Masterpact™ NT/NW
Universal Power Circuit Breakers
Pricing Guide
0613PL0001 R07/13
2013
Class 613
CONTENTS
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
ANSI C37/UL 1066 Rated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Basic Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Circuit Breaker/Cradle Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
ArcBlok™ Circuit Breakers Basic Block . . . . . . . . . . . . . . . . . . . . . . . . . .7
ArcBlok Cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
UL 489 Rated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Basic Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Circuit Breaker/Cradle Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
ArcBlok™ Circuit Breakers Basic Block . . . . . . . . . . . . . . . . . . . . . . . . .11
ArcBlok Cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
DC Circuit Breakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
IEC 60947-2 Rated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Basic Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cradle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Circuit Breaker/Cradle Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
DC Circuit Breakers and Non-Automatic Switches . . . . . . . . . . . . . . . .16
Trip Unit and Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Appendices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
™
2© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
Introduction
This document is intended to provide pricing for a complete circuit breaker with cradle and required accessories, as well as field-installable
accessory kits. Refer to the Masterpact NT/NW Universal Power Circuit Breaker Catalog (0613CT0001) for product descriptions.
For assistance in creating a complete breaker and cradle catalog number, please contact your nearest Square D/Schneider Electric sales office.
To price a complete circuit breaker, first determine the rating required:
ANSI C37/UL 1066 (page 3)
UL 489 (page 8)
IEC 60947-2 (page 13)
Then include:
1. Basic Block
2. Cradle (for drawout circuit breaker)
3. Circuit Breaker/Cradle Connectors
4. Trip Unit and Options (page 17)
Optional:
1. Circuit Breaker Accessories (page 19)
2. Cradle Accessories (page 20)
3. Miscellaneous Accessories (page 22)
Please see Appendix A (pages 25–27) for a request for quotation form.
DE2F Discount
Schedule
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
3
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
ANSI C37/UL 1066 Rated
Basic Block
Please contact your nearest Square D/Schneider Electric sales office for assistance in building a complete circuit breaker or switch catalog number.
aIncludes sensor plug.
bTested to show the arc flash hazard risk category as referenced in NFPA70E.
aWhen used in conjunction with an overcurrent relay, circuit breaker, or fuse.
bIncludes sensor plug.
Table 1: T-, W-, and Y-Frame Drawout Circuit Breaker
Frame Rating
(A) Model Number Interrupting Rating (kA) Sensor Plug (A) $ Price
254 V 508 V 635 V 3-Pole 4-Pole
T-Frame
800 NT08N1 42 42 — 100,250,400,600,800 11726.00 17588.00
W-Frame
800
NW08N1 42 42 42 100, 250, 400, 600, 800 13028.00 19542.00
NW08H1 65 65 65 100, 250, 400, 600, 800 14942.00 22412.00
NW08H2 85 85 85 100, 250, 400, 600, 800 18026.00 27040.00
NW08H3 100 100 85 100, 250, 400, 600, 800 19626.00 29440.00
NW08L1 200 200 130 100, 250, 400, 600, 800 21226.00 N/A
NW08L1F 200 200 130 100, 250, 400, 600, 800 22276.00 N/A
1600
NW16N1 42 42 42 800, 1000, 1200, 1600 20256.00 30384.00
NW16H1 65 65 65 800, 1000, 1200, 1600 24152.00 36230.00
NW16H2 85 85 85 800, 1000, 1200, 1600 27980.00 41970.00
NW16H3 100 100 85 800, 1000, 1200, 1600 33470.00 50204.00
NW16L1 200 200 130 800, 1000, 1200, 1600 38960.00 N/A
NW16L1F 200 200 130 800, 1000, 1200, 1600 40010.00 N/A
2000
NW20H1 65 65 65 1000, 1200, 1600, 2000 28486.00 42728.00
NW20H2 85 85 85 1000, 1200, 1600, 2000 38556.00 57834.00
NW20H3 100 100 85 1000, 1200, 1600, 2000 41812.00 62714.00
NW20L1 200 200 130 1000, 1200, 1600, 2000 45064.00 N/A
NW20L1F 200 200 130 1000, 1200, 1600, 2000 46114.00 N/A
3200
NW32H1 65 65 65 1600, 2000, 2500, 3000, 3200 48124.00 72184.00
NW32H2 85 85 85 1600, 2000, 2500, 3000, 3200 61336.00 92002.00
NW32H3 100 100 85 1600, 2000, 2500, 3000, 3200 68696.00 103040.00
Y-Frame
3200 NW32L1 200 200 130 1600, 2000, 2500, 3000, 3200 76056.00 N/A
4000
NW40H2 85 85 85 2000, 2500, 3000, 3200, 4000 81252.00 121874.00
NW40H3 100 100 85 2000, 2500, 3000, 3200, 4000 91002.00 136498.00
NW40L1 200 200 130 2000, 2500, 3000, 3200, 4000 122853.00 N/A
5000
NW50H2 85 85 85 2500, 3000, 3200, 4000, 5000 95242.00 143132.00
NW50H3 100 100 85 2500, 3000, 3200, 4000, 5000 106876.00 160308.00
NW50L1 200 200 130 2500, 3000, 3200, 4000, 5000 144283.00 N/A
6000
NW60H2 85 85 85 3000, 3200, 4000, 5000, 6000 112068.00 168098.00
NW60H3 100 100 85 3000, 3200, 4000, 5000, 6000 129415.00 188272.00
NW60L1 200 200 130 3000, 3200, 4000, 5000, 6000 174711.00 N/A
Table 2: T-, W-, and Y-Frame Drawout Non-Automatic Switch
Frame Rating
(A) Model Number
Interrupting Rating (kA) Short-Time
Rating
(kA RMS)
$ Price
254 V 508 V 635 V 3-Pole 4-Pole
T-Frame
800 NT08NA 42 42 — 42 12588.00 18880.00
W-Frame
800 NW08HA 65 65 65 65 14942.00 22412.00
1600 NW16HA 65 65 65 65 24152.00 36230.00
2000 NW20HA 65 65 65 65 28486.00 42728.00
3200 NW32HA 65 65 65 65 48124.00 72184.00
Y-Frame
4000 NW40HA 85 85 85 85 81252.00 121874.00
5000 NW50HA 85 85 85 85 95424.00 143132.00
6000 NW60HA 85 85 85 85 112068.00 168098.00
DE2F Discount
Schedule
4© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
ANSI C37/UL 1066 Rated
When used in conjunction with an overcurrent relay, circuit breaker, or fuse.
Includes sensor plug.
Includes sensor plug.
Table 3: W- and Y-Frame Drawout Automatic Switch
Frame Rating
(A)
Model
Number
Interrupting Rating (kA) Short-Time
Rating
(kA RMS)
$ Price
254 V 508 V 635 V 3-Pole 4-Pole
W-Frame
800 NW08HF 100 100 85 85 19626.00 29440.00
NW08HC 200 200 130 30 21226.00 N/A
1600 NW16HF 100 100 85 85 33470.00 50204.00
NW16HC 200 200 130 30 38960.00 N/A
2000 NW20HF 100 100 85 85 41812.00 62714.00
NW20HC 200 200 130 30 45064.00 N/A
3200 NW32HF 100 100 85 85 68696.00 103040.00
Y-Frame
3200 NW32HC 200 200 130 100 76056.00 N/A
4000 NW40HF 100 100 85 85 91002.00 136498.00
NW40HC 200 200 130 100 100752.00 N/A
5000 NW50HF 100 100 85 85 106876.00 160308.00
NW50HC 200 200 130 100 118326.00 N/A
6000 NW60HF 100 100 85 85 112068.00 168098.00
NW60HC 200 200 130 100 138959.00 N/A
Table 4: T-, W-, and Y-Frame Fixed Circuit Breaker
FrameRating
(A) Model Number
Interrupting Rating (kA)
Sensor Plug (A)
$ Price
254 V 508 V 635 V 3-Pole 4-Pole
T-Frame
800 NT08N1 42 42 — 100,250,400,600,800 9960.00 14938.00
W-Frame
800
NW08N1 42 42 42 100, 250, 400, 600, 800 11856.00 17782.00
NW08H1 65 65 65 100, 250, 400, 600, 800 13598.00 20396.00
NW08H2 85 85 85 100, 250, 400, 600, 800 16406.00 24606.00
NW08H3 100 100 85 100, 250, 400, 600, 800 17860.00 26790.00
1600
NW16N1 42 42 42 800, 1000, 1200, 1600 14382.00 21574.00
NW16H1 65 65 65 800, 1000, 1200, 1600 17148.00 25722.00
NW16H2 85 85 85 800, 1000, 1200, 1600 19866.00 29800.00
NW16H3 100 100 85 800, 1000, 1200, 1600 23764.00 35646.00
2000
NW20H1 65 65 65 1000, 1200, 1600, 2000 19656.00 29482.00
NW20H2 85 85 85 1000, 1200, 1600, 2000 26604.00 39906.00
NW20H3 100 100 85 1000, 1200, 1600, 2000 28850.00 43272.00
3200
NW32H1 65 65 65 1600, 2000, 2500, 3000, 3200 42348.00 63520.00
NW32H2 85 85 85 1600, 2000, 2500, 3000, 3200 53976.00 80962.00
NW32H3 100 100 85 1600, 2000, 2500, 3000, 3200 60452.00 90676.00
4000
NW40BH1 65 65 65 2000, 2500, 3000, 3200, 4000 62566.00 N/A
NW40BH2 85 85 85 2000, 2500, 3000, 3200, 4000 64680.00 N/A
NW40BH3 100 100 85 2000, 2500, 3000, 3200, 4000 72442.00 N/A
Y-Frame
4000 NW40H2 85 85 85 2000, 2500, 3000, 3200, 4000 68250.00 114562.00
NW40H3 100 100 85 2000, 2500, 3000, 3200, 4000 76440.00 128308.00
5000 NW50H2 85 85 85 2500, 3000, 3200, 4000, 5000 93516.00 134544.00
NW50H3 100 100 85 2500, 3000, 3200, 4000, 5000 104738.00 150690.00
6000 NW60H2 85 85 85 3000, 3200, 4000, 5000, 6000 110117.00 164075.00
NW60H3 100 100 85 3000, 3200, 4000, 5000, 6000 127491.00 189962.00
DE2F Discount
Schedule
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
5
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
ANSI C37/UL 1066 Rated
When used in conjunction with an overcurrent relay, circuit breaker, or fuse.
Includes sensor plug.
When used in conjunction with an overcurrent relay, circuit breaker, or fuse.
Includes sensor plug.
Table 5: T-, W-, and Y-Frame Fixed Non-Automatic Switch
Frame
Rating
(A)
Model
Number
Interrupting Rating (kA) Short-Time
Rating
(kA RMS)
$ Price
254 V 508 V 635 V 3-Pole 4-Pole
T-Frame
800 NT08NA 42 42 — 42 10150.00 15162.00
W-Frame
800 NW08HA 65 65 65 65 13858.00 20702.00
1600 NW16HA 65 65 65 65 18116.00 27174.00
2000 NW20HA 65 65 65 65 19736.00 29602.00
3200 NW32HA 65 65 65 65 42430.00 63642.00
4000 NW40BHA 65 65 65 65 57034.00 N/A
Y-Frame
4000 NW40HA 85 85 85 85 71638.00 107454.00
5000 NW50HA 85 85 85 85 84134.00 126198.00
6000 NW60HA 85 85 85 85 98810.00 148214.00
Table 6: W- and Y-Frame Fixed Automatic Switch
Frame
Rating
(A)
Model
Number
Interrupting Rating (kA) Short-Time
Rating
(kA RMS)
$ Price
254 V 508 V 635 V 3-Pole 4-Pole
W-Frame
800 NW08HF 100 100 85 85 17860.00 26790.00
1600 NW16HF 100 100 85 85 23764.00 35646.00
2000 NW20HF 100 100 85 85 28850.00 43272.00
3200 NW32HF 100 100 85 85 60452.00 90676.00
4000 NW40BHF 100 100 85 85 72442.00 N/A
Y-Frame
4000 NW40HF 100 100 85 85 76440.00 128308.00
5000 NW50HF 100 100 85 85 104738.00 150690.00
6000 NW60HF 100 100 85 85 110491.00 164632.00
DE2F Discount
Schedule
6© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
ANSI C37/UL 1066 Rated
Cradle
Please contact your nearest Square D/Schneider Electric sales office for
assistance in building a complete circuit breaker or switch catalog
number.
Circuit Breaker/Cradle Connectors
For a complete connector set, order both the “Top” and “Bottom”
connector kits. Kits for use on both fixed and drawout circuit breakers
unless noted.
L1/L1F only.
For a 4-pole connector kit, add the suffix (4) to the kit number
(e.g. SFCF124).
cFor drawout circuit breaker only.
dFor fixed circuit breaker only.
eFor 4000 A W-frame fixed circuit breakers only.
