Configuring Remote Desktop Features in Horizon 7

Conﬁguring Remote Desktop Features

in Horizon 7

VMware Horizon 7 7.2

This document supports the version of each product listed and

supports all subsequent versions until the document is

replaced by a new edition. To check for more recent editions of

this document, see http://www.vmware.com/support/pubs.

EN-002454-00-00

Configuring Remote Desktop Features in Horizon 7

2 VMware, Inc.

You can ﬁnd the most up-to-date technical documentation on the VMware Web site at:

hp://www.vmware.com/support/

The VMware Web site also provides the latest product updates.

If you have comments about this documentation, submit your feedback to:

docfeedback@vmware.com

VMware, Inc.

3401 Hillview Ave.

Palo Alto, CA 94304

www.vmware.com

Contents

1Conguring Remote Desktop Features in Horizon 7 5

2Conguring Remote Desktop Features 7

Conguring Unity Touch 7

Conguring Flash URL Redirection for Multicast or Unicast Streaming 10

Conguring Flash Redirection 14

Conguring Real-Time Audio-Video 20

Conguring Scanner Redirection 33

Conguring Serial Port Redirection 38

Managing Access to Windows Media Multimedia Redirection (MMR) 45

Managing Access to Client Drive Redirection 47

Congure Skype for Business 49

3Conguring URL Content

Redirection 53

Understanding URL Content Redirection 53

Requirements for URL Content Redirection 54

Using URL Content Redirection in a Cloud Pod Architecture Environment 54

Installing Horizon Agent with the URL Content Redirection Feature 54

Conguring Agent-to-Client Redirection 55

Conguring Client-to-Agent Redirection 58

URL Content Redirection Limitations 67

Unsupported URL Content Redirection Features 67

4Using USB Devices with Remote Desktops and Applications 69

Limitations Regarding USB Device Types 70

Overview of Seing Up USB Redirection 71

Network Trac and USB Redirection 72

Automatic Connections to USB Devices 72

Deploying USB Devices in a Secure Horizon 7 Environment 73

Using Log Files for Troubleshooting and to Determine USB Device IDs 75

Using Policies to Control USB Redirection 76

Troubleshooting USB Redirection Problems 86

5Conguring Policies for Desktop and Application

Pools 89

Seing Policies in Horizon Administrator 89

Using Smart Policies 91

Using Active Directory Group Policies 97

Using Horizon 7 Group Policy Administrative Template Files 98

Horizon 7 ADMX Template Files 98

VMware, Inc. 3

Add the ADMX Template Files to Active Directory 100

Horizon Agent Conguration ADMX Template Seings 100

PCoIP Policy Seings 110

VMware Blast Policy Seings 124

Using Remote Desktop Services Group Policies 128

Seing Up Location-Based Printing 163

Active Directory Group Policy Example 168

6Active Directory Group Policy Example 173

Create an OU for Horizon 7 Machines 173

Create GPOs for Horizon 7 Group Policies 174

Add Horizon 7 ADMX Template File to a GPO 175

Enable Loopback Processing for Remote Desktops 175

Index 177

Configuring Remote Desktop Features in Horizon 7

4 VMware, Inc.

Configuring Remote Desktop

Features in Horizon 7 1

Conguring Remote Desktop Features in Horizon 7 describes how to congure remote desktop features that are

installed with Horizon Agent on virtual machine desktops or on an RDS host. You can also congure

policies to control the behavior of desktop and application pools, machines, and users.

Intended Audience

This information is intended for anyone who wants to congure remote desktop features or policies on

virtual machine desktops or RDS hosts. The information is wrien for Windows system administrators who

are familiar with virtual machine technology and data center operations.

VMware, Inc. 5

Configuring Remote Desktop Features in Horizon 7

6 VMware, Inc.

Configuring Remote Desktop

Features 2

Certain remote desktop features that are installed with Horizon Agent can be updated in Feature Pack

Update releases as well as in core Horizon 7 releases. You can congure these features to enhance the remote

desktop experience of your end users.

These features include HTML Access, Unity Touch, Flash URL Redirection, Real-Time Audio-Video,

Windows Media Multimedia Redirection (MMR), USB Redirection, Scanner Redirection, and Serial Port

Redirection.

For information about HTML Access, see the Using HTML Access document, located on

theVMware Horizon Client Documentation Web page.

For information about USB Redirection, see Chapter 4, “Using USB Devices with Remote Desktops and

Applications,” on page 69.

This chapter includes the following topics:

n“Conguring Unity Touch,” on page 7

n“Conguring Flash URL Redirection for Multicast or Unicast Streaming,” on page 10

n“Conguring Flash Redirection,” on page 14

n“Conguring Real-Time Audio-Video,” on page 20

n“Conguring Scanner Redirection,” on page 33

n“Conguring Serial Port Redirection,” on page 38

n“Managing Access to Windows Media Multimedia Redirection (MMR),” on page 45

n“Managing Access to Client Drive Redirection,” on page 47

n“Congure Skype for Business,” on page 49

Configuring Unity Touch

With Unity Touch, tablet and smart phone users can easily browse, search, and open Windows applications

and les, choose favorite applications and les, and switch between running applications, all without using

the Start menu or Taskbar. You can congure a default list of favorite applications that appear in the Unity

Touch sidebar.

You can disable or enable the Unity Touch feature after it is installed by conguring the Enable Unity Touch

group policy seing.

The VMware Horizon Client documents for iOS and Android devices provide more information about end

user features provided by Unity Touch.

VMware, Inc. 7

System Requirements for Unity Touch

Horizon Client software and the mobile devices on which you install Horizon Client must meet certain

version requirements to support Unity Touch.

Horizon 7 desktop To support Unity Touch, the following software must be installed in the

virtual machine that the end user will access:

nYou install the Unity Touch feature by installing View Agent 6.0 or later.

See "Install View Agent on a Virtual Machine" in the Seing Up Virtual

Desktops in Horizon 7 document.

nOperating systems: Windows 7 (32-bit or 64-bit), Windows 8 (32-bit or

64-bit), Windows 8.1 (32-bit or 64-bit), Windows Server 2008 R2, or

Windows Server 2012 R2, Windows 10 (32-bit or 64-bit)

Horizon Client software Unity Touch is supported on the following Horizon Client versions:

nHorizon Client 2.0 for iOS or later

nHorizon Client 2.0 for Android or later

Mobile device operating

systems

Unity Touch is supported on the following mobile device operating systems:

niOS 5.0 and later

nAndroid 3 (Honeycomb), Android 4 (Ice Cream Sandwich), and

Android 4.1 and 4.2 (Jelly Bean)

Configure Favorite Applications Displayed by Unity Touch

With the Unity Touch feature, tablet and smart phone users can quickly navigate to a Horizon 7 desktop

application or le from a Unity Touch sidebar. Although end users can specify which favorite applications

appear in the sidebar, for added convenience, administrators can congure a default list of favorite

applications.

If you use oating-assignment desktop pools, the favorite applications and favorite les that end users

specify will be lost when they disconnect from a desktop unless you enable roaming user proles in Active

Directory.

The default list of favorite applications list remains in eect when an end user rst connects to a desktop

that is enabled with Unity Touch. However, if the user congures his or her own favorite application list, the

default list is ignored. The user's favorite application list stays in the user's roaming prole and is available

when the user connects to dierent machines in a oating or dedicated pool.

If you create a default list of favorite applications and one or more of the applications are not installed in the

Horizon 7 desktop operating system, or the paths to these applications are not found in the Start menu, the

applications do not appear in the list of favorites. You can use this behavior to set up one master default list

of favorite applications that can be applied to multiple virtual machine images with dierent sets of

installed applications.

For example, if Microsoft Oce and Microsoft Visio are installed on one virtual machine, and Windows

Powershell and VMware vSphere Client are installed on a second virtual machine, you can create one list

that includes all four applications. Only the installed applications appear as default favorite applications on

each respective desktop.

You can use dierent methods to specify a default list of favorite applications:

nAdd a value to the Windows registry on the virtual machines in the desktop pool

Configuring Remote Desktop Features in Horizon 7

8 VMware, Inc.

nCreate an administrative installation package from the Horizon Agent installer and distribute the

package to the virtual machines

nRun the Horizon Agent installer from the command line on the virtual machines

N Unity Touch assumes that shortcuts to applications are located in the Programs folder in the Start

menu. If any shortcut is located outside of the Programs folder, aach the prex Programs to the shortcut

path. For example, Windows Update.lnk is located in the ProgramData\Microsoft\Windows\Start Menu folder.

To publish this shortcut as a default favorite application, add the prex Programs to the shortcut path. For

example: "Programs/Windows Update.lnk".

Prerequisites

nVerify that Horizon Agent is installed on the virtual machine.

nVerify that you have administrative rights on the virtual machine. For this procedure, you might need

to edit a registry seing.

nIf you have oating-assignment desktop pools, use Active Directory to set up roaming user proles.

Follow the instructions provided by Microsoft.

Users of oating-assignment desktop pools will be able to see their list of favorite applications and

favorite les every time they log in.

Procedure

n(Optional) Create a default list of favorite applications by adding a value to the Windows registry.

a Open regedit and navigate to the HKLM\Software\VMware, Inc.\VMware Unity registry seing.

On a 64-bit virtual machine, navigate to the HKLM\Software\Wow6432Node\VMware, Inc.\VMware

Unity directory.

b Create a string value called FavAppList.

c Specify the default favorite applications.

Use the following format to specify the shortcut paths to the applications that are used in the Start

menu.

path-to-app-1|path-to-app-2|path-to-app-3|…

For example:

Programs/Accessories/Accessibility/Speech Recognition.lnk|Programs/VMware/VMware vSphere

Client.lnk|Programs/Microsoft Office/Microsoft Office 2010 Tools/Microsoft Office 2010

Language Preferences.lnk

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 9

n(Optional) Create a default list of favorite applications by creating an administrative installation

package from the Horizon Agent installer.

a From the command line, use the following format to create the administrative installation package.

VMware-viewagent-x86_64-y.y.y-xxxxxx.exe /s /a /v"/qn TARGETDIR=""a network share to

store the admin install package"" UNITY_DEFAULT_APPS=""the list of default favorite apps

that should be set in the registry"""

For example:

VMware-viewagent-x86_x64-y.y.y-xxxxxx.exe /s /a /v"/qn TARGETDIR=""\\foo-installer-

share\ViewFeaturePack\"" UNITY_DEFAULT_APPS=""Programs/Accessories/Accessibility/Ease of

Access.lnk|Programs/Accessories/System Tools/Character Map.lnk|

Programs/Accessories/Windows PowerShell/Windows PowerShell.lnk|Programs/Internet

Explorer (64-bit).lnk|Programs/Google Chrome/Google Chrome.lnk|

Programs/iTunes/iTunes.lnk|Programs/Microsoft Office/Microsoft SharePoint Workspace

2010.lnk|Programs/PuTTY/PuTTY.lnk|Programs/Skype/Skype.lnk|Programs/WebEx/Productivity

Tools/WebEx Settings.lnk|"""

b Distribute the administrative installation package from the network share to the desktop virtual

machines by using a standard Microsoft Windows Installer (MSI) deployment method that is

employed in your organization.

n(Optional) Create a default list of favorite applications by running the Horizon Agent installer on a

command line directly on a virtual machine.

Use the following format.

VMware-viewagent-x86_x64-y.y.y-xxxxxx.exe /s /v"/qn UNITY_DEFAULT_APPS=""the list of default

favorite apps that should be set in the registry"""

N The preceding command combines installing Horizon Agent with specifying the default list of

favorite applications. You do not have to install Horizon Agent before you run this command.

What to do next

If you performed this task directly on a virtual machine (by editing the Windows registry or installing

Horizon Agent from the command line), you must deploy the newly congured virtual machine. You can

create a snapshot or make a template and create a desktop pool, or recompose an existing pool. Or you can

create an Active Directory group policy to deploy the new conguration.

Configuring Flash URL Redirection for Multicast or Unicast Streaming

Customers can now use Adobe Media Server and multicast or unicast to deliver live video events in a

virtual desktop infrastructure (VDI) environment. To deliver multicast or unicast live video streams within a

VDI environment, the media stream should be sent directly from the media source to the endpoints,

bypassing the remote desktops. The Flash URL Redirection feature supports this capability by intercepting

and redirecting the ShockWave Flash (SWF) le from the remote desktop to the client endpoint.

The Flash content is then displayed using the clients' local Flash media players.

Streaming Flash content directly from the Adobe Media Server to the client endpoints lowers the load on the

datacenter ESXi host, removes the extra routing through the datacenter, and reduces the bandwidth

required to simultaneously stream Flash content to multiple client endpoints.

Configuring Remote Desktop Features in Horizon 7

10 VMware, Inc.

The Flash URL redirection feature uses a JavaScript that is embedded inside an HTML Web page by the Web

page administrator. Whenever a remote desktop user clicks on the designated URL link from within a Web

page, the JavaScript intercepts and redirects the SWF le from the remote desktop session to the client

endpoint. The endpoint then opens a local Flash Projector outside of the remote desktop session and plays

the media stream locally.

To congure Flash URL Redirection, you must set up your HTML Web page and your client devices.

Procedure

1System Requirements for Flash URL Redirection on page 11

To support Flash URL Redirection, your Horizon 7 deployment must meet certain software and

hardware requirements.

2Verify that the Flash URL Redirection Feature Is Installed on page 12

Before you use this feature, verify that the Flash URL Redirection feature is installed and running on

your virtual desktops.

3Set Up the Web Pages That Provide Multicast or Unicast Streams on page 13

To allow Flash URL redirection to take place, you must embed a JavaScript command in the MIME

HTML (MHTML) Web pages that provide links to the multicast or unicast streams. Users display

these Web pages in the browsers on their remote desktops to access the video streams.

4Set Up Client Devices for Flash URL Redirection on page 13

The Flash URL Redirection feature redirects the SWF le from remote desktops to client devices. To

allow these client devices to play Flash videos from a multicast or unicast stream, you must verify that

the appropriate Adobe Flash Player is installed on the client devices. The clients also must have IP

connectivity to the media source.

5Disable or Enable Flash URL Redirection on page 14

Flash URL Redirection is enabled when you perform a silent installation of Horizon Agent with the

VDM_FLASH_URL_REDIRECTION=1 property. You can disable or reenable the Flash URL Redirection feature

on selected remote desktops by seing a value on a Windows registry key on those virtual machines.

System Requirements for Flash URL Redirection

To support Flash URL Redirection, your Horizon 7 deployment must meet certain software and hardware

requirements.

Horizon 7 desktop nYou install Flash URL Redirection by typing the

VDM_FLASH_URL_REDIRECTION property on the command line during a

silent installation of View Agent 6.0 or later. See "Silent Installation

Properties for Horizon Agent" in the Seing Up Virtual Desktops in

Horizon 7 document.

nThe desktops must run Windows 7 64-bit or 32-bit operating systems.

nSupported desktop browsers include Internet Explorer 8, 9, and 10,

Chrome 29.x, and Firefox 20.x.

Flash media player and

ShockWave Flash (SWF)

You must integrate an appropriate Flash media player such as Strobe Media

Playback into your Web site. To stream multicast content, you can use

multicastplayer.swf or StrobeMediaPlayback.swf in your Web pages. To

stream live unicast content, you must use StrobeMediaPlayback.swf. You can

also use StrobeMediaPlayback.swf for other supported features such as

RTMP streaming and HTTP dynamic streaming.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 11

Horizon Client software The following Horizon Client releases support multicast and unicast:

nHorizon Client 2.2 for Linux or a later release

nHorizon Client 2.2 for Windows or a later release

The following Horizon Client releases support multicast only (they do not

support unicast):

nHorizon Client 2.0 or 2.1 for Linux

nHorizon Client 5.4 for Windows

Horizon Client computer

or client access device

nFlash URL Redirection is supported on all operating systems that run

Horizon Client for Linux on x86 Thin client devices. This feature is not

supported on ARM processors.

nFlash URL Redirection is supported on all operating systems that run

Horizon Client for Windows. For details, see the Using

VMware Horizon Client for Windows document.

nOn Windows client devices, you must install Adobe Flash Player 10.1 or

later for Internet Explorer.

nOn Linux Thin client devices, you must install the libexpat.so.0 and

libflashplayer.so les. See “Set Up Client Devices for Flash URL

Redirection,” on page 13.

N With Flash URL Redirection, the multicast or unicast stream is

redirected to client devices that might be outside your organization's rewall.

Your clients must have access to the Adobe Web server that hosts the

ShockWave Flash (SWF) le that initiates the multicast or unicast streaming.

If needed, congure your rewall to open the appropriate ports to allow

client devices to access this server.

Verify that the Flash URL Redirection Feature Is Installed

Before you use this feature, verify that the Flash URL Redirection feature is installed and running on your

virtual desktops.

The Flash URL Redirection feature must be present on every desktop where you intend to support multicast

or unicast redirection. For Horizon Agent installation instructions, see "Silent Installation Properties for

Horizon Agent" in the Seing Up Virtual Desktops in Horizon 7 document.

Procedure

1 Start a remote desktop session that uses PCoIP.

2 Open the Task Manager.

3 Verify that the ViewMPServer.exe process is running on the desktop.

Configuring Remote Desktop Features in Horizon 7

12 VMware, Inc.

Set Up the Web Pages That Provide Multicast or Unicast Streams

To allow Flash URL redirection to take place, you must embed a JavaScript command in the MIME HTML

(MHTML) Web pages that provide links to the multicast or unicast streams. Users display these Web pages

in the browsers on their remote desktops to access the video streams.

In addition, you can customize the English error message that is displayed to end users when a problem

occurs with Flash URL redirection. Take this optional step if you want to display a localized error message

to your end users. You must embed the var vmwareScriptErroMessage conguration, together with your

localized text string, in the MHTML Web page.

Prerequisites

Verify that the swfobject.js library is imported in the MHTML Web page.

Procedure

1 Embed the viewmp.js JavaScript command in the MHTML Web page.

For example: <script type="text/javascript" src="http://localhost:33333/viewmp.js"></script>

2 (Optional) Customize the Flash URL redirection error message that is sent to end users.

For example: "var vmwareScriptErroMessage=localized error message"

3 Make sure to embed the viewmp.js JavaScript command, and optionally customize the Flash URL

redirection error message, before the ShockWave Flash (SWF) le is imported into the MHTML Web

page.

When a user displays the Web page in a remote desktop, the viewmp.js JavaScript command invokes the

Flash URL Redirection mechanism on the remote desktop, which redirects the SWF le from the desktop to

the hosting client device.

Set Up Client Devices for Flash URL Redirection

The Flash URL Redirection feature redirects the SWF le from remote desktops to client devices. To allow

these client devices to play Flash videos from a multicast or unicast stream, you must verify that the

appropriate Adobe Flash Player is installed on the client devices. The clients also must have IP connectivity

to the media source.

N With Flash URL Redirection, the multicast or unicast stream is redirected to client devices that might

be outside your organization's rewall. Your clients must have access to the Adobe Web server that hosts the

SWF le that initiates the multicast or unicast streaming. If needed, congure your rewall to open the

appropriate ports to allow client devices to access this server.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 13

Procedure

uInstall Adobe Flash Player on your client devices.

Operating System Action

Windows Install Adobe Flash Player 10.1 or later for Internet Explorer.

Linux aInstall the libexpat.so.0 le, or verify that this le is already

installed.

Ensure that the le is installed in the /usr/lib or /usr/local/lib

directory.

bInstall the libflashplayer.so le, or verify that this le is already

installed.

Ensure that the le is installed in the appropriate Flash plug-in

directory for your Linux operating system.

cInstall the wget program, or verify that the program le is already

installed.

Disable or Enable Flash URL Redirection

Flash URL Redirection is enabled when you perform a silent installation of Horizon Agent with the

VDM_FLASH_URL_REDIRECTION=1 property. You can disable or reenable the Flash URL Redirection feature on

selected remote desktops by seing a value on a Windows registry key on those virtual machines.

Procedure

1 Start the Windows Registry Editor on the virtual machine.

2 Navigate to the Windows registry key that controls Flash URL Redirection.

Option Description

Windows 7 64-bit HKEY_LOCAL_MACHINE\Software\Wow6432Node\VMware,Inc.\VMware

ViewMP\enabled = value

Windows 7 32-bit HKEY_LOCAL_MACHINE\Software\VMware,Inc.\VMware

ViewMP\enabled = value

3 Set the value to disable or enable Flash URL Redirection.

Option Value

Disabled 0

Enabled 1

By default, the value is set to 1.

Configuring Flash Redirection

With the Flash Redirection feature, Flash content is sent to the client system and played in a Flash container

window using the Flash Player ActiveX version.

N In Horizon 7.0, Flash Redirection is a Tech Preview feature. In Horizon 7.0.1, it is fully supported.

Although the name of this feature is similar to the feature called Flash URL Redirection, there are important

dierences, as described in the following table.

Configuring Remote Desktop Features in Horizon 7

14 VMware, Inc.

Table 2‑1. Comparison of the Flash Redirection Feature and Flash URL Redirection

Item of Differentiation Flash Redirection Flash URL Redirection

Support level A Tech Preview feature in Horizon 7.0

with no technical support. Fully

supported in Horizon 7.0.1.

Fully supported

Horizon Client types that

support this feature

Windows client only Windows client and Linux client

Display protocol In Horizon 7.0, PCoIP only. In

Horizon 7.0.1, PCoIP and VMware

Blast.

PCoIP

Browsers Internet Explorer 9, 10, or 11 for the

agent (remote desktop)

All browsers that are currently supported on

Horizon Client and Horizon Agent

Conguration mechanism Use an agent-side GPO to specify a

white list or black list of Web sites that

will or will not use Flash Redirection

Modify the source code on the Web page to

embed the required JavaScript

Feature Limitations

The Flash Redirection feature has the following limitations:

nClicking a URL link inside the Flash Player window opens a browser on the client rather than in the

remote desktop (agent side).

nSome Web sites do not work with Flash Redirection on some browser versions. For example, the

vimeo.com Web site does not work if you use Internet Explorer 11.

nIn Horizon 7.0, Flash and Java scripting might not work as expected.

nThe Horizon Client window might freeze while playing Flash content, although you can set a Windows

Registry key to work around this issue.

On a 32-bit client, set HKLM\Software\VMware, Inc.\VMware VDM\Client\EnableD3DRenderer value to

"FALSE" and on a 64-bit client, set HKLM\SOFTWARE\Wow6432Node\VMware, Inc.\VMware

VDM\Client\EnableD3DRenderer to "FALSE".

nFor the YouTube Web site, external interface is disabled by default to avoid playback issues. Therefore,

the following functionalities do not work: Autoplay, the Next and Previous buons, and Theater mode.

To enable Flash media for the latest update of the YouTube Web site, you must remove youtube.com

from the Compatibility View  and manually append &nohtml5=1 to the URL for the video. For

example, https://www.youtube.com/watch?v=NwmRD25HWGE&nohtml5=1.

nYou cannot click on recommended videos on the YouTube site unless you set appMode=1 as a Windows

registry key on the remote desktop.

nIf there is no audio device on the client, errors will happen when playing YouTube Flash media.

nFlash Redirection does not work for redbox.com.

nThe Flash context menu (activated by a right click) is disabled.

nIf a version 4.1 of Horizon Client connects to a Horizon 7.0 desktop with PCoIP, Flash Redirection will

fail. The Flash content is either played by the desktop's native player or the user will see a white screen.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 15

System Requirements for Flash Redirection

With Flash Redirection, if you use Internet Explorer 9, 10, or 11, Flash content is sent to the client system.

The client system plays the media content, which reduces the load on the ESXi host.

Remote desktop nHorizon Agent 7.0 or later must be installed in a single-user (VDI)

remote desktop, with the Flash Redirection option. The Flash

Redirection option is not selected by default.

See " Horizon Agent Custom Setup Options" in the Seing Up Virtual

Desktops in Horizon 7 document.

nThe appropriate group policy seings must be congured. See “Install

and Congure Flash Redirection,” on page 16.

nFlash Redirection is supported on Windows 7, Windows 8, Windows 8.1,

and Windows 10 single-user remote desktops.

nInternet Explorer 9, 10, or 11 must be installed with the corresponding

Flash ActiveX plug-in.

nAfter installation, the VMware View FlashMMR Server add-on must be

enabled in Internet Explorer.

Horizon Client computer

or client access device

nHorizon Client 4.0 or later must be installed. The Flash Redirection

option is enabled by default.

See the topic about installing Horizon Client in the Using VMware

Horizon Client for Windows document.

nFlash Redirection is supported on Windows 7, Windows 8, Windows 8.1,

and Windows 10.

nThe Flash ActiveX plug-in must be installed and enabled

Display protocol for the

remote session

VMware Blast, PCoIP

Install and Configure Flash Redirection

Redirecting Flash content from a remote desktop to a Flash Player window on the local client system

requires installing the Flash Redirection feature and Internet Explorer on the remote desktop and the client

system and specifying which Web sites will use this feature.

To install this feature on the client system, you must use a Horizon Client 4.0 or later installer. To install this

feature on a remote desktop, you must use a Horizon Agent 7.0 or later installer and select the correct

installation option, which is not selected by default. To enable this feature and to specify which Web sites

will use this feature, you use a group policy.

N You can alternatively use Windows Registry seings on the remote desktop to congure a white list

of Web sites to use for Flash Redirection. See “Use Windows Registry Seings to Congure Flash

Redirection,” on page 18.

Prerequisites

nVerify that you can log in as an Administrator domain user on the machine that hosts your Active

Directory server.

nVerify that the MMC and the Group Policy Object Editor snap-in are available on your Active Directory

server.

Configuring Remote Desktop Features in Horizon 7

16 VMware, Inc.

nVerify that the Horizon Agent Conguration ADMX template le vdm_agent.admx le has been added to

the OU for the remote desktop.

nCompile a list of the Web sites that can or cannot redirect Flash content. Compile a white list to ensure

that only the URLs specied in the list will be able to redirect Flash content. Compile a black list to

ensure that the URLs specied in the list will not be able to redirect Flash content.

nVerify that Flash ActiveX is installed and works properly. To verify the installation, run Internet

Explorer and go to hps://helpx.adobe.com/ash-player.html.

Procedure

1 On a Windows 7, Windows 8, Windows 8.1, or Windows 10 client system, install the required version of

Horizon Client and Flash Player ActiveX version.

nInstall Horizon Client 4.0 or later. See the topic about installing Horizon Client, in Using VMware

Horizon Client for Windows document.

nIf necessary, install the ActiveX version of Flash Player (rather than the NPAPI version). Flash

Player is installed by default in Internet Explorer 10 and 11. For Internet Explorer 9, you might

need to go to the following site to download and install Flash Player:

hps://get.adobe.com/ashplayer/.

2 On a Windows 7, Windows 8, Windows 8.1, or Windows 10 remote desktop, install the required version

of Horizon Agent and Internet Explorer, with Flash Player.

nInstall Horizon Agent 7.0 or later and be sure to select the option for Flash Redirection

(experimental). This option is not selected by default.

nInstall Internet Explorer 9, 10, or 11.

nIf necessary, install the ActiveX version of Flash Player (rather than the NPAPI version). Flash

Player is installed by default in Internet Explorer 10 and 11. For Internet Explorer 9, you might

need to go to the following site to download and install Flash Player:

hps://get.adobe.com/ashplayer/.

3 On the remote desktop, in Internet Explorer, select Tools > Manage add-ons from the menu bar and

verify that VMware View FlashMMR Server is listed and enabled.

4 On the Active Directory server, open the Group Policy Management Editor and edit the Flash

Redirection policy seings under Computer .

The seings are located in the Computer  > Policies > Administrative Templates >

Classic Administrative Templates > VMware Horizon Agent  > VMware FlashMMR

folder.

Setting Description

Enable Flash multi-media

redirection

Species whether Flash Redirection (FlashMMR) is enabled on the remote

desktop (agent-side). When enabled, this feature forwards Flash multi-

media data from the designated URLs through a TCP channel to the client,

and invokes the local Flash Player on the client system. This feature greatly

reduces demand on the agent-side CPU and network bandwidth.

Minimum rect size to enable

FlashMMR

Species the minimum width and height, in pixels, of the rectangle in

which the Flash content is played. For example, 400,300 species a width

of 400 pixels and a height of 300 pixels. Flash Redirection will be used only

if the Flash content is equal to or greater than the values specied in this

policy. If this GPO is not congured, the default value used is 320,200.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 17

5 In the Group Policy Management Editor, edit the Flash Redirection policy seings under User

.

The seings are located in the User  > Policies > Administrative Templates > Classic

Administrative Templates > VMware Horizon Agent  > VMware FlashMMR folder.

a (Horizon 7.0.3 or later) Open the seing  for FlashMMR url list usage for dening a list

of host URLs that you want to use with Flash redirection and select the Enabled radio buon.

b In the URL usage drop down list, choose to enable a white list or black list.

nTo enable a white list, select Enable white list.

nTo enable a black list, select Enable black list.

By default, white list is enabled.

c Open the seing Hosts Url lists to enable/disable FlashMMR for adding the list of host URLs that

will or will not use Flash redirection and select the Enabled radio buon.

d Click the Show buon.

e Enter the complete URLs that you compiled as a prerequisite in the Name column, and leave the

Value column blank.

Be sure to include  or . You can use regular expressions. For example, you can specify

https://*.google.com and http://www.cnn.com.

(Horizon 7.0) Leave the Value column blank.

(Horizon 7.0.1 or later) In the Value column, you can optionally specify

requireIECompatibility=true, appMode=0, or both (use a comma to separate the two strings).

Web sites support HTML5 by default and Flash Redirection does not work with these Web sites.

You must set requireIECompatibility=true for these sites to work. This parameter is not required

for the YouTube Web site.

By default, external interface support is enabled when Flash Redirection runs. This can degrade

performance. In certain situations, seing appMode=0 can improve performance and result in a

beer user experience.

6 On the agent machine, open a command prompt and change to the following directory:

%Program Files%\Common Files\VMware\Remote Experience

7 Run the following command to add the white list or black list to Internet Explorer.

cscript mergeflashmmrwhitelist.vbs

8 Restart Internet Explorer.

The sites set with the parameter requireIECompatibility=true are added to Internet Explorer's

compatibility view. You can verify this by selecting Tools > Compatibility View  from the

menu bar.

In Horizon 7.0 only, the sites are also added to Internet Explorer's list of trusted sites. You can verify the

trusted sites by selecting Tools > Internet Options from the Internet Explorer menu bar, and on the

Security tab, click the Sites buon.

Use Windows Registry Settings to Configure Flash Redirection

If you are a domain user who does not have Administrator privileges on the Active Directory server, you

can alternatively congure Flash Redirection by seing the appropriate values in Windows Registry keys on

the remote desktop.

You can use this procedure as an alternative to using GPO seings to congure Flash Redirection.

Configuring Remote Desktop Features in Horizon 7

18 VMware, Inc.

Prerequisites

nCompile a white list of Web sites to ensure that only the URLs specied in the list will be able to redirect

Flash content. Although you can compile a black list of Web sites, you cannot use the Windows registry

seings to enable the black list. A black list ensures that only the URLs specied in the list will not be

able to redirect Flash content. To enable a black list, you must use the GPO seings for Flash

Redirection.

nVerify that Horizon Agent 7.0 or later is installed in the remote desktop, along with Flash Player and

Internet Explorer 9, 10, or 11. See “Install and Congure Flash Redirection,” on page 16.

nVerify that you are using Horizon Client 4.0 or later, along with Flash Player ActiveX version.

Procedure

1 Use Horizon Client to access the remote desktop (agent machine).

2 Open the Windows Registry Editor (regedit.exe) on the agent machine, navigate to the following

folder, and set FlashRedirection to 1:

HKLM\Software\VMware, Inc.\VMware FlashMMR

N This seing enables the Flash Redirection feature, but if this seing is disabled (set to 0) in

HKLM\Software\Policies\VMware, Inc.\VMware FlashMMR, it means Flash Redirection is disabled

domain-wide, and requires a domain administrator to enable it.

3 Navigate to the following folder:

HKEY_CURRENT_USER\SOFTWARE\VMware, Inc.\VMware FlashMMR

If this folder does not already exist, create it.

4 In the VMware FlashMMR folder, create a sub-key named UrlWhiteList.

5 Right-click the UrlWhiteList key, select New > String Value, and for the name, enter the URL of a Web

site that will use Flash Redirection.

You can use regular expressions. For example, you could specify https://*.google.com. Be sure to leave

the Data value empty.

6 (Optional) (Horizon 7.0.1 and 7.0.2 only) In the data eld of the new registry value, add the data

requireIECompatibility=true, appMode=0, or both (use a comma to separate the two strings).

Web sites support HTML5 by default and Flash Redirection does not work with these Web sites. You

must set requireIECompatibility=true for these sites to work. This parameter is not required for the

YouTube Web site.

By default, external interface support is enabled when Flash Redirection runs. This can degrade

performance. For Horizon 7.0.1 or later, in certain situations, seing appMode=0 can improve

performance, and seing appMode=1 can result in a beer user experience.

7 Repeat the previous step to add additional URLs, and when you are nished, close the Registry Editor.

8 On the agent machine, open a command prompt and change to the following directory:

%Program Files%\Common Files\VMware\Remote Experience

9 Run the following command to add the white list to Internet Explorer.

cscript mergeflashmmrwhitelist.vbs

10 Restart Internet Explorer.

The sites set with the parameter requireIECompatibility=true are added to Internet Explorer's

compatibility view. You can verify this by selecting Tools > Compatibility View  from the

menu bar.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 19

In Horizon 7.0 only, the sites are also added to Internet Explorer's list of trusted sites. You can verify the

trusted sites by selecting Tools > Internet Options from the Internet Explorer menu bar, and on the

Security tab, click the Sites buon.

Configuring Real-Time Audio-Video

Real-Time Audio-Video allows Horizon 7 users to run Skype, Webex, Google Hangouts, and other online

conferencing applications on their remote desktops. With Real-Time Audio-Video, webcam and audio

devices that are connected locally to the client system are redirected to the remote desktop. This feature

redirects video and audio data to the desktop with a signicantly lower bandwidth than can be achieved by

using USB redirection.

Real-Time Audio-Video is compatible with standard conferencing applications and browser-based video

applications, and supports standard webcams, audio USB devices, and analog audio input.

This feature installs the VMware Virtual Webcam and VMware Virtual Microphone on the desktop

operating system. The VMware Virtual Webcam uses a kernel-mode webcam driver that provides enhanced

compatibility with browser-based video applications and other 3rd-party conferencing software.

When a conferencing or video application is launched, it displays and uses these VMware virtual devices,

which handle the audio-video redirection from the locally-connected devices on the client. The VMware

Virtual Webcam and Microphone appear in the Device Manager on the desktop operating system.

The drivers for the audio and webcam devices must be installed on your Horizon Client systems to enable

the redirection.

Configuration Choices for Real-Time Audio-Video

After you install Horizon Agent with Real-Time Audio-Video, the feature works on your Horizon 7

desktops without any further conguration. The default values for the webcam frame rate and image

resolution are recommended for most standard devices and applications.

You can congure group policy seings to change these default values to adapt to particular applications,

webcams, or environments. You can also set a policy to disable or enable the feature altogether. An ADMX

template le aloows you to install Real-Time Audio-Video group policy seings on Active Directory or on

individual desktops. See “Conguring Real-Time Audio-Video Group Policy Seings,” on page 30.

If users have multiple webcams and audio input devices built in or connected to their client computers, you

can congure preferred webcams and audio input devices that will be redirected to their desktops. See

“Selecting Preferred Webcams and Microphones,” on page 22.

N You can select a preferred audio device, but no other audio conguration options are available.

When webcam images and audio input are redirected to a remote desktop, you cannot access the webcam

and audio devices on the local computer. Conversely, when these devices are in use on the local computer,

you cannot access them on the remote desktop.

For information about supported applications, see the VMware knowledge base article, Guidelines for Using

Real-Time Audio-Video with 3rd-Party Applications on Horizon View Desktops, at

hp://kb.vmware.com/kb/2053754.

Configuring Remote Desktop Features in Horizon 7

20 VMware, Inc.

System Requirements for Real-Time Audio-Video

Real-Time Audio-Video works with standard webcam, USB audio, and analog audio devices, and with

standard conferencing applications like Skype, WebEx, and Google Hangouts. To support Real-Time Audio-

Video, your Horizon deployment must meet certain software and hardware requirements.

Remote desktops You install the Real-Time Audio-Video feature by installing View Agent 6.0

or later, or Horizon Agent 7.0 or later. To use this feature with published

desktops and applications, you must install Horizon Agent 7.0.2 or later. See

your Seing Up document for information on installing Horizon Agent.

Horizon Client software Horizon Client 2.2 for Windows or a later release

Horizon Client 2.2 for Linux or a later release. For Horizon Client for Linux

3.1 or earlier, this feature is available only with the version of Horizon Client

for Linux provided by third-party vendors. For Horizon Client for Linux 3.2

and later, this feature is also available with the version of the client available

from VMware.

Horizon Client 2.3 for Mac or a later release

Horizon Client 4.0 for iOS or a later release.

Horizon Client 4.0 for Android or a later release.

Horizon Client computer

or client access device

nAll operating systems that run Horizon Client for Windows.

nAll operating systems that run Horizon Client for Linux on x86 devices.

This feature is not supported on ARM processors.

nMac OS X Mountain Lion (10.8) and later. It is disabled on all earlier Mac

OS X operating systems.

nAll operating systems that run Horizon Client for iOS.

nAll operating systems than run Horizon Client for Android.

nFor details about supported client operating systems, see the Using

VMware Horizon Client document for the appropriate system or device.

nThe webcam and audio device drivers must be installed, and the

webcam and audio device must be operable, on the client computer. To

support Real-Time Audio-Video, you do not have to install the device

drivers on the desktop operating system where the agent is installed.

Display protocols nPCoIP

nVMware Blast (requires Horizon Agent 7.0 or later)

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 21

Ensuring That Real-Time Audio-Video Is Used Instead of USB Redirection

Real-Time Audio-Video supports webcam and audio input redirection for use in conferencing applications.

The USB redirection feature that can be installed with Horizon Agent does not support webcam redirection.

If you redirect audio input devices through USB redirection, the audio stream does not synchronize

properly with video during Real-Time Audio-Video sessions, and you lose the benet of reducing the

demand on network bandwidth. You can take steps to ensure that webcams and audio input devices are

redirected to your desktops through Real-Time Audio-Video, not USB redirection.

If your desktops are congured with USB redirection, end users can connect and display their locally

connected USB devices by selecting the Connect USB Device option in the Windows client menu bar or the

Desktop > USB menu in the Mac client. Linux clients block USB redirection of audio and video devices by

default and do not provide the USB device options to end users.

If an end user selects a USB device from the Connect USB Device or Desktop > USB list, that device

becomes unusable for video or audio conferencing. For example, if a user makes a Skype call, the video

image might not appear or the audio stream might be degraded. If an end user selects a device during a

conferencing session, the webcam or audio redirection is disrupted.

To hide these devices from end users and prevent potential disruptions, you can congure USB redirection

group policy seings to disable the display of webcams and audio input devices in VMware Horizon Client.

In particular, you can create USB redirection ltering rules for Horizon Agent and specify the audio-in and

video Device Family Names to be disabled. For information about seing group policies and specifying

ltering rules for USB redirection, see “Using Policies to Control USB Redirection,” on page 76.

C If you do not set up USB redirection ltering rules to disable the USB device families, inform your

end users that they cannot select webcam or audio devices from the Connect USB Device or Desktop > USB

list in the VMware Horizon Client menu bar.

