E141741 Rev A 12/17/14

Page 1 of 3

ANNEX A - PROTOCOL IMPLEMENTATION CONFORMANCE STATEMENT (NORMATIVE)

(This annex is part of this Standard and is required for its use.)

BACnet Protocol Implementation Conformance Statement

Date: December 1, 2014

Vendor Name: Electro Industries / GaugeTech

Product Name: Shark 50B, Shark 100B

Product Model Number: E170102, E141102

Application Software Version: v6.01

Firmware Revision: v2.02

BACnet Protocol Revision: 9

Product Description:

The Shark 50B/100B is an electric meter compatible with an existing BACnet Compliant Building Automation System. The

Ethernet connection conforms to the BACnet/IP standard which is complemented by many network friendly features such as

password-protected web-server browser-accessible based setup screens. Once a user is logged in configuration is easy.

Defaults are well vetted. Once connected to the Building Automation Network, a BACnet client like the Cimetrics BACnet

Explorer or OPC server, can look at the Shark 50B/100B meters as BACnet Devices. Meter data exposed to the BACnet

network includes Power, Energy, Demand, MaxDemand, Power_Factor, Flow, Consumption, Current, Voltage, and Phase.

BACnet Standardized Device Profile (Annex L):

 BACnet Operator Workstation (B-OWS)

 BACnet Advanced Operator Workstation (B-AWS)

 BACnet Operator Display (B-OD)

 BACnet Building Controller (B-BC)

 BACnet Advanced Application Controller (B-AAC)

 BACnet Application Specific Controller (B-ASC)

 BACnet Smart Sensor (B-SS)

 BACnet Smart Actuator (B-SA)

List all BACnet Interoperability Building Blocks Supported (Annex K):

DS-RP-B, DS-RPM-B, DS-WP-B, DM-DDB-B

Segmentation Capability:

 Able to transmit segmented messages Window Size

 Able to receive segmented messages Window Size

Standard Object Types Supported:

An object type is supported if it may be present in the device. For each standard Object Type supported provide the following

data:

1) Whether objects of this type are dynamically creatable using the CreateObject service - NO

2) Whether objects of this type are dynamically deletable using the DeleteObject service - NO

3) List of the optional properties supported – see below

E141741 Rev A 12/17/14

Page 2 of 3

4) List of all properties that are writable where not otherwise required by this standard – n/a

5) List of all properties that are conditionally writable where not otherwise required by this standard –n/a

6) List of proprietary properties and for each its property identifier, datatype, and meaning –n/a

7) List of any property range restrictions – n/a

Object Type Optional Properties Supported

Analog Input Description,

Device_Type,

Reliability,

Min_Pres_Value

Analog Value

Description

Binary Input

Description,

Device_Type, Reliability,

Inactive_Text,

Active_Text,

Change_of_State_Time,

Change_of_State_Count,

Time_of_State_Count_Reset,

Device Description

Data Link Layer Options:

 BACnet IP, (Annex J)

 BACnet IP, (Annex J), Foreign Device

 ISO 8802-3, Ethernet (Clause 7)

 ATA 878.1, 2.5 Mb. ARCNET (Clause 8)

 ATA 878.1, EIA-485 ARCNET (Clause 8), baud rate(s) ____________

 MS/TP master (Clause 9), baud rate(s):

 MS/TP slave (Clause 9), baud rate(s):

 Point-To-Point, EIA 232 (Clause 10), baud rate(s):

 Point-To-Point, modem, (Clause 10), baud rate(s):

 LonTalk, (Clause 11), medium: __________

 BACnet/ZigBee (ANNEX O)

 Other:

Device Address Binding:

Is static device binding supported? (This is currently necessary for two-way communication with MS/TP slaves and certain

other devices.) Yes  No

Networking Options:

 Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc.

 Annex H, BACnet Tunneling Router over IP

E141741 Rev A 12/17/14

Page 3 of 3

 BACnet/IP Broadcast Management Device (BBMD)

Does the BBMD support registrations by Foreign Devices?  Yes  No

Does the BBMD support network address translation?  Yes  No

Character Sets Supported:

Indicating support for multiple character sets does not imply that they can all be supported simultaneously.

 ISO 10646 (UTF-8)  IBM/Microsoft DBCS  ISO 8859-1

 ISO 10646 (UCS-2)  ISO 10646 (UCS-4)  JIS X 0208

If this product is a communication gateway, describe the types of non-BACnet equipment/networks(s) that the

gateway supports: Modbus/RTU internally - direct internal communication only.

Network Security Options:

 Non-secure Device - is capable of operating without BACnet Network Security

 Secure Device - is capable of using BACnet Network Security (NS-SD BIBB)

 Multiple Application-Specific Keys

 Supports encryption (NS-ED BIBB)
