Product Detail Manual

Innovations that work

Professional

Insulated Tools

Supporting

Arc Flash Protection

10,000 Volt

Tested

1000 Volt Rated

from

Description Page

Insulated Adjustable Wrenches 5

8.0, 10.0, 12.0, 15.0”

Wiha Insulated Adjustable Wrenches

Description Page

Ins. 3/8” Hex Dr. Bit Sockets 10

Wiha Insulated 3/8” Hex Drive Bit Sockets

Arc Flash Protection:

Wiha Insulated tools can be a vital component in your Arc Flash

protection strategy. What is Arc Flash?

ARC FLASH

An Arc Flash is an electrical explosion due to a fault condition or short

circuit when either a phase to ground or phase to phase conductor is

connected. Arc flashes cause electrical equipment to explode, result-

ing in an arc-plasma fireball. Temperatures may exceed 35,000° F (the

surface of the sun is 9000° F). These high temperatures cause rapid

heating of surrounding air and extreme pressures, resulting in an arc

blast. The arc blast will likely vaporize all solid copper conductors which

will expand up to 67,000 times its original volume when it is vaporized.

The result of this violent event is usually destruction of the equipment

involved, fire, and severe injury or death to any nearby people.

WHY ARC FLASHES HAPPEN

There are a variety of reasons why an Arc Flash can occur, but most

of them are preventable. Most arc flashes occur when maintenance

workers are manipulating live equipment for testing or repair and

accidentally cause a fault. Improper tools, improper electrical

equipment, corrosion of equipment, improper work techniques and lack

of training are just some of the events that can lead to a devastating

arc flash or arc blast.

ARC FLASH COMPLIANCE

There are 4 main regulations that govern electrical safety & arc flash:

1. OSHA Standards 29CFR, Part 1910. Occupational Safety and

Health Standards. 1910 sub part S (electrical) Standard number

1910.333 specifically addresses Standards for Work Practices and

references NFPA 70E. OSHA 29CFR 1910.335 (a) (1)(i) requires the

use of protective equipment when working where a potential electrical

hazard exists and 29CFR 1910.132(d)(1) which requires the employer

assess the workplace for hazards and the need for personal protective

equipment. OSHA compliance is required by any plant building or facility.

2. The National Fire Protection Association (NFPA) Standard 70 -

2002 “The National Electrical Code” (NEC) contains requirements for

warning labels.

3. NFPA 70E provides guidance on implementing appropriate work

practices that are required to safeguard workers from injury while

working on or near exposed electrical conductors or circuit parts that

could become energized. Part II 2-1.3.3 regarding Arc Flash Analysis

states that a “Flash Hazard Analysis shall be done before a person

approaches any exposed electrical conductor or circuit part that has

not been placed in an electrical safe work condition”. This Arc Flash

Hazard Analysis must be done to determine the level of Personal

Protection Equipment PPE that a worker must use, and the Arc Flash

Boundary in inches along with the incident energy found at each

location. Each panel must be marked with an ANSI z535 approved Arc

Flash Warning Label.

4. The Institute of Electronics and Electrical Engineers (IEEE) 1584 –

2002 Guide to Performing Arc-Flash Hazard Calculations

http://www.martinarcflash.com

OSHA

Wiha tools assists with compliance of OSHA 29CFR 1910

(Sub Parts electrical standard)

Description Page

Insulated Open End Spanners 4-5

Insulated Gear Wrenches 6

Ins. Offset Ring Wrenches 7-8

Description Page

Insulated L-keys 9

Wiha Insulated L-keys

Description Page

Insulated Sockets 1/4, 3/8, 1/2” 10-14

Insulated Ratchets 10,13,15

Insulated T-handle 10,13,15

Insulated Extension Bars 11,13,15

Wiha Insulated Socket Accessories

Description Page

Insulated Knives 8

Wiha Insulated Electrician’s Knives

Description Page

Insulated Cable Cutters 15

Wiha Insulated Cable Cutters

Wiha Insulated Wrenches

2

Description Page

Insulated BitFlip Sets 27

Wiha Insulated BitFlip Sets

Description Page

Insulated Belt Pack Pouches 28

Pliers & Cutters

Pliers/Cutters & Screwdrivers

Pliers/Cutters & Multi Bit Set

Wiha Insulated Belt Pack Pouch Sets

Description Page

Insulated Inomic Pliers 37

Inomic Combo Pliers

Inomic Long Nose Pliers

Inomic Diagonal Cutters

Wiha Insulated Inomic Pliers

Description Page

Xeno Terminal Block 26

Combination Screwdrivers

Insulated TorqueControl 18

Handle & Blade Holder

Insulated 26

Single-Pole Voltage Detector

Insulated Hex 17

Inch/Metric T-handles

Insulated Slotted Drivers 23-24

Insulated Phillips Drivers 23-24

Insulated Torx Drivers 26

Insulated Nut Drivers 25-26

Insulated Square Tip Drivers 24

Retaining Ring Bit Holder 27

Insulated Tweezers 16

Wiha Insulated Tools

Description Page

Insulated Multi-Bit Drivers 18

Wiha Insulated Multi-Bit Holders

Description Page

Insulated Lineman’s Pliers 34

Insulated Combination Pliers 34

Insulated Heavy Duty 35

Diagonal Cutters

Insulated Serrated Edge 35

Cable Cutter

Insulated Bent Nose Pliers 36

Insulated Long Nose Pliers 36

Insulated Round Nose Pliers 36

Insulated Stripping Pliers 37

Insulated Pliers Sets 29-33

Wiha Insulated 1000Volt Pliers/Cutters

Description Page

Insulated Hacksaw 15

Wiha Insulated Hacksaw

Description Page

Insulated SlimLine Handle 19

Insulated SlimLine Blades 19-20

Insulated SlimLine Blade Sets 20

Insulated SlimLine Drivers 21

Insulated SlimLine Driver Sets 22

Wiha Insulated SlimLine Tools

3

Description Page

Insulated Industrial Pliers/Cutters 38-41

Wiha Insulated Industrial Pliers/Cutters

3

Wiha Insulated Open-End Wrenches

14 Piece Insulated Inch Open End Wrench Set

Item OAL OAL

No. Inch Inch Inch Inch lbs.

20133 5/16 3.9 20142 3/4 7.0 5.70

20135 3/8 4.1 20144 13/16 7.5

20136 7/16 4.6 20145 7/8 7.6

20137 1/2 5.5 20146 15/16 7.9

20138 9/16 5.7 20147 1 8.4

20140 5/8 6.2 20148 1-1/16 9.2

20141 11/16 6.5 20149 1-1/8 9.1

1000Volt

Steel

Forged from chrome

vanadium, meets - DIN 3110

Angled 15O

Insulation

High visibility, grip is

double coated

Insulation Test Standards:

Insulation according to ASTM F-1505-01,

EN/IEC 60900, VDE 0680, DIN 7446

and CSA

Each tool individually

tested to 10,000 volts

and certified to 1000

Volt ac or 1500 Volt dc

1000V

15 Piece Insulated Metric Open End Wrench Set

Item OAL OAL

No. mm mm mm mm lbs.

20006 6.0 97 20014 14 150 3.0

20007 7.0 98 20015 15 151

20008 8.0 104 20016 16 164

20009 9.0 108 20017 17 162

20010 10.0 107 20019 19 178

20011 11.0 118 20022 22 196

20012 12.0 129 20024 24 211

20013 13.0 137

1000Volt

8 Piece Insulated Inch Open End Wrench Set

Item OAL OAL

No. Inch Inch Inch Inch lbs.

20133 5/16 3.9 20138 9/16 5.7 1.59

20135 3/8 4.1 20140 5/8 6.2

20136 7/16 4.6 20141 11/16 6.5

20137 1/2 5.5 20142 3/4 7.0

1000Volt

8 Piece Insulated Metric Open End Wrench Set

Item OAL OAL

No. mm mm mm mm lbs.

20006 6.0 97 20013 13.0 137 1.4

20007 7.0 98 20014 14.0 150

20008 8.0 104 20017 17.0 162

20010 10.0 107 20019 19.0 178

1000Volt

4

WH20190

WH20190 WH

WH

WH20192

WH20192 WH

WH

WH20091

WH20091 WH

WH

WH20093

WH20093 WH

WH

Inch Open-End Wrenches, With Insulated Handle

Insulation According to VDE Specification 0680 and EN/IEC 60900,

DIN 7446 and CSA, up to 1000 Volt. Individually Tested.

Chrome-vanadium steel, hardened. Angled 15O.

Item OAL OAL

No. Inch mm Inch lbs. pkg.

1/4 87.5 3.4 .04 1

5/16 100 3.9 .05 1

3/8 105 4.1 .09 1

7/16 117 4.6 .09 1

1/2 140 5.5 .15 1

9/16 146 5.7 .15 1

5/8 158 6.2 .20 1

11/16 165 6.5 .23 1

3/4 178 7.0 .33 1

13/16 191 7.5 .42 1

7/8 192 7.6 .44 1

15/16 201 7.9 .51 1

1 213 8.4 .61 1

1-1/16 233 9.2 .79 1

1-1/8 233 9.2 .77 1

* Lengths are +/- 5% due to coating process

1000Volt

Insulated 8” Adjustable Wrench

Insulation According to ASTM, EN/IEC, NFPA, CSA and ISO

Specification, up to 1000 Volt. Individually Tested. Etched on scale

for pre-setting size. Slip guard handle for added protection.

Item OAL OAL Capacity

No. Inch mm Opening lbs. pkg.

8.0 200 1” .7 1

1000Volt

Insulated 10” Adjustable Wrench

Insulation According to ASTM, EN/IEC, NFPA, CSA and ISO

Specification, up to 1000 Volt. Individually Tested. Etched on scale

for pre-setting size. Slip guard handle for added protection.

Item OAL OAL Capacity

No. Inch mm Opening lbs. pkg.

10.0 250 1-1/4” 1.4 1

1000Volt

Insulated 12” Adjustable Wrench

Insulation According to ASTM, EN/IEC, NFPA, CSA and ISO

Specification, up to 1000 Volt. Individually Tested. Etched on scale

for pre-setting size. Slip guard handle for added protection.

Item OAL OAL Capacity

No. Inch mm Opening lbs. pkg.

12.0 300 1-1/2” 1.9 1

1000Volt

Insulated 15” Adjustable Wrench

Insulation According to ASTM, EN/IEC, NFPA, CSA and ISO

Specification, up to 1000 Volt. Individually Tested. Etched on scale

for pre-setting size. Slip guard handle for added protection.

Item OAL OAL Capacity

No. Inch mm Opening lbs. pkg.

15.0 380 1-11/16” 2.8 1

1000Volt

Metric Open-End Wrenches, With Insulated Handle

Insulation According to VDE Specification 0680 and EN/IEC 60900,

DIN 7446 and CSA, up to 1000 Volt. Individually Tested.

Chrome-vanadium steel, hardened. Angled 15O.

Item OAL OAL

No. mm mm Inch lbs. pkg.

6.0 97 3.8 .04 1

7.0 98 3.9 .05 1

8.0 104 4.1 .07 1

9.0 108 4.3 .07 1

10.0 107 4.2 .08 1

11.0 118 4.6 .11 1

12.0 129 5.1 .11 1

13.0 137 5.4 .19 1

14.0 150 5.9 .19 1

15.0 151 5.9 .17 1

16.0 164 6.5 .22 1

17.0 162 6.4 .24 1

18.0 173 6.8 .41 1

19.0 178 7.0 .32 1

20.0 190 6.9 .36 1

22.0 196 7.7 .39 1

24.0 211 8.3 .58 1

27.0 218 8.6 .68 1

30.0 235 9.3 .97 1

32.0 237 9.3 1.01 1

1000Volt

Wiha Insulated Adjustable Wrenches

3 Pc. Insulated Adjustable Wrenches

Etched on scale for

pre-setting size. Slip guard handle for added protection.

Item No. Set includes the following:

lbs. 4.0 8.0”, 10.0”, 12.0” Adjustable Pliers

5

WH201

WH20131

WH20133

WH20135

WH20136

WH20137

WH20138

WH20140

WH20141

WH20142

WH20144

WH20145

WH20146

WH20147

WH20148

WH20149

WH200

WH20006

WH20007

WH20008

WH20009

WH20010

WH20011

WH20012

WH20013

WH20014

WH20015

WH20016

WH20017

WH20018

WH20019

WH20020

WH20022

WH20024

WH20027

WH20030

WH20032

WH76208

WH76210

WH76212

WH76215

5

WH76290

Inch Insulated Ratchet Wrenches, With Insulated Handle

Insulation According to EN/IEC 60900, ISO 3110 Specification,

Up To 1000 Volt. Individually Tested.

Blade chrome-vanadium steel, hardened.

Item OAL OAL

No. Inch mm Inch lbs. pkg.

3/8 140 5.5 .14 1

7/16 143 5.6 .15 1

1/2 154 6.1 .18 1

9/16 162 6.4 .22 1

5/8 177 7.0 .30 1

3/4 209 8.2 .46 1

Wiha Insulated Ratchet Wrenches

1000Volt

6 Piece Inch Insulated Ratchet Wrenches Set

Item OAL OAL

No. Inch Inch Inch Inch lbs.

21325 3/8 5.5 21331 9/16 6.4 1.95

21327 7/16 5.6 21333 5/8 7.0

21329 1/2 6.1 21335 3/4 8.2

1000Volt

Steel

Forged from chrome

vanadium, meets - DIN 3110

Insulation Test Standards:

Insulation according to ASTM F-1505-01,

EN/IEC 60900, ISO 3110 and CSA

Specification

Each tool individually

tested to 10,000 volts

and certified to 1000

Volt ac or 1500 Volt dc

1000V

Metric Insulated Ratchet Wrenches, With Insulated Handle

Insulation According to EN/IEC 60900, ISO 3110 Specification,

Up To 1000 Volt. Individually Tested.

Blade chrome-vanadium steel, hardened.

Item OAL OAL

No. mm mm Inch lbs. pkg.

8.0 125 4.9 .08 1

10.0 140 5.5 .12 1

12.0 150 5.9 .18 1

13.0 152 6.0 .18 1

14.0 163 6.4 .22 1

17.0 193 7.6 .38 1

19.0 210 8.3 .45 1

1000Volt

7 Piece Metric Insulated Ratchet Wrenches Set

Item OAL OAL

No. mm mm mm mm lbs.

21208 8.0 4.9 21214 14.0 6.4 2.10

21210 10.0 5.5 21217 17.0 7.6

21212 12.0 5.9 21219 19.0 8.3

21213 13.0 6.0

1000Volt

6

WH213

WH21325

WH21327

WH21329

WH21331

WH21333

WH21335

WH

WH21391

WH21391 WH

WH

WH21290

WH21290 WH

WH

WH212

WH21208

WH21210

WH21212

WH21213

WH21214

WH21217

WH21219

7

Wiha Insulated Deep Offset Ring Wrenches

Steel

Forged from chrome

vanadium, meets - DIN 3110

Insulation Test Standards:

Insulation according to ASTM F-1505-01,

EN/IEC 60900, ISO 3110 and CSA

Specification

Each tool individually

tested to 10,000 volts

and certified to 1000

Volt ac or 1500 Volt dc

1000V

Insulated Metric Offset Ring Wrenches, Insulation According

to EN/IEC 60900, ISO 3110 Specification, Up To 1000 Volt.

Individually Tested. Blade Chrome-Vanadium steel, hardened.

Item OAL OAL

No. mm mm Inch lbs. pkg.

8.0 159 6.3 .16 1

9.0 159 6.3 .18 1

10.0 171 6.8 .20 1

11.0 178 7.0 .22 1

12.0 191 7.5 .30 1

13.0 194 7.6 .30 1

14.0 203 8.0 .34 1

15.0 203 8.0 .34 1

17.0 219 8.6 .44 1

19.0 241 9.5 .52 1

22.0 257 10.1 .64 1

24.0 279 11.0 .90 1

27.0 286 11.3 .96 1

30.0 311 12.3 1.28 1

32.0 318 12.5 1.38 1

1000Volt

NEW

From Wiha

1000Volt

WARNING!

Insulated Tools are intended to provide protection against accidental

contact with charged energized circuits. For maximum safety we

recommend de-energizing all circuits whenever possible before starting

work on electrical apparatus or conductors. Always visually inspect

insulation on tools before use, do not use tools if insulation shows signs

of wear or damage to the insulated areas of the tool. Wear appropriate

eye protection when using hand tools. Use NFPA70E certified insulated

protective outer wear when appropriate.

