Pioneer and Onkyo Asia SECL5BT Pioneer SE-CL5BT User Manual SE CL5BT QuickStartGuide front V1
Pioneer & Onkyo Marketing Asia Limited Pioneer SE-CL5BT SE CL5BT QuickStartGuide front V1
Users Manual
1. Set Contents/法语/德语/意大利语
2. Names of Parts/法语/德语/意大利语
3. Replacing the earphone tip/法语/德语/意大利语
4. Wearing the clipper/法语/德语/意大利语
5. Charging the batteries/法语/德语/意大利语
(1) While the power of the unit is off, press and hold the Main Function Button
until the unit enters paring mode.
• The paring mode is confirmed by LED indicator’s alternatively flashing blue and
red.
Release the Main Function Button after confirming that the LED indicator is
alternately lighting blue and red.
Confirm the presence of all parts and componets before use.
1: Earphone
2: Micro-USB cable
3: S, M, L eartips
4: Warranty card (Europe / U.S.A. and Canada / Japan)
5: Quick Start Guide (this document)
6: Safety Guide
1. Set Contents
1: Main Function Button
2: Volume Up Button
3: Volume Down Button
4: LED Indicator
5: Micro-USB Port
6: Microphone
7: Clipper
2. Names of Parts (see Fig.2)
(1) Installation
• Press the mounting surface firmly onto the nozzle.Failure to press the tip fully
onto the nozzle may cause the tip to come off.
(2) Removal
• Hold the earphone body securely and twist off the earphone tip.
3. Replacing the earphone tip (see Fig.3)
The clipper is designed as a clothing clip. This gives you a variety of simple and
practical wearing styles: Just clip it on your shirt, jacket, t-shirt or whatever that
fits your needs. Just clip it on the neckline（as shown in figure 4), collar edge,
or wherever that fits your needs.
4. Wearing the clipper how you like it
This document describes the information and operations required for startup. For
more advanced operation procedures, read the instruction manual which is
available on the website.
Before you start
<Europe>
http://www.pioneer-audiovisual.eu/
<U.S.A.>
www.PioneerElectronics.com/Home
<Canada>
www.PioneerElectronics.ca/Home
The unit’s battery must be recharged before use.
The accessory micro-USB cable must be used for recharging the unit’s battery.
• Battery recharging time and usable battery time may vary depending on
ambient temperature and frequency of use.
• Battery performance is influenced by surrounding temperature. Charge the
supplied rechargeable batteries within a temperature range 10 to 35 degrees
celcius.
• Batteries become slightly warm when charging. This is not a malfunction.
• Recharging may not be possible if computer is in power-saving mode.
• The unit cannot be used during charging.
Connect the appropriate connector on the accessory micro-USB cable to the micro-
USB port on the earphones, and the USB plug on the other end to a USB port on a
computer (see Fig.5).
• When recharging begins, the LED indicator on the earphone will light red.
• Full recharging requires about 2 hours, when recharging is completed, the LED
indication will turn blue.
5. Charging the batteries
Note
Notes on battery charging
Pairing must be performed before the earphones can be used to listen the
music or communicate using a Bluetooth device.
For further details regarding the pairing procedure, consult the user’s manual for
your Bluetooth device.
6. Pairing
To use the wireless earphones to listen to music from a Bluetooth device, you
must first perform pairing with the Bluetooth device using the A2DP audio profile.
For details on how to perform pairing, see < 5.Pairing >.
(1) With power to the wireless earphones’ turned off, hold the MFB depressed
for about three seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
Connect to the Bluetooth device
• Confirm that the power to the wireless earphones is ON before connecting to
the Bluetooth device.
• Depending on the device, connection between the wireless earphones and
Bluetooth device may be effected automatically after pairing.
Disconnecting from the Bluetooth device
• Press and hold the Main Function Button until the LED turns off and the power
of the device turns off.
(2) Turn on the power to the Bluetooth device you are going to pair with, and
begin pairing; search for this unit (wireless earphones) from the paired
Bluetooth device.
• Set Bluetooth device close (within one meter) to the wireless earphones.
• These wireless earphones will appear in the Bluetooth device’s display as
“Pioneer SE-CL5BT”.
(3) Confirm that pairing has been successfully completed with the Bluetooth
device.
• Look at the display for the Bluetooth-enabled device and select “Pioneer
SE-CL5BT”.
• When the LED is flashing in blue slowly about once every 3 seconds, pairing is
completed.
• The PIN code for these wireless earphones has been factory set as “0000”.
Input this code if requested by the Bluetooth device.
7. Enjoying Music
Controls when listening to music
If the connected Bluetooth device supports AVFCP, the following operations can
be used.
• (＋) button
Press once: increase volume
Press and hold: advance to next track or chapter
• (﹣) button
Press once: decrease volume
Press and hold: advance to previous track or chapter
• Main Function Button
Press once: Play / Pause
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the headphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the music
playback settings may need to be configured. Consult the user’s manual for the
Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, a music
playback application may start automatically or the music cannot be
paused/played. Consult the user’s manual for the Bluetooth device.
To use the wireless earphones for vocal communication, pairing must be
performed with the desired Bluetooth device using the “hands-free profile” (HFP)
or “headset profile” (HSP).
For details on how to perform pairing, see < 5.Pairing >.
*If the Bluetooth device supports both profiles HFP & HSP, use the profile HFP.
(1) With power to the wireless earphones’ turned off, hold the Main Function
Button depressed for about 3 seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
8. Vocal communication
Basic
Transmission format.....................................Bluetooth Standard Protocol Ver. 4.1
Maximum transmission distance...................................About 10m line of sight *1
Frequency used...........................................4GHz (2.400 GHz to 2.4835 GHz)*2
Supported Bluetooth profiles...............................................A2DP, AVRCP, HFP, HSP
Supported CODEC...................................................................................SBC
Battery life with continuous use........Maximum 8 hours of continuous transmission
(including music-play time)
Recharging time.........................................................................About 2 hours
Battery.................................. DC3.7V internally rechargeable Lithium-ion battery
IPX level................................................................................................IPX-4
Weight.....................................................................................................21g
Headphone
Type............................................................Fully-enclosed dynamic earphones
Driver units........................................................................................φ9.2mm
Impedance..........................................................................................16 ohm
Frequency response............................................................20 Hz ~ 20 000 Hz
Sensitivity..............................................................................................95 dB
Accessories
S, M, L eartips..........................................................................................1pc
Micro-USB cable (50cm)............................................................................1pc
Warranty card(Europe / U.S.A. and Canada / Japan).....................................1pc
Quick Start Guide (this document)...............................................................1pc
Safety Guide.............................................................................................1pc
*1 Transmission distance is an approximation. Actual usable distance may vary
depending on surrounding conditions.
*2 This product utilizes radio wave in the 2.4 GHz spectrum. Some signal dropouts
may be experienced due to interference with radios, microwave ovens, and other
devices using 2.4 GHz spectrum.
Specification
Note
• “Pioneer” is a trademark of Pioneer Corporation, and is used under license.
• The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Onkyo Corporation is under
license. Other trademarks and trade name are those of their respective owners.
• Android is a trademark of Google Inc
Specifications and design are subject to possible modifications without notice due
to improvements.
About License and Trademarks
Vocal communication controls
If the connected Bluetooth device supports AVRCP, the following operations can
be used.
• (＋) button
Press and hold: Increase volume
• (﹣) button
Press and hold: Decrease volume
• Main Function Button
Press once when receiving a call: Enable conversation.Press once
again to end conversation.
