1 Introduction
This document gives details of the AT Command Set supported by Quectel NB-IoT BC95 module.
The following string will be output after booting the module:
<CR><LF>Neul<CR><LF>OK<CR><LF>
After this string has been received, the AT command processor is ready to accept AT commands.
1.1. Definitions
- <CR>: Carriage return character;
- <LF>: Line feed character;
- <..>: Parameter name. Angle brackets do not appear on command line;
- [..]: Option parameter. Square brackets do not appear on the command line.
1.2. AT Command Syntax
Table 1: AT Commands Syntax
Multiple commands can be placed on a single line using a semi-colon (“;”) between commands. Only the
first command should have AT prefix. Commands can be in upper or lower case.
Test Command
Check possible sub-parameter values
Read
Command
Check current sub-parameter values
Set Command
Set command
Execute
Command
Execute command
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 7 / 58
When entering AT commands spaces are ignored except in the following cases:
- Within quoted strings, where they are preserved;
- Within an unquoted string or numeric parameter;
- Within an IP address;
- Within the AT command name up to and including a „=‟, „?‟ or „=?‟.
They can be used to make the input more human-readable. On input, at least a carriage return is required.
A newline character is ignored so it is permissible to use carriage return/line feed pairs on the input. For
B600, the AT command processor uses carriage return/line feed pairs (\r\n, 0x0D0A) to end lines on its
output.
If no command is entered after the AT token, OK will be returned. If an invalid command is entered,
ERROR will be returned.
Optional parameters, unless explicitly stated, need to be provided up to the last parameter being entered.
1.3. AT Command Responses
When the AT Command processor has finished processing a line, it will output either OK or ERROR
indicating that it is ready to accept a new command. Solicited informational responses are sent before the
final OK or ERROR. Unsolicited information responses will never occur between a solicited informational
response and the final OK or ERROR.
Responses will be of the format:
<CR><LF>+CMD1:<parameters><CR><LF>
<CR><LF>OK<CR><LF>
Or
<CR><LF><parameters><CR><LF>
<CR><LF>OK<CR><LF>
1.4. 3GPP Compliance
3GPP commands are complied with the 3GPP TS 27.007 v13.5.0 (2016-06). For clarification on 3GPP
commands, please refer to this document.
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 8 / 58
2 Implementation Status
Table 2: Types of AT Commands
Command
Description
Implemented in
3GPP
+CGMI
Request Manufacturer Identification
B350 or later
+CGMM
Request Manufacturer Model
B350 or later
+CGMR
Request Manufacturer Revision
B350 or later
+CGSN
Request Product Serial Number
B350 or later
+CEREG
EPS Network Registration Status
B350 or later
+CSCON
Signalling Connection Status
B350 or later
+CLAC
List Available Commands
B350 or later
+CSQ
Get Signal Strength Indicator
B350 or later
+CGPADDR=?
Show PDP Addresses
B350 or later
+COPS
PLMN Selection
B350 or later
+CGATT
PS Attach or Detach
B350 or later
+CIMI
Request International Mobile Subscriber Identity
B350 or later
+CGDCONT
Define PDP Context
B350 or later
+CFUN
Set Phone Functionality
B350 or later
+CMEE
Report Mobile Termination Error
B600 or later
Neul
+NMGS
Neul Send Message Command
B350 or later
+NMGR
Neul Get Message Command
B350 or later
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 9 / 58
+NNMI
Neul New Message Indications
B350 or later
+NSMI
Neul Send message Indications
B350 or later
+NQMGR
Neul Query Messages Received
B350 or later
+NQMGS
Neul Query Messages Sent
B350 or later
+NRB
Neul Reboot
B350 or later
+NCDP
Configure and Query CDP Server Settings
B350 or later
+NUESTATS
Query UE Statistics
B350 or later
+NEARFCN
Specify Search Frequencies
B350 or later
+NSOCR
Create Socket
B350 or later
+NSOST
SendTo Command (UDP Only)
B350 or later
+NSORF
Receive Command (UDP only)
B350 or later
+NSOCL
Close Socket
B350 or later
+NSONMI
Socket Message Arrived Indicator (Response
Only)
B350 or later
+NPING
Test IP Network Connectivity To A Remote Host
B350 or later
+NBAND
Set Supported Bands
B600 or later
+NLOGLEVEL
Set Debug Logging Level
B600 or later
+NCONFIG
Configure UE Behaviour
B650
Temporary
+NTSETID
Set ID
B350 or later
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 10 / 58
3 3GPP Commands
3.1. AT+CGMI Request Manufacturer Identification
This command returns manufacturer information. By default it will return “Neul Ltd; www.neul.com/” on the
standard platform. Refer to Chapter 6 for possible <err> values.
Parameter
Example
AT+CGMI
Neul Ltd; www.neul.com/
OK
3.2. AT+CGMM Request Manufacturer Model
This command returns manufacturer model information. By default it will return “Neul Hi2110” on the
standard platform. Refer to Chapter 6 for possible <err> values.
AT+CGMI Request Manufacturer Identification
Execute Command
AT+CGMI
Response
<manufacturer>
OK
+CME ERROR: <err>
Test Command
AT+CGMI=?
Response
OK
<manufacturer> The total number of characters, including line terminators. In the information text
shall not exceed 2048 characters. Text shall not contain the sequence 0<CR> or
OK<CR>.
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 11 / 58
Parameter
Example
AT+CGMM
Neul Hi2110
OK
3.3. AT+CGMR Request Manufacturer Revision
This command returns the manufacturer revision. The text is human-readable and is not intended for
microcontroller parsing. By default it will return the firmware revision - release and build.
Execution command returns one or more lines of information text <revision>. Refer to Chapter 6 for
possible <err> values.
AT+CGMM Request Manufacturer Model
Execute Command
AT+CGMM
Response
<model>
OK
+CME ERROR: <err>
Test Command
AT+CGMM=?
Response
OK
<model> The total number of characters, including line terminators, in the information text
shall not exceed 2048 characters. Text shall not contain the sequence 0<CR> or
OK<CR>.
AT+CGMR Request Manufacturer Revision
Execute Command
AT+CGMR
Response
<Revision>
OK
+CME ERROR: <err>
Test Command
AT+CGMR=?
Response
OK
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 12 / 58
Parameter
Example
AT+CGMR
V100R100C10B650SP6
OK
AT+CGMR=?
OK
Neul Hi2110 Implementation
- <revision> will change format over time. It should be treated as an opaque identifier.
3.4. AT+CGSN Request Product Serial Number
Execution command returns the IMEI (International Mobile station Equipment Identity number) and
related information. For a TA which does not support <snt>, only OK is returned. Refer to Chapter 6 for
possible <err> values.
<revision> The total number of characters, including line terminators, in the information text
shall not exceed 2048 characters. Text shall not contain the sequence 0<CR> or
OK<CR>
AT+CGSN Request Product Serial Number
Execute Command
AT+CGSN[=<snt>]
Response
When <snt>=0 (or omitted) and command successful:
<sn>
When <snt>=1 and command successful:
+CGSN: <imei>
When <snt>=2 and command successful:
+CGSN: <imeisv>
When <snt>=3 and command successful:
+CGSN: <svn>
OK
+CME ERROR: <err>
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 13 / 58
Parameter
Example
AT+CGSN=1 //Request the IMEI
490154203237511
OK
Neul Hi2110 Implementation
- Serial number, +CGSN=0, is not implemented, and will return an error. This will change in a future
release.
3.5. AT+CEREG EPS Network Registration Status
The set command controls the presentation of an unsolicited result code +CEREG: <stat> when <n>=1
and there is a change in the MT's EPS network registration status in E-UTRAN, or unsolicited result code
+CEREG: <stat>[,[<tac>],[<ci>],[<AcT>]] when <n>=2 and there is a change of the network cell in
E-UTRAN. The parameters <AcT>, <tac> and <ci> are provided only if available. The value <n>=3 further
extends the unsolicited result code with [,<cause_type>,<reject_cause>], when available, when the value
of <stat> changes. Refer to Chapter 6 for possible <err> values.
Test Command
AT+CGSN=?
Response
When TE supports <snt> and command is successful:
+CGSN: (list of supported <snt>s)
OK
<snt> Integer type indicating the serial number type that has been requested
0 Returns <sn>
1 Returns the IMEI (International Mobile station Equipment Identity)
2 Returns the IMEISV (International Mobile station Equipment Identity and Software
Version number)
3 Returns the SVN (Software Version Number)
<sn> The 128-bit UUID of the UE. The total number of characters, including line terminators, in
the information text shall not exceed 2048 characters. Text shall not contain the sequence 0
<CR> or OK<CR>.