Use & Care Guide For Insulated Tools:

Store tools to minimize risk of damage to insulation, always wear

approved eye protection, Inspect insulation prior to each use of any

insulated tool. Use insulated tools where the ambient temperature

is between -20 to +70O C. Have a qualified safety technician visually

inspect insulation on tools annually for safe use.

15 Piece Metric Insulated Offset Ring Wrenches Set

Item No.

Metric:

8.0, 9.0, 10.0, 11.0, 12.0, 13.0, 14.0, 15.0, 17.0,

lbs. 8.70 19.0, 22.0, 24.0, 27.0, 30.0, 32.0mm

8 Piece Metric Insulated Offset Ring Wrenches Set

Item No. Metric:

10.0, 11.0, 12.0, 13.0, 14.0, 15.0, lbs.

17.0, 19.0mm 3.20

WH210

WH21008

WH21009

WH21010

WH21011

WH21012

WH21013

WH21014

WH21015

WH21017

WH21019

WH21022

WH21024

WH21027

WH21030

WH21032

WH21093

WH21095

7

8

Insulated Inch Offset Ring Wrenches

Item OAL OAL

No. Inch mm Inch lbs. pkg.

1/4 159 6.3 .16 1

5/16 159 6.3 .18 1

3/8 171 6.8 .20 1

7/16 178 7.0 .22 1

1/2 191 7.5 .30 1

9/16 194 7.6 .30 1

5/8 203 8.0 .34 1

11/16 203 8.0 .34 1

3/4 219 8.6 .44 1

13/16 241 9.5 .52 1

7/8 257 10.1 .64 1

15/16 279 11.0 .90 1

1.0 286 11.3 .96 1

1-1/16 311 12.3 1.28 1

1-1/4 318 12.5 1.38 1

1000Volt

15 Piece Inch Insulated Offset Ring Wrenches Set

Item No.

Inch:

1/4, 5/16, 3/8, 7/16, 1/2, 9/16, 5/8, 11/16, 3/4,

lbs. 8.70 13/16, 7/8, 15/16, 1, 1-1/16, 1-1/4”

8 Piece Inch Insulated Offset Ring Wrenches Set

Item No. Inch:

5/16, 3/8, 7/16, 1/2, 9/16, lbs.

5/8, 11/16, 3/4” 3.20

Insulated Electrician’s Cable Stripping Knife, With

Insulated Handle, Insulation According To VDE Specification,

Up To 1000 Volt. Individually Tested.

Blade tool steel, hardened, molded directly on. Cover included.

Item Blade OAL OAL

No. mm mm Inch lbs. pkg.

50 216 8.5 .30 1

1000Volt

Insulated Electrician’s Cable Stripping Knife, With

Insulated Handle, Insulation According To VDE Specification,

Up To 1000 Volt. Individually Tested. Straight, partly insulated,

strong blade. Insulation molded directly on. Cover included.

Item Blade OAL OAL

No. mm mm Inch lbs. pkg.

50 230 9.0 .23 1

1000Volt

Insulated Stripping Knife, With Insulated Handle

Insulation According To VDE Specification, Up To 1000 Volt.

Individually Tested. Blade tool steel, hardened. Insulation molded

directly on. Hooked cutting edge, half-round ground. Cover included.

Item Blade OAL OAL

No. mm mm Inch lbs. pkg.

35 222 8.75 .22 1

1000Volt

Wiha Insulated Electrician’s Knives

Insulation Test Standards:

Insulation according to

ASTM, EN/IEC, VDE

& CSA Specification

Individually tested

Each tool individually tested to 10,000 volts &

rated to 1000 Volt ac or 1500 Volt dc

1000V

Insulation

molded on for

permanent bonding

Wiha Insulated Deep Offset Ring Wrenches

NEW

From Wiha

NEW

From Wiha

NEW

From Wiha

WH210

WH21040

WH21042

WH21044

WH21046

WH21048

WH21050

WH21052

WH21054

WH21056

WH21058

WH21060

WH21062

WH21064

WH21066

WH21068

WH21094

WH21096

WH15000

WH15003

WH15050

9

Wiha Insulated Hex L-keys

Insulation Test Standards:

Insulation according to ASTM,

F-1505-01, EN/IEC 60900

and CSA

Inch Insulated Hex L-keys, With Insulated Handle

Insulation According to IEC 60900 Specification, Up To 1000 Volt.

Individually Tested. Blade chrome-vanadium steel, hardened.

Item OAL OAL

No. Inch mm Inch lbs. pkg.

1/16 79 3.1 .05 1

5/64 84 3.3 .05 1

3/32 89 3.5 .05 1

7/64 94 3.7 .06 1

1/8 104 4.1 .06 1

5/32 104 4.1 .06 1

3/16 134 5.3 .10 1

7/32 134 5.3 .12 1

1/4 134 5.3 .16 1

5/16 144 5.7 .24 1

3/8 234 9.2 .51 1

1/2 234 9.2 .77 1

1000Volt

Metric Insulated Hex L-keys, With Insulated Handle

Insulation According to IEC 60900 Specification, Up To 1000 Volt.

Individually Tested. Blade chrome-vanadium steel, hardened.

Item OAL OAL

No. mm mm Inch lbs. pkg.

1.5 100 3.9 .09 1

2.0 105 4.1 .09 1

2.5 115 4.5 .09 1

3 130 5.1 .10 1

4 120 4.7 .10 1

5 140 5.5 .10 1

6 140 5.5 .13 1

8 150 5.9 .24 1

10 220 8.7 .51 1

12 260 10.2 .77 1

1000Volt

8 Piece Insulated Inch Hex L-key Set

Item OAL OAL

No. Inch Inch Inch Inch lbs.

13663 1/8 4.1 13668 1/4 5.3 2.17

13665 5/32 4.1 13669 5/16 5.7

13666 3/16 5.3 13662 3/8 9.2

13667 7/32 5.3 13664 1/2 9.2

1000Volt

7 Piece Insulated Metric Hex L-key Set

Item OAL OAL

No. mm mm mm mm lbs.

13653 3.0 130 13658 8.0 150 2.07

13654 4.0 120 13659 10.0 220

13655 5.0 140 13657 12.0 260

13656 6.0 140

1000Volt

Each tool individually

tested to 10,000 volts

and certified to 1000

Volt ac or 1500 Volt dc

1000V

Insulation

Applied directly

onto blade for

permanent

bonding

13690

13691

10 Piece Insulated Metric Hex L-key Set

Item OAL OAL

No. mm mm mm mm lbs.

13650 1.5 100 13655 5.0 140 2.26

13651 2.0 105 13656 6.0 140

13652 2.5 115 13658 8.0 150

13653 3.0 130 13659 10.0 220

13654 4.0 120 13657 12.0 260

1000Volt

NEW

From Wiha

1000Volt

9

WH136

WH13670

WH13671

WH13672

WH13673

WH13663

WH13665

WH13666

WH13667

WH13668

WH13669

WH13662

WH13664

WH

WH13690

WH136

WH13650

WH13651

WH13652

WH13653

WH13654

WH13655

WH13656

WH13658

WH13659

WH13657

WH

WH13691

WH13691 WH

WH

WH13693

WH

Insulated 1/4” Drive Ratchet, EN/IEC 60900 & CSA

Chrome-Vanadium steel. Reversible.

Item OAL OAL

No. Inch mm Inch lbs. pkg.

1/4” 140 5.5 .28 1

1000Volt

Wiha Insulated 1/4” Sockets & Sets

Insulated 1/4” Drive Sockets - 6 Point, Insulation According

To ASTM F-1505-01, DIN 7448 & CSA Specification, Up To 1000

Volt. Individually Tested. Chrome-vanadium steel, forged, oil-hardened.

Item

No. Inch lbs. pkg.

3/16 .03 1

7/32 .03 1

1/4 .03 1

9/32 .04 1

5/16 .04 1

11/32 .05 1

3/8 .05 1

7/16 .06 1

1/2 .07 1

9/16 .07 1

*Sockets must be used with insulated ratchets & extensions

1000Volt

Insulated 1/4” Drive Sockets - 6 Point, Insulation According

To ASTM F-1505-01, DIN 7448 & CSA Specification, Up To 1000 Volt.

Individually Tested. Chrome-vanadium steel, forged, oil-hardened.

Item

No. mm lbs. pkg.

5.0 .03 1

6.0 .03 1

7.0 .03 1

8.0 .04 1

9.0 .04 1

10.0 .05 1

11.0 .05 1

12.0 .06 1

13.0 .06 1

14.0 .07 1

*Sockets must be used with insulated ratchets & extensions

1000Volt

Metric -

6 Point

Inch -

6 Point

10

Wiha Insulated Hex Bit Sockets

1000Volt

7 Pc. Insulated 3/8” Drive Socket Set - Inch

CV steel, forged, oil-hardened sockets. Insulated to EN/IEC 60900.

Item No. Set includes the following:

lbs. 1.7 3/16, 7/32, 1/4, 5/16, 3/8, 7/16, 1/2”

Insulated 3/8” Drive Sockets - Insulation according to

EN/IEC 60900, DIN 7448 Specification, Up To 1000 Volt.

Individually Tested. Chrome-vanadium steel, forged, oil-hardened.

Item OAL

No. Inch Inch lbs. pkg.

3/16 3.1” .13 1

7/32 3.1” .14 1

1/4 3.1” .14 1

5/16 3.1” .16 1

3/8 3.1” .18 1

7/16 3.1” .20 1

1/2 3.1” .22 1

*Sockets must be used with insulated ratchets & extensions

1000Volt

WARNING!

Insulated Tools are intended to provide protection against accidental

contact with charged energized circuits. For maximum safety we

recommend de-energizing all circuits whenever possible before starting

work on electrical apparatus or conductors. Always visually inspect

insulation on tools before use, do not use tools if insulation shows signs

of wear or damage to the insulated areas of the tool. Wear appropriate

eye protection when using hand tools. Use NFPA70E certified insulated

protective outer wear when appropriate.

Use & Care Guide For Insulated Tools:

Store tools to minimize risk of damage to insulation, always wear

approved eye protection, Inspect insulation prior to each use of any

insulated tool. Use insulated tools where the ambient temperature

is between -20 to +70O C. Have a qualified safety technician visually

inspect insulation on tools annually for safe use.

WH318

WH31805

WH31807

WH31809

WH31811

WH31813

WH31815

WH31817

WH31890

WH313

WH31336

WH31337

WH31338

WH31339

WH31340

WH31341

WH31342

WH31343

WH31344

WH31345

WH313

WH31326

WH31327

WH31328

WH31329

WH31330

WH31331

WH31332

WH31333

WH31334

WH31335

WH12851

11

Insulated 1/4” Extension Bars, ASTM F-1505-01,

EN/IEC 60900 & CSA Chrome-Vanadium steel.

Item OAL OAL

No. Inch mm Inch lbs. pkg.

1/4” 50 2.0 .08 1

1/4” 100 3.9 .12 1

1000Volt

13 Piece Insulated 1/4” Drive Socket Set - Inch

CV steel, forged, oil-hardened sockets. Insulated after EN/IEC 60900.

Item No. Set includes the following:

3/16, 7/32, 1/4, 9/32, 5/16, 11/32,

lbs. 3/8, 7/16, 1/2, 9/16”

1.39 1/4” x 50mm Extension Bar

1/4” x 100mm Extension Bar

1/4” Ratchet - 140mm

1000Volt

13 Piece Insulated 1/4” Drive Socket Set - Metric

CV steel, forged, oil-hardened sockets. Insulated after EN/IEC 60900.

Item No. Set includes the following:

5, 6, 7, 8, 9, 10, 11, 12, 13, 14mm

lbs. 1/4” x 50mm Extension Bar

1.41 1/4” x 100mm Extension Bar

1/4” Ratchet - 140mm

Insulated 1/4” Drive T-handle, With Insulated Handle

Insulation according to EN/IEC 60900 & CSA specification, up to

1000 Volt. Individually Tested. Blade CV steel, hardened.

Item OAL OAL

No. Inch mm Inch lbs. pkg.

1/4 160 6.2” .57 1

1000Volt

Wiha Insulated 1/4” Sockets & Sets

Wiha Insulated 1/4” Socket accessories

1000Volt

11 Piece Insulated 1/4” T-handle & Socket Set - Metric

CV steel, forged, oil-hardened sockets. Insulated after EN/IEC 60900.

Item No. Set includes the following:

5, 6, 7, 8, 9, 10, 11, 12, 13, 14mm

lbs. 1.40 Insulated 1/4” T-handle

1000Volt

11 Piece Insulated 1/4” T-handle & Socket Set - Inch

CV steel, forged, oil-hardened sockets. Insulated after EN/IEC 60900.

Item No. Set includes the following:

3/16, 7/32, 1/4, 9/32, 5/16, 11/32,

lbs. 3/8, 7/16, 1/2, 9/16”

1.40 Insulated 1/4” T-handle

Each tool individually tested to 10,000 volts &

certified to 1000 Volt ac or 1500 Volt dc

11

WH31390

WH31391

WH31394

WH31395

WH29006

WH128

WH12854

WH12855

1000Volt

10 Piece Insulated 3/8” Drive Socket Set - Inch

CV steel, forged, oil-hardened sockets. Insulated to EN/IEC 60900.

Item No. Set includes the following:

5/16, 3/8, 7/16, 1/2,

lbs. 9/16, 5/8, 11/16, 3/4”

2.50 3/8” x 125mm Extension Bar

3/8” Ratchet - 280mm

1000Volt

10 Piece Insulated 3/8” Drive Socket Set - Metric

CV steel, forged, oil-hardened sockets. Insulated to EN/IEC 60900.

Item No. Set includes the following:

8, 10, 11, 12, 13, 14, 17, 19mm

lbs. 3/8” x 125mm Extension Bar

2.50 3/8” Ratchet - 280mm

1000Volt

16 Piece Insulated 3/8” Drive Socket Set - Inch/Metric

CV steel, forged, oil-hardened sockets. Insulated to EN/IEC 60900.

Item No. Set includes the following:

5/16, 3/8, 7/16, 1/2,

lbs. 9/16, 5/8, 11/16, 3/4”

2.01 8, 10, 11, 12, 13, 14, 17, 19mm

Wiha Insulated 3/8” Sockets & Sets

Insulated 3/8” Drive Sockets - Insulation according to

EN/IEC 60900, DIN 7448 & CSA specification, up to 1000 Volt.

Individually Tested. CV steel, forged, oil-hardened.

Item

No. Inch lbs. pkg.

1/4 .07 1

9/32 .07 1

5/16 .07 1

11/32 .07 1

3/8 .08 1

7/16 .08 1

1/2 .10 1

9/16 .10 1

5/8 .10 1

11/16 .13 1

3/4 .14 1

13/16 .17 1

7/8 .18 1

*Sockets must be used with insulated ratchets & extensions

1000Volt

Insulated 3/8” Drive Sockets - Insulation according to VDE,

EN/IEC 60900, DIN 7448 & CSA specification, up to 1000 Volt.

Individually Tested. Chrome-vanadium steel, forged, oil-hardened.

Item

No. mm lbs. pkg.

6.0 .07 1

7.0 .07 1

8.0 .07 1

9.0 .07 1

10.0 .07 1

11.0 .08 1

12.0 .10 1

13.0 .10 1

14.0 .10 1

15.0 .10 1

16.0 .10 1

17.0 .11 1

18.0 .12 1

19.0 .14 1

20.0 .15 1

21.0 .17 1

22.0 .18 1

24.0 .26 1

*Sockets must be used with insulated ratchets & extensions

1000Volt

12

WH314

WH31425

WH31428

WH31429

WH31430

WH31431

WH31432

WH31433

WH31434

WH31435

WH31436

WH31437

WH31438

WH31439

WH315

WH31506

WH31507

WH31508

WH31509

WH31510

WH31511

WH31512

WH31513

WH31514

WH31515

WH31516

WH31517

WH31518

WH31519

WH31520

WH31521

WH31522

WH31524

WH31493

WH31590

WH31491

13

Wiha Insulated 3/8” Sockets & Sets

1000Volt

24 Piece Insulated 3/8” Drive Socket Set - Inch

CV steel, forged, oil-hardened sockets. Insulated to EN/IEC 60900.