Press and hold when receiving a call: Refuse communication
The same controls are supported in the event a call is received while listening to
music.
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the earphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the phone
settings may need to be configured. Consult the user’s manual of the Bluetooth
device.
(1) While the power of the unit is off, press and hold the Main Function Button
until the unit enters paring mode.
• The paring mode is confirmed by LED indicator’s alternatively flashing blue and
red.
Release the Main Function Button after confirming that the LED indicator is
alternately lighting blue and red.
Confirm the presence of all parts and componets before use.
1: Earphone
2: Micro-USB cable
3: S, M, L eartips
4: Warranty card (Europe / U.S.A. and Canada / Japan)
5: Quick Start Guide (this document)
6: Safety Guide
1. Set Contents
1: Main Function Button
2: Volume Up Button
3: Volume Down Button
4: LED Indicator
5: Micro-USB Port
6: Microphone
7: Clipper
2. Names of Parts (see Fig.2)
(1) Installation
• Press the mounting surface firmly onto the nozzle.Failure to press the tip fully
onto the nozzle may cause the tip to come off.
(2) Removal
• Hold the earphone body securely and twist off the earphone tip.
3. Replacing the earphone tip (see Fig.3)
The clipper is designed as a clothing clip. This gives you a variety of simple and
practical wearing styles: Just clip it on your shirt, jacket, t-shirt or whatever that
fits your needs. Just clip it on the neckline（as shown in figure 4), collar edge,
or wherever that fits your needs.
4. Wearing the clipper how you like it
This document describes the information and operations required for startup. For
more advanced operation procedures, read the instruction manual which is
available on the website.
Before you start
<Europe>
http://www.pioneer-audiovisual.eu/
<U.S.A.>
www.PioneerElectronics.com/Home
<Canada>
www.PioneerElectronics.ca/Home
The unit’s battery must be recharged before use.
The accessory micro-USB cable must be used for recharging the unit’s battery.
• Battery recharging time and usable battery time may vary depending on
ambient temperature and frequency of use.
• Battery performance is influenced by surrounding temperature. Charge the
supplied rechargeable batteries within a temperature range 10 to 35 degrees
celcius.
• Batteries become slightly warm when charging. This is not a malfunction.
• Recharging may not be possible if computer is in power-saving mode.
• The unit cannot be used during charging.
Connect the appropriate connector on the accessory micro-USB cable to the micro-
USB port on the earphones, and the USB plug on the other end to a USB port on a
computer (see Fig.5).
• When recharging begins, the LED indicator on the earphone will light red.
• Full recharging requires about 2 hours, when recharging is completed, the LED
indication will turn blue.
5. Charging the batteries
Note
Notes on battery charging
Pairing must be performed before the earphones can be used to listen the
music or communicate using a Bluetooth device.
For further details regarding the pairing procedure, consult the user’s manual for
your Bluetooth device.
6. Pairing
To use the wireless earphones to listen to music from a Bluetooth device, you
must first perform pairing with the Bluetooth device using the A2DP audio profile.
For details on how to perform pairing, see < 5.Pairing >.
(1) With power to the wireless earphones’ turned off, hold the MFB depressed
for about three seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
Connect to the Bluetooth device
• Confirm that the power to the wireless earphones is ON before connecting to
the Bluetooth device.
• Depending on the device, connection between the wireless earphones and
Bluetooth device may be effected automatically after pairing.
Disconnecting from the Bluetooth device
• Press and hold the Main Function Button until the LED turns off and the power
of the device turns off.
(2) Turn on the power to the Bluetooth device you are going to pair with, and
begin pairing; search for this unit (wireless earphones) from the paired
Bluetooth device.
• Set Bluetooth device close (within one meter) to the wireless earphones.
• These wireless earphones will appear in the Bluetooth device’s display as
“Pioneer SE-CL5BT”.
(3) Confirm that pairing has been successfully completed with the Bluetooth
device.
• Look at the display for the Bluetooth-enabled device and select “Pioneer
SE-CL5BT”.
• When the LED is flashing in blue slowly about once every 3 seconds, pairing is
completed.
• The PIN code for these wireless earphones has been factory set as “0000”.
Input this code if requested by the Bluetooth device.
7. Enjoying Music
Controls when listening to music
If the connected Bluetooth device supports AVFCP, the following operations can
be used.
• (＋) button
Press once: increase volume
Press and hold: advance to next track or chapter
• (﹣) button
Press once: decrease volume
Press and hold: advance to previous track or chapter
• Main Function Button
Press once: Play / Pause
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the headphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the music
playback settings may need to be configured. Consult the user’s manual for the
Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, a music
playback application may start automatically or the music cannot be
paused/played. Consult the user’s manual for the Bluetooth device.
To use the wireless earphones for vocal communication, pairing must be
performed with the desired Bluetooth device using the “hands-free profile” (HFP)
or “headset profile” (HSP).
For details on how to perform pairing, see < 5.Pairing >.
*If the Bluetooth device supports both profiles HFP & HSP, use the profile HFP.
(1) With power to the wireless earphones’ turned off, hold the Main Function
Button depressed for about 3 seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
8. Vocal communication
Basic
Transmission format.....................................Bluetooth Standard Protocol Ver. 4.1
Maximum transmission distance...................................About 10m line of sight *1
Frequency used...........................................4GHz (2.400 GHz to 2.4835 GHz)*2
Supported Bluetooth profiles...............................................A2DP, AVRCP, HFP, HSP
Supported CODEC...................................................................................SBC
Battery life with continuous use........Maximum 8 hours of continuous transmission
(including music-play time)
Recharging time.........................................................................About 2 hours
Battery.................................. DC3.7V internally rechargeable Lithium-ion battery
IPX level................................................................................................IPX-4
Weight.....................................................................................................21g
Headphone
Type............................................................Fully-enclosed dynamic earphones
Driver units........................................................................................φ9.2mm
Impedance..........................................................................................16 ohm
Frequency response............................................................20 Hz ~ 20 000 Hz
Sensitivity..............................................................................................95 dB
Accessories
S, M, L eartips..........................................................................................1pc
Micro-USB cable (50cm)............................................................................1pc
Warranty card(Europe / U.S.A. and Canada / Japan).....................................1pc
Quick Start Guide (this document)...............................................................1pc
Safety Guide.............................................................................................1pc
*1 Transmission distance is an approximation. Actual usable distance may vary
depending on surrounding conditions.
*2 This product utilizes radio wave in the 2.4 GHz spectrum. Some signal dropouts
may be experienced due to interference with radios, microwave ovens, and other
devices using 2.4 GHz spectrum.
Specification
Note
• “Pioneer” is a trademark of Pioneer Corporation, and is used under license.
• The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Onkyo Corporation is under
license. Other trademarks and trade name are those of their respective owners.
• Android is a trademark of Google Inc
Specifications and design are subject to possible modifications without notice due
to improvements.
About License and Trademarks
Vocal communication controls
If the connected Bluetooth device supports AVRCP, the following operations can
be used.
• (＋) button
Press and hold: Increase volume
• (﹣) button
Press and hold: Decrease volume
• Main Function Button
Press once when receiving a call: Enable conversation.Press once
again to end conversation.
Press and hold when receiving a call: Refuse communication
The same controls are supported in the event a call is received while listening to
music.
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the earphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the phone
settings may need to be configured. Consult the user’s manual of the Bluetooth
device.
(1) While the power of the unit is off, press and hold the Main Function Button
until the unit enters paring mode.
