IMPORTANT NOTES1HEADSET FEATURES201 0602 04 050312Keys FunctionsFocus Adjustment Wheel Adjust focusRed, Yellow, Green light indicate the batterypower during charging is low, medium or highRed light keeps flashing when battery is lowShort press for sleep or waking upPress for 2 seconds for powering onPress for 5 seconds for powering offPress more than 10 seconds for hardware reset Short press for returning to home screenPress for 2 seconds for recentering the menuConfirmScreen lights on when headset put onScreen lights off when headset taken offCharging or data transferringConnecting to extension device like flash disk with OTG CableBlue light keeps flashing when power on/offStatus LightHome ButtonConfirm ButtonProximity SensorMicro USBPower ButtonKeys FunctionsTouch Pad Direction operationsPress for confirmBack to previous screen or game customized Short press for powering onShort press for returning to home screen if Bluetooth connectedVolume up / downBluetooth is pairing if light keeps flashing slowlyBluetooth is connected if light is offBattery is low if light keeps flashing fastHome ButtonAPP ButtonStatus LightVolume ButtonVolume ButtonStatus LightHome ButtonTouch PadAPP ButtonBattery CoverTips: You can complete basic operations with only using buttons on headset. If you want more interesting and convenient operat-ions, please connect the headset with 3DOF motion controller.a) Power on: Press power button for 2 seconds.b) Power off: Press power button for 5 seconds from powering on.c) Sleep: system will sleep when powering on if, i. Taking off the headset. Put the headset on for waking up. ii. Short press power button. Short press again for waking up.d) Hardware reset: If the system is stuck and could not be power-ed off, you can press the power button for more than 10 seconds to reset the hardware.a) Please put two AAA batteries into the 3DOF motion controller.b) When the headset is powered on, follow the tips on the head-set screen to connect the 3DOF motion controller. Short press Home button on 3DOF motion controller then the headset would connect to the 3DOF motion controller automatically.1. Power on/off , Sleep and Hardware Reset2. Connecting 3DOF Motion ControllerUser Manualpico goblin 08 09 12 131007d) Long press the Home button for recentering the menu.3.5mm Audio JackHome Button Confirm ButtonLenses Proximity SensorStatus LightVolume Button Focus AdjustmentWheelPower ButtonMicro USBSpeakerFoam Cushioning MicrophoneCertificateWechatCommunityCopyright © 2015~2017 Pico Technology Co., Ltd.106761. You could use the buttons on the VR headset for basic operati-ons. For more interesting and convenient operations, please use3DOF motion controller. ( Note: 3DOF motion controller is a Pico customized wireless Bluetooth low energy controller with 9 axis motion senor for more convenient VR interactive experience. )2. Please make sure you do not feel any uncomfortable and be aware of your surroundings when using this device.3. You may feel discomfort for long time using. Please take rest for every 30 minutes. If you feel serious discomfort, please stop using and see doctors immediately.4. Children under 12 years are not suggested to use.5. You can wear this device with your glasses on. If you want to use the focus adjustment, it is suggested you are in the situationbelow, a) Diopter of myopia is between 0 and -8.00 b) Difference between diopters of myopia of two eyes is under 2.00 c) Diopter of astigmatism is between 0 and -2.00 d) Inter-pupillary distance is between 54mm and 71mm.6. This manual is for reference only.a) Touch pad: Up/Down/Left/Right navigation and press down for confirmationb) Move the cursor up/down ;c) Move the cursor left/right ;3. Operating 3DOF Motion ControllerPlease follow the instructions shown below to install the head strap.Notice:1) In step ①, please make sure the buckle’s hook facing up;2) Pull the hook upwards until it is locked tight enough.1. Installing Head StrapPlease follow the instruction to wear headset and adjust the head strap to make yourself feel comfortable. 2. Wearing HeadsetRotate the focus adjustment wheel to adjust the distance betw -een the lens and screen until you see a clear picture.Notice:Diopter of myopia could be adjusted in the range of 0 to -8.00 .Important Notes:You can repair your device for free in 12 months since the purcha-se date, The Limited Warranty does not cover:1. Defects or damage resulting from improper using not included in this manual;2. Attached parts except for controller and headset, such as the packing box or gifts;3. Defects or damage resulting from non-authorized modificati-on, changing or repairing;4. Defects or damage resulting from external causes such as coll-ision with an object, fire, flooding, dirt, windstorm, lightning, ear-thquake or improper use of any electrical source;5. Expire the effective date.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and(2)this device must accept any interference received, including interference that may cause undesired operation.This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residen-tial installation.This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instr-uctions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determin-ed by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help.Any changes or modifications not expressly approved by the partyresponsible for compliance could void the user's authority to oper-ate the equipment. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.FCC RF Radiation Exposure StatementThis equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.You can find the device specific supervision information such as certification, declaration and labels at the software launcher in "Settings"-“About”. This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be requ-ired to take adequate measures.RF Exposure InformationThis device meets the EU requirements (1999/5/EC Article 3.1a) on the limitation of exposure of the general public to electromag-netic fields by way of health protection.The device complies with RF specifications when the device used in normal condition.Hereby, Pico Technology Co., Ltd. declares that this device is incompliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.For more information about Pico’s products, policy and authoriz-ed servers, please visit Pico’s official website or official account on WeChat.For “DECLARATION OF CONFORMITY” of “CE”, please see：Doc Website: www.picovr.com/TBD.docFrequency Range(BT/WIFI): 2400-2483.5MHzMax Output Power(BT/WIFI):20dBmHW Version：001SW Version Format：CCCC_rf01_bvY.Y_svZ.ZZ_YYMMDD_bTTT"CCCC" stands for the nation. "Y.Y " stands for Baseband Version."Z.ZZ" stands for the Software Version. "YY" stands for the update year, "MM" stands for the update month, "DD" stands for the update date."TTT" stands for the Build No. And the update will not change the radio frequency conformance of this product.This equipment maybe operated in3. Adjusting Focus3DOF MOTION CONTROLLERFEATURES3OPERATION4WEARING HEADSET5WARRANTY INFORMATION6SUPERVISIONFCC STATEMENTEU REGULATORY CONFORMANCEATEEISNOBEELITPLBGESLIPTCHFILTROCYFRLUSECZHRLVSIDEHUMTSKDKIENLUKCompany Name: Pico Technology Co., Ltd.Tel: +86 400-6087-666 +86 010-83030050Website: www.picovr.comCompany Address: Room 2101，Shining Tower，No.35 Xueyuan Road, HaiDian District, Beijing, P.R.China13