<imei> String type in decimal format indicating the IMEI
<imeisv> String type in decimal format indicating the IMEISV
<svn> String type in decimal format indicating the current SVN which is a part of IMEISV
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 14 / 58
If the UE wants to apply PSM for reducing its power consumption, the set command controls the
presentation of an unsolicited result code: +CEREG: <stat>[,[<tac>],[<ci>],[<AcT>][,[<cause_
type>],[<reject_cause>][,[<Active-Time>],[<Periodic-TAU>]]]] .
When <n>=4.The unsolicited result code will provide the UE with additional information for the Active
Time value and the extended periodic TAU value if there is a change of the network cell in E-UTRAN. The
value <n>=5 further enhances the unsolicited result code with <cause_type> and <reject_cause> when
the value of <stat> changes. The parameters <AcT>, <tac>, <ci>, <cause_type>, <reject_cause>,
<Active-Time> and <Periodic-TAU> are provided only if available.
The read command returns the status of result code presentation and an integer <stat> which shows
whether the network has currently indicated the registration of the MT. Location information elements
<tac>, <ci> and <AcT>, if available, are returned only when <n>=2 and MT is registered in the network.
The parameters [,<cause_type>,<reject_cause>], if available, are returned when <n>=3.
Test command returns values supported as a compound value.
Parameter
AT+CEREG EPS Network Registration Status
Set Command
AT+CEREG=[<n>]
Response
OK
+CME ERROR: <err>
Read Command
AT+CEREG?
Response
when <n>=0, 1, 2 or 3 and command successful:
+CEREG:
<n>,<stat>[,[<tac>],[<ci>],[<AcT>[,<cause_type>,<reject_
cause>]]]
when <n>=4 or 5 and command successful:
+CEREG:
<n>,<stat>[,[<lac>],[<ci>],[<AcT>],[<rac>][,[<cause_type>
],[<reject_cause>][,[<Active-Time>],[<Periodic-TAU>]]]]
OK
Test Command
AT+CEREG=?
Response
+CEREG: (list of supported <n>s)
OK
<n> Integer type
0 Disable network registration unsolicited result code
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 15 / 58
1 Enable network registration unsolicited result code +CEREG: <stat>
2 Enable network registration and location information unsolicited result code:
+CEREG: <stat>[,[<tac>],[<ci>],[<AcT>]]
3 Enable network registration, location information and EMM cause value information
unsolicited result code:
+CEREG: <stat>[,[<tac>],[<ci>],[<AcT>][,<cause_type>,<reject_cause>]]
4 For a UE that wants to apply PSM, enable network registration and location
information unsolicited result code:
+CEREG: <stat>[,[<tac>],[<ci>],[<AcT>][,,[,[<Active-Time>],[<Periodic-TAU>]]]]
5 For a UE that wants to apply PSM, enable network registration, location information
and EMM cause value information unsolicited result code:
+CEREG:<stat>[,[<tac>],[<ci>],[<AcT>][,[<cause_type>],[<reject_cause>][,[<Active-
Time>],[<Periodic-TAU>]]]]
<stat> Integer type, indicates the EPS registration status
0 Not registered, MT is not currently searching an operator to register to
1 Registered, home network
2 Not registered, but MT is currently trying to attach or searching an operator to register
to
3 Registration denied
4 Unknown (e.g. out of E-UTRAN coverage)
5 Registered, roaming
6 Registered for “SMS only”, home network (not applicable)
7 Registered for “SMS only”, roaming (not applicable)
8 Attached for emergency bearer services only
9 Registered for “CSFB not preferred”, home network (not applicable)
10 Registered for “CSFB not preferred”, roaming (not applicable)
<tac> String type; two bytes tracking area code in hexadecimal format (e.g. “00C3” equals 195 in
decimal)
<ci> String type; four bytes E-UTRAN cell ID in hexadecimal format
<AcT> Integer type; indicates the access technology of the serving cell
0 GSM (not applicable)
1 GSM Compact (not applicable)
2 UTRAN (not applicable)
3 GSM w/EGPRS (not applicable)
4 UTRAN w/HSDPA (not applicable)
5 UTRAN w/HSUPA (not applicable)
6 UTRAN w/HSDPA and HSUPA (not applicable)
7 E-UTRAN
<cause_type> Integer type; indicates the type of <reject_cause>.
0 Indicates that <reject_cause> contains an EMM cause value
1 Indicates that <reject_cause> contains a manufacturer-specific cause
<reject_cause> Integer type; contains the cause of the failed registration. The value is of type as
defined by <cause_type>.
<Active-Time> String type; one byte in an 8 bit format. Indicates the Active Time value (T3324)
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 16 / 58
1. If the EPS MT in GERAN/UTRAN/E-UTRAN also supports circuit mode services and/or GPRS
services, the +CREG command and +CREG: result codes and/or the +CGREG command and
+CGREG: result codes are applied to the registration status and location information for those
services.
2. 3GPP TS 24.008 and 3GPP TS 24.301 specify the condition when the MS is considered as attached
for emergency bearer services.
3. 3GPP TS 44.060 specifies the System Information messages which give the information about
whether the serving cell supports EGPRS.
4. 3GPP TS 25.331 specifies the System Information blocks which give the information about whether
the serving cell supports HSDPA or HSUPA.
Example
AT+CEREG=1 //Enable network registration URC.
OK
AT+CEREG?
+CEREG: 1
OK
AT+CEREG=?
+CEREG:(0,1,2)
OK
Neul Hi2110 Implementation
- Only CEREG <n> values of 0, 1 and 2 are supported.
- <stat> return values 0-5 are supported.
allocated to the UE in E-UTRAN. The Active Time value is coded as one byte (octet 3)
of the GPRS Timer 2 information element coded as bit format (e.g. “00100100” equals
4 minutes). For the coding and the value range, please refer to the GPRS Timer 2 IE
in 3GPP TS 24.008 Table 10.5.163/3Gpp TS 24.008, 3GPP TS 23.682 and 3GPP TS
23.401.
<Periodic-TAU> String type; one byte in an 8 bit format. Indicates the extended periodic TAU value
(T3412) allocated to the UE in E-UTRAN. The extended periodic TAU value is coded
as one byte (octet 3) of the GPRS Timer 3 information element coded as bit format
(e.g. “01000111” equals 70 hours). For the coding and the value range, please refer to
the GPRS Timers 3 IE in 3GPP TS 24.008 Table 10.5.163a/3GPP TS 24.008, 3GPP
TS 23.682 and 3GPP TS 23.401.
NOTES
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 17 / 58
3.6. AT+CSCON Signalling Connection Status
This command gives details of the terminal‟s perceived radio connection status (i.e. to the base station). It
returns an indication of the current state. Please note that this state is only updated when radio events,
such as sending and receiving, take place. This means that the current state may be out of date. The
terminal may think it is "Connected" yet cannot currently use a base station due to a change in the link
quality.
The set command controls the presentation of an unsolicited result code +CSCON. If <n>=1, +CSCON:
<mode> is sent from the MT when the connection mode of the MT is changed. If <n>=2 and there is a
state within the current mode, +CSCON: <mode>[,<state>] is sent from the MT. If <n>=3, +CSCON:
<mode>[,<state>[,<access>]] is sent from the MT. If setting fails, an MT error, +CME ERROR: <err> is
returned. Refer to Chapter 6 for possible <err> values.
When the MT is in UTRAN or E-UTRAN, the mode of the MT refers to idle when no PS signalling
connection and to connected mode when a PS signalling connection between UE and network is setup.
When the UE is in GERAN, the mode refers to idle when the MT is in either the IDLE state or the
STANDBY state and to connected mode when the MT is in READY state.
The <state> value indicates the state of the MT when the MT is in GERAN, UTRAN connected mode or
E-UTRAN.
The read command returns the status of result code presentation and an integer <mode> which shows
whether the MT is currently in idle mode or connected mode. State information <state> is returned only
when <n>=2. Radio access type information <access> is returned only when <n>=3.
Test command returns supported values as a compound value.
AT+CSCON Signalling Connection Status
Set Command
AT+CSCON=[<n>]
Response
OK
+CME ERROR: <err>
Read Command
AT+CSCON?
Response
+CSCON:<n>,<mode>[,<state>]
OK
+CME ERROR: <err>
Test Command
AT+CSCON=?
