Cover
Table of Contents
Product Index
Commercial/Industrial Applications
Residential Applications
Merchandising Support
Weatherproof Products
Energy Controls
Professional Lighting
Pool & Spa Controls
Surge Protection
Consumer Products
Cross Reference
Sales Representatives

www.intermatic.com

General Catalog WEATHERPROOF

ENERGY CONTROLS

PROFESSIONAL LIGHTING

POOL & SPACONTROLS

SURGE PROTECTION

CONSUMER PRODUCTS

Providing a Brighter Solution™

Asystem is defined as a group of units, combined to form a

whole, which operates in unison. Intermatic takes this

definition one step further and combines complete

communication with total connectivity. Instead of

just putting forward a massive listing of part

numbers, Intermatic provides its customers

with a new approach to energy controls that

combines six categories of products into

singular solutions – helping everyone from

distributors and electrical contractors to

architects and designers provide their

customers with smarter and more

reliable energy control systems.

Table of Contents

Commercial/Industrial Applications . . . . . .6

Residential Applications . . . . . . . . . . . . . . .8

Merchandising Support . . . . . . . . . . . . . . .10

Weatherproof Products .............13

Energy Controls ...................20

Professional Lighting ...............58

Pool & Spa Controls ................67

Surge Protection ...................87

Consumer Products ...............121

Cross Reference ...................146

WEATHERPROOF

ENERGY CONTROLS

PROFESSIONAL LIGHTING

POOL & SPACONTROLS

SURGE PROTECTION

CONSUMER PRODUCTS

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER 3

Intermatic’s headquarters and

main manufacturing facilities in

Spring Grove, Illinois... making

quality products since 1891.

Visit us on our website at

www.intermatic.com for the

most up to date information on

Intermatic products.

Icon Legend:

Underwriters

Laboratories Listed

UL Tested to Both

UL & CSA Standards

Canadian Standards

Association Approved

CSA Tested to

UL Standards

CSA Tested to Both

CSA & UL Standards

UL Component

Recognized

Knockouts

Temperature

Shipping Weight

Warranty Period

133PE1484A . . .70, 71, 72

156ET9402A . . . . . . . .45

156ET9403A . . . . . . . .45

178PA28A . . . . . . .70, 72

22T338GR . . . . . . . . . .39

22T535GR . . . . . . . . . .39

24EG5133 . . . . . . . . .115

2T1985GR . . . . . . . . . .38

2T2040GA . . . . . . . . . .38

2T2502GA . . . . . . . . . .38

2T2292GA . . . . . . . . . .38

2T2293GA . . . . . . . . . .38

2T2331GA . . . . . . . . . .38

2T2365GA . . . . . . . . . .39

2T2366GA . . . . . . . . . .39

2T2485GA . . . . . . . . . .38

2T2500GA . . . . . . . . . .38

2T308A ............39

2T511GA . . . . . . . . . .38

6ET1398GA . . . . . . . . .39

AG2401C . . . . . . . . . .119

AG2401C-IND . . . . . .119

AG2403C . . . . . . . . . .119

AG2803C . . . . . . . . . .119

AG4801 . . . . . . . . . .119

AG4803C . . . . . . . . . .119

AG6503C . . . . . . . . . .119

AG6503C-IND . . . . . .119

AG6503L . . . . . . . . . .119

AL10210 . . . . . . . . . . .61

AL102-5C . . . . . . . . . .61

AL111 . . . . . . . . . . . .61

AL115 . . . . . . . . . . . .61

AL1160 . . . . . . . . . . . .61

AL12210 . . . . . . . . . . .61

AL122-5C . . . . . . . . . .61

AL300BW . . . . . . . . . .60

AL300MTW . . . . . . . . .60

AL300RTW . . . . . . . . .59

AL300TPWS . . . . . . . .59

AL375V . . . . . . . . . . .61

AL380C . . . . . . . . . . .61

AL385V . . . . . . . . . . .61

AL395 . . . . . . . . . . . .61

AL395V . . . . . . . . . . .61

AL401 . . . . . . . . . . . .61

AL402 . . . . . . . . . . . .61

AL402TA . . . . . . . . . . .61

AL403 . . . . . . . . . . . .61

AL403TA . . . . . . . . . . .61

AL405 . . . . . . . . . . . .62

AL405V . . . . . . . . . . .62

AL406 . . . . . . . . . . . .62

AL406TA . . . . . . . . . . .62

AL407TA . . . . . . . . . . .62

AL408TA ...........62

AL409 . . . . . . . . . . . .62

AL409TA . . . . . . . . . . .62

AL425C . . . . . . . . . . .62

AL501 . . . . . . . . . . . .62

AL502 . . . . . . . . . . . .62

AL502DS . . . . . . . . . .62

AL502TA ...........63

AL506 . . . . . . . . . . . .63

AL508V . . . . . . . . . . .63

AL510V . . . . . . . . . . .63

AL521 . . . . . . . . . . . .63

AL550 . . . . . . . . . . . .63

AL550DS . . . . . . . . . .63

AL550TA ...........63

AL600MTW . . . . . . . . .60

AL600TPWS . . . . . . . .59

AL600TW . . . . . . . . . .59

AL60TW . . . . . . . . . . .60

AL8-12 . . . . . . . . . . . .61

AL900TPWS . . . . . . . .59

AL900TW . . . . . . . . . .59

C8815 . . . . . . . . . . . .30

C8835 . . . . . . . . . . . .30

C8845 . . . . . . . . . . . .30

C8865 . . . . . . . . . . . .30

C8866 . . . . . . . . . . . .30

CA3000 . . . . . . . . .56, 57

CA3500 . . . . . . . . .56, 57

CA3750 . . . . . . . . .56, 57

CA5000 . . . . . . . . .56, 57

CA5100 . . . . . . . . .56, 57

CA5500BR . . . . . . .56, 57

CA600 . . . . . . . . . .56, 57

CA7100 . . . . . . . . .56, 57

CA9000 . . . . . . . . .56, 57

CL1 . . . . . . . . . . . . .134

CL111R . . . . . . . . . .134

CL115 . . . . . . . . . . . .134

CL191 . . . . . . . . . . . .134

CL191K . . . . . . . . . . .134

CL191S . . . . . . . . . . .134

CL191V . . . . . . . . . . .134

CL280 . . . . . . . . . . . .134

CL305P ...........134

CL4 . . . . . . . . . . . . .134

CL501 . . . . . . . . . . . .134

CL503TA . . . . . . . . . .134

CL507 . . . . . . . . . . . .135

CL508 . . . . . . . . . . . .135

CL509 . . . . . . . . . . . .135

CL635P . . . . . . . . . . .135

CL635R . . . . . . . . . .135

CL635RK . . . . . . . . . .135

CL635RS . . . . . . . . . .135

CL711 . . . . . . . . . . . .135

CL801BC8 . . . . . . . . .135

CL802BSB6 . . . . . . . .135

CL802P7 . . . . . . . . . .135

CL803S2 . . . . . . . . . .135

CL8041 . . . . . . . . . . .136

CL9 . . . . . . . . . . . . .136

CL905 . . . . . . . . . . . .136

CL905K . . . . . . . . . . .136

CL9S . . . . . . . . . . . .136

CP150HPS . . . . . . . . .66

CS110P . . . . . . . . . .132

CS110TA . . . . . . . . . .132

CS120TA . . . . . . . . . .132

CS140K . . . . . . . . . .132

CS14P . . . . . . . . . . .132

CS17K . . . . . . . . . . .132

CS180C . . . . . . . . . .132

CS200C . . . . . . . . . .132

CS230R . . . . . . . . . .132

CS240 . . . . . . . . . . .132

CS330OB . . . . . . . . .132

CS508K . . . . . . . . . .132

CS508P . . . . . . . . . .133

CS508S . . . . . . . . . .133

CS508TA . . . . . . . . . .133

CS7AC1 . . . . . . . . . .133

CS7CT4 . . . . . . . . . .133

CS7E1 . . . . . . . . . . .133

DD150HPS . . . . . . . . .65

DD175MV . . . . . . . . . .65

DT121C . . . . . . . . . .125

DT17C . . . . . . . . . . .125

DT27C . . . . . . . . . . .125

E1010 . . . . . . . . . . . . .51

E1020 . . . . . . . . . . . . .51

E1120 . . . . . . . . . . . . .51

E1220 . . . . . . . . . . . . .51

E1221 . . . . . . . . . . . . .51

EH10 . . . . . . . . . . . . .37

EH40 . . . . . . . . . . . . .37

EI200 . . . . . . . . . . . . .50

EI200LA . . . . . . . . . . .50

EI200W . . . . . . . . . . .50

EI210 . . . . . . . . . . . . .50

EI205 . . . . . . . . . . . . .50

EI205W . . . . . . . . . . .50

EI205LA . . . . . . . . . . .50

EI215 . . . . . . . . . . . . .50

EI215W . . . . . . . . . . .50

EI215LA . . . . . . . . . . .50

EI210 . . . . . . . . . . . . .50

EI210LA . . . . . . . . . . .50

EI210W . . . . . . . . . . .50

EI220 . . . . . . . . . . . . .50

EI220LA . . . . . . . . . . .50

EI220W . . . . . . . . . . .50

EI230 . . . . . . . . . . . . .50

EI230LA . . . . . . . . . . .50

EI230W . . . . . . . . . . .50

EI500C . . . . . . . . . . . .53

EI500LAC . . . . . . . . . .53

EI500WC . . . . . . . . . . .53

EI600C . . . . . . . . . . . .51

EI600WC . . . . . . . . . . .51

EI600LAC . . . . . . . . . .51

EJ351C . . . . . . . . . . .126

EJ500AC . . . . . . . . . .126

EJ500C . . . . . . . . . . .126

ET100C . . . . . . . . . . . .40

ET100CM . . . . . . . . . .40

ET101C ............40

ET102C . . . . . . . . . . . .40

ET103C . . . . . . . . . . . .40

ET104C . . . . . . . . . . . .40

ET104CP . . . . . . . . . . .40

ET105C . . . . . . . . . . . .40

ET171C . . . . . . . . . . . .41

ET171CR . . . . . . . . . .41

ET173C . . . . . . . . . . . .41

ET174C . . . . . . . . . . . .41

ET175C . . . . . . . . . . . .41

ET279C . . . . . . . . . . . .41

ET70115C . . . . . . . . . .43

ET70115CR . . . . . . . . .43

ET70115CR24 . . . . . . .43

ET70215C . . . . . . . . . .43

ET70215CR . . . . . . . . .43

ET70215CR24 . . . . . . .43

ET70415CR . . . . . . . . .44

ET70415CR24 . . . . . . .44

ET70815CR . . . . . . . . .44

ET70815CR24 . . . . . . .44

ET71615CR . . . . . . . . .44

ET71615CR24 . . . . . . .44

ET7232M . . . . . . . . . .45

ET7232M1 . . . . . . . . .45

ET8015C . . . . . . . . . . .42

ET8015CPD82 . . . . . . .42

ET8015CR . . . . . . . . . .42

ET8115C . . . . . . . . . . .42

ET8115CPD82 . . . . . . .42

ET8115CR . . . . . . . . . .42

ET8215C . . . . . . . . . . .42

ET8215CPD82 . . . . . . .42

ET8215CR . . . . . . . . . .42

FD12HC . . . . . . . . . . .48

FD12HH . . . . . . . . . . .48

FD12HHW . . . . . . . . . .48

FD12HWC . . . . . . . . . .48

FD15MAC . . . . . . . . . .48

FD15MC . . . . . . . . . . .48

FD15MH . . . . . . . . . . .48

FD15MHW . . . . . . . . .48

FD15MWC . . . . . . . . .48

FD2H . . . . . . . . . . . . .48

FD2HW . . . . . . . . . . . .48

FD30MAC . . . . . . . . . .48

FD30MC . . . . . . . . . . .48

FD30MH . . . . . . . . . . .48

FD30MHW . . . . . . . . .48

FD30MWC . . . . . . . . .48

FD312HW . . . . . . . . . .48

FD32H . . . . . . . . . . . .48

FD32HW . . . . . . . . . . .48

FD34H . . . . . . . . . . . .48

FD34HW . . . . . . . . . . .48

FD36H . . . . . . . . . . . .48

FD36HW . . . . . . . . . . .48

FD415M . . . . . . . . . . .48

FD430M . . . . . . . . . . .48

FD430MW . . . . . . . . . .48

FD460M . . . . . . . . . . .48

FD460MW . . . . . . . . . .48

FD46H . . . . . . . . . . . .48

FD46HW . . . . . . . . . . .48

FD4H . . . . . . . . . . . . .48

FD4HW . . . . . . . . . . . .48

FD5M . . . . . . . . . . . . .48

FD5MW . . . . . . . . . . .48

FD60HH . . . . . . . . . . .48

FD60MAC . . . . . . . . . .48

FD60MC . . . . . . . . . . .48

FD60MH . . . . . . . . . . .48

FD60MHW . . . . . . . . .48

FD60MWC . . . . . . . . .48

FD6H . . . . . . . . . . . . .48

FD6HHW . . . . . . . . . . .48

FD6HW . . . . . . . . . . . .48

FF12HC . . . . . . . . . . .49

FF12HHC . . . . . . . . . .49

FF15MC . . . . . . . . . . .49

FF15MH . . . . . . . . . . .49

FF2H .............49

FF30MC . . . . . . . . . . .49

FF30MH . . . . . . . . . . .49

FF312H . . . . . . . . . . .49

FF312HH . . . . . . . . . .49

FF315M . . . . . . . . . . .49

FF32H . . . . . . . . . . . .49

FF32HH . . . . . . . . . . .49

FF330M . . . . . . . . . . .49

FF34H . . . . . . . . . . . .49

FF34HH . . . . . . . . . . .49

FF360M . . . . . . . . . . .49

FF36H . . . . . . . . . . . .49

FF412H . . . . . . . . . . .49

FF415M . . . . . . . . . . .49

FF430M . . . . . . . . . . .49

FF460M . . . . . . . . . . .49

FF46H . . . . . . . . . . . .49

FF4H . . . . . . . . . . . . .49

FF5M . . . . . . . . . . . . .49

FF5MH . . . . . . . . . . . .49

FF60MC . . . . . . . . . . .49

FF60MHC . . . . . . . . . .49

FF6H . . . . . . . . . . . . .49

FF6HH . . . . . . . . . . . .49

FL035HPS . . . . . . . . . .65

FL050HPS . . . . . . . . . .65

FL050MH . . . . . . . . . .65

FL070HPS . . . . . . . . . .65

FL070MH . . . . . . . . . .65

FL100HPS . . . . . . . . . .65

FL100MH . . . . . . . . . .65

FL150HPS . . . . . . . . . .65

FL150MH . . . . . . . . . .65

FL150Q . . . . . . . . . . .66

FL175MH . . . . . . . . . .65

FL250HPS . . . . . . . . . .65

FL250MH . . . . . . . . . .65

FL300Q . . . . . . . . . . .66

FL400HPS . . . . . . . . . .65

FL400MH . . . . . . . . . .65

FL500Q . . . . . . . . . . .66

HA01C . . . . . . . . . . .123

HA02C . . . . . . . . . . .123

HA03C . . . . . . . . . . .123

HA04C . . . . . . . . . . .123

HA05C . . . . . . . . . . .124

HA06C . . . . . . . . . . .124

HA07 . . . . . . . . . . . .124

HA09C . . . . . . . . . . .124

HB1116R . . . . . . . . .128

HB112C . . . . . . . . . .126

HB113C . . . . . . . . . .126

HB114C . . . . . . . . . .126

HB31R . . . . . . . . . . .127

HB35R . . . . . . . . . . .127

HB51RC . . . . . . . . . .127

HB61RC . . . . . . . . . .127

HB77RC . . . . . . . . . .128

HB88RC . . . . . . . . . .128

IG11246 . . . . . . . . . .114

IG11266 . . . . . . . . . .114

IG11266BLK10 . . . . . .114

IG11466 . . . . . . . . . .114

IG1201EH . . . . . . . . .101

Product Index

IG1201F20 . . . . . . . .113

IG1201LH . . . . . . . . .103

IG1240FMP3 . . . . . . .116

IG1240RC . . . . . . . . .116

IG1300-2T-1C . . . . . .116

IG1300-4T-2C . . . . . .116

IG141 . . . . . . . . . . . .114

IG141T . . . . . . . . . . .114

IG143 . . . . . . . . . . . .114

IG143T . . . . . . . . . . .114

IG1866A . . . . . . . . . .114

IG1C . . . . . . . . . . . . .118

IG1C3R . . . . . . . . . . .118

IG1CM . . . . . . . . . . .118

IG1SRMP . . . . . . . . .115

IG2012B15 . . . . . . . .114

IG20615 . . . . . . . . . .114

IG2066 . . . . . . . . . . .114

IG2083ECY . . . . . . . . .99

IG2083LYH . . . . . . . .103

IG2083YECA . . . . . . . .98

IG2083YEH . . . . . . . .101

IG2086 . . . . . . . . . . .114

IG20B12 . . . . . . . . . .114

IG2401ECS . . . . . . . . .99

IG2401EH . . . . . . . . .101

IG2401F20 . . . . . . . .113

IG2401LH . . . . . . . . .103

IG2401SECA . . . . . . . .98

IG2403DECA . . . . . . . .98

IG2403DEH . . . . . . . .101

IG2403ECD . . . . . . . . .99

IG2403LDH . . . . . . . .103

IG250LA . . . . . . . . . .120

IG251 . . . . . . . . . . . .117

IG2T . . . . . . . . . . . . .118

IG2T3R . . . . . . . . . . .117

IG2TM . . . . . . . . . . .117

IG3240FMP3 . . . . . . .116

IG3240RC .........116

IG4803DECA . . . . . . . .98

IG4803DEH . . . . . . . .101

IG4803ECD .........99

IG4803ECY . . . . . . . . .99

IG4803LDH . . . . . . . .103

IG4803LYH . . . . . . . .103

IG4803YECA . . . . . . . .98

IG4803YEH ........101

IG4TM . . . . . . . . . . .117

IG9638S55 ........114

IGFLUSH MOUNT KIT .118

K1121 . . . . . . . . . . . .24

K1122 . . . . . . . . . . . .24

K1221 . . . . . . . . . . . .24

K1222 . . . . . . . . . . . .24

K4021C . . . . . . . . . . .21

K4022 . . . . . . . . . . . .21

K4023C . . . . . . . . . . .21

K4024 . . . . . . . . . . . .21

K4027 . . . . . . . . . . . .21

K4033 . . . . . . . . . . . .21

K4035 . . . . . . . . . . . .21

K4121C . . . . . . . . . . .22

K4121M . . . . . . . . . . .22

K4122 . . . . . . . . . . . .22

K4123C . . . . . . . . . . .22

K4123M . . . . . . . . . . .22

K4124 . . . . . . . . . . . .22

K4127 . . . . . . . . . . . .22

K4133 . . . . . . . . . . . .22

K4135 . . . . . . . . . . . .22

K4136M . . . . . . . . . . .22

K4141C . . . . . . . . . . .22

K4221C . . . . . . . . . . .22

K4222 . . . . . . . . . . . .22

K4223C . . . . . . . . . . .22

K4224 . . . . . . . . . . . .22

K4233 . . . . . . . . . . . .22

K4235 . . . . . . . . . . . .22

K4236C . . . . . . . . . . .22

K4251 . . . . . . . . . . . .22

K4253 . . . . . . . . . . . .22

K4321C . . . . . . . . . . .21

K4421M . . . . . . . . . . .22

K4423M . . . . . . . . . . .22

K4521 . . . . . . . . . . . .23

K4522 . . . . . . . . . . . .23

K4524 . . . . . . . . . . . .23

K4533 . . . . . . . . . . . .23

K4535 . . . . . . . . . . . .23

K4536SS . . . . . . . . . .25

K4536SST . . . . . . . . . .25

LC2000 . . . . . . . . . . . .24

LC4521C . . . . . . . . . . .23

LC4521LA . . . . . . . . . .23

LC4523 . . . . . . . . . . . .23

LC4523LA . . . . . . . . . .23

LC4527 . . . . . . . . . . . .23

LC4535 . . . . . . . . . . . .23

LC4535LA . . . . . . . . . .23

LC4536LAC . . . . . . . . .23

LC4536C . . . . . . . . . . .23

LD622 . . . . . . . . . . .138

LD622L . . . . . . . . . . .138

LD641 . . . . . . . . . . .138

LT10 . . . . . . . . . . . . .136

LT13 . . . . . . . . . . . . .136

LT13N . . . . . . . . . . . .136

LT13S . . . . . . . . . . . .136

LT406 . . . . . . . . . . . .137

LT406N . . . . . . . . . . .137

LT8K . . . . . . . . . . . . .136

LT9 . . . . . . . . . . . . .136

LV103 . . . . . . . . . . . .138

LV108 . . . . . . . . . . . .138

LV181 . . . . . . . . . . . .138

LV183 . . . . . . . . . . . .138

LX1 . . . . . . . . . . . . .138

LX703 . . . . . . . . . . . .142

LX9Z . . . . . . . . . . . .138

LZ1 .............141

LZ10130 . . . . . . . . . .141

LZ10131 . . . . . . . . . .141

LZ10131P . . . . . . . . .141

LZ11101OB . . . . . . . .139

LZ11101P . . . . . . . . .139

LZ11101RB . . . . . . . .139

LZ11101V . . . . . . . . .140

LZ11771H . . . . . . . . .140

LZ11771HK . . . . . . . .140

LZ13RP4 . . . . . . . . . .144

LZ14001H . . . . . . . . .140

LZ14001HP . . . . . . . .140

LZ15004 . . . . . . . . . .144

LZ16220 . . . . . . . . . .143

LZ16551 . . . . . . . . . .144

LZ191 . . . . . . . . . . . .139

LZ191K . . . . . . . . . . .139

LZ1W . . . . . . . . . . . .141

LZ1WU . . . . . . . . . . .144

LZ20601P . . . . . . . . .142

LZ21811K .........140

LZ230 . . . . . . . . . . . .140

LZ280RP4 . . . . . . . . .144

LZ3 .............141

LZ302 . . . . . . . . . . . .141

LZ303RB . . . . . . . . . .143

LZ305FP . . . . . . . . . .143

LZ305P . . . . . . . . . . .139

LZ306 ............144

LZ307 . . . . . . . . . . . .144

LZ308 ............144

LZ310 . . . . . . . . . . . .143

LZ312 . . . . . . . . . . . .142

LZ313 . . . . . . . . . . . .144

LZ314 . . . . . . . . . . . .143

LZ3W . . . . . . . . . . . .141

LZ406 . . . . . . . . . . . .140

LZ407 . . . . . . . . . . . .140

LZ413 . . . . . . . . . . . .142

LZ413RP4 . . . . . . . . .142

LZ414 . . . . . . . . . . . .142

LZ415 . . . . . . . . . . . .142

LZ419 . . . . . . . . . . . .143

LZ418 . . . . . . . . . . . .140

LZ422WBR . . . . . . . .140

LZ422W . . . . . . . . . .140

LZ4H . . . . . . . . . . . .141

LZ4HW . . . . . . . . . . .141

LZ4HWGR . . . . . . . . .141

LZ4M . . . . . . . . . . . .141

LZ4MK . . . . . . . . . . .141

LZ4MOB . . . . . . . . . .141

LZ501RP4 . . . . . . . . .144

LZ511A . . . . . . . . . . .143

LZ511B . . . . . . . . . . .143

LZ511C . . . . . . . . . . .143

LZ511R . . . . . . . . . . .143

LZ51GR . . . . . . . . . .139

LZ53RP4 . . . . . . . . . .144

LZ6 . . . . . . . . . . . . .141

LZ601 . . . . . . . . . . . .139

LZ602 . . . . . . . . . . . .139

LZ603 . . . . . . . . . . . .139

LZ604B . . . . . . . . . . .143

LZ635RP4 . . . . . . . . .144

LZ701 . . . . . . . . . . . .142

LZ701W . . . . . . . . . .142

LZ702 . . . . . . . . . . . .142

LZ702W . . . . . . . . . .142

LZ703W . . . . . . . . . .142

LZ704 . . . . . . . . . . . .142

LZ704W . . . . . . . . . .142

LZ705 . . . . . . . . . . . .142

LZ7052 . . . . . . . . . . .142

LZ706 . . . . . . . . . . . .143

LZ7CT4 . . . . . . . . . . .139

LZ7FC4 . . . . . . . . . . .139

LZ7Z6 . . . . . . . . . . . .139

LZ90004 . . . . . . . . . .144

LZB1 . . . . . . . . . . . .144

ML100T . . . . . . . . . .138

ML10401 . . . . . . . . .138

ML10781 . . . . . . . . .138

ML11183 . . . . . . . . .138

ML121RT . . . . . . . . .138

ML200RT . . . . . . . . .138

ML200RTW . . . . . . . .138

ML300RTW . . . . . . . .138

ML44T . . . . . . . . . . .138

ML600TW . . . . . . . . .138

ML60704 . . . . . . . . .138

ML60721 . . . . . . . . .138

ML60722 . . . . . . . . .138

ML60TW . . . . . . . . . .138

ML88T . . . . . . . . . . .138

ML900TW . . . . . . . . .138

ML90401 . . . . . . . . .138

ML90708 . . . . . . . . .138

ML91103 . . . . . . . . .138

MZ101 . . . . . . . . . . .145

MZ102 . . . . . . . . . . .145

MZ105 . . . . . . . . . . .145

MZ204G . . . . . . . . . .145

MZ301 . . . . . . . . . . .145

MZ501 . . . . . . . . . . .145

MZ902 . . . . . . . . . . .145

MZ904 . . . . . . . . . . .145

MZ951 . . . . . . . . . . .145

MZ952 . . . . . . . . . . .145

MZ953 . . . . . . . . . . .145

NA401 . . . . . . . . . . .133

NA501 . . . . . . . . . . .133

NE1C . . . . . . . . . . . .129

NE200C . . . . . . . . . .129

NE250C . . . . . . . . . .129

NE2C . . . . . . . . . . . .129

NE3BC . . . . . . . . . . .129

NE5C . . . . . . . . . . . .129

P1101 . . . . . . . . . . . .85

P1102FE . . . . . . . . . .83

P1102ME . . . . . . . . . .83

P1103FE . . . . . . . . . .83

P1103ME ..........83

P1121 . . . . . . . . . . . .85

P1131 . . . . . . . . . . . .85

P1161 ............85

P1203FR . . . . . . . . . .83

P1261P . . . . . . . . . . .85

P1261PE . . . . . . . . . . .85

P1353ME . . . . . . . . . .70

P171-30 ...........28

P4243ME . . . . . . . . . .71

P7101ME ..........83

P7102ME . . . . . . . . . .83

P7103ME . . . . . . . . . .83

PA114 . . . . . . . . . . . .86

PAV215 . . . . . . . . . . .86

PAV215C . . . . . . . . . . .86

PAV220 . . . . . . . . . . .86

PAV220C . . . . . . . . . . .86

PAV315 . . . . . . . . . . .86

PAV315C . . . . . . . . . . .86

PAV320 . . . . . . . . . . .86

PAV320C . . . . . . . . . . .86

PE1501RC . . . . . . . . . .73

PE153 . . . . . . . . . . . .72

PE153F . . . . . . . . . . . .72

PE153P . . . . . . . . . . .72

PE153PF . . . . . . . . . . .72

PE153PW . . . . . . . . . .72

PE153PWF . . . . . . . . .72

PE153W . . . . . . . . . . .72

PE153WF . . . . . . . . . .72

PE1541RC . . . . . . . . . .73

PE24VA . . . . . . . . . . .86

PE25300 . . . . . . . . . . .73

PE25K120V . . . . . . . . .69

PE25K240V . . . . . . . . .69

PE40K120V . . . . . . . . .69

PE40K240V . . . . . . . . .69

PE45343RC . . . . . . . . .68

PE45343RCT1 . . . .68, 78

PE45343RCT3 . . . .68, 78

PE650 . . . . . . . . . . . .68

PE950 . . . . . . . . . . . .68

PEDCELL . . . . . . . . . .69

PEDCHLR . . . . . . . . . .69

PF1102 . . . . . . . . . . . .80

PF1102M . . . . . . . . . .80

PF1102MT . . . . . . . . .80

PF1102T . . . . . . . . . . .80

PF1103 . . . . . . . . . . . .80

PF1103M . . . . . . . . . .80

PF1103MT . . . . . . . . .80

PF1103T . . . . . . . . . . .80

PF1112T . . . . . . . . . . .81

PF1202T . . . . . . . . . . .81

PF1222TB . . . . . . . . . .81

PG1000-208-3Y . . . . .105

PG1000-240-2S . . . . .105

PG1000-480-3D . . . . .105

PG1000-480-3Y . . . . .105

PG100-208-3Y . . . . . . .93

PG100-240-2S . . . . . . .93

PG100-240-3HLD . . . . .93

PG100-480-3DLL . . . . .93

PG100-480-3Y . . . . . . .93

PG1500-208-3Y . . . . .104

PG1500-240-2S . . . . .104

PG1500-480-3D . . . . .104

PG1500-480-3Y . . . . .104

PG20-208-3Y . . . . . . .102

PG20-240-2S . . . . . . .102

PG20-240-3HLD . . . . .102

PG20-480-3D . . . . . . .102

PG20-480-3Y . . . . . . .102

PG3000-208-3Y . . . . . .96

PG3000-240-2S . . . . . .96

PG3000-240-3HLD . . . .96

PG3000-480-3DLL . . . .96

PG3000-480-3Y . . . . . .96

PG3000-600-3D . . . . . .96

PG3000-600-3Y . . . . . .96

PG3500-208-3Y . . . . . .94

PG3500-240-2S . . . . . .94

PG3500-240-3HLD . . . .94

PG3500-480-3DLL . . . .94

PG3500-480-3Y . . . . . .94

PG3500-600-3D . . . . . .94

PG3500-600-3Y . . . . . .94

PG4001-208-3Y . . . . . .92

PG4001-240-2S . . . . . .92

PG4001-240-3HLD . . . .92

PG4001-480-3DLL . . . .92

PG4001-480-3Y . . . . . .92

PG4001-600-3D . . . . . .92

PG4001-600-3Y . . . . . .92

PG40-240-2S . . . . . . .100

PG40-208-3Y . . . . . . .100

PG40-240-3HLD . . . . .100

PG40-480-3D . . . . . . .100

PG40-480-3Y . . . . . . .100

PG4501-208-3Y . . . . . .91

PG4501-240-2S ......91

PG4501-240-3HLD . . . .91

PG4501-480-3DLL . . . .91

PG4501-480-3Y ......91

PG4501-600-3D . . . . . .91

PG4501-600-3Y . . . . . .91

PG5001-208-3Y . . . . . .90

PG5001-240-2S . . . . . .90

PG5001-240-3HLD ....90

PG5001-480-3DLL . . . .90

PG5001-480-3Y ......90

PG5001-600-3D . . . . . .90

PG5001-600-3Y . . . . . .90

PG60-208-3Y . . . . . . . .97

PG60-240-2S . . . . . . . .97

PG60-240-3HLD . . . . . .97

PG60-480-3DLL . . . . . .97

PG60-480-3Y . . . . . . . .97

PG80-208-3Y . . . . . . . .95

PG80-240-2S . . . . . . . .95

PG80-240-3HLD . . . . . .95

PG80-480-3DLL . . . . . .95

PG80-480-3Y . . . . . . . .95

PJB2175 . . . . . . . . . . .86

PJB4175 . . . . . . . . . . .86

PR3C . . . . . . . . . . . .129

PX100 . . . . . . . . . . . .79

PX100S . . . . . . . . . . .79

PX300 . . . . . . . . . . . .79

PX300S . . . . . . . . . . .79

PX600 . . . . . . . . . . . .79

PX600S . . . . . . . . . . .79

R8806P101C . . . . . . . .31

R8815P101C . . . . . . . .31

R8816P101C . . . . . . . .31

RC2163BE . . . . . . . . . .82

RC2163BFE . . . . . . . . .82

RC2163E . . . . . . . . . .82

RC2163FE . . . . . . . . . .82

RC2263BE . . . . . . . . . .82

RC2263E . . . . . . . . . .82

RC2403RT . . . . . . . . .82

RC613 . . . . . . . . . . . .84

RC613L . . . . . . . . . . .84

RC613R . . . . . . . . . . .84

RC615 . . . . . . . . . . . .84

RC939 . . . . . . . . . . . .84

SC240 . . . . . . . . . . .132

SG160K-208-3Y . . . . .109

SG160K-240-3HLD . . .109

SG160K-480-3D . . . . .109

SG160K-480-3Y . . . . .109

SG240K-208-3Y . . . . .108

SG240K-240-3HLD . . .108

SG240K-480-3D . . . . .108

SG240K-480-3Y . . . . .108

SG320K-208-3Y . . . . .107

SG320K-240-3HLD . . .107

SG320K-480-3D . . . . .107

SG320K-480-3Y . . . . .107

SM2200*1 . . . . . . . . .46

SM2200*16 . . . . . . . .47

SM2200*2 . . . . . . . . .47

SM2200*3 . . . . . . . . .47

SM2200*4 . . . . . . . . .47

SM2200*5 . . . . . . . . .47

SM2200*6 . . . . . . . . .47

SM2200*7 . . . . . . . . .47

SM2200*8 . . . . . . . . .47

SM4400*1 . . . . . . . . .47

SM4400*10 . . . . . . . .47

SM4400*11 . . . . . . . .47

SM4400*12 . . . . . . . .47

SM4400*13 . . . . . . . .47

SM4400*14 . . . . . . . .47

SM4400*16 . . . . . . . .47

SM4400*2 . . . . . . . . .47

SM4400*3 . . . . . . . . .47

SM4400*4 . . . . . . . . .47

SM4400*5 . . . . . . . . .47

SM4400*6 . . . . . . . . .47

SM4400*7 . . . . . . . . .47

SM4400*8 . . . . . . . . .47

SM4400*9 . . . . . . . . .47

SM6600*1 . . . . . . . . .47

SM6600*10 . . . . . . . .47

SM6600*16 . . . . . . . .47

SM6600*2 . . . . . . . . .47

SM6600*3 . . . . . . . . .47

SM6600*4 . . . . . . . . .47

SM6600*5 . . . . . . . . .47

SM6600*6 . . . . . . . . .47

SM6600*7 . . . . . . . . .47

SM6600*8 . . . . . . . . .47

SM6600*9 . . . . . . . . .47

SP130B . . . . . . . . . .130

SP230B . . . . . . . . . .130

SP440B . . . . . . . . . .130

SP500 . . . . . . . . . . .130

SP640B . . . . . . . . . .130

ST01AC . . . . . . . . . .126

ST01C . . . . . . . . . . .126

T10000R ........39, 74

T10004R . . . . . . . .74, 78

T10004RT1 .........78

T10004RT3 .........78

T101 . . . . . . . . . . . . .26

T10101R . . . . . . . . . . .74

T101B . . . . . . . . . . . .26

T101P . . . . . . . . . . . .26

T101R ............26

T102 . . . . . . . . . . . . .26

T102P ............26

T102R . . . . . . . . . . . .26

T103 . . . . . . . . . . . . .26

T103P . . . . . . . . . . . .26

T103R . . . . . . . . . . . .26

T104 . . . . . . . . . . . . .26

T10404R . . . . . . . . . . .74

T104-20 . . . . . . . . . . .36

T104P . . . . . . . . . . . .26

T104R . . . . . . . . . . . .26

T105 . . . . . . . . . . . . .26

T10604R . . . . . . . . . . .74

T106R . . . . . . . . . . . .26

T12404R . . . . . . . . . . .74

T1471BCR . . . . . . . . . .27

T1471BR . . . . . . . . . .27

T1472BR . . . . . . . . . .27

T1475BR . . . . . . . . . .27

T171 . . . . . . . . . . . . .27

T171CR . . . . . . . . . . .27

T172 . . . . . . . . . . . . .27

T173 . . . . . . . . . . . . .27

T173CR . . . . . . . . . . .27

T173R . . . . . . . . . . . .27

T174 . . . . . . . . . . . . .27

T174CR . . . . . . . . . . .27

T174R . . . . . . . . . . . .27

T175 . . . . . . . . . . . . .27

T176 . . . . . . . . . . . . .27

T1871BR . . . . . . . . . .27

T1905 . . . . . . . . . . . . .29

T1905E . . . . . . . . . . . .29

T1906 . . . . . . . . . . . . .29

T1975 . . . . . . . . . . . . .29

T1975E . . . . . . . . . . . .29

T1975ER . . . . . . . . . . .29

T1975R . . . . . . . . . . .29

T1976 . . . . . . . . . . . . .29

T1976R . . . . . . . . . . .29

T20004R . . . . . . . . . . .75

T2005 . . . . . . . . . . . . .33

T2006 . . . . . . . . . . . . .33

T21000R . . . . . . . . . . .75

T21001R . . . . . . . . . . .75

T21004R . . . . . . . . . . .75

T30000R5 . . . . . . . . . .76

T30004R . . . . . . . . . . .76

T30000R . . . . . . . . . . .39

T30401R . . . . . . . . . . .76

T30404R . . . . . . . . . . .76

T30604R . . . . . . . . . . .76

T32404R . . . . . . . . . . .76

T40000R . . . . . . . .39, 77

T40000R4 . . . . . . . . . .77

T40003RT3 . . . . . . . . .78

T40004R5 . . . . . . . . . .77

T40004RSS . . . . . . . . .77

T40004RT1 . . . . . . . . .78

T40004RT3 . . . . . . . . .78

T40404R5 . . . . . . . . . .77

T51211BC . . . . . . . . . .32

T51311BC . . . . . . . . . .32

T7401B . . . . . . . . . . . .34

T7402B . . . . . . . . . . . .34

T7801B . . . . . . . . . . . .34

T7802B . . . . . . . . . . . .34

T8805P101C . . . . . . . .31

T8845PV . . . . . . . . . . .31

TB121C . . . . . . . . . . .125

TN111C . . . . . . . . . .125

TN111GC . . . . . . . . .125

TN311C . . . . . . . . . .125

TN711C . . . . . . . . . .125

TN811C . . . . . . . . . .125

TS100RS . . . . . . . . . .38

UG240R . . . . . . . . . .120

UG28A2083Y . . . . . . .112

UG28A2401S . . . . . . .112

UG28A2403D . . . . . . .112

UG28A4803D . . . . . . .112

UG28A4803Y . . . . . . .112

UG30A2083Y . . . . . . .111

UG30A2401S . . . . . . .111

UG30A2403D . . . . . . .111

UG30A2403G . . . . . . .111

UG30A4803D . . . . . . .111

UG30A4803Y . . . . . . .111

UG40A2083Y . . . . . . .110

UG40A2401S . . . . . . .110

UG40A2403D . . . . . . .110

UG40A2403G . . . . . . .110

UG40A4803D . . . . . . .110

UG40A4803Y .......110

V45471CR . . . . . . . . . .35

V45471R . . . . . . . . . .35

V45472CR ..........35

V45472R . . . . . . . . . .35

WH40 . . . . . . . . . . . . .36

WL035HPS . . . . . . . . .64

WL050HPS . . . . . . . . .64

WL050MH ..........64

WL070HPS . . . . . . . . .64

WL070HPSPC .......66

WL070MH . . . . . . . . . .64

WL100HPS . . . . . . . . .64

WL100MH . . . . . . . . . .64

WL150HPS . . . . . . . . .64

WL150MH . . . . . . . . . .64

WL175MH . . . . . . . . . .64

WL250HPS . . . . . . . . .64

WL250MH . . . . . . . . . .64

WL400HPS . . . . . . . . .64

WL400MH . . . . . . . . . .64

WP1000C . . . . . . . . . .19

WP1000GC . . . . . . . . .19

WP1000HC . . . . . .14, 19

WP1000HGC . . . . . . . .19

WP1000HRC . . . . . . . .16

WP1000RC . . . . . . . . .16

WP101 . . . . . . . . . . . .18

WP1010C . . . . . . . . . .19

WP1010HC . . . . . .14, 19

WP1010HMC . . . . .17, 19

WP1010MC . . . . . .17, 19

WP102 . . . . . . . . . . . .18

WP1020C . . . . . . .14, 19

WP103 . . . . . . . . . . . .18

WP1030C . . . . . . .14, 19

WP1030MC . . . . . .17, 19

WP1050 . . . . . . . .14, 19

WP107 . . . . . . . . . . . .18

WP1100C . . . . . . .14, 19

WP1100WC . . . . . . . . .19

WP1110C . . . . . . .14, 19

WP1110WC . . . . . . . . .19

WP1150C . . . . . . .14, 19

WP1220C . . . . . . .14, 19

WP1230C . . . . . . .14, 19

WP1250C . . . . . . .14, 19

WP17 . . . . . . . . . . . . .18

WP2000 . . . . . . . . . . .16

WP213 . . . . . . . . . . . .18

WP217 . . . . . . . . . . . .18

WP3100 . . . . . . . .14, 15

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Grounded in a tradition of innovation and service

In 1891, Intermatic began producing portable fare registers for

streetcars. Over the next 115 years, Intermatic developed a huge

variety of products that have increased the safety, productivity and

convenience of homes and businesses around the world.

Driven by new technology and the needs of our customers

Today, Intermatic is the leading supplier of high quality energy

control products for industrial and commercial markets — moving

into the 21st century with an extensive line of technology-driven

products backed by an unparalleled level of customer service.

Based on improving convenience and safety

Intermatic is committed to making life productive, convenient

and safe through the innovative use of electrical current.

Continual product innovation, creative marketing and effective

brand management makes Intermatic the most pioneering

company within the wholesale distribution channel.

Your total energy management solution

Through our family of products, Intermatic provides a total

solution for your energy management issues. Through our

family of expert sales, training and technical personnel,

Intermatic provides complete sales and marketing support.

Intermatic has everything contractors, maintenance personnel and plant or facility managers

need to keep their factories, centers and businesses running at their peak.

Commercial and Industrial Applications

For more than a century,Intermatic has been a premier supplier of commercial and industrial products and has

developed a reputation for providing its customers with innovative products that far exceed their expectations. The new InTouch

Wireless Controls™line of home controls will serve as the primary link to the Intermatic System. Brought to life with Z-Wave™

technology,InTouch Wireless Controls™will help our customers grow their business within the booming home controls industry

and will help home and business owners achieve higher levels of convenience, security and safety.

Intermatic Commercial and Industrial

Applications

• Interior and exterior lighting control

• Parking lot lighting control

• Mechanical time switches

• Electronic time switches

• Service entrance and panelboard surge

protection

• Point-of-use surge protection

• Exterior receptacle protection

• Landscape lighting

Intermatic has a full line of commercial and

industrial products needed to reduce

electricity and labor costs and decrease

power quality problems. Small investments

in Intermatic energy controls and surge

protection can:

• Increase energy savings

•Increase up-time

• Increase productivity

•Increase data retention

Whether it’s part of a manufacturing,

distribution or office environment,

Intermatic offers a broad line of

commercially related products for:

• High amperage/voltage machinery

• Heavy duty pumps

• Motors

• Variable frequency drives

• HVAC systems

In addition to a broad range of products,

Intermatic provides complete bid

specifications and wiring diagrams for every

model and each product is backed up by the

industry’sbest sales support and technical

assistance team.

Z-WAVE™

Whether you’re an electrical contractor, homebuilder or homeowner, Intermatic is the only name

you need to know for increased levels of convenience, safety, security and electronic protection.

Residential Applications

The future of the digital home is closer than we realize. Intermatic has a growing list of home control products that

work together to enhance the safety, security and convenience of our complex and eventful lives. Intermatic has the knowledge,

ability and resources to revolutionize home automation.

Intermatic Residential Applications

• Interior and exterior lighting control

• Whole home energy controls

• Whole home surge protection

• Home office and home theatre surge

protection

• Pool and spa controls

• Landscape lighting

• Exterior receptacle protection

• Security floodlighting

With electricity costs on the rise and power

quality problems at an all time high,

Intermatic has a full line of residential

products needed to combat these issues. A

minor investment in energy controls and

surge protection can prove to have major

long-term cost savings and home

appliance/electronic preservation. Intermatic

residential products provide homeowners

with multiple benefits, including:

•Whole home energy savings

• Lighting automation to increase the

beauty,Safety and security of your home

• Surge protection for home appliances and

electronics

• Landscape lighting to accent your home

and property

• Pool and spa controls for improved cost

savings and convenience

Intermatic provides the home building

industry with the most comprehensive

offering of residential energy control and

surge protection products. Intermatic also

offers weatherproof products, pool and spa

controls and low voltage landscape lighting.

Intermatic products can be used through a

home and the surrounding property,

including:

• Garages and outbuildings

•Landscaping

• Entrances

• Kitchens and bathrooms

• Home offices and entertainment centers

• Pool and spas

Intermatic has developed two marketing

programs to benefit those within the

residential market:

•Intermatic Authorized Installer

Program helps contractors up-sell during

aservice call.

•InGenius Homebuilder Program helps

builders of new homes increase their

add-on opportunities.

Z-WAVE™

Intermatic provides you with everything you

need in order to draw, secure and maintain

steady sales growth

Opportunities include:

• Advanced Sales Support

• Sales Incentives

• Sales Training

• Sales Programs and Promotions

• Merchandising

• Interactive Web Site

The Industry’s Best Sales Support

Our distributor sales training includes ways to best

merchandise and up-sell our wide array of products.

Training takes place at local, regional and national trade

shows. In addition, Intermatic holds regular counter days

and product “lunch and learns,” hosted by our direct

sales personnel and sales agents, on location at local

distributors.

Call 800-391-4555 for toll-free technical support and

assistance with programming, installation or application

questions. Intermatic also works with engineers and

specifiers and holds seminars for them on InTouch

Wireless Controls™, surge supression products and Next

Generation time switches. Contact your local Intermatic

sales representative or visit www.intermatic.com.

Intermatic’s order service support is set up to allow

distributors and OEM customers to receive product

when, where and how they want it. Drop shipments,

multi-location shipments, blanket orders, express

shipping and ship complete orders are complemented by

avariety of other order support services. Our highly

trained customer service representatives can also provide

you with support for technical questions and applications

by calling 815-675-7000 between 8:00 a.m. and 4:30

p.m. CST, Monday through Friday.

Customized Sales Incentives

Regular sales spiffs for sales and

counter personnel are designed to

motivate the seller and push product at

every level. Customized sales support

literature can also be designed for local

made-to-order programs.

Comprehensive Sales Training

Providing you with the industry’s best

electrical products is step one. Helping

you get those products into the hands

of your customer is step two. The best

way to make that happen is to supply

you with specific information on how

to sell and up-sell within our five

categories of products. On site or at the

counter,Intermatic gives you the

answers to frequently asked questions

and provides you with good, better and

best scenarios and competitive compar-

isons in order to help you help your

customers make the best buying

decision.

Motivational Sales Programs and

Promotions

Intermatic is a total business partner

and backs the sale of its products with

innovative programs and promotions at

every level, with support provided to

distributors, contractors and home

builders.

• The Power-Plus Program for

distributors increases their margins

and inventory turns while lowering

their transaction costs.

• The Authorized Installer Program

helps contractors add to their bottom

line by up-selling and installing

additional products during service

calls.

• The InGenius Program helps home

builders sell upgrades at model

homes and in the sales office.

Intermatic also provides a regular

selection of promotions that include

shipper/displays, product introductions,

contractor bonus packs and Intermatic

branded merchandise.

Thought-provoking Merchandising

Eighty percent of walk-in customers

will buy additional products, if

merchandising is done effectively.

Sixty-five percent of all purchases are

affected by displays and visual

graphics. That is why Intermatic has

invested heavily in merchandising

resources in order to boost your return

on investment. Intermatic’sIndustrial

Merchandising program provides you

with the support and information you

need to achieve maximum results,

increase impulse purchases and build

effective displays.

Merchandising items include:

• Plan-o-grams

• Header cards

• Floor, wall and counter displays

• Self shipper displays

• P.O.P. displays

• Countermats

• Banners

• Spec and cross reference CDs

•Product demo and literature CDs

Interactive Web Site Marketing

Intermatic’s e-marketing program

utilizes the Internet to provide fast,

efficient, 24/7 communications with

both distributors and end users.

Intermatic’sWeb site includes:

• Authorized distributor locator

• Authorized installer locator

•Downloadable specifications, wiring

diagrams and instruction manuals

•E-mail technical support

• General catalog (downloadable PDF)

• Warranty registration

In the future, a variety of

enhancements will be implemented that

will include improved navigation,

product search by category or model

number, competitive product search,

ordering of product literature and an

events/news page. Also, a new

secured-access distributor intranet will

provide additional product education

and sales training, distributor spec

sheets, pricing and promotions, a

job-quoting tool and a discussion

board.

Intermatic Merchandising/Support

For more information on Intermatic sales support, programs and promotions, contact your

local Intermatic sales representative, visit www.intermatic.com or call 815-675-7000

between 8:00 a.m. and 4:30 p.m. CST, Monday through Friday.

Five reasons to keep your eye on Intermatic

Superior New Product Developments

Intermatic is able to leverage its global and technological

resources to provide its customers with products full of

innovative features and benefits and maintain its

first-to-market stature.

World-class Global Manufacturing

The Intermatic family is made up of a global workforce, who

through lean manufacturing methods, produce the world’s

finest energy control products.

Excellent Supply Chain Management

Regardless of its substantial growth, Intermatic has remained

flexible and responsive and completely customer focused. At

Intermatic, intensive quality control and on-time deliveries are

customary.

Complete Sales and Marketing Support

Over the course of the year, Intermatic helps promote its

products through a variety of sales incentives, promotions and

merchandising campaigns. We also offer distributor training

and technical support at every level.