Selecting Preferred Webcams and Microphones

If a client computer has more than one webcam and microphone, you can congure a preferred webcam and

default microphone that Real-Time Audio-Video will redirect to the desktop. These devices can be built in

or connected to the local client computer.

On a Windows client computer that has Horizon Client for Windows 4.2 or later installed, you can select a

preferred webcam or microphone by conguring Real-Time Audio-Video seings in the Horizon Client

Seings dialog box. With earlier Horizon Client versions, you modify registry seings to select a preferred

webcam and use the Sound control in the Windows operating system to select a default microphone.

On a Mac client computer, you can specify a preferred webcam or microphone by using the Mac defaults

system.

On a Linux client computer, you can specify a preferred webcam by editing a conguration le. To select a

default microphone, you can congure the Sound control in the Linux operating system on the client

computer.

Real-Time Audio-Video redirects the preferred webcam if it is available. If not, Real-Time Audio-Video uses

the rst webcam that is provided by system enumeration.

Select a Preferred Webcam or Microphone on a Windows Client System

With the Real-Time Audio-Video feature, if you have multiple webcams or microphones on your client

system, only one of them is used on your remote desktop or application. To specify which webcam or

microphone is preferred, you can congure Real-Time Audio-Video seings in Horizon Client.

The preferred webcam or microphone is used on the remote desktop or application if it is available, and if

not, another webcam or microphone is used.

Configuring Remote Desktop Features in Horizon 7

22 VMware, Inc.

With the Real-Time Audio-Video feature, video devices, audio input devices, and audio output devices

work without requiring the use of USB redirection, and the amount of network bandwidth required is

greatly reduced. Analog audio input devices are also supported.

N If you are using a USB webcam or microphone, do not connect it from the Connect USB Device

menu in Horizon Client. To do so routes the device through USB redirection, so that the device cannot use

the Real-Time Audio-Video feature.

This procedure applies only to Horizon Client for Windows 4.2 and later. For earlier client versions, you

must modify registry seings to select a preferred webcam and use the Sound control in the Windows

operating system to select a default microphone. For more information, see the Using VMware Horizon Client

for Windows document for your Horizon Client version.

Prerequisites

nVerify that you have a USB webcam, or USB microphone or other type of microphone, installed and

operational on your client system.

nVerify that you are using the VMware Blast display protocol or the PCoIP display protocol for your

remote desktop or application.

nConnect to a server.

Procedure

1 Open the Seings dialog box and select Real-Time Audio-Video in the left pane.

You can open the Seings dialog box by clicking the  (gear) icon in the upper right corner of the

desktop and application screen, or by right-clicking a desktop or application icon and selecting

.

2 Select the preferred webcam from the Preferred webcam drop-down menu and the preferred

microphone from the Preferred microphone drop-down menu.

The drop-down menus show the available webcams and microphones on the client system.

3 Click OK or Apply to save your changes.

The next time you start a remote desktop or application, the preferred webcam and microphone that you

selected are redirected to the remote desktop or application.

Select a Default Microphone on a Mac Client System

If you have multiple microphones on your client system, only one microphone is used on your remote

desktop. You can use System Preferences on your client system to specify which microphone is the default

microphone on the remote desktop.

With the Real-Time Audio-Video feature, audio input devices and audio output devices work without

requiring the use of USB redirection, and the amount of network bandwidth required is greatly reduced.

Analog audio input devices are also supported.

This procedure describes how to choose a microphone from the user interface of the client system.

Administrators can also congure a preferred microphone by using the Mac defaults system. See “Congure

a Preferred Webcam or Microphone on a Mac Client System,” on page 25.

I If you are using a USB microphone, do not connect it from the Connection > USB menu in

Horizon Client. To do so routes the device through USB redirection and the device cannot use the Real-Time

Audio-Video feature.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 23

Prerequisites

nVerify that you have a USB microphone or another type of microphone installed and operational on

your client system.

nVerify that you are using the VMware Blast display protocol or the PCoIP display protocol for your

remote desktop.

Procedure

1 On your client system, select Apple menu > System Preferences and click Sound.

2 Open the Input pane of Sound preferences.

3 Select the microphone that you prefer to use.

The next time that you connect to a remote desktop and start a call, the desktop uses the default microphone

that you selected on the client system.

Configuring Real-Time Audio-Video on a Mac Client

You can congure Real-Time Audio-Video seings at the command line by using the Mac defaults system.

With the defaults system, you can read, write, and delete Mac user defaults by using Terminal

(/Applications/Utilities/Terminal.app).

Mac defaults belong to domains. Domains typically correspond to individual applications. The domain for

the Real-Time Audio-Video feature is com.vmware.rtav.

Syntax for Configuring Real-Time Audio-Video

You can use the following commands to congure the Real-Time Audio-Video feature.

Table 2‑2. Command Syntax for Real-Time Audio-Video Configuration

Command Description

defaults write com.vmware.rtav scrWCamId "webcam-

userid"

Sets the preferred webcam to use on remote desktops. When this

value is not set, the webcam is selected automatically by system

enumeration. You can specify any webcam connected to (or built

into) the client system.

defaults write com.vmware.rtav srcAudioInId "audio-

device-userid"

Sets the preferred microphone (audio-in device) to use on remote

desktops. When this value is not set, remote desktops use the

default recording device set on the client system. You can specify

any microphone connected to (or built into) the client system.

defaults write com.vmware.rtav srcWCamFrameWidth

pixels

Sets the image width. The value defaults to a hardcoded value of

320 pixels. You can change the image width to any pixel value.

defaults write com.vmware.rtav srcWCamFrameHeight

pixels

Sets the image height. The value defaults to a hardcoded value of

240 pixels. You can change the image height to any pixel value.

defaults write com.vmware.rtav srcWCamFrameRate fps Sets the frame rate. The value defaults to 15 fps. You can change

the frame rate to any value.

defaults write com.vmware.rtav LogLevel "level"Sets the logging level for the Real-Time Audio-Video log le

(~/Library/Logs/VMware/vmware-RTAV-pid.log). You can set

the logging level to trace or debug.

defaults write com.vmware.rtav IsDisabled value Determines whether Real-Time Audio-Video is enabled or

disabled. Real-Time Audio-Video is enabled by default. (This

value is not in eect.) To disable Real-Time Audio-Video on the

client, set the value to true.

Configuring Remote Desktop Features in Horizon 7

24 VMware, Inc.

Table 2‑2. Command Syntax for Real-Time Audio-Video Configuration (Continued)

Command Description

defaults read com.vmware.rtav Displays Real-Time Audio-Video conguration seings.

defaults delete com.vmware.rtav seing Deletes a Real-Time Audio-Video conguration seing, for

example: defaults delete com.vmware.rtav

srcWCamFrameWidth

N You can adjust frame rates from 1 fps up to a maximum of 25 fps and resolution up to a maximum of

1920x1080. A high resolution at a fast frame rate might not be supported on all devices or in all

environments.

Configure a Preferred Webcam or Microphone on a Mac Client System

With the Real-Time Audio-Video feature, if you have multiple webcams or microphones on your client

system, only one webcam and one microphone can be used on your remote desktop. You specify which

webcam and microphone are preferred at the command line by using the Mac defaults system.

With the Real-Time Audio-Video feature, webcams, audio input devices, and audio output devices work

without requiring USB redirection, and the amount of network bandwidth required is greatly reduced.

Analog audio input devices are also supported.

In most environments, there is no need to congure a preferred microphone or webcam. If you do not set a

preferred microphone, remote desktops use the default audio device set in the client system's System

Preferences. See “Select a Default Microphone on a Mac Client System,” on page 23. If you do not congure

a preferred webcam, the remote desktop selects the webcam by enumeration.

Prerequisites

nIf you are conguring a preferred USB webcam, verify that the webcam is installed and operational on

your client system.

nIf you are conguring a preferred USB microphone or other type of microphone, verify that the

microphone is installed and operational on your client system.

nVerify that you are using the VMware Blast display protocol or the PCoIP display protocol for your

remote desktop.

Procedure

1 On your Mac client system, start a webcam or microphone application to trigger an enumeration of

camera devices or audio devices to the Real-Time Audio-Video log le.

aAach the webcam or audio device.

b In the Applications folder, double-click VMware Horizon Client to start Horizon Client.

c Start a call and then stop the call.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 25

2 Find log entries for the webcam or microphone in the Real-Time Audio-Video log le.

a In a text editor, open the Real-Time Audio-Video log le.

The Real-Time Audio-Video log le is named ~/Library/Logs/VMware/vmware-RTAV-pid.log, where

pid is the process ID of the current session.

b Search the Real-Time Audio-Video log le for entries that identify the aached webcams or

microphones.

The following example shows how webcam entries might appear in the Real-Time Audio-Video log le:

2013-12-16T12:18:17.404Z| vthread-3| I120: RTAV: static void VideoInputBase::LogDevEnum() -

1 Device(s) found

2013-12-16T12:18:17.404Z| vthread-3| I120: RTAV: static void VideoInputBase::LogDevEnum() -

Name=FaceTime HD Camera (Built-in) UserId=FaceTime HD Camera (Built-

in)#0xfa20000005ac8509 SystemId=0xfa20000005ac8509

The following example shows how microphone entries might appear in the Real-Time Audio-Video log

le:

2013-12-16T12:18:17.404Z| vthread-3| I120: RTAV: int

AVCaptureEnumerateAudioDevices(MMDev::DeviceList&) -

2013-12-16T12:18:17.404Z| vthread-3| I120: RTAV: static void AudioCaptureBase::LogDevEnum()

- 2 Device(s) found

2013-12-16T12:18:17.404Z| vthread-3| I120: RTAV: static void AudioCaptureBase::LogDevEnum()

- Index=255 Name=Built-in Microphone UserId=Built-in Microphone#AppleHDAEngineInput:1B,

0,1,0:1 SystemId=AppleHDAEngineInput:1B,0,1,0:1

2013-12-16T12:18:17.404Z| vthread-3| I120: RTAV: static void AudioCaptureBase::LogDevEnum()

- Index=255 Name=Built-in Input UserId=Built-in Input#AppleHDAEngineInput:1B,0,1,1:2

SystemId=AppleHDAEngineInput:1B,0,1,1:2

3 Find the webcam or microphone that you prefer in the Real-Time Audio-Video log le and make a note

of its user ID.

The user ID appears after the string UserId= in the log le. For example, the user ID of the internal face

time camera is FaceTime HD Camera (Built-in) and the user ID of the internal microphone is Built-in

Microphone.

4 In Terminal (/Applications/Utilities/Terminal.app), use the defaults write command to set the

preferred webcam or microphone.

Option Action

Set the preferred webcam Type

defaults write com.vmware.rtav srcWCamId "webcam-userid",

where webcam-userid is the user ID of the preferred webcam, which you

obtained from the Real-Time Audio-Video log le. For example:

defaults write com.vmware.rtav srcWCamId "HD Webcam C525”

Set the preferred microphone Type

defaults write com.vmware.rtav srcAudioInId "audio-device-

userid", where audio-device-userid is the user ID of the preferred

microphone, which you obtained from the Real-Time Audio-Video log le.

For example:

defaults write com.vmware.rtav srcAudioInId "Built-in

Microphone"

5 (Optional) Use the defaults read command to verify your changes to the Real-Time Audio-Video

feature.

For example: defaults read com.vmware.rtav

The command lists all of the Real-Time Audio-Video seings.

Configuring Remote Desktop Features in Horizon 7

26 VMware, Inc.

The next time you connect to a remote desktop and start a new call, the desktop uses the preferred webcam

or microphone that you congured, if it is available. If the preferred webcam or microphone is not available,

the remote desktop can use another available webcam or microphone.

Select a Default Microphone on a Linux Client System

If you have multiple microphones on your client system, only one of them is used on your Horizon 7

desktop. To specify which microphone is the default, you can use the Sound control on your client system.

With the Real-Time Audio-Video feature, audio input devices and audio output devices work without

requiring the use of USB redirection, and the amount of network bandwidth required is greatly reduced.

Analog audio input devices are also supported.

This procedure describes choosing a default microphone from the user interface of the client system.

Administrators can also congure a preferred microphone by editing a conguration le. See “Select a

Preferred Webcam or Microphone on a Linux Client System,” on page 27.

Prerequisites

nVerify that you have a USB microphone or another type of microphone installed and operational on

your client system.

nVerify that you are using the VMware Blast display protocol or the PCoIP display protocol for your

remote desktop.

Procedure

1 In the Ubuntu graphical user interface, select System > Preferences > Sound.

You can alternatively click the Sound icon on the right side of the toolbar at the top of the screen.

2 Click the Input tab in the Sound Preferences dialog box.

3 Select the preferred device and click Close.

Select a Preferred Webcam or Microphone on a Linux Client System

With the Real-Time Audio-Video feature, if you have multiple webcams and microphones on your client

system, only one webcam and one microphone can be used on your Horizon 7 desktop. To specify which

webcam and microphone are preferred, you can edit a conguration le.

The preferred webcam or microphone is used on the remote desktop if it is available, and if not, another

webcam or microphone is used.

With the Real-Time Audio-Video feature, webcams, audio input devices, and audio output devices work

without requiring the use of USB redirection, and the amount network bandwidth required is greatly

reduced. Analog audio input devices are also supported.

To set the properties in the /etc/vmware/config le and specify a preferred device, you must determine the

values of certain elds. You can search the log le for the values of these elds.

nFor webcams, you set the rtav.srcWCamId property to the value of the UserId eld for the webcam and

the rtav.srcWCamName property to the value of the Name eld for the webcam.

The rtav.srcWCamName property has a higher priority than the rtav.srcWCamId property. Both properties

should specify the same webcam. If the properties specify dierent webcams, the webcam specied by

rtav.srcWCamName is used, if it exists. If it does not exist, the webcam specied by rtav.srcWCamId is

used. If both webcams are not found, the default webcam is used.

nFor audio devices, you set the rtav.srcAudioInId property to the value of the Pulse Audio

device.description eld.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 27

Prerequisites

Depending on whether you are conguring a preferred webcam, preferred microphone, or both, perform

the appropriate prerequisite tasks:

nVerify that you have a USB webcam installed and operational on your client system.

nVerify that you have a USB microphone or another type of microphone installed and operational on

your client system.

nVerify that you are using the VMware Blast display protocol or the PCoIP display protocol for your

remote desktop.

Procedure

1 Launch the client, and start a webcam or microphone application to trigger an enumeration of camera

devices or audio devices to the client log.

aAach the webcam or audio device you want to use.

b Use the command vmware-view to start Horizon Client.

c Start a call and then stop the call.

This process creates a log le.

Configuring Remote Desktop Features in Horizon 7

28 VMware, Inc.

2 Find log entries for the webcam or microphone.

a Open the debug log le with a text editor.

The log le with real-time audio-video log messages is located at /tmp/vmware-<username>/vmware-

RTAV-<pid>.log. The client log is located at /tmp/vmware-<username>/vmware-view-<pid>.log.

b Search the log le to nd the log le entries that reference the aached webcams and microphones.

The following example shows an extract of the webcam selection:

main| I120: RTAV: static void VideoInputBase::LogDevEnum() - 3 Device(s) found

main| I120: RTAV: static void VideoInputBase::LogDevEnum() - Name=UVC Camera (046d:

0819) UserId=UVC Camera (046d:0819)#/sys/devices/pci0000:00/0000:00:1a.

7/usb1/1-3/1-3.4/1-3.4.5 SystemId=/dev/video1

main| I120: RTAV: static void VideoInputBase::LogDevEnum() - Name=gspca main driver

UserId=gspca main driver#/sys/devices/pci0000:00/0000:00:1a.7/usb1/1-3/1-3.4/1-3.4.7

SystemId=/dev/video2

main| I120: RTAV: static void VideoInputBase::LogDevEnum() -

Name=Microsoft® LifeCam HD-6000 for Notebooks UserId=Microsoft® LifeCam HD-6000 for

Notebooks#/sys/devices/pci0000:00/0000:00:1a.7/usb1/1-3/1-3.6 SystemId=/dev/video0

main| W110: RTAV: static bool AudioCaptureLin::EnumCaptureDevices(MMDev::DeviceList&) -

enumeration data unavailable

The following example shows an extract of the audio device selection, and the current audio level

for each:

vthread-18| I120: RTAV: bool AudioCaptureLin::TriggerEnumDevices() - Triggering

enumeration

vthread-18| I120: RTAV: static void AudioCaptureLin::PulseAudioGetSourceCB(pa_context*,

const pa_source_info*, int, void*) - PulseAudio Get Source (idx=1 'alsa_output.usb-

Logitech_Logitech_USB_Headset-00-Headset.analog-stereo.monitor' 'Monitor of Logitech USB

Headset Analog Stereo')

vthread-18| I120: RTAV: static void AudioCaptureLin::PulseAudioGetSourceCB(pa_context*,

const pa_source_info*, int, void*) - channel:0 vol:65536

vthread-18| I120: RTAV: static void AudioCaptureLin::PulseAudioGetSourceCB(pa_context*,

const pa_source_info*, int, void*) - channel:1 vol:65536

vthread-18| I120: RTAV: static void AudioCaptureLin::PulseAudioGetSourceCB(pa_context*,

const pa_source_info*, int, void*) - PulseAudio Get Source (idx=2 'alsa_input.usb-

Logitech_Logitech_USB_Headset-00-Headset.analog-mono' 'Logitech USB Headset Analog Mono')

vthread-18| I120: RTAV: static void AudioCaptureLin::PulseAudioGetSourceCB(pa_context*,

const pa_source_info*, int, void*) - channel:0 vol:98304

vthread-18| I120: RTAV: static void AudioCaptureLin::PulseAudioGetSourceCB(pa_context*,

const pa_source_info*, int, void*) - PulseAudio Get Source (idx=3 'alsa_output.usb-

Microsoft_Microsoft_LifeChat_LX-6000-00-LX6000.analog-stereo.monitor' 'Monitor of

Microsoft LifeChat LX-6000 Analog Stereo')

vthread-18| I120: RTAV: static void AudioCaptureLin::PulseAudioGetSourceCB(pa_context*,

const pa_source_info*, int, void*) - channel:0 vol:65536

Warnings are shown if any of the source audio levels for the selected device do not meet the

PulseAudio criteria if the source is not set to 100% (0dB), or if the selected source device is muted,

as follows:

vthread-18| I120: RTAV: static void AudioCaptureLin::PulseAudioSourceInfoCB(pa_context*,

const pa_source_info*, int, void*) - Note, selected device channel volume: 0: 67%

vthread-18| I120: RTAV: static void AudioCaptureLin::PulseAudioSourceInfoCB(pa_context*,

const pa_source_info*, int, void*) - Note, selected device channel is muted

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 29

3 Copy the description of the device and use it to set the appropriate property in the /etc/vmware/config

le.

For a webcam example, copy Microsoft® LifeCam HD-6000 for Notebooks and Microsoft® LifeCam

HD-6000 for Notebooks#/sys/devices/pci0000:00/0000:00:1a.7/usb1/1-3/1-3.6 to specify the

Microsoft webcam as the preferred webcam and set the properties as follows:

rtav.srcWCamName = “Microsoft® LifeCam HD-6000 for Notebooks”

rtav.srcWCamId = “Microsoft® LifeCam HD-6000 for

Notebooks#/sys/devices/pci0000:00/0000:00:1a.7/usb1/1-3/1-3.6”

For this example, you could also set the rtav.srcWCamId property to "Microsoft". The rtav.srcWCamId

property supports both partial and exact matches. The rtav.srcWCamName property supports only an

exact match.

For an audio device example, copy Logitech USB Headset Analog Mono to specify the Logitech headset

as the preferred audio device and set the property as follows:

rtav.srcAudioInId="Logitech USB Headset Analog Mono"

4 Save your changes and close the /etc/vmware/config conguration le.

5 Log o of the desktop session and start a new session.

Configuring Real-Time Audio-Video Group Policy Settings

You can congure group policy seings that control the behavior of Real-Time Audio-Video (RTAV) on your

Horizon 7 desktops. These seings determine a virtual webcam's maximum frame rate and image

resolution. The seings allow you to manage the maximum bandwidth that any one user can consume. An

additional seing disables or enables the RTAV feature.

You do not have to congure these policy seings. Real-Time Audio-Video works with the frame rate and

image resolution that are set for the webcam on client systems. The default seings are recommended for

most webcam and audio applications.

For examples of bandwidth use during Real-Time Audio-Video, see “Real-Time Audio-Video Bandwidth,”

on page 33.

These policy seings aect your Horizon 7 desktops, not the client systems to which the physical devices are

connected. To congure these seings on your desktops, add the RTAV Group Policy Administrative

Template (ADMX) le in Active Directory.

For information about conguring seings on client systems, see the VMware knowledge base article,

Seing Frame Rates and Resolution for Real-Time Audio-Video on Horizon View Clients, at

hp://kb.vmware.com/kb/2053644.

Add the RTAV ADMX Template in Active Directory and Configure the Settings

You can add the policy seings in the RTAV ADMX le (vdm_agent_rtav.admx), to group policy objects

(GPOs) in Active Directory and congure the seings in the Group Policy Object Editor.

Prerequisites

nVerify that the RTAV setup option is installed on your desktops. This setup option is installed by default

but can be deselected during installation. The seings have no eect if RTAV is not installed. See your

Seing Up document for information on installing Horizon Agent.

nVerify that Active Directory GPOs are created for the RTAV group policy seings. The GPOs must be

linked to the OU that contains your desktops. See “Active Directory Group Policy Example,” on

page 168.

nVerify that the Microsoft MMC and the Group Policy Object Editor snap-in are available on your Active

Directory server.

Configuring Remote Desktop Features in Horizon 7

30 VMware, Inc.

nFamiliarize yourself with RTAV group policy seings. See “Real-Time Audio-Video Group Policy

Seings,” on page 31.

Procedure

1 Download the Horizon 7 GPO Bundle .zip le from the VMware download site at

hps://my.vmware.com/web/vmware/downloads.

Under Desktop & End-User Computing, select the VMware Horizon 7 download, which includes the

GPO Bundle.

The le is named VMware-Horizon-Extras-Bundle-x.x.x-yyyyyyy.zip, where x.x.x is the version and

yyyyyyy is the build number. All ADMX les that provide group policy seings for Horizon 7 are

available in this le.

2 Unzip the VMware-Horizon-Extras-Bundle-x.x.x-yyyyyyy.zip le and copy the ADMX les to your

Active Directory or RDS host.

a Copy the vdm_agent_rtav.admx le and the en-US folder to the C:\Windows\PolicyDefinitions

folder on your Active Directory or RDS host.

b (Optional) Copy the language resource le (vdm_agent_rtav.adml) to the appropriate subfolder in

C:\Windows\PolicyDefinitions\ on your Active Directory or RDS host.

3 On the Active Directory host, open the Group Policy Management Editor and enter the path to the

template le in the editor.

On an individual RDS host, you can open the Local Group Policy Editor with the gpedit.msc utility.

The seings are located in the Computer  > Policies > Administrative Templates > View

RTAV  folder.

What to do next

Congure the group policy seings.

Real-Time Audio-Video Group Policy Settings

The Real-Time Audio-Video (RTAV) group policy seings control the virtual webcam's maximum frame rate

and maximum image resolution. An additional seing lets you disable or enable the RTAV feature. These

policy seings aect remote desktops, not the client systems where the physical devices are connected.

If you do not congure the RTAV group policy seings, RTAV uses the values that are set on the client

systems. On client systems, the default webcam frame rate is 15 frames per second. The default webcam

image resolution is 320x240 pixels.

The resolution group policy seings determine the maximum values that can be used. The frame rate and

resolution that are set on client systems are absolute values. For example, if you congure the RTAV seings

for maximum image resolution to 640x480 pixels, the webcam displays any resolution that is set on the

client up to 640x480 pixels. If you set the image resolution on the client to a value higher than 640x480 pixels,

the client resolution is capped at 640x480 pixels.

Not all congurations can achieve the maximum group policy seings of 1920x1080 resolution at 25 frames

per second. The maximum frame rate that your conguration can achieve for a given resolution depends

upon the webcam being used, the client system hardware, the Horizon Agent virtual hardware, and the

available bandwidth.

The resolution group policy seings determine the default values that are used when resolution values are

not set by the user.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 31

Group Policy

Setting Description

Disable RTAV When you enable this seing, the Real-Time Audio-Video feature is disabled.

When this seing is not congured or disabled, Real-Time Audio-Video is enabled.

This seing is in the VMware View Agent  > View RTAV  folder in the

Group Policy Management Editor.

Max frames per

second

Determines the maximum rate per second at which the webcam can capture frames. You can use this

seing to limit the webcam frame rate in low-bandwidth network environments.

The minimum value is one frame per second. The maximum value is 25 frames per second.

When this seing is not congured or disabled, no maximum frame rate is set. Real-Time Audio-

Video uses the frame rate that is selected for the webcam on the client system.

By default, client webcams have a frame rate of 15 frames per second. If no seing is congured on

the client system and the Max frames per second seing is not congured or disabled, the webcam

captures 15 frames per second.

This seing is located in the VMware View Agent  > View RTAV  >

View RTAV Webcam  folder in the Group Policy Management Editor.

Resolution -

Max image

width in

pixels

Determines the maximum width, in pixels, of image frames that are captured by the webcam. By

seing a low maximum image width, you can lower the resolution of captured frames, which can

improve the imaging experience in low-bandwidth network environments.

When this seing is not congured or disabled, a maximum image width is not set. RTAV uses the

image width that is set on the client system. The default width of a webcam image on a client system

is 320 pixels.

The maximum limit for any webcam image is 1920x1080 pixels. If you congure this seing with a

value that is higher than 1920 pixels, the eective maximum image width is 1920 pixels.

This seing is located in the VMware View Agent  > View RTAV  >

View RTAV Webcam  folder in the Group Policy Management Editor.

Resolution -

Max image

height in

pixels

Determines the maximum height, in pixels, of image frames that are captured by the webcam. By

seing a low maximum image height, you can lower the resolution of captured frames, which can

improve the imaging experience in low-bandwidth network environments.

When this seing is not congured or disabled, a maximum image height is not set. RTAV uses the

image height that is set on the client system. The default height of a webcam image on a client system

is 240 pixels.

The maximum limit for any webcam image is 1920x1080 pixels. If you congure this seing with a

value that is higher than 1080 pixels, the eective maximum image height is 1080 pixels.

This seing is located in the VMware View Agent  > View RTAV  >

View RTAV Webcam  folder in the Group Policy Management Editor.

Resolution -

Default image

resolution

width in

pixels

Determines the default resolution width, in pixels, of image frames that are captured by the webcam.

This seing is used when no resolution value is dened by the user.

When this seing is not congured or disabled, the default image width is 320 pixels.

The value that is congured by this policy seing takes eect only if both View Agent 6.0 or later and

Horizon Client 3.0 or later are used. For older versions of View Agent and Horizon Client, this policy

seing has no eect, and the default image width is 320 pixels.

This seing is located in the VMware View Agent  > View RTAV  >

View RTAV Webcam  folder in the Group Policy Management Editor.

Resolution -

Default image

resolution

height in

pixels

Determines the default resolution height, in pixels, of image frames that are captured by the webcam.

This seing is used when no resolution value is dened by the user.

When this seing is not congured or disabled, the default image height is 240 pixels.

The value that is congured by this policy seing takes eect only if both View Agent 6.0 or later and

Horizon Client 3.0 or later are used. For older versions of View Agent and Horizon Client, this policy

seing has no eect, and the default image height is 240 pixels.

This seing is located in the VMware View Agent  > View RTAV  >

View RTAV Webcam  folder in the Group Policy Management Editor.

Configuring Remote Desktop Features in Horizon 7

32 VMware, Inc.

Real-Time Audio-Video Bandwidth

Real-Time Audio-Video bandwidth varies according to the webcam's image resolution and frame rate, and

the image and audio data being captured.

The sample tests shown in Table 2-3 measure the bandwidth that Real-Time Audio-Video uses in a View

environment with standard webcam and audio input devices. The tests measure the bandwidth to send both

video and audio data from Horizon Client to Horizon Agent. The total bandwidth that is required to run a

desktop session from Horizon Client might be higher than these numbers. In these tests, the webcam

captures images at 15 frames per second for each image resolution.

Table 2‑3. Sample Bandwidth Results for Sending Real-Time Audio-Video Data from Horizon Client to

Horizon Agent

Image Resolution (Width x Height) Bandwidth Used (Kbps)

160 x 120 225

320 x 240 320

640 x 480 600

Configuring Scanner Redirection

By using scanner redirection, Horizon 7 users can scan information in their remote desktops and

applications with scanning and imaging devices that are connected locally to their client computers. Scanner

redirection is available in Horizon 6.0.2 and later releases.

Scanner redirection supports standard scanning and imaging devices that are compatible with the TWAIN

and WIA formats.

After you install Horizon Agent with the Scanner Redirection setup option, the feature works on your

remote desktops and applications without further conguration. You do not have to congure scanner-

specic drivers on remote desktops or applications.

You can congure group policy seings to change default values to adapt to particular scanning and

imaging applications or environments. You can also set a policy to disable or enable the feature altogether.

With an ADMX template le, you can install scanner redirection group policy seings in Active Directory or

on individual desktops. See “Conguring Scanner Redirection Group Policy Seings,” on page 35.

When scanning data is redirected to a remote desktop or application, you cannot access the scanning or

imaging device on the local computer. Conversely, when a device is in use on the local computer, you cannot

access it on the remote desktop or application.

System Requirements for Scanner Redirection

To support scanner redirection, your Horizon 7 deployment must meet certain software and hardware

requirements.

Horizon 7 remote

desktop or application

This feature is supported on RDS desktops, RDS applications, and VDI

desktops that are deployed on single-user virtual machines.

You must install View Agent 6.0.2 or later, and select the Scanner Redirection

setup option, on the parent or template virtual machines or RDS hosts.

On Windows Desktop and Windows Server guest operating systems, the

Horizon Agent Scanner Redirection setup option is deselected by default.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 33

The following guest operating systems are supported on single-user virtual

machines and, where noted, on RDS hosts:

n32-bit or 64-bit Windows 7

n32-bit or 64-bit Windows 8.x

n32-bit or 64-bit Windows 10

nWindows Server 2008 R2 congured as a desktop or RDS host

nWindows Server 2012 R2 congured as a desktop or RDS host

I The Desktop Experience feature must be installed on

Windows Server guest operating systems, whether they are congured

as desktops or as RDS hosts.

The scanner device drivers do not have to be installed on the desktop

operating system where Horizon Agent is installed.

Horizon Client software Horizon Client 3.2 for Windows or a later release

Horizon Client computer

or client access device

Supported operating systems:

n32-bit or 64-bit Windows 7

n32-bit or 64-bit Windows 8.x

n32-bit or 64-bit Windows 10

The scanner device drivers must be installed, and the scanner must be

operable, on the client computer.

Scanning device

standard

TWAIN or WIA

Display protocol for

Horizon 7

PCoIP

Scanner redirection is not supported in RDP desktop sessions.

User Operation of Scanner Redirection

With scanner redirection, users can operate physical scanners and imaging devices that are connected to

their client computers as virtual devices that perform scanning operations in their remote desktops and

applications.

Users can operate their virtual scanners in a way that closely parallels the way that they use the scanners on

their locally connected client computers.

nAfter the Scanner Redirection option is installed with Horizon Agent, a scanner tool tray icon icon ( )

is added to the desktop. On RDS applications, the tool tray icon is redirected to the local client

computer.

You do not have to use the scanner tool tray icon. Scanning redirection works without any further

conguration. You can use the icon to congure options such as changing which device to use if more

than one device is connected to the client computer.

nWhen you click the scanner icon, the Scanner Redirection for VMware Horizon menu is displayed. No

scanners appear in the menu list if incompatible scanners are connected to the client computer.

nBy default, scanning devices are autoselected. TWAIN and WIA scanners are selected separately. You

can have one TWAIN scanner and one WIA scanner selected at the same time.

Configuring Remote Desktop Features in Horizon 7

34 VMware, Inc.

nIf more than one locally connected scanner is congured, you can select a dierent scanner than the one

that is selected by default.

nWIA scanners are displayed in the remote desktop's Device Manager menu, under Imaging devices.

The WIA scanner is named VMware Virtual WIA Scanner.

nIn the Scanner Redirection for VMware Horizon menu, you can click the Preferences option and select

options such as hiding webcams from the scanner redirection menu and determining how to select the

default scanner.

You can also control these features by conguring scanner redirection group policy seings in Active

Directory. See “Scanner Redirection Group Policy Seings,” on page 36.

nWhen you operate a TWAIN scanner, the TWAIN Scanner Redirection for VMware Horizon menu

provides additional options for selecting regions of an image, scanning in color, black and white, or

grayscale, and choosing other common functions.

nTo display the TWAIN user interface window for TWAIN scanning software that does not display the

window by default, you can select an Always show Scanner  dialog option in the VMware

Horizon Scanner Redirection Preferences dialog box.

Note that most TWAIN scanning software displays the TWAIN user interface window by default. For

this software, the window is always displayed, whether you select or deselect the Always show

Scanner  dialog option.

N If you run two RDS applications that are hosted on dierent farms, two scanner redirection tool tray

icons appear on the client computer. Typically, only one scanner is connected to a client computer. In this

case, both icons operate the same device, and it does not maer which icon you select. In some situations,

you might have two locally connected scanners and run two RDS applications that run on dierent farms. In

that case, you must open each icon to see which scanner redirection menu controls which RDS application.

For end-user instructions for operating redirected scanners, see the Using VMware Horizon Client for Windows

document.

Configuring Scanner Redirection Group Policy Settings

You can congure group policy seings that control the behavior of scanner redirection on your Horizon 7

desktops and applications. With these policy seings, you can control centrally, from Active Directory, the

options that are available in the VMware Horizon Scanner Redirection Preferences dialog box on users'

desktops and applications.

You do not have to congure these policy seings. Scanner redirection works with the default seings that

are congured for scanning devices on remote desktops and client systems.

These policy seings aect your remote desktops and applications, not the client systems where the physical

scanners are connected. To congure these seings on your desktops and applications, add the Scanner

Redirection Group Policy Administrative Template (ADMX) le in Active Directory.

Add the Scanner Redirection ADMX Templates in Active Directory

You can add the policy seings in the scanner redirection ADMX template le (vdm_agent_scanner.admx) to

group policy objects (GPOs) in Active Directory and congure the seings in the Group Policy Object Editor.

Prerequisites

nVerify that the Scanner Redirection setup option is installed on your desktops and RDS hosts. The

group policy seings have no eect if scanner redirection is not installed. See your Seing Up document

for information on installing Horizon Agent.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 35

nVerify that Active Directory GPOs are created for the scanner redirection group policy seings. The

GPOs must be linked to the OU that contains your desktops and RDS hosts. See “Active Directory

Group Policy Example,” on page 168.

nVerify that the MMC and the Group Policy Object Editor snap-in are available on your Active Directory

server.

nFamiliarize yourself with scanner redirection group policy seings. See “Scanner Redirection Group

Policy Seings,” on page 36.

Procedure

1 Download the Horizon 7 GPO Bundle .zip le from the VMware download site at

hps://my.vmware.com/web/vmware/downloads.

Under Desktop & End-User Computing, select the VMware Horizon 7 download, which includes the

GPO Bundle.

The le is named VMware-Horizon-Extras-Bundle-x.x.x-yyyyyyy.zip, where x.x.x is the version and

yyyyyyy is the build number. All ADMX les that provide group policy seings for Horizon 7 are

available in this le.

2 Unzip the VMware-Horizon-Extras-Bundle-x.x.x-yyyyyyy.zip le and copy the ADMX les to your

Active Directory or RDS host.

a Copy the vdm_agent_scanner.admx le and the en-US folder to the C:\Windows\PolicyDefinitions

folder on your Active Directory or RDS host.

b (Optional) Copy the language resource le (vdm_agent_scanner.adml) to the appropriate subfolder

in C:\Windows\PolicyDefinitions\ on your Active Directory or RDS host.

3 On the Active Directory host, open the Group Policy Management Editor and enter the path to the

template le in the editor.

On an individual RDS host, you can open the Local Group Policy Editor with the gpedit.msc utility.

The seings are located in the Computer  > Policies > Administrative Templates >

Scanner Redirection folder.

Most seings are also added to the User  folder, located in User  > Policies

> Administrative Templates > Scanner Redirection folder.

What to do next

Congure the group policy seings.

Scanner Redirection Group Policy Settings

The scanner redirection group policy seings control the options that are available in the VMware Horizon

Scanner Redirection Preferences dialog box on users' desktops and applications.

The scanner redirection ADMX template le contains both Computer Conguration and User Conguration

policies. The User Conguration policies allow you to set dierent congurations for users of VDI desktops,

RDS desktops, and RDS applications. Dierent User Conguration policies can take eect even when users'

desktop sessions and applications are running on the same RDS hosts. All of the seings are in the VMware

Horizon Agent  > Scanner Redirection folder in the Group Policy Management Editor.

Configuring Remote Desktop Features in Horizon 7

36 VMware, Inc.

Group Policy

Setting Computer User Description

Disable

functionality

X Disables the scanner redirection feature.

When you enable this seing, scanners cannot be redirected and do not appear

in the scanner menu on users' desktops and applications.

When you disable this seing or do not congure it, scanner redirection works

and scanners appear in the scanner menu.

Lock config X Locks the scanner redirection user interface and prevents users from changing

conguration options on their desktops and applications.

When you enable this seing, users cannot congure the options that are

available from the tray menu on their desktops and applications. Users can

display the VMware Horizon Scanner Redirection Preferences dialog box, but

the options are inactive and cannot be changed.

When you disable this seing or do not congure it, users can congure the

options in the VMware Horizon Scanner Redirection Preferences dialog box.

Compression X Sets the image compression rate during the image transfer to the remote

desktop or application.

You can choose from the following compression modes:

nDisable. Image compression is disabled.

nLossless. Lossless (zlib) compression is used without loss of image

quality.

nJPEG. JPEG compression is used with loss of quality. You specify the level

of image quality in the JPEG compression quality eld. JPEG compression

quality must be a value between 0 and 100.

When you enable this seing, the selected compression mode is set for all users

aected by this policy. However, users can change the Compression option in

the VMware Horizon Scanner Redirection Preferences dialog box, overriding

the policy seing.

When you disable this policy seing or do not congure it, JPEG compression

mode is used.

Hide Webcam X X Prevents webcams from appearing in the scanner selection menu in the

VMware Horizon Scanner Redirection Preferences dialog box.

By default, webcams can be redirected to desktops and applications. Users can

select webcams and use them as virtual scanners to capture images.

When you enable this seing as a Computer Conguration policy, webcams are

hidden from all users of the aected computers. Users cannot change the Hide

Webcam option in the VMware Horizon Scanner Redirection Preferences

dialog box.

When you enable this seing as a User Conguration policy, webcams are

hidden from all aected users. However, users can change the Hide Webcam

option in the VMware Horizon Scanner Redirection Preferences dialog box.

When you enable this seing in both Computer Conguration and User

Conguration, the Hide Webcam seing in Computer Conguration overrides

the corresponding policy seing in User Conguration for all users of the

aected computers.

When you disable this seing or do not congure it in either policy

conguration, the Hide Webcam seing is determined by the corresponding

policy seing (either User Conguration or Computer Conguration) or by

user selection in the VMware Horizon Scanner Redirection Preferences dialog

box.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 37

Group Policy

Setting Computer User Description

Default

Scanner

X X Provides centralized management of scanner autoselection.

You select scanner autoselection options separately for TWAIN and WIA

scanners. You can choose from the following autoselection options:

nNone. Do not select scanners automatically.

nAutoselect Automatically select the locally connected scanner.

nLast used Automatically select the last-used scanner.

n Select the scanner name that you type in the  scanner

text box.