Item No. Set includes the following:

1/4, 9/32, 5/16, 11/32, 3/8, 7/16

1/2, 9/16, 5/8,11/16, 3/4” Sockets

lbs. 3/8” x 125mm Extension Bar

9.07 3/8” x 250mm Extension Bar

3/8” Ratchet - 190mm

Insulated Electrician’s Knife - 50mm

Slotted: 3.5, 4.5, 6.5mm

Phillips: 1, 2, 3

6.3” Long Nose Pliers

8.0” Combo Pliers

6.3” Diagonal Cutters

*Sockets must be used with insulated ratchets & extensions

1000Volt

24 Piece Insulated 3/8” Drive Socket Set - Metric

CV steel, forged, oil-hardened sockets. Insulated to EN/IEC 60900.

Item No. Set includes the following:

6, 7, 8, 9, 10, 11, 12,

13, 14, 17, 19mm Sockets

lbs. 3/8” x 125mm Extension Bar

9.08 3/8” x 250mm Extension Bar

3/8” Ratchet - 190mm

Insulated Electrician’s Knife - 50mm

Slotted: 3.5, 4.5, 6.5mm

Phillips: 1, 2, 3

6.3” Long Nose Pliers

8.0” Combo Pliers

6.3” Diagonal Cutters

*Sockets must be used with insulated ratchets & extensions

Insulated 3/8” Drive Ratchet, EN/IEC 60900

Chrome-Vanadium steel. Reversible.

Item OAL OAL

No. Inch mm Inch lbs. pkg.

3/8” 190 7.5 .93 1

1000Volt

Insulated 3/8” Extension Bars, EN/IEC 60900

Chrome-Vanadium steel.

Item OAL OAL

No. Inch mm Inch lbs. pkg.

3/8” 125 4.9 .41 1

3/8” 250 9.8 .57 1

1000Volt

Insulated 3/8” Drive T-handle

Insulation according to EN/IEC 60900 specification, up to 1000 Volt

Rated. Individually Tested. Blade chrome-vanadium steel, hardened.

Item OAL OAL

No. Inch mm Inch lbs. pkg.

3/8 200 7.9” .55 1

1000Volt

Wiha Insulated 3/8” Socket accessories

10 Piece Insulated 3/8” T-handle & Socket Set - Metric

CV steel, forged, oil-hardened sockets. Insulated after EN/IEC 60900.

Item No. Set includes the following:

8, 10, 11, 12, 13, 14, 17, 19mm

lbs. 3/8” x 125mm Extension Bar

2.47 Insulated 3/8” T-handle

1000Volt

10 Piece Insulated 3/8” T-handle & Socket Set - Inch

CV steel, forged, oil-hardened sockets. Insulated after EN/IEC 60900.

Item No. Set includes the following:

5/16, 3/8, 7/16, 1/2, 9/16, 5/8, 11/16, 3/4”

lbs. 3/8” x 125mm Extension Bar

2.47 Insulated 3/8” T-handle

13

WH31495

WH31592

WH31496

WH31595

WH12852

WH128

WH12856

WH12857

WH29009

1000Volt

24 Piece Insulated 1/2” Drive Socket Set - Inch

CV steel, forged, oil-hardened sockets. Insulated to EN/IEC 60900.

Item No. Set includes the following:

3/8, 7/16, 1/2, 9/16, 5/8, 11/16, 3/4, 13/16, 7/8, 15/16, 1” Sockets

1/2” x 125mm Extension Bar

lbs. 1/2” x 250mm Extension Bar

11.41 1/2” Ratchet - 260mm

Insulated Electrician’s Knife - 50mm

Slotted: 3.5, 4.5, 6.5mm & Phillips: 1, 2, 3

6.3” Long Nose Pliers

8.0” Combo Pliers

6.3” Diagonal Cutters

24 Piece Insulated 1/2” Drive Socket Set - Metric

CV steel, forged, oil-hardened sockets. Insulated to EN/IEC 60900.

Item No. Set includes the following:

8, 9, 10, 12, 13, 14, 15, 17, 19, 22, 24mm Sockets

1/2” x 125mm Extension Bar

lbs. 1/2” x 250mm Extension Bar

11.39 1/2” Ratchet - 260mm

Insulated Electrician’s Knife - 50mm

Slotted: 3.5, 4.5, 6.5mm & Phillips: 1, 2, 3

6.3” Long Nose Pliers

8.0” Combo Pliers

6.3” Diagonal Cutters

Metric

Wiha Insulated 1/2” Sockets & Sets

Insulated 1/2” Drive Sockets - Insulation According to

ASTM F-1505-01, DIN 7448 & CSA Specification, Up To 1000 Volt.

Individually Tested. CV steel, forged, oil-hardened.

Item

No. Inch lbs. pkg.

5/16 .16 1

11/32 .16 1

3/8 .16 1

7/16 .16 1

1/2 .16 1

9/16 .17 1

5/8 .19 1

11/16 .19 1

3/4 .21 1

13/16 .23 1

7/8 .27 1

15/16 .35 1

1 .33 1

1-1/8 .44 1

1-1/4 .58 1

*Sockets must be used with insulated ratchets & extensions

1000Volt

Insulated 1/2” Drive Sockets - Insulation According to VDE,

DIN 7448 & CSA Specification, Up To 1000 Volt.

Item

No. mm lbs. pkg.

8.0 .15 1

9.0 .15 1

10.0 .16 1

11.0 .16 1

12.0 .16 1

13.0 .17 1

14.0 .17 1

15.0 .17 1

16.0 .19 1

17.0 .19 1

18.0 .20 1

19.0 .21 1

20.0 .25 1

21.0 .25 1

22.0 .28 1

23.0 .29 1

24.0 .30 1

26.0 .37 1

27.0 .41 1

28.0 .44 1

30.0 .51 1

32.0 .55 1

1000Volt

Individually Tested

Each tool individually tested to 10,000 volts &

certified to 1000 Volt ac or 1500 Volt dc

Wiha Insulated 1/2” Sockets & Sets

14

*Sockets must be used with insulated ratchets & extensions

Insulated 1/2” Drive Breaker Bar, IEC/EN 60900 & CSA

Chrome-Vanadium steel.

Item OAL OAL

No. Inch mm Inch lbs. pkg.

1/2” 250 9.8 1.04 1

1000Volt

WH317

WH31703

WH31704

WH31705

WH31707

WH31708

WH31809

WH31710

WH31712

WH31713

WH31714

WH31715

WH31716

WH31718

WH31720

WH31722

WH316

WH31608

WH31609

WH31610

WH31611

WH31612

WH31613

WH31614

WH31615

WH31616

WH31617

WH31618

WH31619

WH31620

WH31621

WH31622

WH31623

WH31624

WH31626

WH31627

WH31628

WH31630

WH31632

WH31790

WH31691

WH12326

15

Insulated 1/2” Drive Ratchet, IEC/EN 60900 & CSA

Chrome-Vanadium steel. Reversible.

Item OAL OAL

No. Inch mm Inch lbs. pkg.

1/2” 260 10.2 1.55 1

1000Volt

Insulated 1/2” Extension Bars, EN/IEC 60900 & CSA

Chrome-vanadium steel.

Item OAL OAL

No. Inch mm Inch lbs. pkg.

1/2” 125 4.9 .45 1

1/2” 250 9.8 .91 1

1000Volt

Wiha Insulated 1/2” Socket accessories

Insulated 1/2” Drive T-handle, With Insulated Handle

Insulation according to EN/IEC 60900 & CSA Specification, Up To

1000 Volt. Individually Tested. Blade VC steel, hardened.

Item OAL OAL

No. Inch mm Inch lbs. pkg.

1/2 200 7.9” .68 1

1000Volt

Cable Cutter, With Insulated Handle

Insulation According to EN/IEC 60900, ASTM F-1505 & CSA

Specification, Up To 1000 Volt. Individually Tested.

Blade alloyed tool steel. Induction hardened.

Item OAL OAL Capacity

No. mm Inch mm Inch lbs. pkg.

500 19.6 12 1/2” 3.0 1

1000Volt

Large Capacity Cable Cutter, With Insulated Handle

Insulation According to EN/IEC 60900, ASTM F-1505 & CSA

Specification, Up to 1000 Volt. Individually Tested.

Easy cutting blades, dropped forged, oil hardened. Cuts cable

diameters up to 50mm. Not to be used on steel rods.

Item OAL OAL Capacity

No. mm Inch mm Inch lbs. pkg.

800 31.5 50 2” 8.0 1

1000Volt

Wiha Insulated Cable Cutters

For cutting solid

aluminum & copper

conductors

For cutting multi strand aluminum & copper cables

Waterpump Pliers, With Insulated Handle

Insulation According to EN/IEC 60900, DIN ISO 8976, ASTM F-1505

& CSA Specification, Up To 1000 Volt. Individually Tested.

Box joint. Chrome-vanadium steel, drop forged, oil hardened.

Item OAL OAL Capacity

No. mm Inch mm lbs. pkg.

240 9.5 7/8” 1.1 1

1000Volt

31.5”

Hacksaw, With Insulated Handle

Insulation According to EN/IEC 60900, DIN ISO 8976, ASTM F-1505

& CSA Specification, Up To 1000 Volt. Individually Tested.

Item OAL OAL

No. mm Inch lbs. pkg.

457mm 18.0” 1.92 1

1000Volt End Cutters, With Insulated Handle. Insulation According

to EN/IEC 60900, DIN ISO 8976, ASTM F-1505 & CSA Specification.

Individually Tested. Blade alloyed tool steel. Induction hardened.

Item OAL OAL Capacity

No. mm Inch mm lbs. pkg.

250 10 7/8” 1.1 1

1000Volt

For cutting

solid aluminum,

copper & medium

hard wires

Uses standard

12” blade

Waterpump Pliers, With Insulated Handle

Insulation According to EN/IEC 60900, DIN ISO 8976, ASTM F-1505

& CSA Specification, Up To 1000 Volt. Individually Tested.

Chrome-vanadium steel, drop forged, oil hardened.

Item OAL OAL

No. mm Inch lbs. pkg.

250 10.0” 1.2 1

300 12.0” 1.8 1

1000Volt

NEW

From Wiha

15

WH12853

WH128

WH12858

WH12859

WH29012

WH19767

WH11950

WH40800

WH29240

WH29250

WH116

WH11625

WH11630

16

Insulated Serrated Straight Fine Tip Tweezers,

IEC/EN 60900 & CSA Standards, 10,000 Volt Tested

Item OAL OAL

No. mm Inch lbs. pkg.

130 5.0 .06 1

1000Volt

Insulated Serrated Straight Blunt Tip Tweezers,

IEC/EN 60900 & CSA Standards, 10,000 Volt Tested

Item OAL OAL

No. mm Inch lbs. pkg.

130 5.0 .08 1

1000Volt

Insulated Serrated Straight Blunt Tip Tweezers,

IEC/EN 60900 & CSA Standards, 10,000 Volt Tested

Item OAL OAL

No. mm Inch lbs. pkg.

145 6.0 .10 1

1000Volt

Insulated Serrated Straight Blunt Tip Tweezers,

IEC/EN 60900 & CSA Standards, 10,000 Volt Tested

Item OAL OAL

No. mm Inch lbs. pkg.

200 8.0 .18 1

1000Volt

Insulated Serrated Angled Fine Tip Tweezers,

IEC/EN 60900 & CSA Standards, 10,000 Volt Tested

Item OAL OAL

No. mm Inch lbs. pkg.

145 6.0 .08 1

1000Volt

Insulated Serrated Angled Blunt Tip Tweezers,

IEC/EN 60900 & CSA Standards, 10,000 Volt Tested

Item OAL OAL

No. mm Inch lbs. pkg.

200 8.0 .16 1

1000Volt

NEW

From Wiha

NEW

From Wiha

NEW

From Wiha

NEW

From Wiha

NEW

From Wiha

NEW

From Wiha

Wiha Insulated Serrated Tweezers

Meets EN/IEC Insulation Standards

1000V

10,000Volts tested 1000Volts rated

Slip guards at tips

for user safety

Two layer high contrast

insulated coatings

Carbon steel with

chrome nickel plated

Use & Care Guide For Insulated Tools:

Store tools to minimize risk of damage to insulation, always wear

approved eye protection, Inspect insulation prior to each use of any

insulated tool. Use insulated tools where the ambient temperature

is between -20 to +70O C. Have a qualified safety technician visually

inspect insulation on tools annually for safe use.

WARNING!

Insulated Tools are intended to provide protection against accidental

contact with charged energized circuits. For maximum safety we

recommend de-energizing all circuits whenever possible before starting

work on electrical apparatus or conductors. Always visually inspect

insulation on tools before use, do not use tools if insulation shows signs

of wear or damage to the insulated areas of the tool. Wear appropriate

eye protection when using hand tools. Use NFPA70E certified insulated

protective outer wear when appropriate.

WH75205

WH75210

WH75215

WH75220

WH75302

WH75304

17

Inch T-handle, With Wiha-Molded Handle. Insulation

According to ASTM F-1505-01, New VDE Specification 0682/part 201

and EN/IEC 60900, NFPA70E & CSA, up to 1000Volt. Individually

Tested. Blade CVM steel, hardened. Insulation molded directly onto

blade. Wiha-SoftFinish® handle, multi-component.

Item

No. Inch Inch Inch mm lbs. pkg.

5/32 5.9 6.9 176 .09 10

3/16 5.9 6.9 176 .15 10

7/32 5.9 6.9 176 .19 10

1/4 5.9 7.1 176 .20 10

5/16 5.9 7.1 176 .26 10

3/8 5.9 7.1 176 .44 10

Wiha Insulated T-handles

1000Volt

Metric T-handle, With Wiha-Molded Handle. Insulation

According to ASTM F-1505-01, New VDE Specification 0682/part 201

and EN/IEC 60900, NFPA70E & CSA, up to 1000Volt. Individually

Tested. Blade CVM steel, hardened. Insulation molded directly onto

blade. Wiha-SoftFinish® handle, multi-component.

Item

No. mm mm Inch mm Inch lbs. pkg.

4.0 150 5.9 176 6.9 .09 10

5.0 150 5.9 182 7.1 .15 10

6.0 150 5.9 182 7.1 .18 10

8.0 150 5.9 182 7.1 .26 10

6 Piece Inch T-handle Hex Set

Item

No. Inch mm Inch mm lbs.

5/32 6.9 1/4 7.1 1.66

3/16 6.9 5/16 7.1

7/32 6.9 3/8 7.1

4 Piece Metric T-handle Hex Set

Item

No. mm mm mm mm .99 lbs.

4.0 6.9 6.0 7.1

5.0 7.1 8.0 7.1

1000Volt

Blade

CVM tool steel, hardened

to average 58/60RC

Responds to OSHA’s use

specification 29 CFR1910

Insulation

Molded directly onto blade

for permanent bonding

Insulation Test Standards:

Insulation according to EN/IEC 60900,

ASTM F-1505-01, VDE 0682/part 201,

DIN 7437, NFPA70E & CSA specification

Each tool individually

tested to 10,000 volts

and rated to 1000 Volt

ac or 1500 Volt dc

1000V

1000Volt

17

WH334

WH33481

WH33482

WH33483

WH33485

WH33486

WH33487

WH334

WH33441

WH33443

WH33445

WH33447

WH33490

WH33490 WH33481

WH33482

WH33483

WH33485

WH33486

WH33487

WH33491

WH33491 WH33441

WH33443

WH33445

WH33447

18

Insulated TorqueVario-S, With Window Scale Insulation

up to 1000 Volt. EN/IEC 60900 EN ISO 6798, BS EN 26789,

ASME B107.14M &CSA, +/- 6% Accuracy. Ergonomic multi-component

handle, light & compact. Handle sizes proportioned to optimize torque

range. Audible & perceptible click when torque setting has been attained.

Item Range

No. Inch lbs. Increments mm lbs. pkg.

7.5 - 20 .5 Inch lbs 126 - 131 .43 1

10 - 50 2 Inch lbs 133 - 138 .40 1

20 - 70 2 Inch lbs 137 - 142 .69 1

Each TorqueVario handle has unique serial number & certificate of calibration

Wiha Insulated TorqueControl Tools

Includes Certificate

Wiha Multi-Bit Screwdrivers

Multi-Bit Screwdriver Sets with Wiha Powerhandle,

cellulose-acetate, impact resistant. Snap-lock rotatable cap.

Chambered bit holder equipped with transparent selector and 6 bits.

1/4” Bit holder, stainless steel. Shaft chrome-vanadium-molybdenum

steel, hardened, chrome-plated. Packaged in clear blister package.

