FortiClient - Administration Guide
VERSION5.4.0
FORTINET DOCUMENTLIBRARY
http://docs.fortinet.com
FORTINETVIDEOGUIDE
http://video.fortinet.com
FORTINETBLOG
https://blog.fortinet.com
CUSTOMERSERVICE&SUPPORT
https://support.fortinet.com
FORTIGATECOOKBOOK
http://cookbook.fortinet.com
FORTINETTRAININGSERVICES
http://www.fortinet.com/training
FORTIGUARDCENTER
http://www.fortiguard.com
ENDUSER LICENSE AGREEMENT
http://www.fortinet.com/doc/legal/EULA.pdf
FEEDBACK
Email: techdocs@fortinet.com
November 17, 2016
FortiClient 5.4.0 Administration Guide
04-540-292132-20161117
TABLEOFCONTENTS
Change Log 7
Introduction 8
FortiClient features 8
Standalone mode 9
Managed mode 10
FortiSandbox 10
On-Net / Off-Net 10
Licensing 11
FortiGate Client limits 11
EMS client limits 11
Installation information 12
Firmware images and tools 13
Microsoft Windows 13
Mac OS X 13
Language support 14
What’s New in FortiClient 5.4 16
New features in FortiClient 5.4.0 16
Antivirus 16
Web Filtering 17
VPN 17
Endpoint Control 18
FortiClient GUI 20
Logging 20
Provisioning FortiClient 21
Standard FortiClient installation 21
Download the FortiClient installation files 21
Install FortiClient on a Microsoft Windows computer 21
Install FortiClient on a Microsoft Server 23
Install FortiClient on a Mac OS X computer 23
Install FortiClient on an infected system 24
Install FortiClient as part of a cloned disk image 25
Deploy FortiClient using Microsoft Active Directory server 25
Deploy FortiClient using Microsoft SCCM 2012 26
SCCM setup 27
Task sequences 28
Task sequence examples for FortiClient 35
Endpoint Management 38
Configure endpoint management 38
FortiGate 39
FortiClient EMS 46
Configuring endpoint registration over a VPN 46
Remembered FortiGate/EMS 47
Roaming clients (multiple redundant gateways) example 48
View FortiClient registration in the FortiGate GUI or EMS 50
Configure the FortiGate/EMS IP address in FortiClient for registration 51
Enable FortiClient endpoint registration key password (optional) 51
Display or hide the FortiClient profile details 52
Update FortiClient registration license on FortiGate 52
Endpoint registration with AD user groups 53
Configure users and groups on your AD server 53
Configure your FortiAuthenticator 53
Configure your FortiGate/EMS 53
Connect to the FortiGate/EMS using FortiClient endpoint 54
Monitoring client registrations 55
Antivirus 56
FortiClient Antivirus 56
Enable or disable antivirus 56
FortiSandbox 57
Blocking access and communication channels 58
Notifications 58
Scan now 59
Scan a file or folder on your workstation 59
Submit a file for analysis 59
View FortiClient engine and signature versions 59
Schedule antivirus scanning 60
Add files/folders to an exclusion list 61
View quarantined threats 62
View site violations 63
View alerts dialog box 64
Realtime Protection events 64
Antivirus logging 65
Antivirus options 65
Endpoint control 65
Antivirus profile settings 66
Web Security/Web Filter 70
Enable/Disable Web Security 70
Web Security profile 70
Web Security exclusion list 71
Web Security settings 72
View violations 73
Web Filter 74
FortiGate 74
EMS 77
Application Firewall 79
FortiGate 79
EMS 81
View application firewall profile 82
View blocked applications 82
IPsec VPN and SSL VPN 83
Add a new connection 83
Create a new SSL VPN connection 83
Create a new IPsec VPN connection 84
Provision client VPN connections 87
FortiGate VPN provisioning 87
EMS VPN provisioning 88
Connect to a VPN 90
Save Password, Auto Connect, and Always Up 91
FortiToken and FortiClient VPN 92
Advanced features (Microsoft Windows) 93
Activating VPN before Windows Log on 93
Connect VPN before log on (AD environments) 93
Create a redundant IPsec VPN 93
Priority based SSL VPN connections 94
Advanced features (Mac OS X) 95
Create a redundant IPsec VPN 95
Priority based SSL VPN connections 95
VPN tunnel & script 96
Windows 96
OS X 97
Vulnerability Scan 98
Enable vulnerability scan 98
Scan now 99
View vulnerabilities 99
Settings 101
Backup or restore full configuration 101
Logging 101
Configure logging to FortiAnalyzer or FortiManager 102
Updates 104
VPN options 104
Certificate management 104
Antivirus options 105
Advanced options 105
Single Sign-On mobility agent 106
FortiClient/FortiAuthenticator protocol 106
Configuration lock 108
FortiTray 108
Connect to a VPN connection 109
Custom FortiClient Installations 110
Download the license file 110
Create a custom installer 111
FortiClient (Windows) Configurator tool 111
FortiClient (Mac OS X) Configurator tool 116
Custom installation packages 118
FortiClient (Windows) 118
Advanced FortiClient profiles 119
Provision a full XML configuration file 119
Advanced VPN provisioning 121
Appendix A - Deployment Scenarios 123
Basic FortiClient Profile 123
Advanced FortiClient Profile (Full XML Configuration) 123
Advanced FortiClient Profile (Partial XML Configuration) 124
Advanced VPN Provisioning FortiClient Profile 125
Advanced FortiClient Profile (No Settings Provisioned) 125
Using Active Directory Groups 126
Monitoring registered users 126
Customizing FortiClient using XML settings 127
Silent registration 127
Locked FortiClient settings 127
Disable unregistration 128
Putting it together 128
Off-net VPN auto-connect 128
Appendix B - Using the FortiClient API 131
Overview 131
API reference 131
Appendix C - Rebranding FortiClient 133
Appendix D - FortiClient Log Messages 139
Change Log
Change Log
Date Change Description
2015-10-19 Initial release.
2015-10-28 Updated for FortiClient 5.4.0. Clarified content in the Updates section of the Settings
chapter.
2015-12-30 Updated for FortiClient 5.4.0. The debug logging level should not be permanently
enabled in a production environment.
2016-04-07 Updated for FortiClient 5.4.0 to communicate that FortiClient SSL VPNconnections to
FortiGate support DTLS.
2016-11-17 Clarified how the Always Up setting for VPNworks.
7 Administration Guide
Fortinet Technologies Inc.
Introduction
FortiClient is an all-in-one comprehensive endpoint security solution that extends the power of Fortinet’s
Advanced Threat Protection (ATP) to end user devices. As the endpoint is the ultimate destination for malware
that is seeking credentials, network access, and sensitive information, ensuring that your endpoint security
combines strong prevention with detection and mitigation is critical.
This document provides an overview of FortiClient 5.4.0.
This document was written for FortiClient (Windows) 5.4.0. Not all features described
in this document are supported for FortiClient (Mac OS X) 5.4.0.
FortiClient features
FortiClient offers two licensing modes: Standalone mode and Managed mode. It can also be integrated with
FortiSandbox.
The following table provides a feature comparison between the standalone client (free version) and the managed
client (licensed version).
Standalone Client (Free Version) Managed Client (Licensed Version)
Installation Options
lComplete: All Endpoint Security and VPN
components will be installed.
lVPN Only: only VPN components (IPsec and
SSL) will be installed.
lCreate a custom FortiClient installer using
the FortiClient Configurator tool using the
trial mode. In trial mode, all online updates
are disabled.
Installation Options
lComplete: All Endpoint Security and VPN
components will be installed.
lVPN Only: only VPN components (IPsec and
SSL) will be installed.
lCreate a custom FortiClient installer using
the FortiClient Configurator tool.
Threat Protection
lReal-time Antivirus Protection
lAntirootkit/Antimalware
lGrayware Blocking (Adware/Riskware)
Threat Protection
lReal-time Antivirus Protection
lAntirootkit/Antimalware
lGrayware Blocking (Adware/Riskware)
lCloud Based Behavior Scanning
Web Content
lWeb Filtering
lYouTube Education Filter
Web Content
lWeb Filtering
lYouTube Education Filter
Administration Guide
Fortinet Technologies Inc.
8
Introduction FortiClient features
Standalone Client (Free Version) Managed Client (Licensed Version)
VPN
lSSL VPN
lIPsec VPN
lClient Certificate Support
lX.509 Certificate Support
lElliptical Curve Certificate Support
lTwo-Factor Authentication
VPN
lSSL VPN
lIPsec VPN
lClient Certificate Support
lX.509 Certificate Support
lElliptical Curve Certificate Support
lTwo-Factor Authentication
Logging
lVPN, Antivirus, Web Security, and Update
Logging
lView logs locally
Logging
lVPN, Application Firewall, Antivirus, Web
Filter, Update, and Vulnerability Scan
Logging
lView logs locally
Application Control
lApplication Firewall
lBlock Specific Application Traffic
Vulnerability Management
lVulnerability Scan
lLink to FortiGuard with information on the
impact and recommended actions
Central Management
lCentralized Client Management and
monitoring
lCentralized configuration provisioning and
deployment
lEnforcement of enterprise security policies.
Central Logging
lUpload logs to a FortiAnalyzer or
FortiManager. FortiClient must be registered
to FortiGate to upload logs to FortiAnalyzer
or FortiManager.
Standalone mode
In standalone mode, FortiClient is not registered to a FortiGate or Enterprise Management Server (EMS). In this
mode, FortiClient is free both for private individuals and commercial businesses to use; no license is required. All
features and functions are activated.
9 Administration Guide
Fortinet Technologies Inc.
FortiClient features Introduction
Managed mode
Companies with large installations of FortiClient usually need a method to manage their endpoints. This is
accomplished by registering each FortiClient to a FortiGate or an Enterprise Management Server (EMS). In this
mode, FortiClient licensing is applied to the FortiGate or EMS. No separate license is required on FortiClient
itself.
FortiSandbox
FortiSandbox offers the capabilities to analyze new, previously unknown and undetected virus samples in
realtime. Files sent to it are scanned first, using similar Antivirus (AV) engine and signatures as are available on
the FortiOS and FortiClient. If the file is not detected but is an executable file, it is run in a Microsoft Windows
virtual machine (VM) and monitored. The file is given a rating or score based on its activities and behavior in the
VM.
FortiClient integration with FortiSandbox allows users to submit files to FortiSandbox for automatic scanning.
When configured, FortiClient will send supported files downloaded over the internet to FortiSandbox if they
cannot be detected by the local, real-time scanning. Access to the downloaded file can be blocked until the
scanning result is returned.
As FortiSandbox receives files for scanning from various sources, it collects and generates AV signatures for such
samples. FortiClient periodically downloads the latest AV signatures from the FortiSandbox, and applies them
locally to all real-time and on-demand AV scanning.
For more information, see the FortiSandbox Administration Guide, available in the Fortinet Document Library.
This feature requires a FortiSandbox running version 2.1 or newer and is only available
on FortiClient (Windows).
On-Net / Off-Net
The on-net feature requires the use of a FortiGate as a DHCP server. This is usually configured on the same
FortiGate that the FortiClient will be registered. When the device that FortiClient is running on has an IP address
from the FortiGate's DHCP server, it is on-net. For any other IP addresses, it is off- net.
There is a new way to configure the on-net feature. On the FortiGate, the DHCP server can be used, or several
network subnets can be provided. FortiClient will be on-net if:
lIt is registered using EC to the FortiGate,
lIt belongs to one of the pre-configured on-net subnets, or
lIt provides the DHCP for on-net properties.
Otherwise, FortiClient will be off-net.
Administration Guide
Fortinet Technologies Inc.
10
Introduction Licensing
Licensing
Licensing on the FortiGate is based on the number of registered clients. FortiGate 30 series and higher models
support ten (10) free managed FortiClient licenses. For additional managed clients, a FortiClient license
subscription must be purchased. The maximum number of managed clients varies per device model.
The VPN on-net, off-net feature in Endpoint Control will be activated only when the
FortiGate, to which FortiClient is registered, is running FortiOS 5.2 or 5.4 with a
FortiClient 5.2 or 5.4 license.
FortiGate Client limits
The following table shows client limits per FortiGate model series.
FortiGate Series Free Registrations FortiClient License Upgrade
FortiGate/FortiWiFi 30 to 90 series 10 1 year FortiClient license subscription
for up to 200 clients
FortiGate 100 to 300 series 10 1 year FortiClient license subscription
for up to 600 clients
FortiGate 500 to 800 series, FortiGate
VM01, FortiGate VM02
10 1 year FortiClient license subscription
for up to 2000 clients
FortiGate 1000 series, FortiGate VM04 10 1 year FortiClient license subscription
for up to 8000 clients
FortiGate 3000 to 5000 series,
FortiGate VM08
10 1 year FortiClient license subscription
for up to 20000 clients
In high availability (HA) configurations, all cluster members require an upgrade license
key.
For more information, go to www.forticlient.com.
The FortiClient license for FortiOS 5.2 includes the license file required to use the
FortiClient Configurator tool used to create custom FortiClient installers. The Con-
figurator tool also allows you to rebrand the installer file.
EMS client limits
A newly installed EMS offers 20 000 trial client licenses over a period of 60 days from the day of installation. After
the trail period lapses, the number of client licenses will be 10, same as for a new FortiGate to which no
11 Administration Guide
Fortinet Technologies Inc.
Installation information Introduction
FortiClient license has been applied.
A license may be applied to the EMS at any time during or after the trial period. Licenses are available in
multiples of 100 seats, with a minimum of 100 seats.
Installation information
The following table lists operating system support and the minimum system requirements.
Operating System Support Minimum System Requirements
lMicrosoft Windows XP (32-bit)
lMicrosoft Windows 7 (32-bit and 64-bit)
lMicrosoft Windows 8 (32-bit and 64-bit)
lMicrosoft Windows 8.1 (32-bit and 64-bit)
lMicrosoft Windows 10 (32-bit and 64-bit)
lMicrosoft Internet Explorer version 8 or later
lMicrosoft Windows compatible computer with Intel
processor or equivalent
lCompatible operating system and minimum
512MB RAM
l600MB free hard disk space
lNative Microsoft TCP/IP communication protocol
lNative Microsoft PPP dialer for dial-up connections
lEthernet NIC for network connections
lWireless adapter for wireless network connections
lAdobe Acrobat Reader for documentation
lMSI installer 3.0 or later.
lMicrosoft Windows Server 2008 R2
lMicrosoft Windows Server 2012
lMicrosoft Windows Server 2012 R2
lMicrosoft Internet Explorer version 8 or later
lMicrosoft Windows compatible computer with Intel
processor or equivalent
lCompatible operating system and minimum
512MB RAM
l600MB free hard disk space
lNative Microsoft TCP/IP communication protocol
lNative Microsoft PPP dialer for dial-up connections
lEthernet NIC for network connections
lWireless adapter for wireless network connections
lAdobe Acrobat Reader for documentation
lMSI installer 3.0 or later.
lMac OS X v10.8 Mountain Lion
lMac OS X v10.9 Mavericks
lMac OS X v10.10 Yosemite
lMac OS X v10.11 El Capitan
lApple Mac computer with an Intel processor
l256MB of RAM
l20MB of hard disk drive (HDD) space
lTCP/IP communication protocol
lEthernet NIC for network connections
lWireless adapter for wireless network connections
Administration Guide
Fortinet Technologies Inc.
12
Introduction Firmware images and tools
Firmware images and tools
Microsoft Windows
The following files are available in the firmware image file folder:
lFortiClientSetup_5.4.xx.xxxx.exe
Standard installer for Microsoft Windows (32-bit).
lFortiClientSetup_5.4.xx.xxxx.zip
A zip package containing FortiClient.msi and language transforms for Microsoft Windows (32-bit). Some
properties of the MSI package can be customized with FortiClient Configurator tool.
lFortiClientSetup_5.4.xx.xxxx_x64.exe
Standard installer for Microsoft Windows (64-bit).
lFortiClientSetup_5.4.xx.xxxx_x64.zip
A zip package containing FortiClient.msi and language transforms for Microsoft Windows (64-bit). Some
properties of the MSI package can be customized with FortiClient Configurator tool.
lFortiClientTools_5.4.xx.xxxx.zip
A zip package containing miscellaneous tools including the FortiClient Configurator tool and VPN Automation
files:
lOnlineInstaller
This file downloads and installs the latest FortiClient file from the public FDS.
lFortiClientConfigurator
An installer repackaging tool that is used to create customized installation packages.
lFortiClientVirusCleaner
A virus cleaner.
lSSLVPNcmdline
Command line SSL VPN client.
lSupportUtils
Includes diagnostic, uninstallation, and reinstallation tools.
lVPNAutomation
A VPN automation tool.
When creating a custom FortiClient 5.4 installer using the FortiClient Configurator
tool, you can choose which features to install. You can also select to enable or disable
software updates, configure SSO, and rebrand FortiClient
Mac OS X
The following files are available in the firmware image file folder:
13 Administration Guide
Fortinet Technologies Inc.
Language support Introduction
lFortiClient_5.4.x.xxx_macosx.dmg
Standard installer or Mac OS X.
lFortiClientTools_5.4.x.xxx_macosx.tar
FortiClient includes various utility tools and files to help with installations. The following tools and files are
available in the FortiClientTools .tar file:
lOnlineInstaller
This file downloads and installs the latest FortiClient file from the public FDS.
lFortiClientConfigurator
An installer repackaging tool that is used to create customized installation packages.
lRebrandingResources
Rebranding resources used by the FortiClient Configurator tool.
When creating a custom FortiClient 5.4.0 installer using the FortiClient Repackager tool, you can choose to
install Everything, VPN Only, or SSO only. You can also select to enable or disable software updates and rebrand
FortiClient.
FortiClient 5.4 cannot use FortiClient version 5.0 licenses. To use FortiClient Con-
figurator, you need to use the FortiClient version 5.4 license file.
Language support
The following table lists FortiClient language support information.
Language Graphical User Interface XML Configuration Documentation
English (United States) ü ü ü
Chinese (Simplified) ü- -
Chinese (Traditional) ü- -
French (France) ü- -
German ü- -
Japanese ü- -
Korean ü- -
Portuguese (Brazil) ü- -
Spanish (Spain) ü- -
Please review the FortiClient Release Notes prior to upgrading. Release Notes are
available in the Fortinet Document Library.
Administration Guide
Fortinet Technologies Inc.
14
Introduction Language support
FortiClient language is dependent on the regional settings on the client workstation.
When the regional language setting is not supported, FortiClient defaults to English.
15 Administration Guide
Fortinet Technologies Inc.
What’s New in FortiClient 5.4
The following is a list of new features and enhancements in FortiClient 5.4.
This document was written for FortiClient (Windows) 5.4.0. Not all features described
in this document are supported for FortiClient (Mac OS X) 5.4.0.
New features in FortiClient 5.4.0
The following is a list of new features in FortiClient version 5.4.0.
Antivirus
Advanced Persistent Threats
FortiClient 5.4.0 has enhanced capabilities for the detection of Advanced Persistent Threats (APT). There are two
changes added in this respect:
lBotnet Command and Control Communications Detection
lFortiSandbox integration (Windows only)
Botnet Communication Detection
Botnets running on compromised systems usually generate outbound network traffic directed towards Command
and Control (C&C) servers of their respective owners. The servers may provide updates for the botnet, or
commands on actions to execute locally, or on other accessible, remote systems. When the new botnet feature is
enabled, FortiClient monitors and compare network traffic with a list of known Command and Control servers.
Any such network traffic will be blocked.
FortiSandbox Integration
FortiSandbox offers the capabilities to analyze new, previously unknown and undetected virus samples in real-
time. Files sent to it are scanned first, using similar Antivirus (AV) engine and signatures as are available on the
FortiOS and FortiClient. If the file is not detected but is an executable file, it is run (sandboxed) in a Microsoft
Windows virtual machine (VM) and monitored. The file is given a rating or score based on its activities and
behavior in the VM.
FortiClient integration with FortiSandbox allows users to submit files to FortiSandbox for automatic scanning.
When configured, FortiClient will send supported files downloaded over the internet to FortiSandbox if they
cannot be detected by the local, real-time scanning. Access to the downloaded file is blocked until the scanning
result is returned.
As FortiSandbox receives files for scanning from various sources, it collects and generates AV signatures for such
samples. FortiClient periodically downloads the latest AV signatures from the FortiSandbox, and applies them
locally to all real-time and on-demand AV scanning.
Administration Guide
Fortinet Technologies Inc.
16
What’s New in FortiClient 5.4 New features in FortiClient 5.4.0
This feature requires a FortiSandbox running version 2.1 or newer and is only available
on FortiClient (Windows).
Enhanced Real-Time Protection Implementation
The Real-Time Protection (RTP) or on-access feature in FortiClient uses tight integration with Microsoft Windows
to monitor files locally, or over a network file system, as they are being downloaded, saved, run, copied,
renamed, opened, or written to. The FortiClient driver coupling with Windows has been re-written to use modern
APIs provided by Microsoft. All basic features remain the same, with a few minor differences in behavior. Some
noticeable performance enhancements could be observed in various use case scenarios.
This feature is only available on FortiClient (Windows).
Web Filtering
Web Browser Usage and Duration
If configured, FortiClient will record detailed information about the user's web browser activities, such as:
lA history of websites visited by the user (as shown in regular web browser history)
lAn estimate of the duration or length of stay on the website.
These logs are sent to FortiAnalyzer, if configured. With FortiAnalyzer 5.4.0 or newer, the FortiClient logs sent
from various endpoints may be viewed in FortiView.
This feature requires FortiAnalyzer 5.4.0 or newer.
VPN
Authorized Machine Detection
For enterprises where new computers may be brought into the organization by employees, FortiClient can be
configured to check or identify the computer before allowing it to establish IPsec VPN or SSL VPN connections to
the FortiGate. The administrator may configure restrictions with one or more of the following:
lRegistry check: Ensure a specific registry path contains a predetermined value
lFile check: Verify the existence of a specific file at a specified location
lApplication check: Ensure that a specific application is installed and running
The verification criteria can be configured using advanced FortiClient XML configurations on the FortiGate or
Enterprise Management Server (EMS).
This feature only applies to FortiClient (Windows).
17 Administration Guide
Fortinet Technologies Inc.
New features in FortiClient 5.4.0 What’s New in FortiClient 5.4
New SSL VPN Windows driver
The FortiClient SSL VPN driver pppop.sys was re-written to use the latest Microsoft recommended CoNDIS
WAN driver model. The new driver is selected when FortiClient is installed on Windows 7 or newer. The SSL VPN
driver included in the previous versions of FortiClient will still be maintained.
This feature only applies to FortiClient (Windows).
New IPsec VPN Windows drivers
FortiClient IPsec VPN drivers have been updated to support Microsoft Windows NDIS 6.3 specification. The new
drivers are compatible with Microsoft Windows 8.1 or newer.
This feature only applies to FortiClient (Windows).
Support for DTLS
FortiClient SSL VPN connections to FortiGate now support Datagram Transport Layer Security (DTLS) by using
User Datagram Protocol (UDP) as the transport protocol. Previously FortiClient SSL VPN connections supported
only Transport Control Protocol (TCP). You can now use FortiGate to configure SSL VPN connections that use
DTLS. You cannot use FortiClient to configure SSL VPN connections that use DTLS. When FortiClient endpoints
use a DTLS-enabled SSL VPN connection with FortiGate, and FortiGate communicates DTLS support,
FortiClient uses DTLS via UDP. If DTLS fails, FortiClient will fall back to use TLS to establish an SSL VPN
connection.
This feature only applies to FortiClient (Windows).
Endpoint Control
Integration with the new Enterprise Management Server
The Enterprise Management Server (EMS) is a new product from Fortinet for businesses to use to manage their
computer endpoints. It runs on a Windows Server, not requiring a physical Fortinet device. Administrators may
use it to gain insight into the status of their endpoints. The EMS supports devices running Microsoft Windows,
Mac OS X, Android, and iOS.
FortiClient Endpoint Control (EC) protocol has been updated to seamlessly integrate with the EMS. Various
changes were added to support EMS features, including:
lDeployment of FortiClient to new Microsoft Windows devices
lContinuous monitoring of device statuses
lAV engine and signature update status reports
lAV scanning schedules and requests for AV scans
lNotifications about protection statuses.
Administration Guide
Fortinet Technologies Inc.
18
What’s New in FortiClient 5.4 New features in FortiClient 5.4.0
FortiGate Network Access Control when FortiClient is Deployed using EMS
The new EMS can be used to deploy FortiClient to a large number of Microsoft Windows endpoints. While
creating a profile for FortiClient deployment, the EMS administrator can choose to configure the FortiClient to
register to the same EMS, or to a FortiGate.
Changes in FortiClient 5.4.0 allow the EMS administrator to deploy FortiClient to endpoints, and configure it to
register to a FortiGate, while simultaneously notifying the EMS of its registration status. The FortiClient EC
registration to the FortiGate is required for Network Access Compliance (NAC). The administrator can configure
the FortiGate to allow access to network resources only if the client is compliant with the appropriate interface EC
profile.
EMS can only deploy FortiClient to endpoint devices that are running Microsoft Win-
dows. This feature requires FortiOS 5.4.0 or newer.
Quarantine an Infected Endpoint from the FortiGate or EMS
A computer endpoint that is considered to be infected may be quarantined by the FortiGate or EMS
administrator. FortiClient needs to be online, using EC, and registered to the FortiGate or EMS.
Once quarantined, all network traffic to or from the infected endpoint will be blocked locally. This allows time for
remediation actions to be taken on the endpoint, such as scanning and cleaning the infected system, reverting to
a known clean system restore point, or re-installing the operating system.
The administrator may un-quarantine the endpoint in the future from the same FortiGate or EMS.
This feature requires FortiOS 5.4.0 or newer, or FortiClient EMS 1.0 or newer.
Importing FortiGate CA Certificate after EC Registration
When the FortiGate is configured to use SSL deep inspection, users visiting encrypted websites will usually
receive an invalid certificate warning. The certificate signed by the FortiGate does not have a Certificate Authority
(CA) at the endpoint to verify it. Users can manually import the FortiGate CA certificate to stop the error from
being displayed, however, all users will have to do the same.