• The paring mode is confirmed by LED indicator’s alternatively flashing blue and
red.
Release the Main Function Button after confirming that the LED indicator is
alternately lighting blue and red.
Confirm the presence of all parts and componets before use.
1: Earphone
2: Micro-USB cable
3: S, M, L eartips
4: Warranty card (Europe / U.S.A. and Canada / Japan)
5: Quick Start Guide (this document)
6: Safety Guide
1. Set Contents
1: Main Function Button
2: Volume Up Button
3: Volume Down Button
4: LED Indicator
5: Micro-USB Port
6: Microphone
7: Clipper
2. Names of Parts (see Fig.2)
(1) Installation
• Press the mounting surface firmly onto the nozzle.Failure to press the tip fully
onto the nozzle may cause the tip to come off.
(2) Removal
• Hold the earphone body securely and twist off the earphone tip.
3. Replacing the earphone tip (see Fig.3)
The clipper is designed as a clothing clip. This gives you a variety of simple and
practical wearing styles: Just clip it on your shirt, jacket, t-shirt or whatever that
fits your needs. Just clip it on the neckline（as shown in figure 4), collar edge,
or wherever that fits your needs.
4. Wearing the clipper how you like it
This document describes the information and operations required for startup. For
more advanced operation procedures, read the instruction manual which is
available on the website.
Before you start
<Europe>
http://www.pioneer-audiovisual.eu/
<U.S.A.>
www.PioneerElectronics.com/Home
<Canada>
www.PioneerElectronics.ca/Home
The unit’s battery must be recharged before use.
The accessory micro-USB cable must be used for recharging the unit’s battery.
• Battery recharging time and usable battery time may vary depending on
ambient temperature and frequency of use.
• Battery performance is influenced by surrounding temperature. Charge the
supplied rechargeable batteries within a temperature range 10 to 35 degrees
celcius.
• Batteries become slightly warm when charging. This is not a malfunction.
• Recharging may not be possible if computer is in power-saving mode.
• The unit cannot be used during charging.
Connect the appropriate connector on the accessory micro-USB cable to the micro-
USB port on the earphones, and the USB plug on the other end to a USB port on a
computer (see Fig.5).
• When recharging begins, the LED indicator on the earphone will light red.
• Full recharging requires about 2 hours, when recharging is completed, the LED
indication will turn blue.
5. Charging the batteries
Note
Notes on battery charging
Pairing must be performed before the earphones can be used to listen the
music or communicate using a Bluetooth device.
For further details regarding the pairing procedure, consult the user’s manual for
your Bluetooth device.
6. Pairing
To use the wireless earphones to listen to music from a Bluetooth device, you
must first perform pairing with the Bluetooth device using the A2DP audio profile.
For details on how to perform pairing, see < 5.Pairing >.
(1) With power to the wireless earphones’ turned off, hold the MFB depressed
for about three seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
Connect to the Bluetooth device
• Confirm that the power to the wireless earphones is ON before connecting to
the Bluetooth device.
• Depending on the device, connection between the wireless earphones and
Bluetooth device may be effected automatically after pairing.
Disconnecting from the Bluetooth device
• Press and hold the Main Function Button until the LED turns off and the power
of the device turns off.
(2) Turn on the power to the Bluetooth device you are going to pair with, and
begin pairing; search for this unit (wireless earphones) from the paired
Bluetooth device.
• Set Bluetooth device close (within one meter) to the wireless earphones.
• These wireless earphones will appear in the Bluetooth device’s display as
“Pioneer SE-CL5BT”.
(3) Confirm that pairing has been successfully completed with the Bluetooth
device.
• Look at the display for the Bluetooth-enabled device and select “Pioneer
SE-CL5BT”.
• When the LED is flashing in blue slowly about once every 3 seconds, pairing is
completed.
• The PIN code for these wireless earphones has been factory set as “0000”.
Input this code if requested by the Bluetooth device.
7. Enjoying Music
Controls when listening to music
If the connected Bluetooth device supports AVFCP, the following operations can
be used.
• (＋) button
Press once: increase volume
Press and hold: advance to next track or chapter
• (﹣) button
Press once: decrease volume
Press and hold: advance to previous track or chapter
• Main Function Button
Press once: Play / Pause
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the headphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the music
playback settings may need to be configured. Consult the user’s manual for the
Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, a music
playback application may start automatically or the music cannot be
paused/played. Consult the user’s manual for the Bluetooth device.
To use the wireless earphones for vocal communication, pairing must be
performed with the desired Bluetooth device using the “hands-free profile” (HFP)
or “headset profile” (HSP).
For details on how to perform pairing, see < 5.Pairing >.
*If the Bluetooth device supports both profiles HFP & HSP, use the profile HFP.
(1) With power to the wireless earphones’ turned off, hold the Main Function
Button depressed for about 3 seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
8. Vocal communication
Basic
Transmission format.....................................Bluetooth Standard Protocol Ver. 4.1
Maximum transmission distance...................................About 10m line of sight *1
Frequency used...........................................4GHz (2.400 GHz to 2.4835 GHz)*2
Supported Bluetooth profiles...............................................A2DP, AVRCP, HFP, HSP
Supported CODEC...................................................................................SBC
Battery life with continuous use........Maximum 8 hours of continuous transmission
(including music-play time)
Recharging time.........................................................................About 2 hours
Battery.................................. DC3.7V internally rechargeable Lithium-ion battery
IPX level................................................................................................IPX-4
Weight.....................................................................................................21g
Headphone
Type............................................................Fully-enclosed dynamic earphones
Driver units........................................................................................φ9.2mm
Impedance..........................................................................................16 ohm
Frequency response............................................................20 Hz ~ 20 000 Hz
Sensitivity..............................................................................................95 dB
Accessories
S, M, L eartips..........................................................................................1pc
Micro-USB cable (50cm)............................................................................1pc
Warranty card(Europe / U.S.A. and Canada / Japan).....................................1pc
Quick Start Guide (this document)...............................................................1pc
Safety Guide.............................................................................................1pc
*1 Transmission distance is an approximation. Actual usable distance may vary
depending on surrounding conditions.
*2 This product utilizes radio wave in the 2.4 GHz spectrum. Some signal dropouts
may be experienced due to interference with radios, microwave ovens, and other
devices using 2.4 GHz spectrum.
Specification
Note
• “Pioneer” is a trademark of Pioneer Corporation, and is used under license.
• The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Onkyo Corporation is under
license. Other trademarks and trade name are those of their respective owners.
• Android is a trademark of Google Inc
Specifications and design are subject to possible modifications without notice due
to improvements.
About License and Trademarks
Vocal communication controls
If the connected Bluetooth device supports AVRCP, the following operations can
be used.
• (＋) button
Press and hold: Increase volume
• (﹣) button
Press and hold: Decrease volume
• Main Function Button
Press once when receiving a call: Enable conversation.Press once
again to end conversation.
Press and hold when receiving a call: Refuse communication
The same controls are supported in the event a call is received while listening to
music.
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the earphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the phone
settings may need to be configured. Consult the user’s manual of the Bluetooth
device.
(1) While the power of the unit is off, press and hold the Main Function Button
until the unit enters paring mode.
• The paring mode is confirmed by LED indicator’s alternatively flashing blue and
red.
Release the Main Function Button after confirming that the LED indicator is
alternately lighting blue and red.
Confirm the presence of all parts and componets before use.