Blade Length = 120mm (4.7”) Overall Length = 230mm (9”)

Six Tools in One!

Slotted/Phillips Multi-Bit Screwdriver

With Wiha Powerhandle

and insulated shaft.

Set includes the following 1/4” bits:

Slotted Sizes: 5.5, 6.5mm lbs.

Phillips Sizes: 0, 1, 2, 3 .39

Slotted/Phillips/Square Multi-Bit Screwdriver

With Wiha Powerhandle and insulated shaft

.

Set includes the following 1/4” bits:

Slotted Sizes: 6.5, 8.0mm lbs.

Phillips Sizes: 1, 2 .41

Square Sizes: 1, 2

Insulated Bit Holder

Insulation meets EN/IEC 60900

Tested to

10,000 Volts

1000Volt

Magnetic Bit Holder, 1/4” Wiha Powerhandle and insulated

shaft

. Holder only can hold up to 6 bits.

lbs. .26

Wiha Insulated TorqueControl & SlimLine Tool Sets

Insulated SlimLine Torque Blade Holder

Chrome-vanadium-molybdenum steel. Through hardened black finish.

ClicFix quick release holder securely locks bits.

Item OAL OAL

No. mm mm Inch lbs. pkg.

6.0 170 6.7 .02 1

1000Volt

8 Piece Insulated TorqueControl Set With Slotted &

Phillips SlimLine Blades Certified to EN ISO 6798, BS EN 26789,

ASME B107.14M. Set includes Insulated multi-component adjustable

TorqueVario-S handle, 5 SlimLine blades, SlimLine blade holder &

Torque adjustment tool.

Item No. lbs.

SlimLine Slotted: 3.0, 4.0, 5.5mm .87

SlimLine Phillips: #1, #2

28726 - Handle Range 10-50 Inch/lbs.

SlimLine Blade Holder

With Certificate of Calibration

16 Piece Insulated TorqueControl Set With SlimLine Blades

Certified to EN ISO 6798, BS EN 26789, ASME B107.14M. Set includes

Insulated multi-component adjustable TorqueVario-S handle,

13 SlimLine blades, SlimLine blade holder & Torque adjustment tool.

Item No. lbs.

SlimLine Slotted: 4.0, 5.5, 6.5mm 1.27

SlimLine Phillips: #1, 2

SlimLine Terminal Xeno: #1, 2

SlimLine : T8, T10, T15, T20

SlimLine Square: #1, 2

28727 - Handle Range 20-70 Inch/lbs.

SlimLine Blade Holder

With Certificate of Calibration

1000Volt

Includes SlimLine blade holder

Item Range

No. Nm mm lbs. pkg.

0.6 - 2.0 131 .45 1

1.0 - 5.0 138 .45 1

2.0 - 8.0 142 .72 1

Insulated TorqueVario-S Handle - In Newton Meter Scale

WH380 Sets

WH28724

WH28726

WH28727

WH38006

WH38007

WH38025

WH287

WH28734

WH28736

WH28737

WH28350

WH28791

WH28792

WH

19

Wiha Insulated SlimLine Tools

Insulation Test Standards:

Insulation according to EN/IEC 60900,

ASTM F-1505-01, VDE 0682/part 201,

DIN 7437, NFPA70E & CSA specification

Wiha SlimTECHNOLOGY

Achieves blade

diameters up to 33%

narrower utilizing

integrated insulation

Ideal for jobs

where access

is limited

Integrated Slim

Insulation molded

directly onto blade

High quality chrome

vanadium steel,

through-hardened

1000Volt Rated

Insulated Slotted SlimLine Blades

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Item Slim Working

No. mm Inch Inch mm Dia. Length lbs. Pkg.

3.0 .118 1/8 90 4.1 2.8” .02 1

4.0 .157 5/32 90 4.1 2.8” .02 1

5.5 .216 7/32 90 6.1 2.8” .02 1

6.5 .255 1/4 90 6.1 2.8” .02 1

Insulated Phillips SlimLine Blades

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Item Slim Working

No. Size mm Dia. Length lbs. Pkg.

1 90 4.1 2.8” .02 1

2 90 6.1 2.8” .02 1

SlimLine Blade Holder, With Wiha-SoftFinish® Handle

Insulation According to VDE, ASTM F-1505-01 and EN/IEC 60900,

NFPA70E & CSA, up to 1000 Volt.

Chrome-vanadium steel, through-hardened. Insulation molded

directly onto blade. Quick release holder securely lock blades.

Wiha-SoftFinish® handle, multi-component, cushion grip.

Item

No. Size mm Inch mm Inch lbs. pkg.

1/4” 50 2.0 160 6.3 .15 1

1000Volt

Insulation does

not exceed screw

head diameter

10,000Volt Tested

Wiha Insulated SlimLine BladesWiha Insulated SlimLine Handle

1.8”

33%

narrower

insulation

diameter Slim

Diameter

19

WH28301

WH283

WH28308

WH28309

WH28312

WH28315

WH283

WH28317

WH28319

20

Insulated Xeno Slotted & Phillips SlimLine Blades

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Item Slim Working

No. Size mm Dia. Length lbs. Pkg.

1 90 4.1 2.8” .02 1

2 90 6.1 2.8” .02 1

Insulated SlimLine Blades

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Item Slim Working

No. Size mm Dia. Length lbs. Pkg.

T8 90 4.1 2.8” .02 1

T10 90 4.1 2.8” .02 1

T15 90 6.1 2.8” .02 1

T20 90 6.1 2.8” .02 1

Insulated Square SlimLine Blades

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Item Slim Working

No. Size mm Dia. Length lbs. Pkg.

1 90 4.1 2.8” .02 1

2 90 6.1 2.8” .02 1

Wiha Insulated SlimLine Blades Wiha Insulated SlimLine Blade Sets

1000Volt

8 Piece Insulated SlimLine Blade Set

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Cushion grip handle with quick release holder to securely

lock blades. In roll up pouch

Item No. lbs.

Slotted: 4.0, 6.5 x 90mm .45

Phillips: #1, #2 x 90mm

Xeno: #2 x 90mm

: T15, T20 x 90mm

28301 - SlimLine Cushion Grip Blade Holder

15 Piece Insulated SlimLine Blade Set

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Cushion grip handle with quick release holder to securely

lock blades. In roll up pouch

Item No. lbs.

Slotted: 3.0, 4.0, 5.5, 6.5 x 90mm .56

Phillips: #1, #2 x 90mm

Xeno: #1, #2 x 90mm

: T8, T10, T15, T20 x 90mm

Square: #1, #2 x 90mm

28301 - SlimLine Cushion Grip Blade Holder

1.8”

WH283

WH28327

WH28329

WH283

WH28339

WH28340

WH28341

WH28342

WH283

WH28346

WH28347

WH28391

WH28390

WH

21

Wiha Insulated SlimLine Screwdrivers

Insulation Test Standards:

Insulation according to EN/IEC 60900,

ASTM F-1505-01, VDE 0682/part 201,

DIN 7437, NFPA70E & CSA specification

Ideal for jobs

where access

is limited

Insulated Slotted SlimLine Screwdrivers

Insulation According to ASTM F-1505-01, New VDE Specification

0682/part 201 and EN/IEC 60900, NFPA70E & CSA, up to

1000 Volt. Individually Tested to 10,000Volts.

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Wiha-SoftFinish® handle, multi-component, cushion grip.

Item Slim

No. mm Inch Inch Dia. mm mm lbs. Pkg.

3.5 .139 9/64 3.5 100 204 .07 1

4.0 .157 5/32 4.0 100 211 .12 1

4.5 .177 3/16 4.5 125 211 .14 1

5.5 .216 7/32 5.5 125 243 .21 1

6.5 .255 1/4 6.5 150 268 .25 1

Insulated Phillips SlimLine Screwdrivers

Insulation According to ASTM F-1505-01, New VDE Specification

0682/part 201 and EN/IEC 60900, NFPA70E & CSA, up to

1000 Volt. Individually Tested to 10,000Volts.

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Wiha-SoftFinish® handle, multi-component, cushion grip.

Item Slim

No. Size Dia. mm mm lbs. Pkg.

1 4.5 80 204 .12 1

2 6.0 100 211 .21 1

Insulated Xeno SlimLine Screwdrivers For Terminal Screws

Insulation According to ASTM F-1505-01, New VDE Specification

0682/part 201 and EN/IEC 60900, NFPA70E & CSA, up to

1000 Volt. Individually Tested to 10,000Volts.

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Wiha-SoftFinish® handle, multi-component, cushion grip.

Item Slim

No. Size Dia. mm mm lbs. Pkg.

1 4.5 80 191 .12 1

2 6.0 100 218 .21 1

Insulated Square SlimLine Screwdrivers

Insulation According to ASTM F-1505-01, New VDE Specification

0682/part 201 and EN/IEC 60900, NFPA70E & CSA, up to

1000 Volt. Individually Tested to 10,000Volts.

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Wiha-SoftFinish® handle, multi-component, cushion grip.

Item Slim

No. Size Dia. mm mm lbs. Pkg.

1 4.0 100 218 .12 1

2 4.5 125 243 .19 1

Integrated Slim

Insulation molded

directly onto blade

Wiha SlimTECHNOLOGY

Achieves blade

diameters up to 33%

narrower utilizing

integrated insulation

1000Volt Rated

10,000Volt Tested

1.4”

1.4” 1.4”

21

WH320

WH32046

WH32049

WH32052

WH32055

WH32058

WH321

WH32145

WH32146

WH307

WH30746

WH30747

WH358

WH35844

WH35845

22

Wiha Insulated SlimLine Screwdriver Sets

6 Piece Insulated SlimLine Slotted, Phillips & Square

Screwdrivers. Insulation According to ASTM F-1505-01, New VDE

Specification 0682/part 201 and EN/IEC 60900, NFPA70E & CSA,

up to 1000 Volt. Individually Tested to 10,000Volts.

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Wiha-SoftFinish® handle, multi-component, cushion grip.

Item

No. Size mm mm mm lbs.

1.02

Phillips 1 80

Phillips 2 100

Square 1 100

Square 2 125

Slotted 4.5 125

Slotted 6.5 150

1000Volt

11 Piece Insulated SlimLine Slotted, Phillips, Xeno & Square

Screwdrivers. Insulation According to ASTM F-1505-01, New VDE

Specification 0682/part 201 and EN/IEC 60900, NFPA70E & CSA,

up to 1000 Volt. Individually Tested to 10,000Volts.

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Wiha-SoftFinish® handle, multi-component, cushion grip.

Item

No. Size mm mm mm lbs.

1.75

Phillips 1 80

Phillips 2 100

Square 1 100

Square 2 125

Pozidriv 1 80

Pozidriv 2 100

Slotted 3.5 100

Slotted 4.0 100

Slotted 4.5 125

Slotted 5.5 125

Slotted 6.5 150

1000Volt

Wiha Slim

TECHNOLOGY

Achieves blade

diameters up to

33% narrower

utilizing Wiha

integrated

insulation

8 Piece Insulated SlimLine Slotted, Phillips & Square

Screwdrivers. Insulation According to ASTM F-1505-01, New VDE

Specification 0682/part 201 and EN/IEC 60900, NFPA70E & CSA,

up to 1000 Volt. Individually Tested to 10,000Volts.

High quality CV steel, through hardened. SlimLine blades have up to

33% narrower insulation diameter then standard insulated tools.

Wiha-SoftFinish® handle, multi-component, cushion grip.

Item

No. Size mm mm mm lbs.

1.18

Phillips 1 80

Phillips 2 100

Square 1 100

Square 2 125

Slotted 3.5 100

Slotted 4.0 100

Slotted 4.5 125

Slotted 5.5 125

1000Volt

2 Piece Insulated SlimLine Slotted & Phillips Screwdrivers

Insulation According to ASTM F-1505-01, New VDE Specification

0682/part 201 and EN/IEC 60900, NFPA70E & CSA, up to 1000

Volt. Individually Tested to 10,000Volts. High quality CV steel,

through hardened. SlimLine blades have up to 33% narrower insulation

diameter then standard insulated tools.

Item

No. Size mm mm mm lbs.

2 100 4.5 125 .37

1000Volt

WH32198

WH32197

WH32196

WH32189

23

Blade

CVM tool steel, hardened

to average 58/60RC

Responds to OSHA’s use

specification 29 CFR1910

Insulation

Molded directly

onto the blade for

permanent bonding

SoftFinish® handle

solid molded core

with soft outer

cushion grip. 40%

more torque than

conventional handles

Phillips Screwdriver, With Wiha-SoftFinish® Handle

Insulation According to ASTM F-1505-01, New VDE Specification

0682/part 201 and EN/IEC 60900, NFPA70E & CSA, up to

1000 Volt. Individually Tested. Blade high alloy CVM steel,

hardened, black finish. Insulation molded directly onto blade.

Wiha-SoftFinish® handle, multi-component, cushion grip.

Item

No. Size mm Inch mm Inch lbs. pkg.

0 60 2.4 164 6.5 .06 10

1 80 3.0 191 7.5 .12 10

2 100 4.0 218 8.6 .20 10

3 150 6.0 268 10.6 .34 10

4 200 8.0 318 12.5 .39 10

Insulation Test Standards:

Insulation according to EN/IEC 60900,

ASTM F-1505-01, New VDE 0682/part 201,

DIN 7437, NFPA70E & CSA

Each tool individually tested to

10,000 volts and rated to 1000

Volt ac or 1500 Volt dc

1000V

Slotted Screwdriver, With Wiha-SoftFinish® Handle

Insulation According to ASTM F-1505-01, New VDE Specification

0682/part 201 and EN/IEC 60900, NFPA70E & CSA, up to

1000 Volt. Individually Tested.

Item

No. mm Inch Inch mm Inch mm Inch lbs. pkg.

2.0 .078 5/64 60 3.0 164 6.5 .05 10

2.5 .098 3/32 75 3.0 179 7.1 .06 10

3.0 .118 1/8 100 4.0 204 8.0 .07 10

3.5 .139 9/64 100 4.0 204 8.0 .07 10

4.0 .157 5/32 100 4.0 211 8.3 .12 10

4.5 .177 3/16 100 4.0 211 8.3 .12 10

4.5 .177 3/16 125 5.0 236 9.3 .12 10

4.5 .177 3/16 150 6.0 261 10.2 .14 10

4.5 .177 3/16 175 7.0 286 11.2 .13 10

4.5 .177 3/16 200 8.0 311 12.3 .15 10

5.5 .216 7/32 125 5.0 243 9.5 .15 10

5.5 .216 7/32 175 7.0 293 11.5 .21 10

6.0 .236 15/64 150 6.0 268 10.6 .21 10

6.5 .255 1/4 150 6.0 268 10.6 .21 10

8.0 .315 5/16 175 7.0 299 11.8 .34 10

10.0 .393 3/8 200 8.0 318 12.5 .39 10

4 Piece Slotted & Phillips Set

Item

No. mm mm mm Size mm .76 lbs.

Slotted 3.5 100 0.6 Phillips 1 80

Slotted 4.5 125 1.0 Phillips 2 100

5 Piece Slotted & Phillips Set

Item

No. mm mm mm Size mm lbs.

Slotted 3.0 100 0.6 Phillips 1 80 1.31

Slotted 4.5 125 1.0 Phillips 2 100

Slotted 6.5 150 1.2

32892

page 32

6 Piece Slotted & Phillips Set

Item

No. mm mm mm Size mm lbs.

Slotted 3.5 100 0.6 Phillips 1 80 1.31

Slotted 4.5 125 1.0 Phillips 2 100

Slotted 6.5 150 1.2 Phillips 3 150

Wiha Insulated Screwdrivers with SoftFinish® Cushion Grip Handle

1000Volt

23

WH320

WH32005

WH32010

WH32012

WH32015

WH32017

WH32023

WH32024

WH32027

WH32025

WH32028

WH32031

WH32026

WH32034

WH32039

WH32042

WH32045

WH32090

WH321

WH32100

WH32101

WH32102

WH32103

WH32104

WH32091

WH32092

WH

24

13 Piece Slotted & Phillips Set

Item No.

Slotted: 2.0, 2.5, 3.0, 3.5, 4.5, 5.5, 6.5, 8.0, 10.0mm lbs.

Phillips: 0, 1, 2, 3 2.3

Wiha Insulated Screwdriver Sets

15 Piece Slotted, Phillips & Inch Nut Drivers Set

Item No. lbs.