Superior Enterprise Information Systems

Flexible, Web-based information gives us a competitive

advantage and real-time information keeps us up to date to

help take better care of our customers.

Your Outdoor Needs are Covered

Often times, the simplest things in life

make the biggest impact. Intermatic

understands that simple measures

can have a big effect in protecting

the electrical systems and

products within your home or

business.

Intermatic has designed a

line of hard wearing

weatherproof products that

provide an exact match to

the application, are easy

to install and provide

reliability and longevity.

Our full line of

weatherproof products

are the perfect

combination of utility

and innovation. From

our patented Flexi-Guard

covers to our heavy duty

die-cast outlet boxes, lamp

holders and fittings,

Intermatic has you completely

covered from start to finish.

Intermatic also makes it easy to

stay current with the latest electrical

codes and all models comply with

2002 NEC Article 250.146, which

provides direct mounting of wiring devices

to the switch box. Wehave the best coverage

in the industry and are constantly updating our

product categories to meet your ever-changing needs

and requirements. As new codes and articles are being

introduced and enforced, Intermatic will have the box, cover

or accessory you need to remain compliant.

These NEMA 3R receptacle covers ensure compliance with 2005 NEC Article 406.8 (B) (1) which requires that

15and 20 ampere, 125 and 250 volt receptacles installed in a wet location have an enclosure that is

weatherproof whether or not the attachment plug cap is inserted. They also meet the 1999 NEC Article

410-57(b) and are designed to meet the 1999 NEC Article 210-60(b), which requires that receptacles installed

behind beds in hotels and motels be protected with a suitable guard.

All covers are shipped with gasket, mounting screws, base and cover assembly and patented inserts. The

Flexi-Guard series provides inserts for a variety of applications; 16 for the WP3100/WP1100 single gang

series and 70 for the WP1200 two gang series. The single gang Flexi-Guard models are all designed to mount

horizontally or vertically. The patented insert design ensures flexibility in the field by simply inserting the

proper insert into the base and cover assembly. The two gang Flexi-Guard models utilize six “split” inserts

which create virtually any dual device combination, as well as providing additional flexibility because the

inserts can be rotated 90, 180 or 270 degrees. This provides coverage for horizontally or vertically mounted

devices as well as “left hand” or “right hand” applications without removing and switching the two installed

devices.

The “jumbo covers” WP1150C, WP1250C, WP1050 and WP1050G provide protection for a single large cord

set (up to 3/4" dia.) for portable spa heaters and other heavy duty applications. A lockable hasp is provided

on selected models. The hasp accepts up to .315" (8 mm) diameter shank.

NEMA 3R

Meets UL and CSA Cold Impact Testing at -60˚F (-51˚C)

Patented: U.S. Patent #5 280 135 U.S. Design Pat. #342233

Canadian Patent #2 073 932 Other Patents Pending

Waterproof Cover Applications

•Vending Machines • Amusement Equipment • Ventilating Fans • Landscape Lighting • Outdoor Signs

•RV Connectors • Seasonal Lighting • Remote Power Needs • Portable Spas • Portable Marquee

•Sprinkling Controls • Drinking Fountains • Athletic Field Lighting • Score Board Controls • Bug Zappers

•Car Lot Lighting • Gate Controls • Process Start Up • Equipment • Septic Lift Pumps

•Car Washes • Low Voltage Lighting • Meat Processing • Engine Block Heaters • Holiday Lighting

•Food Preparation • Plant Grow Lighting • Plant Watering • Remote Feeders • Irrigation Pumps

•Hotel Applications •Scoreboard Controls

Specifications

All covers for flushmount, surface mount or FS junction box mounting.

Cover – Clear (gray or white on selected models) UV stabilized polycarbonate with two cordoutlets 1/2"

(12.7 mm) Wide by 9/16" (14.2 mm) High. Models WP1150C, WP1250C and WP1050 one cord outlet 3/4"

(19.1 mm) Wide by 1-5/16" (33.3 mm) High.

Mounting Base and Inserts – Black UV stabilized polycarbonate.

Gasket – Neoprene - 1/8" (4.8 mm) thick with slits for mounting screws.

Shipping Weight – WP3100C – .45 lbs. (0.20 kg)

WP1100C / WP1000HC – .38 lbs. (0.17 kg)

WP1110C / WP1010HC – .41 lbs. (0.19 kg)

WP1150C / WP1230C / WP1030C – .75 lbs. (0.34 kg)

WP1220C / WP1020C – .72 lbs. (0.33 kg)

WP1250C / WP1050 – .9 lbs. (0.41 kg)

UL514D

E142193

C22.2-42.1

LR88576

Weatherproof Receptacle Covers with Patented Insert Design

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

WP3100C - Vertical/Horizontal Cover

Flexi-Guard Weatherproof While-In-Use Cover

Product Features

• Complies with 2005 NEC® Article 406.8(B)(1): “15 and 20 Ampere, 125 and 250V receptacles installed in wet

locations shall have an enclosure that is weatherproof whether or not the attachment plug cap is inserted”

• Easy to remove cord set exit ports

APPLICATIONS

Provides an attractive, code compliant solution for protecting while-in-use outdoor receptacles.

SPECIFICATIONS

• Mounts Vertically or Horizontally

• Hidden Hinges

•Three patented inserts for GFCI, Duplex, Toggle and Single Receptacles

• Inserts include keyhole slots for 16 installation configurations

• Pre-adhered gasket

• Heavy-duty polycarbonate construction

• Clear Cover

• Gray Base

• Meets requirements for cold impact testing at -60º F (-51ºC)

• Lockable hasp for 1/8” shank lock

Warranty: Limited 1-year warranty

Weatherproof Receptacle Covers with Patented Insert Design

GFCI DEVICE SHOWN NOT INCLUDED

1.00 lbs

0.45 kg

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

WP1000RC - Vertical Cover

WP1000HRC - Horizontal Cover

Recessed Weatherproof While-In-Use Cover

Product Features

•Complies with 2005 NEC® Article 406.8(B)(1)

•Heavy duty, polycarbonate cover for long lasting durability

APPLICATIONS

Provides an attractive, code compliant solution for protecting while-in-use

outdoor receptacles.

SPECIFICATIONS

• Device installs recessed in wall for a flush finish for Siding, Stucco or

Brick finishes

• Removable siding flange provides clear finish for all siding types

• Patented single gang inserts for GFCI, duplex, single receptacles,

toggle switch and blank

• Heavy Duty Gasket ensures protection from the elements

• Recessed Sleeve adjusts to ensurelowest profile installation in everyapplication

• Outlet box offers mounting options for stud, block, brick or cut-in

• Cord exit easily handles two 12/3 cord sets

• Handles romex or conduit installations

• Wider access to device for easy cord set installation

• Heavy duty, UV resistant, polycarbonate constructed cover

Warranty: Limited 1-year warranty

WP2000 Flexi-Guard Outlet Post

Weatherproof While-In-Use Cover

PRODUCT FEATURES

•Complies with 2005 NEC® Article 406.8(B)(1)

•Heavy duty PVC construction for long lasting durability

APPLICATIONS

Provides a new, code compliant solution for supplying power to gardens and other out-of-the-way areas.

Aremotely mounted energy saving photo control and/or timer also available to activate area lighting

SPECIFICATIONS

• Patented single gang inserts for GFCI, duplex, single receptacles, toggle switch and blank

•Provisions for installing mechanical or digital timers to control area lighting:

–PB912M10R: 24 hour, 120 Volt mechanical timer – allows for 2 ON/OFF daily cycles

–PB313K: 24 hour, 120 Volt electronic timer – allows for 8 ON/OFF daily cycles (Timers sold separately)

•Provisions for fixed-position, stem-mounting and stem & swivel mounting photo controls to control area lighting

•All ports accept 1/2”,3/4”, or 1” PVC conduit (adapters included)

• Base includes mounting holes and template for optional concrete/pavement mounting

• Cover includes lockable hasp

Warranty: Limited-1 year warranty

Weatherproof Receptacle Covers with Patented Insert Design

3.00 lbs

1.36 kg

GFCI DEVICE SHOWN NOT INCLUDED

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

2.00 lbs

0.91 kg

GFCI DEVICE SHOWN NOT INCLUDED

Die Cast

These heavy duty die cast receptacle covers ensure compliance with the National Electrical Code (NEC). These

models offer the same features as the plastic models but are manufactured of heavy duty cast metal for severe

applications such as schools and commercial buildings. The two gang model WP1030MC includes inserts

for double gang duplex and GFCI requirements. This patented insert design uses the same inserts as all

WP1000 series weatherproof covers and provides flexibility in the field by selecting and inserting the proper

insert. For other applications see insert listing below.

All models are recommended for 14 gauge or lighter cord sets. A lockable hasp is provided (lock not

included). The hasp accepts up to .315" (8 mm) diameter shank.

Specifications

Cover – Gray die cast metal

Mounting Base – Gray die cast metal with cord outlets 1" (25.4 mm) Wide by 5/8" (15.9 mm) High; one

for models WP1010MC and WP1010HMC and two for model WP1030MC.

Inserts – Black UV stabilized polycarbonate.

Gasket – Neoprene 1/8" (3.2 cm) thick with slits for mounting screws.

Shipping Weight – WP1010MC – 0.8 lbs. (0.36 kg)

WP1010HMC – 0.9 lbs. (0.41 kg)

WP1030MC – 1.1 lbs. (0.5 kg)

All models comply with 2005 NEC Article 250.146 which provides direct mounting of wiring devices to the switch box.

Weatherproof Receptacle Covers

UL514D

E142193

C22.2-42.1

LR88576

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Intermatic Flexi-Guard Weatherproof Receptacle Covers let you handle even more configurations with fewer

units. The unique patented inserts and covers allow you to keep even less inventory than before, and cover

more jobs out in the field.

Our single gang models handle both vertical or horizontal applications, just by changing the hinge points. Our

two-gang models include snap-together, rotating inserts that create combinations for almost every application.

With these new Flexi-Guard models, now more than ever, Intermatic is the best NEC code solution under the

sun.

New Features

Single gang plastic models feature pre-adhered gaskets and all covers feature keyhole slots on inserts

for the quickest installation available

Clear & Opaque Gray Models

Clear & White Models

Heavy Duty Die Cast Models

Outlet Post Recessed

Inset Design US Patent #5 280 135

Canadian Patent #2073932

Now you can handle even more with less.

3-1/4"

2-1/2"

6-1/2"

WP1030MC

5-9/16"

3-1/4"

2-1/2"

6-1/2"

WP1010MC

3-3/4"

3-1/4"

2-1/2"

4-1/2"

WP1010HMC

5-3/4"

3-1/2"

2-5/8"

5-1/2"

WP1020/1220C

WP1030/WP1230C

3-1/2"

2-5/8"

5-1/2"

WP1000

WP1010

3-13/16"

3-1/2"

2-5/8"

4-1/4"

WP1000H

WP1010H

4-7/8"

WP1050/WP1250C

4-3/4"

3-1/2"

5-3/8"

WP1150C

3-1/2"

2-7/8"

WP1110C

WP1100C

3-1/2"

2-5/8"

5-1/2"

WP1020/1220C

WP1030/WP1230C

4-7/8"

WP1050/WP1250C

Inserts

Inserts fit single gang models and two gang

models of clear, gray or die cast design. The

2-gang inserts for models WP1020, WP1030,

WP1020GC, WP1030GC, WP1030MC and WP1050

can be mounted at any angle 90, 180 or 270

degrees from that shown. Additional hardware, if

required, and special 2-gang gasket is packaged

with 2-gang (WP200 series) inserts.

16 Configurations for

Single Gang WP1100C Series

70 Configurations for Double

Gang WP1200C Series

Additional inserts available for

Flexi-Guard or Guardian Series

Two Two Two Two Two

Gang Gang Gang Gang Gang

Duplex GFCI Toggle Round Round

1-3/8” 2-5/32”

1-5/8” 2-21/32”

1-3/4”

Single Gang Flexi-Guard Two Gang Flexi-Guard

WP17 WP217

† Converts to toggle, ‡ Converts to toggle,

1-3/8", 1-5/8", 1-3/8" or 1-5/8"

1-3/4" or 2-1/8" diameter round

diameter round

8.17”

SIDE VIEW

9.43”

6.64”

FRONT VIEW

1-13/32”

6-5/8” DIA

1-13/32”1-13/32”

1-5/8” 1-5/8”

BOTTOM VIEW

WP2000

6.81

5.47

7.70

8.62

WET LOCATIONS ONLY WHEN COVER CLOSED

5.88

1.125

0.25

3.50

6.0

1.125 8.62

7.25

5.90

6.81

WET LOCATIONS ONLY WHEN COVER CLOSED

1.125

0.25

6.0

1.125

3.50

WP1000RC WP1000HRC

Now you can handle even more with less.

* With lockable hasp

†Converts to toggle, 1-3/8”, 1-5/8”, 1-3/4” or 2-1/8” diameter round

‡Converts to toggle, 1-3/8” or 1-5/8” diameter round

Insert Design US Patent #5 280 135

Canadian Patent #2073932

Patented Single Gang

Vertical or Horizontal Two Gang with Patented

Snap-Together Inserts Patented Die Cast Metal Patented Two Gang

Fixed Patented Single Gang

Fixed

2-1/4”

Standard

Depth

Clear

WP1220C

Clear

WP1020C

Clear

WP1000C

Vertical

WP1000HC

Horizontal*

Gray

WP1000GC

Vertical

WP1000HGC

Horizontal*

2-3/4”

Standard

Depth

Clear*

WP1100C

White*

WP1100WC

3-1/8”

Standard

Depth

Clear

WP1230C

Grey Die Cast

WP1010MC Vertical

Single Gang

WP1030MC Two Gang

WP1010HMC Horizontal

Single Gang

Clear

WP1030C

Clear

WP1010C

Vertical

WP1010HC

Horizontal*

3-5/8”

Standard

Depth

Clear*

WP1110C

White*

WP1110WC

4-3/4”

Standard

Depth

Clear*

WP1150C

Clear*

WP1250C

Clear*

WP1050

WP1100 Series

Includes 3 Patented

Inserts

WP1200 Series

Includes 6 Snap

Together Patented

Inserts

WP1000MC Series

Includes these Patented

Inserts

WP1000 Series

Includes these Inserts

WP1000 Series

Includes these Inserts

‡

†

‡

Two Gang

Single Gang

†

Vertical or Horizontal

‡

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Giving You Total Control

Within both home and work environments,

Intermatic has been a leader in

innovation for timing, switches and

energy controls for more than 110

years. Intermatic provides the

industry’s broadest line of energy

controls, with ratings and

innovative features designed to

handle any industrial,

commercial or residential

application.

Presently, the home controls

industry is growing at an

annual rate of 18 percent.

Additionally, industry

experts predict that the

category of home controls

could approach annual sales

of $500 million. Intermatic

sees this as a wonderful

opportunity, not only to grow

our business, but help you

grow yours as well – through

the best product offerings,

programs and support at every

step of the way.

Afull line of thermal type photo controls and relay type photo controls provide “dusk-to-dawn” lighting

control. The thermal type controls feature a cadmium sulfide photocell and sonic welded polycarbonate case

and lens to seal out moisture. The design utilizes a dual temperature compensating bimetal and a metal film

resistor for reliable long life operation over ambient temperature extremes. The thermal type photo controls

provide a delay action which eliminates loads switching OFF due to car headlights, lightning, etc.

Applications

•Parking Lot Lighting • Area Lighting • Car Lot Lighting • Security Lighting

•Billboard Lighting • Municipal Lighting • Roadway Lighting • Street Lighting

Fixed Position Mounting, Thermal Type — K4000C Series

Designed to fit into a standard outlet box, a post lamp or wall packs. Model K4321 includes a weatherproof

wall plate with neoprene gasket. The UL listing for this model applies to the entire plate assembly when

properly mounted to an approved outdoor junction box. All other models are equipped with a 3/8"-18

threaded side mounting, locking nut and washer gasket. All models with 9" leads.

Size – Plate - 4-1/2" (11.4 cm) High, 2-3/4" (7.0 cm) Wide;

Mechanism - 1-5/16" (3.3 cm) W, 1-13/16" (4.6 cm) L, 13/16" (2.1 cm) D.

Model # Watts Tungsten VABallast Amps Tungsten Amps Ballast Volts

K4021C 1800 1000 15 8.3 120

K4023C 3100-4150 1700-2300 15 8.3 208-277

K4024 3100 1700 15 8.3 208

K4022 3600 2000 15 8.3 240

K4033 4150 2300 15 8.3 277

K4027*** 5205 2880 15 8.3 347

K4035* 7200 4000 15 8.3 480

K4321C** 1800 1000 15 8.3 120

Note: Wall plate with gasket available for other models; order No. K4001.

*Not UL listed or CSA certified.

** Wall plate included.

*** Certified by CSA to US and Canadian Standards.

Specifications

Unless noted otherwise, the specifications listed below apply to K4000, K4100, K4200, K4300 & K4500

Series.

Size – See individual models. Most hard wired models supplied with 6" leads. K4000 fixed position models

have 9" leads.

Switch Rating – See chartfor each series. Note that the ballast wattage rating is based upon a 50% power

factor.

Activation – 1-5FC “ON”; 3 - 15 FC “OFF” (without shield on models with shield.)

Color – Gray

Shipping Weight – See individual models.

Photo Controls

K4321C

K4021C

Light Shield for K4000

PartNumber 6LV1352

Model

K4321C

UL773A

E42722

K4000

Series

UL773A

E42722

5 Year

Warranty

C22.2-55

LR38068

UL773A

E42722

C22.2-55

LR38068

K4000

Series

UL773A

E42722

5 Year

Warranty

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Photo Controls

Stem Mounting, Thermal Type – K4100 Series

This series features single and multivolt models in both stem mount and stem mount with a swivel. All models

are equipped with a light level slide adjustment and provide a 1/2"-14 threaded stem. A washer gasket and

locking nut are packaged with each photo control. Models with “M” suffix have heavy duty die cast housings.

Model K4251 and K4253 have photo eye located on top and are designed for spot/flood type fixtures.

Size – K4100 Series - 1-9/16" (4.0 cm) Square, 3" (7.6 cm) Long;

K4200 Series - 1/2"-14 threaded swivel, 1-9/16" (4.0 cm) Square, 5-1/2" (14.0 cm) Long;

Model K4236 - 5-3/4" (14.6 cm) High, 3" (7.6 cm) Diameter.

Model # Watts Tungsten VA Ballast Amps Tungsten Amps Ballast Volts

K4121C 1800 1000 15 8.3 120

K4121M 2000 1800 16.7 15 120

K4421M 1800 1000 15 8.3 120

K4124 3100 1700 15 8.3 208

K4122 3600 2000 15 8.3 240

K4123C 3100-4150 1700-2300 15 8.3 208-277

K4423M*** 3100-4150 1700-2300 15 8.3 208-277

K4133 4150 2300 15 8.3 277

K4127**** 5205 2880 15 8.3 347

K4135* 7200 4000 15 8.3 480

K4136M 2000-4625 1800 16.7 8.6 120 or 277

**K4141C* 3000 3000 25 25 120

*Not UL listed or CSA certified.

** 1 year warranty.

*** Model K4423M replaces K4123M

**** Certified by CSA to US and Canadian Standards.

Stem & Swivel Mounting, Thermal Type – K4200 Series

Model # Watts Tungsten VABallast Amps Tungsten Amps Ballast Volts

K4221C 1800 1000 15 8.3 120

K4224 3100 1700 15 8.3 208

K4222 3600 2000 15 8.3 240

K4223C 3100-4150 1700-2300 15 8.3 208-277

K4233 4100 2300 15 8.3 277

K4227*** 5205 2880 15 8.3 347

K4235* 7200 4000 15 8.3 480

K4236C 1800-4150 1000-2300 15 8.3 120 or 208-277

K4251*** 1800 1000 15 8.3 120

K4253*** 3100-4150 1700-2300 15 8.3 208-277

*Not UL listed or CSA certified.

***Certified by CSA to US and Canadian Standards.

UL773A

E42722

5 Year

Warranty

C22.2-55

LR38068

K4121C

K4121M

C22.2-177

LR3730

UL773A

E42722

5 Year

Warranty

C22.2-55

LR38068

K4251

K4236C

K4221C

K4423M

Locking-Type Mounting, Thermal Type — K4500 Series

Easy to install; just plug in and twist. This series is equipped with standard 3-prong NEMA locking-type plug

connections. Incorporates K4000 style thermal switch for reliable long life performance. Complies with ANSI

C136.10.

Size – 3-3/4" (9.5 cm) High, 3" (7.6 cm) Diameter.

Model # Watts Tungsten VA Ballast Amps Tungsten Amps Ballast Volts

K4521 1800 1000 15 8.3 120

K4524** 3100 1700 15 8.3 208

K4522 3600 2000 15 8.3 240

K4533** 4100 2300 15 8.3 277

K4535** 7200 4000 15 8.3 480

* Ballast rating meets UL testing at 50% power factor.

** Not CSA certified.

Accessories for Locking-Type Controls

Pole Bracket Adapter – Model K122 - 105 to 480 Volts; for use with K1200, K4500 or LC4500 Series

locking-type controls. K121 – receptacle only, K121-30 receptacle with 30 inch leads.

Shorting Cap – Model K4500 - 105 to 480 Volts; replaces locking-type photo control to complete circuit.

Low Cost Locking-Type, Thermal Type — LC4500 Series

The LC4500 Series provides low cost reliable control for street lighting and other applications requiring a

NEMA twist and lock type plug connection. An integral housing and lens, with UV protection, keeps moisture

out and ensures long life. Complies with ANSI C136.10.

Activation – .5 FC minimum “ON”; 15 FC maximum “OFF”.

Size – 2-3/4" (7.0 cm) High, 3" (7.6 cm.) Diameter.

Color – Translucent with color coded band for voltage identification.

Model # Watts Tungsten VA Ballast Volts

LC4521C 1000 1000 120

LC4523 1700-2300 1700-2300 208-277

LC4527 5205 2880 347

LC4535** 1000 4000 480

LC4536C 1000-2300 1000-2300 120 or 208-277

LC4521LA 1000 1000 120

LC4523LA 1700-2300 1700-2300 208-277

LC4535LA** 1000 4000 480

LC4536LAC 1000-2300 1000-2300 120 or 208-277

LA Models equipped with 2400 volt open type spark gap arrester.

* Ballast rating meets UL testing at 50% power factor.

** Not CSA certified.

Photo Controls

3/4 lbs

.34 kg

UL773

E59121

5 Year

Warranty

C22.2-177

LR38068

LC4521C

.2 lbs

.09 kg

UL773

E59121

3 Year

Warranty

C22.2-55

LR38068

K4521

K122 K4500 K121

K121-30

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Relay Type Photo Controls With Adjustable Stem or Locking-Type Mounting —

K1100, K1200 Series

This series features “instant ON/OFF switching” in two mounting types. Complies with ANSI C136.10.

Series K1100 – Equipped with an adjustable stem for mounting at almost any angle up to 80 degrees.

Models equipped with three 6" color coded leads.

Series K1200 – Easy to install using NEMA plug-in locking type connection. Models are equipped with

2400 Volt open type spark gap arrester and standard 3-prong connector.

Size - K1100 Series – 5-3/4" (14.6 cm) High, 3" (7.6 cm) Diameter; 1/2"-14 NPT Stem;

K1200 Series – 3-3/4" (9.5 cm) High, 3" (7.6 cm) Diameter.

Activation – 1FC “ON”; 3 - 10 FC “OFF”

Model # Watts Tungsten VA Ballast Volts

K1121 1800 1800 105-130

K1122 1800 1800 210-240

K1221 1800 1800 105-130

K1222 1800 1800 210-240

*Ballast rating meets UL testing at 50% power factor.

Low Cost Relay Type Photo Control with Locking-Type Mounting — LC2000

Features “Instant ON/OFF Switching”. Complies with ANSI C136.10

Size - 2-3/16" (5.6 cm) High, 3-3/16" (8.1 cm) Diameter

Activation – 1to 3 FC “ON”. Turn OFF to turn ON ratio is 4.

Model # Watts Tungsten VA Ballast Volts

LC2000 1000 1800 110-277

Includes 110 Joule MOV Surge Arrester.

Photo Controls

3/4 lbs

.34 kg

UL773

E59121

5 Year

Warranty

C22.2-55

LR38068

UL773A

E42722

3/4 lbs

.34 kg

UL773

E59121

3 Year

Warranty

K1100

K1200

LC2000

Solid State Photo Controls - Locking Type

The K4536SS Photo Control is electronically calibrated and provides reliable control of street lighting and

other applications requiring a NEMA plug-in locking type connection. Complies with ANSI C136.10.

The K4536SST is the same as above, but provides a fixed “OFF” time adjustable in half hour increments from

6:00 PM to 2:00 AM and a fixed “ON” time adjustable in half hour increments from 4:00 AM to 8:00 AM.

The fixed times are based on a real-time clock that sets itself based on the occurrence of sunrise and sunset.

Operation – Instant “ON”, 10 Second Delay “OFF”

Size - same as LC4500 Series

Color - same as LC4500 Series

Model # Watts Tungsten VA Ballast Volts

K4536SS 1000 1800 105-305

K4536SST 1000 1800 105-305

Includes 430 Joule MOV Surge Arrestor.

Photo Controls

5 Year

Warranty

UL773A

E42722

3/4 lbs

.34 kg

K4536SS

K4536SST

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

24 Hour Dial

T100 Series – Designed for industrial, commercial and residential applications. Highest HP ratings in the

industry for loads up to 40 amps, providing direct 24 hr. control of most loads. Provides 1 to 12 “ON/OFF”

operations each day with minimum ON/OFF times of 1 hour. All models equipped with one “ON” and one

“OFF” tripper.

Applications

• Indoor/Outdoor Lighting • Post Lanterns

• Signs • Pool Heaters

• Filters • Hydrochlorinators

• Air Conditioning • Blowers

• Electric Fences • Pumps

• Heating/Ventilating Systems • Music and Signal Systems

• Fans • Poultry Foggers

• Conveyers

Specifications

Case – Drawn steel 7-3/4" (19.7 cm) H, 5" (12.7 cm) W, 3" (7.6 cm) D in gray finish. Spring hasp, with hole

for lock, holds permanently attached, side hinged door closed. Three mounting holes on back plus handy

box mounting holes.

Knockouts – Combination 1/2"–3/4" nominal knockouts, one on back and each side of case and two on

bottom.

Optional Enclosures – See Time Switch Cases page for optional enclosures.

Special Voltages and Cycles – See Time Switch Motors page for available motors.

Switch Rating – Each Pole; 40 Amp Resistive, 120-480 VAC; 40 Amp Tungsten, inductive or 1000 VA pilot

duty, 120-277 VAC; 2 HP (24 FLA) 120 VAC; 5 HP (28 FLA) 240 VAC single phase; 7-1/2 HP (28 FLA) 208

VAC three phase; 10 HP (28 FLA) 240 VAC three phase.

Model # Model # Model # Steel Clock Motor AMPS

Model # w/See-Thru Cover Plastic Case NEMA 3R Case Switch Volts 60 Hz (per pole) HP Rating

T101 T101PCD82 T101P T101R SPST 125 40 2

T102 –– T102P T102R SPST 208-277 40 5

T103 T103PCD82 T103P T103R DPST 125 40 2

T104 T104PCD82 T104P T104R DPST 208-277 40 5

T101B* –– –– SPST 125 40 2

T105 –– –– 1NO / 1NC** 125 40 2

T106R† –– –– 1NO / 1NC** 208-277 40 5

* Separate clock motor terminals for switching circuits not on line voltage.

** Can be wired as SPDT.

† Only available in NEMA 3R case.

For additional trippers (1 ON / 1 OFF per pack), order No. 156T1978A.

Time Switches

C22.2-177

LR3730

UL917

2.75 lbs

1.25 kg

-40°F

(-40°C)

130°F

(54°C)

24 Hr. w/Skipper, Optional Carryover

T170 Series – Same features as the T100 Series plus a skipper option to omit operation on selected days.

Cutout screws are inserted in the dial for days which operation is to be skipped. Provides up to 10 ON/OFF

operations each day with min. ON/OFF operations of 1 hour and max. ON time of 20 hours. Includes one

CUTOUT tripper (also serves as an “ON” tripper), one “OFF” tripper and three skipping screws.

T170CR Series – Same features as the T170 Series Skipper models plus a min. of 16 hours carryover for

maintaining preset schedules during power failures. Carryover automatically rewinds when power resumes;

only one hour of rewinding time required for every two hours of power outage. 4PST models are ideal for

3-phase load control.

Specifications

Case – T170 Series same as T100 except as noted under Optional Enclosures. T170CR only in NEMA 3R

drawn steel 9-3/8" (23.8 cm) H, 5-1/2" (14.0 cm) W, 3-5/8" (9.2 cm) D in gray finish. Hasp, with hole for

lock, holds permanently attached, side-hinged door closed. Bracket plus two holes on back below switch

for mounting. Separate grounding terminal.

Optional Enclosures – 4pole and 2 NO/ 2 NC models not available in standardor plastic case; only in

NEMA 3R steel case. T170CR only available in steel NEMA 3R enclosure.

Special Voltages and Cycles – See Time Switch Motors for available motors. Contact factoryfor

availability of time switch with 50 cycle or other voltages.

Special Voltages and Cycles – Same as T100 Series.

Switch Rating – Same as T100 Series.

Model # Steel Clock Motor AMPS HP

Model # NEMA 3R Case Switch Volts 60 Hz (per pole) Rating

T171 SPST 125 40 2

T172 SPST 208-277 40 5

T173 T173R DPST 125 40 2

T174 T174R DPST 208-277 40 5

T175 1NO / 1NC** 125 40 2

T176 1NO / 1NC** 208-277 40 5

T1471BR* 4PST 125 40 2

T1472BR* 4PST 208-277 40 5

T1475BR* 4PST 480 40 5

T1871BR* 2NO / 2NC*** 125 40 2

T171CR SPST 125 40 2

T173CR DPST 125 40 2

T174CR DPST 208-277 40 5

T1471BCR* 4PST 125 40 2

*Separate clock motor terminals for switching circuits not on line voltage.

** Can be wired as SPDT.

*** Can be wired as DPDT.

For additional trippers (1 ON / 1 OFF / 1 CUTOUT per pack), order No. 156T1948A.

For additional skipper screws (3 skipper screws per pack), order No. 156T3085A.

Time Switches

C22.2-177

LR3730

UL916

2.75 lbs

1.25 kg

Same as

T100

Series

-40°F

(-40°C)

130°F

(54°C)

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Portable

This portable cord connected time switch performs all the functions of the T100 and T170 series time switches

plus it is completely portable eliminating the need for wiring. Supplied complete with 6' grounded cord set and

receptacle installed.

Applications (Indoor Only)

• Photo Copiers • Portable Lights • Signs • Space Heaters

• Electric Water Heaters • Air Conditioning • Fans • Poultry Foggers

• Ventilating Systems • Motors • Pumps • Blowers

Specifications

Case – Drawn steel 7-3/4" (19.7 cm) High, 5" (12.7 cm) Wide, 3" (7.6 cm) Deep in gray finish. Spring hasp,

with hole for lock, holds permanently attached, side hinged door closed. Three mounting holes on back

plus handy box mounting holes.

Knockouts – Not applicable; prewired cord and receptacle.

Switch Rating – 15 Amp Resistive, 15 Amp Tungsten; 345 VA pilot duty (15 FLA), 125 VAC.

Model # Switch Clock Motor Volts 60 Hz Amps (per pole) Skipper Wheel

P171-30 SPST 125 15 Yes

For additional trippers Model Series P170 (1 ON/1 OFF/1 CUTOUT per pack), order No. 156T1948A.

Time Switches

120V - 15A Receptacle

3 lbs

1.36 kg

C22.2-177

LR3730

UL917

-40°F

(-40°C)

130°F

(54°C)

24 Hour Dial w/Skipper

The T1900 Supervisor Series provides up to 96 operations (48 ON /48 OFF) every 24 hours. This series

provides operations with minimum ON / OFF times of 15 minutes. Trippers slide in and out of dial for fast

accurate setting. The skipper models provide for operations to be omitted on selected day(s) of the week.

Model with carryover provides a minimum of 16 hours of carryover to maintain preset schedules within

+/- 2% accuracy during power failures. The carryover automatically rewinds when power resumes. Only one

hour is required to rewind the carryover for each two hours of power outage.

Applications

• Oil Well Pumps • Poultry Feeders • Recorded Music • Silo Unloaders

• Filters • Heaters • Dairy Equipment • Poultry Foggers

• Blowers • Process Equipment • Fans

Specifications

Case – Drawn steel 7-3/4" (19.7 cm) High, 5" (12.7 cm) Wide, 3" (7.6 cm) Deep in gray finish. Spring hasp,

with hole for lock, holds permanently attached, side hinged door closed. Three mounting holes on back

plus handy box mounting holes.

Knockouts – Combination 1/2"-3/4" nominal knockouts, one on back and each side of case and two on

bottom.

Optional Enclosures – See Time Switch Cases for optional enclosures.

Special Voltages and Cycles – See Time Switch Motors for available motors.

Switch Rating – 20 Amp maximum 125, 208-277 and 480 VAC; 1/2 HP , 125 VAC; 1 HP, 250 VAC

Power Input – 5 Watts maximum.

MODEL # STEEL Clock Motor Spring Wound Skipper

Model # NEMA 3R CASE Switch Volts 60 Hz Carryover Amps Wheel

T1905 SPDT 125 No 20 No

T1905E SPDT 480 No 20 Yes

T1906 SPDT 208-277 No 20 No

T1975 T1975R SPDT 125 No 20 Yes

T1976 T1976R SPDT 208-277 No 20 Yes

T1975E T1975ER SPDT 480 No 20 Yes

For additional trippers (12 per pack), order No. 156T1950A.

Replacement Snap Switch 133T701A.

Time Switches

C22.2-177

LR3730

UL917

2.75 lbs

1.25 kg

-40°F

(-40°C)

130°F

(54°C)

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Short Range Cycle Timer

Short Range Cycle Timers provide repeat cycling for “ON” times. Ten combination “ON/OFF” trippers supplied

with each switch.

Applications

• Ventilating Fans • Spraying Equipment • Livestock Feeders • Poultry Fans

• Fogging Equipment • Poultry Feeders • Pumps • Bulk Milk Coolers

• Process Equipment

Specifications

Case – Same as T100 Series.

Knockouts – Same as T100 Series.

Optional Enclosures – Same as T100 Series.

Switch Rating – 20 Amp Resistive 125, 208-277 VAC; 1/2 HP, 125 VAC; 1 HP, 250 VAC

Model # Switch Clock Motor Volts 60 Hz Dial Cycle Tripper Actuating Time Amps

C8815 SPDT 125 10 Min. 5 Sec. 20

C8835 SPDT 125 30 Min. 15 Sec. 20

C8865 SPDT 125 1 Hr. 30 Sec. 20

C8845 SPDT 125 4 Hr. 120 Sec. 20

C8866 SPDT 250 1 Hr. 30 Sec. 20

Note: The life of the switch contacts is affected by the size and type of the controlled load. The expected minimum life at 20 amps (resistive)

load is 100,000 cycles.

Replacement Snap Switch 133T773A.

For additional trippers (12 trippers per pack), order No. 156T1950A.

Time Switches

C22.2-177

LR3730

UL917

2.75 lbs

1.25 kg

-40°F

(-40°C)

130°F

(54°C)

Sprinkler/Irrigation Timer with 14-Day Skipper

These irrigation timers permit 1 to 60 “ON” operations every 24 hours. This series is designed for water

metering in increments of 12 minutes to 20 hours - 45 minutes for maximum conservation of precious water

resources. The 14-day skipper feature permits irrigation to be omitted on selected day(s) and also provides for

“every other” day operation. The “ON/OFF/AUTOMATIC” switch allows shutdown during rainy days or

extended watering during dry periods without disturbing the automatic cycle set on dial.

Applications

•Multi-Station Hydro Indexing Valves • Greenhouses • Lawn Sprinkling • Pumps

•Irrigation Control • Feeders • Drip Irrigation Systems

Specifications

Case – Plastic NEMA 3R case. Cases include hanging bracket plus two mounting holes on back below

switch for mounting.

Knockouts – Combination 1/2"-3/4" nominal knockouts, one on back and each side of case, and two on

bottom.

Switch Rating –

T8805P101C – 15 Amps, 125 VAC, 1/2 HP, SPST.

R8806P101C – 25 Amps, 208-277 VAC, 2 HP, DPST relay.

R8815P101C – 25 Amps, 120 VAC, 1-1/2 HP,DPST relay.

R8816P101C – 25 Amps, 208-277 VAC, 3 HP, DPST relay.

T8845PV – 125 VAC, SPST, output 24 Volts - 20VA

Model # Switch Motor Voltage 60 Hz Output Voltage 60 Hz AMPS (per pole) HP Rating

T8805P101C SPST 125 –– 15 1/2

R8806P101C DPST 208-277 — 25 2

R8815P101C* DPST 120 — 25 1-1/2

R8816P101C* DPST 208-277 –– 25 3

T8845PV** SPST 125 24 20VA ––

*Includes rain sensor input terminals- rain sensor not supplied.

** Includes 24 volt - 20 VAtransformer.

For additional trippers (12 per pack), order No. 156T1950A.

Time Switches

C22.2-177

LR3730

UL917

3.75 lbs

1.7 kg

-40°F

(-40°C)

130°F

(54°C)

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Timing Control Center, 7-Day Dial with Carryover

This series provides photo control initiated / time switch terminated control. These time switches provide a

different “ON/OFF” program each day of the week and a spring wound carryover. These time switches are

recommended for applications where you need to turn a load “ON” at dusk and “OFF” at a preset time. The

spring wound carryover provides a carryover of 16 hours minimum to maintain accurate load control even

during power failure. When power resumes, the carryover automatically rewinds itself. Only 1 hour is required

to rewind the carryover for each 2 hours of outage. The three models provide control of 1, 2 or 3 circuits. A

light level adjustment is provided on the photo control. All models have single pole double throw switches and

manual circuit by-pass switches.

Unit is designed to control the contactor control circuit only. It is not recommended for direct switching of

tungsten, mercury vapor or similar loads.

Applications

•Parking Lot Lighting • Landscape Lighting • Billboard Lighting • Entryway Lighting

•Storefront Lighting • Stairway Lighting • Car Lot Lighting • Security Lighting

Specifications

Case – Steel in gray finish 12-1/2" (31.7 cm) high, 8-1/4" (21.0 cm) wide, 4" (10.2 cm) deep. Indoor type

with toggle action drawbolt and locking feature. Four mounting holes on back. Separate grounding terminal.

Knockouts – Combination 1/2"-3/4" nominal knockouts, two on back one on each side and two on bottom.

Also one 1" nominal on bottom center.

Optional Enclosures – None available.

Contact Rating – 15 Amp, 1/2 HP, 125/250 VAC; 420 VA pilot duty; 150 Watts Tungsten, 125 VAC (May

also be used with 24 volt systems if wired in accordance with National Electrical Code Regulations.)

Model # Description Clock Motor Volts 60 Hz

T51211BC Circuit A - Sunset, Photo Control ON - Preset Time Switch OFF 120

Circuit B - Sunset, Photo Control ON - Sunrise, Photo Control OFF —

T51311BC Circuit A - Sunset, Photo Control ON - Preset Time Switch OFF 120

Circuit B - Sunset, Photo Control ON - Sunrise, Photo Control OFF —

Circuit C - Preset Time Switch ON - Preset Time Switch OFF —

All models have separate clock motor terminals for switching circuits not on line voltage.

For additional trippers (7 ON / 7 Off per pack), order No. 156T2548A.

See Next Generation Electronic Time Switches with AstroFeature

Time Switches

C22.2-177

LR3730

UL917

10.5 lbs

4.8 kg

-40°F

(-40°C)

130°F

(54°C)

Compact, 7-Day

The T2000 Series provides up to 84 (42 “ON/OFF”) operations each week. Minimum “ON/OFF” times for this

series are 2 hours each providing up to 6 “ON/OFF” operations each day.

Applications

•Heating • Air Conditioning • Ventilating • Defrost Control

•Lights • Pumps • Motors • Fans

Specifications

Case – Drawn steel 7-3/4" (19.7 cm) high, 5" (12.7 cm) wide, 3" (7.6 cm) deep in gray finish. Spring hasp,

with hole for lock, holds permanently attached, side hinged door closed. Three mounting holes on back

plus handy box mounting holes.

Knockouts – Combination 1/2"-3/4" nominal knockouts, one on back and each side of case and two on

bottom.

Optional Enclosures – See Time Switch Cases for optional enclosures.

Special Voltages and Cycles – See Time Switch Motors for available motors.

Switch Rating – 20 Amp Resistive, 125 and 208-277 VAC; 1/2 HP 125 VAC; 1 HP 250 VAC

Model # Switch Clock Motor Volts 60 Hz Amps

T2005 SPDT 125 20

T2006 SPDT 208-277 20

For additional trippers (12 per pack), order No. 156T1950A.

Replacement Snap Switch 133T701A.

Time Switches

C22.2-177

LR3730

UL917

2.75 lbs

1.25 kg

-40°F

(-40°C)

130°F

(54°C)

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

7-Day Dial With & Without Carryover

These time switches provide a different “ON/OFF” program each day of the week. They also provide for 4 pole

single throw and 4 pole (2NO/2NC) switching. This series provides true 7-day load control with minimum ON

and minimum OFF times of 3-1/2 hours. The “BC” models with carryover provide a carryover of 16 hours

minimum to maintain accurate load control even during power failure. When power resumes, the carryover

automatically rewinds itself. Only 1 hour is required to rewind the carryover for each 2 hours of outage.

Applications

•Heating • Air Conditioning • Pumps • Indoor Lighting

•Outdoor Lighting • Motors • Signs • Billboards

•Ventilating Systems • Fans • Filters • 3 Phase Loads

Specifications

Case – Steel in gray finish 12-1/2" (31.7 cm) high, 8-1/4" (21.0 cm) wide, 4" (10.2 cm) deep. Indoor type

with toggle action drawbolt and locking feature. Four mounting holes on back. Separate grounding terminal.

Knockouts – Combination 1/2"-3/4" nominal knockouts, two on back, one on each side and two on bottom.

Also one 1" nominal on bottom center.

Optional Enclosures – See Time Switch Cases for optional enclosures.

Special Voltages and Cycles – See Time Switch Motors for available motors. Contact factory for avail-

ability of time switch with 50 cycle or other voltages.

Switch Rating – Each Pole 40 amp resistive, 120-480 VAC; 40 amp tungsten, inductive or 1000 VA pilot

duty, 120-277 VAC; 2 HP (24 FLA) 120 VAC; 5 HP (28 FLA) 240 VAC single phase; 7-1/2 HP (28 FLA) 208

VAC three phase; 10 HP (28 FLA) 240 VAC three phase.

Carryover – Minimum time - mechanical operation: 16 hours. Carryover accuracy +/-2%.

Model # Model with Clock Motor Amps

Model l# Steel NEMA 3R Case CarryOver Switch Volts 60 Hz (per pole)

T7401B T7401BR T7401BC 4PST 125 40

T7402B T7402BC 4PST 208-277 40

T7801B T7801BC 2NO/2NC 125 40

T7802B T7802BC 2NO/2NC 208-277 40

*All models (B or BC suffix) have separate clock motor terminals for switching circuits not on line voltage.

For additional trippers (7 ON / 7 OFF per pack), order No. 156T2548A.

Time Switches

C22.2-177

LR3730

UL917

Models

without

carryover

8lbs

3.6 kg

Models

with

carryover

9lbs

4.1 kg

-40°F

(-40°C)

130°F

(54°C)

Astro Dial With Skipper & Carryover

This time switch self adjusts for seasonal changes. The astronomic dial automatically adjusts itself as the days

grow shorter or longer. A skipper provides lighting control to be omitted on selected day(s) of the week. The

carryover is designed to maintain preset schedule during power outages for a minimum of 16 hours. Only

1hour is required to rewind the carryover for each 2 hours of outage. The 3PST switch configuration provides

for control of 3-phase lighting. Three skipper screws are furnished.

Lighting Applications

•Parking Lots • Landscape Lights • Stairways • Billboards

•Entryways • Security • Storefronts • Car Lots

Specifications

Case – NEMA 3R drawn steel 11-1/2" (29.2 cm) high, 8-1/4" (20.9 cm) wide, 4-1/2" (11.4 cm) deep in gray

finish. Hasp, with hole for lock, holds permanently attached, side hinged door closed. Mounting bracket

plus two holes below switch on back for mounting. Separate grounding terminal.

Knockouts – Combination 1/2"-3/4" nominal knockouts, one on back and each side of case and two on

bottom.

Optional Enclosures – None.

Switch Rating – Each pole: 40 amp tungsten up to 277 VAC; 1 HP, 120 VAC; 690 VA pilot duty.

Model # Switch Clock Motor Volts 60 Hz Amps

V45471CR* 3PST 125 40

V45472CR* 3PST 208-277 40

V45471R 3PST 125 40

V45472R 3PST 208-277 40

#Indicate City and State nearest installation when ordering.

*Includes spring wound carryover.

For additional skipper screws (3 skipper screws per pack), order No. 156T1957A.

For Electronic Time Switches which offer Astro Feature please see pages 42-44

Time Switches

UL917

E10694

C22.2-177

LR3730

Models

V45471C

R &

V45472C

9lbs

4.1 kg

Other

Models

5lbs

2.3 kg

-40°F

(-40°C)

130°F

(54°C)

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Time Switches

Water Heater Time Switches

The WH40 provides a convenient external override switch. Utilities in many areas of the country offer two

electric rates for residential or commercial customers. One rate has the regular daytime electrical rate, the other

is “off peak” rate. The off peak rate provides customers with “lower-priced” electricity during the nighttime and

weekend periods. These time switches allow the customer to shift electricity use into these off-peak time

periods in an attempt to save utility costs.

Applications

Water Heater Control for:

•Residential • Commercial • Industrial • Institutional / Schools • Military Facilities

Specifications

Case – Drawn steel 7-3/4" (19.7 cm) High, 5" (12.7 cm) Wide, 3" (7.6 cm) Deep in gray finish. Spring hasp,

with hole for lock, holds permanently attached, side hinged door closed. Three mounting holes on back

plus handy box mounting holes.

Knockouts – Combination 1/2"-3/4" nominal knockouts, one on back and each side of case and two on

bottom.

Special Voltages and Cycles – See Time Switch Motors for available motors.

Switch Rating – 40 Amp Resistive, Inductive or Tungsten 120-277 VAC; 1000 VA pilot duty 120-277 VAC; 2

HP (24 FLA) 125 VAC; 5 HP (28 FLA) 240 VAC.

Model # Switch Clock Supply Volts 60 Hz Watts External Switch Amps/Pole

T104-20 DPST 208-240 10000 No 40

WH40 DPST 250 10000 Yes 40

For additional trippers (1 ON / 1 OFF per pack), order No. 156T1978A.

The

"LITTLE

GRAY BOX"®

2.75 lbs

1.25 kg

C22.2-177

LR3730

UL917

-40°F

(-40°C)

130°F

(54°C)

Electronic Water Heater Timers

These time switches provide automatic control for electric water heaters. They provide to-the-minute accuracy

in programming and time keeping. The time switches can be programmed for repeat daily scheduling, 5-day

working week scheduling, weekend scheduling or any individual day scheduling. Timers can be scheduled for

operation during the lowest time-of-day rates or to switch off the electric heater during period of utilities peak

power usage. The time switch can be set to operate for up to 6 on/off operations daily for a maximum of

42 on/off operations weekly. Both models provide a convenient external override switch and LED load indicator

for ease in scheduling hot water as required for extra hot water demands. The timers include a “AA” alkaline

batterycarryover which protects both time keeping and program information for a minimum of 3 years.

Applications

Water Heater Control for:

•Residential • Institutional • Industrial

•MilitaryFacilities •Schools •Commercial

Specifications

Case – Drawn steel 7-3/4" (19.7 cm) H x 5" (12.7 cm) W x 3" (7.6 cm) D in gray finish. Spring hasp, with

hole for lock, holds permanently attached, side hinged door closed. Three mounting holes on back plus

handy box mounting holes.

Knockouts – Combination 1/2"–3/4" nominal knockouts, one on back and each side of case and two on

bottom.

Switch Rating – 30 Amp Resistive or Inductive 120-240 VAC; 1 HP, 120 VAC; 1-1/2 HP, 240 VAC;

5Amps Tungsten, 120/240 VAC.

Model # Switch Clock Supply Volts 50/60 Hz Watts External Switch Amps/Pole

EH10 SPST 120 3600 Yes 30

EH40 DPST 240 7200 Yes 30

Time Switches

With Manual External

Override and Load Indicator

UL916

E76987

0 H

z O

2.75 lbs

1.25 kg

C22.2-177

LR3730

-4°F

(-20°C)

122°F

(50°C)

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

A. Plastic Case

Ends rusting problems forever.

Made of heavy-duty industrial grade plastic, Intermatic’s rainproof all plastic case is perfect for applications

where high humidity and/or dust can be a problem. Developed for use with pool and spa equipment, the

non-corroding plastic case is useful for applications in other high moisture areas such as car washes,

industrial water spray areas, etc; NEMA 3R case.

A hasp with a hole for lock holds the side-hinged door closed. A bracket plus two holes below the switch on

the back are for mounting. Has five combination 1/2 - 3/4" nominal knockouts, one on back and each side of

case, two on bottom.