1: Earphone
2: Micro-USB cable
3: S, M, L eartips
4: Warranty card (Europe / U.S.A. and Canada / Japan)
5: Quick Start Guide (this document)
6: Safety Guide
1. Set Contents
1: Main Function Button
2: Volume Up Button
3: Volume Down Button
4: LED Indicator
5: Micro-USB Port
6: Microphone
7: Clipper
2. Names of Parts (see Fig.2)
(1) Installation
• Press the mounting surface firmly onto the nozzle.Failure to press the tip fully
onto the nozzle may cause the tip to come off.
(2) Removal
• Hold the earphone body securely and twist off the earphone tip.
3. Replacing the earphone tip (see Fig.3)
The clipper is designed as a clothing clip. This gives you a variety of simple and
practical wearing styles: Just clip it on your shirt, jacket, t-shirt or whatever that
fits your needs. Just clip it on the neckline（as shown in figure 4), collar edge,
or wherever that fits your needs.
4. Wearing the clipper how you like it
This document describes the information and operations required for startup. For
more advanced operation procedures, read the instruction manual which is
available on the website.
Before you start
<Europe>
http://www.pioneer-audiovisual.eu/
<U.S.A.>
www.PioneerElectronics.com/Home
<Canada>
www.PioneerElectronics.ca/Home
The unit’s battery must be recharged before use.
The accessory micro-USB cable must be used for recharging the unit’s battery.
• Battery recharging time and usable battery time may vary depending on
ambient temperature and frequency of use.
• Battery performance is influenced by surrounding temperature. Charge the
supplied rechargeable batteries within a temperature range 10 to 35 degrees
celcius.
• Batteries become slightly warm when charging. This is not a malfunction.
• Recharging may not be possible if computer is in power-saving mode.
• The unit cannot be used during charging.
Connect the appropriate connector on the accessory micro-USB cable to the micro-
USB port on the earphones, and the USB plug on the other end to a USB port on a
computer (see Fig.5).
• When recharging begins, the LED indicator on the earphone will light red.
• Full recharging requires about 2 hours, when recharging is completed, the LED
indication will turn blue.
5. Charging the batteries
Note
Notes on battery charging
Pairing must be performed before the earphones can be used to listen the
music or communicate using a Bluetooth device.
For further details regarding the pairing procedure, consult the user’s manual for
your Bluetooth device.
6. Pairing
To use the wireless earphones to listen to music from a Bluetooth device, you
must first perform pairing with the Bluetooth device using the A2DP audio profile.
For details on how to perform pairing, see < 5.Pairing >.
(1) With power to the wireless earphones’ turned off, hold the MFB depressed
for about three seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
Connect to the Bluetooth device
• Confirm that the power to the wireless earphones is ON before connecting to
the Bluetooth device.
• Depending on the device, connection between the wireless earphones and
Bluetooth device may be effected automatically after pairing.
Disconnecting from the Bluetooth device
• Press and hold the Main Function Button until the LED turns off and the power
of the device turns off.
(2) Turn on the power to the Bluetooth device you are going to pair with, and
begin pairing; search for this unit (wireless earphones) from the paired
Bluetooth device.
• Set Bluetooth device close (within one meter) to the wireless earphones.
• These wireless earphones will appear in the Bluetooth device’s display as
“Pioneer SE-CL5BT”.
(3) Confirm that pairing has been successfully completed with the Bluetooth
device.
• Look at the display for the Bluetooth-enabled device and select “Pioneer
SE-CL5BT”.
• When the LED is flashing in blue slowly about once every 3 seconds, pairing is
completed.
• The PIN code for these wireless earphones has been factory set as “0000”.
Input this code if requested by the Bluetooth device.
7. Enjoying Music
Controls when listening to music
If the connected Bluetooth device supports AVFCP, the following operations can
be used.
• (＋) button
Press once: increase volume
Press and hold: advance to next track or chapter
• (﹣) button
Press once: decrease volume
Press and hold: advance to previous track or chapter
• Main Function Button
Press once: Play / Pause
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the headphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the music
playback settings may need to be configured. Consult the user’s manual for the
Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, a music
playback application may start automatically or the music cannot be
paused/played. Consult the user’s manual for the Bluetooth device.
To use the wireless earphones for vocal communication, pairing must be
performed with the desired Bluetooth device using the “hands-free profile” (HFP)
or “headset profile” (HSP).
For details on how to perform pairing, see < 5.Pairing >.
*If the Bluetooth device supports both profiles HFP & HSP, use the profile HFP.
(1) With power to the wireless earphones’ turned off, hold the Main Function
Button depressed for about 3 seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
8. Vocal communication
Basic
Transmission format.....................................Bluetooth Standard Protocol Ver. 4.1
Maximum transmission distance...................................About 10m line of sight *1
Frequency used...........................................4GHz (2.400 GHz to 2.4835 GHz)*2
Supported Bluetooth profiles...............................................A2DP, AVRCP, HFP, HSP
Supported CODEC...................................................................................SBC
Battery life with continuous use........Maximum 8 hours of continuous transmission
(including music-play time)
Recharging time.........................................................................About 2 hours
Battery.................................. DC3.7V internally rechargeable Lithium-ion battery
IPX level................................................................................................IPX-4
Weight.....................................................................................................21g
Headphone
Type............................................................Fully-enclosed dynamic earphones
Driver units........................................................................................φ9.2mm
Impedance..........................................................................................16 ohm
Frequency response............................................................20 Hz ~ 20 000 Hz
Sensitivity..............................................................................................95 dB
Accessories
S, M, L eartips..........................................................................................1pc
Micro-USB cable (50cm)............................................................................1pc
Warranty card(Europe / U.S.A. and Canada / Japan).....................................1pc
Quick Start Guide (this document)...............................................................1pc
Safety Guide.............................................................................................1pc
*1 Transmission distance is an approximation. Actual usable distance may vary
depending on surrounding conditions.
*2 This product utilizes radio wave in the 2.4 GHz spectrum. Some signal dropouts
may be experienced due to interference with radios, microwave ovens, and other
devices using 2.4 GHz spectrum.
Specification
Note
• “Pioneer” is a trademark of Pioneer Corporation, and is used under license.
• The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Onkyo Corporation is under
license. Other trademarks and trade name are those of their respective owners.
• Android is a trademark of Google Inc
Specifications and design are subject to possible modifications without notice due
to improvements.
About License and Trademarks
Vocal communication controls
If the connected Bluetooth device supports AVRCP, the following operations can
be used.
• (＋) button
Press and hold: Increase volume
• (﹣) button
Press and hold: Decrease volume
• Main Function Button
Press once when receiving a call: Enable conversation.Press once
again to end conversation.
Press and hold when receiving a call: Refuse communication
The same controls are supported in the event a call is received while listening to
music.
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the earphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the phone
settings may need to be configured. Consult the user’s manual of the Bluetooth
device.
SE-CL5BT
Unit 1033, 10/F., Star House, No. 3 Salisbury Road, Tsim Sha Tsui, Kowloon, Hong Kong
© 2017 Pioneer & Onkyo Marketing Asia Limited
© 2017 Pioneer & Onkyo Marketing Asia Limited
22828 Lockness Avenue Torrance, CA 90501
Tel: 424-223-5203
Tel: +44 (0) 208 363 500
2
1
3
65
4
7
SE-CL5BT
1 2 3
SE-CL5BT
ClipWear Active Wireless Earphones
ClipWear Active Wireless Earphones法语
ClipWear Active Wireless Earphones德语
ClipWear Active Wireless Earphones意大利语
ClipWear Active Wireless Earphones西班牙语
ClipWear Active Wireless Earphones荷兰语
ClipWear Active Wireless Earphones瑞典语
ClipWear Active Wireless Earphones日语
SE-CL5BT
(1) While the power of the unit is off, press and hold the Main Function Button
until the unit enters paring mode.