Table 7: Circuit Breaker/Switch
Frame
Rating
(A)
Model Number
Interrupting Rating /
Withstand Rating
(kA)
$ Price
Circuit
Breaker Switch 254 V 508 V 635 V 3-Pole 4-Pole
T-Frame
800 NT08N1 NT08NA 42 42 — 3440.00 5166.00
NT08H1 NT08HA 42 42 — 3440.00 5166.00
W-Frame
800
NW08N1 — 42 42 42 3822.00 5740.00
NW08H1 NW08HA 65 65 65 3822.00 5740.00
NW08H2 — 85 85 85 3822.00 5740.00
NW08H3 NW08HF 100 100 85 3822.00 5740.00
NW08L1 NW08HC 200 200 130 4544.00 N/A
NW08L1F — 200 200 130 4544.00 N/A
1600
NW16N1 — 42 42 42 3822.00 5740.00
NW16H1 NW16HA 65 65 65 3822.00 5740.00
NW16H2 — 85 85 85 3822.00 5740.00
NW16H3 NW16HF 100 100 85 3822.00 5740.00
NW16L1 NW16HC 200 200 130 4544.00 N/A
NW16L1F — 200 200 130 4544.00 N/A
2000
NW20H1 NW20HA 65 65 65 4250.00 6378.00
NW20H2 — 85 85 85 4250.00 6378.00
NW20H3 NW20HF 100 100 85 4250.00 6378.00
NW20L1 NW20HC 200 200 130 4592.00 N/A
NW20L1F — 200 200 130 4592.00 N/A
3200
NW32H1 NW32HA 65 65 65 9754.00 14638.00
NW32H2 — 85 85 85 9754.00 14638.00
NW32H3 NW32HF 100 100 85 9754.00 14638.00
Y-Frame
3200 NW32L1 NW32HC 200 200 130 12096.00 N/A
4000
NW40H2 NW40HA 85 85 85 16206.00 24318.00
NW40H3 NW40HF 100 100 85 16206.00 24318.00
NW40L1 NW40HC 200 200 130 20094.00 N/A
5000
NW50H2 NW50HA 85 85 85 28856.00 43284.00
NW50H3 NW50HF 100 100 85 28856.00 43284.00
NW50L1 NW50HC 200 200 130 29580.00 N/A
6000
NW60H2 NW60HA 85 85 85 37068.00 55602.00
NW60H3 NW60HF 100 100 85 37068.00 55602.00
NW60L1 NW60HC 200 200 130 43480.00 N/A
Table 8: Connectors
Connector Frame
Rating Location
Kit
Catalog
Numberb
Kit $ Price /
Circuit Breaker
Price Adder
3-Pole 4-Pole
T-Frame
Front Connected
Flat (FCF) 800–1200 A Top SFCF12 716.00 954.00
Bottom SFCF12 716.00 954.00
Rear Connected T
Horizontal/Vertical
(RCTH/RCTV)
800–1200 A
Top S R CT V 12 408.00 544.00
Bottom SRCTV12 408.00 544.00
W- and Y- Frame
Front Connected
Flat (FCF)
800–2000 A
Top SFCF20T c926.00 1386.00
Bottom SFCF20Bc868.00 1304.00
Top SFCF20FTd1030.00 1534.00
Bottom SFCF20FBd956.00 1434.00
3200 Aa
4000 A
Top SFCF40 6252.00 9378.00
Bottom SFCF40 6252.00 9378.00
Front Connected T
(FCT)
800–2000 A
Top SFCT30c1466.00 2198.00
Bottom SFCT30c1466.00 2198.00
Top SFCT30d1466.00 2198.00
Bottom SFCR30Bd1488.00 2234.00
3200 Aa
4000 A
5000 A
Top SFCT50 7196.00 10796.00
Bottom SFCT50 7196.00 10796.00
Rear Connected
Offset Vertical
(RCOV)
2000 Aa
3200 A
Top SRCOV32T 3402.00 5104.00
Bottom SRCOV32B 2004.00 3006.00
4000 AeTop SRCOV40 4138.00 7078.00
Bottom SRCOV40 4138.00 5514.00
Rear Connected T
Horizontal/Vertical
(RCTH /RCTV)
800–2000 A Top SR CTV 20 796.00 1194.00
Bottom SRCTV20 796.00 1194.00
3200 Aa
4000 A
5000 A
Top SR C TV 5 0 5410.00 8114.00
Bottom SRCTV50 5410.00 8114.00
6000 A Top SRCTVA60 14988.00 22480.00
Bottom SRCTVA60 14988.00 22480.00
DE2F Discount
Schedule
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
7
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
ANSI C37/UL 1066 Rated
ArcBlok™ Circuit Breakers Basic Block
Please contact your nearest Square D/Schneider Electric sales office for
assistance in building a complete circuit breaker or switch catalog
number.
fIncludes sensor plug.
gWhen used in conjunction with an overcurrent relay, circuit breaker, or fuse.
hIncludes sensor plug.
iWhen used in conjunction with an overcurrent relay, circuit breaker, or fuse.
jIncludes sensor plug.
ArcBlok Cradle
Please contact your nearest Square D/Schneider Electric sales office for
assistance in building a complete circuit breaker or switch catalog
number.
Table 9: ArcBlok W- and Y-Frame Drawout Circuit Breaker
Frame
Rating
(A)
Model
Number
Interrupting Rating (kA)
Sensor Plug (A)
$ Pricea
254 V 508 V 635 V 3-Pole
W-Frame
800
NW08N1 42 42 42 100, 250, 400, 600, 800 14982.00
NW08H1 65 65 65 100, 250, 400, 600, 800 17183.00
NW08H2 85 85 85 100, 250, 400, 600, 800 20730.00
NW08H3 100 100 85 100, 250, 400, 600, 800 22570.00
1600
NW16N1 42 42 42 800, 1000, 1200, 1600 23294.00
NW16H1 65 65 65 800, 1000, 1200, 1600 27775.00
NW16H2 85 85 85 800, 1000, 1200, 1600 32177.00
NW16H3 100 100 85 800, 1000, 1200, 1600 38491.00
2000
NW20H1 65 65 65 1000, 1200, 1600, 2000 32759.00
NW20H2 85 85 85 1000, 1200, 1600, 2000 44339.00
NW20H3 100 100 85 1000, 1200, 1600, 2000 48084.00
3200
NW32H1 65 65 65 1600, 2000, 2500, 3000, 3200 55343.00
NW32H2 85 85 85 1600, 2000, 2500, 3000, 3200 70536.00
NW32H3 100 100 85 1600, 2000, 2500, 3000, 3200 79000.00
Y-Frame
4000 NW40H2 85 85 85 2000, 2500, 3000, 3200, 4000 93440.00
NW40H3 100 100 85 2000, 2500, 3000, 3200, 4000 104652.00
5000 NW50H2 85 85 85 2500, 3000, 3200, 4000, 5000 109528.00
NW50H3 100 100 85 2500, 3000, 3200, 4000, 5000 122907.00
Table 10: ArcBlok W- and Y-Frame Drawout Non-Automatic
Switch
Frame Rating
(A)
Model
Number
Interrupting Rating (kA)aShort-Time
Rating
(kA RMS)
$ Priceb
254 V 508 V 635 V 3-Pole
W-Frame
800 NW08HA 65 65 65 65 17183.00
1600 NW16HA 65 65 65 65 27775.00
2000 NW20HA 65 65 65 65 32759.00
3200 NW32HA 65 65 65 65 55343.00
Y-Frame
4000 NW40HA 85 85 85 85 93440.00
5000 NW50HA 85 85 85 85 109738.00
Table 11: Arc-Blok W- and Y-Frame Drawout Automatic Switch
Frame
Rating
(A)
Model
Number
Interrupting Rating (kA)aShort-time
Rating
(kA RMS)
$ Priceb
254 V508 V635 V 3-Pole
W-Frame
800 NW08HF 100 100 85 85 22570.00
1600 NW16HF 100 100 85 85 38491.00
2000 NW20HF 100 100 85 85 48084.00
3200 NW32HF 100 100 85 85 79000.00
Y-Frame
4000 NW40HF 100 100 85 85 104652.00
5000 NW50HF 100 100 85 85 122907.00
Table 12: Circuit Breaker/Switch
Frame
Rating
(A)
Model Number
Interrupting Rating / Withstand
Rating
(kA)
$ Price
Circuit
Breaker Switch 254 V 508 V 635 V 3-Pole
W-Frame
800
NW08N1 — 42 42 42 4395.00
NW08H1 NW08HA 65 65 65 4395.00
NW08H2 — 85 85 85 4395.00
NW08H3 NW08HF 100 100 85 4395.00
1600
NW16N1 — 42 42 42 4395.00
NW16H1 NW16HA 65 65 65 4395.00
NW16H2 — 85 85 85 4395.00
NW16H3 NW16HF 100 100 85 4395.00
2000
NW20H1 NW20HA 65 65 65 4888.00
NW20H2 — 85 85 85 4888.00
NW20H3 NW20HF 100 100 85 4888.00
3200
NW32H1 NW32HA 65 65 65 11217.00
NW32H2 — 85 85 85 11217.00
NW32H3 NW32HF 100 100 85 11217.00
Y-Frame
4000 NW40H2 NW40HA 85 85 85 18637.00
NW40H3 NW40HF 100 100 85 18637.00
5000 NW50H2 NW50HA 85 85 85 33184.00
NW50H3 NW50HF 100 100 85 33184.00
DE2F Discount
Schedule
8© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
UL 489 Rated
Basic Block
aIncludes sensor plug.
aThe withstand rating is the fault current (at rated voltage) that the switch will withstand
without damage when protected by a circuit breaker with an equal continuous current
rating.
bIncludes sensor plug.
Table 13: T-, W-, and Y-Frame Fixed Circuit Breaker
Frame
Rating
(A)
Model
Number
Interrupting Rating (kA) Sensor Plug
(A)
$ Pricea
240 V 480 V 600 V 3-Pole 4-Pole
T-Frame
800
NT08N 50 50 35
100, 250, 400,
600, 800
8784.00 13172.00
NT08H 65 50 50 9566.00 14350.00
NT08L1 100 65 — 10418.00 N/A
NT08L 200 100 — 11346.00 N/A
1200
NT12N 50 50 35
600, 800, 1000,
1200
10216.00 15326.00
NT12H 65 50 50 10786.00 16178.00
NT12L1 100 65 — 11384.00 N/A
NT12L 200 100 — 12018.00 N/A
1600
NT16N 50 50 35
800, 1000, 1200,
1600
11608.00 17412.00
NT16H 65 50 50 12178.00 18266.00
NT16L1 100 65 — 12776.00 N/A
NT16L 200 100 — 13648.00 N/A
W-Frame
800 NW08N 65 65 50 100, 250, 400,
600, 800
11388.00 17082.00
NW08H 100 100 85 12402.00 18608.00
1200 NW12N 65 65 50 600, 800, 1000,
1200
12840.00 19260.00
NW12H 100 100 85 13554.00 20330.00
1600 NW16N 65 65 50 800, 1000, 1200,
1600
14312.00 21466.00
NW16H 100 100 85 15104.00 22656.00
2000 NW20N 65 65 50 1000, 1200,
1600, 2000
17116.00 25674.00
NW20H 100 100 85 18064.00 27096.00
2500 NW25H 100 100 85 1200, 1600,
2000, 2500 33068.00 49606.00
3000 NW30H 100 100 85 1600, 2000,
2500, 3000 42172.00 63258.00
Y-Frame
4000 NW40H 100 100 85 2000, 2500,
3000, 4000 68568.00 114868.00
5000 NW50H 100 100 85 2500, 3000,
4000, 5000 90426.00 130838.00
6000 NW60H 100 100 85 3000, 4000,
5000, 6000 123832.00 179178.00
Table 14: T-, W-, and Y-Frame Fixed Automatic Switch
Frame
Rating
(A)
Model
Number
Withstand Rating (kA
RMS)aInstantaneous
Override
(kA RMS)
$ Priceb
240 V 480 V 600 V 3-Pole 4-Pole
T-Frame
800 NT08HF 65 50 50 40 11548.00 16330.00
NT08HB 200 100 NA 10 13328.00 N/A
1200 NT12HF 65 50 50 40 12828.00 18222.00
NT12HB 200 100 NA 10 14060.00 N/A
1600 NT16HF 65 50 50 40 14160.00 20246.00
NT16HB 200 100 NA 10 15628.00 N/A
W-Frame
800 NW08HF 100 100 85 40 14970.00 21176.00
1200 NW12HF 100 100 85 40 16122.00 22898.00
1600 NW16HF 100 100 85 40 17672.00 25226.00
2000 NW20HF 100 100 85 40 20632.00 29664.00
2500 NW25HF 100 100 85 65 35638.00 52174.00
3000 NW30HF 100 100 85 65 44740.00 65826.00
Y-Frame
4000 NW40HF 100 100 85 75 74060.00 110836.00
5000 NW50HF 100 100 85 75 87022.00 130232.00
6000 NW60HF 100 100 85 75 142294.00 213436.00
DE2F Discount
Schedule
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
9
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
UL 489 Rated
Includes sensor plug.
Tested to show the arc flash hazard risk category as referenced in NFPA70E.
The withstand rating is the fault current (at rated voltage) that the switch will withstand
without damage when protected by a circuit breaker with an equal continuous current
rating.
Includes sensor plug.
Table 15: T-, W-, and Y-Frame Drawout Circuit Breaker
Frame
Rating
(A)
Model
Number
Interrupting
Rating (kA) Sensor
Plug
(A)
$ Price
240 V 480 V 600 V 3-Pole 4-Pole
T-Frame
800
NT08N 50 50 35
100, 250,
400,
600, 800
10460.00 15692.00
NT08H 65 50 50 11304.00 16956.00
NT08L1 100 65 — 12216.00 N/A
NT08L 200 100 — 17368.00 N/A
NT08LF 200 100 — 18418.00 N/A
1200
NT12N 50 50 35
600, 800,
1000, 1200
15368.00 23050.00
NT12H 65 50 50 15992.00 23986.00
NT12L1 100 65 — 16640.00 N/A
NT12L 200 100 — 24100.00 N/A
NT12LF 200 100 — 25150.00 N/A
W-Frame
800
NW08N 656550
100, 250,
400, 600,
800
12560.00 18840.00
NW08H 100 100 85 13572.00 20358.00
NW08L 200 150 100 19296.00 N/A
NW08LF 200 150 100 20346.00 N/A
1200
NW12N 656550
600, 800,
1000, 1200
17768.00 26652.00
NW12H 100 100 85 18488.00 27734.00
NW12L 200 150 100 26778.00 N/A
NW12LF 200 150 100 27828.00 N/A
1600
NW16N 656550
800, 1000,
1200, 1600
20190.00 30284.00
NW16H 100 100 85 20992.00 31488.00
NW16L 200 150 100 35416.00 N/A
NW16LF 200 150 100 36466.00 N/A
2000
NW20N 656550
1000, 1200,
1600, 2000
24124.00 36188.00
NW20H 100 100 85 27214.00 40820.00
NW20L 200 150 100 40966.00 N/A
NW20LF 200 150 100 42016.00 N/A
2500 NW25H 100 100 85 1200, 1600,
2000, 2500
36740.00 55110.00
NW25L 200 150 100 47940.00 N/A
3000 NW30H 100 100 85 1600, 2000,
2500, 3000
48176.00 72264.00
NW30L 200 150 100 68892.00 N/A
Y-Frame
4000 NW40H 100 100 85 2000, 2500,
3000, 4000
81252.00 121878.00
NW40L 200 150 100 109690.00 N/A
5000 NW50H 100 100 85 2500, 3000,
4000, 5000
92550.00 138822.00
NW50L 200 150 100 124943.00 N/A
6000 NW60H 100 100 85 3000, 4000,
5000, 6000
126742.00 190108.00
NW60L 200 150 100 171102.00 N/A
Table 16: T-, W-, and Y-Frame Drawout Automatic Switch
Frame
Rating
(A)
Model
Number
Withstand
Rating
(kA RMS)
Instantaneous
Override
(kA RMS)
$ Price
240 V 480 V 600 V 3-Pole 4-Pole
T-Frame
800 NT08HF 65 50 50 40 13444.00 19096.00
NT08HB 200 100 NA 10 19508.00 N/A
1200 NT12HF 65 50 50 40 18214.00 29118.00
NT12HB 200 100 NA 10 26322.00 N/A
W-Frame
800 NW08HF 100 100 85 40 16140.00 22926.00
NW08HB 200 150 100 35 21864.00 N/A
1200 NW12HF 100 100 85 40 21056.00 30304.00
NW12HB 200 150 100 35 29346.00 N/A
1600 NW16HF 100 100 85 40 23560.00 34056.00
NW16HB 200 150 100 35 37984.00 N/A
2000 NW20HF 100 100 85 40 29782.00 43388.00
NW20HB 200 150 100 35 43534.00 N/A
2500 NW25HF 100 100 85 65 39308.00 57678.00
NW25HB 200 150 100 65 50508.00 N/A
3000 NW30HF 100 100 85 65 50744.00 74832.00
NW30HB 200 150 100 65 71460.00 N/A
Y-Frame
4000 NW40HF 100 100 85 75 84000.00 125996.00
NW40HB 200 150 100 75 118936.00 N/A
5000 NW50HF 100 100 85 75 98700.00 148046.00
NW50HB 200 150 100 75 138496.00 N/A
6000 NW60HF 100 100 85 75 161390.00 242078.00
NW60HB 200 150 100 75 215888.00 N/A
DE2F Discount
Schedule
10 © 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
UL 489 Rated
Cradle
.Circuit Breaker/Cradle Connectors
For a complete connector set, order both the “Top” and “Bottom”
connector kits.