Slotted: 2.0, 2.5, 3.0, 3.5, 4.5, 6.5, 8.0mm 5.9

Phillips: 1, 2, 3

Nut Drivers Inch: 1/4, 5/16, 3/8, 7/16, 1/2”

1000Volt

10 Piece Slotted & Phillips Set

Item No.

Slotted: 2.0, 2.5, 3.0, 3.5, 4.5, 6.5 lbs.

Phillips: 0, 1, 2, 3 1.63

1000Volt

6 Piece Insulated Slotted, Phillips & Square Screwdrivers

Item No.

Slotted: 4.5 x 125mm, 6.5 x 150mm lbs.

Phillips: 1 x 80mm, 2 x 100mm .83

Square: 1 x 100mm, 2 x 150mm

Wiha Insulated Square Tip Screwdrivers

Square Tip Screwdriver, With Wiha-SoftFinish® Handle

Insulation According to ASTM F-1505-01, New VDE Specification

0682/part 201 and EN/IEC 60900, NFPA70E and CSA, up to

1000 Volt. Individually Tested. Blade high alloy CVM steel,

hardened, black finish. Insulation molded directly onto blade.

Item

No. Size mm Inch mm Inch lbs. pkg.

1 100 4.0 210 8.2 .12 10

2 150 6.0 268 10.5 .19 10

1000Volt

6 Piece Insulated Slotted, Phillips & Square Screwdrivers

Item No. lbs.

Slotted: 3.0, 5.5mm Phillips: 1, 2 Square: 1, 2 .83

Hex Metric Screwdriver, With Wiha-SoftFinish® Handle

Insulation According to ASTM F-1505-01, New VDE Specification

0682/part 201 and EN/IEC 60900, NFPA70E & CSA, up to

1000 Volt. Individually Tested. Blade high alloy CVM steel,

hardened, black finish. Insulation molded directly onto blade.

Wiha-SoftFinish® handle, multi-component, cushion grip.

Item

No. Size mm Inch mm Inch lbs. pkg.

2.5 75 3.0 179 7.0 .06 10

3.0 75 3.0 179 7.0 .08 10

4.0 75 3.0 186 7.3 .12 10

5.0 75 3.0 186 7.3 .15 10

6.0 100 3.9 218 8.6 .24 10

8.0 100 3.9 218 8.6 .34 10

6 Piece Insulated Hex Metric Screwdriver Set

Item No. lbs.

Hex Metric: 2.5, 3.0, 4.0, 5.0, 6.0, 8.0mm 1.06

Wiha Insulated Hex Mertic Screwdrivers

1000Volt

19 Piece Slotted, Phillips, Square, Xeno Screwdriver Set

Insulated Screwdriver set in a light weight tool box tray.

Item No.

Slotted: 2.5, 3.0, 3.5, 4.0, 4.5, 5.5, 6.0, 6.5, 8.0, 10.0mm

Phillips: #0, #1, #2, #3

Square: #1, #2

lbs. Xeno Terminal: #1, #2

4.92 Single Pole Voltage Detector 110V to 250V

1000Volt

Tool box set

in blow molded tray

NEW

From Wiha

WH32094

WH32093

WH32190

WH32095

WH323

WH32302

WH32303

WH32304

WH32305

WH32306

WH32308

WH32366

WH358

WH35811

WH35812

WH35890

WH35891

WH35890

25

7 Piece Nut Driver Set - Metric Sizes

Item

No. mm mm mm mm lbs.

5.0 125 8.0 125 2.05

5.5 125 10.0 125

6.0 125 13.0 125

7.0 125

7 Piece Nut Driver Set - Inch Sizes

Item

No. Inch Inch Inch Inch lbs.

3/16 5.0 3/8 5.0 2.24

7/32 5.0 7/16 5.0

1/4 5.0 1/2 5.0

5/16 5.0

5 Piece Nut Driver Set - Metric Sizes

Item

No. mm mm mm mm lbs.

6.0 125 9.0 125 1.36

7.0 125 10.0 125

8.0 125

5 Piece Nut Driver Set - Inch Sizes

Item

No. Inch Inch Inch Inch lbs.

7/32 5.0 3/8 5.0 1.52

1/4 5.0 1/2 5.0

5/16 5.0

Nut Driver, With Wiha-SoftFinish® Handle Insulation

According to ASTM F-1505-01, New VDE Specification 0682/part 201

and EN/IEC 60900, NFPA70E & CSA, up to 1000 Volt. Individually

Tested. Blade CVM steel, hardened. Insulation molded directly onto

blade. Deep drawn 1” socket. Wiha-SoftFinish® handle, multi-component.

Item

No. mm mm mm Inch lbs. pkg.

4.0 125 236 9.3 .15 10

5.0 125 236 9.3 .16 10

5.5 125 236 9.3 .16 10

6.0 125 236 9.3 .16 10

7.0 125 243 9.6 .25 10

8.0 125 243 9.6 .25 10

9.0 125 243 9.6 .25 10

10.0 125 243 9.6 .27 10

11.0 125 243 9.6 .37 10

12.0 125 243 9.6 .38 10

13.0 125 243 9.6 .39 10

Nut Driver, With Wiha-SoftFinish® Handle - Inch sizes.

Item

No. Inch Inch mm Inch lbs. pkg.

5/32 5.0 236 9.3 .15 10

3/16 5.0 236 9.3 .15 10

7/32 5.0 236 9.3 .16 10

1/4 5.0 243 9.5 .24 10

5/16 5.0 243 9.5 .25 10

11/32 5.0 242 9.5 .26 10

3/8 5.0 243 9.5 .26 10

7/16 5.0 243 9.5 .36 10

1/2 5.0 243 9.5 .39 10

9/16 5.0 243 9.5 .39 10

5/8 5.0 243 9.5 .41 10

Wiha Insulated Nut Drivers

1000Volt

11 Piece Nut Driver Set - Inch Sizes

Item

No. Inch Inch Inch Inch lbs.

32255 5/32 5.0 32270 3/8 5.0 3.00

32258 3/16 5.0 32273 7/16 5.0

32261 7/32 5.0 32276 1/2 5.0

32264 1/4 5.0 32276 9/16 5.0

32267 5/16 5.0 32280 5/8 5.0

32268 11/32 5.0

25

WH322

WH32206

WH32209

WH32212

WH32215

WH32218

WH32221

WH32224

WH32227

WH32230

WH32233

WH32236

WH322

WH32255

WH32258

WH32261

WH32264

WH32267

WH32268

WH32270

WH32273

WH32276

WH32278

WH32280

WH32296

WH32291

WH32293

WH32292

WH32294

26

Insulated Single-Pole Voltage Detector

Wiha Insulated Screwdrivers

Screwdriver, With Wiha-SoftFinish® Handle

Insulation According to ASTM F-1505-01, New VDE Specification

0682/part 201 and EN/IEC 60900, NFPA70E and CSA, up to

1000 Volt. Individually Tested. Blade high alloy cvm steel,

hardened, black finish. Insulation molded directly onto blade.

Item

No. Size mm Inch mm Inch lbs. pkg.

T5 60 2.4 164 6.5 .06 10

T6 60 2.4 164 6.5 .06 10

T7 60 2.4 164 6.5 .06 10

T8 60 2.4 164 6.5 .06 10

T9 60 2.4 164 6.5 .06 10

T10 60 2.4 164 6.5 .06 10

T15 80 3.0 191 7.5 .12 10

T20 80 3.0 191 7.5 .12 10

T25 80 3.0 198 7.8 .17 10

T27 100 4.0 218 8.6 .20 10

T30 100 4.0 218 8.6 .20 10

T40 150 6.0 274 10.8 .30 10

6 Piece Set

Item

No. Size mm Size mm lbs.

T8 60 T15 80 .83

T9 60 T20 80

T10 60 T25 80

1000Volt

10 Piece Set

Item

No. Size mm Size mm lbs.

T6 60 T15 80 1.2

T7 60 T20 80

T8 60 T25 80

T9 60 T27 100

T10 60 T30 100

1000Volt

Wiha Insulated Inch Nut Driver Set

9 Piece Nut Driver Set - Inch Sizes. In roll-up pouch

Item

No. Inch Inch Inch Inch lbs.

3/16 5.0 7/16 5.0 3.16

1/4 5.0 1/2 5.0

5/16 5.0 9/16 5.0

11/32 5.0 5/8 5.0

3/8 5.0

1000Volt

Combination Terminal Block Xeno Screwdriver, With Wiha

SoftFinish® Handle. Insulation According to ASTM F-1505-01,

VDE, 0682/part 201, EN/IEC 60900, NFPA70E & CSA specification.

Individually Tested. Blade CVM steel, hardened, black finish. Insulation

molded directly onto blade. Wiha-SoftFinish® handle, multi-component,

cushion grip. For combination Slotted/Phillips head terminal screws.

Item

No. Size mm mm Inch lbs. pkg.

1 80 191 7.5 1.23 10

2 100 218 8.6 1.23 10

Combination Slotted/Phillips

Terminal Block Drivers

Insulated Terminal Block Xeno Screwdrivers

Slotted

& Phillips

1000Volt

Insulated Single-Pole Voltage Detector. 110-250 Volts.

Insulation According To DIN 57860/6 And DIN VDE 0680-6,

GS Tested. Blade CVM steel, hardened, nickel-plated. Insulation

molded directly onto blade. Amber LED light. 10,000Volt tested.

Item

No. mm mm mm Inch lbs. pkg.

3.0 65 145 5.7 .04 1

1000Volt

WH32288

WH25511

WH325

WH32505

WH32511

WH32516

WH32521

WH32526

WH32531

WH32536

WH32541

WH32546

WH32551

WH32556

WH32561

WH32590

WH32592

WH307

WH30700

WH30701

27

Insulated BitFlip With Slotted/Phillips/Square Bits

Wiha cushion grip handle and insulated shaft. Tested to 10,000 volts.

Set includes the following 1/4” bits:

Slotted: 4.5, 6.5mm

Phillips: 0, 1, 2, 3 lbs.

Square: 1, 2 .45

8-in-1 Bit Sets

Tested to 10,000Volts

8-in-1 Bit Sets

Insulated BitFlip With Slotted/Phillips/TORX® Bits

Wiha cushion grip handle and insulated shaft. Tested to 10,000 volts.

Set includes the following 1/4” bits:

Slotted: 4.5, 6.5mm

Phillips: 1, 2 lbs.

TORX® : T10, T15, T20, T25 .45

Insulated BitFlip With Slotted/Phillips Bits

Wiha cushion grip handle and insulated shaft. Tested to 10,000 volts.

Set includes the following 1/4” bits:

Slotted: 4.5, 5.5, 6.5, 8.0mm lbs.

Phillips: 0, 1, 2, 3 .45

8-in-1 Bit Sets

Insulated

Retaining Ring Bit Holding Screwdriver, With Wiha-

SoftFinish® Handle Insulation According to VDE, ASTM F-1505-01

and EN/IEC 60900, NFPA70E & CSA, up to 1000 Volt.

Blade high alloy CVM steel, hardened, black finish. Insulation molded

directly onto blade. Wiha-SoftFinish® handle, multi-component.

Item

No. Size mm Inch mm Inch lbs. pkg.

1/4” 125 4.9 242 9.5 .06 10

1000Volt

Holds 1/4” drive bits

Wiha Insulated Retaining Ring Bit Holder

Wiha Insulated “BitFlip” Sets

“8-In-1 Bit Sets”

Each insulated

tool individually

tested to

10,000 volts

BitFlip standard SoftFinish®

handle, multi-component,

cushion grip, easy access

& 8 bit storage

Blade CVM tool

steel, hardened

WARNING!

Insulated Tools are intended to provide protection against accidental

contact with charged energized circuits. For maximum safety we

recommend de-energizing all circuits whenever possible before starting

work on electrical apparatus or conductors. Always visually inspect

insulation on tools before use, do not use tools if insulation shows signs

of wear or damage to the insulated areas of the tool. Wear appropriate

eye protection when using hand tools. Use NFPA70E certified insulated

protective outer wear when appropriate.

27

WH32650

WH38016

WH38017

WH38018

WH32650

28

3 Piece Insulated Pliers/Cutters & Multi-Bit Set In Belt

Pack Pouch Tools meet EN/IEC, ASTM, VDE, NFPA70E & CSA

standards. Pliers chrome finish for long lasting corrosion protection.

Soft grip ergo designed handle body, safety slip guard. Insulated

multi-bit screwdriver includes Slotted, Phillips & Square bits.

Item No. Pliers/Cutters & Multi-Bit Set

6.3” / 160mm Diagonal Cutters

8.0” / 200mm Long Nose Pliers

Set includes Bit Holder and the following bits:

Slotted: 4.5, 6.5mm • Phillips: 1, 2 • Square: 1, 2

lbs. 1.67

1000Volt

5 Piece Insulated Pliers/Cutters & Screwdrivers In Belt

Pack Pouch Tools meet EN/IEC, ASTM, VDE, NFPA70E & CSA

standards. Pliers chrome finish for long lasting corrosion protection.

Soft grip ergo designed handle body, safety slip guard. Insulated

cushion grip drivers, multi-component. Blade CVM tool steel, hardened.

Item No. Insulated Pliers/Cutters & Screwdrivers

6.3” / 160mm Diagonal Cutters

8.0” / 200mm Long Nose Pliers

Insulated Screwdrivers:

Slotted: 3.0, 4.5mm • Phillips: 2

lbs. 1.77

3 Piece Insulated Pliers/Cutters In Belt Pack Pouch

Tools meet EN/IEC, ASTM, VDE, NFPA70E & CSA standards.

Pliers chrome finish for long lasting corrosion protection.

Soft grip ergo designed handle body, safety slip guard.

Item No. Insulated Pliers & Cutters

6.3” / 160mm Diagonal Cutters

8.0” / 200mm Long Nose Pliers

8.0” / 200mm Combination Pliers

lbs. 2.07

1000Volt

Wiha Insulated Belt Pack Pouch Sets

Insulation Test Standards:

Insulation according to EN/IEC 60900,

ASTM F-1505-01, New VDE 0682/part 201,

DIN 7437, NFPA70E & CSA

5 Piece Insulated Pliers/Cutters & Screwdrivers In Belt

Pack Pouch Tools meet EN/IEC, ASTM, VDE, NFPA70E & CSA

standards. Pliers chrome finish for long lasting corrosion protection.

Soft grip ergo designed handle body, safety slip guard. Insulated

cushion grip drivers, multi-component. Blade CVM tool steel, hardened.

Item No. Insulated Pliers/Cutters & Screwdrivers

9.0” / 225mm Lineman’s Pliers

8.0” / 200mm Long Nose Pliers

Insulated Screwdrivers:

Slotted: 4.5, 6.5mm • Phillips: 1

lbs. 2.26

1000Volt

NEW

From Wiha

WH32873

WH32872

WH32871

WH32875

29

WARNING!

Insulated Tools are intended to provide protection against accidental

contact with charged energized circuits. For maximum safety we

recommend de-energizing all circuits whenever possible before starting

work on electrical apparatus or conductors. Always visually inspect

insulation on tools before use, do not use tools if insulation shows signs

of wear or damage to the insulated areas of the tool. Wear appropriate

eye protection when using hand tools. Use NFPA70E certified insulated

protective outer wear when appropriate.

Use & Care Guide For Insulated Tools:

Store tools to minimize risk of damage to insulation, always wear

approved eye protection, Inspect insulation prior to each use of any

insulated tool. Use insulated tools where the ambient temperature

is between -20 to +70O C. Have a qualified safety technician visually

inspect insulation on tools annually for safe use.

