AWH SERIES - COMMERCIAL/ARCHITECTURAL FAN FORCED WALL HEATERS
SUBMITTAL SHEET
AWH SERIES
FAN-FORCED
WALL HEATERS
CAPACITIES
1500, 2000, 3000,
4000 or 4800 Watts
120, 208, 240, 277, 347 or 600V
3000, 4000 or 4800 Watts
208 or 240, 347, 600V, 3Ø
Thermostat Range: 40 - 90 Degrees F
Air Movement: 100 CFM
FILE #E21609
470 Beauty Spot Rd. E, Bennettsville, SC 29512
CATALOG PHASE
ITEM QTY. NUMBER TAG LENGTH WATTS VOLTS Ø AMPS BUILT-IN CONTROLS
ITEM QTY. CAT. NO. TAG DESCRIPTION
ACCESSORIES
AND
CONTROLS
SUBMITTED BY: DATE APPROVED BY: DATE
ZSS-QAWH4 (03-06) Printed in U.S.A.
JOB NAME: _________________________________________________________________
LOCATION: _________________________________________________________________
ARCHITECT: ________________________________________________________________
ENGINEER: _________________________________________________________________
CONTRACTOR: ______________________________________________________________
SUBMITTED BY: _____________________________________________________________
DATE: ______________________________________________________________________
DIMENSIONS
ARCHITECT’S AND ENGINEER’S SPECIFICATIONS*
The heating equipment shall include an electric automatic
fan forced air heater suitable for large area heating, as
manufactured by QMark, A Marley Engineered Products
Brand, Bennettsville, SC. The heater shall be designed
for wall mounting, recess or surface. Heaters shall be UL
listed.
HEATER ASSEMBLY: The heater assembly which fits
into the back box shall consist of a fan panel upon which
is mounted all of the operational parts of the heater.
HEATING ELEMENT: The heating element shall be of
the non-glowing design consisting of an 80/20 nickel-
chromium resistance wire enclosed in a steel sheath to
which plate fins are copper brazed. It shall be warranted
for 5 years.
FAN AND FAN MOTOR: The fan shall be five-bladed
aluminum. The fan motor shall be totally enclosed.
FAN DELAY SWITCH: Fan control shall be of bi-
metallic, snap-action type and shall activate fan after
heating element reaches operating temperature. The
fan shall continue to operate after the thermostat is
satisfied and until the heating element is cool.
THERMOSTAT: The tamper-proof thermostat shall be of
the bi-metallic, snap-action type with enclosed contacts.
It shall be completely concealed behind the front cover to
become tamper proof.
THERMAL CUTOUT: A thermal cutout shall be built into
the system to shut off the heater in the event of over-
heating.
DISCONNECT SWITCH: A double-pole single throw
disconnect switch shall be mounted on the back box for
positive disconnect of power supply. It will be completely
concealed behind the front grid panel.
PNEUMATIC/ELECTRIC SWITCH: An optional
pneumatic/electric switch shall be available for use with
energy management systems employing pneumatic
pressure devices for controlling comfort levels and set-
back operations.
LOW VOLTAGE RELAYS: Normally open 24-volt and
120-volt low voltage holding coil relays shall be available
as optional equipment to control 208, 240, or 277 volt
heaters in conjunction with central energy control sys-
tems. The built-in thermostat can then be used as one of
the thermostats in an automatic night set back operation.
BACK BOX: The back box shall be designed for duty as
a recessed rough-in box in either masonry or frame
installations and is also used with the surface mounting
frame in surface mounting installations. The back box
shall be 20-gauge galvanized steel and shall contain
knockouts through which power leads are brought.
FRONT PANEL: The front panel shall be of the bar grille
type and shall be constructed of 16-gauge cold-rolled
steel, welded into a uniform grille and finished in baked
enamel to direct the warmed air toward the floor. The
front grille shall be surrounded by a decorative satin-
finish aluminum "picture" frame.
THREE PIECE DESIGN: The heater shall be made of a
back box, a heater assembly, and a front panel.
*QMark reserves the right to change specifications
without prior notice.
"A" "B" "C" "D"
MODEL RECESSED THICKNESS FRONT TOTAL
DIM. OF FRAME COVER EXT. INTO
DIM. ROOM
SM 3-13/16'' 1-1/2'' 5-5/16''
S2 1-13/16'' 2'' 1-1/2'' 3-1/2''
S1 2-13/16'' 1'' 1-1/2'' 2-1/2''
RECESSED 3-3/4'' 1-1/2'' 1-12''
AWH SERIES
470 Beauty Spot Rd. E, Bennettsville SC 29512
ASM
S1
S2
ACCESSORIES
CATALOG NO. DESCRIPTION
Pneumatic/Electric switch. Factory set at 10 psig
AWH-PE to “make” on pressure drop. May be field wired
to “break’ on pressure drop. Pressure set point
adjustable to 30 psig. (Field installed.)
Time delay relay 40-60 seconds to close when
AWH-R2 (24 volt) energized. Use 120V or 24V power supply from
AWH-R12 (120 volt) remote source. (Field installed.)
AWH-S-1 1” deep surface mounting frame for semi-
recessed installation.
AWH-S-2 Same as above except 2” deep.
Surface mounting frame for surface installations.
AWH-SM Painted to match heater decor, 313/16” deep.
LFK-SFC 14 Gauge security front cover.
SELECTION CHART
CATALOG NO. VOLTS PH. AMPS WATTS BTU/HR WIRE SIZE
AWH3150 120 1 12.5 1500 5120 12 AWG
AWH3180 120 1 15 1800 6142 12 AWG
AWH4408* 208 1 19.2 4000 13650 10 AWG
9.6 2000 6825
AWH4404* 240 1 16.7 4000 13650 10 AWG
8.3 2000 6825 & 12 AWG
208 1 14.4 3000 10235
7.2 1500 5120
AWH4407* 277 1 14.4 4000 13650 12 AWG
7.22 2000 6825
240 1 12.5 3000 10235
6.3 1500 5120
AWH4307* 277 1 10.8 3000 10235 12 AWG
5.4 1500 5120
AWH4303 347 1 8.6 3000 10235 14 AWG
AWH4508 208 1 23.1 4800 16380 10 AWG
AWH4504 240 1 20 4800 16380 10 AWG
208 1 17.3 3600 12285
AWH4507 277 1 17.3 4800 16380 10 AWG
240 1 15 3600 12285
AWH4503 347 1 13.8 4800 16380 12 AWG
AWH4506 600 3 4.6 4800 16380 14 AWG
AWH44083 208 3 11.1 4000 13650 14 AWG
AWH45083 208 3 13.3 4800 16380 12 AWG
AWH44043 240 3 9.6 4000 13650 14 AWG
AWH45043 240 3 11.6 4800 16380 14 AWG
AWH4306 600 3 3.0 3000 10235 14 AWG
*Heaters shipped at higher wattage. Units can be converted to half-wattage in field.