Model Number Description Weight

2T2500GA* Indoor / Outdoor Plastic Case – 9-3/8" x 5-1/2" x 3-3/4" 1.3 lbs

2T2502GA* Beige Indoor / Outdoor Plastic Case – 9-3/8" x 5-1/2" x 3-3/4" 1.3 lbs

* Available for SERIES T100, T170, T180, T1100, T1200, T1400, T1900, T2000, C8800, ET100C, ET170C,ET700C and models EH10,

EH40, ET279C ET70115, ET70215, and ET8000 series

B. Standard Case

Drawn steel with gray powder coat paint finish. Spring hasp (with hole for seal or lock) holds permanently

attached hinged door closed. Has combination 1/2" - 3/4" nominal knockouts, one on back and on each side,

and two on bottom. (Except “P” Series switches which are equipped with cord-connection and receptacle.)

Convenient mounting holes. NEMA Type 1.

Model Number Description Weight

2T2040GA* Standard Indoor Case – 7 3/4" x 5" x 3" 1.4 lbs

2T2292GA** Indoor Case – 12-1/2" x 8-1/4" x 3-7/8" 7.0 lbs

*Available for SERIES T100, T170, T180, T1100, T1200, T1400, T1900, T2000, C8800, ET100C, ET170C,ET700C and models EH10,

EH40, ET279C ET70115, ET70215, and ET8000 series

** Available for SERIES T7400B, T7800B, T7400BC and T7800BC.

C. Indoor-Outdoor Case

For protecting time switch from rain, sleet, snow and ice. Drawn steel with gray or beige powder coat paint

.036" construction with side-hinged door. Hasp provided for lock. Has combination 1/2-3/4" nominal

knockouts, one on back and each side of case, and two on bottom. Separate grounding terminal. Convenient

mounting holes. NEMA 3R.

Model Number Description Weight

2T511GA* Standard Indoor/Outdoor Case – 9-3/8" x 5-1/2" x 3-5/8" 2.5 lbs

2T2485GA* Beige Standard Indoor/Outdoor Case – 9-3/8" x 5-1/2" x 3-5/8" 2.5 lbs

2T2331GA** Indoor/Outdoor Case – 9-3/8" x 5-1/2" x 3-5/8" 2.5 lbs

2T2293GA*** Indoor/Outdoor Case – 12-1/2" x 8-1/4" x 3-7/8" 2.5 lbs

2T1985GR**** Indoor/Outdoor Case – 9-3/8" x 5-1/2" x 3-5/8" 2.5 lbs

* Available for SERIES T100, T170, T180, T1100, T1200, T1400, T1900, T2000, C8800, ET100C, ET170C,ET700C and models EH10,

EH40, ET279C ET70115, ET70215, and ET8000 series

** Available for SERIES T100CR, T170CR, T1400BR, T1400BCR, T1800BR and T1800BCR.

*** Available for SERIES T7400B, T7800B, T7400BC and T7800BC.

**** Available for SERIES LS7000 only.

D. Stainless Steel Indoor-Outdoor Case

Model Number Description Weight

TS100RS Stainless Steel Indoor-Outdoor Case – 9 7/8" x 6 1/2" x 3 1/5" 3.5 lbs

* Available for SERIES T100, T170, T1400, T1900, T2000, C8800, ET100C, ET170C, ET700C, EH40, ET279C, ET70115,

ET70215 and ET8000.

Time Switch Cases

A. 2T2500GA

Plastic Case NEMA 3R

UL & CSA apply to all

enclosures shown.

C. 2T511GA

Steel Indoor/Outdoor Case NEMA 3R

B. 2T2040GA

Standard Case NEMA 1

UL917

E10694

C22.2-177

LR3730

D. TS100RS

Steel Indoor/Outdoor Case NEMA 3R

E. 2-in-1 Raintight Case and Panel

For use where 2 time switches are to be mounted side by side. Heavy-duty spot-welded raintight construction

with powder coat paint. Hasp (with hole for lock) holds permanently attached hinged door closed. Combination

1/2" - 3/4" nominal knockouts conveniently located (two on back, five on bottom and one on each side).

Top mounting brackets plus two holes below switch level on back of case.

Model Number Description Weight

T10000R (replaces 2T2089GA)* 2-in-1 Indoor/Outdoor Case – 10-1/2" x 10-1/2" x 4" 6.5 lbs

T30000R* Indoor/Outdoor Panel – 16-3/4" x 10-1/2" x 4-1/4" 11.0 lbs

T40000R* Indoor/Outdoor Panel – 20-3/4" x 12-3/4" x 4-1/4" 17.0 lbs

* Available for SERIES T100, T170, T180, T1900, T2000 and C8800. NOT FOR T1400/T1800/T1900 MODELS WITH BCR SUFFIX.

F. Flushmount Case

For concealing mechanism in wall and giving a finished, flushed appearance. Heavy-duty, .063" formed steel

construction with hinged door. Gray finish with powder coat paint. Combination 1/2" - 3/4" nominal knockouts

one each side, and two on bottom, plus one 1" knockout on top and bottom. Convenient mounting holes.

With or without key lock. Cutout 9-1/8" x 6" x 4-1/8" deep; flange 11" x 8"

Model Number Description Weight

2T308A* Standard Flushmount w/Lock 6.5 lbs

2T2365GA** Flushmount Case w/Lock 7.0 lbs

6ET1398GA Flush Cover for ET70415CR and ET70415CR24 2.5 lbs

2T2366GA Flush Cover for ET70415CR and ET70415CR24 with lock 2.5 lbs

* Available for SERIES T100, T170, T180, T1900, T2000 and C8800. NOT FOR T1400/T1800/T1900 MODELS WITH BCR SUFFIX.

** Available for SERIES ET100C, ET170C, ET700C and models EH10, EH40, ET279C, ET7115C, ET7215C, ET70215C and ET70115C.

G. Mounting Brackets

Heavy gauge steel mounting bracket mounts to a standard symmetrical rail TS35 according to DIN46277 and

EN50022. Ideal for panel mounting of mechanical or electronic time switch controls, along side of other DIN

rail mountable electrical devices. This snap-in type bracket accepts a wide range of Intermatic time switches

including most T100, T170, T180, T1900, T2000, C8800, ET100, ET170, ET700 and ET70000 time switches.

Model Number Description Weight

22T535GR Din Rail Bracket – 6" x 5" x 2" 1.0 lbs

22T338GR Surface Mount Snap-in Bracket – 6" x 5" x 2" 1.0 lbs

Time Switch Cases

F. 2T2365GA

Flushmount Case

E. T10000R

2-in-1 Raintight Case

22T713

(Brackets Only)

Din Rail

Bracket

Surface

Mount

Bracket

G. 22T338GR 22T535GR

UL & CSA apply to all

enclosures shown.

UL917

E10694

C22.2-177

LR3730

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

ET100 Series 24-Hour Time Switch (Same Operation Each Day)

These time switches provide the same dependable and uncomplicated performance as the T101 mechanical

time switch...plus to-the-minute programming for accurate load control and reduced energy costs. Up to 8 set

points or events (4 ON/4 OFF) can be preset to automatically repeat on a daily basis. The program can be

overridden at any time by placing the selector switch in the Manual position. Two industrial grade “AA”

Alkaline batteries provide 3 years minimum program and timing protection.

Specifications

Case – NEMA 1 – Drawn steel 7-3/4" (19.7 cm) High, 5" (12.7 cm) Wide, 3" (7.6 cm) Deep in gray finish.

Note: The electronic mechanism snaps into the standard Intermatic time switch case, replacing mechanical mechanisms, if desired.

Knockouts – Combination 1/2"-3/4" nominal knockouts, one on back and each side of case and two on

bottom.

Optional Enclosures – See Time Switch Cases for optional enclosures.

Special Voltages and Cycles – ALL models 50 or 60 Hz.

Switch Rating – Except model ET100C. 30 Amp Inductive/Resistive, 24 / 120 / 240 / 277 VAC 60 Hz; 20

Amp Resistive, 28 VDC; 1 HP 120 VAC 60 Hz; 2 HP 240 VAC 60 Hz; 5 Amp Tungsten, 120 / 240 / VAC 60

Hz; 20 Amp ballast,120-277 VAC 60 Hz. ET100C same ratings for 120 Volt loads only. Models ET105C

normally closed contact ratings: 10A Resistive/General purpose, 12 - 277VAC; 10A Resistive/General

purpose, 28VDC; 3A Ballast, 120 - 277VAC; 1/4 HP, 120 VAC; 1/2 HP, 240 VAC; 30 LRA; 12 FLA; 275 VA

pilot duty, 120 - 240 VAC

Carry-over – Field replaceable “AA” batteries maintain program and accurate time keeping for 3 years

minimum. Up front replacement does not require removal of mechanism or field wiring.

Wiring Terminals – #18 to #10 AWG wire.

Minimum ON/OFF Times – 1 minute.

Maximum ON/OFF Times – 23 hours 59 minutes.

Engineering Specification

24 Hour Electronic Time Switch

The time switch shall be a solid state electronic control capable of permitting 8 ON/OFF set points to be distributed on a daily schedule. The

time and set points shall be programmable to the nearest minute with a minimum ON duration of 1 minute and a maximum ON duration of 23

hours and 59 minutes. The timer shall have a digital LCD readout to show time-of-day using 12 hour AM/PM indicator. The time switch shall

provide a manual override control for both temporary or permanent override. Time switch shall operate over a temperature range of -40°F (-

40°C) to 155°F (68°C).

An industrial grade AA alkaline battery shall protect program information and time-of-day for a minimum of 3 years. Switch configuration to be

__________ (SPST) or (DPST) with a UL listed rating of: 30 amp Inductive/Resistive, 24/120/240 Volts AC, 60 Hz; 20 amps Resistive, 28 VDC;

1 HP, 120 Volts AC, 60 Hz; 2 HP, 240 Volts AC, 60 Hz; 5 amps Tungsten, 120/240 Volts AC, 60 Hz; 20 amps Ballast, 120-277 Volts AC, 60 Hz.

The time switch shall be powered by a __________ (120 volt), (120-277 volts) 50/60 Hz source. The time switch shall be enclosed in a

lockable steel NEMA 1 rated enclosure. The time switch shall be UL listed under UL category 916 Energy Management Equipment and shall be

INTERMATIC Model __________.

Model# Circuits Switch Clock Voltage Amp Rating HP Rating Enclosure

ET100C 1 SPST 120 30 1HP NEMA1

ET100CM11 SPST 120 30 1HP Mech.

ET101C 1SPST 120 30 1HP / 2HP NEMA1

ET102C 1 SPST 120/208/240/277 30 1HP / 2HP NEMA1

ET103C 1 DPST 120 30 1HP / 2HP NEMA1

ET104C 1DPST 120/208/240/277 30 1HP / 2HP NEMA1

ET104CP21 DPST 120/208/240/277 30 1HP / 2HP NEMA3R

ET105C 1 SPDT 120 10/30 1HP / 2HP NEMA1

1Mechanism only no case.

2NEMA 3R UV resistant polycarbonate plastic case.

Electronic Energy Controls

24-Hour Electronic Time Switches

UL917

C22.2-177

LR3730

2.5 lbs

1.1 kg

-40°F

(-40°C)

155°F

(68°C)

Applications:

• Schools

• Offices

• Airports

• Stores

• Hotels

• Restaurants

• Parks

• Apartments

For Controlling:

• Water Heaters

• Parking Lot Lighting

• Commercial Ovens

• Interior Lighting

• Air Conditioners

• Fans/Blowers/Pumps

• Livestock Feeders

• Poultry Equipment

• Process Equipment

ET170 Series 7-Day Time Switch (Permits Different Operation Each Day)

These electronic time switches provide to-the-minute programming for accurate load control and reduced

energy costs. Up to 20 set points or events (10 ON/10 OFF or any combination) can be preset to automatically

repeat on a weekly or daily basis. The program can be overridden at any time by placing the selector switch in

the Manual position. These time switches provide for true 7-day load control with up to 140 operations

(70 ON/70 OFF or any combination) each week. Model ET279C provides 20 operations or momentary contact

closures of 1 to 8 seconds (ten each or any combination) for two independent circuits.

Specifications

Case – NEMA 1 – Drawn steel 7-3/4" (19.7 cm) High, 5" (12.7 cm) Wide, 3" (7.6 cm) Deep in gray finish.

NEMA 3R – Drawn steel 9-3/8" (23.8 cm) high, 5-1/2" (14.0 cm) wide, 3-5/8" (9.0 cm) deep in gray finish.

Both types include permanently attached side hinged door with lockable hasp. Mounting holes and/or

mounting bracket included. Separate grounding terminal.

Note: The electronic mechanism snaps into the standard Intermatic time switch case, replacing mechanical mechanisms, if desired.

Knockouts – Combination 1/2"-3/4" nominal knockouts, one on back and each side of case and two on

bottom.

Optional Enclosures – See Time Switch Cases for optional enclosures.

Special Voltages and Cycles – ALL models 50 or 60 Hz.

Switch Rating – 30 Amp Inductive/Resistive, 24 / 120 / 240 / 277 VAC 60 Hz; 20 Amp Resistive, 28 VDC;

1 HP 120 VAC 60 Hz; 2 HP 240 VAC 60 Hz; 5 Amp Tungsten, 120 / 240 / VAC 60 Hz; 20 Amp ballast,

120-277 VAC 60 Hz. ET100C same ratings for 120 Volt loads only. Model ET175C normally closed contact

ratings: 10A Resistive/General purpose, 12 - 277VAC; 10A Resistive/General purpose, 28VDC; 3A Ballast,

120 - 277VAC; 1/4 HP, 120 VAC; 1/2 HP, 240 VAC; 30 LRA; 12 FLA; 275 VA pilot duty, 120 - 240 VAC

Carry-over – Field replaceable “AA” batteries maintain program and accurate time keeping for 3 years

minimum. Up front replacement does not require removal of mechanism or field wiring.

Wiring Terminals – #18 to #10 AWG wire.

Minimum ON/OFF Times – 1 minute.

Maximum ON/OFF Times – 6 days 23 hours 59 minutes.

Engineering Specification

7 Day 30 Amp Electronic Time Switches

The time switch shall be a solid state electronic control capable of permitting 20 ON/OFF set points to be distributed on independent daily

schedules through a 7-day time period. The time switch shall include a 7-day repeat feature for simplifying programming of identical set points.

The time and set points shall be programmable to the nearest minute with a minimum ON duration of 1 minute and a maximum ON duration of

6 days, 23 hours, 59 minutes. The timer shall have a digital LCD readout to show day of week and time-of-day using 12 hour AM/PM indicator.

The time switch shall provide a manual override control for both temporary or permanent override. Time switch shall operate over a temper-

ature range of -40°F (-40°C) to 155°F (68°C). An industrial grade AA alkaline battery shall protect program information and time-of-day for a

minimum of 3 years. Switch configuration to be __________ (SPST) or (DPST) with a UL listed rating of: 30 amp Inductive/Resistive,

24/120/240 Volts AC, 60 Hz; 20 amps Resistive, 28 VDC; 1 HP, 120 Volts AC, 60 Hz; 2 HP, 240 Volts AC, 60 Hz; 5 amps Tungsten, 120/240

Volts AC, 60 Hz; 20 amps Ballast, 120-277 Volts AC, 60 Hz.

The time switch shall be powered by a __________ (120 volt), (120-277 volts) 50/60 Hz source. The time switch shall be enclosed in a

lockable steel NEMA 1 rated enclosure. The time switch shall be UL listed under UL category 916 Energy Management Equipment and shall be

INTERMATIC Model __________.

Model# Circuits Switch Clock Voltage Amp Rating HP Rating Enclosure

ET171C 1SPST 120 30 1HP / 2HP NEMA1

ET171CR11SPST 120 30 1HP / 2HP NEMA3R

ET173C 1 DPST 120 30 1HP / 2HP NEMA1

ET174C 1DPST 240 30 1HP / 2HP NEMA1

ET175C 1 SPDT 120 10/30 1HP / 2HP NEMA1

ET279C2,3 2 SPST 120 30 1HP / 2HP NEMA1

1NEMA 3R drawn steel enclosure.

2User selectable contacts independent 2xSPST, simultaneous DPST, or pulsed for mechanically held contactor operation.

3Complies with California Title 24 requirements for multi-level outdoor lighting control.

Electronic Energy Controls

7-Day Electronic Time Switches

UL917

C22.2-177

LR3730

2.5 lbs

1.1 kg

-40°F

(-40°C)

155°F

(68°C)

ENERGY CODE UPDATE

In 2002 the Department of Energy (DOE) settled

on ASHRAE 90.1-1999 as the commercial

building standard for state building energy

codes acting on its authority under the Energy

Conservation & Production Act. The deadline

set by the DOE for state compliance was July

15, 2004 by which each state must enact

energy codes at least as strict as the standard

or provide justification for non-compliance.

Intermatic offers a variety of products to assist

the specifying engineer and contractor with

meeting the ASHRAE 90.1-1999 requirements

including the Next Generation series of

programmable time switches, spring wound

and electronic in-wall timers, and a full line of

photo controls.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

ET8000 Series 7-Day Astronomic Time Switch (Tracks Sunrise & Sunset)

Intermatic’s Electronic Astronomic 7-Day Time Switch automatically switches loads according to a preset

weekly schedule with to-the-minute accuracy. The astronomic feature provides sunset ON and sunrise OFF

settings to eliminate the need for separate photo control devices. The independent 7-day programming

provides complete flexibility for applications where load switching differs each day of the week. Astronomic

programming can be combined with independent programs to provide a sunset ON and timed OFF program.

Specifications

Case – NEMA 1 – Drawn steel 7-3/4" (19.7 cm) High, 5" (12.7 cm) Wide, 3" (7.6 cm) Deep in gray finish.

NEMA 3R – Drawn steel 9-3/8" (23.8 cm) high, 5-1/2" (14.0 cm) wide, 3-5/8" (9.0 cm) deep in gray finish.

Both types include permanently attached side hinged door with lockable hasp. Mounting holes and/or

mounting bracket included. Separate grounding terminal.

Note: The electronic mechanism snaps into the standard Intermatic time switch case, replacing mechanical mechanisms, if desired.

Knockouts – Combination 1/2"-3/4" nominal knockouts, one on back and each side of case and two on

bottom.

Optional Enclosures – See Time Switch Cases for optional enclosures.

Special Voltages and Cycles – ALL models 50 or 60 Hz.

Switch Rating – 30 Amp Inductive/Resistive, 24 / 120 / 240 / 277 VAC 60 Hz; 20 Amp Resistive, 28 VDC;

1 HP 120 VAC 60 Hz; 2 HP 240 VAC 60 Hz; 5 Amp Tungsten, 120 / 240 / VAC 60 Hz; 20 Amp ballast,

120-277 VAC 60 Hz. Model ET8115C normally closed contact ratings: 10A Resistive/General purpose,

12 - 277VAC; 10A Resistive/General purpose, 28VDC; 3A Ballast, 120 - 277VAC; 1/4 HP, 120 VAC; 1/2 HP,

240 VAC; 30 LRA; 12 FLA; 275 VA pilot duty, 120 - 240 VAC

Carry-over – Field replaceable “AAA” batteries maintain program and accurate time keeping for 3 years

minimum. Up front replacement does not require removal of mechanism or field wiring.

Wiring Terminals – #18 to #10 AWG wire.

Minimum ON/OFF Times – 1 minute.

Maximum ON/OFF Times – 6 days 23 hours 59 minutes.

Engineering Specification

7 Day 30 Amp Electronic Time Switches

The time switch shall be a solid state electronic control capable of permitting 14 ON, 14 OFF set points to be distributed on independent daily

schedules through a 7-day time period with 1 astro ON and 1 astro OFF set point per controlled channel . The time switch shall include a 7-day

repeat feature for simplifying programming of identical set points. The time and set points shall be programmable to the nearest minute with a

minimum ON duration of 1 minute and a maximum ON duration of 6 days, 23 hours, 59 minutes. The timer shall have a digital LCD readout to

show day of week, time-of-day, and date using 12 hour AM/PM indicator. The time switch shall provide a manual override control for both

temporary or permanent override. Time switch shall operate over a temperature range of -40°F (-40°C) to 155°F (68°C).

An industrial grade AAA alkaline battery shall protect program information and time-of-day for a minimum of 3 years. Switch configuration to

be __________ (SPST) or (DPST) with a UL listed rating of: 30 amp Inductive/Resistive, 24/120/240 Volts AC, 60 Hz; 20 amps Resistive, 28

VDC; 1 HP, 120 Volts AC, 60 Hz;

2 HP, 240 Volts AC, 60 Hz; 5 amps Tungsten, 120/240 Volts AC, 60 Hz; 20 amps Ballast, 120-277 Volts AC, 60 Hz

The time switch shall be powered by a __________ (120 volt), (120-277 volts) 50/60 Hz source. The time switch shall be enclosed in a

lockable steel NEMA 1 rated enclosure. The time switch shall be UL listed under UL category 916 Energy Management Equipment and shall be

INTERMATIC Model __________.

Model# Circuits Switch Clock Voltage Amp Rating HP Rating Enclosure

ET8015C 1 SPST 120/208/240/277 30 1HP / 2HP NEMA1

ET8015CPD82 1 SPST 120/208/240/277 30 1HP / 2HP NEMA3R

ET8015CR11 SPST 120/208/240/277 30 1HP / 2HP NEMA3R

ET8115C 1 SPDT 120/208/240/277 10/30 1HP / 2HP NEMA1

ET8115CPD82 1 SPDT 120/208/240/277 10/30 1HP / 2HP NEMA3R

ET8115CR11 SPDT 120/208/240/277 10/30 1HP / 2HP NEMA3R

ET8215C2,3 2 SPST 120/208/240/277 30 1HP / 2HP NEMA1

ET8215CPD822,3 2 SPST 120/208/240/277 30 1HP / 2HP NEMA3R

ET8215CR1,2,3 2 SPST 120/208/240/277 30 1HP / 2HP NEMA3R

1NEMA 3R drawn steel enclosure.

2User selectable contacts independent 2xSPST, simultaneous DPST, or pulsed for mechanically held contactor operation.

3Complies with California Title 24 requirements for multi-level outdoor lighting control.

Electronic Energy Controls

7-Day Electronic Astronomic Time Switches

UL917

C22.2-177

LR3730

2.5 lbs

1.1 kg

-40°F

(-40°C)

155°F

(68°C)

Applications:

• Schools

• Offices

• Airports

• Stores

• Hotels

• Restaurants

• Parks

• Apartments

For Controlling:

• Water Heaters

• Parking Lot Lighting

• Commercial Ovens

• Interior Lighting

• Air Conditioners

• Fans/Blowers/Pumps

• Livestock Feeders

• Poultry Equipment

• Process Equipment

CPD82

NEMA 3R with clear cover

ASHRAE 90.1-1999 Section

9.2.1.3 Exterior Lighting

Control

Lighting for all exterior applications not

exempted in 9.1 and 9.3.2 shall be controlled

by a photosensor or astronomical time switch

that is capable of automatically turning off the

exterior lighting when sufficient daylight is

available or the lighting is not required.

The Intermatic Next Generation series provides

an easy to program time-of-day lighting

control. The multiple zones, as required in the

standard, are available in 1, 2, 4, 8, or 16 zones

of control. Space control for each zone can be

provided by a remote timed override. Each

override can be set for the code required

maximum of four hours.

ET70000 Series 365-Day Time Switch (1 & 2 Circuit Models)

These electronic time switches provide to-the-minute programming for 7-day or full year load control.

Features: 12/24 Hr clock format, 1,000 + ON/OFF events, 99 holiday schedules, and auto daylight savings time

adjustment. Flexible load control is enhanced by Astro, Variable Pulse, and Interval options as required for

outdoor lighting control, bell ringing and after hours temporary override respectively. Non-volatile memory

maintains all programmed switching times for the life of the time switch. A factory installed field replaceable

lithium battery maintains accurate time keeping and calender information for a minimum of 8 years.

Specifications

Case – NEMA 1 – Drawn steel 7-3/4" (19.7 cm) High, 5" (12.7 cm) Wide, 3" (7.6 cm) Deep in gray finish.

NEMA 3R – Drawn steel 9-3/8" (23.8 cm) high, 5-1/2" (14.0 cm) wide, 3-5/8" (9.0 cm) deep in gray finish.

Both types include permanently attached side hinged door with lockable hasp. Mounting holes and/or

mounting bracket included. Separate grounding terminal.

Note: The electronic mechanism snaps into the standard Intermatic time switch case, replacing mechanical mechanisms, if desired.

ON/OFF Events – 1,000+ Events.

Knockouts – Combination 1/2"-3/4" nominal knockouts, one on back and each side of case and two on

bottom.

Optional Enclosures –See Time Switch Cases for optional enclosures.

Special Voltages and Cycles – Line voltage models 50 or 60 Hz; Low voltage models 60 Hz 24 Volts.

Switch Rating – Each Pole; 20 amp resistive/general purpose, 12–277 Volts AC; 20 amp resistive/general

purpose, 28 Volts DC; 20 amp ballast, 120–277 VAC; 1 HP, 120 VAC 60 Hz; 98 LRA; 22 FLA; 2 HP, 240 VAC

60 Hz; 80 LRA; 30 FLA; 5 amp tungsten, 120–240 VAC; 470 VA pilot duty, 12–240 VAC; TV-5, 120–240

VAC

Carry-over – Non-volatile memory requires no backup. Time keeping and calender data maintained within

0.01% accuracy for minimum of 8 years with one factory installed, field replaceable lithium coin cell.

Wiring Terminals – #18 to #10 AWG wire.

Minimum ON/OFF Times – 1 minute.

Maximum ON/OFF Times – 6 days 23 hours 59 minutes.

Engineering Specification

365 Day 1, 2, & 4 Circuit Electronic Astronomic Time Switches

The time switch shall be a solid state electronic control capable of permitting 1000 ON/OFF set points to be distributed on independent daily

schedules through a 7-day time period and across 99 separate holiday schedules. The time switch shall include a 7-day repeat feature for

simplifying programming of identical set points. The time and set points shall be programmable to the nearest minute with a minimum ON

duration of 1 minute and a maximum ON duration of 6 days, 23 hours, 59 minutes. The timer shall have a digital LED readout to show

day-of-week and time-of-day using 12/24 hour time format. The time switch shall provide a manual override control for both temporary or

permanent override. Time switch shall operate over a temperature range of -40°F (-40°C) to 155°F (68°C). A non-volatile memory shall

maintain all program data for the life of the time switch without the need for battery backup. The time switch shall include a factory installed

lithium battery backup which shall maintain clock time and calendar data for 8 years minimum. Switch configuration to be SPDT for each

circuit with a UL 916 Energy Management Equipment listed rating of: Normally Open Contacts Each Pole; 20 amp resistive/general purpose,

12-277 Volts AC; 20 amp resistive/general purpose, 28 Volts DC; 20 amp ballast, 120-277 VAC; 1 HP

, 120 VAC 60 Hz; 98 LRA; 22 FLA; 2 HP

240 VAC 60 Hz; 80 LRA; 30 FLA; 5 amp tungsten, 120-240 VAC; 470 VA pilot duty, 12-240 VAC; TV-5, 120-240 VAC Normally Closed Contacts

10 Amp Resistive/general purpose, 12-277 VAC; 10 Amp Resistive/general purpose, 28 Volts DC; 3 Amp ballast, 120-277 VAC; 1/4 HP

, 120 VAC

60 Hz; 1/2 HP

, 240 VAC 60 Hz; 30 LRA; 12 FLA; 275 VA pilot duty, 12-240 VAC. The time switch shall be enclosed in a lockable steel _____

(NEMA 1) (NEMA 3R) enclosure. The time switch shall be powered by a __________ (user selectable 120, 208, 240 or 277 VAC 50 or 60 Hz)

(24 VAC 60 Hz) source. The time switch shall be INTERMATIC Model ________________ (ET70115C, ET70115CR or ET70115CR24 1-circuit)

(ET70215C, ET70215CR or ET70215CR24 2-circuits)

Model# Circuits Switch Clock Voltage Amp Rating HP Rating Enclosure

ET70115C 1 SPDT 120/208/240/277 20 1HP / 2HP NEMA1

ET70115CR11 SPDT 120/208/240/277 20 1HP / 2HP NEMA3R

ET70115CR2411 SPDT 24 20 1HP / 2HP NEMA3R

ET70215C2,3 2 SPDT 120/208/240/277 20 1HP / 2HP NEMA1

ET70215CR1,2,3 2SPDT 120/208/240/277 20 1HP / 2HP NEMA3R

ET70215CR241,2,3 2SPDT 24 20 1HP / 2HP NEMA3R

1NEMA 3R drawn steel enclosure.

2User selectable contacts independent 2xSPST, simultaneous DPST, or pulsed for mechanically held contactor operation.

3Complies with California Title 24 for multi-level outdoor lighting control.

Electronic Energy Controls

365-Day Electronic Astronomic Time Switches

UL917

C22.2-177

LR3730

2.5 lbs

1.1 kg

-40°F

(-40°C)

155°F

(68°C)

UL916

E76987

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

ET70000 Series 365-Day Time Switch (4, 8, & 16 Circuit Models)

These electronic time switches provide to-the-minute programming for 7-day or full year load control.

Features: 12/24 Hr Clock Format, 4,000+ ON/OFF Events (8 & 16 circuit models only), 99 Holiday Schedules,

and Auto Daylight Savings Time Adjustment. Flexible load control is enhanced by Astro, Variable Pulse, and

Interval options as required for outdoor lighting control, bell ringing and after hours temporary override

respectively. Non-volatile memory maintains all programmed switching times for the life of the time switch.

A factory installed field replaceable lithium battery maintains accurate time keeping and calender information

for a minimum of 8 years.

Specifications

Case – 4-Circuit NEMA 3R – Heavy duty .047" 18 gauge steel in gray finish; 12-1/2" (31.7 cm) High, 8-1/4"

(21.0 cm) Wide, 4" (10.2 cm) Deep. 8-Circuit NEMA 3R - Heavy duty .048" steel in gray finish; 10-3/4"

(27.3 cm) High, 11-1/2" (29.2 cm) Wide, 4-3/4" (12.1 cm) deep with lockable hasp. 16-Circuit NEMA 3R -

Heavy duty .060" steel in gray finish; 20-5/8" (52.4 cm) High, 13-1/4" (33.7 cm) Wide, 5-1/8" (13.0 cm)

Deep with lockable hasp.

ON/OFF Events – 4-Circuit - 1,000+ Events; 8 & 16-Circuit - 4,000+ Events.

Special Voltages and Cycles – Line voltage models 50 or 60 Hz; Low voltage models 60 Hz 24 Volts.

Switch Rating – Each Pole; 20 amp resistive/general purpose, 12–277 Volts AC; 20 amp resistive/general

purpose, 28 Volts DC; 20 amp ballast, 120–277 VAC; 1 HP, 120 VAC 60 Hz; 98 LRA; 22 FLA; 2 HP,

240 VAC 60 Hz; 80 LRA; 30 FLA; 5 amp tungsten, 120–240 VAC; 470 VA pilot duty, 12–240 VAC; TV-5,

120–240 VAC

Carry-over – Non-volatile memory requires no backup. Time keeping and calender data maintained within

0.01% accuracy for minimum of 8 years with one factory installed, field replaceable lithium coin cell.

Wiring Terminals – #18 to #10 AWG wire.

Engineering Specification

365 Day 8 & 16 Circuit Electronic Astronomic Time Switches

The time switch shall be a solid state electronic control capable of permitting 4000+ ON/OFF set points to be distributed on independent daily

schedules through a 7-day time period and across 99 separate holiday schedules. The time switch shall include a 7-day repeat feature for

simplifying programming of identical set points. The time and set points shall be programmable to the nearest minute with a minimum ON

duration of 1 minute and a maximum ON duration of 6 days, 23 hours, 59 minutes. The timer shall have a digital LED readout to show day-of-

week and time-of-day using 12/24 hour time format. The time switch shall provide a manual override control for both temporary or permanent

override. Time switch shall operate over a temperature range of -40°F (-40°C) to 155°F (68°C). A non-volatile memory shall maintain all

program data for the life of the time switch without the need for battery backup. The time switch shall include a factory installed lithium battery

backup which shall maintain clock time and calendar data for 8 years minimum. Switch configuration to be SPDT for each circuit with a UL 916

Energy Management Equipment listed rating of: Normally Open Contacts Each Pole; 20 amp resistive/general purpose, 12-277 Volts AC;

20 amp resistive/general purpose, 28 Volts DC; 20 amp ballast, 120-277 VAC; 1 HP, 120 VAC 60 Hz; 98 LRA; 22 FLA; 2 HP, 240 VAC 60 Hz;

80 LRA; 30 FLA; 5 amp tungsten, 120-240 VAC; 470 VA pilot duty, 12-240 VAC; TV-5, 120240 VAC| Normally Closed Contacts 10 Amp

Resistive/general purpose, 12-277 VAC; 10 Amp Resistive/general purpose, 28 Volts DC; 3 Amp ballast, 120-277 VAC; 1/4 HP, 120 VAC 60 Hz;

1/2 HP, 240 VAC 60 Hz; 30 LRA; 12 FLA; 275 VA pilot duty, 12-240 VAC. The time switch shall be enclosed in a lockable steel _____ (NEMA 1)

(NEMA 3R) enclosure. The time switch shall be powered by a __________ (user selectable 120, 208, 240 or 277 VAC 50 or 60 Hz)

(24 VAC 60 Hz) source. The time switch shall be INTERMATIC Model ________________ (ET70815CR or ET70815CR24 8-circuit)

(ET71615CR or ET71615CR24 16-circuits).

Model# Circuits Switch Clock Voltage Amp Rating HP Rating Enclosure

ET70415CR14SPDT 120/208/240/277 20 1HP / 2HP NEMA3R

ET70415CR2414 SPDT 24 20 1HP / 2HP NEMA3R

ET70815CR18SPDT 120/208/240/277 20 1HP / 2HP NEMA3R

ET70815CR2418 SPDT 24 20 1HP / 2HP NEMA3R

ET71615CR116 SPDT 120/208/240/277 20 1HP / 2HP NEMA3R

ET71615CR24116 SPDT 24 20 1HP / 2HP NEMA3R

1Complies with California Title 24 requirements for multi-level outdoor lighting control.

Electronic Energy Controls

365-Day Electronic Astronomic Time Switches

Applications:

• Schools

• Offices

• Airports

• Stores

• Hotels

• Restaurants

• Factories

• Parks

• Apartments

For Controlling:

• Water Heaters

• Parking Lot Lighting

• Commercial Ovens

• Interior Lighting

• Bells & Signals

• HVAC Equipment

• Fans/Blowers/Pumps

• Livestock Feeders

• Poultry Equipment

• Process Equipment

UL917

C22.2-177

LR3730

2.5 lbs

1.1 kg

-40°F

(-40°C)

155°F

(68°C)

UL916

E76987

Unleash the Power of the Next Generation Time Switch!

The NextGen programming software written specifically for installing contractors and maintenance personnel

is the fastest and easiest way to program the Intermatic Next Generation series of electronic time switches.

Features

• Programming of all current Next Generation models (1, 2, 4, 8, & 16 circuits)

• Easy point-n-click programming of holiday and daily event schedules

• File save function for archiving event schedules for future editing and use

• On-line help manual gives easy to follow directions

• One-button time and date programming synchronizes the time switch with your PC's date and time

Request Item# 300ET10018

Networking capabilities allow programming of the Next Generation time switches

allowing facility managers to make schedule changes from across the building or

campus through an intranet or even across country through the Internet.

Electronic Energy Controls

Next Generation Programming Software

NEXT GENERATION

ACCESSORIES

ET7232M / ET7232M1

RS232 Serial Interface for all Next Generation

Time switches. Also used as remote override for

1 & 2 circuit models.

156ET9402A

8-Circuit remote override input header. (Not

Pictured)

156ET9403A

16-Circuit remote override input header.

LAN Connection to a PC

Office computers are typically connected through

a local area networks (LANs) which provides an

in-place backbone to allow control of Next

Generation time switches from any linked PC.

This applies to office buildings as well as

distributed facilities such as university or

corporate campuses.

NextGen Distributed Control

By linking distributed Next Generation time

switches together with the facility manager’s PC

the time and associated cost of making periodic

schedule changes is greatly reduced and all

timing throughout the network can be

synchronized to the second with the PC’s internal

clock.

Facility Manager’s Office

Outdoor Lighting

Control

Building

Automation

HVAC

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

SiteMaster Site Lighting Control Panels

These heavy duty lighting control panels are designed for harsh environmental and lighting load conditions.

Features include; Pre-wiring for quick installation, heavy-duty NEMA 3R enclosures, mercury or “Ice Cube”

relays, agency approved disconnect, 40, 80, 120 Amp design, locking hasps, and dead-front storage.

Mechanical or electronic timing, lightning arrester, photo control, and stainless steel options.

SM2200 Series Specifications

Gasketless panel with two 20 Amp DPST Relays. Pre-wired with one 20 Amp double-pole Square D

Homeline™ main breaker. 120 V output: one twin 20 Amp breaker & one single-pole 20 Amp breaker

(for 240 V output- quad breaker with common trip on outside and inside). Capable of controlling

40 Amps @ 120 V and 20 Amps @ 240 V or 12- 400 Watt HID fixtures.

SM4400 Series Specifications

Gasketless panel with two 20 Amp DPST Relays. Pre-wired with one 40 Amp double-pole Square D

Homeline™ main breaker. 120 V output: Six single-pole 20 Amp breakers (240 V output: three double-pole

20 Amp breakers). Capable of controlling 80 Amps @ 120 V and 40 Amps @ 240 V or 24- 400 Watt HID

fixtures.

SM6600 Series Specifications

Gasketless panel with one 60 Amp DPST mercury relay. Split buss service- Upper buss. 120 V output:

Pre-wired with one 60 Amp double-pole Square D Homeline™ main breaker and one-single pole 20 Amp

breaker (240 V output: one 60 Amp double-pole and one 20 Amp double-pole breaker) Lower Buss - for

load connections. Eight single-pole 20 Amp breakers (for 240 V output - four double-pole breakers).

Capable of controlling 120 Amp @ 120 V and 60 Amps @ 240 V or 36- 400 Watt HID fixtures.

SM6240DOT & SM6277DOT Series Specifications

Gasketless 14 AWG stainless-steel panel with 3-point locking system. SM6240DOT: 60 Amp DPST mercury

relay. Split buss service- Upper buss. 120 V output: Pre-wired with one 60 Amp double-pole

Square D Homeline™ main breaker and one single-pole 20 Amp breaker. Lower Buss - for load

connections: Four double-pole 20 Amp breakers. Capable of controlling 60 Amps @ 240 V or 36- 400 Watt

HID fixtures. Pre-installed 15 Amp GFCI duplex convenience receptacle. SM6277DOT: 60 Amp 3PST

mercury relay. Input power 480/277 V 3-Phase: Pre-wired with one 60 Amp 3-Phase main breaker and one

single-phase 20 Amp breaker. Load Output: Six 20 Amp 277 V Single-Phase breakers. Capable of

controlling 180 Amps @ 277 V or 54- 400 Watt HID fixtures.

Engineering Specification

Site Lighting Control Panel

The site lighting control panel shall incorporate agency approved disconnect means with lockout capability, branch circuit breakers for feeding

connected lighting loads, electrically held contactor suitable for switching attached loads, and timing mechanism for control of said contactor.

The control panel shall be pre-wired for installation convenience and reliability. The control panel shall be designed to accept a variety of timing

mechanisms including mechanical and electronic. The control panel and all related

components shall operate over a temperature range of -31°F (-35°C) to 130°F (54°C). The capacity of each branch circuit within the control

panel shall be 20 amps minimum. The control panel shall be a lockable steel NEMA 3R enclosure. The control panel shall be INTERMATIC

Model ________________ (SM2200x-x 2-branch; 4,800 Watt HID) (SM4400x-x 6-branch; 9,600 Watt HID) (SM6600x-x 8-branch; 14,400 Watt

HID) (SM6240DOT) (SM6277DOT).

Electronic Energy Controls

Site Lighting Control Panels

Applications:

• Schools

• Offices

• Airports

• Stores

• Hotels

• Restaurants

• Factories

• Apartments

• Electrical Utilities

• Municipalities

For Controlling:

• Roadway Lighting

• Parking Structures

• Parking Lots

• Billboards

• Entertainment Venues

• Ball Fields

• Driving Ranges

• Parks

• Outdoor Area Lighting

C22.2-177

LR3730

-40°F

(-40°C)

130°F

(54°C)

Model# Time Switch/Description # Outputs Output VAC Photo Control

SM2200*1 T103M Mechanical Time Switch 2 120 VAC No

SM2200*2 T103M Mechanical Time Switch 2 120 VAC Yes

SM2200*3 ET101CM Electronic Time Switch 2 120 VAC No

SM2200*4 ET101CM Electronic Time Switch 2 120 VAC Yes

SM2200*5 ET279C Electronic Time Switch 2 120 VAC No

SM2200*6 ET279C Electronic Time Switch 2 120 VAC Yes

SM2200*7 ET104CM Electronic Time Switch 1 240 VAC No

SM2200*8 ET104CM Electronic Time Switch 1 240 VAC Yes

SM2200*16 ET8215CM Astronomic Time Switch 2 120 VAC No

Model# Time Switch/Description # Outputs Output VAC Photo Control

SM4400*1 T103M Mechanical Time Switch 4 120 VAC No

SM4400*2 T103M Mechanical Time Switch 4 120 VAC Yes

SM4400*3 ET101CM Electronic Time Switch 4 120 VAC No

SM4400*4 ET101CM Electronic Time Switch 4 120 VAC Yes

SM4400*51ET279C Electronic Time Switch 4 120 VAC No

SM4400*61ET279C Electronic Time Switch 4 120 VAC Yes

SM4400*7 ET70115C Electronic Astro Time Switch 4 120 VAC No

SM4400*81ET70215C Electronic Astro Time Switch 4 120 VAC No

SM4400*91ET70215C Electronic Astro Time Switch 4 120 VAC Yes

SM4400*10 T104M Mechanical Time Switch 2 240 VAC No

SM4400*11 T104M Mechanical Time Switch 2 240 VAC Yes

SM4400*12 ET104CM Electronic Time Switch 2 240 VAC No

SM4400*13 ET104CM Electronic Time Switch 2 240 VAC Yes

SM4400*141ET70215C Electronic Astro Time Switch 2 240 VAC No

SM4400*16 ET8215CM Astronomic Time Switch 4 120 VAC No

Model# Time Switch/Description # Outputs Output VAC Photo Control

SM6600*1 T103M Mechanical Time Switch 8 120 VAC No

SM6600*2 T103M Mechanical Time Switch 8 120 VAC Yes

SM6600*3 ET101CM Electronic Time Switch 8 120 VAC No

SM6600*4 ET101CM Electronic Time Switch 8 120 VAC Yes

SM6600*5 ET104CM Electronic Time Switch 4 240 VAC No

SM6600*6 ET104CM Electronic Time Switch 4 240 VAC Yes

SM6600*71ET279CM Electronic Time Switch 8 120 VAC No

SM6600*81ET279CM Electronic Time Switch 8 120 VAC Yes

SM6600*9 ET70115C Electronic Astro Time Switch 8 120 VAC No

SM6600*101ET70215C Electronic Astro Time Switch 8 120 VAC No

SM6600*16 ET8215CM Astronomic Time Switch 8 120 VAC No

1Two independent circuits for bi-level or 2-sided control. Complies with California Title 24 requirements for multi-level outdoor lighting control

Electronic Energy Controls

Pre-Wired For Faster Installations

SM2200*7

Standard Steel

Case –

Stainless-Steel

Case S

Lightning Arrestor

Option LA

Lightning Arrester &

Stainless-Steel LAS

SM6600*7

Standard Steel

Case –

Stainless-Steel

Case S

Lightning Arrestor

Option LA

Lightning Arrester &

Stainless-Steel LAS

SM4400*7

Standard Steel

Case –

Stainless-Steel

Case S

Lightning Arrestor

Option LA

Lightning Arrester &

Stainless-Steel LAS

SITE LIGHTING PANEL

TIME SWITCH OPTIONS

Mechanical, Electronic, & Astronomic Field

Changeable Mechanisms

Panel Dimensions

C22.2-177

LR3730

C22.2-177

LR3730

C22.2-177

LR3730

SM2200

SM4400

SM6600

15”

4.75”

9”

17”

4.75”

11”

28”

5”

13”

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

FD Decorator Series Auto-Off Timers

These energy saving timers use no electricity to operate. These timers are designed to replace any standard

wall switch, single or multi-gang, and automatically limit the “ON” time of fans, lights, motors, heaters and

other energy consuming loads. Time limits of 5, 15, 30 and 60 minutes and 2, 4, 6 and 12 hours are available.

The “hold feature” allows the user to override the automatic shut-off function for extended use of the load as

required. Supplied with a molded white, ivory or almond time dial plate designed to fit either toggle or

decorator style switch plates; single or multi-gang with no field modifications required to fit either style switch

plate. Time saving “up front” terminal connection with teeter type terminals and an easy “press-on” knob

design ensure quick and easy installation.

Specifications

Switch Rating –

Inductive: 20 Amp 125 VAC 50/60 Hz; 10 Amp 250 VAC 50/60 Hz; 10 Amp 277 VAC 50/60 Hz,

Tungsten: 7 Amp 125 VAC,

Motor: 1 HP 125 VAC 50/60 Hz; 2 HP 250 VAC 50/60Hz

Caution: Do not use for sunlamps, sauna, etc...

Colors – Available in White, Ivory, and Almond

Style – Decorator Styling - Can be used with decorator or toggle type switch plates.

Engineering Specification

Spring Wound Auto Shut-Off Timer (a.k.a. Interval Timer).

Provide and install as indicated a mechanical spring wound timer that requires no electricity to operate the timing mechanism. The timer shall

be supplied with a threaded shaft. The timer must be able to fit a standard 2-1/2 inch deep wall box and accept a rectangular decorator wall

plate, standard toggle switch plate or be capable of mounting easily in a panel board. Timer contacts shall break current at the end of timed

cycle. Various timing ranges and switch contact arrangements shall be available up to 12 hours, with or without “HOLD” feature for constant

ON. Timer shall be Intermatic Model FD______ (Fill in for required time range, contact arrangement and color).

Time Cycle IVORY WHITE ALMOND

without hold with hold without hold with hold without hold only

SPST

5 minute FD5M N/A FD5MW N/A N/A

15 minute FD15MC FD15MH FD15MWC FD15MHW FD15MAC

30 minute FD30MC FD30MH FD30MWC FD30MHW FD30MAC

60 minute FD60MC FD60MH FD60MWC FD60MHW FD60MAC

2 hour FD2H N/A FD2HW N/A N/A

4 hour FD4H N/A FD4HW N/A N/A

6 hour FD6H FD60HH FD6HW FD6HHW N/A

12 hour FD12HC FD12HH FD12HWC FD12HHW N/A

SPDT Can be used as a normally closed for “Reverse Action” applications

2 hour FD32H N/A FD32HW N/A N/A

4 hour FD34H N/A FD34HW N/A N/A

6 hour FD36H N/A FD36HW N/A N/A

12 hour N/A N/A FD312HW N/A N/A

DPST

15 minute FD415M N/A N/A N/A N/A

30 minute FD430M N/A FD430MW N/A N/A

60 minute FD460M N/A FD460MW N/A N/A

6 hour FD46H N/A FD46HW N/A N/A

12 hour N/A N/A N/A N/A N/A

Decorator (FD) timers shipped with timer, color coordinated time dial and knob.

In-Wall Electrical Devices

Spring Wound Auto-Off Timers

Applications:

• Indoor Lighting

• Outdoor Lighting

• Lighting Overrides

• Exhaust Fans

• Whole House Fans

• Ventilating Fans

• Tennis Court Lighting

• Pumps

• Air Conditioners

• Steam Rooms

• Bathroom Fans

• Whirlpools

• Porch Lights

• Broom Closets

• Carriage Lights

• Television Sets

• Self Storage Units

• Engine Block Heaters

• Process Controls

2.5 lbs

1.1 kg

-40°F

(-40°C)

155°F

(68°C)

UL916

E76987

C22.2-177

LR3730

FF Commercial Series Auto-Off Timers

These energy saving commercial timers use no electricity to operate. These timers are designed to replace any

standard wall switch, single or multi-gang, and automatically limit the “ON” time of fans, lights, motors,

heaters and other energy consuming loads. Time limits of 5, 15, 30 and 60 minutes and 2, 4, 6 and 12 hours

are available. The “hold feature” allows the user to override the automatic shut-off function for extended use

of the load as required. Rugged time-dial plate takes the abuse encountered in commercial environments.

Time saving “up front” terminal connection with teeter type terminals and an easy “press-on” knob design

ensure quick and easy installation.

Specifications

Switch Rating –

Inductive: 20 Amp 125 VAC 50/60 Hz; 10 Amp 250 VAC 50/60 Hz; 10 Amp 277 VAC 50/60 Hz,

Tungsten: 7 Amp 125 VAC,

Motor: 1 HP 125 VAC 50/60 Hz; 2 HP 250 VAC 50/60Hz

Caution: Do not use for sunlamps, sauna, etc...

Colors – Commercial “brush metal” look.

Style – New simulated metal finish meets NEC requirements.

Engineering Specification

Spring Wound Auto Shut-Off Timer (a.k.a. Interval Timer).