When you enable this seing as a Computer Conguration policy, the seing

determines the scanner autoselection mode for all users of the aected

computers. Users cannot change the Default Scanner option in the VMware

Horizon Scanner Redirection Preferences dialog box.

When you enable this seing as a User Conguration policy, the seing

determines the scanner autoselection mode for all aected users. However,

users can change the Default Scanner option in the VMware Horizon Scanner

Redirection Preferences dialog box.

When you enable this seing in both Computer Conguration and User

Conguration, the scanner autoselection mode in Computer Conguration

overrides the corresponding policy seing in User Conguration for all users of

the aected computers.

When you disable this seing or do not congure it in either policy

conguration, the scanner autoselection mode is determined by the

corresponding policy seing (either User Conguration or Computer

Conguration) or by user selection in the VMware Horizon Scanner Redirection

Preferences dialog box.

Configuring Serial Port Redirection

With serial port redirection, users can redirect locally connected, serial (COM) ports such as built-in RS232

ports or USB to Serial adapters. Devices such as printers, bar code readers, and other serial devices can be

connected to these ports and used in the remote desktops.

Serial port redirection is available in Horizon 6 version 6.1.1 and later releases with Horizon Client for

Windows 3.4 and later releases.

After you install Horizon Agent and set up the serial port redirection feature, the feature can work on your

remote desktops without further conguration. For example, COM1 on the local client system is redirected

as COM1 on the remote desktop, and COM2 is redirected as COM2, unless a COM port already exists on the

remote desktop. If so, the COM port is mapped to avoid conicts. For example, if COM1 and COM2 already

exist on the remote desktop, COM1 on the client is mapped to COM3 by default. You do not have to

congure the COM ports or install device drivers on the remote desktops.

To make a redirected COM port active, a user selects the Connect option from the menu on the serial port

tool tray icon during a desktop session. A user can also set a COM port device to connect automatically

whenever the user logs in to the remote desktop. See “User Operation of Serial Port Redirection,” on

page 39.

You can congure group policy seings to change the default conguration. For example, you can lock the

seings so that users cannot change the COM port mappings or properties. You can also set a policy to

disable or enable the feature altogether. With an ADMX template le, you can install serial port redirection

group policy seings in Active Directory or on individual desktops. See “Conguring Serial Port

Redirection Group Policy Seings,” on page 41.

When a redirected COM port is opened and in use on a remote desktop, you cannot access the port on the

local computer. Conversely, when a COM port is in use on the local computer, you cannot access the port on

the remote desktop.

Configuring Remote Desktop Features in Horizon 7

38 VMware, Inc.

System Requirements for Serial Port Redirection

With this feature, users can redirect locally connected, serial (COM) ports, such as built-in RS232 ports or

USB to Serial adapters, to their remote desktops. To support serial port redirection, your Horizon

deployment must meet certain software and hardware requirements.

Remote desktops The remote desktops must have View Agent 6.1.1 or later, or Horizon Agent

7.0 or later, installed with the Serial Port Redirection setup option, on the

parent or template virtual machines. This setup option is deselected by

default.

The following guest operating systems are supported on single-session

virtual machines:

n32-bit or 64-bit Windows 7

n32-bit or 64-bit Windows 8.x

n32-bit or 64-bit Windows 10

nWindows Server 2008 R2 congured as a desktop

nWindows Server 2012 R2 congured as a desktop

nWindows Server 2016 congured as a desktop

This feature is not currently supported for Windows Server RDS hosts.

Serial port device drivers do not have to be installed on the desktop

operating system where the agent is installed.

Horizon Client computer

or client access device

nSerial port redirection is supported on Windows 7, Windows 8.x client

systems, and Windows 10.

nAny required serial port device drivers must be installed, and the serial

port must be operable, on the client computer. You do not need to install

the device drivers on the remote desktop operating system where the

agent is installed.

Display protocols nPCoIP

nVMware Blast (requires Horizon Agent 7.0 or later)

VMware Horizon serial port redirection is not supported in RDP desktop

sessions.

User Operation of Serial Port Redirection

Users can operate physical COM port devices that are connected to their client computers and use serial port

virtualization to connect the devices to their remote desktops, where the devices are accessible to 3rd party

applications.

nAfter the Serial Port Redirection option is installed with Horizon Agent, a serial port tool tray icon ( )

is added to the remote desktop. For published applications, the icon is redirected to the local client

computer.

The icon appears only if you use the required versions of Horizon Agent and Horizon Client for

Windows, and you connect over PCoIP. The icon does not appear if you connect to a remote desktop

from a Mac, Linux, or mobile client.

You can use the icon to congure options to connect, disconnect, and customize the mapped COM

ports.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 39

nWhen you click the serial port icon, the Serial COM Redirection for VMware Horizon menu appears.

nBy default, the locally connected COM ports are mapped to corresponding COM ports on the remote

desktop. For example: COM1 mapped to COM3. The mapped ports are not connected by default.

nTo use a mapped COM port, you must manually select the Connect option in the Serial COM

Redirection for VMware Horizon menu, or the Autoconnect option must be set during a previous

desktop session or by conguring a group policy seing. Autoconnect congures a mapped port to

connect automatically when a remote desktop session is started.

nWhen you select the Connect option, the redirected port is active. In the Device Manager in the guest

operating system on the remote desktop, the redirected port is shown as Serial Port Redirector for

VMware Horizon (COMn).

When the COM port is connected, you can open the port in a 3rd-party application, which can exchange

data with the COM port device that is connected to the client machine. While a port is open in an

application, you cannot disconnect the port in the Serial COM Redirection for VMware Horizon

menu.

Before you can disconnect the COM port, you must close the port in the application or close the

application. You can then select the Disconnect option to disconnect the port and make the physical

COM port available for use on the client machine.

nIn the Serial COM Redirection for VMware Horizon menu, you can right-click a redirected port to

select the Port Properties command.

In the COM Properties dialog box, you can congure a port to connect automatically when a remote

desktop session is started, ignore the Data Set Ready (DSR) signal, and map the local port on the client

to a dierent COM port on the remote desktop by selecting a port in the Custom port name drop-down

list.

A remote desktop port might be shown as overlapped. For example, you might see COM1

(Overlapped). In this case, the virtual machine is congured with a COM port in the virtual hardware

on the ESXi host. You can use a redirected port even when it is mapped to an overlapped port on the

virtual machine. The virtual machine receives serial data through the port from the ESXi host or from

the client system.

nIn the Device Manager in the guest operating system, you can use the Properties > Port  tab to

congure seings for a redirected COM port. For example, you can set the default baud rate and data

bits. However, the seings you congure in Device Manager are ignored if the application species the

port seings.

For end-user instructions for operating redirected serial COM ports, see the Using VMware Horizon Client for

Windows document.

Guidelines for Configuring Serial Port Redirection

Through the group policy seings, you can congure serial port redirection and control the extent to which

users can customize redirected COM ports. Your choices depend on the user roles and 3rd-party

applications in your organization.

For details about the group policy seings, see “Serial Port Redirection Group Policy Seings,” on page 42.

nIf your users run the same 3rd-party applications and COM port devices, make sure that the redirected

ports are congured in the same way. For example, in a bank or retail store that uses point-of-sale

devices, make sure that all COM port devices are connected to the same ports on the client endpoints,

and all ports are mapped to the same redirected COM ports on the remote desktops.

Configuring Remote Desktop Features in Horizon 7

40 VMware, Inc.

Set the  policy seing to map client ports to redirected ports. Select the Autoconnect item

in  to ensure that the redirected ports are connected at the start of each desktop session.

Enable the Lock  policy seing to prevent users from changing the port mappings or

customizing the port congurations. In this scenario, users never have to connect or disconnect

manually and cannot accidentally make a redirected COM port inaccessible to a 3rd-party application.

nIf your users are knowledge workers who use a variety of 3rd-party applications and might also use

their COM ports locally on their client machines, make sure that users can connect and disconnect from

the redirected COM ports.

You might set the  policy seing if the default port mappings are incorrect. You might or

might not set the Autoconnect item, depending on your users' requirements. Do not enable the Lock

 policy seing.

nMake sure that your 3rd-party applications open the COM port that is mapped to the remote desktop.

nMake sure that the baud rate that is in use for a device matches the baud rate that the 3rd-party

application is aempting to use.

nYou can redirect up to ve COM ports from a client system to a remote desktop.

Configuring Serial Port Redirection Group Policy Settings

You can congure group policy seings that control the behavior of serial port redirection on your remote

desktops. With these policy seings, you can control centrally, from Active Directory, the options that are

available in the Serial COM Redirection for VMware Horizon menu on users' desktops.

You do not have to congure these policy seings. Serial port redirection works with the default seings

that are congured for redirected COM ports on remote desktops and client systems.

These policy seings aect your remote desktops, not the client systems where the physical COM port

devices are connected. To congure these seings on your desktops, add the Serial Port Redirection Group

Policy Administrative Template (ADMX) le in Active Directory.

Add the Serial Port Redirection ADMX Template in Active Directory

You can add the policy seings in the serial port redirection ADMX le (vdm_agent_serialport.admx), to

group policy objects (GPOs) in Active Directory and congure the seings in the Group Policy Object Editor.

Prerequisites

nVerify that the Serial Port Redirection setup option is installed on your desktops. The group policy

seings have no eect if serial port redirection is not installed. See your Seing Up document for more

information on installing the Horizon Agent.

nVerify that Active Directory GPOs are created for the serial port redirection group policy seings. The

GPOs must be linked to the OU that contains your desktops. See “Active Directory Group Policy

Example,” on page 168.

nVerify that the MMC and the Group Policy Object Editor snap-in are available on your Active Directory

server.

nFamiliarize yourself with serial port redirection group policy seings. See “Serial Port Redirection

Group Policy Seings,” on page 42.

Procedure

1 Download the Horizon 7 GPO Bundle .zip le from the VMware download site at

hps://my.vmware.com/web/vmware/downloads.

Under Desktop & End-User Computing, select the VMware Horizon 7 download, which includes the

GPO Bundle.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 41

The le is named VMware-Horizon-Extras-Bundle-x.x.x-yyyyyyy.zip, where x.x.x is the version and

yyyyyyy is the build number. All ADMX les that provide group policy seings for Horizon 7 are

available in this le.

2 Unzip the VMware-Horizon-Extras-Bundle-x.x.x-yyyyyyy.zip le and copy the ADMX les to your

Active Directory or RDS host.

a Copy the vdm_agent_serialport.admx le and the en-US folder to the

C:\Windows\PolicyDefinitions folder on your Active Directory or RDS host.

b (Optional) Copy the language resource le (vdm_agent_serialport.adml) to the appropriate

subfolder in C:\Windows\PolicyDefinitions\ on your Active Directory or RDS host.

3 On the Active Directory host, open the Group Policy Management Editor and enter the path to the

template le in the editor.

On an individual RDS host, you can open the Local Group Policy Editor with the gpedit.msc utility.

The seings are located in the Computer  > Policies > Administrative Templates > Serial

COM folder.

Most seings are also added to the User  folder, located in User  > Policies

> Administrative Templates > Serial COM.

What to do next

Congure the group policy seings.

Serial Port Redirection Group Policy Settings

The serial port redirection group policy seings control the redirected COM port conguration, including

the options that are available in the Serial COM Redirection for VMware Horizon menu on remote

desktops.

The serial port redirection ADMX le contains both Computer Conguration and User Conguration

policies. The User Conguration policies allow you to set dierent congurations for specied users of VDI

desktops. Policy seings that are congured in Computer Conguration take precedence over the

corresponding seings that are congured in User Conguration.

Configuring Remote Desktop Features in Horizon 7

42 VMware, Inc.

Group Policy

Setting Computer User Description

PortSettings1

PortSettings2

PortSettings3

PortSettings4

PortSettings5

X X The port seings determine the mapping between the COM port on the client

system and the redirected COM port on the remote desktop and determines

other seings that aect the redirected COM port. You congure each

redirected COM port individually.

Five port seings policy seings are available, allowing up to ve COM ports

to be mapped from the client to the remote desktop. Select one port seings

policy seing for each COM port that you intend to congure. When you

enable the port seings policy seing, you can congure the following items

that aect the redirected COM port:

nThe Source port number seing species the number of the physical COM

port that is connected to the client system.

nThe Destination virtual port number seing species the number of the

redirected virtual COM port on the remote desktop.

nThe Autoconnect seing automatically connects the COM port to the

redirected COM port at the start of each desktop session.

nWith the IgnoreDSR seing, the redirected COM port device ignores the

Data Set Ready (DSR) signal.

nThe Pause before close port (in milliseconds) seing species the time to

wait (in milliseconds) after a user closes the redirected port and before the

port is actually closed. Certain USB to Serial adapters require this delay to

ensure that transmied data is preserved. This seing is intended for

troubleshooting purposes.

nThe Serial2USBModeChangeEnabled seing resolves issues that apply to

USB to Serial adapters that use the Prolic chipset, including the GlobalSat

BU353 GPS adapter. If you do not enable this seing for Prolic chipset

adapters, connected devices can transmit data but not receive data.

nThe Disable errors in wait mask seing disables the error value in the

COM port mask. This troubleshooting seing is required for certain

applications. For details, see the Microsoft documentation of the

WaitCommEvent function at

hp://msdn.microsoft.com/en-us/library/windows/desktop/aa363479(v=vs.

85).aspx.

nThe HandleBtDisappear seing supports BlueTooth COM port behavior.

This seing is intended for troubleshooting purposes.

nThe UsbToComTroubleShooting seing resolves some issues that apply to

USB to Serial port adapters. This seing is intended for troubleshooting

purposes.

When you enable the port seings policy seing for a particular COM port,

users can connect and disconnect the redirected port, but users cannot

congure properties of the port on the remote desktop. For example, users

cannot set the port to be redirected automatically when they log in to the

desktop, and they cannot ignore the DSR signal. These properties are

controlled by the group policy seing.

N A redirected COM port is connected and active only if the physical

COM port is connected locally to the client system. If you map a COM port

that does not exist on the client, the redirected port appears as inactive and not

available in the tool tray menu on the remote desktop.

When the port seings policy seing is disabled or not congured, the

redirected COM port uses the seings that users congure on the remote

desktop. The Serial COM Redirection for VMware Horizon menu options are

active and available to users.

These seings are in the VMware View Agent  > Serial COM >

 folder in the Group Policy Management Editor.

Local settings

priority

X X Gives priority to the seings that are congured on the remote desktop.

When you enable this policy, the serial port redirection seings that a user

congures on the remote desktop take precedence over the group policy

seings. A group policy seing takes eect only if a seing is not congured

on the remote desktop.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 43

Group Policy

Setting Computer User Description

When this seing is disabled or not congured, group policy seings take

precedence over the seings that are congured on the remote desktop.

This seing is in the VMware View Agent  > Serial COM folder

in the Group Policy Management Editor.

Disable

functionality

X Disables the serial port redirection feature.

When you enable this seing, COM ports are not redirected to the remote

desktop. The serial port tool tray icon on the remote desktop is not displayed.

When this seing is disabled, serial port redirection works, the serial port tool

tray icon is displayed, and COM ports appear in the Serial COM Redirection

for VMware Horizon menu.

When this seing is not congured, seings that are local to the remote

desktop determine whether serial port redirection is disabled or enabled.

This seing is in the VMware View Agent  > Serial COM folder

in the Group Policy Management Editor.

Lock

configuration

X X Locks the serial port redirection user interface and prevents users from

changing conguration options on the remote desktop.

When you enable this seing, users cannot congure the options that are

available from the tool tray menu on their desktops. Users can display the

Serial COM Redirection for VMware Horizon menu, but the options are

inactive and cannot be changed.

When this seing is disabled, users can congure the options in the Serial

COM Redirection for VMware Horizon menu.

When this seing is not congured, local program seings on the remote

desktop determine whether users can congure the COM port redirection

seings.

This seing is in the VMware View Agent  > Serial COM folder

in the Group Policy Management Editor.

Bandwidth

limit

X Sets a limit on the data transfer speed, in kilobytes per second, between the

redirected serial port and client systems.

When you enable this seing, you can set a value in the Bandwidth limit (in

kilobytes per second) box that determines the maximum data transfer speed

between the redirected serial port and the client. A value of 0 disables the

bandwidth limit.

When this seing is disabled, no bandwidth limit is set.

When this seing is not congured, local program seings on the remote

desktop determine whether a bandwidth limit is set.

This seing is in the VMware View Agent  > Serial COM folder

in the Group Policy Management Editor.

Configure USB to Serial Adapters

You can congure USB to Serial adapters that use a Prolic chipset to be redirected to remote desktops by

the serial port redirection feature.

To ensure that data is transmied properly on Prolic chipset adapters, you can enable a serial port

redirection group policy seing in Active Directory or on an individual desktop virtual machine.

If you do not congure the group policy seing to resolve issues for Prolic chipset adapters, connected

devices can transmit data but not receive data.

You do not have to congure a policy seing or registry key on client systems.

Prerequisites

nVerify that the Serial Port Redirection setup option is installed on your desktops. The group policy

seings have no eect if serial port redirection is not installed. See your Seing Up document for more

information on installing Horizon Agent.

Configuring Remote Desktop Features in Horizon 7

44 VMware, Inc.

nVerify that the Serial Port Redirection ADMX template le is added in Active Directory or on the

desktop virtual machine.

nFamiliarize yourself with the Serial2USBModeChangeEnabled item in the  group policy

seing. See “Serial Port Redirection Group Policy Seings,” on page 42.

Procedure

1 In Active Directory or on the virtual machine, open the Group Policy Object Editor.

2 Navigate to the Computer  > Policies > Administrative Templates > Classic

Administrative Templates > VMware View Agent  > Serial COM folder.

3 Select the  folder.

4 Select and enable a  group policy seing.

5 Specify the source and destination COM port numbers to map the COM port.

6 Select the Serial2USBModeChangeEnabled check box.

7Congure other items in the  policy seing as needed.

8 Click OK and close the Group Policy Object Editor.

USB to Serial adapters can be redirected to remote desktops, and can receive data successfully, when users

start their next desktop sessions.

Managing Access to Windows Media Multimedia Redirection (MMR)

Horizon 7 provides the Windows Media MMR feature for VDI desktops that run on single-user machines

and for RDS desktops.

MMR delivers the multimedia stream directly to client computers. With MMR, the multimedia stream is

processed, that is, decoded, on the client system. The client system plays the media content, thereby

ooading the demand on the ESXi host.

MMR data is sent across the network without application-based encryption and might contain sensitive

data, depending on the content being redirected. To ensure that this data cannot be monitored on the

network, use MMR only on a secure network.

If the secure tunnel is enabled, MMR connections between Horizon Clients and the View Secure Gateway

are secure, but connections from the View Secure Gateway to desktop machines are not encrypted. If the

secure tunnel is disabled, MMR connections from Horizon Clients to the desktop machines are not

encrypted.

Enabling Multimedia Redirection in Horizon 7

You can take steps to ensure that MMR is accessible only to Horizon Client systems that have sucient

resources to handle local multimedia decoding and that are connected to Horizon 7 on a secure network.

By default, the global policy in View Administrator, Multimedia redirection (MMR) is set to Deny.

To use MMR, you must explicitly set this value to Allow.

To control access to MMR, you can enable or disable the Multimedia redirection (MMR) policy globally, for

individual desktop pools, or for specic users.

For instructions for seing global policies in Horizon Administrator, see “Horizon 7 Policies,” on page 91.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 45

System Requirements for Windows Media MMR

To support Windows Media Multimedia Redirection (MMR), your Horizon 7 deployment must meet certain

software and hardware requirements. Windows Media MMR is provided in Horizon 6.0.2 and later releases.

View remote desktop nThis feature is supported on virtual machine desktops that are deployed

on single-user virtual machines and on RDS desktops.

View Agent 6.1.1 or later is required to support this feature on RDS

desktops.

View Agent 6.0.2 or later is required to support this feature on single-

user machines.

nThe following guest operating systems are supported:

n64-bit or 32-bit Windows 10. Windows Media Player is supported.

The default player TV & Movies is not supported.

nWindows Server 2016 is a Tech Preview feature. Windows Media

Player is supported. The default player TV & Movies is not

supported.

n64-bit or 32-bit Windows 7 SP1 Enterprise or Ultimate (single-user

machine). Windows 7 Professional is not supported.

n64-bit or 32-bit Windows 8/8.1 Professional or Enterprise (single-

user machine)

nWindows Server 2008 R2 congured as an RDS host

nWindows Server 2012 and 2012 R2 congured as an RDS host

n3D Rendering can be enabled or disabled on the desktop pool.

nUsers must play videos on Windows Media Player 12 or later or in

Internet Explorer 8 or later.

To use Internet Explorer, you must disable Protected Mode. In the

Internet Options dialog box, click the Security tab and deselect Enable

Protected Mode.

Horizon Client software Horizon Client 3.2 for Windows or a later release is required to support

Windows Media MMR on single-user machines.

Horizon Client computer

or client access device

nThe clients must run 64-bit or 32-bit Windows 7, Windows 8/8.1, or

Windows 10 operating systems.

Supported media

formats

Media formats that are supported on Windows Media Player are supported.

For example: M4V; MOV; MP4; WMP; MPEG-4 Part 2; WMV 7, 8, and 9;

WMA; AVI; ACE; MP3; WAV.

N DRM-protected content is not redirected through Windows Media

MMR.

Configuring Remote Desktop Features in Horizon 7

46 VMware, Inc.

Horizon policies In Horizon Administrator, set the Multimedia redirection (MMR) policy to

Allow. The default value is Deny.

Back-end firewall If your Horizon 7 deployment includes a back-end rewall between your

DMZ-based security servers and your internal network, verify that the back-

end rewall allows trac to port 9427 on your desktops.

Determine Whether to Use Windows Media MMR Based on Network Latency

By default, Windows Media MMR adapts to network conditions on single-user desktops that run on

Windows 8 or later and RDS desktops that run on Windows Server 2012 or 2012 R2 or later. If the network

latency between Horizon Client and the remote desktop is 29 milliseconds or lower, the video is redirected

with Windows Media MMR. If the network latency is 30 milliseconds or higher, the video is not redirected.

Instead, it is rendered on the ESXi host and sent to the client over PCoIP.

This feature applies to Windows 8 or later single-user desktops and Windows Server 2012 or 2012 R2 or later

RDS desktops. Users can run any supported client system, Windows 7 or Windows 8/8.1.

This feature does not apply to Windows 7 single-user desktops or Windows Server 2008 R2 RDS desktops.

On these guest operating systems, Windows Media MMR always performs multimedia redirection,

regardless of network latency.

You can override this feature, forcing Windows Media MMR to perform multimedia redirection regardless

of the network latency, by conguring the RedirectionPolicy registry seing on the desktop.

Procedure

1 Start the Windows Registry Editor on the remote desktop.

2 Navigate to the Windows registry key that controls the redirection policy.

The registry key that you congure for a remote desktop depends on the bit version of the Windows

Media Player.

Option Description

64-bit Windows Media Player nFor a 64-bit desktop, use the registry key:

HKEY_LOCAL_MACHINE\Software\VMware,Inc.\VMware tsmmr

32-bit Windows Media Player nFor a 32-bit desktop, use the registry key:

HKEY_LOCAL_MACHINE\Software\VMware,Inc.\VMware tsmmr

nFor a 64-bit desktop, use the registry key:

HKEY_LOCAL_MACHINE\Software\Wow6432Node\VMware,Inc.\VMwa

re tsmmr

3 Set the RedirectionPolicy value to always.

Value name = RedirectionPolicy

Value Type = REG_SZ

Value data = always

4 Restart Windows Media Player on the desktop to allow the updated value to take eect.

Managing Access to Client Drive Redirection

When you deploy Horizon Client 3.5 or later and View Agent 6.2 or later or Horizon Agent 7.0 or later with

client drive redirection, folders and les are sent across the network with encryption. Client drive

redirection connections between clients and the View Secure Gateway and connections from the View

Secure Gateway to desktop machines are secure.

For Horizon Client 4.2 or Horizon 7 version 7.0.2 or later, if VMware Blast Extreme is enabled, les and

folders are transferred across a virtual channel with encryption.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 47

With earlier client or agent releases, client drive redirection folders and les are sent across the network

without encryption and might contain sensitive data, depending on the content being redirected. If the

secure tunnel is enabled, client drive redirection connections between Horizon Client and the View Secure

Gateway are secure, but connections from the View Secure Gateway to desktop machines are not encrypted.

If the secure tunnel is disabled, client drive redirection connections from Horizon Client to the desktop

machines are not encrypted. To ensure that this data cannot be monitored on the network, use client drive

redirection only on a secure network if Horizon Client is earlier than version 3.5 or agent is earlier than

version 6.2.

The Client Drive Redirection setup option in the agent installer is selected by default. As a best practice,

enable the Client Drive Redirection setup option only in desktop pools where users require this feature.

Use Group Policy to Disable Client Drive Redirection

You can disable client drive redirection by conguring a Microsoft Remote Desktop Services group policy

seing for remote desktops and RDS hosts in Active Directory.

For more information about client drive redirection, see the Using VMware Horizon Client document for the

specic type of desktop client device. Go to

hps://www.vmware.com/support/viewclients/doc/viewclients_pubs.html.

N This seing overrides local registry and Smart Policies seings that enable the client drive redirection

feature.

Prerequisites

If your View deployment includes a back-end rewall between your DMZ-based security servers and your

internal network, verify that the back-end rewall allows trac to port 9427 on your single-user and RDS

desktops. TCP connections on port 9427 are required to support client drive redirection.

For Horizon Client 4.2 or Horizon 7 version 7.0.2 or later, port 9427 is not required to be open if VMware

Blast Extreme is enabled because client drive redirection transfers data through the virtual channel.

Procedure

1 In the Group Policy Editor, go to Computer 

Templates\Windows Components\Remote Desktop Services\Remote Desktop Session Host\Device

and Resource Redirection.

This navigation path is for Active Directory on Windows Server 2012. The navigation path diers on

other Windows operating systems.

2 Enable the Do not allow drive redirection group policy seing.

Use Registry Settings to Configure Client Drive Redirection

You can use Windows registry key seings to control client drive redirection behavior on a remote desktop.

This feature requires Horizon Agent 7.0 or later and Horizon Client 4.0 or later.

The Windows registry seings that control client drive redirection behavior on a remote desktop are located

in the following path:

HKLM\Software\VMware, Inc.\VMware TSDR

You can use the Windows Registry Editor on the remote desktop to edit local registry seings.

N Client drive redirection policies set with Smart Policies take precedence over local registry seings.

Configuring Remote Desktop Features in Horizon 7

48 VMware, Inc.

Disabling Client Drive Redirection

To disable client drive redirection, create a new string value named disabled and set its value to true.

HKLM\Software\VMware, Inc.\VMware TSDR\disabled=true

The value is false (enabled) by default.

Preventing Write Access to Shared Folders

To prevent write access to all folders that are shared with the remote desktop, create a new string value

named permissions and set its value to any string that begins with r, except for rw.

HKLM\Software\VMware, Inc.\VMware TSDR\permissions=r

The value is rw (all shared folders are readable and writeable) by default.

Sharing Specific Folders

To share specic folders with the remote desktop, create a new key named default shares and create a new

subkey for each folder to share with the remote desktop. For each subkey, create a new string value named

name and set its value to the path of the folder to share. The following example shares the folders C:\ebooks

and C:\spreadsheets.

HKLM\Software\VMware, Inc.\VMware TSDR\default shares\f1\name=C:\ebooks

HKLM\Software\VMware, Inc.\VMware TSDR\default shares\f2\name=C:\spreadsheets

If you set name to *all, all client drives are shared with the remote desktop. The *all seing is supported

only on Windows client systems.

HKLM\Software\VMware, Inc.\VMware TSDR\default shares\1st\name=*all

To prevent the client from sharing additional folders (that is, folders that are not specied with the default

shares key), create a string value named ForcedByAdmin and set its value to true.

HKLM\Software\VMware, Inc.\VMware TSDR\ForcedByAdmin=true

When the value is true, the Sharing dialog box does not appear when users connect to the remote desktop in

Horizon Client. The value is false (clients can share additional folders) by default.

The following example shares the folders C:\ebooks and C:\spreadsheets, makes both folders read-only,

and prevents the client from sharing additional folders.

HKLM\Software\VMware, Inc.\VMware TSDR\ForcedByAdmin=true

HKLM\Software\VMware, Inc.\VMware TSDR\permissions=r

HKLM\Software\VMware, Inc.\VMware TSDR\default shares\f1\name=C:\ebooks

HKLM\Software\VMware, Inc.\VMware TSDR\default shares\f2\name=C:\spreadsheets

N Do not use the ForcedByAdmin feature as a security feature or share control. A user can bypass the

ForcedByAdmin=true seing by creating a link to an existing share that points to folders not specied with

the default shares key.

Configure Skype for Business

You can make optimized audio and video calls with Skype for Business inside a virtual desktop without

negatively aecting the virtual infrastructure and overloading the network.

All media processing takes place on the client machine instead of in the virtual desktop during Skype audio

and video call.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 49

To use Skype for Business, you must install the Virtualization Pack for Skype for Business feature on the

client machine during Horizon Client for Windows installation. See the Using Vmware Horizon Client for

Windows document.

A Horizon administrator must install the Virtualization Pack for the Skype for Business feature on the

virtual desktop during Horizon Agent installation.

Skype for Business Features

Skype for Business oers the following features:

nPoint to point audio calls

nPoint to point video calls

nPSTN calls via dial pad

nTransfer, forward, mute, hold, and resume a call

nHID commands

nCalls to PSTN through mediation server

nRemote connectivity and calls through Edge Server

nMusic on hold

nVoicemail integration

Skype for Business System Requirements

This feature supports these congurations.

Table 2‑4. Skype for Business System Requirements

System Requirements

Server Lync Server 2013, Skype for Business Server 2015, Oce365

Client Skype for Business 2015 15.0.4675.1003 and later

Skype for Business 2016 as part of Oce 365 Plus: 16.0.7571.2072 or later

Skype for Business 2016 as part of Oce 2016: 16.0.4534.1000 or later

Virtual desktop operating systems Windows 7, Windows 8.1, Windows 10 persistent and non-persistent desktops.

Windows 2008r2 desktop and Windows 2012r2 desktop are also supported.

Client machine operating systems Windows 7, Windows 8.1, Windows 10

Display protocols VMware Blast and PCoIP

Network ports The same ports as those used by the native Skype for Business client. See client

ports in hps://technet.microsoft.com/en-us/library/gg398833.aspx

Webcam The same devices that are qualied to work with Skype for Business. See webcams

listed in hps://technet.microsoft.com/en-us/oce/dn947482.aspx

Audio and video codecs The same as the audio and video codecs used by the native Skype for Business

client. See hps://technet.microsoft.com/en-us/library/gg425841.aspx?

f=255&MSPPError=-2147217396

Media Feature Pack Must be installed on the remote desktop for Windows 10 N and KN versions. You

can install Media Feature from hps://www.microsoft.com/en-

us/download/details.aspx?id=48231

Configuring Remote Desktop Features in Horizon 7

50 VMware, Inc.

Skype for Business Limitations

Skype for Business has the following limitations:

nYou cannot make E.911 calls.

nIPv6 is not supported.

nYou cannot customize ringtones.

nResponse group call, call park, call pickup from park, call via work are not supported.

nWhiteboarding, gallery view, panoramic webcams, and screen sharing are not currently supported.

nYou cannot record calls.

nUsing Lync or Skype for Business client on the client machine concurrently with optimized Skype for

Business client in the remote desktop is not supported.

nThe Lync 2013 client UI is not supported when connecting Skype 2015 client to a Lync 2013 server. An

administrator can congure Skype client UI on the server:

hps://social.technet.microsoft.com/wiki/contents/articles/30282.switch-between-skype-for-business-

and-lync-client-ui.aspx

nAudio and video conferencing involving more than two users is not currently supported.

nMeet Now conferencing is not supported.

nIn the video preview window, if you want to preview a dierent camera than the one listed, select the

device, then close the dialog, then re-open it to preview it.

nIf you are connected to a private network when you install Skype for Business on the remote desktop,

the installer adds inbound and outbound rewall rules for that network prole. When you log on to the

remote desktop from a domain network and then use Skype for Business, you see a rewall exception.

To x the problem, manually add rewall exceptions for Skype for Business client in the rewall rules

for all network proles.

nThe volume control option in the remote desktop operating system does not aect the volume level of

an ongoing Skype call. Use the volume control in the Skype call or use the volume control on the client

machine to make volume changes.

Chapter 2 Configuring Remote Desktop Features

VMware, Inc. 51

Configuring Remote Desktop Features in Horizon 7

52 VMware, Inc.

Configuring URL Content Redirection 3

With the URL Content Redirection feature, you can congure specic URLs to open on the client machine or

in a remote desktop or application. You can redirect URLs that users type in the Internet Explorer address

bar or in an application.

This chapter includes the following topics:

n“Understanding URL Content Redirection,” on page 53

n“Requirements for URL Content Redirection,” on page 54

n“Using URL Content Redirection in a Cloud Pod Architecture Environment,” on page 54

n“Installing Horizon Agent with the URL Content Redirection Feature,” on page 54

n“Conguring Agent-to-Client Redirection,” on page 55

n“Conguring Client-to-Agent Redirection,” on page 58

n“URL Content Redirection Limitations,” on page 67

n“Unsupported URL Content Redirection Features,” on page 67

Understanding URL Content Redirection

The URL Content Redirection feature supports redirection from a remote desktop or application to a client,

and from a client to a remote desktop or application.

Redirection from a remote desktop or application to a client is called agent-to-client redirection. Redirection

from a client to a remote desktop or application is called client-to-agent redirection.

Agent-to-client

redirection

With agent-to-client redirection, Horizon Agent sends the URL to

Horizon Client, which opens the default application for the protocol in the

URL on the client machine.

Client-to-agent

redirection

With client-to-agent redirection, Horizon Client opens a remote desktop or

remote application that you specify to handle the URL. If the URL is

redirected to a remote desktop, the link is opened in the default browser for

the protocol on the desktop. If the URL is redirected to a remote application,

the link is opened by the specied application. The end user must be entitled

to the desktop or application pool.

You can redirect some URLs from a remote desktop or application to a client, and redirect other URLs from

a client to a remote desktop or application. You can redirect any number of protocols, including HTTP,

HTTPS, mailto, and callto.

VMware, Inc. 53

Requirements for URL Content Redirection

To use the URL Content Redirection feature, your client machines, remote desktop machines, and RDS hosts

must meet certain requirements.

Windows clients Horizon Client 4.0 for Windows or later.

To use client-to-agent redirection, you must enable the URL Content

Redirection feature during Horizon Client for Windows installation. You do

not need to enable the URL Content Redirection feature in Horizon Client for

Windows to use agent-to-client redirection.

Mac clients Horizon Client 4.2 for Mac or later.

In Horizon Client 4.2 or 4.3 for Mac, URL Content Redirection is a Tech

Preview feature and it supports only agent-to-client redirection. In

Horizon Client 4.4 for Mac and later, URL Content Redirection is ocially

supported and it supports both agent-to-client and client-to-agent

redirection.

Desktop virtual

machines and RDS

hosts

Horizon Agent 7.0 or later in remote desktop machines and RDS hosts that

provide desktops and applications.

You must enable the URL Content Redirection feature during Horizon Agent

installation.

Web browsers Internet Explorer 9,10, and 11

Display protocols VMware Blast and PCoIP

Using URL Content Redirection in a Cloud Pod Architecture

Environment

If you have a Cloud Pod Architecture environment, you can congure global URL content redirection

seings in addition to local URL content redirection seings.

Unlike local URL content redirection seings, which are visible only in the local pod, global URL content

redirection seings are visible across the pod federation. With global URL content redirection seings, you

can redirect URL links in the client to global resources, such as global desktop entitlements and global

application entitlements.

When a user uses Horizon Client to log in to a Connection Server instance in the pod federation, the

Connection Server instance looks for all of the local and global URL content redirection seings assigned to

the user. The local and global seings are merged and used whenever the user clicks a URL on the client

machine.

For complete information about conguring and managing a Cloud Pod Architecture environment, see the

Administering Cloud Pod Architecture in Horizon 7 document.

Installing Horizon Agent with the URL Content Redirection Feature

To use URL content redirection from a remote desktop or application to a client (agent-to-client redirection),

or from a client to a remote desktop or application (client-to-agent redirection), you must enable the URL

Content Redirection feature when you install Horizon Agent.

Instead of double-clicking the installer le, start the Horizon Agent installation by running the following

command in a command prompt window:

VMware-viewagent-x86_64-y.y.y-xxxxxx.exe /v URL_FILTERING_ENABLED=1

Configuring Remote Desktop Features in Horizon 7

54 VMware, Inc.

Follow the prompts and complete the installation.

To verify that the URL Content Redirection feature is installed, make sure that the vmware-url-protocol-

launch-helper.exe and vmware-url-filtering-plugin.dll les are in the %PROGRAMFILES%\VMware\VMware

View\Agent\bin\UrlRedirection directory. Also, verify that the VMware Horizon View URL Filtering Plugin

Internet Explorer add-on is enabled.

Configuring Agent-to-Client Redirection

With agent-to-client redirection, Horizon Agent sends the URL to Horizon Client, which opens the default

application for the protocol in the URL.

To enable agent-to-client redirection, perform the following conguration tasks.

nEnable the URL Content Redirection feature in Horizon Agent. See “Installing Horizon Agent with the

URL Content Redirection Feature,” on page 54.

nApply the URL Content Redirection group policy seings to your remote desktops and applications.

See “Add the URL Content Redirection ADMX Template to a GPO,” on page 55.

nCongure group policy seings to indicate, for each protocol, how Horizon Agent should redirect the

URL. See “URL Content Redirection Group Policy Seings,” on page 56.

Add the URL Content Redirection ADMX Template to a GPO

The URL Content Redirection ADMX template le, called urlRedirection-enUS.admx, contains seings that

enable you to control whether a URL link is opened on the client (agent-to-client redirection) or in a remote

desktop or application (client-to-agent redirection).

To apply the URL Content Redirection group policy seings to your remote desktops and applications, add

the ADMX template le to GPOs on your Active Directory server. For rules regarding URL links clicked in a

remote desktop or application, the GPOs must be linked to the OU that contains your virtual desktops and

RDS hosts.

You can also apply the group policy seings to a GPO that is linked to the OU that contains your Windows

client computers, but the preferred method for conguring client-to-agent redirection is to use the vdmutil

command-line utility. Because macOS does not support GPOs, you must use vmdutil if you have Mac

clients.

Prerequisites

nVerify that the URL Content Redirection feature is included when you install Horizon Agent. See

“Installing Horizon Agent with the URL Content Redirection Feature,” on page 54.

nVerify that Active Directory GPOs are created for the URL Content Redirection group policy seings.

nVerify that the MMC and Group Policy Management Editor snap-in are available on your Active

Directory server.

Procedure

1 Download the Horizon 7 GPO Bundle .zip le from the VMware download site at

hps://my.vmware.com/web/vmware/downloads.

Under Desktop & End-User Computing, select the VMware Horizon 7 download, which includes the

GPO Bundle.

The le is named VMware-Horizon-Extras-Bundle-x.x.x-yyyyyyy.zip, where x.x.x is the version and

yyyyyyy is the build number. All ADMX les that provide group policy seings for Horizon 7 are

available in this le.

