HID 50-250 Watt Luminaire Ballast Weights and Fuse Kits

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

➊

C.W.A. – Constant Wattage Autotransformer. HX-HPF – High Reactance High Power Factor Autotransformer. Super C.W.A. – Super Constant Wattage Autotransformer.

➋ 150 W HPS units equipped with ballasts to operate 55 volt lamps only.

V CSA Certification only.

Electrical Specifications

Line

Voltage

Type of

Ballast ➊

Starting

Amps

Operating

Amps

Total

Watts

50 Watt High Pressure Sodium

120 HX-HPF 0.58 0.58 64

208 HX-HPF 0.35 0.33 64

240 HX-HPF 0.31 0.29 64

277 HX-HPF 0.25 0.25 64

347VHX-HPF 0.26 0.21 68

70 Watt High Pressure Sodium

120 HX-HPF 0.90 0.82 94

208 HX-HPF 0.50 0.48 94

240 HX-HPF 0.44 0.41 94

277 HX-HPF 0.35 0.36 94

347VHX-HPF 0.30 0.30 94

480 HX-HPF 0.21 0.21 94

100 Watt High Pressure Sodium

120 HX-HPF 1.30 1.15 130

208 HX-HPF 0.76 0.67 130

240 HX-HPF 0.66 0.60 130

277 HX-HPF 0.60 0.52 130

347VHX-HPF 0.45 0.39 130

480 HX-HPF 0.33 0.31 135

480 C.W.I. 0.17 0.30 130

600 C.W.I. 0.14 0.24 130

150 Watt High Pressure Sodium ➋

120 HX-HPF 2.00 1.70 188

208 HX-HPF 1.15 0.95 188

240 HX-HPF 1.00 0.85 188

277 HX-HPF 0.85 0.72 188

347VHX-HPF 0.52 0.56 188

480 HX-HPF 0.50 0.47 189

480 C.W.I. 0.25 0.42 190

600 C.W.I. 0.19 0.35 190

70 Watt Pulse Start Metal Halide

120 HX-HPF 0.80 0.85 95

208 HX-HPF 0.50 0.52 95

240 HX-HPF 0.43 0.44 95

277 HX-HPF 0.39 0.39 95

347VHX-HPF 0.20 0.28 88

480 HX-HPF 0.26 0.23 95

100 Watt Pulse Start Metal Halide

120 HX-HPF 1.20 1.15 130

208 HX-HPF 0.70 0.70 130

240 HX-HPF 0.61 0.58 130

277 HX-HPF 0.55 0.50 130

347VHX-HPF 0.40 0.40 129

480 HX-HPF 0.30 0.35 140

Line

Voltage

Type of

Ballast ➊

Starting

Amps

Operating

Amps

Total

Watts

150 Watt Pulse Start Metal Halide

120 HX-HPF 1.75 1.60 188

208 HX-HPF 1.30 1.00 188

240 HX-HPF 0.85 0.80 188

277 HX-HPF 0.77 0.70 188

347VSuperC.W.A. 0.65 0.55 185

480 SuperC.W.A. 0.45 0.42 185

175 Watt Pulse Start Metal Halide

120 SuperC.W.A. 0.90 1.78 199

208 SuperC.W.A. 0.50 1.08 199

240 SuperC.W.A. 0.35 0.89 199

277 SuperC.W.A. 0.30 0.76 199

347VSuperC.W.A. 0.25 0.65 208

480 SuperC.W.A. 0.25 0.50 213

175 Watt Metal Halide V

120 C.W.A. 1.30 1.80 210

208 C.W.A. 0.75 1.04 210

240 C.W.A. 0.65 0.90 210

277 C.W.A. 0.55 0.80 210

347 C.W.A. 0.50 0.65 210

480 C.W.I. 0.20 0.45 215

600 C.W.I. 0.16 0.37 215

175 Watt Metal Halide V

120 SuperC.W.A. 1.30 1.80 213

208 SuperC.W.A. 0.75 1.10 213

240 SuperC.W.A. 0.65 0.90 213

277 SuperC.W.A. 0.55 0.80 213

480 SuperC.W.A. 0.35 0.45 213

250 Watt Metal Halide V

120 SuperC.W.A. 1.20 2.60 298

208 SuperC.W.A. 0.65 1.50 298

240 SuperC.W.A. 0.60 1.30 298

277 SuperC.W.A. 0.50 1.12 298

480 SuperC.W.A. 0.30 0.65 298

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

964

Mercmaster™ III HID 50-250 Watt Luminaire Electrical Specifications

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

4.75”/

120.7mm

2.62”/66.5mm

17.06”/433.3mm

1.94”/49.3mm

5.87”/

149.1mm

5.87”/

149.1mm

11.00”/279.4mm

15.07”/382.8mm

1.87”/47.5mm

4.00”/

101.6mm

0.94”/

23.9mm

5.50”/

139.7mm

14.90”/

378.5mm

10.17”/

258.3mm

16.90”/429.3mm

6.50”/

165.1mm

8.00”/

203.2mm

2.75”/69.9mm

6.00”/152.4mm

9.00”/228.6mm

5.50”/

139.7mm

10.75”/

273.1mm

12.38”/

314.5mm

12.06”/306.3mm 12.06”/306.3mm 12.06”/306.3mm

13.62”/345.9mm

11.00”/279.4mm 11.00”/279.4mm

11.00”/279.4mm

1.17”/

29.7mm

5.87”/

149.1mm

5.87”/

149.1mm

5.87”/

149.1mm

5.59”/

142.0mm

1.75”/

44.5mm

13.38”/339.9mm

11.00”/279.4mm

7.75”/196.9mm

5.87”/149.1mm

6.69”/

169.9mm

7.78”/199.9mm

7.25”/184.2mm

14.94”/379.5mm

6.06”/

153.9mm

1.94”/

49.3mm

5.87”/

149.1mm

11.00”/

279.4mm

Pendant

(Rigid or Flex)

Ceiling Cone

Wall

90º Straight Stanchion

8” Globe/Refractor

Body/Guard

Polymeric Refractor

25° Angle Stanchion

5.50”/

139.7mm



11.00”/279.4mm



5.87”/

149.1mm



17.23”/437.6mm



9.79”/248.7mm

Globe/Guard/Refractor

13.38”/339.9mm

11.00”/279.4mm

7.75”/196.9mm

5.87”/149.1mm

6.69”/

169.9mm

7.78”/199.9mm

7.25”/184.2mm

14.94”/379.5mm

6.06”/

153.9mm

1.94”/

49.3mm

5.87”/

149.1mm

11.00”/

279.4mm

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

965

Mercmaster™ III HID 50-250 Watt Luminaire Dimensions

High Pressure Sodium and Pulse Start Metal Halide

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Class I, Division 2, Groups A, B, C, D

NEMA 4X

Applications

• Encapsulatedphotocontrolprovidesautomaticdusk-to-dawn

lightingcontrolinClassI,Division2locations.

• Typicalapplicationsincludewalkways,securityareasandany

otheroutdoorlightingapplication.

• ForusewithMercmasterIII–LowProle,MercmasterIII,and

MercmasterIII–400SeriesLuminaires.

• ForremotemountinginFSBoxes.

Features

• Factorysealeddesigneliminatestheneedforanexplosionproof

enclosure.

• Canbeeasilyinstalledintheeld.

• Solidstatedesignforperformanceandreliability.

• Availablefor120,208,240,or277volts.

• 50-400WHIDincandescentoruorescent,50/60Hz.

• 1000VAVoltage/Ampere

• Minimumtimedelay:15secondstoeliminatenuisiancetripping.

• Providedwith(3)18AWGstrandedleads6”/152.4mminlength.

• Willtthroughstandard1/2”knockout.

Materials

• Encapsulatedwithepoxysealingcompound

• FS:aluminum

Certifications and Compliances

• ULStandard:1604–Hazardous(Classied)Locations

• cULusRecognized

Factory-Installed Photocontrol

Add to fixture catalog after voltage; i.e.: KPWBL1075MTH1.Dimensions

Voltage Range Suffix Designation

0.69”

17.5 mm

1.13”

28.7 mm

1.375”

34.9 mm

2.56”

65.0 mm

1.19”

30.2 mm 1.94”

49.2 mm

0.69”

17.5 mm

1.13”

28.7 mm

1.375”

34.9 mm

2.56”

65.0 mm

1.19”

30.2 mm 1.94”

49.2 mm

0.69”

17.5 mm

1.13”

28.7 mm

1.375”

34.9 mm

2.56”

65.0 mm

1.19”

30.2 mm 1.94”

49.2 mm

Mercmaster III wall mounting hood

with photocontrol installed shown

120V,50/60Hz H1

208V,50/60Hz H2

240V,50/60Hz H3

277V,50/60Hz H4

Photocontrol in FS Cover for Use with FS/FD Box

Supplied with two stainless steel screws. For neoprene gasket, order catalog number FS-GKR-1N.

Voltage Range Catalog Number

120V,50/60Hz FSKA-PC120D2

208-277V,50/60Hz FSKA-PC247D2

Photocontrol for Field Installation

Voltage Range Max. Current Catalog Number

120V,50/60Hz 8.3Amp PC120D2

208-277V,50/60Hz 3.5Amp PC247D2

PCD2 Series Factory Sealed Hazardous Location Photocontrol

For use in Class I, Division 2, Groups A, B, C, D locations

Maintains Class I, Division 2 rating for Mercmaster III – Low Profile, Mercmaster III, and Mercmaster III – 400 Series Luminaires, Mercmaster LED

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

966

* Photometric data is based on xtures with

150-watt clear High Pressure Sodium lamp

(16,000 lumen).

For candlepower values of xtures with other

HPS lamps, use the following multipliers: for

70 W (6,400 lumen) HPS lamp – 0.40; for 50 W

(4,000 lumen) HPS lamp – 0.25. For candlepower

values of xture with guard, multiply by 0.95.

Zone Lumens Total Luminaire Efficiency = 86.1%

REPORT NUMBER: KP15LG

0-10 50.74 CIE Type – Semi-Direct

10-20 164.55

Plane

Spacing

Criteria

Lamps: 150 W High Pressure Sodium with Globe only *

20-30 310.47

30-40 611.05 0-180 2.82 Coefficients of Utilization – Zonal Cavity Method

40-50 961.13 90-270 2.82 Effective Floor Cavity Reflectance 0.20

50-60 1308.18 Diagonal 2.80 % Ceiling Rcc 80 70 50 30 10 0

60-70 1542.35 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 1716.10 Zonal Lumen Summary 0 95 95 95 95 89 89 89 89 77 77 77 67 67 67 57 57 57 53

80-90 1799.18 Zone Lumens % Lamp % Fixture 1 81 74 69 64 75 69 64 59 59 55 51 50 47 44 42 39 37 33

90-100 1802.19 0-30 525.75 3.3 3.8 2 71 62 54 47 65 57 50 44 49 43 38 41 36 32 33 30 27 23

100-110 1676.86 0-40 1136.81 7.1 8.3 3 64 52 44 37 58 48 41 34 41 35 30 34 29 25 28 24 20 17

110-120 1379.11 0-60 3406.12 21.3 24.7 4 57 45 36 30 53 42 34 28 35 29 24 29 24 20 24 19 16 13

120-130 441.46 0-90 8463.75 52.9 61.4 5 52 40 31 24 48 37 29 23 31 24 19 26 20 16 21 16 13 10

130-140 9.61 90-120 4858.16 30.4 35.3 6 48 35 26 20 44 32 25 19 27 21 16 23 17 13 18 14 11 8

140-150 3.33 90-130 5299.62 33.1 38.5 7 44 31 23 17 40 29 21 16 24 18 14 20 15 11 16 12 9 7

150-160 0.74 90-150 5312.56 33.2 38.5 8 40 28 20 15 37 26 19 14 22 16 12 18 13 10 15 11 8 6

160-170 0.00 90-180 5313.30 33.2 38.6 9 38 25 18 13 35 24 17 12 20 14 10 17 12 8 14 10 7 5

170-180 0.00 180-0 13777.05 86.1 100.0 10 35 23 16 11 32 22 15 11 18 13 9 15 11 7 13 9 6 4

Zone Lumens Total Luminaire Efficiency = 73.6%

REPORT NUMBER: KP15LST0-10 266.98 CIE Type – Direct

10-20 799.41

Plane

Spacing

Criteria

Lamps: 150 W High Pressure Sodium with

Standard Dome Reflector *

20-30 1337.05

30-40 1732.06 0-180 1.46 Coefficients of Utilization - Zonal Cavity Method

40-50 2067.60 90-270 1.46 Effective Floor Cavity Reflectance 0.20

50-60 2317.60 Diagonal 1.68 % Ceiling Rcc 80 70 50 30 10 0

60-70 2210.81 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 866.77 Zonal Lumen Summary 0 88 88 88 88 86 86 86 86 82 82 82 78 78 78 75 75 75 73

80-90 145.09 Zone Lumens % Lamp % Fixture 1 79 76 72 69 77 74 71 68 71 68 66 68 66 64 65 64 62 60

90-100 14.46 0-30 2403.44 15.0 20.4 2 71 65 59 55 69 63 58 54 61 57 53 58 55 52 56 53 50 49

100-110 8.75 0-40 4135.50 25.8 35.1 3 64 56 49 44 62 55 49 44 52 47 43 50 46 42 48 45 41 40

110-120 7.93 0-60 8520.70 53.3 72.3 4 58 49 42 36 57 48 41 36 46 40 36 44 39 35 42 38 35 33

120-130 4.51 0-90 11743.37 73.4 99.7 5 53 43 36 31 52 42 35 30 40 35 30 39 34 30 38 33 29 28

130-140 2.16 90-120 31.14 0.2 0.3 6 49 38 31 26 47 38 31 26 36 30 26 35 30 25 34 29 25 24

140-150 0.48 90-130 35.65 0.2 0.3 7 45 34 27 23 44 34 27 23 33 27 22 31 26 22 30 26 22 20

150-160 0.00 90-150 38.29 0.2 0.3 8 42 31 24 20 40 31 24 20 30 24 20 29 23 19 28 23 19 18

160-170 0.00 90-180 38.29 0.2 0.3 9 39 28 22 18 38 28 22 18 27 21 17 26 21 17 25 21 17 16

170-180 0.00 180-0 11781.65 73.6 100.0 10 36 26 20 16 35 26 20 16 25 19 16 24 19 16 23 19 15 14

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

967

Mercmaster™ III HID 50-250 Watt Luminaire Photometric Data

150 W HPS

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

* Photometric data is based on xtures with

150-watt clear High Pressure Sodium lamp

(16,000 lumen).

For candlepower values of xtures with other

HPS lamps, use the following multipliers: for

70 W (6,400 lumen) HPS lamp – 0.40; for 50 W

(4,000 lumen) HPS lamp – 0.25. For candlepower

values of xture with guard, multiply by 0.95.

Zone Lumens Total Luminaire Efficiency = 73.1%

REPORT NUMBER: KP15LAN

0-10 222.62 CIE Type - Direct

10-20 664.6

Plane

Spacing

Criteria

Lamps: 150 W High Pressure Sodium with

30° Angle Dome Reflector *

20-30 1084.32

30-40 1536.55 0-180 2.06 Coefficients of Utilization - Zonal Cavity Method

40-50 1771.90 90-270 1.58 Effective Floor Cavity Reflectance 0.20

50-60 1771.51 Diagonal 1.62 % Ceiling Rcc 80 70 50 30 10 0

60-70 1668.93 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 1422.36 Zonal Lumen Summary 0 86 86 86 86 84 84 84 84 79 79 79 75 75 75 71 71 71 70

80-90 994.54 Zone Lumens % Lamp % Fixture 1 76 71 67 63 73 69 65 62 65 62 59 62 59 57 58 56 54 52

90-100 432.23 0-30 1971.54 12.3 16.9 2 68 60 54 49 65 58 53 48 55 50 46 52 48 45 49 46 43 41

100-110 104.58 0-40 3508.09 21.9 30.0 3 61 52 45 39 59 50 44 39 48 42 37 45 40 36 43 39 35 33

110-120 20.99 0-60 7051.50 44.1 60.3 4 55 45 38 32 53 44 37 32 42 36 31 39 34 30 37 33 29 27

120-130 1.21 0-90 11137.33 69.6 95.2 5 50 40 33 27 49 39 32 27 37 31 26 35 30 25 33 29 25 23

130-140 0.04 90-120 557.80 3.5 4.8 6 46 36 28 23 45 35 28 23 33 27 22 31 26 22 30 25 21 20

140-150 0.00 90-130 559.01 3.5 4.8 7 43 32 25 20 41 31 25 20 30 24 19 28 23 19 27 22 19 17

150-160 0.00 90-150 559.04 3.5 4.8 8 40 29 22 18 38 28 22 17 27 21 17 26 21 17 25 20 16 15

160-170 0.00 90-180 559.04 3.5 4.8 9 37 26 20 16 36 26 20 16 25 19 15 24 19 15 23 18 15 13

170-180 0.00 180-0 11696.38 73.1 100.0 10 35 24 18 14 33 24 18 14 23 17 14 22 17 13 21 16 13 12

Zone Lumens Total Luminaire Efficiency = 81.1%

REPORT NUMBER: KP15LJR50-10 72.83 CIE Type - Semi- Direct

10-20 222.26

Plane

Spacing

Criteria

Lamps: 150 W High Pressure Sodium with

8” Prismatic Glass Refracter - NEMA Type V *

20-30 380.73

30-40 621.11 0-180 1.98 Coefficients of Utilization - Zonal Cavity Method

40-50 852.53 90-270 1.98 Effective Floor Cavity Reflectance 0.20

50-60 1765.29 Diagonal 3.40 % Ceiling Rcc 80 70 50 30 10 0

60-70 3192.58 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 2366.61 Zonal Lumen Summary 0 93 93 93 93 89 89 89 89 82 82 82 76 76 76 70 70 70 67

80-90 1230.65 Zone Lumens % Lamp % Fixture 1 80 73 68 63 76 70 65 61 64 60 56 58 55 52 53 50 48 45

90-100 450.14 0-30 675.83 4.2 5.2 2 69 59 51 45 65 56 49 43 51 45 40 46 41 37 41 37 34 31

100-110 712.41 0-40 1296.93 8.1 10.0 3 61 49 40 33 57 47 38 32 42 35 29 38 32 27 34 29 25 22

110-120 499.15 0-60 3914.76 24.5 30.2 4 54 42 32 25 51 40 31 24 35 28 22 32 26 21 28 23 19 16

120-130 323.44 0-90 10704.60 66.9 82.5 5 49 36 27 20 46 34 26 19 31 23 18 27 21 16 24 19 15 12

130-140 185.00 90-120 1661.70 10.4 12.8 6 45 32 23 16 42 30 22 16 27 20 14 24 18 13 21 16 12 10

140-150 81.31 90-130 1985.14 12.4 15.3 7 41 28 20 14 38 27 19 13 24 17 12 21 15 11 19 14 10 8

150-160 21.08 90-150 2251.45 14.1 15.3 8 38 25 17 12 36 24 16 11 22 15 10 19 14 9 17 12 8 6

160-170 2.81 90-180 2275.34 14.2 17.5 9 35 23 15 10 33 22 15 10 20 13 9 18 12 8 16 11 7 5

170-180 0.00 180-0 12979.94 81.1 100.0 10 33 21 14 9 31 20 13 9 18 12 8 16 11 7 15 10 6 5

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

968

Mercmaster™ III HID 50-250 Watt Luminaire Photometric Data

150 W HPS

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

* Photometric data is based on xtures with a

175-watt clear Pulse Start Metal Halide lamp

(17,500 lumen).

