ERROR CODE.DOC Page 1 of 3 24/07/02

T2000 & T3000 ERROR CODES

The information supplied here is to be used only as a guide. Not all codes apply to all models

and some codes are model specific. This information is provided to assist in determining the

cause of a problem only. In some instances, the error message may be caused by an error

in a completely different location, in these cases the error message may be of little value.

01=HEAP OVERLAP

02=HEAP EXHAUSTED

03=INVALID HEAP ADDRESS

04=INVALID TASK NUMBER

05=INVALID TIMER NUMBER

06=INVALID TIMER

07=INVALID MESSAGE CATEGORY or PATH

08=INVALID MESSAGE CODE or TYPE

09=SOFTWARE INTERRUPT

10=INVALID QUEUE NUMBER

11=INVALID USER CHAR

12=INAPPROPRIATE TAST TYPE

13=ILLEGAL OPCODE

14=XIRQ INTERRUPT

15=CANT CREATE ANY MORE TIMERS

16=CANT CREATE ANY TIMERS

17=TIMER DOES NOT EXIST

18=TIMER ALREADY EXISTS

19=INVALID TIMER VECTOR

20=INVALID CODEWORD RECEIVED

21=INDICATOR BYTE ERROR

22=TRANSMISSION TIMEOUT

23=CODEWORD FIELD PARAMETER

24=INVALID CALL REQUEST

25=TEST MODE RESET VECTOR INCORRECT

26=TASK SUSPENSION CALL

27=TASK QUEUE

28=n/a

29=n/a

30=MSK RX CRC NOT READY

31=MSK TX TIMER

32=MSK TX INTERRUPT

33=MSK TX CRC NOT READY

34=MAK TX UNLOCKED

35=n/a

36=n/a

37=n/a

38=n/a

39=n/a

40=INVALID MESSAGE

41=INVALID PERSONALITY

42=INVALID DATA

43=LOGON CHAR

44=INVALID LOGPERS STATUS

45=INVALID LOGPERS POWERUP MESS

46=INVALID LOGPERS NEXT STATE

47=n/a

48=n/a

49=n/a

50=INVALID BCD DATA

51=MESSAGE DATA

52=STACK OVERFLOW

53=INVALID STRING STORE OVERFLOW

54=INVALID QUEUE BUTTON

55=INVALID QUEUE TIMEOUT

56=DISPLAY MODE

57=LANGUAGE POINTER UNINITIALISED

58=INVALID QUEUE DOSPLAY

59=INVALID QUEUED

60=INVALID TRUNKPERS MODE

61=SDMQUEUE FULL

62=SDM RX

63=FLASH PERSONALITY INVALID

64=n/a

65=n/a

66=n/a

67=n/a

68=INVALID CHANNEL NUNBER

69=CHANNEL BLOCK CACULATION

70=SYSNT FREQUENCY NUMBER TOO BIG

71=ILLEGAL TRANSMITTER POWER LEVEL

72=INAPPROPRIATE DATABASE ITEM TYPE

73=INVALID ANN NUMBERING MODEL

74=INVALID BAUD RATE

75=UNPROGRAMMER DYNAMIC ITEM

76=INVALID GROUP ADDRESS

77=INVALID PRESET CALL

78=INVALID DIALLING SCHEME

79=INVALID PRESET LABEL

80=RX OVERFLOW

81=AUDIO TONE FUNCTION

82=INVALID AUDIO TONE NUMBER

83=CCI RX BUFFER OVERFLOW

84=INVALID CALL TYPE

ERROR CODE.DOC Page 2 of 3 24/07/02

1 to 12 µ

µµ

µProcessor tasks Processor unable to perform errors task due to software

or hardware fault (catastrophic condition).

13 Illegal opcode Illegal operating code due to:

- Eprom corruption

- Ctrl board hardware failure.

- The

µ

µµ

µP has detected an invalid EPROM value.

