PRODUCT SPECIFICATIONS
41089-1xP
QuickPort® 1-Port Surface Mount Housing
41089-1xP
APPLICATION
The compact surface mount housing accepts one
QuickPort snap-in connector module. The housing
supports voice/data applications in open ofce, retrot
or other surface mount environments. It includes an ID
window, mounting screws and adhesive, and is available
in four colors.
SPECIFICATION
The surface mount housing shall be small and low prole
to accept one eld-congurable QuickPort module. Base
and snap-on cover shall include knockouts for rear,
bottom, or side cable entry. Base shall also include cable
anchor points. Mounting methods shall include screws
and pressure sensitive adhesive. Cover shall include an
identication window. Construction shall be of high
impact re retardant plastic rated UL 94V-0. Housing
shall be cULus listed and compliant with ANSI/TIA-568-C.
Page 1 of 2
FEATURES
Low prole and small overall footprint
Compatible with all individual QuickPort modules
Housing base functions as a punchdown platform stabilizing
connector modules during termination
Connector module can be pre-terminated prior to snapping into
housing port
Comes in four colors: white, ivory, grey, and black
DESIGN CONSIDERATIONS
Choose either screws or adhesive for mounting
Bottom, side, or rear cable entry options (rear cable entry
recommended to help meet cable bend radius standards)
Allows several port identication methods, including colored
modules, designation labels and custom silkscreening
Allows the use of different colored connectors for different
applications to ID ports, 13 TIA-606 compatible connector
colors available. Leviton's pre-printed Port Designation Labels
are also compatible (PN 41080-L*B)
STANDARDS COMPLIANCE
Meets or exceeds all applicable standards. cULus listed; complies
with NEC Article 800 and ANSI/TIA-568-C.
PHYSICAL SPECIFICATIONS
Dimensions: See page 2
Materials: High-impact, re-retardant plastic rated UL 94V-0
Capacity: One snap-in QuickPort connector module
Mounting: Screws (included) or pressure sensitive adhesive
(included)
COUNTRY OF ORIGIN
United States of America
WARRANTY INFORMATION
For a copy of Leviton warranties,
visit www.leviton.com/warranty.
Leviton Network Solutions
2222 - 222nd St. SE
Bothell, WA 98021-4416
tel 1-800-824-3005
tel +1-425-486-2222
appeng@leviton.com
www.leviton.com
Asia / Pacic
T +1.631.812.6228
E infoasean@leviton.com
Canada
T +1.514.954.1840
E pcservice@leviton.com
Caribbean
T +1.954.593.1896
E infocaribbean@leviton.com
China
T +852.2774.9876
E infochina@leviton.com
Colombia
T +57.1.743.6045
E infocolombia@leviton.com
Europe
T +33.6.8869.1380
E infoeurope@leviton.com
India / SAARC
T +91.80.4322.5678
E infoindia@leviton.com
Mexico
T +52.55.5082.1040
E lsamarketing@leviton.com
Middle East & Africa
T +971.4.886.4722
E lmeinfo@leviton.com
South Korea
T +82.2.3273.9963
E infokorea@leviton.com
Copyright © 2012 Leviton Manufacturing Co., Inc. All rights reserved. Subject to change without notice. September 2012
PRODUCT SPECIFICATIONS
41089-1xP
41089-1xP
I12 4209a
ELECTRONIC FILES
For CAD les, typical specs, or technical drawings (.DXF, .DWG), visit www.leviton.com.
Page 2 of 2
PART NUMBERS
Description Part No.
1-Port Surface Mount Housing - White 41089-1WP
1-Port Surface Mount Housing - Ivory 41089-1IP
1-Port Surface Mount Housing - Grey 41089-1GP
1-Port Surface Mount Housing - Black 41089-1EP
Leviton Network Solutions
2222 - 222nd St. SE
Bothell, WA 98021-4416
tel 1-800-824-3005
tel +1-425-486-2222
appeng@leviton.com
www.leviton.com
Asia / Pacic
T +1.631.812.6228
E infoasean@leviton.com
Canada
T +1.514.954.1840
E pcservice@leviton.com
Caribbean
T +1.954.593.1896
E infocaribbean@leviton.com
China
T +852.2774.9876
E infochina@leviton.com
Colombia
T +57.1.743.6045
E infocolombia@leviton.com
Europe
T +33.6.8869.1380
E infoeurope@leviton.com
India / SAARC
T +91.80.4322.5678
E infoindia@leviton.com
Mexico
T +52.55.5082.1040
E lsamarketing@leviton.com
Middle East & Africa
T +971.4.886.4722
E lmeinfo@leviton.com
South Korea
T +82.2.3273.9963
E infokorea@leviton.com
Copyright © 2012 Leviton Manufacturing Co., Inc. All rights reserved. Subject to change without notice. September 2012
1.01"
1.41"
2.30"