Response
+CSCON: (list of supported <n>s)
OK
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 18 / 58
Parameter
Example
AT+CSCON=0
OK
AT+CSCON?
+CSCON:0,1
OK
AT+CSCON=?
+CSCON:(0,1)
OK
AT+CSCON=1
OK
AT+CSCON?
+CSCON:1,1
<n> Integer type
0 Disable unsolicited result code
1 Enable unsolicited result code +CSCON: <mode>
2 Enable unsolicited result code +CSCON: <mode>[,<state>]
3 Enable unsolicited result code +CSCON: <mode>[,<state>[,<access>]]
<mode> Integer type; indicates the signalling connection status
0 Idle
1 Connected
2-255 <reserved for future use>
<state> Integer type; indicates the CS or PS state while in GERAN and the RRC state information if
the MT is in connected mode while in UTRAN and E-UTRAN
0 UTRAN URA_PCH state
1 UTRAN Cell_PCH state
2 UTRAN Cell_FACH state
3 UTRAN Cell_DCH state
4 GERAN CS connected state
5 GERAN PS connected state
6 GERAN CS and PS connected state
7 E-UTRAN connected state
<access> Integer type; indicates the current radio access type
0 Indicates usage of radio access of type GERAN
1 Indicates usage of radio access of type UTRAN TDD
2 Indicates usage of radio access of type UTRAN FDD
3 Indicates usage of radio access of type E-UTRAN TDD
4 Indicates usage of radio access of type E-UTRAN FDD
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 19 / 58
OK
Neul Hi2110 Implementation
- Unsolicited notifications are not currently supported. This functionality will be added in a future
release.
- Only <n>=0 and <n>=1 are supported. <n>=0 is the default value.
3.7. AT+CLAC List Available Commands
This command lists the available AT commands. Execution command causes the MT to return one or
more lines of AT commands. Refer to Chapter 6 for possible <err> values. Please note that this command
only returns the AT commands that are available for the user.
Parameter
Example
AT+CLAC
AT+GM
AT+GMI
...
AT+GSN
AT+CLAC
OK
AT+CLAC List Available Commands
Execute Command
AT+CLAC
Response
<AT Command>
[<CR><LF><AT Command>[...]]
OK
+CME ERROR: <err>
AT+CLAC=?
Response
OK
<AT Command> Defines the AT command including the prefix AT. Text shall not contain the
sequence 0<CR> or OK<CR>
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 20 / 58
3.8. AT+CSQ Get Signal Strength Indicator
The terminal will provide a current signal strength indicator of 0 to 255 where larger is generally better.
This information is based on a single measurement so can be expected to change greatly over short
periods of time and may never use all possible (or even the majority) of the entire possible range or
codes.
Execution command returns received signal strength indication <rssi> and channel bit error rate <ber>
from the MT. Refer to Chapter 6 for possible <err> values.
Test command returns values supported as compound values.
Parameter
Example
AT+CSQ
+CSQ:31,99
OK
AT+CSQ Get Signal Strength Indicator
Execute Command
AT+CSQ
Response
+CSQ: <rssi>,<ber>
OK
+CME ERROR: <err>
Test Command
AT+CSQ=?
Response
+CSQ: (list of supported <rssi>s),(list of supported <ber>s)
OK
<rssi> Integer type
0 -113dBm or less
1 -111dBm
2...30 -109... -53dBm
31 -51dBm or greater
99 Not known or not detectable
<ber> Integer type; channel bit error rate (in percent)
0...7 As RXQUAL values (refer to 3GPP specification)
99 Not known or not detectable
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 21 / 58
Neul Hi2110 Implementation
- <ber> is currently not implemented, and will always be 99.
3.9. AT+CGPADDR Show PDP Addresses
This command returns the IP address of the device.
The execution command returns a list of PDP addresses for the specified context identifiers. If no <cid> is
specified, the addresses for all defined contexts are returned. Refer to Chapter 6 for possible <err>
values.
The test command returns a list of defined <cid>s. These are <cid>s that have been activated and may or
may not have an IP address associated with them.
Parameter
AT+CGPADDR Show PDP Addresses
Execute Command
AT+CGPADDR[=<cid>[,<cid>[,...]]]
Response
[+CGPADDR: <cid>[,<PDP_addr_1>[,<PDP_addr_2>]]]
[<CR><LF>+CGPADDR:
<cid>,[<PDP_addr_1>[,<PDP_addr_2>]]
[...]]
OK
IPv4: The string is given as dot-separated numeric (0-255)
parameter of the form:
a1.a2.a3.a4
IPv6: The string is given as colon-separated hexadecimal
parameter.
Test Command
AT+CGPADDR=?
Response
+CGPADDR: (list of defined <cid>s)
OK
<cid> Integer type; specifies a particular PDP context definition (see the +CGDCONT and
+CGDSCONT commands).
<PDP_addr_1> and <PDP_addr_2> String type that identify the MT in the address space applicable
to the PDP. The address may be static or dynamic. For a static
address, it will be the one set by the +CGDCONT and
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 22 / 58
In dual-stack terminals (<PDP_type> IPV4V6), the IPv6 address will be provided in <PDP_addr_2>. For
terminals with a single IPv6 stack (<PDP_type> IPV6) or due to backwards compatibility, the IPv6 address
can be provided in parameter <PDP_addr_1>.
Example
AT+CGPADDR=1
+CGPADDR:1,101.43.5.1
OK
AT+CGPADDR=?
+CGPADDR:(1)
OK
Neul Hi2110 Implementation
- Only IPv4 is supported.
- <cid> values between 0 & 10 are supported.
- With AUTOCONNECT enabled, <cid>=0 will not be listed until an IP address is acquired.
+CGDSCONT commands when the context was defined. For a
dynamic address it will be the one assigned during the last PDP
context activation that used the context definition referred to by
<cid>. Both <PDP_addr_1> and <PDP_addr_2> are omitted if
none is available. Both <PDP_addr_1> and <PDP_addr_2> are
included when both IPv4 and IPv6 addresses are assigned,
with <PDP_addr_1> containing the IPv4 address and
<PDP_addr_2> containing the IPv6 address.
The string is given as dot-separated numeric (0-255) parameter
of the form: a1.a2.a3.a4 for IPv4 and
a1.a2.a3.a4.a5.a6.a7.a8.a9.a10.a11.a12.a13.a14.a15.a16 for
IPv6.
When +CGPIAF is supported, its settings can influence the
format of the IPv6 address in parameter <PDP_addr_1> or
<PDP_addr_2> returned with the execute form of +CGPADDR.
NOTE
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 23 / 58
3.10. AT+COPS PLMN Selection
Set command forces an attempt to select and register the GSM/UMTS/EPS network operator using the
SIM/USIM card installed in the currently selected card slot. <mode> is used to select whether the
selection is done automatically by the MT or is forced by this command to operator <oper> (it shall be
given in format <format>) to a certain access technology, indicated in <AcT>. If the selected operator is
not available, no other operator shall be selected (except <mode>=4). If the selected access technology
is not available, then the same operator shall be selected in other access technology. The selected
operator name format shall also apply to further read commands (+COPS?). <mode>=2 forces an attempt
to deregister from the network. The selected mode affects all further network registration (e.g. after
<mode>=2, MT shall be unregistered until <mode>=0 or 1 is selected). This command should be
abortable when registration/deregistration attempt is made. Refer to Chapter 6 for possible <err> values.
Read command returns the current mode, the currently selected operator and the current access
technology. If no operator is selected, <format>, <oper> and <AcT> are omitted.
Test command returns a set of five parameters, each representing an operator present in the network. A
set consists of an integer indicating the availability of the operator <stat>, long and short alphanumeric
format of the operator‟s name, numeric format representation of the operator and access technology. Any
of the formats may be unavailable and should then be an empty field. The list of operators shall be in
order: home network, networks referenced in SIM or active application in the UICC (GSM or USIM) in the
following order: HPLMN selector, user controlled PLMN selector, operator controlled PLMN selector and
PLMN selector (in the SIM or GSM application), and other networks.
It is recommended (although optional) that after the operator list TA returns lists of supported <mode>s
and <format>s. These lists shall be delimited from the operator list by two commas.
The <AcT> access technology selected parameters should only be used in terminals capable to register
to more than one access technology. Selection of <AcT> does not limit the capability to cell reselections,
even though an attempt is made to select an access technology, the phone may still re-select a cell in
another access technology.
AT+COPS PLMN Selection
Se Command
AT+COPS=[<mode>[,<format>[,<oper
>[,<AcT>]]]]
Response
OK
+CME ERROR: <err>
Read Command
AT+COPS?