Provide and install as indicated a mechanical spring wound timer that requires no electricity to operate the timing mechanism. The timer shall

be supplied with a threaded shaft. The timer must be able to fit a standard 2-1/2 inch deep wall box with commercial wall plate or be capable of

mounting easily in a panel board. Timer contacts shall break current at the end of timed cycle. Various timing ranges and switch contact

arrangements shall be available up to 12 hours, with or without “HOLD” feature for constant ON. Timer shall be Intermatic Model FF______

(Fill in for required time range and contact arrangement).

Time Cycle Without Hold With Hold Without Hold With Hold

SPST DPST

5 Minute FF5M FF5MH N/A N/A

15 Minute FF15MC FF15MH FF415M N/A

30 Minute FF30MC FF30MH FF430M N/A

60 Minute FF60MC FF60MHC FF460M N/A

2 Hour FF2H N/A N/A N/A

4 Hour FF4H N/A N/A N/A

6 Hour FF6H FF6HH FF46H N/A

12 Hour FF12HC FF12HHC FF412H N/A

SPDT

15 Minute FF315M N/A

30 Minute FF330M N/A

60 Minute FF360M N/A

2 Hour FF32H FF32HH

4 Hour FF34H FF34HH

6 Hour FF36H N/A

12 Hour FF312H FF312HH

In-Wall Electrical Devices

Spring Wound Auto-Off Timers

ASHRAE 90.1-1999

Section 9.2.1.2

Space Control

Each space enclosed by ceiling height

partitions shall have at least one control device to

independently control the general lighting within

the space. Each control device shall be activated

either manually by an occupant or automatically

by sensing an occupant.

Each control device shall:

(a) control a maximum of 2,500 sq ft area for a

space 10,000 sq ft or less and a maximum

of 10,000 sq ft area for a space greater than

10,000 sq ft,

(b) be capable of overriding the shutoff control

required in 9.2.1.1 for no more than four

hours, and

occupant can see the controlled lighting for

a maximum of four hours.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

ASHRAE 90.1-1999

Section 9.2.1.2

Space Control

Each space enclosed by ceiling height partitions

shall have at least one control device to

independently control the general lighting within

the space. Each control device shall be activated

either manually by an occupant or automatically

by sensing an occupant.

Each control device shall:

(a) control a maximum of 2,500 sq ft area for

a space 10,000 sq ft or less and a

maximum of 10,000 sq ft area for a space

greater than 10,000 sq ft,

(b) be capable of overriding the shutoff

control required in 9.2.1.1 for no more

than four hours, and

occupant can see the controlled lighting

for a maximum of four hours.

EI200 Series Decorator Electronic Auto-Off Timer

The EI200 series timers provide silent operation in time ranges from 30 minutes up to 12 hours. Four basic

models available in three colors reduce the need to stock as many timers, freeing up shelf space and providing

more specification flexibility. Replaces single-pole switches in a variety of applications.

Specifications

Switch – Single-pole

Switch Rating –

Resistive (heater): 15 Amp, 120 VAC 1800 Watts;

Tungsten (incandescent): 8.3 Amp, 120 VAC 1000 Watts;

Ballast (Fluorescent): 8 Amp, 120 VAC;

Motor: 1/4 H.P., 120 VAC;

Caution: Do not use for sunlamps, sauna, etc...

Colors – Available in White, Ivory, and Light Almond

Style – Decorator Styling.

Special Voltages and Cycles – 50 or 60 Hz.

Engineering Specification

Electronic Auto Shut-Off Timer (a.k.a. Interval Timer).

Provide and install as indicated an electronic timing mechanism. The timer shall be supplied with an LED display and single-button operation.

The timer must be able to fit a standard wall box and accept a rectangular decorator wall plate. Timer contacts shall break current at the end of

timed cycle. Timer shall be capable of single-pole operation. Various user selectable timing ranges shall be available up to 12 hours, with or

without “HOLD” feature for constant ON. Timer shall be Intermatic Model ______ (For 5/10/15/30 Minute EI200 - Ivory, EI200W - White,

EI200LA - Light Almond; For 10/20/30/60 Minute EI210 - Ivory, EI210W - White, EI210LA - Light Almond; For 1/2/4/8 Hour EI220 - Ivory,

EI220W - White, EI220LA - Light Almond; For 2/4/8/12 Hour EI230 - Ivory, EI230W - White, EI230LA - Light Almond).

Max

Model# Time Range Switch Clock Voltage Wattage Color HOLD

EI200 5/10/15/30 Minute Single-Pole 120 VAC 1,800 Ivory Yes

EI200W 5/10/15/30 Minute Single-Pole 120 VAC 1,800 White Yes

EI200LA 5/10/15/30 Minute Single-Pole 120 VAC 1,800 Light Almond Yes

EI205* 5/15/30/45/60 Minute Single-Pole 120 VAC 1,800 Ivory No

EI205W* 5/15/30/45/60 Minute Single-Pole 120 VAC 1,800 White No

EI205LA* 5/15/30/45/60 Minute Single-Pole 120 VAC 1,800 Light Almond No

EI210 10/20/30/60 Minute Single-Pole 120 VAC 1,800 Ivory Yes

EI210W 10/20/30/60 Minute Single-Pole 120 VAC 1,800 White Yes

EI210LA 10/20/30/60 Minute Single-Pole 120 VAC 1,800 Light Almond Yes

EI215** 15/30/60 Minute, 2/4Hour Single-Pole 120 VAC 1,800 Ivory No

EI215W** 15/30/60 Minute, 2/4Hour Single-Pole 120 VAC 1,800 White No

EI215LA** 15/30/60 Minute, 2/4Hour Single-Pole 120 VAC 1,800 Light Almond No

EI220 1/2/4/8 Hour Single-Pole 120 VAC 1,800 Ivory Yes

EI220W 1/2/4/8 Hour Single-Pole 120 VAC 1,800 White Yes

EI220LA 1/2/4/8 Hour Single-Pole 120 VAC 1,800 Light Almond Yes

EI230 2/4/8/12 Hour Single-Pole 120 VAC 1,800 IvoryYes

EI230W 2/4/8/12 Hour Single-Pole 120 VAC 1,800 White Yes

EI230LA 2/4/8/12 Hour Single-Pole 120 VAC 1,800 Light Almond Yes

*Meets or exceeds CEC Title 24, ASHRAE 90.1 and IECC requirements for enclosed spaces.

** Meets or exceeds ASHRAE 90.1 Requirements for enclosed spaces.

In-Wall Electrical Devices

Electronic Auto-Off Timers

2.5 lbs

1.1 kg

UL916

E76987

-32°F

(0°C)

158°F

(70°C)

Compact Mechanical In-Wall Time Switches

These compact heavy-duty 24-hour timers can be used to turn on lights, fans, pumps and other heavy-duty

loads for energy savings, security and convenience. Its compact, quiet, low profile design has easy to set tabs

for precise 24-hour control. Models are available for single gang, 2-gang and dual timer applications. Easy

set tabs provide for minimum on/off times of 20 minutes for up to 36 ON/OFF events daily. A manual ON or

OFF override provides for permanent on or off override of loads at any time.

Three models; E1120 - a single timer model, E1220 - a single timer with a 2-gang switch plate for a toggle

switch, and E1221 - a single timer with a 2-gang switch plate for a decorator switch. All four models include

awhite metal single or 2-gang switch plate as required. The toggle or decorator switch is not included with

timers. Model E1221 with decorator switch plate can be wired to control a decorator style receptacle or GFCI

receptacle to provide for “timed receptacle” control.

Specifications

Size – All models 1-1/4" (3.18 cm) Deep. Model E1120 - 4-1/2" (11.43 cm) H, 2-3/4" (6.99 cm) W;Models

E1220, E1221 and E1222 - 4-1/2" (11.43 cm) H, 4-9/16" (11.59 cm) W.

Switch Rating – 120 Volt AC, 60 Hz, 15 Amps, 1875 Watts Resistive 1350 Watts Tungsten, 1/2 HP Motor

Load, 8 Amp Inductive

Manual Control – Timers can be turned on and off manually for temporary or permanent control.

Color – White switch plate and trippers, black dial.

Max

Model# Plate Only Switch Volts /60Hz Amps Wattage Min. On/Off Time Max. On/Off Time

E1120 24EB5495 SPST 120 15 1875 20 mins. 23 hrs. 40 mins.

E1220 24EB5497 SPST 120 15 1875 20 mins. 23 hrs. 40 mins.

E1221 24EB5524 SPST 120 15 1875 20 mins. 23 hrs. 40 mins.

Heavy Duty In-Wall Time Switches

These heavy duty timers can be used to turn on lights, fans, pumps and other heavy duty loads for energy

savings, security and convenience. The timer is designed to mount to any standardjunction box for replacing

awall switch. Models are available in single ON / OFF or multiple ON / OFF type. Both models have an easy

to use manual override.

Model E1010 equipped with a 24 hour dial divided in half-hour increments with a permanently attached “ON”

and “OFF” tripper permitting single “ON / OFF” control every24 hours. Model E1020 equipped with a multiple

program dial. The dial accommodates 12 “ON” and 12 “OFF” trippers. Furnished with two “ON” and two “OFF”

trippers. Both timers have three color code leads and require a hot, neutral and one side of the load.

Specifications

Size – 4-1/4" (10.8 cm) High, 3-1/4" (9.5 cm) Wide, 1-3/8" (3.5 cm) Deep.

Switch Rating – 120 VAC 60 Hz; 1440 Watts Tungsten; 12 Full load Amps.; 15 Amp max load.

Timing Cycle – Minimum “ON” time 1/2 hour, maximum “ON” time 22-1/2 hours; Minimum time between

any two “ON” trippers (and any two “OFF” trippers) is 2 hours.

Max

Model# Switch Volts Amps Wattage Color

E1010 SPST 120 15 1800 Stonedust white housing

E1020 SPST 120 15 1800 Stonedust white housing

For additional trippers for E1020 (2 “ON” / 2 “OFF” per pack), order No. 156EB1945A.

In-Wall Electrical Devices

24-Hour Mechanical Time Switches

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

For Controlling:

•Hall Lights

•Ceiling Lights

•Whole House Fans

• Paddle Fans

•Porch Lights

•Outdoor Lights

•Air Conditioners

•Coffee Makers

•Boilers

•Attic Fans

•Industrial Fans

•Automated Control

ASHRAE 90.1-1999

Section 9.2.1.1

Automatic Lighting Shutoff

Interior lighting in buildings larger than 5,000

sq. ft. shall be controlled with an automatic

control device to shut off building lighting in all

spaces.

This automatic control device

shall function on either;

(a) atime-of-day operated control

device that turns lighting offat

specific programmed times, and

independent program schedule shall

be provided for areas of no more

than 25,000 sq ft but not more than

one floor or

(b) an occupant sensor that shall turn

lighting off within 30 minutes of an

occupant leaving a space or

2.5 lbs

1.1 kg

UL916

E76987

C22.2-177

LR3730

UL917

C22.2-177

LR3730

2.5 lbs

1.1 kg

Applications:

•Schools

•Offices

•Airports

•Stores

•Hotels

•Restaurants

•Parks

•Apartments

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

EI500 Series Decorator Digital 7-Day Time Switch

The EI500 series compact 7-day timers provides up to 7-ON and 7-OFF operations per week which can be

used for 24-hour or 7-day load control of lights, fans, pumps, and other medium-duty loads for energy

savings, security, and convenience. Its compact, quiet, low profile design is easy to program for to-the-minute

24-hour or 7-day control. In addition, the display continuously shows time of day, day of the week, timer load

and the load status. Available in three colors white, ivory, and light almond. Replaces single-pole switches

in a variety of applications.

Specifications

Switch – Single-pole

Switch Rating –

Resistive (heater): 15 Amp, 120 VAC 1800 Watts;

Tungsten (incandescent): 8.3 Amp, 120 VAC 1000 Watts;

Ballast (fluorescent): 8Amp, 120 VAC;

Motor: 1/4 H.P., 120 VAC;

Caution: Do not use for sunlamps, sauna, etc...

Events – 7ON & 7 OFF Events per Day.

Colors – Available in White, Ivory, and Light Almond

Style – Decorator Styling.

Special Voltages and Cycles – 50 or 60 Hz.

Engineering Specification

Electronic 7-Day Timer.

The timer switch shall be a solid state electronic control capable of permitting 7-ON and 7-OFF set points to be distributed through a

7-day time period. The time and set points shall be programmable to the nearest minute with a minimum ON duration of 1 minute and a

maximum ON duration of 6 days, 23 hours, 59 minutes. The timer shall have a backlit digital LCD readout to show day-of-week and time-of-day

using 12 hour AM/PM indicator. The time switch shall provide a manual override control for both temporary or permanent override.

Time switch shall operate over a temperature range of 32°F (0°C) to 158°F (70°C). An internal rechargeable battery shall protect program

information and time-of-day for a minimum of 36 hours. Switch configuration to be SPST with a UL listed rating of: 20 amp Resistive,

120 Volts AC, 50/60 Hz; 15 amps Resistive, 120 Volts AC, 50/60 Hz; 1/4 HP, 120 Volts AC, 50/60 Hz; 8.3 amps Tungsten, 120 Volts AC,

50/60 Hz; 10 amps Ballast, 120 Volts AC, 50/60 Hz The timer must be able to fit a standard wall box and accept a rectangular decorator wall

plate. Timer contacts shall make or break current according to user adjustable program. Timer shall be Intermatic Model ______ (Ivory - EI500,

White - EI500W, Light Almond - EI500LA)

Max

Model# Switch Clock Voltage Wattage Color

EI500C Single-Pole 120 VAC 50/60 Hz 1,800 Ivory

EI500WC Single-Pole 120 VAC 50/60 Hz 1,800 White

EI500LAC Single-Pole 120 VAC 50/60 Hz 1,800 Light Almond

In-Wall Electrical Devices

24-Hour Mechanical Time Switches

ASHRAE 90.1-1999

Section 9.2.1.1

Automatic Lighting Shutoff

Interior lighting in buildings larger than 5,000

sq ft shall be controlled with an automatic

control device to shut offbuilding lighting in all

spaces.

This automatic control device

shall function on either;

(a) a time-of-day operated control device

that turns lighting off at specific

programmed times, and independent

program schedule shall be provided for

areas of no more than 25,000 sq ft but

not more than one floor or

(b) an occupant sensor that shall turn

lighting off within 30 minutes of an

occupant leaving a space or

2.5 lbs

1.1 kg

UL916

E76987

32°F

(0°C)

158°F

(70°C)

EI600 Series Decorator Electronic 7-Day Astro Time Switch

This easy to program timer provides up to 40 ON/OFF operations per week which can be used for 24-hour or

7-day load control. The astronomic feature provides sunset ON and sunrise OFF settings and the auto daylight

savings adjustment means you can “set-it and forget-it”. The independant 7-day programming provides

complete flexibility for applications where load switching differs each day of the week. Astronomic

programming can be combined with independant programs to provide a sunset ON and timed OFF program.

Afactory supplied CR2 lithium battery provides up to three years of time keeping without AC power and user

program selections are stored in non-volatile memory. A low battery indicator appears in the display when the

batteryrequires replacement. In addition, the display continuously shows time of day, day of the week, timer

load and the load status. The timer has an isolated single pole single throw switch which allows the timer to

switch any load type, including PAR lamps and motor loads from 12 to 277 volts AC or 12 to 28 volts DC,

within the specified ratings. A “3 wire” design allows the timer to replace, or be used as a single-pole or 3-

way (multi-way) switch.

Specifications

Switch – Single-pole or 3-way (Multi-way) Compatable

Switch Rating –

Resistive (heater): 20 Amp, 120-277 VAC

Tungsten (incandescent): 15 Amp, 120 VAC; 6 Amp, 208-277 VAC

Ballast (fluorescent): 16 Amp, 120-277 VAC

Motor: 1H.P., 120 VAC; 2 H.P., 240 VAC; 4 Amp, DC Loads:12 VDC; 2 Amp, 28 VDC

Caution: Do not use for sunlamps, sauna, etc...

Events – 40 ON/OFF Events per week.

Colors – Available in White, Ivory, and Light Almond

Style – Decorator Styling.

Special Voltages and Cycles – 50 or 60 Hz.

Warranty – 5 Years

Engineering Specification

Electronic 7-Day astronomic Timer.

The timer switch shall be a solid state electronic control capable of permitting 40 ON/OFF set points to be distributed through a

7-day time period with 1 astroON and 1 astroOFF set point per day. The time and set points shall be programmable to the nearest minute with

aminimum ON duration of 1 minute and a maximum ON duration of 6 days, 23 hours, 59 minutes. The timer shall have a digital LCD readout

to show day-of-week and time-of-day using 12 hour AM/PM indicator.The time switch shall provide a manual override control for both

temporaryor permanent override.

Time switch shall operate over a temperaturerange of 32°F (0°C) to 104°F (40°C). A lithium battery provides up to three years of time keeping

without AC power and user program selections arestored in a non-volatile memory. Switch configuration to be SPST with a UL listed rating of:

Resistive (heater): 20 Amp,120-277 VAC; Tungsten (incandescent):15 Amp, 120 VAC; 6 Amp, 208-277 VAC; Ballast (Fluorescent): 16 Amp,

120-277 VAC; Motor: 1 H.P., 120 VAC; 2 H.P., 240 VAC; 4 Amp, DC Loads: 12 VDC; 2 Amp, 28 VDC. The timer must be able to fit a standard

wall box and accept a rectangular decorator wall plate. Timer contacts shall make or break current according to user adjustable program. Timer

shall be Intermatic Model ______ (Ivory-EI600, White - EI600W, Light Almond - EI600LA)

Max

Model# Switch Contact Wattage Color

EI600C Single-Pole / 3-way 12 - 277 VAC;12 - 28 VDC 1,800 - 4,155 Ivory

EI600WC Single-Pole / 3-way 12 - 277 VAC;12 - 28 VDC 1,800 - 4,155 White

EI600LAC Single-Pole / 3-way 12 - 277 VAC;12 - 28 VDC 1,800 - 4,155 Light Almond

In-Wall Electronic Devices

7-Day Electronic Time Switch

2.5 lbs

1.1 kg

UL917

C22.2-177

LR3730

32°F

(0°C)

158°F

(70°C)

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Applications:

•Schools

•Offices

•Airports

•Stores

•Hotels

•Restaurants

•Parks

•Apartments

For Controlling:

•Indoor Lighting

•Outdoor Lighting

•Pumps & Fans

•HID Lighting

•Library Lights

•Classroom Lights

•Fluorescent Lighting

• PAR Lights

•Heaters

•Recreational Vehicles

•Air Conditioners

•Porch Lights

•Carrage Lights

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

InTouch™ — The Centerpiece for Peaceful Living

Z-wave™ makes reliable wireless home control possible. Intermatic makes it a reality with the InTouch™ series

of wireless controls. Until now home controls had only two options — reliable controls that were too

expensive or low cost controls that were unreliable. That’s all changed with Intermatic’s InTouch wireless

controls, which bring reliable controls together with low cost to deliver a home solution everyone can enjoy.

Named the Best New Emerging Technology by CNET at the 2006 Consumer Electronic Show, and recipient of

the Electronic House Product of the Year Award, Z-wave is a breakthrough technology that enables products

from many different manufacturers to seamlessly work together. This same technology lies at the center of

Intermatic’s InTouch home control system.

Several factors contribute to make Z-wave a breakthrough innovation. First is the “mesh” network, which

basically means that everyline-powered device within the network acts as a repeater to route signals among

distant devices. Second is that Z-wave networks operate in the 900Mhz band, providing a penetrating signal

to deliver reliable communications between devices. Another factor is that with more than 4 billion unique

house codes, Z-wave provides a secure network with no fear of interference from neighboring systems. Finally,

Z-wave has made the leap from theory to reality as more than 100 companies are working in the Z-wave

Alliance to develop actual products that benefit homeowners today and in the near future.

What this means to homeowners, is they now have all of the convenience, comfortand safety of a reliable home

control system without concerns of system reliability, product/ installation costs or compatibility between

products.

The Intermatic InTouch system helps homeowners “set the scene” for entertaining, working or just relaxing

after a long day.Homeowners can now manage and monitor lighting, security systems and other electronics

easily,conveniently and securely from anywhere in the world. Functions such as indoor and outdoor

lighting, entry access, pool & spa functions, home theater systems, window treatments and

heating & cooling are a breeze with Intermatic’s InTouch control system.

InTouch Wireless Controls™

Wireless Home Controls

Intermatic’s InTouch system has taken Z-wave technology to an even higher level of functionality with the intro-

duction of its patent pending InTouch server technology. The InTouch server provides full two-way, real-time

status of every device in the network including legacy Z-wave devices. The InTouch server also makes a host

of never before seen features available to the installer and homeowner including:

• Greater network range – doubling the number of “hops” a signal can take to get to its target from the Z-wave standard

of 4 to 8

• In-field firmware upgrade capability – future-proofing an InTouch network from protocol changes

• System text and graphics messaging – allowing streaming information such as sports scores, stock quotes, weather

and news alerts as well as personal and system status messages

• Centralized scene and status information – ability to remotely edit scenes from anywhere in the network

• Full Z-wave compatibility – adding an InTouch Server to any manufacturer’s Z-wave product instantly upgrades their

capabilities to share many of the InTouch features

Imagine arriving home from a long day’s work and as you step inside, the temperature of the room is just right,

the lighting level is relaxed and inviting, your audio system is playing your favorite song, the shades are being

drawn for the evening and your spa is warm and bubbling.

At Intermatic, we call this living the InTouch lifestyle. Previous home controls systems capable of providing a

similar level of service as InTouch wereexpensive, took weeks to install and didn’tdeliver the same

functionality.

InTouch provides the safety, security and convenience homeowners are looking for while making it price-

accessible for everyone. With an InTouch residential controls package from Intermatic, electrical contractors,

designers, home builders and custom installers can provide homeowners with a robust and intelligent system

for a fraction of the cost of current competitive systems. Best of all, the system can be expanded easily to grow

with homeowners’ changing needs. And since it’s powered by Z-wave technology, InTouch is 100% compatible

with the growing number of Z-wave enabled products.

InTouch products are backed by a 10-year warranty and more than 115 years of experience in the electrical

industry. The controllers, switches and receptacles are designed to complement any décor and the intuitive

controls are designed for minimal programming effort and maximum system functionality.

For the Professional installer:

• Earn back lost sales by offering customers an affordable, full-bodied system at a price that will shock them for being so

affordable.

•Easy Installation equals less spent on time and labor.InTouch devices install with existing wiring and both network

setup and system programming are quick and easy.

• Fewer SKUs means less inventory. Intermatic’s growing line of InTouch products offer changeable faceplates and

combination switches to keep the number of devices the distributor or installer needs to inventory to a minimum.

• Adaptability makes InTouch the perfect solution for new construction as well as retrofit applications.

For the Homeowner:

• Advanced technology fosters a progressive lifestyle at a price anyone can afford.

• Home controls add value to the home, increasing prestige and resale values.

• Reliable and secure control network for consistent comfort, convenience and safety.

• Energy savings brought about by improved electrical management.

• Easily modified as your electronic needs change and grow.

InTouch Wireless Controls™

Wireless Home Controls

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

InTouch™ Residential and Small Business Applications

InTouch Wireless Controls™

Wireless Home Controls

CA7100

Central Command

CA5100

Multi-Point

Control

CA600

Dimming

Control

CA3000

Lighting

Control

CA5000

Multi-Scene

Control

CA9000

Motion

Control

CA3500

Appliance

Control

CA3750

Heavy Load

Control

CA5500BR

Portable Command

InTouch™ Product Line

CA7100

In-Wall Master Control

•Features include multiple scene functions, programming

based on time, action or a combination of both, along

with a full 2-way control system

• Built-in astro clock allows lights to go on at sunset and

off at sunrise, never having to reset the timer

• Voltage: 120 volts 50/60 Hz

• Agency approval: FCC, CSA c/us

CA5500BR

Hand Held Remote with Smartbase

•Offers remote scene control, status feedback and a

rechargeable nickel metal hydride battery

• The Smartbase also features network memorybackup

•Agency approval: FCC

CA5000

Multi-Button Scene Controller

• Offers remote scene control and status feedback

• Includes three interchangeable faceplates

• Colors include White, Ivory and Light Almond

• Voltage: 120 volts 50/60 Hz

• Agency approval: FCC, CSA c/us

CA5100

Accessory Wall Controller

• Features include remote scene control, and mini-scenes

• Includes three interchangeable faceplates

• Colors include White, Ivory and Light Almond

• Voltage: 120 volts 50/60 Hz

• Agency approval: FCC, CSA c/us

CA9000

Wireless PIR Sensor

• Features remote scene control and adjustable time delay

• Requires three AA alkaline batteries

• Agency approval: FCC

CA600

Wall Dimmer Switch

•Offers local and remote scene control,

ON/OFF/dim/bright features and LED feedback

• The 3-way option allows consumers to control lights

from multiple locations, using standard switches, and

the mini-scene function allows a light switch to also

trigger a small scene of up to five additional devices

• Includes three interchangeable faceplates

• Colors include White, Ivory and Light Almond

• Voltage: 120 volts 50/60 Hz

• Rating: 600 W Tungsten

• Agency approval: FCC, CSA c/us

CA3000

Wall Switch

•Includes local and remote scene control, ON/OFF, 3-way

option and mini-scenes

• Includes three interchangeable faceplates

• Colors include White, Ivoryand Light Almond

• Voltage: 120 volts 50/60 Hz

• Rating: 1800 Watts 15A Tungsten;

1800 Watts 15A Resistive/Inductive;

1820VA15A Ballast; 1/2HP Motor

• Agency approval: FCC, CSA c/us

CA3500

Split-Duplex Receptacle

• Features one controlled grounded receptacle and local

control

• Includes three interchangeable faceplates

• Colors include White, Ivory and Light Almond

• Voltage: 125 volts 50/60 Hz

• Rating: 15 Amps General Purpose

• Agency approval: FCC, CSA c/us

CA3750

Contactor Module

• For large loads such as air conditioners, spas and

heaters, the contactor module features a local ON/OFF

control and LED feedback

• Voltage: 120, 208, 240, 277 volts 50/60 Hz

• Rating: 6600 Watts 30 A Resistive;

5500VA 25 Amps Inductive;

5540 Watts 20 Amps @ 277VAC Ballast;

4400 Watts 20 Amps Tungsten;

3HP @ 220VAC Motor

• Agency approval: FCC, CSA c/us

InTouch Wireless Controls™

Wireless Home Controls

CA7100

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

CA5500BR CA600

CA5000 CA3000

CA5100 CA3500

CA3750

CA9000

Your Total Professional Solution

Whether you are looking to light a garden pathway or signs

along the highway, Intermatic has a comprehensive line

of professional lighting to suit your every need.

Intermatic recently introduced its line of High

Intensity Discharge (HID) lighting to satisfy

the growing demand for high quality

industrial lighting. With the same high

quality that you’ve come to expect

from Intermatic controls, Intermatic

HID lighting can withstand the

harshest elements while providing

constant and reliable operation.

When married with Intermatic

switches and other HID control

features like time clocks and

photo controls, Intermatic

provides a total lighting

solution from beginning to

end.

Intermatic’sLight Expressions™

series of low voltage lighting

fixtures is a professional grade

series of landscape lighting that

blends superior styling with

extreme durability. The Light

Expressions™line offers

contractors and landscape

designers a high-end family of

landscape fixtures and transformers

to dramatically enhance the

appearance of the home, while adding

safety and security. With Light

Expressions™,one may highlight architecture,

trees, sculpture, decks, paths and more.

Intermatic®professional grade transformers are the most reliable low voltage transformers available.

Manufactured by Intermatic Incorporated – recognized worldwide for high quality timers and system controls

–these transformers are especially designed for trouble-free operation and long lasting durability.

Ensure that all of your professional lighting installations operate trouble-free and provide long-lasting service

by using only Intermatic®professional grade transformers.

“Your success can depend on it!”

Every professional grade transformer includes these important product features:

•Heavy gauge steel housings with rain-tight covers (Model AL60TW uses a high impact polymer construction)

•Complete ground shield protection for safe operation. Suitable for use with submersible luminaries or submersible pumps

•Suitable for use with submersible luminaries or submersible pumps

•Meets UL and cCSAus safety standards

•Automatic or resettable circuit breakers for overload protection, helps prevent damage to electrical components, caused by overheating

Professional Grade Transformers

A. AL300TPWS

•Heavy-duty 16 ga. stainless steel

case

•Built-in photo control option

•Manual ON/OFF switch

•Fully programmable timer

•One set of 300 watt terminal blocks

•Heavy-duty power cord

• 5 Year limited warranty

•Resettable circuit breaker

•Rain tight enclosure with lifetime

limited warranty

B. AL600TPWS

•Heavy-duty 16 ga. stainless steel

case

•Built-in photo control option

•Manual ON/OFF switch

•Fully programmable timer

•Two sets of 300 watt terminal

blocks

•Heavy-duty power cord

• 5 year limited warranty

•Resettable circuit breaker

•Rain tight enclosure with lifetime

limited warranty

C. AL900TPWS

•Heavy-duty 16 ga. stainless steel

case

•Built-in photo control option

•Manual ON/OFF switch

•Fully programmable timer

•Three sets of 300 watt terminal

blocks

•Heavy-duty power cord

• 5 year limited warranty

•Resettable circuit breaker

•Rain tight enclosure with lifetime

limited warranty

D. AL300RTW

•Heavy-duty 18 ga. steel housing

•Manual ON/OFF switch

•Fully programmable timer

•One set of 300 watt terminal blocks

•Heavy-duty power cord

• 5 year limited warranty

•Automatic circuit breaker

•Rain tight enclosure

E. AL600TW

•Heavy-duty 18 ga. steel housing

•Manual ON/OFF switch

•Fully programmable timer

•Two sets of 300 watt terminal

blocks

•Heavy-duty power cord

• 5 year limited warranty

•Automatic circuit breaker

•Rain tight enclosure

F. AL900TW

•Heavy-duty 18 ga. steel housing

•Manual ON/OFF switch

•Fully programmable timer

•Three sets of 300 watt terminal

blocks

•Heavy-duty power cord

• 5 year limited warranty

•Automatic circuit breaker

•Rain tight enclosure

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

All Intermatic AL Transformers meet UL1838 Standards

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Professional Grade Transformers

J. AL300BW

•High-impact PVC case

•Water tight enclosure, can be buried

to ground level

•Can be controlled externally

•Three 1.5” I.D. knockouts for line

voltage conduit

•Automatic circuit breaker

•Ground shield protection for safe

operation

•5year limited warranty

G. AL60TW

•High-impact polymer case

•Manual ON/OFF switch

•Fully programmable timer

•2sets of ON/OFF trippers

•Automatic circuit breaker

•Ground shield protection

•Heavy-duty power cord

•5year limited warranty

•Rain tight enclosure

H. AL300MTW

TRANSFORMER:

•300VA (True Watts) multi-tap

(12V, 13V, 15V)

•Heavy 18 ga. painted steel housing

•Resettable circuit breaker

•Heavy duty power cord code

compliant for use with submersible

luminaries

•Easy hook-up to color coded and

labeled leads

•Conduit ready with knockouts

•10 year limited warranty on

transformer

INDEPENDENT DIGITAL SELF

ADJUSTING INDOOR TIMER:

•Set it once, no re-setting required

• Automatically adjusts

sunrise/sunset times

•Automatically adjusts for daylight

savings time

•Batteryback-up included

•Easy to read LCD display

•One year limited warranty on timer

I. AL600MTW

TRANSFORMER:

•600VA (True Watts) multi-tap

(12V, 13V, 15V)

•Heavy 18 ga. painted steel housing

•Resettable magnetic circuit

breakers (2)

•Heavy duty power cord code

compliant for use with submersible

luminaries

•Easy hook-up to color coded and

labeled leads

•Conduit ready with knockouts

•10 year limited warranty on

transformer

INDEPENDENT DIGITAL SELF

ADJUSTING INDOOR TIMER:

•Set it once, no re-setting required

•Automatically adjusts

sunrise/sunset Times

•Automatically adjusts for daylight

savings time

•Battery back-up included

•Easy to read LCD display

•One year limited warranty on timer

All Intermatic AL Transformers meet UL1838 Standards

Our Professional Grade Lighting line includes a wide range of weatherproof transformers, low voltage fixtures,

specialty insulated cables and a variety of accessories. Intermatic offers an expanded selection of fixtures

designed for easy installation. All have the most advanced features that result from our many years of

experience in low voltage lighting.

Professional Landscape Lighting

AL111

Well Light with 14W

Poly-Star bulb

AL115

Submersible Light

with 20W halogen

MR16 bulb

AL375V

Metal Light with 18W

wedge base bulb and

Verde finish

AL380C

Copper Light with

18W wedge base bulb

AL385V

Brass Light with 18W

wedge base bulb and

Verde Patina finish

AL395

Brass Light with 18W

wedge base bulb and

Aged Brass finish

AL395V

Brass Light with 18W

wedge base bulb and

Verde Patina finish

AL401

Metal Floodlight with

35W MR16 bulb and

Black finish

AL402

Metal Floodlight with

50W PAR36 bulb and

Black finish

AL402TA

Metal Floodlight with

50W PAR36 bulb and

Textured Architectural

Bronze finish

AL403

Metal Floodlight with

35W Halogen MR16

bulb and Black finish

AL403TA

Metal Floodlight with

35W Halogen MR16

bulb and Textured

Architectural Bronze

finish

Accessories

Low Voltage Cable

AL10210

10/2 100 ft.

AL102-5C

10/2 500 ft.

AL12210

12/2 100 ft.

AL122-5C

12/2 500 ft.

AL8-12

Designed specifically

for weatherproof,

outdoor, hard-wire

installations

AL1160

Fixture Ground Stake,

1/2” Female Thread,

Heavy Duty Plastic

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Professional Landscape Lighting

AL405

Brass Light with 18W

wedge base bulb and

Aged Brass finish

AL405V

Brass Light with 18W

wedge base bulb and

Verde Patina finish

AL406

Metal Deck Light with

8W bayonet bulb and

Black finish

AL406TA

Metal Deck Light with

8W bayonet bulb and

Textured Architectural

Bronze finish

AL407TA

Metal Cone Walk

Light with 18W

wedge base bulb and

Textured Architectural

Bronze finish

AL408TA

Metal Dome Walk

Light with 18W

wedge base bulb and

Textured Architectural

Bronze finish

AL409

Metal BollardLight

with 50W MR16 bulb

and Black finish

AL409TA

Metal BollardLight

with 50W MR16 bulb

and Textured

Architectural Bronze

finish

AL425C

Copper Ellipse Light

with 18W wedge base

bulb

AL501

Mini Floodlight with

35W halogen MR16

bulb and Black finish

AL502

Large Floodlight with

50W PAR36 bulb and

Black finish

AL502DS

Large Floodlight with

50W PAR36 bulb and

Dark Sand finish

Professional Landscape Lighting

AL502TA

Large Floodlight with

50W PAR36 bulb and

Architectural Bronze

finish

AL506

Metal Floodlight with

35W halogen MR16

bulb and Black finish

AL508V

Large Path Light with

18W wedge base bulb

and Verde finish

AL510V

Large Brass

Floodlight with 50W

PAR36 bulb and

Verde finish

AL521

Cast Metal Acorn

Style Path Light with

35W halogen MR16

bulb and Black finish

AL550

3Tier Path Light with

18W wedge base bulb

and Black finish

AL550DS

3 Tier Path Light with

18W wedge base bulb

and Dark Sand finish

AL550TA

3 Tier Path Light with

18W wedge base bulb

and Architectural

Bronze finish

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Intermatic’s line of HID lighting is the perfect solution for a wide variety of outdoor lighting needs. In addition,

Intermatic has a full array of controls and sensors designed to complement any residential, commercial or

industrial lighting system.

Wall Packs

Ideal for: Parking Areas, Entrances, Walkways, Underpasses, Loading Docks, Recreation Areas and Tunnels.

PartNumber Wattage Lamp Voltage Finish Lens

WL035HPS 35W High Pressure Sodium 120V Bronze Polycarbonate

WL050HPS 50W High Pressure Sodium 120V Bronze Polycarbonate

120/208/240/277V

WL050MH 50W Metal Halide Quad Tap Bronze Polycarbonate

120/208/240/277V

WL070HPS 70W High Pressure Sodium Quad Tap Bronze Polycarbonate

120/208/240/277V

WL070MH 70W Metal Halide Quad Tap Bronze Polycarbonate

120/208/240/277V

WL100HPS 100W High PressureSodium Quad Tap Bronze Glass

120/208/240/277V

WL100MH 100W Metal Halide Quad Tap Bronze Glass

120/208/240/277V

WL150HPS 150W High Pressure Sodium Quad Tap Bronze Glass

120/208/240/277V

WL150MH 150W Metal Halide Quad Tap Bronze Glass

120/208/240/277V

WL175MH 175W Metal Halide Quad Tap Bronze Glass

120/208/240/277V

WL250HPS 250W High Pressure Sodium Quad Tap Bronze Glass

120/208/240/277V

WL250MH 250W Metal Halide Quad Tap Bronze Glass

120/208/240/277V

WL400HPS 400W High Pressure Sodium Quad Tap Bronze Glass

120/208/240/277V

WL400MH 400W Metal Halide Quad Tap Bronze Glass

High Intensity Discharge (HID) Lighting

WL050MH

WL070MH

WL100MH

WL035HPS

WL050HPS

WL070HPS

WL100HPS

•UL listed for wet locations

•Heavy duty die-cast aluminum powder coating construction

•Corrosion-resistant hardware

•1/2” tapped holes available for installing photocell (photocell

optional)

WL150MH

WL175MH WL150HPS

WL250MH WL250HPS

WL400MH WL400HPS

Floodlights

Ideal for: Buildings, Backyards, Highway Signs, Outdoor Advertising Boards, Parks and Sports Fields

Part Number Wattage Lamp Voltage Finish Lens

FL035HPS 35W High Pressure Sodium 120V Bronze Glass

FL050HPS 50W High Pressure Sodium 120V Bronze Glass

FL070HPS 70W High Pressure Sodium 120V Bronze Glass

120/208/240/277V

FL050MH 50W Metal Halide Quad Tap Bronze Glass

120/208/240/277V

FL070MH 70W Metal Halide Quad Tap Bronze Glass

120/208/240/277V

FL100HPS 100W High PressureSodium Quad Tap Bronze Glass

120/208/240/277V

FL100MH 100W Metal Halide Quad Tap Bronze Glass

120/208/240/277V

FL150HPS 150W High Pressure Sodium Quad Tap Bronze Glass

120/208/240/277V

FL150MH 150W Metal Halide Quad Tap Bronze Glass

120/208/240/277V

FL175MH 175W Metal Halide Quad Tap Bronze Glass

120/208/240/277V

FL250HPS 250W High PressureSodium Quad Tap Bronze Glass

120/208/240/277V

FL250MH 250W Metal Halide Quad Tap Bronze Glass

120/208/240/277V

FL400HPS 400W High Pressure Sodium Quad Tap Bronze Glass

120/208/240/277V

FL400MH 400W Metal Halide Quad Tap Bronze Glass

Dusk-to-DawnLights

Ideal for: Perimeter and Security Lighting, Loading Platforms, Barnyards, Parking Lots, Rural Homes, Public

Entrances and OFF-Street Parking

PartNumber Wattage Lamp Voltage Lens Arm

DD150HPS 150W High Pressure Sodium 120V Polycarbonate 24”

DD175MV 175W Mercury Vapor 120V Polycarbonate 24”

High Intensity Discharge (HID) Lighting

•UL and CUL listed for wet locations

•Heavy duty die-cast aluminum powder coating construction

•Corrosion-resistant hardware

•High impact-resistant tempered glass

•Lamp holder E-26, UL approved

•Multi-tap ballast: 120/208/240/277 Volts

FL035HPS

FL050HPS

FL070HPS

FL050MH

FL070MH

FL100MH

FL100HPS

FL150MH

FL175MH FL150HPS

FL250MH

FL400MH FL250HPS

FL400HPS

•UL listed for wet locations

•Precision die-cast aluminum housing with natural finish

•UV-stabilized PS Lens

•24” arm

•Dusk-to-dawn with twist-lock photo control

•Mounting hardwareincluded

•Lamp holder E-39, 4KV and UL approved

•120 Volt fixture

DD175MV DD150HPS

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Quartz Floodlights

Ideal for: Building Facades, Signs, Sports Fields and Emergency and Temporary Floodlighting

Part Number Wattage Lamp Voltage Finish Lens

FL150Q 150W Quartz Halogen 120V Bronze Glass

FL300Q 300W Quartz Halogen 120V Bronze Glass

FL500Q 500W Quartz Halogen 120V Bronze Glass

Canopy Lights

Ideal for: Parking Areas, Entrances, Walkways, Underpasses, Loading Docks and Recreation Areas

Part Number Wattage Lamp Voltage Finish Lens

120/208/240/277V

CP150HPS 150W High Pressure Sodium Quad Tap Bronze Polycarbonate

Wall Fixture with Photocell

Ideal for: Parking Areas, Entrances, Walkways, Underpasses, Loading Docks and Recreation Areas

Part Number Wattage Lamp Voltage Finish Lens

WL070HPSPC 70W High PressureSodium 120V Bronze Polycarbonate

High Intensity Discharge (HID) Lighting

•UL and CUL listed for wet locations

•Die-cast aluminum construction

•Tempered door glass

•Hinged front door

•1/2” threaded swivel mount

•Dark bronze finish

•120 Volt fixture

FL150Q

FL300Q

FL500Q

•UL listed for wet locations

•Heavy duty die-cast aluminum powder coating construction

•High impact polycarbonate lens

•Corrosion-resistant hardware

•1/2” tapped holes available for installing photocell (photocell

optional)

•multi tap ballast: 120/208/240/277 Volts

•UL listed for wet locations

•High-impact polycarbonate lens and housing

•Aluminum baseplate with conduit access

•Corrosion-resistant hardware

•120 Volt installed photocell included

•Multi-tap ballast: 120 Volt fixture

CP150HPS

WL070HPSPC

Helping Maintain the Luxuries of Life

Few things exceed the pleasure of a refreshing dip in the

pool on a hot summer day or a relaxing soak in the hot

tub on a chilly evening. Intermatic helps maintain

these luxuries with a variety of reliable controls,

which combine economy and flexibility in a

single enclosure.

Too often, as technology advances,

controlling that technology becomes

exceedingly complex. Intermatic has

made a commitment to provide its

customers with controls that are as

easy to install as they are to use.

While maintaining its reputation

for reliability, Intermatic

designs innovative pool and

spa controls that are powerful

and intuitive.

Providing simple, focused

controls allows the consumer

to purchase only the features

they need for their application

–saving money and easing

frustration. Intermatic’s

products are flexible and

designed to work together

cohesively in an endless number

of scenarios. Intermatic controls

reduce installation costs and

maintain consistent performance for

aeration, freeze protection, lighting

and pumping year after year.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PE40000 Series

I-Wave Wireless Pool/Spa Control

Intermatic’s wireless pool and spa controls utilize ground-breaking Z-wave™ technology. While some controls

communicate transmission problems, Intermatic’s wireless devices allow total and uninterrupted

communication between the controller and the equipment.

Intermatic’s modular approach provides for added diversity and convenience. Modules are capable of working

independently or within a system. Portions can be added or replaced without interfering with the original

system, and each system can be designed to incorporate as many or as few features as needed to accomplish

the task at hand – making Intermatic the most value added and cost-effective choice.

All I-Wave Models include wireless transmitter and transceiver, two PE24VA valve actuators, five total circuits

(three timed and two on demand), two-speed control, water temperature display, heater temperature control,

fireman switch, freeze protection and 125 Amp breaker base.

Applications

•Pool/Spa combinations

•Water features

•Fountains

Specifications

Case — 26.0" (66.3 cm) high x 18.0" (45.9 cm) wide x 5.5" (14.0 cm) deep, 0.048" steel with

electrostatically applied light beige finish.

Knockouts: Two combination 3/4”–1”–1-1/4” and eleven combination 1/2”–3/4” knockouts on the bottom.

Two 3/4”–1” combination and four combination 1/2”–3/4” knockouts on the back. Low voltage

compartment has two combination 1/2”–3/4” knockouts and one 3/4” hole with a shutter bushing installed.

Two combination 3/4”–1” and one combination 1/2–3/4” knockouts. One 1-3/4” x 2-3/4” knockout on the

right side.

Switch Rating: P1353ME – see page 70; P4243ME – see page 71

Model Mechanisms Switch Transformer Volts 60Hz Shipping Weight

PE45343RC P1353ME and P4243ME 5 - SPST None 120 or 208-240 44.0 lbs.

PE45343RCT1 P1353ME and P4243ME 5 - SPST 100 Watt 120 or 208-240 51.0 lbs

PE45343RCT3 P1353ME and P4243ME 5 - SPST 300 Watt 120 or 208-240 56.0 lbs

PE650 Wireless Receiver – – – 5.5 lbs

PE950 Wireless Transmitter – – – 5.5 lbs

Digital Wireless Controls

PE950

PE650

Complete System

PE45343RC

PE25 & PE40 Series

I-Pure Stand Alone Salt Chlorine Generator

While traditional Salt Chlorine Generators can be difficult to manage and operate, the new I-Pure Salt Chlorine

Generator takes the hassle out of sanitizing pools and spas. The I-Pure system produces more chlorine than

other Salt Chlorine Generators and provides homeowners with easy-to-use, high quality sanitation at a

competitive price.

Designed for pools up to 25,000 gallons or 40,000 gallons, the I-Pure Stand Alone Salt Generator’s

self-adjustable control dial allows users to increase or decrease chlorine production with ease. The simplified

controls of the I-Pure deliver easy pool maintenance.

Applications

•Residential Pools • Commercial Pools

• Water Features •Fountains

Specifications

Case — 15.0" (38.3 cm) high x 10.5" (26.8 cm) wide x 4.5" (11.4 cm) deep.

Voltage: 120VAC or 240VAC (See Below)

Shipping Weight: See Chart

Agency Approval: ARL

Checklist for proper operation:

Salt 3000 to 4000 ppm

Free Chlorine 1to 3 ppm

PH 7.2 to 7.8

Total Alkalinity 80 to 180 - adjust per calcium hardness level

Stabilizer (Cyanuric Acid) 60 - 80

Nitrates 0 ppm

Metals 0 ppm

Phosphates 0 ppm

Calcium Hardness Determine level for individual pool surface

Saturation Index -0.3 to 0.3 (0 is ideal)

Model Max Gallons Volts 60 Hz Shipping Weight

PE25K120V 25,000 120 22.0 lbs (9.9 kg)

PE25K240V 25,000 208-240 22.0 lbs (9.9 kg)

PE40K120V 40,000 120 22.0 lbs (9.9 kg)

PE40K240V 40,000 208-240 22.0 lbs (9.9 kg)

I-Pure Demo Kits

PEDCHLR -Empty I-Pure shell only

PEDCELL -Empty I-Purecell only

Salt Chlorine Generators

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PE40K240V

Cell Features

The I-Puresystem utilizes plates that are

specially coated to convert regular table salt into

natural chlorine. The system uses the most

advanced self-cleaning technologies, including

reversed polarity, which allows the Cell to stay

cleaner and last longer than other self-cleaning

cells. The clear Cell also allows for easy regular

inspections for calcium build-up.

PE25KCELL

Replacement 25,000 gallon cell only

PE40KCELL

Replacement 40,000 gallon cell only

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

P1353ME

Digital Pool/Spa Mechanism

Designed as part of the I-Wave system and for aftermarket and retro-fit applications, the P1353ME has the

ability to program three circuits and snap into almost any Intermatic enclosure. Five pre-programmed modes

of operation include single speed pump or two-speed pump and booster/cleaner pump combinations. In

addition, programmed modes that include auxiliaries can control pumps up to 3HP as well as underwater,

garden and/or fountain lighting. Countdown and Override features allow cycle interruptions when pool/spa

service is required. All timing and protection associated with filter pump/cleaner pump combinations and two

speed pumps has already been integrated into the software.

Applications

•Single Speed Pump Combos • Water Feature Applications

•Two-Speed Pump/Booster Pump Combos • Garden & Fountain Lighting

•Pool & Spa Lighting • Landscape Lighting

Key Features Include

•Memory Back-Up • 120V or 240V Input

•Heater Protection (Fireman Switch) • LCD Display

•Three On/Off Events per Day per Circuit • Freeze Protection Probe – 178PA28A (optional)

•Wired Remote – 133PE1484A (optional)

Mode 1 – (Aux1, Aux2, Aux3)

The time switch is a 3-circuit switch with all three switches controlling auxiliary devices.

Mode 2 – (Pump High, Pump Low,Aux3)

The time switch is a 2-circuit switch with the 1st & 2nd switch controlling a two-speed pump. The 3rd

switch is controlling any auxiliary device. All protection associated with a two speed pump is

preprogrammed into this mode.

Mode 3 – (Pump, Aux2, Cleaner Pump)

The time switch is a 3-circuit switch with the 1st switch controlling a single speed pump, the 2nd switch

controls any auxiliary device, and the 3rd switch operates a booster/cleaner pump. All timing & protection

associated with a filter pump/cleaner pump combination is preprogrammed into this mode.

Mode 4 – (PumpHigh, PumpLow,Cleaner Pump)

The time switch is a 2-circuit switch with the 1st & 2nd switch controlling a 2-speed pump. The 3rd switch

is controlling a booster/cleaner pump. All protection associated with a 2-speed pump and booster/cleaner

pump combination is preprogrammed into this mode.

Mode 5 – (Pump L1, Pump L2, Aux3)

The time switch is a 2-circuit switch with the 1st & 2nd switch controlling a 240V pump, where both

L1 & L2 arerequired to be disconnected when the pump is OFF. The 3rd switch is controlling any auxiliary

device.