80 Piece Insulated Master Electrician’s Tool Set In Rolling Water Tight Traveling Tool Box - 10,000Volt Tested, 1000Volt Rated

Item# Set Includes: lbs. 33.9

6.3” Long Nose Pliers 6.3” Diagonal Cutters

8.0” Long Nose Pliers 8.0” High Leverage Cutters

6.3” Bent Nose Pliers 6.3” Cable Cutters

6.3” Long Flat Nose Pliers 6.3” Stripping Pliers

9.0” Combo Pliers/Crimpers 8.0” Adjustable Wrench

1000Volt

Insulated Slotted 2.5mm

Insulated Slotted 3.0mm

Insulated Slotted 3.5mm

Insulated Slotted 4.0mm

Insulated Slotted 4.5mm

Insulated Slotted 5.5mm

Insulated Slotted 6.0mm

Insulated Slotted 6.5mm

Insulated Slotted 8.0mm

Insulated Slotted 10.0mm

Insulated Phillips #0

Insulated Phillips #1

Insulated Phillips #2

Insulated Phillips #3

Insulated Nut Driver 7/32”

Insulated Nut Driver 1/4”

Insulated Nut Driver 5/16”

Insulated Nut Driver 3/8”

Insulated Nut Driver 7/16” Insulated T-handle Hex 5/32”

Insulated T-handle Hex 3/16”

Insulated T-handle Hex 7/32”

Insulated T-handle Hex 1/4”

Insulated T-handle Hex 5/16”

Insulated T-handle Hex 3/8”

Insulated Torx T6

Insulated Torx T7

Insulated Torx T8

Insulated Torx T9

Insulated Torx T10

Insulated Torx T15

Insulated Torx T20

Insulated Torx T25

Insulated Torx T30

Insulated Square #1

Insulated Square #2

Insulated Slt/Ph Terminal #1

Insulated Slt/Ph Terminal #2

Insulated Cable Knife 50mm

2 Meter Ruler In/MM

Insulated Nut Driver 5.0mm

Insulated Nut Driver 5.5mm

Insulated Nut Driver 6.0mm

Insulated Nut Driver 7.0mm

Insulated Nut Driver 8.0mm

Insulated Nut Driver 10.0mm

Insulated Nut Driver 13.0mm

Insulated T-handle Hex 4.0mm

Insulated T-handle Hex 5.0mm

Insulated T-handle Hex 6.0mm

Insulated T-handle Hex 8.0mm

Insulated Socket 1/2”

Insulated Socket 9/16”

Insulated Socket 5/8”

Insulated Socket 11/16”

Insulated Socket 3/4”

Insulated Socket 13/16”

Insulated Socket 7/8”

Insulated Socket 13mm

Insulated Socket 14mm

Insulated Socket 15mm

Insulated Socket 17mm

Insulated Socket 19mm

Insulated Socket 20mm

Insulated Socket 22mm

Insulated Ratchet 3/8” Drive

Insulated 4.9” Extension 3/8” Dr.

Insulated L-key 10mm

Insulated L-key 1/2”

Single Pole Voltage Detector-

110V to 250V

NEW

From Wiha

All Tools In

Dedicated

Positions For

Quick Storage

& Easy Location

Tracking

Wiha Insulated Tools-Comfort Grip Handles

29

WH32800

30

80 Piece Insulated Master Electrician’s Set

Item# Set Includes: lbs. 27.0

6.3” Long Nose Pliers 6.3” Diagonal Cutters

6.3” Bent Nose Pliers 8.0” High Leverage Cutters

8.0” Long Nose Pliers 8.0” Cable Cutters

6.3” Long Flat Nose Pliers 6.3” Stripping Pliers

9.0” Combo Pliers/Crimpers 8.0” Adjustable Wrench

1000Volt

Insulated Slotted 2.0mm

Insulated Slotted 2.5mm

Insulated Slotted 3.0mm

Insulated Slotted 3.5mm

Insulated Slotted 4.0mm

Insulated Slotted 4.5mm

Insulated Slotted 5.5mm

Insulated Slotted 6.0mm

Insulated Slotted 6.5mm

Insulated Slotted 8.0mm

Insulated Slotted 10.0mm

Insulated Phillips #0

Insulated Phillips #1

Insulated Phillips #2

Insulated Phillips #3

Insulated Nut Driver 7/32”

Insulated Nut Driver 1/4”

Insulated Nut Driver 5/16”

Insulated Nut Driver 3/8”

Insulated Nut Driver 7/16”

Insulated T-handle Hex 5/32”

Insulated T-handle Hex 3/16”

Insulated T-handle Hex 7/32”

Insulated T-handle Hex 1/4”

Insulated T-handle Hex 5/16”

Insulated T-handle Hex 3/8”

Insulated Torx T6

Insulated Torx T7

Insulated Torx T8

Insulated Torx T9

Insulated Torx T10

Insulated Torx T15

Insulated Torx T20

Insulated Torx T25

Insulated Torx T30

Insulated Square #1

Insulated Square #2

Insulated Slt/Ph Terminal #1

Insulated Slt/Ph Terminal #2

Insulated Cable Knife 50mm

2 Meter Ruler In/MM

Insulated Nut Driver 5.0mm

Insulated Nut Driver 5.5mm

Insulated Nut Driver 6.0mm

Insulated Nut Driver 7.0mm

Insulated Nut Driver 8.0mm

Insulated Nut Driver 10.0mm

Insulated Nut Driver 13.0mm

Insulated T-handle Hex 4.0mm

Insulated T-handle Hex 5.0mm

Insulated T-handle Hex 6.0mm

Insulated T-handle Hex 8.0mm

Insulated Socket 1/2”

Insulated Socket 9/16”

Insulated Socket 5/8”

Insulated Socket 11/16”

Insulated Socket 3/4”

Insulated Socket 13/16”

Insulated Socket 7/8”

Insulated Socket 13mm

Insulated Socket 14mm

Insulated Socket 15mm

Insulated Socket 17mm

Insulated Socket 19mm

Insulated Socket 20mm

Insulated Socket 22mm

Insulated Ratchet 3/8” Dr.

Insulated 4.9” Extension

Insulated L-key 10mm

Insulated L-key 1/2”

80 Pc.

BIGGEST

SET

Wiha 1000Volt Insulated Tool Sets - Comfort Grip Handles

66 Pc. Master Electrician’s Insulated Set

Item# Set Includes: lbs. 21.5

8.0” Long Nose 6.3” Side Cutters

6.3” Long Flat Nose 8.0” High Leverage Cutters

9.0” Combo Pliers/Crimpers 6.3” Stripping Pliers

8.0” Cable Cutters 8.0” Adjustable Wrench

Insulated Nut Driver 1/4” Insulated Slotted 2.0mm

Insulated Nut Driver 5/16” Insulated Slotted 2.5mm

Insulated Nut Driver 11/32” Insulated Slotted 3.0mm

Insulated Nut Driver 3/8” Insulated Slotted 4.0mm

Insulated Nut Driver 7/16” Insulated Slotted 4.5mm

Insulated T-handle Hex 4.0mm Insulated Slotted 5.5mm

Insulated T-handle Hex 5.0mm Insulated Slotted 6.0mm

Insulated T-handle Hex 6.0mm Insulated Slotted 8.0mm

Insulated T-handle Hex 8.0mm Insulated Slotted 10.0mm

Insulated T-handle Hex 5/32” Insulated Phillips #0

Insulated T-handle Hex 3/16” Insulated Phillips #1

Insulated T-handle Hex 7/32” Insulated Phillips #2

Insulated T-handle Hex 1/4” Insulated Phillips #3

Insulated T-handle Hex 5/16” Insulated Torx T8

Insulated T-handle Hex 3/8” Insulated Torx T10

Insulated Hex L-key 10.0mm Insulated Torx T15

Insulated Hex L-key 1/2” Insulated Torx T20

Insulated Socket 1/2” Insulated Torx T25

Insulated Socket 9/16” Insulated Torx T30

Insulated Socket 5/8” Insulated Square #1

Insulated Socket 11/16” Insulated Square #2

Insulated Socket 3/4” Insulated Slt/Ph Terminal #1x80

Insulated Socket 13/16” Insulated Slt/Ph Terminal #2x100

Insulated Socket 7/8” Insulated Cable Knife 50mm

Insulated Socket 8.0mm Insulated Extension 4.9”

Insulated Socket 10.0mm Insulated Ratchet 3/8” Driver

Insulated Socket 13.0mm Insulated Socket 17.0mm

Insulated Socket 14.0mm Insulated Socket 19.0mm

Insulated Socket 15.0mm Insulated Socket 22.0mm

66 Pc. Master Electrician’s Set. Insulation According to

VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E & CSA,

up to 1000 volt. Individually Tested. Pliers drop-forged from special

tool steel, individually high frequency induction hardened, chrome/nickel

plated, mirror-polished.

1000Volt

Master Electrician’s Set

66 Pc.

BIGGER

SET

WH32877

WH32876

WH32877

WH32876

31

Wiha 1000Volt Insulated Tool Sets - Comfort Grip Handles

31 Pc. Master Electrician’s Insulated Set. In Tool Box

Item# Set Includes: lbs. 12.85

6.3” Long Nose Pliers 6.3” Side Cutters

8.0” Long Nose Pliers 8.0” High Leverage Cutters

7.0” Linemans Pliers 6.3” Stripping Pliers

9.0” Combination Pliers 6.3” Round Nose Pliers

Slotted: 2.0, 2.5, 3.0, 3.5, 4.5, 5.5, 6.5, 8.0, 10.0mm

Phillips: #0, #1, #2, #3

Inch Nut Driver: 5/32, 3/16, 7/32, 1/4, 5/16, 3/8, 7/16, 1/2, 9/16”

31 Piece Pliers & Screwdriver Set. Insulation According to

VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E & CSA,

up to 1000 volt. Individually Tested. Pliers drop-forged from special

tool steel, individually high frequency induction hardened, chrome/nickel

plated, mirror-polished. Set includes 6ft. Fiber glass folding ruler.

1000Volt

31 Pc.

Set

25 Piece Master Electrician’s Insulated Set

Item# Set Includes: lbs. 11.92

8.0” Long Nose 6.3” Stripping Pliers

9.0” Combination Pliers Inch & Metric Folding Ruler

8.0” High Leverage Cutters 8.5” Insulated Knife

Slotted: 3.0, 4.5, 6.0mm Phillips: #1, #2

Square: #1, #2 Terminal Block Driver: #1, #2

Inch Nut Driver: 1/4, 5/16, 11/32, 3/8, 7/16, 1/2”

Metric Nut Driver: 7.0, 8.0, 10.0, 13.0mm

25 Piece Pliers & Screwdriver Set. Insulation According to

VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E &

CSA, up to 1000 volt. Individually Tested.

Pliers drop-forged from special tool steel, individually high frequency

induction hardened, chrome/nickel plated, mirror-polished. In tool box.

1000Volt

25 Pc.

Set

48 Piece Insulated Tool Set

Item# Set Includes: lbs. 19.4

6.3” Long Nose Pliers 6.3” Side Cutters

8.0” Long Nose Pliers 8.0” High Leverage Cutters

6.3” Combination Pliers 6.3” Stripping Pliers

9.0” Combo Pliers/Crimpers 8.0” Adjustable Wrench

Insulated Nut Driver 7/32” Insulated Slotted 2.0mm

Insulated Nut Driver 1/4” Insulated Slotted 2.5mm

Insulated Nut Driver 5/16” Insulated Slotted 3.0mm

Insulated Nut Driver 3/8” Insulated Slotted 3.5mm

Insulated Nut Driver 7/16” Insulated Slotted 4.0 mm

Insulated Nut Driver 1/2” Insulated Slotted 4.5mm

Insulated T-handle Hex 5/32” Insulated Slotted 5.5mm

Insulated T-handle Hex 3/16” Insulated Slotted 6.0mm

Insulated T-handle Hex 7/32” Insulated Slotted 6.5mm

Insulated T-handle Hex 1/4” Insulated Slotted 8.0mm

Insulated T-handle Hex 5/16” Insulated Phillips #0

Insulated T-handle Hex 3/8” Insulated Phillips #1

Insulated Torx T8 Insulated Phillips #2

Insulated Torx T9 Insulated Phillips #3

Insulated Torx T10 Insulated Square #1

Insulated Torx T15 Insulated Square #2

Insulated Torx T20 Insulated Slt/Ph Terminal #1

Insulated Torx T25 Insulated Slt/Ph Terminal #2

Insulated Torx T27 Insulated Cable Knife 50mm

Insulated Torx T30 2 Meter Ruler In/MM

48 Piece Insulated Tool Set. Insulation According to

VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E & CSA,

up to 1000 volt. Individually Tested. Pliers drop-forged from special

tool steel, individually high frequency induction hardened, chrome/nickel

plated, mirror-polished. Cushion Grip Insulated handles. Canvas tool bag.

1000Volt 48 Pc. BIG SET

13 Piece Pliers & Screwdriver Set. In Tool Box

Item# Set Includes: lbs. 6.60

8.0” Long Nose 9.0” Combo Pliers/Crimpers

8.0” High Leverage Cutters 50mm Cable Stripping Knife

Insulated Slotted: 3.0mm Insulated Phillips: #1

Insulated Slotted: 4.5mm Insulated Phillips: #2

Insulated Slotted: 6.0mm Insulated Square: #1

Insulated Slt/Ph Terminal: #1 Insulated Square: #2

Insulated Slt/Ph Terminal: #2

31

WH32874

WH32879

WH32896

WH32878

32

1000Volt

10 Piece Pliers & Screwdriver Set

Insulation According to VDE 0682/part 201, EN/IEC 60900, ASTM

F-1505-01, NFPA70E & CSA, up to 1000 volt. Individually Tested.

Item# Set Includes: lbs. 5.54

8.0” Combination Pliers 8.0” Long Nose

8.0” Side Cutters 8.0” Cable Cutters

6.3” Universal Wire Stripper

Insulated Phillips #1 Insulated Slotted 4.5mm

Insulated Phillips #2 Insulated Slotted 6.5mm

Insulated Phillips #3

10 Piece Pliers & Screwdriver Set. Insulation According

to VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E

& CSA, up to 1000 volt. Individually Tested. Pliers drop-forged

from special tool steel, individually high frequency induction hardened,

chrome and nickel plated, mirror-polished. In molded tool box

Item# Set Includes: lbs. 6.64

8.0” Bent Nose 8.0” Combination Pliers

6.3” Long Nose 6.3” Side Cutters

Insulated Phillips #0 Insulated Slotted 3.0mm

Insulated Phillips #1 Insulated Slotted 4.5mm

Insulated Phillips #2 Insulated Slotted 6.5mm

12 Piece Pliers & Screwdriver Set In Molded Tool Box

Item# Set Includes: lbs. 8.60

8.0” Bent Nose 8.0” Combination Pliers

6.3” Long Nose 6.3” Side Cutters

Insulated Slotted 4.5mm Insulated Nut Driver 1/4”

Insulated Slotted 6.5mm Insulated Nut Driver 5/16”

Insulated Phillips #1 Insulated Nut Driver 3/8”

Insulated Phillips #2 Insulated Nut Driver 1/2”

14 Piece Pliers & Screwdriver Set. In Zipper Case

Item# Set Includes: lbs. 6.60

8.0” Long Nose 6.3” Side Cutters

9.0” Combination Pliers 8.0” High Leverage Cutters

6.3” Stripping Pliers Insulated Slotted 2.5mm

Insulated Phillips #1 Insulated Slotted 3.0mm

Insulated Phillips #2 Insulated Slotted 3.5mm

Insulated Phillips #3 Insulated Slotted 4.5mm

Insulated Slotted 2.0mm Insulated Slotted 6.5mm

14 Piece Pliers & Screwdriver Set

Insulation According to VDE 0682/part 201, EN/IEC 60900, ASTM

F-1505-01, NFPA70E & CSA, up to 1000 volt. Individually Tested.

Wiha Insulated Pliers with High Visibility Comfort Grip Handle

11 Piece Pliers & Screwdriver Set In Canvas Pouch

Item# Set Includes: lbs. 3.58

6.3” Long Nose 6.3” Side Cutters

8.0” Combination Pliers 6.3” Stripping Pliers

Insulated Slotted 2.5mm Insulated Phillips #0

Insulated Slotted 3.5mm Insulated Phillips #1

Insulated Slotted 4.5mm Insulated Phillips #2

Insulated Slotted 6.0mm

1000Volt

WH32888

WH32891

WH32892

WH32895

WH32894

33

NEW

From Wiha

8 Piece Pliers & Cutters Set

Insulation According to VDE 0682/part 201, EN/IEC 60900, ASTM

F-1505-01, NFPA70E & CSA, up to 1000 volt. Individually Tested.

Item# Set Includes: lbs. 4.63

6.3” Long Nose Pliers 8.0” Long Nose Pliers

6.3” Lineman’s Pliers 6.3” Diagonal Cutters

9.0” Lineman’s Pliers 8.0” High Lev. Cutters

6.3” Wire Stripping Pliers Electrician’s Knife

• Pliers drop-forged

from special tool steel,

individually high

frequency induction

hardened, chrome

and nickel plated,

mirror-polished.