Response
+COPS: <mode>[,<format>,<oper>][,<AcT>]
OK
+CME ERROR: <err>
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 24 / 58
Parameter
Test Command
AT+COPS=?
Response
+COPS: [list of supported(<stat>,long alphanumeric <oper>,
short alphanumeric <oper>, numeric <oper>[,<Act>])s][,,(list
of supported <mode>s),(list of supported <format>s)]
OK
+CME ERROR: <err>
<mode> Integer type
0 Automatic (<oper> field is ignored)
1 Manual (<oper> field shall be present, and <AcT> is optional)
2 Deregister from network
3 Set only <format> (for read command +COPS?), do not attempt to
register/deregister (<oper> and <AcT> fields are ignored); this value is not
applicable in read command response
4 Manual/automatic (<oper> field shall be present); if manual selection fails,
automatic mode (<mode>=0) is entered
<format> Integer type
0 Long format alphanumeric <oper>
1 Short format alphanumeric <oper>
2 Numeric <oper>
<oper> String type; <format> indicates if the format is alphanumeric or numeric; long alphanumeric
format can be up to 16 characters long and short format up to 8 characters; numeric format
is the GSM Location Area Identification number which consists of a three BCD digit ITU-T
country code coded, plus a two or three BCD digit network code, which is administration
specific.<stat> Integer type
0 Unknown
1 Available
2 Current
3 Forbidden
<AcT> Integer type; access technology selected
0 GSM
1 GSM Compact
2 UTRAN
3 GSM w/EGPRS
4 UTRAN w/HSDPA
5 UTRAN w/HSUPA
6 UTRAN w/HSDPA and HSUPA
7 E-UTRAN
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 25 / 58
1. 3GPP TS 44.060 specifies the system information messages which give the information about
whether the serving cell supports EGPRS.
2. 3GPP TS 25.331 specifies the system information blocks which give the information about whether
the serving cell supports HSDPA or HSUPA.
Example
AT+COPS=0,2
OK
AT+COPS?
+COPS:0,2,"46001"
OK
AT+COPS=?
+COPS:(2,"RADIOLINJA","RL","24405"),
(0,"TELE","TELE","24491"),(2)
OK
Neul Hi2110 Implementation
- <Act>, if provided, must be set to 7.
- Only <format>=2 is supported.
- Only <mode>=0, <mode>=1 & <mode>=2 are supported.
- When <mode>=1, the PLMN setting will not be retained after the UE is rebooted.
- <mode>=1 is only for development use and <mode>=0 should be used in production when
AUTOCONNECT is enabled.
- The test command currently returns the configured values rather than performs a PLMN search.
3.11. AT+CGATT PS Attach or Detach
The execution command is used to attach the MT to, or detach the MT from, the Packet Domain service.
After the command has completed, the MT remains in V.250 command state. If the MT is already in the
requested state, the command is ignored and the OK response is returned. If the requested state cannot
be achieved, an ERROR or +CME ERROR response is returned. Refer to Chapter 6 for possible <err>
values.
Any active PDP contexts will be automatically deactivated when the attachment state changes to
detached.
NOTES
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 26 / 58
The read command returns the current Packet Domain service state.
The test command is used for requesting information on the supported Packet Domain service states.
Parameter
Example
AT+CGATT?
+CGATT:0
OK
AT+CGATT=1
OK
AT+CGATT=?
+CGATT:(0,1)
OK
1. If the initial PDP context is supported, the context with <cid>=0 is automatically defined at startup.
2. This command has the characteristics of both the V.250 action and parameter commands. Hence it
AT+CGATT PS Attach or Detach
Execute/Set Command
AT+CGATT=<state>
Response
OK
+CME ERROR:<err>
Read Command
AT+CGATT?
Response
+CGATT:<state>
OK
Test Command
AT+CGATT=?
Response
+CGATT:(list of supported <state>s)
OK
<state> Integer type; indicates the state of PDP context activation. The default value is
manufacturer specific
0 Detached
1 Attached
<err> Error value
NOTES
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 27 / 58
has the read form in addition to the execution/set and test forms.
Neul Hi2110 Implementation
- When <state>=1, +COPS=0 is automatically selected.
- If a CGATT command is in progress, further execution of the CGATT command will return an “Uplink
busy” error.
3.12. AT+CIMI Request International Mobile Subscriber Identity
This command returns International Mobile Subscriber Identity (string without double quotes).
Execution command causes the TA to return <IMSI>, which is intended to permit the TE to identify the
individual SIM card or active application in the UICC (GSM or USIM) which is attached to MT.
Refer to Chapter 6 for possible <err> values.
Parameter
Example
AT+CIMI
460001357924680
OK
AT+CIMI Request International Mobile Subscriber Identity
Execute Command
AT+CIMI
Response
<IMSI>
OK
+CME ERROR: <err>
Test Command
AT+CIMI=?
Response
OK
<IMSI> International Mobile Subscriber Identity (string without double quotes)
<err> TBD
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 28 / 58
Neul Hi2110 Implementation
- IMSI may not be displayed for a few seconds after power-on.
3.13. AT+CGDCONT Define PDP Context
The set command specifies PDP context parameter values for a PDP context identified by <cid>, the
(local) context identification parameter, and also allows the TE to specify whether security protected
transmission of ESM information is requested, because the PCO can include information that requires
ciphering. There can be other reasons for the UE to use security protected transmission of ESM
information, e.g. if the UE needs to transfer an APN. The number of PDP contexts that may be in a
defined state at the same time is given by the range returned by the test command. Refer to Chapter 6 for
possible <err> values.
For EPS, the PDN connection and its associated EPS default bearer is identified herewith.
A special form of the set command, +CGDCONT=<cid> causes the values for context number <cid> to
become undefined.
If the initial PDP context is supported, the context with <cid>=0 is automatically defined at startup, please
refer to 3GPP TS 27.007 V13.5.0, subclause 10.1.0. As all other contexts, the parameters for <cid>=0 can
be modified with +CGDCONT. If the initial PDP context is supported, +CGDCONT=0 resets context
number 0 to its particular default settings.
The read command returns the current settings for each defined context.
The test command returns values supported as compound values. If the MT supports several PDP types,
the parameter value ranges for each <PDP_type> are returned on a separate line.
AT+CGDCONT Define PDP Context
Execute/Set Command
AT+CGDCONT=[<cid>[,<PDP_type>[,
<APN>[,<PDP_addr>[,<d_comp>[,<h_
comp>[,<IPv4AddrAlloc>[,<request_t
ype>[,<P-CSCF_discovery>[,<IM_CN
_Si_gnalling_Flag_Ind>[,<NSLPI>[,<s
ecurePCO>[,<IPv4_MTU_discovery>][
,<Local_Addr_Ind>]]]]]]]]]]]]
Response
OK
Read Command
AT+CGDCONT?
Response
[+CGDCONT:
<cid>,<PDP_type>,<APN>,<PDP_addr>,<d_comp>,<h_co
mp>[,<IPv4AddrAlloc>[,<request_type>[,<P-CSCF_disco
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 29 / 58
Parameter
very>[,<IM_CN_Signalling_Flag_Ind>[,<NSLPI>[,<secure
PCO>[,<IPv4_MTU_discovery>]]]]]]]]
[<CR><LF>+CGDCONT:
<cid>,<PDP_type>,<APN>,<PDP_addr>,<d_comp>,<h_co
mp>[,<IPv4AddrAlloc>[,<request_type>[,<P-CSCF_disco
very>[,<IM_CN_Signalling_Flag_Ind>[,<NSLPI>[,<secure
PCO>[,<I Pv4_MTU_discovery>]]]]]]]
[...]]
OK
Test Command
AT+CGDCONT=?
Response
+CGDCONT: (range of supported <cid>s),<PDP_type>,,,(list
of supported <d_comp>s),(list of supported <h_comp>s),(list
of supported <IPv4AddrAlloc>s),(list of supported
<request_type>s),(list of supported
<P-CSCF_discovery>s),(list of supported
<IM_CN_Signalling_Flag_Ind>s) ,(list of supported
<NSLPI>s),(list of supported <securePCO>s),(list of
supported <IPv4_MTU_discovery>s)
[<CR><LF>+CGDCONT: (range of supported
<cid>s),<PDP_type>,,,(list of supported <d_comp>s),(list of
supported <h_comp>s),(list of supported
<IPv4AddrAlloc>s),(list of supported <request_type>s),(list of
supported <p-CSCF_discovery>s),(list of supported
<IM_CN_Signalling_Flag_Ind>s) ,(list of supported
<NSLPI>s),(list of supported <securePCO>s,(list of
supported <IPv4_MTU_discovery>s)) [...]]
