Polar Electro R7 Polar iWL User Manual
Polar Electro Oy Polar iWL Users Manual
Users Manual
ENGLISH
This user manual contains instructions for Polar
WearLink®+ Bluetooth transmitter.
Please follow the pictures on the front cover.
Transmitter Parts
1. The electrode areas on the reverse side of
the strap detect heart rate. Picture A1.
2. The connector sends the heart rate signal
to the wrist unit. Picture A2.
Wear the Transmitter
1. Wet the electrode areas of the strap under
running water and make sure that they
are well moistened. Picture B1.
2. Attach the connector to the strap. Adjust
the strap length to fit snugly and
comfortably. Picture B2.
3. Tie the strap around your chest, just
below the chest muscles, and attach the
hook to the other end of the strap. Picture
B3.
4. Check that the wet electrode areas are
firmly against your skin and that the Polar
logo of the connector is in a central,
upright position. Picture B4.
Detach the transmitter connector from the
strap and rinse the strap under running water
after every use.
The Polar WearLink Bluetooth connector can
be used with specific apparel with built-in
soft textile electrodes. Wet the electrodes and
clip the connector onto the apparel without
the strap, with the Polar logo in an upright
position.
ENGLISH
1
Care and Maintenance
The transmitter is a high-tech instrument that
should be handled with care. The following
instructions will help you fulfill guarantee
obligations.
Detach the transmitter connector from the
strap and rinse the strap under running water
after every use. Dry the connector with a soft
towel. Never use alcohol or any abrasive
material (steel, wool or cleaning chemicals).
Wash the strap regularly in a washing
machine at 40ºC/104ºF or at lest after every
fifth use. This ensures reliable measurement
and maximizes the life span of the transmitter.
Use a washing pouch. Do not soak, spin-dry,
iron, dry clean or bleach the strap. Do not use
detergent with bleach or fabric softener. Never
put the transmitter connector in the washing
machine or drier!
Dry and store the strap and connector
separately. Wash the strap in a washing
machine before long-term storage, and always
after use in pool water with high chlorine
content.
Keep the transmitter in a cool and dry place. Do
not store wet in non-breathing material, such as
a sports bag. Sweat and moisture keep the
electrodes wet and activated. Do not expose to
direct sunlight for extended periods.
Service
ENGLISH
2
Batteries
To change the battery yourself, follow below
instructions. See picture C.
1. Using a coin, open the battery cover by
turning it counterclockwise to OPEN.
2. Insert the battery (CR2025) inside the
cover with the positive (+) side against
the cover. Make sure the sealing ring is in
the groove to ensure water resistance.
3. Press the cover back into the connector.
4. Use the coin to turn the cover clockwise
to CLOSE.
Open the cover only when changing the battery
to ensure a long life, and make sure the sealing
ring is not damaged, in which case you should
replace it with a new one.
Battery kits with sealing rings are available at
Polar retailers and authorized Polar Service
Centers. In the USA and Canada, sealing rings
are available at authorized Polar Service Centers
only.
Keep batteries away from children. If
swallowed, contact a doctor immediately.
Caution!
Danger of explosion if the battery is replaced
with wrong type
Batteries should be disposed of in compliance
with local regulations.
Precautions
For allergy information, see the listed materials
in Technical Specifications. Avoid skin
reactions by wearing the transmitter over a shirt,
moistened under the electrodes.
Keep insect repellent away from the transmitter.
ENGLISH
3
The moisture and abrasion may cause
staining on light-colored clothes.
Using Your Transmitter in a Water Environment
Polar WearLink Bluetooth transmitter is water
resistant but will not measure heart rate in
water.
Technical Specifications
Battery type: CR 2025 (Panasonic
recommended)
Battery sealing ring: O-ring 20.0 x 1.0 Material FPM
Polar WearLink
Bluetooth
transmitter battery
life:
150 hours or use
Operating
temperature: 0 - +50C
Connector material: Polyamide
Strap material: 35% Polyester, 35% Polyamide,
30% Polyurethane
This product is compliant with the Directives
93/42/EEC and 1999/5/EC. The relevant Declaration of
Conformity is available at www.support.polar.fi
/declaration_of_conformity.html.
This crossed out wheeled bin marking shows that Polar
products are electronic devices and are in the scope of
Directive 2002/96/EC of the European Parliament and
of the Council on waste electrical and electronic
equipment (WEEE). These products should thus be
disposed of separately in EU countries. Polar
encourages you to minimize possible effects of waste
on the environment and human health also outside the
European Union by following local waste disposal
regulations and, where possible, utilize separate
collection of electronic devices.
ENGLISH
4
This marking shows that product is protected against
electric shocks.
CANADA Industry Canada (IC) regulatory information
This device complies with RSS-210 of Industry Canada
rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any
interference received, including interference that may
cause undesired operation. This class [B] digital
apparatus complies with Canadian ICES-003.
Avis de conformité à la réglementation d’Industrie
Canada Cet appareil est conform à la norme CNR-210
du Industrie Canada. L’utilisation de ce dispositif est
autorisée seulement aux deux conditions suivantes : (1)
il ne doit pas produire de brouillage, et (2) l’utilisateur
du dispositif doit être prêt à accepter tout brouillage
radioélectrique reçu, même si ce brouillage est
susceptible de compromettre le fonctionnement du
dispositif. Cet appareil numérique de la classe [B] est
conforme à la norme NMB-003 du Canada.
USA FCC regulatory information This device complies
with part 15 of the FCC rules. Operation is subject to
the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must
accept any interference received, including interference
that may cause undesired operation.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to
radio or television reception, which can be determined
ENGLISH
5
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures: 1) Reorient or relocate
the receiving antenna. 2) Increase the separation
between the equipment and receiver. 3) Connect the
equipment into an outlet on a circuit different from
that to which the receiver is connected. 4) Consult the
dealer or an experienced radio/TV technician for help.
Caution! Changes or modifications not expressly
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
Copyright 2008 Polar Electro Oy, FIN-90440
KEMPELE, Finland.
Polar Electro Oy is a ISO 9001:2000 certified
company.
All rights reserved. No part of this manual may be used
or reproduced in any form or by any means without
prior written permission of Polar Electro Oy. The names
and logos marked with a ™ symbol in this user manual
or in the package of this product are trademarks of
Polar Electro Oy. The names and logos marked with a ®
symbol in this user's manual or in the package of this
product are registered trademarks of Polar Electro Oy,
except Windows which is a registered trademark of
Microsoft Corporation.
Disclaimer
The material in this manual is for informational
purposes only. The products it describes are subject to
change without prior notice, due to the manufacturer’s
continuous development program.
Polar Electro Inc. / Polar Electro Oy makes no
representations or warranties with respect to this
manual or with respect to the products described
herein.
Polar Electro Inc. / Polar Electro Oy shall not be liable
for any damages, losses, costs or expenses, direct,
indirect or incidental, consequential or special, arising
out of, or related to the use of this material or the
products described herein.
ENGLISH
6
This product is protected by the incorporeal rights of
Polar Electro Oy as defined by the following documents:
FI 110915, EP1361819, US7324841, FI 23471, EU
00046107, USD492783S, USD492784S,
USD492999S. Other patents pending.
www.polar.fi