When registering EC to a FortiGate, the FortiClient will receive the FortiGate's CA certificate and install it into the
system store. If Firefox is installed on the endpoint, the FortiGate's CA certificate will also be installed into the
Firefox certificate store. This way the end user will no longer receive the invalid certificate error message when
visiting encrypted websites.
FortiGate CA certificates will be removed from the system store if FortiClient is unin-
stalled.
Enhancement to On-net/Off-net Configuration
The on-net feature requires the use of a FortiGate as a DHCP server. This is usually configured on the same
FortiGate that the FortiClient will be registered. When the device that FortiClient is running on has an IP address
from the FortiGate's DHCP server, it is on-net. For any other IP addresses, it is off- net.
There is a new way to configure the on-net feature. On the FortiGate, the DHCP server can be used, or several
network subnets can be provided.
19 Administration Guide
Fortinet Technologies Inc.
New features in FortiClient 5.4.0 What’s New in FortiClient 5.4
FortiClient will be on-net if:
lIt is registered using EC to the FortiGate,
lIt belongs to one of the pre-configured on-net subnets, or
lIt provides the DHCP for on-net properties.
Otherwise, FortiClient will be off-net.
FortiClient GUI
Antivirus Settings Page
With the introduction of botnet detection, and the integration with FortiSandbox with FortiClient (Windows), the
AV settings page on the FortiClient GUI has been updated to allow configuration of the new features. The AV
settings page is accessible from the FortiClient dashboard. Select the AV tab on the left pane. Then click the
settings icon on Real-Time Protection in the right pane.
The following may be selected on the AV settings page:
lFile scanning (previously, Real-Time Protection or RTP)
lScan unknown, supported files using FortiSandbox (Windows only)
lMalicious website detection
lBotnet detection (block known communication channels)
To use FortiSandbox , file scanning must be enabled (Windows only).
FortiClient Banner Design
If FortiClient (full version or VPN only) is running in standalone mode and not registered to a FortiGate or EMS, a
single banner at the bottom of the GUI is displayed. When registered to a FortiGate or EMS, the banner is hidden
by default. Similarly, when created from a FortiClient Configurator (Windows) or Repackager (OS X), no banner is
displayed by default.
Logging
Enhancement to FortiClient logs
FortiClient will create a log entry to show just the URL visited by the user through a web browser. This is in
addition to the network level logs generated by FortiClient.
Administration Guide
Fortinet Technologies Inc.
20
Provisioning FortiClient
FortiClient can be installed on a standalone computer using the installation wizard or deployed to multiple
Microsoft Windows systems using Microsoft Active Directory (AD) or the Microsoft System Center 2012
Configuration Manager (SCCM).
This chapter contains the following sections:
lStandard FortiClient installation
lInstall FortiClient on an infected system
lInstall FortiClient as part of a cloned disk image
lDeploy FortiClient using Microsoft Active Directory server
lDeploy FortiClient using Microsoft SCCM 2012
For information on customizing your FortiClient installation, see Custom FortiClient Installations.
Standard FortiClient installation
The following section describes installing FortiClient to a standalone Microsoft Windows and Apple Mac
computer.
Download the FortiClient installation files
The FortiClient installation files can be downloaded from the following sites:
lFortinet Customer Service & Support: https://support.fortinet.com
Requires a support account with a valid support contract. Download either the Microsoft Windows (32-bit/64-
bit) or the Mac OS X online installation file.
lFortiClient homepage: www.forticlient.com
Download the FortiClient online installation file. The installer file performs a virus and malware scan of the
target system prior to installing FortiClient.
lFortinet Resource Center: http://www.fortinet.com/resource_center/product_downloads.html
Download the FortiClient online installation file. On this page you can download the latest version of
FortiClient for Microsoft Windows and Mac OS X, and link to the iOS, and Android versions.
In FortiOS 5.0.1 and later, you can download the FortiClient installation files in the FortiGate dashboard. Go to
System > Dashboard > Status, in the License Information widget select Mac or Windows to download the
FortiClient Online Installer file.
Install FortiClient on a Microsoft Windows computer
The following instructions will guide you though the installation of FortiClient on a Microsoft Windows computer.
For more information, see the FortiClient (Windows) Release Notes.
When installing FortiClient, it is recommended to use the FortiClientOnlineInstaller file. This file will launch the
FortiClient Virus Cleaner which will scan the target system prior to installing the FortiClient application.
21 Administration Guide
Fortinet Technologies Inc.
Standard FortiClient installation Provisioning FortiClient
To check the digital signature of FortiClient, right-click on the installation file and select Properties. In this menu
you can set file attributes, run the compatibility troubleshooter, view the digital signature and certificate, install
the certificate, set file permissions, and view file details.
To install FortiClient (Windows):
1. Double-click the FortiClient executable file to launch the setup wizard. The Setup Wizard will launch on your
computer. When using the FortiClient Online Installer file, the FortiClient Virus Cleaner will run before launching
the Setup Wizard.
If a virus is found that prevents the infected system from downloading the new FortiClient package, see
Install FortiClient on an infected system on page 24.
2. In the Welcome screen, read the license agreement, select the checkbox, and select Next to continue. You have
the option to print the EULA in this License Agreement screen. The Choose Setup Type screen is displayed.
3. Select one of the following setup types:
lComplete: All Endpoint Security and VPN components will be installed.
lVPN Only: Only VPN components (IPsec and SSL) will be installed.
4. Select Next to continue. The Destination Folder screen is displayed.
5. Select Change to choose an alternate folder destination for installation.
Administration Guide
Fortinet Technologies Inc.
22
Provisioning FortiClient Standard FortiClient installation
6. Select Next to continue.
FortiClient will search the target system for other installed antivirus software. If found, FortiClient will display
the Conflicting Antivirus Software page. You can either exit the current installation and uninstall the
antivirus software, disable the antivirus feature of the conflicting software, or continue with the installation
with FortiClient real-time protection disabled.
This dialog box is displayed during a new installation of FortiClient and when
upgrading from an older version of FortiClient which does not have the antivirus
feature installed.
It is recommended to uninstall the conflicting antivirus software before installing
FortiClient or enabling the antivirus real-time protection feature. Alternatively, you can
disable the antivirus feature of the conflicting software.
7. Select Next to continue.
8. Select Install to begin the installation.
9. Select Finish to exit the FortiClient Setup Wizard.
On a new FortiClient installation, you do not need to reboot your system. When upgrading the FortiClient
version, you must restart your system for the configuration changes made to FortiClient to take effect. Select
Yes to restart your system now, or select No to manually restart later.
FortiClient will update signatures and components from the FortiGuard Distribution Network (FDN).
10. If the FortiGate/EMS on the network is broadcasting discovery messages, FortiClient will attempt to register to the
FortiGate.
If the FortiGate is not broadcasting discovery messages, select the Register Endpoint button in the
FortiClient header, specify the address of the FortiGate in the text field, and select the Go icon.
If you have any questions about registering FortiClient to FortiGate, please contact
your network administrator.
11. To launch FortiClient, double-click the desktop shortcut icon.
Install FortiClient on a Microsoft Server
You can install FortiClient on a Microsoft Windows Server 2008 R2, 2012, or 2012 R2 server. You can use the
regular FortiClient Windows image for Server installations.
Please refer to the Microsoft knowledge base for caveats on installing antivirus soft-
ware in a server environment. See the Microsoft Anti-Virus exclusion list: http://so-
cial.technet.microsoft.com/wiki/contents/articles/953.microsoft-anti-virus-
exclusion-list.aspx
Install FortiClient on a Mac OS X computer
The following instructions will guide you though the installation of FortiClient on a Mac OS X computer. For more
information, see the FortiClient (Mac OS X) Release Notes.
23 Administration Guide
Fortinet Technologies Inc.
Install FortiClient on an infected system Provisioning FortiClient
To install FortiClient (Mac OS X):
1. Double-click the FortiClient .dmg installer file to launch the FortiClient installer. The FortiClient Installer will install
FortiClient on your computer. Select Continue.
2. Select the lock icon in the upper right corner to view certificate details.
3. Read the Software License Agreement and select Continue. You have the option to print or save the Software
Agreement in this window. You will be prompted to Agree with the terms of the license agreement.
4. Select the destination folder for the installation.
5. Select Install to perform a standard installation on this computer. You can change the install location from this
screen.
6. Depending on your system, you may be prompted to enter your system password.
7. The installation was successful. Select Close to exit the installer.
8. FortiClient has been saved to the Applications folder.
9. Double-click the FortiClient icon to launch the application. The application console loads to your desktop. Select
the lock icon in the FortiClient console to make changes to the FortiClient configuration.
Install FortiClient on an infected system
The FortiClient installer always runs a quick antivirus scan on the target host system before proceeding with the
complete installation. If the system is clean, installation proceeds as usual.
Any virus found during this step is quarantined before installation continues.
In case a virus on an infected system prevents downloading of the new FortiClient package, use the following
process:
lBoot into “safe mode with networking” (which is required for the FortiClient installer to download the latest signature
packages from the Fortinet Distribution Network).
lRun the FortiClient installer.
Administration Guide
Fortinet Technologies Inc.
24
Provisioning FortiClient Install FortiClient as part of a cloned disk image
This scans the entire file system. A log file is generated in the logs sub-directory. If a virus is found, it will be
quarantined. When complete, reboot back into normal mode and run the FortiClient installer to complete the
installation.
Microsoft Windows will not allow FortiClient installation to complete in safe mode. An
error message will be generated. It is necessary to reboot back into normal mode to
complete the installation.
Install FortiClient as part of a cloned disk image
If you configure computers using a cloned hard disk image, you need to remove the unique identifier from the
FortiClient application. You will encounter problems with FortiGate if you deploy multiple FortiClient applications
with the same identifier.
This section describes how to include a custom FortiClient installation in a cloned hard disk image but remove its
unique identifier. On each computer configured with the cloned hard disk image, the FortiClient application will
generate its own unique identifier the first time the computer is started.
To include a FortiClient installation in a hard disk image:
1. Using an MSI FortiClient installer, install and configure the FortiClient application to suit your requirements.
You can use a standard or a customized installation package.
2. Right-click the FortiClient icon in the system tray and select Shutdown FortiClient.
3. From the folder where you expanded the FortiClientTools.zip file, run RemoveFCTID.exe. The RemoveFCTID
tool requires administrative rights.
Do not include the RemoveFCTID tool as part of a logon script.
4. Shut down the computer.
Do not reboot the Windows operating system on the computer before you create the
hard disk image. The FortiClient identifier is created before you log on.
5. Create the hard disk image and deploy it as needed.
Deploy FortiClient using Microsoft Active Directory server
There are multiple ways to deploy FortiClient to endpoint devices including using Microsoft Active Directory (AD).
The following instructions are based from Microsoft Windows Server 2008. If you are
using a different version of Microsoft Server, your MMC or snap-in locations may be dif-
ferent.
25 Administration Guide
Fortinet Technologies Inc.
Deploy FortiClient using Microsoft SCCM 2012 Provisioning FortiClient
Using Microsoft AD to deploy FortiClient:
1. On your domain controller, create a distribution point.
2. Log on to the server computer as an administrator.
3. Create a shared network folder where the FortiClient MSI installer file will be distributed from.
4. Set file permissions on the share to allow access to the distribution package. Copy the FortiClient MSI installer
package into this share folder.
5. Select Start > Administrative Tools > Active Directory Users and Computers.
6. After selecting your domain, right-click to select a new Organizational Unit (OU).
7. Move all the computers you wish to distribute the FortiClient software to into the newly-created OU.
8. Select Start > Administrative Tools > Group Policy Managementt. The Group Policy Management MMC Snap-in
will open. Select the OU you just created. Right-click it, Select Create a GPO in this domain, and Link it here.
Give the new GPO a name then select OK.
9. Expand the Group Policy Object container and find the GPO you just created. Right-click the GPO and select Edit.
The Group Policy Management Editor MMC Snap-in will open.
10. Expand Computer Configuration > Policies > Software Settings. Right-click Software Settings and select New >
Package.
11. Select the path of your distribution point and FortiClient installer file and then select Open. Select Assigned and
select OK. The package will then be generated.
12. If you wish to expedite the installation process, on both the server and client computers, force a GPO update.
13. The software will be installed on the client computer’s next reboot. You can also wait for the client computer to poll
the domain controller for GPO changes and install the software then.
Uninstall FortiClient using Microsoft Active Directory server:
1. On your domain controller, select Start > Administrative Tools > Group Policy Management. The Group Policy
Management MMC Snap-in will open. Expand the Group Policy Objects container and right-click the Group Policy
Object you created to install FortiClient and select Edit. The Group Policy Management Editor will open.
2. Select Computer Configuration > Policy > Software Settings > Software Installation. You will now be able to see
the package that was used to install FortiClient.
3. Right-click the package, select All Tasks > Remove. Choose Immediately uninstall the software from users and
computers, or Allow users to continue to use the software but prevent new installations. Select OK. The package
will delete.
4. If you wish to expedite the uninstall process, on both the server and client computers, force a GPO update as
shown in the previous section. The software will be uninstalled on the client computer’s next reboot. You can also
wait for the client computer to poll the domain controller for GPO changes and uninstall the software then.
Deploy FortiClient using Microsoft SCCM 2012
The Microsoft System Center 2012 Configuration Manager (SCCM) may be used to deploy and manage multiple
FortiClient Installations. This section presents various scenarios that you can utilize.
A fully functional SCCM server, along with discovered devices, is required. Visit the Microsoft web site for
supporting documentation.
Administration Guide
Fortinet Technologies Inc.
26
Provisioning FortiClient Deploy FortiClient using Microsoft SCCM 2012
These instructions assume you have already installed and configured SCCM. If you
have not, please refer to Microsoft’s online help sources for information on this task.
The Microsoft System Center 2012 Configuration Manager (SCCM) may be used to deploy and manage multiple
FortiClient Installations. This chapter presents various scenarios that you can utilize.
A fully functional SCCM server, along with discovered devices, is required. Visit the Microsoft web site for
supporting documentation.
The following topics are detailed in this section:
lSCCM setup
lTask sequences
lTask sequence examples for FortiClient.
SCCM setup
Microsoft maintains a public free virtual lab of the System Center 2012 Configuration Manager (SCCM) at
http://technet.microsoft.com/virtuallabs/bb539977.
At this page you can access a completely installed and properly configured system that can be used for testing
various SCCM deployment scenarios. For ongoing enterprise use, a new system has to be created and
configured.
The following subsections discuss some of the preparations required to enable control of FortiClient host
computers.
Client discovery options and configuration
The uses various methods to discover the Windows devices that an administrator can control on the network. One
such method is the use of a common domain. To use this method, the Windows server hosting the Configuration
Manager should be configured as domain controller. All Windows devices that will be managed should then join
the domain. The Configuration Manager automatically discovers all Windows devices that join.
Client installation
The Configuration Manager console may be used to install configuration manager client software on target
Windows devices that have joined the controlled domain. This is required for pushing the configuration to the
devices.
Client policy polling interval settings
The configuration manager client on each Windows device polls for policy changes on the server at a regular
interval. The polling interval defaults to 60 minutes. Each newly pushed or deployed task will run on all selected
clients within this polling interval. You can customize the polling interval as required.
Client collections
New configurations are usually deployed to collections of devices. All of the devices that have joined the
controlled domain will be added to a default collection.
27 Administration Guide
Fortinet Technologies Inc.
Deploy FortiClient using Microsoft SCCM 2012 Provisioning FortiClient
You may want to deploy a different set of configurations to different groups of devices based on your user base.
This can be accomplished by creating different client collections. Devices that have joined the domain will be
added to one or more of those collections. Configurations may then be selectively deployed.
Client security issues
The Configuration Manager is able to deploy a large variety of applications to all the devices that joined the
domain. Most of these tasks run with the administrator or system user authorisation level on the client devices. It
is important to keep the Configuration Manager host under the highest level of security control possible.
It is also important to always test new planned application deployments in a controlled lab environment, or on a
small client collection, before deploying to the entire client base.
Network share for all clients
The Configuration Manager console is used to deploy applications to client devices. Some of the applications
require specification of files by file path and name. The client devices must have access to the files when the
applications run. For instance, to upload a FortiClient XML configuration file to a given client collection, all client
devices in the collection must independently have local access to the new XML configuration file.
The files may be provided by any suitable method. Examples include use of an HTTP or FTP server. The
examples in this document use a network share. This should be available to all devices on the given client
collection.
Task sequences
The Configuration Manager provides task sequences as a means of deploying commands to discovered clients
without requiring user intervention. The FortiClient configuration examples in this chapter use the Run Command
Line task sequences to run various command-line commands on client devices.
Here is a simple example of how task sequences may be used to control client devices.
In this example, a simple set of command-line commands are created in the Configuration Manager console.
Once deployed, the commands will print information requested to the log file for each client.
The following commands will be executed on each client:
cd
dir c:\users
whoami
The first command will print the current working directory. This is likely to be c:\windows\system32. The
second command will print the contents of the specified directory. The third command will print the name of the
current user (the user under which the task sequence is running).
The output of the commands can be found in the log file on each client device at:
C:\Windows\CCM\Logs\smsts.log
Administration Guide
Fortinet Technologies Inc.
28
Provisioning FortiClient Deploy FortiClient using Microsoft SCCM 2012
To create a new task sequence:
1. Launch the Configuration Manager console. The Configuration Manager console opens.
2. Select Software Library > Overview > Operating Systems > Task Sequences.
3. Right-click the Task Sequence menu item and select Create Task Sequence.
Alternatively, you can select Create Task Sequence in the toolbar.
The Create Task Sequence Wizard opens.
4. Select the Create a new custom task sequence radio button. Then select Next to proceed.
5. Enter a name for the task sequence.
29 Administration Guide
Fortinet Technologies Inc.
Deploy FortiClient using Microsoft SCCM 2012 Provisioning FortiClient
6. Enter a comment to describe the task sequence.
7. Select Next to proceed.
A summary of the task sequence configuration is displayed.
8. Select Close to save the configuration. The new task sequence is created and displayed in the Configuration
Manager console.
9. Select Task Sequences in the menu in the left pane of the Configuration Manager console. The new task
sequence is displayed in the right pane.
To add individual tasks into the task sequence:
1. Right-click in the newly created task sequence.
2. From the shortcut menu list, select Edit. The Task Sequence Editor dialog box is displayed.
Alternatively, select the Task Sequence and select the Edit icon in the toolbar.
3. Select the Add drop-down button.
4. From the drop-down list, select General and the select Run Command Line.
A new tab is displayed in the right pane of the dialog box.
5. Configure the following settings:
Name Enter a name for the command.
Description Enter a description for the command.
Administration Guide
Fortinet Technologies Inc.
30
Provisioning FortiClient Deploy FortiClient using Microsoft SCCM 2012
Command line Enter the command line in the text field.
The command will usually start with “cmd /c”. For instance, the first command in this
example is entered as:
cmd /c cd
cmd /c dir c:\users
cmd /c whoami
6. Select Apply to apply the configuration.
7. Select OK to continue.
The task sequence will be saved with the three command-line tasks. To view or modify the tasks, select Edit
in the short-cut menu for the selected task sequence.
There are three commands in this example. Each of the commands may be created as
a single task. There will be a total of three tasks in the left pane of the dialog box. Each
of the tasks will have one of the command-line commands:
cmd /c cd
cmd /c dir c:\users
cmd /c whoami
This format is preferred as it isolates any client errors to a specific task.
The three commands may also be combined into a lengthy single command:
cmd /c cd ; dir c:\users ; whoami
This format may mask task sequence errors. It is not recommended.
There is also an option to use a batch script.
Deploy the task sequence:
1. Right-click the task sequence.
2. Select Deploy in the right-click menu list. The Deploy Software Wizard dialog box opens.
Alternatively, select the Task Sequence and select the Deploy icon in the toolbar.
3. Select Browse.
31 Administration Guide
Fortinet Technologies Inc.
Deploy FortiClient using Microsoft SCCM 2012 Provisioning FortiClient
The Browse Collections dialog box appears listing all currently configured client collections.
4. Select the client collection to which this task sequence should be deployed
5. Select OK to close the Browse Collections dialog box. Pressing CTRL returns you to the General tab of the
Deploy Software Wizard dialog box.
6. Select Next. The Deployment Settings tab is displayed
7. In the Purpose drop-down menu select Required. This makes the task mandatory for all clients receiving it.
8. Select the Send wake-up packets checkbox to enable this feature.
9. Select Next. The Scheduling tab is displayed
10. Select New. In the Assignment Schedule dialog box select the Assign immediately after this event radio button.
11. Select OK. This closes the Assignment Schedule dialog box. The Scheduling tab is displayed.
12. Select Next. The User Experience tab is displayed.
13. Select the Show Task Sequence progress checkbox to enable this feature.
This configuration is optional. It displays a progress dialog box on each client as the task executes. If a silent
background execution of tasks is desired, leave this checkbox unchecked.
14. Select Next. The Distribution Points tab is displayed. For this example, there is nothing to change in this tab.
15. Select Next. The Summary tab is displayed.
16. Select Next. The Completion tab is displayed which shows a summary of all selections.
17. Select Close to close the Deploy Software Wizard.
This completes the deployment of the task sequence to the selected client collections. Client devices in the
collection should start to receive and execute the task. All clients will run the task within the Policy Polling
Interval configured.
Monitor a deployed task sequence:
1. Launch the Configuration Manager console.
2. Select Monitoring from the tree-menu.
3. Select the Overview menu item in the left pane to expand the menu.
4. Select the Deployments menu item. The list of deployments is displayed in the right pane.
Administration Guide
Fortinet Technologies Inc.
32
Provisioning FortiClient Deploy FortiClient using Microsoft SCCM 2012
5. Click to select the recently deployed task sequence in the right pane. The Deployments window is displayed.
To monitor a deployed task sequence on the client device, use the following process:
1. Launch the Software Center console on the client device. It displays a list of tasks deployed to it.
If a recently deployed task sequence is not displayed, most likely the Policy Polling
Interval is yet to expire on this client.
2. Select the Task Sequence. The current status is displayed.
In addition to the two monitoring procedures above, the client log file is available on the client device at:
C:\Windows\CCM\Logs\smsts.log
It will contain details of the task sequence, including:
lthe command-line commands executed
lany output generated by the commands
lany error messages
Map a network drive
When a file is referenced in a task sequence, it must be made available to all clients before the task sequence
starts. The processes listed below explain how to map a network folder to a drive in a given task sequence. If the
33 Administration Guide
Fortinet Technologies Inc.
Deploy FortiClient using Microsoft SCCM 2012 Provisioning FortiClient
mapping is successful, all the files in the shared folder will be available for the command-line commands in the
task sequence.
To map a network drive in the task sequence:
1. Create a new custom task sequence.
2. Edit the task sequence. The Task Sequence Editor dialog box is displayed.
3. Select the Add drop-down button.
4. In the drop-down list, select General > Connect to Network Folder. A new tab is displayed in the right pane of the
dialog box.
5. Type a name for the command.
6. Type a description for the command.
7. Type the full path to the network shared folder or use the Browse button to select it. Here is an example of a valid
path: \\172.21.85.245\accounts_dept.
When using the Browse button, be sure that the network share is being reported with
the same path as the client devices will use.
8. Type a drive letter, along with a colon.
For example: G:
9. Select Set and provide a user name and password that is valid for the network shared folder selected.
10. Select OK to return to the Task Sequence Editor dialog box.
11. Select Apply to save the task.
More tasks may be added to the task sequence as described in earlier parts of this section. Tasks may be re-
ordered using the other buttons provided in the top of the left pane in the Task Sequence Editor dialog box.
12. When all tasks have been added, select OK to close the dialog box.
Administration Guide
Fortinet Technologies Inc.
34
Provisioning FortiClient Deploy FortiClient using Microsoft SCCM 2012
Task sequence examples for FortiClient
The task sequence processes described in the preceding section may be applied to any regular Windows tasks
that runs on the command line. This section discusses several example FortiClient configurations that could be
completed from the Windows command-line.
The examples in this section list only the command-line commands to be used. When deploying these from the
Configuration Manager console, remember to always use the processes discussed this chapter to create the task
sequence. The procedure is the same, only the contents of the Run Command Line commands will differ.
Install FortiClient
FortiClient can be installed from the command line using msiexec. In this example, a FortiClient MSI file that is
provided on a network shared folder is used to install FortiClient to devices in the client collection.
Use the following commands in a task sequence to install FortiClient on a Windows client device.
1. Connect to a network folder:
lName: map_network_drive
lDescription: Mount a network shared directory that contains the FortiClient image to install
lPath: \\172.21.85.245\accounts_dept
lDrive: G:
lAccount: vNexttest\administrator
2. Run command line:
lName: copy_fct_image
lDescription: Copy FortiClient MSI image from network shared directory
lCommand line: cmd /c copy /y G:\FortiClient.msi c:\temp\FortiClient.msi
3. Run command line:
lName: install_fct
lDescription: Install FortiClient using MSI image
lCommand line: cmd /c msiexec /i c:\temp\FortiClient.msi /qn
Ensure that the FortiClient.msi file is available in the network share, and that the network share is accessible
to all client devices in the client collection before deploying this task sequence.
Export the FortiClient XML configuration file
FortiClient features may be controlled using an XML configuration file. The configuration file is first exported from
FortiClient, modified with a text editor, and re-imported into FortiClient. The XML configuration syntax and usage
is documented in the FortiClient XML Reference.
Use the following commands in a task sequence to export the XML configuration file from a Windows client
device which has FortiClient installed.
1. Connect to a network folder:
lName: map_network_share
lDescription: Mount a network shared directory to which configuration file will be copied.
lPath: \\172.21.85.245\engineering_dept
lDrive: M:
lAccount: vNexttest\administrator
35 Administration Guide
Fortinet Technologies Inc.