Specifications

Input Voltage – 120 Volt or 208-240 Volt, 50/60 Hz.

Number of Circuits – Up to three SPST 3HP circuits.

Switch Rating (each circuit) – 20 Amp Resistive, 120/240 VAC, 50/60 Hz; 20 Amp FLA @ 120 VAC, 96

Amp LRA @ 120 VAC, 50/60 Hz; 17 Amp FLA @ 240 VAC, 80 Amp LRA @ 240 VAC, 50/60 Hz; 5 Amp

Tungsten, 120/240 VAC, 50/60 Hz; 5 Amp Ballast, 120/240V VAC, 50/60 Hz

Shipping Weight – 3.0lbs. (1.4 kg.)

Note: The P1353ME will not retro-fit into any enclosure that uses stand off posts to attach the mechanism.

Digital Control Mechanisms

P1353ME

133PE1484A

178PA28A

P4243ME

Pump/Valve Actuator Mechanism

Designed as part of the I-Wave system, this electronic control mechanism, especially designed for pool/spa

combinations, will snap into most Intermatic panels and enclosures in use today. Designed as a very versatile,

user-friendly device, it can be combined with a number of different Intermatic controls in order to facilitate a

variety of custom applications. This mechanism can handle two motor loads, up to 3 HP, switch up to

3valve actuators, the heater thermostats and also allow the user to select pool and spa heater operation.

The control options are numerous. For example, the Pool-to-Spa operation can be activated three different

ways. By a remote installed count down timer, a radio receiver or a simple toggle switch. In the pool mode,

any new or existing timer or manual switch may be used to control the filter pump operation. In the Spa mode,

the filter pump and an additional piece of equipment can be controlled by a wired remote on the spa side

(133PE1484A), by wireless remote, or by the buttons provided on the face of the mechanism.

If combined with the P1353ME Digital Pool/Spa mechanism, the two units can handle all the equipment

variations of a pool/spa combination, including two-speed filter pump, cleaner pump, up to three 24 volt valve

actuators, two stage protected heater,jet pump, blower and lights.

Applications

•Pool/Spa Combinations •Filter Pump

•Blower • Jets

•Pool & Spa Lighting • Landscape Lighting

•Water Feature

Specifications

Input Voltage – 120 Volt or 208-240 Volt, 50/60 Hz.

Switch Rating (each circuit) – 17 Amp resistive 120-240V, 10 Amp Tungsten – 120V, 1.5 HP – 120V, 3 HP

–240V,60Hz

Number of Circuits – Up to two DPST 3HP circuits

Shipping Weight – 5lbs (2.2 kg)

Digital Control Mechanisms

P4243ME

133PE1484A

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PE100 Series

Mini PE Series Digital Pool or Spa Controls

Intermatic’s Mini-PE Series Digital Controls couple the standard features of our compact T100 Series

mechanical time switches with the convenience of digital automation. One of Intermatic’s latest innovations,

the P1353ME allows the ability to program up to three circuits. Beyond single and two-speed pump/booster

pump applications, auxiliary modes can control pumps up to 3HP as well as underwater, garden and/or

fountain lighting.

Countdown and override features allow cycle interruptions when pool/spa service is required. All timing and

protection associated with filter pump/booster pump combos and two-speed pumps has already been

integrated into the digital software. The Mini-PE Series is available in both metal and plastic enclosures and

with a wired remote command, freeze probe or both. See chart below for details.

Intermatic makes it simple to convert your Mini-PE Series Digital Control into a Wireless Control System.

Simply install a Panel Mounted Transceiver (RC650) and Hand-Held Transceiver (PE950) to any Mini-PE

Series control, which allows the system to display the status of each of the three circuits as well as pool or spa

water temperature, pool or spa thermostat set point, heating status and overall communication status.

Applications

•Single Speed Pump/Booster Pump Combos • Two-Speed Pump/Booster Pump Combos

•Water Feature Applications • Garden & Fountain Applications

•Pool & Spa Lighting • Landscape Lighting

Specifications

Case – NEMA 3R rated for indoor-outdoor installation. 9-3/8" (23.8 cm) high, 5-1/2" (14.0 cm) wide,

3-5/8" (9.2 cm) deep in beige finish. “P” suffix models are same dimensions, except made from outdoor

grade plastic.

Knockouts – Combination 1/2" – 3/4" nominal knockouts, one on back and each side of case and two

on bottom.

Switch Rating (each circuit) – 20 Amp Resistive, 120/240 VAC, 50/60 Hz; 20 Amp FLA @ 120 VAC, 96

Amp LRA @ 120 VAC, 50/60 Hz; 17 Amp FLA @ 240 VAC, 80 Amp LRA @ 240 VAC, 50/60 Hz; 5 Amp

Tungsten, 120/240 VAC, 50/60 Hz; 5 Amp Ballast, 120/240V VAC, 50/60 Hz

Shipping Weight – 3.7 lbs (1.7 kg)

Agency Approval – CSA/C-US

Model # Description Switch Clock Supply

PE153 Digital Time Clock in Metal Enclosure 3 - SPST 120 or 240V

PE153W Digital Time Clock in Metal Enclosure 3 - SPST 120 or 240V

with 100' Wired Remote Command

PE153F Digital Time Clock in Metal Enclosure 3 - SPST 120 or 240V

with Freeze Protection Probe

PE153WF Digital Time Clock in Metal Enclosure 3 - SPST 120 or 240V

with 100' Wired Remote Command & Freeze Protection Probe

PE153P Digital Time Clock in Plastic Enclosure 3 - SPST 120 or 240V

PE153PW Digital Time Clock in Plastic Enclosure 3 - SPST 120 or 240V

with 100' Wired Remote Command

PE153PF Digital Time Clock in Plastic Enclosure 3 - SPST 120 or 240V

with Freeze Protection Probe

PE153PWF Digital Time Clock in Plastic Enclosure 3 - SPST 120 or 240V

with 100' Wired Remote Command & Freeze Protection Probe

NOTE: See page 68 for PE650 and PE950 specifications and page 70 for P1353ME specifications

Digital Controls

PE153

PE153W

PE153F

PE153WF

PE Series Digital Controls

For pool, spa or water feature applications, the PE Series Digital Controls includes one P1353ME mechanism

that controls a total of three timed circuits, including single-speed or two-speed filter pumps, cleaner/booster

pumps, pool lights, spa lights and landscape lights.

Intermatic makes it simple to convert your PE Series Digital Control into a Wireless Control System. Simply

install a Panel Mounted Transceiver (RC650) and a Hand-Held Transceiver (PE950).

Applications

•Single Speed Pump/Booster Pump Combos • Two-Speed Pump/Booster Pump Combos • Pool & Spa Lighting

•Water Feature Applications • Garden & Fountain Applications • Landscape Lighting

PE25300

Case – 16-1/2" (41.9 cm) high x 10-7/8" (27.6 cm) wide x 4-1/4" (10.8 cm) deep, 0.048" steel with

electrostatically applied light beige finish.

Knockouts – One 1.09 diameter through hole, six combination 1/2"-3/4" knockouts, and three combination

3/4"-1" knockouts on the bottom. Two combination 1/2"-3/4" on the left side and one combination 3/4"-1" on

the back. One knockout 1-3/4" x 2-3/4" on the right side for mounting switches or GFCI.

Panel Rating – 60 Amp 120/240 V.A.C or 120/208 VAC single phase

Switch Rating – P1353ME - See page 70

Agency Approval – CSA/C-US

PE35300

Case – 22" (55.9 cm) high x 14-3/4" (37.5 cm) wide x 4-1/4" (10.8 cm) deep, 0.048" steel with light beige

finish.

Knockouts – One 1.09 diameter through hole, six combination 1/2"-3/4" knockouts, 2 combination 3/4", 1",

1-1/4" knockouts, four 1/2" knockouts on the bottom. Two combination 1/2"-3/4" knockouts on the left side

and four combination 1/2"-3/4" knockouts, two combination 3/4"-1" on the back. One knockout 1-3/4" x 2-

3/4" on the right side for mounting switches or GFCI.

Panel Rating – 80 Amp 120/240 VAC or 120/208 VAC single phase

Switch Rating – P1353ME - See page 70

Agency Approval – CSA/C-US

Model # Description/Mechanism Switch Clock Supply Volts 60 Hz Shipping Weight

PE25300 P1353ME 3–SPST 120 or 240 14.0 lbs (6.3 kg)

PE35300 P1353ME 3-SPST 120 or 240 19.0 lbs (8.6 kg)

PE1500RC Series

Mini-Wave Wireless Pool/Spa Control Panels

For pool/spa combinations or pool/water feature combinations, the PE1541RC controls four circuits, two

PE24VAvalve actuators, Wireless Panel Mounted Transceiver (PE650) and Hand-Held Transceiver (PE950),

which allows the system to display the status of each of the four on-demand circuits, pool and spa water

temperature, pool and spa thermostat set point, heating status and overall communication status. PE1501RC

does not include actuators and is designed for pool or spa applications.

PE1500RC

Panel Rating – 100 Amp 120/240 VAC or 120/208 VAC single phase

Switch Rating – 17A Resistive, 120/240 VAC., 50/60 Hz; 1.5 HP @ 120 VAC., 50/60 Hz; 3.0 HP @ 240

VAC., 50/60 Hz; 10 Amp Tungsten, 120/240 VAC, 50/60 Hz

Shipping Weight – 24.3 lbs. (10.9 kg)

Agency Approval – CSA/C-US

Model # Description/Mechanism Circuits Actuators Switch Clock Supply Volts 60 Hz

PE1541RC PB313E 4 2 4–SPST 120 or 240

PE1501RC PB313E 4 None 4-SPST 120 or 240

Digital Controls

PE25300

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PE35300

PE1541RC

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

T10000R Series

Pool & Spa Control Centers

The T10000R Series Control Centers feature an all-weather enclosure and contain one or two heavy duty timer

mechanisms. In addition, they have provision to install switches or GFCI receptacle on the side and additional

switches inside. The enclosure accepts any combinations of P1353ME or P4243ME or T100M or RC2000M

or PF1000M Series mechanisms.

Applications

•Filter Pumps-Booster Pump Combinations • Yard Lighting

•Filter Pump-Light Controls • Signs

•Pool-Spa Combinations

Specifications

Case – 12" (30.5 cm) H x 12" (30.5 cm) W x 4-1/4" (10.8 cm) D, 0.048" steel with electrostatically applied

light beige finish.

Knockouts – Five combination 1/2"-3/4" and two combination 3/4"-1" knockouts on the bottom. One

combination 1/2"-3/4" on the left side and one combination 3/4"-1" on the back.

One knockout 1-3/4" x 2-3/4" on the right side for mounting switches or GFCI.

Center Rating – 92 Amp per leg, 168 Amp Max. 120-240 VAC or 120-208 VAC single phase - 60 Hz

Time Switch Rating – 30 Amp Resistive Inductive, Tungsten or 1000 VApilot duty each pole 120/208/240

VAC; 2 HP (24 FLA) - 120 VAC; 5 HP (28 FLA) - 240 VAC

Shipping Weight – See Table.

Agency Approval – CSA/C-US

Model # Description/Mechanism Switch Clock Supply Volts 60 Hz Shipping Weight

T10000R Enclosure Only None NA / NA 9.3 lbs (4.2 kg)

T10101R Two T101M SPST – SPST 120 /120 11.0 lbs (5.0 kg)

T10004R One T104M NA – DPST NA / 240 10.5 lbs (4.7 kg)

T10404R Two T104M DPST – DPST 240 / 240 11.0 lbs (5.0 kg)

T10604R* T106M & T104M SPDT – DPST 240 / 240 11.0 lbs (5.0 kg)

T12404R** T104M201 & T104M DPST –DPST 240 / 240 11.0 lbs (5.0 kg)

*For 2 Speed Pump Applications.

** The heater protection switch (fireman switch) is closed when the time switch contacts are open to allow remote operation of

the heater. A flow or pressure switch therefore must always be part of the heater control circuit.

For additional trippers ( 1 “ON” 1 “OFF” per pack), order No. 156T1978A.

For additional “OFF” trippers (25 “OFF” per pack), order No. PA115.

For Stand offs for décor knockouts (4 stand-offs per pack), order No. 21T156A.

Mechanical Controls

T10404R

T10004R

T10000R

T20000R Series

60 Amp Pool/Spa Control Panels

The T20000R Series Control Panels feature an all-weather enclosure and contain a 4 circuit breaker base, an

equipment grounding bar and a mechanical time switch mechanism. The circuit breaker base accepts

interchangeable type breakers made by a number of different manufacturers. In addition, the enclosure

has provision for installing additional switches or GFCI receptacles on the side and inside.

Applications

•Filter Pumps • Lights • Ventilating Systems

•Signs • Air Conditioners • Heaters

Specifications

Case – 16-3/4" (42.6 cm) H x 8-7/8" (22.5 cm) W x 4-3/8" (11.1 cm) D. 0.048" steel with electrostatically

applied light beige finish.

Knockouts – Five combination 1/2"-3/4" and three 3/4" - 1" on the bottom, one combination 1/2"-3/4" on the

left side, one 3/4"-1" on the back and one combination 1-3/4" x 2-3/4" knockout on the right side for

mounting switches or GFCI

Panel Rating – 60 Amp 120/240 VAC or 120/208 VAC; Single Phase-60 Hz

Time Switch Rating – 30 Amp Resistive Inductive, Tungsten or 1000 VA pilot duty each pole 120/208/240

VAC; 2 HP (24 FLA) - 120 VAC; 5 HP (28 FLA) - 240 VAC

Shipping Weight – See table.

Agency Approval – CSA/C-US

Model # Description/Mechanism Switch Clock Supply Volts 60 Hz Shipping Weight

T21000R Enclosure only None NA 11.2 lbs (5.0 kg)

T21001R T101M SPST 120 14.0 lbs (6.3 kg)

T21004R T104M DPST 240 14.0 lbs (6.3 kg)

T20004R* T104M DPST 240 14.0 lbs (6.3 kg)

*T20004R has a limited availability, T21004R is the replacement model.

For additional trippers ( 1 “ON” 1 “OFF” per pack ), order No. 156T1978A

For additional “OFF” trippers (25 “OFF” per pack), order No. PA115

For Stand offs for décor knockouts (4 stand-offs per pack), order No. 21T156A

Mechanical Controls

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

T21000R

T21004R

T20004R

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

T30000R Series

100 Amp Pool/Spa Control Panels

The T30000R Series Control Panels reduce installation costs and provide all of the electrical requirements for

any pool and/or spa installation. They offer an all-in-one electrical control center which can be custom wired

for a wide variety of requirements, and eliminate the need for additional junction boxes and service panels. The

enclosure accepts any combinations of P1353ME or P4243ME or T100M or RC2000M or PF1000M Series

mechanisms

Applications

•Filter Pumps • Booster Pumps • Heating Systems • Lights • Cleaning Systems

•Security Systems • Fountains • Sprinkler Systems • Valve Actuators • Yard Lights

Specifications

Case – 16-1/2" (41.9 cm) H x 10-7/8" (27.6 cm) W x 4-1/4" (10.8 cm) D, 0.048" steel with electrostatically

applied beige finish

Knockouts – Two 1/2", three combination 1/2"-3/4", and two combination 3/4"-1" knockouts on the bottom.

Four 1/2", three combination 1/2"-3/4" on the back. One combination 3/4"-1" on the left side. One 1-3/4" x 2-

3/4" knockout on the right side for mounting switches and GFCI.

Panel Rating – 100 Amp., 120-240 VAC or 120-208 VAC single phase - 60Hz.

Timer Switch Rating – 30 Amp Resistive Inductive, Tungsten or 1000 VA pilot duty each pole 120/208/240

VAC; 2 HP (24 FLA) - 120 VAC; 5 HP (28 FLA) - 240 VAC

Shipping Weight – See table.

Agency Approval – CSA/C-US

Model # Description/Mechanism Switch Clock Supply Volts 60 Hz Shipping Weight

T30000R5 EnclosureOnly None NA / NA 18.6 lbs (8.4 kg)

T30004R One T104M None / SPST NA / 240 18.6 lbs (8.4 kg)

T30401R T104M & T101M DPST / SPST 240 / 120 18.6 lbs (8.4 kg)

T30404R Two T104M DPST / DPST 240 / 240 18.6 lbs (8.4 kg)

T30604R T106M & T104M SPDT / DPST 240 / 240 18.6 lbs (8.4 kg)

T32404R T104M201 & T104M DPST / DPST 240 / 240 18.6 lbs (8.4 kg)

*The heater protection switch (fireman switch) is closed when the time switch contacts are open to allow remote operation of

the heater.Aflow or pressure switch therefore must always be part of the heater control circuit.

For additional trippers ( 1 “ON” 1 “OFF” per pack), order No. 156T1978A.

For additional “OFF” trippers (25 “OFF” per pack), order No. PA115.

For Stand offs for décor knockouts (4 stand-offs per pack), order No. 21T156A.

Mechanical Controls

T30000R5

T30004R

T32404R

T40000R Series

125 Amp Pool/Spa Control Panels

The T40000R Series Control Panels reduce installation costs and provide all of the electrical requirements for

any pool and/or spa installation. They offer an all-in one electrical control center which can be custom wired

for a wide variety of requirements, and eliminate the need for additional junction boxes and service panels. The

enclosure accepts any combinations of P1353ME or P4243ME or T100M or RC2000M or PF1000M Series

mechanisms.

Applications

•Filter Pumps • Booster Pumps • Heating Systems • Lights • Cleaning Systems

•Security Systems • Fountains • Sprinkler Systems • Yard Lights

Specifications

Case – 20-3/4" (52.7 cm) high x 12-3/4" (32.4 cm) wide x 4-1/4" (10.8 cm) deep, 0.048" steel with electro-

statically applied light beige finish

Knockouts – Seven combination 1/2"-3/4" and three combination 3/4"-1" knockouts on the bottom.

Five combination 1/2"-3/4" on the left side. One 1-3/4" x 2-3/4" knockout on the right side for mounting

switches and GFCI

Panel Rating – 1

Timer Switch Rating – 30 Amp Resistive Inductive, Tungsten or 1000 VA pilot duty each pole 120/208/240

VAC; 2 HP (24 FLA) - 120 VAC; 5 HP (28 FLA) - 240 VAC

Shipping Weight – See table.

Agency Approval – CSA/C-US

Model # Description/Mechanism Switch Clock Supply Volts 60 Hz Shipping Weight

T40000R Enclosure Only None NA 16.0 lbs (7.2 kg)

T40004R One T104M DPST NA / 240 20.5 lbs (9.2 kg)

T40404R Two T104M DPST 240 / 240 21.2 lbs (9.5 kg)

For additional trippers ( 1 “ON” 1 “OFF” per pack ), order No. 156T1978A.

For additional “OFF” trippers (25 “OFF” per pack), order NO. PA115.

For additional stand-offs for décor knockouts (4 stand-offs per pack), order No. 21T156A.

T40000R Series

100 Amp Specialty Control Panels

These specialty Control Panels arethe same as the T40000R Series, except they have been designed for

specialty applications. Models include a factory installed GFCI, or stainless steel panel for high corrosive

environments or an inside wiring compartment for two devices. These enclosures accept any combinations of

T100M, P1353ME, P4243ME or T100M or RC2000M or PF1000M Series mechanisms.

Applications - Same as above.

Specifications

Case, Knockouts, Timer Switch Rating & Agency Approval – Same as above

Panel Rating – 115 Amp. 120-240 VAC or 120-208 VAC single phase - 60 Hz.

Shipping Weight – See table.

Model # Description/Mechanism Switch Clock Supply Volts 60 Hz Shipping Weight

T40000R4* Inside Compartment None / None NA / NA 19.4 lbs (8.7 kg)

T40004RSS** One T104M None / DPST NA / 240 20.5 lbs (9.2 kg)

T40004R5 One T104M & GFCI Installed None / DPST NA / 240 21.6 lbs (9.7 kg)

T40404R5 Two T104M & GFCI Installed DPST / DPST 240 / 240 24.6 lbs (11.0 kg)

*Enclosure only with inside wiring compartment for twist-lock receptacle and GFCI.

** Stainless Steel Enclosure.

For additional trippers ( 1 “ON” 1 “OFF” per pack ), order No. 156T1978A.

For additional “OFF” trippers (25 “OFF” per pack), order NO. PA115.

For additional stand-offs for décor knockouts (4 stand-offs per pack), order No. 21T156A.

Quality Pool & Spa Controls

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

T40000R

T40004R

T40404R

T40000R4

T40004RSS

T40004R5

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

T10000RT, T40000RT & PE45343RCT Series

Pool Panels with Transformer

These Panels with Transformer offer an all-in-one, easy to wire and extremely cost effective electrical control

center for any pool or spa installation. Inside the enclosure are the time switch, the transformer and other

components needed for the completion of this installation. The T40000RT Series panels will accept additional

Intermatic mechanisms and/or components.

The PE45343RCT Series includes all the features of the PE Series Digital Controls plus two PE24VA valve

actuators, Wireless Panel Mounted Transceiver (PE950), which allows the system to display the status of each

of the five circuits (3 timed and 2 on demand), pool and spa water temperature, pool and spa thermostat set

point, heating status and overall communication status.

Applications

•Filter Pumps • Blowers • Low Voltage Pool/Spa Lighting

•Low Voltage Outdoor Lighting • Fountains

Specifications

T10000RT Series

Case – 12" (30.5 cm) H x 12" (30.5 cm) W x 4-1/4" (10.8 cm) D, 0.048" steel with electrostatically applied

light beige finish

Knockouts – Five combination 1/2"-3/4" and two combination 3/4"-1" knockouts on the bottom.

One combination 1/2"-3/4" on the left side and one combination 3/4"-1" on the back. One knockout

1-3/4" x 2-3/4" on the right side for mounting switches or GFCI

Center Rating – 92 Amp per leg, 168 Amp Max. 120-240 VAC or 120-208 VAC single phase - 60 Hz.

T40000RTSeries

Case – 20-3/4" (52.7 cm) high x 12-3/4" (32.4 cm) wide x 4-1/4" (10.8 cm) deep, 0.048" steel with

electrostatically applied light beige finish.

Knockouts – Seven combination 1/2"-3/4" and three combination 3/4"-1" knockouts on the bottom. Five

combination 1/2"-3/4" on the left side. One 1-3/4" x 2-3/4" knockout on the right side for mounting switches

and GFCI.

Panel Rating – T40000RT Series - 100 Amp 120-240 VAC or 120-208 VAC single phase - 60 HZ

Timer Switch Rating – 30 Amp Resistive Inductive, Tungsten or 1000 VA pilot duty each pole

120/208/240 VAC; 2 HP (24 FLA) - 120 VAC; 5 HP (28 FLA) - 240 VAC

PE45343RCT Series

Case – 12" (30.5 cm) H x 12" (30.5 cm) W x 4-1/4" (10.8 cm) D, 0.048" steel with electrostatically applied

light beige finish

Knockouts – Five combination 1/2"-3/4" and two combination 3/4"-1" knockouts on the bottom.

One combination 1/2"-3/4" on the left side and one combination 3/4"-1" on the back. One knockout

1-3/4" x 2-3/4" on the right side for mounting switches or GFCI

Panel Rating – T40000RTSeries - 100 Amp 120-240 VAC or 120-208 VAC single phase - 60 HZ

Agency Approval – CSA/C-US

Model # Transformer Input 60 Hz Output Mechanism Shipping Weight

T10004RT1 100 Watt 120V, 1 Amp 12V, 13V, T104M 14.0 lbs (6.3 kg)

T10004RT3 300 Watt 120V, 3 Amp 12V, 13V, 14V T104M 20.0 lbs (9.0 kg)

T40003RT3 300 Watt 120V, 3 Amp 12V, 13V, 14V T103M 32.0 lbs (14.4 kg)

T40004RT1 100 Watt 120V, 1 Amp 12V, 13V, T104M 26.0 lbs (11.7 kg)

T40004RT3 300 Watt 120V, 3 Amp 12V, 13V, 14V T104M 32.0 lbs (14.4 kg)

PE45343RCT1 100 Watt 120V, 1 Amp 12V, 13V P1353ME & P4243ME 56.0 lbs (25.2 kg)

PE45343RCT3 300 Watt 120V, 3 Amp 12V, 13V, 14V P1353ME & P4243ME 61.0 lbs (27.5 kg)

For additional trippers ( 1 “ON” 1 “OFF” per pack ), order No. 156T1978A.

For additional “OFF” trippers (25 “OFF” per pack), order No. PA115.

For stand-offs for décor knockouts (4 stand-offs per pack), order No. 21T156A.Note: See Page 29 for a detailed list of T100M replacement

mechanisms and page 16 for PE650 and PE950 specifications

Safety Transformers

T10004RT1

T40004RT3

PE45343RCT3

PX100, PX300 & PX600 SeriesSafety Transformers

These Safety Transformers are specifically designed to supply 12 volts to pool/spa lights, submersible fixtures

and outdoor garden lights. A grounded shield between the primary and secondary windings assures safe

operation and the built-in circuit protection will disconnect power to the transformer in case of defect or

overload.

Applications

•Pool Lights • Spa Lights • Garden Lights • Fountain Lights

Specifications - PX100/S, PX300/S

Enclosure – 7.25" (19.4 cm) H x 5.25" (13.3 cm) W x 4.5" (11.4 cm) D. Stainless steel or steel with

electrostatically applied light beige finish. Mounting brackets top and bottom.

Knockouts – Total of ten combination 1/2”-3/4” knockouts, (2) right side, (2) left side, (2) back, (4) bottom.

Electrical Rating – See table.

Shipping Weight – See table.

Specifications – PX600/S

Enclosure – 10" (25.4 cm) high x 10" (25.4 cm) wide x 5" (12.7 cm) deep. Stainless steel or steel with

electrostatically applied light beige finish. Mounting brackets top and bottom.

Knockouts – Two combination 1/2"-3/4", and 4 combination 3/4"-1" knockouts on the bottom. Total of six

combination 1/2"-3/4" knockouts, (2) right side, (2) left side, (2) back.

Electrical Rating – See table.

Shipping Weight – See table.

Model # Description Input Output Shipping Weight

PX100 100 Watt Beige Steel Enclosure 120V, 1AMP 12 or 13V 7.0 lbs (3.2 kg)

PX100S 100 Watt Stainless Steel Enclosure 120V, 1AMP 12 or 13V 7.0 lbs (3.2 kg)

PX300 300 Watt Beige Steel Enclosure 120V, 3AMP 12,13 or 14V 13.0 lbs (5.9 kg)

PX300S 300 Watt Stainless Steel Enclosure 120V, 3AMP 12,13 or 14V 13.0 lbs (5.9 kg)

PX600 600 Watt Beige Steel Enclosure 120V, 6AMP 12,13 or 14V 26.0 lbs (11.7 kg)

PX600S 600 Watt Stainless Steel Enclosure 120V,6AMP 12,13 or 14V 26.0 lbs (11.7 kg)

Safety Transformers

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PX100

PX100S

PX300

PX300S

PX600

PX600S

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PF1100 Series

Single Circuit Freeze Protection Controls

These Freeze Protection Controls are designed to protect the pool and spa equipment and plumbing against

freeze damage. They turn the pump and the heater ON vwhen the outdoor temperature drops below the temper-

ature set by the user-adjustable thermostat.

Models without timer connect to a timing or switching device and together, they control operation of the

equipment as well as protect it against freeze damage. Models with timer provide both automation and

protection for the equipment.

APPLICATIONS

•Filter Pumps • Filter Pump/Booster Pump Combinations

•Waterfalls • Water Features

SPECIFICATIONS

CASE - 0.034 inch drawn steel, electrostatically coated, beige color. Hasp, with hole for lock, holds

permanently attached side-hinged door closed. 9-3/8" (23.8 cm) high x 5-1/4" (14.0 cm) wide x 3-5/8"

(9.2 cm) deep.

KNOCKOUTS - 1/2" - 3/4" combination knockouts, one back, one on each side, two bottom.

THERMOSTATRANGE - 45°F - 32°Fwith 5 degrees differential.

ELECTRICAL RATING - See table

SHIPPING WEIGHT - See table.

AGENCY APPROVAL - CSA/C-US

Model # Description Input Rating H.P. Shipping Weight

PF1102 Thermostat only. For 240V installation. 240V 3 3.7 lbs (1.7 kg)

PF1102M Same as above, mechanism only. 240V 3 2.0 lbs (0.9 kg)

PF1102T Timer with thermostat. For 240V installation. 240V 3 4.5 lbs (2.0 kg)

PF1102MT Same as above, mechanism only. 240V 3 2.5 lbs (1.1 kg)

PF1103 Thermostat only. For 120/240V installation. 120/240V* 1.5/3 3.7 lbs (1.7 kg)

PF1103M Same as above, mechanism only. 120/240V* 1.5/3 2.0 lbs (0.9 kg)

PF1103T Timer with thermostat. For 120/240V installation 120/240V* 1.5/3 4.5 lbs (2.0 kg)

PF1103MT Same as above, mechanism only. 120/240V* 1.5/3 2.5 lbs (1.1 kg)

*Neutral must be installed.

Freeze Protection Controls

PF1102M

PF1102

PF1103MT

PF1103T

PF1100 & PF1200 Series

Multi Circuit Freeze Protection Control Centers & Panels

These heavy-duty Freeze Protection Controls are designed specifically for pools requiring one or two time

switches and protect the pool and spa equipment and plumbing against freeze damage. They turn the pump

and the heater ON when the outdoor temperature drops below the temperature set by the user-adjustable

thermostat. In addition, they have a provision to install switches inside or GFCI receptacle on the side of

enclosure.

Applications

•Filter Pumps • Filter Pump-Booster Pump • Fountains

•Combinations • Pool-Spa Combinations

Specifications

PF1112T, PF1202T

Case – 12" (30.5 cm) H x 12" (30.5 cm) W x 4-1/4" (10.8 cm) D, 0.048" steel with electrostatically applied

light beige finish.

Knockouts – Five combination 1/2"-3/4" and two combination 3/4"-1" knockouts on the bottom. One combi-

nation 1/2"-3/4" on the left side and one combination 3/4"-1" on the back. One knockout 1-3/4" x 2-3/4" on

the right side for mounting switches or GFCI

Center Rating – 92 Amp per leg, 168 Amp Max. 120-240 VAC or 120-240VAC single phase - 60 Hz.

Electrical Rating – See table.

Thermostat Range – 44°F - 32°F with 5 degrees differential.

Shipping Weight – See table.

Agency Approval – CSA/C-US

PF1222TB

Case – 16-1/2" (41.9 cm) H x 10-7/8" (27.6 cm) W x 4-1/4" (10.8 cm) D, 0.048" steel with electrostatically

applied beige finish.

Knockouts – Two 1/2", three combination 1/2"-3/4", and two combination 3/4"-1" knockouts on the bottom.

Four 1/2", three combination 1/2"-3/4" on the back. One combination 3/4"-1" on the left side. One 1-3/4" x 2-

3/4" knockout on the right side for mounting switches and GFCI.

Panel Rating – 100 Amp max., 120-240 VAC or 120-208 VAC single phase - 60 Hz.

Electrical Rating – See table.

Thermostat Range – 44°F - 32°F with 5 degrees differential.

Shipping Weight – See table.

Agency Approval – CSA/C-US

Model # Description Electrical Input Rating HP Shipping Weight

PF1112T For pools requiring one time switch 240V 3 8.0 lbs (3.6 kg)

PF1202T For pools with cleaner, requiring two time switches 240V 3 10.0 lbs (4.5 kg)

PF1222TB Same as a PF1202T with 4/8 breaker base and heater protection 240V 3 17.0 lbs (7.7 kg)

For additional trippers ( 1 “ON” 1 “OFF” per pack ), order No. 156T1978A.

For additional “OFF” trippers (25 “OFF” per pack), order NO. PA115.

For additional stand-offs for décor knockouts (4 stand-offs per pack), order No. 21T156A.

Freeze Protection Controls

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PF1112T

PF1202T

PF1222TB

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Air Operated Pool/Spa & Pool-to-Spa Controls

This line of Air Operated Controls is specially designed to control pool/spa combinations economically and

reliably for up to 100 ft. away from the equipment. Everything needed to control the filter pump, valves, heater

thermostat, booster pump, blower or lights is included in a single package and can be installed in less than

two hours. A number of accessories are available to enhance the control capacity of these units. Comes

complete with two PE24VA 24-Volt valve actuators.

Applications

•Pool/Spa Combinations • Water Features

Specifications

Case – 0.048" steel with electrostatically applied light beige finish. See table for nominal dimensions.

Maximum Range – 100 ft. (The actual distance between the control and air button depends on the amount

of displaced air, the inside diameter of the air hose and other factors beyond the control of the

manufacturer.)

Timer – 24 Hour Electronic.

Specifications/Features RC2163E RC2163FE RC2263E RC2403RT

Voltage 120/240 120/240 120/240 120/240

Remote Command 1-Air Any Switch* 1-Air 2-Air

Filter Pump Timer Controlled in Pool Mode Y Y Y Y

Single Speed Only (HP) 3 HP 3 HP NA NA

Single or Two Speed (HP) NA NA 2 HP 2 HP

Heater Control (Single or Two Stage) Y Y Y NO

Number of Valve Actuator Connections 3 3 3 0

Heater Protection (Optional) Y Y NO NO

Blower NO NO Y Y

Independent Circuit (DPST 30A, 3HP-240V) NO NO NO Y

StandardEnclosure(In) 12.9 x 10.9 x 4.3 12.9 x 10.9 x 4.3 12.9 x 10.9 x 4.3 12.9 x 10.9 x 4.3

Number of Breaker Space NA NA NA NA

Shipping Weight (lbs) 20.0 (9.0 kg) 20.0 (9.0 kg) 23.7 (10.7 kg) 19.0 (8.6 kg)

Reference Picture RC2163E RC2163E RC2163E RC2163E

*Can use spring wound timer, toggle switch or remote control with transmitter to operate equipment

Specifications/Features RC2163BE RC2163BFE RC2263BE

Voltage 120/240 120/240 120/240

Remote Command 1-Air Any Switch* 1-Air

Filter Pump Timer Controlled in Pool Mode Y Y Y

Single Speed Only (HP) 3 HP 3 HP NA

Single or Two Speed (HP) NA NA 2 HP

Heater Control (Single or Two Stage) Y Y Y

Number of Valve Actuator Connections 3 33

Heater Protection (Optional) Y Y NO

Blower NO NO Y

Independent Circuit (DPST 30A, 3HP-240V) NO NO NO

StandardEnclosure(In) 16.8 x 10.9 x 4.3 16.8 x 10.9 x 4.3 16.8 x 10.9 x 4.3

Number of Breaker Space 8/16 8/16 8/16

Shipping Weight (lbs) 24.3 (10.9 kg) 24.3 (10.9 kg) 28.0 (12.6 kg)

Reference Picture RC2263BE RC2263BE RC2263BE

Air Operated Controls

RC2403RT

RC2163E

RC2263BE

P1000 & P7000 Series

Electronic Time Switches and Mechanisms

This line of electronic time switches in safety enclosures are specially suited for applications where a need to

turn equipment up to 8 ON and OFF cycles daily, and where the automatic operation of the equipment requires

occasional override by someone other than a qualified service professional. Electronic technology allows up-

to-the-minute programming accuracy. The unique “door within the door” provides safe access to the timer

control buttons, but prevents entry into the wiring compartment. Light indicator illuminates when timer is in

ON position. An override feature is provided to allow pool service without interruption of ON-OFF settings.

Select feature allows timer to be continuously ON, OFF or in Auto mode. The addition of a radio receiver

(Model P1203FR) provides a 2nd circuit for any other load (light, blower etc.) requiring control from a remote

location. Typical application for the clock circuit would be the pool pump, and a pool light for the radio circuit.

In case of power failure, a replaceable battery preserves programming for up to three years.

Applications

•Filter pumps

•Pool/Spa lights

•Water Features

•Fountains

Specifications

Case – All plastic NEMA 3R rated for indoor-outdoor installation. 9-3/8" (23.9 cm) H, 5-1/2" (14.0 cm) W,

3-5/8" (9.2 cm) D in beige finish.

Knockouts – Combination 1/2" - 3/4" nominal knockouts, (1) on back and each side of case, and (2) on

bottom.

Rating – P1102FE - 3.0 HP @ 240V, 30 Amp resistive; P1203FR - 1.5 HP @ 120V, 3.0 HP @ 240V, 30 Amp

resistive; Radio Circuit - 15 Amp resistive, 10 Amp Tungsten, 1 HP motor load - 120 VAC

Shipping Weight - 3.75 lbs (1.7 kg)

Agency Approval – CSA/C-US

Model Supply

Number Description Switch Voltage 50/60 Hz

P1102ME 24-Hour Electronic Mechanism Only One DPST 240V only clock & load

P1103ME 24-Hour Electronic Mechanism Only One DPST 120V for clock

120V or 240V only clock & load

P7101ME 7-Day Electronic Mechanism Only One DPST 120V only clock & load

P7102ME 7-Day Electronic Mechanism Only One DPST 240V only clock & load

P7103ME 7-Day Electronic Mechanism Only One DPST 120V for clock

120V or 240V only clock & load

P1102FE 24-Hour Electronic Time Switch One DPST 240V only clock & load

P1103FE 24-Hour Electronic Time Switch One DPST 120V for clock

120V or 240V only clock & load

P1203FR 24-Hour Electronic Time Switch One DPST 3.0 HP - 208-240V only clock & load

Radio Receiver Module One SPST 120V only receiver & load

Electronic Time Switches

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

P1102ME

P1102FE

P1203FR

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

RC600 & RC900

Outdoor Radio Remote Controls

These Modular Radio Receivers are one half of a two part remote control system. They operate as ordinary

ON/OFF switches but they also respond to the signals of a hand held transmitter — the other half of the

system. The modules are designed for indoor or outdoor use, and can handle a variety of switching

applications, typical around the house or farm. By the push of a button on the face of the transmitter, the user

is able to turn ON-OFF the connected load (lights, pump, etc.) from any remote location, inside or outside of

the house, safely and conveniently. In addition, a single transmitter can operate up to three receivers and is

able to “teach” each module a different code (Transmitter model RC939 sold separately).

Applications

•Pool/Spa Pumps, Lights and Heaters • Air Blowers

•Fountain Pumps • Signs

•Outdoor Lighting •Motorized Gates

•Motorized Valves

Specifications

Enclosure–Beige outdoor grade plastic.

Maximum Range – 100 ft. See transmitter model RC939 for details.

Model # Description Electrical Rating Size Shipping Weight

RC613 Receiver with ON/OFF Button 15 Amp Resistive, 10 Amp (1200 W) 4-1/2" H (11.4 cm) 0.5 lbs (0.2 kg)

Tungsten, 1 HP, Motor Load - 120 V 3" W (7.6 cm), 1-1/4" D (4.0 cm)

RC613L RC613 with (3) 36" Long Leads Same as RC613 Same as RC613 0.7 lbs (0.3 kg)

RC613R Heavy Duty Receiver Module 30 Amp Resistive, 120/240 V 7-3/4" H (19.7 cm) 1.4 lbs (0.6 kg)

12.5 Amp (1500 W), 1.5 HP - 140 V 4" W (10.7 cm)

1.5 HP - 140 V, 3 HP - 240 V, 3-1/2" D (8.9 cm)

Double Pole, Single Throw Contacts

RC615 Timer Interface Module Same as RC613 Same as RC613 0.5 lbs (0.2 kg)

without Manual Button

Hand Held Radio Transmitter

This hand held radio transmitter operates the shared equipment of a pool/spa combination by the touch

of a button. In addition, morebuttons are available on the transmitter to turn ON-OFF a booster pump,

ablower and lights.

Applications

•Pool-Spa Combinations • Water Features

Specifications

Enclosure – Beige plastic, 4-3/8" (11.1 cm) H, 2-3/4" (7.0 cm) W and 1" (2.5 cm) D.

Model # Description Range* Battery Shipping Weight

RC939 3Channel Radio Transmitter 100 ft. 9V Transistor type 0.5 lbs (0.2 kg)

* The range is 100 feet but depends on many factors like the age of the battery, proximity of large metal objects, the location of the receiver

and environmental conditions at the time of transmission.

Radio Remote Controls

RC613L

RC613R

RC939

P1200 Series

Two-Circuit Portable Outdoor Timer

These Portable Two-circuit Above Ground Pool Timers incorporate a plug in for a timed circuit (normally used

for a pool pump) and a plug in for a live circuit (typically used for a pool light). GFCI protected circuits and a

three-prong grounded plug for the time switch supply are also built-in.

Applications

•Above ground pool pumps

•Above ground pool lights

Specifications

Case - NEMA 3R rated for indoor-outdoor installation.

9-3/8” (23.8 cm) high x 5-1/2” (14.0 cm) wide x 3-5/8” (9.2 cm) deep

Knockouts - Combination 1/2” - 3/4” nominal knockouts, one on the back and each side of case, two

pre-cut on bottom

Timer - 24 hour with 23-1/2 hour maximum ON time. Two ON, two OFF trippers - standard. Dial will accept

up to 12 sets of trippers.

Shipping Weight - 2.8 lbs. (1.3kg)

Model Description Electrical Plug & Receptacle

P1261P PB913N84 Timer 15 Amp (1800 W), Resistive or 5-15

Tungsten 1 HP, 15 FLA (96 LRA)

Motor Load

P1261PE PB313E Electronic Timer 15 Amp (1800 W), Resistive or 5-15

Tungsten 1 HP,15 FLA (96 LRA)

Motor Load

For additional trippers ( 2 “ON” 2 “ OFF” per pack ), order No. 156PB10398A

P1100 Series

Portable Outdoor Timers – Heavy Duty Outdoor Timers

These Portable Outdoor Timers are specially designed to control the filter pump of a portable pool or spa, but

they can also be used to turn ON and OFF (in off-season) outdoor decoration, engine block heaters and other

appliances, indoors or outdoors.

Applications

•Filter Pumps • Air Conditioners

•Signs • Lights

•Engine Block Heaters • Fans

Specifications

Case – Outdoor grade plastic. 5" (12.7 cm) H x 5-1/2" (13.97 cm) W x 3-3/4" (9.52 cm) D. Cord – 3 wire,

outdoor grade, 22" long.

Timer – 24 hour with 23-1/2 hour maximum ON time. Two ON, two OFF trippers - standard. Dial will accept

up to 12 sets of trippers.

Shipping Weight – 1.7 lbs (0.7 kg)

Model # Description Electrical Plug & Receptacle

P1101 Timer 15 Amp (1800 W), Resistive or Tungsten

1HP Air Conditioner, 15 FLA (96 LRA), Motor Load 5-15

P1121 Timer 15 Amp (1800 W), Resistive or Tungsten

1HP Air Conditioner,15 FLA (96 LRA), Motor Load 5-15

P1131 Heavy-Duty Timer with Resistive, 1 HP, 16 FLA (96 LRA) Motor Load 5L-20

Twist-Lock Plug & Receptacle

P1161 Safety Timer with Ground Fault Circuit Protection 15 Amp (1800 W) Resistive, Tungsten

15 FLA (90 LRA) Motor 5-15

For additional trippers ( 2 “ON” 2 “ OFF” per pack ), order No. 156PB10398A

Portable Outdoor Timers

P1261P

P1121

P1131

P1161

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

P1261PE

P1101

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PJB Series

Pool/Spa Junction Box & Mounting Bracket

These polymeric, water tight, multi-fixture Junction Boxes are especially designed for pools, pool-spa combi-

nations and landscape applications. The PJB4175 provides safe and reliable connection for up to four lights.

While the PJB2175 supports up to two lights. They will accommodate flexible cords from #16-3 up to #12-3

and #10-3 in any combination and non-metallic conduits from 1/2 to 1 inch, including one for supply

conductor feed. An optional wall/post mounting bracket is also available.

Applications

•Pool Lights

•Spa Lights

•Landscape Lights

Specifications

Case – Outdoor grade plastic. PJB4175 - 7.5" L x 4.75" W x 5.0" D. PJB2175 - 7.0" L x 3.0" W x 4.0" D

Model # Description Light Connection Case Qty. Shipping Weight

PJB2175 Pool/Spa Light Junction Box 2 24 19.2 lbs (8.6 kg)

PJB4175 Pool/Spa Light Junction Box 4 12 13.2 lbs (6.0 kg)

PA114 Wall/Post Mounting Bracket — 10 5lbs (2.3 kg)

PAV Series

Maintenance Free Water Valves

Intermatic’s Maintenance Free Water Valves have been designed to provide reliable control of water flow to

pools, spas, solar collectors, cleaners and water features. These 2-way and 3-way valves have excellent flow

characteristics while maintaining back pressure. Manufactured with Intermatic’s high quality standards, the

PAV Series Water Valves offer long maintenance free performance

Applications

•Pools

•Spas

•Fountains

• Water Features

Standard Features

•Teflon-coated diverter requires no lubrication and ensures maintenance free performance

•Innovative field adjustable stop ensures precise valve positioning

•1-1/2” valves fit 1-1/2” and 2” plumbing, 2” plumbing, 2” valves fit 2” and 2-1/2” plumbing

•Available in standard PVC and high temperature CPVC

Model PortSize Configuration Material Shipping Weight Each

PAV215 1-1/2” 2-WAY PVC 1.5 lbs (0.6 kg)

PAV215C 1-1/2” 2-WAY CPVC 1.5 lbs (0.6 kg)

PAV220 2” 2-WAY PVC 1.6 lbs (0.7 kg)

PAV220C 2” 2-WAY CPVC 1.6 lbs (0.7 kg)

PAV315 1-1/2” 3-WAY PVC 1.5 lbs (0.6 kg)

PAV315C 1-1/2” 3-WAYCPVC 1.5 lbs (0.6 kg)

PAV320 2” 3-WAY PVC 1.6 lbs (0.7 kg)

PAV320C 2” 3-WAY CPVC 1.6 lbs (0.7 kg)

Model # Description Voltage Shipping Weight Each

PE24VAValve Actuator 24 VAC 3.5 lbs (2.2 kg)

Pool/Spa Accessories

PJB4175

PA114

PAV320

PAV220C

For maximum convenience in

pool/spa automation, PAVSeries

water valves can be used in

conjunction with Intermatic PE24VA

valve actuators.

PJB2175

Setting a New Standard for Protection

The same quality and coverage you’ve come to expect

from Intermatic controls can also be found in a

complete line of panel-mount and point-of-use

surge protection — from high current capacity

industrial models to residential models, with

integrated phone and coax protection.

On average, the typical home or

business gets hit with more than

2,000 electrical surges annually,

costing home and business

owners more than $26 billion

dollars. As more and more

homes begin housing more

elaborate home theater and

entertainment systems,

home offices and other

appliances, it is becoming

increasingly important to

protect all electronic

investments from transient

voltage or “bad power.”

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Electrical disturbances and downtime cost North American Companies more than $26 billion every year. Every

process within your building is controlled by electrical and electronic components which all require surge

protection to function reliably.

ANSI/IEEE has defined common disturbances which occur in modern facilities per the waveforms to the left.

Depending on the proximity of the equipment to your power entry points, the severity increases. As the transient

event propagates throughout your building, it degrades your electronic components by stressing them with

excess voltage and current.

Every modern facility is a strong candidate for protection. Intermatic has a broad line of Service Entrance,

Panelboard and Point-of-Use Protection to select from.

Service Entrance, Panelboard and Point-of-Use surge protection can be found in the following

types of facilities and installations:

Virtually all devices which are powered by electricity are vulnerable. Surge Suppression

is required for protection of the following types of systems:

Surge Suppression Definitions

Surge Current Capacity is the rated surge current that a design will withstand based on the standard

8x20 microsecond current waveform. Nema LS-1 states that this should be given for each mode of a surge

protection device, since devices can have different components in each mode.

Modes of Protection are the coupling paths that exist in a single or three phase system.

In a three phase wye system there are 10 potential modes where a transient can be coupled:

L1 to Neutral L1 to Ground L2 to Neutral L2 to Ground

L3 to Neutral L3 to Ground L1 to L2 L2 to L3

L3 to L1 Neutral to Ground

In a three phase delta system therearesix potential modes whereatransient can be coupled:

L1 to Ground L2 to Ground L3 to Ground

L1 to L2 L2 to L3 L3 to L1

All modes must have suppression components coupled between them in order to be 100% effective.

MCOV (Maximum Continuous Operating Voltage) is the maximum steady state rms voltage at which the unit

can safely operate.The recommended MCOV is 115% of nominal voltage for all voltage configurations.

EMI/RFI Noise Attenuation is a way to rate filter performance over a range of specific frequencies. IEEE

characterizes line noise as less than two times peak voltage. Line noise can be somewhat attenuated by the

capacitance found in MOVs, but typically requires the addition of capacitors to increase effectiveness. EMI/RFI

filters should be UL1283 Listed for safety.