1000Volt

Wiha Insulated Pliers with High Visibility Comfort Grip Handle

10 Piece Pliers & Screwdriver Set In Canvas Pouch

Item# Set Includes: lbs. 4.06

6.3” Diagonal Cutters 9.0” Combo Pliers

6.3” Long Nose Pliers 6.3” Wire Strippers

7.0” Crimping Pliers

Insulated Slotted 4.5mm Insulated Phillips #1

Insulated Slotted 6.0mm Insulated Phillips #2

Insulated Square: #2

WARNING!

Insulated Tools are intended to provide protection against accidental

contact with charged energized circuits. For maximum safety we

recommend de-energizing all circuits whenever possible before starting

work on electrical apparatus or conductors. Always visually inspect

insulation on tools before use, do not use tools if insulation shows signs

of wear or damage to the insulated areas of the tool. Wear appropriate

eye protection when using hand tools. Use NFPA70E certified insulated

protective outer wear when appropriate.

Use & Care Guide For Insulated Tools:

Store tools to minimize risk of damage to insulation, always wear

approved eye protection, Inspect insulation prior to each use of any

insulated tool. Use insulated tools where the ambient temperature

is between -20 to +70O C. Have a qualified safety technician visually

inspect insulation on tools annually for safe use.

10 Piece Pliers & Screwdriver Set In Canvas Pouch

Item# Set Includes: lbs. 4.24

7.0” Diagonal Cutters 9.0” Combo Pliers

8.0” Long Nose Pliers 6.3” Wire Strippers

7.0” Crimping Pliers

Insulated Slotted 3.0mm Insulated Phillips #1

Insulated Slotted 4.5mm Insulated Phillips #2

Insulated Slotted 6.0mm

NEW

From Wiha

14 Piece Pliers/Cutters & Screwdrivers Set

Insulation According to VDE 0682/part 201, EN/IEC 60900, ASTM

F-1505-01, NFPA70E & CSA, up to 1000 volt. Individually Tested.

Item# Set Includes: lbs. 6.52

9.0” Lineman’s Pliers 8.0” High Leverage Cutters

8.0” Cable Cutters 8.0” Long Nose Pliers

6.0” Stripping Pliers 10-20 AWG

SlimLine Slotted 3.0mm SlimLine Phillips #1

SlimLine Slotted 4.5mm SlimLine Phillips #2

SlimLine Slotted 6.5mm SlimLine Terminal #2

SlimLine Square #1 Single Pole Tester

SlimLine Square #2

NEW

From Wiha

1000Volt

33

WH32889

WH32867

WH32868

WH32869

Insulated Combination Lineman’s Pliers

Item

No. mm Inch Pkg. wt.

160 6.3 #10 1 .53

180 7.0 #9 1 .58

200 8.0 #8 1 .72

Combination Pliers. Insulation According to VDE 0682/part

201, EN/IEC 60900, ASTM F-1505-01, NFPA70E & CSA, up to

1000 volt. Individually Tested. DIN ISO 5746 Extra long cutting edge

for flat & round cables. Serrated jaws. Cutting edges additionally

induction hardened to approx. 60HRC. Special CV tool steel forgings,

Chrome finish. Use for gripping and holding as well as cutting soft and

hard wires and cables. Two component soft grip ergonomic handles.

1000volt

Safety slip

guard

Hard chrome finish for

long lasting corrosion

protection

Cutters additionally

induction hardened

Soft grip ergonomically

designed handle body

Wiha Insulated Pliers & Cutters

1000V

Insulation Standards:

EN/IEC 60900, ASTM F-1505-01,

and or According to VDE 0682/part 201,

NFPA70E and CSA

Tools Meet 10,000 Volt Test Standards

Rated to 1000 Volt ac or 1500 Volt dc

Insulated High Leverage Combination Pliers

1000volt

Lineman’s

Item

No. mm Inch Pkg. wt.

225 9.0 #4 1 .86

High Leverage Combination Pliers. Insulation According

to EN/IEC 60900, ASTM F-1505-01, NFPA70E & CSA, up to 1000

volt. Individually Tested. DIN ISO 5746

Extra long cutting edge for flat and round cables. Serrated jaws.

Cutting edges additionally induction hardened to approx. 64HRC.

C 60 Special tool steel. Use for gripping, pulling & holding as well as

cutting wires and cables ranging in hardness from soft to extremely

hard. Two component soft grip ergonomic handles.

Cutting Capacity

Copper AWG

Cutting Capacity

Copper AWG

Insulated Linemans Pliers With Crimpers

1000volt

5-In-1 Lineman’s Pliers

With Lower Crimping Jaw

Item

No. mm Inch Pkg. wt.

225 9.0 #4 1 .88

Insulated Lineman’s Pliers “5-In-1” Professional Design

Insulation According to EN/IEC, ASTM, NFPA70E & CSA,

up to 1000 volt. Individually Tested.

Deep cut radius conduit jaws for non-slip handling. Sure grip knurled

& cross hatched flat jaw for non-slip griping. Extra long induction

hardened precision matched cutting edges. Lower crimping jaw accepts

most standard non-insulated electrical connectors. Large head with

square anvil surface on each side. Made from premium CV tool steel

forgings. Two component cushion grips for best user comfort.

Cutting Capacity

Copper AWG

34

WH32821

WH32820

WH328

WH32814

WH32816

WH32818

35

Item

No. mm Inch mm2 AWG Pkg. wt.

180 7.0 0.25-2.5 6-30 1 .57

Insulated Crimping Pliers. Insulation According to

VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E

and CSA, up to 1000 Volt. Individually Tested.

Semi-circular profiles for secure connection between end sleeve and

conductor. Long life is achieved through additional induction hardening

to 64 HRC. CV 60 special tool steel hardened & tempered.

Insulated Crimping Pliers

NEW

From Wiha

Insulated Diagonal Cutters

1000volt

Item

No. mm Inch Pkg. wt.

140 5.5 #6 1 .47

160 6.3 #6 1 .49

180 7.0 #6 1 .62

Diagonal Cutters. Insulation According to VDE 0682/part 201,

EN/IEC 60900, ASTM F-1505-01, NFPA70E & CSA, up to 1000 volt.

Individually Tested. DIN ISO 5749 Low wear lap joint, riveted and

able to withstand high levels of load. Lightweight action, clean

cutting. Long term cutting is achieved through additional inductive

hardening to approx. 60 HRC. Special tool steel hardened and tempered.

For soft & medium hard wire. 32832 & 32834 for soft, hard & piano wire.

1000volt

Item

No. mm Inch Pkg. wt.

160 6.3 #6 1 .64

180 7.0 #5 1 .67

200 8.0 #4 1 .80

High Leverage Diagonal Cutters. Insulation According to

VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E &

CSA, up to 1000 volt. Individually Tested. DIN ISO 5749

Semi-circular. Low wear lap joint, riveted and able to withstand high

levels of load. Lightweight action, clean cutting. Long term cutting is

achieved through additional inductive hardening to approx. 64 HRC.

C 60 special tool steel hardened and tempered to high quality. For soft,

hard and piano wire, lay-on joint, optimized power transmission.

Insulated High Leverage Diagonal Cutters

Cutting Capacity

Copper AWG

Cutting Capacity

Copper AWG

Item

No. mm Inch Pkg. wt.

160 6.3 #6 1 .55

Diagonal Cutters W/Stripping Holes. Insulation According

to VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E &

CSA, up to 1000 volt. Individually Tested. Drop-forged from special

tool steel, cutters additionally induction hardened (approx. 60 HRC),

chrome-nickel plated, mirror-polished. Ergo comfort grip with slip guard.

Holes in the cutting edge for stripping copper wire of Ø 1.5 and 2.5.

Insulated Electrician’s Diagonal Cutters

1000volt

Cutting Capacity

Copper AWG

1000volt

Item

No. mm Inch Ø mm2 Pkg. lbs.

160 6.3 16 50 1 .42

200 8.0 20 60 1 .67

Serrated Edge Cable Cutters. Insulation According to VDE

0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E and CSA,

up to 1000 Volt. Individually Tested. Light, clean cutting ground

precision cutting edges. Durable cutting is achieved through additional

inductive hardening to approx. 62 HRC. Special tool steel, hardened &

tempered. For cutting of copper & aluminum cables without crushing.

Insulated Serrated Edge Cable Cutters

Strips AWG

#10 & #14

New dynamic joint provides

40% easier cuts and

significantly longer tool life

35

WH328

WH32830

WH32832

WH32834

WH328

WH32835

WH32836

WH32838

WH32861

WH328

WH32826

WH32828

WH32841

Insulated Long Nose Pliers

1000volt

Item

No. mm Inch Pkg. wt.

160 6.3 #10 1 .32

200 8.0 #8 1 .42

Long Nose Pliers With Cutters. Insulation According to

VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E & CSA,

up to 1000 volt. Individually Tested. Drop-forged from special tool

steel, cutters additionally induction hardened (approx. 60 HRC), chrome-

nickel plated, mirror-polished, ergonomic comfort grip with slip guard,

half-round jaws, serrated gripping surface.

Item

No. mm Inch Pkg. wt.

200 8.0 #8 1 .43

160 6.3 #10 1 .32

Bent Nose Pliers With Cutters. Insulation According to

VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E &

CSA, up to 1000 volt. Individually Tested.

Drop-forged from special tool steel, cutters additionally induction

hardened (approx. 60 HRC), chrome-nickel plated, mirror-polished.

Ergonomic comfort grip with slip guard. Half-round jaws, serrated

gripping surface, nose bent 40o.

Insulated Bent Nose Pliers

Angled 40O

1000volt

Cutting Capacity

Copper AWG

Cutting Capacity

Copper AWG

Item

No. mm Inch Pkg. wt.

160 6.3 1 .34

Round Nose Pliers. Insulation According to VDE 0682/part

201, EN/IEC 60900, ASTM F-1505-01, NFPA70E & CSA, up to

1000 volt. Individually Tested. Drop-forged from special tool

steel, individually induction hardened, chrome and nickel plated,

mirror-polished. Ergonomic comfort grip with slip guard. Serrated jaws.

1000volt

Round Nose Pliers

Item

No. mm Inch Pkg. wt.

160 6.3 1 .39

Long Flat Nose Pliers. Insulation According to

VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E &

CSA, up to 1000 volt. Individually Tested. DIN ISO 5745

Extra long head. Serrated Jaws are induction hardened. Special CV

tool steel forgings, Chrome finish. Two component Soft Grip handles.

Use for Gripping and right-angle bending of wires and sheet metal parts.

1000volt

Insulated Long Flat Nose Pliers

36

Wiha Canvas Pliers Holster

Pliers Canvas Holster

Item Width Height

No. Size Size lbs. pkg.

3.5 x 6.75 .15 1

· Canvas holster with belt clip and belt loop

· Security pliers strap

· Screwdriver holder in the front

WH328

WH32806

WH32808

WH328

WH32804

WH32807

WH32870

WH32810

WH91256

37

Item

No. mm Inch Pkg. lbs.

Z01016180 180 7.0 #6 1 .46

Inomic Combo Pliers. Insulation According to EN/IEC 60900,

ASTM F-1505-01, NFPA70E & CSA, up to 1000 volt. Individually

Tested. DIN ISO 5749 Precision machined forged head. Induction

hardened for longest tool life. Cross hatched flat jaw & deep cut radius

jaws for secure gripping of the work piece. Cutting edges are matched

for precise cutting action. Award winning ergonomic design with head

mounted at 23° angle to grip for reduced user fatigue. Palm side of grip

has molded soft panel for added comfort in prolonged use.

Cutting Capacity

Copper AWG

1000volt

Item

No. mm Inch Pkg. lbs.

Z01016160 160 6.3 #6 1 .43

Cutting Capacity

Copper AWG

Item

No. mm Inch Pkg. lbs.

Z01016160 160 6.3 #6 1 .41

Inomic Diagonal Cutters

Cutting Capacity

Copper AWG

Wiha Inomic 1000Volt Insulated Pliers

Insulation Standards:

EN/IEC 60900, ASTM F-1505-01, NFPA70E & CSA

Each tool includes

a convenient

jaw lock & handle

return spring

Heads drop

forged CV

premium tool

steel

Tools Meet

10,000 Volt Test Standards

Rated to 1000Volt ac or 1500 Volt dc

Inomic Canvas Holster

Item Width Height

No. Size Size lbs. pkg.

4.0 x 4.5 .05 1

Holds

any

Inomic

Pliers

Item# Set Includes: lbs. 1.45

Inomic Combo Pliers Inomic Diagonal Cutters

Inomic Long Nose Pliers Inomic Holster (Includes 3)

3 Pc. Insulated Inomic Pliers/Cutters Set

Meets ASTM, EN/IEC, NFPA, CSA, ISO specifications.

Award winning ergonomic design with head mounted

at 23° angle to grip for reduced user fatigue.

Three

Holsters

Included

Award winning ergonomic

design with head mounted at

23° angle to grip for reduced

user fatigue

Tools Meet 10,000 Volt Test Standards Rated

to 1000 Volt ac or 1500 Volt dc

Inomic Long Nose Pliers

32850 32852 32854

Stripping Pliers. Insulation According to VDE 0682/part

201, EN/IEC 60900, ASTM F-1505-01, NFPA70E and CSA,

up to 1000 volt. Individually Tested. Heavy duty forged with

induction hardened cutting edges for even stripping of insulation.

Drop-forged from special tool steel, chrome and nickel plated,

mirror-polished. Ergonomic comfort grip with slip guard. Spring and

adjusting screw, for stripping up to Ø 5mm/#4 Awg.

Item

No. mm Inch Pkg. wt.

160 6.3 #4 - #28 1 .50

1000volt

Insulated Stripping Pliers

Stripping Capacity

Copper AWG

Item No. mm Inch Ø AWG Pkg. lbs.

160 6.3” 0.81-2.59 20-10 5 .26

Insulated Stripping Pliers. Insulation According to EN/IEC

60900, DIN ISO 8976, ASTM F-1505 & CSA Specification.

Individually Tested. Wide long head with ridged gripping surface, shears

blade and firm wire stripping stations. Wire stripping stations 0.81 / 1.0 /

1.3 / 1.6 / 2.0 / 2.59mm, AWG 20 / 18 / 16 / 14 / 12 / 10.

1000Volt

NEW

From Wiha

1000Volt

37

WH32860

WH10250

WH32850

WH32852

WH32854

WH32852

WH32854

WH32859

WH91230

WH WH WH

38

Tools meet ASTM, IEC, VDE,

EN, NFPA & CSA standards

10,000 Volt tested

1000 Volt Rated

Induction hardened

jaws and cutters

to 60 HRC

1000volt

Insulated Lineman’s Pliers With Crimpers

1000volt

Insulated Long Nose Pliers With Cutters

Insulated Diagonal Cutters

1000V

Two component ergo

cushion grip handles

Industrial

brushed finish

Insulated Industrial

Pliers & Cutters

Item

No. mm Inch Pkg. wt.

225 9.0 #4 1 .98

Insulated Industrial Lineman’s Pliers “5-In-1” Professional

Design Insulation According to EN/IEC, ASTM, NFPA70E & CSA,

up to 1000 volt. Individually Tested. Deep cut radius conduit

jaws for non-slip handling. Sure grip knurled & cross hatched flat jaw

for non-slip griping. Extra long induction hardened precision matched

cutting edges. Lower crimping jaw accepts most standard non-insulated

electrical connectors. Large head with square anvil surface on each

side. Premium CV tool steel forgings.

Cutting Capacity

Copper AWG

Item

No. mm Inch Pkg. wt.

160 6.3 #10 1 .36

200 8.0 #8 1 .46

Insulated Industrial Long Nose Pliers With Cutters.

Insulation According to VDE 0682/part 201, EN/IEC 60900, ASTM

F-1505-01, NFPA70E & CSA, up to 1000 volt. Individually Tested.

Drop-forged from special tool steel, cutters additionally induction

hardened (approx. 60 HRC), half-round jaws, serrated gripping surface.

Industrial brushed finish. Ergonomic comfort grip with slip guard.

Cutting Capacity

Copper AWG

Item

No. mm Inch Pkg. wt.

160 6.3 #6 1 .64

200 8.0 #6 1 .80

Insulated Industrial Diagonal Cutters. Insulation According to

VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E & CSA,

up to 1000 volt. Individually Tested. DIN ISO 5749 Low wear lap

joint, riveted and able to withstand high levels of load. Lightweight action,

clean cutting. Long term cutting is achieved through additional inductive

hardening to approx. 60 HRC. Special tool steel hardened and tempered.