OK
<cid> Integer type; specifies a particular PDP context definition. The parameter is local to the
TE-MT interface and is used in other PDP context-related commands. The range of
permitted values (minimum value=1 or if the initial PDP context is supported, minimum
value=0) is returned by the test form of the command.
The <cid>s for network-initiated PDP contexts will have values outside the ranges indicated
for the <cid> in the test form of the +CGDCONT and +CGDSCONT commands.
<PDP_type> String type; specifies the type of packet data protocol. The default value is manufacturer
specific.
X.25 ITU-T/CCITT X.25 layer 3 (Obsolete)
IP Internet Protocol (IETF STD 5 [103])
IPV6 Internet Protocol, version 6
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 30 / 58
IPV4V6 Virtual <PDP_type> introduced to handle dual IP stack UE capability
OSPIH Internet Hosted Octect Stream Protocol (Obsolete)
PPP Point to Point Protocol (IETF STD 51 [104])
Only IP, IPV6 and IPV4V6 values are supported for EPS services.
<APN> String type; a logical name that is used to select the GGSN or the external packet data
network. If the value is null or omitted, then the subscription value will be requested. The
APN is a string of up to 82 characters.
<PDP_addr> String type; identifies the MT in the address space applicable to the PDP. This parameter
can be left blank.
When +CGPIAF is supported, its settings can influence the format of this parameter
returned with the read form of +CGDCONT.
The value of this parameter is ignored with the set command. The parameter is included in
the set command for backwards compatibility reasons only.
<d_comp> Integer type; controls PDP data compression
0 Off
1 On (manufacturer preferred compression)
2 V.42bis
3 V.44
<h_comp> Integer type; controls PDP header compression
0 Off
1 On (manufacturer preferred compression)
2 RFC 1144 [105] (applicable for SNDCP only)
3 RFC 2507 [107]
4 RFC 3095 [108] (applicable for PDCP only)
<IPv4AddrAlloc> Integer type; controls how the MT/TA requests to get the IPv4 address information
0 IPv4 address allocation through NAS signalling
1 IPv4 address allocated through DHCP
<request_type> Integer type; indicates the type of PDP context activation request for the PDP
context. Please refer to 3GPP TS 24.301 (subclause 6.5.1.2) and 3GPP TS
24.008 (subclause 10.5.6.17). If the initial PDP context is supported it is not
allowed to assign <cid>=0 for emergency bearer services. According to 3GPP TS
24.008 (subclause 4.2.4.2.2 and subclause 4.2.5.1.4) and 3GPP TS 24.301
(subclause 5.2.2.3.3 and subclause 5.2.3.2.2), a separate PDP context must be
established for emergency bearer services.
If the PDP context for emergency bearer services is the only activated context,
only emergency calls are allowed, refer to 3GPP TS 23.401 subclause 4.3.12.9.
0 PDP context is for new PDP context establishment or for handover from
a non-3GPP access network (how the MT decides whether the PDP
context is for new PDP context establishment or for handover is
implementation specific).
1 PDP context is for emergency bearer services
2 PDP context is for new PDP context establishment
3 PDP context is for handover from a non-3GPP access network
<P-CSCF_discovery>Integer type; influences how the MT/TA requests to get the P-CSCF address, refer
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 31 / 58
Example
AT+CGDCONT=?
+CGDCONT:(1-3),("IP"),,,(0-1),(0-1)
OK
AT+CGDCONT=1,“IP”,“HUAWEI.COM”
OK
AT+CGDCONT?
+CGDCONT:1,“IP”,HUAWEI.COM, ,0,0
OK
to 3GPP TS 24.229 [89] annex B and annex L.
0 Preference of P-CSCF address discovery not influenced by +CGDCONT
1 Preference of P-CSCF address discovery through NAS signalling
2 Preference of P-CSCF address discovery through DHCP
<IM_CN_Signalling_Flag_Ind>Integer type; indicates to the network whether the PDP context is for IM
CN subsystem related signalling only or not.
0 UE indicates that the PDP context is not for IM CN
subsystem-related signalling only
1 UE indicates that the PDP context is for IM CN
subsystem-related signalling only
<NSLPI> Integer type; indicates the NAS signalling priority requested for this
PDP context
0 Indicates that this PDP context is to be activated with the
value for the low priority indicator configured in the MT.
1 Indicates that this PDP context is to be activated with the
value for the low priority indicator set to "MS is not
configured for NAS signalling low priority".
The MT utilizes the provided NSLPI information as
specified in 3GPP TS 24.301 [83] and 3GPP TS 24.008.
<securePCO> Integer type. Specifies if security protected transmission of PCO is
requested or not (applicable for EPS only).
0 Security protected transmission of PCO is not requested
1 Security protected transmission of PCO is requested
<IPv4_MTU_discovery> Integer type; influences how the MT/TA requests to get the IPv4 MTU
size, refer to 3GPP TS 24.008 subclause 10.5.6.3.
0 Preference of IPv4 MTU size discovery not influenced by
+CGDCONT
1 Preference of IPv4 MTU size discovery through NAS
signalling
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 32 / 58
Neul Hi2110 Implementation
- Only <PDP_type>=“IP” is supported. <PDP_type>=“IPV6” will be supported in a future release.
- Neul supports +CGDCONT=<cid>,<PDP_type>,<APN> only.
- <cid> values of 0-10 are supported.
- <cid>=0 is read only and is only defined when AUTOCONNECT is enabled.
- Only <hcomp> and <dcomp> values of 0 are supported.
3.14. AT+CFUN Set Phone Functionality
Set command selects the level of functionality in the MT. Level "full functionality" is where the highest level
of power is drawn. "Minimum functionality" is where minimum power is drawn. Level of functionality
between these may also be specified by manufacturers. When supported by manufacturers, MT resetting
with <rst> parameter may be utilized. Refer to Chapter 6 for possible <err> values.
It is manufacturer specific if this command affects network registration. +COPS is used to force
registration/deregistration.
Read command returns the current setting of <fun>.
Test command returns values supported by the MT as compound values.
AT+CFUN Set Phone Functionality
Set Command
AT+CFUN=[<fun>[,<rst>]]
Response
OK
+CME ERROR: <err>
Read Command
AT+CFUN?
Response
+CFUN:<fun>
OK
Test Command
AT+CFUN=?
Response
+CFUN:(list of supported<fun>s), (list of supported<rst>s)
OK
NOTE
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 33 / 58
Parameter
Example
AT+CFUN=?
+CFUN:(0,1),(0,1)
OK
AT+CFUN=1
OK
AT+CFUN?
+CFUN:1
OK
<fun> Integer type
0 Minimum functionality
1 Full functionality. Enable MT to transmit and receive RF circuits for all
supported radio access technologies. For MTs supporting +CSRA, this
equals the RATs indicated by the response of +CSRA=?. Currently +CSRA
setting is ignored. It is not required that the transmitting and receiving RF
circuits are in a disabled state when this setting takes effect.
2 Disable MT to transmit RF circuits only
3 Disable MT to receive RF circuits only
4 Disable MT to transmit and receive RF circuits
5...127 Reserved for manufacturers as intermediate states between full and minimum
functionality
128 Full functionality with radio access support according to the setting of +CSRA.
Enables MT to transmit and receive RF circuits if it not already enabled. This
<fun> setting is applicable for MTs supporting +CSRA.
129 Prepare for shutdown. This setting has its prime use when some of the MT‟s
resources (e.g. file system) are located on a tightly integrated TE (host). The
MT will execute pending actions resulting in "permanent" changes, e.g.
execute pending file system operations. The MT will also make an orderly
network detachment.
After this action and +CFUN has returned OK, the MT can be shut down with
<fun>=0, or by other means.
After setting <fun>=129, only <fun>=0 is valid. All other values will make
+CFUN return ERROR.
<rst> Integer type
0 Do not reset the MT before setting it to <fun> power level. This shall be
always default when <rst> is not given.
1 Reset the MT before setting it to <fun> power level
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 34 / 58
Neul Hi2110 Implementation
- Only <fun>=0&1 are supported.
- <rst> is not supported and will be ignored.
3.15. AT+CMEE Report Mobile Termination Error
Set command disables or enables the use of final result code +CME ERROR: <err> as an indication of an
error relating to the functionality of the MT. When enabled, MT related errors cause +CME ERROR: <err>
final result code instead of the regular ERROE final result code. ERROR is returned normally when error
is related to syntax, invalid parameters or TA functionality.