• The paring mode is confirmed by LED indicator’s alternatively flashing blue and
red.
Release the Main Function Button after confirming that the LED indicator is
alternately lighting blue and red.
Confirm the presence of all parts and componets before use.
1: Earphone
2: Micro-USB cable
3: S, M, L eartips
4: Warranty card (Europe / U.S.A. and Canada / Japan)
5: Quick Start Guide (this document)
6: Safety Guide
1. Set Contents
1: Main Function Button
2: Volume Up Button
3: Volume Down Button
4: LED Indicator
5: Micro-USB Port
6: Microphone
7: Clipper
2. Names of Parts (see Fig.2)
(1) Installation
• Press the mounting surface firmly onto the nozzle.Failure to press the tip fully
onto the nozzle may cause the tip to come off.
(2) Removal
• Hold the earphone body securely and twist off the earphone tip.
3. Replacing the earphone tip (see Fig.3)
The clipper is designed as a clothing clip. This gives you a variety of simple and
practical wearing styles: Just clip it on your shirt, jacket, t-shirt or whatever that
fits your needs. Just clip it on the neckline（as shown in figure 4), collar edge,
or wherever that fits your needs.
4. Wearing the clipper how you like it
This document describes the information and operations required for startup. For
more advanced operation procedures, read the instruction manual which is
available on the website.
Before you start
<Europe>
http://www.pioneer-audiovisual.eu/
<U.S.A.>
www.PioneerElectronics.com/Home
<Canada>
www.PioneerElectronics.ca/Home
The unit’s battery must be recharged before use.
The accessory micro-USB cable must be used for recharging the unit’s battery.
• Battery recharging time and usable battery time may vary depending on
ambient temperature and frequency of use.
• Battery performance is influenced by surrounding temperature. Charge the
supplied rechargeable batteries within a temperature range 10 to 35 degrees
celcius.
• Batteries become slightly warm when charging. This is not a malfunction.
• Recharging may not be possible if computer is in power-saving mode.
• The unit cannot be used during charging.
Connect the appropriate connector on the accessory micro-USB cable to the micro-
USB port on the earphones, and the USB plug on the other end to a USB port on a
computer (see Fig.5).
• When recharging begins, the LED indicator on the earphone will light red.
• Full recharging requires about 2 hours, when recharging is completed, the LED
indication will turn blue.
5. Charging the batteries
Note
Notes on battery charging
Pairing must be performed before the earphones can be used to listen the
music or communicate using a Bluetooth device.
For further details regarding the pairing procedure, consult the user’s manual for
your Bluetooth device.
6. Pairing
To use the wireless earphones to listen to music from a Bluetooth device, you
must first perform pairing with the Bluetooth device using the A2DP audio profile.
For details on how to perform pairing, see < 5.Pairing >.
(1) With power to the wireless earphones’ turned off, hold the MFB depressed
for about three seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
Connect to the Bluetooth device
• Confirm that the power to the wireless earphones is ON before connecting to
the Bluetooth device.
• Depending on the device, connection between the wireless earphones and
Bluetooth device may be effected automatically after pairing.
Disconnecting from the Bluetooth device
• Press and hold the Main Function Button until the LED turns off and the power
of the device turns off.
(2) Turn on the power to the Bluetooth device you are going to pair with, and
begin pairing; search for this unit (wireless earphones) from the paired
Bluetooth device.
• Set Bluetooth device close (within one meter) to the wireless earphones.
• These wireless earphones will appear in the Bluetooth device’s display as
“Pioneer SE-CL5BT”.
(3) Confirm that pairing has been successfully completed with the Bluetooth
device.
• Look at the display for the Bluetooth-enabled device and select “Pioneer
SE-CL5BT”.
• When the LED is flashing in blue slowly about once every 3 seconds, pairing is
completed.
• The PIN code for these wireless earphones has been factory set as “0000”.
Input this code if requested by the Bluetooth device.
7. Enjoying Music
Controls when listening to music
If the connected Bluetooth device supports AVFCP, the following operations can
be used.
• (＋) button
Press once: increase volume
Press and hold: advance to next track or chapter
• (﹣) button
Press once: decrease volume
Press and hold: advance to previous track or chapter
• Main Function Button
Press once: Play / Pause
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the headphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the music
playback settings may need to be configured. Consult the user’s manual for the
Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, a music
playback application may start automatically or the music cannot be
paused/played. Consult the user’s manual for the Bluetooth device.
To use the wireless earphones for vocal communication, pairing must be
performed with the desired Bluetooth device using the “hands-free profile” (HFP)
or “headset profile” (HSP).
For details on how to perform pairing, see < 5.Pairing >.
*If the Bluetooth device supports both profiles HFP & HSP, use the profile HFP.
(1) With power to the wireless earphones’ turned off, hold the Main Function
Button depressed for about 3 seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
8. Vocal communication
Basic
Transmission format.....................................Bluetooth Standard Protocol Ver. 4.1
Maximum transmission distance...................................About 10m line of sight *1
Frequency used...........................................4GHz (2.400 GHz to 2.4835 GHz)*2
Supported Bluetooth profiles...............................................A2DP, AVRCP, HFP, HSP
Supported CODEC...................................................................................SBC
Battery life with continuous use........Maximum 8 hours of continuous transmission
(including music-play time)
Recharging time.........................................................................About 2 hours
Battery.................................. DC3.7V internally rechargeable Lithium-ion battery
IPX level................................................................................................IPX-4
Weight.....................................................................................................21g
Headphone
Type............................................................Fully-enclosed dynamic earphones
Driver units........................................................................................φ9.2mm
Impedance..........................................................................................16 ohm
Frequency response............................................................20 Hz ~ 20 000 Hz
Sensitivity..............................................................................................95 dB
Accessories
S, M, L eartips..........................................................................................1pc
Micro-USB cable (50cm)............................................................................1pc
Warranty card(Europe / U.S.A. and Canada / Japan).....................................1pc
Quick Start Guide (this document)...............................................................1pc
Safety Guide.............................................................................................1pc
*1 Transmission distance is an approximation. Actual usable distance may vary
depending on surrounding conditions.
*2 This product utilizes radio wave in the 2.4 GHz spectrum. Some signal dropouts
may be experienced due to interference with radios, microwave ovens, and other
devices using 2.4 GHz spectrum.
Specification
Note
• “Pioneer” is a trademark of Pioneer Corporation, and is used under license.
• The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Onkyo Corporation is under
license. Other trademarks and trade name are those of their respective owners.
• Android is a trademark of Google Inc
Specifications and design are subject to possible modifications without notice due
to improvements.
About License and Trademarks
Vocal communication controls
If the connected Bluetooth device supports AVRCP, the following operations can
be used.
• (＋) button
Press and hold: Increase volume
• (﹣) button
Press and hold: Decrease volume
• Main Function Button
Press once when receiving a call: Enable conversation.Press once
again to end conversation.
Press and hold when receiving a call: Refuse communication
The same controls are supported in the event a call is received while listening to
music.
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the earphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the phone
settings may need to be configured. Consult the user’s manual of the Bluetooth
device.
(1) While the power of the unit is off, press and hold the Main Function Button
until the unit enters paring mode.
• The paring mode is confirmed by LED indicator’s alternatively flashing blue and
red.