For candlepower values of xtures with other

PSMH lamps, use the following multipliers: for a

100 W (8,500 lumen) PSMH lamp – 0.49; for a 70

W (6,200 lumen) PSMH lamp – 0.36; for a 200 W

(21,000 lumen) PSMH lamp – 1.2. For candlepower

values of xture with guard, multiply by 0.95.

Zone Lumens Total Luminaire Efficiency = 75.4%

REPORT NUMBER: KP17PG

0-10 57.98 CIE Type - General Diffuse

10-20 217.30 Lamps: 175 W Pulse Start Metal Halide with Globe only *

20-30 372.71

30-40 696.29 Coefficients of Utilization - Zonal Cavity Method

40-50 1009.65 Effective Floor Cavity Reflectance 0.20

50-60 1226.57 % Ceiling Rcc 80 70 50 30 10 0

60-70 1473.76 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 1757.30 Zonal Lumen Summary 0 93 93 93 93 87 87 87 87 75 75 75 64 64 64 54 54 54 50

80-90 1902.34 Zone Lumens % Lamp % Fixture 1 79 73 68 63 73 68 63 59 58 54 50 48 45 43 40 37 35 31

90-100 1946.09 0-30 647.99 3.7 4.3 2 70 61 54 47 65 57 50 44 48 42 38 39 35 32 32 29 26 22

100-110 1829.51 0-40 1344.28 7.7 9.0 3 63 52 44 37 58 48 41 35 40 34 29 33 28 24 27 23 20 16

110-120 1657.20 0-60 3580.49 20.5 24.0 4 57 45 37 30 52 42 34 28 35 29 24 29 24 20 23 19 16 12

120-130 750.27 0-90 8713.89 49.8 58.4 5 52 40 31 25 47 37 29 23 31 24 20 25 20 16 20 16 13 10

130-140 14.15 90-120 5432.80 31.0 36.4 6 47 35 27 21 43 32 25 19 27 21 17 22 17 14 18 14 11 8

140-150 4.47 90-130 6183.06 35.3 41.4 7 44 31 23 18 40 29 22 17 24 18 14 20 15 12 16 12 9 7

150-160 0.52 90-150 6201.69 35.4 41.6 8 40 28 21 15 37 26 19 14 22 16 12 18 14 10 15 11 8 6

160-170 1.35 90-180 6203.74 35.4 41.6 9 37 26 18 13 34 24 17 13 20 15 11 17 12 9 13 10 7 5

170-180 0.18 180-0 14917.63 85.2 100.0 10 35 23 16 12 32 22 15 11 18 13 9 15 11 8 12 9 6 4

Zone Lumens Total Luminaire Efficiency = 72.3%

REPORT NUMBER: KP17PST0-10 285.95 CIE Type - Direct

10-20 876.46

Plane

Spacing

Criteria

Lamps: 175 W Pulse Start Metal Halide with

Standard Dome Reflector *

20-30 1472.88

30-40 1924.39 0-180 1.50 Coefficients of Utilization - Zonal Cavity Method

40-50 2213.42 90-270 1.50 Effective Floor Cavity Reflectance 0.20

50-60 2305.55 Diagonal 1.66 % Ceiling Rcc 80 70 50 30 10 0

60-70 2256.32 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 1115.75 Zonal Lumen Summary 0 86 86 86 86 84 84 84 84 80 80 80 77 77 77 74 74 74 72

80-90 198.05 Zone Lumens % Lamp % Fixture 1 78 74 71 68 76 72 69 67 69 67 65 67 64 63 64 62 61 59

90-100 3.56 0-30 2635.28 15.1 20.8 2 70 63 58 54 68 62 57 53 59 55 52 57 54 50 55 52 49 48

100-110 0.00 0-40 4559.67 26.1 36.0 3 63 55 48 43 61 54 48 43 51 46 42 49 45 41 47 44 41 39

110-120 0.00 0-60 9078.64 51.9 71.8 4 57 48 41 36 56 47 40 35 45 39 35 43 38 34 42 37 34 32

120-130 0.00 0-90 12648.77 72.3 100.0 5 52 42 35 30 51 41 35 30 40 34 30 38 33 29 37 32 29 27

130-140 0.00 90-120 3.56 0.00 0.00 6 48 38 31 26 47 37 30 26 36 30 25 34 29 25 33 29 25 23

140-150 0.00 90-130 3.56 0.00 0.00 7 44 34 27 22 43 33 27 22 32 26 22 31 26 22 30 25 22 20

150-160 0.00 90-150 3.56 0.00 0.00 8 41 31 24 20 40 30 24 20 29 24 19 28 23 19 27 23 19 18

160-170 0.00 90-180 3.56 0.00 0.00 9 38 28 22 18 37 28 22 17 27 21 17 26 21 17 25 21 17 16

170-180 0.00 180-0 12652.33 72.3 100.0 10 36 26 20 16 35 25 20 16 25 19 16 24 19 15 23 19 15 14

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

969

Mercmaster™ III HID 50-250 Watt Luminaire Photometric Data

175 W PSMH

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

* Photometric data is based on xtures with a

175-watt clear Pulse Start Metal Halide lamp

(17,500 lumen).

For candlepower values of xtures with other

PSMH lamps, use the following multipliers: for

a 100 W (8,500 lumen) PSMH lamp – 0.49; for 70

W (6,200 lumen) PSMH lamp – 0.36; for a 200 W

(21,000 lumen) PSMH lamp – 1.2. For candlepower

values of xture with guard, multiply by 0.95.

Zone Lumens Total Luminaire Efficiency = 67.1%

REPORT NUMBER: KP17PAN

0-10 240.21 CIE Type - Direct

10-20 750.99

Plane

Spacing

Criteria

Lamps: 175 W Pulse Start Metal Halide with

30° Angle Dome Reflector *

20-30 1195.39

30-40 1662.85 0-180 1.96 Coefficients of Utilization - Zonal Cavity Method

40-50 1830.67 90-270 1.70 Effective Floor Cavity Reflectance 0.20

50-60 1740.13 Diagonal 1.56 % Ceiling Rcc 80 70 50 30 10 0

60-70 1571.75 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 1324.18 Zonal Lumen Summary 0 79 79 79 79 77 77 77 77 73 73 73 69 69 69 66 66 66 64

80-90 900.65 Zone Lumens % Lamp % Fixture 1 70 66 62 59 68 64 61 58 60 58 55 57 55 53 54 52 51 49

90-100 367.96 0-30 2186.59 12.5 18.6 2 63 56 51 46 61 55 49 45 52 47 44 49 45 42 46 43 41 39

100-110 107.38 0-40 3849.44 22.0 32.8 3 57 48 42 37 55 47 41 37 45 40 36 42 38 35 40 37 34 32

110-120 27.79 0-60 7420.24 42.4 63.2 4 51 42 36 31 50 41 35 30 39 34 30 37 33 29 35 31 28 26

120-130 5.54 0-90 11216.82 64.1 95.6 5 47 38 31 26 45 37 30 26 35 29 25 33 28 25 32 27 24 22

130-140 4.20 90-120 503.12 2.9 4.3 6 43 34 27 22 42 33 27 22 31 26 22 30 25 21 28 24 21 19

140-150 4.42 90-130 508.66 2.9 4.3 7 40 30 24 20 39 30 24 19 28 23 19 27 22 19 26 22 18 17

150-160 2.00 90-150 517.28 3.0 4.4 8 37 27 21 17 36 27 21 17 26 20 17 25 20 16 24 19 16 15

160-170 1.70 90-180 521.31 3.0 4.4 9 35 25 19 15 33 25 19 15 24 18 15 23 18 15 22 18 14 13

170-180 0.33 180-0 11738.13 67.1 100.0 10 32 23 17 14 31 23 17 14 22 17 13 21 16 13 20 16 13 12

Zone Lumens Total Luminaire Efficiency = 81.1%

REPORT NUMBER: KP17PJR5

0-10 22.77 CIE Type - Semi-Direct

10-20 171.20

Plane

Spacing

Criteria

Lamps: 175 W Pulse Start Metal Halide with

8” Prismatic Glass Refracter - NEMA Type V *

20-30 325.41

30-40 531.35 0-180 1.66 Coefficients of Utilization - Zonal Cavity Method

40-50 1173.62 90-270 1.64 Effective Floor Cavity Reflectance 0.20

50-60 1165.11 Diagonal 1.92 % Ceiling Rcc 80 70 50 30 10 0

60-70 3171.29 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 3719.35 Zonal Lumen Summary 0 94 94 94 94 90 90 90 90 83 83 83 77 77 77 71 71 71 69

80-90 1751.05 Zone Lumens % Lamp % Fixture 1 78 71 65 60 74 68 62 57 62 57 53 57 53 49 51 48 46 43

90-100 523.23 0-30 519.38 3.0 3.7 2 67 57 48 41 63 54 46 39 49 42 36 44 38 33 39 35 31 28

100-110 716.53 0-40 1050.73 6.0 7.4 3 59 46 37 29 55 44 35 28 40 32 26 35 29 24 32 26 22 19

110-120 431.18 0-60 3389.46 19.4 23.9 4 52 39 30 22 49 37 28 21 33 26 20 30 23 18 26 21 16 14

120-130 265.20 0-90 12031.16 68.7 84.8 5 47 34 24 17 45 32 23 17 29 21 15 26 19 14 23 17 13 10

130-140 142.69 90-120 1670.94 9.5 11.8 6 43 30 21 14 41 28 20 14 25 18 12 23 16 11 20 15 10 8

140-150 57.09 90-130 1936.15 11.1 13.7 7 40 27 18 12 37 23 17 11 23 16 10 20 14 9 18 13 8 6

150-160 13.48 90-150 2135.93 12.2 15.1 8 37 24 16 10 35 23 15 10 20 14 9 18 12 8 16 11 7 5

160-170 2.44 90-180 2152.72 12.3 15.2 9 34 22 14 9 32 21 13 8 19 12 8 17 11 7 15 10 6 4

170-180 0.88 180-0 14183.88 81.1 100.0 10 32 20 12 8 30 19 12 7 17 11 7 16 10 6 14 9 5 4

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

970

Mercmaster™ III HID 50-250 Watt Luminaire Photometric Data

175 W PSMH

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Degree Candela Lumens TOTAL LUMINAIRE EFFICIENCY = 70.8% REPORT NUMBER: KPB175PG3

Lamps: 175 W Pulse Start Metal Halide ED28 Mogul Base with

G3 Globe only

0657 CIE Type – Semi-Direct

5668 65 SpacingCriteria:1.7

15 784 224

25 966 451

35 1194 705 COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

45 871 711 EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

55 1267 1142 RC 80 70 50 30 10 0

65 1309 1303 RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

75 1430 1509 0 78 78 78 78 73 73 73 73 64 64 64 56 56 56 48 48 48 44

85 1528 1661 1 67 61 57 53 62 57 53 49 49 46 43 42 39 37 35 33 31 28

90 1537 ZONAL LUMEN SUMMARY 2 59 51 45 40 54 48 42 37 41 36 32 34 31 27 28 26 23 20

95 1552 1680 ZONE LUMENS %LAMP %FIXT. 3 53 44 37 31 49 40 34 29 34 29 25 29 25 21 24 21 18 15

105 1452 1532 0-30 740 4.2 6.0 4 48 38 31 25 44 35 29 24 30 25 20 25 21 17 21 17 14 12

115 1339 1232 0-40 1445 8.3 11.7 5 43 33 26 21 40 31 24 20 26 21 17 22 18 14 18 15 12 9

125 68 143 0-60 3297 18.8 26.6 6 40 29 23 18 37 27 21 16 23 18 14 20 15 12 16 13 10 8

135 19 16 0-90 7770 44.4 62.7 7 37 26 20 15 34 25 18 14 21 16 12 18 13 10 15 11 9 7

145 13 11 90-120 4444 25.4 35.9 8 34 24 17 13 31 22 16 12 19 14 11 16 12 9 13 10 7 6

155 7 3 90-130 4586 26.2 37.0 9 32 22 16 11 29 20 15 11 17 13 9 15 11 8 12 9 7 5

165 1 1 90-150 4613 26.4 37.2 10 29 20 14 10 27 18 13 9 16 11 8 14 10 7 11 8 6 4

175 2 0 90-180 4617 26.4 37.3

180 7 0-180 12387 70.8 100.0

Degree Candela Lumens TOTAL LUMINAIRE EFFICIENCY = 65.6% REPORT NUMBER: KPB175PG3_ST

Lamps: 175 W Pulse Start Metal Halide ED28 Mogul Base with

G3 Globe and Standard Dome Reflector

02785 CIE Type – Direct

950

1500

2850

0°15°30°

90°

75°

60°

45°

52797 269 SpacingCriteria:1.5

15 2902 823

25 2931 1358

35 2979 1821 COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

45 2388 1874 EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

55 2393 2145 RC 80 70 50 30 10 0

65 2044 2034 RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

75 664 856 0 78 78 78 78 76 76 76 76 73 73 73 69 69 69 66 66 66 65

85 150 183 1 71 67 64 62 69 66 63 61 63 61 59 60 58 57 58 56 55 53

90 24 ZONAL LUMEN SUMMARY 2 64 58 53 49 62 57 52 48 54 50 47 52 49 46 50 47 45 43

95 5 11 ZONE LUMENS %LAMP %FIXT. 3 58 50 44 40 56 49 44 39 47 42 39 45 41 38 43 40 37 35

105 16 17 0-30 2450 14.0 21.3 4 52 44 38 33 51 43 37 33 41 36 32 39 35 32 38 34 31 29

115 91 73 0-40 4271 24.4 37.2 5 48 39 32 28 46 38 32 28 36 31 27 35 30 27 34 30 26 25

125 5 9 0-60 8290 47.4 72.2 6 44 35 28 24 42 34 28 24 33 27 23 31 27 23 30 26 23 21

135 7 3 0-90 11363 64.9 99.0 7 40 31 25 21 39 30 25 21 29 24 20 28 24 20 27 23 20 19

145 8 2 90-120 101 0.6 0.9 8 37 28 22 18 36 28 22 18 27 22 18 26 21 18 25 21 18 16

155 2 2 90-130 110 0.6 1.0 9 35 26 20 16 34 25 20 16 24 19 16 24 19 16 23 19 16 15

165 2 0 90-150 115 0.7 1.0 10 33 24 18 15 32 23 18 15 23 18 14 22 17 14 21 17 14 13

175 2 1 90-180 118 0.7 1.0

180 11 0-180 11481 65.6 100.0

Candela Distribution TOTAL LUMINAIRE EFFICIENCY = 58.2% REPORT NUMBER: KPB175PG3_AN

Lamps: 175 W Pulse Start Metal Halide ED28 Mogul Base with

G3 Globe and 30° Angle Dome Reflector

0.0 45.0 90.0 135.0 180.0 Flux CIE Type – Direct

0-deg

90-deg

180-deg

LEGEND

02333 2333 2333 2333 2333

Plane

Spacing

Criteria

52491 2467 2321 2205 2141 223

15 2904 2753 2337 2160 2099 692

0° 1.8

25 3010 2891 2480 2242 2120 1170

90° 1.5 COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

35 3471 3100 2544 2027 1367 1512

180° 1.1 EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

45 2978 2719 1993 832 546 1427

RC 80 70 50 30 10 0

55 3296 2939 1791 421 154 1533

RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

65 3153 2801 776 74 0 1349

0 69 69 69 69 67 67 67 67 63 63 63 60 60 60 57 57 57 56

75 3175 2621 392 3 0 1140

1 61 57 54 51 59 56 53 50 53 50 48 50 48 46 48 46 45 43

85 2729 967 117 5 0 709

2 55 49 44 40 53 48 43 40 45 42 38 43 40 37 41 38 36 34

90 1601 662 11 5 5

ZONAL LUMEN SUMMARY 3 49 42 37 33 48 41 36 32 39 35 31 37 34 31 35 32 30 28

95 790 461 3 11 16 247

ZONE LUMENS %LAMP %FIXT. 4 45 37 32 27 43 36 31 27 34 30 26 33 29 26 31 28 25 24

105 413 175 11 19 21 109

0-30 2085 11.9 20.5 5 41 33 27 23 40 32 27 23 31 26 22 29 25 22 28 24 21 20

115 117 8 8 29 90 56

0-40 3597 20.6 35.3 6 38 30 24 20 37 29 24 20 28 23 19 26 22 19 25 22 19 17

125 5 11 13 13 11 2

0-60 6557 37.5 64.4 7 35 27 21 18 34 26 21 17 25 20 17 24 20 17 23 19 16 15

135 0 3 3 3 0 1

0-90 9755 55.7 95.8 8 33 24 19 16 32 24 19 15 23 18 15 22 18 15 21 17 15 13

145 5 5 11 5 0 4

90-120 412 2.4 4.1 9 30 22 17 14 29 22 17 14 21 17 14 20 16 13 19 16 13 12

155 0 3 5 5 0 2

90-130 415 2.4 4.1 10 28 20 16 12 28 20 15 12 19 15 12 19 15 12 18 14 12 11

165 5 3 8 5 0 1

90-150 420 2.4 4.1

175 0 5 3 3 0 0

90-180 423 2.4 4.2

180 6666 6

0-180 10178 58.2 100.0

* Photometric data is based on xtures with a

175-watt clear Pulse Start Metal Halide lamp

(17,500 lumen).