For a 4-pole connector kit, add the suffix (4) to the kit number (e.g. SFCF20T4).
Not available for drawout circuit breakers.
Table 17: T-, W-, and Y-Frame Circuit Breaker/
Automatic Switch
Frame
Rating
(A)
Model Number Interrupting Rating /
Withstand Rating (kA) $ Price
Circuit
Breaker Switch 240 V 480 V 600 V 3-Pole 4-Pole
T-Frame
800
NT08N — 50 50 35 3440.00 5166.00
NT08H NT08HF 65 50 50
NT08L1 — 100 65 — 3718.00 N/A
NT08L NT08HB 200 100 —
NT08LF — 200 100 — 3718.00 N/A
1200
NT12N — 50 50 35 3440.00 5166.00
NT12H NT12HF 65 50 50
NT12L1 — 100 65 — 3718.00 N/A
NT12L NT12HB 200 100 —
NT12LF — 200 100 — 3718.00 N/A
W-Frame
800
NW08N — 65 65 50 3822.00 5734.00
NW08H NW08HF 100 100 85
NW08L NW08HB 200 150 100 4130.00 N/A
NW08LF — 200 150 100 4130.00 N/A
1200
NW12N — 65 65 50 3822.00 5734.00
NW12H NW12HF 100 100 85
NW12L NW12HB 200 150 100 4130.00 N/A
NW12LF — 200 150 100 4130.00 N/A
1600
NW16N — 65 65 50 3822.00 5734.00
NW16H NW16HF 100 100 85
NW16L NW16HB 200 150 100 4130.00 N/A
NW16LF — 200 150 100 4130.00 N/A
2000
NW20N — 65 65 50 4248.00 6372.00
NW20H NW20HF 100 100 85
NW20L NW20HB 200 150 100 4590.00 N/A
NW20LF — 200 150 100 4590.00 N/A
2500 NW25H NW25HF 100 100 85 7892.00 11838.00
NW25L NW25HB 200 150 100 8156.00 N/A
3000 NW30H NW30HF 100 100 85 7892.00 11836.00
NW30L NW30HB 200 150 100 8156.00 N/A
Y-Frame
4000 NW40H NW40HF 100 100 85 14348.00 21518.00
NW40L NW40HB 200 150 100 14826.00 N/A
5000 NW50H NW50HF 100 100 85 26730.00 40096.00
NW50L NW50HB 200 150 100 27626.00 N/A
6000 NW60H NW60HF 100 100 85 35990.00 53982.00
NW60L NW60HB 200 150 100 37194.00 N/A
Table 18: T-, W-, and Y-Frame Fixed and Drawout
Connector Frame
Rating Location
Kit
Catalog
Number
Kit $ Price /
Circuit Breaker
Price Adder
3-Pole 4-Pole
T-Frame Fixed and Drawout
Front Connected Flat
(FCF) 800–1200 A Top SFCF12 716.00 954.00
Bottom SFCF12 716.00 954.00
Rear Connected T
Horizontal/Vertical
(RCTH/RCTV)
800–1200 A
Top SRCTV12 408.00 544.00
Bottom SRCTV12 408.00 544.00
Rear Connected T
Vertical (RCTV)
+
Heat Sink
1600 A
Top SRCTV16U 1336.00 1780.00
Bottom SRCTV16U 1336.00 1780.00
W- and Y- Frame Fixed
Front Connected Flat
(FCF) 800–2000 A Top SFCF20FT 1030.00 1534.00
Bottom SFCF20FB 956.00 1434.00
Front Connected T
(FCT) 800–3000 A Top SFCT30 1466.00 2198.00
Bottom SFCT30B 1488.00 2234.00
Rear Connected T
Horizontal/Vertical
(RCTH /RCTV)
800–2000 A Top SRCTV20 796.00 1194.00
Bottom SRCTV20 796.00 1194.00
2500–3000 A Top SRCTV30 2124.00 3186.00
Bottom SRCTV30 2124.00 3186.00
4000–5000 A Top SRCTV50 5410.00 8114.00
Bottom SRCTV50 5410.00 8114.00
6000 A Top SRCTV60 14988.00 22480.00
Bottom SRCTV60 14988.00 22480.00
W- and Y- Frame Drawout
Front Connected Flat
(FCF)
800–2000 A Top SFCF20T 926.00 1386.00
Bottom SFCF20B 868.00 1304.00
4000 A Top SFCF40 6252.00 9378.00
Bottom SFCF40 6252.00 9378.00
Front Connected T
(FCT)
800–3000 A Top SFCT30 1466.00 2198.00
Bottom SFCT30 1466.00 2198.00
4000 A
5000 A
Top SFCT50 7196.00 10796.00
Bottom SFCT50 7196.00 10796.00
Rear Connected T
Horizontal/Vertical
(RCTH /RCTV)
800–2000 A Top SRCTV20 796.00 1194.00
Bottom SRCTV20 796.00 1194.00
2500–3000 A Top SRCTV30 2124.00 3186.00
Bottom SRCTV30 2124.00 3186.00
4000 A
5000 A
Top SRCTV50 5410.00 8114.00
Bottom SRCTV50 5410.00 8114.00
Rea Connected T
Vertical (RCTV) 6000 A Top SRCTV60 14988.00 22480.00
Bottom SRCTV60 14988.00 22480.00
DE2F Discount
Schedule
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
11
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
UL 489 Rated
ArcBlok™ Circuit Breakers Basic Block
Includes sensor plug.
The withstand rating is the fault current (at rated voltage) that the switch will withstand
without damage when protected by a circuit breaker with an equal continuous current
rating.
Includes sensor plug.
ArcBlok Cradle
.
Table 19: W- and Y-Frame ArcBlok Circuit Breaker
Frame
Rating
(A)
Model
Number
Interrupting Rating (kA) Sensor Plug
(A)
$ Price
240 V 480 V 600 V 3-Pole
W-Frame
800 NW08N 65 65 50 100, 250, 400, 600, 800 14444.00
NW08H 100 100 85 15608.00
1200 NW12N 65 65 50 600, 800, 1000, 1200 20433.00
NW12H 100 100 85 21261.00
1600 NW16N 65 65 50 800, 1000, 1200, 1600 23219.00
NW16H 100 100 85 24141.00
2000 NW20N 65 65 50 1000, 1200, 1600, 2000 27743.00
NW20H 100 100 85 31296.00
2500 NW25H 100 100 85 1200, 1600, 2000, 2500 42251.00
3000 NW30H 100 100 85 1600, 2000, 2500, 3000 55402.00
Y-Frame
4000 NW40H 100 100 85 2000, 2500, 3000, 4000 93440.00
5000 NW50H 100 100 85 2500, 3000, 4000, 5000 106433.00
Table 20: W- and Y-Frame ArcBlok Automatic Switch
Frame
Rating
(A)
Model
Number
Withstand Rating (kA RMS) Instantaneous
Override
(kA RMS)
$ Price
240 V 480 V 600 V 3-Pole
W-Frame
800 NW08HF 100 100 85 40 18561.00
1200 NW12HF 100 100 85 40 24214.00
1600 NW16HF 100 100 85 40 27094.00
2000 NW20HF 100 100 85 40 34249.00
2500 NW25HF 100 100 85 65 45204.00
3000 NW30HF 100 100 85 65 58356.00
Y-Frame
4000 NW40HF 100 100 85 75 96600.00
5000 NW50HF 100 100 85 75 113505.00
Table 21: Cradle for W- and Y-Frame ArcBlok Circuit Breaker /
Automatic Switch
Frame
Rating
(A)
Model Number Interrupting Rating/
Withstand Rating (kA) $ Price
Circuit Breaker Switch 240 V 480 V 600 V 3-Pole
W-Frame
800 NW08N — 65 65 50 4395.00
NW08H NW08HF 100 100 85 4395.00
1200 NW12N — 65 65 50 4395.00
NW12H NW12HF 100 100 85 4395.00
1600 NW16N — 65 65 50 4395.00
NW16H NW16HF 100 100 85 4395.00
2000 NW20N — 65 65 50 4885.00
NW20H NW20HF 100 100 85 4885.00
2500 NW25H NW25HF 100 100 85 9076.00
3000 NW30H NW30HF 100 100 85 9076.00
Y-Frame
4000 NW40H NW40HF 100 100 85 16500.00
5000 NW50H NW50HF 100 100 85 30740.00
DE2F Discount
Schedule
12 © 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
UL 489 Rated
DC Circuit Breakers
Tested to UL489 Supplement SC
NOTE: All UL rated DC Masterpact circuit breakers are Version C, 2-pole and Version C1, 3-pole circuit breakers. See catalog 0613CT0501.
NOTE: Fixed breaker is provided with connectors for Version C and C1 and there are no optional connectors. Connectors can be rotated from vertical to horizontal.
NOTE: Trip Units and Connectors are included in Basic Block Price.
NOTE: Most electrical and mechanical accessories are the same as the AC circuit breaker.
NOTE: All UL rated DC Masterpact circuit breakers are Version C, 2-pole and Version C1, 3-pole circuit breakers. See catalog 0613CT0501.
NOTE: Cradle is provided with connectors for Version C and C1 and there are no optional connectors. Connectors can be rotated from vertical to horizontal.
NOTE: Connectors are included in Cradle Price.
NOTE: Most electrical and mechanical accessories are the same as the AC cradle.
Table 22: Fixed and Drawout Circuit Breakers
Frame Rating (A) Model Number
Interrupting Rating (kA)
500 Vdc
(max 600 Vdc unloaded)
$ Price Fixed $ Price
Drawout
Version C Version C1 Version C Version C1
W-Frame, Type N
800 NW08NDC 35 42214.00 42746.00 39824.00 40888.00
1200 NW12NDC 35 42214.00 42746.00 39824.00 40888.00
1600 NW16NDC 35 42214.00 42746.00 39824.00 40888.00
2000 NW20NDC 35 42214.00 42746.00 39824.00 40888.00
2500 NW25NDC 35 56158.00 56690.00 56662.00 57726.00
3000 NW30NDC 35 70100.00 70632.00 73500.00 74564.00
4000 NW40NDC 35 84044.00 84576.00 90338.00 91402.00
W-Frame, Type H
800 NW08HDC 85 46435.00 47021.00 43806.00 44977.00
1200 NW12HDC 85 46435.00 47021.00 43806.00 44977.00
1600 NW16HDC 85 46435.00 47021.00 43806.00 44977.00
2000 NW20HDC 85 46435.00 47021.00 43806.00 44977.00
2500 NW25HDC 85 61774.00 62359.00 62328.00 63499.00
3000 NW30HDC 85 77110.00 77695.00 80850.00 82020.00
4000 NW40HDC 85 92448.00 93034.00 99372.00 100543.00
Table 23: Cradle for DC Drawout Circuit Breakers
Frame Rating (A) Model Number
Interrupting Rating (kA)
500 Vdc
(max 600 Vdc unloaded)
$ Price
Version C Version C1
W-Frame, Type N
800 NW08NDC 35 11778.00 12842.00
1200 NW12NDC 35 11778.00 12842.00
1600 NW16NDC 35 11778.00 12842.00
2000 NW20NDC 35 11778.00 12842.00
2500 NW25NDC 35 11778.00 12842.00
3000 NW30NDC 35 11778.00 12842.00
4000 NW40NDC 35 11778.00 12842.00
W-Frame, Type H
800 NW08HDC 85 11778.00 12842.00
1200 NW12HDC 85 11778.00 12842.00
1600 NW16HDC 85 11778.00 12842.00
2000 NW20HDC 85 11778.00 12842.00
2500 NW25HDC 85 11778.00 12842.00
3000 NW30HDC 85 11778.00 12842.00
4000 NW40HDC 85 11778.00 12842.00
DE2F Discount
Schedule
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
13
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
IEC 60947-2 Rated
Basic Block
Includes sensor plug.
Switches are IEC 60947-3 rated.
The withstand rating is the fault current (at rated voltage) that the switch will withstand
without damage when protected by a circuit breaker with an equal continuous current
rating.
Includes sensor plug.
.
Switches are IEC 60947-3 rated.
Includes sensor plug.
When used in conjunction with an overcurrent relay, circuit breaker, or fuse.
0.5s for T-frame.