Release the Main Function Button after confirming that the LED indicator is
alternately lighting blue and red.
Confirm the presence of all parts and componets before use.
1: Earphone
2: Micro-USB cable
3: S, M, L eartips
4: Warranty card (Europe / U.S.A. and Canada / Japan)
5: Quick Start Guide (this document)
6: Safety Guide
1. Set Contents
1: Main Function Button
2: Volume Up Button
3: Volume Down Button
4: LED Indicator
5: Micro-USB Port
6: Microphone
7: Clipper
2. Names of Parts (see Fig.2)
(1) Installation
• Press the mounting surface firmly onto the nozzle.Failure to press the tip fully
onto the nozzle may cause the tip to come off.
(2) Removal
• Hold the earphone body securely and twist off the earphone tip.
3. Replacing the earphone tip (see Fig.3)
The clipper is designed as a clothing clip. This gives you a variety of simple and
practical wearing styles: Just clip it on your shirt, jacket, t-shirt or whatever that
fits your needs. Just clip it on the neckline（as shown in figure 4), collar edge,
or wherever that fits your needs.
4. Wearing the clipper how you like it
This document describes the information and operations required for startup. For
more advanced operation procedures, read the instruction manual which is
available on the website.
Before you start
<Europe>
http://www.pioneer-audiovisual.eu/
<U.S.A.>
www.PioneerElectronics.com/Home
<Canada>
www.PioneerElectronics.ca/Home
The unit’s battery must be recharged before use.
The accessory micro-USB cable must be used for recharging the unit’s battery.
• Battery recharging time and usable battery time may vary depending on
ambient temperature and frequency of use.
• Battery performance is influenced by surrounding temperature. Charge the
supplied rechargeable batteries within a temperature range 10 to 35 degrees
celcius.
• Batteries become slightly warm when charging. This is not a malfunction.
• Recharging may not be possible if computer is in power-saving mode.
• The unit cannot be used during charging.
Connect the appropriate connector on the accessory micro-USB cable to the micro-
USB port on the earphones, and the USB plug on the other end to a USB port on a
computer (see Fig.5).
• When recharging begins, the LED indicator on the earphone will light red.
• Full recharging requires about 2 hours, when recharging is completed, the LED
indication will turn blue.
5. Charging the batteries
Note
Notes on battery charging
Pairing must be performed before the earphones can be used to listen the
music or communicate using a Bluetooth device.
For further details regarding the pairing procedure, consult the user’s manual for
your Bluetooth device.
6. Pairing
To use the wireless earphones to listen to music from a Bluetooth device, you
must first perform pairing with the Bluetooth device using the A2DP audio profile.
For details on how to perform pairing, see < 5.Pairing >.
(1) With power to the wireless earphones’ turned off, hold the MFB depressed
for about three seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
Connect to the Bluetooth device
• Confirm that the power to the wireless earphones is ON before connecting to
the Bluetooth device.
• Depending on the device, connection between the wireless earphones and
Bluetooth device may be effected automatically after pairing.
Disconnecting from the Bluetooth device
• Press and hold the Main Function Button until the LED turns off and the power
of the device turns off.
(2) Turn on the power to the Bluetooth device you are going to pair with, and
begin pairing; search for this unit (wireless earphones) from the paired
Bluetooth device.
• Set Bluetooth device close (within one meter) to the wireless earphones.
• These wireless earphones will appear in the Bluetooth device’s display as
“Pioneer SE-CL5BT”.
(3) Confirm that pairing has been successfully completed with the Bluetooth
device.
• Look at the display for the Bluetooth-enabled device and select “Pioneer
SE-CL5BT”.
• When the LED is flashing in blue slowly about once every 3 seconds, pairing is
completed.
• The PIN code for these wireless earphones has been factory set as “0000”.
Input this code if requested by the Bluetooth device.
7. Enjoying Music
Controls when listening to music
If the connected Bluetooth device supports AVFCP, the following operations can
be used.
• (＋) button
Press once: increase volume
Press and hold: advance to next track or chapter
• (﹣) button
Press once: decrease volume
Press and hold: advance to previous track or chapter
• Main Function Button
Press once: Play / Pause
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the headphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the music
playback settings may need to be configured. Consult the user’s manual for the
Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, a music
playback application may start automatically or the music cannot be
paused/played. Consult the user’s manual for the Bluetooth device.
To use the wireless earphones for vocal communication, pairing must be
performed with the desired Bluetooth device using the “hands-free profile” (HFP)
or “headset profile” (HSP).
For details on how to perform pairing, see < 5.Pairing >.
*If the Bluetooth device supports both profiles HFP & HSP, use the profile HFP.
(1) With power to the wireless earphones’ turned off, hold the Main Function
Button depressed for about 3 seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
8. Vocal communication
Basic
Transmission format.....................................Bluetooth Standard Protocol Ver. 4.1
Maximum transmission distance...................................About 10m line of sight *1
Frequency used...........................................4GHz (2.400 GHz to 2.4835 GHz)*2
Supported Bluetooth profiles...............................................A2DP, AVRCP, HFP, HSP
Supported CODEC...................................................................................SBC
Battery life with continuous use........Maximum 8 hours of continuous transmission
(including music-play time)
Recharging time.........................................................................About 2 hours
Battery.................................. DC3.7V internally rechargeable Lithium-ion battery
IPX level................................................................................................IPX-4
Weight.....................................................................................................21g
Headphone
Type............................................................Fully-enclosed dynamic earphones
Driver units........................................................................................φ9.2mm
Impedance..........................................................................................16 ohm
Frequency response............................................................20 Hz ~ 20 000 Hz
Sensitivity..............................................................................................95 dB
Accessories
S, M, L eartips..........................................................................................1pc
Micro-USB cable (50cm)............................................................................1pc
Warranty card(Europe / U.S.A. and Canada / Japan).....................................1pc
Quick Start Guide (this document)...............................................................1pc
Safety Guide.............................................................................................1pc
*1 Transmission distance is an approximation. Actual usable distance may vary
depending on surrounding conditions.
*2 This product utilizes radio wave in the 2.4 GHz spectrum. Some signal dropouts
may be experienced due to interference with radios, microwave ovens, and other
devices using 2.4 GHz spectrum.
Specification
Note
• “Pioneer” is a trademark of Pioneer Corporation, and is used under license.
• The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Onkyo Corporation is under
license. Other trademarks and trade name are those of their respective owners.
• Android is a trademark of Google Inc
Specifications and design are subject to possible modifications without notice due
to improvements.
About License and Trademarks
Vocal communication controls
If the connected Bluetooth device supports AVRCP, the following operations can
be used.
• (＋) button
Press and hold: Increase volume
• (﹣) button
Press and hold: Decrease volume
• Main Function Button
Press once when receiving a call: Enable conversation.Press once
again to end conversation.
Press and hold when receiving a call: Refuse communication
The same controls are supported in the event a call is received while listening to
music.
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the earphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the phone
settings may need to be configured. Consult the user’s manual of the Bluetooth
device.
(1) While the power of the unit is off, press and hold the Main Function Button
until the unit enters paring mode.
• The paring mode is confirmed by LED indicator’s alternatively flashing blue and
red.
Release the Main Function Button after confirming that the LED indicator is
alternately lighting blue and red.
Confirm the presence of all parts and componets before use.