For candlepower values of xtures with other

PSMH lamps, use the following multipliers: for a

100 W (8,500 lumen) PSMH lamp – 0.49; for a 70

W (6,200 lumen) PSMH lamp – 0.36; for a 200 W

(21,000 lumen) PSMH lamp – 1.2. For candlepower

values of xture with guard, multiply by 0.95.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

971

Mercmaster™ III HID 50-250 Watt Luminaire Photometric Data

175 W PSMH

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Degree Candela Lumens TOTAL LUMINAIRE EFFICIENCY = 84.1% REPORT NUMBER: KPB100LG3

Lamps: 100 W High Pressure Sodium C100S54 ED23 - 1/2

Mogul Base with G3 Globe only

0269 CIE Type – Semi-Direct

5267 27 SpacingCriteria:3.1

15 407 117

25 571 267

35 748 442 COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

45 451 380 EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

55 848 735 RC 80 70 50 30 10 0

65 915 908 RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

75 976 1033 0 93 93 93 93 87 87 87 87 76 76 76 66 66 66 57 57 57 53

85 1021 1113 1 79 72 67 62 73 67 62 58 58 54 50 49 46 43 41 39 36 32

90 1027 ZONAL LUMEN SUMMARY 2 69 60 52 46 64 56 49 43 48 42 37 40 36 32 33 30 26 23

95 1019 1109 ZONE LUMENS %LAMP %FIXT. 3 62 51 43 36 57 47 40 34 40 34 29 34 29 24 28 24 20 17

105 953 1002 0-30 410 4.3 5.1 4 56 44 36 29 51 41 33 27 35 28 23 29 24 20 24 19 16 13

115 791 734 0-40 852 9.0 10.7 5 51 39 30 24 47 36 28 22 30 24 19 25 20 16 21 17 13 10

125 54 103 0-60 1967 20.7 24.6 6 47 34 26 20 43 32 24 19 27 21 16 23 17 13 19 14 11 8

135 13 9 0-90 5021 52.9 62.9 7 43 31 23 17 40 28 21 16 24 18 14 20 15 13 17 13 9 7

145 13 8 90-120 2845 29.9 35.6 8 40 28 20 15 37 26 19 14 22 16 12 19 14 10 15 11 8 6

155 4 2 90-130 2948 31.0 36.9 9 37 25 18 13 34 23 17 12 20 14 10 17 12 9 14 10 7 5

165 0 0 90-150 2965 31.2 37.1 10 34 23 16 11 32 21 15 11 18 13 9 16 11 8 13 9 6 5

175 0 0 90-180 2967 31.2 37.1

180 1 0-180 7988 84.1 100.0

Degree Candela Lumens TOTAL LUMINAIRE EFFICIENCY = 72.9% REPORT NUMBER: KPB100LG3_ST

Lamps: 100 W High Pressure Sodium C100S54 ED23 - 1/2

Mogul Base with G3 Globe and Standard Dome Reflector

01466 CIE Type – Direct

51473 142 SpacingCriteria:1.6

15 1607 456

25 1675 775

35 1757 1071 COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

45 1316 1047 EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

55 1502 1316 RC 80 70 50 30 10 0

65 1377 1362 RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

75 465 589 0 87 87 87 87 85 85 85 85 81 81 81 77 77 77 74 74 74 72

85 92 111 1 78 74 71 68 76 73 70 67 70 67 65 67 64 62 64 62 60 59

90 16 ZONAL LUMEN SUMMARY 2 70 64 58 53 68 62 57 53 59 55 51 57 53 50 54 52 49 47

95 3 5 ZONE LUMENS %LAMP %FIXT. 3 63 55 48 43 61 54 47 43 51 46 42 49 45 41 47 43 40 38

105 6 6 0-30 1373 14.5 19.8 4 57 48 41 35 55 47 40 35 45 39 34 43 38 34 41 37 33 32

115 40 33 0-40 2445 25.7 35.3 5 52 42 35 30 51 41 34 29 39 34 29 38 33 29 36 32 28 26

125 5 8 0-60 4807 50.6 69.4 6 48 37 30 25 46 37 30 25 35 29 25 34 29 25 33 28 24 23

135 3 2 0-90 6869 72.3 99.2 7 44 34 27 22 43 33 26 22 32 26 22 31 25 21 29 25 21 20

145 3 1 90-120 45 0.5 0.6 8 41 30 24 19 40 30 24 19 29 23 19 28 23 19 27 22 19 17

155 2 1 90-130 53 0.6 0.8 9 38 23 21 17 37 27 21 17 26 21 17 25 20 17 25 20 17 15

165 0 1 90-150 56 0.6 0.8 10 36 25 19 15 35 25 19 15 24 19 15 23 19 15 23 18 15 14

175 1 0 90-180 58 0.6 0.8

180 1 0-180 6927 72.9 100.0

Candela Distribution TOTAL LUMINAIRE EFFICIENCY = 65.0% REPORT NUMBER: KPB100LG3_AN

Lamps: 100 W High Pressure Sodium C100S54 ED23 - 1/2

Mogul Base with G3 Globe and 30° Angle Reflector

0.0 45.0 90.0 135.0 180.0 Flux CIE Type – Direct

0-deg

90-deg

180-deg

LEGEND

1270 1270 1270 1270 1270

Plane

Spacing

Criteria5

1317 1302 1271 1227 1211 122

1554 1471 1384 1341 1298 398

0° 1.9

1779 1680 1528 1353 1246 694

90° 1.7 COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

1923 1830 1593 1256 1020 917

180° 1.3 EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

1715 1564 1163 599 361 848

RC 80 70 50 30 10 0

1981 1862 1100 287 122 953

RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

1923 1751 869 104 0 869

0 77 77 77 77 75 75 75 75 71 71 71 67 67 67 64 64 64 62

1879 1272 298 9 0 711

1 68 64 61 57 66 62 59 56 59 56 54 56 54 52 53 51 50 48

1371 828 140 1 0 424

2 61 55 49 45 59 53 48 44 50 46 43 48 44 41 45 42 40 38

680 422 89 2 1

ZONAL LUMEN SUMMARY 3 55 47 41 36 53 46 40 36 44 39 35 41 37 34 39 36 33 31

416 259 47 4 4 144

ZONE LUMENS %LAMP %FIXT. 4 50 41 35 30 48 40 34 30 38 33 29 36 32 28 35 31 28 26

105

191 93 4 7 6 59

0-30 1213 12.8 19.7 5 46 37 30 25 44 36 30 25 34 29 25 32 28 24 31 27 24 22

115

40 18 51 54 92 31

0-40 2131 22.4 34.5 6 42 33 26 22 41 32 26 22 30 25 21 29 24 21 28 24 20 19

125

133312

0-60 3932 41.4 63.7 7 39 30 23 19 38 29 23 19 28 22 19 26 22 18 25 21 18 17

135

123211

0-90 5936 62.5 96.1 8 36 27 21 17 35 26 21 17 25 20 16 24 20 16 23 19 16 15

145

012001

90-120 234 2.5 3.8 9 34 25 19 15 33 24 19 15 23 18 15 22 18 14 21 17 14 13

155

012101

90-130 236 2.5 3.8 10 32 23 17 14 31 22 17 13 21 17 13 20 16 13 20 16 13 12

165

011100

90-150 238 2.5 3.9

175

222100

90-180 239 2.5 3.9

180

22222

0-180 6175 65.0 100.0

* Photometric data is based on xtures with a

100-watt clear High Pressure Sodium lamp

(9,400 lumen).

For candlepower values of xtures with other

HPS lamps, use the following multipliers: for a 70

W (6,400 lumen) HPS lamp – 0.68; for 50 W (4,000

lumen) HPS lamp – 0.43; for candlepower values

of xture with guard, multiply by 0.95.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

972

Mercmaster™ III HID 50-250 Watt Luminaire Photometric Data

100 W HPS

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Degree Candela Lumens TOTAL LUMINAIRE EFFICIENCY = 81.1% REPORT NUMBER: KPB150LG3

Lamps: 150 W High Pressure Sodium C100S54 ED23 - 1/2 Mogul

Base with G3 Globe only

0488 CIE Type – Semi-Direct

5459 46 SpacingCriteria:3.0

15 703 202

25 938 442

35 1107 672 COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

45 892 710 EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

55 1420 1253 RC 80 70 50 30 10 0

65 1542 1529 RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

75 1629 1723 0 90 90 90 90 84 84 84 84 74 74 74 65 65 65 56 56 56 53

85 1675 1824 1 76 70 65 60 71 65 60 56 56 53 49 48 45 42 41 38 36 32

90 1665 ZONAL LUMEN SUMMARY 2 67 58 51 44 62 54 47 42 46 41 36 39 35 31 33 29 26 23

95 1643 1788 ZONE LUMENS %LAMP %FIXT. 3 60 49 41 34 55 46 38 32 39 33 28 33 28 24 27 23 20 17

105 1515 1599 0-30 689 4.3 5.3 4 54 43 34 29 50 40 32 26 34 27 22 28 23 19 23 19 16 13

115 1072 1042 0-40 1361 8.5 10.5 5 49 37 29 23 45 35 27 21 30 23 18 25 20 16 21 16 13 10

125 51 115 0-60 3324 20.8 25.6 6 45 33 25 19 42 31 23 18 26 20 15 22 17 13 18 14 11 8

135 20 16 0-90 8400 52.5 64.7 7 41 30 22 16 38 27 20 15 24 18 13 20 15 11 16 12 9 7

145 19 12 90-120 4429 27.7 34.1 8 38 27 19 14 35 25 18 13 21 16 11 18 13 10 15 11 8 6

155 6 4 90-130 4544 28.4 35.0 9 36 24 17 12 33 23 16 12 19 14 10 17 12 8 14 10 7 5

165 1 0 90-150 4572 28.6 35.2 10 33 22 15 11 31 21 14 10 18 12 9 15 11 7 13 9 6 4

175 0 0 90-180 4576 28.6 35.3

180 2 0-180 12976 81.1 100.0

Degree Candela Lumens TOTAL LUMINAIRE EFFICIENCY = 69.6% REPORT NUMBER: KPB150LG3_ST

Lamps: 150 W High Pressure Sodium C100S54 ED23 - 1/2 Mogul

Base with G3 Globe and Standard Dome Reflector

02403 CIE Type – Direct

52391 230 SpacingCriteria:1.6

15 2624 744

25 2678 1247

35 2705 1673 COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

45 2250 1754 EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

55 2444 2161 RC 80 70 50 30 10 0

65 2246 2192 RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

75 655 851 0 83 83 83 83 81 81 81 81 77 77 77 74 74 74 70 70 70 69

85 147 174 1 75 71 68 65 73 70 67 64 66 64 62 64 62 60 61 59 58 56

90 26 ZONAL LUMEN SUMMARY 2 67 61 56 51 65 60 55 51 57 53 49 54 51 48 52 49 47 45

95 6 8 ZONE LUMENS %LAMP %FIXT. 3 61 52 46 41 59 51 46 41 49 44 40 47 43 39 45 41 38 37

105 11 13 0-30 2221 13.9 19.9 4 55 46 39 34 53 45 38 34 43 37 33 41 36 33 39 35 32 30

115 73 71 0-40 3895 24.3 35.0 5 50 40 33 28 48 39 33 28 38 32 28 36 31 27 35 31 27 25

125 7 12 0-60 7809 48.8 70.1 6 46 36 29 24 44 35 29 24 34 28 24 32 27 24 31 27 23 22

135 6 3 0-90 11027 68.9 99.0 7 42 32 26 21 41 32 25 21 30 25 21 29 24 20 28 24 20 19

145 4 2 90-120 92 0.6 0.8 8 39 29 23 18 38 29 23 18 28 22 18 27 22 18 26 22 18 16

155 4 2 90-130 104 0.6 0.9 9 36 27 20 16 35 26 20 16 25 20 16 24 20 16 24 19 16 15

165 2 1 90-150 109 0.7 1.0 10 34 24 19 15 33 24 18 15 23 18 14 22 18 14 22 17 14 13

175 2 0 90-180 112 0.7 1.0

180 1 0-180 11139 69.6 100.0

Candela Distribution TOTAL LUMINAIRE EFFICIENCY = 61.0% REPORT NUMBER: KPB150LG3_AN

Lamps: 150 W High Pressure Sodium C100S54 ED23 - 1/2 Mogul

Base with G3 Globe and 30° Angle Reflector

0.0 45.0 90.0 135.0 180.0 Flux CIE Type – Direct

0-deg

90-deg

180-deg

LEGEND

01964 1964 1964 1964 1964

Plane

Spacing

Criteria

52035 2007 1941 1871 1838 187

15 2375 2307 2140 2047 2037 619

0° 2.0

25 2755 2587 2288 2095 1853 1081

90° 1.7 COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

35 2924 2763 2415 1885 1276 1416

180° 1.3 EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

45 2790 2552 2015 780 518 1368

RC 80 70 50 30 10 0

55 3166 2937 1945 410 157 1520

RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

65 3188 2913 777 77 0 1380

0 72 72 72 72 70 70 70 70 66 66 66 63 63 63 60 60 60 58

75 3145 2547 408 1 2 1118

1 64 60 57 54 62 58 55 53 55 53 50 52 50 48 50 48 47 45

85 2533 927 117 0 2 663

2 57 51 46 42 55 50 45 41 47 43 40 45 41 39 42 40 37 36

90 1490 640 14 5 9

ZONAL LUMEN SUMMARY 3 52 44 38 34 50 43 38 33 41 36 33 39 35 32 37 33 31 29

95 765 449 5 8 11 239

ZONE LUMENS %LAMP %FIXT. 4 47 39 33 28 45 38 32 28 36 31 27 34 30 26 32 29 26 24

105 380 163 6 11 15 106

0-30 1886 11.8 19.3 5 43 34 28 24 41 33 28 24 32 27 23 30 26 22 29 25 22 21

115 114 4 6 18 63 44

0-40 3302 20.6 33.8 6 39 31 25 20 38 30 24 20 28 24 20 27 23 19 26 22 19 18

125 257875

0-60 6190 38.7 63.5 7 36 28 22 18 35 27 22 18 26 21 17 25 20 17 24 20 17 15

135 267864

0-90 9351 58.4 95.9 8 34 25 20 16 33 24 19 16 23 19 15 22 18 15 22 18 15 14

145 026423

90-120 389 2.4 4.0 9 32 23 18 14 30 22 17 14 21 17 14 21 16 13 20 16 13 12

155 246642

90-130 395 2.5 4.0 10 30 21 16 13 29 21 16 12 20 15 12 19 15 12 18 15 12 11

165 435421

90-150 401 2.5 4.1

175 023320

90-180 404 2.5 4.1

180 22222

0-180 9754 61.0 100.0

* Photometric data is based on xtures with a

150-watt clear High Pressure Sodium lamp

(16,000 lumen).

For candlepower values of xtures with other

HPS lamps, use the following multipliers: for a

70 W (6,400 lumen) HPS lamp – 0.40; for a 50 W

(4,000 lumen) HPS lamp – 0.25. For candlepower

values of xture with guard, multiply by 0.95.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

973

Mercmaster™ III HID 50-250 Watt Luminaire Photometric Data

150 W HPS

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Zone Lumens TOTAL LUMINAIRE EFFICIENCY = 67.4% REPORT NUMBER: KPBG250PAN

Lamps: 250 W Metal Halide Pulse Start

Mogul Base

0-10 307.05 CIE Type – Direct

10-20 986.27 SpacingCriteria:2.16

20-30 1556.63

30-40 2215.28

40-50 2539.71 COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

50-60 2525.66 EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

60-70 2313.2 RC 80 70 50 30 10 0

70-80 1992.57 RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

80-90 1470.76 0 79 79 79 79 77 77 77 77 73 73 73 69 69 69 65 65 65 64

90-100 689.06 1 70 65 62 58 67 63 60 57 60 57 54 56 54 52 53 51 50 48

100-110 177.72 ZONAL LUMEN SUMMARY 2 62 55 50 45 60 54 49 44 51 46 43 48 44 41 45 42 39 38

110-120 46 ZONE LUMENS %LAMP %FIXT. 3 56 48 41 36 54 46 40 36 44 39 34 41 37 33 39 35 32 30

120-130 10.39 0-30 2849.95 11.4 16.9 4 51 42 35 30 49 41 34 29 38 33 29 36 31 28 34 30 27 25

130-140 6.24 0-40 5065.22 20.3 30.1 5 47 37 30 25 45 36 30 25 34 28 24 32 27 23 30 26 23 21

140-150 5.71 0-60 10130.59 40.5 60.1 6 43 33 26 21 41 32 26 21 30 25 21 29 24 20 27 23 20 18

150-160 3.95 0-90 15907 63.6 94.4 7 40 30 23 19 38 29 23 18 27 22 18 26 21 18 25 20 17 16

160-170 2.26 90-120 912.78 3.7 5.4 8 37 27 21 16 35 26 20 16 25 20 16 24 19 16 23 18 15 14

170-180 .8 90-130 923.17 3.7 5.5 9 34 24 19 15 33 24 18 14 23 18 14 22 17 14 21 17 14 12

90-150 935.11 3.7 5.5 10 32 22 17 13 31 22 17 13 21 16 13 20 16 12 19 15 12 11

90-180 942.12 3.8 5.6

0-180 16849.24 67.4 100.0

Zone Lumens TOTAL LUMINAIRE EFFICIENCY = 72.6% REPORT NUMBER: KPBG250PST

Lamps: 250 W Metal Halide Pulse Start

Mogul Base

0-10 382.83 CIE Type – Direct

10-20 1200.76 SpacingCriteria:1.58

20-30 1987.77

30-40 2662.58

40-50 3136.15 COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

50-60 3436.26 EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

60-70 3412.32 RC 80 70 50 30 10 0

70-80 1660.08 RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

80-90 278.17 0 86 86 86 86 84 84 84 84 81 81 81 77 77 77 74 74 74 73

90-100 3.43 1 78 74 71 68 76 73 70 67 70 67 65 67 65 63 64 62 61 59

100-110 0 ZONAL LUMEN SUMMARY 2 70 63 58 53 68 62 57 53 59 55 51 57 53 50 55 52 49 47

110-120 0ZONE LUMENS %LAMP %FIXT. 3 63 55 48 43 61 53 47 42 51 46 42 49 45 41 47 43 40 38

120-130 0 0-30 3571.36 14.3 19.7 4 57 48 41 35 55 47 40 35 45 39 34 43 38 34 41 37 33 32

130-140 0 0-40 6233.94 24.9 34.3 5 52 42 35 30 50 41 34 29 39 34 29 38 33 29 37 32 28 27

140-150 0 0-60 12806.35 51.2 70.5 6 48 37 30 25 46 37 30 25 35 29 25 34 29 25 33 28 24 23

150-160 0 0-90 18156.91 72.6 100 7 44 33 27 22 43 33 26 22 32 26 22 31 25 21 30 25 21 20

160-170 0 90-120 3.43 0 0 8 41 30 24 19 40 30 23 19 29 23 19 28 23 19 27 22 19 17

170-180 0 90-130 3.43 0 0 9 38 28 21 17 37 27 21 17 26 21 17 25 20 17 25 20 17 15

90-150 3.43 0 0 10 35 25 19 15 35 25 19 15 24 19 15 23 18 15 23 18 15 14

90-180 3.43 0 0

0-18018160.34. 72.6 100.0

Candela Distribution TOTAL LUMINAIRE EFFICIENCY = 85.5% REPORT NUMBER: KPBG250PG

Lamps: 250 W Metal Halide Pulse Start

Mogul Base

Zone CIE Type – General Diffuse

0-10

74.54

10-20

304.58

20-30

486.47

30-40

948.61

COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

40-50

1471.61

EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

50-60

1887.31

RC 80 70 50 30 10 0

60-70

2239.17

RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80

2561.7

0 94 94 94 94 87 87 87 87 76 76 76 65 65 65 55 55 55 51

80-90

2747.67

1 80 74 68 63 74 68 63 59 58 54 51 49 46 43 40 38 36 31

90-100

2779.02

2 71 61 54 47 65 57 50 44 48 42 38 40 36 32 32 29 26 22

100-110

2564.95

ZONAL LUMEN SUMMARY 3 63 52 44 37 58 48 41 34 41 34 29 33 29 25 27 23 20 16

110-120

2148.15

ZONE LUMENS %LAMP %FIXT. 4 57 45 36 30 52 42 34 28 35 29 24 29 24 20 23 19 16 13

120-130

1109.49

0-30 865.59 3.5 4.1 5 52 40 31 25 47 36 29 23 31 24 19 25 20 16 20 16 13 10

130-140

37.55

0-40 1814.2 7.3 8.5 6 47 35 27 21 43 32 25 19 27 21 16 22 17 13 18 14 11 8

140-150

3.93

0-60 5173.13 20.7 24.2 7 44 31 23 18 40 29 22 16 24 18 14 20 15 11 16 12 9 7

150-160

.76

0-90 12721.67 50.9 59.5 8 40 28 20 15 37 26 19 14 22 16 12 18 13 10 15 11 8 6

160-170

.09

90-120 7492.124 30 35.1 9 37 25 18 13 34 24 17 12 20 14 10 17 12 9 13 10 7 5

170-180

.03

90-130 8601.61 34.4 40.3 10 35 23 16 12 32 22 15 11 18 13 9 15 11 8 12 9 6 4

90-150 8643.09 34.6 40.5

90-180 8643.97 34.6 40.5

0-180 21365.63 85.5 100.0

* Photometric data is based on xtures with a

250-watt clear Pulse Start Metal Halide lamp

(23,000 lumen).