Table 24: T-, W-, and Y-Frame Fixed Circuit Breaker
Frame
Rating
(A)
Model
Number
Interrupting
Rating (kA) Sensor
Plug
(A)
$ Price
240 V 440 V 690 V 3-Pole 4-Pole
T-Frame
800
NT08H1 42 42 42
250, 400,
630, 800
8516.00 11880.00
NT08H2 50 50 42 9468.00 13118.00
NT08L1 150 130 25 10420.00 14356.00
1000
NT10H1 42 42 42
400, 630,
800, 1000
9068.00 12600.00
NT10H2 50 50 42 9986.00 13792.00
NT10L1 150 130 25 10904.00 14984.00
1250 NT12H1 42 42 42 630, 800,
1000, 1250
9624.00 13322.00
NT12H2 50 50 42 10186.00 14052.00
1600 NT16H1 42 42 42 800, 1000,
1250, 1600
10748.00 14782.00
NT16H2 50 50 42 11310.00 15512.00
W-Frame
800
NW08N1 42 42 42
400, 630,
800
10136.00 14142.00
NW08H1 65 65 65 11388.00 15768.00
NW08H2 100 100 85 12404.00 17090.00
1000
NW10N1 42 42 42
400, 630,
800, 1000
10796.00 15000.00
NW10H1 65 65 65 12114.00 16712.00
NW10H2 100 100 85 12980.00 17838.00
1250
NW12N1 42 42 42
630, 800,
1000, 1250
11458.00 15860.00
NW12H1 65 65 65 12840.00 17654.00
NW12H2 100 100 85 13554.00 18586.00
1600
NW16N1 42 42 42
800, 1000,
1250, 1600
12796.00 17598.00
NW16H1 65 65 65 14310.00 19568.00
NW16H2 100 100 85 15106.00 20598.00
2000 NW20H1 65 65 65 1000, 1250,
1600, 2000
17116.00 23214.00
NW20H2 100 100 85 18064.00 24448.00
2500 NW25H1 65 65 65 1250, 1600,
2000, 2500
29488.00 39298.00
NW25H2 100 100 85 33070.00 43956.00
3200 NW32H1 65 65 65 1600, 2000,
2500, 3200
36670.00 48634.00
NW32H2 100 100 85 42172.00 55788.00
4000 NW40H1 65 65 65 2000, 2500,
3200, 4000
60184.00 79202.00
NW40H2 100 100 85 68988.00 90648.00
Y-Frame
4000 NW40bH1 100 100 100 2000, 2500,
3200, 4000
72565.00 80547.00
NW40bH2 150 150 100 87078.00 96657.00
5000 NW50H1 100 100 100 2500, 3200,
4000, 5000
90426.00 100328.00
NW50H2 150 150 100 108628.00 121068.00
6300 NW63H1 100 100 100 3200, 4000,
5000, 6300
121718.00 135536.00
NW63H2 150 150 100 156020.00 173460.00
Table 25: W-Frame Fixed Automatic Switch
Frame
Rating
(A)
Model
Number
Withstand
Rating (kA RMS) Instantaneous
Override
(kA RMS)
$ Price
240 V 440 V 690 V 3-Pole 4-Pole
W-Frame
800 NW08HF 85 85 85 85 14974.00 19658.00
1000 NW10HF 85 85 85 85 15548.00 20406.00
1250 NW12HF 85 85 85 85 16122.00 21154.00
1600 NW16HF 85 85 85 85 17674.00 23168.00
2000 NW20HF 85 85 85 85 20632.00 27016.00
2500 NW25HF 85 85 85 85 35640.00 46524.00
3200 NW32HF 85 85 85 85 44740.00 58356.00
4000 NW40HF 85 85 85 85 71556.00 93216.00
Table 26: T-, W-, and Y-Frame Fixed Non-Automatic Switch
Frame
Rating
(A)
Model
Number
Withstand
Rating (kA RMS)
Short-Time
(1s)
Rating
(kA RMS)
$ Price
240 V 440 V 690 V 3-Pole 4-Pole
T-Frame
800 NT08HA 42 42 42 42 9370.00 12990.00
1000 NT10HA 42 42 42 42 9994.00 13804.00
1250 NT12HA 42 42 42 42 10622.00 14616.00
1600 NT16HA 42 42 42 42 11042.00 15164.00
W-Frame
800 NW08NA 42 42 42 42 11156.00 15464.00
NW08HA 50 50 50 50 12492.00 18284.00
1000 NW10NA 42 42 42 42 11898.00 16432.00
NW10HA 50 50 50 50 13326.00 19368.00
1250 NW12NA 42 42 42 42 12644.00 17400.00
NW12HA 50 50 50 50 14162.00 20452.00
1600 NW16NA 42 42 42 42 13144.00 18052.00
NW16HA 50 50 50 50 14722.00 21182.00
2000 NW20HA 50 50 50 50 18516.00 25032.00
2500 NW25HA 50 50 50 50 25758.00 34450.00
3200 NW32HA 50 50 50 50 32368.00 43042.00
4000 NW40HA 50 50 50 50 51790.00 68290.00
Y-Frame
4000 NW40bHA 85 85 85 85 65956.00 86707.00
5000 NW50HA 85 85 85 85 80122.00 105124.00
6300 NW63HA 85 85 85 85 117038.00 153112.00
DE2F Discount
Schedule
14 © 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
IEC 60947-2 Rated
Includes sensor plug.
1000 V for T-frame.
Switches are IEC 60947-3 rated.
The withstand rating is the fault current (at rated voltage) that the switch will withstand
without damage when protected by a circuit breaker with an equal continuous current
rating.
Includes sensor plug.
Switches are IEC 60947-3 rated.
Includes sensor plug.
When used in conjunction with an overcurrent relay, circuit breaker, or fuse.
1000 V for T-frame.
Table 27: T-, W-, and Y-Frame Drawout Circuit Breaker
Frame
Rating
(A)
Model
Number
Interrupting
Rating (kA) Sensor
Plug
(A)
$ Price
240 V 440 V 690 V 1150 V 3-Pole 4-Pole
T-Frame
800
NT08H1 42 42 42 —
250, 400,
630, 800
9928.00 13772.00
NT08H2 50 50 42 — 10626.00 15608.00
NT08L1 150 130 25 — 15790.00 21390.00
1000
NT10H1 42 42 42 —
400, 630,
800, 1000
11322.00 17444.00
NT10H2 50 50 42 — 12756.00 19596.00
NT10L1 150 130 25 — 17718.00 24026.00
1250 NT12H1 42 42 42 — 630, 800,
1000, 1250
14192.00 21750.00
NT12H2 50 50 42 — 15184.00 22026.00
1600 NT16H1 42 42 42 — 800, 1000,
1250, 1600
16176.00 22302.00
NT16H2 50 50 42 — 17168.00 22578.00
W-Frame
800
NW08N1 42 42 42 —
400, 630,
800
11032.00 15302.00
NW08H1 65 65 65 — 12732.00 17060.00
NW08H2 100 100 85 — 13742.00 18438.00
NW08L1 150 150 100 — 17544.00 23768.00
NW08H10 — — — 50 14916.00 19972.00
1000
NW10N1 42 42 42 —
400, 630,
800, 1000
12580.00 17418.00
NW10H1 65 65 65 — 14434.00 19384.00
NW10H2 100 100 85 — 15534.00 20884.00
NW10L1 150 150 100 — 19686.00 26696.00
NW10H10 — — — 50 16618.00 22294.00
1250
NW12N1 42 42 42 —
630, 800,
1000, 1250
15768.00 21770.00
NW12H1 65 65 65 — 17938.00 24166.00
NW12H2 100 100 85 — 18716.00 25144.00
NW12L1 150 150 100 — 24344.00 33052.00
NW12H10 — — — 50 20122.00 27078.00
1600
NW16N1 42 42 42 —
800, 1000,
1250, 1600
17974.00 24780.00
NW16H1 65 65 65 — 20362.00 27474.00
NW16H2 100 100 85 — 21164.00 28568.00
NW16L1 150 150 100 — 32198.00 43772.00
NW16H10 — — — 50 22546.00 30384.00
2000
NW20H1 65 65 65 —
1000, 1250,
1600, 2000
24684.00 32594.00
NW20H2 100 100 85 — 27770.00 36806.00
NW20H3 150 150 100 — 29802.00 39498.00
NW20L1 150 150 100 — 37242.00 49884.00
NW20H10 — — — 50 26868.00 35504.00
2500
NW25H1 65 65 65 —
1250, 1600,
2000, 2500
33318.00 44276.00
NW25H2 100 100 85 — 36746.00 48956.00
NW25H3 150 150 100 — 39902.00 52836.00
NW25H10 — — — 50 35502.00 47188.00
3200
NW32H1 65 65 65 —
1600, 2000,
2500, 3200
44752.00 59882.00
NW32H2 100 100 85 — 48180.00 64564.00
NW32H3 150 150 100 — 52878.00 69710.00
NW32H10 — — — 50 46936.00 62792.00
4000
NW40H1 65 65 65 —
2000, 2500,
3200, 4000
74102.00 97300.00
NW40H2 100 100 85 — 79592.00 104792.00
NW40H3 150 150 100 — 86214.00 113046.00
NW40H10 — — — 50 76286.00 100210.00
Y-Frame
4000 NW40bH1 100 100 100 —2000, 2500,
3200, 4000
82832.00 108509.00
NW40bH2 150 150 100 93626.00 122650.00
5000 NW50H1 100 100 100 —2500, 3200,
4000, 5000
91562.00 119996.00
NW50H2 150 150 100 109760.00 144840.00
6300 NW63H1 100 100 100 —3200, 4000,
5000, 6300
124008.00 162172.00
NW63H2 150 150 100 157290.00 207604.00
Table 28: W-Frame Drawout Automatic Switch
Frame
Rating
(A)
Model
Number
Withstand
Rating (kA RMS) Instantaneous
Override
(kA RMS)
$ Price
240 V 440 V 690 V 1150 V 3-Pole 4-Pole
W-Frame
800 NW08HF 85 85 85 — 85 16010.00 21006.00
1000 NW10HF 85 85 85 — 85 17892.00 23452.00
1250 NW12HF 85 85 85 — 85 21170.00 27712.00
1600 NW16HF 85 85 85 — 85 23804.00 31136.00
2000 NW20HF 85 85 85 — 85 30142.00 39376.00
2500 NW25HF 85 85 85 — 85 39486.00 51524.00
3200 NW32HF 85 85 85 — 85 51492.00 67132.00
4000 NW40HF 85 85 85 — 85 82436.00 107360.00
Table 29: T-, W-, and Y-Frame Drawout Non-Automatic Switch
Frame
Rating
(A)
Model
Number
Withstand
Rating (kA RMS) Short-Time
(1s)
Rating
(kA RMS)r
$ Price
240 V 440 V 690 V 1150 V 3-Pole 4-Pole
T-Frame
800 NT08HA 42 42 42 — 42 10054.00 13940.00
1000 NT10HA 42 42 42 — 42 12466.00 17069.00
1250 NT12HA 42 42 42 — 42 14872.00 20200.00
1600 NT16HA 42 42 42 — 42 15352.00 20822.00
W-Frame
800
NW08NA 42 42 42 — 42 11172.00 15488.00
NW08HA 50 50 50 — 50 12512.00 18310.00
NW08HA10 — — — 50 50 14696.00 22184.00
1000
NW10NA 42 42 42 — 42 13850.00 18966.00
NW10HA 50 50 50 — 50 15510.00 22206.00
NW10HA10 — — — 50 50 17694.00 26080.00
1250
NW12NA 42 42 42 — 42 16524.00 22444.00
NW12HA 50 50 50 — 50 18508.00 26104.00
NW12HA10 — — — 50 50 20692.00 29978.00
1600
NW16NA 42 42 42 — 42 17056.00 23136.00
NW16HA 50 50 50 — 50 19104.00 26876.00
NW16HA10 — — — 50 50 21288.00 30750.00
2000 NW20HA 50 50 50 — 50 23186.00 31106.00
NW20HA10 — — — 50 50 20700.00 28906.00
2500 NW25HA 50 50 50 — 50 27402.00 36586.00
NW25HA10 — — — 50 50 29586.00 40460.00
3200 NW32HA 50 50 50 — 50 42530.00 56250.00
NW32HA10 — — — 50 50 44714.00 60126.00
4000 NW40HA 50 50 50 — 50 68046.00 89426.00
NW40HA10 — — — 50 50 70230.00 93300.00
Y-Frame
4000 NW40bHA 85 85 85 — 85 75484.00 99613.00
5000 NW50HA 85 85 85 — 85 80738.00 105926.00
6300 NW63HA 85 85 85 — 85 117938.00 154282.00
DE2F Discount
Schedule
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
15
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
IEC 60947-2 Rated
Cradle
Circuit Breaker/Cradle Connectors
For a complete connector set, order both the “Top” and “Bottom”
connector kits.
For a 4-pole connector kit, add (4) to the end of the catalog number
(e.g. SFCF32T4).
NW40b circuit breakers use 5000 A connectors.
Table 30: T-, W-, and Y-Frame Circuit Breaker/Switch
Frame
Rating
(A)
Model Number $ Price
Circuit
Breaker Switch 3-Pole 4-Pole
T-Frame
800
NT08H1
NT08H10
NT08HA
NT08HA10 3284.00 4274.00
NT08L1 — 3378.00 4396.00
1000
NT10H1
NT10H10
NT10HA
NT10HA10 3284.00 4274.00
NT10L1 — 3378.00 4396.00
1250 NT12H1
NT12H10
NT12HA,
NT12HA10 3284.00 4274.00
1600 NT16H1
NT16H10
NT16HA,
NT16HA10 3284.00 4274.00
W-Frame
800
NW08N1 NW08NA
3650.00 4748.00
NW08H1 NW08HA
NW08H2 NW08HF
NW08H10 NW08HA10
NW08L1 — 3754.00 4882.00
1000
NW10N1 NW08NA
3650.00 4748.00
NW10H1 NW08HA
NW10H2 NW08HF
NW10H10 NW08HA10
NW10L1 — 3754.00 4882.00
1250
NW12N1 NW08NA
3650.00 4748.00
NW12H1 NW08HA
NW12H2 NW08HF
NW12H10 NW08HA10
NW12L1 — 3754.00 4882.00
1600
NW16N1 NW08NA
3650.00 4748.00
NW16H1 NW08HA
NW16H2 NW08HF
NW16H10 NW08HA10
NW16L1 — 3754.00 4882.00
2000
NW20H1 NW20HA
3690.00 4796.00NW20H2 NW20HF
NW20H10 NW20HA10
NW20H3 — 3742.00 4864.00
NW20L1 — 3796.00 4932.00
2500
NW25H1 NW25HA
7886.00 10126.00NW25H2 NW25HF
NW25H10 NW25HA10
NW25H3 — 8112.00 10542.00
3200
NW32H1 NW32HA
7886.00 10252.00NW32H2 NW32HF
NW32H10 NW32HA10
NW32H3 — 8112.00 10542.00
4000
NW40H1 NW40HA
11626.00 15112.00NW40H2 NW40HF
NW40H10 NW40HA10
NW40H3 — 11960.00 15540.00
Y-Frame
4000 NW40bH1 NW40bHA 19839.00 25786.00
NW40bH2 —
5000 NW50H1 NW50HA 27718.00 36032.00
NW50H2 —
6300 NW63H1 NW63HA 38724.00 50342.00
NW63H2 —
Table 31: T-Frame
Connector Frame
Rating Location
Kit
Catalog
Number t
Kit $ Price/
Circuit Breaker
Price Adder
3-Pole 4-Pole
Fixed Circuit Breaker Connectors
Front Connected
Flat (FCF)
800–1600A
Fixed Only
Top SFCF16F 1316.00 1756.00
Bottom SFCF16F 1316.00 1756.00
Rear Connected T
Horizontal/Vertical
(RCTH/RCTV)
800–1600A
Fixed Only
Top SRCTV16 744.00 992.00
Bottom SRCTV16 744.00 992.00
Drawout Circuit Breaker Cradle Connectors
Front Connected
Flat (FCF)
800–1600A
Drawout Only
Top SFCF16T 1202.00 1602.00
Bottom SFCF16B 886.00 1182.00
Rear Connected T
Horizontal/Vertical
(RCTH/RCTV)
800–1600A
Drawout Only
Top SRCTV16 744.00 992.00
Bottom SRCTV16 744.00 992.00
Drawout and Fixed Circuit Breaker Connectors
Rea Spreader
Adapter 800–1600A Top SR SA 16 1336.00 1776.00
Bottom SRSA16 1336.00 1776.00
Rear T Adapter 800–1600A Top SR TA 1 6 2338.00 3110.00
Bottom SRTA16 2338.00 3110.00
Rear Flat Adapter 800–1600A Top SR FA1 6 1336.00 1776.00
Bottom SRFA16 1336.00 1776.00
Table 32: W/Y-Frame
Connector Frame
Rating Location
Kit
Catalog
Number
Kit $ Price/
Circuit Breaker
Price Adder
3-Pole 4-Pole
Fixed Circuit Breaker Connectors
Front Connected
Flat (FCF)
800–3200 A
Fixed Only
Top SFCF32T 2386.00 3174.00
Bottom SFCF32B 2236.00 2974.00
Drawout Circuit Breaker Cradle Connectors
Front Connected
Flat (FCF)
800–3200 A
Drawout Only
Top SFCF32 2236.00 2976.00
Bottom SFCF32 2236.00 2976.00
Drawout and Fixed Circuit Breaker Connectors
Rear Connected T
Horizontal/Vertical
(RCTH/RCTV)
800–3200 A Top SRCTV32 762.00 1014.00
Bottom SRCTV32 762.00 1014.00
5000 A Top SRCTV50E 2864.00 3810.00
Bottom SRCTV50E 2864.00 3810.00
Rear Connected T
Horizontal (RCTH) 4000 A To p SRC TH4 0 1414.00 1880.00
Bottom SRCTH40 1414.00 1880.00
Rear Connected T
Vertical (RCTV)
4000 A Top SRCTV40 2178.00 2896.00
Bottom SRCTV40 2178.00 2896.00
6300 A Top SRCTV63 4462.00 5936.00
Bottom SRCTV63 4462.00 5936.00
DE2F Discount
Schedule
16 © 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
IEC 60947-2 Rated
DC Circuit Breakers and Non-Automatic Switches
Tested to IEC 60947 Standards
IEC 60947-2 Rated (DC Circuit Breakers)
NOTE: IEC rated DC Masterpact (H rated) can have connectors version C, D or E,
3-pole circuit breakers. See catalog 0613CT0501.