Chapter 3 Configuring URL Content Redirection

VMware, Inc. 55

2 Unzip the VMware-Horizon-Extras-Bundle-x.x.x-yyyyyyy.zip le and copy the URL Content

Redirection ADMX le to your Active Directory server.

a Copy the urlRedirection-enUS.admx le to the C:\Windows\PolicyDefinitions folder.

b Copy the urlRedirection.adml language resource le to the appropriate subfolder in the

C:\Windows\PolicyDefinitions directory.

For example, for the EN locale, copy the urlRedirection-enUS.adml le to the

C:\Windows\PolicyDefinitions\en-US folder.

3 On your Active Directory server, open the Group Policy Management Editor.

The URL Content Redirection group policy seings are installed in Computer  > Policies

> Administrative Templates > VMware Horizon URL Redirection.

What to do next

Congure the group policy seings.

URL Content Redirection Group Policy Settings

The URL Content Redirection template le contains group policy seings that enable you to create rules for

agent-to-client and client-to-agent redirection. The template le contains only Computer Conguration

seings. All of the seings are in the VMware Horizon URL Redirection folder in the Group Policy

Management Editor.

The following table describes the group policy seings in the URL Content Redirection template le.

Table 3‑1. URL Content Redirection Group Policy Settings

Setting Properties

IE Policy: Prevent users from

changing URL Redirection plugin

loading behavior

Determines whether users can disable the URL Content Redirection

feature.

This seing is not congured by default.

IE Policy: Automatically enable URL

Redirection plugin

Determines whether newly installed Internet Explorer plug-ins are

automatically activated.

This seing is not congured by default.

Url Redirection Enabled Determines whether the URL Content Redirection feature is enabled.

You can use this seing to disable the URL Content Redirection feature

even if the feature has been installed in the client or agent.

This seing is not congured by default.

Configuring Remote Desktop Features in Horizon 7

56 VMware, Inc.

Table 3‑1. URL Content Redirection Group Policy Settings (Continued)

Setting Properties

Url Redirection Protocol 'http' For all URLs that use the HTTP protocol, species the URLs that should

be redirected. This seing has the following options:

nbrokerHostname - IP address or fully qualied name of the

Connection Server host to use when redirecting URLs to a remote

desktop or application.

nremoteItem - display name of the remote desktop or application

pool that can handle the URLs specied in agentRules.

nclientRules - the URLs that should be redirected to the client. For

example, if you set clientRules to .*.mycompany.com, all URLs that

include the text mycompany.com are redirected to the Windows-

based client and are opened in the default browser on the client.

nagentRules - the URLs that should be redirected to the remote

desktop or application specied in remoteItem. For example, if you

set agentRules to .*.mycompany.com, all URLs that include

"mycompany.com" are redirected to the remote desktop or

application.

When you create agent rules, you must also use the brokerHostname

option to specify the IP address or fully qualied domain name of the

Connection Server host, and the remoteItem option to specify the

display name of the desktop or application pool.

N The preferred method for conguring client rules is to use the

vdmutil command-line utility.

This seing is enabled by default.

Url Redirection Protocol '[...]' Use this seing for any protocol other than HTTP, such as HTTPS, email,

or callto.

The options are the same as for Url Redirection Protocol 'http'.

If you do not need to congure other protocols, you can delete or

comment out this entry before adding the URL Content Redirection

template le to Active Directory.

As a best practice, congure the same redirection seings for the HTTP

and HTTPS protocols. That way, if a user types a partial URL into

Internet Explorer, such as mycompany.com, and that site automatically

redirects from HTTP to HTTPS, the URL Content Redirection feature

will work as expected. In this example, if you set a rule for HTTPS but

do not set the same redirection seing for HTTP, the partial URL that the

user types is not redirected.

This seing is not congured by default.

For client-to-agent redirection, if you congure a protocol that does not have a default handler, after you

congure a group policy seing for this protocol, you must start Horizon Client once before URLs that

specify this protocol are redirected.

Syntax for Creating URL Content Redirection Rules

You can use regular expressions when you specify which URLs to open on the client or in a remote desktop

or application. Use semicolons to separate multiple entries. Spaces are not allowed between entries.

The following table describes some sample entries.

Chapter 3 Configuring URL Content Redirection

VMware, Inc. 57

Entry Description

.* Species that all URLs are redirected.

If you use this seing for agent rules (agentRules option), all URLs are opened in the

specied remote desktop or application.

If you use this seing for client rules (clientRules option), all URLs are redirected to

the client.

.*.acme.com;.*.example.com Species that all URLs that include the text .acme.com or example.com are

redirected.

[space or leave empty] Species that no URLs are redirected. For example, leaving the clientRules option

empty species that no URLs are redirected to the client.

Agent-to-Client Redirection Group Policy Example

You might want to use agent-to-client redirection to conserve resources or as an added security layer. If

employees are working in a remote desktop or application and they want to watch videos, for example, you

might redirect those URLs to the client machine so that no extra load is put on the data center. Or for

security purposes, for employees working outside the company network, you might want all URLs that

point to external locations outside the company network to be opened on an employee's own client machine.

You could, for example, congure rules so that any content that is not company-related, that is, any URLs

that do not point to the company network, are redirected to open on the client machine. In this case you

could use the following seings, which include regular expressions:

nFor agentRules: .*.mycompany.com

This rule redirects any URL that contains the text mycompany.com to be opened on the specied remote

desktop or application (agent).

nFor clientRules: .*

This rule redirects all URLs to the client, to be opened with the default client browser.

The URL Content Redirection feature uses the following process to apply client and agent rules:

1 When a user clicks a link in a remote application or desktop, the client rules are checked rst.

2 If the URL matches a client rule, the agent rules are checked next.

3 If there is a conict between the agent rules and the client rules, the link is opened locally. In this case,

the URL is opened on the agent machine.

4 If there is no conict, the URL is redirected to the client.

In the example, the client and agent rules conict because URLs with mycompany.com are a subset of all

URLs. Because of this conict, URLs that include mycompany.com are opened locally. If you click a link

that includes mycompany.com in the URL while in a remote desktop, the URL is opened on that remote

desktop. If you click a link with mycompany.com in the URL in it from a client system, the URL is opened

on the client.

Configuring Client-to-Agent Redirection

With client-to-agent redirection, Horizon Client opens a remote desktop or application to handle a URL link

that a user clicks on the client. If a remote desktop is opened, the default application for the protocol in the

URL processes the URL. If a remote application is opened, the application processes the URL.

To use client-to-agent redirection, perform the following conguration tasks.

nEnable the URL Content Redirection feature in Horizon Agent. See “Installing Horizon Agent with the

URL Content Redirection Feature,” on page 54.

Configuring Remote Desktop Features in Horizon 7

58 VMware, Inc.

n(Windows clients only) Enable the URL Content Redirection feature in Horizon Client for Windows. See

“Installing Horizon Client for Windows with the URL Content Redirection Feature,” on page 59.

nUse the vdmutil command-line utility to create a URL content redirection seing that indicates, for each

protocol, how Horizon Client should redirect the URLs. See “Create a Local URL Content Redirection

Seing,” on page 61 or “Create a Global URL Content Redirection Seing,” on page 62.

nUse the vdmutil command-line utility to assign the URL content redirection seing to Active Directory

users or groups. See “Assign a URL Content Redirection Seing to a User or Group,” on page 64.

nVerify the URL content redirection seing. See “Test a URL Content Redirection Seing,” on page 65.

N You can use group policy seings to congure client-to-agent redirection rules, but using the vdmutil

command-line utility is the preferred method. For more information, see “Using Group Policy Seings to

Congure Client-to-Agent Redirection,” on page 67.

Installing Horizon Client for Windows with the URL Content Redirection Feature

To use URL Content Redirection from a Windows client to a remote desktop or application (client-to-agent

redirection), you must install Horizon Client for Windows with the URL Content Redirection feature.

To enable the URL Content Redirection feature, you must use the Horizon Client for Windows installer with

a command-line option. Instead of double-clicking the installer le, start the installation by running the

following command in a command prompt window:

VMware-Horizon-Client-x86-y.y.y-xxxxxx.exe /v URL_FILTERING_ENABLED=1

To verify that the feature is installed, make sure that the vmware-url-protocol-launch-helper.exe and

vmware-url-filtering-plugin.dll les are in the %PROGRAMFILES%\VMware\VMware Horizon View Client

directory. Also, verify that the VMware Horizon View URL Filtering Plugin Internet Explorer add-on is

installed.

N Horizon Client 4.4 for Mac supports client-to-agent redirection by default. No extra installation steps

are required. Horizon Client 4.2 and 4.3 for Mac do not support client-to-agent redirection.

Using the vdmutil Command-Line Utility

You can use the vdmutil command-line interface to create, assign, and manage URL content redirection

seings for client-to-agent redirection.

Command Usage

The syntax of the vdmutil command controls its operation from a Windows command prompt.

vdmutil command_option [additional_option argument] ...

The additional options that you can use depend on the command option.

By default, the path to the vdmutil command executable le is C:\Program Files\VMware\VMware

View\Server\tools\bin. To avoid entering the path on the command line, add the path to your PATH

environment variable.

Command Authentication

You must run the vdmutil command as a user who has the Administrators role.

You can use Horizon Administrator to assign the Administrators role to a user. For more information, see

the View Administration document.

Chapter 3 Configuring URL Content Redirection

VMware, Inc. 59

The vdmutil command includes options to specify the user name, domain, and password to use for

authentication. You must use these authentication options with all vdmutil command options except for

--help and --verbose.

Table 3‑2. vdmutil Command Authentication Options

Option Description

--authAs User name of a Horizon administrator user to authenticate to the Connection Server

instance. Do not use domain\username or user principal name (UPN) format.

--authDomain Fully qualied domain name for the Horizon administrator user specied in the

--authAs option.

--authPassword Password for the Horizon administrator specied in the --authAs option. Typing "*"

instead of a password causes the vdmutil command to prompt for the password and

does not leave sensitive passwords in the command history on the command line.

For example, the following vdmutil command logs in the user mydomain\johndoe.

vdmutil --listURLSetting --authAs johndoe --authDomain mydomain --authPassword secret

Command Output

The vdmutil command returns 0 when an operation succeeds and a failure-specic non-zero code when an

operation fails. The vdmutil command writes error messages to standard error. When an operation produces

output, or when verbose logging is enabled by using the --verbose option, the vdmutil command writes

output to standard output in US English.

Options for URL Content Redirection

You can use the following vdmutil command options to create, assign, and manage URL content redirection

seings. All options are preceded by two dashes (--).

Table 3‑3. vdmutil Command Options for URL Content Redirection

Option Description

--addGroupURLSetting Assigns a group to a particular URL content redirection seing.

--addUserURLSetting Assigns a user to a particular URL content redirection seing.

--createURLSetting Creates a URL content redirection seing.

--deleteURLSetting Deletes a URL content redirection seing.

--disableURLSetting Disables a URL content redirection seing.

--enableURLSetting Enables a URL content redirection seing that was previously disabled

with the --disableURLSetting option.

--listURLSetting Lists all of the URL content redirection seings on the Connection

Server instance.

--readURLSetting Displays information about a URL content redirection seing.

--removeGroupURLSetting Removes a group assignment from a URL content redirection seing.

--removeUserURLSetting Removes a user assignment from a URL content redirection seing.

--updateURLSetting Updates an existing URL content redirection seing.

You can display syntax information for all vdmutil options by typing vdmutil --help. To display detailed

syntax information for a particular option, type vdmutil --option --help.

Configuring Remote Desktop Features in Horizon 7

60 VMware, Inc.

Create a Local URL Content Redirection Setting

You can create a local URL content redirection seing that redirects specic URLs to open on a remote

desktop or application. A local URL content redirection seing is visible only in the local pod.

You can congure any number of protocols, including HTTP, HTTPS, mailto, and callto.

As a best practice, congure the same redirection seings for the HTTP and HTTPS protocols. That way, if a

user types a partial URL into Internet Explorer, such as mycompany.com, and that site automatically redirects

from HTTP to HTTPS, the URL Content Redirection feature will work as expected. In this example, if you

set a rule for HTTPS but do not set the same redirection seing for HTTP, the partial URL that the user types

is not redirected.

To create a global URL content redirection seing, which is visible across the pod federation, see “Create a

Global URL Content Redirection Seing,” on page 62.

Prerequisites

Become familiar with vdmutil command-line interface options and requirements and verify that you have

sucient privileges to run the the vdmutil command. See “Using the vdmutil Command-Line Utility,” on

page 59.

Procedure

1 Log in to the Connection Server instance.

2Run the vdmutil command with the --createURLSetting option to create the URL content redirection

seing.

vdmutil --createURLSetting --urlSettingName value --urlRedirectionScope LOCAL

[--description value] [--urlScheme value] [--entitledApplication value | --entitledDesktop

value] [--agentURLPattern value]

Option Description

--urlSettingName Unique name for the URL content redirection seing. The name can

contain between 1 and 64 characters.

--urlRedirectionScope Scope of the URL content redirection seing. Specify LOCAL to make the

seing visible only in the local pod.

--description Description of the URL content redirection seing. The description can

contain between 1 and 1024 characters.

--urlScheme Protocol to which the URL content redirection seing applies, for example,

hp, hps, mailto, or callto.

--entitledApplication Display name of a local application pool to use to open the specied URLs,

for example, iexplore-2012. You can also use this option to specify the

display name of a local RDS desktop pool.

--entitledDesktop Display name of a local desktop pool to use to open the specied URLs, for

example, xx. For RDS desktop pools, use the --entitledApplication

option.

--agentURLPattern A quoted string that species the URL that should be opened on the

remote desktop or application. You must include the protocol prex. You

can use wildcards to specify a URL paern that matches multiple URLs.

For example, if you type "http://google.*", all URLs that include the

text google are redirected to the remote desktop or application pool that

you specied. If you type .* (dot star), all URLs are redirected to the

remote desktop or application.

Chapter 3 Configuring URL Content Redirection

VMware, Inc. 61

3(Optional) Run the vdmutil command with the --updateURLSetting option to add more protocols,

URLs, and local resources to the URL content redirection seing that you created.

vdmutil --updateURLSetting --urlSettingName value --urlRedirectionScope LOCAL

[--description value][--urlScheme value][--entitledApplication value | --entitledDesktop

value] [--agentURLPattern value]

The options are the same as for the vdmutil command with the --createURLSetting option.

Example: Creating a Local URL Content Redirection Setting

The following example creates a local URL content redirection seing called url-filtering that redirects all

client URLs that include the text http://google.* to the application pool called iexplore2012.

VdmUtil --createURLSetting --urlSettingName url-filtering --urlScheme http

--entitledApplication iexplore2012 --agentURLPattern "http://google.*"

--urlRedirectionScope LOCAL --authAs johndoe --authDomain mydomain --authPassword secret

The following example updates the url-filtering seing to also redirect all client URLs that contain the

text https://google.* to the application pool called iexplore2012.

vdmutil --updateURLSetting --urlSettingName url-filtering --urlScheme https

--entitledApplication iexplore2012 --agentURLPattern "https://google.*"

--urlRedirectionScope LOCAL --authAs johndoe --authDomain mydomain --authPassword secret

The following example updates the url-filtering seing to redirect all client URLs that contain the text

mailto://.*.mycompany.com to the application pool called Outlook2008.

vdmutil --updateURLSetting --urlSettingName url-filtering --urlScheme mailto

--entitledApplication Outlook2008 --agentURLPattern "mailto://.*.mycompany.com"

--urlRedirectionScope LOCAL --authAs johndoe --authDomain mydomain --authPassword secret

What to do next

Assign the URL content redirection seing to a user or group. See “Assign a URL Content Redirection

Seing to a User or Group,” on page 64.

Create a Global URL Content Redirection Setting

If you have a Cloud Pod Architecture environment, you can create a global URL content redirection seing

that redirects specic URLs to open on a remote desktop or application in any pod in the pod federation.

A global URL content redirection seing is visible across the pod federation. When you create a global URL

content redirection seing, you can redirect URLs to global resources, such as global desktop entitlements

and global application entitlements.

You can congure any number of protocols, including HTTP, HTTPS, mailto, and callto.

As a best practice, congure the same redirection seings for the HTTP and HTTPS protocols. That way, if a

user types a partial URL into Internet Explorer, such as mycompany.com, and that site automatically redirects

from HTTP to HTTPS, the URL Content Redirection feature will work as expected. In this example, if you

set a rule for HTTPS but do not set the same redirection seing for HTTP, the partial URL that the user types

is not redirected.

For complete information about conguring and managing a Cloud Pod Architecture environment, see the

Administering Cloud Pod Architecture in Horizon 7 document.

To create a local URL content redirection seing, see “Create a Local URL Content Redirection Seing,” on

page 61.

Configuring Remote Desktop Features in Horizon 7

62 VMware, Inc.

Prerequisites

Become familiar with vdmutil command-line interface options and requirements and verify that you have

sucient privileges to run the the vdmutil command. See “Using the vdmutil Command-Line Utility,” on

page 59.

Procedure

1 Log in to any Connection Server instance in the pod federation.

2Run the vdmutil command with the --createURLSetting option to create the URL content redirection

seing.

vdmutil --createURLSetting --urlSettingName value --urlRedirectionScope GLOBAL

[--description value] [--urlScheme value] [--entitledApplication value | --entitledDesktop

value] [--agentURLPattern value]

Option Description

--urlSettingName Unique name for the URL content redirection seing. The name can

contain between 1 and 64 characters.

--urlRedirectionScope Scope of the URL content redirection seing. Specify GLOBAL to make the

seing visible across the pod federation.

--description Description of the URL content redirection seing. The description can

contain between 1 and 1024 characters.

--urlScheme Protocol to which the URL content redirection seing applies, for example,

hp, hps, mailto, or callto.

--entitledApplication Display name of a global application entitlement to use to open the

specied URLs.

--entitledDesktop Display name of a global desktop entitlement to use to open the specied

URLs, for example, GE-1.

--agentURLPattern A quoted string that species the URL that should be opened on the

remote desktop or application. You must include the protocol prex. You

can use wildcards to specify a URL paern that matches multiple URLs.

For example, if you type "hp://google.*", all URLs that include the text

google are redirected to the remote desktop or application. If you type .*

(dot star), all URLs are redirected to the remote desktop or application.

3(Optional) Run the vdmutil command with the --updateURLSetting option to add more protocols,

URLs, and global resources to the URL content redirection seing that you created.

vdmutil --updateURLSetting --urlSettingName value --urlRedirectionScope GLOBAL

[--description value][--urlScheme value][--entitledApplication value | --entitledDesktop

value] [--agentURLPattern value]

The options are the same as for the vdmutil command with the --createURLSetting option.

Example: Configuring a Global URL Content Redirection Setting

The following example creates a global URL content redirection seing called Operations-Setting that

redirects all client URLs that include the text http://google.* to the global application entitlement called

GAE1.

vdmutil --createURLSetting --urlSettingName Operations-Setting --urlRedirectionScope GLOBAL

--urlScheme http --entitledApplication GAE1 --agentURLPattern "http://google.*" --authAs johndoe

--authDomain mydomain --authPassword secret

Chapter 3 Configuring URL Content Redirection

VMware, Inc. 63

The following example updates the Operations-Setting seing to also redirect all URLs that contain the text

https://google.* to the global application entitlement called GAE1.

vdmutil --updateURLSetting --urlSettingName Operations-Setting --urlRedirectionScope GLOBAL

--urlScheme https --entitledApplication GAE1 --agentURLPattern "https://google.*" -authAs

johndoe

--authDomain mydomain --authPassword secret

The following example updates the Operations-Setting seing to redirect all URLs that contain the text

"mailto://.*.mycompany.com" to the global application entitlement called GA2.

vdmutil --updateURLSetting --urlSettingName Operations-Setting --urlRedirectionScope GLOBAL

--urlScheme mailto --entitledApplication GAE2 --agentURLPattern "mailto://.*.mycompany.com"

--authAs johndoe --authDomain mydomain --authPassword secret

What to do next

Assign the URL content redirection seing to a user or group. See “Assign a URL Content Redirection

Seing to a User or Group,” on page 64.

Assign a URL Content Redirection Setting to a User or Group

After you create a URL content redirection seing, you can assign it to an Active Directory user or group.

Prerequisites

Become familiar with vdmutil command-line interface options and requirements and verify that you have

sucient privileges to run the vdmutil command. See “Using the vdmutil Command-Line Utility,” on

page 59.

Procedure

nTo assign a URL content redirection seing to a user, run the vdmutil command with the

--addUserURLSetting option.

vdmutil --addUserURLSetting --urlSettingName value --userName value

Option Description

--urlSettingName Name of the URL content redirection seing to assign.

--userName Name of the Active Directory user in domain\username format.

nTo assign a URL content redirection seing to a group, run the vdmutil command with the

--addGroupURLSetting option.

vdmutil --addGroupURLSetting --urlSettingName value --groupName value

Option Description

--urlSettingName Name of the URL content redirection seing to assign.

--groupName Name of the Active Directory group in domain\group format.

Example: Assigning a URL Content Redirection Setting

The following example assigns the URL content redirection seing called url-filtering to the user named

mydomain\janedoe.

vdmutil --addUserURLSetting --authAs johndoe --authDomain mydomain

--authPassword secret --urlSettingName url-filtering --userName mydomain\janedoe

Configuring Remote Desktop Features in Horizon 7

64 VMware, Inc.

The following example assigns the URL content redirection seing called url-filtering to the group called

mydomain\usergroup.

vdmutil --addGoupURLSetting --authAs johndoe --authDomain mydomain

--authPassword secret --urlSettingName url-filtering --groupName mydomain\usergroup

What to do next

Verify your URL content redirection seings. See “Test a URL Content Redirection Seing,” on page 65.

Test a URL Content Redirection Setting

After you create and assign a URL content redirection seing, perform certain steps to verify that the seing

is working properly.

Prerequisites

Become familiar with vdmutil command-line interface options and requirements and verify that you have

sucient privileges to run the the vdmutil command. See “Using the vdmutil Command-Line Utility,” on

page 59.

Procedure

1 Log in to the Connection Server instance.

2Run the vdmutil command with the --readURLSetting option.

For example:

vdmutil --readURLSetting --urlSettingName url-filtering --authAs johndoe

--authDomain mydomain --authPassword secret

The command displays detailed information about the URL content redirection seing. For example,

the following command output for the url-filtering seing shows that HTTP and HTTPS URLs that

contain the text google.* are redirected from the client to the local application pool named

iexplore2012.

URL Redirection setting url-filtering

Description : null

Enabled : true

Scope of URL Redirection Setting : LOCAL

URL Scheme And Local Resource handler pairs

URL Scheme : http

Handler type : APPLICATION

Handler Resource name : iexplore2012

URL Scheme : https

Handler type : APPLICATION

Handler Resource name : iexplore2012

AgentPatterns

https://google.*

http://google.*

ClientPatterns

No client patterns configured

3 On a Windows client machine, open Horizon Client, connect to the Connection Server instance, click

URLs that match the URL paerns congured in the seing, and verify that the URLs are redirected as

expected.

Chapter 3 Configuring URL Content Redirection

VMware, Inc. 65

4 On the same Windows client machine, open the registry editor (regedit) and check the registry keys in

the path \Computer\HKEY_CURRENT_USER\Software\Vmware. Inc.\VMware VDM\URLRedirection\.

You should see a key for each protocol specied in the seing. You can click a protocol to see the rules

associated with that protocol. For example, agentRules shows the URLs that are being redirected,

brokerHostName shows the IP address or fully qualied host name of the Connection Server instance

that is used when redirecting the URLs, and remoteItem shows the display name of the desktop or

application pool that handles the redirected URLs.

Managing URL Content Redirection Settings

You can use vdmutil commands to manage your URL content redirection seings.

You must specify the --authAs, --authDomain, and --authPassword options with all commands. For

more information, see “Using the vdmutil Command-Line Utility,” on page 59.

Displaying Settings

Run the vdmutil command with the --listURLSetting option to list the names of all congured URL

content redirection seings.

vdmutil --listURLSetting

Run the vdmutil command with the --readURLSetting to view detailed information about a particular

URL content redirection seing.

vdmutil --readURLSetting --urlSettingName value

Deleting a Setting

Run the vdmutil command with the --deleteURLSetting option to delete a URL content redirection

seing.

vdmutil --deleteURLSetting --urlSettingName value

Disabling and Enabling a Setting

Run the vdmutil command with the --disableURLSetting option to disable a URL content redirection

seing.

vdmutil --disableURLSetting --urlSettingName value

Run the vdmutil with the --enableURLSeing option to enable a URL content redirection seing that was

disabled.

vdmutil --enableURLSetting --urlSettingName value

Removing a User or Group From a Setting

Run the vdmutil command with the --removeUserURLSetting option to remove a user from a URL

content redirection seing.

vdmutil --removeUserURLSetting --urlSettingName value --userName value

Run the vdmutil command with the --removeGroupURLSetting option to remove a group from a URL

content redirection seing.

vdmutil --removeGroupURLSetting --urlSettingName value --userGroup value

Use the format domain\username or domain\groupname when specifying a user or group name.

Configuring Remote Desktop Features in Horizon 7

66 VMware, Inc.

Using Group Policy Settings to Configure Client-to-Agent Redirection

The URL Content Redirection ADMX template le (urlRedirection-enUS.admx) contains group policy

seings that you can use to create rules that redirect URLs from the client to a remote desktop or application

(client-to-agent redirection).

N The preferred method for conguring client-to-agent redirection is to use the vdmutil command-line

interface. Because GPOs are not supported by macOS, you cannot use GPOs to congure client-to-agent

conguration if you have macOS clients.

To create a rule for client-to-agent redirection, you use the remoteItem option to specify the display name of

a remote desktop or application pool and the agentRules option to specify the URLs that should be

redirected to the remote desktop or application. You must also use the brokerHostname option to specify

the IP address or fully qualied domain name of the Connection Server host to use when redirecting the

URLs to a remote desktop or application.

For example, for security purposes you might want all HTTP URLs that point to the company network to be

opened in a remote desktop or application. In this case, you might set the agentRules option

to .*.mycompany.com.

For URL Content Redirection template le installation instructions, see “Add the URL Content Redirection

ADMX Template to a GPO,” on page 55.

URL Content Redirection Limitations

The behavior of the URL Content Redirection feature might have certain unexpected results.

nIf the URL opens a country-specic page based on the locale, the source of the link determines the locale

page that is opened. For example, if the remote desktop (agent source) resides in a data center in Japan

and the user computer resides in the U.S., if the URL is redirected from the agent to the client machine,

the page that opens on the U.S. client is the Japanese page.

nIf users create favorites from Web pages, the favorites are created after redirection. For example, if a

user clicks a link on the client machine and the URL is redirected to a remote desktop (agent), and the

user creates a favorite for that page, the favorite is created on the agent. The next time the user opens

the browser on the client machine, the user might expect to nd the favorite on the client machine, but

the favorite was stored on the remote desktop (agent source).

nFiles that users download appear on the machine where the browser was used to open the URL, for

example, when a user clicks a link on the client machine and the URL is redirected to a remote desktop.

If the link downloaded a le, or if the link is for a Web page where the user downloads a le, the le is

downloaded to the remote desktop rather than to the client machine.

nIf you install Horizon Agent and Horizon Client on the same machine, you can enable URL Content

Redirection in Horizon Agent or in Horizon Client, but not in both. On this machine, you can set up

either client-to-agent redirection or agent-to-client redirection, but not both.

Unsupported URL Content Redirection Features

The URL Content Redirection feature does not work in certain circumstances.

Shortened URLs

Shortened URLs, such as https://goo.gl/abc, can be redirected based on ltering rules, but the ltering

mechanism does not examine the original unshortened URL.

Chapter 3 Configuring URL Content Redirection

VMware, Inc. 67

For example, if you have a rule that redirects URLs that contain acme.com, an original URL, such as

http://www.acme.com/some-really-long-path, and a shortened URL of the original URL, such as

https://goo.gl/xyz, the original URL is redirected, but the shortened URL is not redirected.

You can work around this limitation by creating rules to block or redirect URLs from the Web sites most

often used for shortening URLs.

Embedded HTML Pages

Embedded HTML pages bypass URL redirection, for example, when a user goes to a URL that does not

match a URL redirection rule. If a page contains an embedded HTML page (an iFrame or inline frame) that

contains a URL that does match a redirection rule, the URL redirection rule does not work. The rule works

only on the top-level URL.

Disabled Internet Explorer Plug-Ins

URL Content Redirection does not work in situations where Internet Explorer plug-ins are disabled, for

example, when a user switches to InPrivate Browsing in Internet Explorer. People use private browsing so

that Web pages and les downloaded from Web pages will not be logged in to the browsing and download

history on their computer. This limitation occurs because the URL Redirection feature requires a certain

Internet Explorer plug-in to be enabled, and private browsing disables these plug-ins.

You can work around this limitation by using the GPO seing to prevent users from disabling plug-ins.

These seings include "Do not allow users to enable or disable add-ons" and "Automatically enable newly

installed add-ons." In the Group Policy Management Editor, these seings are under Computer

 > Administrative Templates > Windows Components > Internet Explorer.

To work around this limitation specically for Internet Explorer, use the GPO seing to disable InPrivate

mode. This seing is called "Turn o InPrivate Browsing." In the Group Policy Management Editor, these

seings are under Computer  > Administrative Templates > Windows Components >

Internet Explorer > Privacy.

These workarounds are best practices and can prevent issues with redirection that situations other than

private browsing can cause.

Windows 10 Universal App Is the Default Handler for a Protocol

URL redirection does not work if a Windows 10 Universal app is the default handler for a protocol specied

in a link. Universal applications are built on the Universal Windows Platform so that they can be

downloaded to PCs, tablets, and phones, include the Microsoft Edge browser, Mail, Maps, Photos, Grove

Music and others.

If you click a link for which one of these applications is the default handler, the URL is not redirected. For

example, if a user clicks an email link in an application and the default email application is the Mail

universal app, the URL specied in the link is not redirected.

You can work around this limitation by making a dierent application the default handler of the protocol of

URLs that you want to redirect. For example, if Edge is the default browser, make Internet Explorer the

default browser.

Secure Boot Enabled Machines

Machines that have secure boot enabled leave the URL Content Redirection feature disabled. URLs cannot

be redirected from these machines. URLs can be redirected to these machines.

Configuring Remote Desktop Features in Horizon 7

68 VMware, Inc.

Using USB Devices with Remote

Desktops and Applications 4

Administrators can congure the ability to use USB devices, such as thumb ash drives, cameras, VoIP

(voice-over-IP) devices, and printers, from a remote desktop. This feature is called USB redirection, and it

supports using the Blast Extreme, PCoIP, or Microsoft RDP display protocol. A remote desktop can

accommodate up to 128 USB devices.

You can also redirect locally connected USB thumb ash drives and hard disks for use in RDS desktops and

applications. Other types of USB devices, including other types of storage devices, are not supported in RDS

desktops and applications.

When you use this feature in desktop pools that are deployed on single-user machines, most USB devices

that are aached to the local client system become available in the remote desktop. You can even connect to

and manage an iPad from a remote desktop. For example, you can sync your iPad with iTunes installed in

your remote desktop. On some client devices, such as Windows and Mac computers, the USB devices are

listed in a menu in Horizon Client. You use the menu to connect and disconnect the devices.

In most cases, you cannot use a USB device in your client system and in your remote desktop or application

at the same time. Only a few types of USB devices can be shared between a remote desktop and the local

computer. These devices include smart card readers and human interface devices such as keyboards and

pointing devices.

Administrators can specify which types of USB devices end users are allowed to connect to. For composite

devices that contain multiple types of devices, such as a video input device and a storage device, on some

client systems, administrators can split the device so that one device (for example, the video input device) is

allowed but the other device (for example, the storage device) is not.

The USB redirection feature is available only on some types of clients. To nd out whether this feature is

supported on a particular type of client, see the feature support matrix included in the "Using

VMware Horizon Client" document for the specic type of desktop or mobile client device. Go to

hps://www.vmware.com/support/viewclients/doc/viewclients_pubs.html.

I When you deploy the USB redirection feature, you can take steps to protect your organization

from the security vulnerabilities that can aect USB devices. See “Deploying USB Devices in a Secure

Horizon 7 Environment,” on page 73.

This chapter includes the following topics:

n“Limitations Regarding USB Device Types,” on page 70

n“Overview of Seing Up USB Redirection,” on page 71

n“Network Trac and USB Redirection,” on page 72

n“Automatic Connections to USB Devices,” on page 72

n“Deploying USB Devices in a Secure Horizon 7 Environment,” on page 73

VMware, Inc. 69

n“Using Log Files for Troubleshooting and to Determine USB Device IDs,” on page 75

n“Using Policies to Control USB Redirection,” on page 76

n“Troubleshooting USB Redirection Problems,” on page 86

Limitations Regarding USB Device Types

Although Horizon 7 does not explicitly prevent any devices from working in a remote desktop, due to

factors such as network latency and bandwidth, some devices work beer than others. By default, some

devices are automatically ltered, or blocked, from being used.

In Horizon 6.0.1, together with Horizon Client 3.1 or later, you can plug USB 3.0 devices into USB 3.0 ports

on the client machine, on Windows, Linux, and Mac clients. USB 3.0 devices are supported only with a

single stream. Because multiple stream support is not implemented in this release, USB device performance

is not enhanced. Some USB 3.0 devices that require a constant high throughput to function correctly might

not work in a VDI session, due to network latency.

In earlier View releases, although super-speed USB 3.0 devices are not supported, USB 3.0 devices do often

work when plugged into a USB 2.0 port on the client machine. However, there might be exceptions,

depending on the type of USB chipset on the motherboard of the client system.

The following types of devices might not be suitable for USB redirection to a remote desktop that is

deployed on a single-user machine:

nDue to the bandwidth requirements of webcams, which typically consume more than 60 Mbps of

bandwidth, webcams are not supported through USB redirection. For webcams, you can use the Real-

Time Audio-Video feature.

nThe redirection of USB audio devices depends on the state of the network and is not reliable. Some

devices require a high data throughput even when they are idle. If you have the Real-Time Audio-

Video feature, audio input and output devices will work well using that feature, and you do not need to

use USB redirection for those devices.

nUSB CD/DVD burning is not supported.

nPerformance of some USB devices varies greatly, depending on the network latency and reliability,

especially over a WAN. For example, a single USB storage device read-request requires three round-

trips between the client and the remote desktop. A read of a complete le might require multiple USB

read operations, and the larger the latency, the longer the round-trip will take.

The le structure can be very large, depending on the format. Large USB disk drives can take several

minutes to appear in the desktop. Formaing a USB device as NTFS rather than FAT helps to decrease

the initial connection time. An unreliable network link causes retries, and performance is further

reduced.

Similarly, USB CD/DVD readers, as well as scanners and touch devices such as signature tablets, do not

work well over a latent network such as a WAN.

nThe redirection of USB scanners depends on the state of the network, and scans might take longer than

normal to complete.

You can redirect the following types of devices to a published desktop or application on an RDS host:

nUSB thumb ash drives

nUSB hard disks

Configuring Remote Desktop Features in Horizon 7

70 VMware, Inc.

Beginning with Horizon 7 version 7.0.2, you can redirect signature pads, dictation foot pedals, and some

Wacom tablets to a published desktop or application. These devices are disabled by default in Horizon 7

version 7.0.2. To enable these devices, delete the Windows registry key seings ExcludeAllDevices and

IncludeFamily from the following path: HKLM\Software\Policies\VMware, Inc\VMware VDM\Agent\USB. These

devices are enabled by default in Horizon 7 version 7.0.3 and later.

You cannot redirect other types of USB devices, and other types of USB storage devices such as security

storage drives and USB CD-ROM, to a published desktop or application.

Overview of Setting Up USB Redirection

To set up your deployment so that end users can connect removable devices, such as USB ash drives,

cameras, and headsets, you must install certain components on both the remote desktop or RDS host and the

client device, and you must verify that the global seing for USB devices is enabled in View Administrator.

This checklist includes both required and optional tasks for seing up USB redirection in your enterprise.

The USB redirection feature is available only on some types of clients, such as Windows, Mac, and partner-

supplied Linux clients. To nd out whether this feature is supported on a particular type of client, see the

feature support matrix included in the "Using VMware Horizon Client" document for the specic type of

client device. Go to hps://www.vmware.com/support/viewclients/doc/viewclients_pubs.html.

I When you deploy the USB redirection feature, you can take steps to protect your organization

from the security vulnerabilities that can aect USB devices. For example, you can use group policy seings

to disable USB redirection for some remote desktops and users, or to restrict which types of USB devices can

be redirected. See “Deploying USB Devices in a Secure Horizon 7 Environment,” on page 73.

1 When you run the Horizon Agent installation wizard on the remote desktop source or RDS host, be

sure to include the USB Redirection component.

This component is deselected by default. You must select the component to install it.

2 When you run the VMware Horizon Client installation wizard on the client system, be sure to include

the USB Redirection component.

This component is included by default.

3 Verify that access to USB devices from a remote desktop or application is enabled in View

Administrator.

In View Administrator, go to Policies > Global Policies and verify that USB access is set to Allow.

4 (Optional) Congure Horizon Agent group policies to specify which types of devices are allowed to be

redirected.

See “Using Policies to Control USB Redirection,” on page 76.

5 (Optional) Congure similar seings on the client device.

You can also congure whether devices are automatically connected when Horizon Client connects to

the remote desktop or application, or when the end user plugs in a USB device. The method of

conguring USB seings on the client device depends on the type of device. For example, for Windows

client endpoints, you can congure group policies, whereas for Mac endpoints, you use a command-

line command. For instructions, see the "Using VMware Horizon Client" document for the specic type

of client device.

6 Have end users connect to a remote desktop or application and plug their USB devices into the local

client system.

If the driver for the USB device is not already installed in the remote desktop or RDS host, the guest

operating system detects the USB device and searches for a suitable driver, just as it would on a

physical Windows computer.

Chapter 4 Using USB Devices with Remote Desktops and Applications

VMware, Inc. 71

Network Traffic and USB Redirection

USB redirection works independently of the display protocol (RDP or PCoIP) and USB trac usually uses

TCP port 32111.

Network trac between a client system and a remote desktop or application can travel various routes,

depending on whether the client system is inside the corporate network and how the administrator has

chosen to set up security.

1 If the client system is inside the corporate network, so that a direct connection can be made between the

client and desktop or application, USB trac uses TCP port 32111.

2 If the client system is outside the corporate network, the client can connect through a View security

server.

A security server resides within a DMZ and acts as a proxy host for connections inside your trusted

network. This design provides an additional layer of security by shielding the View Connection Server

instance from the public-facing Internet and by forcing all unprotected session requests through the

security server.

A DMZ-based security server deployment requires a few ports to be opened on the rewall to allow

clients to connect with security servers inside the DMZ. You must also congure ports for

communication between security servers and the View Connection Server instances in the internal

network.

For information on specic ports, see "Firewall Rules for DMZ-Based Security Servers" in the View

Architecture Planning Guide.

3 If the client system is outside the corporate network, you can use View Administrator to enable the

HTTPS Secure Tunnel. The client then makes a further HTTPS connection to the View Connection

Server or security server host when users connect to a remote desktop or application. The connection is

tunneled using HTTPS port 443 to the security server, and then the onward connection for USB trac

from the server to the remote desktop or application uses TCP port 32111. USB device performance is

slightly degraded when using this tunnel.

N If you are using a zero client, USB trac is redirected using a PCoIP virtual channel, rather than

through TCP 32111. Data is encapsulated and encrypted by the PCoIP Secure Gateway using TCP/UDP

port 4172. If you are using only zero clients, it is not necessary to open TCP port 32111.

Automatic Connections to USB Devices

On some client systems, administrators, end users, or both can congure automatic connections of USB

devices to a remote desktop. Automatic connections can be made either when the user plugs a USB device in

to the client system or when the client connects to the remote desktop.