For candlepower values of xtures with other

PSMH lamps, (21,000 lumen) PSMH lamp – 0.913.

For candlepower values of xture with guard,

multiply by 0.95.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

974

Mercmaster™ III HID 50-250 Watt Luminaire Photometric Data

250 W PSMH

Zone Lumens TOTAL LUMINAIRE EFFICIENCY = 79% REPORT NUMBER: KPBR250PJ3

Lamps: 250 W Metal Halide Pulse Start

Mogul Base

0-10 28.46 CIE Type – Semi-Direct

10-20 222.99 SpacingCriteria:1.64

20-30 438.39

30-40 727.7

40-50 1709.75 COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

50-60 2094.28 EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

60-70 4828.69 RC 80 70 50 30 10 0

70-80 4189.12 RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

80-90 2131.34 0 91 91 91 91 87 87 87 87 80 80 80 74 74 74 68 68 68 65

90-100 748.43 1 77 70 65 60 73 67 62 57 61 57 53 55 52 49 50 48 45 42

100-110 1109.54 ZONAL LUMEN SUMMARY 2 66 56 48 42 62 54 46 40 48 42 37 43 38 34 39 35 31 28

110-120 701.88 ZONE LUMENS %LAMP %FIXT. 3 58 46 37 30 55 44 36 29 39 32 27 35 29 24 31 26 22 19

120-130 410.51 0-30 689.84 2.8 3.5 4 52 39 30 23 49 37 29 22 33 26 20 30 23 18 26 21 17 14

130-140 237.73 0-40 1417.54 5.7 7.2 5 47 34 25 18 44 32 24 17 29 21 16 25 19 14 22 17 13 10

140-150 123.53 0-60 5221.56 20.9 26.4 6 43 30 21 15 40 28 20 14 25 18 13 22 16 12 20 14 10 8

150-160 37.79 0-90 16370.71 65.5 82.9 7 39 26 18 12 37 25 17 12 22 16 11 20 14 9 18 12 8 6

160-170 3.51 90-120 2559.84 10.2 13 8 36 24 16 10 34 22 15 10 20 14 9 18 12 8 16 11 7 5

170-180 .32 90-130 2970.35 11.9 15 9 33 21 14 9 32 20 13 8 18 12 8 16 11 7 15 10 6 4

90-150 3331.61 13.3 16.9 10 31 19 12 8 29 18 12 7 17 11 7 15 10 6 13 9 5 4

90-180 3373.23 13.5 17.1

0-180 19743.94 79 100.0

Zone Lumens TOTAL LUMINAIRE EFFICIENCY = 84% REPORT NUMBER: KPBR250PJ5

Lamps: 250 W Metal Halide Pulse Start

Mogul Base

0-10 28.96 CIE Type – Semi-Direct

10-20 214.01 SpacingCriteria:1.64

20-30 402.91

30-40 678.83

40-50 1539.03 COEFFICIENTS OF UTILIZATION - ZONAL CAVITY METHOD

50-60 1537.39 EFFECTIVE FLOOR CAVITY REFLECTANCE 0.20

60-70 4450.44 RC 80 70 50 30 10 0

70-80 5789.28 RW 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

80-90 3160.26 0 97 97 97 97 93 93 93 93 86 86 86 80 80 80 74 74 74 71

90-100 855.15 1 80 72 66 60 76 69 63 57 63 58 53 57 53 49 52 48 45 42

100-110 1095.13 ZONAL LUMEN SUMMARY 2 68 57 48 40 65 54 46 38 49 42 35 44 38 33 39 34 30 27

110-120 596.59 ZONE LUMENS %LAMP %FIXT. 3 60 47 37 29 56 44 35 27 40 32 25 35 29 23 31 26 21 18

120-130 345.11 0-30 645.89 2.6 3.1 4 54 40 29 22 50 37 28 21 33 25 19 30 23 17 26 20 15 13

130-140 189.6 0-40 1324.72 5.3 6.3 5 48 34 24 17 45 32 23 16 29 21 15 26 19 13 23 17 12 9

140-150 82.84 0-60 4401.15 17.6 21 6 44 30 21 14 41 28 20 13 25 18 12 23 16 11 20 14 10 7

150-160 22.91 0-90 17801.14 71.2 84.8 7 41 27 18 11 38 25 17 11 23 15 10 20 14 9 18 12 8 6

160-170 2.78 90-120 2546.87 10.2 12.1 8 38 24 16 10 35 23 15 9 21 14 8 18 12 8 16 11 7 5

170-180 .71 90-130 2891.98 11.6 13.8 9 35 22 14 8 33 21 13 8 19 12 7 17 11 7 15 10 6 4

90-150 3164.41 12.7 15.1 10 33 20 12 7 31 19 12 7 17 11 6 16 10 6 14 9 5 3

90-180 3190.80 12.8 15.2

0-180 20991.94 84 100.0

* Photometric data is based on xtures with a

250-watt clear Pulse Start Metal Halide lamp

(23,000 lumen).

For candlepower values of xtures with other

PSMH lamps, (21,000 lumen) PSMH lamp – 0.913.

For candlepower values of xture with guard,

multiply by 0.95.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

975

Mercmaster™ III HID 50-250 Watt Luminaire Photometric Data

250 W PSMH

Listed for simultaneous exposure to combustible dusts and flammable gases or vapors.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Applications

• Enclosedandgasketedxturessuitableforusein:

—Marineandwetlocations

—Awiderangeofindustrial,chemicalprocessingandotherareas

whereammablegasesandvaporsorcombustibledustsare

presentunderconditionsdenedbytheNationalElectrical

CodeasClassI,Division2;ClassII,Division1and2;and

ClassIII

—Inapplicationsinvolvingmediumandhighmountingheights

—Inapplicationswhereenergyefcient,highlumenoutputis

required

—TheAExnAnRMercmasterIIIxtureisfactorysealedand

preventsvaporsandgasesfromenteringtheglobechamber.

Therearenosealsorputtyrequired.

—TheAExnRMercmasterIIIxturerequiresallwiringentriesto

besealed.

—Non-hazardouslocationswheresevereweatherconditions,

excessivemoisture,dirt,dust,corrosiveatmosphereorhigh

ambienttemperaturesareencountered

• Typicalapplicationsinclude:

—Pulpandpapermills

—Processingplants

—Chemicalplants

—Oilreneries

—Foundries

—Manufacturingplants

—Storageareas

—Wasteandsewagetreatment

—Otherareaswheredust,water,dirtandroughusagearea

problem

Features

• Superiorcorrosionresistance.

• Choiceoflightsources:highpressuresodium,andpulsestart

metalhalide.

• Sixmountingarrangementstosuitanylightinglayout:pendant,

ceiling,wallbracket,25°(angle)stanchion,90°(straight)

stanchionandcone.

• Hingehashighlipforaddedsafetyduringinstallationand

servicing.Hingeandboltconstructionassures360ºcompression

atallpointsonballasthousinggasketforpositivesealing.Swing

awaydesignofcaptiveboltandnutsimpliesservicing.

• Choiceofopticalassemblies:prismaticglobe;enclosedreec-

torwithsealedlens;orTypeVorTypeIIclosedprismaticglass

refractor,withorwithoutguards.

• Widechoiceofphotometricdistributions.

• Allxturesdesignedtoperformina104ºF/40ºCambienttemper-

ature.Selectedxturesaresuitableforambienttemperaturesup

to149ºF/65ºC.

• Mogulbaseporcelainlampholderwithnickel-platedcontacts

has392°F/200°Cratedweldedleads,pre-wiredtotheballast.

Assurestrouble-freeoperationininstallationswherehighambient

temperaturesareencountered.

• Forelectricalprotection,agroundwireisprovidedoneach

Mercmastertobondhoodandballasthousing.

• TerminalblocksareprovidedforZone2xturestofacilitatewiring.

• Standarddomeof30ºanglereectorsmadeofberglassrein-

forcedwhitepolyester.Highlyresistanttocorrosiveatmospheres.

• Awiderangeofvoltagesavailable(120to600Volt)andballast

types(CWA,CWIandSuperCWA).

• One-pieceballasthousingforeachcomponentprovideseven

heatdissipationforcooleroperationandlongerballastlife.

• AllMercmastermountinghoodshaveprovisionforeasyeldin-

stallationoffusesinxtures(seefusekitlistings).

Standard Materials

• Mountinghoodsandballastbodies:castcopperfree(lessthan

4/10of1%copper)aluminum

• Reectors:Fiberglassreinforcedwhitepolyester

• Guards,hardwareandcatchassemblies:stainlesssteel

• Globe:heat-andimpact-resistantinternallyutedglass

• Refractors:prismaticglass

• Enclosedreector:etchedAlzakaluminumwithsealed,tempered

heat-andimpact-resistantlens

• Bodyandglobegaskets:high-temperaturesiliconerubber

Standard Finishes

• Mountinghoodsandguards:epoxypowdercoat,electrostatically

appliedforcompleteanduniformprotection

Options

• AExnAnRxturesareavailablewithaClassI,Zone2rating.Add

sufx-Z2.

• AExnRxturesareavailablewithaClassI,Zone2rating.Add

sufx-ZB.

• ExnRxturesareavailablewithaClassI,Zone2rating.Add

sufx-Z V.

• QuartzAuxiliarycomestofullbrightnessimmediatelyand

remainslituntiltheHIDlampattains60-70%offullillumination.

QuartzAuxiliarysuppliedwithrelayswitchandsockettoaccept

120Vquartzdouble-contactbayonetbaselamp(notincluded).

(Notsuitableforhazardouslocations.)Addsufx-E.

• Factorysealedphotocontrolavailable.SeePCD2Series.

• SmartStarterincorporatesa1-1/2-minutetimerandperforms

asaconventionalstartertonormallystartlamp.Removes

itselffromcircuitiflampburnsoutorisremovedfromsocket.

Eliminatesstarterfailurescausedbyprolongedoperationwith

cyclingorfailinglampsandsimpliesndingtheirlocation,

reducingmaintenanceandrepaircosts.AvailableforallHPS

andPSMHxtures.Addsufx-S.

Certifications and Compliances

• ULStandard:UL1598,UL1598A,UL844,UL60079-0,UL

60079-15

• ULListed:E10444

Enclosed Reflector Prismatic Glass Globe 12” Glass Refractor

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

976

Mercmaster™ III 400 Luminaire for Hazardous and Wet Locations

High Pressure Sodium and Pulse Start Metal Halide

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

V CSA Certification only.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

977

Mercmaster™ III 400 Luminaires for Hazardous and Wet Locations

High Pressure Sodium and Pulse Start Metal Halide

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

Illustrated Features

Vented Reflectors

Reflectorsarethick,toughfiberglass-

reinforcedwhitepolyester,ventedfor

cooleroperation.Quicklyattachwith

furnishedstainlesssteelscrews.

Ballast Assembly

Utilizingnon-sparkingcomponents

avoidingtheignitionofgasesorvapors

thatmaybepresent(nA).

Mounting Hood and Globe Gaskets

Siliconerubbergasketsealsoutmoisture,

dirtanddust.Staysflexible,withstands

hightemperatures.Closuredesign

assuresuniformgasketcompression.

Electrical Protection

Groundwireprovidedtobondmounting

hoodtoballasthousing.

High Temperature Sockets

Mogulbasehigh-temperatureporcelain

sockets.

Aluminum Inner Reflector

Solidaluminuminnerreflector(for

refractorballasthousingsonly)improves

photometricefficiency.

Globe Chamber

Completelysealedfromtheballast

housingandoutsidevapors/air(nR).

Terminal Blocks (Zone 2)

Aseven-pointterminalblockisprovided

tofacilitatewiring.Terminalblock

accommodateswiresizerangingfrom#8

to#24AWG.

Stainless Steel Inserts

Ballastbodieshavestainlesssteel

threadedinsertstoreceivestainlesssteel

screwsforreflectorsandguard.Prevents

"freezing”,allowingguardsandreflectors

tobeeasilyremovedandreplacedatany

time,withoutdamagetothehousing.

"Safety" High

Hinge

Extra-highhinge

providesadditional

protectionagainst

accidental

ballasthousing

disengagement

duringinstallation

ormaintenance.

Epoxy Finish

Ballasthousing,hoodsandguardsare

copperfreealuminumwithepoxypowder

coatfinish.

Photocell

Availableforallfixturesexceptconeand

ceilingmount.Installsthroughknock-out

inmountinghood.Providescontinuous

ON-OFFdusk-to-dawncontrol.

Cooler Operating Cone Hood

Largerslopedsurfaceshedsdusts,dirt

andcombustiblefibersprovidingbetter

heatdissipation.

Stainless Steel

Latch Assembly

Captive,stainless

steellatchassembly

boltandnutcloses

securely,resists

attackofcorrosive

atmospheres.

Swing-awaydesign

simplifiesservicing.

Prismatic Glass Globes, Refractors

and Enclosed Reflector

Heat-resistantglobes,refractorsand

enclosedreflectorthreadintoballast

housingandsealagainstahigh

temperaturesiliconerubbergasket.

Fuses

Twoscrewssecurefusekittomounting

bossinanyMercmastermountinghood.

Fuseincluded.

V CSA Certification only.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Orderusingcatalognumberingguidebeloworselectcatalognumberfromtablesonfollowingpages.

Catalog Numbering Guide

KP A L 40 10 J5 G MT S Z2

Series:

KP-

MercmasterIII

400

LampType:

L -HighPressure

 Sodium

P -PulseStart

MetalHalide

HubSize:

75-3/4”NPT

10-1”NPT

125-1-1/4”NPT

stanchion

150-1-1/2”NPT

stanchion

GuardOptions:➋

G-GlobeGuard

BG-Refractor

Guard

NG-Enclosed

RelfectorGuard

Blank-NoGuard

Options:

E-EmergencyQuartz

F-FuseKit(Specify

Voltage)

S-SmartStarter

H1-Photocontrol120V

H2-Photocontrol208V

H3-Photocontrol240V

H4-Photocontrol277V

C-SafetyCable

AdaptedV

E40-ExportSocket

D-E-40Export

SocketV

T-TerminalBlocksV

V-Anti-Vibration

ModificationsV

X-Appledapter➏

MountingHood

AdapterV

Mounting:

A -Pendant(rigid

mounting)

C -Ceiling

CH-PendantConeHood

F -Pendant(flexible

mounting)

ST -90°Stanchion

S -25°Stanchion

WB-Wall

Wattage:

25-250WHPS,PSMH➎

32-320WPSMH

35-350WPSMH

40-400WPSMH&HPS

40-400WMHV

OpticalAssembly:➊

Blank-GlassGlobe

J2-NEMAIIGlass

Refractor➍

J5-NEMAVGlass

Refractor➍

R-EnclosedRefractor

withSealedLens

Voltage:➌

MT -120/208/240/277,

60Hz

5MT -120/208/240/

277/480,60Hz

48 -480,60Hz

125-120,50Hz

226-220,60Hz

235-230,50Hz

245-240,50Hz

C2-208,60Hz,CWIV

C3-240,60Hz,CWIV

C6-480,60Hz,CWIV

C7-600,60Hz,CWIV

TT-120/277/347,60Hz,

CWAV

Suffix:

Z2-Zone2suffix

(requiredfor

AExnAnR

rating)

ZB-Zone2suffix

(requiredfor

AExnRrating)

Z-Zone2suffix

(requiredfor

ExnR)V

Refer to “Mounting Hoods and Ballast” page for available Voltage Configuration.

 NO DESIGNATION is required for fixtures with standard type globe.

 NO DESIGNATION is required for fixtures without guards.

➌ Other voltages available. Contact your local sales representative.

➍ J2 and J5 refractions are not available with Z2 or ZB suffix.

➎ Available for 480 V, 50 Hz and 5MT ballast options. For MT and TT voltage suffix, see Mercmaster III 50-250 Luminaries.

➏ Appledapter is available for use with the pendant, ceiling and angled stanchion mounting only.

V CSA Certification only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

978

Mercmaster™ III 400 Luminaires for Hazerdous and Wet Locations

High Pressure Sodium and Pulse Start Metal Halide

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

“T” Numbers Represent the Maximum Lamp Temperature for Class I, Division 2 Locations and

Maximum Surface Temperature Under Dust Blanket for Class II, Division 1 Locations

“T”

Number T1 350 325 T2 T2A T2B T2C T2D T3 T3A T3B T3C T4 T4A T5 T6

Temp.

Range

(˚ºF)

664-

842

619-

662

574-

617

538-

572

502-

536

448-

500

421-

446

394-

419

358-

392

331-

356

322-

329

277-

320

250-

275

214-

248

187-

212 185

Temp

Range

(ºC)

351-

450

326-

350

301-

325

281-

300

261-

280

231-

260

216-

230

201-

215

181-

200

166-

180

161-

165

136-

160

121-

135

101-

120

86-

100 85

➊ “T” numbers are for Groups E and F only.

V CSA Certification only.

“T” Numbers

Lamp Supply

Wire

Temp.

(°F/°C) ➊

Ambient

Temp.