14 to 21 Timer and

processing errors The µ

µµ

µProcessor cannot function due to software or

hardware problems. The µ

µµ

µP’s XIRQ line has a low

present. This line should always be high.

22 Transmission

timeout An FFSK transmission has not been completed within an

appropriate time (check TXSYNC line from the MODEM

to the µ

µµ

µP). The µ

µµ

µP has not received proper syncronising

signals from the FFSK modem during transmit mode.

30 FFSK receive error FFSK CRC calculation error.

31 to 33 FFSK transmit error FFSK to be transmitted corrupted or FFSK timing error.

34 Synthesiser not

locked Synthesiser taking too long to lock up.

40 to 60 Software error

codes Not helpful for servicing.

70 to 79 Programming errors Incorrect programming of the radio. Causes:

- Wrong programming software used.

- Wrong or invalid data programmed into radio.

T2000 - Out of lock indication

T2010 The active channel light is on and all other channel lights flash.

T2015 The right hand channel digit flashes.

T2020 Both BUSY & TX lights flash.

Trunking error messages

U1 – ESN – ERROR The radios ESN, has become corrupt. The radio will have to be

returned to TAIT to be re-formatted.

U2 – DATA – ERROR The programming of the radio has been lost or corrupt.

Programme the radio.

U3 – ECC – ERROR Either the wrong firmware has been fitted to the logic board, in

which case fitting the correct firmware should clear the problem.

Or the ECC has become corrupt, in which case the radio should

be returned to TAIT.

UA0 Function unavailable.

UA1 Out of range, no communications with the network.

UA2 Called unit, out of range, or switched off.

UA3 Invalid selection.

UA4 Called unit engaged – try again later.

ERROR CODE.DOC Page 3 of 3 24/07/02

Specific errors

ERROR MESSAGE MODEL ACTION

Error 0 T700 RAM problem.

Error 02 ALL A request for a block of dynamic memory from the heap

cannot be satisfied, as there is insufficient memory

available.

Error 02 ALL The available memory inside the µ

µµ

µP, for storing events,

has been used up. For example this error may occur if the

PTT is repeatedly used in quick succession.

Error 13 ALL The µ

µµ

µP has encountered an illegal instruction. This

should not happen in normal use but may occur if there is

a problem on the µ

µµ

µP bus.

Error 14 ALL The µ

µµ

µP has detected a logic low on it's XIRQ pin. This line

should always stay high.

Error 22 ALL The µ

µµ

µP is not receiving correct synchronisation signals

form the FFSK modem during transmit mode.

Error 31 ALL The µ

µµ

µP could not reply to an incoming code word within

the required time.

Error 34 ALL TX VCO out of lock.

Error 68 ALL The radio has tried to tune to an invalid channel number.

Error 70 T2035 Change firmware to v3.10 or later.

Error 70 ALL

trunking The channel number the radio has just selected is invalid

(not permitted according to the network parameters). This

may occur if a mistake is made during programming and

the network parameters "highest and lowest channel in

network" have been set wrongly, or changed after setting

all other channel parameters.

Error 75 ALL The frequency of the channel, which has just been

selected, is invalid (outside the limits allowed for the

radio). This error is usually the result of setting up the

channel blocks (trunking) incorrectly at the time it was

programmed.

Error 80 ALL The micro is receiving a continuos active signal on the

serial link from the control head (T700TR's), or

programming equipment (T500TR's). This will be visible

as a low logic level at the serial input port of the µ

µµ

µP.

CONF--ERR T2020

T2030

T2035

T2040

T2050

This happens if the radio's configuration codes become

corrupt. Switch off radio, short "factory" test points,

switch on radio for 5 seconds, switch off radio and

remove link. When the radio is switched back on it should

show "PROG", if so programme the radio with a known

good file. Trunking radios may still not work and may

need to be returned to Tait to have their electronic serial

numbers re programmed.

PROG T2020

T2040

T2050

The radio has lost it's setup information. Re-program with

a known good setup file.