Some devices, such as smart phones and tablets, require automatic connections because these devices are

restarted, and therefore disconnected, during an upgrade. If these devices are not set to automatically

reconnect to the remote desktop, during an upgrade, after the devices restart, they connect to the local client

system instead.

Conguration properties for automatic USB connections that administrators set on the client, or that end

users set by using a Horizon Client menu item, apply to all USB devices unless the devices are congured to

be excluded from USB redirection. For example, in some client versions, webcams and microphones are

excluded from USB redirection by default because these devices work beer through the Real-Time Audio-

Configuring Remote Desktop Features in Horizon 7

72 VMware, Inc.

Video feature. In some cases, a USB device might not be excluded from redirection by default but might

require administrators to explicitly exclude the device from redirection. For example, the following types of

USB devices are not good candidates for USB redirection and must not be automatically connected to a

remote desktop:

nUSB Ethernet devices. If you redirect a USB Ethernet device, your client system might lose network

connectivity if that device is the only Ethernet device.

nTouch screen devices. If you redirect a touch screen device, the remote desktop will receive touch input

but not keyboard input.

If you have set the remote desktop to autoconnect USB devices, you can congure a policy to exclude

specic devices such as touch screens and network devices. For more information, see “Conguring Filter

Policy Seings for USB Devices,” on page 79.

On Windows clients, as an alternative to using seings that automatically connect all but excluded devices,

you can edit a conguration le on the client that sets Horizon Client to reconnect only a specic device or

devices, such as smart phones and tablets, to the remote desktop. For instructions, see Using

VMware Horizon Client for Windows.

Deploying USB Devices in a Secure Horizon 7 Environment

USB devices can be vulnerable to a security threat called BadUSB, in which the rmware on some USB

devices can be hijacked and replaced with malware. For example, a device can be made to redirect network

trac or to emulate a keyboard and capture keystrokes. You can congure the USB redirection feature to

protect your Horizon 7 deployment against this security vulnerability.

By disabling USB redirection, you can prevent any USB devices from being redirected to your users'

Horizon 7 desktops and applications. Alternatively, you can disable redirection of specic USB devices,

allowing users to have access only to specic devices on their desktops and applications.

The decision whether to take these steps depends on the security requirements in your organization. These

steps are not mandatory. You can install USB redirection and leave the feature enabled for all USB devices in

your Horizon 7 deployment. At a minimum, consider seriously the extent to which your organization

should try to limit its exposure to this security vulnerability.

Disabling USB Redirection for All Types of Devices

Some highly secure environments require you to prevent all USB devices that users might have connected to

their client devices from being redirected to their remote desktops and applications. You can disable USB

redirection for all desktop pools, for specic desktop pools, or for specic users in a desktop pool.

Use any of the following strategies, as appropriate for your situation:

nWhen you install Horizon Agent on a desktop image or RDS host, deselect the USB redirection setup

option. (The option is deselected by default.) This approach prevents access to USB devices on all

remote desktops and applications that are deployed from the desktop image or RDS host.

nIn Horizon Administrator, edit the USB access policy for a specic pool to either deny or allow access.

With this approach, you do not have to change the desktop image and can control access to USB devices

in specic desktop and application pools.

Only the global USB access policy is available for RDS desktop and application pools. You cannot set

this policy for individual RDS desktop or application pools.

nIn View Administrator, after you set the policy at the desktop or application pool level, you can

override the policy for a specic user in the pool by selecting the User Overrides seing and selecting a

user.

nSet the Exclude All Devices policy to true, on the Horizon Agent side or on the client side, as

appropriate.

Chapter 4 Using USB Devices with Remote Desktops and Applications

VMware, Inc. 73

nUse Smart Policies to create a policy that disables the USB redirection Horizon Policy seing. With this

approach, you can disable USB redirection on a specic remote desktop if certain conditions are met.

For example, you can congure a policy that disables USB redirection when users connect to a remote

desktop from outside your corporate network.

If you set the Exclude All Devices policy to true, Horizon Client prevents all USB devices from being

redirected. You can use other policy seings to allow specic devices or families of devices to be redirected.

If you set the policy to false, Horizon Client allows all USB devices to be redirected except those that are

blocked by other policy seings. You can set the policy on both Horizon Agent and Horizon Client. The

following table shows how the Exclude All Devices policy that you can set for Horizon Agent and

Horizon Client combine to produce an eective policy for the client computer. By default, all USB devices

are allowed to be redirected unless otherwise blocked.

Table 4‑1. Effect of Combining Exclude All Devices Policies

Exclude All Devices Policy on

Horizon Agent

Exclude All Devices Policy on

Horizon Client

Combined Effective Exclude All

Devices Policy

false or not dened (include all USB

devices)

false or not dened (include all USB

devices)

Include all USB devices

false (include all USB devices) true (exclude all USB devices) Exclude all USB devices

true (exclude all USB devices) Any or not dened Exclude all USB devices

If you have set Disable Remote Configuration Download policy to true, the value of Exclude All Devices on

Horizon Agent is not passed to Horizon Client, but Horizon Agent and Horizon Client enforce the local

value of Exclude All Devices.

These policies are included in the Horizon Agent Conguration ADMX template le (vdm_agent.admx).

Disabling USB Redirection for Specific Devices

Some users might have to redirect specic locally-connected USB devices so that they can perform tasks on

their remote desktops or applications. For example, a doctor might have to use a Dictaphone USB device to

record patients' medical information. In these cases, you cannot disable access to all USB devices. You can

use group policy seings to enable or disable USB redirection for specic devices.

Before you enable USB redirection for specic devices, make sure that you trust the physical devices that are

connected to client machines in your enterprise. Be sure that you can trust your supply chain. If possible,

keep track of a chain of custody for the USB devices.

In addition, educate your employees to ensure that they do not connect devices from unknown sources. If

possible, restrict the devices in your environment to those that accept only signed rmware updates, are

FIPS 140-2 Level 3-certied, and do not support any kind of eld-updatable rmware. These types of USB

devices are hard to source and, depending on your device requirements, might be impossible to nd. These

choices might not be practical, but they are worth considering.

Each USB device has its own vendor and product ID that identies it to the computer. By conguring

Horizon Agent Conguration group policy seings, you can set an include policy for known device types.

With this approach, you remove the risk of allowing unknown devices to be inserted into your environment.

For example, you can prevent all devices except a known device vendor and product ID,

vid/pid=0123/abcd, from being redirected to the remote desktop or application:

ExcludeAllDevices Enabled

IncludeVidPid o:vid-0123_pid-abcd

N This example conguration provides protection, but a compromised device can report any vid/pid,

so a possible aack could still occur.

Configuring Remote Desktop Features in Horizon 7

74 VMware, Inc.

By default, Horizon 7 blocks certain device families from being redirected to the remote desktop or

application. For example, HID (human interface devices) and keyboards are blocked from appearing in the

guest. Some released BadUSB code targets USB keyboard devices.

You can prevent specic device families from being redirected to the remote desktop or application. For

example, you can block all video, audio, and mass storage devices:

ExcludeDeviceFamily o:video;audio;storage

Conversely, you can create a whitelist by preventing all devices from being redirected but allowing a specic

device family to be used. For example, you can block all devices except storage devices:

ExcludeAllDevices Enabled

IncludeDeviceFamily o:storage

Another risk can arise when a remote user logs into a desktop or application and infects it. You can prevent

USB access to any Horizon 7 connections that originate from outside the company rewall. The USB device

can be used internally but not externally.

Be aware that if you block TCP port 32111 to disable external access to USB devices, time zone

synchronization will not work because port 32111 is also used for time zone synchronization. For zero

clients, the USB trac is embedded inside a virtual channel on UDP port 4172. Because port 4172 is used for

the display protocol as well as for USB redirection, you cannot block port 4172. If required, you can disable

USB redirection on zero clients. For details, see the zero client product literature or contact the zero client

vendor.

Seing policies to block certain device families or specic devices can help to mitigate the risk of being

infected with BadUSB malware. These policies do not mitigate all risk, but they can be an eective part of an

overall security strategy.

Using Log Files for Troubleshooting and to Determine USB Device IDs

Useful log les for USB are located on both the client system and the remote desktop operating system or

RDS host. Use the log les in both locations for troubleshooting. To nd product IDs for specic devices, use

the client-side logs.

If you are trying to congure USB device spliing or ltering, or if you are trying to determine why a

particular device does not appear in a Horizon Client menu, look in the client-side logs. Client logs are

produced for the USB arbitrator and the Horizon View USB Service. Logging on Windows and Linux clients

is enabled by default. On Mac clients, logging is disabled by default. To enable logging on Mac clients, see

the Using VMware Horizon Client for Mac document.

When you congure policies for spliing and ltering out USB devices, some values you set require the VID

(vendor ID) and PID (product ID) for the USB device. To nd the VID and PID, you can search on the

Internet for the product name combined with vid and pid. Alternatively, you can look in the client-side log

le after you plug in the USB device to the local system when Horizon Client is running. The following table

shows the default location of the log les.

Table 4‑2. Log File Locations

Client or Agent Path to Log Files

Windows client %PROGRAMDATA%\VMware\VDM\logs\debug-*.txt

C:\Windows\Temp\vmware-SYSTEM\vmware-usbarb-*.log

Horizon Agent %PROGRAMDATA%\VMware\VDM\logs\debug-*.txt

Chapter 4 Using USB Devices with Remote Desktops and Applications

VMware, Inc. 75

Table 4‑2. Log File Locations (Continued)

Client or Agent Path to Log Files

Mac client /var/root/Library/Logs/VMware/vmware-view-usbd-xxxx.log

/Library/Logs/VMware/vmware-usbarbitrator-xxxx.log

Linux client (Default location) /tmp/vmware-root/vmware-view-usbd-*.log

If a problem with the device occurs after the device is redirected to the remote desktop or application,

examine both the client- and agent-side logs.

Using Policies to Control USB Redirection

You can congure USB policies for both the remote desktop or application (Horizon Agent) and

Horizon Client. These policies specify whether the client device should split composite USB devices into

separate components for redirection. You can split devices to restrict the types of USB devices that the client

makes available for redirection, and to make Horizon Agent prevent certain USB devices from being

forwarded from a client computer.

If you have older versions of Horizon Agent or Horizon Client installed, not all the features of the USB

redirection policies are available. Table 4-3 shows how Horizon 7 applies the policies for dierent

combinations of Horizon Agent and Horizon Client.

Table 4‑3. Compatibility of USB Policy Settings

Horizon Agent

Version

Horizon

Client

Version Effect of USB Policy Settings on USB Redirection

5.1 or later 5.1 or later USB policy seings are applicable to both Horizon Agent and Horizon Client. You

can use Horizon Agent USB policy seings to block USB devices from being

forwarded to a desktop. Horizon Agent can send device spliing and ltering policy

seings to Horizon Client. You can use Horizon Client USB policy seings to

prevent USB devices from being redirected from a client computer to a desktop.

N In View Agent 6.1 or later and Horizon Client 3.3 or later, these USB

redirection policy seings apply to RDS desktops and applications as well as to

remote desktops that run on single-user machines.

5.1 or later 5.0.x or earlier USB policy seings apply only to Horizon Agent. You can use Horizon Agent USB

policy seings to block USB devices from being forwarded to a desktop. You cannot

use Horizon Client USB policy seings to control which devices can be redirected

from a client computer to a desktop. Horizon Client cannot receive device spliing

and ltering policy seings from Horizon Agent. Existing registry seings for USB

redirection by Horizon Client remain valid.

5.0.x or earlier 5.1 or later USB policy seings apply only to Horizon Client. You can use Horizon Client USB

policy seings to prevent USB devices from being redirected from a client computer

to a desktop. You cannot use Horizon Agent USB policy seings to block USB

devices from being forwarded to a desktop. Horizon Agent cannot send device

spliing and ltering policy seings to Horizon Client.

5.0.x or earlier 5.0.x or earlier USB policy seings do not apply. Existing registry seings for USB redirection by

Horizon Client remain valid.

If you upgrade Horizon Client, any existing registry seings for USB redirection, such as

HardwareIdFilters, remain valid until you dene USB policies for Horizon Client.

On client devices that do not support client-side USB policies, you can use the USB policies for

Horizon Agent to control which USB devices are allowed to be forwarded from the client to a desktop or

application.

Configuring Remote Desktop Features in Horizon 7

76 VMware, Inc.

Configuring Device Splitting Policy Settings for Composite USB Devices

Composite USB devices consist of a combination of two or more dierent devices, such as a video input

device and a storage device or a microphone and a mouse device. If you want to allow one or more of the

components to be available for redirection, you can split the composite device into its component interfaces,

exclude certain interfaces from redirection and include others.

You can set a policy that automatically splits composite devices. If automatic device spliing does not work

for a specic device, or if automatic spliing does not produce the results your application requires, you can

split composite devices manually.

Automatic Device Splitting

If you enable automatic device spliing Horizon 7 aempts to split the functions, or devices, in a composite

device according to the lter rules that are in eect. For example, a dictation microphone might be split

automatically so that the mouse device remains local to the client, but the rest of the devices are forwarded

to the remote desktop.

The following table shows how the value of the Allow Auto Device Splitting seing determines whether

Horizon Client aempts to split composite USB devices automatically. By default, automatic spliing is

disabled.

Table 4‑4. Effect of Combining Disable Automatic Splitting Policies

Allow Auto Device Splitting Policy

on Horizon Agent

Allow Auto Device Splitting Policy

on Horizon Client

Combined Effective Allow Auto

Device Splitting Policy

Allow - Default Client Setting false (automatic spliing disabled) Automatic spliing disabled

Allow - Default Client Setting true (automatic spliing enabled) Automatic spliing enabled

Allow - Default Client Setting Not dened Automatic spliing enabled

Allow - Override Client Setting Any or not dened Automatic spliing enabled

Not dened Not dened Automatic spliing disabled

N These policies are included in the Horizon Agent Conguration ADMX template le. The ADMX

template le is named (vdm_agent.admx).

By default, Horizon 7 disables automatic spliing, and excludes any audio-output, keyboard, mouse, or

smart-card components of a composite USB device from redirection.

Horizon 7 applies the device spliing policy seings before it applies any lter policy seings. If you have

enabled automatic spliing and do not explicitly exclude a composite USB device from being split by

specifying its vendor and product IDs, Horizon 7 examines each interface of the composite USB device to

decide which interfaces should be excluded or included according to the lter policy seings. If you have

disabled automatic device spliing and do not explicitly specify the vendor and product IDs of a composite

USB device that you want to split, Horizon 7 applies the lter policy seings to the entire device.

If you enable automatic spliing, you can use the Exclude Vid/Pid Device From Split policy to specify the

composite USB devices that you want to exclude from spliing.

Chapter 4 Using USB Devices with Remote Desktops and Applications

VMware, Inc. 77

Manual Device Splitting

You can use the Split Vid/Pid Device policy to specify the vendor and product IDs of a composite USB

device that you want to split. You can also specify the interfaces of the components of a composite USB

device that you want to exclude from redirection. Horizon 7 does not apply any lter policy seings to

components that you exclude in this way.

I If you use the Split Vid/Pid Device policy, Horizon 7 does not automatically include the

components that you have not explicitly excluded. You must specify a lter policy such as Include Vid/Pid

Device to include those components.

Table 4-5 shows the modiers that specify how Horizon Client handles a Horizon Agent device spliing

policy seing if there is an equivalent device spliing policy seing for Horizon Client. These modiers

apply to all device-spliing policy seings.

Table 4‑5. Splitting Modifiers for Device-Splitting Policy Settings on Horizon Agent

Modifier Description

m (merge) Horizon Client applies the Horizon Agent device spliing policy seing in addition to the

Horizon Client device spliing policy seing.

o (override) Horizon Client uses the Horizon Agent device spliing policy seing instead of the

Horizon Client device spliing policy seing.

Table 4-6 shows examples of how Horizon Client processes the seings for Exclude Device From Split by

Vendor/Product ID when you specify dierent spliing modiers.

Table 4‑6. Examples of Applying Splitting Modifiers to Device-Splitting Policy Settings

Exclude Device From Split by

Vendor/Product ID on Horizon Agent

Exclude Device From Split by

Vendor/Product ID on

Horizon Client

Effective Exclude Device From Split

by Vendor/Product ID Policy Setting

Used by Horizon Client

m:vid-XXXX_pid-XXXX vid-YYYY_pid-YYYY vid-XXXX_pid-XXXX;vid-YYYY_pid-

YYYY

o:vid-XXXX_pid-XXXX vid-YYYY_pid-YYYY vid-XXXX_pid-XXXX

m:vid-XXXX_pid-XXXX;vid-

YYYY_pid-YYYY

vid-YYYY_pid-YYYY vid-XXXX_pid-XXXX;vid-YYYY_pid-

YYYY

o:vid-XXXX_pid-XXXX;vid-

YYYY_pid-YYYY

vid-YYYY_pid-YYYY vid-XXXX_pid-XXXX;vid-YYYY_pid-

YYYY

Horizon Agent does not apply the device spliing policy seings on its side of the connection.

Horizon Client evaluates the device spliing policy seings in the following order of precedence.

nExclude Vid/Pid Device From Split

nSplit Vid/Pid Device

A device spliing policy seing that excludes a device from being split takes precedence over any policy

seing to split the device. If you dene any interfaces or devices to be excluded from spliing,

Horizon Client excludes the matching component devices from being available for redirection.

Examples of Setting Policies to Split Composite USB Devices

Set spliing policies for desktops to exclude devices with specic vendor and product IDs from redirection

after automatic spliing and pass these policies to client computers:

nFor Horizon Agent, set the Allow Auto Device Splitting policy to Allow - Override Client Setting.

Configuring Remote Desktop Features in Horizon 7

78 VMware, Inc.

nFor Horizon Agent, se the Exclude VidPid From Split policy to o:vid-xxx_pid-yyyy, where xxx and

yyyy are the appropriate IDs.

Allow automatic device spliing for desktops and specify policies for spliing specic devices on client

computers:

nFor Horizon Agent, set the Allow Auto Device Splitting policy to Allow - Override Client Setting.

nFor the client device, set the Include Vid/Pid Device lter policy to include the specic device that you

want to split; for example, vid-0781_pid-554c.

nFor the client device, set the Split Vid/Pid Device policy to vid-0781_pid-554c(exintf:00;exintf:01)

for example, to split a specied composite USB device so that interface 00 and interface 01 are excluded

from redirection.

Configuring Filter Policy Settings for USB Devices

Filter policy seings that you congure for Horizon Agent and Horizon Client establish which USB devices

can be redirected from a client computer to a remote desktop or application. USB device ltering is often

used by companies to disable the use of mass storage devices on remote desktops, or to block a specic type

of device from being forwarded, such as a USB-to-Ethernet adapter that connects the client device to the

remote desktop.

When you connect to a desktop or application, Horizon Client downloads the Horizon Agent USB policy

seings and uses them in conjunction with the Horizon Client USB policy seings to decide which USB

devices it will allow you to redirect from the client computer.

Horizon 7 applies any device spliing policy seings before it applies the lter policy seings. If you have

split a composite USB device, Horizon 7 examines each of the device's interfaces to decide which should be

excluded or included according to the lter policy seings. If you have not split a composite USB device,

Horizon 7 applies the lter policy seings to the entire device.

The device spliing policies are included in the Horizon Agent Conguration ADMX template le

(vdm_agent.admx).

Interaction of Agent-Enforced USB Settings

The following table shows the modiers that specify how Horizon Client handles a Horizon Agent lter

policy seing for an agent-enforceable seing if an equivalent lter policy seing exists for Horizon Client.

Table 4‑7. Filter Modifiers for Agent-Enforceable Settings

Modifier Description

m (merge) Horizon Client applies the Horizon Agent lter policy seing in addition to the

Horizon Client lter policy seing. In the case of Boolean, or true/false, seings, if the client

policy is not set, the agent seings are used. If the client policy is set, the agent seings are

ignored, except for the Exclude All Devices seing. If the Exclude All Devices policy

is set on the agent side, the policy overrides the client seing.

o (override) Horizon Client uses the Horizon Agent lter policy seing instead of the Horizon Client

lter policy seing.

For example, the following policy on the agent side overrides any include rules on the client side, and only

device VID-0911_PID-149a will have an include rule applied:

IncludeVidPid: o:VID-0911_PID-149a

You can also use asterisks as wildcard characters; for example: o:vid-0911_pid-****

I If you congure the agent side without the o or m modier, the conguration rule is considered

invalid and will be ignored.

Chapter 4 Using USB Devices with Remote Desktops and Applications

VMware, Inc. 79

Interaction of Client-Interpreted USB Settings

The following table shows the modiers that specify how Horizon Client handles a Horizon Agent lter

policy seing for a client-interpreted seing.

Table 4‑8. Filter Modifiers for Client-Interpreted Settings

Modifier Description

Default (d in the registry

seing)

If a Horizon Client lter policy seing does not exist, Horizon Client uses the

Horizon Agent lter policy seing.

If a Horizon Client lter policy seing exists, Horizon Client applies that policy seing and

ignores the Horizon Agent lter policy seing.

Override (o in the

registry seing)

Horizon Client uses the Horizon Agent lter policy seing instead of any equivalent

Horizon Client lter policy seing.

Horizon Agent does not apply the lter policy seings for client-interpreted seings on its side of the

connection.

The following table shows examples of how Horizon Client processes the seings for Allow Smart Cards

when you specify dierent lter modiers.

Table 4‑9. Examples of Applying Filter Modifiers to Client-Interpreted Settings

Allow Smart Cards Setting on

Horizon Agent

Allow Smart Cards Setting on

Horizon Client

Effective Allow Smart Cards Policy

Setting Used by Horizon Client

Disable - Default Client

Setting (d:false in the registry

seing)

true (Allow) true (Allow)

Disable - Override Client

Setting (o:false in the registry

seing)

true (Allow) false (Disable)

If you set the Disable Remote Configuration Download policy to true, Horizon Client ignores any lter

policy seings that it receives from Horizon Agent.

Horizon Agent always applies the lter policy seings in agent-enforceable seings on its side of the

connection even if you congure Horizon Client to use a dierent lter policy seing or disable

Horizon Client from downloading lter policy seings from Horizon Agent. Horizon Client does not report

that Horizon Agent is blocking a device from being forwarded.

Precedence of Settings

Horizon Client evaluates the lter policy seings according to an order of precedence. A lter policy seing

that excludes a matching device from being redirected takes precedence over the equivalent lter policy

seing that includes the device. If Horizon Client does not encounter a lter policy seing to exclude a

device, Horizon Client allows the device to be redirected unless you have set the Exclude All Devices

policy to true. However, if you have congured a lter policy seing on Horizon Agent to exclude the

device, the desktop or application blocks any aempt to redirect the device to it.

Horizon Client evaluates the lter policy seings in order of precedence, taking into account the

Horizon Client seings and the Horizon Agent seings together with the modier values that you apply to

the Horizon Agent seings. The following list shows the order of precedence, with item 1 having the highest

precedence.

1Exclude Path

2Include Path

3Exclude Vid/Pid Device

Configuring Remote Desktop Features in Horizon 7

80 VMware, Inc.

4Include Vid/Pid Device

5Exclude Device Family

6Include Device Family

7Allow Audio Input Devices, Allow Audio Output Devices, Allow HIDBootable, Allow HID (Non

Bootable and Not Mouse Keyboard), Allow Keyboard and Mouse Devices, Allow Smart Cards, and Allow

Video Devices

8 Combined eective Exclude All Devices policy evaluated to exclude or include all USB devices

You can set Exclude Path and Include Path lter policy seings only for Horizon Client. The Allow lter

policy seings that refer to separate device families have equal precedence.

If you congure a policy seing to exclude devices based on vendor and product ID values, Horizon Client

excludes a device whose vendor and product ID values match this policy seing even though you might

have congured an Allow policy seing for the family to which the device belongs.

The order of precedence for policy seings resolves conicts between policy seings. If you congure Allow

Smart Cards to allow the redirection of smart cards, any higher precedence exclusion policy seing

overrides this policy. For example, you might have congured an Exclude Vid/Pid Device policy seing to

exclude smart-card devices with matching path or vendor and product ID values, or you might have

congured an Exclude Device Family policy seing that also excludes the smart-card device family entirely.

If you have congured any Horizon Agent lter policy seings, Horizon Agent evaluates and enforces the

lter policy seings in the following order of precedence on the remote desktop or application, with item 1

having the highest precedence.

1Exclude Vid/Pid Device

2Include Vid/Pid Device

3Exclude Device Family

4Include Device Family

5 Agent-enforced Exclude All Devices policy set to exclude or include all USB devices

Horizon Agent enforces this limited set of lter policy seings on its side of the connection.

By dening lter policy seings for Horizon Agent, you can create a ltering policy for non-managed client

computers. The feature also allows you to block devices from being forwarded from client computers, even

if the lter policy seings for Horizon Client permit the redirection.

For example, if you congure a policy that permits Horizon Client to allow a device to be redirected,

Horizon Agent blocks the device if you congure a policy for Horizon Agent to exclude the device.

Examples of Setting Policies to Filter USB Devices

The vendor IDs and product IDs used in these examples are examples only. For information about

determining the vendor ID and product ID for a specify device, see “Using Log Files for Troubleshooting

and to Determine USB Device IDs,” on page 75.

nOn the client, exclude a particular device from being redirected:

Exclude Vid/Pid Device: Vid-0341_Pid-1a11

nBlock all storage devices from being redirected to this desktop or application pool. Use an agent-side

seing:

Exclude Device Family: o:storage

Chapter 4 Using USB Devices with Remote Desktops and Applications

VMware, Inc. 81

nFor all users in a desktop pool, block audio and video devices to ensure that these devices will always

be available for the Real-Time Audio-Video feature. Use an agent-side seing::

Exclude Device Family: o:video;audio

Note that another strategy would be to exclude specic devices by vendor and product ID.

nOn the client, block all devices from being redirected except one particular device:

Exclude All Devices: true

Include Vid/Pid Device: Vid-0123_Pid-abcd

nExclude all devices made by a particular company because these devices cause problems for your end

users. Use an agent-side seing:

Exclude Vid/Pid Device: o:Vid-0341_Pid-*

nOn the client, include two specic devices but exclude all others:

Exclude All Devices: true

Include Vid/Pid Device: Vid-0123_Pid-abcd;Vid-1abc_Pid-0001

USB Device Families

You can specify a family when you are creating USB ltering rules for Horizon Client, or View Agent or

Horizon Agent.

N Some devices do not report a device family.

Table 4‑10. USB Device Families

Device Family

Name Description

audio Any audio-input or audio-output device.

audio-in Audio-input devices such as microphones.

audio-out Audio-output devices such as loudspeakers and headphones.

bluetooth Bluetooth-connected devices.

comm Communications devices such as modems and wired networking adapters.

hid Human interface devices excluding keyboards and pointing devices.

hid-bootable Human interface devices that are available at boot time excluding keyboards and pointing devices.

imaging Imaging devices such as scanners.

keyboard Keyboard device.

mouse Pointing device such as a mouse.

other Family not specied.

pda Personal digital assistants.

physical Force feedback devices such as force feedback joysticks.

printer Printing devices.

security Security devices such as ngerprint readers.

smart-card Smart-card devices.

storage Mass storage devices such as ash drives and external hard disk drives.

unknown Family not known.

vendor Devices with vendor-specic functions.

video Video-input devices.

Configuring Remote Desktop Features in Horizon 7

82 VMware, Inc.

Table 4‑10. USB Device Families (Continued)

Device Family

Name Description

wireless Wireless networking adapters.

wusb Wireless USB devices.

USB Settings in the Horizon Agent Configuration ADMX Template

You can dene USB policy seings for both Horizon Agent and Horizon Client. On connection,

Horizon Client downloads the USB policy seings from Horizon Agent and uses them in conjunction with

the Horizon Client USB policy seings to decide which devices it will allow to be available for redirection

from the client computer.

The Horizon Agent Conguration ADMX template le contains policy seings related to the authentication

and environmental components of Horizon Agent, including USB redirection. The ADMX template le is

named (vdm_agent.admx). The seings apply at the computer level. Horizon Agent preferentially reads the

seings from the GPO at the computer level, and otherwise from the registry at

HKLM\Software\Policies\VMware, Inc.\VMware VDM\Agent\USB

Settings for Configuring USB Device Splitting

The following table describes each policy seing for spliing composite USB devices in the Horizon Agent

Conguration ADMX template le. All of these seings are in the VMware Horizon Agent  >

View USB  > Client Downloadable only  folder in the Group Policy Management

Editor. Horizon Agent does not enforce these seings. Horizon Agent passes the seings to Horizon Client

for interpretation and enforcement according to whether you specify the merge (m) or override (o) modier.

Horizon Client uses the seings to decide whether to split composite USB devices into their component

devices, and whether to exclude the component devices from being available for redirection. For a

description of how Horizon applies the policies for spliing composite USB devices, see “Conguring

Device Spliing Policy Seings for Composite USB Devices,” on page 77.

Chapter 4 Using USB Devices with Remote Desktops and Applications

VMware, Inc. 83

Table 4‑11. Horizon Agent Configuration Template: Device-Splitting Settings

Setting Properties

Allow Auto Device

Splitting

Property:

AllowAutoDeviceSplitting

Allows the automatic spliing of composite USB devices.

The default value is undened, which equates to false.

Exclude Vid/Pid Device

from Split

Property: SplitExcludeVidPid

Excludes a composite USB device specied by vendor and product IDs from

spliing. The format of the seing is {m|o}:vid-xxx1_pid-yyy2[;vid-xxx2_pid-

yyy2]...

You must specify ID numbers in hexadecimal. You can use the wildcard character (*)

in place of individual digits in an ID.

For example: o:vid-0781_pid-55**

The default value is undened.

Split Vid/Pid Device

Property: SplitVidPid

Treats the components of a composite USB device specied by vendor and product

IDs as separate devices. The format of the seing is

{m|o}:vid-xxxx_pid-yyyy(exintf:zz[;exintf:ww])

You can use the exintf keyword to exclude components from redirection by

specifying their interface number. You must specify ID numbers in hexadecimal, and

interface numbers in decimal including any leading zero. You can use the wildcard

character (*) in place of individual digits in an ID.

For example: o:vid-0781_pid-554c(exintf:01;exintf:02)

N Horizon 7 does not automatically include the components that you have not

explicitly excluded. You must specify a lter policy such as Include Vid/Pid

Device to include those components.

The default value is undened.

Horizon Agent -Enforced USB Settings

The following table describes each agent-enforced policy seing for USB in the Horizon Agent

Conguration ADMX template le. All of these seings are in the VMware Horizon Agent  >

View USB  folder in the Group Policy Management Editor. Horizon Agent uses the seings to

decide if a USB device can be forwarded to the host machine. Horizon Agent also passes the seings to

Horizon Client for interpretation and enforcement according to whether you specify the merge (m) or

override (o) modier. Horizon Client uses the seings to decide if a USB device is available for redirection.

As Horizon Agent always enforces an agent-enforced policy seing that you specify, the eect might be to

counteract the policy that you have set for Horizon Client. For a description of how Horizon 7 applies the

policies for ltering USB devices, see “Conguring Filter Policy Seings for USB Devices,” on page 79.

Configuring Remote Desktop Features in Horizon 7

84 VMware, Inc.

Table 4‑12. Horizon Agent Configuration Template: Agent-Enforced Settings

Setting Properties

Exclude All Devices

Property: ExcludeAllDevices

Excludes all USB devices from being forwarded. If set to true, you can use other

policy seings to allow specic devices or families of devices to be forwarded. If set to

false, you can use other policy seings to prevent specic devices or families of

devices from being forwarded.

If set to true and passed to Horizon Client, this seing always overrides the seing

on Horizon Client. You cannot use the merge (m) or override (o) modier with this

seing.

The default value is undened, which equates to false.

Exclude Device Family

Property: ExcludeFamily

Excludes families of devices from being forwarded. The format of the seing is {m|

o}:family_name_1[;family_name_2]...

For example: o:bluetooth;smart-card

If you have enabled automatic device spliing, Horizon 7 examines the device family

of each interface of a composite USB device to decide which interfaces should be

excluded. If you have disabled automatic device spliing, Horizon 7 examines the

device family of the whole composite USB device.

The default value is undened.

Exclude Vid/Pid Device

Property: ExcludeVidPid

Excludes devices with specied vendor and product IDs from being forwarded. The

format of the seing is {m|o}:vid-xxx1_pid-yyy2[;vid-xxx2_pid-yyy2]...

You must specify ID numbers in hexadecimal. You can use the wildcard character (*)

in place of individual digits in an ID.

For example: m:vid-0781_pid-****;vid-0561_pid-554c

The default value is undened.

Include Device Family

Property: IncludeFamily

Includes families of devices that can be forwarded. The format of the seing is {m|

o}:family_name_1[;family_name_2]...

For example: m:storage

The default value is undened.

Include Vid/Pid Device

Property: IncludeVidPid

Includes devices with specied vendor and product IDs that can be forwarded. The

format of the seing is {m|o}:vid-xxx1_pid-yyy2[;vid-xxx2_pid-yyy2]...

You must specify ID numbers in hexadecimal. You can use the wildcard character (*)

in place of individual digits in an ID.

For example: o:vid-0561_pid-554c

The default value is undened.

Client-Interpreted USB Settings

The following table describes each client-interpreted policy seing in the Horizon Agent Conguration

ADMX template le. All of these seings are in the VMware Horizon Agent  > View USB

 > Client Downloadable only  folder in the Group Policy Management Editor.

Horizon Agent does not enforce these seings. Horizon Agent passes the seings to Horizon Client for

interpretation and enforcement. Horizon Client uses the seings to decide if a USB device is available for

redirection.

Table 4‑13. Horizon Agent Configuration Template: Client-Interpreted Settings

Setting Properties

Allow Audio Input Devices

Property: AllowAudioIn

Allows audio input devices to be forwarded.

The default value is undened, which equates to true.

Allow Audio Output Devices

Property: AllowAudioOut

Allows audio output devices to be forwarded.

The default value is undened, which equates to false.

Allow HID-Bootable

Property: AllowHIDBootable

Allows input devices other than keyboards or mice that are available at boot time

(also known as hid-bootable devices) to be forwarded.

The default value is undened, which equates to true.

Chapter 4 Using USB Devices with Remote Desktops and Applications

VMware, Inc. 85

Table 4‑13. Horizon Agent Configuration Template: Client-Interpreted Settings (Continued)

Setting Properties

Allow Other Input Devices Allows input devices other than hid-bootable devices or keyboards with integrated

pointing devices to be forwarded.

The default value is undened.

Allow Keyboard and Mouse

Devices

Property: AllowKeyboardMouse

Allows keyboards with integrated pointing devices (such as a mouse, trackball, or

touch pad) to be forwarded.

The default value is undened, which equates to false.

Allow Smart Cards

Property: AllowSmartcard

Allows smart-card devices to be forwarded.

The default value is undened, which equates to false.

Allow Video Devices

Property: AllowVideo

Allows video devices to be forwarded.

The default value is undened, which equates to true.

Troubleshooting USB Redirection Problems

Various problems can arise with USB redirection in Horizon Client.

Problem

USB redirection in Horizon Client fails to make local devices available on the remote desktop, or some

devices do not appear to be available for redirection in Horizon Client.

Cause

The following are possible causes for USB redirection failing to function correctly or as expected.

nThe device is a composite USB device and one of the devices it includes is blocked by default. For

example, a dictation device that includes a mouse is blocked by default because mouse devices are

blocked by default. To work around this problem, see "Conguring Device Spliing Policy Seings for

Composite USB Devices" in the Conguring Remote Desktop Features in Horizon 7 document.

nUSB redirection is not supported on Windows Server 2008 RDS hosts that deploy remote desktops and

applications. USB redirection is supported on Windows Server 2012 RDS hosts with View Agent 6.1 and

later, but only for USB storage devices. USB redirection is supported on Windows Server 2008 R2 and

Windows Server 2012 R2 systems that are used as single-user desktops.

nOnly USB ash drives and hard disks are supported on RDS desktops and applications. You cannot

redirect other types of USB devices, and other types of USB storage devices such as security storage

drives and USB CD-ROM, to an RDS desktop or application.

nWebcams are not supported for redirection.

nThe redirection of USB audio devices depends on the state of the network and is not reliable. Some

devices require a high data throughput even when they are idle.

nUSB redirection is not supported for boot devices. If you run Horizon Client on a Windows system that

boots from a USB device, and you redirect this device to the remote desktop, the local operating system

might become unresponsive or unusable. See hp://kb.vmware.com/kb/1021409.

nBy default, Horizon Client for Windows does not allow you to select keyboard, mouse, smart card and

audio-out devices for redirection. See hp://kb.vmware.com/kb/1011600.

nRDP does not support the redirection of USB HIDs for the console session, or of smart card readers. See

hp://kb.vmware.com/kb/1011600.

nWindows Mobile Device Center can prevent the redirection of USB devices for RDP sessions. See

hp://kb.vmware.com/kb/1019205.

Configuring Remote Desktop Features in Horizon 7

86 VMware, Inc.

nFor some USB HIDs, you must congure the virtual machine to update the position of the mouse

pointer. See hp://kb.vmware.com/kb/1022076.

nSome audio devices might require changes to policy seings or to registry seings. See

hp://kb.vmware.com/kb/1023868.

nNetwork latency can cause slow device interaction or cause applications to appear frozen because they

are designed to interact with local devices. Very large USB disk drives might take several minutes to

appear in Windows Explorer.

nUSB ash cards formaed with the FAT32 le system are slow to load. See

hp://kb.vmware.com/kb/1022836.

nA process or service on the local system opened the device before you connected to the remote desktop

or application.

nA redirected USB device stops working if you reconnect a desktop or application session even if the

desktop or application shows that the device is available.

nUSB redirection is disabled in Horizon Administrator.

nMissing or disabled USB redirection drivers on the guest.

Solution

nIf available, use PCoIP instead of RDP as the protocol.

nIf a redirected device remains unavailable or stops working after a temporary disconnection, remove

the device, plug it in again, and retry the redirection.

nIn Horizon Administrator, go to Policies > Global Policies, and verify that USB access is set to Allow

under View Policies.

nExamine the log on the guest for entries of class ws_vhub, and the log on the client for entries of class

vmware-view-usbd.

Entries with these classes are wrien to the logs if a user is not an administrator, or if the USB

redirection drivers are not installed or are not working. For the location of these log les, see "Using Log

Files for Troubleshooting and to Determine USB Device IDs" in the Conguring Remote Desktop Features

in Horizon 7 document.

nOpen the Device Manager on the guest, expand Universal Serial Bus controllers, and reinstall the

VMware View Virtual USB Host Controller and VMware View Virtual USB Hub drivers if these drivers

are missing or re-enable them if they are disabled.

Chapter 4 Using USB Devices with Remote Desktops and Applications

VMware, Inc. 87

Configuring Remote Desktop Features in Horizon 7

88 VMware, Inc.

Configuring Policies for Desktop and

Application Pools 5

You can congure policies to control the behavior of desktop and application pools, machines, and users.

You use Horizon Administrator to set policies for client sessions. You can use Active Directory group policy

seings to control the behavior of Horizon Agent, Horizon Client for Windows, and features that aect

single-user machines, RDS hosts, PCoIP, or VMware Blast.