NOTE: Trip units and connectors are included in the circuit breaker price
NOTE: Most electrical and mechanical accessories are the same as the AC circuit
breaker.
IEC 60947-3 Rated (DC Non-Automatic Switch)
NOTE: IEC rated DC Masterpact non-automatic switches (HA rated) can have
connectors version C, D or E, 3-pole non-automatic switch. See catalog
0613CT0501.
NOTE: Connectors are included in breaker or switch price.
NOTE: Most electrical and mechanical accessories are the same as the AC circuit
breakers.
IEC 60947-2 Rated (DC Circuit Breakers)
NOTE: IEC rated DC Masterpact (H rated) can have connectors version C, D or E,
3-pole circuit breakers. See catalog 0613CT0501.
NOTE: Connectors are included in cradle price
NOTE: Most electrical and mechanical accessories are the same as the AC cradle.
IEC 60947-3 Rated (DC Non-Automatic Switch)
NOTE: IEC rated DC Masterpact (HA rated) can have connectors version C, D or
E, 3-pole non-automatic switch. See catalog 0613CT0501.
NOTE: Connectors are included in cradle price.
NOTE: Most electrical and mechanical accessories are the same as the AC cradle.
Table 33: Fixed and Drawout Circuit Breakers
Frame
Rating (A)
Model
Number
Connection
Version
Icu KA for
U = 500 Vdc - L/R
≤ 15 ms
$ Price
Fixed
$ Price
Drawout
W- Frame
Type N
1000 NW10NDC C 35 38376.00 36204.00
2000 NW20NDC C 35 38376.00 36204.00
4000 NW40NDC C 35 76404.00 82126.00
Type H
1000 NW10HDC C 85 41260.00 38920.00
1000 NW10HDC D 85 44132.00 41634.00
1000 NW10HDC E 85 49890.00 47064.00
2000 NW20HDC C 85 41260.00 38920.00
2000 NW20HDC D 85 44132.00 41634.00
2000 NW20HDC E 85 49890.00 47064.00
4000 NW40HDC C 85 82134.00 88300.00
4000 NW40HDC D 85 87864.00 94450.00
4000 NW40HDC E 85 99324.00 106764.00
Table 34: Fixed and Drawout Non-Automatic Switch
Frame Rating
(A) Model Number Connection
Version
Icw KA for
U = 500 Vdc
$ Price
Fixed
$ Price
Drawout
W- Frame
Type HA
1000 NW10HADC C 85 33008.00 31136.00
1000 NW10HADC D 85 35306.00 33308.00
1000 NW10HADC E 85 39912.00 37652.00
2000 NW20HADC C 85 33008.00 31136.00
2000 NW20HADC D 85 35306.00 33308.00
2000 NW20HADC E 85 39912.00 37652.00
4000 NW40HADC C 85 65708.00 70640.00
4000 NW40HADC D 85 70292.00 75560.00
4000 NW40HADC E 85 79460.00 85412.00
Table 35: Cradle (DC Products)
Frame Rating (A) Model Number Connection
Version
Icu KA for
U = 500 Vdc - L/R
≤ 15 ms
$ Price
W-Frame
Type N
1000 NW10NDC C 35 11508.00
2000 NW20NDC C 35 11508.00
4000 NW40NDC C 35 11508.00
Type H
1000 NW10HDC C 85 11508.00
1000 NW10HDC D 85 12314.00
1000 NW10HDC E 85 13920.00
2000 NW20HDC C 85 11508.00
2000 NW20HDC D 85 12314.00
2000 NW20HDC E 85 13920.00
4000 NW40HDC C 85 11508.00
4000 NW40HDC D 85 12314.00
4000 NW40HDC E 85 13920.00
Table 36: Cradle (DC Products)
Frame Rating (A) Model Number Connection
Version
Icw KA for
U = 500 Vdc $ Price
W- Frame
Type HA
1000 NW10HADC C 85 11508.00
1000 NW10HADC D 85 12314.00
1000 NW10HADC E 85 13920.00
2000 NW20HADC C 85 11508.00
2000 NW20HADC D 85 12314.00
2000 NW20HADC E 85 13920.00
4000 NW40HADC C 85 11508.00
4000 NW40HADC D 85 12314.00
4000 NW40HADC E 85 13920.00
DE2F Discount
Schedule
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
17
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
Trip Unit and Options
The standard rating plug supplied with a trip unit will be the “A” rating plug. To specify an
alternative adjustable rating plug, please add the letter designation to the end of the
catalog number. Please refer to following table for a complete listing of adjustable settings
available with each plug. (Example: S143B would specify a “B” rating plug instead of the
standard "A" plug.) Use suffix “N” if no rating plug is required, deduct $200. from the
complete trip unit kit price.
Requires circuit breaker Communications Module.
When replacing a basic trip unit with type A (Ammeter), P (Power metering) or H
(Harmonic analysis) trip unit, order the 12-pin connector kit S33101, price $228.
Standard offer.
For replacement only; rating plug included in price of trip unit.
A Zone-Selective Interlocking (ZSI) system with/without MDGF/SGR
may require a Restraint Interface Module (RIM), catalog number S48890
(120 Vac/24 Vdc) or S48895 (240 Vac/24 Vdc). Price: $2480. See the
Masterpact NT/NW Universal Power Circuit Breaker catalog
(0613CT0001) for details.
Available as factory-installed circuit breaker option only.
See the Class 0613 catalog, Masterpact Low-Voltage Power Circuit Breakers for details.
NOTE: Standard for “P” trip unit; optional for “A” trip unit.
Table 37: Trip Unit
Model Protection Additional
Features
Field-Installable
Catalog
Number
$ Kit Price/
Circuit Breaker
Price Adder
2.0 (IEC only) LS0
None
S132R 2920.00
3.0 (UL/ANSI only) LI S131A 2920.00
5.0 LSI S133A 4176.00
2.0A (IEC only) LS0
Ammeter
S142R 4554.00
3.0A (UL/ANSI only) LI S141A 4554.00
5.0A LSI S143A 5812.00
6.0A LSIG S144A 7418.00
5.0P LSI Metering,
Advanced Protection
S163A 8720.00
6.0P LSIG S164A 10324.00
5.0H LSI Metering,
Advanced Protection &
Harmonic Analysis
S173A 14770.00
6.0H LSIG S174A 16374.00
Table 38: Trip Unit Adjustable Rating Plug
Standard Options Settings
(Tolerance:1.05–1.2)
Field-Installable Kit
Trip Unit
Character
5
Catalog
Number
$ Price
UL/ANSI
Plug “A” .4 - .45 - .50 - .60 - .63 - .7 - .8 - .9 - 1 A S48818
200.00
Plug “B” .4 - .44 - .50 - .56 - .63 - .75 - .88 - .95 - 1 B S48819
Plug “C” .42 - .50 - .53 - .58 - .67 - .75 - .83 - .95 - 1 C S48820
Plug “D” .4 - .48 - .64 - .7 - .8 - .9 - .93 - .95 - 1 D S48836
Plug “E” .60 - .70 - .75 - .80 - .85 - .90 - .93 - .95 - 1 E S48837
Plug “F” .84 - .86 - .88 - .9 - .92 - .94 - .96 - .98 - 1 F S48838
Plug “G” .66 - .68 - .7 - .72 - .74 - .76 - .78 - .8 - .82 G S48839
Plug “H” .48 - .5 - .52 - .54 - .56 - .58 - .6 - .62 - .64 H S48840
IEC
Standard .4 - .5 - .6 - .7 - .8 - .9 - .95 - .98 - 1 R S33542
200.00
Lower Range .4 - .45 - .5 - .55 - .6 - .65 - .7 - .75 - .8 S S33543
Upper Range .8 - .82 - .85 - .88 - .9 - .92 - .95 - .98 - 1 T S33544
OFF No long time protection P S33545
Table 39: Trip Unit Options
Description Circuit Breaker
$ Price Adder
CT Characterization 4410.00
Automatic Reset 658.00
Table 40: Circuit Breaker Communications Module
Communications Type
Catalog Number Kit $ Price /
Circuit Breaker
Price AdderFixed Drawout
NW MODBUS®S47405 S48384 2470.00
NT MODBUS S48188 S47485 2470.00
DE2F Discount
Schedule
18 © 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
Trip Unit and Options
Neutral Sensor
Oversized neutral protection = 1.6 Ir where Ir = long time pick-up.
Table 42: W/Y-Frame Circuit Breakers
External neutral sensor for 3-phase, 4-wire residual ground fault system (or for neutral current monitoring) and external sensor for Modified
Differential Ground Fault (MDGF) or Source Ground Return (SGR) system.
Kit includes qty. (2) neutral sensors.
Four MDGF sensors (phase + 1 neutral) are required for W-frame; eight MDGF sensors are required for Y-frame.
For SGR system only one sensor (neutral) is required for W-frame; two sensors for Y-Frame.
A MDGF/SGR ground-fault interface module (Cat. no. S48891) is also required for each circuit breaker. Price: $2688.
Oversized neutral protection = 1.6 Ir where Ir = long time pick-up.
These neutral sensors include their wiring harness. To order this harness as a spare part (cat. no. NCTWIRING) the Price is $204.
Table 41: T-Frame Circuit Breakers
External neutral sensor for 3-phase, 4-wire residual ground fault system (or for neutral current monitoring).
NT Circuit Breaker
Sensor Plug
External Neutral Sensor
for general use
External Neutral Sensor
for use in
Square D™ Panelboards
External Neutral Sensor
for use in
Square D Switchboards
$ Price
External neutral sensor for circuit breakers with standard neutral protection
100–250 A S33575 S33924 S33926 1914.00
400–1600 A S33576 S33925 S33927
External neutral sensor for circuit breakers with oversized neutral protection
100 A S33575 S33924 S33926
1914.00250 A N/A N/A N/A
400–1000 A S33576 S33925 S33927
1200/1250 A S48896 N/A NA 2044.00
1600 A S48182 N/A NA 2208.00
Frame
Sensor
Plug
(A)
External Neutral Sensor PZ4 External Neutral Sensor
(For use in PZ4 Switchgear)
MDGF/
SGR
Sensor
$ Price
For
Residual
Ground Fault
$ Price
For 3-Pole
Circuit Breaker
with
Oversize Neutral
Protection
$ Price
For
Residual
Ground Fault
$ Price
For 3-Pole
Circuit Breaker
with
Oversize Neutral
Protection
$ Price
W
100 S48916
2014.00
S48916 2014.00 S48902
3168.00
S48902 3168.00
250 N/A — N/A —
400
S34036
S34036 2014.00
S48903
S48903 3168.00
S33579 570.00
600/630
800
1000
1200/1250 S48896 2044.00
1600
S48182 2208.00
N/A —
2000 S48896 2044.00
2500
S48182 2208.00 S48182
3000
N/A —3200
4000 N/A N/A
Y
2000
S48897 4426.00
S48897 4426.00 S48898 4584.00
S48898 4584.00
S33579 570.00
2500
3000
N/A —
3200
4000
5000
N/A — S48897 —6000
6300 N/A
DE2F Discount
Schedule
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
19
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
Accessories
Each electrical accessory kit includes the necessary push-in secondary disconnects for a drawout circuit breaker.
Included in basic block price.
Cannot be installed into a circuit breaker with original sensor plug higher than 250 A. Likewise a circuit breaker with original sensor plug of 100 A or 250 A cannot be replaced with a sensor
plug higher than 250 A.
IEC and ANSI W-frame.
Standard on circuit breaker, information for replacement purposes only.
4a/4b standard on circuit breaker, information for replacement purpose only.
Incompatible with remote reset switch (RES).
Type P or H trip unit required.
Incompatible with undervoltage coil.