Read command returns the current setting of <n>.
Test command returns values supported as a compound value.
Refer to Chapter 6 for possible <err> values.
Parameter
Neul Hi2110 Implementation
- Only <n>=0 & <n>=1 are supported.
AT+CMEE Report Mobile Termination Error
Set Command
AT+CMEE=<n>
Response
OK
Read Command
AT+CMEE?
Response
+CMEE:<n>
OK
Test Command
AT+CMEE=?
Response
+CMEE:(list of supported<n>s)
OK
<n> Integer type
0 Disable +CMEE ERROR: <err> result code and use ERROR instead
1 Enable +CMEE ERROR: <err> result code and use numeric <err> values (Refer
to Chapter 6 for possible <err> values)
2 Enable +CMEE ERROR: <err> result code and use verbose <err> values
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 35 / 58
4 Neul Commands
4.1. AT+NMGS Neul Send Message Command
The send message command is used to send a message from the Terminal to the network via the CDP
server. This command will give an <err> code and description as an intermediate message if it can‟t send
the message. Refer to Chapter 6 for possible <err> values.
Parameter
Example
AT+NMGS=3,AA11BB
OK
Neul Hi2110 Implementation
- There is a maximum data length of 512 bytes.
- Only one message will be buffered at any one time.
4.2. AT+NMGR Neul Get Message Command
Receive a message from the CDP server.
AT+NMGS Neul Send Message Command
Set Command
AT+NMGS=<length>,<data>
Response
OK
+CME ERROR: <err>
<length> Decimal length of message
<data> Data to be transmitted in hex string format
<err> TBD
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 36 / 58
The get message command returns the oldest buffered message and deletes from the buffer. If there are
no messages then no command response will be given. If new message indications (+NNMI) are turned
on then received messages will not be available via this command.
Parameter
Example
AT+NMGR
5,48656C6C6F
OK
Neul Hi2110 Implementation
- Maximum received data length is 512 bytes.
4.3. AT+NNMI Neul New Message Indications
This command sets or gets new message indications that are sent. New message indications can be sent
when a downstream message is received by the terminal from the CDP server. Refer to Chapter 6 for
possible <err> values.
When new message indications and messages are enabled (NNMI=1), all currently buffered messages
will be returned in the format of +NNMI: <length>,<data>. For example: +NNMI: 5,48656C6C6F.
If indications alone are turned on (NNMI=2), each newly received message triggers an indication that a
new datagram is waiting using the unsolicited informational response. The buffered messages can be
collected using +NMGR. The format of response is: +NNMI.
AT+NMGR Neul Get Message Command
Execute Command
AT+NMGR
Response
<length>,<data>
OK
+CME ERROR: <err>
<length> Decimal length of message
<data> Data received in hex string format
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 37 / 58
The default setting is 0: no indications are sent.
Parameter
Example
AT+NNMI=1
OK
AT+NNMI?
+NNMI:1
OK
4.4. AT+NSMI Neul Sent Message Indications
This command sets or gets indications that are sent when an upstream message is sent to the CDP
server.
If sent message indications are turned on, the unsolicited informational response: +NSMI:<status> (e.g
+NSMI: SENT) will be issued when a new message is sent into NB-IoT stack. Refer to Chapter 6 for
possible <err> values.
The default setting is 0: no indications are sent.
AT+NNMI Neul New Message Indications
Set Command
AT+NNMI=<status>
Response
OK
+CME ERROR: <err>
Read Command
AT+NNMI?
Response
+NNMI: <status>
OK
<status> 0 No indications, the default setting
1 Indications and message
2 Indications only
<length> Decimal length of message
<data> Data to be transmitted in hex string format
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 38 / 58
Parameter
Example
AT+NSMI=1
OK
AT+NSMI?
+NSMI:1
OK
4.5. AT+NQMGR Neul Query Messages Received
This command queries the status of the downstream messages received from the CDP server. Refer to
Chapter 6 for possible <err> values.
AT+NSMI Neul Sent Message Indications
Set Command
AT+NSMI=<indications>
Response
OK
+CME ERROR: <err>
Read Command
AT+NSMI?
Response
+NSMI:<indications>
OK
<indications> 0 No indications, the default setting
1 Indications will be sent
<status> SENT
DISCARDED
AT+NQMGR Neul Query Messages Received
Execute Command
AT+NQMGR
Response
BUFFERED=<buffered>,
RECEIVED=<received>,
DROPPED=<dropped>
OK
+CME ERROR: <err>
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 39 / 58
Parameter
Example
AT+NQMGR
BUFFERED=0,RECEIVED=34,DROPPED=2
OK
4.6. AT+NQMGS Neul Query Messages Sent
This command queries the status of the upstream messages sent to the CDP server. Refer to Chapter 6
for possible <err> values.
Parameter
Example
AT+NQMGS
PENDING=1,SENT=34,ERROR=0
OK
<buffered> The number of messages waiting to be read in the downstream buffer
<received> The total number of messages received by the terminal since terminal boot
<dropped> The number of messages dropped by the terminal since terminal boot
AT+NQMGS Neul Query Messages Sent
Execute Command
AT+NQMGS
Response
PENDING=<pending>, SENT=<sent>, ERROR=<error>
OK
+CME ERROR: <err>
<pending> The number of messages waiting to be sent in the upstream buffer, if Layer 3 is
registered and activated
<sent> The total number of uplink messages sent into the NB-IoT stack since terminal
boot
<error> The number of messages that could not be sent by the terminal due to an error
since terminal boot
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 40 / 58
4.7. AT+NRB Neul Reboot
This command reboots the terminal. There is a short delay after issuing this command before the terminal
reboots. No further AT commands will be processed. Refer to Chapter 6 for possible <err> values.
Please note that there is no final OK to signal that the command line has finished processing as AT
command processing terminates with this command. No confirmation messages are expected until the
reboot.
Example
AT+NRB
REBOOTING
4.8. AT+NCDP Configure and Query CDP Server Settings
This command is used to set and query the server IP address and port for the Connected Device Platform
(CDP) server. It is used when there is a Neul CDP or Huawei IoT platform acting as gateway to network
server applications. Refer to Chapter 6 for possible <err> values.
AT+NRB Neul Reboot
Execute Command
AT+NRB
Response
REBOOTING
AT+NCDP Configure and Query CDP Server Settings
Set Command
AT+NCDP=<ip_addr>[,<port>]
Response
Update the CDP server configuration from the supplied
parameters. If they are set correctly, return OK. If it fails, an
error is returned.
+CME ERROR: <err>
Test Command
AT+NCDP?
Response
Return the current CDP server IP address and port. Return an
error if not set.
+NCDP:<ip_addr>,<port>
OK
+CME ERROR: <err>
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 41 / 58
Parameter
Example
AT+NCDP=192.168.5.1
OK
AT+NCDP?
+NCDP:192.168.5.1,5683
OK
Neul Hi2110 Implementation
- Only IPv4 is supported.
- The values assigned are persistent across reboots.
- This command is available after the IMEI has been configured.
- This command must be executed when the radio is inactive (AT+CFUN=0 will force the module to
enter into this state).
- IP addresses can be specified in decimal, octal or hexadecimal notation.
4.9. AT+NUESTATS Query UE Statistics
This command fetches the most recent operational statistics. Refer to Chapter 6 for possible <err>
values.
<ip_addr> IPv4 address, IP address in dot-separated numeric (0-255) parameter of the form:
a1.a2.a3.a4
<port> Unsigned integer 0-65535. If port 0 is provided, the default port (5683) will be used. If
no port is specified the previously set port will be used. If no port is specified, and no
port was previously set, the default port will be used.
AT+NUESTATS Query UE Statistics
Execute Command
AT+NUESTATS
Response
Signal power:<signal power in centibels>
Total power:<total power in centibels>
TX power:<current Tx power level in centibels >
TX time:<total Tx time since last reboot in millisecond>
RX time:<total Rx time since last reboot in millisecond>
Cell ID:<last cell ID>
DL MCS:<last DL MCS value>
UL MCS:<last UL MCS value>
DCI_MCS:<last DCI MCS value>
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 42 / 58
Parameter
Example
AT+NEUSTATS
Signal power:50
Total power:500
TX power:30
TX time:1234567
RX time:12345
Cell ID:70
DL MCS:5
UL MCS:5
DCI_MCS:5
ECL:1
OK
4.10. AT+NEARFCN Specify Search Frequencies
The set command provides a mechanism to lock to a specific E-ULTRA Absolut Radio Frequency
Channel Number (EARFCN). All actions will be locked to this carrier until either the lock is removed or the
UE is rebooted. Refer to Chapter 6 for possible <err> values.