This chapter includes the following topics:

n“Seing Policies in Horizon Administrator,” on page 89

n“Using Smart Policies,” on page 91

n“Using Active Directory Group Policies,” on page 97

n“Using Horizon 7 Group Policy Administrative Template Files,” on page 98

n“Horizon 7 ADMX Template Files,” on page 98

n“Add the ADMX Template Files to Active Directory,” on page 100

n“Horizon Agent Conguration ADMX Template Seings,” on page 100

n“PCoIP Policy Seings,” on page 110

n“VMware Blast Policy Seings,” on page 124

n“Using Remote Desktop Services Group Policies,” on page 128

n“Seing Up Location-Based Printing,” on page 163

n“Active Directory Group Policy Example,” on page 168

Setting Policies in Horizon Administrator

You use Horizon Administrator to congure policies for client sessions.

You can set these policies to aect specic users, specic desktop pools, or all client sessions users. Policies

that aect specic users and desktop pools are called user-level policies and desktop pool-level policies.

Policies that aect all sessions and users are called global policies.

User-level policies inherit seings from the equivalent desktop pool-level policy seings. Similarly, desktop

pool-level policies inherit seings from the equivalent global policy seings. A desktop pool-level policy

seing takes precedence over the equivalent global policy seing. A user-level policy seing takes

precedence over the equivalent global and desktop pool-level policy seings.

VMware, Inc. 89

Lower-level policy seings can be more or less restrictive than the equivalent higher-level seings. For

example, you can set a global policy to Deny and the equivalent desktop pool-level policy to Allow, or vice

versa.

N Only global policies are available for RDS desktop and application pools. You cannot set user-level

policies or pool-level policies for RDS desktop and application pools.

Configure Global Policy Settings

You can congure global policies to control the behavior of all client sessions users.

Prerequisites

Familiarize yourself with the policy descriptions. See “Horizon 7 Policies,” on page 91.

Procedure

1 In Horizon Administrator, select Policies > Global Policies.

2 Click Edit policies in the View Policies pane.

3 Click OK to save your changes.

Configure Policies for Desktop Pools

You can congure desktop-level policies to aect specic desktop pools. Desktop-level policy seings take

precedence over their equivalent global policy seings.

Prerequisites

Familiarize yourself with the policy descriptions. See “Horizon 7 Policies,” on page 91.

Procedure

1 In Horizon Administrator, select Catalog > Desktop Pools.

2 Double-click the ID of the desktop pool and click the Policies tab.

The Policies tab shows the current policy seings. When a seing is inherited from the equivalent

global policy, Inherit appears in the Desktop Pool Policy column.

3 Click Edit Policies in the View Policies pane.

4 Click OK to save your changes.

Configure Policies for Users

You can congure user-level policies to aect specic users. User-level policy seings always take

precedence over their equivalent global and desktop pool-level policy seings.

Prerequisites

Familiarize yourself with the policy descriptions. See “Horizon 7 Policies,” on page 91.

Procedure

1 In Horizon Administrator, select Catalog > Desktop Pools.

2 Double-click the ID of the desktop pool and click the Policies tab.

The Policies tab shows the current policy seings. When a seing is inherited from the equivalent

global policy, Inherit appears in the Desktop Pool Policy column.

3 Click User Overrides and then click Add User.

Configuring Remote Desktop Features in Horizon 7

90 VMware, Inc.

4 To nd a user, click Add, type the name or description of the user, and then click Find.

5 Select one or more users from the list, click OK, and then click Next.

The Add Individual Policy dialog box appears.

6Congure the Horizon policies and click Finish to save your changes.

Horizon 7 Policies

You can congure Horizon 7 policies to aect all client sessions, or you can apply them to aect specic

desktop pools or users.

Table 5-1 describes each Horizon 7 policy seing.

Table 5‑1. Horizon Policies

Policy Description

Multimedia redirection (MMR) Determines whether MMR is enabled for client systems.

MMR is a Windows Media Foundation lter that forwards multimedia data

from specic codecs on remote desktops directly through a TCP socket to the

client system. The data is then decoded directly on the client system, where it is

played.

The default value is Deny.

If client systems have insucient resources to handle local multimedia

decoding, leave the seing as Deny.

Multimedia Redirection (MMR) data is sent across the network without

application-based encryption and might contain sensitive data, depending on

the content being redirected. To ensure that this data cannot be monitored on

the network, use MMR only on a secure network.

USB Access Determines whether remote desktops can use USB devices connected to the

client system.

The default value is Allow. To prevent the use of external devices for security

reasons, change the seing to Deny.

PCoIP hardware acceleration Determines whether to enable hardware acceleration of the PCoIP display

protocol and species the acceleration priority that is assigned to the PCoIP

user session.

This seing has an eect only if a PCoIP hardware acceleration device is

present on the physical computer that hosts the remote desktop.

The default value is Allow at Medium priority.

Using Smart Policies

You can use Smart Policies to create policies that control the behavior of the USB redirection, virtual

printing, clipboard redirection, client drive redirection, and PCoIP display protocol features on specic

remote desktops. You can also use Smart Policies to create policies that control the behavior of published

applications.

With Smart Policies, you can create policies that take eect only if certain conditions are met. For example,

you can congure a policy that disables the client drive redirection feature if a user connects to a remote

desktop from outside your corporate network.

Requirements for Smart Policies

To use Smart Policies, your Horizon 7 environment must meet certain requirements.

nYou must install Horizon Agent 7.0 or later and VMware User Environment Manager 9.0 or later on the

remote desktops that you want to manage with Smart Policies.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 91

nUsers must use Horizon Client 4.0 or later to connect to remote desktops that you manage with Smart

Policies.

Installing User Environment Manager

To use Smart Policies to control the behavior of remote desktop features on a remote desktop, you must

install User Environment Manager 9.0 or later on the remote desktop.

You can download the User Environment Manager installer from the VMware Downloads page. You must

install the VMware UEM FlexEngine client component on each remote desktop that you want to manage

with User Environment Manager. You can install the User Environment Manager Management Console

component on any desktop from which you want to manage the User Environment Manager environment.

For a linked-clone pool, you install User Environment Manager in the parent virtual machine that you use as

a base image for the linked clones. For an RDS desktop pool, you install User Environment Manager on the

RDS host that provides the RDS desktop sessions.

For User Environment Manager system requirements and complete installation instructions, see the User

Environment Manager Administrator's Guide document.

Configuring User Environment Manager

You must congure User Environment Manager before you can use it to create smart policies for remote

desktop features.

To congure User Environment Manager, follow the conguration instructions in the User Environment

Manager Administrator's Guide. The following conguration steps supplement the information in that

document.

nWhen conguring the VMware UEM FlexEngine client component on remote desktops, create

FlexEngine logon and logo scripts. Use the -HorizonViewMultiSession -r parameter for the logon

script and the -HorizonViewMultiSession -s parameter for the logo script.

N Do not use logon scripts to start other applications on a remote desktop. Additional logon

scripts can delay remote desktop logon for up to 10 minutes.

nEnable the user group policy seing Run logon scripts synchronously on remote desktops. This

seing is located in the folder User Configuration\Policies\Administrative

Templates\System\Scripts.

nEnable the computer group policy seing Always wait for the network at computer startup and

logon on remote desktops. This seing is located in the folder Computer Configuration\Administrative

Template\System\Logon.

nFor Windows 8.1 remote desktops, disable the computer group policy seing Configure Logon Script

Delay. This seing is located in the folder Computer Configuration\Administrative

Templates\System\Group Policy.

nTo ensure that Horizon Smart Policy seings are refreshed when users reconnect to desktop sessions,

use the User Environment Manager Management Console to create a triggered task. Set the trigger to

Reconnect session, set the action to User Environment refresh, and select Horizon Smart Policies for

the refresh.

N If you create the triggered task while a user is logged in to the remote desktop, the user must log

o from the desktop for the triggered task to take eect.

Configuring Remote Desktop Features in Horizon 7

92 VMware, Inc.

Horizon Smart Policy Settings

You control the behavior of remote desktop features in User Environment Manager by creating a Horizon

smart policy.

Table 5-2 describes the seings that you can select when you dene a Horizon smart policy in

User Environment Manager.

Table 5‑2. Horizon Smart Policy Settings

Setting Description

USB redirection Determines whether USB redirection is enabled on the remote desktop. The USB redirection feature

allows users to use locally aached USB devices, such as thumb ash drives, cameras, and printers,

from the remote desktop.

Printing Determines whether virtual printing is enabled on the remote desktop. The virtual printing feature

allows users to print to a virtual printer or a USB printer that is aached to the client computer from

the remote desktop.

Clipboard Determines the direction in which clipboard redirection is allowed. You can select one of these

values:

nDisable. Clipboard redirection is disabled in both directions.

nAllow all. Clipboard redirection is enabled. Users can copy and paste from the client system to

the remote desktop and from the remote desktop to the client system.

nAllow copy from client to agent. Users can copy and paste only from the client system to the

remote desktop.

nAllow copy from agent to client. Users can copy and paste only from the remote desktop to the

client system.

Client drive

redirection

Determines whether client drive redirection is enabled on the remote desktop and if shared drives

and folders are writeable. You can select one of these values:

nDisable. Client drive redirection is disabled on the remote desktop.

nAllow all. Client drives and folders are shared with the remote desktop and are readable and

writeable.

nRead-only. Client drives and folders are shared with the remote desktop and are readable, but

not writeable.

If you do not congure this seing, whether shared drives and folders are writeable depends on

local registry seings. For more information, see “Use Registry Seings to Congure Client Drive

Redirection,” on page 48.

Bandwidth prole Congures a bandwidth prole for PCoIP and Blast sessions on the remote desktop. You can select

a predened bandwidth prole, for example, LAN. Selecting a predened bandwidth prole

prevents the agent from aempting to transmit at a higher rate than the link capacity. If you select

the default prole, the maximum bandwidth is 90000 kilobits per second.

For more information, see “Bandwidth Prole Reference,” on page 94.

HTML Access le

transfer

Determines the transfer of HTML les between client and agent.

In general, Horizon smart policy seings that you congure for remote desktop features in

User Environment Manager override any equivalent registry key and group policy seings.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 93

Bandwidth Profile Reference

With Smart Policies, you can use the Bandwidth prole policy seing to congure a bandwidth prole for

PCoIP or Blast sessions on remote desktops.

Table 5‑3. Bandwidth Profiles

Bandwidth Profile

Max Session

BW (Kbps)

Min

Session

BW (Kbps)

Enable

BTL

Max Initial


Quality

Min Image

Quality Max FPS

Max Audio

BW (Kbps)

Image Quality

Performance

High-speed LAN 900000 100 Yes 100 50 60 1600 50

LAN 900000 100 Yes 90 50 30 1600 50

Dedicated WAN 900000 100 No 80 40 30 500 50

Broadband WAN 5000 100 No 70 40 20 500 50

Low-speed WAN 2000 100 No 70 30 15 200 25

Extremely low-speed

connection

1000 100 No 70 30 5 90 0

Adding Conditions to Horizon Smart Policy Definitions

When you dene a Horizon Smart Policy in User Environment Manager, you can add conditions that must

be met for the policy to take eect. For example, you can add a condition that disables the client drive

redirection feature only if a user connects to the remote desktop from outside your corporate network.

You can add multiple conditions for the same remote desktop feature. For example, you can add one

condition that enables local printing if a user is a member of the HR group and another condition that

enables local printing if the remote desktop is in the Win7 pool.

For detailed information about adding and editing conditions in the User Environment Manager

Management Console, see the User Environment Manager Administrator's Guide.

Using the Horizon Client Property Condition

When a user connects or reconnects to a remote desktop, Horizon Client gathers information about the

client computer and Connection Server sends that information to the remote desktop. You can add the

Horizon Client Property condition to a Horizon Policy denition to control when the policy takes eect

based on the information that the remote desktop receives.

N The Horizon Client Property condition is eective only if a user launches the remote desktop with

the PCoIP display protocol or the VMware Blast display protocol. If a user launches the remote desktop

with the RDP display protocol, the Horizon Client Property condition has no eect.

Table 5-4 describes the predened properties that you can select from the Properties drop-down menu when

you use the Horizon Client Property condition. Each predened property corresponds to a ViewClient_

registry key.

Configuring Remote Desktop Features in Horizon 7

94 VMware, Inc.

Table 5‑4. Predefined Properties for the Horizon Client Property Condition

Property Corresponding Registry Key Description

Client location ViewClient_Broker_GatewayLocation Species the location of the user's client system. Valid

values are as follows:

nInternal - the policy takes eect only if a user

connects to the remote desktop from inside the

corporate network

nExternal - the policy takes eect only if a user

connects to the remote desktop from outside the

corporate network

For information about seing the gateway location for a

Connection Server or security server host, see the View

Administration document.

For information about seing the gateway location for

an Access Point appliance, see the Deploying and

Conguring Unied Access Gateway document.

Launch tag(s) ViewClient_Launch_Matched_Tags Species one or more tags. Separate multiple tags with

a comma or semicolon. The policy takes eect only if

the tag that enabled the remote desktop or application

launch to occur matches one of the specied tags.

For information about assigning tags to Connection

Server instances and desktop pools, see your Seing Up

document.

Pool name ViewClient_Launch_ID Species a desktop or application pool ID. The policy

takes eect only if the ID of the desktop or application

pool the user selected when launching the remote

desktop or application matches the specied desktop or

application pool ID. For example, if the user selected

the Win7 pool and this property is set to Win7, the

policy takes eect.

N If more than one application pool is launched in

the same RDS host session then the value is the ID of

the rst application that is launched from Horizon

Client.

The Properties drop-down menu is also a text box, and you can manually enter any ViewClient_ registry

key in the text box. Do not include the ViewClient_ prex when you enter the registry key. For example, to

specify ViewClient_Broker_URL, enter Broker_URL.

You can use the Windows Registry Editor (regedit.exe) on the remote desktop to view the ViewClient_

registry keys. Horizon Client writes client computer information to the system registry path

HKEY_CURRENT_USER\Volatile Environment on remote desktops that are deployed on single-user machines.

For remote desktops that are deployed in RDS sessions, Horizon Client writes the client computer

information to the system registry path HKEY_CURRENT_USER\Volatile Environment\x, where x is the session

ID on the RDS host.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 95

Using Other Conditions

The User Environment Manager Management Console provides many conditions. The following conditions

can be especially useful when creating policies for remote desktop features.

Group Member You can use this condition to congure the policy to take eect only if a user

is a member of a specic group.

Remote Display

Protocol

You can use this condition to congure the policy to take eect only if the

user selects a particular display protocol. The condition seings include RDP,

PCoIP, and Blast.

IP Address You can use this condition to congure the policy that takes eect only if a

user connects from inside or outside the corporate network. Use the

condition seings to specify an internal IP address range or an external IP

address range.

N You can also use the Client location property in the Horizon Client

Property condition.

For descriptions of all the available conditions, see the User Environment Manager Administrator's Guide

document.

Create a Horizon Smart Policy in User Environment Manager

You use the User Environment Manager Management Console to create a Horizon smart policy in

User Environment Manager. When you dene a Horizon smart policy, you can add conditions that must be

met for the smart policy to take eect.

Prerequisites

nInstall and congure User Environment Manager. See “Installing User Environment Manager,” on

page 92 and “Conguring User Environment Manager,” on page 92.

nBecome familiar with the Horizon Smart Policy seings. See “Horizon Smart Policy Seings,” on

page 93.

nBecome familiar with the conditions that you can add to Horizon Smart Policy denitions. See “Adding

Conditions to Horizon Smart Policy Denitions,” on page 94.

For complete information about using the User Environment Manager Management Console, see the User

Environment Manager Administrator's Guide document.

Procedure

1 In the User Environment Manager Management Console, select the User Environment tab and click

Horizon Smart Policies in the tree view.

Existing Horizon smart policy denitions, if any, appear in the Horizon Smart Policies pane.

2 Right-click Horizon Smart Policies and select Create Horizon Smart Policy  to create a new

smart policy.

The Horizon Smart Policy dialog box appears.

Configuring Remote Desktop Features in Horizon 7

96 VMware, Inc.

3 Select the  tab and dene the smart policy seings.

a In the General Seings section, type a name for the smart policy in the Name text box.

For example, if the smart policy will aect the client drive redirection feature, you might name the

smart policy CDR.

b In the Horizon Smart Policy Seings section, select the remote desktop features and seings to

include in the smart policy.

You can select multiple remote desktop features.

4 (Optional) To add a condition to the smart policy, select the Conditions tab, click Add, and select a

condition.

You can add multiple conditions to a smart policy denition.

5 Click Save to save the smart policy.

User Environment Manager processes the Horizon smart policy each time a user connects or reconnects to

the remote desktop.

User Environment Manager processes multiple smart policies in alphabetical order based on the smart

policy name. Horizon smart policies appear in alphabetical order in the Horizon Smart Policies pane. If

smart policies conict, the last smart policy processed takes precedence. For example, if you have a smart

policy named Sue that enables USB redirection for the user named Sue, and another smart policy named

Pool that disables USB redirection for the desktop pool named Win7, the USB redirection feature is enabled

when Sue connects to a remote desktop in the Win7 desktop pool.

Using Active Directory Group Policies

You can use Microsoft Windows Group Policy to optimize and secure remote desktops, control the behavior

of Horizon 7 components, and to congure location-based printing.

Group Policy is a feature of Microsoft Windows operating systems that provides centralized management

and conguration of computers and remote users in an Active Directory environment.

Group policy seings are contained in entities called group policy objects (GPOs). GPOs are associated with

Active Directory objects. You can apply GPOs to Horizon 7 components at a domain-wide level to control

various areas of the Horizon 7 environment. After they are applied, GPO seings are stored in the local

Windows Registry of the specied component.

You use the Microsoft Windows Group Policy Object Editor to manage group policy seings. The Group

Policy Object Editor is a Microsoft Management Console (MMC) snap-in. The MMC is part of the Microsoft

Group Policy Management Console (GPMC). See the Microsoft TechNet Web site for information on

installing and using the GPMC.

Creating an OU for Remote Desktops

Create an organizational unit (OU) in Active Directory specically for your remote desktops.

To prevent group policy seings from being applied to other Windows servers or workstations in the same

domain as your remote desktops, create a GPO for your Horizon 7 group policies and link it to the OU that

contains your remote desktops.

See the Microsoft Active Directory documentation on the Microsoft TechNet Web site for information on

creating OUs and GPOs.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 97

Enabling Loopback Processing for Remote Desktops

By default, a user's policy seings come from the set of GPOs that are applied to the user object in Active

Directory. However, in the Horizon 7 environment, GPOs apply to users based on the computer they log in

to.

When you enable loopback processing, a consistent set of policies applies to all users that log in to a

particular computer, regardless of their location in Active Directory.

See the Microsoft Active Directory documentation for information on enabling loopback processing.

N Loopback processing is only one approach to handling GPOs in Horizon 7. You might need to

implement a dierent approach.

Using Horizon 7 Group Policy Administrative Template Files

Horizon 7 provides several component-specic Group Policy Administrative ADMX template les. You can

optimize and secure remote desktops and applications by adding the policy seings in the ADMX template

les to a new or existing GPO in Active Directory.

All ADMX les that provide group policy seings for Horizon 7 are available in a bundled .zip le named

VMware-Horizon-Extras-Bundle-x.x.x-yyyyyyy.zip, where x.x.x is the version and yyyyyyy is the build

number. You can download the le from the VMware download site at

hps://my.vmware.com/web/vmware/downloads. Under Desktop & End-User Computing, select the

VMware Horizon 7 download, which includes the bundled .zip le.

The Horizon 7 ADMX template les contain both Computer Conguration and User Conguration group

policies.

nThe Computer Conguration policies set policies that apply to all remote desktops, regardless of who

connects to the desktop.

nThe User Conguration policies set policies that apply to all users, regardless of the remote desktop or

application they connect to. User Conguration policies override equivalent Computer Conguration

policies.

Microsoft Windows applies policies at desktop startup and when users log in.

Horizon 7 ADMX Template Files

The Horizon 7 ADMX template les provide group policy seings that allow you to control and optimize

Horizon 7 components.

Table 5‑5. Horizon ADMX Template Files

Template Name Template File Description

Horizon Agent Conguration vdm_agent.admx Contains policy seings related to the

authentication and environmental components

of Horizon Agent.

Horizon Client Conguration vdm_client.admx Contains policy seings related to

Horizon Client for Windows.

Clients that connect from outside the Connection

Server host domain are not aected by policies

applied to Horizon Client.

See the Using VMware Horizon Client for Windows

document.

Configuring Remote Desktop Features in Horizon 7

98 VMware, Inc.

Table 5‑5. Horizon ADMX Template Files (Continued)

Template Name Template File Description

VMware Horizon URL Redirection urlRedirection-enUS.admx Contains policy seings related to the URL

Content Redirection Feature. If you add this

template to a GPO for a remote desktop pool or

application pool, certain URL links clicked inside

the remote desktops or app can be redirected to

a Windows-based client and opened in a client-

side browser.

If you add this template to a client-side GPO,

when a user clicks certain URL links in a

Windows-based client system, the URL can be

opened in a remote desktop or application.

See Chapter 3, “Conguring URL Content

Redirection,” on page 53 and see the Using

VMware Horizon Client for Windows document.

Connection Server Conguration vdm_server.admx Contains policy seings related to Connection

Server.

See the View Administration document.

View Common Conguration vdm_common.admx Contains policy seings that are common to all

Horizon components.

See the View Administration document.

PCoIP Session Variables pcoip.admx Contains policy seings related to the PCoIP

display protocol.

PCoIP Client Session Variables pcoip.client.admx Contains policy seings related to the PCoIP

display protocol that aect Horizon Client for

Windows.

See the Using VMware Horizon Client for Windows

document.

Horizon Persona Management

Conguration

ViewPM.admx Contains policy seings related to Horizon

Persona Management.

See the Seing Up Virtual Desktops in Horizon 7

document.

Remote Desktop Services vmware_rdsh.admx Contains policy seings related to Remote

Desktop Services.

See “Using Remote Desktop Services Group

Policies,” on page 128.

Real-Time Audio-Video

Conguration

vdm_agent_rtav.admx Contains policy seings related to webcams that

are used with the Real-Time Audio-Video

feature.

See “Real-Time Audio-Video Group Policy

Seings,” on page 31.

Scanner Redirection vdm_agent_scanner.admx Contains policy seings related to scanning

devices that are redirected for use in published

desktops and applications.

See “Scanner Redirection Group Policy Seings,”

on page 36.

Serial Port Redirection vdm_agent_serialport.admx Contains policy seings related to serial (COM)

ports that are redirected for use in virtual

desktops.

See “Serial Port Redirection Group Policy

Seings,” on page 42.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 99

Add the ADMX Template Files to Active Directory

You can add the policy seings for specic remote desktop features in the Horizon 7 ADMX les to group

policy objects (GPOs) in Active Directory.

Prerequisites

nVerify that the setup option for the remote desktop feature you are applying the policy for is installed

on your desktops and RDS hosts. The group policy seings have no eect if the remote desktop feature

is not installed. See your Seing Up document for information on installing Horizon Agent.

nCreate GPOs for the remote desktop features that you want to apply the group policy seings to and

link them to the OU that contains your RDS hosts.

nVerify the name of the ADMX template le that you want to add to Active Directory. See “Horizon 7

ADMX Template Files,” on page 98.

nVerify that the Group Policy Management feature is available on your Active Directory server.

The steps for opening the Group Policy Management Console dier in the Windows 2012, Windows

2008, and Windows 2003 Active Directory versions. See “Create GPOs for Horizon 7 Group Policies,”

on page 169.

Procedure

1 Download the Horizon 7 GPO Bundle .zip le from the VMware download site at

hps://my.vmware.com/web/vmware/downloads.

Under Desktop & End-User Computing, select the VMware Horizon 7 download, which includes the

GPO Bundle.

The le is named VMware-Horizon-Extras-Bundle-x.x.x-yyyyyyy.zip, where x.x.x is the version and

yyyyyyy is the build number. All ADMX les that provide group policy seings for Horizon 7 are

available in this le.

2 Unzip the VMware-Horizon-Extras-Bundle-x.x.x-yyyyyyy.zip le and copy the ADMX les to your

Active Directory or RDS host.

a Copy the .admx les and the en-US folder to the %systemroot%\PolicyDefinitions folder on your

Active Directory or RDS host.

b Copy the language resource les (.adml) to the appropriate subfolder in %systemroot

%\PolicyDefinitions\ on your Active Directory or RDS host.

3 On the Active Directory host, open the Group Policy Management Editor and enter the path to the

template les where they appear in the editor after installation.

On an individual RDS host, you can open the Local Group Policy Editor with the gpedit.msc utility.

What to do next

Congure the group policy seings.

Horizon Agent Configuration ADMX Template Settings

The Horizon Agent Conguration ADMX template le (vdm_agent.admx) contains policy seings related to

the authentication and environmental components of Horizon Agent.

The ADMX les are available in a bundled .zip le named VMware-Horizon-Extras-Bundle-x.x.x-

yyyyyyy.zip, which you can download from the VMware download site at

hps://my.vmware.com/web/vmware/downloads. Under Desktop & End-User Computing, select the

VMware Horizon 7 download, which includes the bundled .zip le.

Configuring Remote Desktop Features in Horizon 7

100 VMware, Inc.

The following table describes policy seings in the Horizon Agent Conguration ADMX template le other

than those seings that are used with USB devices. The template contains both Computer Conguration and

User Conguration seings. The User Conguration seing overrides the equivalent Computer

Conguration seing.

Table 5‑6. Horizon Agent Configuration Template Settings

Setting Computer User Properties

AllowDirectRDP X Determines whether clients other than Horizon Client

devices can connect directly to remote desktops with

RDP. When this seing is disabled, the agent permits only

Horizon-managed connections through Horizon Client.

When connecting to a remote desktop from

Horizon Client for Mac, do not disable the

AllowDirectRDP seing. If this seing is disabled, the

connection fails with an Access is denied error.

By default, while a user is logged in to a Horizon 7

desktop session, you can use RDP to connect to the

virtual machine from outside of Horizon 7. The RDP

connection terminates the Horizon 7 desktop session, and

the user's unsaved data and seings might be lost. The

user cannot log in to the desktop until the external RDP

connection is closed. To avoid this situation, disable the

AllowDirectRDP seing.

I The Windows Remote Desktop Services

service must be running on the guest operating system of

each desktop. You can use this seing to prevent users

from making direct RDP connections to their desktops.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

This seing is enabled by default.

AllowSingleSignon X Determines whether single sign-on (SSO) is used to

connect users to desktops and applications. When this

seing is enabled, users are required to enter their

credentials only once, when they log in to the server.

When this seing is disabled, users must reauthenticate

when the remote connection is made.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

This seing is enabled by default.

CommandsToRunOnConnect XSpecies a list of commands or command scripts to be

run when a session is connected for the rst time.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

See “Running Commands on Horizon Desktops,” on

page 110 for more information.

CommandsToRunOnDisconnect XSpecies a list of commands or command scripts to be

run when a session is disconnected.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

See “Running Commands on Horizon Desktops,” on

page 110 for more information.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 101

Table 5‑6. Horizon Agent Configuration Template Settings (Continued)

Setting Computer User Properties

CommandsToRunOnReconnect XSpecies a list of commands or command scripts to be

run when a session is reconnected after a disconnect.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

See “Running Commands on Horizon Desktops,” on

page 110 for more information.

ConnectionTicketTimeout XSpecies the amount of time in seconds that the Horizon

connection ticket is valid.

Horizon Client devices use a connection ticket for

verication and single sign-on when connecting to the

agent. For security reasons, a connection ticket is valid for

a limited amount of time. When a user connects to a

remote desktop, authentication must take place within

the connection ticket timeout period or the session times

out. If this seing is not congured, the default timeout

period is 900 seconds.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

CredentialFilterExceptions XSpecies the executable les that are not allowed to load

the agent CredentialFilter. Filenames must not include a

path or sux. Use a semicolon to separate multiple

lenames.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

Disable Time Zone

Synchronization

X X Determines whether the time zone of the Horizon

desktop is synchronized with the time zone of the

connected client. An enabled seing applies only if the

Disable time zone forwarding seing of the

Horizon Client Conguration policy is not set to disabled.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

This seing is disabled by default.

DPI Synchronization X X Adjusts the system-wide DPI seing for the remote

session. When this seing is enabled or not congured,

the system-wide DPI seing for the remote session is set

to match the corresponding DPI seing on the client

operating system. When this seing is disabled, the

system-wide DPI seing for the remote session is never

changed.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

This seing is not congured by default.

N This seing applies only to version 7.0.2 or later

and to Windows clients on which Horizon Client 4.2 or

later is installed.

Configuring Remote Desktop Features in Horizon 7

102 VMware, Inc.

Table 5‑6. Horizon Agent Configuration Template Settings (Continued)

Setting Computer User Properties

Enable multi-media

acceleration

X Determines whether multimedia redirection (MMR) is

enabled on the remote desktop.

MMR is a Windows Media Foundation lter that

forwards multimedia data from specic codecs on the

remote system directly through a TCP socket to the client.

The data is then decoded directly on the client, where it is

played. You can disable MMR if the client has insucient

resources to handle local multimedia decoding.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

This seing is enabled by default.

Force MMR to use software

overlay

X MMR tries to use the hardware overlay to play back

video for beer performance. When working with

multiple displays, the hardware overlay exists only on

one of the displays, either the primary display or the

display where WMP was started. If WMP is dragged to

another display, the video appears as a black rectangle.

Use this option to force MMR to use a software overlay

that works on all displays.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

This seing is not congured by default.

Single sign-on retry timeout XSpecies the time, in milliseconds, after which single

sign-on is retried. Set the value to 0 to disable single sign-

on retry. The default value is 5000 milliseconds.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

This seing is not congured by default.

ShowDiskActivityIcon X This seing is not supported in this release.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

Toggle Display Settings

Control

X Determines whether to disable the  tab in the

Display control panel when a client session uses the

PCoIP display protocol.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

This seing is enabled by default.

UnAuthenticatedAccessEnabled Enables or disables the unauthenticated access feature.

When this seing is enabled, unauthenticated access

users can access published applications from a Horizon

Client without requiring AD credentials. When this

seing is disabled, unauthenticated access users cannot

access published applications from a Horizon Client

without requiring AD credentials.

You must reboot the RDS host for this seing to take

eect.

This seing is in the VMware View Agent 

> Agent  folder in the Group Policy

Management Editor.

This seing is enabled by default.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 103

Table 5‑6. Horizon Agent Configuration Template Settings (Continued)

Setting Computer User Properties

Send updates for empty or

offscreen windows

XSpecies whether the client receives updates about empty

or oscreen windows. When this seing is disabled,

information about window that are smaller than 2x2

pixels, or that are located entirely oscreen, are not sent

to the client.

This seing is in the VMware View Agent 

> Unity Touch and Hosted Apps folder in the Group

Policy Management Editor.

This seing is disabled by default.

Enable Unity Touch X Determines whether the Unity Touch functionality is

enabled on the remote desktop. Unity Touch supports the

delivery of remote applications in Horizon and allows

mobile device users to access applications in the Unity

Touch sidebar.

This seing is in the VMware View Agent 

> Unity Touch and Hosted Apps folder in the Group

Policy Management Editor.

This seing is enabled by default.

Enable system tray

redirection for Hosted Apps

X Determines whether system tray redirection is enabled

while a user is running remote applications.

This seing is in the VMware View Agent 

> Unity Touch and Hosted Apps folder in the Group

Policy Management Editor.

This seing is enabled by default.

Enable user profile

customization for Hosted Apps

X X Species whether to customize the user prole when

remote applications are used. If this seing is enabled, a

user prole is generated, the Windows theme is

customized, and startup applications are registered.

This Computer Conguration seing is in the VMware

View Agent  > Unity Touch and Hosted

Apps folder in the Group Policy Management Editor. The

User Conguration seing is in the VMware View Agent

 > Agent Security > Unity Touch and

Hosted Apps folder in the Group Policy Management

Editor.

This seing is disabled by default.

Limit usage of Windows hooks X Disables most hooks when remote applications or Unity

Touch are used. This seing is intended for applications

that have compatibility issues when OS-level hooks are

set. For example, enabling this seing disables the use of

most Windows active accessibility and in-process hooks.

This seing is in the VMware View Agent 

> Unity Touch and Hosted Apps folder in the Group

Policy Management Editor.

This seing is disabled by default, which means that all

preferred hooks are used.

Configuring Remote Desktop Features in Horizon 7

104 VMware, Inc.

Table 5‑6. Horizon Agent Configuration Template Settings (Continued)

Setting Computer User Properties

Accept SSL encrypted

framework channel

X Enables the SSL encrypted framework channel. The

following options are available:

nDisable - Disable SSL.

nEnable - Enable SSL. Allow legacy clients to connect

without SSL.

nEnforce - Enable SSL. Refuse legacy client

connections.

This seing is in the VMware View Agent 

> Agent Security folder in the Group Policy Management

Editor.

This seing is not congured by default. The default

value is Enable.

Default Proxy Server X Default Internet Explorer connection seing for the proxy

server. Species the proxy server to use in Internet

Options > Local Area Network (LAN) Seings.

This seing is in the VMware View Agent 

> VMware Client IP Transparency folder in the Group

Policy Management Editor.

This seing is not enabled by default.

Enable X Enables VMware Client IP Transparency. Remote

connections to Internet Explorer use the client's IP

address instead of the IP address of the remote desktop

machine. This seing takes eect at the next login.

This seing is in the VMware View Agent 

> VMware Client IP Transparency folder in the Group

Policy Management Editor.

If the VMware Client IP Transparency custom setup

option is selected in the Horizon Agent installer, this

seing is enabled by default.

Default auto detect proxy X Default Internet Explorer connection seing. Turns on

Automatically detect  in Internet Options > Local

Area Network (LAN) Seings.

This seing is in the VMware View Agent 

> VMware Client IP Transparency folder in the Group

Policy Management Editor.

This seing is not enabled by default.

Set proxy for Java applet X Sets the proxy for Java applets. The following options are

available:

nUse client ip transparency for Java proxy - directs a

remote connection to use the client's IP address

instead of the IP address of the remote desktop

machine for Java applets.

nUse direct connection for Java proxy - uses a direct

connection to bypass the browser seing for Java

applets.

nUse the default value for Java proxy - restores the

original Java proxy seings.

This seing is in the VMware View Agent 

> VMware Client IP Transparency folder in the Group

Policy Management Editor.

This seing is not enabled by default.

Enable flash multi-media

redirection

XSpecies whether Flash Redirection is enabled on the

agent.

This seing is in the VMware View Agent 

> VMware FlashMMR folder in the Group Policy

Management Editor.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 105

Table 5‑6. Horizon Agent Configuration Template Settings (Continued)

Setting Computer User Properties

Minimum rect size to enable

FlashMMR

XSpecies the minimum rect size to enable Flash

Redirection.

This seing is in the VMware View Agent 

> VMware FlashMMR folder in the Group Policy

Management Editor.

The default width is 320 pixels and the default height is

200 pixels.

Definition for FlashMMR url

list usage

XDenes the white list or black list rule that enables or

disables URLs from using Flash Redirection.

If you select Enable white list from the  for

FlashMMR url list usage drop-down menu, only the

URLs in the URL list are enabled to use Flash Redirection.

If you select Enable black list from the  for

FlashMMR url list usage drop-down menu, the URLs in

the URL list are not able to use Flash Redirection.

You specify the URL list in the Hosts Url list to

enable FlashMMR group policy seing.

This seing is in the VMware View Agent 

> VMware FlashMMR folder in the Group Policy

Management Editor.

This seing species a white list by default.

Hosts Url list to enable

FlashMMR

XSpecies the URL list that is enabled or disabled to use

Flash Redirection based on the Definition for

FlashMMR url list usage group policy seing.

You must include  or . You can use regular

expressions. For example, you can specify

https://*.google.com and http://www.cnn.com.

This seing is in the VMware View Agent 

> VMware FlashMMR folder in the Group Policy

Management Editor.

N The Connect using DNS Name seing was removed in the Horizon 6 version 6.1 release. You can set

the Horizon 7 LDAP aribute, pae-PreferDNS, to tell Horizon Connection Server to give preference to DNS

names when sending the addresses of desktop machines and RDS hosts to clients and gateways. See "Give

Preference to DNS Names When Horizon Connection Server Returns Address Information" in the View

Installation document.

USB Settings for the Horizon Agent

See “USB Seings in the Horizon Agent Conguration ADMX Template,” on page 83.

Client System Information Sent to Remote Desktops

When a user connects or reconnects to a remote desktop, Horizon Client gathers information about the

client system and Connection Server sends that information to the remote desktop.

Horizon Agent writes the client computer information to the system registry path HKCU\Volatile

Environment on remote desktops that are deployed on single-user machines. For remote desktops that are

deployed in RDS sessions, Horizon Agent writes the client computer information to the system registry path

HKCU\Volatile Environment\x, where x is the session ID, on the RDS host.

Configuring Remote Desktop Features in Horizon 7

106 VMware, Inc.

If Horizon Client is running inside of a remote desktop session, it sends the physical client information

instead of the virtual machine information to the remote desktop. For example, if a user connects from their

client system to a remote desktop, launches Horizon Client inside the remote desktop and connects to

another remote desktop, the IP address of the physical client system is sent to the second remote desktop.

This feature is referred to as nested mode or a double-hop scenario. Horizon Client sends

ViewClient_Nested_Passthrough, which is set to 1, along with the client system information to indicate that

it is sending nested mode information.

N With Horizon Client 4.1, client system information is passed to the second-hop desktop on the initial

protocol connection. With Horizon Client 4.2 and later, client system information is also updated if the rst-

hop protocol connection disconnects and reconnects.

You can add commands to the Horizon Agent CommandsToRunOnConnect, CommandsToRunOnReconnect, and

CommandsToRunOnDisconnect group policy seings to run commands or command scripts that read this

information from the system registry when users connect and reconnect to desktops. See “Running

Commands on Horizon Desktops,” on page 110 for more information.

Table 5-7 describes the registry keys that contain client system information and lists the types of desktops

and client systems that support them. If Yes appears in the Supports Nested Mode column, it indicates that

physical client information (rather than virtual machine information) is sent to a second-hop desktop.

Table 5‑7. Client System Information

Registry Key Description

Supports

Nested

Mode Supported Desktops

Supported Client

Systems

ViewClient_IP_Address The IP address of the

client system.

Yes VDI (single-user

machine)

RDS

Windows, Linux, Mac,

Android, iOS,

Windows Store

ViewClient_MAC_Address The MAC address of the

client system.

Yes VDI (single-user

machine)

RDS

Windows, Linux, Mac,

Android

ViewClient_Machine_Name The machine name of the

client system.

Yes VDI (single-user

machine)

RDS

Windows, Linux, Mac,

Android, iOS,

Windows Store

ViewClient_Machine_Domain The domain of the client

system.

Yes VDI (single-user

machine)

RDS

Windows, Windows

Store

ViewClient_LoggedOn_Userna

The user name that was

used to log in to the

client system.

VDI (single-user

machine)

RDS

Windows, Linux, Mac

ViewClient_LoggedOn_Domain

name

The domain name that

was used to log in to the

client system.

VDI (single-user

machine)

RDS

Windows, Windows

Store

For Linux and Mac

clients, see

ViewClient_Machine

_Domain.ViewClient

_LoggedOn_Domainna

me is not given by the

Linux or Mac client

because Linux and

Mac accounts are not

bound to Windows

domains.

ViewClient_Type The thin client name or

operating system type of

the client system.

Yes VDI (single-user

machine)

RDS

Windows, Linux, Mac,

Android, iOS,

Windows Store

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 107

Table 5‑7. Client System Information (Continued)

Registry Key Description

Supports

Nested

Mode Supported Desktops

Supported Client

Systems

ViewClient_Broker_DNS_Name The DNS name of the

View Connection Server

instance.