Deploy FortiClient using Microsoft SCCM 2012 Provisioning FortiClient
2. Run command line:
lName: export_fct_xml
lDescription: Export the FortiClient XML configuration file
lCommand line: cmd /c C:\Program Files\Fortinet\FortiClient\fcconfig -o export -f c:\temp\fct_xml.conf
3. Run command line:
lName: copy_fct_xml
lDescription: Copy FortiClient XML file to network shared directory
lCommand line: cmd /c copy /y c:\temp\fct_xml.conf M:\
This copies fct_xml.conf to the mounted share. If there is more than one device in the client collection, they
will each overwrite the same file. You may use a batch script to uniquely rename the file as it is copied.
The full path to the FortiClient installation directory is used as a prefix to
FCConfig.exe. The value provided in this example is the default on a 32-bit
system. The default on 64-bit systems is:
C:\Program Files (x86)\Fortinet\FortiClient
If the client collection has a mixture of both 32-bit and 64-bit devices, a
batch script may be used to selectively run from the correct platform-
dependent directory.
Import a modified XML configuration file
Use the following commands in a task sequence to import an XML configuration file into FortiClient in a Windows
client device.
1. Connect to a network folder:
lName: map_network_share
lDescription: Mount a network shared directory that contains the XML configuration file
lPath: \\172.21.85.245\engineering_dept
lDrive: M:
lAccount: vNexttest\administrator
2. Run command line:
lName: copy_fct_xml
lDescription: Copy FortiClient XML configuration file from network shared directory
lCommand line: cmd / c copy /y M:\fct_xml.conf c:\temp\
3. Run command line:
lName: import_fct_xml
lDescription: Import the FortiClient XML configuration file
lCommand line: cmd /c “C:\Program Files\Fortinet\FortiClient\fcconfig -o import -f c:\temp\fct_xml.conf”
The same configuration file is used by all devices in the client collection.
When deploying a custom FortiClient XML configuration, use the advanced Endpoint
Profile options in FortiGate to ensure the Endpoint Profile settings do not overwrite
your custom XML settings. For more information, see the FortiClient XML Reference
and the CLI Reference for FortiOS 5.2.
Administration Guide
Fortinet Technologies Inc.
36
Provisioning FortiClient Deploy FortiClient using Microsoft SCCM 2012
Upgrade FortiClient
The FortiClient upgrade process is similar to the regular installation. The only difference is the use of a different
version of FortiClient during the installation. A reboot is required, but the task sequence should handle this
properly.
The same procedure listed earlier for FortiClient installation could be reused.
Uninstall FortiClient
Use the following command in a task sequence to uninstall FortiClient from Windows client devices.
Run command line:
lName: uninstall_fct
lDescription: Uninstall FortiClient
lCommand line: wmic product where name="FortiClient" call uninstall /nointeractive
The task sequence should process the required reboot correctly.
37 Administration Guide
Fortinet Technologies Inc.
Endpoint Management
The purpose of this section is to provide basic instructions on how to configure, deploy, and manage FortiClient
configurations from your FortiGate device or EMS.
Endpoint Management is available on FortiGate 30D series devices and higher.
Endpoint Management requires FortiClient 5.0 or later and a FortiGate device running
FortiOS 5.0 or later, a FortiCarrier device running FortiOS Carrier 5.0 or later, or a
server running FortiClient EMS 1.0 or later.
FortiOS 5.2 and later can manage FortiClient 5.0 and later registrations. Certain fea-
tures are only available in FortiClient 5.2 and later.
Configure endpoint management
With FortiClient 5.4 and newer, configuration and management of endpoints can be handled by a FortiGate
device or FortiClient EMS.
You can configure your FortiGate device or EMS to discover new devices on the network, enforce FortiClient
registration, and deploy pre-configured profiles to connected devices. Multiple profiles can be configured.
The FortiClient profile consists of the following sections:
lAntivirus Protection
lWeb Category Filtering
You can select the web filtering security profile to associate with the FortiClient profile. You can also select to
enable Web Filtering when the client is protected by the FortiGate/EMS (On-Net).
lVPN
Select to enable client VPN provisioning. You can specify the VPN name, type, gateway and other settings the
client will use to connect to your FortiGate device via the VPN connection. Two-factor authentication is
configured in the FortiGate VPN configuration.
lApplication Firewall
You can select the application control sensor to associate with the FortiClient profile.
lEndpoint Vulnerability on Client
You can select to scan daily, weekly or monthly. You can also select to scan the client after registration with
your FortiGate device. Vulnerability Scan must be enabled via the CLI in order for it to be displayed in the
FortiClient Profile.
lUpload logs to FortiAnalyzer/FortiManager
Administration Guide
Fortinet Technologies Inc.
38
Endpoint Management Configure endpoint management
You can select to use the same IP address as the FortiGate device or specify a different device IP address.
You can specify the frequency of the log upload. FortiClient must be registered to FortiGate to upload logs to
FortiAnalyzer/FortiManager.
lUse FortiManager for client software/signature update
Select to enable this feature and enter the IP address of your FortiManager device. You can select to failover
over to the FortiGuard Distribution Network (FDN) when the FortiManager is not available.
lDashboard Banner
You can select to display or hide the FortiClient advertisement banner. FortiClient ads are downloaded from
the FortiGuard Distribution Servers.
Select if profile details may be displayed before endpoint control registration is completed.
lClient-based Logging when On-Net
Select to enable client-based logging when protected by the FortiGate/EMS (On-Net).
When FortiClient is On-Net, the icon displayed to the left of the username will be
green. When FortiClient is Off-Net, the icon is gray.
See the FortiOS Handbook or the FortiClient EMS Administration Guide for more information on configuring
your device, .
FortiGate
Configure endpoint management on the FortiGate device:
1. Enable device management and broadcast discovery messages.
a. Go to Network> Interfaces, select the applicable interface, then select Edit in the toolbar.
b. On the Edit Interface page you can select to enable Detect and Identify Devices.
c. To enable Broadcast Discovery Messages (optional) you must first enable FCT-Access under
Administrative Access.
d. Select OK to save the setting.
Broadcast Discovery Messages is an optional configuration. When enabled, the
FortiGate will broadcast messages to your network, allowing client connections to
discover the FortiGate for FortiClient registration. Without this feature enabled, the
user will enter the IP address or URL of the FortiGate to complete registration.
2. Configure the following settings:
Administrative Access Select the checkbox for FCT-Access. This option is available for both IPv4
and IPv6 Administrative Access.
39 Administration Guide
Fortinet Technologies Inc.
Configure endpoint management Endpoint Management
Security Mode Select None or Captive Portal. When selecting Captive Portal, users are
forwarded to a captive portal where they need to enter their username and
password to authenticate with the FortiGate. You can customize the portal
message and specify user groups.
This option is available when Addressing mode is set to Manual.
Device Management
Detect and
Identify Devices
Select to detect and identify devices on the selected interface.
Broadcast
Discovery
Messages
Once enabled, the FortiGate unit broadcasts a discovery message that
includes the IP address of the interface and listening port number to the
local network. All PCs running FortiClient on that network listen for this
discovery message.
This option is available when FCT-Access is enabled.
3. When configuring FortiClient access on an internal interface, you can select to send users to a captive portal.
Security Mode Select Captive Portal from the drop-down list
Authentication
Portal
Select either Local or External. When selecting External, you can specify
the link path.
User Groups Select user groups from the drop-down list.
FortiClient does not support nested groups in FortiOS.
Exempt List Select an exempt list from the drop-down list.
Customize Portal
Messages
Enable and select the edit icon to edit the portal replacement message.
Configure the FortiClient profile:
1. To configure the FortiClient profile, go to SecurityProfiles > FortiClient Profiles. You can edit the default profile
or create a new FortiClient profile.
The option to assign the profile to device groups, user groups, and users is only
available when selecting to create a new FortiClient profile. You can assign the profile
to user groups and users when using Active Directory authentication or RADIUS
authentication for VPN.
In FortiOS 5.0.3 and later, you must enable Multiple Security Profiles in the Feature
Settings to create a new FortiClient profile.
Administration Guide
Fortinet Technologies Inc.
40
Endpoint Management Configure endpoint management
When registering to a FortiGate device, FortiClient will receive the configured
FortiClient profile. The FortiClient configuration is overwritten by the FortiClient profile
settings. When selecting to unregister FortiClient, the settings will reflect that of the
FortiClient profile.
2. Configure the following settings:
Toolbar Options FortiClient Profile page
Select Create New to create a new FortiClient profile. Select a
profile in the list and select Edit to edit the FortiClient Profile.
Select a profile in the list and select Delete to delete the
FortiClient Profile.
Edit FortiClient Profile page
Select the create new icon to create a new FortiClient profile.
Select the clone icon to create a clone of an existing FortiClient
profile. Select the view list icon to view FortiClient profiles and
assignment.
Profile Name When editing the default profile, the name cannot be changed. When
creating a new FortiClient profile, XSS vulnerability characters are not
allowed.
Enter a name for the new FortiClient profile.
41 Administration Guide
Fortinet Technologies Inc.
Configure endpoint management Endpoint Management
Comments Enter a profile description. (optional)
Assign to Profile To: lDevice Groups: Select device groups in the drop-down list. Use the add
icon to assign multiple device groups to the FortiClient profile, for
example Mac and Windows PC.
lUser Groups: Select user groups in the drop-down list.
lUsers: Select users in the drop-down list.
lSource Address: Select source addresses.
These options are only available when creating a new FortiClient profile.
You can assign the profile to user groups and users when using Active
Directory authentication or RADIUS authentication for VPN.
FortiClient does not support nested groups in FortiOS.
On-Net Detection By
Address
Select addresses from the drop-down list to enable On-Net detection on
them.
Security
AntiVirus Toggle the button on or off to enable or disable this feature.
Web Filter Toggle the button on or off to enable or disable this feature.
When enabled, you can select a web filter profile in the drop-down list.
Select the checkbox to disable web category filtering on the client when
protected by the FortiGate (On-net).
Application
Firewall
Toggle the button on or off to enable or disable this feature.
When enabled, you can select an application control sensor in the drop-
down list.
VPN Toggle the button on or off to enable or disable this feature.
Select the checkbox for Client VPN Provisioning. When enabled, you can
configure multiple IPsec VPN and SSL VPN connections.
Use the add icon to add additional VPN connections. Enter the VPN name,
type, remote gateway, and authentication method information.
Select the checkbox to auto connect to a VPN when the client is Off-Net.
Select a VPN from the drop-down list.
Advanced
Install CA
Certificates
Select to install CA certificates.
Disable
Unregister
Option
Select to disable the option of unregistering from the FortiGate.
Administration Guide
Fortinet Technologies Inc.
42
Endpoint Management Configure endpoint management
Upload Logs to
FortiAnalyzer
Toggle the button on or off to enable or disable this feature.
When enabled, you can select to use the same FortiAnalyzer/FortiManager
used by the FortiGate or select Specify to enter a different device IP
address. You can set the schedule to hourly or daily. The FortiClient upload
logs to the FortiAnalyzer/FortiManager only when it is able to connect to
the device on the specified IP address.
FortiClient must be registered to FortiGate to upload logs to
FortiAnalyzer/FortiManager.
When upgrading from FortiOS 5.2 to 5.4, a FortiClient 5.4 license must be
applied against the FortiGate for this option to be available in the
FortiClient Profile. Optionally, you can enable this setting in the FortiOS
CLI.
FortiManager
updates
Toggle the button on or off to enable or disable this feature.
When enabled, you can specify the IP address of the FortiManager.
Select the checkbox to failover to the FortiGuard Distribution Network when
the FortiManager is not available.
Dashboard
Banner
Toggle the button on or off to enable or disable this feature.
Client-based
Logging when
Toggle the button on or off to enable or disable this feature.
3. Select Apply to save the FortiClient profile setting.
When deploying a custom FortiClient XML configuration, use the advanced FortiClient
Profile options in FortiGate to ensure the FortiClient Profile settings do not overwrite
your custom XML settings. For more information, see the FortiClient XML Reference
and the CLI Reference for FortiOS.
For information on configuring firewall policies for Endpoint Management, see the
FortiOS Handbook - The Complete Guide for FortiOS.
Configure firewall policies (Optional):
1. To configure a firewall policy for Endpoint Management, go to Policy & Objects>IPv4 Policy and select Create
New in the toolbar. The New Policy window is displayed.
2. Configure the policy as required. Select the source user(s) and source device types from the drop-down list.
3. Toggle Compliant with FortiClient Profile to ON. Users will be redirected (via a web browser) to a dedicated portal
where they can download the client. Once registered to the FortiGate, the FortiClient profile will be assigned.
You can create policies for users and devices which will be captive portal exempt.
When creating a device policy, if Device Management > Detect and Identify Devices
is not enabled on the incoming interface you will be prompted a confirmation dialog
box with the option to Enable Device Identification.
4. Select OK to save the rule.
43 Administration Guide
Fortinet Technologies Inc.
Configure endpoint management Endpoint Management
After the FortiGate configuration has been completed, you can proceed with FortiClient configuration.
Configure your Windows PC on the corporate network with the default gateway set to the IP address of the
FortiGate.
FortiClient endpoint network topologies
The following FortiClient Profile topologies are supported:
1. Client is directly connected to FortiGate; either to a physical port, switch port or WiFi SSID.
This topology supports client registration, configuration sync, and FortiClient profile enforcement.
2. Client is connected to FortiGate, but is behind a router or NAT device.
This topology supports client registration and configuration sync.
3. Client is connected to FortiGate across a VPN connection.
This topology supports client registration, configuration sync, and FortiClient profile enforcement.
Network topologies
Configure FortiClient for endpoint management:
1. Download and install the FortiClient software.
Open a web browser from your workstation and attempt to open a web page, the web page will be directed to
the NAC Download Portal. Follow the instructions in the portal to download and install FortiClient.
To allow users to download FortiClient, you must enable this setting in the SSL VPN
Portal on your FortiGate device. To enable this feature, go to VPN> SSL-VPN
Portals and select Create New in the toolbar.
Administration Guide
Fortinet Technologies Inc.
44
Endpoint Management Configure endpoint management
To configure NAC download portal endpoint control replacement messages, go to
System> Replacement Message. Select Extended View in the toolbar to display
Endpoint Control replacement messages for Android, iOS, Mac, Windows, and other.
2. Register FortiClient.
After FortiClient completes installation, FortiClient will automatically launch and search for a FortiGate
device for registration.
There are four ways that the FortiClient/FortiGate communication is initiated:
lFortiClient will attempt to connect to the default gateway IP address;
lFortiClient will attempt endpoint control registration over VPN (if configured on the FortiGate);
lFortiClient will attempt to connect to a remembered FortiGate;
lFortiClient will attempt to connect to a redundant FortiGate.
Your personal computer’s default gateway IP address should be configured to be the
IP address set in the FortiGate interface.
FortiClient will search for available FortiGate devices to complete registration. You can include the option to
prompt the user to enter the FortiClient registration key password. Select the Register Endpoint button in the
FortiClient console to retry the search.
If FortiClient is unable to detect a FortiGate device, enter the IP address or URL of the device and select the
Go icon. When FortiClient locates the FortiGate, you will be prompted to confirm the registration. Select the
Accept button to complete registration. Upon successful registration, the FortiGate will send the FortiClient
profile configuration.
3. Deploy the FortiClient profile from the FortiGate device.
The FortiGate will deploy the FortiClient profile after registration is complete. This FortiClient profile will
permit traffic through the FortiGate. A system tray bubble message will be displayed once update is
complete.
The FortiClient console will display that it is successfully registered to the FortiGate. The FortiClient profile is
installed on FortiClient.
45 Administration Guide
Fortinet Technologies Inc.
Configure endpoint management Endpoint Management
Deploy the FortiClient profile to clients over a VPN connection:
1. In the FortiClient console, select the Register Endpoint button. Enter the IP address and port number (if required)
of the FortiGate’s internal interface and select the Go icon.
2. Configure an IPsec VPN connection from FortiClient to the management FortiGate. For more information on
configuring IPsec VPN see Create a new IPsec VPN connection on page 84.
3. Connect to the VPN.
4. You can now search for the FortiGate gateway. For more information see Register FortiClient.
5. After registration, the client is able to receive the FortiClient profile.
When creating a new FortiClient VPN (IPsec) or SSL VPN tunnel configuration on your
FortiGate device, you must enable Endpoint Registration. See the IPsec VPN for
FortiOS and SSL VPN for FortiOS sections of the FortiOS Handbook for more inform-
ation.
FortiClient EMS
The EMS is a new product from Fortinet for businesses to manage their endpoints. It runs on a Windows Server,
not requiring a physical Fortinet device. Administrators may use it to gain insight into the status of their
endpoints.
For information on FortiClient EMS, see the FortiClient EMS Administration Guide, available in the Fortinet
Document Library.
Configuring endpoint registration over a VPN
FortiGate/EMS can register FortiClient-equipped endpoints over either an interface-based IPsec VPN or a tunnel-
mode SSL VPN. After the user authenticates, the FortiGate/EMS sends the FortiClient application the IP address
and port to be used for registration. If the user accepts the invitation to register, registration proceeds and the
FortiClient profile is downloaded to the client.
Users without FortiClient Endpoint Security connecting to the SSL VPN through a browser can be redirected to a
captive portal to download and install the FortiClient software. The security policy must enable Compliant with
FortiClient Profile and disable Captive Portal Exempt.
Endpoint registration on an IPsec VPN
You can enable endpoint registration when you configure the FortiClient VPN or you can enable it on an existing
FortiClient VPN.
To enable endpoint registration while configuring the VPN (FortiGate):
Enable Allow Endpoint Registration on the Network page of the VPN Wizard when creating the FortiClient VPN.
To enable endpoint registration on an existing VPN (FortiGate):
1. Go to System> Network> Interfaces and edit the VPN’s tunnel interface. The tunnel is a subinterface of the
physical network interface.
2. In Administrative Access, make sure that FCT-Access is enabled.
3. Select OK.
Administration Guide
Fortinet Technologies Inc.
46
Endpoint Management Remembered FortiGate/EMS
Endpoint registration on the SSL VPN
To enable endpoint registration on the SSL VPN (FortiGate):
1. Go to VPN> SSL-VPN Portal.
2. Make sure Enable Tunnel Mode is enabled.
3. Optionally, enable Include FortiClient Download.
Users who access the VPN with a browser will be able to download FortiClient Endpoint Security for their
device.
4. Select Apply.
Remembered FortiGate/EMS
FortiClient 5.0.1 or later adds the option to remember up to 20 FortiGate/EMS when accepting the broadcast
registration message. FortiClient can remember and register to multiple FortiGate/EMS devices. This feature
enables users to move freely between office locations and register conveniently to each FortiGate/EMS.
When prompted to enter a registration key, FortiClient can remember the registration password.
Select the user name in the console to view information about the current registered device including the IP
address, serial number, endpoint user, domain, and hostname.
Forget a remembered FortiGate/EMS:
1. In the FortiClient console, click on the registered device name to display the registration dialog box.
2. Select Show Remembered FortiGate/EMS to show a list of FortiGate/EMS that FortiClient has previously
registered with.
3. Select Forget next to the device that you would like to remove from the remembered list.
When selecting to forget a FortiGate/EMS, FortiClient will not automatically register to
the FortiGate when re-connecting to the network. When the device is detected, you
will be prompted to accept registration.
47 Administration Guide
Fortinet Technologies Inc.
Remembered FortiGate/EMS Endpoint Management
Unregister from FortiGate/EMS:
1. In the FortiClient console, click on the registered device name to display the registration details. The Registration
dialog box opens.
2. Select Unregister in the registration dialog box. A confirmation dialog box is displayed.
3. Select Yes to unregister FortiClient from the FortiGate selected.
When selecting to unregister from FortiGate, FortiClient will automatically register
with the FortiGate when re-connecting to the network. To prevent this behavior, you
must select to Forget the device.
Roaming clients (multiple redundant gateways) example
The following figure illustrates three corporate FortiGate networks. Each FortiGate can reach each other over a
WAN network. FortiClient can only reach one FortiGate at a time. FortiClient may connect directly to the
FortiGate or through a NAT device.
Roaming clients topology
Administration Guide
Fortinet Technologies Inc.
48
Endpoint Management Remembered FortiGate/EMS
If FortiClient connects through a NAT device to the FortiGate, do not enforce endpoint control compliance on the
FortiGate.
On each of the three FortiGate devices configure the following:
lInterface IP addresses
lFortiClient profile
lDevice identification in the interface
lFortiClient profile in the applicable firewall policy
lEndpoint control synchronization
Endpoint control synchronization allows you to synchronize endpoint control for multiple FortiGate devices. To
enable endpoint control synchronization via the CLI enter the following commands on your FortiGate:
config endpoint-control forticlient-registration-sync
edit 1
set peer-ip 172.20.52.19
next
edit 2
set peer-ip 172.22.53.29
end
end
The IP addresses set for the peer-ip field are the WAN IP addresses for each of the FortiGate devices in the
synchronization group.
You need to add the following XML configuration to FortiClient for this synchronization group. Modify the
configuration file to add the following:
<forticlient_configuration>
<endpoint_control>
<!-- List of redundant FortiGates, since 5.0.2 -->
<fortigates>
<fortigate>
<name>Corporate Network</name>
<addresses>10.18.51.9;10.20.52.19;10.22.53.29</addresses>
</fortigate>
</fortigates>
</endpoint_control>
</forticlient_configuration>
The IP addresses are the internal IP addresses for each of the three FortiGates in the synchronization group.
FortiClient can reach any of these IPs, one at a time.
If the three FortiGate devices share the same DNS name, use the following XML configuration:
<forticlient_configuration>
<endpoint_control>
<!-- List of redundant FortiGates, since 5.0.2 -->
<fortigates>
<fortigate>
<name>Fortinet Americas</name>
<addresses>fct_americas.fortinet.com</addresses>
</fortigate>
</fortigates>
</endpoint_control>
</forticlient_configuration>
The DNS server should return one reachable FortiGate IP address for the domain name used.
49 Administration Guide
Fortinet Technologies Inc.
View FortiClient registration in the FortiGate GUI or EMS Endpoint Management
You will need to manually add FortiClient to the synchronization group when FortiClient initially registers with the
FortiGate. Once added, no further action is required.
On your FortiGate, use the following CLI command to list all registered FortiClient endpoints:
diagnose endpoint registration list registered-forticlients
FortiClient #1 (0):
UID = BE6B76C509DB4CF3A8CB942AED200000
vdom = root
status = registered
registering time = Fri May 2 15:00:07 2014
registration expiry time = none
source IP = 172.172.172.111
source MAC = b0:ac:6f:70:e0:a0
user = user
host OS = Microsoft Windows 7 , 64-bit
restored registration = no
remote registration = yes
registration FGT = FGT60C3G11000000
Total number of licences: 10
Total number of granted licenses: 1
Total number of available licences: 9
The remote registration entry indicates whether this specific FortiClient is registered to this FortiGate, or
to another FortiGate within the synchronization group.
If any of the FortiGate devices require a password to complete registration, you can use the following XML
configuration to provide password information to FortiClient:
<forticlient_configuration>
<endpoint_control>
<!-- List of redundant FortiGates, since 5.0.2 -->
<fortigates>
<fortigate>
<name>Corporate Network</name>
<addresses>10.18.51.9;10.20.52.19;10.22.53.29</addresses>
<registration_password>uNbre@kab1e</registration_password>
</fortigate>
</fortigates>
</endpoint_control>
</forticlient_configuration>
View FortiClient registration in the FortiGate GUI or EMS
You can view all registered FortiClient agents in the FortiGate GUI or EMS.
On FortiGate, each new registration will be automatically added to the device table. To view registered devices
go to User & Device > Device List. The state for the new FortiClient registration is listed as Registered.
Alternatively, go to Monitor> FortiClient Monitor.
To view registered endpoints in EMS, select Workgroups > All Groups.
Administration Guide
Fortinet Technologies Inc.
50
Endpoint Management Configure the FortiGate/EMS IP address in FortiClient for registration
Configure the FortiGate/EMS IP address in FortiClient for registration
The FortiClient administrative user can specify a FortiGate/EMS IP address for registration and client
configuration management. When an unregistered FortiClient starts up, FortiClient will list all reachable
FortiGate/EMS for endpoint control registration in the registration drop-down list. The list will include any
FortiGate/EMS that sends endpoint control broadcasts. Select the registration button in the FortiClient console to
list discovered FortiGate/EMS. Any IP address provided in the Settings page under the Registration element is
included in the list.
To configure a FortiGate/EMS IP address in FortiClient, select the Register Endpoint button in the FortiClient
console. In the Specify Address field, enter the IP address and port number (if required) of the FortiGate/EMS’s
internal interface, and select the Go icon.
The FortiClient settings are locked, and cannot be modified after registration to a
FortiGate/EMS is completed. See Configuration lock on page 108 for information on
configuring this feature.
Enable FortiClient endpoint registration key password (optional)
You can configure a registration key password for FortiClient endpoint registration to FortiGate devices. Upon
registering to FortiGate/EMS, the user will need to enter the registration key password before registration can be
completed.
Enable registration key password requirement on registration (FortiGate):
1. On your FortiGate device, go to System> Config> Advanced.
2. Under FortiClient Endpoint Registration, select Enable Registration Key for FortiClient and enter a registration
key password.
3. Select Apply to save the setting.
51 Administration Guide
Fortinet Technologies Inc.
Update FortiClient registration license on FortiGate Endpoint Management
Alternatively, you can configure this via the CLI. On your FortiGate device, go to System> Dashboard>
Status. Enter the following the CLI command in the CLI Console widget:
config endpoint-control settings
set forticlient-key-enforce enable
set forticlient-reg-key <password>
end
4. When FortiClient users attempt to register with FortiGate, they will receive the Registering to FortiGate dialog
box. The user will need to enter the registration key password you configured before they can register to
FortiGate.
FortiClient users can select to remember the registration key password in this page.
Enable registration key password requirement on registration (EMS):
1. On your EMS, select View> Endpoint Registration IP List.
2. Edit an existing list, or select Add to create a new list.
3. Enable Registration Key, enter the key, then confirm the key.
FortiClient will use that key to register to FortiGates on the list.
