Act. Don’t react.

Spot subtle but significant deterioration early

Now vital signs can count for more. The SureSigns VS4 helps

you track subtle signs of deterioration so you can document

and escalate effectively. It simplifies your workflow with an

intuitive touchscreen interface, and provides time-saving

tools like QuickCapture and QuickCheck for documentation,

and QuickAlerts (single- or multi-parameter modified Early

Warning Scoring) to activate your hospital’s Rapid Response

Team (RRT) as appropriate. Now you can act decisively

to provide targeted care when it can do the most good.

Because it’s wiser to act rather than react.

Key advantages

• Brings configurable Early Warning Scores to the

bedside to help you identify subtle signs of patient

deterioration for decisive action

• Provides intuitive tools, such as QuickCapture

to simplify documentation, and QuickAlerts to

highlight patient deterioration for escalation

• Offers desired interfacing, using standard networking

infrastructures and the latest security and encryption1

SureSigns

VS4 vital signs monitor

Specs that matter,

clinical benefits that count

Now there’s a vital signs monitor that helps you identify subtle signs of

patient deterioration early and act decisively. Alternate between spot

check and frequent measurement of vitals. Capture and check values.

Streamline your workflow.

Simplify your workflow

• Touchscreen: color LED backlit screen

• Connect with IntelliVue Guardian software (MEWS)

• QuickCheck

- Caregiver authentication at the bedside

- Patient record validation at the bedside

- Patient record review before export to EHR

• QuickCapture

- Customize up to 40 observation and assessment

entries for fast recall and reuse

• QuickAlerts

- Choose Single or Modified Early Warning Scoring at

the bedside, including detection of patient deterioration

• QuickNBP

- Provides fast NBP measurements

- One-touch NBP on/off button

• SpO2

- Choice of Philips FAST-based SpO2 algorithm

or Masimo® SET® or rainbow® SpO2 (including certain

Masimo rainbow parameters)

- Either choice is compatible with a wide variety

of sensors

• Microstream™ etCO2 option

- Includes Integrated Pulmonary Index (IPI)

• Temperature choices

- Welch Allyn® Predictive, Covidien™ tympanic,

or Exergen® temporal

• Biomedical and IT device maintenance tool kit

• Exergen TemporalScanner™ thermometer option

- With optional disposable covers for cost-savings

• 1D/2D/RFID barcode scanner

- Programmable to support consistent and reliable

patient ID entry

Other benefits

• Uses same supplies as all Philips monitors

• Time-sync with hospital or network clock

• Stores up to 800 patient records

• Confirmation of exported records easily seen in green

• LAN/serial data export in HL7 format

• Internal WiFi – 802.11 a/b/g option

• USB port for easy software upgrades and to import

configuration settings

• Nurse call output

• Lithium ion battery

• Battery management, including a visible icon

to show unit is plugged in and charging

• AC power input with power cord clip

• Sturdy handle and rugged housing for easy portability

• Compatible with SureSigns Dashboard

“

An EWS system would be a major change

in the hospital, especially from the nursing

and medical records perspective.

”

Archie Marangos, Biomed, Tufts Medical Center, Boston, MA

Easy to use, easy to maintain

Width, height,

depth

W: 26 cm (10.2 in), H: 22 cm (8.6 in),

D: 14.5 cm (5.7 in)

Weight 3.6 kg (8 lb)

Screen 21.3 cm (8.4 in) SVGA TFT-AM LCD,

resistive touchscreen, 800 active pixels/line

Resolution: 600 active lines per frame

Viewing angle: ±60 degrees

NBP • Oscillometric using stepwise deflation pressure

– NBP interval choices

• Adult measurement range

– Systolic: 30 – 270 mmHg (4.0 – 36.0 kPa)

– Diastolic: 10 – 245 mmHg (1.3 – 32.7 kPa)

– MAP: 20 – 250 mmHg (2.7 – 34.0 kPa)

• Pediatric measurement range

– Systolic: 30 – 180 mmHg (4.0 – 24.0 kPa)

– Diastolic: 10 – 150 mmHg (1.3 – 20.0 kPa)

– MAP: 20 – 160 mmHg (2.7 – 21.3 kPa)

• Neonatal measurement range

– Systolic: 30 – 130 mmHg (4.0 – 17.0 kPa)

– Diastolic: 10–100 mmHg (1.3 – 13.3 kPa)

– MAP: 20 – 120 mmHg (2.7 – 16.0 kPa)

• The NBP measurement has an accuracy

over the ranges listed for these values

– Maximum standard deviation: 8 mmHg

– Maximum mean error: ±5 mmHg

• Subsequent cuff inflation

(in NBP interval mode only)

– The subsequent inflation pressure is

determined automatically depending on the

previous measurement and patient type

CO2Measurement range: 0 mmHg – 150 mmHg

Total response time for adults: 3.9 seconds

Accuracy: 0 mmHg – 38 mmHg: ±2 mmHg

39 mmHg – 150 mmHg: ±(5% of reading +

0.08% for every 1 mmHg above 38 mmHg)