ECL:<last ECL value>
OK
+CME ERROR: <err>
<signal power in centibels> Signal power in centibels
<total power in centibels> Total power in centibels
<current Tx power level in centibels> Current Tx power level in centibels
<total Tx time since last reboot in millisecond> Total Tx time since last reboot in millisecond
<total Rx time since last reboot in millisecond> Total Rx time since last reboot in millisecond
<last cell ID> Last cell ID
<last DL MCS value> Last DL MCS value
<last UL MCS value> Last UL MCS value
<last DCI MCS value> Last DCI MCS value
<last ECL value> Last ECL value
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 43 / 58
Parameter
Example
AT+NEARFCN=0,10
OK
4.11. AT+NSOCR Create Socket
This command creates a socket on the UE and associates with specified protocol. If the port is set,
receiving is enabled and +NSONMI unsolicited messages will appear for any message that is received on
that port. Refer to Chapter 6 for possible <err> values.
If a socket has already been created for a protocol, port combination, +NSOCR will fail if requested a
second time.
Parameter
AT+NEARFCN Specify Search Frequencies
Set Command
AT+NEARFCN=<search_mode>,<earf
cn>
Response
OK
+CME ERROR: <err>
<search_mode> Specifies the type of search and defines the supplied parameters
0 Single point EARFCN search
<earfcn> A number in the range 1-65535 representing the EARFCN to search. An
<earfcn> value of 0 will remove the restriction.
AT+NSOCR Create Socket
Set Command
AT+NSOCR=<type>,<protocol>,<liste
n port>[,<receive control>]
Response
<socket>
OK
+CME ERROR: <err>
<type> Socket Type. Supported value is DGRAM
<protocol> Standard internet protocol definition. For example, UDP is 17
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 44 / 58
Example
AT+NSOCR=DGRAM,17,5683,1
0
OK
AT+NSOCR=DGRAM,17,1234,1
1
OK
Neul Hi2110 Implementation
- A maximum of 7 sockets are supported, but other services may reduce this number.
- Only UDP, protocol 17, is supported.
- <type>=RAW and <protocol>=6 will be accepted, but are not supported and should not be used.
4.12. AT+NSOST SendTo Command (UDP Only)
Send a UDP datagram containing length bytes of data to remote_port on remote_addr.
This command sends a UDP datagram containing length bytes of data to the specified host:port. It will
return with the socket that it was sent on, and the number of bytes of data sent. If the amount of data is
larger than the largest datagram that can be sent, +NSOST return value will indicate how much of the
data was successfully sent. Refer to Chapter 6 for possible <err> values.
<listen port> A number in the range 0-65535. This is the local port that will be included in sent
messages and on which messages will be received.
<socket> This is a reference to the created socket. It is an integer greater than or equal to 0.
<receive control> Set to 1 if incoming messages should be received, 0 if incoming messages should
be ignored. Default is 1 (messages will be received).
AT+NSOST SendTo Command (UDP Only)
Set Command
AT+NSOST=socket,remote_addr,rem
ote_port, length,data
Response
<socket>,<length>
OK
+CME ERROR: <err>
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 45 / 58
Parameter
Example
AT+NSOST=0,192.158.5.1,1024,2,AB30
0,2
OK
Neul Hi2110 Implementation
- Maximum data size is 512 bytes.
- Only IPv4 is supported.
- <data>: only hex string format is supported.
- IP addresses can be specified in decimal, octal or hexadecimal notation.
4.13. AT+NSORF Receive Command (UDP Only)
Read up to <req_length> characters of data from <socket>, and returned length is the actual number of
characters returned.
Receive data on a socket. When data arrives a +NSONMI response will be generated to indicate the
socket the message was received on and also the amount of data. The +NSORF command takes a length,
which is the maximum amount of data that will be returned.
If the requested length is larger than the actual size of the returned data, only the length of returned data
is provided, and the remaining length is returned as 0. If the requested length is less than the amount of
data returned, only the requested amount of data will be returned, plus an indication of the number of
bytes remaining. Once a message has been fully read, a new +NSONMI notification will be sent if there is
another message to process. Refer to Chapter 6 for possible <err> values.
If messages arrive faster than they are read, and the internal message buffer is full, the most recent
message will be discarded.
<socket> Socket number returned by +NSOCR
<remote_addr> IPv4 A dot notation IP address
<remote_port> A number in the range 0-65535. This is the remote port on which messages will be
received
<length> Decimal length of data to be sent
<data> Data received in hex string format, or quoted string format
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 46 / 58
Parameter
Example
AT+NSORF=0,10
0,192.168.5.1,1024,2,ABAB,0
OK
Neul Hi2110 Implementation
- Maximum data size is 512 bytes.
- Only IPv4 is supported.
- Remaining length is always 0. The remaining data is readable.
4.14. AT+NSOCL Close Socket
Close the specified socket. If there are pending messages to be read, they will be dropped. No further
unsolicited +NSONMI notifications will be generated. If the socket has already been closed, or was never
created, an error will be returned.
AT+NSORF Receive Command (UDP Only)
Set Command
AT+NSORF=<socket>,<req_length>
Response
<socket>,<ip_addr>,<port>,<length>,<data>,<remaining_
length>
OK
+CME ERROR: <err>
<socket> Socket number returned by +NSOCR
<req_length> Maximum amount of data to be returned as a decimal byte length.
<ip_addr> Address of system sending the message
IPv4 A dot notation IP address
<port> A number in the range 0-65535. This is the remote port that messages was sent
from
<length> Amount of data returned as a decimal byte length
<remaining_length> Amount of data left to read for this message as a decimal byte length
<data> Data received in hex string format, or quoted string format.
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 47 / 58
Parameter
Example
AT+NSOCL=0
OK
4.15. +NSONMI Socket Message Arrived Indicator (Response Only)
Unsolicited message to notify that data has been received on a socket and is ready to be read. This
command returns socket number and number of bytes of data available to read for the first message that
is queued. If another message is received on the same socket, it will only be notified when the preceding
message has been completely read. Refer to Chapter 6 for possible <err> values.
Parameter
Neul Hi2110 Implementation
- Maximum data size is 512 bytes.
- This message can occur at any point if it is indicating a new message with no messages buffered. If
there are buffered messages it will occur in the AT+NSORF command before the data is returned.
AT+NSOCL Close Socket
Set Command
AT+NSOCL=<socket>
Response
OK
+CME ERROR: <err>
<socket> Socket number returned by +NSOCR
+NSONMI Socket Message Arrived Indicator (Response Only)
Command
+NSONMI:
Response
<socket>,<length>
<socket> Socket on which data is received. Decimal number returned by +NSOCR
<length> Number of bytes of data in the first message
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 48 / 58
4.16. AT+NPING Test IP Network Connectivity To A Remote Host
This command sends an ICMP packet to the specified host address. Refer to Chapter 6 for possible
<err> values.
AT+NPING initiates the sending of a PING packet to the specified address. This will either cause a packet
to be returned if the remote system is connected and responding to PING packets or no response will be
received. A maximum of 1 ping attempts will be tried. If none of the packets receive a response within the
timeout period, an error will be raised.
If a response is received, the unsolicited +NPING message will be returned. If no response is received the
+NPINGERR unsolicited response will be returned with an error value.
Parameter
Neul Hi2110 Implementation
- IP addresses can be specified in decimal, octal or hexadecimal notation.
4.17. AT+NBAND Set Supported Bands
This command restricts the set of bands to be used. Refer to Chapter 6 for possible <err> values.
AT+NPING Test IP Network Connectivity To A Remote Host
Set Command
AT+NPING=<remote_address>
Response
OK
+NPING:<retry_num>,<remote_address>,<ttl>,<rtt>
Else
+NPINGERR: <err>
<remote_address> Address of system sending the message
IPv4 A dot notation IP address
<retry_num> Number of packets sent before a response was received
<ttl> TTL in the response packet
<rtt> Elapsed time in msec from packet sent to response received
<err> An integer value to provide some information on why the ping request failed
1 No response from remote host within timeout period
2 Failed to send ping request
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 49 / 58
Parameter
Neul Hi2110 Implementation
- Only bands 5, 8 & 20 are supported initially.
- AT+NBAND=? does not return the list of supported bands.