4. Select Save to save your changes.
Display or hide the FortiClient profile details
You can select to display or hide the FortiClient profile details in the Registering to FortiGate page. When
disabled, the user will not be able to view the profile details prior to completing registration to FortiGate.
To display or hide the FortiClient profile details:
1. On your FortiGate device, go to System> Dashboard.
2. Enter the following the CLI command in the CLI Console widget:
config endpoint-control profile
edit <profile name>
config forticlient-winmac-settings
set view-profile-details {enable| disable}
end
end
Update FortiClient registration license on FortiGate
To update the FortiClient registration license on FortiGate, use the following CLI command:
execute FortiClient-NAC update-registration-license <license key/activation code>
Administration Guide
Fortinet Technologies Inc.
52
Endpoint Management Endpoint registration with AD user groups
Endpoint registration with AD user groups
The user's AD domain name and group are both sent to the FortiGate/EMS during endpoint registration.
Administrators may configure the FortiGate/EMS to deploy endpoint and/or firewall profiles based on the end
user's AD domain group.
The following steps are discussed in more details:
lConfigure users and groups on your AD server
lConfigure your FortiAuthenticator
lConfigure your FortiGate/EMS
lConnect to the FortiGate/EMS using FortiClient endpoint
lMonitoring client registrations
Configure users and groups on your AD server
Create the user accounts and groups on the AD server. Groups may have any number of users. A user may
belong to more than one group at the same time.
Configure your FortiAuthenticator
Configure FortiAuthenticator to use the AD server that you created. For more information see the
FortiAuthenticator Administration Guide in the Fortinet Document Library.
Configure your FortiGate/EMS
FortiGate
Add the FortiAuthenticator or Fortinet Single Sign-On Agent (FSSO):
1. Go to User & Device > Single Sign-On.
2. Select Create New in the toolbar. The New Single Sign-On Server window opens.
3. In the type field, select Fortinet Single-Sign-On Agent.
53 Administration Guide
Fortinet Technologies Inc.
Endpoint registration with AD user groups Endpoint Management
4. Enter the information required for the agent. This includes the name, primary and secondary IP addresses, and
passwords. Select an LDAP server in the drop-down list if applicable. Select More FSSO agents to add up to three
additional agents.
5. Select OK to save the agent configuration.
Create a user group:
1. Go to User & Device> User Groups.
2. Select Create New in the toolbar. The New User Group window opens.
3. In the type field, select Fortinet Single-Sign-On (FSSO).
4. Select members from the drop-down list.
5. Select OK to save the group configuration.
Configure the FortiClient profile:
1. Go to Security Profiles > FortiClient Profiles.
2. Select Create New in the toolbar. The New FortiClient Profile window opens.
3. Enter a profile name and optional comments.
4. In the Assign Profile To drop-down list select the FSSO user group(s).
5. Configure FortiClient configuration deployment as required.
6. Select OK to save the new FortiClient profile.
Create any number of FortiClient profiles with different groups and different settings.
The default profile will be assigned to users who register successfully but have no
matching FortiClient profile.
Configure the firewall policy:
Configure the firewall policy as described in Configure endpoint management on page 38. Ensure that Compliant
with FortiClient Profile is selected in the policy.
EMS
Add a new domain:
1. Under the Endpoints heading, in the Domains section, select Add a new domain. The Domain Settings window
opens.
2. Enter the domain information as required.
3. Select Test to confirm functionality, then, if successful, select Save to add the domain.
The domains groups will automatically be populated in the Workgroups section under the Endpoints heading.
For more information, see the FortiClient EMS Administration Guide, available in the Fortinet Document Library.
Connect to the FortiGate/EMS using FortiClient endpoint
The Microsoft Windows system on which FortiClient is installed should join the domain of the AD server
configured earlier. Users may log in with their domain user name.
Following this, FortiClient endpoint registrations will send the logged-in user's name and domain to the
FortiGate/EMS. The FortiGate/EMS will assign the appropriate profiles based on the configurations.
Administration Guide
Fortinet Technologies Inc.
54
Endpoint Management Endpoint registration with AD user groups
Monitoring client registrations
The following FortiOS CLI command lists information about registered clients. This includes domain-related
details for the client (if any).
diagnose endpoint record-list
Record #1:
IP_Address = 172.172.172.111(1)
MAC_Address = b0:ac:6f:70:e0:a0
Host MAC_Address = b0:ac:6f:70:e0:a0
MAC list = b0-ac-6f-70-e0-a0;
VDOM = root
Registration status: Forticlient installed but not registered
Online status: offline
DHCP on-net status: off-net
DHCP server: None
FCC connection handle: 6
FortiClient version: 5.1.29
AVDB version: 22.137
FortiClient app signature version: 3.0
FortiClient vulnerability scan engine version: 1.258
FortiClient feature version status: 0
FortiClient UID: BE6B76C509DB4CF3A8CB942AED2064A0 (0)
FortiClient config dirty: 1:1:1
FortiClient KA interval dirty: 0
FortiClient Full KA interval dirty: 0
FortiClient server config: d9f86534f03fbed109676ee49f6cfc09::
FortiClient config: 1
FortiClient iOS server mconf:
FortiClient iOS mconf:
FortiClient iOS server ipsec_vpn mconf:
FortiClient iOS ipsec_vpn mconf:
Endpoint Profile: Documentation
Reg record pos: 0
Auth_AD_groups:
Auth_group:
Auth_user:
Host_Name:
OS_Version: Microsoft Windows 7 , 64-bit Service Pack 1 (build 7601)
Host_Description: AT/AT COMPATIBLE
Domain:
Last_Login_User: FortiClient_User_Name
Host_Model: Studio 1558
Host_Manufacturer: Dell Inc.
CPU_Model: Intel(R) Core(TM) i7 CPU Q 720 @ 1.60GHz
Memory_Size: 6144
Installed features: 55
Enabled features: 21
online records: 0; offline records: 1
status -- none: 0; uninstalled: 0; unregistered: 1; registered: 0; blocked: 0
55 Administration Guide
Fortinet Technologies Inc.
Antivirus
This chapter includes the following sections:
lFortiClient Antivirus
lAntivirus logging
lAntivirus options
lEndpoint control
FortiClient Antivirus
FortiClient includes an antivirus module to scan system files, executable files, removable media, dynamic-link
library (DLL) files, and drivers. FortiClient will also scan for and remove rootkits. In FortiClient, File Based
Malware, Malicious Websites, Phishing, and Spam URL protection is part of the antivirus module. Scanning can
also be extended using FortiSandbox.
This section describes how to enable and configure antivirus options.
Enable or disable antivirus
To enable real-time protection:
1. On the AntiVirus tab, select the settings icon next to Realtime Protection Disabled. The real-time protection
settings page will open.
2. Select Scan files as they are downloaded or copied to my system.
3. Select OK.
Administration Guide
Fortinet Technologies Inc.
56
Antivirus FortiClient Antivirus
If you have another antivirus program installed on your system, FortiClient will show a warning that your system
may lock up due to conflicts between different antivirus products.
To disable real-time protection:
1. On the AntiVirus tab, select the settings icon next to Realtime Protection Enable. The real-time protection
settings page will open.
2. Deselect Scan files as they are downloaded or copied to my system.
3. Select OK.
When FortiClient is registered to FortiGate for endpoint control, antivirus is enabled
and disabled in the FortiClient Profile.
Conflicting antivirus warning
It is recommended to remove the conflicting antivirus product before installing FortiCli-
ent or enabling the antivirus real-time protection feature.
FortiSandbox
FortiClient integration with FortiSandbox allows users to submit files to FortiSandbox for automatic scanning.
When configured, FortiClient will send supported files downloaded over the internet to FortiSandbox if they
cannot be detected by the local, real-time scanning. Access to the downloaded file is blocked until the scanning
result is returned.
As FortiSandbox receives files for scanning from various sources, it collects and generates AV signatures for such
samples. FortiClient periodically downloads the latest AV signatures from the FortiSandbox, and applies them
locally to all real-time and on-demand AV scanning.
This option cannot be configured on a registered endpoint, and must instead be configured on the
FortiGate/EMS.
To extend scanning using FortiSandbox:
1. On the AntiVirus tab, select the settings icon to open the real-time protection settings page.
2. Select Extend scanning using FortiSandbox.
57 Administration Guide
Fortinet Technologies Inc.
FortiClient Antivirus Antivirus
3. Enter the FortiSandbox IPaddress, then select Test to ensure that the connection is correct.
4. Optionally, select Identify malware & exploits using signatures received from FortiSandbox.
5. Select OK to apply your changes.
Blocking access and communication channels
To block access to malicious websites and known communication channels used by attackers:
1. On the AntiVirus tab, select the settings icon to open the real-time protection settings page.
2. Select Block all access to malicious websites and Block known communication channels used by attackers.
3. Select OK to apply your changes.
Notifications
Select the notifications icon in the FortiClient console to view notifications. When a virus has been detected, the
notifications icon will change from gray to yellow.
Administration Guide
Fortinet Technologies Inc.
58
Antivirus FortiClient Antivirus
Event notifications include:
lAntivirus events including scheduled scans and detected malware.
lEndpoint Control events including configuration updates received from FortiGate.
lWebFilter events including blocked web site access attempts.
lSystem events including signature and engine updates and software upgrades.
Select the Threat Detected link to view quarantined files, site violations, and real-time protection events.
Scan now
To perform on-demand antivirus scanning, select the Scan Now button in the FortiClient console. Use the drop-
menu to select Custom Scan,Full Scan,Quick Scan, or Removable media Scan. The console displays the
date of the last scan to the left of the button.
lCustom Scan runs the rootkit detection engine to detect and remove rootkits. It allows you to select a specific file
folder on your local hard disk drive (HDD) to scan for threats.
lFull Scan runs the rootkit detection engine to detect and remove rootkits, then performs a full system scan
including all files, executable files, DLLs, and drivers for threats.
lQuick System Scan runs the rootkit detection engine to detect and remove rootkits. It only scans executable files,
DLLs, and drivers that are currently running for threats.
lRemovable media Scan runs the rootkit detection engine to detect and remove rootkits. It scans all connected
removable media, such as USB drives.
Scan a file or folder on your workstation
To perform a virus scan a specific file or folder on your workstation, right-click the file or folder and select Scan
with FortiClient AntiVirus from the menu.
Submit a file for analysis
You can select to send up to 5 files a day to FortiGuard for analysis. To submit a file, right-click a file or
executable and select Submit for analysis from the menu. A dialog box will be displayed which allows you to see
the number of files you have submitted. Confirm the location of the file you want to submit then select the Submit
button.
You do not receive feedback for files submitted for analysis. The FortiGuard team is
able to create signatures for any files which are submitted for analysis and determined
to be malicious.
View FortiClient engine and signature versions
To view the current FortiClient version, engine, and signature information, select Help in the toolbar, and select
About in the menu. Hover the mouse over the status field to see the date and time that FortiClient last updated
the selected item.
59 Administration Guide
Fortinet Technologies Inc.
FortiClient Antivirus Antivirus
When FortiClient is registered to FortiGate for endpoint control, you can select to use
a FortiManager device for client software and signature updates. When configuring
the FortiClient profile, select Use FortiManager for client software/signature updates
to enable the feature and enter the IP address of your FortiManager device. You can
select to failover to FDN when FortiManager is not available.
Schedule antivirus scanning
Select the settings icon beside Realtime Protection in the FortiClient console to open the antivirus settings page,
then select the Scheduled Scan tab to schedule antivirus scanning.
Scans cannot be scheduled on registered endpoint.
Configure the following settings:
Schedule Type Select Daily,Weekly, or Monthly from the drop-down list.
Administration Guide
Fortinet Technologies Inc.
60
Antivirus FortiClient Antivirus
Scan On For Weekly scheduled scan, select the day of the week in the drop-down
list.
For Monthly scheduled scan, select the day of the month in the drop-down
list.
Start Select the time of day that the scan starts. The time format uses a 24-hour
clock.
Scan Type Select the scan type:
lQuick system scan runs the rootkit detection engine to detect and
remove rootkits. It only scans executable files, DLLs, drivers that
are currently running for threats.
lFull system scan runs the rootkit detection engine to detect and
remove rootkits. It then performs a full system scan including all
files, executable files, DLLs, and drivers for threats.
lCustom scan runs the rootkit detection engine to detect and
remove rootkits. It allows you to select a specific file folder on your
local hard disk drive (HDD) to scan for threats.
You cannot schedule a removable media scan. A full scan will scan remov-
able media.
Disable Scheduled Scan Select to disable scheduled scan.
Select OK to save the setting and return to the main FortiClient console page.
If you configure monthly scans to occur on the 31st of each month, the scan will occur
on the first day of the month for those months with less than 31 days.
Add files/folders to an exclusion list
Select the settings icon beside Realtime Protection in the FortiClient console to open the antivirus settings page,
then select the Exclusion List tab.
To add files/folders to the antivirus exclusion list, select the add icon and then select Add file or Add folder from
the drop-down list. Any files or folders in this exclusion list will not be scanned. Select the minus icon to remove
files or folders from the list.
61 Administration Guide
Fortinet Technologies Inc.
FortiClient Antivirus Antivirus
Select OK to save the setting and return to the FortiClient console page.
View quarantined threats
To view quarantined threats, select the X Threats Detected link in the FortiClient console, then select the
Quarantined Files tab. In this page you can view, restore, or delete the quarantined file. You can also view the
original file location, the virus name, submit the suspicious file to FortiGuard, and view logs.
This page displays the following:
File Name The name of the file.
Date Quarantined The date and time that the file was quarantined by FortiClient.
Refresh Select to refresh the quarantined files list.
Administration Guide
Fortinet Technologies Inc.
62
Antivirus FortiClient Antivirus
Details Select a file from the list to view detailed information including the file name, original
location, date and time that the virus was quarantined, the submitted status, status,
virus name, and quarantined file name.
Logs Select to view FortiClient log data.
Refresh Select to refresh the list.
Submit Select to submit the quarantined file to FortiGuard. Press and hold the control key to
submit multiple entries.
Restore Select to restore the quarantined file. A confirmation dialog box will be displayed. You
can select Yes to add this file/folder to the exclusion list, No to restore the file, or
Cancel to exit the operation. Press and hold the control key to restore multiple entries.
Delete Select to delete the quarantined file. A confirmation dialog box will be displayed,
select Yes to continue. Press and hold the control key to delete multiple entries.
Close Select to close the page and return to the FortiClient console.
View site violations
To view site violations, select the X Threats Detected link in the FortiClient console, then select the Site
Violations tab. On this page you can view site violations and submit sites to be re-categorized.
This page displays the following:
Website Displays the name of the website.
Time Displays the date and time of the site violation.
Refresh Select to refresh the site violation list.
63 Administration Guide
Fortinet Technologies Inc.
FortiClient Antivirus Antivirus
Details Select an entry in the list to view site violation details including the website name, cat-
egory, date and time, user name, and status.
Select the category link to request to have the site category re-evaluated.
View alerts dialog box
When FortiClient antivirus detects a virus while attempting to download a file via a web-browser, you will receive
a warning dialog message.
Select View recently detected virus(es) to collapse the virus list. Select a file in the list and right-click to access
the context menu.
Delete Select to delete a quarantined or restored file.
Quarantine Select to quarantine a restored file.
Restore Select to restore a quarantined file.
Submit Suspicious File Select to submit a file to FortiGuard as a suspicious file.
Submit as False Positive Select to submit a quarantined file to FortiGuard as a false positive.
Add to Exclusion List Select to add a restored file to the exclusion list. Any files in the exclusion
list will not be scanned.
Open File Location Select to open the file location on your workstation.
When Alert when viruses are detected under AntiVirus Options on the Settings page
is not selected, you will not receive the virus alert dialog box when attempting to down-
load a virus in a web browser.
Realtime Protection events
When an antivirus real-time protection event has occurred you can select to view these events in the FortiClient
console. From the AntiVirus tab, select X Threats Detected, then select Real-time Protection events (x) in the
left pane. The realtime_scan.log will open in the default viewer.
Example log output:
Realtime scan result:
time: 09/29/15 10:46:07, virus found: EICAR_TEST_FILE, action: Quarantined,
c:\users\user\desktop\eicar.com
time: 09/29/15 10:46:07, virus found: EICAR_TEST_FILE, action: Quarantined,
c:\users\user\desktop\eicar.com.txt
time: 09/29/15 10:46:07, virus found: EICAR_TEST_FILE, action: Quarantined,
c:\users\user\desktop\eicarcom2.zip
time: 09/29/15 10:46:08, virus found: EICAR_TEST_FILE, action: Quarantined,
c:\users\user\desktop\eicar_com.zip
time: 09/29/15 10:46:39, virus found: EICAR_TEST_FILE, action: Quarantined,
c:\users\user\appdata\local\temp\3g_bl8y9.com.part
time: 03/18/15 10:48:13, virus found: EICAR_TEST_FILE, action: Quarantined,
c:\users\user\appdata\local\temp\xntwh8q1.zip.part
Administration Guide
Fortinet Technologies Inc.
64
Antivirus Antivirus logging
Antivirus logging
To configure logging, select File > Settings from the toolbar then expand the Logging section.
Configure the following settings:
Enable logging for these
features
Select antivirus to enable logging for this feature.
Log Level Select the level of logging:
lEmergency: The system becomes unstable.
lAlert: Immediate action is required.
lCritical: Functionality is affected.
lError: An error condition exists and functionality could be affected.
lWarning: Functionality could be affected.
lNotice: Information about normal events.
lInformation: General information about system operations.
lDebug: Debug FortiClient.
Log file
Export logs Select to export logs to your local hard disk drive (HDD) in .log format.
Clear logs Select to clear all logs. You will be presented a confirmation window, select
Yes to proceed.
Antivirus options
For information on configuring antivirus options, see Antivirus options on page 105.
Endpoint control
When FortiClient is registered to FortiGate/EMS for endpoint control, FortiClient receives configuration and
settings via the FortiClient Profile configured on the device.
To enable antivirus protection on FortiGate:
1. Log in to your FortiGate.
2. In the left tree menu, select Security Profiles > FortiClient Profiles.
65 Administration Guide
Fortinet Technologies Inc.
Endpoint control Antivirus
3. In the right pane, in the Edit FortiClient Profile page, in the Security tab, enable AntiVirus.
4. Select Apply to save the profile.
The FortiGate will send the FortiClient Profile configuration update to registered clients.
To enable antivirus protection on EMS:
1. Log in to the EMS.
2. Go to Endpoint Profiles and select a profile to edit.
3. In the right pane, select AntiVirus Protection to enable antivirus protection and configure as needed.
4. Select Save to save the profile.
The EMS will send the FortiClient Profile configuration update to registered clients.
Antivirus profile settings
FortiGate and EMS share similar settings for antivirus profiles. EMS also includes advanced options.
Administration Guide
Fortinet Technologies Inc.
66
Antivirus Endpoint control
After enabling antivirus protection on FortiGate/EMS, the following settings can be configured:
Scan Downloads Scan files as they are downloaded or copied to my system.
Scan with FortiSandbox Extended scanning using FortiSandbox.
FortiClient will send supported files downloaded over the internet to
FortiSandbox if they cannot be detected by the local, real-time scanning
FortiSandbox
IPaddress
The IPaddress of the FortiSandbox device.
Wait for
FortiSandbox res-
ults
Wait for FortiSandbox results before allowing file access.
Use FortiSand-
box signatures
Identify malware & exploits using signatures or URLs received from
FortiSandbox.
67 Administration Guide
Fortinet Technologies Inc.
Endpoint control Antivirus
Block malicious websites Block all access to malicious websites.
EMS also has the option of using the exclusion list defined in the web filter
profile.
Block attack channels Block known communcation channels used by attackers.
Alert when viruses are
detected
This option is EMS only.
Schedule Scan Schedule automatic scans daily, weekly, or monthly at a specific time of
day. Quick, Full, and Custom scans can be run automatically.
Excluded Paths Files or folders that are not scanned.
Advanced options available on EMS only include:
Scan Downloads Files that are scanned as they are downloaded or copied to the system
can be treated in one of the following ways:
lClean infected files (quarantine if cannot clean)
lRepair infected files (quarantine if cannot clean)
lWarn the user if a process attempts to access infected files
lQuarantine infected files
lDeny access to infected files
Scan with FortiSandbox If waiting for FortiSandbox results is enabled, access to downloaded
files can be denied if FortiSandbox is offline.
Scan compresses files Scan compressed files that are up to a specified size (default: 10Mb).
Scan email Scan email messages and attachments.
User process scanning lScan files when processes read or write them
lScan files when processes read them
lScan files when processes write them
Scan network files Scan network files.
System process scanning lScan files when system processes read or write them
lScan files when system processes read them
lScan files when system processes write them
lDo not scan files when system processes read or write them
Administration Guide
Fortinet Technologies Inc.
68
Antivirus Endpoint control
On demand scanning Configure on-demand file scan options.
lClean infected files (quarantine if cannot clean)
lRepair infected files (quarantine if cannot clean)
lWarn the user if a process attempts to access infected files
lQuarantine infected files
Integrate FortiClient
into Windows
Explorer's mouse
menu
Add the options to Scan with FortiClient AntiVirus and Submit for ana-
lysis to the Windows Explorer right-click menu.
Pause scanning
when running on bat-
tery power
Pause a scanning process when the computer is running on battery
power.
Automatically submit
suspicious files to
FortiGuard for ana-
lysis
Submit all files to FortiGuard for analysis.
Scan compresses
files
Scan compressed files that are up to a specified size (default: 10Mb, 0
means unlimited)
Maximize scan speed Select the amount of memory a computer must have before FortiClient
maximizes its scan speed. One of: 4MB, 6MB, 8MB, 12MB, 16MB.
More Options Enable or disable various other options, including:
lScan for rootkits
lScan for adware
lScan for riskware
lEnable advanced heuristics
lScan removable media on insertion
lScan mime files (inbox files)
lEnable FortiGuard Analytics
lNotify logged in users if their AntiVirus signatures expire
69 Administration Guide
Fortinet Technologies Inc.
Web Security/Web Filter
Web Security/Web Filter allows you to block, allow, warn, and monitor web traffic based on URL category or
custom URL filters. URL categorization is handled by the FortiGuard Distribution Network (FDN). You can create
a custom URL filter exclusion list which overrides the FDN category.
When FortiClient is not registered to FortiGate, you can enable or disable the Web Security feature. You can
define what sites are allowed, blocked, or monitored and view violations.
Enable/Disable Web Security
To enable or disable FortiClient Web Security, toggle the Enable/Disable link in the FortiClient console. Web
Security is enabled by default.
Enable/Disable Select to enable or disable Web Security.
X Violations (In the Last 7
Days)
Select to view Web Security log entries of the violations that have occurred
in the last 7 days.
Settings Select to configure the Web Security profile, exclusion list, and settings,
and to view violations.
Web Security profile
You can configure a Web Security profile to allow, block, warn, or monitor web traffic based on website categories
and sub-categories. Select the settings icon, then select the site category. Select the action icon, then select the
action in the drop-down menu for each category or sub-category.
Administration Guide
Fortinet Technologies Inc.
70
Web Security/Web Filter Web Security exclusion list
Allow Set the category or sub-category to Allow to allow access.
Block Set the category or sub-category to Block to block access. The user will receive a Web Page
Blocked message in the web browser.
Warn Set the category or sub-category to Warn to block access. The user will receive a Web Page
Blocked message in the web browser. The user can select to proceed or go back to the pre-
vious web page.
Monitor Set the category or sub-category to Monitor to allow access. The site will be logged.
You can select to enable or disable Site Categories in the Web Security settings
page. When site categories are disabled, FortiClient is protected by the exclusion list.
Web Security exclusion list
To manage the exclusion list, select the settings icon then select Exclusion List from the menu. You can add
websites to the exclusion list and set the permission to allow, block, monitor, or exempt. Use the add icon to add
URLs to the exclusion list. If the website is part of a blocked category, an allow permission in the Exclusion List
would allow the user to access the specific URL.
For more information on URL formats, type, and action, see the FortiOS Handbook in
the Fortinet Document Library.
71 Administration Guide
Fortinet Technologies Inc.
Web Security settings Web Security/Web Filter
Configure the following settings:
Exclusion List Select to exclude URLs that are explicitly blocked or allowed. Use the add
icon to add URLs and the delete icon to delete URLs from the list. Select a
URL and select the edit icon to edit the selection.
URL Enter a URL or IP address.
Type Select one of the following pattern types from the drop-down list:
lSimple
lWildcard
lRegular Expression
Actions Select one of the following actions from the drop-down list:
lBlock: Block access to the web site regardless of the URL category
or sub-category action.
lAllow: Allow access to the web site regardless of the URL category
or sub-category action.
lMonitor: Allow access to the web site regardless of the URL
category or sub-category action. A log message will be generated
each time a matching traffic session is established.
Web Security settings
To configure web security settings, select the settings icon then select Settings from the menu.
Administration Guide
Fortinet Technologies Inc.
72
Web Security/Web Filter View violations
Configure the following settings:
Enable Site Categories Select to enable Site Categories. When site categories are disabled,
FortiClient is protected by the exclusion list.
Log all URLs Select to log all URLs.
Identify user initiated web
browsing
Select to identify web browser that is user initiated.
View violations
To view Web Security violations, either select the settings icon then select Violations from the menu, or select X
Violations (In the Last 7 Days).
Website The website name or IP address.
73 Administration Guide
Fortinet Technologies Inc.
Web Filter Web Security/Web Filter
Category The website sub-category.
Time The date and time that the website was accessed.
User The name of the user generating the traffic. Hover the mouse cursor over the column to
view the complete entry in the pop-up bubble message.
Web Filter
When FortiClient is registered to a FortiGate/EMS, the Web Security tab will become the Web Filter tab.
You can disable Web Filter in FortiClient from the FortiGate FortiClient profile. You
can also select to enable or disable Web Filter when the FortiClient device is On-Net.
When FortiGuard Categories is disabled, FortiClient will be protected by the Exclu-
sion List configured in the URL in the FortiClient profile.