(°F/°C) ➊

Class I, Division 2

Class II, Division 1

Groups E, F and G

Simultaneous Exposure

Class I, Division 2 / Class II, Division 1

Watts Type Globe

Globe &

Reflector Refractor

Enclosed

Reflector Globe

Globe &

Reflector Refractor

Enclosed

Reflector Globe

Globe &

Reflector Refractor

Enclosed

Reflector

250 HPS

230/110 104/40 T2 T2 T2 T2 T3B T3B T4 T4A 325 325 325 325

230/110 131/55 325 325 T2 T2 — — T3B T4A — — T1 325

230/110 149/65 — — T2 T2 — — T3B T4 — — T1 350

400 HPS 194/90 104/40 350 T1 T1 350 T3 * T3 * T3C T3C T1 T1 T1 350

250 PSMH

194/90 104/40 T2B T2B T2B T2C T3 (EF) T3 (EF) T4 T4A — — — —

194/90 131/55 T2A T2A T2B T2C — — — — — — — —

194/90 149/65 — — — T2C — — — — — — — —

320 PSMH 194/90 104/40 T2B T2B T2B T2B — — T3C T3C — — — —

194/90 131/55 T2A T2A T2A T2B — — — — — — — —

350 PSMH 194/90 104/40 T2B T2B T2B T2B — — T3C T3C — — — —

194/90 131/55 T2A T2A T2A T2B — — — — — — — —

400 PSMH 194/90 104/40 T2A T2A T2B T2B — — T3C T3C — — — —

400 MHV194/90 104/40 T2 T2 T2A T2A — — T3A T4 — — — —

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

979

Mercmaster™ III 400 Luminaire Thermal Performance

Class I, Division 2; Class II, Division 1; Simultaneous Exposure to Hazardous Conditions on Both Classifications

Temperature identification numbers of Mercmaster III – 400 Fixtures.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

“T” Numbers

Lamp Supply

Wire

Temp.

(°F/°C) ➊

Ambient

Temp.

(°F/°C) ➊

Class 1, Zone 2 AEx nA nR / Ex nR Class 1, Zone 2 AEx nR

Watts Type Globe

Globe &

Reflector

Enclosed

Reflector Globe

Globe &

Reflector

Enclosed

Reflector

250

HPS 230/110 104/40 T4 T4 T5 T4 T4 T5

HPS 230/110 131/55 T3 T3 T3 T3 T3 T3

HPS 230/110 149/65 — — T3 — — T3

400 HPS 194/90 104/40 T4 T4 T5 T4 T4 T5

250

PSMH 194/90 104/40 T3 T3 T3 — — —

PSMH 194/90 131/55 T3 T3 T3 — — —

PSMH 194/90 104/40 — — T3 — — —

320 PSMH 194/90 104/40 T4 T4 T4 T4 T4 T4

PSMH 194/90 131/55 T3 T3 T4 T3 T3 T4

350 PSMH 194/90 104/40 T4 T4 T4 T4 T4 T4

PSMH 194/90 131/55 T3 T3 T4 T3 T3 T4

400 PSMH 167/75 104/40 T3 T3 T3 T3 T3 T3

400 MHV167/75 104/40 T3 T3 T3 — — —

“T” Numbers represent the maximum surface temperature for luminaries with AEx nA nR and AEx nR rating:

To comply with AEx nR Requirements, all wiring entries must be sealed.

“T”

Number T1 T2 T3 T4 T5 T6

Temp.

Range (°F) 547-842 394-572 277-392 214-275 187-212 185

Temp.

Range (°C) 301-450 201-300 136-200 101-135 86-100 85

➊ Use 194 °F/90 °C rated supply wire.

V CSA Certification only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

980

Mercmaster™ III 400 Luminaire Thermal Performance

Class I, Zone 2, AEx nR IIC, AEx nA nR IIC, IP66, NEMA 4X

Temperature identification numbers of Mercmaster III – 400 Fixtures.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Type

Mounting

Lamp

Type

Lamp

Watts

Hub Size

(Inches)

Catalog Numbers ➌

➍

➎

With Globe˚ With Type V 12” Refractor˚˚ ➋With Enclosed Reflector˚

Pendant — One Hub, Rigid Mounting ➊

Shown with Globe

HPS 250 3/4 KPAL2575 KPAL2575J5 KPAL2575R

1KPAL2510 KPAL2510J5 KPAL2510R

HPS 400 3/4 KPAL4075 KPAL4075J5 KPAL4075R

1KPAL4010 KPAL4010J5 KPAL4010R

Pendant Cone — One Hub, Rigid Mounting

Shown with 12" Glass Refractor

HPS 250 3/4 KPCHL2575 KPCHL2575J5 KPCHL2575R

1KPCHL2510 KPCHL2510J5 KPCHL2510R

HPS 400 3/4 KPCHL4075 KPCHL4075J5 KPCHL4075R

1KPCHL4010 KPCHL4010J5 KPCHL4010R

Ceiling — Five Hubs, Four Close-Up Plugs

Shown with Enclosed Reflector

HPS 250 3/4 KPCL2575 KPCL2575J5 KPCL2575R

1KPCL2510 KPCL2510J5 KPCL2510R

HPS 400 3/4 KPCL4075 KPCL4075J5 KPCL4075R

1KPCL4010 KPCL4010J5 KPCL4010R

➊ For Flexible Pendant Mount, change A to F in catalog number.

➋ To order fixture with NEMA Type II refractor, change digits J5 in catalog number to J2. Refractor not available for Z, Z2 or ZB suffix.

➌ For fixtures with guards, add suffix G before adding voltage suffix. BG for refractor. NG for enclosed reflector.

➍ Add the following voltage and frequency designations before Z, Z2 or ZB suffix:

Lamp Type Lamp Watts Voltage Suffixes

MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 250 X X X X — X X — — — — — X

HPS 400 X X X X — — X — — — — — X

PSMH 250 — X X X — — X — — — — — —

PSMH 320 X X X X — — X — — — — — X

PSMH 350 X X X X — — X — — — — — X

PSMH 400 X X X — — — X — — — — — X

MH V400 X — — X X — — X X X X X X

Voltages:

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➎ Add Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add ZB suffix for restricted breathing protection (AEx nR).

➏ Add Z for factory sealed restricted breathing protection (Ex nR) V.

V CSA Certification only.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

981

Mercmaster™ III 400 Luminaires for Hazerdous and Wet Locations

250 W, 400 W HPS

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Type

Mounting

Lamp

Type

Lamp

Watts

Hub Size

(Inches)

Catalog Numbers ➌

➍

➎

With Globe˚ With Type V 12” Refractor˚˚ ➋With Enclosed Reflector˚

Wall Five Hubs, Four Close-Up Plugs

Shown with 12” Glass Refractor

HPS 250 3/4 KPWBL2575 KPWBL2575J5 KPWBL2575R

1KPWBL2510 KPWBL2510J5 KPWBL2510R

HPS 400 3/4 KPWBL4075 KPWBL4075J5 KPWBL4075R

1 KPWBL4010 KPWBL4010J5 KPWBL4010R

25° Stanchion One Hub

Shown with Prismatic Glass Globe

and Optional Guard

HPS 250 1-1/4 KPSL25125 KPSL25125J5 KPSL25125R

1-1/2 KPSL25150 KPSL25150J5 KPSL25150R

HPS 400 1-1/4 KPSL40125 KPSL40125J5 KPSL40125R

1-1/2 KPSL40150 KPSL40150J5 KPSL40150R

90° Stanchion One Hub

Shown with Prismatic Glass Globe

and Optional Guard

HPS 250 1-1/4 KPSTL25125 KPSTL25125J5 KPSTL25125R

1-1/2 KPSTL25150 KPSTL25150J5 KPSTL25150R

HPS 400 1-1/4 KPSTL40125 KPSTL40125J5 KPSTL40125R

1-1/2 KPSTL40150 KPSTL40150J5 KPSTL40150R

➊ For Flexible Pendant Mount, change A to F in catalog number.

➋ To order fixture with NEMA Type II refractor, change digits J5 in catalog number to J2. Refractor not available for Z, Z2 or ZB suffix.

➌ For fixtures with guards, add suffix G before adding voltage suffix. BG for refractor. NG for enclosed reflector.

➍ Add the following voltage and frequency designations before Z, Z2 or ZB suffix:

Lamp Type Lamp Watts Voltage Suffixes

MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 250 X X X X — X X — — — — — X

HPS 400 X X X X — — X — — — — — X

PSMH 250 — X X X — — X — — — — — —

PSMH 320 X X X X — — X — — — — — X

PSMH 350 X X X X — — X — — — — — X

PSMH 400 X X X — — — X — — — — — X

MH V400 X — — X X — — X X X X X X

Voltages:

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➎ Add Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add ZB suffix for restricted breathing protection (AEx nR).

➏ Add Z for factory sealed restricted breathing protection (Ex nR) V.

V CSA Certification only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

982

Mercmaster™ III 400 Luminaires for Hazardous and Wet Locations

250 W, 400 W HPS

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Type

Mounting

Lamp

Type

Lamp

Watts

Hub Size

(Inches)

Catalog Numbers ➌

➍

➎

With Globe˚ With Type V 12” Refractor˚˚ ➋With Enclosed Reflector˚

Pendant One Hub, Rigid Mounting ➊

Shown with Globe

PSMH 250➐3/4 KPAP2575 KPAP2575J5 KPAP2575R

1KPAP2510 KPAP2510J5 KPAP2510R

PSMH 320 3/4 KPAP3275 KPAP3275J5 KPAP3275R

1KPAP3210 KPAP3210J5 KPAP3210R

PSMH 350 3/4 KPAP3575 KPAP3575J5 KPAP3575R

1KPAP3510 KPAP3510J5 KPAP3510R

PSMH 400 3/4 KPAP4075 KPAP4075J5 KPAP4075R

1KPAP4010 KPAP4010J5 KPAP4010R

Pendant Cone One Hub, Rigid Mounting

Shown with 12" Glass Refractor

PSMH 250➐3/4 KPCHP2575 KPCHP2575J5 KPCHP2575R

1KPCHP2510 KPCHP2510J5 KPCHP2510R

PSMH 320 3/4 KPCHP3275 KPCHP3275J5 KPCHP3275R

1KPCHP3210 KPCHP3210J5 KPCHP3210R

PSMH 350 3/4 KPCHP3575 KPCHP3575J5 KPCHP3575R

1KPCHP3510 KPCHP3510J5 KPCHP3510R

PSMH 400 3/4 KPCHP4075 KPCHP4075J5 KPCHP4075R

1KPCHP4010 KPCHP4010J5 KPCHP4010R

Ceiling Five Hubs, Four Close-Up Plugs

Shown with Enclosed Refractor

PSMH 250➐3/4 KPCP2575 KPCP2575J5 KPCP2575R

1KPCP2510 KPCP2510J5 KPCP2510R

PSMH 320 3/4 KPCP3275 KPCP3275J5 KPCP3275R

1KPCP3210 KPCP3210J5 KPCP3210R

PSMH 350 3/4 KPCP3575 KPCP3575J5 KPCP3575R

1KPCP3510 KPCP3510J5 KPCP3510R

PSMH 400 3/4 KPCP4075 KPCP4075J5 KPCP4075R

1KPCP4010 KPCP4010J5 KPCP4010R

➊ For Flexible Pendant Mount, change A to F in catalog number.

➋ To order fixture with NEMA Type II refractor, change digits J5 in catalog number to J2. Refractor not available for Z, Z2 or ZB suffix.

➌ For fixtures with guards, add suffix G before adding voltage suffix. BG for refractor. NG for enclosed reflector.

➍ Add the following voltage and frequency designations before Z, Z2 or ZB suffix:

Lamp Type Lamp Watts Voltage Suffixes

MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 250 X X X X — X X — — — — — X

HPS 400 X X X X — — X — — — — — X

PSMH 250 — X X X — — X — — — — — —

PSMH 320 X X X X — — X — — — — — X

PSMH 350 X X X X — — X — — — — — X

PSMH 400 X X X — — — X — — — — — X

MH V400 X — — X X — — X X X X X X

Voltages:

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➎ Add Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add ZB suffix for restricted breathing protection (AEx nR).

➏ Add Z for factory sealed restricted breathing protection (Ex nR) V.

V CSA Certification only.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

983

Mercmaster™ III 400 Luminaires for Hazardous and Wet Locations

250 W, 320 W, 350 W, 400 W PSMH

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Type

Mounting

Lamp

Type

Lamp

Watts

Hub Size

(Inches)

Catalog Numbers ➌

➍

➎

With Globe˚ With Type V 12” Refractor˚˚ ➋With Enclosed Reflector˚

Wall Five Hubs, Four Close-Up Plugs

Shown with 12” Glass Refractor

PSMH 250➐3/4 KPWBP2575 KPWBP2575J5 KPWBP2575R

1KPWBP2510 KPWBP2510J5 KPWBP2510R

PSMH 320 3/4 KPWBP3275 KPWBP3275J5 KPWBP3275R

1 KPWBP3210 KPWBP3210J5 KPWBP3210R

PSMH 350 3/4 KPWBP3575 KPWBP3575J5 KPWBP3575R

1 KPWBP3510 KPWBP3510J5 KPWBP3510R

PSMH 400 3/4 KPWBP4075 KPWBP4075J5 KPWBP4075R

1 KPWBP4010 KPWBP4010J5 KPWBP4010R

25° Stanchion One Hub

Shown with Prismatic Glass Globe

and Optional Guard

PSMH 250➐1-1/4 KPSP25125 KPSP25125J5 KPSP25125R

1-1/2 KPSP25150 KPSP25150J5 KPSP25150R

PSMH 320 1-1/4 KPSP32125 KPSP32125J5 KPSP32125R

1-1/2 KPSP32150 KPSP32150J5 KPSP32150R

PSMH 350 1-1/4 KPSP35125 KPSP35125J5 KPSP35125R

1-1/2 KPSP35150 KPSP35150J5 KPSP35150R

PSMH 400 1-1/4 KPSP40125 KPSP40125J5 KPSP40125R

1-1/2 KPSP40150 KPSP40150J5 KPSP40150R

90° Stanchion One Hub

Shown with Prismatic Glass Globe

and Optional Guard

PSMH 250➐1-1/4 KPSTP25125 KPSTP25125J5 KPSTP25125R

1-1/2 KPSTP25150 KPSTP25150J5 KPSTP25150R

PSMH 320 1-1/4 KPSTP32125 KPSTP32125J5 KPSTP32125R

1-1/2 KPSTP32150 KPSTP32150J5 KPSTP32150R

PSMH 350 1-1/4 KPSTP35125 KPSTP35125J5 KPSTP35125R

1-1/2 KPSTP35150 KPSTP35150J5 KPSTP35150R

PSMH 400 1-1/4 KPSTP40125 KPSTP40125J5 KPSTP40125R

1-1/2 KPSTP40150 KPSTP40150J5 KPSTP40150R

➊ For Flexible Pendant Mount, change A to F in catalog number.

➋ To order fixture with NEMA Type II refractor, change digits J5 in catalog number to J2. Refractor not available for Z, Z2 or ZB suffix.

➌ For fixtures with guards, add suffix G before adding voltage suffix. BG for refractor. NG for enclosed reflector.

➍ Add the following voltage and frequency designations before Z, Z2 or ZB suffix:

Lamp Type Lamp Watts Voltage Suffixes

MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 250 X X X X — X X — — — — — X

HPS 400 X X X X — — X — — — — — X

PSMH 250 — X X X — — X — — — — — —

PSMH 320 X X X X — — X — — — — — X

PSMH 350 X X X X — — X — — — — — X

PSMH 400 X X X — — — X — — — — — X

MH V400 X — — X X — — X X X X X X

Voltages:

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➎ Add Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add ZB suffix for restricted breathing protection (AEx nR).

➏ Add Z for factory sealed restricted breathing protection (Ex nR) V.

V CSA Certification only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

984

Mercmaster™ III 400 Luminaires for Hazardous and Wet Locations

250 W, 320 W, 350 W, 400 W PSMH

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Type

Mounting

Lamp

Type

Lamp

Watts

Hub Size

(Inches)

Catalog Numbers ➌

➍

➎

With Globe˚ With Type V 12” Refractor˚˚ ➋With Enclosed Reflector˚

Pendant One Hub, Rigid Mounting ➊

Shown with Globe

MHV400 3/4 KPAH4075 KPAH4075J5 KPAH4075R

1KPAH4010 KPAH4010J5 KPAH4010R

Pendant Cone One Hub, Rigid Mounting

Shown with 12" Glass Refractor

MHV400 3/4 KPCHH4075 KPCHH4075J5 KPCHH4075R

1KPCHH4010 KPCHH4010J5 KPCHH4010R

Ceiling Five Hubs, Four Close-Up Plugs

Shown with Enclosed Refractor

MHV400 3/4 KPCH4075 KPCH4075J5 KPCH4075R

1KPCH4010 KPCH4010J5 KPCH4010R

Mercmaster™ III 400 Luminaires for Hazardous and Wet Locations

400 W MH V

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

➊ For Flexible Pendant Mount, change A to F in catalog number.

➋ To order fixture with NEMA Type II refractor, change digits J5 in catalog number to J2. Refractor not available for Z, Z2 or ZB suffix.

➌ For fixtures with guards, add suffix G before adding voltage suffix. BG for refractor. NG for enclosed reflector.

➍ Add the following voltage and frequency designations before Z, Z2 or ZB suffix:

Lamp Type Lamp Watts Voltage Suffixes

MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 250 X X X X — X X — — — — — X

HPS 400 X X X X — — X — — — — — X

PSMH 250 — X X X — — X — — — — — —

PSMH 320 X X X X — — X — — — — — X

PSMH 350 X X X X — — X — — — — — X

PSMH 400 X X X — — — X — — — — — X

MH V400 X — — X X — — X X X X X X

Voltages:

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➎ Add Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add ZB suffix for restricted breathing protection (AEx nR).

➏ Add Z for factory sealed restricted breathing protection (Ex nR) V.

➐ Available for 480 V, 50 Hz and 5MT ballast options. For MT and TT voltage suffix, see Mercmaster III 50-250 Luminaries.

V CSA Certification only.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

985

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Type

Mounting

Lamp

Type

Lamp

Watts

Hub Size

(Inches)

Catalog Numbers ➌

➍

➎

With Globe˚ With Type V 12” Refractor˚˚ ➋With Enclosed Reflector˚

Wall Five Hubs, Four Close-Up Plugs

Shown with 12” Glass Refractor

MHV400 3/4 KPWBH4075 KPWBH4075J5 KPWBH4075R

1 KPWBH4010 KPWBH4010J5 KPWBH4010R

25° Stanchion One Hub

Shown with Prismatic Glass Globe

and Optional Guard

MHV400 1-1/4 KPSH40125 KPSH40125J5 KPSH40125R

1-1/2 KPSH40150 KPSH40150J5 KPSH40150R

90° Stanchion One Hub

Shown with Prismatic Glass Globe

and Optional Guard

MHV400 1-1/4 KPSTH40125 KPSTH40125J5 KPSTH40125R

1-1/2 KPSTH40150 KPSTH40150J5 KPSTH40150R

Mercmaster™ III 400 Luminaires for Hazardous and Wet Locations

400 W MH V

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

➊ For Flexible Pendant Mount, change A to F in catalog number.

➋ To order fixture with NEMA Type II refractor, change digits J5 in catalog number to J2. Refractor not available for Z, Z2 or ZB suffix.