1: Earphone
2: Micro-USB cable
3: S, M, L eartips
4: Warranty card (Europe / U.S.A. and Canada / Japan)
5: Quick Start Guide (this document)
6: Safety Guide
1. Set Contents
1: Main Function Button
2: Volume Up Button
3: Volume Down Button
4: LED Indicator
5: Micro-USB Port
6: Microphone
7: Clipper
2. Names of Parts (see Fig.2)
(1) Installation
• Press the mounting surface firmly onto the nozzle.Failure to press the tip fully
onto the nozzle may cause the tip to come off.
(2) Removal
• Hold the earphone body securely and twist off the earphone tip.
3. Replacing the earphone tip (see Fig.3)
The clipper is designed as a clothing clip. This gives you a variety of simple and
practical wearing styles: Just clip it on your shirt, jacket, t-shirt or whatever that
fits your needs. Just clip it on the neckline（as shown in figure 4), collar edge,
or wherever that fits your needs.
4. Wearing the clipper how you like it
This document describes the information and operations required for startup. For
more advanced operation procedures, read the instruction manual which is
available on the website.
Before you start
<Europe>
http://www.pioneer-audiovisual.eu/
<U.S.A.>
www.PioneerElectronics.com/Home
<Canada>
www.PioneerElectronics.ca/Home
The unit’s battery must be recharged before use.
The accessory micro-USB cable must be used for recharging the unit’s battery.
• Battery recharging time and usable battery time may vary depending on
ambient temperature and frequency of use.
• Battery performance is influenced by surrounding temperature. Charge the
supplied rechargeable batteries within a temperature range 10 to 35 degrees
celcius.
• Batteries become slightly warm when charging. This is not a malfunction.
• Recharging may not be possible if computer is in power-saving mode.
• The unit cannot be used during charging.
Connect the appropriate connector on the accessory micro-USB cable to the micro-
USB port on the earphones, and the USB plug on the other end to a USB port on a
computer (see Fig.5).
• When recharging begins, the LED indicator on the earphone will light red.
• Full recharging requires about 2 hours, when recharging is completed, the LED
indication will turn blue.
5. Charging the batteries
Note
Notes on battery charging
Pairing must be performed before the earphones can be used to listen the
music or communicate using a Bluetooth device.
For further details regarding the pairing procedure, consult the user’s manual for
your Bluetooth device.
6. Pairing
To use the wireless earphones to listen to music from a Bluetooth device, you
must first perform pairing with the Bluetooth device using the A2DP audio profile.
For details on how to perform pairing, see < 5.Pairing >.
(1) With power to the wireless earphones’ turned off, hold the MFB depressed
for about three seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
Connect to the Bluetooth device
• Confirm that the power to the wireless earphones is ON before connecting to
the Bluetooth device.
• Depending on the device, connection between the wireless earphones and
Bluetooth device may be effected automatically after pairing.
Disconnecting from the Bluetooth device
• Press and hold the Main Function Button until the LED turns off and the power
of the device turns off.
(2) Turn on the power to the Bluetooth device you are going to pair with, and
begin pairing; search for this unit (wireless earphones) from the paired
Bluetooth device.
• Set Bluetooth device close (within one meter) to the wireless earphones.
• These wireless earphones will appear in the Bluetooth device’s display as
“Pioneer SE-CL5BT”.
(3) Confirm that pairing has been successfully completed with the Bluetooth
device.
• Look at the display for the Bluetooth-enabled device and select “Pioneer
SE-CL5BT”.
• When the LED is flashing in blue slowly about once every 3 seconds, pairing is
completed.
• The PIN code for these wireless earphones has been factory set as “0000”.
Input this code if requested by the Bluetooth device.
7. Enjoying Music
Controls when listening to music
If the connected Bluetooth device supports AVFCP, the following operations can
be used.
• (＋) button
Press once: increase volume
Press and hold: advance to next track or chapter
• (﹣) button
Press once: decrease volume
Press and hold: advance to previous track or chapter
• Main Function Button
Press once: Play / Pause
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the headphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the music
playback settings may need to be configured. Consult the user’s manual for the
Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, a music
playback application may start automatically or the music cannot be
paused/played. Consult the user’s manual for the Bluetooth device.
To use the wireless earphones for vocal communication, pairing must be
performed with the desired Bluetooth device using the “hands-free profile” (HFP)
or “headset profile” (HSP).
For details on how to perform pairing, see < 5.Pairing >.
*If the Bluetooth device supports both profiles HFP & HSP, use the profile HFP.
(1) With power to the wireless earphones’ turned off, hold the Main Function
Button depressed for about 3 seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
8. Vocal communication
Basic
Transmission format.....................................Bluetooth Standard Protocol Ver. 4.1
Maximum transmission distance...................................About 10m line of sight *1
Frequency used...........................................4GHz (2.400 GHz to 2.4835 GHz)*2
Supported Bluetooth profiles...............................................A2DP, AVRCP, HFP, HSP
Supported CODEC...................................................................................SBC
Battery life with continuous use........Maximum 8 hours of continuous transmission
(including music-play time)
Recharging time.........................................................................About 2 hours
Battery.................................. DC3.7V internally rechargeable Lithium-ion battery
IPX level................................................................................................IPX-4
Weight.....................................................................................................21g
Headphone
Type............................................................Fully-enclosed dynamic earphones
Driver units........................................................................................φ9.2mm
Impedance..........................................................................................16 ohm
Frequency response............................................................20 Hz ~ 20 000 Hz
Sensitivity..............................................................................................95 dB
Accessories
S, M, L eartips..........................................................................................1pc
Micro-USB cable (50cm)............................................................................1pc
Warranty card(Europe / U.S.A. and Canada / Japan).....................................1pc
Quick Start Guide (this document)...............................................................1pc
Safety Guide.............................................................................................1pc
*1 Transmission distance is an approximation. Actual usable distance may vary
depending on surrounding conditions.
*2 This product utilizes radio wave in the 2.4 GHz spectrum. Some signal dropouts
may be experienced due to interference with radios, microwave ovens, and other
devices using 2.4 GHz spectrum.
Specification
Note
• “Pioneer” is a trademark of Pioneer Corporation, and is used under license.
• The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Onkyo Corporation is under
license. Other trademarks and trade name are those of their respective owners.
• Android is a trademark of Google Inc
Specifications and design are subject to possible modifications without notice due
to improvements.
About License and Trademarks
Vocal communication controls
If the connected Bluetooth device supports AVRCP, the following operations can
be used.
• (＋) button
Press and hold: Increase volume
• (﹣) button
Press and hold: Decrease volume
• Main Function Button
Press once when receiving a call: Enable conversation.Press once
again to end conversation.
Press and hold when receiving a call: Refuse communication
The same controls are supported in the event a call is received while listening to
music.
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the earphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the phone
settings may need to be configured. Consult the user’s manual of the Bluetooth
device.
(1) While the power of the unit is off, press and hold the Main Function Button
until the unit enters paring mode.
• The paring mode is confirmed by LED indicator’s alternatively flashing blue and
red.
Release the Main Function Button after confirming that the LED indicator is
alternately lighting blue and red.
Confirm the presence of all parts and componets before use.
1: Earphone
2: Micro-USB cable
3: S, M, L eartips
4: Warranty card (Europe / U.S.A. and Canada / Japan)
5: Quick Start Guide (this document)
6: Safety Guide
1. Set Contents
1: Main Function Button
2: Volume Up Button
3: Volume Down Button
4: LED Indicator
5: Micro-USB Port
6: Microphone
7: Clipper
2. Names of Parts (see Fig.2)
(1) Installation
• Press the mounting surface firmly onto the nozzle.Failure to press the tip fully
onto the nozzle may cause the tip to come off.