The FortiClient Endpoint Control feature enables the site administrator to distribute a Web Filter profile from a
FortiGate or add web filtering to an endpoint profile on EMS.
On a FortiGate device, the overall process is as follows:
lCreate a Web Filter profile on the FortiGate,
lAdd the Web Filter profile to the FortiClient Profile on the FortiGate.
On EMS, web filtering is part of the endpoint profile.
FortiGate
Step 1: Create a Web Filter Profile on the FortiGate
Use the following steps to create a custom Web Filter profile on the FortiGate:
Administration Guide
Fortinet Technologies Inc.
74
Web Security/Web Filter Web Filter
1. Go to Security Profiles> Web Filter.
2. To create a new profile, click the create new icon in the toolbar. The New Web Filter Profile page opens.
3. Configure the following settings:
Name Enter a name for the Web Filter profile.
Comments Enter a description in the comments field. (optional)
Inspection Mode This setting is not applicable to FortiClient.
75 Administration Guide
Fortinet Technologies Inc.
Web Filter Web Security/Web Filter
FortiGuard Categories Select category and sub-category actions.
lIn FortiClient5.4.0, the Security Risk category is part of the
AntiVirus module. The Local Categories category is not applicable
to FortiClient. The Authenticate and Disable actions are not
applicable to FortiClient.
lWhen FortiGuard Categories is disabled, FortiClient will be
protected by the Exclusion List configured in the URL in the
FortiClient profile.
Categories Usage Quota This setting is not applicable to FortiClient.
Allow users to override
blocked categories
This setting is not applicable to FortiClient.
Search Engines
Enforce 'Safe
Search'
Select to enable search engine Safe Search on Google, Yahoo!, Bing, and
Yandex.
YouTube
Education Filter
Select to enable the YouTube educational filter and enter your filter code.
The filter blocks non-educational content as per your YouTube filter code.
Log all search
keywords
This setting is not applicable to FortiClient.
Static URL Filter
Block invalid
URLs
This setting is not applicable to FortiClient.
URL Filter Select to enable URL filter. Select Create New to add a URL to the list. For
Type, select one of Simple,Reg. Expression, or Wildcard. For Action,
select one of Exempt,Block,Allow, or Monitor. For Status, select either
Enable or Disable.
FortiClient does not support the Exempt action. Any URLs in the URL filter
with an exempt action will be added to the FortiClient Exclusion List with an
allow action.
Block malicious
URLs discovered
by FortiSandbox
Select to block URLs that have been marked as malicious by FortiSandbox.
A FortiSandbox device or cloud must be configured.
Web Content
Filter
This setting is not applicable to FortiClient.
Rating Options These settings are not applicable to FortiClient.
Proxy Options These settings are not applicable to FortiClient.
4. Select OK to save the profile.
Administration Guide
Fortinet Technologies Inc.
76
Web Security/Web Filter Web Filter
If the FortiGate device is not licensed, you will receive an dialog box advising that
traffic may be blocked if this option is enabled.
Step 2: Add the Web Filter profile to the FortiClient Profile
1. Go to SecurityProfiles > FortiClient Profiles.
2. Select the FortiClient Profile then select Edit. The Edit FortiClient Profile page is displayed.
3. Enable Web Filter, then select the Web Filter profile from the drop-down list.
4. Optionally, select to enable Client Side when On-Net.
5. Select Apply to save the profile.
The FortiGate will send the FortiClient Profile configuration update to registered clients.
The Web Filtering module is now available in FortiClient.
EMS
To add web filtering to an endpoint profile:
1. Go to Endpoint Profiles and either select a profile to edit, or create a new profile.
2. Select the Web Filter tab.
77 Administration Guide
Fortinet Technologies Inc.
Web Filter Web Security/Web Filter
3. Select the on/off button to add web filtering to the profile.
4. Adjust the web filter settings as required, then select Save to save your changes.
Administration Guide
Fortinet Technologies Inc.
78
Application Firewall
FortiClient can recognize the traffic generated by a large number of applications. You can create rules to block or
allow this traffic per category, or application.
In FortiClient 5.2 and later, this feature is disabled by default and the tab is disabled
for standalone clients. For uses who are registered to a FortiGate using endpoint con-
trol, the FortiGate administer may choose to enable this feature.
For more information on configuring application control security profiles, see the
FortiOS Handbook - The Complete Guide to FortiOS available in the Fortinet Docu-
ment Library.
In FortiClient, the application firewall feature is enabled in the FortiClient Profile. The profile includes application
firewall configuration.
The FortiClient Endpoint Control feature enables the site administrator to distribute an Application Control sensor
from FortiGate/EMS.
On the FortiGate, the process is as follows:
lCreate an Application Sensor and Application Filter on the FortiGate,
lAdd the Application Sensor to the FortiClient Profile on the FortiGate.
On EMS, the application firewall is part of the endpoint profile.
FortiGate
Step 1: Create a custom Application Control Sensor
1. Log in to your FortiGate.
2. In the left tree menu, select Security Profiles> Application Control.
3. To create a new sensor, click the Create New icon in the toolbar. The New Application Sensor page is displayed.
79 Administration Guide
Fortinet Technologies Inc.
Application Firewall
4. Configure the following options:
Name Enter a unique name for the application sensor.
Comments Enter an option comment for the application sensor.
Categories Select categories to allow or block.
Allow The application category or application signature will be allowed in
FortiClient Application Firewall.
Monitor The application category or application signature will be allowed in
FortiClient Application Firewall.
FortiClient will allow application traffic but will not monitor.
Block The application category or application signature will be blocked in
FortiClient Application Firewall.
View Signatures Select to view signatures and add filters to the category.
Administration Guide
Fortinet Technologies Inc.
80
Application Firewall
Application Overrides Select Add Signatures to add application signatures and set the
category. An application which belongs to a blocked category can be
set to allow.
Filter Overrides Select Add Filter to add filters to the sensor.
Options The options set in the FortiOS application sensor are ignored by
FortiClient application firewall.
5. Select OK to save the sensor.
Step 2: Add the Application Control Sensor to the FortiClient Profile
1. In the left tree menu, select SecurityProfiles > FortiClient Profiles.
2. Select the FortiClient Profile and select Edit in the toolbar. The Edit FortiClient Profile page is displayed.
3. In the right pane, turn on the Application Firewall, then select an Application Sensor from the Application Control
list drop-down list.
4. Select Apply to save the profile.
The FortiGate will send the FortiClient Profile configuration update to registered clients.
The Application Firewall tab is now available in FortiClient.
EMS
To add application firewall to an endpoint profile:
1. Go to Endpoint Profiles and either select a profile to edit, or create a new profile.
2. Select the Application Firewall tab.
81 Administration Guide
Fortinet Technologies Inc.
Application Firewall
3. Select the on/off button to add application firewall to the profile.
4. Adjust the settings as required, then select Save to save your changes.
View application firewall profile
To view the application firewall profile, select Show all.
View blocked applications
To view blocked applications, select the Applications Blocked link in the FortiClient console. This page lists all
applications blocked in the past seven days, including the count and time of last occurrence.
Administration Guide
Fortinet Technologies Inc.
82
IPsec VPN and SSL VPN
FortiClient supports both IPsec and SSL VPN connections to your network for remote access. You can provision
client VPN connections in the FortiClient Profile or configure new connections in the FortiClient console.
This section describes how to configure remote access.
Add a new connection
Select Configure VPN in the FortiClient console to add a new VPN configuration.
Create a new SSL VPN connection
To create a new SSL VPN connection, select Configure VPNor use the drop-down menu in the FortiClient
console.
Select SSL-VPN, then configure the following settings:
Connection Name Enter a name for the connection.
Description Enter a description for the connection. (optional)
Remote Gateway Enter the IP address/hostname of the remote gateway. Multiple remote
gateways can be configured by separating each entry with a semicolon. If
one gateway is not available, the VPN will connect to the next configured
gateway.
Customize port Select to change the port. The default port is 443.
83 Administration Guide
Fortinet Technologies Inc.
Add a new connection IPsec VPN and SSL VPN
Authentication Select to prompt on login, or save login. The option to disable is available
when Client Certificate is enabled.
Username If you selected to save login, enter the username in the dialog box.
Client Certificate Select to enable client certificates, then select the certificate from the drop-
down list.
Do not Warn Invalid Server
Certificate
Select if you do not want to warned if the server presents an invalid cer-
tificate.
Add Select the add icon to add a new connection.
Delete Select a connection and then select the delete icon to delete a connection.
Select Apply to save the VPN connection, then select Close to return to the Remote Access screen.
Create a new IPsec VPN connection
To create a new IPsec VPN connection, select Configure VPN or use the drop-down menu in the FortiClient
console.
Select IPsec VPN, then configure the following settings:
Connection Name Enter a name for the connection.
Description Enter a description for the connection. (optional)
Remote Gateway Enter the IP address/hostname of the remote gateway. Multiple
remote gateways can be configured by separating each entry
with a semicolon. If one gateway is not available, the VPN will
connect to the next configured gateway.
Administration Guide
Fortinet Technologies Inc.
84
IPsec VPN and SSL VPN Add a new connection
Authentication Method Select either X.509 Certificate or Pre-shared Key in the drop-
down menu.
Authentication (XAuth) Select to prompt on login, save login, or disable.
Username If you selected save login, enter the username in the dialog box.
Advanced Settings Configure VPN settings, Phase 1, and Phase 2 settings.
VPN Settings
Mode Select one of the following:
lMain: In Main mode, the phase 1 parameters are
exchanged in multiple rounds with encrypted
authentication information.
lAggressive: In Aggressive mode, the phase 1
parameters are exchanged in a single message with
authentication information that is not encrypted.
Although Main mode is more secure, you must select Aggress-
ive mode if there is more than one dialup phase 1 configuration
for the interface IP address, and the remote VPN peer or client
is authenticated using an identifier (local ID).
Options Select one of the following:
lMode Config: IKE Mode Config can configure host IP
address, Domain, DNS and WINS addresses.
lManually Set: Manual key configuration. If one of the
VPN devices is manually keyed, the other VPN device
must also be manually keyed with the identical
authentication and encryption keys. Enter the DNS
server IP, assign IP address, and subnet values. Select
the check box to enable split tunneling.
lDHCP over IPsec: DHCP over IPsec can assign an IP
address, Domain, DNS and WINS addresses. Select the
check box to enable split tunneling.
Phase 1 Select the encryption and authentication algorithms used to gen-
erate keys for protecting negotiations and add encryption and
authentication algorithms as required.
You need to select a minimum of one and a maximum of two
combinations. The remote peer or client must be configured to
use at least one of the proposals that you define.
IKE Proposal Select symmetric-key algorithms (encryption) and message
digests (authentication) from the drop-down lists.
85 Administration Guide
Fortinet Technologies Inc.
Add a new connection IPsec VPN and SSL VPN
DH Group Select one or more Diffie-Hellman groups from DH group 1, 2, 5
and 14. At least one of the DH Group settings on the remote
peer or client must match one the selections on the FortiGate
unit. Failure to match one or more DH groups will result in failed
negotiations.
Key Life Enter the time (in seconds) that must pass before the IKE
encryption key expires. When the key expires, a new key is gen-
erated without interrupting service. The key life can be from 120
to 172,800 seconds.
Local ID Enter the Local ID (optional). This Local ID value must match
the peer ID value given for the remote VPN peer’s Peer Options.
Dead Peer Detec-
tion
Select this check box to reestablish VPN tunnels on idle con-
nections and clean up dead IKE peers if required.
NAT Traversal Select the check box if a NAT device exists between the client
and the local FortiGate unit. The client and the local FortiGate
unit must have the same NAT traversal setting (both selected or
both cleared) to connect reliably.
Phase 2 Select the encryption and authentication algorithms that will be
proposed to the remote VPN peer. You can specify up to two
proposals. To establish a VPN connection, at least one of the
proposals that you specify must match configuration on the
remote peer.
IKE Proposal Select symmetric-key algorithms (encryption) and message
digests (authentication) from the drop-down lists.
Key Life The Key Life setting sets a limit on the length of time that a
phase 2 key can be used. The default units are seconds. Altern-
atively, you can set a limit on the number of kilobytes (KB) of
processed data, or both. If you select both, the key expires
when either the time has passed or the number of KB have been
processed. When the phase 2 key expires, a new key is gen-
erated without interrupting service.
Enable Replay
Detection
Replay detection enables the unit to check all IPsec packets to
see if they have been received before. If any encrypted packets
arrive out of order, the unit discards them.
Enable Perfect
Forward Secrecy
(PFS)
Select the check box to enable Perfect forward secrecy (PFS).
PFS forces a new Diffie-Hellman exchange when the tunnel
starts and whenever the phase 2 key life expires, causing a new
key to be generated each time.
DH Group Select one Diffie-Hellman (DH) group (1, 2, 5 or 14). This must
match the DH Group that the remote peer or dialup client uses.
Administration Guide
Fortinet Technologies Inc.
86
IPsec VPN and SSL VPN Provision client VPN connections
Add Select the add icon to add a new connection.
Delete Select a connection and then select the delete icon to delete a
connection.
Select Apply to save the VPN connection, then select Close to return to the Remote Access screen.
Provision client VPN connections
You can provision client VPN connections in the FortiClient Profile for registered clients.
FortiGate VPN provisioning
Provision a client VPN in the FortiClient Profile:
1. Log in to your FortiGate device.
2. In the left tree menu, select SecurityProfiles > FortiClient Profiles.
3. Select the FortiClient profile and select Edit from the toolbar.
4. Select the VPN tab.
5. Turn on VPN and Client VPN Provisioning.
6. Configure the following:
87 Administration Guide
Fortinet Technologies Inc.
Provision client VPN connections IPsec VPN and SSL VPN
IPsec VPN Configure remote gateway and authentication settings for IPsec VPN.
SSL-VPN Configure remote gateway and access settings for SSL VPN.
Auto-connect when Off-Net Turn on the automatically connect when Off-Net, then configure the
following:
lVPN Name: Select a VPN from the list.
lPrevent VPN Disconnect: Turn on to not allow users to disconnect
when the VPN is connected.
lCaptive Portal Support: Turn on the enable support for captive
portals.
VPN before Windows logon Enable VPN connection before Windows log on.
7. Select Apply to save the profile.
The FortiGate will send the FortiClient Profile configuration update to registered clients.
When registered to a FortiGate, VPN settings are enabled and configured in the FortiClient Profile.
Alternatively, you can provision a client VPN using the advanced VPN FortiClient Pro-
file options in FortiGate. For more information, see the FortiClient XML Reference
and the CLI Reference for FortiOS.
EMS VPN provisioning
Provision a client VPN in the FortiClient Profile:
1. Log in to EMS.
2. Go to Endpoint Profiles and either select a profile to edit, or create a new profile.
3. Select the VPN tab.
Administration Guide
Fortinet Technologies Inc.
88
IPsec VPN and SSL VPN Provision client VPN connections
4. Select the on/off button to enable VPN.
5. Configure the following settings:
Allow Personal VPN Select to enable personal VPN connections
Disable
Connect/Disconnect
Select to disable not allowing users to disconnect when the VPN is
connected.
Show VPN Before Logon Enable VPN connection before Windows log on, and select from the
following options:
lUse Legacy VPN Before Logon
lUse Windows Credentials
89 Administration Guide
Fortinet Technologies Inc.
Provision client VPN connections IPsec VPN and SSL VPN
Local Computer Windows
Store Certificates (IPSec
only)
Select to enable local Windows store certificates (IPsec only).
Current User Windows
Store Certificates (IPSec
only)
Select to enable current user Windows store certificates (IPsec only).
Auto-connect only when
Off-Net
Turn on the automatically connect only when Off-Net.
Add VPN Tunnel Select to add a VPN tunnel, then enter the following information:
lVPN Name: Enter the VPN name.
lType: Select the type of VPN tunnel, either SSL VPN or IPsec
VPN.
lRemote Gateway: Enter the remote gateway IPaddress or
hostname.
lRequire Certificate: Turn on to require a certificate (SSL VPN only).
lAccess Port: Enter the access port number (SSL VPN only).
lAuthentication Method: Select the authentication method, wither
Pre-shared Key or Certificate (IPsec VPN only).
lPre-Shared Key: Enter the pre-shared key (IPsec VPN with pre-
shared key only).
lAdvanced Configuration:
6. Select Save to save your changes.
Connect to a VPN
To connect to a VPN, select the VPN connection from the drop-down menu. Enter your username, password, and
select the Connect button.
Administration Guide
Fortinet Technologies Inc.
90
IPsec VPN and SSL VPN Save Password, Auto Connect, and Always Up
Provisioned VPN connections will be listed under Corporate VPN. Locally configured
VPN connections will be listed under Personal VPN.
Optionally, you can click on the system tray, right-click the FortiClient icon and select the VPN connection you
want to connect to.
You can also select to edit an existing VPN connection and delete an existing VPN connection using the drop-
down menu.
When connected, the console will display the connection status, duration, and other relevant information. You
can now browse your remote network. Select the Disconnect button when you are ready to terminate the VPN
session.
Save Password, Auto Connect, and Always Up
When configuring a FortiClient IPsec or SSL VPN connection on your FortiGate/EMS, you can select to enable
the following features:
lSave Password: Allows the user to save the VPN connection password in the console.
lAuto Connect: When FortiClient is launched, the VPN connection will automatically connect.
lAlways Up (Keep Alive): When selected, FortiClient attempts to re-connect VPN when the VPNconnection
unexpectedly disconnects. FortiClient does not attempt re-connection when the user manually disconnects VPN.
For SSL VPN tunnel mode configurations these features are enabled/disabled in the
SSL VPN Portal.
When enabled in the FortiGate configuration, once the FortiClient is connected to the FortiGate, the client will
receive these configuration options.
91 Administration Guide
Fortinet Technologies Inc.
FortiToken and FortiClient VPN IPsec VPN and SSL VPN
For FortiClient VPN configurations, once these features are enabled they may only be edited from the command
line. Use the following FortiOS CLI commands to disable these features:
config vpn ipsec phase1-interface
edit [vpn name]
set save-password disable
set client-auto-negotiate disable
set client-keep-alive disable
end
end
FortiToken and FortiClient VPN
You can use FortiToken with FortiClient for two-factor authentication. See the FortiOS Handbook for information
on configuring FortiToken, user groups, VPN, and two-factor authentication on your FortiGate device for
FortiClient VPN connections.
Administration Guide
Fortinet Technologies Inc.
92
IPsec VPN and SSL VPN Advanced features (Microsoft Windows)
Advanced features (Microsoft Windows)
When deploying a custom FortiClient XML configuration, use the advanced FortiClient
Profile options in FortiGate/EMS to ensure the FortiClient Profile settings do not over-
write your custom XML settings. For more information, see the FortiClient XML Refer-
ence and the FortiOS CLI Reference.
Activating VPN before Windows Log on
When using VPN before Windows log on, the user is offered a list of pre-configured VPN connections to select
from on the Windows log on screen. This requires that the Windows log on screen is not bypassed. As such, if
VPN before Windows log on is enabled, it is required to also check the check box Users must enter a user name
and password to use this computer in the User Accounts dialog box.
To make this change, proceed as follows:
In FortiClient:
1. Create the VPN tunnels of interest or use Endpoint Control to register to a FortiGate/EMS which provides the VPN
list of interest
2. Enable VPN before log on on the FortiClient Settings page, see VPN options on page 104.
On the Microsoft Windows system,
1. Start an elevated command line prompt.
2. Enter control passwords2 and press Enter. Alternatively, you can enter netplwiz.
3. Check the check box for Users must enter a user name and password to use this computer.
4. Click OK to save the setting.
Connect VPN before log on (AD environments)
The VPN <options> tag holds global information controlling VPN states. The VPN will connect first, then log on
to AD/Domain.
<forticlient_configuration>
<vpn>
<options>
<show_vpn_before_logon>1</show_vpn_before_logon>
<use_windows_credentials>1</use_windows_credentials>
</options>
</vpn>
</forticlient_configuration>
Create a redundant IPsec VPN
To use VPN resiliency/redundancy, you will configure a list of FortiGate/EMS IP/FQDN servers, instead of just
one:
<forticlient_configuration>
<vpn>
<ipsecvpn>
<options>
93 Administration Guide
Fortinet Technologies Inc.
Advanced features (Microsoft Windows) IPsec VPN and SSL VPN
...
</options>
<connections>
<connection>
<name>psk_90_1</name>
<type>manual</type>
<ike_settings>
<prompt_certificate>0</prompt_certificate>
<server>10.10.90.1;ipsecdemo.fortinet.com;172.17.61.143</server>
<redundantsortmethod>1</redundantsortmethod>
...
</ike_settings>
</connection>
</connections>
</ipsecvpn>
</vpn>
</forticlient_configuration>
This is a balanced, but incomplete XML configuration fragment. All closing tags are included, but some important
elements to complete the IPsec VPN configuration are omitted.
RedundantSortMethod = 1
This XML tag sets the IPsec VPN connection as ping-response based. The VPN will connect to the
FortiGate/EMS which responds the fastest.
RedundantSortMethod = 0
By default, RedundantSortMethod =0 and the IPsec VPN connection is priority based. Priority based
configurations will try to connect to the FortiGate/EMS starting with the first in the list.
Priority based SSL VPN connections
SSL VPN supports priority based configurations for redundancy.
<forticlient_configuration>
<vpn>
<sslvpn>
<options>
<enabled>1</enabled>
...
</options>
<connections>
<connection>
<name>ssl_90_1</name>
<server>10.10.90.1;ssldemo.fortinet.com;172.17.61.143:443</server>
...
</connection>
</connections>
</sslvpn>
</vpn>
</forticlient_configuration>
This is a balanced, but incomplete XML configuration fragment. All closing tags are included, but some important
elements to complete the SSL VPN configuration are omitted.
For SSL VPN, all FortiGate/EMS must use the same TCP port.
Administration Guide
Fortinet Technologies Inc.
94
IPsec VPN and SSL VPN Advanced features (Mac OS X)
Advanced features (Mac OS X)
When deploying a custom FortiClient XML configuration, use the advanced FortiClient
Profile options in FortiGate/EMS to ensure the FortiClient Profile settings do not over-
write your custom XML settings. For more information, see the FortiClient XML Refer-
ence and the FortiOS CLI Reference.
Create a redundant IPsec VPN
To use VPN resiliency/redundancy, you will configure a list of FortiGate/EMS IP/FQDN servers, instead of just
one:
<forticlient_configuration>
<vpn>
<ipsecvpn>
<options>
...
</options>
<connections>
<connection>
<name>psk_90_1</name>
<type>manual</type>
<ike_settings>
<prompt_certificate>0</prompt_certificate>
<server>10.10.90.1;ipsecdemo.fortinet.com;172.17.61.143</server>
<redundantsortmethod>1</redundantsortmethod>
...
</ike_settings>
</connection>
</connections>
</ipsecvpn>
</vpn>
</forticlient_configuration>
This is a balanced, but incomplete XML configuration fragment. All closing tags are included, but some important
elements to complete the IPsec VPN configuration are omitted.
RedundantSortMethod = 1
This XML tag sets the IPsec VPN connection as ping-response based. The VPN will connect to the
FortiGate/EMS which responds the fastest.
RedundantSortMethod = 0
By default, RedundantSortMethod =0 and the IPsec VPN connection is priority based. Priority based
configurations will try to connect to the FortiGate/EMS starting with the first in the list.
Priority based SSL VPN connections
SSL VPN supports priority based configurations for redundancy.
<forticlient_configuration>
<vpn>
95 Administration Guide
Fortinet Technologies Inc.
VPN tunnel & script IPsec VPN and SSL VPN
<sslvpn>
<options>
<enabled>1</enabled>
...
</options>
<connections>
<connection>
<name>ssl_90_1</name>
<server>10.10.90.1;ssldemo.fortinet.com;172.17.61.143:443</server>
...
</connection>
</connections>
</sslvpn>
</vpn>
</forticlient_configuration>
This is a balanced, but incomplete XML configuration fragment. All closing tags are included, but some important
elements to complete the SSL VPN configuration are omitted.
For SSL VPN, all FortiGate/EMS must use the same TCP port.
VPN tunnel & script
This feature supports auto running a user-defined script after the configured VPN tunnel is connected or
disconnected. The scripts are batch scripts in Windows and shell scripts in Mac OS X. They are defined as part of
a VPN tunnel configuration on FortiGate/EMS's XML format FortiClient Profile. The profile will be pushed down to
FortiClient from FortiGate/EMS. When FortiClient's VPN tunnel is connected or disconnected, the respective
script defined under that tunnel will be executed.
Windows
Map a network drive after tunnel connection
The script will map a network drive and copy some files after the tunnel is connected.
<on_connect>
<script>
<os>windows</os>
<script>
<script>
<![CDATA[net use x: \\192.168.10.3\ftpshare /user:Ted Mosby md c:\test copy
x:\PDF\*.* c:\test ]]>
</script>
</script>
</script>
</on_connect>
Delete a network drive after tunnel is disconnected
The script will delete the network drive after the tunnel is disconnected.
<on_disconnect>
<script>
<os>windows</os>
Administration Guide
Fortinet Technologies Inc.
96
IPsec VPN and SSL VPN VPN tunnel & script
<script>
<script>
<![CDATA[net use x: /DELETE ]]>
</script>
</script>
</script>
</on_disconnect>
OS X
Map a network drive after tunnel connection
The script will map a network drive and copy some files after the tunnel is connected.
<on_connect>
<script>
<os>mac</os>
<script>
/bin/mkdir /Volumes/installers
/sbin/ping -c 4 192.168.1.147 > /Users/admin/Desktop/dropbox/p.txt
/sbin/mount -t smbfs //kimberly:RigUpTown@ssldemo.fortinet.com/installers
/Volumes/installers/ > /Users/admin/Desktop/dropbox/m.txt
/bin/mkdir /Users/admin/Desktop/dropbox/dir
/bin/cp /Volumes/installers/*.log /Users/admin/Desktop/dropbox/dir/.