Respiration rate range: 1 – 150 bpm

Respiration accuracy: ±1 bpm in the range of

0 – 70 bpm, ±2 bpm in the range of 71 – 120

bpm, ±3 bpm in the range of 121 – 150 bpm

Product specifications

SpO2

Philips

FAST-based

Meets EN ISO 9919 standard

Measurement range: 0 – 100%

Pulse rate measurement range:

30 bpm – 300 bpm

Pulse accuracy: within 2% or 1 bpm

SpO2

Masimo SET

and rainbow

SpO2 measurement range: 0 – 100%

SpO2 accuracy: depends upon patient type

and motion/no motion

SpHb measurement range, no motion:

0 – 25.0 g/dL

SpHb accuracy: ±1 g/dL over range of 8 – 17 g/dL

RRa measurement range: 0 breaths per

minute to 70 breaths per minute

RRa accuracy: 4 breaths per minute to 70

breaths per minute, ±1 breath per minute

SpHb and RRa are only supported on adult

and pediatric patients (>10 kg)

Temperature

Welch Allyn®

predictive

Modes: predictive and monitored

Probe sites: oral, rectal, or axillary

Range:

Monitor mode: 26.7 – 43.3 °C (80.1 – 109.9 °F)

Predictive mode: 34.4 – 40.6 °C (93.9 – 105.1 °F)

Accuracy: ±0.1 °C (±0.2 °F)

Measurement time: 4 - 6 seconds

Temperature

Covidien™

tympanic

Equivalency modes: ear (no adjustment),

oral, core, and rectal (adjusted from ear)

Range: 33 – 42.0 °C (91.4 – 107.6 °F)

Accuracy (overall range): ±0.2 °C (±0.4 °F)

Measurement response time: ≤ 2 seconds

Temperature

Exergen®

temporal

Range: 16 – 43 °C (60.8 – 109.4 °F)

Accuracy: ±0.1 °C (±0.2 °F)

Response time: approximately 1 second

IntelliVue

Guardian

software

Adult only

Battery Lithium ion, 10.8 – 11.1 V

Data output HL7 format, via Ethernet port

Serial data

Patient type Adult, pediatric, neonatal

“

An EWS system would be a major change

in the hospital, especially from the nursing

and medical records perspective.

Archie Marangos, Biomed, Tufts Medical Center, Boston, MA

Philips reserves the right to make changes in

specifications and/or to discontinue any product at

any time without notice or obligation and will not be

liable for any consequences resulting from the use

of this publication. Trademarks are the property of

Koninklijke Philips N.V. or their respective owners.

www.philips.com/SureSigns

Printed in the Netherlands.

4522 991 18911 * MAY 2016

1 SureSigns VS4 has tested compatible with Cisco Compatible Extensions, Version 4. Go to www.cisco.com/go/compatibledisclaimer for complete disclaimer.

Masimo, SET, and rainbow are registered trademarks of Masimo Corporation. Microstream and Covidien are trademarks of Covidien companies.

Welch Allyn is a registered trademark and TemporalScanner is a trademark of Welch Allyn Corporation. Exergen is a registered trademark

of Exergen Corporation. All other trademarks are property of their respective owners.

Make vital signs count for more

Ordering information

Catch the subtle signs that signal patient deterioration.

With the SureSigns VS4, you can act, not just react.

Premium rollstand has

an easy-to-clean molded

basket that swivels for easy

positioning in tight spaces,

and dedicated sections

for accessories such as a

barcode scanner, cleaning

wipes, NBP cuffs, extra

disposable temperature

covers, and the SpO2 sensor.

Parameters To order

NBP, FAST-based SpO2863283

SpO2 and NBP

accessories included

A01

No accessories A02

Temperature

Welch Allyn predictive

temperature

T01

Covidien tympanic

temperature

T02

Exergen temporal temperature T03

Exergen temporal cap holder C05

SpO2

Masimo SET SpO2M01

Masimo rainbow SpO2, SpHb M02

Masimo rainbow SpO2, RRa M03

Masimo SpO2 LNCS cable C01

Masimo SpO2, SpHb cable C02

Masimo SpO2, SpHb, RRa cable C03

Masimo SpO2, SpHb/LNCS,

RRa cable

C04

Adult NBP cuff N01

Capnography

Microstream CO2E01

Other

FIPS (US only) F01

IntelliVue Guardian software G01

Recorder R01

802.11 a/b/g wireless W01

Also available To order

SureSigns

premium rollstand

989803176601

SureSigns

standard rollstand

989803144001

Wall mount 989803144011

2D barcode scanner 989803147821

2D barcode

scanner holder

989803191611

HS-1 2D barcode

scanner

989803176611

HS-1 barcode scanner

roll-stand insert

989803184701

Serial interface adapter 989803159601

Wireless upgrade kit 989803181201

Tympanic temperature

upgrade kit

863293

Predictive temperature

upgrade kit

863294

Temporal temperature

upgrade kit

863342

IntelliVue Guardian

software license

863357

SpO2 FAST to Masimo

SET upgrade kit

863343