Why Every Facility Needs Surge Protection

•Computer/Peripherals

•Network Servers/ Routers/Modems

•Telecom Equipment

•Variable Frequency Drives

•Lighting Ballasts

•HVAC Controls

•FireAlarmSystems

•Security Systems

•Lighting Control and Dimming Systems

•Automatic Test Equipment

•Wafer Fabrication Equipment

•Uninterruptible Power Supplies

•Bar Code Scanning Equipment

•Programmable Logic Controllers

•CNC Machines

•Pumps, motors and related equipment

which has electronic controls or starters

•Manufacturing

•Healthcare/Medical

•Education/University

•Data Centers

•Telecom/Cell Sites

•Utility

•Correctional

•Military Installations

•Airports

•Broadcast Studios

• Financial Institutions

•Retail

•General Office

•Semiconductor Fabrication

•Wastewater Facilities

•Restaurants

•Entertainment Facilities

020 40 60 TIME .s

1.0

V(t)/Vp

0.8

0.6

0.4

0.2

0.0 80 100

DURATION = 50 s

RISE TIME = 1.2 s

010 20 30 TIME .s

1.0

l(t)/lp

0.8

0.6

0.4

0.2

0.0 40 50

DURATION = 20 s

FRONT TIME = 8 s

10 s

RISE TIME = 0.5 s

010 20 30TIME .s

1.0

V(t)/Vp

0.6

0.4

0.2

-0.0

-0.2

-0.4

-0.6

-0.8

-1.0

-1.2

Voltage Waveform

Current Waveform

100 kHz Ringwave

System Voltage

The wiring diagrams characterize common voltage

configurations available for the products. Refer to

individual product pages for models available

in below configurations. Match the voltage

configuration below with your voltage configuration

at your Service Entrance, Distribution Panel or

Panelboardlocation whereyou want protection.

120 Volt

Single Phase

2Wire plus Ground

120/240 Volt

Single Phase

3Wire plus Ground

(split phase)

120/208 Volt

Three Phase Wye

4Wire plus Ground

120/240 Volt

Three Phase HLD

(High Leg Delta)

4Wire plus Ground

240 Volt

Three Phase Delta

3 Wireplus Ground

277/480 Volt

Three Phase Wye

4 Wireplus Ground

480 Volt

Three Phase Delta

3 Wireplus Ground

347/600 Volt

Three Phase Wye

4 Wire plus Ground

600 Volt

Three Phase Delta

3 Wire plus Ground

ANSI/IEEE C62.41.1-2002 and ANSI/IEEE C62.41.2-2002 are the recognized American National Standards for

establishing the surge withstand capability of equipment connected to utility power circuits in residential,

commercial or industrial applications. The standard has established the following Location Categories which

can be applied to virtually any type of facility.

The following values and waveforms are recognized within Categories C, B and A. Location Category C is the

Outside and Service Entrance and the harshest surge environment.

Combination Waves Ring Waves

1.2 x 50 microsecond / 8 x 20 microsecond 100KHz 0.5 microsecond

Location Voltage (Peak) Current (Peak) Location Voltage Current

Category 1.2 x 50 µ sec. 8 x 20 µ sec. Category (peak) (peak)

A6,000 Volt 500 Amp A 6,000 Volts 200 Amp

B 6,000 Volt 3,000 Amp B 6,000 Volts 500 Amp

Clow 6,000 Volt 3,000 Amp

C high 10,000 Volt 10,000 Amp

Product Selection Chart – Surge Suppression Recommendations

The following guidelines can be followed for Intermatic products:

Choose Model by Voltage and distance from incoming Service

Location 480 VAC 277/480 VAC 120/208 VAC Wye Refer to Page

Large Service Entrance (2000 to 4000 Amperes)

Best PG5001-480-3DLL PG5001-480-3Y PG5001-208-3Y 90

Better PG4501-480-3DLL PG4501-480-3Y PG4501-208-3Y 91

Good PG4001-480-3DLL PG4001-480-3Y PG4001-208-3Y 92

Small Service Entrance (Less than 1600 Amperes)

Best PG4501-480-3DLL PG4501-480-3Y PG4501-208-3Y 91

Better PG4001-480-3DLL PG4001-480-3Y PG4001-208-3Y 92

Good PG100-480-3DLL PG100-480-3Y PG100-208-3Y 93

Large Distribution Panel (1000 to 1600 Amperes)

Best PG4001-480-3DLL PG4001-480-3Y PG4001-208-3Y 92

Better PG100-480-3DLL PG100-480-3Y PG100-208-3Y 93

Good PG80-480-3DLL PG80-480-3Y PG80-208-3Y 95

Small Distribution Panel (600 to 1000 Amperes)

Best PG100-480-3DLL PG100-480-3Y PG100-208-3Y 93

Better PG80-480-3DLL PG80-480-3Y PG80-208-3Y 95

Good PG60-480-3DLL PG60-480-3Y PG60-208-3Y 97

Large Panelboard (225 to 400 Amperes)

Best PG80-480-3DLL PG80-480-3Y PG80-208-3Y 95

Better PG60-480-3DLL PG60-480-3Y PG60-208-3Y 97

Good PG40-480-3D PG40-480-3Y PG40-208-3Y 100

Small Panelboard (60 to 200 Amperes)

Best PG60-480-3DLL PG60-480-3Y PG60-208-3Y 97

Better PG40-480-3D PG40-480-3Y PG40-208-3Y 100

Good PG20-480-3D PG20-480-3Y PG20-208-3Y 102

Note for the PG 60/80/100 models equivalent models areavailable in Nema 3R enclosures for outdoor applications (see PG2500, PG3000,

PG3500 Series).

Standards and Guidelines

Category C

•Outside and Service Entrance

•Any underground lines

•Overhead line to detached building

Category B

•Feeders and short branch circuits

•Distribution panel devices

•Lighting systems in large buildings

Category A

•Outlets and long branch circuits

Meter

Service

Entrance

Service

Entrance

Meter

ABC

ANSI/IEEE C62.45 is the American National Standard for

uniform testing of surge suppression devices. All

Intermatic testing follows these guidelines.

Nema Standard LS-1 is the National Electrical

Manufacturers Association specification guideline for low

voltage surge protection devices.

Underwriters Laboratories – UL1449 has recently

been revised (August 1998) and requires surge

suppression devices to safely pass overvoltage tests,

abnormal overvoltage tests, shortcircuit withstand tests as

well as assigns suppress voltage ratings based on a 6 KV,

500 Amp combination wave or impulse.

UL1283 – The safety standard for EMI/RFI noise

attenuation filters. While this device does not rate filters or

performance – it does provide a level of testing to ensure

the filter is safe for commercial application.

Therearefour main factors to consider

when specifying the appropriate device

for your facility:

1. What is the amperage (size) of the

Switchboard or Panelboard at the point of

installation?

2. What is the geographic location of the

facility?(i.e. the relative level of lightning

exposure and utility grid switching activity)

3. What is the density of electronic equipment

and how critical is the application?

(i.e. a 7 x 24 computer data center would require a

higher level of protection than a retail store)

4. What is the level of transient and noise

producing loads within your facility?

(i.e. a heavy industrial manufacturing environment

or a densely populated computer data center would

require a higher level of protection)

NOTES:

•Pick appropriate model to match the voltage of your Service

Entrance, Distribution Panel or Panelboard.

•See individual product pages for other available voltages.

•Afacility without any Service Entrance protection would warrant

ahigher level of protection at downstream locations.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PG5000 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • Safety Interlocked Disconnect

•40 kA Brute Force MOVs • Thermally Protected MOVs for maximum safety

•200 KAIC Surge Rated Fuses • EMI/RFI Filtration – Up to 54 dB from 20 kHz to 100 MHz

•Fault Current Tested to 200 KAIC • UL1449, 2nd Edition and UL1283 Listed, cULus

•Easily Replaceable Master Surge Module • Lugs accept #10 to #2 AWG

•NEMA 3R Style Enclosure • 10 year product warranty

•Redundant Protection per mode • Complementary Listed as Secondary Surge Arrester (OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights • Digital Surge Counter

•Form C Contacts • Audible Alarm

•Intermatic Thermal Monitoring System

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

PG5001-240-2S 120/240 VAC Single Phase (split)

115% 200 kA 200 kA 200 kA 200 kA 400 kA 400 V 400 V 330 V 700 V

PG5001-208-3Y 120/208 VAC Three Phase Wye

115% 200 kA 200 kA 200 kA 200 kA 400 kA 400 V 400 V 330 V 700 V

PG5001-240-3HLD 120/240 VAC Three Phase High Leg Delta

115% 200 kA 200 kA 200 kA 200 kA 400 kA 400 V / 400 V / 330 V 900 V

(700 V) (700 V)

PG5001-480-3Y 277/480 VAC Three Phase Wye

115% 200 kA 200 kA 200 kA 200 kA 400 kA 800 V 700 V 700 V 1,500 V

PG5001-480-3DLL 480 VAC Three Phase Delta

115% — — — 200 kA 200 kA — — — 1,500 V

PG5001-600-3Y 347/600 VAC Three Phase Wye

115% 200 kA 200 kA 200 kA 200 kA 400 kA 1,000 V 1,000 V 1,000 V 1,800 V

PG5001-600-3D 600 VAC Three Phase Delta

115% — 200 kA — 200 kA 400 kA — 1,500 V — 1,800 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above are independently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

PER

PHASE

400kA

The PG5000 Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Categorylocations.

Dimensions:

28.66"H x 15.11"W x 8.05"D

Weight: 65 lbs.

PG4500 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • Safety Interlocked Disconnect

•40 kA Brute Force MOVs • Thermally Protected MOVs for maximum safety

•200 KAIC Surge Rated Fuses • EMI/RFI Filtration – Up to 54 dB from 20 kHz to 100 MHz

•Fault Current Tested to 200 KAIC • UL1449, 2nd Edition and UL1283 Listed, cULus

•Easily Replaceable Master Surge Module • Lugs accept #10 to #2 AWG

•NEMA 3R Style Enclosure • 10 year product warranty

•Redundant Protection per mode • Complementary Listed as Secondary Surge Arrester (OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights • Digital Surge Counter

•Form C Contacts • Audible Alarm

•Intermatic Thermal Monitoring System

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

PG4501-240-2S 120/240 VAC Single Phase (split)

115% 150 kA 150 kA 150 kA 150 kA 300 kA 400 V 400 V 330 V 700 V

PG4501-208-3Y 120/208 VAC Three Phase Wye

115% 150 kA 150 kA 150 kA 150 kA 300 kA 400 V 400 V 330 V 700 V

PG4501-240-3HLD 120/240 VAC Three Phase High Leg Delta

115% 150 kA 150 kA 150 kA 150 kA 300 kA 400 V / 400 V / 330 V 900 V

(700 V) (700 V)

PG4501-480-3Y 277/480 VAC Three Phase Wye

115% 150 kA 150 kA 150 kA 150 kA 300 kA 800 V 700 V 700 V 1,500 V

PG4501-480-3DLL 480 VAC Three Phase Delta

115% — — — 150 kA 150 kA — — — 1,500 V

PG4501-600-3Y 347/600 VAC Three Phase Wye

115% 150 kA 150 kA 150 kA 150 kA 300 kA 1,000 V 1,000 V 1,000 V 1,800 V

PG4501-600-3D 600 VAC Three Phase Delta

115% — 150 kA — 150 kA 300 kA — 1,500 V — 1,800 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above are independently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

PER

PHASE

300 kA

The PG4500 Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Category locations.

Dimensions:

28.66"H x 15.11"W x 8.05"D

Weight: 65 lbs.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PG4000 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • Safety Interlocked Disconnect

•40 kA Brute Force MOVs • Thermally Protected MOVs for maximum safety

•200 KAIC Surge Rated Fuses • EMI/RFI Filtration – Up to 54 dB from 20 kHz to 100 MHz

•Fault Current Tested to 200 KAIC • UL1449, 2nd Edition and UL1283 Listed, cULus

•Easily Replaceable Master Surge Module • Lugs accept #10 to #2 AWG

•NEMA 3R Style Enclosure • 10 year product warranty

•Redundant Protection per mode • Redundant Protection per mode

•Complementary Listed as Secondary Surge Arrester (OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights • Digital Surge Counter

•Form C Contacts • Audible Alarm

•Intermatic Thermal Monitoring System

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8 x 20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

PG4001-240-2S 120/240 VAC Single Phase (split)

115% 125 kA 125 kA 125 kA 125 kA 250 kA 400 V 400 V 330 V 700 V

PG4001-208-3Y 120/208 VAC Three Phase Wye

115% 125 kA 125 kA 125 kA 125 kA 250 kA 400 V 400 V 330 V 700 V

PG4001-240-3HLD 120/240 VAC Three Phase High Leg Delta

115% 125 kA 125 kA 125 kA 125 kA 250 kA 400 V / 400 V / 330 V 900 V

(700 V) (700 V)

PG4001-480-3Y 277/480 VAC Three Phase Wye

115% 125 kA 125 kA 125 kA 125 kA 250 kA 800 V 700 V 700 V 1,500 V

PG4001-480-3DLL 480 VAC Three Phase Delta

115% — — — 125 kA 125 kA — — — 1,500 V

PG4001-600-3Y 347/600 VAC Three Phase Wye

115% 125 kA 125 kA 125 kA 125 kA 250 kA 1,000 V 1,000 V 1,000 V 1,800 V

PG4001-600-3D 600 VAC Three Phase Delta

115% — 125 kA — 125 kA 250 kA — 1,500 V — 1,800 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above are independently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

PER

PHASE

250 kA

The PG4000 Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Categorylocations.

Dimensions:

28.66"H x 15.11"W x 8.05"D

Weight: 65 lbs.

PG100 Series

Features

•Panel Extension design for mounting above or below 20" wide panel • UL1449, 2nd Edition and UL1283 Listed, cULus

•Available wiring space on each side for branch circuit or main input conductors • NEMA 12 Style Enclosure

•All mode Protection (L-N, L-G, N-G, L-L) • Lugs accept #10 to #2 AWG

•Redundant Protection per mode, replaceable master module • Available with flush mount cover PG1-FMP

•Integral 200 KAIC fusing and thermal protection • 10 year product warranty

•Fault Current Tested to 200 KAIC • EMI/RFI Filtration – Up to 54 dB from 20 kHz to

•Complementary Listed as Secondary Surge Arrester (OWHX,E135626) 100 MHz

Integral Diagnostics

•LED Indicator Lights for each mode

•Form C Contacts

•Audible Alarm

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

PG100-240-2S 120/240 VAC Single Phase (split)

115% 100 kA 100 kA 100 kA 100 kA 200 kA 330 V 330 V 330 V 600 V

PG100-208-3Y 120/208 VAC Three Phase Wye

115% 100 kA 100 kA 100 kA 100 kA 200 kA 330 V 330 V 330 V 600 V

PG100-240-3HLD 120/240 VAC Three Phase High Leg Delta

115% 100 kA 100 kA 100 kA 100 kA 200 kA 330 V 330 V 330 V 900 V

(600 V) (700 V)

PG100-480-3Y 277/480 VAC Three Phase Wye

115% 100 kA 100 kA 100 kA 100 kA 200 kA 800 V 800 V 700 V 1,500 V

PG100-480-3DLL 480 VAC Three Phase Delta

115% — — — 100 kA 100 kA — — — 1,200 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above are independently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

PER

PHASE

200kA

Flush Mount Plate PG1-FMP

The PG100 Series is a hard wired

suppression device installed in

parallel) and recommended for all

ANSI/IEEE Category locations.

Dimensions:

16.0”H x 20.0”W x 6.0”D

Weight: 40 lbs

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PG3500 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • Redundant Protection per mode

•40 kA Brute Force MOVs • Thermally Protected MOVs for maximum safety

•200 KAIC Surge Rated Fuses • EMI/RFI Filtration – Up to 54 dB from 20 kHz to 100 MHz

•Fault Current Tested to 200 KAIC • UL1449, 2nd Edition and UL1283 Listed, cULus

•Easily Replaceable Master Surge Module • Lugs accept #10 to #2 AWG

•NEMA 3R Style Enclosure • 10 year product warranty

•Complementary Listed as Secondary Surge Arrester (OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights • Audible Alarm

•Intermatic Thermal Monitoring System • Form C Contacts

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

PG3500-240-2S 120/240 VAC Single Phase (split)

115% 100 kA 100 kA 100 kA 100 kA 200 kA 400 V 400 V 330 V 700 V

PG3500-208-3Y 120/208 VAC Three Phase Wye

115% 100 kA 100 kA 100 kA 100 kA 200 kA 400 V 400 V 330 V 700 V

PG3500-240-3HLD 120/240 VAC Three Phase High Leg Delta

115% 100 kA 100 kA 100 kA 100 kA 200 kA 400 V / 400 V / 330 V 900 V

(700 V) (700 V)

PG3500-480-3Y 277/480 VAC Three Phase Wye

115% 100 kA 100 kA 100 kA 100 kA 200 kA 800 V 700 V 700 V 1,500 V

PG3500-480-3DLL 480 VAC Three Phase Delta

115% — — — 100 kA 100 kA — — — 1,500 V

PG3500-600-3Y 347/600 VAC Three Phase Wye

115% 100 kA 100 kA 100 kA 100 kA 200 kA 1,000 V 1,000 V 1,000 V 1,800 V

PG3500-600-3D 600 VAC Three Phase Delta

115% — 100 kA — 100 kA 200 kA — 1,500 V — 1,800 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above are independently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wirewye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

PER

PHASE

200kA

The PG3500 Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Category locations.

Dimensions:

28.66"H x 15.11"W x 8.05"D

Weight: 60 lbs.

PG80 Series

Features

•Panel Extension design for mounting above or below 20" wide panel • UL1449, 2nd Edition and UL1283 Listed, cULus

•Available wiring space on each side for branch circuit or main input conductors • NEMA 12 Style Enclosure

•All mode Protection (L-N, L-G, N-G, L-L) • Lugs accept #10 to #2 AWG

•Redundant Protection per mode, replaceable master module • Available with flush mount cover PG1-FMP

•Integral 200 KAIC fusing and thermal protection • 10 year product warranty

•EMI/RFI Filtration – Up to 54 dB from 20 kHz to 100 MHz • Fault Current Tested to 200 KAIC

•Complementary Listed as Secondary Surge Arrester (OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights for each mode

•Form C Contacts

•Audible Alarm

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

PG80-240-2S 120/240 VAC Single Phase (split)

115% 80 kA 80 kA 80 kA 80 kA 160 kA 330 V 330 V 330 V 600 V

PG80-208-3Y 120/208 VAC Three Phase Wye

115% 80 kA 80 kA 80 kA 80 kA 160 kA 330 V 330 V 330 V 600 V

PG80-240-3HLD 120/240 VAC Three Phase High Leg Delta

115% 80 kA 80 kA 80 kA 80 kA 160 kA 330 V 330 V 330 V 900 V

(600 V) (700 V)

PG80-480-3Y 277/480 VAC Three Phase Wye

115% 80 kA 80 kA 80 kA 80 kA 160 kA 800 V 800 V 700 V 1500 V

PG80-480-3DLL 480 VAC Three Phase Delta

115% — 80 kA — 80 kA 80 kA — — — 1,200 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above are independently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

PER

PHASE

160kA

The PG80 Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Category locations.

Dimensions:

16.0"H x 20.0"W x 6.0"D

Weight: 40 lbs.

Flush Mount Plate PG1-FMP

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PG3000 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • Redundant Protection per mode

•40 kA Brute Force MOVs • 200 KAIC Surge Rated Fuses

•Thermally Protected MOVs for maximum safety • Fault Current Tested to 200 KAIC

•EMI/RFI Filtration – Up to 54 dB from 20 kHz to 100 MHz • Easily Replaceable Master Surge Module

•UL1449, 2nd Edition and UL1283 Listed, cULus • NEMA 3R Style Enclosure

• 10 year product warranty • Complementary Listed as Secondary Surge Arrester

(OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights • Audible Alarm

•Intermatic Thermal Monitoring System • Form C Contacts

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8 x 20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

PG3000-240-2S 120/240 VAC Single Phase (split)

115% 80 kA 80 kA 80 kA 80 kA 160 kA 400 V 400 V 330 V 700 V

PG3000-208-3Y 120/208 VAC Three Phase Wye

115% 80 kA 80 kA 80 kA 80 kA 160 kA 400 V 400 V 330 V 700 V

PG3000-240-3HLD 120/240 VAC Three Phase High Leg Delta

115% 80 kA 80 kA 80 kA 80 kA 160 kA 400 V / 400 V / 330 V 900 V

(700 V) (700 V)

PG3000-480-3Y 277/480 VAC Three Phase Wye

115% 80 kA 80 kA 80 kA 80 kA 160 kA 800 V 700 V 700 V 1,500 V

PG3000-480-3DLL 480 VAC Three Phase Delta

115% — — — 80 kA 80 kA — — — 1,500 V

PG3000-600-3Y 347/600 VAC Three Phase Wye

115% 80 kA 80 kA 80 kA 80 kA 160 kA 1,000 V 1,000 V 1,000 V 1,800 V

PG3000-600-3D 600 VAC Three Phase Delta

115% — 80 kA — 80 kA 160 kA — 1,500 V — 1,800 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above are independently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

The PG3000 Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Category locations.

Dimensions:

28.66"H x 15.11"W x 8.05"D

Weight: 60 lbs.

PER

PHASE

160kA

PG60 Series

Features

•Panel Extension design for mounting above or below 20" wide panel • UL1449, 2nd Edition and UL1283 Listed, cULus

•Available wiring space on each side for branch circuit or main input conductors • NEMA 12 Style Enclosure

•All mode Protection (L-N, L-G, N-G, L-L) • Lugs accept #10 to #2 AWG

•Redundant Protection per mode, replaceable master module • Available with flush mount cover PG1-FMP

•Integral 200 KAIC fusing and thermal protection • 10 year product warranty

•EMI/RFI Filtration – Up to 54 dB from 20 kHz to 100 MHz • Fault Current Tested to 200 KAIC

•Complementary Listed as Secondary Surge Arrester (OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights for each mode

•Form C Contacts

•Audible Alarm

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

PG60-240-2S 120/240 VAC Single Phase (split)

115% 60 kA 60 kA 60 kA 60 kA 120 kA 330 V 330 V 330 V 600 V

PG60-208-3Y 120/208 VAC Three Phase Wye

115% 60 kA 60 kA 60 kA 60 kA 120 kA 330 V 330 V 330 V 600 V

PG60-240-3HLD 120/240 VAC Three Phase High Leg Delta

115% 60 kA 60 kA 60 kA 60 kA 120 kA 330 V 330 V 330 V 900 V

(600 V) (700 V)

PG60-480-3Y 277/480 VAC Three Phase Wye

115% 60 kA 60 kA 60 kA 60 kA 120 kA 800 V 800 V 700 V 1,500 V

PG60-480-3DLL 480 VAC Three Phase Delta

115% — — — 60 kA 60 kA — — — 1,200 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above are independently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

PER

PHASE

12 0 kA

Flush Mount Plate PG1-FMP

The PG60 Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Category locations.

Dimensions:

16.0"H x 20.0"W x 6.0"D

Weight: 40 lbs.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PG2500 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • EMI/RFI Filtration – Up to 54 dB from 20 kHz to 100 MHz

•Redundant Protection per mode • UL1449, 2nd Edition and UL1283 Listed, cULus

•200 KAIC Surge Rated Fuses • NEMA 3R Style Enclosure

•Thermally Protected MOVs for maximum safety • Pre-wired with 40" of #10 AWG wire leads

•Fault Current Tested to 200 KAIC • 10 year product warranty

•Complementary Listed as Secondary Surge Arrester (OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights for each mode

•Form C Contacts

•Audible Alarm

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

IG2401SECA 120/240 VAC Single-Phase (Split)

115% 60 kA 60 kA 60 kA 60 kA 120 kA 400 V 400 V 330 V 600 V

IG2083YECA 120/208 VAC Three Phase Wye

115% 60 kA 60 kA 60 kA 60 kA 120 kA 400 V 400 V 330 V 600 V

IG2403DECA 120/240 VAC Three Phase High Leg Delta

115% 60 kA 60 kA 60 kA 60 kA 120 kA 400 V / 400 V / 330 V 700 V

(600 V) (700 V)

IG4803YECA 277/480 VAC Three Phase Wye

115% 60 kA 60 kA 60 kA 60 kA 120 kA 800 V 800 V 400 V 1,500 V

IG4803DECA 480 VAC Three Phase Delta

115% — 120 kA — 60 kA 180 kA — 1,500 V — 1,200 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above areindependently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

PER

PHASE

12 0 kA

The PG2500 Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Categorylocations.

Dimensions:

16.47"H x 10.59"W x 4.9"D

Weight: 28 lbs.

Flush Mount Plate IG1FMP-PG

PG2000 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • EMI/RFI Filtration – Up to 54 dB from 20 kHz to 100 MHz

•Redundant Protection per mode • UL1449, 2nd Edition and UL1283 Listed, cULus

•200 KAIC Surge Rated Fuses • NEMA 3R Style Enclosure

•Thermally Protected MOVs for maximum safety • Pre-wired with 40" of #10 AWG wire leads

•Fault Current Tested to 200 KAIC • 10 year product warranty

•Complementary Listed as Secondary Surge Arrester (OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights

•Form C Contacts

•Intermatic Thermal Monitoring System

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

IG2401ECS 120/240 VAC Single-Phase (Split)

115% 30 kA 30 kA 30 kA 30 kA 60 kA 500 V 400 V 400 V 700 V

IG2083ECY 120/208 VAC Three Phase Wye

115% 30 kA 30 kA 30 kA 30 kA 60 kA 400 V 500 V 400 V 700 V

IG2403ECD 120/240 VAC Three Phase High Leg Delta

115% 30 kA 30 kA 30 kA 30 kA 60 kA 400 V / 400 V / 330 V 700 V

(700 V) (700 V)

IG4803ECY 277/480 VAC Three Phase Wye

115% 30 kA 30 kA 30 kA 30 kA 60 kA 800 V 800 V 400 V 1,500 V

IG4803ECD 480 VAC Three Phase Delta

115% — 60 kA — 30 kA 90 kA — 1,500 V — 1,500 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above areindependently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

PER

PHASE

60kA

The PG2000 Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Categorylocations.

Dimensions:

16.47"H x 10.59"W x 4.9"D

Weight: 28 lbs.

Flush Mount Plate IG1FMP-PG

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PG40 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • UL1449, 2nd Edition and UL1283 Listed, cULus

•Redundant Protection per mode • NEMA 4 style enclosure

•Integral 200 KAIC fusing and thermal protection • Pre-wired with 30" of #10 AWG wire leads

•Thermally protected MOVs for maximum safety • Available with flush mount cover PG2-FMP

•Fault current tested to 200 KAIC • 10 year product warranty

•EMI/RFI Filtration – Up to 54 dB from 20 kHz to 100 MHz • Complementary Listed as Secondary Surge Arrester

(OWHX,E135626)

Integral Diagnostics

• LED indicator lights for each mode

•Form C Contacts

•Audible alarm

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

PG40-240-2S 120/240 VAC Single Phase (split)

115% 40 kA 40 kA 40 kA 40 kA 80 kA 330 V 330 V 400 V 700 V

PG40-208-3Y 120/208 VAC Three Phase Wye

115% 40 kA 40 kA 40 kA 40 kA 80 kA 330 V 330 V 400 V 700 V

PG40-240-3HLD 120/240 VAC Three Phase High Leg Delta

115% 40 kA 40 kA 40 kA 40 kA 80 kA 330 V 330 V 400 V 900 V

(600 V) (600 V)

PG40-480-3Y 277/480 VAC Three Phase Wye

115% 40 kA 40 kA 40 kA 40 kA 80 kA 800 V 800 V 800 V 1,500 V

PG40-480-3D 480 VAC Three Phase Delta

115% — 40 kA — 40 kA 80 kA — 1,200 V — 1,200

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above are independently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

PER

PHASE

80kA

The PG40 Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Categorylocations.

Dimensions:

11.0"H x 5.875"W x 3.75"D

Weight: 22 lbs.

Flush Mount Plate PG2-FMP

100

101

EH Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • EMI/RFI Filtration – 20 to 30 dB from 20 kHz to 100 MHz

•Redundant Protection per mode • UL1449, 2nd Edition Listed, cULus

•200 KAIC Surge Rated Fuses • NEMA 12 Style Enclosure

•Thermally Protected MOVs for maximum safety • Pre-wired with 30" of #10 AWG wire leads

•Fault Current Tested to 200 KAIC • 10 year product warranty

•Complementary Listed as Secondary Surge Arrester (OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights

•Intermatic Thermal Monitoring System

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8 x 20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

IG1201EH 120 VAC Single Phase

115% 26 kA 26 kA 26 kA — 52 kA 500 V 500 V 500 V —

IG2401EH 120/240 VAC Single Phase (split)

115% 26 kA 26 kA 26 kA 26 kA 52 kA 400 V 400 V 400 V 700 V

IG2083YEH 120/208 VAC Three Phase Wye

115% 26 kA 26 kA 26 kA 26 kA 52 kA 400 V 400 V 400 V 700 V

IG2403DEH 120/240 VAC Three Phase High Leg Delta

115% 26 kA 26 kA 26 kA 26 kA 52 kA 400 V / 400 V / 400 V 700 V

(700 V) (700 V)

IG4803YEH 277/480 VAC Three Phase Wye

115% 26 kA 26 kA 26 kA 26 kA 52 kA 800 V 800 V 400 V 1,500 V

IG4803DEH 480 VAC Three Phase Delta

115% — 52 kA — 26 kA 78 kA — 1,200 V — 1,500 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above are independently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

Flush Mount Plate IG1FMP-H

PER

PHASE

52kA

The EH Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Categorylocations.

Dimensions:

7.5"H x 4.25"W x 4.0"D

Weight: 5.5 lbs.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PG20 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • UL1449, 2nd Edition and UL1283 Listed, cULus

•Redundant Protection per mode • NEMA 4 style enclosure

•Integral 200 KAIC fusing and thermal protection • Pre-wired with 30" of #10 AWG wire leads

•Thermally protected MOVs for maximum safety • Available with flush mount cover PG2-FMP

•Fault current tested to 200 KAIC • 10 year product warranty

•EMI/RFI Filtration – Up to 54 dB from 20 kHz to 100 MHz • Complementary Listed as Secondary Surge Arrester

(OWHX,E135626)

Integral Diagnostics

• LED indicator lights for each mode

•Form C Contacts

•Audible alarm

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

PG20-240-2S 120/240 VAC Single Phase (split)

115% 20 kA 20 kA 20 kA 20 kA 40 kA 330 V 330 V 400 V 700 V

PG20-208-3Y 120/208 VAC Three Phase Wye

115% 20 kA 20 kA 20 kA 20 kA 40 kA 330 V 330 V 400 V 700 V

PG20-240-3HLD 120/240 VAC Three Phase High Leg Delta

115% 20 kA 20 kA 20 kA 20 kA 40 kA 330 V 330 V 400 V 900 V

(600 V) (600 V)

PG20-480-3Y 277/480 VAC Three Phase Wye

115% 20 kA 20 kA 20 kA 20 kA 40 kA 800 V 800 V 800 V 1,500 V

PG20-480-3D 480 VAC Three Phase Delta

115% — 20 kA — 20 kA 40 kA — 1,200 V — 1,200 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above are independently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

Flush Mount Plate PG2-FMP

PER

PHASE

40kA

The PG20 Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Category locations.

Dimensions: 11.0"H x 5.875"W x

3.75"D

Weight: 22 lbs.

102

103

LH Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • UL1449, 2nd Edition, cULus

•200 KAIC Surge Rated Fuses • NEMA 12 Style Enclosure

•Thermally Protected MOVs for maximum safety • Pre-wired with 30" of #10 AWG wire leads

•Fault Current Tested to 200 KAIC • 10 year product warranty

•EMI/RFI Filtration – 20 to 30 dB from 20 kHz to 100 MHz • Complementary Listed as Secondary Surge Arrester

(OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights

•Intermatic Thermal Monitoring System

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8 x 20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

IG1201LH 120 VAC Single Phase

115% 13 kA 13 kA 13 kA — 26 kA 500 V 500 V 400 V —

IG2401LH 120/240 VAC Single Phase (split)

115% 13 kA 13 kA 13 kA 13 kA 26 kA 400 V 500 V 400 V 700 V

IG2083LYH 120/208 VAC Three Phase Wye

115% 13 kA 13 kA 13 kA 13 kA 26 kA 500 V 500 V 400 V 700 V

IG2403LDH 120/240 VAC Three Phase High Leg Delta

115% 13 kA 13 kA 13 kA 13 kA 26 kA 500 V / 500 V / 500 V 700 V

(700 V) (700 V)

IG4803LYH 277/480 VAC Three Phase Wye

115% 13 kA 13 kA 13 kA 13 kA 26 kA 800 V 800 V 500 V 1,500 V

IG4803LDH 480 VAC Three Phase Delta

115% — 26 kA — 13 kA 39 kA — 1,500 V — 1,500 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above are independently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

Flush Mount Plate IG1FMP-H

PER

PHASE

26kA

The LH Series is a hardwired

suppression device (installed in

parallel) and recommended for

ANSI/IEEE Category locations for A

and B.

Dimensions:

7.5"H x 4.25"W x 4.0"D

Weight: 5.5 lbs.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

PG1500 Series

Features

•L-N, N-G protection modes (4 mode) • UL1449, 2nd Edition and UL1283 Listed, cULus

•Redundant protection per mode • NEMA 4 style enclosure

•Integral 200 KAIC fusing and thermal protection • Pre-wired with 30" of #10 AWG wire leads

•Thermally protected MOVs for maximum safety • Available with flush mount cover PG2-FMP

•Fault current tested to 200 KAIC • 10 year product warranty

•EMI/RFI filtration – Up to 54 dB from 20 kHz to 100 MHz • Complementary Listed as Secondary Surge Arrester

(OWHX,E135626)

Integral Diagnostics

• LED indicator lights for each mode

•Form C Contacts

•Audible alarm

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-N L-N L-G N-G L-L L-N L-G N-G L-L

PG1500-240-2S 120/240 VAC Single Phase (split)

115% 80 kA — 40 kA 80 kA 80 kA 330 V 700 V 400 V 600 V

PG1500-208-3Y 120/208 VAC Three Phase Wye

115% 80 kA — 40 kA 80 kA 80 kA 330 V 700 V 400 V 600 V

PG1500-480-3Y 277/480 VAC Three Phase Wye

115% 80 kA — 40 kA 80 kA 80 kA 800 V 1,500 V 800 V 1,500 V

PG1500-480-3D 480 VAC Three Phase Delta

115% — 80 kA — 80 kA 160 kA — 1,200 V — 1,200 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above areindependently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

PER

PHASE

80kA

The PG1500 Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Categorylocations.

Dimensions:

11.0"H x 5.875"W x 3.75"D

Weight: 22 lbs.

Flush Mount Plate PG2-FMP

104

105

PG1000 Series

Features

•L-N, N-G protection modes (4 mode) • UL1449, 2nd Edition and UL1283 Listed, cULus

•Redundant protection per mode • NEMA 4 style enclosure

•Integral 200 KAIC fusing and thermal protection • Pre-wired with 30" of #10 AWG wire leads

•Thermally protected MOVs for maximum safety • Available with flush mount cover PG2-FMP

•Fault current tested to 200 KAIC • 10 year product warranty

•EMI/RFI filtration – Up to 54 dB from 20 kHz to 100 MHz • Complementary Listed as Secondary Surge Arrester

(OWHX,E135626)

Integral Diagnostics

• LED indicator lights for each mode

•Form C Contacts

•Audible alarm

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode)2Phase36kV, 500 Amp (8 x 20 usec)4

Intermatic MCOV1

Model L-N L-N L-G N-G L-L L-N L-G N-G L-L

PG1000-240-2S 120/240 VAC Single Phase (split)

115% 40 kA — 40 kA 40 kA 40 kA 330 V 700 V 400 V 600 V

PG1000-208-3Y 120/208 VAC Three Phase Wye

115% 40 kA — 40 kA 40 kA 40 kA 330 V 700 V 400 V 600 V

PG1000-480-3Y 277/480 VAC Three Phase Wye

115% 40 kA — 40 kA 40 kA 40 kA 800 V 1,500 V 800 V 1,500 V

PG1000-480-3D 480 VAC Three Phase Delta

115% — 40 kA — 40 kA 80 kA — 1,200 V — 1,200 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percentage of nominal voltage.

2All surge currents listed above areindependently tested and verified per NEMA LS-1.

3Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

4Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Surge Suppression System

PER

PHASE

40kA

The PG1000 Series is a hardwired

suppression device (installed in

parallel) and recommended for all

ANSI/IEEE Category locations.

Dimensions:

11.0"H x 5.875"W x 3.75"D

Weight: 22 lbs.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Flush Mount Plate PG2-FMP

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Product Selection Chart – Modular Models

The following guidelines can be followed for Intermatic products:

Choose Model by Voltage

Location 480 VAC Delta 277/480 VAC Wye 120/208 VAC Wye Refer to Page

Large Service Entrance 2000 to 4000 Amp

Best SG320K-480-3D SG320K-480-3Y SG320K-208-3Y 107

Better SG240K-480-3D SG240K-480-3Y SG240K-208-3Y 108

Good UG40A4803D UG404803Y UG40A2083Y 110

Small Service Entrance Less than 1600 Amp

Best SG240K-480-3D SG240K-480-3Y SG240K-208-3Y 108

Better SG160K-480-3D SG160K-480-3Y SG160K-208-3Y 109

Good UG30A4803D UG30A4803Y UG30A2083Y 111

Distribution Panel 1000 to 1600 Amp

Best SG160K-480-3D SG160K-480-3Y SG160K-208-3Y 109

Better UG30A4803D UG30A4803Y UG30A2083Y 111

Good UG28A4803D UG28A4803Y UG28A2083Y 112

Panelboard 60 to 400 Amp

Best UG30A4803D UG30A4803Y UG30A2083Y 111

Better UG28A4803D UG28A4803Y UG28A2083Y 112

Modular Protection System

NOTES:

•Pick appropriate model to match the voltage of your Service

Entrance, Distribution Panel or Panelboard.

• See individual product pages for other available voltages.

• A facility without any Service Entrance protection would

warrant a higher level of protection at downstream locations.

There are four main factors to

consider when specifying the

appropriate device for your facility:

1. What is the amperage (size) of the

Switchboard or Panelboard at the

point of installation?

2. What is the geographic location of

the facility? (i.e. the relative level of

lightning exposure and utility grid

switching activity)

3. What is the density of electronic

equipment and how critical is the

application? (i.e. a 7 x 24 computer

data center would require a higher level

of protection than a retail store)

4. What is the level of transient and

noise producing loads within your

facility? (i.e. a heavy industrial

manufacturing environment or a densely

populated computer data center would

require a higher level of protection)

106

107

SG320 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • 40 kA Brute Force MOVs

•Fault Current Tested to 200 KAIC • Redundant Protection per mode

•EMI/RFI Filtration – Up to 50 dB from 20 kHz to 100 MHz • Thermally Protected MOVs for maximum safety

•Replaceable Modules for low MTTR • UL1449, 2nd Edition and UL1283 Listed, UL and cUL

•NEMA 12 Enclosure • 5 year product warranty

Installation:

•Recommended installation is with 30-100 Amp breaker

Integral Diagnostics

•LED Indicator Lights • Audible Alarm

•Form C Contacts • Digital Surge Counter

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode) Phase26kV, 500 Amp (8 x 20 usec)3

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

SG320K-208-3Y 120/208 VAC Three Phase Wye

115% 160 kA 160 kA 120 kA 160 kA 320 kA 400 V 400 V 700 V 800 V

SG320K-240-3HLD 120/240 VAC Three Phase High Leg Delta

115% 160 kA 160 kA 120 kA 160 kA 320 kA 400 V / 400 V / 700 V 800 V

(800 V) (800 V)

SG320K-480-3Y 277/480 VAC Three Phase Wye

115% 160 kA 160 kA 120 kA 160 kA 320 kA 800 V 800 V 1,500 V 1,500 V

SG320K-480-3D 480 VAC Three Phase Delta

115% — 160 kA — 160 kA 320 kA — 1,500 V — 2,500 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percent of nominal voltage.

2Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

3Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Modular Protection System

REPLACEMENT MODULE INFORMATION

System Number: Quantity & Part Number

SG320K-208-3Y (3) SG160-120V-M

SG320K-240-3HLD (2) SG160-120V-M

(1) SG160-240V-M

SG320K-480-34 (3) SG160-277V-M

SG320K-480-3D (3) SG160-480V-M

The SG320 Series is a modular

hardwired suppression device and

recommended for all ANSI/IEEE

Categorylocations. Contains one

bolt-on module per phase for easy

maintenance.

Dimensions: 16"H x 14"W x 6"D

Weight: 29 lbs.

PER

PHASE

320 kA

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

SG240 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • 40 kA Brute Force MOVs

•Fault Current Tested to 200 KAIC • Redundant Protection per mode

•EMI/RFI Filtration – Up to 50 dB from 20 kHz to 100 MHz • Thermally Protected MOVs for maximum safety

•Replaceable Modules for low MTTR • UL1449, 2nd Edition and UL1283 Listed, UL and cUL

•NEMA 12 Enclosure • 5 year product warranty

Installation:

•Recommended installation is with 30-100 Amp breaker

Integral Diagnostics

•LED Indicator Lights • Audible Alarm

•Form C Contacts • Digital Surge Counter

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8 x 20 usec) (per mode) Phase26kV, 500 Amp (8 x 20 usec)3

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

SG240K-208-3Y 120/208 VAC Three Phase Wye

115% 120 kA 120 kA 120 kA 120 kA 240 kA 400 V 400 V 700 V 800 V

SG240K-240-3HLD 120/240 VAC Three Phase High Leg Delta

115% 120 kA 120 kA 120 kA 120 kA 240 kA 400 V / 400 V / 700 V 800 V

(800 V) (800 V)

SG240K-480-3Y 277/480 VAC Three Phase Wye

115% 120 kA 120 kA 120 kA 120 kA 240 kA 800 V 800 V 1,500 V 1,500 V

SG240K-480-3D 480 VAC Three Phase Delta

115% — 120 kA — 120 kA 240 kA — 1,500 V — 2,500 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percent of nominal voltage.

2Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

3Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Modular Protection System

REPLACEMENT MODULE INFORMATION

System Number: Quantity & PartNumber

SG240K-208-3Y (3) SG120-120V-M

SG240K-240-3HLD (2) SG120-120V-M

(1) SG120-240V-M

SG240K-480-34 (3) SG120-277V-M

SG240K-480-3D (3) SG120-480V-M

The SG240 Series is a modular

hardwired suppression device and

recommended for all ANSI/IEEE

Category locations. Contains one

bolt-on module per phase for easy

maintenance.

Dimensions:

16"H x 14"W x 6"D

Weight: 28 lbs.

PER

PHASE

240kA

108

109

SG160 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • 40 kA Brute Force MOVs

•Fault Current Tested to 200 KAIC • Redundant Protection per mode

•EMI/RFI Filtration – Up to 50 dB from 20 kHz to 100 MHz • Thermally Protected MOVs for maximum safety

•Replaceable Modules for low MTTR • UL1449, 2nd Edition and UL1283 Listed, UL and cUL

•NEMA 12 Enclosure • 5 year product warranty

Installation:

•Recommended installation is with 30-100 Amp breaker

Integral Diagnostics

•LED Indicator Lights • Audible Alarm

•Form C Contacts • Digital Surge Counter

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8x20 usec) (per mode) Phase26kV, 500 Amp (8 x 20 usec)3

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

SG160K-208-3Y 120/208 VAC Three Phase Wye

115% 80 kA 80 kA 120 kA 80 kA 160 kA 400 V 400 V 700 V 800 V

SG160K-240-3HLD 120/240 VAC Three Phase High Leg Delta

115% 80 kA 80 kA 120 kA 80 kA 160 kA 400 V / 400 V / 700 V 800 V

(800 V) (800 V)

SG160K-480-3Y 277/480 VAC Three Phase Wye

115% 80 kA 80 kA 120 kA 80 kA 160 kA 800 V 800 V 1,500 V 1,500 V

SG160K-480-3D 480 VAC Three Phase Delta

115% — 80 kA — 80 kA 160 kA — 1,500 V — 2,500 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percent of nominal voltage.

2Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

3Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Modular Protection System

REPLACEMENT MODULE INFORMATION

System Number: Quantity & Part Number

SG160K-208-3Y (3) SG80-120V-M

SG160K-240-3HLD (2) SG80-120V-M

(1) SG80-240V-M

SG160K-480-34 (3) SG80-277V-M

SG160K-480-3D (3) SG80-480V-M

The SG160 Series is a modular

hardwired suppression device and

recommended for all ANSI/IEEE

Category locations. Contains one

bolt-on module per phase for easy

maintenance.

Dimensions: 16"H x 14"W x 6"D

Weight: 27 lbs.

PER

PHASE

160kA

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

UG40 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • Fault Current Tested to 200 KAIC

•Integral Disconnect • 200 KAIC Surge Rated Fuses

•Redundant Protection per mode • EMI/RFI Filtration – 20 to 30 dB from 20 kHz to 100 MHz

•Thermally Protected MOVs for maximum safety • Replaceable Modules for low MTTR

•UL1449, 2nd Edition, cULus • NEMA 3R Style Enclosure

•10 year product warranty • Complementary Listed as Secondary Surge Arrester

(OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights • Intermatic Thermal Monitoring System

•Audible Alarm • Form C Contacts

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8 x 20 usec) (per mode) Phase26kV, 500 Amp (8 x 20 usec)3

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

UG40A2401S 120/240VAC Single Phase (split)

115% 45 kA 45kA 90 kA 45 kA 90 kA 500 V 500 V 500 V 800 V

UG40A2083Y 120/208 VACThree Phase Wye

115% 45 kA 45 kA 135 kA 45 kA 90 kA 500 V 500 V 500 V 700 V

UG40A2403D 120/240 VAC Three Phase High Leg Delta

115% 45 kA 45 kA 135 kA 45 kA 90 kA 500 V / 500 V / 500 V 800 V

(800 V) (700 V)

UG40A2403G 240 VAC Three Phase Delta

115% — 90 kA — 45 kA 125 kA — 700 V — 800 V

UG40A4803Y 277/480 VAC Three Phase Wye

115% 45 kA 45 kA 135 kA 45 kA 90 kA 900 V 900 V 800 V 1,500 V

UG40A4803D 480 VAC Three Phase Delta

115% — 90 kA — 45 kA 135 kA — 1,500 V — 1,500 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percent of nominal voltage.

2Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

3Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Modular Protection System

REPLACEMENT MODULE INFORMATION

System Number: Quantity & Part Number

UG40A2401S (2) UG41120A

UG40A2083Y (3) UG41120B

UG40A2403D (2) UG41120A

(1) UG41208A

UG40A2403G (3) UG41240A

UG40A4803Y (3) UG41277A

UG40A4803D (3) UG41480A

The UG40 Series is a modular

hardwired suppression device and

recommended for all ANSI/IEEE

Category locations. Contains one

module per phase for easy

maintenance.

Dimensions:

20.75"H x 10.75"W x 4.75"D

Weight: 23 lbs.

PER

PHASE

90kA

110

111

UG30 Series

Features

•All mode Protection (L-N, L-G, N-G, L-L) • Thermally Protected MOVs for maximum safety

•Fault Current Tested to 200 KAIC • Replaceable Modules for low MTTR

•200 KAIC Surge Rated Fuses • UL1449, 2nd Edition, cULus

•Redundant Protection per mode • NEMA 3R Style Enclosure

•EMI/RFI Filtration – 20 to 30 dB from 20 kHz to 100 MHz • 10 year product warranty

•Complementary Listed as Secondary Surge Arrester (OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights

•Intermatic Thermal Monitoring System

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8 x 20 usec) (per mode) Phase26kV, 500 Amp (8 x 20 usec)3

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

UG30A2401S 120/240 VAC Single Phase (split)

115% 45kA 45 kA 90 kA 45 kA 90 kA 500 V 500 V 400 V 700 V

UG30A2083Y 120/208 VAC Three Phase Wye

115% 45 kA 45 kA 135 kA 45 kA 90 kA 500 V 500 V 400 V 700 V

UG30A2403D 120/240 VAC Three Phase High Leg Delta

115% 45 kA 45 kA 135 kA 45 kA 90 kA 500 V / 500 V / 400 V 700 V

(700 V) (700 V)

UG30A2403G 240 VAC Three Phase Delta

115% — 90 kA — 45 kA 135 kA — 700 V — 700 V

UG30A4803Y 277/480 VAC Three Phase Wye

115% 45 kA 45 kA 135 kA 45 kA 90 kA 800 V 800 V 800 V 1,500 V

UG30A4803D 480 VAC Three Phase Delta

115% — 90 kA — 45 kA 135 kA — 1,500 V — 1,500 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percent of nominal voltage.

2Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

3Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Modular Protection System

Flush Mount Plate UG1-FMP

REPLACEMENT MODULE INFORMATION

System Number: Quantity & Part Number

UG30A2401S (2) UG29120A

UG30A2083Y (3) UG29120A

UG30A2403D (2) UG29120A

(1) UG29208A

UG30A2403G (3) UG29240A

UG30A4803Y (3) UG29277A

UG30A4803D (3) UG29480A

PER

PHASE

90kA

The UG30 Series is a modular

hardwired suppression device and

recommended for all ANSI/IEEE

Categorylocations. Contains one

module per phase for easy

maintenance.