</script>
</script>
</on_connect>
Delete a network drive after tunnel is disconnected
The script will delete the network drive after the tunnel is disconnected.
<on_disconnect>
<script>
<os>mac</os>
<script>
/sbin/umount /Volumes/installers
/bin/rm -fr /Users/admin/Desktop/dropbox/*
</script>
</script>
</on_disconnect>
97 Administration Guide
Fortinet Technologies Inc.
Vulnerability Scan
FortiClient includes an Vulnerability Scan module to check your workstation for known system vulnerabilities.
You can scan on-demand or on a scheduled basis. This feature is disabled by default and the tab is hidden for
standalone clients. For users who are registered to a FortiGate using endpoint control, the FortiGate
administrator may choose to enable this feature. Vulnerability Scan is enabled via the FortiGate Command Line
Interface (CLI) only. Once enabled, the Endpoint Vulnerability Scan on Client setting is available in the
FortiClient Profile.
Enable vulnerability scan
This section describes how to enable Vulnerability Scan in the FortiClient Profile via the FortiGate CLI and
configuration options.
1. Enable Vulnerability Scan in the FortiClient Profile:
2. Log in to your FortiGate CLI.
3. Enter the following CLI commands:
config endpoint-control profile
edit <profile-name>
config forticlient-winmac-settings
set forticlient-vuln-scan enable
set forticlient-vuln-scan-schedule {daily| weekly| monthly}
set forticlient-vuln-scan-on-registration {enable| disable}
set forticlient-ui-options {av| wf| af| vpn| vs}
end
end
When setting the forticlient-ui-options, you must include all the modules
that you want to enable in the FortiClient console.
<profile-name> Enter the name of the FortiClient Profile.
forticlient-vuln-scan
{enable| disable}
Enable or disable the Vulnerability Scan module.
forticlient-vuln-
scan-schedule
{daily| weekly|
monthly}
Configure a daily, weekly, or monthly vulnerability scan on the client
workstation.
forticlient-vuln-
scan-on-registration
{enable| disable}
Enable or disable vulnerability scan on client registration to FortiGate.
Administration Guide
Fortinet Technologies Inc.
98
Vulnerability Scan Scan now
forticlient-ui-
options {av| wf|
af| vpn| vs}
Set the FortiClient components that will be available to the client upon
registration with FortiGate.
lav: Antivirus
lwf: Web Filter
laf: Application Firewall
lvpn: Remote Access
lvs: Vulnerability Scan
4. The FortiGate will send the FortiClient Profile configuration update to registered clients.
The Vulnerability Scan tab is now accessible in FortiClient.
Scan now
To perform a vulnerability scan, select the Scan Now button in the FortiClient console. FortiClient will scan your
workstation for known vulnerabilities. The console displays the date of the last scan above the button.
You can select to use a FortiManager device for client software and signature updates.
When configuring the FortiClient Profile, select Use FortiManager for client soft-
ware/signature update to enable the feature and enter the IP address of your
FortiManager device.
View vulnerabilities
When the scan is complete, FortiClient will display the number of vulnerabilities found in the FortiClient console.
Select the Vulnerabilities Detected link to view a list of vulnerabilities detected on your system. Conversely,
select Detected: X on the Vulnerability Scan tab to view the vulnerabilities.
99 Administration Guide
Fortinet Technologies Inc.
View vulnerabilities Vulnerability Scan
This page displays the following:
Vulnerability Name The name of the vulnerability
Severity The severity level assigned to the vulnerability: Critical, High, Medium,
Low, or Info.
Details FortiClient vulnerability scan lists a Bugtraq (BID) number under the details
column. You can select the BID to view details of the vulnerability on the
FortiGuard site, or search the web using this BID number.
Close Close the window and return to the FortiClient console.
Select the Details ID number from the list to view information on the selected vulnerability on the FortiGuard site.
The site details the release date, severity, impact, description, affected products, and recommended actions.
Administration Guide
Fortinet Technologies Inc.
100
Settings
This sections describe the available options in the settings menu.
Backup or restore full configuration
To backup or restore the full configuration file, select File > Settings from the toolbar. Expand the System
section, then select Backup or Restore as needed. Restore is only available when operating in standalone
mode.
When performing a backup you can select the file destination, password requirements, and add comments as
needed.
Logging
To configure logging, select File > Settings from the toolbar then expand the Logging section.
VPN VPN logging is available when in standalone mode or when registered to
FortiGate/EMS.
Application Firewall Application Firewall logging is available when registered to FortiGate/EMS.
AntiVirus Antivirus activity logging is available when in standalone mode or when
registered to FortiGate/EMS.
Web Filter Web Filter logging is available when in standalone mode (Web Security) or
when registered to FortiGate/EMS.
Update Update logging is available when in standalone mode or when registered to
FortiGate/EMS.
Vulnerability Scan Vulnerability Scan logging is available when registered to FortiGate/EMS.
101 Administration Guide
Fortinet Technologies Inc.
Logging Settings
Log Level This setting can be configured when in standalone mode. When registered
to FortiGate, this setting is set by the XML configuration (if configured).
Log File The option to export the log file (.log) is available when in standalone
mode or when registered to FortiGate/EMS. The option to clear logs is only
available when in standalone mode.
The following table lists the logging levels and description:
Logging Level Description
Emergency The system becomes unstable.
Alert Immediate action is required.
Critical Functionality is affected.
Error An error condition exists and functionality could be affected.
Warning Functionality could be affected.
Notice Information about normal events.
Information General information about system operations.
Debug Debug FortiClient.
It is recommended to use the debug logging level only when needed. Do not leave the
debug logging level permanently enabled in a production environment to avoid unne-
cessarily consuming disk space.
Configure logging to FortiAnalyzer or FortiManager
To configure FortiClient to log to your FortiAnalyzer or FortiManager you require the following:
lFortiClient 5.2.0 or later
lA FortiGate device running FortiOS 5.2.0 or later, or EMS 1.0
lA FortiAnalyzer or FortiManager device running 5.0.7 or later
The registered FortiClient device will send traffic logs, vulnerability scan logs, and event logs to the log device on
port 514 TCP.
FortiClient must be registered to FortiGate/EMS to upload logs to FortiAna-
lyzer/FortiManager.
When FortiClient is On-Net, the icon displayed to the left of the username will be
green. When FortiClient is Off-Net, the icon is gray.
Administration Guide
Fortinet Technologies Inc.
102
Settings Logging
Some features such as Client-based Logging when On-Net, are only available in the
FortiClient Profile when a FortiClient 5.2 license has been applied to the FortiGate.
Enable logging on the FortiGate device:
1. On your FortiGate device, select Log & Report > Log Settings. The Log Settings window opens.
2. Enable Send Logs to FortiAnalyzer/FortiManager.
3. Enter the IP address of your log device in the IPAddress field. You can select Test Connectivity to ensure your
FortiGate is able to communicate with the log device on this IP address.
4. Select Apply to save the setting.
FortiClient must be able to access the FortiAnalyzer IP address in order to forward
logs.
Enable logging in the FortiGate FortiClient profile:
1. Go to SecurityProfiles > FortiClient Profiles.
2. Select the FortiClient Profile and select Edit from the toolbar. The Edit FortiClient Profile page opens.
3. In the Advanced tab, enable Upload Logs to FortiAnalyzer.
4. Select either Same as System to send the logs to the FortiAnalyzer or FortiManager configured in the Log
Settings, or Specify to enter a different IP address.
5. In the Schedule field, select to upload logs wither Hourly or Daily.
6. Select Apply to save the settings.
Once the FortiClient Profile change is synchronized with the client, you will start receiving logs from
registered clients on your FortiAnalyzer/FortiManager system.
Alternatively, you can configure logging in the command line interface. Go to System> Dashboard>
Status. In the CLI Console widget, enter the following CLI commands:
config endpoint-control profile
edit <profile-name>
config forticlient-winmac-settings
set forticlient-log-upload enable
set forticlient-log-upload-server <IP address>
set forticlient-log-upload-schedule {hourly| daily}
set forticlient-log-ssl-upload {enable| disable}
set client-log-when-on-net {enable| disable}
end
end
To download the FortiClient log files on the FortiAnalyzer go to the Log View tab, select the ADOM, and
select the FortiClient menu object.
Enable logging in the EMS endpoint profile:
1. On EMS, select an endpoint profile, then go to the System Settings tab.
2. Enable Upload Logs to FortiAnalyzer/FortiManager.
3. Enter the IP address or hostname, schedule upload (in minutes), and log generation timeout (in seconds).
4. Select Save to save the settings.
103 Administration Guide
Fortinet Technologies Inc.
Updates Settings
Updates
To configure updates, select File > Settings from the toolbar, then expand the System section.
Select to either automatically download and install updates when they are available on the FortiGuard
Distribution Servers, or to send an alert when updates are available.
This setting can only be configured when in standalone mode.
You can select to use a FortiManager device for signature updates. When configuring
the endpoint profile, select Use FortiManager for client software/signature updates to
enable the feature and enter the IP address of your FortiManager device.
To configure FortiClient to use FortiManager for signature updates (FortiGate):
1. On your FortiOS device, select Security Profiles > FortiClient Profiles.
2. On the Advanced tab, enable FortiManager updates.
3. Specify the IP address or domain name of the FortiManager device.
4. Select Failover to FDN to have FortiClient receive updates from the FortiGuard Distribution Network when the
FortiManager is not available.
5. Select Apply to save the settings.
To configure FortiClient to use FortiManager for signature updates (EMS):
1. On EMS, select an endpoint profile, then go to the System Settings tab.
2. Toggle the Use FortiManager for client software/signature update option to ON.
3. Specify the IP address or hostname of the FortiManager device.
4. Select Failover to FDN when FortiManager is not available to have FortiClient receive updates from the
FortiGuard Distribution Network when the FortiManager is not available.
5. Select Save to save the settings.
VPN options
To configure VPN options, select File > Settings from the toolbar and expand the VPN section. Select Enable
VPN before logon to enable VPN before log on.
This setting can only be configured when in standalone mode.
Certificate management
To configure VPN certificates, select File > Settings from the toolbar and expand the Certificate Management
section. Select Use local certificate uploads (IPsec only) to configure IPsec VPN to use local certificates and
import certificates to FortiClient.
This setting can only be configured when in standalone mode.
Administration Guide
Fortinet Technologies Inc.
104
Settings Antivirus options
Antivirus options
To configure antivirus options, select File > Settings from the toolbar and expand the Antivirus Options section.
These settings can only be configured when in standalone mode.
Configure the following settings:
Grayware Options Grayware is an umbrella term applied to a wide range of malicious applic-
ations such as spyware, adware and key loggers that are often secretly
installed on a user's computer to track and/or report certain information
back to an external source without the user's permission or knowledge.
Adware Select to enable adware detection and quarantine during the antivirus
scan.
Riskware Select to enable riskware detection and quarantine during the antivirus
scan.
Scan removable media on
insertion
Select to scan removable media when it is inserted.
Alert when viruses are
detected
Select to have FortiClient provide a notification alert when a threat is detec-
ted on your personal computer. When Alert when viruses are detected
under AntiVirus Options is not selected, you will not receive the virus alert
dialog box when attempting to download a virus in a web browser.
Pause background scan-
ning on battery power
Select to pause background scanning when your computer is operating on
battery power.
Enable FortiGuard Ana-
lytics
Select to automatically send suspicious files to the FortiGuard Network for
analysis.
When registered to FortiGate, you can select to enable or disable FortiClient Antivirus Protection in the
FortiClient Profile.
Advanced options
To configure advanced options, select File > Settings from the toolbar and expand the Advance section.
These settings can only be configured when in standalone mode. When registered to FortiGate/EMS, these
settings are set by the XML configuration (if configured).
105 Administration Guide
Fortinet Technologies Inc.
Single Sign-On mobility agent Settings
Configure the following settings:
Enable WAN Optimization Select to enable WAN Optimization. You should enable only if you have a
FortiGate device and your FortiGate is configured for WAN Optimization.
This setting can be configured when in standalone mode.
Maximum Disk
Cache Size
Select to configure the maximum disk cache size. The default value is
512MB.
Enable Single Sign-On
mobility agent
Select to enable Single Sign-On Mobility Agent for FortiAuthenticator. To
use this feature you need to apply a FortiClient SSO mobility agent license
to your FortiAuthenticator device.
This setting can be configured when in standalone mode.
Server address Enter the FortiAuthenticator IP address.
Customize port Enter the port number. The default port is 8001.
Pre-shared Key Enter the pre-shared key. The pre-shared key should match the key con-
figured on your FortiAuthenticator device.
Disable proxy (troubleshoot-
ing only)
Select to disable proxy when troubleshooting FortiClient.
This setting can be configured when in standalone mode.
Default tab Select the default tab to be displayed when opening FortiClient.
This setting can be configured when in standalone mode.
Single Sign-On mobility agent
The FortiClient Single Sign-On (SSO) Mobility Agent is a client that updates with FortiAuthenticator with user
logon and network information.
FortiClient/FortiAuthenticator protocol
The FortiAuthenticator listens on a configurable TCP port. FortiClient connects to FortiAuthenticator using
TLS/SSL with two-way certificate authentication. The FortiClient sends a logon packet to FortiAuthenticator,
which replies with an acknowledgment packet.
FortiClient/FortiAuthenticator communication requires the following:
Administration Guide
Fortinet Technologies Inc.
106
Settings Single Sign-On mobility agent
lThe IP address should be unique in the entire network.
lThe FortiAuthenticator should be accessible from clients in all locations.
lThe FortiAuthenticator should be accessible by all FortiGates.
FortiClient Single Sign-On Mobility Agent requires a FortiAuthenticator running 2.0.0
or later, or v3.0.0 or later. Enter the FortiAuthenticator (server) IP address, port num-
ber, and the pre-shared key configured on the FortiAuthenticator.
Enable Single Sign-On mobility agent on FortiClient:
1. Select File in the toolbar and select Settings in the drop-down menu.
2. Select Advanced to view the drop-down menu.
3. Select to Enable Single Sign-On mobility agent.
4. Enter the FortiAuthenticator server address and the pre-shared key.
This setting can be configured when in standalone mode. When registered to
FortiGate, this setting is set by the XML configuration (if configured).
Enable FortiClient SSO mobility agent service on the FortiAuthenticator:
1. Select Fortinet SSO Methods > SSO > General. The Edit SSO Configuration page opens.
2. Select Enable FortiClient SSO Mobility Agent Service and enter a TCP port value for the listening port.
3. Select Enable authentication and enter a secret key or password.
4. Select OK to save the setting.
To enable FortiClient FSSO services on the interface:
1. Select System > Network > Interfaces. Select the interface and select Edit from the toolbar. The Edit Network
Interface window opens.
107 Administration Guide
Fortinet Technologies Inc.
Configuration lock Settings
2. Select the checkbox to enable FortiClient FSSO.
3. Select OK to save the setting.
To enable the FortiClient SSO Mobility Agent Service on the FortiAuthenticator, you
must first apply the applicable FortiClient license for FortiAuthenticator. For more
information, see the FortiAuthenticator Administration Guide in the Fortinet Docu-
ment Library.
For information on purchasing a FortiClient license for FortiAuthenticator, please con-
tact your authorized Fortinet reseller.
Configuration lock
To prevent unauthorized changes to the FortiClient configuration, select the lock icon located at the bottom left of
the Settings page. You will be prompted to enter and confirm a password. When the configuration is locked,
configuration changes are restricted and FortiClient cannot be shutdown or uninstalled.
When the configuration is locked you can perform the following actions:
lAntivirus
lComplete an antivirus scan, view threats found, and view logs
lSelect Update Now to update signatures
lWeb Security
lView violations
lApplication Firewall
lView applications blocked
lRemote Access
lConfigure, edit, or delete an IPsec VPN or SSL VPN connection
lConnect to a VPN connection
lVulnerability Scan
lComplete a vulnerability scan of the system
lView vulnerabilities found
lRegister and unregister FortiClient for Endpoint Control
lSettings
lExport FortiClient logs
lBackup the FortiClient configuration
To perform configuration changes or to shut down FortiClient, select the lock icon and enter the password used to
lock the configuration.
FortiTray
When FortiClient is running on your system, you can select the FortiTray icon in the Windows system tray to
perform various actions. The FortiTray icon is available in the system tray even when the FortiClient console is
closed.
Administration Guide
Fortinet Technologies Inc.
108
Settings FortiTray
lDefault menu options
lOpen FortiClient console
lShutdown FortiClient
lDynamic menu options depending on configuration
lConnect to a configured IPsec VPN or SSL VPN connection
lDisplay the antivirus scan window (if a scheduled scan is currently running)
lDisplay the Vulnerability scan window (if a vulnerability scan is running)
If you hover the mouse cursor over the FortiTray icon, you will receive various notifications including the version,
antivirus signature, and antivirus engine.
When the configuration is locked, the option to shut down FortiClient from FortiTray is
grayed out.
Connect to a VPN connection
To connect to a VPN connection from FortiTray, select the Windows System Tray and right-click in the FortiTray
icon. Select the connection you wish to connect to, enter your username and password in the authentication
window, then select OK to connect.
109 Administration Guide
Fortinet Technologies Inc.
Custom FortiClient Installations
The FortiClient Configurator tool FortiClient is the recommended method of creating customized FortiClient
installation files.
You can also customize which modules are displayed in the FortiClient dashboard in
the FortiClient Profile. This will allow you to activate any of the modules at a later date
without needing to re-install FortiClient. Any changes made to the FortiClient Profile
are pushed to registered clients.
When creating VPN only installation files, you cannot enable other modules in the
FortiClient Profile as only the VPN module is installed.
When deploying a custom FortiClient XML configuration, use the advanced FortiClient
Profile options in FortiGate to ensure the FortiClient Profile settings do not overwrite
your custom XML settings. For more information, see the FortiClient XML Reference
and the CLI Reference for FortiOS.
The FortiClient Configurator tool is included with the FortiClient Tools file in FortiClient 5.2. This file is only
available on the Customer Service & Support portal and is located in the same file directory as the FortiClient
images.
The Configurator tool requires activation with a license file. Ensure that you have completed the following steps
prior to logging in to your FortiCare product web portal:
lPurchased FortiClient Registration License
lActivated the FortiClient license on a FortiGate
This video explains how to purchase and apply a FortiClient License:
http://www.youtube.com/watch?feature=player_embedded&v=sIkWaUXK0Ok
This chapter contains the following sections:
lDownload the license file
lCreate a custom installer
lCustom installation packages
lAdvanced FortiClient profiles
Download the license file
To retrieve your license file:
1. Go to https://support.fortinet.com and log in to your FortiCare account.
2. Under Asset select Manage/View Products. Select the FortiGate device that has the FortiClient registration
license activated. You will see the Get the Key File link in the Available Key(s) section.
Administration Guide
Fortinet Technologies Inc.
110
Custom FortiClient Installations Create a custom installer
3. Click the link and download license file to your management computer. This file will be needed each time you use
the FortiClient Configurator tool.
To use FortiClient Configurator, you need to use a FortiClient 5.4 license file.
Create a custom installer
Fortinet offers a repacking tool for both Microsoft Windows and Mac OS X operating systems. The following
section provides instructions on creating a custom installer file using the FortiClient Configurator tool.
When selecting to install custom features, only modules selected are installed. To
enable other features you will need to uninstall FortiClient, and reinstall an MSI file
with these features included in the installer.
FortiClient (Windows) Configurator tool
To create a custom installer using the FortiClient Configurator tool:
1. Unzip the FortiClientTools file, select the FortiClientConfigurator file folder, and double-click the
FortiClientConfigurator.exe application file to launch the tool.
The tool opens at the Welcome page.
111 Administration Guide
Fortinet Technologies Inc.
Create a custom installer Custom FortiClient Installations
Licensed Licensed mode requires a FortiClient license file.
Trial In FortiClient 5.4, the FortiClient Configurator tool can be used in trial
mode. In trial mode, all online updates are disabled. The trial installer is
intended to be deployed in a test environment.
2. Browse and select the FortiClient Configurator Activation Key file (.lic) on your management computer.
The FortiClient Configurator tool is not installed on the management computer. You
must upload the FortiClient Configurator Activation Key file (.lic) each time you run
the tool.
3. After entering the FortiClient Configurator license, select Next. The Configuration File page is displayed.
Select Config File
(optional)
The configuration file (.conf, .sconf) settings will be included in the
installer file.
Password If the configuration file is encrypted (.sconf), enter the password used to
encrypt the file.
You can use an XML editor to make changes to the FortiClient configuration file. For
more information on FortiClient XML configuration, see the FortiClient XML
Reference in the Fortinet Document Library, http://docs.fortinet.com.
4. Browse and select the FortiClient configuration file on your management computer. This is an optional step. If you
do not want to import settings from a configuration file, select Skip to continue. The Settings page is displayed.
Administration Guide
Fortinet Technologies Inc.
112
Custom FortiClient Installations Create a custom installer
The following options are available for custom installations:
Features to Install
Everything All Security and VPN components will be installed.
Client security
only
Only AntiVirus, Web Filtering, and Application Firewall will be installed.
VPN only Only VPN components (IPsec and SSL) will be installed.
Other Select one of the following from the drop-down list:
lAntiVirus & Web Filtering only
lWeb Filtering only
lApplication Firewall only
lApplication Firewall & Web Filtering only
lWeb Filtering, VPN and Application Firewall
lSingle Sign-On mobility agent only
Options
Desktop Shortcut Select to create a FortiClient desktop icon.
Start Menu Select to add FortiClient to the start menu.
Enable Software
Update
Select to enable software updates. This option is disabled when Rebrand
FortiClient is selected. This option is also disabled when using Trial mode.
Configure Single
Sign-On mobility
agent
Select to configure Singe Sign-On mobility agent for use with
FortiAuthenticator.
113 Administration Guide
Fortinet Technologies Inc.
Create a custom installer Custom FortiClient Installations
Features to Install
Rebrand
FortiClient
Select to rebrand FortiClient. When selected, the option to enable software
update is not available. For more information on rebranding FortiClient,
see Appendix C - Rebranding FortiClient on page 133.
5. Select the features to install and options and select Next to continue.
If you selected to configure the single sign-on mobility agent, the Single Sign-On Mobility Agent Settings
page is displayed.
6. Configure the following settings:
Server IP/FQDN Enter the IP address or FQDN of the FortiAuthenticator server.
Port Number Enter the port number. The default port is 8001.
Pre-Shared Key Enter the FortiAuthenticator pre-shared key.
Confirm Pre-Shared Key Enter the FortiAuthenticator pre-shared key confirmation.
7. Select Next to continue. If you selected to rebrand FortiClient, the Rebranding page is displayed.
Administration Guide
Fortinet Technologies Inc.
114
Custom FortiClient Installations Create a custom installer
8. Rebrand FortiClient elements as required. The resources folder contains graphical elements. For more
information, see Appendix C - Rebranding FortiClient on page 133.
9. Select Next to continue. The Package Signing page is displayed.
10. Configure the following settings:
Select Code Signing
Certificate (optional)
If you have a code signing certificate, you can use it to digitally sign the
installer package this tool generates.
Password If the certificate file is password protected, enter the password.
11. Browse and select the code signing certificate on your management computer. This is an optional step. If you do
not want to digitally sign the installer package, select Skip to continue. The Execution page is displayed.
115 Administration Guide
Fortinet Technologies Inc.
Create a custom installer Custom FortiClient Installations
This page provides details of the installer file creation and the location of files for Active Directory deployment
and manual distribution. The tool creates files for both 32-bit (x86) and 64-bit (x64) operating systems.
12. When you select Finish, if Browse to output MSI file upon exit is selected, the folder containing the newly created
MSI file will open.
Before deploying the custom MSI files, it is recommended that you test the packages
to confirm that they install correctly. In FortiClient 5.2.0 and later, an .exe installation
file is created for manual distribution.
Installation files are organized in folders within the FortiClientTools> FortiClient
Configurator > FortiClient repackaged folder. Folder names identify the type of
installation files that were created and the creation date.
FortiClient (Mac OS X) Configurator tool
To create a custom installer using the FortiClient Configurator tool:
1. Unzip the FortiClientTools file, select the Configurator file folder, and double-click the
FortiClientConfigurator.dmg application file, and double-click the FCTConfigurator icon to launch the tool. The
Configurator tool opens.
Administration Guide
Fortinet Technologies Inc.
116
Custom FortiClient Installations Create a custom installer
2. Configure the following settings:
Licensed | Trial Licensed mode requires a FortiClient 5.2 license file. In FortiClient v5.2,
the FortiClient Configurator tool can be used in trial mode. In trial mode, all
online updates are disabled. The trial installer is intended to be deployed in
a test environment.
Source Select the FortiClient Installer file on your management computer.
You must use the full installer file, otherwise FortiClient Configurator will
fail to create a custom installation file.
The FortiClient Installer version and FortiClient Configurator version must
match, otherwise the Configurator will fail to create a custom installation
file.
Destination Enter a name for the custom installation file and select a destination to
save the file on your management computer.
Features to Install Select to install all FortiClient modules, VPN only, or SSO only. If SSO only
is selected, you must configure the SSO settings in the attached
configuration file.
Server IP/FQDN Enter the IP address or FQDN of the FortiAuthenticator server.
This option is available when selecting SSO only for features to install.
Port Number Enter the port number. The default port is 8001.
This option is available when selecting SSO only for features to install.
Pre-Shared Key Enter the FortiAuthenticator pre-shared key.
This option is available when selecting SSO only for features to install.
Confirm Pre-Shared Key Enter the FortiAuthenticator pre-shared key confirmation.
This option is available when selecting SSO only for features to install.
Config file Optionally, select a pre-configured FortiClient backup configuration file.
If you selected Everything or VPN only for features to install, you must use
a configuration file to configure the related settings.
Software Update Select to enable or disable software updates.
117 Administration Guide
Fortinet Technologies Inc.
Custom installation packages Custom FortiClient Installations
Rebrand Select to rebrand FortiClient. When selected, the option to enable software
update is not available. For more information on rebranding FortiClient,
see Appendix C - Rebranding FortiClient on page 133.