Table 43: Sensor Plug
Lowest possible sensor plug is 50% of frame rating
except for the 100 A and 250 A plug
Rating
(A)
Catalog
Number $ Price Rating
(A)
Catalog
Number $ Price Rating
(A)
Catalog
Number $ Price
100 S47051
1040.00
1000 S33093
1040.00
3000 S48825
1040.00
250 S47052 1200 S48824 3200 S33984
— — — — 4000 S47820
400 S47053 1250 S33094 — —
600 S48823 1600 S33095 — —
630 S33091 2000 S33982 — —
800 S33092 2500 S33983 — —
Table 44: Special Y-Frame Sensor Plug
Rating (A) Catalog Number $ Pricea
2000 S47821
1040.00
2500 S47822
3000 S48826
3200 S47823
4000 S47824
5000 S47825
6000 S48827
6300 S47826
Table 45: Auxiliary and Alarm Contacts, Programmable Contact Module, Electrical Close Pushbutton
Description
T-Frame W- & Y-Frame
Fixed Drawout $ Price Fixed Drawout $ Price
1a/1b Form C Auxiliary Contact S47042 S47043 136.00 ———
Low Level 1a/1b Form C Auxiliary Contact S47339 S33806 170.00 ———
4a/4b Form C Auxiliary Contact (OF) — — — S48198 S48468 546.00
4a/4b Form C Auxiliary Contact (OF) with Actuator — — — S48859 S48860 630.00
1a/1b Form C Second Trip Alarm Contact (SDE2) S47340 S47430 136.00 S48200 S48475 136.00
Low Level 1a/1b Form C Second Trip Alarm Contact S47341 S47431 170.00 S48201 S48476 170.00
1a/1b Form C Ready-to-Close Contact (PF) S47342 S47432 470.00 S47342 S48469 470.00
Low Level 1a/1b Form C Ready-to-Close Contact S47343 S47433 504.00 S47343 S48470 504.00
2 Programmable Contact Module (M2C) S47403 S47483 966.00 S47403 S48382 966.00
6 Programmable Contact Module (M6C) S47404 S47484 1470.00 S47404 S48383 1470.00
Electrical Close Pushbutton (BPFE) S47512 S47512 1208.00 S48534 1208.00
Table 46: Shunt Trip, Second Shunt Trip , and Shunt Close
Voltage
50/60 Hz
T-, W-, & Y-Frame
Fixed
T-Frame
Drawout
W- & Y-Frame
Drawout $ Price
12 dc S47359 S33809 S48490
666.00
24–30 ac/dc S47360 S33810 S48491
48–60 ac/dc S47361 S33811 S48492
100–130 ac/dc S47362 S33812 S48493
200–240 ac/dc S47363 S33813 S48494
277 ac S47364 S33814 S48495
380–480 ac S47365 S33815 S48496
Table 47: Shunt Trip and Shunt Close for Circuit Breaker
with Communication
Voltage
50/60 Hz
T-, W-, & Y-Frame
Fixed
T-Frame
Drawout
W- & Y-Frame
Drawout $ Price
12 dc S47320 S33791 S48457
666.00
24–30 ac/dc S47321 S33792 S48458
48–60 ac/dc S47322 S33793 S48459
100–130 ac/dc S47323 S33794 S48460
200–240 ac/dc S47324 S33795 S48461
277 ac S47325 S33796 S48462
380–480 ac S47326 S33797 S48463
Table 48: Undervoltage Trip
Voltage T-, W-, & Y-Frame
Fixed
T-Frame
Drawout
W- & Y-Frame
Drawout $ Price
Instantaneous UV Trip (MN)
24–30 ac/dc S47380 S33819 S48501
1054.00
48–60 ac/dc S47381 S33820 S48502
100–130 ac/dc S47382 S33821 S48503
200–240 ac/dc S47383 S33822 S48504
380–480 ac S47385 S33824 S48506
Adjustable Time Delay Module
DE2F Discount
Schedule
20 © 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
Accessories
Incompatible with extra trip alarm switch (SDE2).
Can fit up to two locks.
To order Kirk Key or Schneider Electric locks, please fill out the keylock order form from
page 26.
For replacement only, door escutcheon included with circuit breaker.
Cradle Accessories
Includes padlock provision.
2 required.
A set of 3 actuating arms is standard on the cradle. One actuating arm can operate up to
3 switches.
Table 49: Spring Charging Motor (MCH)
Voltage
T-Frame
$ Price
W- & Y-Frame
$ Price
Fixed Drawout Fixed Drawout
AC
48 S47391 S47461
3580.00
S48207 S48522
3734.00
100–130 S47395 S47465 S48211 S48526
200–240 S47396 S47466 S48212 S48527
277 S47398 S47468 S48213 S48528
380–415 S47398 S47468 S48214 S48529
440–480 S47400 S47470 S48215 S48530
DC
24–30 S47390 S47460
3580.00
S48206 S48521
3734.00
48–60 S47391 S47461 S48207 S48522
100–130 S47392 S47462 S48208 S48523
200–250 S47393 S47463 S48209 S48524
Table 50: Remote Reset (RES)
Voltage
T-Frame
$ Price
W- & Y-Frame
$ Price
Fixed Drawout Fixed Drawout
110–130 S47344 S47434 844.00 S48202 S48472 844.00
200–240 S47345 S47435 S48203 S48473
Table 51: Circuit Breaker Locking Options
Description
One Lock
$ Price
Two Locks
(W/Y-Frame only) $ Price
T-Frame W/Y-Frame Identical Different
Kirk Key Lock
+ Provision S48939 S48945 2546.00 S48946 S48947 4092.00
Schneider Electric Lock
+ Provision S48942 S48948 2314.00 S48949 S48950 3722.00
Provision for
Kirk / Schneider Electric
Lock
S47517 S48542 908.00 ———
Ronis Key Lock
+ Provision S47521 S48549 3310.00 S48550 S48551 5322.00
Profalux Key Lock
+ Provision S47519 S48545 3310.00 S48546 S48547 5322.00
Provision for
Ronis Lock S47516 S48541 908.00 ———
Provision for
Profalux Lock S47515 S48541 908.00 ———
Provision for
Castell Lock S47518 S48543 908.00 ———
Padlock
Attachment S47514 S48539 256.00 ———
Padlockable Open/Close
Push Button Cover S33897 S48536 186.00 ———
Table 52: Miscellaneous Circuit Breaker Accessories
Description T-Frame $ Price W- & Y-Frame $ Price
Mechanical Operation Counter S33895 920.00 S48535 920.00
Door Escutcheon for Fixed
Circuit Breaker S33718 176.00 S48601 176.00
Table 53: Cradle Communications Module
Communications Type Catalog Number $ Price
MODBUS S48377 2002.00
Table 54: ANSI C37/UL 1066/UL 489 Cradle Safety Shutter,
Secondary Disconnects Terminal Shield
Description 3-Pole $ Price 4-Pole $ Price
T-Frame
Safety Shutter S48933 342.00 S48934 444.00
Secondary Disconnects Terminal Shield S33763 220.00 S33764 274.00
W-Frame
Safety Shutter S65346 680.00 S65347 908.00
Shutter Padlock Provision S65350 201.00 S65350 201.00
Secondary Disconnects Terminal Shield S48595 296.00 S48596 394.00
Y-Frame
Safety Shutter S65348 1162.00 S65349 1548.00
Shutter Padlock Provision S65350 201.00 S65350 201.00
Secondary Disconnects Terminal Shield S48597 376.00 S48598 502.00
Table 55: IEC 60947-2 Cradle Safety Shutter, Secondary
Disconnects Terminal Shield
Description 3-Pole $ Price 4-Pole $ Price
T-Frame
Safety Shutter S33765 342.00 S33766 444.00
Secondary Disconnects Terminal Shield S33763 220.00 S33764 274.00
W-Frame
Safety Shutter S48587 680.00 S48589 908.00
Shutter Padlock Provision S48591 100.00 S48591 100.00
Secondary Disconnects Terminal Shield S48595 296.00 S48596 394.00
Y-Frame
Safety Shutter S48588 1162.00 S48590 1548.00
Shutter Padlock Provision S48591 100.00 S48591 100.00
Secondary Disconnects Terminal Shield S48597 376.00 S48598 502.00
Table 56: Cradle Position Switches (Cell Switches)
Description Catalog
Number $ Price
T-, W-, and Y-Frame
1a/1b Form C Connected/Test/Disconnected Switch S33170 148.00
Low Level 1a/1b Form C Connected/Test/Disconnected Switch S33171 216.00
W- and Y-Frame
1a Connected/Test/Disconnected Switch (Ring Tongue) S48929 84.00
1b Connected/Test/Disconnected Switch (Ring Tongue) S48930 84.00
Set of 3 Cell Switch Actuating Arms S48560 48.00
DE2F Discount
Schedule
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
21
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
Accessories
Includes mounting provision.
To order Kirk Key or Schneider Electric locks, please fill out the keylock order form from
page 26.
Unit comes with 10 mounting brackets included.
For replacement only.
For NW20L1/NW20L circuit breaker.
For replacement only, door escutcheon included with circuit breaker.
For Automatic Spring Discharge (DAE) for IEC drawout circuit breakers, add $586.00.
For Off-Button-Crank Interface (IBPO) function for IEC drawout circuit breakers, add
$586.00.
Table 57: Cradle Cell Keying and Cradle Position Locking
Description T-Frame W/Y-Frame $ Price
Cell Keying Kit (all pins the same length) S33767 S48562 96.00
Cell Keying Kit for W/Y-frame (pins of varying lengths)
All production after December 2012 — NWCELLKEY 176.00
Key Locks—Kirk/Schneider Electric
1 Kirk Lock S48917 S48923 2154.00
2 Identical Kirk Locks S48918 S48924 3312.00
2 Different Kirk Locks S48919 S48925 3312.00
1 Schneider Electric Lock S48920 S48926 1960.00
2 Identical Schneider Electric Locks S48921 S48927 3012.00
2 Different Schneider Electric Locks S48922 S48928 3012.00
Provision for 2 Kirk/Schneider Electric Locks S33936 S48565 908.00
Provision for 1 Kirk/Schneider Electric Lock S33772 — 908.00
Key Locks—Ronis/Profalux
1 Ronis Lock S33776 S48572 2802.00
2 Identical Ronis Locks S33777 S48573 4306.00
2 Different Ronis Locks S33778 S48574 4306.00
1 Profalux Lock S33773 S48568 2802.00
2 Identical Profalux Locks S33774 S48569 4306.00
2 Different Profalux Locks S33775 S48570 4306.00
Provision for 2 Ronis Locks S33770 S48564 908.00
Provision for 2 Profalux Locks S33769 S48564 908.00
Provision for 2 Castell Locks S33771 S48566 908.00
Table 58: Masterpact NW/NT Circuit Breaker Remote Racking
Description Cat. No. $ Price
Masterpact NW/NT Remote Racking Device NWNTMPRRT 32,000.00
Masterpact NW Remote Racking Device NWMPRRT 21,500.00
Masterpact NT Remote Racking Device NTMPRRT 21,500.00
Mounting Bracket Kit for NW Remote Racking
(contains 10 mounting brackets) S47100 215.00
Mounting Bracket Kit for NT Remote Racking
(contains 10 mounting brackets) S47104 215.00
Control Unit for NW Remote Racking S47101 3650.00
30 ft Control Cable for NW Remote Racking S47102 620.00
Drive Shaft for NW Remote Racking S47103 290.00
Drive Shaft for NT Remote Racking S47103 290.00
Table 59: Cradle Metering CT Kit (set of 3)
For use with UL and ANSI rated circuit breakers only.
Sensor Plug
(A)
Catalog
Number $ Price
W-Frame
250 SMCT250 1372.00
400 SMCT400 1372.00
600 SMCT600 1380.00
800 SMCT800 1410.00
1200 SMCT1200 1476.00
1600 SMCT1600 1548.00
2000 SMCT2000 2412.00
2000 SMCT2000R 2020.00
2500 SMCT2500R 2110.00
3000 SMCT3000R 2258.00
3200 SMCT3200R 2452.00
Y-Frame
2000 SMCT2000Y 2552.00
2500 SMCT2500Y 2712.00
3000 SMCT3000Y 2868.00
3200 SMCT3200Y 2940.00
4000 SMCT4000Y 3326.00
5000 SMCT5000Y 3656.00
6000 SMCT6000Y 4080.00
Table 60: Cradle Miscellaneous Accessories
Description T-Frame $ Price W/Y-Frame $ Price
Door Interlock Kit (VPEC) S33786 330.00 S48579 330.00
Racking Interlock Kit (IBPO) S33788 238.00 S48582 238.00
Door Escutcheon S33857 370.00 685980 370.00
Transparent Cover S33859 1290.00 685981 1290.00
Combined “Connected” and “Closed”
Switch (1a/1b EF Switch) N/A — S48477 264.00
Low Level EF Switch N/A — S48478 542.00
Cable Door Interlock for Drawout Circuit Breakers S33921 2584.00 S48614 2584.00
Cable Door Interlock for Fixed Circuit Breakers S33920 2584.00 S48614 2584.00
Table 61: Spare Parts for ArcBlok™ UL/ANSI Masterpact NW
Circuit Breakers, Switches, and Cradles
Description Cat. No. $ Price
ArcBlok Shields 65251 92.00
UL/ANSI ArcBlok 2 Cluster Support 65253 577.00
UL/ANSI ArcBlok 3 Cluster Support 65254 577.00
UL/ANSI ArcBlok 4 Cluster Support 65255 577.00
UL/ANSI ArcBlok 6 Cluster Support 65256 577.00
UL/ANSI ArcBlok 10 Cluster Support 65257 577.00
ArcBlok Prepared Space Cassette (W-Frame) 65252 17183.00
ArcBlok Prepared Space Cassette (Y-Frame) 65263 34367.00
DE2F Discount
Schedule
22 © 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
Accessories
Includes positioning tool, reset tool and a grease tube.
Used for testing Micrologic trip units. Included in the price of the hand-held /
full-function test kits. Kit for replacement only.
Used for testing STR trip units. Included in the price of the hand-held /
full-function test kits. Kit for replacement only.
Included in the price of the full-function test kit. Kit for replacement only.
Included in the price of the hand-held test kit. Kit for replacement only.
For compliance with NEC 240.6(c).
Circuit breaker/cradle serial number also required if report is ordered after circuit
breaker/cradle is shipped.
Certified test reports are standard for ANSI circuit breakers and cradles. Order certified
test reports for UL and IEC products as desired.
Complete kit.
Complete kit requires: (2) S47926 + (1) S33209 or
(2) S33200 + (1) S33209 or
(2) S33201 + (1) S33209.
Required for mounting cluster support on standard Masterpact NW drawout circuit
breaker. Tool is not required for ArcBlok™ circuit breakers.