Industrial brushed finish. For soft, medium hard wire & piano wire.

Cutting Capacity

Copper AWG

Long life high

performance

dynamic 60/40 joint

New dynamic joint provides

40% easier cuts & significantly

longer tool life

Long life high performance

dynamic 60/40 joint

NEW

From Wiha

NEW

From Wiha

NEW

From Wiha

NEW

From Wiha

WH32917

WH329

WH32926

WH32923

WH329

WH32933

WH32929

39

Insulated Industrial Stripping Pliers. Insulation According

to VDE 0682/part 201, DIN 7437, EN/IEC 60900, ASTM F-1505-01,

NFPA70E & CSA, 1000 volt rated. Individually Tested.

DIN ISO 5745 Made from Premium CV tool steel forgings. Induction

hardened jaws and cutters to 60 HRC. Industrial brushed finish. Two

component ergo cushion grips for best user comfort. Spring & adjusting

screw, for stripping up to Ø 5mm/#4 Awg.

Item

No. mm Inch Pkg. wt.

160 6.3 #4 - #28 1 .46

1000volt

Insulated Stripping Pliers

Stripping Capacity

Copper AWG

NEW

From Wiha

1000volt

Insulated Combo Pliers With Dynamic Joint

1000volt

Insulated Heavy Duty Cable Cutters

1000volt

Insulated Crimpers

Item

No. mm Inch Pkg. wt.

200 8.0 #4 1 .92

Insulated Industrial High Leverage Combination Pliers.

Insulation According to EN/IEC 60900, ASTM F-1505-01, NFPA70E &

CSA, up to 1000 volt. Individually Tested. DIN ISO 5746

Extra long cutting edge for flat and round cables. Serrated jaws.

Cutting edges additionally induction hardened to approx. 60HRC.

Use for gripping, pulling & holding as well as cutting wires and cables

ranging in hardness from soft to extremely hard. Industrial brushed

finish. Two component soft grip ergonomic handles.

Cutting Capacity

Copper AWG

Item

No. mm Inch Ø mm2 Pkg. lbs.

200 8.0 20 60 1 .78

Insulated Industrial Serrated Edge Cable Cutters. Insulation

According to VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01,

NFPA70E and CSA, up to 1000 Volt. Individually Tested. Light,

clean cutting ground precision cutting edges. Durable cutting is achieved

through additional inductive hardening to approx. 60 HRC. Premium

CV tool steel forgings. For cutting of copper & aluminum cables without

crushing. Two component ergo cushion grips for best user comfort.

Item

No. mm Inch mm2 AWG Pkg. wt.

180 7.0 0.25-2.5 6-30 1 .64

Insulated Industrial Crimping Pliers. Insulation

According to VDE 0682/part 201, EN/IEC 60900, ASTM F-1505-01,

NFPA70E and CSA, up to 1000 Volt. Individually Tested.

Semi-circular profiles for secure connection between end sleeve and

conductor. Long life is achieved through additional induction hardening

to 60 HRC. Industrial brushed finish. Two component ergo cushion

grips for best user comfort. Crimps 6 - 30 AWG Connectors.

Long life high

performance

dynamic 60/40 joint

NEW

From Wiha

NEW

From Wiha

NEW

From Wiha

WH32947

39

WH32930

WH32927

WH32945

40

WARNING!

Insulated Tools are intended to provide protection against accidental

contact with charged energized circuits. For maximum safety we

recommend de-energizing all circuits whenever possible before starting

work on electrical apparatus or conductors. Always visually inspect

insulation on tools before use, do not use tools if insulation shows signs

of wear or damage to the insulated areas of the tool. Wear appropriate

eye protection when using hand tools. Use NFPA70E certified insulated

protective outer wear when appropriate.

5 Pc. Insulated Industrial Diagonal Cutters & Screwdrivers

Insulation According to VDE 0682/part 201, DIN EN 60900, EN/IEC

60900, ASTM F-1505-01, NFPA70E, up to 1000 volt.

Individually Tested.

Item No. Insulated Diagonal Cutters & Screwdrivers

6.3”/160mm Diagonal Cutter

Insulated Divers: Slotted: 3.0, 4.5mm • Phillips: #1, #2

lbs. 1.17

1000Volt

6 Pc. Insulated Industrial Combo Pliers & Screwdrivers

Insulation According to VDE 0682/part 201, DIN EN 60900, EN/IEC

60900, ASTM F-1505-01, NFPA70E, up to 1000 volt.

Individually Tested.

Item No. Insulated Combination Pliers & Screwdrivers

8.0” Combination Pliers & 8” Long Nose Pliers

Divers: Slotted: 3.0, 4.5mm • Phillips: #2 • Square: #2

lbs. 2.06

1000Volt

7 Pc. Insulated Industrial Pliers/Cutters & Screwdrivers

Item No. Insulated Pliers/Cutters & Screwdrivers

8.0” Combo Pliers, 6.3” Long Nose, 6.3” Diagonal Cutters

Insulated Divers: Slotted: 3.0, 4.5mm • Phillips: #1, #2

lbs. 2.30

1000Volt

In Belt Pack

Pouch

NEW

From Wiha

NEW

From Wiha

NEW

From Wiha

3 Pc. Insulated Industrial Pliers & Cutters. Insulation

According to VDE 0682/part 201, DIN EN 60900, EN/IEC 60900,

ASTM F-1505-01, NFPA70E, up to 1000 volt. Individually Tested.

Item No. Insulated Pliers & Cutters

8.0” Combo Pliers, 8.0” Long Pliers, 8.0” Diagonal Cutters

lbs. 2.18

1000Volt

NEW

From Wiha

Tools meet ASTM,

IEC, VDE, EN,

NFPA & CSA

standards

Tools meet ASTM,

IEC, VDE, EN,

NFPA & CSA

standards

Tools meet ASTM,

IEC, VDE, EN,

NFPA & CSA

standards

Tools meet ASTM,

IEC, VDE, EN,

NFPA & CSA

standards

9 Piece Insulated Industrial Pliers & Cutters Set

Insulated pliers & cutters set in a light weight tool box tray.

Item No.

9.0” Lineman’s Pliers 8.0” High Leverage Combo Pliers

6.3” Long Nose Pliers 8.0” Cable Cutters

8.0” Long Nose Pliers 6.3” Stripping Pliers

lbs. 6.3” Diagonal Cutters 7.0” Crimping Pliers

6.34 8.0” Diagonal Cutters

1000Volt

Tool box set

in blow molded tray

NEW

From Wiha

Wiha Insulated Industrial Tool Sets

WH32999

WH32985

WH32981

WH32983

WH32984

41

Use & Care Guide For Insulated Tools:

Store tools to minimize risk of damage to insulation, always wear

approved eye protection, Inspect insulation prior to each use of any

insulated tool. Use insulated tools where the ambient temperature

is between -20 to +70O C. Have a qualified safety technician visually

inspect insulation on tools annually for safe use.

Wiha Insulated Industrial Tool Sets

11 Pc. Pliers & Screwdriver Set. Insulation According to

VDE 0682/part 201, DIN EN 60900, EN/IEC 60900, ASTM F-1505-01,

NFPA70E, up to 1000 volt. Individually Tested. In Roll Out Pouch

Item# Set Includes: lbs. 3.62

6.3” Long Nose Pliers 6.3” Diagonal Cutters

8.0” Combination Pliers 6.3” Stripping Pliers

Insulated Slotted: 3.0, 4.5, 5.5mm

Insulated Phillips: #1, #2 Insulated Square: #1, #2

1000Volt

In Roll

Out

Pouch

8 Pc. Pliers & Cutters Set. Insulation According to VDE

0682/part 201, DIN EN 60900, EN/IEC 60900, ASTM F-1505-01,

NFPA70E, up to 1000 volt. Individually Tested. In Roll Out Pouch

Item# Set Includes: lbs. 5.52

6.3” Long Nose Pliers 6.3” Diagonal Cutters

8.0” Long Nose Pliers 8.0” H.D. Diagonal Cutters

9.0” Lineman’s w/Cutters 6.3” Stripping Pliers

8.0” Cable Cutters 7.0” Crimpers

1000Volt

22 Pc. Pliers & Cutters Set. Insulation According to VDE

0682/part 201, DIN EN 60900, EN/IEC 60900, ASTM F-1505-01,

NFPA70E, up to 1000 volt. Individually Tested. In Roll Out Pouches

Item# Set Includes: lbs. 5.74

8.0” Long Nose Pliers 6.3” Diagonal Cutters

9.0” Lineman’s w/Cutters 8.0” H.D. Diagonal Cutters

8.0” Cable Cutters 6.3” Stripping Pliers

7.0” Crimpers

15 Pc. SlimLine Blade Set includes: Insulated SlimLine Blade Holder

Slotted: 3.0, 4.0, 5.5, 6.5 Phillips: #1, #2 Xeno: #1, #2

: T8, T10, T15, T20 Square: #1, #2

1000Volt

In Roll

Out

Pouch

In Roll

Out

Pouches

NEW

From Wiha

11 Pc. Pliers & Driver Set. Insulation According to VDE

0682/part 201, EN/IEC 60900, ASTM F-1505-01, NFPA70E & CSA,

up to 1000 volt. Individually Tested. In molded tool box

Item# Set Includes: lbs. 7.5

8.0” Linemans Pliers 6.3” Long Nose Pliers W/Cutter

8.0” Long Nose Pliers W/Cutter 6.3” Diagonal Cutter

8.0” High Leverage Cutter

Insulated Phillips #0 Insulated Slotted 3.0mm(1/8”)

Insulated Phillips #1 Insulated Slotted 4.5mm(3/16”)

Insulated Phillips #2 Insulated Slotted 6.5mm(1/4”)

1000Volt

NEW

From Wiha

NEW

From Wiha

NEW

From Wiha

WH32986

WH32987

WH32988

41

WH32390

Numerical Index by Item Number

42

Item No. Page Item No. Page Item No. Page Item No. Page Item No. Page

10250 37

11625 15

11630 15

11950 15

12326 14

12851 10

12852 13

12853 15

12854 11

12855 11

12856 13

12857 13

12858 15

12859 15

13650 9

13651 9

13652 9

13653 9

13654 9

13655 9

13656 9

13657 9

13658 9

13659 9

13662 9

13663 9

13664 9

13665 9

13666 9

13667 9

13668 9

13669 9

13670 9

13671 9

13672 9

13673 9

13690 9

13691 9

13693 9

15000 8

15003 8

15050 8

19767 15

20006 5

20007 5

20008 5

20009 5

20010 5

20011 5

20012 5

20013 5

20014 5

20015 5

20016 5

20017 5

20018 5

20019 5

20020 5

20022 5

20024 5

20027 5

20030 5

20032 5

20091 4

20093 4

20131 5

20133 5

20135 5

20136 5

20137 5

20138 5

20140 5

20141 5

20142 5

20144 5

20145 5

20146 5

20147 5

20148 5

20149 5

20190 4

20192 4

21008 7

21009 7

21010 7

21011 7

21012 7

21013 7

21014 7

21015 7

21017 7

21019 7

21022 7

21024 7

21027 7

21030 7

21032 7

21040 8

21042 8

21044 8

21046 8

21048 8

21050 8

21052 8

21054 8

21056 8

21058 8

21060 8

21062 8

21064 8

21066 8

21068 8

21093 7

21094 8

21095 7

21096 8

21208 6

21210 6

21212 6

21213 6

21214 6

21217 6

21219 6

21290 6

21325 6

21327 6

21329 6

21331 6

21333 6

21335 6

21391 6

25511 26

28301 19

28308 19

28309 19

28312 19

28315 19

28317 19

28319 19

28327 20

28329 20

28339 20

28340 20

28341 20

28342 20

28346 20

28347 20

28350 18

28390 20

28391 20

28724 18

28726 18

28727 18

28734 18

28736 18

28737 18

28791 18

28792 18

29006 11

29009 13

29012 15

29240 15

29250 15

30700 26

30701 26

30746 21

30747 21

31326 10

31327 10

31328 10

31329 10

31330 10

31331 10

31332 10

31333 10

31334 10

31335 10

31336 10

31337 10

31338 10

31339 10

31340 10

31341 10

31342 10

31343 10

31344 10

31345 10

31390 11

31391 11

31394 11

31395 11

31425 12

31428 12

31429 12

31430 12

31431 12

31432 12

31433 12

31434 12

31435 12

31436 12

31437 12

31438 12

31439 12

31491 12

31493 12

31495 13

31496 13

31506 12

31507 12

31508 12

31509 12

31510 12

31511 12

31512 12

31513 12

31514 12

31515 12

31516 12

31517 12

31518 12

31519 12

31520 12

31521 12

31522 12

31524 12

31590 12

31592 13

31595 13

31608 14

31609 14

31610 14

31611 14

31612 14

31613 14

31614 14

31615 14

31616 14

31617 14

31618 14

31619 14

31620 14

31621 14

31622 14

31623 14

31624 14

31626 14

31627 14

31628 14

31630 14

31632 14

31691 14

31703 14

31704 14

31705 14

31707 14

31708 14

31709 14

31710 14

31712 14

31713 14

31714 14

31715 14

31716 14

31718 14

WH

43

32215 25

32218 25

32221 25

32224 25

32227 25

32230 25

32233 25

32236 25

32255 25

32258 25

32261 25

32264 25

32267 25

32268 25

32270 25

32273 25

32276 25

32278 25

32280 25

32288 25

32291 25

32292 25

32293 25

32294 25

32296 25

32302 24

32303 24

32304 24

32305 24

32306 24

32308 24

32366 24

32390 41

32505 26

32511 26

32516 26

32521 26

32526 26

32531 26

32536 26

32541 26

32546 26

32551 26

32556 26

32561 26

32590 26

32592 26

32650 27

32800 29

32804 36

32806 36

32807 36

32808 36

31720 14

31722 14

31790 14

31805 10

31807 10

31809 10

31811 10

31813 10

31815 10

31817 10

31890 10

32005 23

32010 23

32012 23

32015 23

32017 23

32023 23

32024 23

32025 23

32026 23

32027 23

32028 23

32031 23

32034 23

32039 23

32042 23

32045 23

32046 21

32049 21

32052 21

32055 21

32058 21

32090 23

32091 23

32092 23

32093 24

32094 24

32095 24

32100 23

32101 23

32102 23

32103 23

32104 23

32145 21

32146 21

32189 22

32190 24

32196 22

32197 22

32198 22

32206 25

32209 25

32212 25

32810 36

32814 34

32816 34

32818 34

32820 34

32821 34

32826 35

32828 35

32830 35

32832 35

32834 35

32835 35

32836 35

32838 35

32841 35

32850 37

32852 37

32854 37

32859 37

32860 37

32861 35

32867 33

32868 33

32869 33

32870 36

32871 28

32872 28

32873 28

32874 31

32875 28

32876 30

32877 30

32878 31

32879 31

32888 32

32889 33

32891 32

32892 32

32894 32

32895 32

32896 31

32917 38

32923 38

32926 38

32927 39

32929 38

32930 39

32933 38

32945 39

32947 39

32981 40

32983 40

32984 40

32985 40

32986 41

32987 41

32988 41

32999 40

33441 17

33443 17

33445 17

33447 17

33481 17

33482 17

33483 17

33485 17

33486 17

33487 17

33490 17

33491 17

35811 24

35812 24

35844 21

35845 21

35890 24

35891 24

38006 18

38007 18

38016 27

38017 27

38018 27

38025 18

40800 15

75205 16

75210 16

75215 16

75220 16

75302 16

75304 16

76208 5

76210 5

76212 5

76215 5

76290 5

91230 37

91256 36

Item No. Page Item No. Page Item No. Page Item No. Page Item No. Page

WH

43

WH

Catalog Item No. 99919

version - 2/1/12

COMPLIANCE TESTING

Insulation Test Cold Impact Test

Material Integrity Test Puncture Test

Flame Resistance Test Adhesion Test

from

Also Available

Wiha / LH Dottie ESD Tools

L.H. Dottie Company

6131 Garfield Avenue

Commerce, CA 90040

tel: 323.725.1000

lhdottie.com

.D

Subject to change without notice

Product Detail Manual

109139-Catalog 109139-Catalog 109139-Catalog 084705 Batch5 unilog cesco-content

110677-Attachment 110677-Attachment 110677-Attachment 084705 Batch5 unilog cesco-content

Navigation menu

Versions of this User Manual:

Views

Navigation