➌ For fixtures with guards, add suffix G before adding voltage suffix. BG for refractor. NG for enclosed reflector.

➍ Add the following voltage and frequency designations before Z, Z2 or ZB suffix:

Lamp Type Lamp Watts Voltage Suffixes

MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 250 X X X X — X X — — — — — X

HPS 400 X X X X — — X — — — — — X

PSMH 250 — X X X — — X — — — — — —

PSMH 320 X X X X — — X — — — — — X

PSMH 350 X X X X — — X — — — — — X

PSMH 400 X X X — — — X — — — — — X

MH V400 X — — X X — — X X X X X X

Voltages:

MT - 120/208/240/277 V 60 Hz

5MT - 120/208/240/277/480 V 60 Hz

48 - 480 V 60 Hz

125 - 120 V 50 Hz

225 - 225 V 50 Hz

226 - 220 V 60 Hz

235 - 230 V 50 Hz

245 - 240 V 50 Hz

C2 - 208 V 60 Hz, CWI V

C3 - 240 V 60 Hz, CWI V

C6 - 480 V 60 Hz, CWI V

C7 - 600 V 60 Hz, CWI V,

TT - 120/277/347 V 60 Hz, CWA V

➎ Add Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add ZB suffix for restricted breathing protection (AEx nR).

➏ Add Z for factory sealed restricted breathing protection (Ex nR) V.

V CSA Certification only.

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

986

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

Mounting Hoods

Description Hub Size (Inches) Catalog Number

Pendant

OneHub,RigidMounting 3/4 KPA-75

1KPA-100

Pendant — Flexible

OneHub,FlexibleMounting 3/4 KPAF-75

1KPAF-100

Pendant Cone

OneHub,Rigid

3/4 KPCH-75

1KPCH-100

Ceiling

FiveHubs,FourClose-UpPlugs

3/4 KPC-75

1KPC-100

Wall

FiveHubs,FourClose-UpPlugs

3/4 KPWB-75

1KPWB-100

25° Stanchion

OneHub 1-1/4 KPS-125

1-1/2 KPS-150

90° Stanchion

OneHub 1-1/4 KPST-125

1-1/2 KPST-150

Ballast Bodies

High Pressure Sodium —ConstantWattage(Min.P.F.90%)

Pulse Start Metal Halide —SuperConstantWattage(Min.P.F.90%)

Lamp

Type

Lamp

Watts

Catalog

Numbers ➋➍

Voltage Suffixes

MT 5MT 48 125 225 226 235 245 C2 VC3 VC6 VC7 VTT V

HPS 250 KPB250L ➊➌ X X X X — X X — — — — — X

HPS 400 KPB400L ➊➌ X X X X — — X — — — — — X

PSMH 250 KPB250P ➊➌ — X X X — — X — — — — — X

PSMH 320 KPB320P ➊➌ X X X X — — X — — — — — X

PSMH 350 KPB350P ➊➌ X X X X — — X — — — — — X

PSMH 400 KPB400P ➊➌ X X X — — — X — — — — — X

MHV400 KPB400H X — — X X — — X X X X X X

Voltages:

MT-120/208/240/277V60Hz

5MT-120/208/240/277/480V60Hz

48-480V60Hz

125-120V50Hz

225-225V50Hz

226-220V60Hz

235-230V50Hz

245 -240V50Hz

C2-208V60Hz,CWIV

C3-240V60Hz,CWIV

C6-480V60Hz,CWIV

C7-600V60Hz,CWIV,

TT-120/277/347V60Hz,CWAV

➊ Add -S after voltage designation for ballast body with Smart Starter (HPS and PSMH only).

➋ Add -E after voltage designation for ballast body with provision for Quartz Emergency Light (not suitable for hazardous location).

➌ Add Z2 suffix for factory sealed non-sparking/restricted breathing protection (AEx nA nR). Add ZB suffix for restricted breathing protection (AEx nR).

➍ Add Z for factory sealed restricted breathing protection (Ex nR) V.

V CSA Certification only.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

987

Mercmaster™ III 400 Luminaire Mounting Hood and Ballast Bodies

High Pressure Sodium and Pulse Start Metal Halide - Hazardous and Wet Locations

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

Description Catalog Number

Prismatic Glass Globes — Heat-Resistant

Clear VPGL-4HR

Glass Globe

Enclosed Reector Assembly

Heat-andimpact-resistantglasslens KPR-4HB

Enclosed Reflector

Light Distribution IES/NEMA Distribution Curves Catalog Number

Closed Prismatic Glass Refractors ➌ — All Heat-Resistant

NEMATypeII KPRF400-2

NEMATypeV KPRF400-5

Glass Refractor

Item Description Catalog Number

White Polyester Reflectors Furnished with stainless steel screws

Forusewithglobextures

StandardDome CMR4-ST ➊

30°Angle CMR4-AN

DeepDome CMR4-DD ➊➋

Standard and Deep Dome 30° Angle

Guards

Refractor Guard

Enclosed Reflector Guard

Globe Guard

GlobeGuard KPGU400

RefractorGuard KPBG12

EnclosedReflectorGuard GHB7000-NG

➊ Contact your local sales representative if used with KPWB or KPST mounting hoods.

➋ Complies Dark Skies.

➌ Not suitable for use with Z, Z2 or ZB suffixes (Zone 2).

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

988

Mercmaster™ III 400 Luminaire Optics and Accessories

High Pressure Sodium and Pulse Start Metal Halide - Hazardous and Wet Locations

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

Class I, Division 2, Groups A, B, C, D

Class I, Zone 2, AEx nA nR IIC (Z2)

Class I, Zone 2, Ex nR IIC (Z) V

Class I, Zone 2, AEx nR IIC (ZB)

Class II, Division 1 and 2, Groups E, F, G

Class III

Simultaneous Exposure (Class I, Division 2/

Class II, Division 1)

Fixtures Outside Type (Salt Water)

Type 4X

IP66

➊ C.W.A. – Constant Wattage Autotransformer. HX-HPF – High Reactance

High Power Factor Autotransformer.

Super C.W.A. – Super Constant Wattage Autotransformer.

V CSA Certification only.

Electrical Specifications

Line

Voltage

Type of

Ballast ➊Frequency

Starting

Amps

Operating

Amps

Total

Watts

250 Watt High Pressure Sodium

120 C.W.A. 60 2.00 2.50 295

208 C.W.A. 60 1.20 1.50 295

240 C.W.A. 60 1.00 1.30 295

277 C.W.A. 60 0.85 1.10 295

347VC.W.A. 60 0.60 0.93 295

480 C.W.A. 60 0.40 0.65 295

120 C.W.A. 50 1.85 2.75 300

230 C.W.A. 50 0.95 1.44 300

400 Watt High Pressure Sodium

120 C.W.A. 60 3.30 3.80 465

208 C.W.A. 60 1.80 2.20 465

240 C.W.A. 60 1.60 1.90 465

277 C.W.A. 60 1.40 1.70 465

347VC.W.A. 60 1.00 1.32 464

480 C.W.A. 60 0.80 1.00 465

120 C.W.A. 50 3.70 4.00 465

230 C.W.A. 50 1.85 2.00 465

250 Watt Pulse Start Metal Halide

120 C.W.A. 60 1.96 2.50 291

208 C.W.A. 60 1.13 1.45 291

240 C.W.A. 60 0.98 1.25 291

277 C.W.A. 60 0.85 1.10 291

347VC.W.A. 60 0.62 0.90 291

480 C.W.A. 60 0.32 0.69 298

480 SuperC.W.A. 60 0.45 0.60 285

120 SuperC.W.A. 50 1.90 2.60 288

230 SuperC.W.A. 50 1.00 1.35 288

320 Watt Pulse Start Metal Halide

120 SuperC.W.A. 60 2.60 3.25 368

208 SuperC.W.A. 60 1.50 1.90 368

240 SuperC.W.A. 60 1.30 1.65 368

277 SuperC.W.A. 60 1.15 1.40 368

347VSuperC.W.A. 60 0.70 1.10 368

480 SuperC.W.A. 60 0.60 0.80 368

120 SuperC.W.A. 50 2.28 3.05 365

230 SuperC.W.A. 50 1.14 1.60 365

350 Watt Pulse Start Metal Halide

120 SuperC.W.A. 60 3.30 3.60 400

208 SuperC.W.A. 60 1.90 2.10 400

240 SuperC.W.A. 60 1.65 1.80 400

277 SuperC.W.A. 60 1.40 1.55 400

347VSuperC.W.A. 60 0.85 1.20 400

480 SuperC.W.A. 60 0.75 0.90 400

120 SuperC.W.A. 50 2.45 3.34 394

230 SuperC.W.A. 50 1.26 1.74 394

400 Watt Pulse Start Metal Halide

120 SuperC.W.A. 60 3.50 4.00 454

208 SuperC.W.A. 60 2.00 2.30 454

240 SuperC.W.A. 60 1.75 2.00 454

277 SuperC.W.A. 60 1.50 1.25 454

347VSuperC.W.A. 60 1.10 1.35 452

480 SuperC.W.A. 60 0.90 1.00 454

120 SuperC.W.A. 50 3.17 3.90 454

230 SuperC.W.A. 50 1.65 2.00 454

Electrical Specifications

Line

Voltage

Type of

Ballast ➊Frequency

Starting

Amps

Operating

Amps

Total

Watts

400 Watt Metal Halide V

120 C.W.A. 60 3.25 4.00 458

208 C.W.A. 60 1.90 2.30 458

240 C.W.A. 60 1.80 2.00 458

277 C.W.A. 60 1.70 1.75 458

347 C.W.A. 60 1.40 1.75 458

480 C.W.I. 60 0.85 1.00 462

600 C.W.I. 60 0.30 0.70 475

120 C.W.A. 50 2.70 4.10 462

220 C.W.A. 50 1.50 2.10 462

240 C.W.A. 50 1.50 2.10 462

Fuse Kit

Order fuses as a separate item by catalog number from right columns.

Lamp

Watts Volts

Fuse

Quantity

Required

Fuse Catalog Number

HPS PSMH MH V

250

120 1 F7 — —

208 2 F4 — —

240 2 F4 — —

277 1 F3 — —

347V1F3 F3 F3

480 2 F2 — —

120 1 F7 — —

230 2 F4 — —

250 480 2 —F2 —

230 1 —F3 —

320

120 1 —F9 —

208 2 —F6 —

240 2 —F5 —

277 1 —F4 —

347V1—F3 F3

480 2 —F3 —

120 1 —F10 —

230 2 —F5 —

350

120 1 —F10 —

208 2 —F7 —

240 2 —F5 —

277 1 —F5 —

347V1—F3 —

480 2 —F3 —

120 1 —F10 —

230 2 —F5 —

400

120 1 F15 F10 —

208 2 F8 F7 —

240 2 F8 F5 —

277 1 F5 F5 —

347V1F5 F5 F5

480 2 F5 F3 —

120 1 F10 F10 —

230 2 F6 F5 —

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

989

Mercmaster™ III 400 Luminaire Electrical Specifications and Fuse Kits

High Pressure Sodium and Pulse Start Metal Halide - Hazardous and Wet Locations

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

Pendant with Globe,

Guard and Reflectors

Ceiling with Refractor

Enclosed Reflector and Guards

25° Stanchion

Wall

Cone

90° Stanchion

Mercmaster III – 400 Ballast and Accessory Weights

Lamp Watts

Ballast Housing (Wt. Lbs/Kg) Mounting Hoods

and Reflectors Wt. Lbs.

Globe Refractor, Enclosed

Reflector and Guards Wt. Lbs/KgHPS PSMH

250 24.5/11.1 —Pendant 2.25/1.0 GlassGlobe 7.0/3.2

PendantCone 2.50/1.1 GlobeGuard 3.0/1.4

320 —28.0/12.7 Ceiling 3.00/1.4 12”GlassRefractor 12.0/5.4

Wall 4.00/1.8 RefractorGuard 4.5/2.0

350 —28.5/12.9 25°Stanchion 3.25/1.5 EnclosedReflector 11.0/5.0

90°Stanchion 3.75/1.7 EnclosedReflectorGuard 2.0/0.9

400 28.5/12.9 28.5/12.9 StandardDome 3.50/1.6

30°Angle 3.50/1.6

Weights are approximate. Add 0.25 lb. for Quartz option.

Deep Dome

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

990

Mercmaster™ III 400 Luminaire Dimensions and Weights

High Pressure Sodium and Pulse Start Metal Halide - Hazardous and Wet Locations

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

991

Class I, Division 2, Groups A, B, C, D

NEMA 4X

Applications

• Encapsulatedphotocontrolprovidesautomaticdusk-to-dawn

lightingcontrolinClassI,Division2locations.

• Typicalapplicationsincludewalkways,securityareasandany

otheroutdoorlightingapplication.

• ForusewithMercmasterIII–LowProle,MercmasterIII,and

MercmasterIII–400SeriesLuminaires.

• ForremotemountinginFSBoxes.

Features

• Factorysealeddesigneliminatestheneedforanexplosionproof

enclosure.

• Canbeeasilyinstalledintheeld.

• Solidstatedesignforperformanceandreliability.

• Availablefor120,208,240,or277volts.

• 50-400WHID,incandescentoruorescent,50/60Hz.

• 1000VAVoltage/Ampere

• Minimumtimedelay:15secondstoeliminatenuisiancetripping.

• Providedwith(3)18AWGstrandedleads6”/152.4mminlength.

• Willtthroughstandard1/2”knockout.

Materials

• Encapsulatedwithepoxysealingcompound

• FS:aluminum

Certifications and Compliances

• ULStandard:1604–Hazardous(Classied)Locations

• cULusRecognized

Factory-Installed Photocontrol

Add to fixture catalog after voltage; i.e.: KPWBL1075MTH1.Dimensions

Voltage Range Suffix Designation

0.69”

17.5 mm

1.13”

28.7 mm

1.375”

34.9 mm

2.56”

65.0 mm

1.19”

30.2 mm 1.94”

49.2 mm

0.69”

17.5 mm

1.13”

28.7 mm

1.375”

34.9 mm

2.56”

65.0 mm

1.19”

30.2 mm 1.94”

49.2 mm

0.69”

17.5 mm

1.13”

28.7 mm

1.375”

34.9 mm

2.56”

65.0 mm

1.19”

30.2 mm 1.94”

49.2 mm

Mercmaster III wall mounting hood

with photocontrol installed shown

120V,50/60Hz H1

208V,50/60Hz H2

240V,50/60Hz H3

277V,50/60Hz H4

Photocontrol in FS Cover for Use with FS/FD Box

Supplied with two stainless steel screws. For neoprene gasket, order catalog number FS-GKR-1N.

Voltage Range Catalog Number

120V,50/60Hz FSKA-PC120D2

208-277V,50/60Hz FSKA-PC247D2

Photocontrol for Field Installation

Voltage Range Max. Current Catalog Number

120V,50/60Hz 8.3Amp PC120D2

208-277V,50/60Hz 3.5Amp PC247D2

PCD2 Series Factory Sealed Hazardous Location Photocontrol

For use in Class I, Division 2, Groups A, B, C, D locations

Maintains Class I, Division 2 rating for Mercmaster III – Low Profile, Mercmaster III, and Mercmaster III – 400 Series Luminaires, Mercmaster LED

* Photometric data is based on a xture with

a 400-watt clear Pulse Start Metal Halide lamp

(44,000 lumen).

For candlepower values of xtures with other

PSMH lamps, use the following multipliers: for a 320

W (33,000 lumen) PSMH lamp – .750; for a 350 W

(37,000 lumen) PSMH lamp – .840. For candlepower

values of xture with guard, multiply by – 0.95.

Zone Lumens TOTAL LUMINAIRE EFFICIENCY = 92.6%

REPORT NUMBER: KP40PG0-10 118.85 CIE Type - General Diffuse

10-20 488.36 Lamps: 400 W Pulse Start Metal Halide with Globe *

20-30 948.99

30-40 1678.84 Coefficients of Utilization - Zonal Cavity Method

40-50 2714.15 Effective Floor Cavity Reflectance 0.20

50-60 3299.55 % Ceiling Rcc 80 70 50 30 10 0

60-70 3919.47 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 4497.45 ZONAL LUMEN SUMMARY 0

100100100100

93 93 93 93 80 80 80 68 68 68 57 57 57 51

80-90 4892.41 Zone Lumens % Lamp % Fixture 186 80 74 69 79 73 68 64 62 58 54 51 48 45 41 39 37 32

90-100 4803.79 0-30 1556.19 3.5 3.8 276 67 59 52 70 61 54 48 51 45 41 42 37 33 33 30 27 22

100-110 4404.56 0-40 3235.03 7.4 7.9 368 57 48 41 62 52 44 38 45 37 32 35 30 26 28 24 20 16

110-120 3849.71 0-60 9248.74 21.0 22.7 462 49 40 33 56 45 37 30 37 31 26 30 25 21 24 20 16 13

120-130 3078.18 0-90 22558.07 51.3 55.4 556 43 34 27 51 40 31 25 33 26 21 27 21 17 21 17 13 10

130-140 1852.83 90-120 13058.07 29.7 32.0 651 38 29 23 47 35 27 21 29 23 18 24 18 14 18 14 11 8

140-150 185.86 90-130 16136.25 36.7 39.6 747 34 25 20 43 31 24 18 26 20 15 21 16 12 17 12 9 7

150-160 14.88 90-150 18174.93 41.3 44.6 844 31 22 17 40 28 21 16 24 17 13 19 14 10 15 11 8 6

160-170 1.78 90-180 18191.71 41.3 44.6 941 28 20 15 37 26 18 14 21 15 11 18 13 9 14 10 7 5

170-180 0.12 0-180 40749.78 92.6 100.0 10 38 25 18 13 35 23 16 12 20 14 10 16 11 8 13 9 6 4

Zone Lumens TOTAL LUMINAIRE EFFICIENCY = 81.4%

REPORT NUMBER: KP40PST0-10 561.93 CIE Type - Direct

10-20 1748.92

Plane

Spacing

Criteria

Lamps: 400 W Pulse Start Metal Halide with

Standard Dome Reflector *

20-30 2859.54

30-40 4018.21 0-180 1.76 Coefficients of Utilization - Zonal Cavity Method

40-50 5254.58 90-270 1.76 Effective Floor Cavity Reflectance 0.20

50-60 5772.38 Diagonal 1.86 % Ceiling Rcc 80 70 50 30 10 0

60-70 6052.84 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 5887.04 ZONAL LUMEN SUMMARY 0

97 97 97 97

95 95 95 95 90 90 90 86 86 86 83 83 83 81

80-90 3512.71 Zone Lumens % Lamp % Fixture 184 78 73 68 81 76 71 67 72 69 65 69 66 63 66 63 61 59

90-100 137.17 0-30 5170.39 11.8 14.4 274 65 58 51 72 63 57 51 60 54 49 57 52 48 55 51 47 45

100-110 0.00 0-40 9188.60 20.9 25.7 366 55 47 40 64 54 46 40 51 44 39 49 43 38 46 42 37 35

110-120 0.00 0-60 20215.55 45.9 56.5 460 48 39 32 58 47 39 32 44 37 32 42 36 31 40 35 31 28

120-130 0.00 0-90 35668.14 81.1 99.6 555 42 33 27 53 41 33 27 39 32 26 37 31 26 36 30 26 24

130-140 0.00 90-120 137.17 0.3 0.4 650 37 29 23 48 36 28 23 35 28 22 33 27 22 32 26 22 20

140-150 0.00 90-130 137.17 0.3 0.4 746 33 25 20 44 33 25 19 31 24 19 30 24 19 29 23 19 17

150-160 0.00 90-150 137.17 0.3 0.4 843 30 22 17 41 30 22 17 28 22 17 27 21 17 26 21 17 15

160-170 0.00 90-180 137.17 0.3 0.4 940 28 20 15 38 27 20 15 26 19 15 25 19 15 24 19 15 13

170-180 0.00 0-180 35805.32 81.4 100.0 10 37 25 18 13 36 25 18 13 24 18 13 23 17 13 22 17 13 12

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

992

Mercmaster™ III 400 Luminaire Photometric Data

400 W PSMH

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

* Photometric data is based on a xture with

a 400-watt clear Pulse Start Metal Halide lamp

(44,000 lumen).