Rebranding resources Select the FortiClient resources file on your management computer.
3. Select the Start button to create the custom FortiClient installation file.
4. You can now deploy the repackaged FortiClient .dmg file to your Mac OS X systems.
Custom installation packages
When deploying a custom FortiClient XML configuration, use the advanced FortiClient
Profile options in FortiGate to ensure the FortiClient Profile settings do not overwrite
your custom XML settings. For more information, see the FortiClient XML Reference
and the CLI Reference for FortiOS.
FortiClient (Windows)
After the configurator tool generates the custom installation packages, it can be used to deploy the FortiClient
software either manually, or using Active Directory. Both options can be found in the .../FortiClient_packaged
directory. Files are created for both x86 (32-bit) and x64 (64-bit) operating systems.
If Active Directory is being used to deploy FortiClient, you can use the custom installer with the MST file found in
the .../ActiveDirectory folder.
For manual distribution, use the .exe file in the .../ManualDistribution folder.
Administration Guide
Fortinet Technologies Inc.
118
Custom FortiClient Installations Advanced FortiClient profiles
Advanced FortiClient profiles
When creating custom FortiClient MSI files for deployment, you will need to configure advanced FortiClient
profiles on the FortiGate/EMS to ensure that settings in the FortiClient profile do not overwrite your custom XML
settings. You can configure the FortiClient profile to deliver the full XML configuration, VPN only, or specific
FortiClient XML configurations. For more information on customizing the FortiClient XML configuration file, see
the Appendix C - Rebranding FortiClient on page 133.
Fortinet recommends creating OS specific endpoint profiles when provisioning XML
settings. When creating a new FortiClient profile, select the device group as either
Windows PC or Mac. If a FortiClient (Windows) XML configuration is pushed to a
FortiClient (Mac OS X) system, FortiClient (Mac OS X) will ignore settings which are
not supported.
Provision a full XML configuration file
You can deploy the full XML configuration file from the CLI or GUI.
To deploy the full XML configuration via the CLI:
1. Log in to the FortiGate Command-line Interface.
2. Enter the following CLI commands:
config endpoint-control profile
edit <profile_name>
config forticlient-winmac-settings
set forticlient-advanced-cfg enable
set forticlient-advanced-cfg-buffer “Copy & Paste your FortiClient XML
configuration here”
end
end
After forticlient-advanced-cfg is enabled, the forticlient-advanced-
cfg-buffer CLI command is available from the CLI.
The buffer size for the FortiClient Control XML configuration is 32kB.
Copy directly from your XML editor, preserving the XML file format. Copy all
information from the <?xml version="1.0" encoding="UTF-8" ?> start of
syntax to the </forticlient_configuration> end of syntax XML tags. Add
double quotes at the start and end of the XML syntax statements.
To deploy the full XML configuration via the FortiGate GUI:
1. Go to Security Profiles > FortiClient Profiles.
2. Select the FortiClient Profile and select Edit from the toolbar. The Edit FortiClient Profile page is displayed.
119 Administration Guide
Fortinet Technologies Inc.
Advanced FortiClient profiles Custom FortiClient Installations
3. Configure the following settings:
Profile Name Enter a unique name to identify the FortiClient profile.
Comments Optionally, enter a comment.
Assign Profile To For more information on configuring device groups, user groups, and users,
see the FortiOS Handbook.
These options are only available when creating a new FortiClient profile.
You can assign the profile to user groups and users when using Active
Directory authentication or RADIUS authentication for VPN.
FortiClient does not support nested groups in FortiOS.
XML text window Copy and paste the FortiClient XML configuration file in the text window.
The XML syntax must be preserved.
4. Select Apply to save the FortiClient profile settings.
To deploy the full XML configuration via EMS:
1. Go to Endpoint Profiles and either select a profile to edit, or create a new profile.
2. Select the Advanced option to the right of the profile name.
3. Select Yes in the confirmation dialog box.
4. Copy and paste the XML configuration file text into the text box.
5. Select Save to save the FortiClient profile settings.
Partial configuration
The current buffer size is 32kB. This may not be large enough to accommodate your FortiClient XML
configuration. As a workaround, you can use the FortiClient Configurator tool to create a custom MSI installation
file using a .confFortiClient backup configuration that contains static custom configurations. You can then
include a partial configuration in the advanced FortiClient profile. This will push the partial configuration when the
client registers with the FortiGate. The partial configuration will be merged with the existing XML configuration on
the client.
To provision specific FortiClient XML configuration while preserving custom XML configurations in your MSI file,
cut & paste the specific XML configuration into the FortiClient Profile in the following format:
<?xml version="1.0" encoding="UTF-8" ?>
<forticlient_configuration>
<partial_configuration>1</partial_configuration>
<system>
<ui>
<ads>0</ads>
<default_tab>VPN</default_tab>
<flashing_system_tray_icon>0</flashing_system_tray_icon>
<hide_system_tray_icon>0</hide_system_tray_icon>
<suppress_admin_prompt>0</suppress_admin_prompt>
<culture_code>os-default</culture_code>
</ui>
<update>
<use_custom_server>0</use_custom_server>
<port>80</port>
<timeout>60</timeout>
Administration Guide
Fortinet Technologies Inc.
120
Custom FortiClient Installations Advanced FortiClient profiles
<failoverport>8000</failoverport>
<fail_over_to_fdn>1</fail_over_to_fdn>
<scheduled_update>
<enabled>0</enabled>
<type>interval</type>
<daily_at>03:00</daily_at>
<update_interval_in_hours>3</update_interval_in_hours>
</scheduled_update>
</update>
</system>
</forticlient_configuration>
Ensure that the <partial_configuration>1</partial_configuration> tag is set to 1 to indicate
that this partial configuration will be deployed upon registration with the FortiGate. All other XML configuration
will be preserved.
Advanced VPN provisioning
You need to enable VPN provisioning and advanced VPN from the FortiOS CLI to import the FortiClient XML VPN
configuration syntax. You can import the XML VPN configuration in the CLI or the GUI.
Import XML VPN configuration into the FortiClient Profile via the CLI:
1. Log in to your FortiGate command-line interface.
2. Enter the following CLI commands:
config endpoint-control profile
edit <profile_name>
config forticlient-winmac-settings
set forticlient-vpn-provisioning enable
set forticlient-advanced-vpn enable
set auto-vpn-when-off-net enable
set auto-vpn-name <VPN name to connect to automatically when off-net>
set forticlient-advanced-vpn-buffer <Copy & paste the advanced VPN
configuration>
end
end
After the forticlient-vpn-provisioning and forticlient-advanced-
vpn CLI commands are enabled, the forticlient-advanced-vpn-buffer
CLI command is available from the CLI.
Copy directly from your XML editor, preserving the XML file format. Copy all
information from the <vpn> start of syntax to the </vpn> end of syntax XML tags.
Add double quotes before the <vpn> tag and after the </vpn> tag.
3. You can also choose to copy & paste the XML content in the GUI, go to Security Profiles > FortiClient Profiles
and select the VPN tab.
4. Configure the following settings:
Profile Name Enter a unique name to identify the FortiClient profile.
121 Administration Guide
Fortinet Technologies Inc.
Advanced FortiClient profiles Custom FortiClient Installations
Comments Optionally, enter a comment.
Assign Profile To For more information on configuring device groups, user groups, and users,
see the FortiOS Handbook.
These options are only available when creating a new endpoint profile.
You can assign the profile to user groups and users when using Active
Directory authentication or RADIUS authentication for VPN.
FortiClient does not support nested groups in FortiOS.
VPN Enable Client VPN Provisioning.
Cut and paste the FortiClient XML configuration <vpn> to </vpn> tags in
the text window. The XML syntax must be preserved.
Enable Auto-connect when Off-Net and select a VPN name from the drop-
down list.
5. Select Apply to save the FortiClient profile settings.
For more information, see Appendix A - Deployment Scenarios on page 123.
Administration Guide
Fortinet Technologies Inc.
122
Appendix A - Deployment Scenarios
Basic FortiClient Profile
In this scenario, you want to configure all FortiClient Profile settings in the FortiGate GUI. When clients register,
they will receive the settings configured in the FortiClient Profile. You can configure the default profile, or create a
new profile. When creating a new profile, you have additional options to specify device groups, user groups, and
users.
Create a basic FortiClient Profile:
1. In the FortiGate GUI, go to SecurityProfiles > FortiClient Profiles. You can either select the default FortiClient
Profile or select Create New in the toolbar. The default FortiClient Profile does not include the Assign Profile To
setting. The Edit Endpoint Profile page opens.
2. Set the profile settings as required and select OK to save the changes.
Advanced FortiClient Profile (Full XML Configuration)
In this scenario, you have created a custom XML configuration file. The custom file includes all settings required
by the client at the time of deployment. When the client registers to the FortiGate, you want to ensure that the
client receives the full XML configuration. For future configuration changes you can use the Advanced FortiClient
Profile (Partial XML Configuration) on page 124 procedure.
The buffer size in the FortiClient Profile is 32kB. Depending on the size of the FortiCli-
ent XML configuration file you may not be able to deploy the full XML configuration file
in the FortiClient Profile. Alternatively, you can create a custom installation file with
the repackager tool and push a partial XML configuration. For more information, see
Advanced FortiClient Profile (Partial XML Configuration) on page 124.
To reduce the size of the FortiClient XML configuration file, you can delete all help text
found within the <!-- .... --> comment tags.
Create an advanced FortiClient Profile with the full XML configuration provisioned:
1. In the FortiGate Command-line Interface enter the following commands:
config endpoint-control profile
edit <profile_name>
config forticlient-winmac-settings
set forticlient-advanced-cfg enable
end
end
2. In the FortiGate GUI, go to SecurityProfiles > FortiClient Profiles. Select the advanced FortiClient profile and
select Edit in the toolbar. The Edit FortiClient Profile page opens.
123 Administration Guide
Fortinet Technologies Inc.
Advanced FortiClient Profile (Partial XML Configuration) Appendix A - Deployment Scenarios
3. Open the FortiClient XML configuration file in a source code editor. Copy and paste the FortiClient XML
configuration file into the XML text field in the FortiClient Profile.
Alternatively, you can copy and paste the XML configuration into the CLI using the
set forticlient-advanced-cfg-buffer command.
4. Select OK to save the changes.
In the future, if you need to update the FortiClient configuration follow the procedure in Advanced FortiClient
Profile (Partial XML Configuration) on page 124.
Advanced FortiClient Profile (Partial XML Configuration)
In this scenario, you have created a custom XML configuration file and you have created a custom FortiClient
installation file using the repackaging tool. The custom XML configuration file includes most settings required by
the client at the time of deployment. Due to the 32kB buffer size limitation, you are not able to follow Advanced
FortiClient Profile (Full XML Configuration) on page 123 procedure.
When the client registers to the FortiGate, you want to ensure that the client receives the partial XML
configuration. The partial configuration will be merged with the existing XML configuration.
Create an advanced FortiClient Profile with the partial XML configuration provisioned:
1. In the FortiGate Command-line Interface enter the following commands:
config endpoint-control profile
edit <profile_name>
config forticlient-winmac-settings
set forticlient-advanced-cfg enable
end
end
2. In the FortiGate GUI, go to SecurityProfiles > FortiClient Profiles. Select the advanced FortiClient profile and
select Edit in the toolbar. The Edit FortiClient Profile page opens.
3. Open the FortiClient XML configuration file in a source code editor. Copy and paste the following lines directly
from the source code editor into the XML text field in the FortiClient profile:
<?xml version="1.0" encoding="UTF-8" ?>
<forticlient_configuration>
<partial_configuration>1</partial_configuration>
.......
</forticlient_configuration>
By setting the <partial_configuration> statement to 1, the XML configuration will be merged into
the existing XML configuration.
Alternatively, you can copy and paste the XML configuration into the CLI using the
set forticlient-advanced-cfg-buffer command.
4. Select OK to save the changes.
In the future if you need to update the FortiClient configuration follow the procedure in Advanced FortiClient
Profile (Full XML Configuration) on page 123.
Administration Guide
Fortinet Technologies Inc.
124
Appendix A - Deployment Scenarios Advanced VPN Provisioning FortiClient Profile
Advanced VPN Provisioning FortiClient Profile
In this scenario, you want to provision multiple XML VPN configurations while setting the other FortiClient Profile
settings in the FortiGate GUI. As the current buffer size in the CLI is 32kB, your FortiClient XML configuration
may be too large to deploy using the regular advanced FortiClient Profile. You can use the repackaging tool to
configure settings which are not available in the FortiClient Profile page by including the FortiClient XML
configuration file in the installation
Create an advanced FortiClient Profile with XML VPN configurations:
1. In the FortiGate Command-line Interface enter the following commands:
config endpoint-control profile
edit <profile_name>
config forticlient-winmac-settings
set forticlient-vpn-provisioning enable
set forticlient-advanced-vpn enable
set auto-vpn-when-off-net enable
set auto-vpn-name <VPN name to connect to automatically when off-net>
end
end
2. In the FortiGate GUI, go to SecurityProfiles > FortiClient Profiles. Select the advanced FortiClient profile and
select Edit in the toolbar. The Edit FortiClient Profile page opens.
3. Open the FortiClient XML configuration file in a source code editor. Copy and paste all information from the
<vpn> comment tag to the </vpn> comment tag directly from the source code editor into the XML text field in
the endpoint profile.
Alternatively, you can copy and paste the XML configuration into the CLI using the
set forticlient-advanced-vpn-buffer command.
4. Select OK to save the changes.
Advanced FortiClient Profile (No Settings Provisioned)
In this scenario, you have created a custom installation file using the repackager tool. The custom file includes all
settings required by the client at the time of deployment. When the client registers to the FortiGate, you want to
ensure that no settings are pushed to the client and the XML configuration remains intact.
When changes are required you can push a partial configuration to the clients with the specific XML configuration
changes.
Create an advanced FortiClient Profile with no settings provisioned:
1. In the FortiGate Command-line Interface enter the following commands:
config endpoint-control profile
edit <profile_name>
config forticlient-winmac-settings
set forticlient-advanced-cfg enable
end
end
125 Administration Guide
Fortinet Technologies Inc.
Using Active Directory Groups Appendix A - Deployment Scenarios
2. In the FortiGate GUI, go to SecurityProfiles > FortiClient Profiles. Select the advanced FortiClient profile and
select Edit in the toolbar. The Edit FortiClient Profile page opens.
3. Open the FortiClient XML configuration file in a source code editor. Copy and paste the following lines directly
from the source code editor into the XML text field in the FortiClient profile:
<?xml version="1.0" encoding="UTF-8" ?>
<forticlient_configuration>
<partial_configuration>1</partial_configuration>
</forticlient_configuration>
By setting the <partial_configuration> statement to 1, the XML configuration will be merged into
the existing XML configuration. Since no other XML statements are included, no changes will be made to the
XML configuration on the client.
Alternatively, you can copy and paste the XML configuration into the CLI using the
set forticlient-advanced-cfg-buffer command.
4. Select OK to save the changes.
In the future if you need to update the FortiClient configuration follow the procedure in Advanced FortiClient
Profile (Partial XML Configuration) on page 124.
Using Active Directory Groups
Some organizations may choose to deploy different FortiClient profiles to different user groups. FortiGate and
EMS are able to send different FortiClient profiles based on the AD group of the user. This requires use of the
FortiAuthenticator.
No special configuration is required on FortiClient.
Monitoring registered users
Administrators can monitor managed FortiClient users. When the client successfully registers to the
FortiGate/EMS, the client can be monitored on the FortiGate/EMS.
In the FortiGate GUI, all registered clients can be observed on the Monitor > FortiClient Monitor page.
Either of the following FortiGate CLI commands will list all registered clients:
ldiagnose endpoint registration list, or
ldiagnose endpoint record-list.
Administration Guide
Fortinet Technologies Inc.
126
Appendix A - Deployment Scenarios Customizing FortiClient using XML settings
In the EMS, registered clients can be observed on the Workgroups page.
Customizing FortiClient using XML settings
FortiClient configurations can be customized at the XML level. For more information, see the FortiClient XML
Reference.
Silent registration
You may want to configure FortiClient to silently register to FortiGate without any user interaction. When
configured, the user will not be prompted to register to a FortiGate. The <silent_registration> tag is intended to
be used with the <disable_unregister> tab. For more information, see Disable unregistration on page 128. The
following XML elements can be used to enable this:
<forticlient_configuration>
<endpoint_control>
<silent_registration>1</silent_registration>
</endpoint_control>
</forticlient_configuration>
Locked FortiClient settings
End-users with administrator permission on their Windows system have access to the FortiClientsettings page. If
this is not desired, it can be locked with a password from the FortiGate. The following FortiOS CLI command,
when included, requires that any client registered to the FortiGate to provide the password before they can
access the settings page.
config endpoint-control profile
edit "fmgr"
config forticlient-winmac-settings
...
set forticlient-settings-lock disable
set forticlient-settings-lock-passwd <password>
...
end
...
next
end
127 Administration Guide
Fortinet Technologies Inc.
Off-net VPN auto-connect Appendix A - Deployment Scenarios
Disable unregistration
With silent endpoint control registration enabled, a user could unregister after FortiClient has registered to the
FortiGate. The capability to unregister can be disabled using the following XML element:
<forticlient_configuration>
<endpoint_control>
<disable_unregister>1</disable_unregister>
</endpoint_control>
</forticlient_configuration>
Putting it together
Here is a sample complete FortiClient5.4.0XML configuration file with the capabilities discussed above:
<forticlient_configuration>
<partial_configuration>1</partial_configuration>
<endpoint_control>
<enabled>1</enabled>
<disable_unregister>1</disable_unregister>
<silent_registration>1</silent_registration>
<fortigates>
<fortigate>
<serial_number />
<name />
<registration_password>un9r3Ak@b!e</registration_password>
<addresses>newyork.example.com</addresses>
</fortigate>
</fortigates>
</endpoint_control>
</forticlient_configuration>
The FortiGate that is registered to is listed in the <fortigates> element. The <registration_
password> element is required if the endpoint control configuration on the FortiOS requires one. This can be
exported as an encrypted file from a registered FortiClient.
The configuration provided above is not the full FortiClient configuration file. Thus, the <partial_
configuration> element is set to 1.
Off-net VPN auto-connect
Configure off-net VPN auto-connect and disable the VPN disconnect button
1. Configure the corresponding FortiClient profile from the FortiGate CLI. Enter the following CLI commands:
config endpoint-control profile
edit <profile_name>
config forticlient-winmac-settings
set forticlient-vpn-provisioning enable
set forticlient-advanced-vpn enable
end
2. Log into FortiGate GUI.
3. Go to Security Profiles > FortiClient Profiles and select the profile you edited in the previous step.
Administration Guide
Fortinet Technologies Inc.
128
Appendix A - Deployment Scenarios Off-net VPN auto-connect
4. Copy and paste the VPN configuration in XML format into the VPN field. This includes the VPN connection and the
settings for off-net VPN auto connect.
<vpn>
<options>
<autoconnect_tunnel>ssl209.77</autoconnect_tunnel>
<autoconnect_only_when_offnet>1</autoconnect_only_when_offnet>
<keep_running_max_tries>0</keep_running_max_tries>
<allow_personal_vpns>0</allow_personal_vpns>
<disable_connect_disconnect>1</disable_connect_disconnect>
</options>
<sslvpn>
<options>
<enabled>1</enabled>
</options>
<connections>
<connection>
<name>ssl209.77</name>
<server>209.207.125.77:443</server>
<username />
<single_user_mode>0</single_user_mode>
<ui>
<show_remember_password>1</show_remember_password>
<show_alwaysup>1</show_alwaysup>
<show_autoconnect>1</show_autoconnect>
</ui>
<password />
<certificate />
<prompt_certificate>0</prompt_certificate>
<prompt_username>1</prompt_username>
<fgt>1</fgt>
<on_connect>
<script>
<os>windows</os>
<script>
<![CDATA[]]>
</script>
</script>
</on_connect>
<on_disconnect>
<script>
<os>windows</os>
<script>
<![CDATA[]]>
</script>
</script>
</on_disconnect>
</connection>
</connections>
</sslvpn>
</vpn>
5. FortiClient will receive the profile from the FortiGate upon registration. The user will be prompted to enter their
username and password and connect to the VPN.
6. When FortiClient is detected as Off-Net, the VPN connection window will be displayed. The user will enter their
username and password and connect to the VPN.
7. After the VPN is connected, the disconnect button will be disabled.
129 Administration Guide
Fortinet Technologies Inc.
Off-net VPN auto-connect Appendix A - Deployment Scenarios
8. FortiClient will then always attempt to connect to the VPN.
Administration Guide
Fortinet Technologies Inc.
130
Appendix B - Using the FortiClient API
You can operate FortiClient VPNs using the COM-based FortiClient API. The API can be used with IPsec VPN
only. SSL VPN is currently not supported.
This chapter contains the following sections:
lOverview
lAPI reference
Overview
The FortiClient COM library provides functionality to:
lRetrieve a list of the VPN tunnels configured in the FortiClient application.
lStart and stop any of the configured VPN tunnels.
lSend XAuth credentials.
lRetrieve status information:
lconfigured tunnel list
lactive tunnel name
lconnected or not
lidle or not
lremaining key life
lRespond to FortiClient-related events:
lVPN connect
lVPN disconnect
lVPN is idle
lXAuth authentication requested
For more information, see the vpn_com_examples ZIP file located in the VPN Automation file folder in the
FortiClientTools file.
API reference
The following tables provide API reference values.
Disconnect(bstrTunnelName As
String)
Close the named VPN tunnel.
GetPolicy pbAV As Boolean, pbAS As
Boolean, pbFW As Boolean, pbWF
As Boolean)
Command is deprecated in FortiClient v5.0.
131 Administration Guide
Fortinet Technologies Inc.
API reference Appendix B - Using the FortiClient API
GetRemainingKeyLife(bstrTunnelName
As String, pSecs As Long,
pKBytes As Long)
Retrieve the remaining key life for the named con-
nection. Whether keylife time (pSecs) or data
(pKBytes) are significant depends on the detailed set-
tings in the FortiClient application.
MakeSystemPolicyCompliant() Command is deprecated in FortiClient v5.0.
SendXAuthResponse (tunnelName As
String, userName As String,
password As String,
savePassword As Boolean)
Send XAuth credentials for the named connection:
lUser name, Password
lTrue if password should be saved.
SetPolicy (bAV As Boolean, bAS As
Boolean, bFW As Boolean, bWF
As Boolean)
Command is deprecated in FortiClient v5.0.
GetTunnelList() Retrieve the list of all connections configured in the
FortiClient application.
IsConnected (bstrTunnelName As
String) As Boolean
Return True if the named connection is up.
IsIdle (bstrTunnelName As String)
As Boolean
Return True if the named connection is idle.
OnDisconnect(bstrTunnelName As
String)
Connection disconnected.
OnIdle(bstrTunnelName As String) Connection idle.
OnOutOfCompliance(bAV As Boolean,
bAS As Boolean, bFW As
Boolean, bWF As Boolean)
Command is deprecated in FortiClient v5.0.
OnXAuthRequest(bstrTunnelName As
String)
The VPN peer on the named connection requests
XAuth authentication.
Administration Guide
Fortinet Technologies Inc.
132
Appendix C - Rebranding FortiClient
The FortiClient Configurator can be used to create custom FortiClient MSI installers with various combinations.
The customized MSI installer generated may be used to install FortiClient on all supported platforms using Active
Directory or SCCM. A FortiClient setup executable file is also generated for manual distribution.
The FortiClient license for FortiOS 5.2 includes the license file required to use the
FortiClient Configurator tool used to create custom FortiClient installers. The Con-
figurator tool also allows you to rebrand the installer file.
Under Options, you can select to enable software updates, configure the single sign-on mobility agent, and
rebrand FortiClient. Rebranding allows you to edit various UI elements including graphics.
When replacing files in the resource folder, the replacement file should be the same
file type and dimensions. Icons (.ico) are a special case. The Main_icon.ico file
for example, is a composite file of multiple icons. The operating system picks the
appropriate icon size from this file for the context in which the icon is being displayed.
Rebranding elements:
Installer Product Name Where Used: Setup Wizard header and body, File directory name in
Installer Company Name file folder, engine/signature update bubble mes-
sages.
Default Value: FortiClient
Installer Company Name Where Used: File directory name in Program Files.
Default Value: Fortinet
133 Administration Guide
Fortinet Technologies Inc.
Appendix C - Rebranding FortiClient
Manufacturer Name Where Used: Default Value: Fortinet Inc
Shortcut Text Where Used: Name of shortcut on desktop
Default Value: FortiClient
Product Name Where Used: Name of installer file (.msi/.mst), UI header, configuration
received from FortiGate bubble messages,
Default Value: FortiClient
Product Name Text Where Used: Name of client in main page
Default Value: FortiClient
Company Where Used: Help > About > Copyright page
Default Value: Fortinet
Company WebSite URL Where Used: Help > About > Copyright page
Default Value: http://www.fortinet.com
Company Website Text Where Used: Help > About > Copyright page
Default Value: www.fortinet.com
Feedback Email Where Used: Help > About > Copyright page, Send Feedback
Default Value: forticlient-feedback@fortinet.com
Feedback Email Text Where Used: Help > About > Copyright page, Send Feedback
Default Value: forticlient-feedback@fortinet.com
EULA Where Used: Help > About > Copyright page, Click here to view the
license agreement
Default Value: http://www.fortinet.com/doc/legal/EULA.pdf
Knowledge Base Text Where Used: Help menu option
Default Value: Fortinet Knowledge Base
Leave this field blank to omit the field in the console.
Knowledge Base Link Where used: Link used by Knowledge Base text
Default value: http://kb.fortinet.com
Leave this field blank to omit the field in the console.
Advertisement 1 Where used: Link used by dashboard banner advertisement 1
Default value: http://www.forticlient.com/video/001
Advertisement 2 Where used: Link used by dashboard banner advertisement 2
Default value: http://www.forticlient.com/video/002
Advertisement 3 Where used: Link used by dashboard banner advertisement 3
Default value: http://www.forticlient.com/video/003
Resources folder elements:
Administration Guide
Fortinet Technologies Inc.