Dimensions:

12.88"H x 10.94"W x 4.65"D

Weight: 15 lbs.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

UG28 Series

Features

•Nine mode Protection (L-N, L-G, L-L) • Thermally Protected MOVs for maximum safety

•Fault Current Tested to 200 KAIC • Replaceable Modules for low MTTR

•200 KAIC Surge Rated Fuses • UL1449, 2nd Edition, cULus

•Redundant Protection per mode • NEMA 3R Style Enclosure

•EMI/RFI Filtration – 20 to 30 dB from 20 kHz to 100 MHz • 10 year product warranty

•Complementary Listed as Secondary Surge Arrester (OWHX,E135626)

Integral Diagnostics

•LED Indicator Lights

•Intermatic Thermal Monitoring System

Surge Current Capacity Per UL 1449 Clamping Voltage (SVR)

(8 x 20 usec) (per mode) Phase26kV, 500 Amp (8 x 20 usec)3

Intermatic MCOV1

Model L-G L-N L-G N-G L-L L-N L-G N-G L-L

UG28A2401S 120/240 VAC Single Phase (split)

115% 45kA 45 kA — 45 kA 90 kA 500 V 500 V — 700 V

UG28A2083Y 120/208 VAC Three Phase Wye

115% 45 kA 45 kA — 45 kA 90 kA 500 V 500 V — 700 V

UG28A2403D 120/240 VAC Three Phase High Leg Delta

115% 45 kA 45 kA — 45 kA 90 kA 500 V / 500 V / — 700 V

(700 V) (700 V)

UG28A4803Y 277/480 VAC Three Phase Wye

115% 45 kA 45 kA — 45 kA 90 kA 800 V 800 V — 1,500 V

UG28A4803D 480 VAC Three Phase Delta

115% — 90 kA — 45 kA 135 kA — 1,500 V — 1,500 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percent of nominal voltage.

2Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

3Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Modular Protection System

Flush Mount Plate UG1-FMP

REPLACEMENT MODULE INFORMATION

System Number: Quantity & Part Number

UG28A2401S (2) UG27120A

UG28A2083Y (3) UG27120A

UG28A2403D (2) UG27120A

(1) UG27208A

UG28A4803Y (3) UG27277A

UG28A4803D (3) UG27480A

PER

PHASE

90kA

The UG28 Series is a modular

hardwired suppression device and

recommended for all ANSI/IEEE

Categorylocations. Contains one

module per phase for easy

maintenance.

Dimensions:

12.88"H x 10.94"W x 4.65"D

Weight: 15 lbs.

112

113

F20 Series

Features

•All mode Protection • NEMA 4 Enclosure

•Thermally Protected MOVs for maximum safety • EMI/RFI Filtration – 26 to 39 dB

•UL1449, 2nd Edition and UL1283 Listed, cULus • 5 year product warranty

Integral Diagnostics

•LED Indicator Lights

•Intermatic Thermal Monitoring System

•Form C Contacts

Surge Current Capacity UL 1449 Clamping Voltage (SVR)

(8 x 20 usec) (per mode) 6kV, 500 Amp (8 x 20 usec)3

Intermatic MCOV1Per

Model L-G L-N L-G N-G L-L Phase2L-N L-G N-G L-L

IG1201F20 120 VAC Single Phase

115% 16 kA 16 kA 16 kA — 32 kA 500 V 500 V 500 V —

IG2401F20 240 VAC Single Phase

115% — 32 kA — 16 kA 48 kA — 700 V — 700 V

NOTES:

1MCOV is Maximum Continuous Operating Voltage expressed in percent of nominal voltage.

2Per Phase is defined as L-N + L-G for three phase 4-wire wye systems; L-G + L-L for three phase 3-wire delta systems.

3Let-Through Voltage measured with 6 inch lead lengths per UL Standard 1449, 2nd Edition.

Industrial Point-of-Use Protection

Din Rail Adapter Kit IG1DIN-F20

The F20 Series is a hardwired in line

suppression device for protection of

loads up to 20 Amps including fire

alarm circuits, industrial controls,

PLC’s and any other sensitive

electronic equipment.

Dimensions:

4.54"H x 3.5"W x 2.2"D

Weight: 2.5 lbs.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Features

•Designed for heavy industrial use • 14 gauge SJT power cord with molded plug

•3-mode Surge Protection (L-N, L-G, N-G) • Protection monitoring circuitry with LED light indicator

•UL1449, 2nd Edition, cULus • 15 amp resettable breaker

•EMI/RFI noise filtration • Ivory metal housing

See chart on page 115 for UL1449 ratings and EMI/RFI filtration.

Computer Control Centers

Features

•6centralized switches • 9 ft., 14 gauge power cord

•One unswitched receptacle • LED Indicator Light monitors power on & protection status

•Metal housing • L-N, L-G and N-G surge protection

•Static discharge pad • cULus

•15 Amp, resettable circuit breaker • UL1449, 2nd Edition

Industrial Point-of-Use Protection

A. IG11246

•4-outlets

• 6 ft. cord

•Lighted On/Off switch

B. IG11466

•6-outlets

• 6 ft. cord

•Lighted On/Off switch

•Enhanced EMI/RFI noise filtration, UL1283

C. IG11266

•6-outlets

• 6 ft. cord

•Lighted On/Off switch

D. IG11266BLK10

•Black

•6-outlets

•10 ft. cord

•Lighted On/Offswitch

E. IG2066 & IG20615

• 6 specification-grade outlets

•Master On/Offswitch

•Enhanced EMI/RFI noise filtration, UL1283

• 6 ft. cord (IG2066); 15 ft. cord (IG20615)

F. IG1866A

•6-outlets

• 6 ft. cord

•Audible alarm

•Master On/Off switch

• Enhanced EMI/RFI noise filtration, UL1283

G. IG20B12 & IG2012B15

• 6 specification-grade outlets

•Master On/Off switch

•Enhanced EMI/RFI noise filtration, UL1283

• 6 ft. cord (IG20B12); 15 ft. cord (IG2012B15)

H. IG2086

• 8 specification-grade outlets

•Master On/Offswitch

•Enhanced EMI/RFI noise filtration, UL1283

• 6 ft. cord

I. IG9638S55

• 6 specification-grade outlets

•Lighted On/Off switch

•Steel housing

•15 ft. cord

J. IG141

•Standardmodel

K. IG141T

•Standard model with phone/fax/modem protection

•RJ11 connectors

L. IG143

•Enhanced EMI/RFI noise attenuation

•Dual choke design for lower clamping

M. IG143T

•Enhanced model with phone/fax/modem protection

•RJ11 connectors

114

115

Mounting Bracket & Plate

N. IG1SRMP

•Allows any IG strip to be mounted on a 19" equipment rack

O. 24EG5133

•Secures mounting bracket for all IG strips in extruded aluminum alloy housing (See models on chart with *)

Product Selection Chart – Point of Use Models

Energy Capacity UL1449 EMI-RFI Noise

Clamping Filtration

Number Max. Max. Connected Voltage (SVR) Prod.

Intermatic of Cord Electrical Joule. Surge. Equipment 6 kV, 500A Frequency Max. Warr.

Model Outlets Length Rating Rating Amperage $ Coverage (8 x 20 µ sec) Range (Hz) Reduc. (yrs)

Industrial Grade L-N/L-G/N-G

IG11246* 4 6 120 V/15 A 480 24,000 A $10,000 400/400/400 100k-20M 25dB 5

IG11266* 6 6 120 V/15 A 480 24,000 A $10,000 400/400/400 100k-20M 25dB 5

IG11266BLK10* 6 10 120 V/15 A 480 24,000 A $10,000 400/400/400 100k-20M 25dB 5

IG11466* 6 6 120 V/15 A 480 24,000 A $10,000 400/400/400 100k-20M 40dB 5

IG1866A* 6 6 120 V/15 A 960 48,000 A $25,000 330/330/330 100k-100M 62dB 5

IG2066* 6 6 120 V/15 A 960 48,000 A $25,000 330/330/330 100k-100M 62dB 5

IG20615* 6 15 120 V/15 A 960 48,000 A $25,000 330/330/330 100k-100M 62dB 5

IG20B12* 6 6 120 V/15 A 480 24,000 A $5,000 400/400/400 100k-20M 25dB 5

IG2012B15* 6 15 120 V/15 A 480 24,000 A $ 5,000 400/400/400 100k-20M 25dB 5

IG9638S55 6 15 120 V/15 A 480 24,000 A — 400/400/400 100k-20M 21dB 5

IG2086* 8 6 120 V/15 A 960 48,000 A $25,000 330/330/330 100k-100M 62dB 5

Computer Control Centers

IG141 6 9 120 V/15 A 480 24,000 A $10,000 400/400/400 100k-20M 25dB 5

IG141T 6 9 120 V/15 A 480 24,000 A $10,000 400/400/400 100k-20M 25dB 5

IG143 6 9120 V/15 A 960 48,000 A $25,000 330/330/330 100k-100M 62dB 5

IG143T 6 9 120 V/15 A 960 48,000 A $25,000 330/330/330 100k-100M 62dB 5

*=Extruded aluminum housing

NOTE: Cord lengths can be modified up to 25 feet. Consult Factory for pricing and availability.

Industrial Point-of-Use Protection

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

IG Series

Features

•Hardwired models provide greater capacity to handle surge energy (based on their close location to the service ground) compared to

standard plug-in strips

•Designed for 120/240 volt single or (split-phase) panels

•Dual LED indicator(s) provides surge protection status on AC

A. IG1300-2T-1C

•120/240 VAC Single (Split) Phase

•6 Modes of Surge Protection (L1-N, L2-N, L1-G, L2-G, N-G, L1-L2)

•Provides protection for 2 Telephone Lines (Analog Phone Line, Modem, or DSL) and 1 Coax Line

(Cable TV, Cable Internet or Satellite TV)

•UL 1449 Listed, 2nd Edition and UL497A Listed, cULus

•NEMA 3R Raintight Enclosure for indoor or outdoor installations (9.38"H x 5.25"W x 4.0"D)

• Tested to 65 kAIC per NEC Section 285

• 5 Year Product Warranty

•$10,000 Connected Equipment Coverage

•Complementary Listed as Secondary Surge Arrester (OWHX,E135626)

B. IG1300-4T-2C

•120/240 VAC Single (Split) Phase

•6 Modes of Surge Protection (L1-N, L2-N, L1-G, L2-G, N-G, L1-L2)

•Provides protection for 4 Telephone Lines (Analog Phone Line, Modem, or DSL) and 2 Coax Lines

(Cable TV, Cable Internet or Satellite TV)

•UL 1449 Listed, 2nd Edition and UL497A Listed, cULus

•NEMA 3R Raintight Enclosure for indoor or outdoor installations (9.38"H x 5.25"W x 4.0"D)

• Tested to 65 kAIC per NEC Section 285

• 5 Year Product Warranty

•$10,000 Connected Equipment Warranty (Appliances and Electronics) [5 year]

•Complementary Listed as Secondary Surge Arrester (OWHX,E135626)

C. IG1240RC

•120/240 VAC Single (Split) phase

•6 Modes of Surge Protection (L1-N, L2-N, L1-G, L2-G, N-G, L1-L2)

•Green LED indicator provides status of protection; Red LED indicator indicates reduced protection

•NEMA 4 plastic housing (5.65"H x 4.18"W x 3.33"D)

• 5 year product warranty

•UL Listed UL1449, 2nd edition, cULus

•Tested to 65 kAIC per NEC Section 285

•$10,000 Connected Equipment Coverage (Appliances and Electronics) [5 year]

•ComplementaryListed as Secondary Surge Arrester (OWHX,E135626)

IG1240FMP3

•Includes faceplate, screws and mounting bracket for IG1240RC

D. IG3240RC

•120/240 VAC Single (Split) phase

•6 Modes of Surge Protection (L1-N, L2-N, L1-G, L2-G, N-G, L1-L2)

•Green LED indicator provides status of protection; Red LED indicator indicates reduced protection

•NEMA 4 metal housing (6.28"H x 4.4"W x 3.25"D)

•10 year product warranty

•UL Listed UL1449, 2nd edition, cULus

•Tested to 65 kAIC per NEC Section 285

•$25,000 Connected Equipment Coverage (Appliances and Electronics) [5 year]

•ComplementaryListed as SecondarySurge Arrester (OWHX,E135626)

IG3240FMP3

•Includes faceplate, screws and mounting bracket for IG3240RC

Residential Hardwired Protection

Flush Mount Plates

IG1240FMP3 IG3240FMP3

116

117

E. IG251

•Handles up to 600 Amp service capacity

•Enclosure size (6.0"H x 3.5"W x 3.0"D)

•Epoxy encapsulation protects surge components from moisture, dirt and corrosion

•5year product warranty

•UL 1449 2nd edition listed as a Transient Voltage Surge Suppressor

•250 Volt MCOV for generator applications

UL1449 Clamping

Peak Surge Voltage (SVR)

Current 6 kV, 500 Amp

Intermatic Service Leads Wire Per Phase/ (8 x 20 µ sec)

Model Voltage Phase # – Length Gauge Config. System L-N L-G N-G L-L

IG1300-2T-1C 120/240 2 4 24 14 L1, L2, N, GND 20 kA/60 kA 400 400 400 700

IG1300-4T-2C 120/240 2 4 24 14 L1, L2, N, GND 20 kA/60 kA 400 400 400 700

IG1240RC 120/240 2 4 30 14 L1, L2, N, GND 20 kA/60 kA 400 400 400 700

IG3240RC 120/240 2 4 30 14 L1, L2, N, GND 60 kA/180 kA 330 330 330 600

IG251 120/240 2 4 24 12 L1, L2, N, GND 48 kA/115 kA 600 — — 1200

Stand Alone Telephone / Modem / DSL Internet Lines

F. IG2TM

•Provides protection for 2 lines

•Tip to Ground, Tip to Ring and Ring to Ground Modes

•40 kA surge protection per line

•Gas Tube Protection 350 Volt DC Breakdown

•UL497A

•Nema 1 Type Enclosure

Breakdown

Model Number Application Lines Gauge Wire Configuration Voltage Application

IG2TM phone/modem/DSL up to 2 #24-#16 AWG 4wire 350 Vdc Indoor

G. IG4TM

•Protection same as IG2TM

•Protects 4 Lines

Breakdown

Model Number Application Lines Gauge Wire Configuration Voltage Application

IG4TM phone/modem/DSL up to 4 #24-#16 AWG 8 wire 350 Vdc Indoor

H. IG2T3R

•Protection same as IG2TM

•Provides protection for 2 lines (expandable to 12 Lines)

•Nema 3R Type Enclosure

Breakdown

Model Number Application Lines Gauge WireConfiguration Voltage Application

IG2T3R phone/modem/DSL 2 standard #24-#16 AWG 4 wire (up to 24 wire) 350 Vdc Indoor/Outdoor

(up to 12)

Residential Hardwired Protection

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Stand Alone Local Antenna/Cable - Satellite/Cable Internet Protection

I. IG1CM

•Provides Protection for 1 Line (Expandable to 2 Lines)

•10 kA surge protection per line

•Gas Tube Protection 90 Volt DC Breakdown

Breakdown

Model Number Application Lines Thread Type Voltage Application

IG1CM Cable TV/internet/satellite 1 F 90 Vdc Indoor

J. IG1C3R

•Protection same as IG1CM

•Provides Protection for 1 Line (Expandable to up to 6 Coax Lines)

•Nema 3R Type Enclosure

Breakdown

Model Number Application Lines Thread Type Voltage Application

IG1C3R Cable TV/internet/satellite 1Standard(up to 6) F 90 Vdc Indoor/Outdoor

K. IG2T

•Spare Telephone / Modem / DSL Internet Protection Module

Model Number Lines For Use In:

IG2T Spare 2 IG2TM, IG1CM, IG2T3R, IG1C3R, IG1300-2T-1C

L. IG1C

•Spare Coax Cable Protection Module

Model Number Lines For Use In:

IG1C Spare 1 IG1CM, IG1C3R, IG2TM, IG4TM, IG2T3R

M. IGFlush Mount Kit

•Flush mount kit for IG2TM, IG4TM, and IG1CM

Model Number For Use In:

IG Flush Mount Kit IG2TM IG4TM, IG1CM

Residential Hardwired Protection

118

119

Features:

•Designed for outdoor installations on service entrance and utility meter cabinets

•Approved for outdoor applications such as irrigation equipment, pumps, lighting fixtures, traffic signaling devices, farm equipment,

HVAC controls and motors

•Parallel metal oxide varistors (MOV) from each line to grounded neutral provide increased product capability

•Molded polycarbonate housing with 1/2" x 20 threaded nipple is weatherproof and UV resistant

•Epoxy encapsulation protects components from moisture, dirt and corrosion

•Color coded 18" leads

•UL listed as a secondary surge arrester, ANSI/IEEE C62.11 for Category “C” locations “OWHX”

• 2 year product warranty

Number of Leads/ Wire Actual Clamping Voltage

Model Service Voltage Poles Length Configuration (Line to Ground)

Standard(No LED’s) 1500A 5000A 10000A

AG2401C 120/240V 1 or 2 3/18" L1, L2, GND/N 490 980 1410

AG2083C 208V 3 4/18" L1, L2, L3, GND/N 490 980 1410

AG2403C 240V 3 4/18" L1, L2, L3, GND/N 740 1330 1850

AG4801 277V or 480V 1 or 2 3/18" L1, L2, GND 1450 2130 2620

AG4803C 480V 3 4/18" L1, L2, L3, GND/N 1450 2130 2620

AG6503C Up to 600V 3 4/18" L1, L2, L3, GND/N 1640 2340 2920

AG6503L Up to 600V 3 4/36" L1, L2, L3, GND/N 1640 2340 2920

Enhanced (with LED‘s)

AG2401C-IND 120/240V 1 or 2 3/18" L1, L2, GND/N 490 980 1410

AG6503C-IND Up to 600V 3 4/18" L1, L2, L3, GND/N 1640 2340 2920

Match the correct model to the voltage of your system/machine

The chart below shows Typical Clamp Voltage for each model.

Surge Arresters

Mounting Bracket

AG1BRKT

A. AG2401C

•120/240 single phase, 2 pole 3 wire device

•18" 14 gauge leads

B. AG2083C

•120/208 VAC, 3 pole 4 wire device

•18" 12 gauge leads

C. AG2403C

•240 VAC, 3 pole 4 wire device

•18" 12 gauge leads

D. AG4803C

•277/480 VAC or 480 VAC, 3 pole 4 wire device

•18" 12 gauge leads

E. AG6503C &

AG6503L

•Up to 600 V three phase, 3 pole 4 wire device

•18" 12 gauge leads (AG6503); 36" 10 gauge leads

(AG6503L)

F. AG4801

•277V or 480V VAC single phase, 2 pole 3 wire device

•18" 10 gauge leads

•18" 6 gauge green ground lead

G. AG2401C-IND

•120/240 single phase, 2 pole 3 wiredevice

•18" 14 gauge leads

H. AG6503C-IND

•Up to 600 V three phase 3 pole 4 wiredevice

•18" 12 gauge leads

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Number Peak Surge Current Clamping Enclosure

Service of 24" Wire Per Phase/ Voltage Size Weight

Model Voltage Phase Leads Configuration Per System @500A (inches) Lbs

UG240R 120/240 2 3 L1, L2, N 48 kA/115 kA L-N: 555 6.06 x 3.81 x 3.31 2.4

L-L 1028

IG250LA 120/240 2 3 L1, L2, N 48 kA/115 kA L-N: 555 6.0 x 3.5 x 3.0 2.4

L-L: 1028

Surge Protection Device Connected Equipment Coverage

Maximum Repair or

Product Type Page # Model Number Replacement Coverage

Metal Multi-Outlet Strip 114 IG2012B15 IG20B12

Metal Multi-Outlet Strip 114 IG11246 IG11266 IG11466

Computer Control Center 114 IG141 IG141T

Residential Grade Protector 116 IG1240RC IG1300-2T-1C IG1300-4T-2C

117 IG2TM IG4TM IG2T3R

118 IG1CM IG1C3R

Metal Multi-Outlet Strip 114 IG1866A IG2046

114 IG2066 IG2086

Computer Control Center 114 IG143 IG143T

Residential Grade Protector 116 IG3240RC

Surge Arresters

Surge Protection devices, with Connected

Equipment Coverage, offers the user extended

protection for sensitive equipment. In the

unlikely event that a damaging transient surge

passes through the surge device and damage

occurs to the connected equipment, Intermatic

will pay up to $25,000 to repair or replace the

equipment based on the specified model and

coverage provided. Refer to the warranty

document included with the product for specific

coverage details and

limitations.

A. UG240R

•120/240 V Surge Arrester for up to 600 Amp service

• 2 pole 3 wire configuration for installation on utility

cabinets and outdoor service panels

•Enclosure size (6.0"H x 3.5"W x 3.0"D)

•Steel weatherproof housing with lockable cover

•Epoxy encapsulation protects components from moisture,

dirt and corrosion

•UL listed as a Secondary Surge Arrester (OWHX)

•LED indicator provides surge protection status

• 5 year product warranty

B. IG250LA

•120/240 V Surge Arrester for up to 600 Amp service

•Designed for applications frequently subjected to high

level surge energy

•Enclosure size (6.63"H x 3.75"W x 2.5"D)

•Epoxy encapsulation protects components from moisture,

dirt and corrosion

•UL listed as a Secondary Surge Arrester (OWHX)

•LED indicator provides surge protection status

• 5 year product warranty

120

121

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Entering a New Century of Energy

Management and Home Security!

Indoor and Outdoor Timers

Intermatic offers a wide variety of styles

to meet today’s application

requirements.

Intermatic timers add convenience by

turning lights ON when needed, and

saves energy by turning lights OFF when

not needed. They give homes a lived-in

look providing an easy and economical

way to improve home security.

Outdoor timers also let users control

outside lights and holiday displays while

staying comfortably inside.

Power Failure Lights & Photo

Controls

Intermatic power failure lights have

many practical applications in the home:

in bedrooms, hallways, stairways,

bathrooms, kitchens and more.

Photo controls are a simple solution to

turning lights on when dark, off when

light.

Do-it-Yourself Security Alarms

The Burglary Prevention Council

statistics show that residential break-ins

occur every 11 seconds.

Intermatic answers the demand for

easy-to-install, affordable security

products with a full line of DIY portable

security alarms that have superior

features.

Intermatic Wireless Alarms provide

economical home security. There are no

monthly fees or setup charges. The

wireless feature offers easy do-it-

yourself installation at affordable prices.

24 Hr. Heavy-Duty

Programmable

Digital Timer for

lamps, stereos, &

appliances

Heavy Duty

Outdoor Timers

for lights, motors

& pool pumps

All purpose

Heavy-Duty

Lamp &

Appliance

Timers

Outdoor Digital

Timers with light

sensor to control

outdoor lights &

holiday displays

Heavy-Duty

Digital 7-Day

Wall Switch

Timers to control

fans, lights &

appliances with

“never set it

again” feature

Do-it-yourself

Wireless

Motion

Sensor

Alarms

Home

Controls,

Modules and

controllers

Digital Photo

Control

automatically

turns lights on

at dusk, off

6 hours later

122

123

Until now, the ability to reliably and cost efficiently control lighting and electronics and electrical devices in

the home, using Radio Frequency, was extremely limited. Intermatic introduces a line of cost effective plug-in

modules, in-wall receptacles and switches and easy-to-use controllers that allow fingertip control of multiple

items in and around the house. Intermatic’s Home Controls incorporate Z-Wave™ technology – the most

advanced, low cost and highly efficient Radio Frequency based technology in the industry.

Innovative Features:

• All items are controlled by Radio Frequency (no wiring is involved)

• Easy DIY installation

• All products use unique Z-Wave™ technology

• Two-way feedback lets you know if the system is properly set up and if the system is working properly

• The cost for this highly reliable system is priced much less than comparable systems that require contractor installation

• All modules and in-wall products can be set for timing control

• Each module includes a “repeater” function, for unmatched reliability

• Controllers can control up to 192 devices and can create “scenes” to create the light level look wanted

Intermatic Home Controls

A. HA01C Wall Receptacle

• Replaces standard wall receptacles

• One receptacle is controlled

• LED shows feedback from controller during setup and

that the controlled device is working

• Use with decora wall plate (not included)

Specifications:

• For indoor use only • 15 Amps Resistive

• 8.3 Amps Tungsten • 120VAC, 60 Hz

• Temperature operating range: 0°C to 60°C

B. HA02C Plug-In Appliance Module

• Controls appliances up to 15 Amps and lighting

(including compact fluorescent bulbs)

• Heavy-duty 3 prong plug and receptacle

• Manual override

• LED shows feedback from controller during setup and

that the controlled device is working

Specifications:

• For indoor use only • 15 Amps Resistive

• 1200 W Inductive • 1/2 HP

• 8.3 Amps Tungsten • 120VAC, 60 Hz

• Temperature operating range: 0°C to 60°C

C. HA03C Plug-In Indoor Lamp

Module

• Controls ON/OFF/DIM for incandescent lamps

• Manual override

• LED shows feedback from controller during setup and

that the controlled device is working

Specifications:

• For indoor use only • 300 Watts

• 120VAC, 60 Hz

• Temperature operating range: 0°C to 60°C

D. HA04C Outdoor Lighting Module

• Controls ON/OFF outdoor devices

• Weather resistant

• 6" cord

• Manual override

• LED shows feedback from controller during setup and

that the controlled device is working

Specifications:

• 15 Amp Resistive • 1/2 HP

• 1200 W Inductive • 8.3 Amp Tungsten

• 120 VAC, 60 Hz

• Temperature operating range: -35°C to 60°C

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Intermatic Home Controls

E. HA05C Outdoor Lamp Screw-In

Module

• For incandescent and PAR lamps

• Fits most outdoor fixtures

• ON/OFF functions

• Manual override

• LED shows feedback from controller during setup and

that the controlled device is working

Specifications:

• 300 W Tungsten, 4 W compact fluorescent

• 120 VAC, 60 Hz

• Temperature operating range: -35° C to 60° C

F. HAO6C Indoor Wall Switch

• Rocker style uses decorative wall plate (not included)

• ON/OFF/DIM controls

• Manual override

• LED shows feedback from controller

during setup and that the controlled

device is working

Specifications:

• For indoor use only

• 300 Watts Tungsten

• 120 VAC, 60 Hz

• Temperature operating range: 0°C to 70°C

G. HA07 Master Remote Controller

• Controls all Intermatic Home Settings devices

• Large LCD screen shows all functions when set-up is

successful, dim levels, channels and time functions

• Easy to set up

• Attractive design can be set on a table or wall mounted

• ALL ON/ALL OFF buttons controls devices to warn

would-be intruders

• Controls up to 12 channels

• Each channel can control up to 16 devices

• Timing controls for all devices include:

- Set the Astronomic feature and you will never have to

reset the timer for the everyday changes in SUNRISE

and SUNSET times.

- Multiple time options: all week, 5 days, weekends or

individual days

- RANDOM timing option for a “lived-in” look

- Optional automatic Daylight Savings Time function

• 8 dimming levels

• Requires 4 AA batteries (not included).

Specifications:

• Temperature operating range: 0°C to 60°C

H. HA09C Handy Remote Control

• Controls all Intermatic Home Controls devices

• Easy to set up

• Attractive, easy to hold

• Controls up to 6 channels

• Each channel can control up to 16 devices

• 8 dimming levels

• Requires 4 AAA batteries (not included)

Specifications:

• Temperature operating range: 0°C to 60°C

124

125

Heavy Duty Lamp & Appliance Timers

Digital Plug-in Timers

Indoor Plug-In Timers

Override switch

with on/off

indicator faces

up - easiest to

view and change

Oversized

color-coded

trippers -

simplest to

use

Unique “time

of day”

window -

quickest and

easiest to set

A. TN111C

Lamp & Appliance Timer

•2ON/2OFF settings per day

•Controls lamps & appliances

•Ideal for all-purpose use

•Ratings: 15 Amp Resistive, 1750 Watts Tungsten, 1/3 HP,

125 VAC, 60 Hz

B. TN111GC

Lamp & Appliance Timer With

Lighted Dial

•Transparent plastic dial acts as a night light

• 2 ON / 2 OFF settings per day

•Ideal for all-purpose use

•Ratings: 15 Amp Resistive, 1750 Watts Tungsten, 1/3 HP,

125 VAC, 60 Hz

C. TN811C

Multi-Setting Timer

•24 ON / 24 OFF settings per day

•Convenient programmable settings

•Enhances safety & security by making home look more

“lived-in”

•Ratings: 15 Amp Resistive, 1750 Watts Tungsten, 1/3 HP,

125 VAC, 60 Hz

D. TN711C

Random Pattern Security Timer

•2on/2 off settings per day

•Turns lights on and off automatically within ±15 min. of

the set times

•Eliminates the predictable “timer-controlled” look

•Ratings: 15 Amp Resistive, 1750 Watts Tungsten, 1/3 HP,

125 VAC, 60 Hz

E. TN311C

Heavy-Duty Grounded Timer

•3on/3 off settings per day

•For air conditioners, heaters and other heavy electrical

loads

•Ratings: 15 Amp Resistive, 1750 Watts Tungsten &

Resistive, 125 VAC, 60 Hz, 12 FLA, 72 LRA, 120 VAC

Motor (12 AMP Air Conditioner)

F. DT17C

7-Day Heavy-Duty Digital Timer

•Up to 14 ON / 14 OFF settings per day or 98 ON / 98

OFF settings per week

•Random setting option avoids predictable “timer-

controlled” look

•3-prong grounded plug and receptacle

•Controls lamps (including fluorescent), TVs, stereos and

appliances

•Easy-to-set hand-held programming with battery backup

•Manual override feature

•Ratings: 15 Amp Resistive & Inductive, 500 Watts

Tungsten, 1/3 HP 120 VAC

G. DT121C

Digital Lamp Timer

•2ON / 2 OFF settings per day

•Controls indoor lamps

•To-the-minute accuracy

•Large display, easy to read

•Manual override feature

•Ratings: 8.3 Amp Resistive and Inductive, 300 Watts

Tungsten, 120 VAC, 60 Hz

H. DT27C

Heavy-Duty Digital Timer with

Astronomic Feature

•Up to 7 ON/OFF settings per day

•Astronomic features allow setting it once without ever

having to reset it again; follows daily changes in

sunrise/sunset times

•Random setting option avoids predictable “timer-

controlled” look

•3-prong grounded plug and receptacle

•Controls lamps (including fluorescent), TVs, stereos and

appliances

•Easy to program

•Battery backup

•Manual override feature

•15 Amp Resistive and Inductive, 500 Watts Tungsten, 1/3

HP,120 VAC, 60 Hz

I. TB121C

Digital Table Top Timer

•2ON / 2 OFF settings per day

•Attractive tabletop styling in decorative platinum

• 5 ft. cord

•Easy to reach

•Large display, easy to read

•To-the-minute accuracy

•Manual override feature

•Ratings: 8.3 Amp Resistive and Inductive, 300 Watts

Tungsten, 120 VAC, 60 Hz

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Heavy Duty Appliance Timers

Wall Switch Timers

A. HB112C

Air Conditioner &

Appliance Timer

• Automatically controls 240 volt

air conditioners, heaters,

heavy-duty appliances

and lamps

• 3,750 watt capacity

• Plugs directly into wall outlet

• 2 ON/2 OFF settings per day

• 3-prong 220-240 Volt grounded plug and receptacle

• Manual override ON/OFF switch

B. HB114C

Air Conditioner &

Appliance Timer

• Same as HB112C except for

the following:

• 5,000 Watt capacity

C. HB113C

Air Conditioner &

Appliance Timer

Same as HB112C except

for the following:

• Automatically controls 120 Volt

air conditioners, heaters,

heavy-duty appliances

and lamps

• 2,500 Watt capacity

Appliance & Wall Switch Timers

3750W/240V/

2 H.P. 240V Max.

Motor Load

5000W/240V/

2 H.P. 240V Max.

Motor Load

2500W/120V/

1 H.P. 120V Max.

Motor Load

D. ST01C

Heavy Duty In-Wall Timer with

Astronomic Feature

Can be used with four separate programming options:

Same settings Monday through Friday, Saturday & Sunday,

all 7 days of the week or individual daily settings.

• DST for 2006, 2007 and flexible for future changes, if

needed

• Set it once and never set it again; follows daily changes

in sunrise/sunset times

• For single pole and three way applications up to 100 ft.

• Controls lighting including fluorescent and heavy duty

loads such as fans and appliances

• Up to 6 ON/OFF settings per 7-day period a total of 42

ON/42 OFF settings per week

• Easy-to-set 6 button programming

• LCD digital clock and readout

• To-the-minute setting accuracy

• Battery backup

• Random setting feature available to avoid predictable

“timer controlled” look

• Manual override feature

• Use with decorator-style wall plate (not included)

• Ratings:

Resistive: 15 A, 120-277 VAC

Tungsten: 15 A, 120 VAC, 6 A, 208-277 VAC

Ballast: 8 A, 120 VAC, 4 A, 208-277 VAC

Motor: 1 HP, 120 VAC, 2 HP, 240 VAC

DC Loads: 4 A, 12 VDS, 2 A, 28 VDS

E. ST01AC

Heavy Duty In-Wall Timer with

Astronomic Feature

Same as ST01C except Almond color

F. EJ351C

Programmable 24-hour

Security Timer

• Up to 24 ON/24 OFF settings per day

• Random setting turns light ON and OFF at slightly

different times each day

• Self-learning feature: if not manually programmed, it will

repeat the first 24 hr. ON/OFF pattern

• 15 minute memory guard protects against power failure

• Replaces any standard wall light switch

• Use with existing wall plate; standard (toggle) or

decorator (rocker) styles

• Ratings: 500 Watts Incandescent, 120 VAC, 60 Hz

G. EJ500C

Indoor Digital Wall Switch Timer

with Astronomic Feature

• Flushmount design

• 6 ON/6 OFF settings per day

• Controls incandescent and fluorescent (class “P” ballast)

lighting

• Easy to set programming

• Set it once and never set it again; follows daily changes

in sunrise/sunset times

• Battery backup guards against memory loss

• Replaces any standard wall switch

• Use with decorative style wall plate(not included)

• Ratings: 500 Watts Incandescent, 120 VAC, 60 Hz

H. EJ500AC

Indoor Digital Wall Switch Timer

with Astronomic Feature

Same as EJ500C except Almond Color

126

127

Model Max. ON Min. ON

Number Time Time Capacity

HB31R 23-1/2 hrs. 1/2 hr. 15 Amps, 1800 Watts Resistive; 15 Amps, 1800 Watts Tungsten,

15 FLA, 90 LRA; 120 VAC Operating Temp.: -40˚C to +40˚C

HB35R 23-1/2 hrs. 1/2 hr. 10 Amps, 1200 Watts Resistive; 10 Amps, 1200 Watts Tungsten;

120 VAC Operating Temp.: -40˚C to +40˚C

HB51RC Dusk to 8 hr. Dusk to 2 hr. 8.3 Amps, 1000 Watts Resistive; 8.3 Amps, 1000 Watts Tungsten,

120 VAC Operating Temp.: -35˚C to +40˚C

HB61RC Dusk to 8 hr. Dusk to 2 hr. 8.3 Amps, 1000 Watts Resistive; 8.3 Amps, 1000 Watts Tungsten,

120 VAC Operating Temp.: -35˚C to +40˚C

Outdoor Timers

A. HB31R

Heavy Duty Outdoor Timer

(15 Amp)

• Up to 2 ON / 2 OFF settings per day

• Full 15 Amp capacity controls lighting and heavy-duty

loads such as motors and pool pumps

• Grounded plug

• Manual override ON/OFF switch

• Waterproof cover

• Heavy-duty 12" grounded cord

• 120 VAC, 60 Hz

B. HB35R

Outdoor Timer (10 Amp)

• 2 ON / 2 OFF settings per day

• Grounded plug

• Manual override ON/OFF switch

• Waterproof cover

• Heavy-duty 15" cord

• 120 VAC, 60 Hz

C. HB51RC

Outdoor Timer with Light Sensor

• Highly versatile control with choice of operating modes

• Photo ON / Timer OFF mode provides automatic ON at

dusk, OFF after owner’s choice on 2, 4, 6 or 8 hours

• Photo ON / Photo OFF mode offers automatic ON at

dusk, OFF at dawn

• 8.3 Amp lighting timer

• Manual override ON/OFF switch

• Grounded, compact 6" cord

D. HB61RC

Digital Outdoor Timer with

Light Sensor

• Photo ON at dusk, OFF at dawn

• Photo ON at dusk, OFF at 1 hour increments from 1-9

hours

• Immediate ON/OFF at owner’s selection in 1 hour

increments for 1-9 hours

• Manual override

• Grounded 6" cord and receptacle

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Model Max. ON Min. ON

Number Time Time Capacity

HB77R 6 days 1 min. 15 Amps Resistive and Inductive, 500 Watts Tungsten, 1/3 H.P.,

23 hrs. 59 min. 120 VAC Operating Temp.: -35˚C to +40˚C

HB1116R 23-1/2 hrs. 1/2 hr. 15 Amps, 1800 Watts Resistive; 15 Amps 1800 Watts Tungsten

15 FLA, 90 LRA, 120 VAC Operating Temp.: -40˚C to +40˚C

HB88RC 6 days 1 min. 15 Amps, 1000 Watts Resistive; 15 Amps 1000 Watts Tungsten

23 hrs. 59 min. 1/2 HP; 120 VAC; 60 Hz

Outdoor Timers

E. HB77R

Digital Outdoor Timer

• 15 Amp capacity controls lighting and heavy-duty loads

such as motors and pool pumps

• 14 ON / OFF settings per day - a total of 42 ON / OFF

settings per week - can be used with 4 separate

programming options

– Same settings Monday through Friday

– Same settings Saturday and Sunday

– Same settings all 7 days of the week

– Various daily settings

• Easy hand-held programming

• Replaceable button cell batteries (included) maintains

program, during power failure

F. HB1116R

6 Outlet Electromechanical Timer

with Stake

• 2 ON/OFF settings per day

• Full 15 Amp capacity controls lighting and heavy loads

such as motors, engine block heaters and pool pumps

• Weatherproof cover

• 24" grounded cord

• Grounded receptacle

• Circuit breaker

• Manual override ON/OFF switch

• For wall mounting or stake mounting

G. HB88RC

Programmable Outdoor Timer

• 15 Amp capacity controls lighting and heavy duty loads

such as engine block heaters, holiday and landscape

lighting, pool/spa pumps and more

• 7 day / 7 event programming

• Multiple daily programming options

– Same settings Monday through Friday

– Same settings Saturday and Sunday

– Same settings all 7 days of the week

– Individual daily settings

• Two timed receptacles

• Battery backup

• Ratings: 15 Amp Resistive and Tungsten, 1000W

Inductive, 1/2 HP, 120 VAC, 60 Hz

128

129

Safety Light Products

Power Failure Light

Photo Controls

Power Failure Light

A. NE1C

Screw-In Photo Control

• Automatically turns electrical load ON at dusk, OFF at

dawn

• Screws into any standard incandescent light socket

• Controls interior and exterior lights

B. NE2C

Automatic Security Light Dual

Photo Cell with Flicker Eliminator

• Automatically turns electrical load ON at dusk, OFF at

dawn

• Advanced technology circuit saves energy

• Screws into any standard incandescent light socket

• Controls interior and exterior lights

C. NE3BC

Digital Photo Control,

Time Controlled

• Automatically turns light ON at dusk and OFF 6 hours

later

• Soft start extends bulb life

• Controls incandescent lights up to 150 Watts

• Screw into any standard incandescent light socket

• Controls indoor and exterior lights

• Handles up to 150 Watt incandescent and 45 Watt

fluorescent bulbs

D. NE200C

Plug-In Photo Control

• Automatically turns electrical load ON at dusk, OFF at

dawn

• For outdoor spot and flood lamps, used on driveways

and patios

• Also ideal for indoor or outdoor PL lamp fixtures

(compact fluorescent)

E. NE250C

Outdoor Photo Control

• Automatically turns electrical load ON at dusk, OFF at

dawn

• For outdoor spot and flood lamps, used on driveways

and patios

• Handles up to 150 Watt incandescent bulbs

F. NE5C

Plug-In Photo Control

• Automatically turns electrical load ON at dusk, OFF at

dawn

• Plugs into any polarized indoor wall socket

• Controls indoor devices such as table light, floor light,

radio or TV

G. PR3C

3-in-1 Power Failure Light

• Light automatically comes on when power goes out

• Automatic guide light

• Can be used as a handy rechargeable flashlight

• Screw-off cover with replaceable #14 flashlight bulb

• Plugs into any polarized indoor wall socket

• Provides safety and security

• Unique receptacle for plugging in additional lamp or

appliance

• 120 Volts, 60 Hz, 1 Watt

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Security Alarms

Intermatic Do-It-Yourself Security

A. SP230B

Wireless Alarm with Motion Sensor

• Place on wall, table or shelf

• Piercing alarm activated when movement is detected

• Warning sticker included

• Programmable code entered on keypad

activates/deactivates alarm

• 110 dB siren

B. SP130B

Wireless Door Alarm with

Programmable Keypad

• Piercing alarm activated when contact point is broken

• Mounts on door

• Code entered on keypad activates/deactivates alarm

• 110 dB siren

C. SP440B

Wireless Window Alarm

• Piercing alarm activated when contact point is broken

• Mounts on window

• ON/OFF switch activates/deactivates alarm

• 90 dB siren

D. SP500

Window Stickers

• Discourages intruders

• 4 pack

E. SP640B

Personal Security Alarm

• Piercing alarm sounds when pin is removed

• Small enough to hold in the palm of the hand

• Alerts others that help is required

• Includes flashlight and belt clip

• 90 dB siren

130

131

Malibu®, the leading landscape lighting brand, has been making lighting systems to enhance the beauty, safety

and security of American homes for almost 40 years. In that time we’ve learned a lot about how American

consumers use their outdoor space, and we’ve seen the definition of “outdoor lifestyle” grow. People spend

more time outdoors than ever before, and it’s important to them to decorate their outdoor space. Malibu®helps

them make their outdoors as beautiful, livable and enjoyable as their indoors.

Fixtures For Every Need

The traditional approaches to outdoor lighting are to provide uplight, to highlight trees or bushes and create

a focal point for beauty; downlight to place along walkways and steps or outline driveways for safety; and

backlight to illuminate walls or fences and light up a home’s exterior for security. To fill these needs, Malibu®

offers a wide variety of floodlights and decorative fixtures, path and garden lights. Traditional lighting

approaches are still very relevant today, but the trend that expands gracious living to a home’s outdoor space

has led to a new approach, the creation of outdoor decorative elements that provide function and beauty in the

daytime, as well as illumination at night. These items include an illuminated birdbath, lighthouse and rock

spotlights.

Market Leading Power Packs and Accessories

Malibu®high quality Power Packs offer dependable power and integrated Intermatic timers to ensure that your

customers’ landscape lighting delivers bright reliable light in any weather, year in and year out. Malibu®bulbs

and cable complete the picture to give you safe, weather-resistant installations.

Malibu®Products are Affordable and Guaranteed

Malibu®is committed to building the best products available across several price ranges. We also offer one

of the most comprehensive warranties in the industry; from 3 years to lifetime depending on the fixture, and 5

years on Power Packs.

For more information and to view the most up-to-date listing of Malibu®Landscape Lighting products, see

our Landscape Lighting catalog, or visit our web site at www.intermatic.com.

Malibu®Low Voltage Landscape Lighting

12 volt fixtures provide

important benefits not

available with conventional

110 volt systems

• Fast, easy installation

• Flexibility to add and adjust fixtures as landscape

matures

• Economical operation, thanks to longer lamp life &

less energy usage

• No hard wiring required

• No need for junction box on each fixture

• Maximum eye appeal both night (when on) & day

(when off)

Lighting the way to outdoor living

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Malibu®Low Voltage Landscape Lighting

CS110P

Metal Walk Light with

11W wedge base

bulb and Pewter

finish

CS110TA

Metal Walk Light with

11W wedge base bulb

and Architectural

Bronze finish

CS120TA

Metal Walk Light with

18W wedge base bulb

and Architectural

Bronze finish

CS14P

Metal Carriage Light

with 11W wedge base

bulb and Pewter

finish

CS17K

Metal Mission Light

with 11W wedge base

bulb and Antique

Copper finish

CS140K

Metal Lantern Light

with 18W wedge base

bulb and Antique

Copper finish

CS180C

Copper Floodlight

with 20W halogen

MR16 bulb

CS200C

Copper Tier Light

with 18W wedge base

bulb

CS230R

Metal Mission Light

with 18W wedge base

bulb and Aged Brass

finish

CS240

Metal Parfait Light

with 18W wedge base

bulb and Aged Brass

finish

CS330OB

Metal Walk Light with

11W wedge base bulb

and Oiled Bronze finish

CS508K

Metal floodlight with

35W halogen MR16

bulb and Antique

Copper finish

132

133

Malibu®Low Voltage Landscape Lighting

CS508P

Metal floodlight with

35W halogen MR16

bulb and Pewter

finish

CS508S

Metal floodlight with

35W halogen MR16

bulb and Sand finish

CS508TA

Metal floodlight with

35W halogen MR16

bulb and Architectural

Bronze finish

CS7AC1

Metal garden light

with 11W wedge base

bulb and Antique

Copper and Oil

Rubbed bronze finish

CS7CT4

Metal garden light

with 4W wedge base

bulb and Black finish

CS7E1

Metal garden light

with 4W wedge base

bulb and Black finish

NA320

Natural Rock Light

with 20W MR11 bulb

NA401

Metal Birdbath Light

with 35 watt MR16

bulb and Verdigris

finish

NA501

Metal Hanging Floral

Basket Light with 7 watt

wedge base bulb and

Verde finish

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Malibu®Low Voltage Landscape Lighting

Finishes & Colors

Choose from classic or contemporary

designs in a variety of finishes and

textures. Use Malibu®fixtures to blend

into your landscape design, add an

elegant touch to a garden path or

highlight architecture for safety and

security.

Due to Intermatic’s dedication to technological advancement,

it is possible that specifications and/or appearances of our

products may have changed after the printing of this literature.

See price list for the latest available product light sets.

CL1

Metal floodlight with

50W halogen MR16

bulb and Black finish

CL111R

Well Light with 11W

Poly-Star bulb and

Black finish

CL115

Submersible Light

with 20W halogen

MR16 bulb and Black

finish

CL191

Metal Tier Light with

11W wedge base bulb

and Black finish

CL191K

Metal Tier Light with

11W wedge base bulb

and Antique Copper

finish

CL191S

Metal Tier Light with

11W wedge base bulb

and Sand finish

CL191V

Metal Tier Light with

11W wedge base bulb

and Verde finish

CL280

Metal Tulip Light with

18W wedge base bulb

and Black finish

CL305P

Metal Walk Light with

11 watt wedge base

bulb and Pewter finish

CL4

Metal Hanging

Lantern with 7W

wedge base bulb and

Black finish

CL501

Metal Well Uplight with

35 watt MR16 bulb and

Black finish

CL503TA

Metal Surface Light

with 7 watt wedge

base bulb and

Architectural Bronze

finish

134

Aged Brass

Black Chrome

(BC)

Antique Copper

(K)

Architectural Bronze

(TA)

Black Satin Bronze

(BSB)

Brushed Nickel

(N)

Copper

(C)

Graphite

(GR)

Oil Rubbed Bronze

(OB)

Pewter

(P)

Sand

(S)

Rustic Brick

(RB)

Verde

(V)

Verde Patina

(V)

Verdigris

135

Malibu®Low Voltage Landscape Lighting

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

CL507

Metal Floodlight with

20W halogen MR16

bulb and Black finish

CL508

Metal Floodlight with

35W halogen MR16

bulb and Black finish

CL509

Metal Wall Wash

Floodlight with 20W

halogen bi-pin bulb

and Black finish

CL635R

Metal Bollard Light

with 20W MR11 bulb

and Black Finish

CL635P

Metal Bollard Light with

20W MR11 bulb and

Pewter finish

CL635RS

Metal Bollard Light

with 20W MR11 bulb

and Sand finish

CL635RK

Metal Bollard Light with

20W MR11 bulb and

Antique Copper finish

CL711

Metal Mushroom

Light with 10W

halogen bi-pin bulb

and Black finish

CL801BC8

Metal garden light with

4and 11W wedge base

bulbs, Black Chrome

finish and Frosted

Crackel Glass Globe

CL802BSB6

Metal garden light with

4and 11W wedge base

bulbs, Black Satin

Bronze finish and

Mocha Marble Glass

Globe

CL802P7

Metal garden light with

4and 11W wedge base

bulbs, Pewter finish and

SquareFrosted Glass

Globe

CL803S2

Metal garden light

with 4 and 11W

wedge base bulbs,

Sand finish and

Frosted Ribbed Glass

Globe

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Malibu®Low Voltage Landscape Lighting

CL8041

Metal garden light with

4and 11W wedge base

bulbs, Black finish and

Alabaster-Style Glass

Globe

CL9

Metal Floodlight with

20W halogen bi-pin

bulb and Black finish

CL9S

Metal Floodlight with

20W halogen bi-pin

bulb and Sand finish

CL905

Metal Half Brick Light

with 7W wedge base

bulb and Black finish

136

CL905K

Metal Half Brick Light

with 7W wedge base

bulb and Antique

Copper finish

LT8

Metal Surface Light

with 7W wedge base

bulb and Black finish

LT8K

Metal Surface Light

with 7W wedge base

bulb and Antique

Copper finish

LT9

Metal Floodlight with

10W halogen bi-pin

bulb and Black finish

LT10

Metal Shaded Flare

Light with 11W

wedge base bulb and

Black finish

LT13

Metal Three Tier Light

with 7W wedge base

bulb and Black finish

LT13N

Metal Three Tier Light

with 7W wedge base

bulb and Nickel finish

LT13S

Metal Three Tier Light

with 7W wedge base

bulb and Sand finish

137

Malibu®Low Voltage Landscape Lighting

LT406

Metal Two Tier Light

with 4W wedge base

bulb and Black finish

LT406N

Metal Two Tier Light

with 4W wedge base

bulb and Nickel finish

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Power Packs

Intermatic offers the widest variety of Power Packs in any wattage and control option your system may require.

Power Packs are available from 44 to 900 watts, allowing you to choose which power supply is right for your

particular lighting plan.

