3000K and warmer CCTs only

SW1

Site Wallforms

revision 8/2/16 • kl-sw1_spec.pdf

Approvals:

Specifications Head: One-piece cast, low-copper (<0.6 Cu) aluminum alloy, F" wall

thickness with external reveal. Attachment to wall is by two bolts

concealed within the head.

Reflector and Socket: Formed specular Alzak® reflector panel secured

to a harness which holds a porcelain medium base 4KV socket (HID and

Incandescent), GX24q - Universal Socket (42W Fluorescent), or two

single ended twin tube sockets (13W Fluorescent). Entire assembly is

removable in one piece for access to mounting screws and is factory wired

with a disconnect plug. No reflector provided for LED.

Lens: Clear flat B" thick tempered glass retained by two stainless steel

brackets, and four stainless steel, hex socket cap screws, fully gasketed.

Electrial Module: Factory mounted to removable harness within fixture

head. Wire leads supplied with disconnect plugs. HID: High power

factor with starting temperatures of -20°F. for PMH and -40°F. for HPS

lamp modes. 13W Fluorescent: 120V 32°F. starting; 277V 0°F. starting.

26W, 32W, 42W Fluorescent: High power factor with starting

temperature of 0°F. LED: A total of 9 LED emitters configured in a

rectangular array comprised together as a module. Two (2) modules

for 18 LED version and four (4) modules for 36 LED version. Available

in 3500K and 5100K.

LED Driver: Rated for 18 or 36 LED. Universal voltage from 120 to

277V with a ±10% tolerance. -40ºF starting temperature. All drivers are

Underwriters Laboratories recognized.

NOTE: The 120V driver can be dimmed with an off-the-shelf phase

control line dimmer (SCR/TRIAC style).

Mounting Plate: Zinc plated steel for attachment to standard

4" octagonal junction box. Gasket provided between mounting plate and

fixture plus rope caulk between fixture and wall.

Finish: Fade and abrasion resistant, electrostatically applied,

thermally cured, triglycidal isocyanurate (TGIC) polyester powdercoat.

Standard colors are Black, Dark Bronze, Light Gray, Titanium, Platinum

Silver, or White. Custom colors are available and subject to additional

charges, minimum quantities and longer lead times. Consult

representative.

CAUTION: Fixtures must be grounded in accordance with local codes

or the National Electrical Code. Failure to do so may result in serious

personal injury.

Date:

Page: 1 of 2

Type:

Job:

Catalog number:

© 2016 KIM LIGHTING • 16555 EAST GALE AVENUE, CITY OF INDUSTRY, CA 91745-1788 • TEL: 626/968-5666 • FAX: 626/968-5716

SW1 / / /

Fixture Electrical Module Finish Option

See page 2

8"

(203.2 mm)

12J"

(311.2 mm)

SW1 Model

50 watt HID

Medium Base Lamps

42 watt Compact Fluorescent

SW1

Maximum weight: 8 lb

5J"

(133.4 mm)

4" Octagonal

J-box in wall

(b

y

others)

Mounting Plate,

Gasket, and

Rope Caulk

by Kim

Dimensions

8"

(202.2 mm)

12J"

(311.2 mm)

5J"

(133.2 mm)

Mounting Plate,

Gasket, and

Rope Caulk

by Kim

12J"

(311.2 mm)

SW1 LED Model

18 and 36 LEDs

SW1 Model

50 watt HID

Medium Base Lamps

60 watt Incandescent

42 watt Compact Fluorescent

Mounting Plate

Gasket and

Rope Caulk

by Kim

Mounting Plate

Gasket and

Rope Caulk

by Kim

1Suitable for wet locations

2Dark Sky Approved 3000K and warmer CCTs only

KIM LIGHTING RESERVES THE RIGHT TO CHANGE SPECIFICATIONS WITHOUT NOTICEE.

HID drawing shown above

Listings and Ratings

ETL1 to UL standards 1598 & 8750 IP66 Rated 25°C Ambient

IP66 Rated Full Cutoff 2

Fixture Cat. No. SW1 Site Wallforms

SW1

Site Wallforms

revision 8/2/16 • kl-sw1_spec.pdf

Page: 2 of 2

Type:

Job:

Standard Features

© 2016 KIM LIGHTING • 16555 EAST GALE AVENUE, CITY OF INDUSTRY, CA 91745-1788 • TEL: 626/968-5666 • FAX: 626/968-5716

Lamp Lamp Line

Watts Type Volts

50 PMH 277

NOTE: For lamp/ballast

information outside of the

U.S.A. and Canada, please

consult your local Kim

representative.

Finish

Super TGIC powder coat

paint over a titanated

zirconium conversion

coating on fixture and shaft.

Electrical Module

PMH = Pulse Start

Metal Halide

HPS = High Pressure

Sodium

PL = Compact Fluorescent

INC = Incandescent

LED = Light-emitting diode

Optional Feature

Textured Glass Lens

Cat. No.  TG

 No Option

Unique textured glass reduces LED glare and improves visual

comfort.

For PMH, HPS and PL.

See footnote 3 below for LED

Cat. Nos. for Electrical Modules available:

 50PMH120  50HPS120  13PL1201  42PL2  60INC120

 50PMH277  13PL2771

Lamp ED-17, ED-17, (2) Twin (1) Triple T-10

Coated Coated Tubes Tube Inside Frost

Socket Medium Base Medium Base GX23-2 GX24q-4 —

ANSI Ballast M-98 S-68

1Two lamps required per fixture.

242PL operates one 26, 32, or 42 watt lamp at 120 thru 277 volts (50-60 Hz).

NOTE: Coated lamps are recommended.

3For LED, 18L = 18 LED Emitters; 36L = 36 LED Emitters; 3K = 3500K color temperature;

5K = 5100K color temperature; UV = Universal Voltage from 120 to 277V with a ± 10%

tolerance.

 18L3KUV3  36L3KUV3

 18L5KUV3  36L5KUV3

Lamp LED LED

Socket N/A N/A

Pulse Start

Metal Halide

LED

High Pressure

Sodium Compact

Fluorescent Incandescent

4Custom colors subject to additional charges, minimum quantities and extended lead

times. Consult representative. Custom color description:

Color: Black Dark Bronze Light Gray Titanium Platinum Silver White Custom Color4

Cat. No.:  BL  DB  LG  TT  PS  WH  CC