4.18. AT+NLOGLEVEL Set Debug Logging Level
This command sets the logging level. It can take one of the following values. The default logging level is
NONE. And the value is persistent across reboots.
AT+NBAND Set Supported Bands
Set Command
AT+NBAND=n[,n[,n[…]]]
Response
OK
+CME ERROR: <err>
Read Command
AT+NBAND?
Response
+NBAND: n[,n[,n[…]]]
OK
Execute Command
AT+NBAND=?
Response
+NBAND: (n[,n[,n[…]]])
OK
<n> Band as a decimal number
AT+NLOGLEVEL Set Debug Logging Level
Set Command
AT+NLOGLEVEL=<core>,<level>
Response
OK
+CME ERROR: <err>
Read Command
AT+NLOGLEVEL?
Response
+NLOGLEVEL: <core>,<level>
OK
Execute Command
AT+NLOGLEVEL=?
Response
+NLOGLEVEL: (<core>, …),(<level>,<level>, …)
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 50 / 58
Parameter
Neul Hi2110 Implementation
- Logging level is not persistent.
- Application and Security core logging are not supported.
4.19. AT+NCONFIG Configure UE Behaviour
This command allows configuring certain aspects of UE behavior. It takes a function and a value that
controls operation of that function.
OK
<level> Logging level required
VERBOSE
CUSTOM
NORMAL
WARNING
ERROR
NONE
<core> PROTOCOL
APPLICATION
SECURITY
AT+NCONFIG Configure UE Behaviour
Set Command
AT+NCONFIG=<function>,<value>
Response
OK
+CME ERROR: <err>
Read Command
AT+NCONFIG?
Response
+NCONFIG:<function>,<value>
[+NCONFIG:<function>,<value>
[…]]
OK
Execute Command
AT+NCONFIG=?
Response
+NCONFIG:(<function>,(<value1>,<value2>[,<value3>[,…
]]))
[+NCONFIG:(<function>,(<value1>,<value2>[,<value3>[,
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 51 / 58
Parameter
…]]))
[,…]]
OK
<function> UE function to configure
AUTOCONNECT: Control whether the platform will automatically attempt to
connect to the network after power-on or reboot. When enabled, it will set
+CFUN=1 and read the PLMN from the SIM. And it will use the APN provided
by the network.
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 52 / 58
5 Temporary Commands
As part of development, some commands are temporarily added. They are unsupported and may
disappear, or change behaviour, without warning. They are listed here for completeness.
5.1. AT+NTSETID Set ID
Set system identities such as UUID or IMEI value. This is a temporary command that will be replaced with
a production tool.
Parameter
Example
AT+NTSETID=1,123456789012345
OK
Neul Hi2110 Implementation
- IMEI is persistent.
- SVN is not persistent and will default to 0x00.
- IMEI can only be set when the radio is inactive (AT+CFUN=0 will force the module to enter into this
state).
AT+NTSETID Set ID
Set Command
AT+NTSETID=<snt>,<data>
Response
OK
+CME ERROR: <err>
<snt> Integer type indicating the serial number type that has been requested
1 Set the IMEI
2 SVN
<data> If <snt>=1 IMEI 15-character string type in decimal format
If <snt>=2 SVN 2 digit SVN
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 53 / 58
6 Error Values
The error codes listed below are not implemented, and only a subset will be implemented.
In B600 and later, the +CMEE command is implemented and supports modes 0 & 1. In mode 1 a limited
set of error codes are returned.
Error codes are aligned to the 3GPP spec. Refer to 3GPP TS 27.007 V13.5.0, sub-clause 9.2 for all
possible <err> values. The error codes listed are those returned for the Hi2110 implementation.
Error codes 0-255 are reserved and defined in 3GPP TS 27.007 and may be used by Neul in future
releases.
Table 3: Error Values
Error Code
Error Text
3
Operation not allowed
4
Operation not supported
23
Memory failure
32
Flow control
50
Incorrect parameters
159
Uplink busy
256
Required parameter not configured
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 54 / 58
7 Examples
7.1. Attach Network
The module can automatically attach network by default in B650 version, which is controlled by
AT+NCONFIG=AUTOCONN,TRUE command. If you want to manually attach the network, please
execute AT+NCONFIG=AUTOCONNECT, FALSE to disable automatic attachment. This value will be
saved to NV and take effect after restarting the module.
The following shows a simple example to manually attach the network.
Neul //Module is powered on, wait for 3 seconds.
OK
AT+CGSN=1 //Query the IMEI number. If only ERROR is returned, you
need to write the IMEI.
+CGSN: 863703030104298
OK
AT+CFUN=1 //Configure the level of functionality in the MT.
OK
AT+CIMI //Query the IMSI and wait for 4 seconds after executing
AT+CFUN=1.
460012345678966
OK
AT+NBAND? //Query the band information, set BC95-CM/B8 to BAND 8,
BC95-SL/B5 to BAND 5, and BC95-VF/B20 to BAND 20.
Execute AT+NBAND=n to set the frequency band. It will take
effect after restart.
+NBAND:8
OK
AT+CGDCONT=1,“IP”,“HUAWEI.COM” //Configuration PDP.
OK
AT+CGATT=1 //Activate the network.
OK
AT+CSQ //Query current signal quality.
+CSQ:31,99
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 55 / 58
OK
AT+CGATT? //Query whether network is activated, +CGATT:1 means
activated successfully. And wait for some time.
+CGATT:1
OK
AT+CEREG? //Query current EPS network registration status: Registered.
+CEREG:0,1
OK
AT+CSCON? //Query the signaling connection status, 1 means CONNECT, 0
means IDLE.
+CSCON:0,1
OK
7.2. CoAP Messages
The following is a simple example of sending, receiving and reading a CoAP message.
AT+NCDP=192.53.100.53 //Configuration CDP server. This command must be
executed after executing AT+CFUN=0.
OK
AT+NCDP? //Query CDP server
+NCDP:192.53.100.53,5683
OK
AT+NSMI=1 //Turn on the sent message indications.
OK
AT+NNMI=2 //Turn on the new message indications when a
downstream message is received by the terminal from
the CDP server.
OK
AT+NMGS=10, AA7232088D0320623399 //Send messages.
OK
+NSMI:SENT //Message is sent.
AT+NQMGS //Query whether messages is sent successfully.
PENDING=0,SEND=1,ERROR=0
OK
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 56 / 58
+NNMI //Receive a downstream message.
AT+NQMGR //Query whether messages is received.
BUFFERED=1,RECEIVED=0,DROPPED=0
OK
AT+NMGR //Get messages.
2,AABB
OK
AT+NQMGR //Query whether messages is received.
BUFFERED=0,RECEIVED=1,DROPPED=0
OK
7.3. UDP Messages
The following shows a simple example of sending, receiving and reading a UDP message. Once the
socket is closed, no replies will be received.
AT+NSOCR= DGRAM,17,5683,1 //Create socket
0
OK
AT+NSOST=0,192.53.100.53,5683,25,400241C7B17401724D0265703D323031363038323331363438
//Send messages
0,25
OK
+NSONMI:0,4 //Receive messages
AT+NSORF=0,4 //Read messages
0,192.53.100.53,5683,4,60A041C7,0
OK
AT+NSOCL=0 //Close socket
OK
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 57 / 58
8 Appendix A Reference
Table 4: Terms and Abbreviations
Abbreviation
Description
APN
Access Point Name
CDP
Connected Device Platform
CS
Circuit Switched
DCE
Data Communication Equipment
EGPRS
Enhanced General Packet Radio Service
GPRS
General Packet Radio Service
GERAN
GSM/EDGE Radio Access Network
HPLMN
Home Public Land Mobile Network
HSDPA
High Speed Downlink Packet Access
HSUPA
High-Speed Uplink Packet Access
IMEI
International Mobile Equipment Identity
IMEISV
International Mobile Equipment Identity and Software Version
ICMP
Internet Control Messages Protocol
MS
Mobile Station
NB-IoT
Narrow Band-Internet of Thing
PDP
Packet Data Protocol
RRC
Radio Resource Control
SVN
Software Version Number
TA
Terminal Adapter
Quectel
Confidential
NB-IoT Module Series
BC95 AT Commands Manual
BC95_AT_Commands_Manual Confidential / Released 58 / 58
TCP
Transmission Control Protocol
TE
Terminal Equipment
TTL
Time To Live
UDP
User Datagram Protocol
UE
User Equipment
UICC
Universal Integrated Circuit Card
UUID
Universally Unique Identifier
Quectel
Confidential

Navigation menu