VDI (single-user

machine)

RDS

Value is sent directly

from View Connection

Server, not gathered

by Horizon Client.

ViewClient_Broker_URL The URL of the View

Connection Server

instance.

VDI (single-user

machine)

RDS

Value is sent directly

from View Connection

Server, not gathered

by Horizon Client.

ViewClient_Broker_Tunneled The status of the tunnel

connection for the View

Connection Server,

which can be either true

(enabled) or false

(disabled).

VDI (single-user

machine)

RDS

Value is sent directly

from View Connection

Server, not gathered

by Horizon Client.

ViewClient_Broker_Tunnel_U

The URL of the View

Connection Server tunnel

connection, if the tunnel

connection is enabled.

VDI (single-user

machine)

RDS

Value is sent directly

from View Connection

Server, not gathered

by Horizon Client.

ViewClient_Broker_Remote_I

P_Address

The IP address of the

client system that is seen

by the View Connection

Server instance.

VDI (single-user

machine)

RDS

Value is sent directly

from View Connection

Server, not gathered

by Horizon Client.

ViewClient_TZID The Olson time zone ID.

To disable time zone

synchronization, enable

the Horizon Agent

Disable Time Zone

Synchronization group

policy seing.

VDI (single-user

machine)

RDS

Windows, Linux, Mac,

Android, iOS

ViewClient_Windows_Timezon

The GMT standard time.

To disable time zone

synchronization, enable

the Horizon Agent

Disable Time Zone

Synchronization group

policy seing.

VDI (single-user

machine)

RDS

Windows, Windows

Store

ViewClient_Broker_DomainNa

Domain name used to

authenticate to View

Connection Server.

VDI (single-user

machine)

RDS

Value is sent directly

from View Connection

Server, not gathered

by Horizon Client.

ViewClient_Broker_UserName Username used to

authenticate to View

Connection Server.

VDI (single-user

machine)

RDS

Value is sent directly

from View Connection

Server, not gathered

by Horizon Client.

ViewClient_Client_ID Species the Unique

Client HardwareId

used as a link to the

license key.

VDI (single-user

machine)

RDS

Windows, Linux, Mac,

Android, iOS,

Windows Store

ViewClient_Displays.Number Species the number of

monitors being used on

the client.

VDI (single-user

machine)

RDS

Windows, Linux, Mac,

Android, iOS,

Windows Store

Configuring Remote Desktop Features in Horizon 7

108 VMware, Inc.

Table 5‑7. Client System Information (Continued)

Registry Key Description

Supports

Nested

Mode Supported Desktops

Supported Client

Systems

ViewClient_Displays.Topolo

Species the

arrangement, resolution,

and dimensions of

displays on the client.

VDI (single-user

machine)

RDS

Windows, Linux, Mac,

Android, iOS,

Windows Store

ViewClient_Keyboard.Type Species the type of

keyboard being used on

the client. For example:

Japanese, Korean.

VDI (single-user

machine)

RDS

Windows

ViewClient_Launch_SessionT

ype

Species the session

type. The type can be

desktop or application.

VDI (single-user

machine)

RDS

Value is sent directly

from View Connection

Server, not gathered

by Horizon Client.

ViewClient_Mouse.Identifie

Species the type of

mouse.

VDI (single-user

machine)

RDS

Windows

ViewClient_Mouse.NumButton

Species the number of

buons supported by the

mouse.

VDI (single-user

machine)

RDS

Windows

ViewClient_Mouse.SampleRat

Species the rate, in

reports per second, at

which input from a PS/2

mouse is sampled.

VDI (single-user

machine)

RDS

Windows

ViewClient_Protocol Species the protocol

being used.

VDI (single-user

machine)

RDS

Windows, Linux, Mac,

Android, iOS,

Windows Store

ViewClient_Language Species the operating

system language.

VDI (single-user

machine)

RDS

Windows, Linux, Mac,

Android, iOS,

Windows Store

ViewClient_Launch_Matched_

Tags

Species one or more

tags.

VDI (single-user

machine)

RDS

Windows, Linux, Mac,

Android, iOS,

Windows Store

ViewClient_Launch_ID Species the desktop or

application pool Unique

ID.

VDI (single-user

machine)

RDS

Windows, Linux, Mac,

Android, iOS,

Windows Store

ViewClient_Broker_Farm_ID Species the Farm ID of

the desktop or

application pool on an

RDS host.

RDS Windows, Linux, Mac,

Android, iOS,

Windows Store

N The denitions of ViewClient_LoggedOn_Username and ViewClient_LoggedOn_Domainname in Table 5-7

apply to Horizon Client 2.2 for Windows or later releases.

For Horizon Client 5.4 for Windows or earlier releases, ViewClient_LoggedOn_Username sends the user name

that was entered in Horizon Client, and ViewClient_LoggedOn_Domainname sends the domain name that was

entered in Horizon Client.

Horizon Client 2.2 for Windows is a later release than Horizon Client 5.4 for Windows. Starting with

Horizon Client 2.2, the release numbers for Windows are consistent with the Horizon Client releases on

other operating systems and devices.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 109

Running Commands on Horizon Desktops

You can use the Horizon Agent CommandsToRunOnConnect, CommandsToRunOnReconnect, and

CommandsToRunOnDisconnect group policy seings to run commands and command scripts on Horizon

desktops when users connect, reconnect, and disconnect.

To run a command or a command script, add the command name or the le path of the script to the group

policy seing's list of commands. For example:

date

C:\Scripts\myscript.cmd

To run scripts that require console access, prepend the -C or -c option followed by a space. For example:

-c C:\Scripts\Cli_clip.cmd

-C e:\procexp.exe

Supported le types include .CMD, .BAT, and .EXE. .VBS les will not run unless they are parsed with

cscript.exe or wscript.exe. For example:

-C C:\WINDOWS\system32\wscript.exe C:\Scripts\checking.vbs

The total length of the string, including the -C or -c option, should not exceed 260 characters.

PCoIP Policy Settings

The PCoIP ADMX template le contains policy seings related to the PCoIP display protocol. The ADMX

template le is named (pcoip.admx). You can congure seings to default values that can be overridden by

an administrator, or you can congure seings to non-overridable values.

The ADMX les are available in a bundled .zip le named VMware-Horizon-Extras-Bundle-x.x.x-

yyyyyyy.zip, which you can download from the VMware download site at

hps://my.vmware.com/web/vmware/downloads. Under Desktop & End-User Computing, select the

VMware Horizon 7 download, which includes the bundled .zip le.

The PCoIP Session Variables ADMX template le contains two subcategories:

Overridable

Administrator Defaults

Species PCoIP policy seing default values. These seings can be

overridden by an administrator. These seings write registry keys values to

HKLM\Software\Policies\Teradici\PCoIP\pcoip_admin_defaults. All of these

seings are in the Computer  > Policies > Administrative

Templates > PCoIP Session Variables > Overridable Administrator

Defaults folder in the Group Policy Management Editor.

Not Overridable

Administrator Settings

Contains the same seings as Overridable Administrator Defaults, but these

seings cannot be overridden by an administrator. These seings write

registry key values to HKLM\Software\Policies\Teradici\PCoIP\pcoip_admin.

All of these seings are in the User  > Policies >

Administrative Templates > PCoIP Session Variables > Not Overridable

Administrator  folder in the Group Policy Management Editor.

The template contains both Computer Conguration and User Conguration seings.

Configuring Remote Desktop Features in Horizon 7

110 VMware, Inc.

Non-Policy Registry Keys

If a local machine seing needs to be applied and cannot be placed under

HKLM\Software\Policies\Teradici, local machine seings can be placed in registry keys in

HKLM\Software\Teradici. The same registry keys can be placed in HKLM\Software\Teradici as in

HKLM\Software\Policies\Teradici. If the same registry key is present in both locations, the seing in

HKLM\Software\Policies\Teradici overrides the local machine value.

PCoIP General Settings

The PCoIP ADMX template le contains group policy seings that congure general seings such as PCoIP

image quality, USB devices, and network ports.

All of these seings are in the Computer  > Policies > Administrative Templates > PCoIP

Session Variables > Overridable Administrator Defaults folder in the Group Policy Management Editor.

All of these seings are also in the User  > Policies > Administrative Templates > PCoIP

Session Variables > Not Overridable Administrator  folder in the Group Policy Management

Editor.

Table 5‑8. PCoIP General Policy Settings

Setting Description

Configure PCoIP event log cleanup by

size in MB

Enables the conguration of the PCoIP event log cleanup by size in MB.

When this policy is congured, the seing controls how large a log le

can grow before it is cleaned up. For a non-zero seing of m, log les

larger than m MB are automatically and silently deleted. A seing of 0

indicates that no le cleanup by size takes place.

When this policy is disabled or not congured, the default event log

cleanup by size is 100 MB.

The log le cleanup is performed once at session startup. A change to

the seing is not applied until the next session.

Configure PCoIP event log cleanup by

time in days

Enables the conguration of the PCoIP event log cleanup by time in

days.

When this policy is congured, the seing controls how many days can

pass before the log le is cleaned up. For a non-zero seing of n, log les

older than n days are automatically and silently deleted. A seing of 0

indicates that no le cleanup by time takes place.

When this policy is disabled or not congured, the default event log

cleanup is 7 days.

The log le cleanup is performed once at session startup. A change to

the seing is not applied until the next session.

Configure PCoIP event log verbosity Sets the PCoIP event log verbosity. The values range from 0 (least

verbose) to 3 (most verbose).

When this seing is enabled, you can set the verbosity level from 0 to 3.

When the seing is not congured or disabled, the default event log

verbosity level is 2.

When this seing is modied during an active PCoIP session, the new

seing takes eect immediately.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 111

Table 5‑8. PCoIP General Policy Settings (Continued)

Setting Description

Configure PCoIP image quality levels Controls how PCoIP renders images during periods of network

congestion. The Minimum Image Quality, Maximum Initial Image

Quality, and Maximum Frame Rate values interoperate to provide ne

control in network-bandwidth constrained environments.

Use the Minimum Image Quality value to balance image quality and

frame rate for limited-bandwidth scenarios. You can specify a value

between 30 and 100. The default value is 40. A lower value allows higher

frame-rates, but with a potentially lower quality display. A higher value

provides higher image quality, but with potentially lower frame rates

when network bandwidth is constrained. When network bandwidth is

not constrained, PCoIP maintains maximum quality regardless of this

value.

Use the Maximum Initial Image Quality value to reduce the network

bandwidth peaks required by PCoIP by limiting the initial quality of the

changed regions of the display image. You can specify a value between

30 and 100. The default value is 80. A lower value reduces the image

quality of content changes and decreases peak bandwidth requirements.

A higher value increases the image quality of content changes and

increases peak bandwidth requirements. Unchanged regions of the

image progressively build to a lossless (perfect) quality regardless of this

value. A value of 80 or lower best utilizes the available bandwidth.

The Minimum Image Quality value cannot exceed the Maximum

Initial Image Quality value.

Use the Maximum Frame Rate value to manage the average bandwidth

consumed per user by limiting the number of screen updates per

second. You can specify a value between 1 and 120 frames per second.

The default value is 30. A higher value can use more bandwidth but

provides less jier, which allows smoother transitions in changing

images such as video. A lower value uses less bandwidth but results in

more jier.

These image quality values apply to the soft host only and have no eect

on a soft client.

When this seing is disabled or not congured, the default values are

used.

When this seing is modied during an active PCoIP session, the new

seing takes eect immediately.

Configure frame rate vs image quality

preference

Congure the frame rate and image quality preference from 0 (highest

frame rate) to 100 (highest image quality). If this policy is disabled or not

congured, the default seing is 50.

Higher value (max: 100) means you prefer high image quality even if

frame rate is choppy. Lower value (min: 0) means you prefer a uent

experience with aggressive image quality.

This seing could work with the Configure PCoIP image quality

levels GPO, which determines the max initial image quality level and

min image quality level. While the Frame rate and image quality

preference can adjust the image quality level for each frame, it cannot

exceed the max/min quality level threshold congured by Configure

PCoIP image quality levels GPO.

When this policy is changed during run time, it could take eect

immediately.

Configuring Remote Desktop Features in Horizon 7

112 VMware, Inc.

Table 5‑8. PCoIP General Policy Settings (Continued)

Setting Description

Configure PCoIP session encryption

algorithms

Controls the encryption algorithms advertised by the PCoIP endpoint

during session negotiation.

Checking one of the check boxes disables the associated encryption

algorithm. You must enable at least one algorithm.

This seing applies to both agent and client. The endpoints negotiate the

actual session encryption algorithm that is used. If FIPS140-2 approved

mode is enabled, the Disable AES-128-GCM encryption value is always

overridden so that AES-128-GCM encryption is enabled.

Supported encryption algorithms, in order of preference, are

SALSA20/12-256, AES-GCM-128, and AES-GCM-256. By default, all

supported encryption algorithms are available for negotiation by this

endpoint.

If both endpoints are congured to support all three algorithms and the

connection does not use a Security Gateway (SG), the SALSA20

algorithm will be negotiated and used. However, if the connection uses

an SG, SALSA20 is automatically disabled and AES128 will be

negotiated and used. If either endpoint or the SG disables SALSA20 and

either endpoint disables AES128, then AES256 will be negotiated and

used.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 113

Table 5‑8. PCoIP General Policy Settings (Continued)

Setting Description

Configure PCoIP USB allowed and

unallowed device rules

Species the USB devices that are authorized and not authorized for

PCoIP sessions that use a zero client that runs Teradici rmware. USB

devices that are used in PCoIP sessions must appear in the USB

authorization table. USB devices that appear in the USB unauthorization

table cannot be used in PCoIP sessions.

You can dene a maximum of 10 USB authorization rules and a

maximum of 10 USB unauthorization rules. Separate multiple rules with

the vertical bar (|) character.

Each rule can be a combination of a Vendor ID (VID) and a Product ID

(PID), or a rule can describe a class of USB devices. A class rule can

allow or disallow an entire device class, a single subclass, or a protocol

within a subclass.

The format of a combination VID/PID rule is 1xxxxyyyy, where xxxx is

the VID in hexadecimal format and yyyy is the PID in hexadecimal

format. For example, the rule to authorize or block a device with VID

0x1a2b and PID 0x3c4d is 11a2b3c4d.

For class rules, use one of the following formats:

Allow all USB

devices

Format: 23XXXXXX

Example: 23XXXXXX

Allow USB

devices with a

specific class

Format: 22classXXXX

Example: 22aaXXXX

Allow a specific

subclass

Format: 21class-subclassXX

Example: 21aabbXX

Allow a specific

protocol

Format: 20class-subclass-protocol

Example: 20aabbcc

For example, the USB authorization string to allow USB HID (mouse

and keyboard) devices (class ID 0x03) and webcams (class ID 0x0e) is

2203XXXX|220eXXXX. The USB unauthorization string to disallow USB

Mass Storage devices (class ID 0x08) is 2208XXXX.

An empty USB authorization string means that no USB devices are

authorized. An empty USB unauthorization string means that no USB

devices are banned.

This seing applies to Horizon Agent only and only when the remote

desktop is in a session with a zero client that runs Teradici rmware.

Device use is negotiated between the endpoints.

By default, all devices are allowed and none are disallowed.

Configuring Remote Desktop Features in Horizon 7

114 VMware, Inc.

Table 5‑8. PCoIP General Policy Settings (Continued)

Setting Description

Configure PCoIP virtual channels Species the virtual channels that can and cannot operate over PCoIP

sessions. This seing also determines whether to disable clipboard

processing on the PCoIP host.

Virtual channels that are used in PCoIP sessions must appear on the

virtual channel authorization list. Virtual channels that appear in the

unauthorized virtual channel list cannot be used in PCoIP sessions.

You can specify a maximum of 15 virtual channels for use in PCoIP

sessions.

Separate multiple channel names with the vertical bar (|) character. For

example, the virtual channel authorization string to allow the mksvchan

and vdp_rdpvcbridge virtual channels is mksvchan|vdp_vdpvcbridge.

If a channel name contains the vertical bar or backslash (\) character,

insert a backslash character before it. For example, type the channel

name awk|ward\channel as awk\|ward\\channel.

When the authorized virtual channel list is empty, all virtual channels

are disallowed. When the unauthorized virtual channel list is empty, all

virtual channels are allowed.

The virtual channels seing applies to both agent and client. Virtual

channels must be enabled on both agent and client for virtual channels

to be used.

The virtual channels seing provides a separate check box that allows

you to disable remote clipboard processing on the PCoIP host. This

value applies to the agent only.

By default, all virtual channels are enabled, including clipboard

processing.

Configure the PCoIP transport header Congures the PCoIP transport header and sets the transport session

priority.

The PCoIP transport header is a 32-bit header that is added to all PCoIP

UDP packets (only if the transport header is enabled and supported by

both sides). The PCoIP transport header allows network devices to make

beer prioritization/QoS decisions when dealing with network

congestion. The transport header is enabled by default.

The transport session priority determines the PCoIP session priority

reported in the PCoIP transport header. Network devices make beer

prioritization/QoS decisions based on the specied transport session

priority.

When the Configure the PCoIP transport header seing is

enabled, the following transport session priorities are available:

nHigh

nMedium (default value)

nLow

n

The transport session priority value is negotiated by the PCoIP agent

and client. If the PCoIP agent species a transport session priority value,

the session uses the agent-specied session priority. If only the client has

specied a transport session priority, the session uses the client-specied

session priority. If neither agent nor client has specied a transport

session priority, or  Priority is specied, the session uses the

default value, Medium priority.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 115

Table 5‑8. PCoIP General Policy Settings (Continued)

Setting Description

Configure the TCP port to which the

PCoIP host binds and listens

Species the TCP agent port bound to by software PCoIP hosts.

The TCP port value species the base TCP port that the agent aempts

to bind to. The TCP port range value determines how many additional

ports to try if the base port is not available. The port range must be

between 1 and 10.

The range spans from the base port to the sum of the base port and port

range. For example, if the base port is 4172 and the port range is 10, the

range spans from 4172 to 4182.

Do not set the size of the retry port range to 0. Seing this value to 0

causes a connection failure when users log in to the desktop with the

PCoIP display protocol. Horizon Client returns the error message, The

Display protocol for this desktop is currently not

available. Please contact your system administrator.

This seing applies to Horizon Agent only.

On single-user machines, the default base TCP port is 4172 in View 4.5

and later. The default base port is 50002 in View 4.0.x and earlier. By

default, the port range is 1.

On RDS hosts, the default base TCP port is 4173. When PCoIP is used

with RDS hosts, a separate PCoIP port is used for each user connection.

The default port range that is set by the Remote Desktop Service is large

enough to accommodate the expected maximum of concurrent user

connections.

I As a best practice, do not use this policy seing to change

the default port range on RDS hosts, or change the TCP port value from

the default of 4173. Most important, do not set the TCP port value to

4172. Reseing this value to 4172 will adversely aect PCoIP

performance in RDS sessions.

Configure the UDP port to which the

PCoIP host binds and listens

Species the UDP agent port bound to by software PCoIP hosts.

The UDP port value species the base UDP port that the agent aempts

to bind to. The UDP port range value determines how many additional

ports to try if the base port is not available. The port range must be

between 1 and 10.

Do not set the size of the retry port range to 0. Seing this value to 0

causes a connection failure when users log in to the desktop with the

PCoIP display protocol. Horizon Client returns the error message, The

Display protocol for this desktop is currently not

available. Please contact your system administrator.

The range spans from the base port to the sum of the base port and port

range. For example, if the base port is 4172 and the port range is 10, the

range spans from 4172 to 4182.

This seing applies to Horizon Agent only.

On single-user machines, the default base UDP port is 4172 for View 4.5

and later and 50002 for View 4.0.x and earlier. By default, the port range

is 10.

On RDS hosts, the default base UDP port is 4173. When PCoIP is used

with RDS hosts, a separate PCoIP port is used for each user connection.

The default port range that is set by the Remote Desktop Service is large

enough to accommodate the expected maximum of concurrent user

connections.

I As a best practice, do not use this policy seing to change

the default port range on RDS hosts, or change the UDP port value from

the default of 4173. Most important, do not set the UDP port value to

4172. Reseing this value to 4172 will adversely aect PCoIP

performance in RDS sessions.

Configuring Remote Desktop Features in Horizon 7

116 VMware, Inc.

Table 5‑8. PCoIP General Policy Settings (Continued)

Setting Description

Enable access to a PCoIP session from

a vSphere console

Determines whether to allow a vSphere Client console to display an

active PCoIP session and send input to the desktop.

By default, when a client is aached through PCoIP, the vSphere Client

console screen is blank and the console cannot send input. The default

seing ensures that a malicious user cannot view the user's desktop or

provide input to the host locally when a PCoIP remote session is active.

This seing applies to Horizon Agent only.

When this seing is disabled or not congured, console access is not

allowed. When this seing is enabled, the console displays the PCoIP

session and console input is allowed.

When this seing is enabled, the console can display a PCoIP session

that is running on a Windows 7 system only when the Windows 7

virtual machine is hardware v8. Hardware v8 is available only on ESXi

5.0 and later. By contrast, console input to a Windows 7 system is

allowed when the virtual machine is any hardware version.

Enable/disable audio in the PCoIP

session

Determines whether audio is enabled in PCoIP sessions. Both endpoints

must have audio enabled. When this seing is enabled, PCoIP audio is

allowed. When it is disabled, PCoIP audio is disabled. When this seing

is not congured, audio is enabled by default.

Enable/disable microphone noise and

DC offset filter in PCoIP session

Determines whether to enable the microphone noise and DC oset lter

for microphone input during PCoIP sessions.

This seing applies to Horizon Agent and Teradici audio driver only.

When this seing is not congured, the Teradici audio driver uses the

microphone noise and DC oset lter by default.

Turn on PCoIP user default input

language synchronization

Determines whether the default input language for the user in the

PCoIP session is synchronized with the default input language of the

PCoIP client endpoint. When this seing is enabled, synchronization is

allowed. When this seing is disabled or not congured,

synchronization is disallowed.

This seing applies to Horizon Agent only.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 117

Table 5‑8. PCoIP General Policy Settings (Continued)

Setting Description

Configure SSL Connections to satisfy

Security Tools

Species how SSL session negotiation connections are established.

In order to satisfy port scanners, enable this 'Congure SSL connections'

seing and on Horizon Agent, complete the following tasks:

1 In Microsoft Management Console, store a correctly named and

signed certicate into the Personal store for the Local Machine's

computer account and mark it exportable.

2 Store the certicate for the Certicate Authority that signed it in the

Trusted Root certicate store.

3 Disable connections to VMware View 5.1 and earlier.

4Congure Horizon Agent to load certicates only from the

Certicate Store. If the Personal store for the Local Machine is used,

leave the certicate store names unchanged as "MY" and "ROOT"

(without the quotes), unless a dierent store location was used in

steps 1 and 2.

The resulting PCoIP Server will satisfy Security Tools such as port

scanners.

Configure SSL Protocols Congures the OpenSSL protocol to restrict the use of certain protocols

before establishing an encrypted SSL connection. The protocol list

consists of one or more openssl protocol strings separated by colons.

Note that all cipher strings are case insensitive.

The default value is: 'TLS1.1:TLS1.2"

This means that both TLS v1.1 and TLS v1.2 are enabled (SSL v2.0,

SSLv3.0 and TLS v1.0 are disabled).

This seing applies to both Horizon Agent and Horizon Client.

If it is set on both sides, the OpenSSL protocol negotation rule will be

followed.

PCoIP Clipboard Settings

The Horizon PCoIP ADMX template le contains group policy seings that congure clipboard seings for

copy-and-paste operations.

All of these seings are in the Computer  > Policies > Administrative Templates > PCoIP

Session Variables > Overridable Administrator Defaults folder in the Group Policy Management Editor.

All of these seings are also in the User  > Policies > Administrative Templates > PCoIP

Session Variables > Not Overridable Administrator  folder in the Group Policy Management

Editor.

Configuring Remote Desktop Features in Horizon 7

118 VMware, Inc.

Table 5‑9. PCoIP Clipboard Policy Settings

Setting Description

Configure clipboard memory size on

server (in kilobytes)

Species the server's clipboard memory size value, in kilobytes. The

client also has a value for the clipboard memory size. After the session is

set up, the server sends its clipboard memory size value to the client.

The eective clipboard memory size value is the lesser of the client and

server clipboard memory size values.

You can specify a minimum value of 512 kilobytes and a maximum

value of 16384 kilobytes. If you specify 0 or do not specify a value, the

default server clipboard memory size is 1024 kilobytes.

This seing applies only to version 7.0.1 or later and to Windows, Linux,

and Mac clients on which Horizon Client 4.1 or later is installed. In

earlier releases, the clipboard memory size is 1 MB.

N A large clipboard memory size can negatively aect

performance, depending on your network. VMware recommends that

you do not set the clipboard memory size to a value greater than 16 MB.

Configure clipboard redirection Determines the direction in which clipboard redirection is allowed. You

can select one of these values:

nEnabled client to agent only (That is, allow copy and paste only

from the client system to the remote desktop.)

nDisabled in both directions

nEnabled in both directions

nEnabled agent to client only (That is, allow copy and paste only

from the remote desktop to the client system.)

Clipboard redirection is implemented as a virtual channel. If virtual

channels are disabled, clipboard redirection does not function.

This seing applies to Horizon Agent only.

When this seing is disabled or not congured, the default value is

Enabled client to agent only.

Filter text out of the incoming

clipboard data

Species whether textual data is ltered out of the clipboard data

coming from the client to the agent. When this seing is enabled and the

check box is selected, the data is ltered out. When this seing is

disabled or not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter Rich Text Format data out of

the incoming clipboard data

Species whether Rich Text Format data is ltered out of the clipboard

data coming from the client to the agent. When this seing is enabled

and the check box is selected, the data is ltered out. When this seing is

disabled or not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter images out of the incoming

clipboard data

Species whether image data is ltered out of the clipboard data coming

from the client to the agent. When this seing is enabled and the check

box is selected, the data is ltered out. When this seing is disabled or

not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter Microsoft Office text data out

of the incoming clipboard data

Species whether Microsoft Oce text format data (BIFF12 format) is

ltered out of the clipboard data coming from the client to the agent.

When this seing is enabled and the check box is selected, the data is

ltered out. When this seing is disabled or not congured, the data is

allowed.

This seing applies to version 7.0.2 and later.

Filter Microsoft Chart and Smart Art

data out of the incoming clipboard

data

Species whether Microsoft Oce Chart and Smart Art data

(Art::GVML ClipFormat) is ltered out of the clipboard data coming

from the client to the agent. When this seing is enabled and the check

box is selected, the data is ltered out. When this seing is disabled or

not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 119

Table 5‑9. PCoIP Clipboard Policy Settings (Continued)

Setting Description

Filter Microsoft Text Effects data

out of the incoming clipboard data

Species whether Microsoft Oce text eects data (HTML Format) is

ltered out of the clipboard data coming from the client to the agent.

When this seing is enabled and the check box is selected, the data is

ltered out. When this seing is disabled or not congured, the data is

allowed.

This seing applies to version 7.0.2 and later.

Filter text out of the outgoing

clipboard data

Species whether textual data is ltered out of the clipboard data sent

from the agent to the client. When this seing is enabled and the check

box is selected, the data is ltered out. When this seing is disabled or

not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter Rich Text Format data out of

the outgoing clipboard data

Species whether Rich Text Format data is ltered out of the clipboard

data sent from the agent to the client. When this seing is enabled and

the check box is selected, the data is ltered out. When this seing is

disabled or not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter images out of the outgoing

clipboard data

Species whether image data is ltered out of the clipboard data sent

from the agent to the client. When this seing is enabled and the check

box is selected, the data is ltered out. When this seing is disabled or

not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter Microsoft Office text data out

of the outgoing clipboard data

Species whether Microsoft Oce text format data (BIFF12 format) is

ltered out of the clipboard data sent from the agent to the client. When

this seing is enabled and the check box is selected, the data is ltered

out. When this seing is disabled or not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter Microsoft Chart and Smart Art

data out of the outgoing clipboard

data

Species whether Microsoft Oce Chart and Smart Art data

(Art::GVML ClipFormat) is ltered out of the clipboard data sent from

the agent to the client. When this seing is enabled and the check box is

selected, the data is ltered out. When this seing is disabled or not

congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter Microsoft Text Effects data

out of the outgoing clipboard data

Species whether Microsoft Oce text eects data (HTML Format) is

ltered out of the clipboard data sent from the agent to the client. When

this seing is enabled and the check box is selected, the data is ltered

out. When this seing is disabled or not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

PCoIP Bandwidth Settings

The Horizon PCoIP ADMX template le contains group policy seings that congure PCoIP bandwidth

characteristics.

All of these seings are in the Computer  > Policies > Administrative Templates > PCoIP

Session Variables > Overridable Administrator Defaults folder in the Group Policy Management Editor.

All of these seings are also in the User  > Policies > Administrative Templates > PCoIP

Session Variables > Not Overridable Administrator  folder in the Group Policy Management

Editor.

Configuring Remote Desktop Features in Horizon 7

120 VMware, Inc.

Table 5‑10. Horizon PCoIP Session Bandwidth Variables

Setting Description

Configure the maximum PCoIP session

bandwidth

Species the maximum bandwidth, in kilobits per second, in a PCoIP

session. The bandwidth includes all imaging, audio, virtual channel,

USB, and control PCoIP trac.

Set this value to the overall capacity of the link to which your endpoint

is connected, taking into consideration the number of expected

concurrent PCoIP sessions. For example, with a single-user VDI

conguration (a single PCoIP session) that connects through a 4Mbit/s

Internet connection, set this value to 4Mbit, or 10% less than this value to

leave some allowance for other network trac. When you expect

multiple concurrent PCoIP sessions to share a link, comprising either

multiple VDI users or an RDS conguration, you might want to adjust

the seing accordingly. However, lowering this value will restrict the

maximum bandwidth for each active session.

Seing this value prevents the agent from aempting to transmit at a

higher rate than the link capacity, which would cause excessive packet

loss and a poorer user experience. This value is symmetric. It forces the

client and agent to use the lower of the two values that are set on the

client and agent side. For example, seing a 4Mbit/s maximum

bandwidth forces the agent to transmit at a lower rate, even though the

seing is congured on the client.

When this seing is disabled or not congured on an endpoint, the

endpoint imposes no bandwidth constraints. When this seing is

congured, the seing is used as the endpoint's maximum bandwidth

constraint in kilobits per second.

The default value when this seing is not congured is 900000 kilobits

per second.

This seing applies to Horizon Agent and the client. If the two

endpoints have dierent seings, the lower value is used.

Configure the PCoIP session bandwidth

floor

Species a lower limit, in kilobits per second, for the bandwidth that is

reserved by the PCoIP session.

This seing congures the minimum expected bandwidth transmission

rate for the endpoint. When you use this seing to reserve bandwidth

for an endpoint, the user does not have to wait for bandwidth to become

available, which improves session responsiveness.

Make sure that you do not over-subscribe the total reserved bandwidth

for all endpoints. Make sure that the sum of bandwidth oors for all

connections in your conguration does not exceed the network

capability.

The default value is 0, which means that no minimum bandwidth is

reserved. When this seing is disabled or not congured, no minimum

bandwidth is reserved.

This seing applies to Horizon Agent and the client, but the seing only

aects the endpoint on which it is congured.

When this seing is modied during an active PCoIP session, the

change takes eect immediately.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 121

Table 5‑10. Horizon PCoIP Session Bandwidth Variables (Continued)

Setting Description

Configure the PCoIP session MTU Species the Maximum Transmission Unit (MTU) size for UDP packets

for a PCoIP session.

The MTU size includes IP and UDP packet headers. TCP uses the

standard MTU discovery mechanism to set MTU and is not aected by

this seing.

The maximum MTU size is 1500 bytes. The minimum MTU size is 500

bytes. The default value is 1300 bytes.

Typically, you do not have to change the MTU size. Change this value if

you have an unusual network setup that causes PCoIP packet

fragmentation.

This seing applies to Horizon Agent and the client. If the two

endpoints have dierent MTU size seings, the lowest size is used.

If this seing is disabled or not congured, the client uses the default

value in the negotiation with Horizon Agent.

Configure the PCoIP session audio

bandwidth limit

Species the maximum bandwidth that can be used for audio (sound

playback) in a PCoIP session.

The audio processing monitors the bandwidth used for audio. The

processing selects the audio compression algorithm that provides the

best audio possible, given the current bandwidth utilization. If a

bandwidth limit is set, the processing reduces quality by changing the

compression algorithm selection until the bandwidth limit is reached. If

minimum quality audio cannot be provided within the bandwidth limit

specied, audio is disabled.

To allow for uncompressed high quality stereo audio, set this value to

higher than 1600 kbit/s. A value of 450 kbit/s and higher allows for

stereo, high-quality, compressed audio. A value between 50 kbit/s and

450 kbit/s results in audio that ranges between FM radio and phone call

quality. A value below 50 kbit/s might result in no audio playback.

This seing applies to Horizon Agent only. You must enable audio on

both endpoints before this seing has any eect.

In addition, this seing has no eect on USB audio.

If this seing is disabled or not congured, a default audio bandwidth

limit of 500 kilobits per second is congured to constrain the audio

compression algorithm selected. If the seing is congured, the value is

measured in kilobits per second, with a default audio bandwidth limit

of 500 kilobits per second.

This seing applies to View 4.6 and later. It has no eect on earlier

versions of View.

When this seing is modied during an active PCoIP session, the

change takes eect immediately.

Turn off Build-to-Lossless feature Species whether to turn the build-to-lossless feature of the PCoIP

protocol o or on. This feature is turned o by default.

If this seing is enabled or not congured, the build-to-lossless feature is

turned o, and images and other desktop and application content are

never built to a lossless state. In network environments with constrained

bandwidth, turning o the build-to-lossless feature can provide

bandwidth savings.

If this seing is disabled, the build-to-lossless feature is turned on.

Turning on the build-to-lossless feature is recommended in

environments that require images and other desktop and application

content to be built to a lossless state.

When this seing is modied during an active PCoIP session, the

change takes eect immediately.

For more information about the PCoIP build-to-lossless feature, see

“PCoIP Build-to-Lossless Feature,” on page 123.

Configuring Remote Desktop Features in Horizon 7

122 VMware, Inc.

PCoIP Keyboard Settings

The View PCoIP ADMX template le contains group policy seings that congure PCoIP seings that aect

the use of the keyboard.

All of these seings are in the Computer  > Policies > Administrative Templates > PCoIP

Session Variables > Overridable Administrator Defaults folder in the Group Policy Management Editor.

All of these seings are also in the User  > Policies > Administrative Templates > PCoIP

Session Variables > Not Overridable Administrator  folder in the Group Policy Management

Editor.

Table 5‑11. Horizon PCoIP Session Variables for the Keyboard

Setting Description

Disable sending CAD when users press

Ctrl+Alt+Del

When this policy is enabled, users must press Ctrl+Alt+Insert instead of

Ctrl+Alt+Del to send a Secure Aention Sequence (SAS) to the remote

desktop during a PCoIP session.

You might want to enable this seing if users become confused when

they press Ctrl+Alt+Del to lock the client endpoint and an SAS is sent to

both the host and the guest.

This seing applies to Horizon Agent only and has no eect on a client.

When this policy is not congured or is disabled, users can press Ctrl

+Alt+Del or Ctrl+Alt+Insert to send an SAS to the remote desktop.

Use alternate key for sending Secure

Attention Sequence

Species an alternate key, instead of the Insert key, for sending a Secure

Aention Sequence (SAS).

You can use this seing to preserve the Ctrl+Alt+Ins key sequence in

virtual machines that are launched from inside a remote desktop during

a PCoIP session.

For example, a user can launch a vSphere Client from inside a PCoIP

desktop and open a console on a virtual machine in vCenter Server. If

the Ctrl+Alt+Ins sequence is used inside the guest operating system on

the vCenter Server virtual machine, a Ctrl+Alt+Del SAS is sent to the

virtual machine. This seing allows the Ctrl+Alt+Alternate Key sequence

to send a Ctrl+Alt+Del SAS to the PCoIP desktop.

When this seing is enabled, you must select an alternate key from a

drop-down menu. You cannot enable the seing and leave the value

unspecied.

When this seing is disabled or not congured, the Ctrl+Alt+Ins key

sequence is used as the SAS.

This seing applies to Horizon Agent only and has no eect on a client.

PCoIP Build-to-Lossless Feature

You can congure the PCoIP display protocol to use an encoding approach called progressive build, or

build-to-lossless, which works to provide the optimal overall user experience even under constrained

network conditions. This feature is turned o by default.

The build-to-lossless feature provides a highly compressed initial image, called a lossy image, that is then

progressively built to a full lossless state. A lossless state means that the image appears with the full delity

intended.

On a LAN, PCoIP always displays text using lossless compression. If the build-to-lossless feature is turned

on, and if available bandwidth per session drops below 1Mbs, PCoIP initially displays a lossy text image

and rapidly builds the image to a lossless state. This approach allows the desktop to remain responsive and

display the best possible image during varying network conditions, providing an optimal experience for

users.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 123

The build-to-lossless feature provides the following characteristics:

nDynamically adjusts image quality

nReduces image quality on congested networks

nMaintains responsiveness by reducing screen update latency

nResumes maximum image quality when the network is no longer congested

You can turn on the build-to-lossless feature by disabling the Turn off Build-to-Lossless feature group

policy seing. See “PCoIP Bandwidth Seings,” on page 120.

VMware Blast Policy Settings

The VMware Blast group policy ADMX template le vdm_blast.admx contains policy seings for the

VMware Blast display protocol. After the policy is applied, the seings are stored in the registry key

HKLM\Software\Policies\VMware, Inc.\VMware Blast\config.

These seings apply to HTML Access and all Horizon Clients.

Table 5‑12. VMware Blast Policy Settings

Setting Description

Max Session

Bandwidth

Species the maximum bandwidth, in kilobits per second (kbps), for a VMware Blast session.

The bandwidth includes all imaging, audio, virtual channel, USB, and VMware Blast control

trac. The default is 1 Gbps.

Min Session

Bandwidth

Species the minimum bandwidth, in kilobits per second (kbps), that is reserved for a

VMware Blast session. The default is 256 kbps.

Max Bandwidth Slope

for the Kbps Per

Megapixel

Species the maximum bandwidth slope, in kilobits per second (kbps), that is reserved for a

VMware Blast session. The minimum value is 100. The maximum value is 100000. The default

value is 6200.

Max Frame Rate Species the maximum rate of screen updates. Use this seing to manage the average

bandwidth that users consume. The default is 30 updates per second.

UDP Protocol Species whether to use the UDP or the TCP protocol. The default is to use the UDP protocol.

This seing requires a reboot of the Horizon Agent machine on which the registry key exists.

This seing does not apply to HTML Access, which always uses the TCP protocol.

H264 Species whether to use H.264 encoding or JPEG/PNG encoding. The default is to use H.264

encoding.

PNG If you enable or do not congure this seing, PNG encoding is available for remote sessions.

If you disable this seing, only JPEG encoding is used for encoding in JPEG/PNG mode. This

policy does not apply when the H.264 encoder is active. This seing is not congured by

default.

This seing applies to 7.0.2 and later.

Screen Blanking Species whether to have the desktop VM's console show the actual desktop that the user

sees or to show a blank screen when the desktop has an active session. The default is to show

a blank screen.

Cookie Cleanup

Interval

Determines how often, in milliseconds, cookies associated with inactive sessions are deleted.

The default is 100 ms.