For candlepower values of xtures with other

PSMH lamps, use the following multipliers: for a 320

W (33,000 lumen) PSMH lamp – .750; for a 350 W

(37,000 lumen) PSMH lamp – .840. For candlepower

values of xture with guard, multiply by – 0.95.

Zone Lumens TOTAL LUMINAIRE EFFICIENCY = 76%

REPORT NUMBER: KP40PAN0-10 499.96 CIE Type - Direct

10-20 1605.38

Plane

Spacing

Criteria

Lamps: 400 W Pulse Start Metal Halide with

30° Angle Dome Reflector *20-30 2680.72

30-40 3841.49 0-180 2.28 Coefficients of Utilization - Zonal Cavity Method

40-50 4899.23 90-270 1.92 Effective Floor Cavity Reflectance 0.20

50-60 4819.21 Diagonal 1.84 % Ceiling Rcc 80 70 50 30 10 0

60-70 4564.58 % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

70-80 4063.65 089 89 89 89 86 86 86 86 80 80 80 75 75 75 71 71 71 69

80-90 3258.13 178 72 68 64 75 70 66 62 65 62 59 61 58 56 57 55 53 50

90-100 2105.14 ZONAL LUMEN SUMMARY 269 61 55 49 66 59 53 48 55 50 46 51 47 43 48 44 41 39

100-110 762.24 Zone Lumens % Lamp % Fixture 362 52 45 39 59 51 44 38 47 41 37 44 39 35 41 37 33 31

110-120 138.12 0-30 4786.06 10.9 14.3 456 46 38 32 54 44 37 31 41 35 30 38 33 29 36 31 28 26

120-130 77.59 0-40 8627.55 19.6 25.8 551 40 33 27 49 39 32 26 36 30 25 34 29 24 32 27 23 21

130-140 73.07 0-60 18345.99 41.7 54.9 647 36 28 23 45 35 28 22 32 26 22 30 25 21 29 24 20 18

140-150 25.07 0-90 30232.35 68.7 90.4 743 32 25 20 42 31 24 19 29 23 19 27 22 18 26 21 17 16

150-160 10.91 90-120 3005.49 6.8 9.0 840 29 22 17 39 28 22 17 27 21 16 25 20 16 24 19 15 14

160-170 5.30 90-130 3083.09 7.0 9.2 937 26 20 15 36 26 19 15 24 19 15 23 18 14 22 17 14 12

170-180 1.45 90-150 3181.23 7.2 9.5 10 35 24 18 14 34 24 17 13 22 17 13 21 16 13 20 15 12 11

90-180 3198.89 7.3 9.6

0-180 33431.25 76.0 100.0

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

993

Mercmaster™ III 400 Luminaire Photometric Data

400 W PSMH

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

* Photometric data is based on a xture with

a 400-watt clear Pulse Start Metal Halide lamp

(44,000 lumen).

For candlepower values of xtures with other

PSMH lamps, use the following multipliers: for a 320

W (33,000 lumen) PSMH lamp – .750; for a 350 W

(37,000 lumen) PSMH lamp – .840. For candlepower

values of xture with guard, multiply by – 0.95.

Zone Lumens TOTAL LUMINAIRE EFFICIENCY = 78.4%

REPORT NUMBER: KP40PJ50-10 77.24 CIE Type - Semi-Direct

10-20 575.14

Plane

Spacing

Criteria

Lamps: 400 W Pulse Start Metal Halide with

8” Prismatic Glass Refracter - NEMA Type V *

20-30 1061.45

30-40 1581.40 0-180 1.36 Coefficients of Utilization - Zonal Cavity Method

40-50 4468.52 90-270 1.40 Effective Floor Cavity Reflectance 0.20

50-60 4938.88 Diagonal 2.42 % Floors Rfc 20

60-70 6338.26 % Ceiling Rcc 80 70 50 30 10 0

70-80 5875.90 ZONAL LUMEN SUMMARY % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

80-90 3886.90 Zone Lumens % Lamp % Fixture 090 90 90 90 87 87 87 87 80 80 80 74 74 74 68 68 68 65

90-100 1318.17 0-30 1713.83 3.9 5.0 177 71 66 61 73 68 63 59 62 58 54 57 53 50 52 49 47 44

100-110 1872.98 0-40 3295.23 7.5 9.6 267 58 50 44 64 55 48 42 50 44 39 45 41 37 41 37 34 31

110-120 1122.17 0-60 12702.64 28.9 36.8 359 48 40 33 56 46 38 32 42 35 30 38 32 27 34 29 25 23

120-130 616.83 0-90 28803.69 65.5 83.5 453 41 33 26 50 39 31 25 35 29 23 32 26 21 29 24 20 17

130-140 358.56 90-120 4313.33 9.8 12.5 548 36 27 21 45 34 26 20 31 24 18 28 22 17 25 20 16 13

140-150 224.03 90-130 4930.15 11.2 14.3 644 31 23 17 41 30 22 16 27 20 15 24 18 14 22 17 13 11

150-160 128.38 90-150 5512.75 12.5 16.0 740 28 20 14 38 26 19 14 24 17 13 22 16 12 19 14 11 9

160-170 50.79 90-180 5699.61 13.0 16.5 837 25 17 12 35 24 17 11 22 15 11 19 14 10 18 13 9 7

170-180 7.69 0-180 34503.3 78.4 100.0 934 22 15 10 32 21 15 10 20 13 9 18 12 8 16 11 8 6

10 32 20 14 9 30 20 13 9 18 12 8 16 11 7 15 10 7 5

Zone Lumens TOTAL LUMINAIRE EFFICIENCY = 64.2%

REPORT NUMBER: KP40PHB0-10 514.26 CIE Type - Direct

10-20 1734.49

Plane

Spacing

Criteria

Lamps: 400 W Pulse Start Metal Halide with

Enclosed Reflector (KPR-4HB) *

20-30 3370.99

30-40 5333.06 0-180 2.32 Coefficients of Utilization - Zonal Cavity Method

40-50 7165.13 90-270 2.32 Effective Floor Cavity Reflectance 0.20

50-60 6195.93 Diagonal 2.04 % Floors Rfc 20

60-70 2879.28 % Ceiling Rcc 80 70 50 30 10 0

70-80 921.95 ZONAL LUMEN SUMMARY % Walls Rw 70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10 0

80-90 111.28 Zone Lumens % Lamp % Fixture 076 76 76 76 75 75 75 75 71 71 71 68 68 68 65 65 65 64

90-100 0.14 0-30 5619.74 12.8 19.9 170 67 65 63 69 66 64 62 63 61 60 61 59 58 59 57 56 55

100-110 0.00 0-40 10952.81 24.9 38.8 264 59 55 51 62 58 54 50 55 52 49 53 51 48 51 49 47 46

110-120 0.00 0-60 24313.86 55.3 86.1 358 51 46 42 56 50 46 42 48 44 41 47 43 40 45 42 40 38

120-130 0.00 0-90 28226.37 64.2 100.0 453 45 39 35 51 44 39 35 43 38 34 41 37 34 40 36 33 32

130-140 0.00 90-120 0.14 0.0 0.0 548 40 34 30 47 39 34 29 38 33 29 36 32 29 35 31 28 27

140-150 0.00 90-130 0.14 0.0 0.0 644 35 29 25 43 35 29 25 34 29 25 32 28 25 31 28 24 23

150-160 0.00 90-150 0.14 0.0 0.0 741 32 26 22 39 31 26 22 30 25 22 29 25 21 28 24 21 20

160-170 0.00 90-180 0.14 0.0 0.0 837 29 23 19 36 28 23 19 27 22 19 26 22 19 26 22 19 17

170-180 0.00 0-180 28226.50 64.2 100.0 935 26 20 17 34 25 20 17 25 20 17 24 20 16 23 19 16 15

10 32 24 18 15 32 23 18 15 23 18 15 22 18 15 21 17 15 13

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

994

Mercmaster™ III 400 Luminaire Photometric Data

400 W PSMH

Listed for si mul ta ne ous ex po sure to com bust i ble dusts and flam ma ble gas es or va pors.

Applications

• Enclosedandgasketedxturessuitableforusein:

—Marineandwetlocations

—Areaswhereammablegases,vaporsorcombustibledusts

arepresentunderconditionsdenedbytheIECasZone2

and22

—Applicationswhereenergyefcient,highlumenoutputis

required

—Non-hazardouslocationswheresevereweatherconditions,

excessivemoisture,dirt,dust,corrosiveatmosphereorhigh

ambienttemperaturesareencountered

• Typicalapplicationsinclude:

—Pulpandpapermills

—Processingplants

—Chemicalplants

—Oilreneries

—Foundries

—Manufacturingplants

—Storageareas

—Wasteandsewagetreatment

—Otherareaswheredust,water,dirtandroughusagearea

problem

Features

• Powersupply230/240V(+6%-10%)50Hz.

• Instantrelightingwithauxiliaryhalogenlamps,dependingon

model(lampsnotsupplied).

• Fastrelightingfor70Wand150Wsodium:5to30seconds

dependingonthedurationofthemainspowersupplyfailure.

• Connectionviaterminalblock(0.003x0.006in2/

2x4mm2max.).

• Superiorcorrosion-resistance:copperfreedie-castmounting

hoods,ballasthousingandguardshaveagrayepoxypowder

coat,electrostaticallyappliedforcompleteanduniform

protection.

• Widechoiceoflightsources:highpressuresodium,metal

halide,mercuryvaporandincandescent.

• Sixmountingarrangementstosuitanylightinglayout–pendant,

ceiling,wallbracket,angledorstraightstanchionandpendant

cone(fordustapplications).

• Hingehashighlipforaddedsafetyduringinstallation

andservicing.Hingeandboltconstructionassures360°

compressionatallpointsonballasthousinggasketforpositive

sealing.Swingawaydesignofcaptiveboltandnutsimplies

servicing.

• Allxturesdesignedtoperformina-40°F/-40°Cambient

temperatureupto131°F/55°C.

• Standarddomeor30°anglereectorsmadeofberglass

reinforcedwhitepolyester.Highlyresistanttocorrosive

atmospheresandventedtoimprovexturecooling

characteristics.

• Fixturehousingmountinghoodsandguardsaredie-cast

copperfreealuminumwithepoxypowdercoatnish.

• Allexposedhardwareisstainlesssteelandcaptive.Stainless

threadinsertsintheballastbodiesprevent“freezing”ofthe

screwsthatafxguardsandreectors,simplifyingremovalfor

service.

• One-pieceballasthousingforeachcomponentprovideseven

heatdissipationforcooleroperationandlongerballastlife.

• FixturebodiesareprovidedwithtwosiliconerubberO-Ring

stylegasketsthatwillstayexibleandassureevencompression

aroundtheircircumference.Theyeasilywithstandhigh

temperatures,moisture,dirtanddustforworryfreeoperation.

Standard Materials

• Mountinghoodsandballastbodies:die-castcopperfree(4/10

of1%max.)aluminum

• Hardwareandcatchassemblies:stainlesssteel

• Globe:heatandimpactresistantinternallyutedglass

• Gasket:hightemperaturesilicon

• Reector:berglassreinforcedpolyester

• Guards:polyesterpowdercoatnishedcastcopperfree

aluminum(LN1andLN2sizes)orstainlesssteel(LN3andLN4

sizes)

Standard Finishes

• Mountinghoods,ballastbodiesandguards:epoxypowdercoat

nish,electrostaticallyappliedforcomplete,uniformsurface

protection

• Reectors:whitepolyesternish

Low Profile Ceiling Mount with

Prismatic Globe and Optional Guard

50-200 Watt 25° Stanchion Mount

with Prismatic Globe

50-200 Watt 90° Stanchion Mount

with Prismatic Globe and

Optional Guard

400 Watt Straight Stanchion Mount

with Prismatic Glass Globe and

Optional Guard

Zone 2 and 22

II 3 GD

ATEX / IEC IP66

LN Series Wellglass Luminaires

Zone 2 and 22

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

995

Orderusingcatalognumberingguidebeloworselectcatalognumberfromtablesonfollowingpages.

Catalog Numbering Guide for LN Series Luminaires

LN 1 A H 70 A G2 XA P

Series:

LN-LNSeries

Zone2,22

ATEX/IECCertified

Mounting:

A-Pendant

(Rigid

Mounting)

C-Ceiling

D-PendantCone

F-Pendant

(Flexible

Mounting)

R-Straight

Stanchion

S-25°Stanchion

W-Wall

LampWattage:

70-70W

80-80W

85-85W

Inductiononly

10-100W

12-125W

15-150W

25-250W

40-400W

Globe:

G2-GlassGlobe

VPGL-2HR

G4-GlassGlobe

VPGL-4HR

Options:

P-PTFECoating

BodySize:

1-Size1(MLBG)

2-Size2(KPB)

3-Size3(KPBR)

4-Size4(KPB400)

LampType:

H-MetalHalide

L-Sodium

M-MercuryVapor

Q-Induction

Z-Halogen/

Incandescent

HubSize:

A-M20

2-3/4"NPT

3-1"NPT

4-1-1/4"NPT

5-1-1/2"NPT

Voltage(MagneticBallast):

XA-220Vac50Hz

XJ-230/240Vac50Hz

Certifications and Compliances

• Gas:CerticationTypeLN

 —Zone2

 —ConformingtoATEX94/9/CE:CE II3G

 —ATEX/IECProtection:ExnRII

 —AmbientTemperature:104°F/40°Cto131°F/55°C

 —CEDeclarationofConformity:50217

 —ATEXCerticate:LCIE08ATEX6036X

 —IECCerticate:LCIEEx08.003X

 —OtherCertications:GOST

• Dust:CerticationTypeLN

 —Zone22

 —ConformingtoATEX94/9/CE:CE II3D

 —ATEX/IECProtection:ExtDA22

 —AmbientTemperature:104°F/40°Cto131°F/55°C

 —CEDeclarationofConformity:50217

 —ATEXCerticate:LCIE08ATEX6036X

 —IECCerticate:LCIEEx08.003X

 —OtherCertications:GOST

• Exstandards:EN/IEC60079-0;60079-15;61241-0;61241-1

• Productstandards:EN/IEC60598-1

• EMCstandards:EN/IEC55015;61547

• Otherstandards:EN/IEC60529(IP)

Zone 2 and 22

II 3 GD

ATEX / IEC IP66

LN Series Wellglass Luminaires

Zone 2 and 22

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

996

T Rating for Zone 2 Locations

Not available for Zone 22 locations

Zone 2 T Rating Ambient Temperatures Zone 22 Surface Temperature for

Ambient T° = +131 °F/+55°C

+104 °F/+40°C +122 °F/+50°C +131 °F/+55°C Dust Surface Cable

70WHPS TRating T4 T4 T4 235°F/113°C —

100WHPS TRating T4 T3 T3 289°F/143°C —

100WIncandescent TRating T4 T3 T3 289°F/143°C —

100WHalogen TRating T4 T3 T3 289°F/143°C —

125WMercury TRating T4 T3 T3 289°F/143°C —

150WHPS TRating T4 T3 T3 289°F/143°C —

150WHalide TRating T4 T3 T3 289°F/143°C —

150WIncandescent TRating T4 T3 T3 289°F/143°C —

150WHalogen TRating T4 T3 T3 289°F/143°C —

250WHPS TRating T4 T4 T3 279°F/137°C —

250WHalide TRating T4 T3 T3 289°F/143°C —

250WMercury TRating T4 T3 T3 289°F/143°C —

400WHPS TRating T3 T3 T3 333°F/167°C 192°F/89°C

CableT° – 183 °F/84 °C 192 °F/89 °C

400WHalide TRating T3 T3 T3 340°F/171°C 189°F/87°C

CableT° – 180 °F/82 °C 189 °F/87 °C

400WMercury TRating T3 T3 T3 340°F/171°C 192°F/89°C

CableT° – 183 °F/84 °C 192 °F/89 °C

Zone 2 and 22

II 3 GD

ATEX / IEC IP66

LN Series Wellglass Luminaires

Zone 2 and 22

“T” Numbers Represent the Maximum Lamp Temperature Locations and Maximum Surface Temperature Under Dust Blanket.

“T”

Number T1 350 325 T2 T2A T2B T2C T2D T3 T3A T3B T3C T4 T4A T5 T6

Temp.

Range

(˚ºF)

664-

842

619-

662

574-

617

538-

572

502-

536

448-

500

421-

446

394-

419

358-

392

331-

356

322-

329

277-

320

250-

275

214-

248

187-

212 185

Temp.