Table 62: Secondary Disconnects Wiring Kit
Type Fixed Drawout
T-, W-, & Y-Frame $ Price T-Frame $ Price W- & Y-Frame $ Price
Push-in Terminal Kit (3 Wires) S47074 80.00 S33098 120.00 S47849 120.00
Push-in Terminal Kit (6 Wires) S47075 240.00 S33099 240.00 S47850 240.00
Ring Tongue Kit 1a
N/A N/A
S48912 64.00
Ring Tongue Kit 1b S48913 64.00
Ring Tongue Kit 1a & 1b S48914 126.00
Trip Unit 12-Pin Connectors S33101 228.00 S33101 228.00 S33101 228.00
External Voltage Sensing Wiring Kit S47506 266.00 S47507 266.00 S48533 266.00
Table 63: Finger Cluster and Cluster Tools
Description Catalog
Number $ Price
Finger Cluster (Each) S33166 164.00
Cluster Grease (12 oz. Tube) S48899 132.00
Cluster Positioning Tool S47542 1504.00
Cluster Reset Tool CLUSRETOOL 250.00
Cluster Service Kit CLUSTOOLSK 1886.00
Table 64: Test Kit and External Power Supply Module
Description Catalog
Number $ Price
Hand-Held Test Kit S33594 5386.00
Full-Function Test Kit S33595 33792.00
FFTK Report Generator Software FFTKRPTV10 800.00
Seven-Pin Test Cable
(for connection between test kit and trip unit) S48907 1488.00
Two-Pin Test Cable
(for connection between test kit and trip unit) S48908 784.00
230 Vac Filtered Power Cord S48856 166.00
120 Vac Filtered Power Cord S48855 60.00
Primary Injection Test Adapter S33937 252.00
NW Phenix Primary Injection Kit ULW10025 4000.00
NW Multi Amp Primary Injection Kit ULW10026 4000.00
NT Primary Injection Kit ULW10027 4000.00
Trip Unit Seal (6 pieces) MICROTUSEAL 60.00
Table 65: 24 Vdc Power Supply and Battery Backup Modules
(Not UL Listed)
Description Catalog
Number $ Price
Power Supply with 24-30 Vdc Input 685823
1130.00
Power Supply with 48/60 Vdc Input 685824
Power Supply with 125 Vdc Input 685825
Power Supply with 110-130 Vac Input 685826
Power Supply with 200-240 Vac Input 685827
Power Supply with 380-415 Vac Input 685829
Battery Backup (12 Hours) 685831 3260.00
Trip Unit Battery for Trip Indicator Lights S33593 438.00
Table 66: Lifting Device Kits
Description Catalog
Number $ Price
Crossbar for W-Frame Circuit Breaker or Cradle S48900 7738.00
Crossbar for Y-Frame Circuit Breaker or Cradle S48901 8912.00
Set of Two Lifting Hooks S48906 3722.00
Table 67: Fixed Circuit Breaker Mounting Brackets (Set of 2)
Description Catalog
Number $ Price
W- and Y-Frame Only
Mounting Brackets for horizontal mount S47828 458.00
Mounting Brackets for vertical mount S47829
Table 68: Certified Test Reports
Test Report Catalog
Number $ Price
Circuit Breaker 4804930501B 252.00
Cradle 4804930501C 132.00
Table 69: Source Changeover Interlocks
Type of Interlock Kit T-Frame
Fixed $ Price T-Frame
Drawout $ Price W- & Y-
Frame $ Price
Rod Interlock Kit for
two circuit breakers S33912 2304.00 S33913 2304.00 S48612 2304.00
Cable Interlock Kit for two circuit breakersl
Cable Interlock S33209 248.00 S33209 248.00 S33209 248.00
Cable Mounting Plate S33200 1234.00 S33201 1234.00 S47926 1234.00
Cable Interlock Kit for three circuit breakers
Three main circuit breakers S48610 3686.00
Two main circuit breakers and one tie circuit breaker S48609 3686.00
Two main circuit breakers and one generator circuit breaker S48608 3686.00
Table 70: Miscellaneous Spare Parts for
Masterpact™ NW Circuit Breakers
Catalog
Number Description $ Price
S47935
Type S Arc Chute (each) for:
UL: NW08—NW30 N/H/HF
ANSI: NW08—NW32 N1/H1/H2/H3/HA
IEC: NW08—NW40 N1/H1/H2/NA/HA/HF
412.00
S47936
Type G Arc Chute (each) for:
UL: NW40—NW60 H/HF, NW20—NW60 L
ANSI: NW40—NW50 H2/H3/HA, NW32—NW50 L1
IEC: NW50—NW63 H1/H2/HA, NW20—NW40 H3
588.00
S47937
Type B Arc Chute (each) for:
UL: NW08—NW16 L
ANSI: NW08—NW20 L1
IEC: NW08—NW20 L1
412.00
Faceplate cover
430.00
S47939 IEC fixed & drawout, UL/ANSI fixed
S47939U UL/ANSI drawout non limiter
S47939L UL/ANSI drawout limiter (L/L1 AIR)
S47940 Spring charging handle 172.00
S47944 Masterpact NW racking handle 344.00
S47092 Masterpact NT racking Handle 344.00
64274 Cradle interlock defeat tool 60.00
S47034 UL/ANSI 3 cluster support
214.00
S47035 UL/ANSI 2 cluster support
S47036 UL/ANSI 4 cluster support limiter
S47037 UL/ANSI 6 cluster support limiter
S47038 UL/ANSI 6 cluster support
S47039 UL/ANSI 4 cluster support
S47040 UL/ANSI 10 cluster support
S47041 UL/ANSI 10 cluster support limiter
S48857 Cluster support mounting tool 3200.00
DE2F Discount
Schedule
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
23
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
Accessories
Masterpact MP/MC Retrofit Kits
These bus adapter kits will allow direct mechanical replacement of the old Masterpact MP/MC (UL/ANSI) with the Masterpact NW circuit breaker.
Order the corresponding Masterpact NW circuit breaker without connectors and the retrofit kit for a complete replacement.
Some electrical accessories characteristics and wiring connections may not be identical between Masterpact MP/MC and Masterpact NW.
Evaluation with regards to products compatibility must be completed before commissioning the replacement circuit breaker.
Kit is shown as a set of 3 (3-pole) or 4 (4-pole) for Top and Bottom connection.
Masterpact MP: UL 489 circuit breaker
Masterpact MC: UL1066 (ANSI C37) circuit breaker
Masterpact M Retrofit Kits
These bus adapter kits will allow direct mechanical replacement of the old Masterpact M (IEC) with the
Masterpact NW circuit breaker.
Order the corresponding Masterpact NW circuit breaker without connectors and the retrofit kit for a complete replacement.
Some electrical accessories characteristics and wiring connections may not be identical between Masterpact M and Masterpact NW. Evaluation
with regards to products compatibility must be completed before commissioning the replacement circuit breaker.
Kit is shown as a set of 3 (3-pole) or 4 (4-pole) for Top and Bottom connection.
Masterpact M: IEC 60947-2 circuit breaker
Table 71: Retrofit Kits
Old Circuit Breaker
Being Replaced
New Circuit Breaker
Without Connectors
Retrofit Kit
3-Pole
Top
$ Price
Retrofit Kit
3-Pole
Bottom
$ Price
Retrofit Kit
4-Pole
Top
$ Price
Retrofit Kit
4-Pole
Bottom
$ Price
Masterpact MP/MC UL/ANSI Drawout Circuit Breakers
MP/MC 08-16 Vertical NW08-16 S64120T 3758.00 S64120B 3758.00 S64131T 5138.00 S64131B 5138.00
MP/MC 08-16 Horizontal NW08-16 S64121 3946.00 S64122 3946.00 S64132 5394.00 S64133 5394.00
MP/MC 20 Vertical NW20 S64123 3946.00 S64124 3946.00 S64134 5394.00 S64135 5394.00
MP 25-30 Vertical NW25-30 S64125 7374.00 S64125 7374.00 S64136 10536.00 S64137 10536.00
MC 32 Vertical NW32 S64126 9002.00 S64126 9002.00 N/A N/A N/A N/A
MP/MC 40 Vertical NW40 S64127 11710.00 S64128 11710.00 S64138 15464.00 S64139 15464.00
MP/MC 50 Vertical NW50 S64129 11710.00 S64169 11710.00 S64140 15464.00 S64170 15464.00
MP 63 Vertical NW60 S64130 22338.00 S64130 22338.00 N/A N/A N/A N/A
Masterpact MP UL Fixed Circuit Breakers
MP 08-16 Vertical NW08-16 S64141 3946.00 S64142 3946.00 S64153 5394.00 S64154 5394.00
MP 08-16 Horizontal NW08-16 S64143 3946.00 S64144 3946.00 S64155 5394.00 S64156 5394.00
MP 20 Vertical NW20 S64145 3946.00 S64146 3946.00 S64157 5394.00 S64158 5394.00
MP 25-30 Vertical NW25-30 S64147 7374.00 S64148 7374.00 S64159 10536.00 S64160 10536.00
MP 40 Vertical NW40 S64149 11710.00 S64150 11710.00 N/A N/A N/A N/A
MP 50 Vertical NW50 S64151 11710.00 S64152 11710.00 N/A N/A N/A N/A
Table 72: Retrofit Kits
Old Circuit Breaker
Being Replaced
New Circuit Breaker
Without Connectors
Retrofit Kit
3-Pole
Top
$ Price
Retrofit Kit
3-Pole
Bottom
$ Price
Retrofit Kit
4-Pole
Top
$ Price
Retrofit Kit
4-Pole
Bottom
$ Price
Masterpact M IEC Drawout Circuit Breakers
M 08-12 N1/NI Vertical NW08-12 S48966 3912.00 S48966 3912.00 S48966Q 5214.00 S48966Q 5214.00
M 08-12 N1/NI Horizontal NW08-12 S48951 3912.00 S48964 3912.00 S48951Q 5214.00 S48964Q 5214.00
M 08-12 H1/H2/HI/HF Vertical NW08-12 S48969 3912.00 S48969 3912.00 S48969Q 5214.00 S48969Q 5214.00
M 08-12 H1/H2/HI/HF Horizontal NW08-12 S48954 3912.00 S48965 3912.00 S48954Q 5214.00 S48965Q 5214.00
M 16 N1/H1/H2/NI/HI/HF Vertical NW16 S48969 3912.00 S48969 3912.00 S48969Q 5214.00 S48969Q 5214.00
M 16 N1/H1/H2/NI/HI/HF Horizontal NW16 S48954 3912.00 S48965 3912.00 S48954Q 5214.00 S48965Q 5214.00
M 20-25 N1/H1/H2/NI/HI/HF Vertical NW20-25 S48970 6012.00 S48970 6012.00 S48970Q 7314.00 S48970Q 7314.00
M 20-25 N1/H1/H2/NI/HI/HF Horizontal NW20-25 S48957 6012.00 S48958 6012.00 S48957Q 7314.00 S48958Q 7314.00
M 32 H1/H2/HI/HF Vertical NW32 S48974 7062.00 S48974 7062.00 S48978Q 8364.00 S48978Q 8364.00
M 32 H1/H2/HI/HF for neutral left NW32 S48973 7062.00 S48973 7062.00 S48976Q 8364.00 S48977Q 8364.00
M 32 H1/H2/HI/HF for neutral right NW32 S48973 7062.00 S48973 7062.00 S48977Q 8364.00 S48976Q 8364.00
Masterpact M IEC Fixed Circuit Breakers
M 08-12 N1/NI Horizontal NW08-12 S48951 3912.00 S48964 3912.00 S48951Q 5214.00 S48964Q 5214.00
M 08-12 H1/H2/HI/HF Horizontal NW08-12 S48954 3912.00 S48965 3912.00 S48954Q 5214.00 S48965Q 5214.00
M 16 N1/H1/H2/NI/HI/HF Horizontal NW16 S48954 3912.00 S48965 3912.00 S48954Q 5214.00 S48965Q 5214.00
M 20-25 N1/H1/H2/NI/HI/HF Horizontal NW20-25 S48957 6012.00 S48958 6012.00 S48957Q 7314.00 S48958Q 7314.00
M 32 H1/H2/HI/HF Horizontal NW32 S48962 7062.00 S48961 7062.00 S48960Q 8364.00 S48960Q 8364.00
DE2F Discount
Schedule
24 © 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Pricing Guide
Masterpact™ NT/NW Universal Power Circuit Breakers
Accessories
Masterpact MP/MC/M Neutral CT Retrofit Kits
If required, select the appropriate neutral CT based on the sensor plug ampere rating, Type (UL/ANSI or IEC) and frame rating of the Masterpact
NW circuit breaker
Examples:
For UL Masterpact NW 4000 A Frame (NW 40) with 3000 A Sensor plug, select NCT catalog no. S64164
For IEC Masterpact NW 4000 A Frame (NW 40) with 3000 A Sensor plug, select NCT catalog no. S64163
Kit includes the Masterpact NW neutral sensor with special bus connection that provides exact touch point to the existing bus of the Masterpact
MP/MC/M neutral sensor being replaced.
Table 73: Neutral CT Retrofit Kits
Sensor Plug Rating
(A)
UL/ANSI Circuit Breaker
Frame IEC Circuit Breaker Frame NCT
Catalog No. $ Price
100–250 NW 08 NW 08 S64161 2428.00
400–2000 NW 08-20 NW 08-20 S64162 2428.00
2500–4000 NW 25-32 NW 25-40 S64163 2428.00
2000–6300 NW 40-60 NW 50-63 S64164 4870.00
DE2F Discount
Schedule
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
25
Appendix A—Selection
Page 1 of 2
Request for Quotation Form
For faster quote processing, please use the following request for quotation form. For each section, check the applicable box or enter value corresponding to your
choice. Note: this request for quotation form does not take into account incompatibilities. Orders to be placed on CSSS.
Square D: Date Customer Name: RFQ No.
From Location Account No. Q2C No.
Phone No. Fax No. Contact Name Phone No.
Messages Location Fax No.
