Polycom PS8452 Polycom SpectraLink 8400 Wireless Telephone User Manual SpectraLink 8400 Series Product Specification

Polycom Inc. Polycom SpectraLink 8400 Wireless Telephone SpectraLink 8400 Series Product Specification

Manual 4

The Polycom® SpectraLink® 8400 VoWLAN series handsets deliver on a
fundamental need for enterprise-grade on-site voice mobility. Characterized by
market-leading Polycom HD Voice™ quality, durability, and broad telephony and
WLAN interoperability, SpectraLink 8400 handsets deliver a reliable user experience
and predictable return on investment.
The SpectraLink 8400 series enhances the customer value proposition through an
optional integrated barcode scanner and an enhanced standards-based applications
interface. In partnership with the Polycom applications development ecosystem,
the SpectraLink 8400 product toolset enables new opportunities for end-user
productivity solutions.
Physical Characteristics
Durability and Performance
Display:
•  2.2-inch 240 x 320 resolution
•  65,000 color palette
Buttons:
•  Four (4) context-sensitive softkey buttons
•  Dedicated Push-to-Talk
•  Five-way navigation and select control
•  Home & back navigation keys
•  Up/Down volume control
•  Barcode reader (8450 handset)
•  Start and End Keys
Status LED
•  Message (voicemail) waiting
•  Out of coverage
•  Phone ringing
Peripheral Interfaces
•  Micro USB interface for wall charging and configuration
•  2.5mm TRS connector for wired headset
•  Bluetooth
SpectraLink 8400 Series Product Specifications
A POLYCOM SPECIFICATIONS SHEET
SpectraLink 8440 and 8450 Rear
SpectraLink 8440 Face
SpectraLink 8450 Face
1
Batteries
•  Two easy-access cosmetic battery capacity options
•  Standard – Up to 8 hrs talk time, 80hrs standby time
•  Enhanced – Up to 12 hrs talk time, 120hrs standby time
Durability
•  Drop/shock: MIL STD 810F, method 516.5 procedure VI
•  Ingress protection standard IP-64 per IEC 60529
•  Rubberized molding
•  Magnesium LCD mounting
Environmental
•  Operational temperature: 32F to 104F (0 to 40C)
•  Storage temperature: -22 to 140F (-30 to 60C)
Dimensions & weight
Wireless Networking
Wi-Fi
Bluetooth
•  Version 2.1, HSP Version 1.2
•  Class 1 support with range of ~10 meters
Telephony Features
Rich call server feature integration and native Push-to-Talk
Call Handling Features*
•  Up to 6 telephone line appearances
•  Call Hold/Resume function
•  Last Call Return
•  Music on Hold
•  Consultation Hold
•  Call Transfer (Attended, Unattended)
•  Overlap dialing
•  Bridged Line Appearance (BLA)
•  Three-Way Conferencing (local)
•  Find-Me call forking
•  Call Screening (Incoming, outgoing)
•  Automatic Answer
•  Call Park & Retrieve
•  Group Call Pickup
•  Call Waiting
•  Multiple Calls per Line
•  Do Not Disturb
•  Calling party ID (name and number)
•  Called party ID (name and number)
•  Connected party ID (name and number)
•  Call Forward (Busy, No answer, Unconditional)
•  Call Reject
* Summary only – actual feature support will vary among call platforms
Codecs
•  G.711 (a-law, u-law), G.729, G.722 , G.722.1
Push-to-Talk (PTT)/Paging
•  On-board native ‘walkie-talkie’ capability
•  One-to-one, one-to-many broadcast communication
•  24 configurable channels
•  Priority, default channel
Additional Telephony Features
•  RTCP (RFC3550, 1889)
•  Call server redundancy
•  Predictive dialing from contacts list
•  Recent call lists
SpectraLink 8440 SpectraLink 8450
Dimensions 147mm by 53mm by25mm 147mm by 53mm by 28mm
Weight 5.6 oz 6.2 oz
Band Frequency Data Rates
802.11a
5.15 - 5.25 GHz
5.25 - 5.35 GHz
5.47 - 5.725 GHz
5.725 - 5.825 GHz
6, 9, 12, 18, 24, 36, 48, 54
Mbps
802.11b 2.4 - 2.4835 GHz 1, 2, 5.5, 11 Mbps
802.11g 2.4 - 2.4835 GHz 6, 9, 12, 18, 24, 36, 48, 54
Mbps
802.11n* 2.4 & 5 GHz 21.7, 43.3, 65, 72.2 Mbps
2.4GHz and 5GHz dynamic band roaming supported
*Single-stream, 20MHz channel with SGI
A POLYCOM SPECIFICATIONS SHEET SpectraLink 8400 Series Product Specifications
2
Management
Ease of Provisioning, Performance and Fault Management
Provisioning
•  Server based central provisioning via FTP, TFTP, HTTP or
HTTPs
•  Centralized user administration
•  Provisioning and call server redundancy
•  Initial configuration via USB
•  Unicode UTF-8 Multilingual User Interface
Performance and Fault Management
•  On-board site survey and diagnostics tools
•  Enhanced syslog reporting
•  Roaming and handoff reporting
•  Event logging
•  Hardware diagnostics
•  Status and status reporting
•  PING support (initiate and response)
•  Traceroute
Configuration Management
•  User and administrator login and privileges
•  PC-connected (USB) and remote over-the-air configuration
management
Applications Tools
Feature rich data applications interface options