Range

(°C)

351-

450

326-

350

301-

325

281-

300

261-

280

231-

260

216-

230

201-

215

181-

200

166-

180

161-

165

136-

160

121-

135

101-

120

86-

100 85

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

997

Lamp

Type Cable Entry

Lamp

Watts Lampholder

Weight

Lbs/kg

Volume

(in3/dm3)

Catalog

Number

Pendant

HPS 1x3/4”NPT

70 E27 16.31/7.4 2379.93/39 LN1AL702G2XJ

100 E40 19.84/9.0 3356.31/55 LN2AL102G2XJ

150 E40 19.84/9.0 3356.31/55 LN2AL152G2XJ

250 E40 35.27/16.0 4271.66/70 LN3AL252G4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4AL402G4XJ

Pendant Cone

HPS 1x3/4”NPT

70 E27 16.31/7.4 2379.93/39 LN1DL702G2XJ

100 E40 19.84/9.0 3356.31/55 LN2DL102G2XJ

150 E40 19.84/9.0 3356.31/55 LN2DL152G2XJ

250 E40 35.27/16.0 4271.66/70 LN3DL252G4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4DL402G4XJ

Ceiling

HPS

5x1”NPTwith:

-4x1”NPTfittedplugs

-2x1”NPT-M20adaptors

-2xM20plugs

70 E27 16.31/7.4 2379.93/39 LN1CL70AG2XJ

100 E40 19.84/9.0 3356.31/55 LN2CL10AG2XJ

150 E40 19.84/9.0 3356.31/55 LN2CL15AG2XJ

250 E40 35.27/16.0 4271.66/70 LN3CL25AG4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4CL40AG4XJ

Wall

HPS

5x1”NPTwith:

-4x1”NPTfittedplugs

-2x1”NPT-M20adaptors

-2xM20plugs

70 E27 16.31/7.4 2379.93/39 LN1WL70AG2XJ

100 E40 19.84/9.0 3356.31/55 LN2WL10AG2XJ

150 E40 19.84/9.0 3356.31/55 LN2WL15AG2XJ

250 E40 35.27/16.0 4271.66/70 LN3WL25AG4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4WL40AG4XJ

25° Angled Stanchion

HPS 1x1-1/4”NPT

70 E27 16.31/7.4 2379.93/39 LN1SL704G2XJ

100 E40 19.84/9.0 3356.31/55 LN2SL104G2XJ

150 E40 19.84/9.0 3356.31/55 LN2SL154G2XJ

250 E40 35.27/16.0 4271.66/70 LN3SL254G4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4SL404G4XJ

Straight Stanchion

HPS 1x1-1/4”NPT

70 E27 16.31/7.4 2379.93/39 LN1RL704G2XJ

100 E40 19.84/9.0 3356.31/55 LN2RL104G2XJ

150 E40 19.84/9.0 3356.31/55 LN2RL154G2XJ

250 E40 35.27/16.0 4271.66/70 LN3RL254G4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4RL404G4XJ

Zone 2 and 22

II 3 GD

ATEX / IEC IP66

LN Series Wellglass Luminaires

Zone 2 and 22

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

998

Lamp Type Cable Entry

Lamp

Watts Lampholder

Weight

Lbs/kg

Volume

(in3/dm3)

Catalog

Number

Pendant

Inc./

Halogen 1x3/4”NPT 100 E27 16.31/7.4 2379.93/39 LN1AZ102G2

150 E27 16.31/7.4 2379.93/39 LN1AZ152G2

Pendant Cone

Inc./

Halogen 1x3/4”NPT 100 E27 16.31/7.4 2379.93/39 LN1DZ102G2

150 E27 16.31/7.4 2379.93/39 LN1DZ152G2

Ceiling

Inc./

Halogen

5x1”NPTwith:

-4x1”NPTfittedplugs

-2x1”NPT-M20adaptors

-2xM20plugs

100 E27 16.31/7.4 2379.93/39 LN1CZ10AG2

150 E27 16.31/7.4 2379.93/39 LN1CZ15AG2

Wall

Inc./

Halogen

5x1”NPTwith:

-4x1”NPTfittedplugs

-2x1”NPT-M20adaptors

-2xM20plugs

100 E27 16.31/7.4 2379.93/39 LN1WZ10AG2

150 E27 16.31/7.4 2379.93/39 LN1WZ15AG2

25° Angled Stanchion

Inc./

Halogen 1x1-1/4”NPT 100 E27 16.31/7.4 2379.93/39 LN1SZ104G2

150 E27 16.31/7.4 2379.93/39 LN1SZ154G2

Straight Stanchion

Inc./

Halogen 1x1-1/4”NPT 100 E27 16.31/7.4 2379.93/39 LN1RZ104G2

150 E27 16.31/7.4 2379.93/39 LN1RZ154G2

Zone 2 and 22

II 3 GD

ATEX / IEC IP66

LN Series Wellglass Luminaires

Zone 2 and 22

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

999

Lamp Type Cable Entry

Lamp

Watts Lampholder

Weight

Lbs/kg

Volume

(in3/dm3)

Catalog

Number

Pendant

MV 1x3/4”NPT

150 E27 16.31/7.4 2379.93/39 LN1AM122G2XJ

250 E40 30.86/14.0 4271.66/70 LN3AM252G4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4AM402G4XJ

Pendant Cone

MV 1x3/4”NPT

150 E27 16.31/7.4 2379.93/39 LN1DM122G2XJ

250 E40 30.86/14.0 4271.66/70 LN3DM252G4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4DM402G4XJ

Ceiling

5x1”NPTwith:

-4x1”NPTfittedplugs

-2x1”NPT-M20adaptors

-2xM20plugs

150 E27 16.31/7.4 2379.93/39 LN1CM12AG2XJ

250 E40 30.86/14.0 4271.66/70 LN3CM25AG4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4CM40AG4XJ

Wall

5x1”NPTwith:

-4x1”NPTfittedplugs

-2x1”NPT-M20adaptors

-2xM20plugs

150 E27 16.31/7.4 2379.93/39 LN1WM12AG2XJ

250 E40 30.86/14.0 4271.66/70 LN3WM25AG4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4WM40AG4XJ

25° Angled Stanchion

MV 1x1-1/4”NPT

150 E27 16.31/7.4 2379.93/39 LN1SM124G2XJ

250 E40 30.86/14.0 4271.66/70 LN3SM254G4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4SM404G4XJ

Straight Stanchion

MV 1x1-1/4”NPT

150 E27 16.31/7.4 2379.93/39 LN1RM124G2XJ

250 E40 30.86/14.0 4271.66/70 LN3RM254G4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4RM404G4XJ

Zone 2 and 22

II 3 GD

ATEX / IEC IP66

LN Series Wellglass Luminaires

Zone 2 and 22

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

1000

Lamp

Type Cable Entry

Lamp

Watts Lampholder

Weight

Lbs/kg

Volume

(in3/dm3)

Catalog

Number

Pendant

MH 1x3/4”NPT

150 E40 19.84/9.0 3356.31/55 LN2AH152G2XJ

250 E40 35.27/16.0 4271.66/70 LN3AH252G4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4AH402G4XJ

Pendant Cone

MH 1x3/4”NPT

150 E40 19.84/9.0 3356.31/55 LN2DH152G2XJ

250 E40 35.27/16.0 4271.66/70 LN3DH252G4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4DH402G4XJ

Ceiling

5x1”NPTwith:

-4x1”NPTfittedplugs

-2x1”NPT-M20adaptors

-2xM20plugs

150 E40 19.84/9.0 3356.31/55 LN2CH15AG2XJ

250 E40 35.27/16.0 4271.66/70 LN3CH25AG4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4CH40AG4XJ

Wall

5x1”NPTwith:

-4x1”NPTfittedplugs

-2x1”NPT-M20adaptors

-2xM20plugs

150 E40 19.84/9.0 3356.31/55 LN2WH15AG2XJ

250 E40 35.27/16.0 4271.66/70 LN3WH25AG4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4WH40AG4XJ

25° Angled Stanchion

MH 1x1-1/4”NPT

150 E40 19.84/9.0 3356.31/55 LN2SH154G2XJ

250 E40 35.27/16.0 4271.66/70 LN3SH254G4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4SH404G4XJ

Straight Stanchion

MH 1x1-1/4”NPT

150 E40 19.84/9.0 3356.31/55 LN2RH154G2XJ

250 E40 35.27/16.0 4271.66/70 LN3RH254G4XJ

400 E40 41.89/19.0 5199.22/85.2 LN4RH404G4XJ

Zone 2 and 22

II 3 GD

ATEX / IEC IP66

LN Series Wellglass Luminaires

Zone 2 and 22

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

1001

Item Description Catalog Number

White Polyester Reflectors — Furnished with stainless steel screws

For Globe Fixtures – LN1 and LN2 sizes

StandardDome KR2-ST

30°Angle KR2-AN

For Glass Refractor Fixtures † – LN3 and LN4 sizes

StandardDome CMR-4ST

Standard Dome 30° Angle 30°Angle CMR-4AN

Guards

For Globe Fixtures – LN1 and LN2 sizes

Aluminum KRGU2

For Glass Refractor Fixtures † – LN3 and LN4 sizes

StainlessSteel KPGU400

Globe Guard Globe Guard

† Fixtures with refractors are not UL Listed when used with reflectors.

LN Series Wellglass Luminaires

Zone 2 and 22

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

1002

LN Series Wellglass Luminaires

Zone 2 and 22

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

1003

Ballast Body with Globe

LN1 LN2 LN3 LN4

13.52”/346.0 mm

11.61”/295.0 mm

Fix.

12.68”/322.0 mm

13.52”/346.0 mm

Fix.

12.68”/322.0 mm

10.83”/275.0 mm

13.52”/346.0 mm

Fix.

12.68”/322.0 mm

16.73”/425.0 mm

13.52”/346.0 mm

Fix.

12.68”/322.0 mm

20.50”/520.7 mm

Mounting Hoods

Pendant Pendant Cone Ceiling

12.06”/306.0 mm

1.17”/

30.0 mm

12.06”/306.0 mm

5.59”/

142.0 mm

12.06”/306.0 mm

13.62”/346.0 mm

1.75”/

45.0 mm

0.375”/

9.5 mm

Dia. (+DFT)

0.56”/

14.3 mm

Dia. (+DFT)

2.00”/

50.8 mm

Dia. (+DFT)

2.50”/

63.5 mm

Dia. (+DFT)

5.00”/

127.0 mm

Wall 25° Stanchion 90° Stanchion

17.01”/

432.0 mm

10.94”/

278.0 mm

12.05”/

306.0 mm

3.38”/

85.8 mm

4.06”/

103.0 mm

(4) Mounting Holes

0.31”/8.0 mm

7.60”/

193.0 mm

12.05”/

306.0 mm

2.00”/

51.0 mm

15.28”/

388.0 mm

9.25”/

235.0 mm

12.06”/306.0 mm

17.23”/438.0 mm

9.79”/249.0 mm

LN Series Wellglass Luminaire Photometric Data

Zone 2 and 22

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

1004

Polarcurvesfora1000lmflux,accordingtoNFC71-120

LuminairesymbolaccordingtoNFC71-121 Longitudinal

Transverse

High Pressure Sodium

70 W HP Sodium

Efficiency 74.6%

150 W HP Sodium

Efficiency 87.3%

250 W HP Sodium

Efficiency 89.1%

400 W HP Sodium

Efficiency 82.3%

Degrees Degrees Degrees Degrees

Metal Halide

150 W Metal Halide

Efficiency 82.4%

250 W Metal Halide

Efficiency 96.2%

400 W Metal Halide

Efficiency 89.8%

Degrees Degrees Degrees

Incandescent or Halogen

150 W HP Incandescent Halogen

Efficiency 90.6%

Degrees

Mercury Vapor

250 W Mercury Vapor

Efficiency 76%

Degrees

Class I, Division 2, Groups A, B, C, D †

Class II, Division 1 and 2, Groups E, F, G ‡

Class III

Fixtures Outside Type (Salt Water)

Applications

• EnclosedandgasketedHIDlightingxturesforuseintunnels,

walkways,bridges,storagefacilities,processingplants,parking

lots,foundries,manufacturingplants,powerplantsandother

locationswheremoisture,dirt,dustorcorrosiveatmospheres

areencountered.

• FixturessuitedforClassI,Division2;ClassII,Division1and

2;andClassIII.Suitableforuseinwetandoutdoorsaltwater

locations.

• Widerangeofwattagesandvoltages.Choiceofballastsfor100

W-200WPSMH;and50W-150WHPSlampsin120,208,240,

277and480voltages.

• Choiceoflightsources:highpressuresodiumandpulsestart

metalhalide.

• Choiceofopticalassembles:(1)prismaticglobewithorwithout

guardthrough200W;or(2)TypeVclosedprismaticglass

refractorthrough200W.(TypesII,IIIandIValsoavailable

through200W.Alsopolycarbonateglobesfor100Wmax.)

• Choiceofmountinghoods:pendant(rigidorexible),25°(angle)

stanchion,ceilingandwallmounting.

• PorcelainreectorforstandardapplicationsandFiberglass

reinforcedpolyesterreectorforinstallationswhereluminaireis

subjecttoexceptionallyseverecorrosiveatmospheres.

Features

• Superiorcorrosion-resistance:copperfreealuminummounting

hoods,ballastsandguardswithepoxypowdercoat,inside

andout.

• Standardpendantmountinghoodforrigidorexiblemounting.

Balancedrounddesignautomaticallyhangsplumbwhenused

withexiblehanger.

• Positivesealing.Hingeandboltconstructionassures360°

compressionatallpointsongasket.

• One-pieceballasthousingforeachcomponentprovideseven

heatdissipationforcooleroperationandlongerballastlife.

• Heatbarrierisolatescapacitorfromballast.Standardnon-PCB

biodegradablecapacitorsinstalledinseparatecompartment.

• Mogulsocketisfurnishedwith392°F/200°Cweldedleads,

pre-wiredtotheballast.

• Porcelainsocketassurestrouble-freeoperationinhighambient

installations.

• Guardsprotectglobesfromdamage.Keyholeslotsalloweasy

installationandaresecuredwithstainlesssteelscrews.

• Prismaticglassglobesandglass

refractorsarestandard(plasticrefractorsalsoavailable)and

threaddirectlyintoxturehousing.Eliminateglareandprovide

uniformlightdistribution.

• Ventedreectorsresultincooler,dirt-freeoperation,increased

lumenoutput.

• Reectorssecuredtomountinghoodwithscrews(furnished).

• Choiceofreectorstyles:whiteporcelainenamelorFiberglass

reinforcedpolyester;standarddomeor30°angle.

• Optionalphotocellprovidesautomatic“on-off”control.

• AllMercmastermountinghoodshaveprovisionforeasyeld

installationoffusesinxtures(seefusekitlistings).

Standard Materials

• Mountinghoods,ballastbodiesandguards:copperfree(4/10of

1%max.)aluminum

• Reectors:berglassreinforcedpolyester

• Globes:50W-100W,threadedprismaticglass;150W,175W

and200W,threadedheat-resistantprismaticglass

• Refractors:50Wto150W,heat-resistantprismaticglassand

plastic;175Wto200W,prismaticglass

Standard Finishes

• Mountinghoods,ballastbodies,guards:epoxypowder-coat

nish.Two-coatbakednish,electrostaticallyappliedfor

completeuniformsurfaceprotection

• Polyesterreectors:naturalnish

Options

• Fusesforxtures.ForfusekitsseeElectrical Specications and

Fuse Kitspage.

• MHxturesforQuartzAuxiliarylamps.Relayswitchinstalled

inxturewhenspecied.Addsufx-MTEtoxturecatalog

numberfor120Vthrough277V,andsufx-480Etoxture

catalognumberfor480Vxture.

• SmartHotRestrikeemergencyoption,availablefor50W-150W

HPSonly.Addsufx-SR.See50 W, 70 W, 100W, 150 W HPS

page.

• HotRestrikeoptionaddsufx-R.

• SmartStarteravailableforHPSandPSMH.Addsufx-S.

Certifications and Compliances

• ULStandard:UL1598,UL1598A,UL844

• ULListed:E10444

† For specific Class I suitability of each fixture listed, see Thermal Suitability.

‡ For 175 W and 200 W fixtures, use 12” refractor only for Groups E, F and G. Heat-resistant glass globe supplied with 175 W and 200 W fixtures.

Note: Fixtures equipped with optional photocell or quartz auxilliary lamp do not comply with UL requirements and are not suitable for use in classfied locations.

Lighting Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

1005

Mercmaster™ II HID Luminaires

High Pressure Sodium and Pulse Start Metal Halide. Mogul Base

UNILETS® for Use with Threaded Metal Conduit.

Class I, Division 2, Groups A, B, C, D †

Class II, Division 1 and 2, Groups E, F, G ‡

Class III

Fixtures Outside Type (Salt Water)

Lighting

Lighting: EncLosEd and gaskEtEd — arEa — hid

Visit our website at www.appletonelec.com or contact us at (800) 621-1506.

1006

Mercmaster™ II HID Luminaires

High Pressure Sodium and Pulse Start Metal Halide. Mogul Base

UNILETS® for Use with Threaded Metal Conduit.

Illustrated Features

High Temperature Sockets

Mogulbasehightemperaturesocketfor

50Wthrough400WHIDlamps.

Aluminum Inner Reflector

Solidaluminuminnerreflectorimproves

photometricefficiency.

Hood/Ballast Gasket

Siliconerubbergasketsealsoutmoisture,

dirtanddust.

Stainless Steel

Latch Assembly

Captive,stainless

steellatchassembly

boltandnutcloses

securely,resists

attackofcorrosive

atmospheres.

Swing-awaydesign

simplifiesservicing.

Epoxy Finish

Ballasthousing,hoodsandguardsare

copperfreealuminumwithepoxypowder

coatfinish.

Balanced Round

Design

Pendantfixtures

automaticallyhang

plumb.Fixturesand

hangerssuitablefor

ClassI,Division2

applications.

JB Series Box and

Flexible Hanger

Electrical Protection

Groundwireprovidedtobondmounting

hoodtoballasthousing.Fiberinsulator

protectsballastandcapacitor.

"Safety" High

Hinge

Extra-highhinge

providesadditional

protectionagainst

accidental

ballasthousing

disengagement

duringinstallation

ormaintenance.

Photocell

Installsthroughknock-outinmounting

hood;providescontinuousON-OFFdusk-

to-dawncontrol.Fixtureswithoptional

photocellorquartzauxiliarylampdonot

complywithULrequirementsforusein

classifiedlocations.

Fuses Mount to Hood Bosses

Twoscrewssecurefusekittomounting

bossinanyMercmastermountinghood.

† For specific Class I suitability of each fixture listed, see Thermal Suitability.

‡ For 175 W and 200 W fixtures, use 12” refractor only for Groups E, F and G. Heat-resistant glass globe supplied with 175 W and 200 W fixtures.

† For specific Class I suitability of each fixture listed, see Thermal Suitability.

‡ For 175 W and 200 W fixtures, use 12” refractor only for Groups E, F and G. Heat-resistant glass globe supplied with 175 W and 200 W fixtures.

* NOTE: Fixtures equipped with quartz emergency light do not comply with UL requirements and are not suitable for use in classified locations.

Quartz Emergency Light for Pulse Start Metal Halide or High Pressure Sodium Fixtures *

Mercmasterfixturesforormetalhalideandhighpressuresodiumlampscanbesuppliedwith

asockettoaccepta150W120Vquartzlamp.ThisD.C.bayonetbasesocketisinadditionto

thestandardlampsocket.Intheeventofamomentarypowerinterruption,thequartzlampis

automaticallyswitchedon.ThesingleendedquartzlampremainsenergizeduntiltheHIDrestrikes

andreachesabout60%output.

Thequartzemergencylampsocketiswiredtoa120Vtapontheballastandistherefore

independentofthelightingfixturevoltage.Nospecialfieldwiringisnecessary.

Description Catalog Suffix

Forfixturevoltsof120,208,240or277 -MTE

Forfixturevoltsof480 -480E

HPS Smart Hot Restrike Accessory for HPS Fixtures

Encapsulated HPS

Smart Hot Restrike

Ignition Accessory