134
Appendix C - Rebranding FortiClient
About_red_shield_logo.png Where Used:
File Type: PNG File (.png)
Width: 43 pixels
Height: 43 pixels
Bit Depth: 32
Advertisement_ad_0.png Where Used: Dashboard advertisement banner
File Type: PNG File (.png)
Width: 628 pixels
Height: 66 pixels
Bit Depth: 32
Advertisement_ad_1.png Where Used: Dashboard advertisement banner
File Type: PNG File (.png)
Width: 628 pixels
Height: 66 pixels
BitBit Depth: 32
Advertisement_ad_2.png Where Used: Dashboard advertisement banner
File Type: PNG File (.png)
Width: 628 pixels
Height: 66 pixels
Bit Depth: 32
Antivirus_AV_scan_top_banner_left_hand_
Where Used:
File Type: BMP File (.bmp)
Width: 1 pixel
Height: 40 pixels
Bit Depth: 8
Antivirus_AV_scan_top_banner_right_hand_
Where Used: Banner used in right-click “scan with
product name” dialog box
File Type: BMP File (.bmp)
Width: 440 pixels
Height: 40 pixels
Bit Depth: 8
Common_fgt-not-found-page-bg.png Where Used: FortiGate not found page
File Type: PNG File (.png)
Width: 673 pixels
Height: 189 pixels
Bit Depth: 32
Common_fortinet-icon.png Where Used:
File Type: PNG File (.png)
Width: 79 pixels
Height: 79 pixels
Bit Depth: 32
135 Administration Guide
Fortinet Technologies Inc.
Appendix C - Rebranding FortiClient
Common_registration_icon.png Where Used: FortiGate detected page
File Type: PNG File (.png)
Width: 85 pixels
Height: 85 pixels
Bit Depth: 32
Common_searching-page-bg.png Where Used: Searching for FortiGate page
File Type: PNG File (.png)
Width: 673 pixels
Height: 189 pixels
Bit Depth: 32
Dashboard_forticlient_v5_dashboard_bg.png Where Used: Client console
File Type: PNG File (.png)
Width: 628 pixels
Height: 451 pixels
Bit Depth: 32
Dashboard_warning-shield.png Where Used: Dashboard warning shield, displayed
when antivirus is disabled.
File Type: PNG File (.png)
Width: 59 pixels
Height: 75 pixels
Bit Depth: 32
Installer_background.bmp Where used: Setup Wizard background image.
File Type: BMP file (.bmp)
Width: 491 pixels
Height: 312 pixels
Bit Depth: 8
Installer_banner.bmp Where Used: Setup Wizard banner image on des-
tination page, ready to install page, installing pages.
File Type: BMP file (.bmp)
Width: 491 pixels
Height: 58 pixels
Bit Depth: 8
LightInstaller_icon.ico Where Used: Light Installer Icon
File Type: ICO File (.ico)
Width: 32 pixels
Height: 32 pixels
Bit Depth: 32
Main_icon.ico Where Used: Shortcut on desktop
File Type: ICO file (.ico)
Width: 48 pixels
Height: 48 pixels
Bit Depth: 32
Administration Guide
Fortinet Technologies Inc.
136
Appendix C - Rebranding FortiClient
Main_logo_black.ico Where Used: Client console header
File Type: ICO file (.ico)
Width: 32 pixels
Height: 32 pixels
Bit Depth: 32
setup.ico Where Used: Setup icon
File Type: ICO File (.ico)
Width: 256 pixels
Height: 256 pixels
Bit Depth: 32
Tray_Icons_alert.ico Where Used: System tray alert icon
File Type: ICO File (.ico)
Width: 16 pixels
Height: 16 pixels
Bit Depth: 32
Tray_Icons_alert_vpn.ico Where Used: System tray VPN alert icon
File Type: ICO File (.ico)
Width: 16 pixels
Height: 16 pixels
Bit Depth: 32
Tray_Icons_running.ico Where Used: System tray running icon
File Type: ICO File (.ico)
Width: 16 pixels
Height: 16 pixels
Bit Depth: 32
Tray_Icons_scan1.ico, Tray_Icons_scan2.ico,
Tray_Icons_scan3.ico, Tray_Icons_scan4.ico,
Tray_Icons_scan5.ico, Tray_Icons_scan6.ico,
Tray_Icons_scan7.ico, Tray_Icons_scan8.ico,
Tray_Icons_scan9.ico, Tray_Icons_scan10.ico
Tray_Icons_scan11.ico
Where Used: System tray, these eleven images
animate the scanning activity of the tray icon.
File Type: ICO File (.ico)
Width: 16 pixels
Height: 16 pixels
Bit Depth: 32
Tray_Icons_vpn.ico Where Used: System tray VPN icon
File Type: ICO File (.ico)
Width: 16 pixels
Height: 16 pixels
Bit Depth: 32
VPN_xauth-dialog-logo.png Where Used: VPN xAuth dialog logo
File Type: PNG File (.png)
Width: 88 pixels
Height: 100 pixels
Bit Depth: 32
zzz_rebranding.ini Where Used: This file is used by the FortiClient Con-
figurator tool for element/resource mapping.
File Type: Configuration settings (.ini)
137 Administration Guide
Fortinet Technologies Inc.
Appendix C - Rebranding FortiClient
When rebranding FortiClient, you can select to digitally sign the installer package using a code signing certificate.
Administration Guide
Fortinet Technologies Inc.
138
Appendix D - FortiClient Log Messages
Client
Feature
ID Level Format Description
Antivirus 0x00017912 Warning Found virus by [Antivirus
scan|Antivirus realtime pro-
tection] in [filesys-
tem|disk|email]
This message is logged when a
virus is found.
Antivirus 0x00017913 Warning Found malware by [Antivirus
scan|Antivirus realtime pro-
tection] in [filesystem|email]
This message is logged when a
malware is found.
Antivirus 0x00017914 Warning Found suspicious by [Antivirus
scan|Antivirus realtime pro-
tection] in [filesys-
tem|disk|email]
This message is logged when a
suspicious is found.
Antivirus 0x00017915 Info User enabled Realtime
Antivirus protection
Logged when someone
enables Realtime Antivirus.
Antivirus 0x00017916 Warning User disabled Realtime
Antivirus protection
Logged when someone dis-
ables Realtime Antivirus.
Antivirus 0x00017917 Info Communication error, [detailed
info], err=[error_code]
Communication error with other
modules
Antivirus 0x00017918 Warning Antivirus realtime protection
killed malware process : [pro-
cess name]
A malware process killed a mal-
ware process.
Antivirus 0x0001791d Info av_task scan is started This message is logged if AV
scanning is started.
Antivirus 0x0001791e Info av_task scan is stopped This message is logged if AV
scanning is stopped.
Antivirus 0x00017919 Info av_task scan thread is sus-
pended
This message is logged if AV
scanning is paused.
Antivirus 0x0001791a Info av_task scan thread is resumed This message when AV scan-
ning is resumed.
Antivirus 0x0001791b Warning av_task killed suspicious pro-
cess : <filename or process
name>
<filename or process name> is
a suspicous process and has
been terminated.
139 Administration Guide
Fortinet Technologies Inc.
Appendix D - FortiClient Log Messages
Client
Feature
ID Level Format Description
Antivirus 0x0001791c Info Cannot start scan task, license
expired
License expired.
Antivirus 0x0001791f Error Scheduled scan failed: Path to
file/folder no longer exists.
Path not found.
Webfilter 0x000178f4 Info User enabled Webfilter Logged when someone
enables webfiltering.
Webfilter 0x000178f5 Warning User disabled Webfilter Logged when someone dis-
ables webfiltering.
Webfilter 0x000178f6 Warning user's access to the url [action
and reason]
the action to the user's access,
and the reason
Webfilter 0x000178f7 Info user's access to the url [action
and reason]
the action to the user's access,
and the reason
Webfilter 0x000178f8 Warning The Webfilter Violation report
was cleared [user name]
Logged when someone clears
the webfilter violation report.
Webfilter 0x000178f9 Warning Unable to create proxy/web-
filter communication socket.
FortiClient will not be able to
determine the FortiGuard rat-
ing of URLs.
Webfilter 0x000178fa Warning Unable to retrieve the webfilter
UDP port number.
FortiClient will not be able to
determine the FortiGuard rat-
ing of URLs.
Webfilter 0x000178fb Warning status=warn [logged on user]
temporarily disabled blocking of
category [category id] ([cat-
egory name]) to access [url]
The user [logged on user] pro-
ceeded to the url [url] after
acknowwledging a warning mes-
sage.
Application
FireWall
0x00017980 Warning Firewall action, type=[num] pro-
tocol=[num] direction=[num]
source=[addr] destination=
[addr]
Firewall action
Application
FireWall
0x00017981 Info Firewall action, type=[num] pro-
tocol=[num] direction=[num]
source=[addr] destination=
[addr]
Firewall action
Application
FireWall
0x00017982 Info User enabled Firewall User enabled Firewall
Administration Guide
Fortinet Technologies Inc.
140
Appendix D - FortiClient Log Messages
Client
Feature
ID Level Format Description
Application
FireWall
0x00017983 Warning User disabled Firewall User disabled Firewall
Application
FireWall
0x00017984 Warning The Application Firewall report
was cleared
Logged when someone clears
the application firewall report.
IKE VPN 0x00017930 Info VPN tunnel status VPN tunnel status
IKE VPN 0x00017931 Warning locip=<ip address> loc-
port=<port number> remip=<ip
address> remport=<port num-
ber> outif=<interface> vpn-
tunnel=<tunnel name>
status=negotiate_error msg-
g=No response from the peer,
phase1 retransmit reaches max-
imum count.
No response from the peer,
phase1 retransmit reaches max-
imum count.
IKE VPN 0x00017932 Warning locip=<ip address> loc-
port=<port number> remip=<ip
address> remport=<port num-
ber> outif=<interface> vpn-
tunnel=<tunnel name>
status=negotiate_error msg-
g=No response from the peer,
phase2 retransmit reaches max-
imum count.
No response from the peer,
phase2 retransmit reaches max-
imum count.
IKE VPN 0x00017933 Warning locip=<ip address> loc-
port=<port number> remip=<ip
address> remport=<port num-
ber> outif=<interface> vpn-
tunnel=<tunnel name>
status=negotiate_error msg-
g=Received delete payload
from peer check xauth pass-
word.
Received delete payload from
peer check xauth password.
IKE VPN 0x00017934 Error locip=<ip address> loc-
port=<port number> remip=<ip
address> remport=<port num-
ber> outif=<interface> vpn-
tunnel=<tunnel name>
msg=Failed to acquire an IP
address.
Failed to acquire an IP address
for the virtual adapter.
IKE VPN 0x00017935 Error ike error, <detailed error info> General error of IKE
141 Administration Guide
Fortinet Technologies Inc.
Appendix D - FortiClient Log Messages
Client
Feature
ID Level Format Description
IKE VPN 0x00017936 Info negotionation information,
<detailed info>
negotionation information
IKE VPN 0x00017937 Error negotionation error, <detailed
error>
negotionation error
IKE VPN 0x00017938 Error replayed packet detected
(packet dropped), <detailed
error>
replayed packet detected
(packet dropped).
IKE VPN 0x00017939 Info VPN user accept the banner
and continue with the tunnel
setup
The VPN user accept the ban-
ner warning
IKE VPN 0x0001793a Info VPN user choose disconnect
the tunnel or no response
The VPN user reject the banner
warning and disconnect the tun-
nel
IKE VPN 0x0001793b Info locip=<ip address> loc-
port=<port number> remip=<ip
address> remport=<port num-
ber> outif=<interface> vpn-
tunnel=<tunnel name>
action=install_sa, inspi-
i=<inbound spi> out-
spi=<outbound spi>
<Initiator|Responder> tunnel
<ip address/ip address> install
sa
Send sa to the IPsec driver.
IKE VPN 0x0001793c Info VPN before logon was enabled Logged when someone
enables VPN before logon.
IKE VPN 0x0001793d Info VPN before logon was disabled Logged when someone dis-
ables VPN before logon.
SSL VPN 0x00017958 Info SSLVPN tunnel status SSLVPN tunnel status
Wan Accle-
ration
0x00017a71 Info User enabled WAN Accel-
eration
User enabled WAN Accel-
eration
Wan Accle-
ration
0x00017a70 Info User disabled WAN Accel-
eration
User disabled WAN Accel-
eration
Administration Guide
Fortinet Technologies Inc.
142
Appendix D - FortiClient Log Messages
Client
Feature
ID Level Format Description
Wan Accle-
ration
0x0000b000 Error Network registry keys are miss-
ing
When enumerating the network
interface subkeys, it was found
that there were no subkeys
present.
Wan Accle-
ration
0x0000b001 Error Network adapter is missing a
description
When enumerating the network
interfaces, one was found
without a descriptions.
Wan Accle-
ration
0x0000b002 Error Error opening redirector device Wan acceleration will not func-
tion.
Wan Accle-
ration
0x0000b003 Info WAN Acceleration was enabled
by [user name]
Logged when someone
enables WAN Acceleration.
Wan Accle-
ration
0x0000b004 Info WAN Acceleration was disabled
by [user name]
Logged when someone dis-
ables WAN Acceleration.
Vulnerability
Scan
0x00017908 Info The vulnerability scan status
has changed
A vulnerability scan status
change
Vulnerability
Scan
0x00017909 Info A vulnerability scan result has
been logged
A Vulnerability scan result log
EndPoint Con-
trol
0x00017ab6 Info upload logs, [state] Upload logs to registered
FortiGate
EndPoint Con-
trol
0x00017ab7 Info Endpoint control policy syn-
chronization was enabled
Logged when someone
enables Endpoint control policy
synchronization.
EndPoint Con-
trol
0x00017ab8 Warning Endpoint control policy syn-
chronization was disabled
Logged when someone dis-
ables Endpoint control policy
synchronization.
EndPoint Con-
trol
0x00017ab9 Info Endpoint Control Status
changed to [status]
Endpoint Control Status
Changed
EndPoint Con-
trol
0x00017aba Warning OffNet configuration version
[version] doesn't match
FortiGate configuration version
[version]
OffNet configuration version
doesn't match FortiGate con-
figuration version
EndPoint Con-
trol
0x00017abb Info Endpoint Control Registration
Status changed to [status] with
FGT [serial], [address] and cli-
ent ip [address]
Endpoint Control Registration
Status Changed
143 Administration Guide
Fortinet Technologies Inc.
Appendix D - FortiClient Log Messages
Client
Feature
ID Level Format Description
Update 0x00017a2a Info Customer initiated a software
update request.
Logged when a user presses
the gui's update button.
Update 0x00017a37 Info Checking for updates. Checking for updates.
Update 0x00017a2c Info Update allowed only if you have
a valid license
Update allowed only if you have
a valid license
Update 0x00017a38 Info Software update started. Software update started.
Update 0x00017a2d Info Software updates are disabled. Software updates from
FortiGuard have been disabled.
Update 0x00017a2e Info Software updates from from
FortiGuard have been disabled
becaue this client is managed.
Software updates from
FortiGuard have been disabled.
Update 0x00017a2f Info Software updates require
administrative privileges.
The user does not have suf-
ficient priviledges to perform
software updates.
Update 0x00017a30 Info Software update successful. Software update successful.
Update 0x00017a31 Info Software update failed. Software update failed.
Update 0x00017a32 Info Unable to perform software
update. Registry does not con-
tain image id to download.
The image id that is expected
to be in the registry is missing.
Update 0x00017a33 Info Update <module description>
successful, new version is <ver-
sion number>
Update was successful to the
given version for the given mod-
ule.
Update 0x00017a34 Error Unable to load AV engine Failed to load the av engine
Update 0x00017a35 Error Error patching AV signature. Error patching AV signature.
Update 0x00017a36 Error Unable to load FASLE engine Unable to load FASLE engine
Update 0x00017a39 Info Update successful, <all
engine/signature versions>
Update was successful, current
engine/signature information
recorded.
Scheduler 0x00017a20 Info Forcefully kill a child process
after grace period expires
A scheduler owned child pro-
cess failed to stop when instruc-
ted to do so, so was forcefully
terminated.
Administration Guide
Fortinet Technologies Inc.
144
Appendix D - FortiClient Log Messages
Client
Feature
ID Level Format Description
Scheduler 0x00017a21 Error The scheduler cannot start the
scheduled task because the
task's license is expired.
The scheduler cannot start the
scheduled task because the
task's license is expired.
Scheduler 0x00017a68 Info FortiClient is starting up FortiClient is starting up
Scheduler 0x00017a69 Info %s is shutting down FortiClient is shutting down
FortiProxy 0x00017a49 Info Fortiproxy is enabled Fortiproxy is enabled
FortiProxy 0x00017a48 Warning Fortiproxy is disabled Fortiproxy is disabled
FortiShield 0x00017a53 Info FortiShield is enabled FortiShield is enabled
FortiShield 0x00017a52 Warning FortiShield is disabled FortiShield is disabled
FortiShield 0x00017a54 Info The console was locked The console password was
locked.
FortiShield 0x00017a55 Warning The console was unlocked The console password was
unlocked.
FortiShield 0x00017a56 Warning The console password was
removed
The console password was
removed.
FortiShield 0x00017a57 Warning FortiShield blocked application:
[application path] from modi-
fying: [file or registry path]
FortiShield has prevented an
application from modifying a
file or registry setting protected
by FortiClient.
Application
Database
0x0000d001 Error <context> <file reference> db
error - creating new database.
A critical error occured. The
application database will not
work. <context> is the service
that generated the log. <file ref-
erence> is optional and
describes the file was being
accessed when the log was gen-
erated.
Application
Database
0x0000d003 Error <context> <file reference> db
error - BIND command.
A critical error occured. The
application database will not
work. <context> is the service
that generated the log. <file ref-
erence> is optional and
describes the file was being
accessed when the log was gen-
erated.
145 Administration Guide
Fortinet Technologies Inc.
Appendix D - FortiClient Log Messages
Client
Feature
ID Level Format Description
Application
Database
0x0000d004 Error <context> <file reference> db
error - opening database.
A critical error occured. The
application database is not
present. An attempt to auto-
matically regenerate it will
occur. <context> is the service
that generated the log. <file ref-
erence> is optional and
describes the file was being
accessed when the log was gen-
erated.
Application
Database
0x0000d005 Error <context> <file reference> db
error - preparing sql statement.
The sql statement used is
invalid. <context> is the service
that generated the log. <file ref-
erence> is optional and
describes the file was being
accessed when the log was gen-
erated.
Application
Database
0x0000d006 Error <context> <file reference> db
error - unable to find fingerprint.
The fingerprint does not exist in
the database. <context> is the
service that generated the log.
<file reference> is optional and
describes the file was being
accessed when the log was gen-
erated.
Application
Database
0x0000d007 Error <context> <file reference> db
error - invalid md5.
The parameter supplied is not
an MD5. <context> is the ser-
vice that generated the log.
<file reference> is optional and
describes the file was being
accessed when the log was gen-
erated.
Application
Database
0x0000d008 Error <context> <file reference> db
error - row not found.
The requested row does not
exist. <context> is the service
that generated the log. <file ref-
erence> is optional and
describes the file was being
accessed when the log was gen-
erated.
Administration Guide
Fortinet Technologies Inc.
146
Appendix D - FortiClient Log Messages
Client
Feature
ID Level Format Description
Application
Database
0x0000d00a Error <context> <file reference>
Can't open file.
The file cannot be opened.
<context> is the service that
generated the log. <file ref-
erence> is optional and
describes the file was being
accessed when the log was gen-
erated.
Application
Database
0x0000d00b Error <context> <file reference>
Unable to extract vendor id.
The files is not digitally signed,
or the signature cannot be
read. <context> is the service
that generated the log. <file ref-
erence> is optional and
describes the file was being
accessed when the log was gen-
erated.
Application
Database
0x0000d00e Error <context> <file reference>
Can't access file because of
sharing violation.
Can't access file because of
sharing violation. <context> is
the service that generated the
log. <file reference> is optional
and describes the file was
being accessed when the log
was generated.
Application
Database
0x0000d00f Error <context> <file reference>
Can't open driver.
Can't open the apd driver. <con-
text> is the service that gen-
erated the log. <file reference>
is optional and describes the
file was being accessed when
the log was generated.
Application
Database
0x0000d010 Error <context> <file reference>
Can't start driver.
Can't start the apd driver. <con-
text> is the service that gen-
erated the log. <file reference>
is optional and describes the
file was being accessed when
the log was generated.
Application
Database
0x0000d011 Error <context> <file reference>
Driver io error.
APD driver io error. <context> is
the service that generated the
log. <file reference> is optional
and describes the file was
being accessed when the log
was generated.
147 Administration Guide
Fortinet Technologies Inc.
Appendix D - FortiClient Log Messages
Client
Feature
ID Level Format Description
Application
Database
0x0000d016 Error <context> <file reference>
Server-side pipe error.
A communication error
occured. It is probably tem-
porary. <context> is the service
that generated the log. <file ref-
erence> is optional and
describes the file was being
accessed when the log was gen-
erated.
Application
Database
0x0000d017 Error <context> <file reference> Pipe
server initialization error.
A communication initializion
error occured. It is probably tem-
porary. <context> is the service
that generated the log. <file ref-
erence> is optional and
describes the file was being
accessed when the log was gen-
erated.
Application
Database
0x0000d018 Error <context> <file reference> Pipe
server creation error.
A communication initializion
error occured. It is probably tem-
porary. <context> is the service
that generated the log. <file ref-
erence> is optional and
describes the file was being
accessed when the log was gen-
erated.
Application
Database
0x0000d019 Error <context> <file reference>
Unable to bypass fortishield.
Failed to bypass self-pro-
tection. The daemon might not
function normally after this.
<context> is the service that
generated the log. <file ref-
erence> is optional and
describes the file was being
accessed when the log was gen-
erated.
Application
Database
0x0000d01a Error <context> <file reference>
Invalid arguments.
Invalid command line options
supplied. <context> is the ser-
vice that generated the log.
<file reference> is optional and
describes the file was being
accessed when the log was gen-
erated.
Administration Guide
Fortinet Technologies Inc.
148
Appendix D - FortiClient Log Messages
Client
Feature
ID Level Format Description
Application
Database
0x0000d01c Error <context> <file reference>
Unable to allocate memory for
vendor id cache.
Low memory. <context> is the
service that generated the log.
<file reference> is optional and
describes the file was being
accessed when the log was gen-
erated.
Application
Database
0x0000d01d Error <context> <file reference>
Vendor id cache not initialized.
This is probably temporary. An
attempt will be made later to
read/write to the cache. <con-
text> is the service that gen-
erated the log. <file reference>
is optional and describes the
file was being accessed when
the log was generated.
Application
Database
0x0000d01e Error <context> <file reference>
Unable to open vendor id cache
shared memory.
Application detection will not be
functioning normally. <context>
is the service that generated
the log. <file reference> is
optional and describes the file
was being accessed when the
log was generated.
Application
Database
0x0000d01f Error <context> <file reference>
Unable to open mutex to
access vendor id shared
memory.
Application detection will not be
functioning normally. <context>
is the service that generated
the log. <file reference> is
optional and describes the file
was being accessed when the
log was generated.
Config
Import/Export
0x00017a5c Info A configuration file is exported
to [location]
Logged when someone exports
a config file.
Config
Import/Export
0x00017a5d Info A configuration file is imported
from [location]
Logged when someone imports
a config file.
Single Sign-
On Mobility
Agent
0x00017ad4 Info Single Sign-On event Single Sign-On event.
Single Sign-
On Mobility
Agent
0x00017ad5 Info Single Sign-On Mobility Agent
was enabled
Logged when someone
enables Single Sign-On Mobil-
ity Agent.
149 Administration Guide
Fortinet Technologies Inc.
Appendix D - FortiClient Log Messages
Client
Feature
ID Level Format Description
Single Sign-
On Mobility
Agent
0x00017ad6 Warning Single Sign-On Mobility Agent
was disabled
Logged when someone dis-
ables Single Sign-On Mobility
Agent.
Single Sign-
On Mobility
Agent
0x00017ad7 Info Single Sign-On Mobility Agent
is starting..., version:[nnn]
Single Sign-On Mobility Agent
is starting
Single Sign-
On Mobility
Agent
0x00017ad8 Info Single Sign-On Mobility Agent
is stopping..., version:[nnn]
Single Sign-On Mobility Agent
is stopping
UI 0x00017a66 Warning Logs were cleared Logged when logs are cleared.
UI 0x00017a67 Info Alerts were cleared Logged when alerts are cleared
by a user.
Administration Guide
Fortinet Technologies Inc.
150
Copyright© 2015 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, FortiCare® and FortiGuard®, and certain other marks are registered trademarks of Fortinet,
Inc., in the U.S. and other jurisdictions, and other Fortinet names herein may also be registered and/or common law trademarks of Fortinet. All other product or company
names may be trademarks of their respective owners. Performance and other metrics contained herein were attained in internal lab tests under ideal conditions, and
actual performance and other results may vary. Network variables, different network environments and other conditions may affect performance results. Nothing herein
represents any binding commitment by Fortinet, and Fortinet disclaims all warranties, whether express or implied, except to the extent Fortinet enters a binding written
contract, signed by Fortinet’s General Counsel, with a purchaser that expressly warrants that the identified product will perform according to certain expressly-identified
performance metrics and, in such event, only the specific performance metrics expressly identified in such binding written contract shall be binding on Fortinet. For
absolute clarity, any such warranty will be limited to performance in the same ideal conditions as in Fortinet’s internal lab tests. In no event does Fortinet make any
commitment related to future deliverables, features or development, and circumstances may change such that any forward-looking statements herein are not accurate.
Fortinet disclaims in full any covenants, representations, and guarantees pursuant hereto, whether express or implied. Fortinet reserves the right to change, modify,
transfer, or otherwise revise this publication without notice, and the most current version of the publication shall be applicable.

Navigation menu