Polycom XML Applications Program Interface
•  Standards-based XHTML API
•  On-board WebKit-based browser (JavaScript, CSS, DOM) for
rich applications integration
•  Bundled with Polycom Productivity Suite for Corporate
Directory access using LDAP and Voice Quality Monitoring
Polycom Open Application Interface (OAI)
•  Backward compatibility with SpectraLink OAI applications
Instant Messaging
•  Handset-to-handset, PC client-to-handset IM support via
Microsoft OCS 2007 R2 Instant Messaging
Real Time Location Services (RTLS)
•  Embedded RTLS beacon (Ekahau) for location tracking
Calendar - Exchange Server Integration
•  Day and month view
•  Meeting reminders
Performance
Industry leading voice and call quality
Audio quality
•  TIA 810B, TIA 920 audio quality standards
•  Full-duplex audio (compliant with IEEE 1329 full duplex
standards)
•  Voice activity detection (VAD)
•  Comfort noise fill
•  Adaptive jitter buffer & packet loss concealment
•  Acoustic echo cancellation & background noise suppression
Quality of Service (QoS)
•  WMM (Wi-Fi Multimedia)
•  WMM-Power Save, WMM-Admission Control (draft)
•  IEEE 802.1p/Q tagging (VLAN)/DSCP tagging
Security
•  WEP, WPA-Personal, WPA2-Personal, WPA2-Enterprise with
802.1X (EAP-FAST, PEAP-MSCHAPv2) with Opportunistic
Key Caching (OKC) and Cisco Client Key Management
(CCKM)
•  Media encryption via Secure Real-Time Protocol (SRTP)
•  SIP signaling encryption via Transport Layer Security (TLS)
•  Server-based configuration file encryption (AES 128bit)
•  HTTPS secure provisioning
•  Support for signed software executables
Networking
Strong support for Networking Standards
•  Address assignment via Manual or Dynamic host configuration
protocol (DHCP)
•  Domain name resolution via Domain Name Service (DNS)
•  Time and date synchronization using Simple Network Time
Protocol (SNTP)
•  Lightweight Directory Access Protocol (LDAP) for directory
lookup and download
•  IEEE 802.1p/Q tagging (VLAN)/DSCP tagging
A POLYCOM SPECIFICATIONS SHEET SpectraLink 8400 Series Product Specifications
3
Data Capture Specifications
High-performance scanning
1D CMOS Linear Imager
Barcode Symbologies
RSS, Stacked RSS, RSS-14, GS1-DataBar, Code 39,
Code 93, Code 128, UPC (E&A)
Note: 2D area imager solution available at a later date
Usability
Intuitive and user-friendly
User Profiles
•  Downloadable to any handset with ID and Login
Additional
•  Intuitive Graphical User Interface
•  Selectable wallpaper/background
•  Adjustable display brightness
•  Backlit keypad with adjustable timeout period
•  Ten (10) selectable ring tones
•  Ten (10) selectable alert tones
•  Multiple vibrate cadence options
•  Vibrate-to-ring options
•  Audible and vibrate notification options
•  Speed dial menu list
•  Contacts directory with support for 1000 local entries
•  Call logs - Minimum of 20 logged entries for each call type
(Incoming, dialed, and missed)
•  Emergency system-wide speed dial
•  Auto-answer & any key answer capability
•  Selectable ring tones
Accessories
Accessories that deliver mobile communication solutions to the
Enterprise
Speakerphone dock
•  Docking base provides full-duplex HD Voice speakerphone and
charging
•  Ideal for small group conference settings
•  Suitable for replacement of a wired set
•  Includes on-board mute, volume and speakerphone controls
•  Wired headset options
•  Spare battery charging slot with LED charge status indicator
Dual Charger
•  Ideal for desktop use to augment or replace a wired desktop
phone
•  Provides desktop handset and spare battery charging
•  LED charge status indicator
Quad Charger
•  Charging for up to 4 spare battery packs simultaneously
•  Ideal for shift-work environments and highly-mobile users
•  Designed for tabletop or wall-mounting
Feature Specification
Light Source 617 nm Highly Visible LED
Scan Rate Up to 500 scans/s
Scan Angle 38°
Label print contrast Down to 25%
Min. label x. dimension 0.15mm (6 mils)
Reading distance Up to 40cm (16in.)
Polycom Worldwide Headquarters
4750 Willow Road, Pleasanton, CA 94588
1.800.POLYCOM or +1.925.924.6000
www.polycom.com
© 2011 Polycom, Inc. All rights reserved. POLYCOM®, the Polycom “Triangles” logo and the names and marks associated with Polycom’s products are trademarks and/or service marks of Polycom, Inc. and are
registered and/or common law marks in the United States and various other countries. All other trademarks are property of their respective owners. No portion hereof may be reproduced or transmitted in any form
or by any means, for any purpose other than the recipient’s personal use, without the express written permission of Polycom.
3080_0511
A POLYCOM SPECIFICATIONS SHEET SpectraLink 8400 Series Product Specifications