Configuring Remote Desktop Features in Horizon 7

124 VMware, Inc.

Table 5‑12. VMware Blast Policy Settings (Continued)

Setting Description

Image Quality Species the image quality of the remote display. You can specify two low-quality seings,

two high-quality seings, and a mid-quality seing. The low-quality seings are for areas of

the screen that change often, for example, when scrolling occurs. The high-quality seings are

for areas of the screen that are more static, resulting in a beer image quality. You can specify

the following seings:

nLow JPEG Quality (available range of values: 1 - 100, default: 25)

nLow JPEG Chroma Subsampling (available range of values: 4:1:0 (lowest), 4:1:1, 4:2:0,

4:2:2, and 4:4:4 (highest), default: 4:1:0)

nMid JPEG Quality (available range of values: 1 - 100, default: 35)

nHigh JPEG Quality (available range of values: 1 - 100, default: 90)

nHigh JPEG Chroma Subsampling (available range of values: 4:1:0 (lowest), 4:1:1, 4:2:0,

4:2:2, and 4:4:4 (highest), default: 4:4:4)

H.264 Quality Species the image quality for the remote display congured to use H.264 encoding. You can

specify the minimum and maximum quantization values that determine how much an image

is controlled for lossless compression. You can specify a minimum quantization value for the

best image quality. You can specify a maximum quantization value for the lowest image

quality. You can specify the following seings:

nH264maxQP (available range of values: 0-51, default: 36)

nH264minQP (available range of values: 0-51, default: 10)

For the best image quality, set the quantization values to within +5 or -5 of the available range

of values.

HTTP Service Species the port that is used for secure communication (HTTPS) between the security server

or Access Point appliance and a desktop. The rewall must be congured to have this port

open. The default is 22443.

Audio playback Species whether audio playback is enabled for remote desktops. This seing is to enable

audio playback.

Configure clipboard

redirection

Species the permissible behavior for clipboard redirection. The options are:

nEnabled in both directions

nDisabled in both directions

nEnabled client to server only (Users can copy/paste from the client to the desktop only.)

nEnabled server to client only (Users can copy/paste from the desktop to the client only.)

The default is Enabled client to server only.

Clipboard memory

size on server(in

kilobytes)

Species the server's clipboard memory size value, in kilobytes. The client also has a value for

the clipboard memory size. After the session is set up, the server sends its clipboard memory

size value to the client. The eective clipboard memory size value is the lesser of the client

and server clipboard memory size values.

You can specify a minimum value of 512 kilobytes and a maximum value of 16384 kilobytes.

If you specify 0 or do not specify a value, the default server clipboard memory size is 1024

kilobytes.

This seing applies only to version 7.0.1 and later and to Windows, Linux, and Mac clients on

which Horizon Client 4.1 or later is installed. In earlier releases, the clipboard memory size is

1 MB.

N A large clipboard memory size can negatively aect performance, depending on your

network. VMware recommends that you do not set the clipboard memory size to a value

greater than 16 MB.

Keyboard locale

synchronization

Species whether to synchronize a client's keyboard locale list and default keyboard locale to

the remote desktop or application. If this seing is enabled, synchronization occurs. This

seing applies to Horizon Agent only.

N This feature is supported only for Horizon Client for Windows.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 125

Table 5‑12. VMware Blast Policy Settings (Continued)

Setting Description

Configure file

transfer

Species the permissible behavior for le transfer between a remote desktop and the

HTML Access client. You can select one of the following values:

nDisabled both upload and download

nEnabled both upload and download

nEnabled  upload only (Users can upload les from the client system to the remote

desktop only.)

nEnabled  download only (Users can download les from the remote desktop to the

client system only.)

The default is Enabled  upload only.

This seing applies only to version 7.0.1 and later and to HTML Access 4.1 and later.

Filter text out of

the incoming

clipboard data

Species whether textual data is ltered out of the clipboard data coming from the client to

the agent. When this seing is enabled and the check box is selected, the data is ltered out.

When this seing is disabled or not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter Rich Text

Format data out of

the incoming

clipboard data

Species whether Rich Text Format data is ltered out of the clipboard data coming from the

client to the agent. When this seing is enabled and the check box is selected, the data is

ltered out. When this seing is disabled or not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter images out of

the incoming

clipboard data

Species whether image data is ltered out of the clipboard data coming from the client to the

agent. When this seing is enabled and the check box is selected, the data is ltered out.

When this seing is disabled or not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter Microsoft

Office text data out

of the incoming

clipboard data

Species whether Microsoft Oce text format data (BIFF12 format) is ltered out of the

clipboard data coming from the client to the agent. When this seing is enabled and the check

box is selected, the data is ltered out. When this seing is disabled or not congured, the

data is allowed.

This seing applies to version 7.0.2 and later.

Filter Microsoft

Chart and Smart Art

data out of the

incoming clipboard

data

Species whether Microsoft Oce Chart and Smart Art data (Art::GVML ClipFormat) is

ltered out of the clipboard data coming from the client to the agent. When this seing is

enabled and the check box is selected, the data is ltered out. When this seing is disabled or

not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter Microsoft

Text Effects data

out of the incoming

clipboard data

Species whether Microsoft Oce text eects data (HTML Format) is ltered out of the

clipboard data coming from the client to the agent. When this seing is enabled and the check

box is selected, the data is ltered out. When this seing is disabled or not congured, the

data is allowed.

This seing applies to version 7.0.2 and later.

Filter text out of

the outgoing

clipboard data

Species whether textual data is ltered out of the clipboard data sent from the agent to the

client. When this seing is enabled and the check box is selected, the data is ltered out.

When this seing is disabled or not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter Rich Text

Format data out of

the outgoing

clipboard data

Species whether Rich Text Format data is ltered out of the clipboard data sent from the

agent to the client. When this seing is enabled and the check box is selected, the data is

ltered out. When this seing is disabled or not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter images out of

the outgoing

clipboard data

Species whether image data is ltered out of the clipboard data sent from the agent to the

client. When this seing is enabled and the check box is selected, the data is ltered out.

When this seing is disabled or not congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Configuring Remote Desktop Features in Horizon 7

126 VMware, Inc.

Table 5‑12. VMware Blast Policy Settings (Continued)

Setting Description

Filter Microsoft

Office text data out

of the outgoing

clipboard data

Species whether Microsoft Oce text format data (BIFF12 format) is ltered out of the

clipboard data sent from the agent to the client. When this seing is enabled and the check

box is selected, the data is ltered out. When this seing is disabled or not congured, the

data is allowed.

This seing applies to version 7.0.2 and later.

Filter Microsoft

Chart and Smart Art

data out of the

outgoing clipboard

data

Species whether Microsoft Oce Chart and Smart Art data (Art::GVML ClipFormat) is

ltered out of the clipboard data sent from the agent to the client. When this seing is enabled

and the check box is selected, the data is ltered out. When this seing is disabled or not

congured, the data is allowed.

This seing applies to version 7.0.2 and later.

Filter Microsoft

Text Effects data

out of the outgoing

clipboard data

Species whether Microsoft Oce text eects data (HTML Format) is ltered out of the

clipboard data sent from the agent to the client. When this seing is enabled and the check

box is selected, the data is ltered out. When this seing is disabled or not congured, the

data is allowed.

This seing applies to version 7.0.2 and later.

Applying VMware Blast Policy Settings

If the following VMware Blast policies change during a client session, Horizon Client detects the change and

immediately applies the new seing.

nH264

nAudio Playback

nMax Session Bandwidth

nMin Session Bandwidth

nMax Frame Rate

nImage Quality

For all other VMware Blast policies, Microsoft GPO update rules apply. GPOs can be updated manually or

by restarting the Horizon Agent machine. For more information, see the Microsoft documentation.

Enabling Lossless Compression for VMware Blast

You can enable the VMware Blast display protocol to use an encoding approach called progressive build, or

build-to-lossless. This feature provides a highly compressed initial image, called a lossy image, that is then

progressively built to a full lossless state. A lossless state means that the image appears with the full delity

intended.

To enable lossless compression for VMware Blast, set the EncoderBuildToPNG key to 1 in the

HKEY_LOCAL_MACHINE\SOFTWARE\VMware, Inc.\VMware Blast\Config folder in the Windows registry on the

agent machine. The default value is 0 (disabled), which means the codec does not build to PNG, which is a

lossless format.

Conguration changes to the EncoderBuildToPNG key take place immediately.

N Enabling lossless compression for VMware Blast causes an increase in bandwidth and CPU usage.

VMware recommends that you use the PCoIP display protocol instead of VMware Blast if you require

lossless compression. For information about conguring lossless compression for PCoIP, see “PCoIP Build-

to-Lossless Feature,” on page 123.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 127

Using Remote Desktop Services Group Policies

You can use Remote Desktop Services (RDS) group policies to control the conguration and performance of

RDS hosts and RDS desktop and application sessions. Horizon 7 provides ADMX les that contain the

Microsoft RDS group policies that are supported in Horizon 7.

As a best practice, congure the group policies that are provided in the Horizon 7 ADMX les rather than

the corresponding Microsoft group policies. The Horizon 7 group policies are certied to support your

Horizon 7 deployment.

Configure the RDS Per Device CAL Storage

You can congure the RDS Per Device CAL storage options to specify the location of the CALs to be stored.

This feature lets you decide whether you want to store the CALs or not.

Sometimes, there might be potential over usage of Per Device CALs, such as Horizon RDS Deployments

might have both Windows Server 2008 and Windows Server 2012 systems. Enabling this feature makes the

CAL usage ecient in Horizon RDS deployments. This is achieved by storing the issued license, supplying

the license when the client is trying to connect to the RDS host, and storing the license again if there is any

license upgrade.

You can congure the RDS Per Device CAL in the Horizon Administrator or manually in the Horizon LDAP

database.

Procedure

1 In the Horizon Administrator, click View  > Global .

2 In the General pane, click Edit.

3 Select one of the following congurations from the RDS Per Device CAL Storage Options drop-down

menu.

Option Description

Save only on Broker The Per Device CALs are saved only on Broker.

N The LDAP entry, cs-enablerdslicensing=true and

sendRdsLicense=false.

Save on both Clients and Broker The Per Device CALs are stored on both Clients and Broker.

N The LDAP entries cs-enablerdslicensing=true and

sendRdsLicense=true.

Don't save the Per Device CAL The Per Device CALs are not stored at any location.

N The LDAP entries, cs-enablerdslicensing=false and

sendRdsLicense=false.

4 Click OK.

Add the Remote Desktop Services ADMX Files to Active Directory

You can add the policy seings in the Horizon 7 RDS ADMX les to group policy objects (GPOs) in Active

Directory. You can also install the RDS ADMX les on individual RDS hosts.

Prerequisites

nCreate GPOs for the RDS group policy seings and link them to the OU that contains your RDS hosts.

nVerify that the Group Policy Management feature is available on your Active Directory server.

Configuring Remote Desktop Features in Horizon 7

128 VMware, Inc.

The steps for opening the Group Policy Management Console dier in the Windows 2012, Windows

2008, and Windows 2003 Active Directory versions. See “Create GPOs for Horizon 7 Group Policies,”

on page 169.

Procedure

1 Download the Horizon 7 GPO Bundle .zip le from the VMware download site at

hps://my.vmware.com/web/vmware/downloads.

Under Desktop & End-User Computing, select the VMware Horizon 7 download, which includes the

GPO Bundle.

The le is named VMware-Horizon-Extras-Bundle-x.x.x-yyyyyyy.zip, where x.x.x is the version and

yyyyyyy is the build number. All ADMX les that provide group policy seings for Horizon 7 are

available in this le.

2 Unzip the VMware-Horizon-Extras-Bundle-x.x.x-yyyyyyy.zip le and copy the RDS ADMX les to

your Active Directory or RDS host.

a Copy the vmware_rdsh.admx and vmware_rdsh_server.admx les and the en-US folder to the

C:\Windows\PolicyDefinitions folder on your Active Directory or RDS host.

b (Optional) Copy the language resource les vmware_rdsh.adml and vmware_rdsh_server.adml to the

appropriate subfolder in C:\Windows\PolicyDefinitions\ on your Active Directory or RDS host.

3 On the Active Directory host, open the Group Policy Management Editor.

On an individual RDS host, you can open the Local Group Policy Editor with the gpedit.msc utility.

The Horizon 7 RDS group policy seings are installed in the Computer  > Policies >

Administrative Templates > Windows Components > Remote Desktop Services > Remote Desktop

Session Host folder.

Some Horizon 7 RDS group policy seings are also installed in the User  >

Administrative Templates > Windows Components > Remote Desktop Services > Remote Desktop

Session Host folder.

4 (Optional) Congure the group policy seings in the Remote Desktop Services > Remote Desktop

Session Host folder.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 129

RDS Application Compatibility Settings

The RDS Application Compatibility group policy seings control Windows installer compatibility, remote

desktop IP virtualization, network adapter selection, and the use of the RDS host IP address.

Table 5‑13. RDS Application Compatibility Group Policy Settings

Setting Description

Turn off Windows Installer RDS Compatibility This policy seing species whether Windows Installer RDS

Compatibility runs on a per user basis for fully installed

applications. Windows Installer allows one instance of the

msiexec process to run at a time. By default, Windows

Installer RDS Compatibility is turned on.

If you enable this policy seing, Windows Installer RDS

Compatibility is turned o, and only one instance of the

msiexec process can run at a time.

If you disable or do not congure this policy seing, Windows

Installer RDS Compatibility is turned on, and multiple per

user application installation requests are queued and handled

by the msiexec process in the order in which they are

received.

Turn on Remote Desktop IP Virtualization This policy seing species whether Remote Desktop IP

Virtualization is turned on.

By default, Remote Desktop IP Virtualization is turned o.

If you enable this policy seing, Remote Desktop IP

Virtualization is turned on. You can select the mode in which

this seing is applied. If you are using Per Program mode, you

must enter a list of programs to use virtual IP addresses. List

each program on a separate line (do not enter any blank lines

between programs). For example:

explorer.exe

mstsc.exe

If you disable or do not congure this policy seing, Remote

Desktop IP Virtualization is turned o.

Select the network adapter to be used for

Remote Desktop IP Virtualization

This policy seing species the IP address and network mask

that corresponds to the network adapter used for virtual IP

addresses. The IP address and network mask should be

entered in Classless Inter-Domain Routing notation. For

example: 192.0.2.96/24.

If you enable this policy seing, the specied IP address and

network mask are used to select the network adapter used for

the virtual IP addresses.

If you disable or do not congure this policy seing, Remote

Desktop IP Virtualization is turned o. A network adapter

must be congured for Remote Desktop IP Virtualization to

work.

Do not use Remote Desktop Session Host server

IP address when virtual IP address is not

available

This policy seing species whether a session uses the IP

address of the RDS host if a virtual IP address is not available.

If you enable this policy seing, the IP address of the RDS host

is not used if a virtual IP is not available. The session will not

have network connectivity.

If you disable or do not congure this policy seing, the IP

address of the RDS host is used if a virtual IP is not available.

Configuring Remote Desktop Features in Horizon 7

130 VMware, Inc.

RDS Connections Settings

The RDS Connections group policy seings let users set policies for connections to sessions on RDS hosts.

The Horizon 7 RDS group policy seings are installed in the Computer  > Policies >

Administrative Templates > Windows Components > Remote Desktop Services > Remote Desktop

Session Host > Connections folder.

The Horizon 7 RDS group policy seings are also installed in the User  > Administrative

Templates > Windows Components > Remote Desktop Services > Remote Desktop Session Host >

Connections folder.

Table 5‑14. RDS Connections Group Policy Settings

Setting Description

Automatic reconnection Species whether to allow remote desktop connection clients

to automatically reconnect to sessions on an RDS host if their

network link is temporarily lost. By default, a maximum of

twenty reconnection aempts are made at ve second

intervals.

If you enable this policy seing, automatic reconnection is

aempted for all clients running the remote desktop

connection whenever their network connection is lost.

If you disable this policy seing, automatic reconnection of

clients is prohibited.

If you do not congure this policy seing, automatic

reconnection is not specied at the Group Policy level.

However, users can congure automatic reconnection using

the Reconnect if connection is dropped checkbox on the

Experience tab in the remote desktop connection.

Allow users to connect remotely using Remote

Desktop Services

This policy seing congures remote access to computers

using Remote Desktop Services.

If you enable this policy seing, users who are members of the

Remote Desktop Users group on the target computer can

connect remotely to the target computer using Remote

Desktop Services.

If you disable this policy seing, users cannot connect

remotely to the target computer using Remote Desktop

Services. The target computer will maintain any current

connections, but will not accept any new incoming

connections.

If you do not congure this policy seing, Remote Desktop

Services uses the Remote Desktop seing on the target

computer to determine whether remote connection is allowed.

This seing is found on the Remote tab in System Properties.

By default, remote connection is not allowed.

N You can limit which clients are able to connect

remotely using Remote Desktop Services by conguring the

"Require user authentication for remote connections by using

Network Level Authentication" policy seing located in the

Computer  > Administrative Templates >

Windows Components > Remote Desktop Services > Remote

Desktop Session Host > Security folder. You can limit the

number of users who can connect simultaneously by

conguring the Maximum Connections option on the

Network Adapter tab in the Remote Desktop Session Host

Conguration tool or by conguring the "Limit number of

connections" policy seing located in the Computer

 > Administrative Templates > Windows

Components > Remote Desktop Services > Remote Desktop

Session Host > Connections folder.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 131

Table 5‑14. RDS Connections Group Policy Settings (Continued)

Setting Description

Deny logoff of an administrator logged in to

the console session

This policy seing determines whether an administrator

aempting to connect remotely to the console of a server can

log o an administrator currently logged on to the console.

This policy is useful when the currently connected

administrator does not want to be logged o by another

administrator. If the connected administrator is logged o,

any data not previously saved is lost.

If you enable this policy seing, logging o the connected

administrator is not allowed.

If you disable or do not congure this policy seing, logging

o the connected administrator is allowed.

N The console session is also known as Session 0.

Console access can be obtained by using the /console switch

from Remote Desktop Connection in the computer eld name

or from the command line.

Configure keep-alive connection interval This policy seing allows you to enter a keep-alive interval to

ensure that the session state on the RDS host is consistent with

the client state.

After a client loses the connection to an RDS host, the session

on the RDS host might remain active instead of changing to a

disconnected state, even if the client is physically

disconnected from the RDS host. If the client logs on to the

same RDS host again, a new session might be established (if

the RDS host is congured to allow multiple sessions), and the

original session might still be active.

If you enable this policy seing, you must enter a keep-alive

interval. The keep-alive interval determines how often, in

minutes, the server checks the session state. The range of

values you can enter is 1 to 999,999.

If you disable or do not congure this policy seing, a keep-

alive interval is not set and the server will not check the

session state.

Limit number of connections Species whether Remote Desktop Services limits the number

of simultaneous connections to the server.

You can use this seing to restrict the number of Remote

Desktop Services sessions that can be active on a server. If this

number is exceeded, additional users who try to connect

receive an error message that states the server is busy and to

try again later. Restricting the number of sessions improves

performance because fewer sessions are demanding system

resources. By default, RDS hosts allow an unlimited number

of Remote Desktop Services sessions, and Remote Desktop for

Administration allows two Remote Desktop Services sessions.

To use this seing, enter the number of connections you want

to specify as the maximum for the server. To specify an

unlimited number of connections, type 999999.

If you enable this policy seing, the maximum number of

connections is limited to the specied number consistent with

the version of Windows and the mode of Remote Desktop

Services running on the server.

If you disable or do not congure this policy seing, limits to

the number of connections are not enforced at the Group

Policy level.

N This seing is designed to be used on RDS hosts,

which are servers running the Windows operating system

with Remote Desktop Session Host role service installed.

Configuring Remote Desktop Features in Horizon 7

132 VMware, Inc.

Table 5‑14. RDS Connections Group Policy Settings (Continued)

Setting Description

Set rules for remote control of Remote

Desktop Services user sessions

Use this policy seing to specify the level of remote control

permied in a Remote Desktop Services session.

You can use this policy seing to select one of two levels of

remote control: View Session or Full Control. View Session

permits the remote control user to watch a session. Full

Control permits the administrator to interact with the session.

Remote control can be established with or without the user's

permission.

If you enable this policy seing, administrators can remotely

interact with a user's Remote Desktop Services session

according to the specied rules. To set these rules, select the

desired level of control and permission in the Options list. To

disable remote control, select "No remote control allowed."

If you disable or do not congure this policy seing, remote

control rules are determined by the seing on the Remote

Control tab in the Remote Desktop Session Host

Conguration tool. By default, remote control users have full

control of the session with the user's permission.

N This policy seing appears in both Computer

Conguration and User Conguration. If both policy seings

are congured, the Computer Conguration policy seing

takes precedence.

Restrict Remote Desktop Services users to a

single Remote Desktop Services session

Use this policy seing to restrict users to a single Remote

Desktop Services session.

If you enable this policy seing, users who log on remotely

using Remote Desktop Services will be restricted to a single

session (either active or disconnected) on that server. If the

user leaves the session in a disconnected state, the user

automatically reconnects to that session at next logon.

If you disable this policy seing, users are allowed to make

unlimited simultaneous remote connections using Remote

Desktop Services.

If you do not congure this policy seing, the "Restrict each

user to one session" seing in the Remote Desktop Session

Host Conguration tool will determine if users are restricted

to a single Remote Desktop Services session.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 133

Table 5‑14. RDS Connections Group Policy Settings (Continued)

Setting Description

Allow remote start of unlisted programs Use this policy seing to specify whether remote users can

start any program on the RDS host when they start a Remote

Desktop Services session, or whether they can only start

programs that are listed in the RemoteApp Programs list.

You can control which programs on an RDS host can be

started remotely by using the RemoteApp Manager tool to

create a list of RemoteApp programs. By default, only

programs in the RemoteApp Programs list can be started

when a user starts a Remote Desktop Services session.

If you enable this policy seing, remote users can start any

program on the RDS host when they start a Remote Desktop

Services session. For example, a remote user can start any

program by specifying the program's executable path at

connection time by using the Remote Desktop Connection

client.

If you disable or do not congure this policy seing, remote

users can only start programs that are listed in the

RemoteApp Programs list in RemoteApp Manager when they

start a Remote Desktop Services session.

Turn off Fair Share CPU Scheduling Fair Share CPU Scheduling dynamically distributes processor

time across all Remote Desktop Services sessions on the same

RDS host, based on the number of sessions and the demand

for processor time within each session.

If you enable this policy seing, Fair Share CPU Scheduling is

turned o.

If you disable or do not congure this policy seing, Fair

Share CPU Scheduling is turned on.

RDS Device and Resource Redirection Settings

The RDS device and resource redirection group policy seings control access to devices and resources on a

client computer in Remote Desktop Services sessions.

The Horizon 7 RDS group policy seings are installed in the Computer  > Policies >

Administrative Templates > Windows Components > Remote Desktop Services > Remote Desktop

Session Host > Device and Resource Redirection folder.

The Horizon 7 RDS group policy seings are also installed in the User  > Administrative

Templates > Windows Components > Remote Desktop Services > Remote Desktop Session Host > Device

and Resource Redirection folder.

Configuring Remote Desktop Features in Horizon 7

134 VMware, Inc.

Table 5‑15. RDS Device and Resource Redirection Group Policy Settings

Setting Description

Allow audio and video playback redirection Use this policy seing to specify whether users can redirect

the remote computer's audio and video output in a Remote

Desktop Services session.

Users can specify where to play the remote computer's audio

output by conguring the remote audio seings on the Local

Resources tab in Remote Desktop Connection (RDC). Users

can choose to play the remote audio on the remote computer

or on the local computer. Users can also choose to not play the

audio. Video playback can be congured by using the

videoplayback seing in a Remote Desktop Protocol (.rdp)

le. By default, video playback is enabled.

By default, audio and video playback redirection is not

allowed when connecting to a computer running Windows

Server 2008 R2, Windows Server 2008, or Windows Server

2003. Audio and video playback redirection is allowed by

default when connecting to a computer running Windows 7,

Windows Vista, or Windows XP Professional.

If you enable this policy seing, audio and video playback

redirection is allowed.

If you disable this policy seing, audio and video playback

redirection is not allowed, even if audio playback redirection

is specied in RDC or video playback is specied in the .rdp

le.

If you do not congure this policy seing, the Audio and

video playback seing on the Client Seings tab in the Remote

Desktop Session Host Conguration tool determines whether

audio and video playback redirection is allowed.

Allow audio recording redirection Use this policy seing to specify whether users can record

audio to the remote computer in a Remote Desktop Services

session.

Users can specify whether to record audio to the remote

computer by conguring the remote audio seings on the

Local Resources tab in Remote Desktop Connection (RDC).

Users can record audio by using an audio input device on the

local computer, such as a built-in microphone.

By default, audio recording redirection is not allowed when

connecting to a computer running Windows Server 2008 R2.

Audio recording redirection is allowed by default when

connecting to a computer running Windows 7.

If you enable this policy seing, audio recording redirection is

allowed.

If you disable this policy seing, audio recording redirection

is not allowed, even if audio recording redirection is specied

in RDC.

If you do not congure this policy seing, the Audio

recording seing on the Client Seings tab in the Remote

Desktop Session Host Conguration tool determines whether

audio recording redirection is allowed.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 135

Table 5‑15. RDS Device and Resource Redirection Group Policy Settings (Continued)

Setting Description

Limit audio playback quality Use this policy seing to limit the audio playback quality for a

Remote Desktop Services session. Limiting the quality of

audio playback can improve connection performance,

particularly over slow links.

If you enable this policy seing, you must select one of the

following: High, Medium, or Dynamic. If you select High, the

audio will be sent without any compression and with

minimum latency. This requires a large amount of bandwidth.

If you select Medium, the audio will be sent with some

compression and with minimum latency as determined by the

codec that is being used. If you select Dynamic, the audio will

be sent with a level of compression that is determined by the

bandwidth of the remote connection.

The audio playback quality that you specify on the remote

computer by using this policy seing is the maximum quality

that can be used for a Remote Desktop Services session,

regardless of the audio playback quality congured on the

client computer. For example, if the audio playback quality

congured on the client computer is higher than the audio

playback quality congured on the remote computer, the

lower level of audio playback quality will be used.

Audio playback quality can be congured on the client

computer by using the audioqualitymode seing in a Remote

Desktop Protocol (.rdp) le. By default, audio playback

quality is set to Dynamic.

Do not allow clipboard redirection Species whether to prevent the sharing of clipboard contents

(clipboard redirection) between a remote computer and a

client computer during a Remote Desktop Services session.

You can use this seing to prevent users from redirecting

clipboard data to and from the remote computer and the local

computer. By default, Remote Desktop Services allows

clipboard redirection.

If you enable this seing, users cannot redirect clipboard data.

If you disable this seing, Remote Desktop Services always

allows clipboard redirection.

If you do not congure this seing, clipboard redirection is

not specied at the Group Policy level. However, an

administrator can still disable clipboard redirection using the

Remote Desktop Session Host Conguration tool.

Do not allow COM port redirection Species whether to prevent the redirection of data to client

COM ports from the remote computer in a Remote Desktop

Services session.

You can use this seing to prevent users from redirecting data

to COM port peripherals or mapping local COM ports while

they are logged on to a Remote Desktop Services session. By

default, Remote Desktop Services allows this COM port

redirection.

If you enable this seing, users cannot redirect server data to

the local COM port.

If you disable this seing, Remote Desktop Services always

allows COM port redirection.

If you do not congure this seing, COM port redirection is

not specied at the Group Policy level. However, an

administrator can still disable COM port redirection using the

Remote Desktop Session Host Conguration tool.

Configuring Remote Desktop Features in Horizon 7

136 VMware, Inc.

Table 5‑15. RDS Device and Resource Redirection Group Policy Settings (Continued)

Setting Description

Do not allow drive redirection Species whether to prevent the mapping of client drives in a

Remote Desktop Services session (drive redirection).

By default, an RD Session Host server maps client drives

automatically upon connection. Mapped drives appear in the

session folder tree in Windows Explorer or Computer in the

format <driveleer> on <computername>. You can use this

seing to override this behavior.

If you enable this seing, client drive redirection is not

allowed in Remote Desktop Services sessions.

If you disable this seing, client drive redirection is always

allowed.

If you do not congure this seing, client drive redirection is

not specied at the Group Policy level. However, an

administrator can still disable client drive redirection by using

the Remote Desktop Session Host Conguration tool.

Do not allow LTP Port redirection Species whether to prevent the redirection of data to client

LPT ports during a Remote Desktop Services session.

You can use this seing to prevent users from mapping local

LPT ports and redirecting data from the remote computer to

local LPT port peripherals. By default, Remote Desktop

Services allows this LPT port redirection.

If you enable this seing, users in a Remote Desktop Services

session cannot redirect server data to the local LPT port.

If you disable this seing, LPT port redirection is always

allowed.

If you do not congure this seing, LPT port redirection is not

specied at the Group Policy level. However, an administrator

can still disable local LPT port redirection using the Remote

Desktop Session Host Conguration tool.

Do not allow supported Plug and Play device

redirection

Use this policy seing to control the redirection of supported

Plug and Play devices, such as Windows Portable Devices, to

the remote computer in a Remote Desktop Services session.

By default, Remote Desktop Services allows redirection of

supported Plug and Play devices. Users can use the "More"

option on the Local Resources tab of Remote Desktop

Connection to choose the supported Plug and Play devices to

redirect to the remote computer.

If you enable this policy seing, users cannot redirect their

supported Plug and Play devices to the remote computer.

If you disable this policy seing or do not congure this policy

seing, users can redirect their supported Plug and Play

devices to the remote computer.

N You can also disallow redirection of supported Plug

and Play devices on the Client Seings tab in the Remote

Desktop Session Host Conguration tool. You can disallow

redirection of specic types of supported Plug and Play

devices by using the policy seings in the Computer

 > Administrative Templates > System >

Device Installation > Device Installation Restrictions folder.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 137

Table 5‑15. RDS Device and Resource Redirection Group Policy Settings (Continued)

Setting Description

Do not allow smart card device redirection Use this policy seing to control the redirection of smart card

devices in a Remote Desktop Services session.

If you enable this policy seing, Remote Desktop Services

users cannot use a smart card to log on to a Remote Desktop

Services session.

If you disable or do not congure this policy seing, smart

card device redirection is allowed. By default, Remote

Desktop Services automatically redirects smart card devices

on connection.

N The client computer must be running at least Microsoft

Windows 2000 Server or at least Microsoft Windows XP

Professional and the target server must be joined to a domain.

Allow time zone redirection This policy seing determines whether the client computer

redirects its time zone seings to the Remote Desktop Services

session.

If you enable this policy seing, clients that are capable of

time zone redirection send their time zone information to the

server. The server base time is then used to calculate the

current session time (current session time = server base time +

client time zone).

If you disable or do not congure this policy seing, the client

computer does not redirect its time zone information and the

session time zone is the same as the server time zone.

RDS Licensing Settings

The RDS Licensing group policy seings control the order in which RDS license servers are located, whether

problem notications are displayed, and whether Per User or Per Device licensing is used for RDS Client

Access Licenses (CALs).

The Horizon 7 RDS group policy seings are installed in the Computer  > Policies >

Administrative Templates > Windows Components > Remote Desktop Services > Remote Desktop

Session Host > Licensing folder.

Configuring Remote Desktop Features in Horizon 7

138 VMware, Inc.

Table 5‑16. RDS Licensing Group Policy Settings

Setting Description

Use the specified Remote Desktop license

servers

This policy seing allows you to specify the order in which an

RDS host server aempts to locate Remote Desktop license

severs.

If you enable this policy seing, an RDS host server rst

aempts to locate the license servers that you specify. If the

specied license servers cannot be located, the RDS host

server will aempt automatic license server discovery.

In the automatic license server discovery process, an RDS host

server in a Windows Server-based domain aempts to contact

a license server in the following order:

1 License servers that are specied in the Remote Desktop

Session Host Conguration tool.

2 License servers that are published in Active Directory

Domain Services.

3 License servers that are installed on domain controllers in

the same domain as the RDS host.

If you disable or do not congure this policy seing, the RDS

host uses the license server discovery mode specied in the

Remote Desktop Session Host Conguration tool.

Hide notifications about RD Licensing

problems that affect the RD Session Host

server

This policy seing determines whether notications are

displayed on an RDS host when there are problems with RD

Licensing that aect the RDS host.

By default, notications are displayed on an RDS host after

you log on as a local administrator, if there are problems with

RD Licensing that aect the RDS host. If applicable, a

notication will also be displayed that notes the number of

days until the licensing grace period for the RDS host will

expire.

If you enable this policy seing, these notications will not be

displayed on the RDS host.

If you disable or do not congure this policy seing, these

notications will be displayed on the RDS host after you log

on as a local administrator.

Set the Remote Desktop licensing mode This policy seing allows you to specify the type of Remote

Desktop Services client access license (RDS CAL) that is

required to connect to this RDS host.

You can use this policy seing to select one of two licensing

modes: Per User or Per Device.

Per User licensing mode requires that each user account

connecting to this RDS host have an RDS Per User CAL.

Per Device licensing mode requires that each device

connecting to this RDS host have an RDS Per Device CAL.

If you enable this policy seing, the licensing mode that you

specify takes precedence over the licensing mode that is

specied during the installation of Remote Desktop Session

Host or specied in the Remote Desktop Session Host

Conguration tool.

If you disable or do not congure this policy seing, the

licensing mode that is specied during the installation of

Remote Desktop Session Host role service or specied in the

Remote Desktop Session Host Conguration tool is used.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 139

RDS Printer Redirection Settings

The RDS Printer Redirection group policy seings let users congure policies for printer redirection.

The Horizon 7 RDS group policy seings are installed in the Computer  > Policies >

Administrative Templates > Windows Components > Remote Desktop Services > Remote Desktop

Session Host > Printer Redirection folder.

The Horizon 7 RDS group policy seings are also installed in the User  > Administrative

Templates > Windows Components > Remote Desktop Services > Remote Desktop Session Host > Printer

Redirection folder.

Table 5‑17. RDS Printer Redirection Group Policy Settings

Setting Description

Do not set default client printer to be default

printer in a session

Use this policy seing to specify whether the client default

printer is automatically set as the default printer in a

session on an RDS host.

By default, Remote Desktop Services automatically

designates the client default printer as the default printer in

a session on an RDS host. You can use this policy seing to

override this behavior.

If you enable this policy seing, the default printer is the

printer specied on the remote computer.

If you disable this policy seing, the RDS host

automatically maps the client default printer and sets it as

the default printer upon connection.

If you do not congure this policy seing, the default

printer is not specied at the Group Policy level. However,

an administrator can congure the default printer for client

sessions by using the Remote Desktop Session Host

Conguration tool.

Do not allow client printer redirection Use this policy seing to specify whether to prevent the

mapping of client printers in Remote Desktop Services

sessions.

You can use this policy seing to prevent users from

redirecting print jobs from the remote computer to a

printer aached to their local (client) computer. By default,

Remote Desktop Services allows this client printer

mapping.

If you enable this policy seing, users cannot redirect print

jobs from the remote computer to a local client printer in

Remote Desktop Services sessions.

If you disable this policy seing, users can redirect print

jobs with client printer mapping.

If you do not congure this policy seing, client printer

mapping is not specied at the Group Policy level.

However, an administrator can still disable client printer

mapping by using the Remote Desktop Session Host

Conguration tool.

Configuring Remote Desktop Features in Horizon 7

140 VMware, Inc.

Table 5‑17. RDS Printer Redirection Group Policy Settings (Continued)

Setting Description

Use Remote Desktop Easy Print printer driver

first

Use this policy seing to specify whether the Remote

Desktop Easy Print printer driver is used rst to install all

client printers.

If you enable or do not congure this policy seing, the

RDS host rst tries to use the Remote Desktop Easy Print

printer driver to install all client printers. If for any reason

the Remote Desktop Easy Print printer driver cannot be

used, a printer driver on the RDS host that matches the

client printer is used. If the RDS host does not have a

printer driver that matches the client printer, the client

printer is not available for the Remote Desktop session.

If you disable this policy seing, the RDS host tries to nd

a suitable printer driver to install the client printer. If the

RDS host does not have a printer driver that matches the

client printer, the RDS host tries to use the Remote Desktop

Easy Print driver to install the client printer. If for any

reason the Remote Desktop Easy Print printer driver

cannot be used, the client printer is not available for the

Remote Desktop Services session.

N If the "Do not allow client printer redirection" policy

seing is enabled, the "Use Remote Desktop Easy Print

printer driver rst" policy seing is ignored.

Chapter 5 Configuring Policies for Desktop and Application Pools

VMware, Inc. 141

Table 5‑17. RDS Printer Redirection Group Policy Settings (Continued)

Setting Description

Specify RD Session Host Server fallback printer

driver behavior

Use this policy seing to specify the RDS host fallback

printer driver behavior.

By default, the RDS host fallback printer driver is disabled.

If the RDS host does not have a printer driver that matches

the client's printer, no printer will be available for the

Remote Desktop Services session.

If you enable this policy seing, the fallback printer driver

is enabled, and the default behavior is for the RDS host to

nd a suitable printer driver. If a printer driver is not

found, the client's printer is not available. You can choose

to change this default behavior. The available options are:

nDo nothing if one is not found. If there is a

printer driver mismatch, the RDS host will aempt to

nd a suitable driver. If one is not found, the client's

printer is not available. This is the default behavior.

nDefault to PCL if one is not found. If no

suitable printer driver can be found, default to the

Printer Control Language (PCL) fallback printer driver.

nDefault to PS if one is not found. If no

suitable printer driver can be found, default to the

PostScript (PS) fallback printer driver.

nShow both PCL and PS if one is not found. If

no suitable driver can be found, show both PS and

PCL-based fallback printer drivers.

If you disable this policy seing, the RDS host fallback

driver is disabled and the RDS host will not aempt to use

the fallback printer driver.

If you do not congure this policy seing, the fallback

printer driver behavior is o by default.

N If the "Do not allow client printer redirection"

seing is enabled, this policy seing is ignored and the

fallback printer driver is disabled.

Redirect only the default client printer Use this policy seing to specify whether the default client

printer is the only printer redirected in Remote Desktop

Services sessions.

If you enable this policy seing, only the default client

printer is redirected in Remote Desktop Services sessions.

If you disable or do not congure this policy seing, all

client printers are redirected in Remote Desktop Services

sessions.

Configuring Remote Desktop Features in Horizon 7

142 VMware, Inc.

RDS Profiles Settings

The RDS Proles group policy seings control roaming prole and home directory seings for Remote

Desktop Services sessions.

Table 5‑18. RDS Profiles Group Policy Settings

Setting Description

Limit the size of the entire roaming user

profile cache

This policy seing allows you to limit the size of the entire

roaming user prole cache on the local drive. This policy

seing only applies to a computer on which the Remote

Desktop Session Host role service is installed.

N If you want to limit the size of an individual user

prole, use the Limit profile size policy seing located in

User 

.

If you enable this policy seing, you must specify a

monitoring interval (in minutes) and a maximum size (in

gigabytes) for the entire roaming user prole cache. The

monitoring interval determines how often the size of the

entire roaming user prole cache is checked. When the size of

the entire roaming user prole cache exceeds the maximum

size that you have specied, the oldest (least recently used)

roaming user proles will be deleted until the size of the

entire roaming user prole cache is less than the maximum

size specied.

If you disable or do not congure this policy seing, no

restriction is placed on the size of the entire roaming user

prole cache on the local drive.

Note: This policy seing is ignored if the Prevent Roaming

Profile changes from propagating to the server

policy seing located in Computer



 is enabled.

Set Remote Desktop Services User Home

Configuring Remote Desktop Features In Horizon 7 VMware 7.2 72

Navigation menu

Versions of this User Manual:

Views

Navigation