All Power Packs are certified for safe operation and long life. Keyhole mountings are featured for ease of

operation and installation. See chart below for available Power Packs and features.

Models Max. Wattage Output Specifications

ML44T 44 Watt Timer with 2 sets of trippers

ML60TW 60 Watt Timer with 2 sets of trippers and ground shield

ML88T 88 Watt Timer with 2 sets of trippers

ML100T 100 Watt Timer with 2 sets of trippers

ML121RT 121 Watt Timer with 2 sets of trippers

ML200RT 200 Watt Timer with 2 sets of trippers

ML200RTW 200 Watt Timer with 2 sets of trippers and ground shield

ML300RTW 300 Watt Timer with 2 sets of trippers and ground shield

ML600TW 600 Watt Timer with 2 sets of trippers and ground shield

ML900TW 900 Watt Timer with 2 sets of trippers and ground shield

IMPORTANT: When planning your lighting and choosing a Power Pack, your total bulb wattage must not exceed maximum transformer wattage

output rating.

Power PackModels

Malibu®Low Voltage Landscape Lighting

ML44T

ML60TW

ML88T

ML100T

ML121RT

ML200RT

ML200RTW

ML300RTW

ML600TW ML900TW

Low Voltage Polymer

LD622L/ML60721

Plastic Deck Light

4W wedge base bulb

LV181/ML10781

Plastic Tier Light

7W wedge base bulb

LV103/ML91103

Plastic Floodlight

11W wedge base bulb

LV108/ML90708

Plastic Floodlight

7W wedge base bulb

LV183/ML11183

Plastic Tier Light

11W wedge base bulb

LD641/ML60704

Plastic Deck Light

7W wedge base bulb

LX9Z/ML90401

Plastic Floodlight

4W wedge base bulb

LX1/ML10401

Plastic Tier Light

4W wedge base bulb

LD622/ML60722

Plastic Deck Light

4W wedge base bulb

138

Low Voltage Cable

For fast, easy installation of Malibu®light

fixtures, use low voltage cable. It’s safe,

weather-resistant, self sealing and available

in 16, 14 and 12 gauge sizes.

139

Solar accent lighting is the simplest and safest way to brighten your home’s walkways, decorate patios and

flower beds or create an enchanting lake view. Solar powered light fixtures cost nothing to operate and each

fixture automatically recharges during the day and turns on at dusk. Malibu solar accent lights utilize the

latest in L.E.D. technology to create lights that are brighter and stay lit longer than other

solar-powered brands. Choose from our new brighter white L.E.D. light fixtures or from our more traditional

amber colored L.E.D. fixtures. Each fixture contains a scientifically designed solar collector panel that converts

sunlight into electrical energy. With no plug-in receptacles or power packs, solar accent lights can be installed

even in remote areas where the sun shines and regular power sources aren’t available. Malibu solar lights

operate independently, allowing you to use as many as you like.

Premium Metal Walk Light

Malibu®Solar-Powered Accent Lighting

LZ7CT4

Metal Contemporary

Walk Light with White

L.E.D.

LZ7FC4

Metal French Country

Walk Light with White

L.E.D.

LZ7Z6

Premium Cast Metal

Zen style Walk Light

with White L.E.D.

LZ51GR

Metal French Lantern

with White L.E.D.,

Graphite Finish

LZ191

Cast Metal Tier Light

with White L.E.D.

LZ191K

Copper finish

LZ305P

Metal Pillar-Style

Walklight with White

L.E.D. and Pewter

finish.

LZ601

Metal Lanternwith

Graphite Finish and

White L.E.D.

LZ602

Metal Diamond

Mission Light with

Aged Brass Finish and

White L.E.D.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

LZ603

Metal Pagoda Light

with Black Finish and

White L.E.D.

LZ11101OB

Metal Walklight with

White L.E.D. and Oil

Bronze finish.

LZ11101P

Metal Walklight with

White L.E.D. and

Pewter finish.

LZ11101RB

Metal Walklight with

White L.E.D. and

Rustic Brick finish.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Metal Walk Lights

Malibu®Solar-Powered Accent Lighting

140

Understanding Solar-Powered

Accent Lighting

Solar lights are not for every lighting

application. Malibu Solar Lights produce

aglow that is ideal for outlining

locations and darkened areas such as

steps, walks, etc. Solar Lights are

perfect for for those applications where a

regular power source is unavailable,

where some sort of accent light is

desired and where the area has exposure

to the full daylight sun. Malibu Solar

Lights can be installed just about

anywhere; as long as there is enough

sunlight available to recharge the

batteries. The specially designed solar

panel collects natural sunlight and

converts it into electrical power that is

stored in highly efficient, rechargeable

batteries. Be sure all Solar collector

panels are installed in a sunny location

wherethey will receive adequate,

unobstructed sunlight each day. Solar

Light performance will be diminished

during cloudy, rainy, or wintery weather

conditions. With fully charged batteries,

Solar Lights will provide many hours of

nighttime illumination.

LZ11101V

Metal Walklight with

White L.E.D. and

Verde finish.

LZ11771H

Metal Prairie Style

Light with White L.E.D.

and Architectural

Bronze finish.

LZ11771HK

Metal Prairie Style

Light with White L.E.D.

and Antique

Copper finish.

LZ14001H

Metal Lantern Light

with White L.E.D. and

Black finish.

LZ14001HP

Pewter finish.

LZ21811K

Metal Fence Post Light

with White L.E.D. and

Antique Copper finish.

LZ25030RB

Small Metal Prairie

style Lantern with

Amber L.E.D. and

Rustic Brick finish.

LZ25030V

Verde finish.

LZ230

Metal Mission Light

with White L.E.D. and

Aged Brass finish.

LZ406

Metal Tier Light with

Amber L.E.D.

LZ407

Metal Tier Light with

White L.E.D. and

Pewter finish.

LZ418

Metal Walklight with

Oil Rubbed Bronze

Finish, White L.E.D..

LZ422WBR

Dark Brown Walklight

with White L.E.D..

LZ422W

Black Walklight with

White L.E.D..

141

Plastic Walk Lights

Malibu®Solar-Powered Accent Lighting

LZ10130

Metal Tier Light with

Amber L.E.D..

LZ10131

Metal Tier Light with

White L.E.D..

LZ10131P

Metal Tier Light with

White L.E.D. and

Pewter finish.

LZ1

Plastic Tier Light with

Amber L.E.D..

LZ1W

Plastic Tier Light with

White L.E.D..

LZ3

Plastic Contemporary

Solar Fixturewith

Amber L.E.D.

LZ3W

White L.E.D.

LZ4H

Plastic Hanging

Carriage Light with

Amber L.E.D.

LZ4HW

White L.E.D.

LZ4HWGR

White L.E.D. with

Graphite finish.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

LZ4M

Plastic Carriage Light

with White L.E.D. and

Black finish.

LZ4MK

Antique Copper finish.

LZ4MOB

Plastic Carriage Light

with White L.E.D. and

Rubbed Bronze finish.

LZ6

Table Top Accent Light

with Amber L.E.D.

LZ302

Plastic Post Top Light

with White L.E.D.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Solar Flood Lights

Malibu®Solar-Powered Accent Lighting

LZ312

Path Marker Light with

White L.E.D.

LZ701/LZ701W

Plastic Walklight with

White or Amber L.E.D.

and Brown finish.

LZ702/LZ702W

Plastic Walklight with

White or Amber L.E.D.

and Black finish.

LZ703/LZ703W

Plastic Walklight with

White or Amber L.E.D.

and Black finish.

LZ704/LZ704W

Plastic Walklight with

White or Amber L.E.D.

and Brown finish.

LZ705/LZ705W

Plastic Walklight with

White or Amber L.E.D.

and Black finish.

LZ20601P

Plastic Coach Light

with White L.E.D. and

Pewter finish.

142

LZ413

Plastic Flood Light Set

with Remote Panel and

3White L.E.D.s per

Lamp

LZ413RP4

Plastic Flood Light Set

with 4 Lamps, 3 White

L.E.D.s per lamp

LZ414

Plastic Flood Light Set

with Remote Panel and

3White L.E.D.s per

Lamp

LZ415

Flood Light with 3

White L.E.D.s

143

Specialty Solar Lights

Malibu®Solar-Powered Accent Lighting

LZ419

Resin Flood Light with

3White L.E.D.s

LZ605RP

Metal Flood Light with

12 White L.E.D.s, Black

Finish

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

LZ511A,B,C,R

Driveway Markers with

Steady ON or Flash

Modes

LZ604B

Solar Island Torch with

Flickering Amber

L.E.D.s

LZ706

Resin Pagoda Light

with Amber L.E.D. and

Natural finish.

LZ16220

Plastic Deck Light with

Amber L.E.D.

LZ303RB

Metal Hanging Lantern

with White L.E.D. and

Rustic Brick finish.

LZ305FP

Metal Pillar-Style

Walklight with White

Flickering L.E.D.s and

Pewter finish.

LZ310

Cast Metal Lamp-Post

Replacement Fixture

with 1 Watt White

L.E.D.

LZ314

Address Light with

Amber L.E.D.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Novelty Solar lights

Kits

Malibu®Solar-Powered Accent Lighting

LZ16551

Plastic Floating Light

with White L.E.D.

LZB1

Plastic Solar Luminary

with Amber L.E.D

LZ306

Decorative Frog Light

with White L.E.D.

LZ307

Large Turtle with White

L.E.D.

LZ308

Decorative Lighthouse

with Amber L.E.D.

LZ313

Turtle with Amber

L.E.D.

LZ90004

Replacement Batteries

LZ1WU

Replacement Bulb

LZ15004

Nickel Metal Hydride replacements

144

LZ635RP4

Metal Bollard Set with

2White L.E.D.s per

Lamp and Remote

Panel, Black Finish

LZ13RP4

Metal Tier Light Set

with 2 White L.E.D.s

per Lamp and Remote

Panel, Black Finish

LZ53RP4

Metal Deck Light Set

with 2 White L.E.D.s

per Lamp and Remote

Panel, Oil Rubbed

Bronze Finish

LZ280RP4

Metal Tulip Set with 2

White L.E.D.s per

Lamp and Remote

Panel, Oil Rubbed

Bronze Finish

LZ501RP4

Metal Walk Light Set

with 2 White L.E.D.s

per Lamp and Remote

Panel, Oil Rubbed

Bronze Finish

145

Malibu® Outdoor Living

Mosquito Sentinel 360

MZ501

Trap

ACCESSORIES

MZ951

Mosquito Sentinel 360 Octenol Lure

MZ952

Mosquito Sentinel 360 Replacement Nets

MZ953

Mosquito Sentinel 360 Replacement Bulbs

• Attracts and kills mosquitoes in your yard

• Provides 360º protection against mosquitoes

up to 1/2 acre

• Uses safe low-voltage power - No propane

cylinders to refill

MZ105 MZ904 MZ204G MZ301

• Repels Mosquitoes up to 400 Sq. Ft.

•Patented chemical developed at University

of Florida

MZ101 MZ102 MZ902

• Blocks Mosquitoes up to 100 square feet!

Patented Inhibitor blocks mosquito’s ability

to track your scent.

• Easy to Use

• Long Lasting

•Inhibitor refill lasts up to 3 weeks.

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Time Switch Motors

Model

(Series) UPC*

to be used Description Part # Item #

MOTOR ONLY OLD STYLE T100

T100, T170 24V 60Hz N/A

T100R201, 125V 50Hz N/A

T1400BR, 125V 60Hz WG430-10D 11972 6

T1800BR, 208/277V 50Hz WG434-20D§ 11978*

T180, T500, 208/277V 60Hz WG433-20D 11976 5

WH10,30, 480V 60Hz WG436-20 11979*

WH40,70,80

MOTOR ONLY NEW STYLE T100

T100, T170 24V 60Hz CW1570-10D 10828 8

T180, 125V 60Hz WG1570-10D 11915 4

T100R201, 125V 50Hz WG1571-10D 11919 2

T100R301, 208/277V 50Hz WG1574-10D 11932 1

WH10,30, 208/277V 60Hz WG1573-10D 02012 2

WH40,70,80 480V 60Hz WG1576-10D 11938 3

MOTOR ONLY T100CR

T100CR, 24V 60Hz N/A

T170CR, 125V 50Hz WG1381-10§ 11903*

T1400BCR, 125V 60Hz WG1380-11§ 11902*

T1800BCR 208/277V 50Hz N/A

208/277V 60Hz WG1383-11§ 11904*

480V 60Hz N/A

MOTOR AND CARRYOVER COMBINED T100CR

T100CR, 24V 60Hz N/A

T170CR, 125V 50Hz 131T93GA 60090

T1400BCR, 125V 60Hz 131T68GA 21170

T1800BCR 208/277V 50Hz 131T70GA 60091

208/277V 60Hz 131T69GA 21180

480V 60Hz N/A

MOTOR ONLY

AT1300R 24V 60Hz N/A

125V 50Hz N/A

125V 60Hz WG430-20D 02009 2

208/277V 50Hz WG434-20§ 11978*

208/277V 60Hz WG433-20D 02010 8

480V 60Hz WG436-20 11979*

Malibu Repl. 125V 60Hz WG630D 02013*

Motors 125V 60Hz WG1750-10§ 11911*

125V 60Hz N/A

MOTOR ONLY

T1900, 24V 60Hz N/A

T8800, 125V 50Hz N/A

R8800 125V 60Hz WG730-14D 12001*

208/277V 50Hz N/A

208/277V 60Hz WG733-14D 12005 1

480V 60Hz WG736-14D 12008 2

MOTOR ONLY

T7400B 24V 60Hz N/A

T7800B 125V 50Hz N/A

125V 60Hz WG1600-11 11939 0

208/277V 50Hz N/A

208/277V 60Hz WG1603-11D 11951 2

480V 60Hz WG1606-11§ 11948 2

Model

(Series) UPC*

to be used Description Part # Item #

MOTOR ONLY

T7400BC 24V 60Hz N/A

T7800BC 125V 50Hz WG1381-10§ 11903*

125V 60Hz WG1380-11 11902 4

208/277V 50Hz N/A

208/277V 60Hz WG1383-11 11905 5

480V 60Hz N/A

MOTOR AND CARRYOVER COMBINED

T7400BC 24V 60Hz N/A

T7800BC 125V 50Hz 131T93GA 60090

125V 60Hz 131T68GA§ 21170

208/277V 50Hz N/A

208/277V 60Hz 131T69GA 21180

480V 60Hz N/A

MOTOR AND CARRYOVER COMBINED

V41079CR 24V 60Hz N/A

V45000 125V 50Hz 131T93GA 60090

V46100C 125V 60Hz 131T68GA§ 21170

208/277V 50Hz N/A

208/277V 60Hz 131T69GA 21180

480V 60Hz N/A

MOTOR ONLY

V45400 24V 60Hz N/A

V46400 125V 50Hz WG1381-10§ 11903*

125V 60Hz WG1380-11§ 11900*

208/277V 50Hz N/A

208/277V 60Hz WG1383-11§ 11904*

480V 60Hz N/A

MOTOR ONLY

T2000 24V 60Hz CW720-10§ 10846*

125V 50Hz N/A

125V 60Hz WG720-10D 11997 0

208/277V 50Hz WG724-10§ 12000*

208/277V 60Hz WG723-10D§ 11999 4

480V 60Hz N/A

MOTOR ONLY

V47000 24V 60Hz N/A

V48000 125V 50Hz N/A

V49000 125V 60Hz WG690-10 11991*

208/277V 50Hz N/A

208/277V 60Hz N/A

480V 60Hz N/A

MOTOR ONLY

LS7000 24V 60Hz CW190-10D 10839 4

125V 50Hz WG191-10§ 11957*

125V 60Hz WG190-15D 11956 7

208/277V 50Hz WG194-10§ 11960*

208/277V 60Hz N/A

480V 60Hz N/A

MOTOR ONLY

E1000 24V 60Hz N/A

125V 50Hz N/A

125V 60Hz WG230-13D 11966 6

208/277V 50Hz N/A

208/277V 60Hz WG233-18§ 60037

480V 60Hz N/A

Model

(Series) UPC*

to be used Description Part # Item #

MOTOR ONLY

C8815 24V 60Hz N/A

125V 50Hz N/A

125V 60Hz WG790-11D 12019 8

208/277V 50Hz N/A

208/277V 60Hz N/A

480V 60Hz N/A

MOTOR ONLY

C8825 24V 60Hz N/A

125V 50Hz N/A

125V 60Hz WG760-10 12011*

208/277V 50Hz N/A

208/277V 60Hz N/A

480V 60Hz N/A

MOTOR ONLY

C8835 24V 60Hz N/A

125V 50Hz N/A

125V 60Hz WG780-12D 12017 4

208/277V 50Hz N/A

208/277V 60Hz N/A

480V 60Hz N/A

MOTOR ONLY

C8845 24V 60Hz N/A

125V 50Hz N/A

125V 60Hz WG750-10D 12010 5

208/277V 50Hz N/A

208/277V 60Hz N/A

480V 60Hz N/A

MOTOR ONLY

C8855 24V 60Hz N/A

125V 50Hz N/A

125V 60Hz WG800-11D 10854 7

208/277V 50Hz N/A

208/277V 60Hz N/A

480V 60Hz N/A

MOTOR ONLY

C8865 24V 60Hz CW770-10§ 10852*

125V 50Hz N/A

125V 60Hz WG770-10D 12013 6

208/277V 50Hz N/A

208/277V 60Hz WG773-10 12014*

480V 60Hz N/A

MOTOR ONLY

C8866 24V 60Hz CW770-10§ 10852*

125V 50Hz N/A

125V 60Hz WG770-10 12012*

208/277V 50Hz WG774-10 12015*

208/277V 60Hz WG773-10 12014*

480V 60Hz N/A

N/A Not available.

All time switch motors are available in voltage and cycle shown in 2nd

column. For example: To order new style T100 Series Motor in 60Hz

125V, order WG1570-10D.

NOTE: Carryover only sold as a complete unit with motor. **These

voltages and corresponding motor numbers apply to all model

numbers.

§ Available while supplies last.

Internal revisions may result in the motor you receive having a

different dash number (WG430-3 vs. WG430-10) than the motor

ordered. This revision has no effect on the motor function.

Cross Reference

146

24-Hour Time Switches

INTERMATIC Paragon Tork

24 Hour Time Switches (1 hour minimum “ON’’ time)

T101 4001-00 1101/1191

T102 4002-71 1102

T103 4003-00 1103/1962

T104 4004-71, 4004-20 1104/1962

T105 4005-00S 3121

T101B 4001-00V —

T101R 4011-00 1101-0/1191-0

T102R 4012-20 —

T103R 4013-00 1103-0/1962-0

T104R 4014-71, 4014-20 1104-0

T106R — —

24 Hour Time Switches with Skip-A-Day

(1 hour minimum “ON’’ time)

T171 P101S 7100

T172 — 7102

T173 4003-00S, P103S 7200

T174 4004-71S, P104S 7202

T175 4005-00S 7120

T176 4006-71S 7122

T171R 4013-00S 7100-0

T172R 4014-20S 7102-0

T173R 4013-00S 7200-0

T174R 4014-20S, 4014-71S 7202-0

T176R — 7122-0

T1471BR 47017-0S 7300

T1472BR 47017-20S 7302

T1475BR — —

T1871BR — 7220

24 Hour Time Switches with Skip-A-Day and

Carryover 1 hour minimum ‘’ON’’ time

T1471BCR 47217-00S 7300L/7300L-0

T171CR ——

T173CR 4213-0S 7200L

T174CR 4114-27S 7202L

Water Heater Time Switches with manual

“external override’’

WH40 — WH2

Specialty Time Switches

INTERMATIC Paragon Tork

Irrigation Time Switches (12 minute minimum “ON’’ time)

T8805P101C — —

R8806P101C — —

Cycle Time Switches (5 minute-4 hour dial)

C8815 — 8121

C8835 — 8301

C8845 — —

C8855 — 8061

C8865 — 8601

C8866 — 8602

Lighting Control Centers (7 day dial)

T51211BC — T920L

T51311BC — T930L

Swimming Pool Time Switches

INTERMATIC Paragon Tork

24 Hour Time Switches in Plastic Case

T101P 4011-00P 1101-N

T102P — —

T103P 4013-00P 1103-N

T104P 4014-71P 1104-N

24 Hour Time Switches w/ Heater Circuit

T101R201 41011-00 —

T104R201 41014-20 1104FM

T101P201 41011-00M —

T104P201 41014-20M —

2 in 1 24 Hour Time Switches

T10101R 4912-99 1101D

T10404R 4918-99 1104D

T12404R 4928-99 1104DF

Astronomic Time Switches

INTERMATIC Paragon Tork

Astro Dial

V45471R 4003SZ,47017-00S & 00SZ 7200Z/7300Z

V45472R 47017-71S & 71SZ 7202Z/7302Z

V45471CR 47217-00SZ 7200ZL/7300ZL

V45472CR 47217-20SZ & 27SZ 7202ZL/7302ZL

Special Timing Cycle

INTERMATIC Paragon Tork

24 Hour Time Switches 15 minute minimum “ON’’ time

T1905 1015-00RS 8001

T1905R 42011-00 —

T1906 1015-00RS 8004

T1975 1015-00RS 8007

T1976 1015-00RS 8008

T1975E 1015-40TS 8001-U

Signal Timers

ET279C 25001-0S —

ET279C 25002-0S —

ET279C 23001-00S 5701/5702

ET279C 23002-20S —

ET279C 23002-00S —

24 Hour Switching (with adjustable 10-60 min.) “ON’’ times

T185 8025-00 4277

Momentary Contact Time Switches (with dry contacts for

low voltage remote and mechanically held contactor

control)

ET279C 47016-00S 1847A

ET279C 47216-00S 1847AL

ET279C — 1847AW

ET279C 7216-00 1847AWL

7-Day Time Switches

INTERMATIC Paragon Tork

T7401B 7007-00 W100/W200/ W300/W400

T7402B 7007-20, 7007-71 W202/W302/W402

T7801B 7008-00 W120/W220

T7802B 7008-20, 7008-71 W222

T7401BC 7217-00 W300L/W400L

T7402BC 7217-20 W302L/W402L

T7801BC 7218-00 W220L

In-Wall Timers

INTERMATIC Grasslin Paragon Tork

24-Hour Electro-Mechanical In-Wall Timers

E1010 — — —

E1020/E1120 KM2 ST-16 701A/701AC WB101

E1221 — 701A-2G WB103

E1220 KM2 ST-2G — WB103

24 Hour Electronic In-Wall Timers

EJ351C ETC-502 — —

EJ353C ETC-503 — —

EI500C — — —

Digital In-Wall Timers

INTERMATIC Paragon Tork

Interval Timers – Electronic

EI15MH E500/ET2000/ET1100 —

EI200 — —

EI210 — —

EI220 — —

EI230 — —

Cross Reference

147

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

Spring Wound Timers

INTERMATIC† M.H. Rhodes Tork†† Paragon†††

Mark Time

FF5M/FD5M 90004/9305M A505M SW5M/SWD5M

FF15M/FD15M 90005/9315M A515M SW15M/SWD15M

FF30M/FD30M 90006/9330M A530M SW30M/SWD30M

FF60M/FD60M 90008/9360M A560M SW60M/SWD60M

FF2H/FD2H 90281/9302H A502H SW2H/SWD2H

FF4H/FD4H 90240/9304H A504H SW4H/SWD4H

FF6H/FD6H 90007/9306H A506H SW6H/SWD6H

FF12H/FD12H 90001/9312H A512H SW12H/SWD12H

FF5MH 90030 ––– SW5MH

FF15MH/FD15MH 90539/9315MH A515MH SW15MH/SWD15MH

FF30MH/FD30MH 90032/9330MH A530MH SW30MH/SWD30MH

FF60MH/FD60MH 90024/9360MH A560MH SW60MH/SWD60MH

FF6HH/FD6HH 90017/9306HH A506HH SW6HH/SWD6HH

FF12HH/FD12HH 90015/9312HH A512HH SW12HH/SWD12HH

INTERMATIC† M.H. Rhodes Tork†† Paragon†††

*SPDT (for reverse action applications)

FF32HH 9302HH ––– –––

FF34HH 9304HH ––– –––

FF36H/FD36H ––– ––– –––

FF312H ––– ––– –––

FF315M 90012 ––– –––

FF330M 90011 ––– –––

FF360M 90010 ––– –––

DPST (for breaking both sides of 240 volt loads)

FF415M/FD415M ––– ––– –––

FF430M/FD430M ––– ––– –––

FF460M/FD460M ––– ––– –––

FF46H/FD46H ––– ––– –––

FF412H ––– ––– –––

Cross Reference

† FF Models with brushed aluminum plate for commercial/industrial applications. FD Models-decorator design with ivory or white time dial for use with existing toggle or decorator style switch plate.

†† Decorator models only.

††† PSW series no longer available; replaced by SW and SWD series

Next Generation 365 Day Multi-Function Electronic Time Switches

INTERMATIC Paragon Tork Lithonia

ET70115C (SPDT) EL71/Series DT100** ––

*(SPST) EC7001/208-240V DT100-2**

**(DPDT) EC7001/277V DT100-3**

EC7001/208-277V DZS100**

EC7004/208-240V*

EC7004/277V*

EC7004/208-277V*

EC71/18S/120V

EC71D/18S/240V

EC71ST/120V

EC71ST/240V

EC71ST/277V

EC71STM/120V

EC71STM/277V

EC365/C/120V

ET70115CR (SPDT) EL71PC/Series DZS100A

EC71STN3/120V DTS100A

**(DPDT) DG180 —

DG180-2

ET70115CR24 DG180-3

for 24 Volt / 60 Hz DG100

Input only DG100-2

DG100-3

DG120**

DG120-2**

DZS100**

DZS100-2**

DZS100-3**

DGS100

DGS100-2

DGS100-3

DGS180

DGS180-2

DGS180-3

DGM100** —

DGM100-2**

DGM100-3**

DWZ100A**

INTERMATIC Paragon Tork Lithonia

ET70215C EL72/Series DT200 ––

EC72/120V DT200-2

EC72/240V DT200-3

EC72/277V

EC72D/120V

EC72D/240V

EC72ST/120V

EC72ST/240V

EC72ST/277V

ET70215CR EL72PC/Series DZS200A ––

EC72STN3/120V DTS200A

ET70215CR24 DZM200A

for 24 Volt / 60 Hz DS200

Input only DS200-2

DS200-3

DZS200

DZS200-2

DZS200-3

DZM200

DZM200-2

DZM200-3

ET70415CR EL74 DZS400A ––

EC74/50S/120V DTS400A

ET70415CR24 EC74/50S/240V Z400B

for 24 Volt / 60 Hz EC74/120D/120/240V Z400B-2

Input only EC74/192MA/120/240V K400Z

K400Z-2

K401Z

K401Z-2

DIN103A

(3PDT)

ET70815CR EL78 K600Z LITE-

EC77/140/120, 240V K800Z KEEPER

ET70815CR24 K600Z-2 LK8

for 24 Volt / 60 Hz K800Z-2

Input only K601Z

K601Z-2

K801Z

K801Z-2

ET71615CR EL712 AI200 LK16

ET71615CR24 EC712/120, 240V A1600 CK16

for 24 Volt / 60 Hz EC128 LK32†

Input only CK32†

IMPORTANT NOTE: Review manufacturer’s literature for

possible feature differences

148

Weatherproof Outdoor Receptacle Covers

Intermatic Taymac Carlon Cooper Arlington T&B Raco P&S

WP1000C n/a E9UVCRN n/a n/a n/a 5752-0* n/a

WP1000GC n/a E9UVGRN n/a n/a n/a n/a n/a

WP1000HC n/a E9UHCRN n/a n/a n/a 5761-0* n/a

WP1000HGC n/a E9UVGRN n/a n/a n/a n/a n/a

WP1000RC 71101* n/a n/a DBV* series n/a n/a n/a

WP1000HRC n/a n/a n/a DBV* series n/a n/a n/a

WP1010C n/a E9UDVCRN n/a n/a n/a n/a n/a

WP1010HC n/a n/a n/a n/a n/a n/a n/a

WP1010HMC MX3300 n/a n/a n/a CKMD* n/a n/a

WP1010MC MX3200 n/a n/a n/a CKSDV* n/a n/a

WP1020C MM2440C n/a n/a DBUL1DC n/a n/a n/a

WP1030C n/a n/a n/a n/a n/a n/a n/a

WP1030MC MX6200* n/a n/a n/a 2CKD* n/a n/a

WP1050 MM7440C n/a n/a n/a n/a n/a n/a

WP1100C MM400C n/a WIU-1 DBU1C CKNM* n/a WIUC10CL

WP1110C n/a n/a n/a n/a n/a n/a n/a

WP1150C MM740C n/a WIU-1D n/a n/a n/a WIUC10DL

WP1100WC n/a n/a WIU-1W DBUL1 n/a n/a WIUC10WL

WP1110WC n/a n/a n/a n/a n/a n/a n/a

WP1220C MM2440C* E9U2CRN* WIU-2* n/a 2CKNM* 5770-0* n/a

WP1230C n/a n/a n/a n/a n/a n/a WIUC20CL

WP1250C MM7440C* n/a n/a n/a n/a 5789-0 n/a

WP2000 n/a n/a n/a n/a n/a n/a n/a

*Competitive product does not meet all possible device configurations and installation methods that the Intermatic cover handles.

Cross Reference

7-Day Electronic Time Switches

INTERMATIC Paragon Tork EZ Controls

ET171C (SPST) EC7000/120* ES101, EW101 EZ-701-1

*(SPDT) ES120*, EW120*

EC7004/120 DG100*, DG180* EZ-701-1A

DIN101A*

ET173C (DPST) EC7005/120 ES103, EW103 EZ-701-2

EZ-701-2A

ET174C (DPST) EC7000/208-240* ES103-2,ES103-3 EZ-701-72

*(SPDT) ES120-2*, ES120-3*

EC7000/277* EW103-2,

EC7004/208-240 EW103-3

EC7004/277

EC7005/120, 208-240

EC7005/277

ET279C (SPST) EC11 Series* DGM100** EZ-701-2M**

*(SPDT) **(DPDT) EC7001/120* CD100A, DS200**

DIN100*, DIN200*

ET8115C EC71/30S/120 E, ES & EW120 EZ-T105

DG100, DG180 EZ-701-1A

(SPST)

DIN101A

ET8215C — DG120 (DPDT) —

ET8215C EC71D/30SM/ DGM100 EZ-701-2M

*(SPDT) **(DPDT) 120*

EH10†† — EH10 —

EH40†† — EH20 —

†† With external load indicator and external load override.

24 Hour Electronic Time Switches

INTERMATIC Paragon Tork EZ Controls

ET100C (SPST) EC1015P/120* E101, E120* EZ-T101

*(SPDT) EC4000/120*

EC4004/120

EC4004P/120

EC4004PC/120

EC4000P/120*

EC4000PC/120*

EC11 & 11D/120*

ET101C (SPST) — E101, E120* EZ-T101

*(SPDT)

ET102C (SPST) EC1015P/208-277 E101-2 EZ-T102

*(SPDT) EC4000/208-277*

EC4004/208-277 E101-3

EC4004P/208-277

EC4000P/208-277 E120-2*

EC4004PC/208-277

EC4005P/120, 208-240**

EC4005PC/120, 208-240**

**(DPST) EC11D/240* E120-3*

ET103C (DPST) — E103 EZ-T103

ET104C (DPST) EC4005/120-240 E103-2, E103-3 EZ-T104

Astronomic Electronic Time Switches

INTERMATIC Paragon Tork EZ Controls

ET70115CR† (SPDT) EC71ST/120 DZS100 EZ-701-2AS

EC71ST-N3/120V

EC71ST/277 DZS100-3 EZ-701-72AS

† Replaces ET816CR and ET833CR.

NOTE: ET70000 Series provides astronomic programming for any circuit(s).

149

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

High Intensity Discharge (HID) Lighting

Intermatic RAB Stonco

WL050MH WP1H50 LPSC50MA-8

WL070MH WP1H70 LPSC70MA-8

WL100MH WP1H100 LPM2C100MA-8

WL150MH WP2H150QT WPM150MA-8

WL175MH WP2H175QT WPM175MA-8

WL250MH WP3H250QT WP250MA-8

WL400MH WP4H400QT WP400MA-8

WL035HPS WP1SN35 WNPS35NLXL

WL050HPS WP1SN50 WNPS50NLXL

WL070HPS WP1SN70 WNPS70NLXL-8

WL100HPS WP1SN100 WNPS100NLXL-8

WL150HPS WP2SH150QT WPM150NLXL-8

WL250HPS WP3SC250QT WP250NLXL-8

WL400HPS WP4SC400QT WP400LXL-8

FL050MH FFH50 TLX50NMAL-1

FL070MH FFH70 SLA70NMAL-1

FL100MH EZHH100QT SLA100MAL-8

FL150MH EZHH150QT SLA150MAL-8

Intermatic RAB Stonco

FL175MH EZHH175QT SLA175MAL-8

FL250MH FZH250QT SLM250MAL-8

FL400MH FZH400QT SLM400MAL-8

FL035HPS FF35 TLX35NLXL-1

FL050HPS FF50 TLX50NLXL-1

FL070HPS FF70 TLX70NLXL-1

FL100HPS EZSH100 SLA100LXL-8

FL150HPS EZSH150QT SLA150LXL-8

FL250HPS FZS250QT SLM250LXL-8

FL400HPS FZS400QT SLM400LXL-8

DD175MV YLM175 DTDA175NMML-1

DD150HPS YLS150 DTDA150NLXL-1

FL150Q QF150 EQX150L

FL300Q QF300 EQ300L

FL500Q QF500 EQ500L

WL070HPSPC WPTS70 TLW70NLXL-1

CP150HPS VAN5S150QT LCQ155LXL-8

Cross Reference

Electronic Astronomic Time Switches

Intermatic Paragon Tork

SPST Astro Time Switches in NEMA 1 Case

ET8015C — —

SPST Astro Time Switches in NEMA 3R Case

ET8015CR EC365DST1/120V —

SPDT Astro Time Switches in NEMA 1 Case

ET8115C — —

SPDT Astro Time Switches in NEMA 3R Case

ET8115CR EL71/120V DWZ100A

EL71/208-240V DZS100A

EL71/277V

DPST Astro Time Switches in NEMA 1 Case

ET8215C — —

DPST Astro Time Switches in NEMA 3R Case

ET8215CR EC365DST2/120V DW200A

EC365DST2/277V DZS200A

EL72/120V

EL72/208-240V

EL72/277V

Electronic Auto-Off Timers

Intermatic Leviton Leviton

5-10-15-30 Minute Range

EI200 6230MI —

EI200LA 6230MA —

EI200W 6230MW —

10-20-30-60 Minute Range

EI210 6260MI 6560MI

EI210LA 6260MA 6560MA

EI210W 6260MW 6560MW

1-2-4-8 Hour Range

EI220 — —

EI220LA — —

EI220W — —

2-4-8-12 Hour Range

EI230 6212HI 6512HI

EI230LA 6212HA 6512HA

EI230W 6212HW 6512HW

150

Photo Controls

Intermatic ALR Tork Ripley Mulberry Precision Paragon Fisher Pierce

K4021C AA105 3000 7001/7011 30850 A105 LB201-00 FA105/FA305/6241A/6210

K4024 AA106 — — 30851 — — —

K4022 AA107 — — 30852 — — 6242A

K4033 AA108 — — — — — —

K4023C AA1068 3002 7002/7003/7012/7013 30853 A1068 LB201-71 FA1068

K4035 — — — — — — —

K4321C AA105W 3010 7105 30855 A105W LB201W-00 FA105W

K4121C PT15 2101/2100 — 30825/30820 T-15 CW201-00 6241B/FT15

K4124 AT16 — — 30827 — — —

K4122 AT17 — — 30829 — — 6242B

K4123C PT168/AT368 — — — T-168 CW201-71 FT168

K4133 AT18 — — 30831 — — —

K4135 AT19/PT19/AT39 — — — T-19 — FT19

K4141C AT30 (metal) 2105 (polycarbonate) — 30847 T-30 CW302-00 —

K4221C SAT15/SPT15 2001/3020 — 30826/30868 ST-15 CW201S-00 SFT15

K4224 SAT16—— ————

K4222 SAT17 — — — — — —

K4233 SAT18 — — — — — —

K4235 SAT19/SPT19 — — — ST-19 — SFT19

K4236 PT20/SAT168/SPT168 2104/2102/2002 — 30830/30833/3082 ST-168 CW201-71 SFT168

K4121M AT15 2101 — — TL15AL CW201-00 FT15

K4123M AT168 2104 — — — CW201-71 FT168

K4136M AT20 2107 — — — CW201-70 —

K4251 TL115 2021 — — ET-15 PN201-00 FL115

K4253 TL168 2022 — — ET-168 — —

LC4521C/K4521 LC120 2003/5001S — 30834 P-2275/M2275 TL201-00 NFP120/N6401-NS

LC4521LA BF120/M120 2003S/5021S 7046 — P2275LA — NFP120H/N7760-SSS**

LC4523 LC208-277 2004/5004S — 30837 P68275 TL201-71 NFP277

LC4523LA BF208-277/M208-277 2004S/5024S 7049 — 8672** — NFP-277H/M208-277

LC4535 — — — 30842 P7275 — —

LC4535LA BF480/M480 2008D/5008S/2008** — — LM7275/8694** —

LC4536C — — 6190** 30844 P26275/8690N** TL201-70 7790B-NSS**

LC4536LA BFPV/MPV 2007D/5007S/2007** — — 8690** — 7790B-ESS**/N7790B

K4524 — — — 30836 — — —

K4522 — — — 30838 — — —

K4533 — — — 30840 — — —

K4535 — 2008 — 30842 P7275 — —

K4023* AA1068W/AA1068P — — — A1068W/A1068P — —

K1121 — — — — — — —

K1122 — — — — — — —

LC2000 — 2005 6146/6281 — EC120 — 7760/7762/7790B/7792B

LC2000 — 2007 — — EC240,ECDV — 7770/7772/7790B

Accessories

K4500 SC10 2500/5500 6005/6007 30846 JP275 SC201-99 NS1038-1

K121 AM1ANB 2223/2224 — — 603 — NS47681

K122 AM1A, AM2A, AM2ANB 2421/2422 5925/5926/5927 30862 M2A TB201-99 NS476-71/NS476-732

* With K4001

** Quick response type

For quick access to Intermatic Energy Control products and Weatherproof Covers simply go

to www.intermatic.com/energycontrols

This will take you directly to our Energy Controls Search where you may search for products

by Application, by Feature, by Series or by Category.

This file provides you the ability to download and print specifications, wiring diagrams and

product photographs. Many of our instruction sheets, all in pdf format, can also be found on

the site.

Cross Reference

151

WEATHERPROOF • ENERGY CONTROLS • PROFESSIONAL LIGHTING • POOL & SPA • SURGE PROTECTION • CONSUMER

1. *DAVID ROLE & COMPANY 216 New Boston Street,

Woburn, MA 01801

Phone: (781) 932-8810 FAX: (781) 932-8815

2. P&M SALES, LTD. 400 Chapel Road,

Unit 2-1, South Windsor, CT 06074-4169

Phone: (860) 528-9181 FAX: (860) 528-7050

3. *BURGOYNE SALES, INC. 110 McGaw Drive, Raritan

Industrial Center, Edison, NJ 08837

Phone: (732) 225-0450 FAX: 732-225-7454

4. MILLS TALBOT CO. 100 Thompson Street,

Fayetteville, NY 13066

Phone: (315) 637-0511 FAX: (315) 637-0512

5. *R.C. COLERICK, INC. 1244 Ritchie Hwy., Suite 13,

Arnold, MD 21012

Phone: (410) 421-9511 FAX: (410) 421-9514

6. *SYNERGY ELECTRICAL SALES 95 Canal Rd., Penn

Warner Industrial Park, Fairless Hills, PA 19030

Phone: (800) 220-5691 FAX: (215) 428-1137

7. Electra Products, Inc. 2750 Breckinridge Blvd

Suite 400 Duluth, GA 30095 Phone: (770) 451-9146

Phone: (800) 225-4820 FAX: (770) 451-9424

8. *PAOLICELLI & ASSOCIATES Gregg & Hammond

Sts., Carnegie Industrial Park, P.O. Box 665,

Carnegie, PA 15106-0665

Phone: (412) 276-8816 FAX: (412) 276-6670

9. *E.F. LOMBARDI CO. P.O. Box 669186, Charlotte, NC

28266, 2101 Freedom Drive, Charlotte, NC 28208

Phone: (704) 334-1637 FAX: (704) 372-6078

10. *INTERMATIC INCORPORATED 3150 NW Prospect

Road, Suite 330, Ft. Lauderdale, FL 33309

Phone: (954) 535-0020 FAX: (954) 535-0040

11. Interwest 345 West 62nd Ave.

Suite B Denver, CO. 80216

Phone: (303) 650-5162 FAX: (303) 650-5165

12. *RIFFLE & ASSOCIATES INC. 2671 Crescentville Rd.,

Cincinnati, OH 45241

Phone: (513) 771-0002 FAX: (513) 771-0011

13. *L.P. CHICK CO. P.O. Box 19021, Louisville, KY

40259-0021; 1110 Industrial Blvd., Louisville, KY

40219

Phone: (502) 964-8181 FAX: (502) 964-8196

14. RIFFLE & ASSOCIATES 16760 W. Park Circle Dr.,

Chagrin Falls, OH 44023

Phone: (440) 543-8257 FAX: (440) 543-7236

15. ELECTROCOM-MIDWEST SALES, INC. (EAST) 32500

Concord Drive, Suite 298, Madison Heights, MI

48071

Phone: (248) 307-1640 FAX: (248) 307-1630

16. ELECTROCOM-MIDWEST SALES, INC. (WEST) 4485

Plainfield N.E. Suite 103, Grand Rapids, MI 49525

Phone: (616) 364-8084 FAX: (616) 364-0135

17. ARTHUR A. BOYLE CO., INC. 5172 E. 65th Street,

Indianapolis, IN 46220 Phone: (800) 776-9101

(317) 577-9100 FAX: (317) 577-9161

18. LAKESHORE ELECTRICAL, INC. 614 W. Brown Deer

Rd., Suite 230, Bayside, WI 53217

Phone: (414) 228-0580 (800) 229-2227

FAX: (414) 228-0585

19. INTERMATIC INCORPORATED CORPORATE OFFICES

Intermatic Plaza, Spring Grove, IL 60081-9698

Phone: (815) 675-2321 FAX: (815) 675-7105

20. MARTIN ELECTRICAL SALES, INC. 136 West

Adams, P.O. Box 220189, Kirkwood, MO 63122

Phone: (314) 966-8659 FAX: (314) 966-6748

21. *ETEL 7106 Cavalcade, Houston, TX 77028

Phone: (713) 678-4460 FAX: (713) 678-4371

22. ELECTRA SALES 2320 Hinton Drive,

Irving, TX 75061

Phone: (972) 554-8200 FAX: (972)554-7861

23. ELECTRA SALES 2200 SW 14th St.,

Oklahoma City, OK 73108

Phone: (405) 722-6905 FAX (405) 722-2458

24. CURTIS H. STOUT INC. 2400 Cantrell Road, Suite

100, Little Rock, AR 72202

Phone: (501) 372-2555 FAX: (501) 375-4451

25. CURTIS H. STOUT INC. 3478 Winhoma Drive,

Memphis, TN 38118

Phone: (901) 362-1616 FAX: 901-795-0481

26. CURTIS H. STOUT INC. 201 Evans Road, #110,

Harahan, LA 70123

Phone: (504) 818-1848 FAX: (504) 818-1631

27. STOVER & ASSOCIATES, INC. 4460 W. 107th St.,

Shawnee Mission, KS 66207

Phone: (913) 649-6600 FAX: (913) 649-2762

28. JOE BERTSCH ELECTRICAL SALES 5832 Dry Creek

Lane N.E., Cedar Rapids, IA 52402,

Phone: (319) 395-9220 FAX: (319) 395-9224

29. JOE BERTSCH ELECTRICAL SALES 201 S. 84th St,

Suite D, Lincoln, NE 68510

Phone: (402) 488-1614 FAX: (402) 488-1615

30. JOE BERTSCH ELECTRICAL SALES 8450 Hickman

Rd., Suite 15F,Des Moines, IA 50325

Phone: (515) 276-8967 FAX: (515) 276-8968

31. LEE-NOONAN CO. 2230 Country Rd. H2,

Moundsview, MN 55112

Phone: (763) 278-1036 FAX: (763) 560-3282

32. CENTAURI SALES 10708 Elena Dr. NE,

Albuquerque, NM 87122

Phone: (505) 823-9816 FAX: (505) 823-9608

33. *BLOMQUIST, DENSELY & YOUNG (BDY) 2550 Decker

Blvd. – #28, Salt Lake City, UT 84119 Phone: (801)

972-0070 FAX: (801) 973-0526

34. *PRO-LINES SALES & MARKETING P.O. Box 58248,

Tukwila, WA 98138, 18700 – 80th Place South,

Kent, WA 98032

Phone: (425) 272-0348 FAX: (425) 272-0362

35. PRO-LINES SALES & MARKETING SOUTH

7272 SW Durham Road, Suite 750, Portland, OR

97224

Phone: (503) 692-6993 FAX: (503) 612-6706

36. *INTERMATIC INCORPORATED 10524 Pioneer Blvd.,

Santa Fe Springs, CA 90670

Phone: (562) 906-0900 FAX: (562) 906-0955

37. *LAU COMPANY 47-096 Kam Hwy, Kaneone Oahu,

HI 96744

Phone: (808) 234-0199 FAX: (808) 235-7765

38. CURTIS H. STOUT INC. 11051 Coursey Blvd., Suite

B, Baton Rouge, LA 70816

Phone: (225) 291-5709 FAX: (225) 291-5713

39. BAILEY/MARTIN & ASSOCIATES 935 6th Ave. South,

Nashville, TN 37203

Phone: (615) 256-3000 FAX: (615) 242-6780

40. CURTIS H. STOUT INC. 310 Edgewood Terrace,

Suite B, Jackson, MS 39206

Phone: (601) 366-1903 FAX: (601) 981-8439

41. INTERMATIC INCORPORATED CANADA 6430-B

Kennedy Rd. Unit B Mississauga, Ontario L5T 2Z5

Canada Phone: (905) 696-7621 FAX: (905) 696-

0846

INTERMATIC CANADIAN WAREHOUSE 1200 Cardiff

Blvd, Mississauga, Ontario L5S 1P6

FAX: 1(800) 700-9671

42. INTRALEC ELECTRICAL PRODUCTS LTD. 1200

CardiffBlvd, Unit 1, Mississauga, Ontario Canada

L5S 1P6

Phone: (905) 670-0970 FAX: (905) 670-3098

43. ADANAC #3-2075 Brigantine Drive, Coquitlam,

British Columbia, Canada V3K 7B8

Phone: (604) 540-0220 FAX: (604) 540-0124

44. D.A.D. SALES 2013, 17th Ave., Didsbury,Alberta

TOM OWO, Canada T2G 5G5

Phone: (403) 335-3531 FAX: (403) 335-8347

45. JEBCO AGENCIES, LTD. #4 - 2225 First Avenue

North, Saskatoon, Saskatchewan, Canada S7K 2A5

Phone: (306) 373-0771 FAX: (306) 374-8023

46. JEBCO AGENCIES, LTD. Unit 19 – 1865 Sargent

Avenue, Winnipeg, Manitoba Canada R3H 0E4

Phone: (204) 786-2604 FAX: (204) 786-4734

47. CONTACT DELAGE, INC. 135 J.A. Bombardier, Suite

90, Boucherville, Quebec Canada J4B 8P1

Phone: (450) 449-9444 FAX: (450) 449-6090

48. BROCKWAY ENTERPRISES 51 Cobequid Road,

Suite 203 Lower Sackville, Nova Scotia, Canada

B4C 2N1

Phone: (902) 865-4192 FAX: (902) 865-5967

49. BROCKWAYENTERPRISES 7 Howard Court,

Quispamsis, New Brunswick, Canada E2E 4J6

Phone: (506) 849-6000 FAX: (506) 847-5329

50. BROCKWAY ENTERPRISES 62 Kerry Avenue,

Conception Bay South, New Foundland,

Canada A1X 7H7

Phone: (709) 834-7444 FAX: (709) 834-7446

51. BOB JONES & ASSOCIATES 3837 E. Anne Street,

Phoenix, Arizona 85040

Phone: (602)-437-1111 FAX: (602)-437-2339

www.intermatic.com

General Catalog

Effective January 2007

CORPORATE HEADQUARTERS:

7777 Winn Road

Spring Grove, IL 60081

Phone: (815) 675-2321

Fax: (815) 675-7105

www.intermatic.com

*indicates carries stock of industrial and consumer products

INDUSTRIAL & COMMERCIAL

SALES REPRESENTATIVES

GeneralCatalog Eff. 1/07

WEATHERPROOF

ENERGY CONTROLS

PROFESSIONAL LIGHTING

POOL & SPACONTROLS

SURGE PROTECTION

CONSUMER PRODUCTS

Intermatic General Catalog 121623

81385-Catalog 81385-Catalog 81385-Catalog 078275 Batch3 unilog cesco-content

202465-Catalog 202465-Catalog 202465-Catalog 078275 Batch4 unilog cesco-content

213245-Catalog 213245-Catalog 213245-Catalog 078275 Batch5 unilog cesco-content

91770-Catalog 91770-Catalog 91770-Catalog 078275 Batch10 unilog cesco-content

Navigation menu

Versions of this User Manual:

Views

Navigation