Circuit Breakers or Switches Quantity: ______
Brand: Schneider Electric Square D
Standard ANSI UL IEC
Type NT NW
Number of Poles 3 4
Frame rating Amperes: ______
Sensor plug rating Amperes: ______
Interrupting/ N, N1, NA, L, LF, L1, L1F, H, H1
Withstand rating H2, H3, H10, HA, HA10, HF, HB, HC
_____
Cradle options: Circuit breaker with cradle
Circuit breaker without cradle
Cradle only
Fixed circuit breaker
ArcBlok™ circuit breaker
with cradle
without cradle
ArcBlok cradle only
Optional characterization for CTs
Micrologic Trip Units
Dummy Trip Unit (for switch only)
Basic Trip Unit
Basic protection 2.0 3.0
Selective protection 5.0
Trip Unit with Ammeter
Basic protection 2.0A 3.0A
Selective protection 5.0A
Selective protection + equip. ground fault 6.0A
Trip Unit with Power Metering
Selective protection 5.0P
Selective protection + equip. ground fault 6.0P
Trip Unit with Harmonic Metering
Selective protection 5.0H
Selective protection + equip. ground fault 6.0H
Rating plug type (A=UL/ANSI; R=IEC)
(for non-standard, see page 17) ______
Choose one: External neutral sensor (CT)
Mod. differential ground-fault (MDGF)
Source ground return (SGR)
Micrologic™ Trip Unit Accessories
Choose one: Programmable contact module (M2C)
Programmable contact module (M6C)
MODBUS® circuit breaker com. module (BCM)
MODBUS cradle com. module (CCM)
Restraint interface module (RIM)
External power supply (24 Vdc) input voltage____
Number of power supplies/circuit breaker: 1 or 2
Battery backup quantity: 1 or 2
External voltage sensing
Automatic reset (RAR)
Manufacturing Numbers Provided with Quotation
See Delivery Schedule on the next page
Not available on Masterpact NT (T-frame circuit breaker)
Complete only if ordering cradle without circuit breaker.
ArcBlok circuit breakers and cradles are available for ANSI and UL489 3-pole circuit breakers and cradles
only. ArcBlok devices are not available for interrupting / withstand ratings of L, LF, L1, L1F, HF or HB.
Cradle Secondary Disconnects
Choose one:
Push-in terminal (standard)
Ring terminal
Accessories for Remote Operation
Spring-charging motor (MCH) ______ Vac
______ Vdc
Shunt close (XF): Standard or Communication ______ Vac
______ Vdc
Shunt trip (MX1): Standard or Communication ______ Vac
______ Vdc
Additional shunt trip (MX2) ______ Vac
OR ______Vdc
Undervoltage trip (MN)—choose one
Instantaneous ______ Vac
______ Vdc
Fixed–time delayed ______ Vac
______ Vdc
Adjustable–time delayed ______ Vac
______ Vdc
Electrical closing push button (BPFE)
Remote reset after fault trip (RES) 110–130 Vac
(incompatible with SDE2) 200–240 Vac
Wiring for Cradle
Circuit breaker communication module (BCM) wiring
Wiring for zone-selective interlocking (ZSI), modified differential
ground fault (MDGF), neutral current transformer (CT) and 24 V power supply
Wiring for programmable contact modules (M2C and M6C)
Wiring for additional overcurrent trip switch (SDE2) or electrical reset (RES)
Wiring for undervoltage trip (MN) or additional shunt trip (MX2)
Wiring for shunt trip (MX), shunt close (XF) and spring-charging motor (MCH)
Wiring for ready-to-close contact (PF)
Wiring for four additional form C auxiliary switches (push-in terminals) or
2a+2b auxiliary switches (ring terminals) (OF)
Wiring for eight additional form C auxiliary switches (push-in terminals) (OF)
Circuit Breaker:
Cradle:
26 © 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Appendix A—Selection
Page 2 of 2
Request for Quotation Form
Not available on Masterpact NT (T-frame circuit breaker)
Not available on IEC circuit breaker
Not available on IEC Masterpact NT.
Standard with IEC offer.
Auxiliary, Alarm and Cradle Position Switches
Auxiliary switch (OF) Push-in type terminal or Ring terminal
choose one: 4a/4b form C (std.) 2a + 2b
4a/4b low level NT 4a + 4b
8a/8b form C
12a/12b form C
Overcurrent trip switches
Standard (1a/1b form C) (SDE1) standard
Additional overcurrent trip switches (choose one)
(1a/1b form C) (incompatible with RES) (SDE2)
(1a/1b form C) (incompatible with RES) (low-level SDE2)
Ready-to-close switch (PF) Std low level
Push-in type cradle position switches (1a/1b form C) Qty
Connected position (max. qty.: 3 NW/3 NT) (CE) ______
Test position (max. qty.: 3 NW/1 NT) (CT) ______
Disconnected position (max. qty.: 3 NW/2 NT) (CD) ______
Low-level cradle position switch
Choose one: Qty
Connected/Closed switch (max. qty.: 8) (EF) ______
Connected/Closed switch (max. qty.: 8) (low-level EF) ______
Ring terminal type cradle position switches (1a or 1b contact)
Connected position (max. 3a or 3b) qty/type _________
Test position (max. 1a or 1b) qty/type _________
Disconnected position (max. 3a or 3b) qty/type _________
Locking and Interlocking Cradle Brkr
Padlockable push button cover
Padlock provision only
One key lock (select manufacturer below)
Two key locks keyed alike
(select manufacturer below)
Two key locks keyed differently
(select manufacturer below)
Key lock manufacturer:
Kirk Ronis
Schneider Electric Profalux Castell
Cradle Connections
Front-connected
800–3200 A Front-connected flat (FCF)
Front-connected “T” (FCT)
4000 A Front-connected flat (FCF)
4000–5000 A Front-connected “T” (FCT)
Rear-connected
800–3200 A Rear-connected “T” vertical (RCTV)
Rear-connected “T” horizontal (RCTH)
2000 A L1/L
3200 A (ANSI)
Rear-connected offset vertical (RCOV)
Rear-connected offset vertical (RCOV)
4000-6300 A Rear connected “T” vertical (RCTV)
Rear-connected “T” horizontal (RCTH)
Cradle Interlocking and Accessories
Door interlock(VPEL)
Racking interlock between racking crank and Off position
—std. on UL/ANSI (IBPO)
Racking interlock (VPOC)
Automatic spring discharge (DAE)—std. on UL/ANSI
Cradle rejection kit standard
Auxiliary terminal shield
Metering CT (optional for UL/ANSI only)
Lock cradle in all positions—std. on UL/ANSI
Miscellaneous Accessories
Mechanical operation counter
Shutter (Required option for IEC NW circuit breakers
Shutter with padlock provision and position indicator
Transparent cover (drawout circuit breaker only)
Lifting device for lifting hooks (set of 2)
T-frame, W-frame, or Y-frame circuit breaker lifting bar (short)
lifting bar (long)
Masterpact NW/NT remote racking device
Test Equipment
Hand-held test kit
Full-function test kit
Test report for circuit breaker, standard for ANSI, check for UL, IEC
Test report for cradle, standard on ANSI, check for UL, IEC
Delivery Schedule
Circuit breaker and cradle to be shipped together
Cradle to be shipped prior to circuit breaker
Schneider Electric Conditions of Sale Apply
Manufacturing Number Provided
with Quotation List Price
Circuit Breaker: $
Cradle: $
$
Tota l
Delivery (from receipt of order)
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
27
Appendix B—DC Circuit Breakers Selection
Page 1 of 2
REQUEST FOR QUOTATION FORM
Manufacturing Numbers Provided with Quotation
Circuit Breaker: ___________________________________________
Cradle: __________________________________________________
For faster quote processing, please use the following request for quotation form. For each section, check the applicable box or enter values corresponding to your
choice. Note: this request for quotation form does not take into account incompatibilities. Order to be placed on CSSS.
Date Customer Name: RFQ No.:
From Location Account No.: Q2C No.:
Phone No. Fax No. Contact Name: Phone No.:
Messages Location: Fax No.:
UL Listed Circuit Breaker Qty
Masterpact Type
NW08
NW12
NW16
NW20
NW25
NW30
NW40
Circuit Breaker Type N and H are available
Type of Sensor
1250 to 2500 A
2500 to 5400 A
5000 to 11000 A
Load Connection Version C Version C1
Type of Equipment Fixed
Drawout chassis
Type of Connection Vertical Top Bottom
Horizontal Top Bottom
IEC Rated Circuit Breaker or Switch Disconnector Qty
Masterpact Type
NW10
NW20
NW40
Circuit Breaker Type N, H
Switch-disconnector Type HA
Type of Sensor
1250 to 2500 A
2500 to 5400 A
5000 to 11000 A
Load Connection C, D, E
Type of Equipment Fixed
Drawout
Type of Connection Vertical Top Bottom
Horizontal Top Bottom
Cradle Secondary Disconnects
Choose One:
Push-in terminal (standard)
Ring terminal (UL option only)
Accessories for Remote Operation
Spring-charging Motor (MCH) ________ V ac
________ V dc
Shunt close (XF) ________ V ac
________ V dc
Shunt Trip (MX1) ________ V ac
________ V dc
Additional shunt trip (MX2) ________ V ac
OR ________ V dc
Undervoltage Trip (MN) –choose one
Instantaneous ________ V ac
________ V dc
Fixed-time delay ________ V ac
________ V dc
Adjustable-time delay ________ V ac
________ V dc
Electrical closing push button (BPFE)
Remote reset after fault trip (RES) 100–130 Vac
(incompatible with SDE2) 200–240 Vac
Wiring for Cradle
(Complete only if ordering cradel without circuit breaker)
Wiring for additional overcurrent trip switch (SED2) or electrical reset
(RES)
Wiring for undervoltage trip (MN) or additional shunt trip (MX2)
(Wiring for shunt trip (MX), shunt close (XF) and spring-charging motor
(MCH)
Wiring for ready-to-close contact (PF)
Wiring for four additional Form C auxiliary switches (push-in
terminals) or 2a+2b auxiliary switches (ring terminals (OF)
Wiring for eight additional form C auxiliary switches (Push-in Terminals)
(OF)
28 © 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
Appendix B—DC Circuit Breaker Selection
Page 2 of 2
REQUEST FOR QUOTATION FORM
Auxiliary, Alarm and Cradle Position Switches
Auxiliary Switch (OF)
Choose one: Push-in type terminal or Ring terminal
4a/4b form C (std.) 2a + 2b
8a/8b form C 4a + 4b
12A/12B form C
Overcurrent trip switches
Standard (1a/1b form C) (SDE1) standard
Additional overcurrent trip switches (choose one)
(1a/1b form c) (incompatible with RES) (SDE2)
(1a/1b form c) (incompatible with RES) (low level (SDE2)
Ready-to-close switch (PF) Std low-level
Push-in type cradle position switches (1a/1b form C)
Connected position (max. qty: 3) qty ______
Test position (max. qty: 3) qty ______
Disconnected position (max. qty: 3) qty ______
Low-level cradle position switch
Choose one: Qty.
Connected/Closed switch (max. qty: 8) (EF) ______
Connected/Closed switch (max. qty: 8) (low-level EF) _____
Ring terminal type cradle position switches (1a or 1b contact)
Connected position (max. 3a or 3b) qty ______
Test position (max. 1a or 1b) qty ______
Disconnected position (max. 3a or 3b) qty ______
Cradle Interlocking and Accessories
Door Interlock
Racking interlock between racking crank and Off position
std on UL, check for IEC
Racking interlock (VPOC)
Automatic spring discharge (DAE) std on UL, check for IEC
Cradle rejection kit standard
Auxiliary terminal shield
Miscellaneous Accessories
Mechanical operation counter
Shutter
Shutter with padlock provision and position indicator
Locking and Interlocking Cradle Brkr.
Padlockable push button cover
Padlock provision only Std
One key lock
(Select manufacturer below)
Two key locks keyed alike
(Select manufacturer below)
Two key locks keyed differently
(Select manufacturer below)
Key lock manufacturer
Kirk Ronis
Schneider Electric Profalux Castell
Test report for circuit breaker
Test report for cradle
Manufacturing Number (provided with quotation)
List Price
Circuit Breaker: $
Cradle: $ Delivery (from receipt of order)
Total $
Delivery Schedule
Circuit Breaker and cradle to be shipped together
Cradle to be shipped prior to circuit breaker
Schneider Electric Conditions of Sale Apply
© 2000-2013 Schneider Electric All Rights Reserved
Prices subject to change without notice.
07/2013
29
Appendix C—Keylock Selection
Kirk® or Schneider Electric™ Keylock Order Information
Form Use: To supply order information when the Kirk key or Schneider Electric lock for the part numbers listed below are ordered
Purchase Order # ________________________________________
Circuit Breaker Catalog # :__________________________________
Choose one:
Please note: Since these are registered keys, the following information is REQUIRED before the order can be processed.
Q2C # : Job Name : Date Completed :
Line Items(s) : Completed By : From (Location) :
Qty Keylock Schneider
Electric Drawing
Used On
Kirk Single Lock (Part No. 35635) — Masterpact NT/NW and PowerPact P Cradle Only
Kirk Single Lock F 1/2 E (Part No. 35635) — CK Circuit Breakers Only
Kirk Single Lock (Horizontal Mount) SK41683-1 48186-220-50 PowerPact M-, P-, and R-Frame Circuit Breakers Only
Kirk Single Lock (Vertical Mount) KLF030010 48185-267-01 PowerPact M- and P-Frame Circuit Breakers Only
Kirk Double Lock (Vertical Mount) KFL003720 48185-266-01 PowerPact M-,and P-Frame Circuit Breakers Only
Kirk Double Lock (Horizontal Mount) SK41686-1 48186-224-50 PowerPact R-Frame Circuit Breakers Only
Schneider Electric Single Lock 12A-1MG — Masterpact NT/NW and PowerPact P Cradle Only
Schneider Electric Single Lock (Horizontal Mount) VFR-3/8-E 48186-221-50 PowerPact M-, P-, and R-Frame Circuit Breakers Only
Schneider Electric Single Lock (Vertical Mount) VF-3/8-E 48185-267-01 PowerPact M- and P-Frame Circuit Breakers Only
Schneider Electric Double Lock (Vertical Mount) VM2F-3/8-EE 48185-266-01 PowerPact M- and P-Frame Circuit Breakers Only
Schneider Electric Double Lock (Horizontal Mount) VM2FR-3/8-EE 48186-224-50 PowerPact R-Frame Circuit Breakers Only
Ultimate User’s Name and Address
Ultimate User’s Name and Address Contact Person and Phone Number
Keyed Alike Keyed Differe t
Qty. Catalog No. Qty. Catalog No.
Qty. Catalog No. Qty. Catalog No.
Sets Keyed Alike Keyed Like Existing Lock
Qty. Catalog No. Key / Lock No.
Submit to: Customer Service At Location: Cedar Rapids Plant FAX: 319-369-6448
07/2013
Schneider Electric USA, Inc.
1415 S. Roselle Road
Palatine, IL 60067 USA
1-888-778-2733
www.schneider-electric.us
© 2000-2013 Schneider Electric All Rights Reserved
Square D™, Schneider Electric™, and Masterpact™ are trademarks owned by Schneider Electric
Industries SAS or its affiliated companies. All other trademarks are the property of their respective
owners.
0613PL0001 R07/13 Replaces 0613PL0001 R10/12

Navigation menu