(2) Removal
• Hold the earphone body securely and twist off the earphone tip.
3. Replacing the earphone tip (see Fig.3)
The clipper is designed as a clothing clip. This gives you a variety of simple and
practical wearing styles: Just clip it on your shirt, jacket, t-shirt or whatever that
fits your needs. Just clip it on the neckline（as shown in figure 4), collar edge,
or wherever that fits your needs.
4. Wearing the clipper how you like it
This document describes the information and operations required for startup. For
more advanced operation procedures, read the instruction manual which is
available on the website.
Before you start
<Europe>
http://www.pioneer-audiovisual.eu/
<U.S.A.>
www.PioneerElectronics.com/Home
<Canada>
www.PioneerElectronics.ca/Home
The unit’s battery must be recharged before use.
The accessory micro-USB cable must be used for recharging the unit’s battery.
• Battery recharging time and usable battery time may vary depending on
ambient temperature and frequency of use.
• Battery performance is influenced by surrounding temperature. Charge the
supplied rechargeable batteries within a temperature range 10 to 35 degrees
celcius.
• Batteries become slightly warm when charging. This is not a malfunction.
• Recharging may not be possible if computer is in power-saving mode.
• The unit cannot be used during charging.
Connect the appropriate connector on the accessory micro-USB cable to the micro-
USB port on the earphones, and the USB plug on the other end to a USB port on a
computer (see Fig.5).
• When recharging begins, the LED indicator on the earphone will light red.
• Full recharging requires about 2 hours, when recharging is completed, the LED
indication will turn blue.
5. Charging the batteries
Note
Notes on battery charging
Pairing must be performed before the earphones can be used to listen the
music or communicate using a Bluetooth device.
For further details regarding the pairing procedure, consult the user’s manual for
your Bluetooth device.
6. Pairing
To use the wireless earphones to listen to music from a Bluetooth device, you
must first perform pairing with the Bluetooth device using the A2DP audio profile.
For details on how to perform pairing, see < 5.Pairing >.
(1) With power to the wireless earphones’ turned off, hold the MFB depressed
for about three seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
Connect to the Bluetooth device
• Confirm that the power to the wireless earphones is ON before connecting to
the Bluetooth device.
• Depending on the device, connection between the wireless earphones and
Bluetooth device may be effected automatically after pairing.
Disconnecting from the Bluetooth device
• Press and hold the Main Function Button until the LED turns off and the power
of the device turns off.
(2) Turn on the power to the Bluetooth device you are going to pair with, and
begin pairing; search for this unit (wireless earphones) from the paired
Bluetooth device.
• Set Bluetooth device close (within one meter) to the wireless earphones.
• These wireless earphones will appear in the Bluetooth device’s display as
“Pioneer SE-CL5BT”.
(3) Confirm that pairing has been successfully completed with the Bluetooth
device.
• Look at the display for the Bluetooth-enabled device and select “Pioneer
SE-CL5BT”.
• When the LED is flashing in blue slowly about once every 3 seconds, pairing is
completed.
• The PIN code for these wireless earphones has been factory set as “0000”.
Input this code if requested by the Bluetooth device.
7. Enjoying Music
Controls when listening to music
If the connected Bluetooth device supports AVFCP, the following operations can
be used.
• (＋) button
Press once: increase volume
Press and hold: advance to next track or chapter
• (﹣) button
Press once: decrease volume
Press and hold: advance to previous track or chapter
• Main Function Button
Press once: Play / Pause
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the headphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the music
playback settings may need to be configured. Consult the user’s manual for the
Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, a music
playback application may start automatically or the music cannot be
paused/played. Consult the user’s manual for the Bluetooth device.
To use the wireless earphones for vocal communication, pairing must be
performed with the desired Bluetooth device using the “hands-free profile” (HFP)
or “headset profile” (HSP).
For details on how to perform pairing, see < 5.Pairing >.
*If the Bluetooth device supports both profiles HFP & HSP, use the profile HFP.
(1) With power to the wireless earphones’ turned off, hold the Main Function
Button depressed for about 3 seconds.
The earphones’ power will turn on and the LED indicator will flash blue.
(2) Turn on the Bluetooth function on the device you wish to connect to.
When pairing is completed, the wireless earphones will automatically connect
to the Bluetooth device.
*If automatic connection is not achieved, or the earphones automatically connect
to a different Bluetooth device than the one you wish to use, follow the
instructions for the desired Bluetooth device regarding manual connection.
8. Vocal communication
Basic
Transmission format.....................................Bluetooth Standard Protocol Ver. 4.1
Maximum transmission distance...................................About 10m line of sight *1
Frequency used...........................................4GHz (2.400 GHz to 2.4835 GHz)*2
Supported Bluetooth profiles...............................................A2DP, AVRCP, HFP, HSP
Supported CODEC...................................................................................SBC
Battery life with continuous use........Maximum 8 hours of continuous transmission
(including music-play time)
Recharging time.........................................................................About 2 hours
Battery.................................. DC3.7V internally rechargeable Lithium-ion battery
IPX level................................................................................................IPX-4
Weight.....................................................................................................21g
Headphone
Type............................................................Fully-enclosed dynamic earphones
Driver units........................................................................................φ9.2mm
Impedance..........................................................................................16 ohm
Frequency response............................................................20 Hz ~ 20 000 Hz
Sensitivity..............................................................................................95 dB
Accessories
S, M, L eartips..........................................................................................1pc
Micro-USB cable (50cm)............................................................................1pc
Warranty card(Europe / U.S.A. and Canada / Japan).....................................1pc
Quick Start Guide (this document)...............................................................1pc
Safety Guide.............................................................................................1pc
*1 Transmission distance is an approximation. Actual usable distance may vary
depending on surrounding conditions.
*2 This product utilizes radio wave in the 2.4 GHz spectrum. Some signal dropouts
may be experienced due to interference with radios, microwave ovens, and other
devices using 2.4 GHz spectrum.
Specification
Note
• “Pioneer” is a trademark of Pioneer Corporation, and is used under license.
• The Bluetooth® word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by Onkyo Corporation is under
license. Other trademarks and trade name are those of their respective owners.
• Android is a trademark of Google Inc
Specifications and design are subject to possible modifications without notice due
to improvements.
About License and Trademarks
Vocal communication controls
If the connected Bluetooth device supports AVRCP, the following operations can
be used.
• (＋) button
Press and hold: Increase volume
• (﹣) button
Press and hold: Decrease volume
• Main Function Button
Press once when receiving a call: Enable conversation.Press once
again to end conversation.
Press and hold when receiving a call: Refuse communication
The same controls are supported in the event a call is received while listening to
music.
*When sound volume is set to maximum or minimum levels, a beep sound will be
produced from the earphones.
*Sound volume can be adjusted on the matching Bluetooth device.
*Depending on the specifications of the connected Bluetooth device, the controls
noted above and controls on the Bluetooth device may not be supported.
*Depending on the specifications of the connected Bluetooth device, the phone
settings may need to be configured. Consult the user’s manual of the Bluetooth
device.
1. Set Contents/西班牙语/荷兰语/瑞典语/日语
2. Names of Parts/西班牙语/荷兰语/瑞典语/日语
3. Replacing the earphone tip/西班牙语/荷兰语/瑞典语/日语
4. Wearing the clipper/西班牙语/荷兰语/瑞典语/日语
5. Charging the batteries/西班牙语/荷兰语/瑞典语/日语
2
1
3
65
4
7
SE-CL5BT
1 2 3
SE-CL5BT
